3-292-622-11(1)
Operating Instructions
©2008 Sony Corporation Printed in China
XDR-F1HD
FM/AM
Digital Tuner
WARNING
To reduce the risk of re or electric shock,
do not expose this apparatus to rain or
moisture.
To reduce the risk of re, do not cover the ventilation of
the apparatus with newspapers, tablecloths, curtains, etc.
And do not place lighted candles on the apparatus.
To reduce the risk of re or electric shock, do not expose
this apparatus to dripping or splashing, and do not
place objects lled with liquids, such as vases, on the
apparatus.
Do not install the appliance in a conned space, such as a
bookcase or built-in cabinet.
Do not expose the batteries (battery pack or batteries
installed) to excessive heat such as sunshine, re or the
like for a long time.
As the main plug is used to disconnect the unit from the
mains, connect the unit to an easily accessible AC outlet.
Should you notice an abnormality in the unit, disconnect
the main plug from the AC outlet immediately.
You are cautioned that any changes or
modications not expressly approved in this manual
could void your authority to operate this equipment.
ese following indications are located on the bottom
exterior.
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk
of electric shock to persons.
This symbol is intended to alert the user
to the presence of important operating
and maintenance (servicing) instructions
in the literature accompanying the
appliance.
INFORMATION
is equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. ese limits are designed
to provide reasonable protection against harmful
interference in a residential installation. is equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving
antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the manufacturers
instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. e wide blade or the third prong are
provided for your safety. If the provided plug does
not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specied by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
HD Radio™ Technology Manufactured Under License
From iBiquity Digital Corp. U.S. and Foreign Patents.
HD Radio™ and the HD Radio logo are proprietary
trademarks of iBiquity Digital Corp.
What is HD Radio™
Technology?
HD Radio Broadcasting was approved by the Federal
Communications Commission in October 2002 as the
system for digital AM and FM broadcasting in the U.S.
HD Radio technology features include:
Static-free, clear radio reception.
FM Multicasting – the ability to broadcast multiple
program streams over a single FM frequency.
A variety of “data services,” including text-based
information – artist name, song title, etc. scrolled
across your receiver display.
Digital broadcasts in the same frequencies as analog
broadcasts; listeners do not need to learn a new station
number and today’s stations remain at their current
place on the dial.
HD Radio technology is developed and licensed by
iBiquity Digital Corporation and supported by the
leaders of the broadcasting, consumer electronics and
automotive industries.
Features
Compact size HD Radio™ tuner unit.
Large LCD display to show information about the
content.
Up to 20 presets for FM and AM stations.
Audio-output (Stereo: pin jack.)
Full function remote control.
Precautions
Play the unit on the power source specied in
“Specications.
To disconnect the AC power cord (mains lead), pull it
out by the plug, not the cord.
e unit is not disconnected from the AC power
source (mains) as long as it is connected to the wall
outlet, even if the unit itself has been turned o.
e nameplate, the symbol for CLASS II and the dating
code are located on the bottom exterior.
Do not leave the unit in a location near a heat source
such as a radiator or airduct, or in a place subject to
direct sunlight, excessive dust, mechanical vibration, or
shock.
Allow adequate air circulation to prevent internal heat
build-up. Do not place the unit on a surface (a rug, a
blanket, etc.) or near materials (a curtain) which might
block the ventilation holes.
Should any solid object or liquid fall into the unit,
unplug the unit and have it checked by a qualied
personnel before operating it any further.
To clean the casing, use a so cloth dampened with a
mild detergent solution.
Never touch the wire of the external FM antenna
during a thunderstorm. Furthermore, immediately
disconnect the AC power code from the radio.
If you have any questions or problems concerning your
unit, please consult your nearest Sony dealer.
Troubleshooting
Should any problem persist aer you have made the
following checks, consult your nearest Sony dealer.
Only analog broadcast is received in an HD Radio
reception area.
Depending on the conditions, if the incoming signal
strength is too weak or unstable, the HD indicator
will not ash or light up. In that case, the HD Radio
broadcast will be received as an analog signal.
Noise occurs.
Ensure that the unit and the antenna are not near a
digital amplier or any other components that emits
noise.
Owners Record
e model number and the serial number are located on the bottom.
Record the serial number in the space provided below. Refer to them whenever you call upon your Sony dealer regarding this product.
Model No. XDR-F1HD
Serial No. ________________________________
Connecting the antenna
To connect the AM loop
antenna
e shape and the length of the antenna is designed
to receive AM signals. Do not dismantle or roll up the
antenna.
1 Remove only the loop part from the plastic
stand.
2 Set up the AM loop antenna.
3 Connect the cords to the AM antenna
terminals.
Cord (A) or cord (B) can be connected to either
terminal.
A B
Only insert up
to here.
Insert the cord while
pushing down the
terminal clamp.
4 Make sure the AM loop antenna is connected
rmly by pulling soly.
Adjusting the AM loop antenna
Find a place and an orientation that provide good
reception.
Do not place the AM loop antenna near the unit or
other AV equipment, as noise may result.
If you use an external polarized AM antenna, be sure
to connect the ground cord to the U terminal. e
supplied AM antenna cord has no polarity.
Tip
Adjust the direction of the AM loop antenna for best AM
broadcast sound.
To connect the FM antenna
is unit comes supplied with an FM dipole antenna.
Connect an antenna that provides good reception to the
FM antenna terminal.
FM dipole antenna
(supplied)
Adjusting the FM dipole antenna
Be sure to fully extend the FM dipole antenna. Attach the
antenna in the shape of a T to a high position on a wall
away from this unit.
Tip
If you have poor FM reception, use a 75 coaxial cable
(not supplied) to connect the unit to an outdoor FM
antenna as shown below.
Outdoor FM antenna
ANTENNA
AM FM
For customers who purchased this product in the USA
Please register this product on line at http://www.sony.com/productregistration.
Proper registration will enable us to send you periodic mailings about new products, services, and other
important announcements. Registering your product will also allow us to contact you in the unlikely
event that the product needs adjustment or modification. Thank you.
Connecting the system
is section describes how to hook up the unit to the
audio system. Be sure to turn o the power of each
component before making the connections.
ANTENNA
AUDIO OUT
AM
RESET
L
R
FM
AUDIO OUT
(Stereo pin plug)
(Red) (R)
AUDIO OUT
(Stereo pin plug)
(White) (L)
Audio input
(White) (L)
Audio input
(Red) (R)
Audio cable (Not supplied)
Notes
Install this system so that the power cord can be
unplugged from the wall socket immediately in the
event of trouble.
If noise occurs, separate the unit from other
components.
Noise may occur during AM reception if the unit
is connected to a digital amplier or a component
equipped with a digital amplier.
