QUICK
START GUIDE
EUFYCAM 2
WIRE-FREE HD SECURITY CAMERA
Adding eufyCam 2
Product Overview
TABLE OF
CONTENTS
Charging eufyCam 2
Mounting the Camera
What’s Included
Notice
01
02
03
09
04
10
For eufyCam 2 installation
WHAT’S
INCLUDED
1
Product
Overview
2
01
02
Mounting
Bracket
Mounting Screws
and Anchors
Micro-USB
Charging Cable
Indoor
Mount
Hook
(for Indoor Mount)
eufyCam 2
(T8114)
eufyCam 2
1. Photosensitive sensor
2. Camera len
3. Motion sensor
4. Microphone
5. LED indicator
6. Sync button
7. USB charging port
8. Screw hole
6
3
4
5
2
1
8
7
3
Add eufyCam 2 to Your
Existing System
03
On Eufy Security app, follow the onscreen instructions
to add your Eufy Security devices. Choose Add
Device, then select eufyCam 2 to add it to your
system.
4
ADDING
eufyCam 2
04
Find a Good Mounting Spot
MOUNTING
THE CAMERA
To find a spot to mount eufyCam 2, you need to
test wireless signal strength.
① Open the Eufy Security app, go to
Camera Settings > Mounting Guide.
②
To test the wireless signal strength, take your camera
and phone to the location where you want to
mount the camera.
③ Move the camera as close to your HomeBase as
possible if the wireless signal strength is poor.
Outdoor mount is designed specifically for outdoor
environment.
1. Turn the knob of the mounting bracket clockwise to
loosen and disassemble it.
2. Drill holes with a 15/64 inch (5.99 mm) drill bit, then
insert the anchors into the holes; anchors are
necessary for walls that are made out of hard
materials such as concrete, brick, or stucco.
Mount the Camera Outdoors
Hang eufyCam 2 7-10 ft (2-3 m) above the ground.
This height maximizes the detection range of the
motion sensor of eufyCam 2. Avoid placing eufyCam 2
under direct sunlight.
05 06
Select Height and Location
Motion
Detection
Zone
Camera field
of view
Up to 30 ft (10 m)
7-10 ft
(2 - 3 m)
Mount the Camera Outdoors
3. Firmly screw the base of the mounting bracket onto
the wall. Fasten the ball knob of the bracket to the
base of the bracket.
4. Tighten eufyCam 2 camera to the mounting bracket
and adjust the viewing angle by checking the live
stream feed in the Eufy Security app.
Mount the Camera Indoors
07 08
Stick the camera directly to any flat surface made out
of iron. Or you can use the indoor mount to mount
the camera:
① Drill a hole. Use the included anchor if it’s drywall
and fasten the hook.
② Hang the indoor mount on the hook.
③ Attach eufyCam 2 to the indoor mount and adjust
the viewing angle.
a
LED indication
Charging time
Charging: Steady blue
Fully charged：Off
12 hours
Charge eufyCam 2
CHARGING
EUFYCAM 2
5
5V / 2A
Method 1
Method 2
6
NOTICE
09 10
FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures: (1) Reorient or relocate
the receiving antenna. (2) Increase the separation between
the equipment and receiver. (3) Connect the equipment
into an outlet on a circuit different from that to which the
receiver is connected. (4) Consult the dealer or an
experienced radio/TV technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure
requirements. The device can be used in fixed/mobile
exposure condition. The min separation distance is 20cm.
11 12
Notice: Shielded cables
All connections to other computing devices must be made
using shielded cables to maintain compliance with FCC
regulations.
The following importer is the responsible party
Company Name: Fantasia Trading LLC
Address: 9155 Archibald Avenue, Suite 202, Rancho
Cucamonga, CA 91730, USA
Telephone:1-909-484-1530
This product complies with the radio interference
requirements of the European Community.
Declaration of Conformity
Hereby, Anker Innovations Limited declares that this device
is in compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU. For the
declaration of conformity, visit the Web site
www.eufylife.com
Do not use the Device in the environment at too high or
too low temperature, never expose the Device under
strong sunshine or too wet environment.
The suitable temperature for eufyCam 2C and accessories
is -20°C-50°C.
When charging, please place the device in an environment
that has a normal room temperature and good ventilation.
It is recommended to charge the device in an environment
with a temperature that ranges from 5°C~25°C.
RF exposure information: The Maximum Permissible
Exposure (MPE) level has been calculated based on a
distance of d=20 cm between the device and the human
body. To maintain compliance with RF exposure
requirement, use product that maintain a 20cm distance
between the device and human body.
CAUTION RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Wi-Fi Operating Frequency Range:2412~2472MHz ; Wi-Fi
Max Output Power:19dBm
SUB-1G Frequency range: 866~866.8MHz; SUB-1G
Output Power:12.4dBm
The following importer is the responsible party (contact
for EU matters only)
Importer: Anker Technology (UK) Ltd
Importer Address: Suite B, Fairgate House, 205 Kings Road,
Tyseley, Birmingham, B11 2AA, United Kingdom
This product is designed and manufactured with
high quality materials and components, which can be
recycled and reused.
This symbol means the product must not be
discarded as household waste, and should be delivered to
an appropriate collection facility for recycling. Proper
disposal and recycling helps protect natural resources,
human health and the environment. For more information
on disposal and recycling of this product, contact your local
municipality, disposal service, or the shop where you
bought this product.
IC Statement
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the
device."
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement."
This Class B digital apparatus complies with Canadian
ICES-003.
