NICOR, Inc. 2200 Midtown Place NE, Albuquerque, NM 87107 P: 800.821.6283 F: 800.892.8393 www.nicorlighting.com August 20, 2019 5:08 PM
What’s In The Box
One (1) NUC5
One (1) Romex Connector
ATTENTION:
• Turn power o before inspection, installation, or removal.
• Suitable for use in dry or damp indoor locations. Use only on 120 VAC, 60Hz circuits.
NUC5 Select LED Undercabinet
INSTALLATION INSTRUCTIONS
Models: NUC508S**, NUC512S**, NUC521S**,
NUC530S**, NUC540S**
Installation Steps
WARNING:
• Risk of electric shock. Disconnect power at fuse or circuit breaker before installing or servicing.
• To prevent early failure, xture should only be installed in operating environments between -20°C and + 40°C (-4°F and 104°F)
• No user serviceable parts inside. To avoid electric shock, do not disassemble product.
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp object
Tools & Materials Needed
This LED Undercabinet requires very few tools for
installation. A drill or a screwdriver and a pair of wire cutters will
aid in installation.
Turn o power to appropriate
circuit at the breaker box.
1
Insert Romex connector into the
desired knockout, install green
wire with ring end over the
connector and secure with lock
nut.
2
3 4
5 6
Three (3) Wire Nuts
Two (2) Mounting Screws
Pre-installed
Mount housing to desired surface
with the two captive mounting
screws (5) provided.
Note: For 40” xtures, there is an additional
mounting screw hole in the middle of
housing. Open the top cover and securely
fasten the mounting screw.
Insert supply wires through
connector and secure with the
two screws on the connector.
Using wire nuts (provided), attach black xture wire to black
supply wire, white xture wire to white supply wire, green
xture grounding lead to grounding lead. Unit is TRIAC or
ELV dimmable. Follow dimmer manufacturer instructions for
proper intsallation.
Restore power and check for proper operation.
Note:
1) On/O switch controls illumination.
2) CCT selection switch is a three-position switch that will
adjust Color Temperature between 2700K, 3000K, or 4000K.
Note: Requires 120VAC/60Hz power supply for proper operation.
