Cut the drywall.
Note:Always allow at least
one-half inch between a wall
stud and the speaker cutout or
the locking tabs will not be able
to swivel into place.
Replace the metal grille.
Screw down each of the four
Phillips head screws.The
locking tabs will swivel into
place and secure the unit to
the rear surface of the drywall.
Put in the strips of adhesive to
secure the grille.
Connect the speaker wires to
the speaker.
6.5'' Waterproof Rated Marine Speakers
Dual 6.5'' Waterproof Marine Speakers, Full Range Stereo Sound, Camo Style, 150 Watt (Pair)
PLMR60DK
FEATURES:
• Includes (2) 6.5'' Component Speakers
• Marine Grade Construction
• Waterproof Rated & Weather-Resistant Design
• Hunting Camouage Pattern Style
• Full Range Stereo Sound Reproduction
• Dual Cone Speakers
• Polypropylene Cone, Cloth Surround
• Molded ABS Machined Basket and Grill
• For Marine, Automobile & O-Road Vehicles
• Universal Standard OEM Replacement Size
WHAT’S IN THE BOX:
• (2) 6.5’’ Marine Speakers
• (2) Speaker Wire, 9.8’ ft.
TECHNICAL SPECS:
• MAX Power: 150 Watt (RMS Power: 75 Watt)
• Marine Grade Rating: IP-44
• Voice Coil: 1.0'', Aluminum
• Impedance: 4 Ohm
• Frequency Response: 45Hz - 16kHz
• Magnet Structure: 20 oz.
• Housing Construction Material: Engineered ABS
• Speaker Total Diameter: 7.09'' -inches
• Speaker Cut-Out Diameter: 5.2'' -inches
• Speaker Mounting Depth: 2.48'' -inches
• Single Speaker Weight: 1.54 lbs. -Each
Installation Guide:
