If you have questions, call 1.800.561.3344 or visit our website at:
www.geappliances.ca
Built-In Wall Oven
27” (68.6 cm) models
JCK1000, JCK3000, JCK5000
30” (76.2 cm) models
JCT3000, JCT5000, PCT7050
Installation
Instructions
Materials Needed
Strain Relief Clamp
for 1/2” conduit
Junction
Box
Wire Nuts
Before You Begin
Read these instructions carefully and completely.
• IMPORTANT³6DYHWKHVH
instructions for local inspector’s use.
•
IMPORTANT³2EVHUYHDOO
governing codes and ordinances.
1RWHWR,QVWDOOHU³%HVXUHWROHDYHWKHVH
instructions with the consumer.
1RWHWR&RQVXPHU³.HHSWKHVH
instructions for future reference.
• Proper installation is the responsibility
of the installer and product failure due
to improper installation is NOT covered under
warranty.
127(³7KLVDSSOLDQFHPXVWEHSURSHUO\
grounded.
•
ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approved junction box. A
plug and receptacle is NOT permitted on these
products.
31-10884-1 06-13 GE
Tools Needed
1/8” (3 mm) Drill Bit and
Electric or Hand Drill
Phillips
Screwdriver
Parts Included
Taped to top of unit.
(Appearance will vary.)
Screws for Oven Mounting
[ÀDWKHDG3KLO-
lips wood screws)
Metal Bottom Trim
Assembly
Screws for Bottom Trim
Mounting (8-18 x .625 pan
head Phillips sheet metal
screws)
