Ta ble of contents
1 Important 3
1.1 Safety 3
1.2 Care of the screen 3
1.3 Recycling 3
2Your TV 4
2.1 Television overview 4
2.2 Product highlights 5
3 Getting started 5
3.1 Position the TV 5
3.2 Wall mounting - VESA 5
3.3 Remote control batteries 7
3.4 Antenna cable 7
3.5 Connect the mains 7
3.6 First time installation 7
4 Use your TV 8
4.1 Switch on or off - Standby 8
4.2 Watch TV 9
4.3 Watch channels from a digital receiver 9
4.4 Watch connected devices 9
4.5 Watch a DVD 10
4.6 Select a Teletext page 10
4.7 Change Ambilight mode 11
5 Use more of your TV 12
5.1 Remote Control overview 12
5.2 TV menu overview 13
5.3 Picture and sound settings 15
5.4 Ambilight 18
5.5 Teletext 19
5.6 Create favourite channel lists 20
5.7 Electronic Programme Guide 21
5.8 Timers and locks 22
5.9 Subtitles 23
5.10 View and play photos, MP3... 24
5.11 Listen to digital radio channels 26
5.12 Software update 26
6 Channel installation 28
6.1 Automatic channel installation 28
6.2 Manual channel installation 29
6.3 Rearrange stored channels 29
6.4 Automatic channel management 30
6.5 Digital reception test 30
6.6 Factory settings 30
7 Connections (DVD, receiver, ...) 31
7.1 Connections overview 31
7.2 About connecting 32
7.3 Connect your devices 34
7.4 Connections setup 38
7.5 Preparing for digital services 39
8Technical data 40
9Troubleshooting 41
10 Index 43
Register your product and get support at
www.philips.com/welcome.
Ta ble of contents 1
ENGLISH
2700.1 en 13-09-2007 12:54 Pagina 1
2007 © Koninklijke Philips Electronics
N.V. All rights reserved. Specifications
are subject to change without notice.
Trademarks are the property of
Koninklijke Philips Electronics N.V. or
their respective owners.
Philips reserves the right to change
products at any time without being
obliged to adjust earlier supplies
accordingly.
The material in this manual is believed
adequate for the intended use of the
system. If the product, or its individual
modules or procedures, are used for
purposes other than those specified
herein, confirmation of their validity and
suitability must be obtained. Philips
warrants that the material itself does
not infringe any United States patents.
No further warranty is expressed or
implied.
Warranty
No components are user-serviceable.
Do not open or remove covers to the
inside of the product. Repairs may only
be done by Philips Service Centres and
official repairshops. Failure to do so shall
void any warranty, stated or implied.
Any operation expressly prohibited in
this manual, any adjustments, or
assembly procedures not recommended
or authorised in this manual shall void
the warranty.
Pixel characteristics
This LCD product has a high number of
colour pixels. Although it has effective
pixels of 99,999% or more, black dots or
bright points of light (red, green or blue)
may appear constantly on the screen.This
is a structural property of the display
(within common industry standards) and
is not a malfunction.
Open source software
This television contains open source
software. Philips hereby offers to deliver
or make available, upon request, for a
charge no more than the cost of
physically performing source distribution,
a complete machine-readable copy of
the corresponding source code on a
medium customarily used for software
interchange.
This offer is valid for a period of 3 years
after the date of purchase of this
product.To obtain the source code,
write to
Philips Innovative Applications N.V.
Ass. to the Development Manager
Pathoekeweg 11
B-8000 Brugge
Belgium
Compliance with EMF
Koninklijke Philips Electronics N.V.
manufactures and sells many products
targeted at consumers, which, like any
electronic apparatus, in general have the
ability to emit and receive
electromagnetic signals.
One of Philips’ leading Business Principles
is to take all necessary health and safety
measures for our products, to comply
with all applicable legal requirements and
to stay well within the EMF standards
applicable at the time of producing the
products.
Philips is committed to develop, produce
and market products that cause no
adverse health effects.
Philips confirms that if its products are
handled properly for their intended use,
they are safe to use according to scientific
evidence available today.
Philips plays an active role in the
development of international EMF and
safety standards, enabling Philips to
anticipate further developments in
standardisation for early integration in its
products.
Mains fuse (UK only)
This TV is fitted with an approved
moulded plug. Should it become
necessary to replace the mains fuse, this
must be replaced with a fuse of the
same value as indicated on the plug
(example 10A).
1. Remove fuse cover and fuse.
2. The replacement fuse must comply
with BS 1362 and have the ASTA
approval mark. If the fuse is lost,
contact your dealer in order to verify
the correct type.
3. Refit the fuse cover.
In order to maintain conformity to the
EMC directive, the mains plug on this
product must not be detached from the
mains cord.
Copyrights
VESA, FDMI and the VESA
Mounting Compliant logo are
trademarks of the Video Electronics
Standards Association.
Manufactured under license
from Dolby Laboratories.
‘Dolby’,‘Pro Logic’ and the double D
symbol
G, are trademarks of Dolby
Laboratories.
Manufactured under license
from BBE Sound, Inc.
Licensed by BBE, Inc under one or more
of the following US patents: 5510752,
5736897. BBE and BBE symbol are
registered trademarks of BBE Sound Inc.
Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries
® Kensington and MicroSaver are
registered US trademarks of ACCO
World Corporation with issued
registrations and pending applications in
other countries throughout the world.
All other registered and unregistered
trademarks are the property of their
respective owners.
2
2700.1 en 13-09-2007 12:54 Pagina 2
ENGLISH
Important 3
1 Important
Read this user manual before you start to use this
product.
Pay attention to this section and closely follow the
instructions.The warranty does not apply to
damage caused by not taking into account the
instructions.
1.1 Safety
•To avoid short circuit, do not expose the product
to rain or water.
•To avoid a risk of fire or electric shock do not
place naked flame sources (e.g. lighted candles)
close to the TV.
• Leave a space of at least 10cm (4 inches) all
around the TV for ventilation.
• Keep away from radiators or other heat sources.
• Do not install the TV in a confined space such as
a book case. Make sure that curtains, cupboards
and so on cannot obstruct the air flow through
the ventilation slots.
• Make sure the TV can not fall down. Place the TV
on a solid and flat surface and only use the stand
provided with the TV.
•To prevent damaging the mains cord which may
cause a fire or electric shock, do not place the TV
on the cord or anything else that can pinch te
cord.
• When mounted on a swivel stand or VESA wall
bracket avoid force coming on the mains plugs.
Partly loosened mains plugs can cause arcing or
fire.
1.2 Care of the screen
• Unplug the TV before cleaning.
• Clean the surface with a soft damp cloth. Do not
apply any other substance (chemical or
household cleaning agent).This may damage the
screen.
• Do not touch, push or rub or strike the screen
with anything hard as this may scratch, mar or
damage the screen permanently.
•To avoid deformations and colour fading, wipe off
water drops as soon as possible.
• Stationary images
Avoid stationary images as much as possible. If
you can not, reduce screen contrast and
brightness to prevent damage to the screen.
Stationary images are images that remain on the
screen for a long time. Examples of stationary
images are: on screen menus, teletext pages, black
bars, stock market information,TV channel logos,
time displays, and so on.
1.3 Recycling
•Take the packaging to your local recycling centre.
• Dispose old batteries safely according local
regulations.
• This product is designed and manufactured for
material recycling and re-use.
• This product should not be disposed with other
household waste. Inform yourself or ask your
dealer about local environmentally safe recycling
and local regulations. Uncontrolled waste disposal
harms the environment and human health.
(EEC 2002/96/EC)
2700.1 en 13-09-2007 12:54 Pagina 3
2Your TV
This section gives you an overview of the controls
and functions of this TV.
2.1 Television overview
Side controls
1Volume up and down
2 Menu
3 Program or Channel up and down
4Power switch
5 Led indicator (Blue: On; Red: Standby)
6 Remote control sensor
Side connectors
To connect a camera, game console, headphone or
a USB memory device.
Back connectors
To connect the antenna, DVD,VCR or other device.
Remote control
1 Standby or On
2DVD,VCR, ... device selection
3 Colour keys
4Navigation key (up o,down œ, left p,
right π)
OK and LIST
5Teletext key
6 Menu key
7 Programme up or down
8Volume up or down
9 Ambilight on or off
Find more on your remote control in section 5.1
Remote control overview.
4 Your TV
MENU
b
¬
P
V
321
654
98
0
7
i
Ambilight MODE
B
BROWSE
DEMO
OPTION
GUIDE
a
OK
LIST
v
INPUT
j b q
MHEG
CANCEL
1
2
3
4
6
5
7
8
9
- PROGRAM
+-
VOLUME +
MENUB POWER
5-6
1
2
3
4
2700.1 en 13-09-2007 12:54 Pagina 4
ENGLISH
2.2 Product highlights
Your new TV is equipped with some of the most
modern audio or video innovations.
Your TV offers the following advantages ...
Full High Definition LCD display
A full HD resolution of 1920x1080p, the highest
resolution HD broadcast can transmit. It offers a
brilliant flicker-free progressive scan picture with
optimum brightness and superb colours.
Ambilight
For a more relaxed viewing experience and
improved perceived picture quality.
Perfect Pixel HD
Offers perfect picture quality from any source.
100Hz Clear LCD (if present)
100Hz Clear LCD results in superior sharpness of
motion reproduction, better black level,high
contrast with a flicker-free, quiet image and a larger
viewing angle.
DVB-T integrated tuner
Next to normal analogue TV broadcast your TV
receives digital terrestrial TV and radio broadcasts.
Electronic Programme Guide - EPG
The EPG shows the scheduled digital TV
programmes on screen.The guide can remind you
when programmes start, switch the TV on, etc.
HDMI connectors
3 HDMI connectors for highest quality high
definition connectivity.
USB connection
Multimedia connection for instantly view or play
your photos or music.
3 Getting started
This section helps you with the positioning and the
first time installation of the TV.
3.1 Position the TV
) Warning
Carefully read the safety precautions in section 1.1
Safety before you position the TV.
Large screen TVs are heavy. Carry and handle the
TV with at least two persons.
Connect your devices first before you position your
TV or mount it on the wall.
The ideal viewing distance for watching TV is three
times its screensize.
For ideal viewing conditions, position the TV where
light does not fall directly on the screen.
Best Ambilight effect is watched in a room with
dimmed lighting conditions.
For the best Ambilight effect, position the TV 10 to
20 cm away from the wall. Position the TV where
sunlight does not fall directly on the TV.
Kensington Security Slot
Your TV is equipped with a Kensington Security Slot
at the back of the TV for an anti-theft lock.
An anti-theft Kensington lock has to be purchased
separately.
Your TV 5
2700.1 en 13-09-2007 12:54 Pagina 5
3.2 Wall mounting - VESA
Your TV is prepared for VESA compliant wall
mounting.This bracket is not included.
Use a VESA compliant bracket with code
VESA MIS-F, 600, 400 M8.
ç Warning
Consider the TV’s weight if you wall mount it.
Improper mounting could result in severe injury or
damage. Koninklijke Philips Electronics N.V. bears
no responsibility for improper mounting that
results in accident or injury.
‡ Locate the 4 small discs at the back of the TV.
® Unscrew the discs and use the free holes (M8)
for fixing the VESA wall bracket.
ÒTo remove the TV stand locate the 4 screws of
the TV stand.
† Unscrew the 4 screws.
º Lift the TV off the stand.
◊Make all connections at the back of the TV
before you wall mount the TV. See section 7
Connections.
Now go on with the instructions supplied with the
VESA wall bracket.
6 Your TV
4x
2
2700.1 en 13-09-2007 12:54 Pagina 6
ENGLISH
3.3 Remote control batteries
‡ Open the battery cover on the back of the
remote control.
® Insert the 2 batteries supplied (Type AA-R6-
1,5V). Make sure the + and - ends of the
batteries line up correctly (inside of case is
marked.)
ÒClose the cover.
rNote
Remove the batteries if you don’t use the remote
control for a long time.
3.4 Antenna cable
‡ Locate the antenna connection at the back of
the TV.
® Insert the antenna cable tightly into the antenna
socket x Antenna.
3.5 Connect the mains cord
‡ Verify that your mains voltage corresponds with
the voltage printed on the sticker at the back of
the TV. Do not insert the mains cord if the
voltage is different.
® Insert the mains cord tightly.
The TV is never powered off completely unless the
mains cord is physically unplugged.Therefore the
mains plug must be accessible at all time.
3.6 First time installation
The first time, and only the first time, the mains
cord is inserted, the installation procedures starts
up automatically. Follow the instructions on screen.
à Tips
• If you notice you have selected a wrong language,
press the red key on the remote control to
return to the language selection menu.
•To rearrange the stored channels, see section 6.3
Rearrange stored channels.
Your TV 7
ANTENNA
UK - EIRE
Menu lan
g
ua
ge
Es
pa
ñ
ol
Hrv
a
t
s
k
i
It
a
li
a
n
o
Ma
gy
a
r
...
Please select
y
ou
r
lan
g
ua
g
e..
.
usin
g
cursor u
p
an
d
do
w
n
En
g
lis
h
N
e
x
t
2700.1 en 13-09-2007 12:54 Pagina 7
4 Use your TV
Learn how to operate your TV for daily use.
4.1 Switch on or off - Standby
To switch on the TV:
• Press B Power at the right side of the TV if the
standby led is off.
• Press B on the remote control if the standby
led in on.
To switch to standby:
• Press B on the remote control.
To switch on from standby without remote control:
• Press B Power at the side of the TV to switch
off first and press B Power again to switch on.
To switch off:
• Press B Power at the side of the TV.
rNote
Energy consumption contributes to air and water
pollution. As long as the mains cord is plugged in,
the TV consumes energy.This TV has a very low
standby power consumption.
8 Use your TV
- PROB POWER
B
DEMO
OPTION
GUIDE
a
v
INPUT
j b q
MHEG
CANCEL
B
a
2700.1 en 13-09-2007 12:54 Pagina 8
ENGLISH
4.2 Watch TV
4.2.1 Switch channels
‡ To switch TV channels:
• Press a number (1 to 999) or press P+ or P-
on your remote control.
• Press
Program/Channel - or + on the side
controls of the TV.
® Press R to return to the previously viewed TV
channel .
4.2.2 Adjust volume
‡ To adjust the volume:
• Press V + or - on the remote control
• Press Volume + or - on the side controls
of your TV.
® To m ute the sound:
• Press ¬ on the remote control
• Press ¬ again to restore the sound.
4.3 Watch channels from a
digital receiver
‡ Switch on the digital receiver.
The picture from your receiver might appear
automatically on your screen.
® Use the remote control of your digital receiver
to select TV channels.
If the picture does not appear:
‡ Press v on the remote control.
® Press v repeatedly to select the device. Wait
a few seconds until the picture appears.
ÒPress
OK.
† Use the remote control of the digital receiver
to select TV channels.
4.4 Watch connected devices
‡ Switch on the device.
The picture from your device might appear
automatically.
If the picture does not appear:
® Press v on the remote control.
ÒPress v repeatedly to select the device. Wait
a few seconds until the picture appears.
† Press
OK.
º Use the remote control of your device to select
TV channels.
Use your TV 9
B
DEMO
OPTION
GUIDE
a
v
INPUT
j b q
MHEG
CANCEL
v
¬
P
V
321
654
98
0
7
i
Ambilight MODE
BROWSE
P
90
-
¬
P
V
321
654
98
0
7
i
BROWSE
V
¬
2700.1 en 13-09-2007 12:54 Pagina 9
10 Use your TV
4.5 Watch a DVD
‡ Insert a DVD disc in your player.
® Press Play π.
The picture from your player appears
automatically on your screen.
If the picture does not appear:
‡ Press v on the remote control.
® Press v repeatedly to select the DVD player.
Wait a few seconds until the picture appears.
ÒPress
OK.
† Press Play π.
4.6 Select a Teletext page
Most TV channels broadcast information via
Teletext.
To watch Teletext:
‡ Press b.
The main index page appears.
® To select a page of your choice:
• Enter the page number with the number keys.
• Press P- or P+ or o, œ to view the next or
the previous page.
•Press a colour key to select one of the colour
coded items at the bottom of the screen.
à Tip
Press R to return to the previously viewed page.
ÒPress b again to switch Teletext off.
r
Note
Only for UK: some digital TV channels offer
dedicated digital text services (for example BBC1).
For more information on teletext, see section 5.5
Teletext.
B
DEMO
OPTION
GUIDE
a
v
INPUT
j b q
MHEG
CANCEL
v
MENU
b
¬
P
V
OK
LIST
b
2700.1 en 13-09-2007 12:54 Pagina 10
ENGLISH
Use your TV 11
4.7 Change Ambilight mode
You can choose among four Ambilight modes:
• Colour
Sets Ambilight to a constant colour.
• Relaxed
Sets Ambilight to change soft and smoothly with
the images on screen.
• Moderate
Sets Ambilight between Relaxed and Dynamic.
• Dynamic
Sets Ambilight to change quick and responsive.
To change the Ambilight mode:
‡ Press Ambilight to switch on or off.
® Press Mode repeatedly to toggle through the
Ambilight modes.
ÒPress
OK.
For more information on Ambilight, see section 5.4
Ambilight.
à Tip
To fully enjoy Ambilight, switch off or dim the room
lights.
Ambilight MODE
Ambilight MODE
2700.1 en 13-09-2007 12:54 Pagina 11
Use more of your TV
5.1 Remote control overview 1 Standby B
To switch the TV on or back to standby.
2 Input v
To select a connected device or to return to
TV.
3 Dual screen b
To show teletext on the right and the picture
on the left of the screen.
4 Widescreen Picture format q
To select a picture format.
5 Colour keys
• Easy selection of teletext pages.
• Easy selection of tasks.
6 Guide a
To switch on or off the Electronic Programme
Guide.
7
OK/List
•To display the channel list.
•To activate a setting.
8 Navigation keys pπoœ
To navigate the menu.
9 Teletext b
To switch teletext on or off.
10 +P- Channel up or down
To switch to the next or previous channel in
the channel list.
11 Mute ¬
To m ute the sound or restore it.
12 Number keys
To select a TV channel.
13 Previous channel R
To return to the previously viewed channel.
14 Mode
To toggle through the Ambilight modes
15 Ambilight
To switch Ambilight on or off.
16 On screen information i
To show channel or programme information if
available.
12
5 Use more of your TV
This section deals with the more advanced use of
your TV:
•how to use the menus
• to adjust the picture, sound and Ambilight
settings
• more about Teletext
•how to create favourite channel lists
• the advantages of Electronic Programme Guide
•how to set locks and timers
• to set subtitles and select a subtitle language
•how you can view your photos or play your
favourite music from a USB memory device.
MENU
b
¬
P
V
321
654
98
0
7
i
Ambilight MODE
B
BROWSE
DEMO
OPTION
GUIDE
a
OK
LIST
v
INPUT
j b q
MHEG
CANCEL
18
17
16
15
19
21
22
20
6
1
2
4
5
3
8
7
9
10
12
11
13
14
2700.1 en 13-09-2007 12:54 Pagina 12
ENGLISH
Use more of your TV
17 Volume up or down V
To adjust the volume.
18 Menu
To switch the menu on or off.
19 Option
To switch the Quick access menu on or off.
20 Demo
To switch the Demo menu on and to get a
demonstration of the features of the TV.
21 Subtitles j
To activate or deactivate the subtitle mode.
22
MHEG cancel (only for UK)
To cancel only Digital text or Interactive
services.
See section 10 Index to find the section in the
manual about a specific remote control key.
5.2 TV menu overview
With the on screen menus you install your TV,
adjust picture, sound and Ambilight settings and
access features.This section gives an overview of
the menus and describes how to navigate.
5.2.1 The menu
‡ Press Menu on the remote control to show the
main menu.
® Press Menu to quit the menu.
The main menu offers the following items:
• TV menu
Select this menu for installation, picture and
sound settings, Ambilight and other feature
settings.
• Channel list
Select this item to show the Channel list.
Create your Favourite channel lists here.
•Programme guide
Available when digital channels are installed, this
item shows information about the digital
programmes.
According to the type of Electronic Programme
Guide, you can also access the table of scheduled
Digital TV programmes and easily select and tune
to a desired programme. See section 5.7
Electronic Programme Guide.
• Multimedia
Select this item to view photos or play music
stored on a USB device. See section 5.10 View
and play photos, MP3, ...
13
MENU
b
¬
P
V
BROWSE
OK
LIST
MENU
BROWSE
T
e
l
e
vi
s
i
on
M
u
ltim
ed
i
a
TV
m
e
n
u
C
hannel lis
t
Pro
g
ramm
e
g
uid
e
2700.1 en 13-09-2007 12:54 Pagina 13
Use more of your TV
5.2.2 Use of the menu
Learn to use the menus with this example.
‡ Press Menu on the remote control.
The main menu appears on the screen.
® Press π to enter the TV menu.
ÒPress π to enter the TV settings menu.
† Press œ to select Picture.
º Press π to enter the picture settings.
◊Press œ to select Brightness.
‹Press π to enter the Brightness setting.
≈Press o or œ to adjust the setting.
ÚPress p to return to the Picture settings or
press Menu to quit the menu.
rNote:
More choices come available when digital channels
are installed and broadcasted.
14
MENU
b
BROWSE
OPTION
a
OK
LIST
MENU
BROWSE
T
e
l
e
vi
s
i
on
M
u
ltim
ed
i
a
TV
m
e
n
u
C
hannel lis
t
Pro
g
ramm
e
g
uid
e
TV settin
g
s Pi
c
t
u
r
e
C
ontras
t
Bri
g
htness
P
e
rf
ec
t Pix
e
l H
D
C
olou
r
H
ue
Soun
d
Ambili
g
h
t
...
Shar
p
ness
Tin
t
R
ese
t t
o
s
t
a
n
da
r
d
Pi
c
t
u
r
e
Pi
c
t
u
r
e
C
ontras
t
C
olou
r
H
ue
P
e
rf
ec
t Pix
e
l H
D
HD N
a
t
u
r
a
l M
o
ti
on
Shar
p
ness
Tin
t
Bri
g
htness
90
52
0
4
47
C
ontras
t
Pi
c
t
u
r
e
Bri
g
htness
C
ontras
t
C
olou
r
H
ue
P
e
rf
ec
t Pix
e
l H
D
HD N
a
t
u
r
a
l M
o
ti
on
Shar
p
ness
Tin
t
Bri
g
htness
98
52
0
4
47
Bri
g
htness
TV
m
e
n
u
TV settin
g
s
Settin
g
s assistan
t
R
ese
t t
o
s
t
a
n
da
r
d
Pi
c
t
u
r
e
Soun
d
Ambili
g
h
t
F
ea
t
u
r
es
Software u
p
dat
e
In
s
t
a
ll
a
ti
on
settin
g
s
TV settin
g
s Settin
g
s assisten
t
Start no
w
Soun
d
Ambili
g
h
t
R
ese
t t
o
s
t
a
n
da
r
d
Pi
c
t
u
r
e
2700.1 en 13-09-2007 12:54 Pagina 14
ENGLISH
5.2.3 Quick access menu
The Quick access menu gives direct access to some
often needed menu items.
When digital channels are installed and broadcasted
the relevant digital options are shown in the menu.
‡ Press Option on the remote control.
® Press o or œ to select an option.
ÒPress
OK to show the selected option menu.
† Press o, œ, p, π to adjust the settings in the
menu.
º Press Option to quit the menu.
• Audio language
See section 5.3.5 Adjust sound settings.
• Subtitle language
See section 5.9.3 Select a digital subtitle language.
• Subtitles
See section 5.9 Subtitles.
• Picture format
See section 5.3.4 Widescreen picture format.
• Equalizer
See section 5.3.5 Adjust sound settings.
• Clock
Display the clock
‡ Press
OK to display the clock permanently.
® Press Option and press o or œ to select
Clock again.
ÒPress
OK to hide the clock.
5.3 Picture and Sound settings
This section describes how to adjust picture and
sound in the menus.
5.3.1 Settings assistant
Use the Settings assistant to guide you through
basic picture, sound and Ambilight settings in an
easy way.
‡ Press Menu on the remote control and select
TV menu > TV settings > Settings assistant and
press π to enter.
® Press
OK.
ÒPress the green key on the remote control to
start the assistant.
† Press p or π to select the left or right side to
make your choice.
º Press the green key to go to the next setting.
You will go through several settings. When
finished the TV will ask you to store these
settings.
◊Press the green key to store all your settings.
5.3.2 Reset to standards
Sets the TV to one of the predefined settings. Each
setting combines picture, sound and Ambilight.
‡ Press Menu on the remote control and select
TV menu > TV settings > Reset to standard
and press π to enter the list.
® Press o or œ to select a setting.
ÒPress the green key to store your selection.
Standard settings: Current, Natural,Vivid, Movie
Use more of your TV 15
DEMO
OPTION
GUIDE
a
OK
LIST
v
j b q
MHEG
CANCEL
OPTION
Q
u
i
c
k
access
Subtitl
e
Audio lan
g
ua
ge
Subtitle lan
g
ua
ge
E
q
ualize
r
Pi
c
t
u
r
e
f
o
rm
at
C
loc
k
2700.1 en 13-09-2007 12:54 Pagina 15
Use more of your TV
5.3.3 Picture settings
This section describes how to adjust all picture
settings.
‡ Press Menu on the remote control and select
TV menu > TV settings > Picture and press π
to enter the list.
® Press o or œ to select a setting.
• Contrast
Changes the level of bright parts in the picture
but keeps the dark parts unchanged.
• Brightness
Changes the level of light of the total picture.
• Colour
Changes the level of saturation.
• Hue
If NTSC is broadcasted, this level compensates
the colour variations.
• Sharpness
Changes the level of sharpness of fine details.
• Tint
Sets the colours to Normal, Warm (reddish) or
Cool (bluish). Select Custom to make a setting of
your own in the Custom tint menu.
• Custom tint
If Custom is selected in the Tint menu you can
make a setting of your own here.
Press the green key to select each bar to change
the value of:
- R-WP red whitepoint
- G-WP green whitepoint
- B-WP blue whitepoint
- R-BL red blacklevel
- G-BL green blacklevel
• Perfect Pïxel HD
Enables or disables Perfect Pixel HD, the most
ideal picture setting.
• HD Natural Motion
Reduces the field and line flicker and reproduces
smooth movement especially in movies.
Set the level to Minimum, Maximum or Off.
• 100Hz Clear LCD (if present)
Switches 100Hz Clear LCD on or off.
• Dynamic contrast
Enhances the contrast in the picture as the image
on the screen changes.
Set the level to Minimum, Medium, Maximum or
Off.The level medium is recommended.
• Noise reduction
Filters out and reduces the noise in the picture.
Set the level to Minimum, Medium, Maximum or
Off.
• MPEG artefact reduction
Smoothens the transitions on digital pictures.
Switches MPEG artefact reduction on or off.
• Colour enhancement
Makes the colours more vivid and improves the
resolution of details in bright colours.
Set the level to Minimum, Medium, Maximum or
Off.
• Active control
Corrects all incoming signals in order to provide
the best picture possible.
Switches Active control on or off.
• Light sensor
Adjusts the picture and Ambilight settings on the
lighting conditions in the room.
Switches Light sensor on or off.
• Picture format
See section 5.3.4 Widescreen picture format.
16
TV settin
g
s Pi
c
t
u
r
e
C
ontras
t
Bri
g
htness
C
olou
r
H
ue
Soun
d
Ambili
g
h
t
P
e
rf
ec
t Pix
e
l HD
HD Natural Motion
Shar
p
ness
Tin
t
D
y
namic contras
t
100 Hz Clear LCD
N
o
i
se
r
educ
ti
on
MPE
G
artefact red
.
C
olour enhanc
…
Pi
c
t
u
r
e
f
o
rm
at
A
c
tiv
e
co
ntr
ol
Li
g
ht senso
r
Settin
g
s assistan
t
R
ese
t t
o
s
t
a
n
da
r
d
Pi
c
t
u
r
e
2700.1 en 13-09-2007 12:54 Pagina 16
ENGLISH
5.3.4 Widescreen picture format
Avoid black bars on the sides or on top and
bottom of the picture. Change the picture format
to a format that fills the screen.
‡ Press q to switch on the Picture format
menu.
® Press o or œ to select an available picture
format.
ÒPress o to shift the picture upwards to make
partly covered subtitles visible.
à Tip
The Auto format setting is recommended for
minimal distortion .
Auto format (Not for PC.)
Enlarges the picture
automatically to fill the
screen. Subtitles remain
visible.
Super zoom (Not for HD.)
Removes the black bars on
the side of 4:3 broadcasts.
There is a minimal
distortion.
4:3 (Not for HD.)
Shows the classical 4:3
format.
Movie expand 14:9
(Not for HD.)
Scales classical 4:3 format to
14:9.
Movie expand 16:9
(Not for HD.)
Scales classical 4:3 format to
16:9.
Wide screen
Stretches 4:3 format to 16:9.
Unscaled
(Only for HD and PC.)
Maximum sharpness.
Distortion may appear on
borders. Black bars may
appear with pictures from
your PC.
rNote
Do not forget to name the connection in the
Connection menu. See section 7.4.3 Naming your
devices.
5.3.5 Sound settings
This section describes how to adjust all sound
settings.
‡ Press Menu on the remote control and select
TV menu > TV settings > Sound and press π
to enter the list.
® Press o or œ to select a setting.
• Equalizer
Changes the bass and treble of the sound. Select
each bar to change the setting. See also section
5.2.3 Quick access menu.
•Volume
Changes the volume.
When adjusting the volume with V a volume
bar appears. If you don’t want it to appear go to
TV menu > Installation > Preferences and press
π to enter the list and select Volume bar off.
‡ Press o or œ to select Volume bar.
® Press π to enter.
ÒSelect On to activate the temporarily display of
the volume bar when adjusting the volume.
• Balance
Sets the balance of the left and right
loudspeakers to fit best your listening position.
Use more of your TV 17
DEMO
OPTION
GUIDE
a
OK
LIST
v
j b q
MHEG
CANCEL
q
TV settin
g
s Soun
d
E
q
ualize
r
V
o
l
u
m
e
B
a
l
a
n
ce
Audio lan
g
ua
ge
Ambili
g
h
t
Surround mod
e
Headphone volume
Dual I
/
I
I
Mono
/
Stere
o
Auto volume level...
D
e
lt
a
v
o
l
u
m
e
A
u
t
o
su
rr
ou
n
d
Soun
d
Settin
g
s assistan
t
R
ese
t t
o
s
t
a
n
da
r
d
Pi
c
t
u
r
e
e
2700.1 en 13-09-2007 12:54 Pagina 17
Use more of your TV
• Audio language
A list of audio languages for the current
programme may be available when digital
channels are installed and broadcasted.
See also section 5.2.3 Quick access menu.
To permanently change the audio language, see
section 6 Channel installation.
• Dual I/II
If broadcasted, you can choose between two
different languages.
• Mono/stereo
If stereo broadcasting is available, you can select
Mono or Stereo per TV channel.
• Surround mode
To select a more spatial sound if broadcasted or
if available from a connected device.
• Headphone volume
Changes the volume of the headphone.
You can mute the TV speakers with ¬ on the
remote control.
• Automatic volume leveller
Reduces sudden volume differences like at the
beginning of commercials or when switching from
one channel to another.
Select on or off.
• Delta volume
Levels out volume differences between channels
or connected devices.
‡ Switch to the channel or device you want to
level out the volume difference.
® Select Delta volume in the Sound menu and
change the volume level.
• Auto surround
Switches the TV automatically to the best
surround sound mode broadcasted.
Select on or off.
5.4 Ambilight
This section describes how to adjust Ambilight
settings.
‡ Press Menu on the remote control and select
TV menu > TV settings > Ambilight and press
π to enter the list.
® Press o or œ to select a setting.
• Ambilight
Switches Ambilight on or off.
• Brightness
Changes the light output of Ambilight.
• Mode
You can choose among four Ambilight modes:
Colour, Relaxed, Moderate, Dynamic. See section
4.7 Change Ambilight mode.
• Colour
If Colour is selected in the Mode menu you can
select a constant colour from the list or make a
custom colour of your own.
- Warm white
- Cool white
- Blue
- Custom
When Custom is selected in the Colour menu
you can customise your colour.
‡ Select Saturation first and set the value high.
® Select Palette and slide from 0 to 100 to go
from red over yellow, green to blue.
• Separation
Sets the level of difference in colour between the
left and right side of the TV if Relaxed, Moderate
or Dynamic is selected in the Mode menu.
Separation off shows a dynamic but mono colour
Ambilight.
• Colour boost
Amplifies the colours for a more dynamic effect if
Relaxed, Moderate or Dynamic is selected in the
Mode menu.
• Balance
Like stereo sound balance, sets the level of
Ambilight for the left and right side of the TV.
ç Caution
To avoid bad infrared remote control reception,
place your devices out of sight of Ambilight.
18
TV settin
g
s Ambili
g
h
t
Ambili
g
h
t
C
olou
r
Se
p
aratio
n
Bri
g
htness
M
ode
Soun
d
C
olour boos
t
B
a
l
a
n
ce
Ambili
g
h
t
Settin
g
s assistan
t
R
ese
t t
o
s
t
a
n
da
r
d
Pi
c
t
u
r
e
2700.1 en 13-09-2007 12:54 Pagina 18
ENGLISH
TV standby with Ambilight
When the TV is standby, you can switch Ambilight
on. In this case Ambilight is only available as
constant colour.
‡ Press Ambilight on the remote control when
the TV is in standby.
® Press Mode repeatedly to select an available
colour.
5.5 Teletext
Your TV has a 1200 pages memory that stores
broadcasted teletext pages and subpages to reduce
waiting time.
To select a teletext page see section 4.6 Select a
Teletext page.
5.5.1 Select pagenumber subpages
A teletext page number can hold several subpages.
The pages are shown on a bar next to the main
pagenumber.
‡ Press b.
® Select a teletext page.
ÒPress p or π to select a subpage.
5.5.2 Select T.O.P. teletext broadcasts
T.O.P. teletext (Table of Pages) is not broadcast by
all TV channels. You can easily jump from one
subject to another without using pagenumbers.
‡ Press b.
® Press i.
The T.O.P. overview appears.
ÒUse p, π or o, œ to select a subject.
† Press
OK to view the page.
5.5.3 Dual screen teletext
(Not available for channels with Digital text
services.)
View the TV channel and teletext next to each
other.
‡ Press b for Dual screen teletext.
® Press b again to show normal teletext .
ÒPress b to switch off teletext.
5.5.4 Search teletext
Quickly jump to a subject linked to a series of
pagenumbers or search for specific words in
teletext pages.
‡ Press b.
® Press
OK to highlight the first word or number.
ÒPress o, œ or p, π to jump to the next word
or number on the page.
† Press
OK the search a page which holds the
highlighted word or number.
º Press o until no word or number is highlighted
to quit Search.
5.5.5 Enlarge teletext pages
For a more comfortable reading, you can enlarge
the teletext page.
‡ Press b and select a teletext page.
® Press Option on the remote control to enlarge
the top part of the page.
ÒPress Option again to view the enlarged lower
part of the page.
† Press o or œ to scroll through the enlarged
page.
º Press Option again to return to the normal
page size.
Use more of your TV 19
0
i
Ambilight MODE
Ambilight MODE
98
0
7
i
Ambilight MODE
i
DEMO
OPTION
GUIDE
a
OK
LIST
v
j b q
MHEG
CANCEL
OPTION
2700.1 en 13-09-2007 12:54 Pagina 19
Use more of your TV
5.5.6 Teletext menu
With the options in the teletext menu you can
reveal hidden info, let cycle subpages automatically
and change the character setting.
•Reveal
Hide or unhide hidden information on a page,
such as solutions to riddles or puzzles.
• Cycle subpages
If subpages are available for the selected page,
you can make subpages cycle automatically.
• Language
Some languages use a different set of characters.
Switch to the other group to show the text
correctly.
‡ Press b.
® Press Menu.
ÒPress o or œ to select an option.
† Press
OK to change a setting.
º Press Menu to quit the teletext menu.
◊Press b to switch off teletext.
5.5.7 Digital text services (UK only)
Some digital TV broadcasters offer dedicated digital
text or interactive services (for example BBC1) on
their digital TV channels .These services work as
normal Teletext with the number, colour and
navigation keys to select and navigate.
‡ Press b.
® Press o, œ or p, π to select or highlight
items.
ÒPress one of the colour keys to select an
option.
† Press
OK to confirm or activate.
º Press MHEG Cancel to cancel Digital text or
interactive services.
ç Caution
Digital text services are blocked when subtitles are
broadcasted and Subtitle On is set in the Features
menu. See section 5.9 Subtitles.
5.5.8 Teletext 2.5
If broadcasted by the TV channel this teletext offers
more colours and better graphics.
Teletext 2.5 is switched on as a factory setting.
‡ Press Menu on the remote control and select
TV menu > Installation > Preferences >
Teletext 2.5 and press π to enter the list.
® Select on or off.
5.6 Create favourite channel
lists
View the All channels list or set up a Favourite list
of your own with your preferred TV channels and
radio stations. For example, each member of your
family can create his or her own favourite list.
5.6.1 Select a favourite list
Learn how to select one of the favourite channel
lists.
‡ Press
OK.
The first time after you have finished the
installation, the All channels list is shown. In
other situations, it brings up the last selected
favourite list.
® Press the red key to show all favourite lists.
ÒPress o or œ to select a list.
† Press
OK.
The selected favourite list appears.
º Press
OK again to quit.
20
Menu
Reveal
Language
Gr. II
Off
Cycle subpages
Off
All
c
h
a
nn
e
l
s
....
EXT
3
3 Di
g
ital channel
2
4 R
ad
i
o
c
h
a
nn
e
l
1
2 Di
g
ital channel
1
1 Analo
g
ue channel
1
....
Select lis
t
A
2700.1 en 13-09-2007 12:54 Pagina 20
ENGLISH
5.6.2 To set up a favourite list
Create or modify your own favourite list.
‡ Press
OK.
The last selected list appears.
® Press the red key to show all favourite lists.
ÒPress o or œ to select a list.
† Press
OK.
º Press the green key to enter the Edit mode.
The selected list brings up a full channel list.
◊Press o or œ to highlight a channel.
‹Press
OK to mark (or unmark) the highlighted
channel.
The channel is added to (or removed from) the
selected list.
≈Press the green key again to leave the Edit
mode.
The modified channel list appears again.
5.6.3 Select a channel from a favourite list
‡ Press
OK.
The last selected channel list appears.
® Use o or œ to highlight a channel.
ÒPress
OK.
The TV tunes to that channel.
à Tip
• Use
-P+ to go through the TV channels of the
selected favourite list.
• With the number keys you can still select
channels which are not marked as favourite.
5.7 Electronic Programme
Guide - EPG -
The Electronic Programme guide is an on screen
guide to scheduled digital TV programmes.
You can navigate, select and view programmes by
time, title or genre.There are two types of EPG,
‘Now and Next’ and ‘7 or 8 day’ EPG.
When digital channels are installed and
broadcasted, EPG is available. ‘Now and Next’ is
always available but the ‘7 or 8 day’ EPG is only
available in some countries.
With the EPG menu you can ...
• see a list of current broadcasted programmes
• see the next programme
• group programmes by genre
• set reminders when programmes will start
• set up preferred EPG channels
• etc.
5.7.1 Switch on EPG
‡ Press a.
The following type of EPG appears
‘Now and Next’ EPG
Detailed information about the current programme
is shown.
Use more of your TV 21
¬
P
V
321
654
98
0
7
i
Ambilight MODE
BROWSE
P
90
-
26 BBC1 Tue., 12 Sep 09:17
Title : Commonwealth Games
Info: 7:50 - 12:30 : 280 min
..........
Exi
t
Press -P+ to chan
g
e channel
.
N
e
x
t
DEMO
OPTION
GUIDE
a
OK
LIST
v
j b q
MHEG
CANCEL
GUIDE
a
2700.1 en 13-09-2007 12:54 Pagina 21
22 Use more of your TV
Or
‘7 or 8 day’ EPG
It may take some time to receive the EPG data.
The list of TV programmes will show
® Use the colour keys to activate the available
actions at the bottom of the screen.
• Next: to show information about the next
programme.
• Remind: to mark or unmark a programme as a
reminder.
• Watch: to watch or listen to a current
programme.
• Jump to...: to jump to the next or previous day.
• Info: to display information on a selected
programme (if available).
ÒPress a to quit the EPG.
5.7.2 More on ‘7 or 8 day’ EPG
Search by genre, scheduled reminders, etc. are
managed in the Programme guide menu.
‡ Press a on the remote control.
® Press Menu.
The Programme guide menu appears.
ÒPress o or œ to select a menu option.
† Press π to enter.
º Press œ or o to make a selection.
◊Press
OK to activate or press the green key to
watch
‹Press a to quit the EPG.
rNote
Only channels marked as Preferred EPG channels
appear in the Programme guide menu.
5.8 Timers and locks
This section describes how to switch the TV on or
off at a specified time and to lock or unlock the TV.
5.8.1 Automatically switch to standby
Sleeptimer switches the TV to standby after a time.
‡ Press Menu on the remote control and select
TV menu > Features > Sleeptimer and press π
to enter the sleeptimer bar.
® Press o or œ to set the time up to 180
minutes in steps of 5 minutes. If set to 0
minutes, the Sleeptimer is switched off.
You can always switch off your TV earlier or reset
the time during countdown.
5.8.2 Automatically switch the TV on
On timer switches the TV on automatically to a
specified channel at a specified time, from standby.
‡ Press Menu on the remote control and select
TV menu > Features > On timer and press π
to enter the On timer menu.
® Use o or œ, p or π to select and enter the
menu items one by one to set a channel, a day
of the week or daily, and a starting time.
ÒPress
OK to confirm.
† Press Menu to quit the menu.
à Tip
To switch off the On timer, select Off in the On
timer menu.
5.8.3 Lock TV channels and programmes
Lock TV channels and/or programmes from
connected devices to prevent children from
watching them. Lock and unlock with a four number
code.
Set or change your code
‡ Press Menu on the remote control and select
TV menu > Features > Set or Change code
and press π to enter your code.
® Enter your code with the number keys.
The Features menu reappears with a message
confirming that your code has been created or
changed.
Programme guide Tue., 12 Sep
09:55
BBC ONE
BBC TWO
five
BBC THREE
BB
C
F
OUR
abc1
09:50 Tweenies
09:00 The Wright Stuff
05:32 This is BBC THREE
05
:
3
2 This is BB
C
F
OUR
09
:2
0
Moonli
g
htin
g
12:30 Commonwealth
10:15 Something Special
10:30 Trisha Goddard
12:00 This is BBC THREE
12:
00
This is BB
C
F
OUR
1
0
:1
5
D
add
i
o
Around Next
07:50 Commonwealth
1
3
:
50
Anastasia
00
1
0
- EEN
R
e
min
d
W
a
t
ch
Inf
o
Jum
p
to ..
.
Pro
g
ramme
g
uid
e
Wh
a
t'
s
on
12:30 South Toda
y
1
3
:
00
In aller Freun
d
11:50 Workin
g
Lunc
h
Preferred EP
G
ch..
.
Ac
q
uire EPG dat
a
Wh
a
t'
s
on
Search b
y
g
enr
e
2700.1 en 13-09-2007 12:54 Pagina 22
Use more of your TV 23
ENGLISH
Did you forget your code ?
‡ Select Change code.
® Press π.
ÒEnter the overriding code 8-8-8-8.
† Enter a new personal code.
º Confirm your new entered code.
The previous code is erased and the new code
is stored.
5.8.4 Activate or deactivate Child lock
If your code is set, you can lock all channels and
devices, lock a specific channel or device, set a time
after which all channels and devices are locked or
set the age of your child for parental rating when
digital channels are installed and broadcasted.
‡ Press Menu on the remote control and select
TV menu > Features > Child lock and press π
to enter your code.
® Enter your code with the number keys.
ÒSelect one of the options.
† Press π.
Lock or unlock all channels and connected devices
‡ Select Lock or Unlock.
® Press
OK.
Lock a certain programme or all channels from a
certain time
‡ Select Custom lock.
® Press π to enter the Custom lock menu.
ÒPress π again to enter the Lock after menu.
† Select On to switch on the Timer lock.
º Press p.
◊Select Time.
‹Press π.
≈Enter the time with o or œ and π.
ÚPress
OK.
Lock one or more channels and connected devices
‡ Select Custom lock.
® Press π to enter.
ÒPress o or œ to select Channel lock.
† Press π.
º Press o or œ to select the channel(s) you
want to lock or unlock.
◊Each time press
OK to lock or unlock the
channel.
Set an age rating to a digital programme
Some digital broadcasters have their programmes
rated (depending on your country).When the
rating is higher than your child’s age, the
programme will be locked.
‡ Select Custom lock.
® Press π to enter.
ÒPress o or œ to select Parental rating.
† Press π.
º Press o or œ to select an age rating.
◊Press Menu to quit the Child lock menu.
5.9 Subtitles
For each TV channel, subtitles can be set, coming
from Teletext or DVB-T (digital) broadcasts.
If digital channels are installed and broadcasted, you
can select your preferred subtitle language.
5.9.1 Subtitling from analogue TV channels
‡ Select an analogue TV channel.
® Press b to switch on Teletext.
ÒEnter the three number pagenumber of the
subtitle page.
† Press b to switch off Teletext.
rNote
The Teletext subtitle page of analogue channels
must be stored for each TV channel separately.
C
hild loc
k
C
ustom loc
k
L
oc
k
a
ft
er
C
hannel loc
k
Parental ratin
g
L
ock
C
ustom loc
k
U
nloc
k
2700.1 en 13-09-2007 12:54 Pagina 23
5.9.2 Activate or deactivate subtitling
‡ Press Menu on the remote control and select
TV menu > Features > Subtitle and press π to
enter the list.
® Press o or œ to select On to show the
subtitles always or On during mute to show the
subtitles only when the sound is muted with the
¬ key on the remote control.
ÒPress p to return to the Features menu.
à Tip
Select the Subtitle menu directly with Option on
the remote control. See section 5.2.3 Quick access
menu.
5.9.3 Select a digital subtitle language
If subtitle broadcasting is available with digital
channels, you can select a preferred subtitle
language out of a list of broadcasted languages.The
preferred subtitle language set in the Installation
menu is overruled temporarily.
‡ Press Menu on the remote control and select
TV menu > Features > Subtitle language and
press π to enter the list of available languages.
® Press o or œ to select a subtitle language.
ÒPress
OK.
à Tip
Select the Subtitle language menu directly with
Option on the remote control. See section 5.2.3
Quick access menu.
5.10 View and play: photos,
MP3, ...
Watch pictures or listen to music stored on a USB
device (not supplied with the TV). Watch your
pictures as a slideshow or listen to a self made
music playlist.
rNote
Philips can not be held responsible if your USB
device is not supported nor shall Philips accept any
liability for damage or loss of stored data.
5.10.1 Insert a USB device
Insert a device at the side of the TV while the TV is
switched on.
The main menu appears automatically and the
name of the USB device is highlighted next to
Multimedia.
5.10.2 Remove the USB device
ç Caution
To avoid damaging the USB device always quit the
menu on screen and wait five seconds before you
remove the USB device.
‡ Press Menu to quit the menu.
® Remove the USB device.
5.10.3 View your pictures
The Multimedia menu shows the files you have
stored on your USB device.
‡ Press π to enter the Multimedia menu.
Picture is highlighted.
® Press π to enter the Picture folder.
ÒPress o or œ to select a picture or a picture
album on the USB device.
24 Use more of your TV
TV
m
e
n
u
F
ea
t
u
r
es
Subtitl
e
Subtitle lan
g
ua
ge
Slee
p
time
r
C
hild loc
k
Set/Chan
g
e cod
e
O
n time
r
C
ommon interfac
e
D
e
m
o
F
ea
t
u
r
es
In
s
t
a
ll
a
ti
on
Software u
p
dat
e
TV
settin
g
s
US
B
Pi
c
t
u
r
e
Afrika
_
200
1
Paris
_
200
6
M
y
_car.
jpg
Jean.
jpg
Mar
y
.
jpg
M
us
i
c
Pi
c
t
u
r
e
T
e
l
e
vi
s
i
on
M
u
ltim
ed
i
a
TV
m
e
n
u
C
hannel lis
t
Pro
g
ramm
e
g
uid
e
2700.1 en 13-09-2007 12:54 Pagina 24
† Press OK to view the picture or to start a
slideshow of the pictures in the album.
º Press
OK to pause the slideshow. Press again to
restart.
◊Press one of the colour keys on the remote
control to perform the corresponding function
shown at the bottom of the screen.
Press the blue key to stop the show and to see
more functions.
If the function bar at the bottom disappeared,
press any colour key to let it reappear.
‹Press p and select another picture or another
album.
Slideshow settings
• Details / More details
Shows the picture name, date, size and next
picture in the slideshow.
• Transitions
Shows the list of available transition styles of the
pictures.
Press o or œ to select and press
OK to
activate.
• Slide time
Sets the time lag for the picture transitions:
Short, Medium or Long.
• Rotate
To rotate a picture.
• Zoom
Show a list of available zoom magnifications to
select.
• Start/Show
To stop and restart the slideshow.
5.10.4 Thumbnails
View the pictures of a selected album in an
overview.
‡ Select a picture album.
® Press π to enter the picture list.
ÒPress the green key.
† Press o or œ, p or π to highlight a picture.
º Press
OK to view the picture.
◊Press p to return to the thumbnail overview.
‹Press the green key again to go back to the
picture list.
5.10.5 Listen to music
Find your songs in the Music album of the
Multimedia menu.
‡ Highlight Music in the Multimedia menu.
® Press π to enter the Music folder.
ÒPress o or œ to select a song or a music
album.
† Press
OK to play the selected song or to play a
song followed by the next song in the same
album.
Music settings
• Details
Shows the file name.
• Repeat one/all
Repeat all songs in the album until you stop a
song or only repeat the one song selected until
you stop the song.
• Shuffle
Play songs in a random sequence.
5.10.6 Slideshow with background music
Watch a slideshow of your stored pictures
accompanied with your stored background music.
‡ Select an album of songs first and press
OK.
® Highlight the Picture folder and select an album
of pictures and press
OK.
Use more of your TV 25
ENGLISH
Jean.
jpg
Mar
y
.
jpg
Pi
c
t
u
r
e
Afrika
_
200
1
Ken
y
a.
jpg
Con
g
o.
jpg
Victoria.
jpg
Cairo.
jpg
Paris
_
200
5
M
y
_car.
jpg
Afrika
_
200
1
Afrika
_
200
1
Afrika
_
200
1
Ken
y
a.
jpg
Con
g
o.
jpg
Victoria.
jpg
Dakar.
jpg
Cairo.
jpg
Ken
y
a.
jpg
US
B
Afrika
_
200
1
—
Ken
y
a.
jpg
—
Ken
y
a.
jpg
2700.1 en 13-09-2007 12:54 Pagina 25
5.11 Listen to radio channels
If digital broadcasting is available, digital radio
channels will be installed during installation.
To listen to a digital radio channel:
‡ Press
OK on the remote control.
The All channels menu is displayed.
® Use the number keys to select a radio channel
available from channel number 400 onwards.
To reorder see section 6.3.3 Reorder the
channels.
ÒPress
OK.
5.12 Software update
Philips continuously tries to improve its products. It
may be recommended for you to update the TV’s
software. Update the software from the internet or
activate new software sent to you by digital
broadcast.
rNote
The device must have at least 48Mb free space.
Make sure the write protection is turned off.
Some USB devices do not work with our TV.
Contact your dealer.
5.12.1 Update assistant
The Update assistant helps you to update the TV’s
software.
TV identification
The TV will identify itself to your USB memory
device.
‡ Press Menu.
® Press π.
ÒPress o or œ to select Software update.
† Press π.
º Press o or œ to select Update assistant.
◊Press π.
‹Press
OK to activate.
≈Insert a USB memory device to the USB
connector at the side of the TV.
The main menu appears.
Ú Press the green key to proceed.
A message appears the TV has successfully
written the identification file to the USB
memory device.
œ Press the green key again to finish.
πRemove the USB memory device from the TV.
5.12.2 Software download from the PC to
the USB device
‡ Insert the USB memory device into a PC linked
to the internet.
® Locate and open the file “update.htm” on your
USB device.
ÒRead the instructions on screen and click on
the Send
ID button.
The software update is downloaded on the
USB memory device.
† Remove the USB memory device from your
PC.
5.12.3 Transfer of the downloaded software
update to the TV
The downloaded software on the USB memory
device must now be uploaded to your TV.
ç Caution
• Do not remove the USB memory device during
the software update.
• If a power drop occurs during the update, do not
remove the USB memory device from the TV.
The TV will continue the update as soon as the
power comes back.
‡ Insert the USB memory device to the USB
connector at the side of the TV.
26 Use more of your TV
TV
m
e
n
u
Software u
p
dat
e
C
urrent software..
.
U
p
date assistan
t
Local u
p
dates
Ann
ou
n
ce
m
e
n
t
F
ea
t
u
r
es
In
s
t
a
ll
a
ti
on
Software u
p
dat
e
TV
settin
g
s
2700.1 en 13-09-2007 12:54 Pagina 26
® The TV switches off.The screen stays black for
about 10 seconds. Wait and do not use the
power switch B on the TV.
Ò The update process starts automatically. Please
wait.
The update is finished when the message
‘Operation successful’ appears on the screen.
† Remove the USB memory device from the TV.
º Press B on the remote control.
rNote
Do not press more than once and do not use the
Power B switch on the TV.
◊The TV switches off.The screen stays black for
about 10 seconds. Please, wait.
‹The TV switches back on again.The update is
done.
5.12.4 Verify the current software version
Updating software is only possible if the version of
the new available software is different from the
current one.You can verify your current software
version.
‡ Select Software update in the TV menu.
® Press π.
ÒPress o or œ to select Current software info.
The version and the description of the current
software appears.
5.12.5 Software update by digital broadcast
(DVB-T)
Your TV might receive new software from the
digital broadcast system automatically.
If you receive an update message on screen it is
strongly advised to update the software
immediately - select Now.
Select Later, if you want to be reminded later on.
Select Cancel to quit the update (not
recommended). If you cancelled the update you can
still update yourself from the TV menu > Software
update > Local update.
Use more of your TV 27
ENGLISH
Operation Successful! Re
P
r
g
B
DEMO
GUIDE
a
v
INPUT
j b q
MHEG
CANCEL
B
a
2700.1 en 13-09-2007 12:54 Pagina 27
6 Channel installation
The first time you switched on your TV you’ve
selected the language of the TV menus and allthe
available channels have been installed.
This chapter will help you if you find it necessary to
re-do the initial installation or if you want to tune in
a new analogue TV channel.
rNotes:
-You do not have to follow every step described if
it is not necessary.
- Re-installation will modify the All channels list and
new added channels will not be added to any
favourite list.
6.1 Automatic installation
This section describes how to search for and store
all available channels automatically.
Step 1 Menu language
Sets the language of the TV menus.
Go to a next step if your language settings are
correct.
‡ Press Menu on the remote control and select
TV menu > Installation > Languages and press
π to enter Menu language.
® Press o or œ to select your language.
ÒPress
OK to confirm.
† Press p to return to the Installation menu.
The Languages menu also offers the following
language settings when digital channels are installed
and broadcasted.
• Preferred audio
Select one of the available audio languages as
preferred language.
• Preferred subtitles
Select one of the available subtitle languages as
preferred language. See section 5.9 Subtitles.
• Hearing impaired
Select On to display the hearing impaired subtitle
version of your preferred audio or subtitle
language when available.
Step 2 Select your country
Select the country where you are located.The TV
will install and arrange the TV channels according to
your country.
‡ Press œ to select Country.
® Press π to enter the list.
ÒPress o or œ to select your country.
† Press p to return to the Installation menu.
Step 3 Time zone selection
Only available for countries with different time
zones.
‡ Press œ to select Time zone.
® Press π to enter the list.
ÒPress o or œ to select your time zone.
† Press p to return to the Installation menu.
Step 4 Install TV and radio channels
Your TV will search for and store all available digital
and non-digital TV channels and all available digital
radio channels.
‡ Press œ to select Channel installation.
® Press π to enter the Channel installation menu.
Automatic installation is highlighted.
ÒPress π to select Start now.
† Press
OK.
º Press the green key to start.
The installation may take a few minutes.
◊When the channel search is completed, press
the red key to return to the Installation menu.
‹Press Menu to quit the TV menu.
à Tip
When digital TV channels are found, the list of
installed channels may show some empty channel
numbers.
If you want to rename, reorder or uninstall stored
channels, see section 6.3 Rearrange channels.
28 Use more of your TV
Installation Languages
Menu language
Preferred audio
Preferred subtitles
Hearing impaired
Languages
Country
Time zone
Channel install...
Preferences
Connections
…
2700.1 en 13-09-2007 12:54 Pagina 28
6.2 Analogue: Manual installation
You can tune-in analogue TV channels channel by
channel manually with Manual installation.
6.2.1 Select the system
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Analogue: Manual installation.
® Press π to enter the Manual installation menu.
System is highlighted.
ÒPress π to enter the System list.
† Press o or œ to select your country or part
of the world where you are now located.
º Press p to return to the Manual installation
menu.
6.2.2 Search for and store a new channel
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Analogue: manual installation > Search.
® Press π to enter the Search menu.
ÒPress the red key to enter the frequency
yourself or press the green key to search for a
next channel.
à Tip
If you know the frequency, enter the three numbers
of the frequency with the number keys of the
remote control.
† Press p when the new channel has been
found.
º Select Store as new channel to store the new
channel under a new channel number.
◊Press π to enter.
‹Press
OK.
Done appears.
≈Press Menu to quit the channel installation
menu.
6.2.3 Fine tune a channel
Fine tune a found channel when the reception is
poor.
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Analogue: manual installation > Fine tune.
® Press π to enter the Fine tune menu.
ÒPress o or œ to adjust the frequency
† Press p when you finished fine tuning.
º Select Store current channel to store the fine
tuned channel under the current channel
number.
◊Press π to enter.
‹Press
OK.
Done appears.
≈Press Menu to quit the Channel installation
menu.
6.3 Rearrange stored channels
To rename, reorder, uninstall or reinstall stored
channels.
6.3.1 Rename a channel
Assign or change a channel name to a channel for
which a name has not yet been entered.
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Rearrange.
® Press π to enter the channel list.
ÒPress o or œ in the channel list to select the
channel you want to rename.
† Press the red key.
º Press p or π to select a character or o or œ
to change the characters. Space, numbers and
other special characters are located between z
and A.
◊Press the green key or
OK to finish.
à Tip
With the yellow key all characters can be deleted.
With the blue key you can delete the character
which is highlighted.
Use more of your TV 29
ENGLISH
C
hannel install..
.
Analo
g
ue: Manual..
.
S
y
ste
m
Searc
h
Fin
e
t
u
n
e
Store as new ch..
.
A
u
t
o
m
a
ti
c
in
s
t
a
ll..
.
Installation u
p
dat
e
Di
g
ital: Test rece
p
t..
.
Rearran
ge
2700.1 en 13-09-2007 12:54 Pagina 29
6.3.2 Uninstall or reinstall a channel
To uninstall a stored channel so that it is no longer
possible to tune to.
Reinstall an earlier uninstalled channel.
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Rearrange.
® Press π to enter the channel list.
ÒPress o or œ in the channel list to select the
channel you want to uninstall or reinstall.
† Press the green key to uninstall or reinstall the
channel.
º Press Menu to quit the menu.
6.3.3 Reorder the channels
Change the order of the stored channels.
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Rearrange.
® Press π to enter the channel list.
ÒPress o or œ in the channel list to select the
channel you want to reorder.
† Press the yellow key to move up the highlighted
channel in your channel list.
º Press the blue key to move down the
highlighted channel in your channel list.
◊Press Menu to quit the menu.
6.4 Automatic
channel management
Once a day, at 3 AM, all available TV channels are
updated automatically.The update is done if your
TV is in standby.
Earlier stored channels not found by the update will
be removed from the channel list.
You can do this update yourself anytime.
‡ Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Installation update.
® Press π to enter the Installation update menu.
ÒPress
OK.
† Press the green key to start.
The update starts and may take a few minutes.
º When the update is completed, press the red
key to return to the Channel installation menu.
◊Press Menu to quit the menu.
6.5 Digital reception test
If you receive Digital TV broadcasting you can check
the quality and signal strength of a specific channel.
‡ Select a channel.
® Press Menu on the remote control and select
TV menu > Installation > Channel installation >
Digital:Test reception.
ÒPress π to enter
† Press
OK.
The channel frequency, the network name, the
signal quality and strength appear.
º Press the green key to start or directly enter
the frequency of the channel you want to test.
If the signal quality and strength are poor,
reposition the antenna.
◊Press the yellow key to store the frequency if
the signal quality and strength are good.
‹Press the red key to return to the Channel
installation menu.
≈Press Menu to quit the menu.
à Tip
To achieve the best results, contact a specialised
antenna installer.
6.6 Factory settings
If you are lost in the picture, sound and Ambilight
settings, you can reset the TV to the factory settings
of picture, sound and Ambilight
‡ Press Menu on the remote control and select
TV menu > Installation > Factory settings.
® Press π to enter the Factory settings menu.
ÒPress
OK.
† Press Menu to quit the menu.
rNote
The channel installation settings are not changed.
30 Use more of your TV
2700.1 en 13-09-2007 12:54 Pagina 30
Back connectors
1
EXT1
Scart connector for DVD,VCR, digital receiver,
game console, etc.
2
EXT2
Second scart connector.
3
EXT3
Component Video Y Pb Pr and Audio L/R
connectors for DVD, digital receiver or game
console, etc.
4 Common Interface
Slot for Conditional Access Modules (CAM)
5
Audio Out L/R
Sound output cinch connectors for a Home
Theatre System, etc.
6
Digital Audio In (if present)
Sound input cinch connector for use with any
of the HDMI connectors with a HDMI to DVI
adaptor.
7
Digital Audio Out
Sound output cinch connector for a Home
Theatre System, etc.
8 HDMI 1 In
HDMI in connector for Blu-ray Disc player, HD
digital receiver or HD game console, etc.
9 HDMI 2 In
Second HDMI in connector.
10 HDMI 3 In
Third HDMI in connector.
11 Antenna input
Side connectors
12 S-Video
S-Video input connector to be used together
with Audio L/R connectors for camcorder, game
console, etc.
13 Video
Video input cinch connector to be used together
with Audio L/R connectors for camcorder, game
console, etc.
14 Audio L/R in
Audio L/R for camcorder, game console, etc.
15 Headphones
Stereo Mini Jack.
16 USB
USB connector.
Connections 31
ENGLISH
7 Connections
7.1 Connection overview
EXT 3
Y
Pb
Pr
AUDIO
L/R
S-VIDEO
VIDEO
AUDIO
L
R
EXT 1
USB
EXT 2
AUDIO OUT DIGITAL
AUDIO
L
R
ANTENNA
COMMON INTERFAC
E
IN
OUT
SERVICE
UAR
T
DISPLAY SYNCHRONIZED
DISPLAY SYNCHRONIZED
.
HDMI 1 HDMI 2 HDMI 3
123
12
13
14
16
4 8 9 10 115 76
15
2700.1 en 13-09-2007 12:54 Pagina 31
7.2 About connecting
Learn here how to make the best connection for
your device.
Six connections are ready to use at the back of the
TV - EXT1, EXT2, EXT3, HDMI1, HDMI2 and
HDMI3. Connect your device with the highest
possible quality connection. Look for the highest
quality connection on your device. Use that
connection to your TV.
Connection set up
When connecting is done the TV needs to know
what connections you made, which device is
connected to which connector. Use the TV menu to
do this. See section 7.4 Connection set up.
7.2.1 HDMI - Highest quality ★★★★★
A HDMI connection has the best picture and sound
quality. One cable combines video and audio signals.
Use HDMI for HD (High Definition) TV signals.
HDMI can offer easy operation of your devices by
the touch of one button when these devices have
HDMI with CEC.A device connected with HDMI to
the TV can only send out audio and video signals to
your TV.The device cannot receive or record audio
and video from your TV.
HDMI cable (max. 5m)
à Tip
Use a HDMI / DVI adaptor in case your device has
only a DVI connection. An extra audio cable is
needed to complete this connection.
rNote
HDMI supports HDCP (High-bandwidth Digital
Contents Protection). HDCP is a copy protection
signal that comes with HD content (DVD disc or
Blu-ray Disc).
7.2.2 HDMI with CEC (if present)
HDMI with Consumer Electronics Control (CEC)
adds to the normal HDMI advantages. It offers easy
operation of the TV and connected devices.These
devices also have to be equipped with HDMI with
CEC.
‡ Press Menu on the remote control and select
TV menu > Installation > Preferences and press
navigation key right to enter the list.
® Press navigation key up or down to select
HDMI-control.
ÒPress navigation key right to enter.
† Select On to activate HDMI with CEC.
rNote
HDMI with CEC might not work with other brands.
One touch play
Insert a DVD disc to watch and your TV will switch
on from standby and show the DVD programme
automatically when you start playing the disc.
‡ Press Play π on the device.
The TV is switched on from standby.
System standby
Switches off all devices with the TV remote control.
‡ Press B on the TV remote control for a few
seconds.
All devices will switch to standby.
7.2.3 YPbPr - Higher quality ★★★★
Use the Component Video YPbPr connections
together with the Audio L/R mini jack. Match the
cable colours when you connect.
YPbPr can handle HD TV signals.
Component Video Audio L/R to Stereo
YPbPr cable mini jack cable
- Red, Green, Blue
32 Connections
2700.1 en 13-09-2007 12:54 Pagina 32
7.2.4 Scart - Good quality ★★★
One cable combines video and audio signals.
Scart connectors can handle RGB video but no HD
TV signals.
Scart cable
7.2.5 S-Video - Good quality ★★
Use a S-Video cable together with an Audio L/R
(cinch) cable. Match the cable colours when you
connect.
An S-Video cable Audio L/R cable
- Red, White
7.2.6 Video - Basic quality ★
Use a Video (cinch) cable together with an Audio
L/R (cinch) cable. Match the cable colours when
you connect
Combined Video - yellow and Audio L/R cable
- red and white
7.2.7 Display synchronised audio out
For the best match of image and sound in speech
on screen, connect a Home Theatre System to
Audio L/R or Digital Audio outputs.
See diagrams 7.3.4 and 7.3.8.
Do not connect the audio signal of a DVD player,
digital receiver or other audio/video device directly
to the Home Theatre System.
Connections 33
ENGLISH
2700.1 en 13-09-2007 12:54 Pagina 33
7.3 Connect your devices
The connections shown in this section are
recommendations for the most used cases.
Other solutions may be possible.
7.3.1 DVD player
Use a scart cable to connect the device to the
EXT1 input at the back of the TV.
7.3.2 DVD Recorder or Digital Receiver
Use a scart cable and 2 antenna cables.
7.3.3 DVD Recorder and Digital Receiver
Use 3 scart cables and 3 antenna cables.
34 Connections
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
AUDIO OUT
L
R
OUT
IN
ANTENNA
DIGITAL
AUDIO
Receiver / Cable boxDVD Recorder
IN
OU
T
I
N
OUT
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
DVD Player
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
DVD Recorder / Digital receiver
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
IN
OUT
2700.1 en 13-09-2007 12:54 Pagina 34
7.3.4 DVD Recorder and Home Theatre
System
Use a scart cable, 2 antenna cables and 1 digital
audio (cinch) cable.
7.3.5 DVD Recorder and DVD Home
Theatre System
Use 2 scart cables, 2 antenna cables and 1 digital
audio (cinch) cable.
7.3.6 Satellite receiver
Use a scart cable and 2 antenna cables.
Connections 35
ENGLISH
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
Satellite receiver
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
OUT
Home Theatre SystemDVD Recorder
DIGITAL
AUDIO
IN
IN
OUT
DIGITAL
AUDIO
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DVD Home Theatre SystemDVD Recorder
IN
OUT
DIGITAL
AUDIO
2700.1 en 13-09-2007 12:54 Pagina 35
7.3.7 HD Digital receiver / HD satellite
receiver
Use a HDMI cable and 2 antenna cables.
7.3.8 DVD-R, Home Theatre System and
Digital receiver
Use 3 scart cables, 3 antenna cables and 1 audio
(cinch) cable.
7.3.9 Blu-ray Disc player
Use a HDMI cable.
36 Connections
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
Blu-ray Disc player
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
OUT
HDMI
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
HD Digital receiver / HD Satellite receiver
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
IN
OUTOUT
HDMI
EXT 3
Y
Pb
Pr
AUDIO
L/R
HDMI 3HDMI 1 HDMI 2
EXT 1EXT 2
AUDIO OUT
L
R
OUT
IN
ANTENN
A
DIGITAL
AUDIO
OUT
Home Theatre SystemDigital ReceiverDVD Recorder
DIGITAL
AUDIO
IN
IN
OUT
IN
OUT
DIGITAL
AUDIO
2700.1 en 13-09-2007 12:54 Pagina 36
7.3.10 Game console
The most practical connection for a game console
is at the side of the TV. More qualitative
connections are at the back of the TV.
Connected at the side of the TV
Use the Video and Audio L/R (cinch) connectors.
Connected at the back of the TV
Use a HDMI or the YPbPr (EXT3) input for HD
quality.
7.3.11 Camcorder
The most practical connection for a camcorder is at
the side of the TV. More qualitative connections are
at the back of the TV.
Connected at the side of the TV
Use the Video and Audio L/R (cinch) connectors or
use the S-Video and Audio L/R connectors.
Connected at the back of the TV
Use a HDMI or the YPbPr (EXT3) input for HD
quality.
7.3.12 Personal Computer
The best connection for a PC is at the back of the
TV. A more practical connection, but only for
viewing photos and films from your PC, is the
connection at the side of the TV.
ç Caution
Before connecting the PC, set the PC monitor
refresh rate to 60Hz.
Connected at the back of the TV
Use the DVI connection of your PC to connect to
a HDMI connection of the TV. Use a HDMI to DVI
cable or a HDMI-to-DVI-adaptor.
Add an audio cable with a Stereo mini jack for
sound. Connect the Stereo mini jack to
EXT3 on
the TV.
In the Connections menu, link this
EXT3 audio to
the HDMI connector you are using.
See section 7.4 Connections setup.
Connected at the side of the TV
If your PC has no DVI connection, use the S-Video
and Audio L/R (cinch) connectors at the side of the
TV.This connection is only suited for applications
like Windows Media Center or similar.
à Tip
Change the TV picture format to Unscaled in the
Picture format menu for maximal picture sharpness.
See section 5.3.4.Widescreen picture format.
For supported PC monitor resolutions, see section
8 Technical data.
Connections 37
ENGLISH
S-VIDEO
VIDEO
AUDIO
L
R
DVI
AUDI
O OUT
DVI
AUDIO
OUT
HDMI
HDMI
EXT 3 - AUDIO L/R
S-VIDEO
VIDEO
AUDIO
L
R
S-VIDEO
VIDEO
AUDIO
L
R
2700.1 en 13-09-2007 12:54 Pagina 37
7.4 Connections setup
When all devices have been connected the TV
needs to know what connections you have made,
which device is connected to which connector.
7.4.1 Digital Audio In
(if present)
If you use the Digital Audio In connection,
assign this connection, in the menu, to the device
from where the sound comes from.
‡ Press Menu on the remote control and select
TV menu > Installation > Connections > Digital
Audio In.
® Press π to enter the list.
ÒPress œ or o to select the connector used by
the device.
7.4.2 Audio In L/R
If you use the Audio In L/R connection, assign this
connection, in the menu, to the device from where
the sound comes from.
‡ Press Menu on the remote control and select
TV menu > Installation > Connections > Audio
In L/R.
® Press π to enter the list.
ÒPress œ or o to select the connector used by
the device.
7.4.3 Naming your devices
Name the connected devices for easy selection and
best signal handling.
Assign the type of device (DVD,VCR, Game ...) to
the connector you use for that device.
‡ Press Menu on the remote control and select
TV menu > Installation > Connections >
EXT1.
® Press π to enter the list.
ÒPress œ or o to select the type of device.
† Press Menu to quit the menu.
7.4.4 Decoder channels
Decoders that decode an antenna channel are
connected to
EXT1 or EXT2 (scart).
You have to assign the TV channel as a channel to
be decoded.Then assign the connection where the
decoder is connected.
‡ Press Menu on the remote control and select
TV menu > Installation > Decoder > Channel.
® Press π to enter the list.
ÒPress œ or o to select the channel to decode.
† Press p and go back to select Status.
º Press œ or o to select the connector used by
the decoder.
◊Press Menu to quit the menu.
38 Connections
C
onnections DI
G
ITAL A
U
DI
O
I
N
N
o
n
e
EXT 1
EXT 2
EXT
3
HDMI 1
HDMI 2
HDMI
3
Sid
e
...
EXT
3
HDMI 1
HDMI 2
HDMI
3
Sid
e
AUDIO IN L
/R
DI
G
ITAL A
U
DI
O
I
N
C
onnections AUDIO IN L
/R
N
o
n
e
EXT
3
HDMI 1
HDMI 2
HDMI
3
EXT 2
EXT
3
HDMI 1
HDMI 2
HDMI
3
Sid
e
AUDIO IN L
/R
C
onnections
EXT 1
N
o
n
e
DVD
Blu-ra
y
HDD
/
DVD
R
HD r
ec.
G
am
e
V
CR
...
EXT 1
EXT 2
EXT
3
HDMI 1
HDMI 2
HDMI
3
Sid
e
...
2700.1 en 13-09-2007 12:54 Pagina 38
7.5 Preparing for digital
services
Scrambled digital TV channels can be decoded with
a Conditional Access Module (CAM) and a Smart
card provided by a digital TV service operator.The
CAM may enable several services depending on the
operator you choose (e.g. Pay TV).
Contact your digital TV service operator for more
information and terms.
7.5.1 Insert a Conditional Access Module -
CAM
) Warning
Switch off your TV before inserting a CAM.
Look on the CAM for the correct inserting
direction. Inserting the module incorrectly may
damage the CAM and your TV.
‡ Gently insert the CAM into the Common
Interface slot at the back of your TV as far as it
will go.
® Leave the CAM in the Common Interface slot
permanently.
It may take a few minutes before a CAM is
activated. Removing the CAM will deactivate the
digital TV service.
7.5.2 Common interface menu
From this menu you access the CAM service you
have installed.The applications and their function,
the content and the messages on screen come
from the CAM service provider.
‡ Press Menu on the remote control and select
TV menu > Features > Common interface.
This menu option is available when a CAM is
inserted and has made contact with the provider.
Connections 39
ENGLISH
COMMON INTERFACE COMMON INTERFACE
2700.1 en 13-09-2007 12:54 Pagina 39
8Technical data
Picture / Display
• Display type: LCD, Full HD W-UXGA
•Panel resolution: 1920x1080p
•Perfect Pixel HD picture enhancement
• 1080p 24/25/30/50/60Hz processing
• 100 Hz ClearLCD (if present)
Supported display resolutions
• Computer formats (via HDMI/DVI input)
Resolution Refresh rate
640 x 480 60Hz
800 x 600 60Hz
1024 x 768 60Hz
1280 x 768 60Hz
1360 x 768 60Hz
1920 x 1080i 60Hz
1920 x1080p 60Hz
• Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 50Hz, 60Hz
1080i 50Hz, 60Hz
1080p 24Hz, 25Hz, 30Hz
1080p 50Hz, 60Hz
Tuner / Reception / Transmission
• Antenna input: 75ohm coaxial (IEC75)
• TV system: DVD COFDM 2K/8K
• Video playback: NTSC, SECAM, PAL
•DVD: DVB Terrestrial
(see selected countries on the TV typeplate)
Dimensions and weights (approx.)
TV model 37-42-47-52PFL9632D/10
37” 42” 47” 52”
- width 950 1060 1170 1310 mm
- height 612 675 736 824 mm
- depth 125 125 125 125 mm
- weight 22 28 32 41 kg
TV + stand
- width 950 1060 1170 1310 mm
- height 677 740 801 889 mm
- depth 184 256 297 218 mm
- weight 25 32 37 47 kg
Sound
• Sound system:
- Virtual Dolby Digital
- BBE
Multimedia
• Connection: USB
• Playback formats: MP3, LPCM, Slideshow (.alb)
JPEG
Remote control
•Type: RC4450
• Batteries: 2 Size AA- R6 type
Connectivity
• EXT1 (scart): Audio L/R, CVBS in/out, RGB
• EXT2 (scart): Audio L/R, CVBS in/out, RGB,
S-video in/out
• EXT3:Y Pb Pr, Audio L/R in (mini jack)
• HDMI 1
• HDMI 2
• HDMI 3
• HDMI-control 1.3a
• Analog Audio L/R out - display synchronised
• Digital Audio in (coaxial-cinch-S/PDIF) (if present)
• Digital Audio out (coaxial-cinch-S/PDIF) -
display synchronised
• Side: Audio L/R in,Video (CVBS) in, S-Video
Headphone out (stereo mini jack), USB
Power
• Mains power: AC 220-240V (±10%)
•Power and standby power consumption:
See technical specification on www.philips.com
• Ambient temperature: 5°C - 35°C
Specifications are subject to change without notice.
For more specification details of this product see
www.philips.com/support.
40 Technical data
2700.1 en 13-09-2007 12:54 Pagina 40
9Troubleshooting
Te levision and remote control
The TV does not switch on
•Verify the mains cord connection.
•Verify if the batteries of the remote control are
flat or weak.Verify their + / - orientation.
You can use the keys on the TV to switch the TV
on.
• Unplug the mains cord, wait for one minute and
plug in the mains again.
The TV does not react on the remote control
•Verify if the batteries of the remote control are
not empty or weak.Verify their + / - orientation.
• Clean the remote control and TV sensor lens.
• Use the side control keys to change some of the
basic settings of picture and sound.
‡ Press Volume - and + to adjust the volume.
® Press Program/Channel - and + to go through
the channels marked as favourites.
ÒPress Menu to show the main menu.
Press Program/Channel - and + to select and
adjust picture and sound menu items.
The red light on the TV blinks
• Unplug the mains cord for half a minute and
insert it again.Verify if there is enough space for
ventilation.Wait until the TV has cooled down.
When the TV does not restart to standby and
the blinking occurs again, call our Customer
Support Centre.
You forgot your code to unlock Child lock
• See section 5.8.3 Set code / Change code.
Wrong language in the TV menu ?
Follow these steps to change the language.
‡ Press Menu on the remote control.
® Press π.
ÒUse œ to highlight the third line.
† Press π three times.
º Press œ or o to select your language.
◊Press
OK.
‹Press Menu to quit the menus.
TV channels
Some TV channels are gone
•Verify if the correct channel list is chosen.
•A channel could be uninstalled in the Rearrange
menu.
No digital channels found during installation
•Verify if the TV supports DVB-T in your country.
See the list of countries on the TV typeplate.
The blue light is on, but there is no picture
•Verify if the antenna is connected properly.
•Verify if the correct device is selected.
The sound is on, but there is no picture
•Verify the contrast or brightness setting in the
menu.
The TV picture is poor
•Verify if the antenna is connected properly.
• Loudspeakers, non-earthed audio devices, neon
lights, high buildings or mountains can influence
the picture quality.Try to improve the picture by
changing the antenna direction or place devices
away from the TV.
•Verify if the correct TV system is chosen in the
Manual installation menu.
• If only a certain channel is poor, try to fine tune
this channel in the Fine tune menu. See section
6.2.3.
The picture has poor colour
•Verify the colour settings in the Picture menu.
Select any of the Reset to standard settings in
the Reset to standard menu. See section 5.3.2.
•Verify the connections and cables of the
connected devices.
The TV did not remember my settings when I
switch back on
•Verify if the TV is set to Home in the TV menu >
Installation > Preferences > Location menu.
The picture does not fit the screen, it is too big or
too small
• Select a more fitting picture format in the Picture
format menu.
See section 5.3.4 Widescreen picture format.
• Name your connected device in the Connections
menu to obtain the best signal handling.
See section 7.4.3 Naming your devices.
The picture position on screen is not correct
• Some picture signals from some devices do not
fit the screen correctly.You can shift the picture
with the p, π or o, œ keys on the remote
control. Check the signal output of the device.
Troubleshooting 41
ENGLISH
2700.1 en 13-09-2007 12:54 Pagina 41
Sound
There is a picture but no sound
•Verify the volume is not set to 0.
•Verify the sound has not been muted with the
¬ key.
•Verify if all cables are connected properly.
• If no sound signal is detected, the TV
automatically switches off the sound.
This is proper operation and does not indicate
malfunction.
The sound is poor
•Verify if the sound is set to Stereo.
•Verify the Equalizer settings.
• Select any of the Reset to standards settings in
the Reset to standard menu. See section 5.3.2.
The sound comes from one speaker only
•Verify if the Balance is not set to extreme left or
right.
HDMI connections
Trouble with devices connected with HDMI
• The HDMI - HDCP procedure might take a few
seconds before the TV shows the picture from a
device.
• If the TV does not recognise the device and the
screen shows no picture, try switching from one
device to another and back again to restart the
HDCP procedure.
• If sound interruptions occur persistently, see the
user manual of the device to verify the output
settings. If that does not help, connect an
additional audio cable.
• If an HDMI-to-DVI adaptor is used, verify if an
additional audio connection is in place to
complete the DVI connection.
USB connection
The TV does not show the USB device content
• Set your device (camera) to ‘Mass Storage Class’
compliant.
• The USB device may need specific driver
software. Unfortunately this software can not be
downloaded to your TV.
I can not see my files in the Multimedia menu.
• Not all audio and picture files are supported. See
section 8 Technical data.
Audio and picture files do not playback smoothly
• The transfer performance of the USB device
limits the transfer rate.
Personal computer
The PC display on my TV is not stable or is not
synchronised
•Verify if the correct resolution mode is selected
on your PC. See section 8 Technical data.
If your problem is not solved
Switch your TV off and on again. If the problem is
not solved, call the Customer Support Centre or
consult our website www.philips.com/support.
See the Customer Support Centre telephone
numbers on the last page of this user manual.
Please, have the TV Model and Product Number
ready before you call.
You can find these numbers on the packaging label
or on the typelabel on the back and bottom of the
TV.
) Warning
Never try to repair the TV yourself.
42 Troubleshooting
2700.1 en 13-09-2007 12:54 Pagina 42
10 Index
100 Hz ClearLCD 16
Active Control 16
Ambilight
colour 18
colour boost 18
menu / settings 18
modes 11
with TV standby 19
Analogue
manual installation 29
TV channels 29
Antenna
cable 7
connect 7
with devices 31
Auto format 17
Automatic installation 28
Auto surround 18
Automatic Volume Leveler 18
Balance
Ambilight 18
sound 17
Batteries 3,7
Blacklevel 16
Blu-ray 31,32,36
Brightness 16
ambilight 18
CA module 31,39
Cable
HDMI 32
Scart 33
YPbPr 32
S-Video 33
Video 33
Camcorder 37
Camera (photo) 37
Care of the screen 3
Change code 22
Channel
all channels list 20
favourite list 20
installation 28
lock 20
management 30
previous 12
rearrange 29
store / install 29
Child lock 23
Clock 15
Code 22
Colour enhancement 16
Colour
menu 16
keys 4,12
Common interface (CAM)
menu 39
slot 31,39
Connection
best 32
overview 32
set up 32,37
Contrast 16
Country
digital system 30
selection 28
Custom colour 18
Custom lock 20
Custom tint 16
Decoder
channel 37
Delta volume 18
Device
connecting 32
naming 37
watch 9
Digital
audio out 31
audio language 17
subtitle language 24
receiver 34
text services 20
test reception 30
Dual I/II 18
Dual screen 12
DVB-T 5
DVD
connect 34
playback 9
player 34
recorder 34
Dynamic contrast 16
Electronic Programme Guide 21
Equalizer 17
External 1,2,3 (EXT) 31
Factory settings 30
Favourite channel lists 20
Fine tune 29
Game console 37
HDCP 32
HDMI
connection 31
control 33
HD digital receiver 36
HD Natural Motion 16
Headphone
connect 4,31
volume 18
Hearing impaired 28
Home
location 41
Home theatre system 35
Hue 16
Installation
automatic 28
manual 29
menu 28
update 30
Kensington Security Slot 5
Key(s)
colour 12
on TV 4
on remote control 4,12
Language
menu 28
audio 18
subtitle 19
Light sensor 16
Location 41
Locks 22
L
K
I
H
G
F
E
D
C
B
A
Index 43
ENGLISH
2700.1 en 13-09-2007 12:54 Pagina 43
Mains cord 8
Menu key 13
Mono 18
Movie expand 17
MPEG artefact reduction 16
Music 25
Mute key 12
Naming devices 37
Noise reduction 16
OK key 12
On timer 22
Perfect Pixel HD 16
Personal Computer
connect 37
display resolutions 40
Photo viewer 24
format 16
menu 16
Position the TV 5
Power 8
Programme up/down 12
Quick access menu 15
Radio channel 26
Rearrange channels 29
Recorder 34
Recycling 3
Remote control
batteries 7
overview 12
Rename 29
Reorder 29
Reset to standards 15
Safety 3
Satellite receiver 35
Scart connection 33
Screen cleaning 3
Search
channels 29
teletext pages 19
Set code 22
Settings assistant 15
Sharpness 16
Sleeptimer 22
Software update 26
Sound
menu 17
surround mode 18
Standby 22
Super zoom 17
Stationary images 3
Stereo 18
Subtitle 23
shift 17
Switch on 8
Tab le of Pages T.O.P 19
Technical data 40
Teletext 19
teletext 2.5 20
digital 29
dual screen 19
menu 20
page 19
Time zone 28
Timers 22
Tint 16
Troubleshooting 41
TV settings menu 15
USB
connector 31
device 24
photo viewer 24
VCR
connect 34
Video cable 33
Video formats 40
Volume
key 12
menu 17
Whitepoint 16
Widescreen picture format 17
YPbPr 32
Y
W
V
U
T
S
R
Q
P
O
N
M
44 Index
2700.1 en 13-09-2007 12:54 Pagina 44
