Vizio XVT3D650SV 65-Inch Theater 3D Edge Lit Razor LED LCD User Manual

XVT3D650SV – USER MANUAL

65” THEATER 3D

LED LCD HDTV

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

This product qualies for ENERGY STAR in the “factory

default” setting and this is the setting in which power

savings will be achieved. Changing the factory default

picture settings or enabling other features will increase

power consumption that could exceed the limits necessary

to qualify for ENERGY STAR rating.

SRS TruSurround HD and SRS TruVolume are trademarks

of SRS Labs, Inc. TruSurround HD and TruVolume

technologies are incorporated under license from SRS

Labs, Inc.

HDMI, the HDMI logo and High-Denition Multimedia

Interface are trademarks or registered trademarks of HDMI

Licensing LLC.

Welcome!

Thank You for Choosing VIZIO

And congratulations on your new VIZIO HDTV.

To get the most out of your new VIZIO product, read these instructions before

using your product and retain them for future reference. Be sure to inspect the

package contents to ensure there are no missing or damaged parts.

Product Registration

To purchase or inquire about accessories and installation services for your VIZIO

product, visit our website at www.VIZIO.com or call toll free at 1-888-849-4623.

We recommend that you either:

r3FHJTUFSZPVS7*;*0QSPEVDUBUXXX7*;*0DPN

r$PNQMFUFUIFFODMPTFESFHJTUSBUJPODBSEBOENBJMJUUP

7*;*0

5FTMB

*SWJOF$"

Extended Warranties

For peace of mind, and to protect your investment beyond the standard warranty,

VIZIO offers on-site extended warranty service plans. These plans provide

additional coverage during the standard warranty period. To purchase an extended

warranty service plan, visit www.VIZIO.com.

When Reading this Manual

When you see this symbol, please read the accompanying important

warning or notice.

When you see this symbol, please read the accompanying helpful

tip.

My Product Information

Enter your product information here for easy reference:

.PEFM/VNCFS975%47

4FSJBM/VNCFS



%BUFPG1VSDIBTF



VIZIO recommends you attach your sales receipt to this manual for safekeeping.

"UUBDI4BMFT3FDFJQU)FSF

975%47

Important Safety Information for Viewing 3D Content

You may experience discomfort while watching 3D content. You

may feel symptoms of eye strain, vision fatigue, color or depth

distortion, motion sickness, nausea, dizziness, disorientation, or

other discomforts. If you experience any of these symptoms, stop

watching and take a break for at least thirty minutes before resuming.

If the symptoms are severe or continue even after you have stopped

watching 3D content, consult a doctor.

Take care to monitor children’s watching of 3D content. Children

(including teenagers) may be more at risk of experiencing discomfort

while watching 3D content and less likely to report symptoms. Monitor

children’s 3D content viewing and watch for signs of discomfort.

Some viewers may be susceptible to epileptic seizures or strokes

when viewing 3D images, even if those conditions have not been

previously diagnosed. If you or anyone in your family has a history

of seizures or strokes, or if you have any other reason to think you

or someone under your supervision may be susceptible to epileptic

seizures or strokes, consult a doctor before watching 3D content.

Even if you do not experience any of the above symptions, take

regular breaks from watching 3D content.

Important Safety Instructions

Your DTV is designed and manufactured to operate within deﬁned design limits.

Misuse may result in electric shock or ﬁre. To prevent your DTV from being

damaged, the following instructions should be observed for the installation,

use, and maintenance of your DTV. Read the following safety instructions before

operating your DTV. Keep these instructions in a safe place for future reference.

To reduce the risk of electric shock or component damage, switch off the power

before connecting other components to your HDTV.

r6OQMVHUIFQPXFSDPSECFGPSFDMFBOJOHZPVS)%57"EBNQDMPUIJT

TVGàDJFOUGPSDMFBOJOHZPVS)%57%POPUVTFBMJRVJEPSBTQSBZDMFBOFS

GPSDMFBOJOHZPVS)%57%POPUVTFBCSBTJWFDMFBOFST

r"MXBZTVTFUIFBDDFTTPSJFTSFDPNNFOEFECZUIFNBOVGBDUVSFSUP

JOTVSFDPNQBUJCJMJUZ

r8IFONPWJOHZPVS)%57GSPNBOBSFBPGMPXUFNQFSBUVSFUPBOBSFB

PGIJHIUFNQFSBUVSFDPOEFOTBUJPONBZGPSNJOUIFIPVTJOH8BJU

CFGPSFUVSOJOHPOZPVS)%57UPBWPJEDBVTJOHàSFFMFDUSJDTIPDLPS

DPNQPOFOUEBNBHF

r6TFPOMZXJUIUIFDBSUTUBOEUSJQPECSBDLFUPSUBCMFTQFDJàFECZ

NBOVGBDUVSFSPSTPMEXJUIZPVS)%578IFOBDBSUJTVTFEVTFDBVUJPO

XIFONPWJOHUIFDBSU)%57DPNCJOBUJPOUPBWPJEJOKVSZGSPNUJQPWFS

%POPUQMBDFZPVS)%57POBOVOTUBCMFDBSUTUBOEPSUBCMF*GZPVS

)%57GBMMTJUDBOJOKVSFBQFSTPOBOEDBVTFTFSJPVTEBNBHFUPZPVS

)%576TFPOMZBDBSUPSTUBOESFDPNNFOEFECZUIFNBOVGBDUVSFSPS

TPMEXJUIZPVS)%57

r"EJTUBODFPGBUMFBTUUISFFGFFUTIPVMECFNBJOUBJOFECFUXFFOZPVS

)%57BOEBOZIFBUTPVSDFTVDIBTBSBEJBUPSIFBUFSPWFOBNQMJàFS

FUD%POPUJOTUBMMZPVS)%57DMPTFUPTNPLF0QFSBUJOHZPVS)%57

DMPTFUPTNPLFPSNPJTUVSFNBZDBVTFàSFPSFMFDUSJDTIPDL

r4MPUTBOEPQFOJOHTJOUIFCBDLBOECPUUPNPGUIFDBCJOFUBSFQSPWJEFE

GPSWFOUJMBUJPO5PFOTVSFSFMJBCMFPQFSBUJPOPGZPVS)%57BOEUPQSPUFDU

JUGSPNPWFSIFBUJOHCFTVSFUIFTFPQFOJOHTBSFOPUCMPDLFEPSDPWFSFE

%POPUQMBDFZPVS)%57JOBCPPLDBTFPSDBCJOFUVOMFTTQSPQFS

WFOUJMBUJPOJTQSPWJEFE

r/FWFSQVTIBOZPCKFDUJOUPUIFTMPUTBOEPQFOJOHTPOZPVS)%57

DBCJOFU%POPUQMBDFBOZPCKFDUTPOUIFUPQPGZPVS)%57%PJOHTP

DPVMETIPSUDJSDVJUQBSUTDBVTJOHBàSFPSFMFDUSJDTIPDL/FWFSTQJMM

MJRVJETPOZPVS)%57

975%47

r:PVS)%57TIPVMECFPQFSBUFEPOMZGSPNUIFUZQFPGQPXFSTPVSDF

JOEJDBUFEPOUIFMBCFM*GZPVBSFOPUTVSFPGUIFUZQFPGQPXFSTVQQMJFE

UPZPVSIPNFDPOTVMUZPVSEFBMFSPSMPDBMQPXFSDPNQBOZ

r%POPUBQQMZQSFTTVSFPSUISPXPCKFDUTBUZPVS)%575IJTNBZ

DPNQSPNJTFUIFJOUFHSJUZPGUIFEJTQMBZ5IFNBOVGBDUVSFSTXBSSBOUZ

EPFTOPUDPWFSVTFSBCVTFPSJNQSPQFSJOTUBMMBUJPOT

r5IFQPXFSDPSENVTUCFSFQMBDFEXIFOVTJOHEJGGFSFOUWPMUBHFUIBOUIF

WPMUBHFTQFDJàFE'PSNPSFJOGPSNBUJPODPOUBDUZPVSEFBMFS

r:PVS)%57JTFRVJQQFEXJUIBUISFFQSPOHFEHSPVOEFEQMVHBQMVH

XJUIBUIJSEHSPVOEJOHQJO5IJTQMVHXJMMàUPOMZJOUPBHSPVOEFEQPXFS

PVUMFU5IJTJTBTBGFUZGFBUVSF*GZPVSPVUMFUEPFTOPUBDDPNNPEBUFUIF

UISFFQSPOHFEIBWFBOFMFDUSJDJBOJOTUBMMUIFDPSSFDUPVUMFUPSVTFBO

BEBQUFSUPHSPVOEZPVS)%57TBGFMZ%POPUEFGFBUUIFTBGFUZQVSQPTF

PGUIFHSPVOEFEQMVH

r8IFODPOOFDUFEUPBQPXFSPVUMFUQPXFSJTBMXBZTáPXJOHJOUPZPVS

)%575PUPUBMMZEJTDPOOFDUQPXFSVOQMVHUIFQPXFSDPSE

r5IFMJHIUOJOHáBTIXJUIBSSPXIFBETZNCPMXJUIJOBOFRVJMBUFSBMUSJBOHMF

JTJOUFOEFEUPBMFSUUIFVTFSUPUIFQSFTFODFPGVOJTPMBUFEEBOHFSPVT

WPMUBHFXJUIJOUIFJOTJEFPGZPVS)%57UIBUNBZCFPGTVGàDJFOU

NBHOJUVEFUPDPOTUJUVUFBSJTLPGFMFDUSJDTIPDLUPQFSTPOT

r%POPUPWFSMPBEQPXFSTUSJQTBOEFYUFOTJPODPSET0WFSMPBEJOHDBO

SFTVMUJOàSFPSFMFDUSJDTIPDL

r5IFXBMMTPDLFUTIPVMECFJOTUBMMFEOFBSZPVS)%57BOEFBTJMZ

BDDFTTJCMF

r0OMZQPXFSPGUIFNBSLFEWPMUBHFDBOCFVTFEGPSZPVS)%57"OZ

PUIFSWPMUBHFUIBOUIFTQFDJàFEWPMUBHFNBZDBVTFàSFPSFMFDUSJD

TIPDL

r%POPUUPVDIUIFQPXFSDPSEEVSJOHMJHIUOJOH5PBWPJEFMFDUSJDTIPDL

BWPJEIBOEMJOHUIFQPXFSDPSEEVSJOHFMFDUSJDBMTUPSNT

r6OQMVHZPVS)%57EVSJOHBMJHIUOJOHTUPSNPSXIFOJUXJMMOPUCFVTFE

GPSMPOHQFSJPEPGUJNF5IJTXJMMQSPUFDUZPVS)%57GSPNEBNBHFEVFUP

QPXFSTVSHFT

r%POPUBUUFNQUUPSFQBJSPSTFSWJDFZPVS)%57ZPVSTFMG0QFOJOHPS

SFNPWJOHUIFCBDLDPWFSNBZFYQPTFZPVUPIJHIWPMUBHFTFMFDUSJD

TIPDLBOEPUIFSIB[BSET*GSFQBJSJTSFRVJSFEDPOUBDUZPVSEFBMFSBOE

SFGFSBMMTFSWJDJOHUPRVBMJàFETFSWJDFQFSTPOOFM

r,FFQZPVS)%57BXBZGSPNNPJTUVSF%POPUFYQPTFZPVS)%57UPSBJO

PSNPJTUVSF*GXBUFSQFOFUSBUFTJOUPZPVS)%57VOQMVHUIFQPXFSDPSE

BOEDPOUBDUZPVSEFBMFS$POUJOVPVTVTFJOUIJTDBTFNBZSFTVMUJOàSF

PSFMFDUSJDTIPDL

r%POPUVTFZPVS)%57JGBOZBCOPSNBMJUZPDDVST*GBOZTNPLFPSPEPS

CFDPNFTBQQBSFOUVOQMVHUIFQPXFSDPSEBOEDPOUBDUZPVSEFBMFS

JNNFEJBUFMZ%POPUUSZUPSFQBJSZPVS)%57ZPVSTFMG

r"WPJEVTJOHESPQQFEPSEBNBHFEBQQMJBODFT*GZPVS)%57JTESPQQFE

BOEUIFIPVTJOHJTEBNBHFEUIFJOUFSOBMDPNQPOFOUTNBZGVODUJPO

BCOPSNBMMZ6OQMVHUIFQPXFSDPSEJNNFEJBUFMZBOEDPOUBDUZPVS

EFBMFSGPSSFQBJS$POUJOVFEVTFPGZPVS)%57NBZDBVTFàSFPSFMFDUSJD

TIPDL

r%POPUJOTUBMMZPVS)%57JOBOBSFBXJUIIFBWZEVTUPSIJHIIVNJEJUZ

0QFSBUJOHZPVS)%57JOFOWJSPONFOUTXJUIIFBWZEVTUPSIJHIIVNJEJUZ

NBZDBVTFàSFPSFMFDUSJDTIPDL

r'PMMPXJOTUSVDUJPOTGPSNPWJOHZPVS)%57&OTVSFUIBUUIFQPXFSDPSE

BOEBOZPUIFSDBCMFTBSFVOQMVHHFECFGPSFNPWJOHZPVS)%57

r8IFOVOQMVHHJOHZPVS)%57IPMEUIF"$%$QPXFSBEBQUFSOPUUIF

DPSE1VMMJOHPOUIFQPXFSDPSENBZEBNBHFUIFXJSFTJOTJEFUIFDPSE

BOEDBVTFàSFPSFMFDUSJDTIPDL8IFOZPVS)%57XJMMOPUCFVTFEGPS

BOFYUFOEFEQFSJPEPGUJNFVOQMVHUIFQPXFSDPSE

r5PSFEVDFSJTLPGFMFDUSJDTIPDLEPOPUUPVDIUIFDPOOFDUPSXJUIXFU

IBOET

r*OTFSUCBUUFSJFTJOBDDPSEBODFXJUIJOTUSVDUJPOT*ODPSSFDUQPMBSJUJFTNBZ

DBVTFUIFCBUUFSJFTUPMFBLXIJDIDBOEBNBHFUIFSFNPUFDPOUSPMPS

JOKVSFUIFPQFSBUPS

r*GBOZPGUIFGPMMPXJOHPDDVSTDPOUBDUUIFEFBMFS

5IFQPXFSDPSEGBJMTPSGSBZT

-JRVJETQSBZTPSBOZPCKFDUESPQTJOUPZPVS)%57

:PVS)%57JTFYQPTFEUPSBJOPSPUIFSNPJTUVSF

:PVS)%57JTESPQQFEPSEBNBHFEJOBOZXBZ

5IFQFSGPSNBODFPGZPVS)%57DIBOHFTTVCTUBOUJBMMZ

975%47

Television Antenna Connection Protection

If an outside antenna/satellite dish or cable system is to be connected to the TV,

make sure that the antenna or cable system is electrically grounded to provide

some protection against voltage surges and static charges.

Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information

with regard to proper grounding of the mast and supporting structure, grounding

of the lead-in wire to an antenna discharge unit, size of the grounding conductors,

location of antenna discharge unit, connection to grounding electrodes, and

requirements of the grounding electrode.

Lightning Protection

For added protection of the TV during a lightning storm or when it is left

unattended or unused for long periods of time, unplug the TV from the wall outlet

and disconnect the antenna or cable system.

Power Lines

Do not locate the antenna near overhead light or power circuits, or where it could

fall into such power lines or circuits. Remember, the screen of the coaxial cable is

intended to be connected to earth in the building installation.

DTV Transition Advisory

The nationwide switch to digital television broadcasting was complete on June

12, 2009. Analog-only television sets that receive TV programming through an

antenna now need a converter box to continue to receive over-the-air TV. Watch

your local stations to ﬁnd out when they will turn off their analog signal and switch

to digital-only broadcasting. Analog-only TVs should continue to work as before

to receive low power, Class A or translator television stations and with cable and

satellite TV services, gaming consoles, VCRs, DVD players, and similar products.

For additional information, please contact the parties listed below, as appropriate:

FCC (US Federal Communications Commission)

Web: www.fcc.gov

Phone: 1-888-CALL-FCC (1-888-225-5322)

TTY: 1-888-TELL-FCC (1-888-835-5322)

Fax: 1-866-418-0232

E-mail: fccin[email protected]ov

NTIA (National Telecommunications and Information Administration)

Web: www.ntia.doc.gov

Phone: 1-888-DTV-2009 (1-888-388-2009)

List of US Television Stations: www.high-techproductions.com/usTVstations.htm

Your TV comes with a built-in tuner capable of processing digital

broadcasts. No extra converter box is needed.

Table of Contents

Installing the TV .......................................................................1

Inspecting the Package Contents ........................................................... 1

Installing the TV Stand ............................................................................ 2

Installing the TV on a Wall ....................................................................... 3

Watching 3D at the Best Distance and Angle ......................................... 4

Incorrect 3D Viewing Distance and Angle............................................ 4

Correct 3D Viewing Distance and Angle .............................................. 4

Controls & Connections ............................................................5

Front Panel .............................................................................................. 5

Using the Jag Wheel ............................................................................... 5

Using the Quick Menu ......................................................................... 5

Rear Panel ............................................................................................... 6

Bluetooth Remote ................................................................................... 7

Replacing the Batteries ........................................................................ 8

Activating the Bluetooth Remote Control ............................................ 8

Using the Remote for Your Other Devices ........................................... 8

Completing the First-Time Setup ..............................................9

Connecting Your Devices to the TV ........................................... 11

Before You Begin .................................................................................... 11

HDMI .................................................................................................... 11

Component .......................................................................................... 11

RGB ..................................................................................................... 11

RF/Antenna .......................................................................................... 11

Choosing the Correct Connection .......................................................... 11

BEST .................................................................................................... 11

BETTER ................................................................................................ 11

Connecting Your Devices ........................................................................ 12

Setting Up Your Network Connection ..................................................... 13

Connecting to A Wired Network .......................................................... 13

Connecting to a Wireless Network ...................................................... 13

Adjusting the TV Settings ......................................................... 15

Changing the Input Source ..................................................................... 15

Adjusting the Picture Settings ................................................................. 15

Adjusting the Advanced Picture Settings ............................................ 16

Adjusting the Color Temperature ......................................................... 17

Adjusting the Picture Size and Position ............................................... 17

Resetting the Picture Settings ............................................................ 17

Adjusting the Audio Settings ................................................................... 18

Adjusting the Advanced Audio Settings .............................................. 18

Resetting the Audio Settings ............................................................... 19

Adjusting the Tuner Settings ................................................................... 19

Setting the Tuner Mode ....................................................................... 19

Scanning for Channels ......................................................................... 19

Adding New Channels ......................................................................... 19

Skipping Channels ............................................................................... 20

Changing the Audio Language ............................................................ 21

Changing the Names of the Inputs ...................................................... 21

Activating Game Mode ........................................................................... 22

Using the Parental Controls .................................................................... 22

Accessing the Parental Controls Menu ................................................ 22

Enabling or Disabling Program Ratings ............................................... 22

Locking and Unlocking Channels ........................................................ 22

Blocking and Unblocking Content by Rating ....................................... 22

Changing the Parental Control Passcode ............................................ 23

Resetting the Content Locks ............................................................... 23

Changing the On-Screen Menu Language ............................................. 23

Setting the Time Zone ............................................................................. 24

Using the Other TV Settings .....................................................25

Changing the 3D Mode ........................................................................... 25

Changing the Screen Aspect Ratio ......................................................... 25

Setting Up Closed Captioning ................................................................ 26

XVT3D650SV

Changing the Appearance of Digital Closed Captions ........................ 26

Using the Sleep Timer .......................................................................... 27

Using Picture-In-Picture (PIP) / Picture-Outside-Picture (POP) .............. 27

Choosing Inputs for the Main and Secondary Windows ..................... 27

TV ......................................................................................................... 27

Composite AV ...................................................................................... 27

Component .......................................................................................... 27

HDMI .................................................................................................... 27

RGB ..................................................................................................... 27

Using the Network Connection Menu ..................................................... 28

Connecting to a Wireless Network ...................................................... 28

Changing the Advanced Network Settings .......................................... 29

Testing Your Network Connection ....................................................... 29

Setting Up a Bluetooth Device ................................................................ 29

Using the Help Menu .............................................................................. 30

Displaying System Information ............................................................ 30

Resetting the TV Settings .................................................................... 30

Restoring the TV to Factory Default Settings ...................................... 30

Using Guided Setup ............................................................................. 31

Using the Digital Episode Guide ............................................................. 32

Using the Info Window ......................................................................... 32

Using VIZIO Internet Apps ......................................................... 33

Using the VIA Shortcut Buttons .............................................................. 33

Using the VIA Dock ................................................................................. 33

Moving an App on the VIA Dock .......................................................... 33

Adding a New App to the VIA Dock ..................................................... 34

Removing an App from the VIA Dock .................................................. 34

Creating and Managing User Proles ..................................................... 34

Creating an Owner PIN ........................................................................ 34

Creating a New User Prole ................................................................. 35

Removing a User Prole ...................................................................... 35

Restoring the VIA Dock to the Factory Default Settings ......................... 36

Viewing Theater 3D ..................................................................37

How Theater 3D Works ........................................................................... 37

What You Need to View 3D Content ....................................................... 37

Watching Blu-ray 3D Content ................................................................. 37

Watching SBS, TB, or Sensio 3D Content .............................................. 38

Troubleshooting & Technical Support........................................39

The TV displays “No Signal.” ............................................................... 39

There is no power. ................................................................................ 39

There is no sound. ............................................................................... 39

The power is on, but there is no image on the screen. ........................ 39

The colors on the TV don’t look right. .................................................. 39

The buttons on the remote aren’t working. .......................................... 39

The image quality is not good. ............................................................. 39

The picture is distorted. ....................................................................... 39

The display image does not cover the entire screen. .......................... 40

The TV has pixels (dots) that are always dark or always lit. ................ 40

I see “noise” or static on the screen. ................................................... 40

When I change input source, the volume changes. ............................. 40

When I change input source, the display image changes size. ........... 40

Speciﬁcations ..........................................................................41

Warranty Information ............................................................... 43

ON PARTS AND LABOR ......................................................................... 43

Parts and Labor ................................................................................... 43

Type of Service .................................................................................... 43

Limitations and Exclusions .................................................................. 43

Personal Data ...................................................................................... 43

Zero Bright Pixel Defect Guarantee ..................................................... 43

Legal & Compliance ................................................................. 45

Installing the TV

Inspecting the Package Contents

Before installing your new TV, take a moment to inspect the package contents.

Use the images below to ensure nothing is missing or damaged.

When you have completed your inspection, install the TV.

VIZIO 65” Theater 3D HDTV with Stand

Bluetooth

Remote Control

with Batteries

Power Cord Cleaning ClothUser Guide and

Quick Start Guide

Safety Cable

XVT3D424SV / XVT 3D474SV / XVT3D5 54SV

QUICK START GUIDE

XVT3D424SV / XVT3D474S V / XVT3D554SV

QUICK START GUIDE

Basic Theater 3D Glasses (2)

Premium Theater 3D Glasses (2)

Package Contents

XVT3D650SV

After removing the TV from the box and inspecting the package contents you can

begin installing the TV. Your TV can be installed in two ways:

 6UHÅH[Z\YMHJL\ZPUN[OLPUJS\KLKZ[HUK

 6UH^HSS\ZPUNH=,:(Z[HUKHYK^HSSTV\U[UV[PUJS\KLK

Installing the TV Stand

Your TV includes a stand designed to support the weight of the TV and keep it

from falling over. However, the TV can still fall over if:

 0[PZWSHJLKVUHU\UL]LU\UZ[HISLVYUVUSL]LSZ\YMHJL

 0[PZW\ZOLKW\SSLKVYV[OLY^PZLPTWYVWLYS`TV]LK

 0MHULHY[OX\HRLVJJ\YZHUK[OL;=PZUV[WYVWLYS`ZLJ\YLK

Your TV comes in the box with the base already attached. Only use

the following instructions if you need to reattach the base.

To install the TV stand:

1. Place the TV screen-down on a clean,

ﬂat surface. To prevent scratches or

damage to the screen, place the TV on

a soft surface, such as carpet, rug, or

blanket.

2. Slide the base plate into the slot on

the stand, making sure the arrow on

the stand base plate points toward the

front of the TV.

If your stand has a wing screw on the

bottom, tighten it securely.

3. Using a philips-head screwdriver, insert

the four screws into the four holes in

the stand as shown.

4. Move the TV with attached stand into

an upright position and place on a ﬂat,

level, and stable surface.

5. To help prevent the TV from falling

over, attach one end of the included

safety cable to the wall behind the

TV. Attach the other end to one of the

wall-mounting holes on the back of the

TV.

6. To ensure proper ventilation, leave 1”

of space between the back of the TV

and any other objects (walls, etc).

XVT3D650SV

4. Pull the stand away from the TV.

5. Attach your TV and wall mount

to the wall, carefully following the

instructions that came with the mount.

Installing the TV on a Wall

To mount your TV on a wall, you will need a wall mount. Consult the information

below to ﬁnd the appropriate mount for your TV model:

Screw size: M8

Screw length: 18mm

Screw pitch: 1.25mm

Hole pattern: 400(V) x 600(H)mm (VESA standard)

Installing a TV on a wall requires lifting. To prevent injury or damage

to the TV, ask someone to help you.

Be sure the mount you choose is capable of supporting the weight of the TV. After

you have determined that you have the correct mount for your TV, you can begin

the installation.

To install your TV on a wall:

1. Disconnect any cables connected to

your TV.

2. Place the TV face-down on a clean,

ﬂat, stable surface. Be sure the surface

is clear of debris that can scratch or

damage the TV.

3. Using a philips-head screwdriver,

remove the screws holding the stand

to the TV.

XVT3D650SV

Watching 3D at the Best Distance and Angle

For the best viewing experience, VIZIO recommends that you install the TV with

the viewing distance and vertical viewing angle in mind. When viewing 3D

content, it is important that you view the TV at an optimal angle, or some of the

3D effect may be lost.

For your TV, VIZIO recommends:

Viewing Distance: 10

feet

Vertical Viewing Angle:

25° (from center)

Illustrations in this section are not drawn to scale. They are for

instructional purposes only.

Incorrect 3D Viewing Distance and Angle

In the example below, two of the viewers are sitting too close to the TV for a good

3D effect. In addition, the child on the ﬂoor is not seeing the best possible picture

because his/her eyes are not inside the viewing angle.

The viewers in the example below are not seeing the best 3D picture.

Too Close - Losing 3D Effects

10’

Eye Line

Correct 3D Viewing Distance and Angle

In the examples below, all of the viewers are experiencing the best possible 3D

picture quality.

Best 3D - TV on Stand

10’

Eye Line

In this example, the viewers are sitting at a good distance. Their eyes are all

close to the ideal eye line. They will experience good 3D quality.

Best 3D - Tilt Mounted

10’

Eye Line

In this example, the viewers have mounted the TV on a VIZIO Tilt Mount so

that they can sit closer to the TV. They are at the correct distance and they are

viewing at a good angle. They will experience the best 3D picture quality.

Before the ﬁrst-time setup, take a few moments to familiarize yourself with the

various controls and connections. This will make the setup process much faster

and your experience with the TV much more enjoyable!

Front Panel

Remote Control Sensor: Point the remote directly at this sensor when

using it in IR mode.

VIZIO Light: When the TV is on, the light is white.

When the TV is off, the light is orange.

After you set up the remote to work in Bluetooth mode, you do not

have to point it at the Remote Control Sensor to use it. See

Activating

the Bluetooth Remote Control

on page 8.

Using the Jag Wheel

The Jag Wheel is an innovative, all-in-one control on the side of your HDTV that

performs functions you might see as buttons on other TVs. Functions including

volume up/down, power, input source, and channel up/down have been combined

into a single Quick Menu controlled by the Jag Wheel.

Jag Wheel

To power the TV on or off:

 7YLZZ[OL1HN>OLLS VUJL[V[\YU[OL;=VU

 7YLZZHUKOVSK[OL1HN>OLLSMVY[OYLLZLJVUKZ[V[\YU[OL;=VMM

To increase or decrease the volume, turn the Jag Wheel.

Using the Quick Menu

To open the Quick Menu, press the Jag Wheel. Turn the Jag Wheel to highlight a

function. Press the Jag Wheel to select the highlighted function.

Volume: Select to increase or

decrease volume.

Channel: Open the channel list and

select a channel.

Input Source: Change the input

device.

Exit: Close the Quick Menu.

Power Off: Turn the TV off.

The Quick Menu closes automatically after

10 seconds if no activity is detected.

Jag Wheel

VIZIO Light

Controls & Connections

Remote Control

Sensor

XVT3D650SV

Rear Panel Detail

Rear Panel

USB (1, 2, 3): For service technician use only.

HDMI (1, 2, 3, 4, 5): Connect external device (Blu-Ray/DVD player,

game console, etc).

Optical: Connect to audio device (VIZIO sound bar, home

theater system).

Audio Out (R, L): Connect RCA audio device.

Ethernet: Connect an ethernet cable to access a network or

the Internet.

Audio: Connect 1/8” mini stereo connector from com-

puter.

RGB PC: Connect RGB cable from computer.

Component: Connect component video/audio devices.

Cable/Antenna: Connect coaxial cable for external antenna or

cable TV.

DC IN: Connect the included Power Cable here. Connect

the other end to an electrical outlet.

USB

BEST

HDMI

CABLE / ANTENN A

DTV / TV

RGB PC

COMPONENT (BETTER)

RGB PC

ETHERNET

Rear Panel

USB

HDMI

Optical

Audio Out

Audio

Ethernet RGB PC Component Cable/Antenna

DC IN

XVT3D650SV

Bluetooth

Remote

Device Power/Standby

Input

A/V Controls

List

Exit

Back

VIA

Volume Up/Down

Mute

Number Pad

Last

Channel Up/Down

VIA Shortcuts

Guide

Arrow

Info

Power/Standby

QUERTY KeypadArrow

Move/Delete App from VIA Dock

Change Screen Size

(when VIA Sidebar is open)

View Settings for Active VIA App

Exit App/Exit VIA Dock

VIA Shortcuts

Bluetooth Remote

Power/Standby: Turn the TV on or off.

Info: Display the Info Window. See

Using the Digital

Episode Guide

on page 32.

Arrow: Navigate the on-screen menu and episode guide.

OK: Select highlighted menu option.

Menu: Display the on-screen menu. See

Adjusting the TV

Settings

on page 15.

Exit: Close the on-screen menu.

Back: Go to the previous on-screen menu options.

Guide: Display the episode guide (digital channels only).

See

Using the Digital Episode Guide

on page

32.

Mute: Turn the sound off or on. When mute is activated,

the TV’s audio is turned off.

Last: Return to the channel last viewed.

Volume Up/Down: Increase or decrease the loudness of the TV’s

audio.

Channel Up/Down: Change the channel. With each press of the but-

ton, the channel will increase or decrease by one.

Number Pad: Use the number pad to manually enter a channel.

Input: Change the input device. With each press of the

button, the TV will display a different input.

A/V Controls: Control external device (Blu-Ray or DVD player).

List: Display list of available channels.

VIA Shortcuts: Control VIZIO Internet Apps.

3D: Switch between 3D display modes.

QUERTY Keypad: Enter letters or numbers.

Device Power/Standby: Turn external device on or off.

VIA: Start VIA Internet Apps. See

Using VIZIO Internet

Apps

on page 33.

XVT3D650SV

Replacing the Batteries

1. Remove the battery cover.

2. Insert two AA batteries into the remote

control. Make sure that the (+) and (-)

symbols on the batteries match the

(+) and (-) symbols inside the battery

compartment.

3. Replace the battery cover.

Ki[edboW]eeZgkWb_joXWjj[ho$

?di[hj_d]j^[XWjj[ho_dYehh[YjbocWoh[ikbj_dYhWYa_d]ehb[WaW][

that may cause a ﬁre or result in injury.

:_ifei[e\ebZehZ[WZXWjj[h_[i_dWYYehZWdY[m_j^beYWb^WpWhZeki

waste regulations.

A[[fXWjj[h_[iWmWo\hecY^_bZh[dWdZf[ji$

Activating the Bluetooth Remote Control

OekhJL_dYbkZ[iWh[cej[Yedjhebj^WjZe[idejh[gk_h[WZ_h[Yjb_d[e\i_]^jje

the TV. Because the remote uses Bluetooth to transmit your commands, as long

as you are within range of the TV (30 feet), the remote will work even if it is not

pointed at the TV.

However, until you activate the Bluetooth remote control, the remote will only

work when pointed directly at the TV (30 foot range) with no intervening obstacles.

If you have already activated the remote in the ﬁrst-time setup using

the Setup App, then you do not have to activate the remote again.

To activate the Bluetooth remote control:

1. Press the MENU button on the remote.

2. Select Bluetooth and press OK.

3. Select Pair Device and press OK.

4. Press and hold the Record and Green VIA Shortcut buttons for 5

seconds.

5. Select Start searching for devices and press OK. The TV begins to search

for the remote.

6. When the remote is found, the TV displays a success message.

Using the Remote for Your Other Devices

The included remote can be used as a universal remote to control your other

devices.

See

Ki_d]=k_Z[ZI[jkf

on page 31 to set up the remote for use with your

other devices.

J^[h[cej[Yedjhebi^ekbZX[a[fjZhoWdZWmWo\hec^[WjiekhY[i$

7le_Z^kc_Z_jo$

?\j^[:JLh[ifedZi[hhWj_YWbbojej^[h[cej[YedjhebehZe[idej

respond at all, the battery may need to be replaced.

M^[dijeh_d]j^[h[cej[Yedjheb"h[cel[j^[XWjj[h_[i$

:edejjWa[XWjj[h_[iWfWhj"^[Wjj^[c"ehj^hemj^[c_djeWÓh[$

:edejijh_a["j^hem"ehZhefj^[h[cej[Yedjheb$

:edejWjj[cfjjeYb[Wdj^[h[cej[Yedjhebm_j^WlebWj_b[iebl[dj$

JeYb[Wdj^[h[cej["m_f[_jm_j^WYb[Wd"ZWcfYbej^$

The ﬁrst time you turn on the TV, the Setup App will guide you through each of the

steps necessary to get your TV ready for use.

Before you begin the ﬁrst-time setup:

 @V\Y;=ZOV\SKILPUZ[HSSLKHUK[OLWV^LYJVYKZOV\SKILJVUULJ[LK

[VHULSLJ[YPJHSV\[SL[:LL

0UZ[HSSPUN[OL;=

VUWHNL

 @V\YKL]PJLZZOV\SKILJVUULJ[LK:LL

*VU[YVSZ*VUULJ[PVUZVU

WHNL



 0M`V\OH]LH^PYLSLZZUL[^VYROH]L[OLUL[^VYRRL`YLHK`

 0M`V\HYLJVUULJ[PUN[V`V\YUL[^VYR^P[OHUL[OLYUL[JHISLJVUULJ[

P[[V[OLL[OLYUL[WVY[VU[OL;=:LL

:L[[PUN<W@V\Y5L[^VYR

*VUULJ[PVU

VUWHNL

To complete the ﬁrst-time setup:

1. Press the Power/Standby button on

the remote. The TV powers on and the

Setup App starts.

2. Use the Up/Down Arrow buttons on

the remote to highlight Home Mode

Setup and press OK.

3. Activate the remote by pressing

Record and the Green VIA Shortcut

button for 5 seconds, then highlight

Begin Activation and press OK.

Wait for the remote to be found.

4. When the remote is found, use the

Arrow Up/Down buttons on the

remote to highlight Connect to the

Internet and press OK.

5. Use the OK and Arrow Up/Down

buttons on the remote to read and

accept the Terms of Service and

When you are ﬁnished, highlight Next

and press OK.

6. Select the name of your wireless

network from the list of available

networks and press OK.

Enter the network key using the

QUERTY Keypad on the remote, then

highlight Connect and press OK.

If the TV is connected to your network via an ethernet cable, you will

not see this screen.

If you are not connecting your TV to your network, you can skip this

step. Highlight Skip and press OK.

7. Enter your First Name, Last Name,

Phone Number, ZIP Code, and E-mail

Address using the QUERTY Keypad on

the remote.

Highlight Next and press OK.

Completing the First-Time Setup

XVT3D650SV

8. Choose the input to which your TV

signal is connected.

Answer the on-screen questions about

your TV connection using the Arrow

and OK buttons on the remote.

9. Choose the device you would like to

connect.

Answer the on-screen questions about

your TV connection using the Arrow

and OK buttons on the remote.

10. When you have ﬁnished adding devices, highlight Exit to Live TV and

press OK.

The First-Time Setup is complete.

Your 3D HDTV can be easily connected to an external device:

r%7%PS#MV3BZQMBZFS

r7JEFPHBNFDPOTPMF

r$BCMFCPY

r&YUFSOBMBOUFOOB

r0SPUIFSEFWJDF

Before You Begin

To connect an external device to the 3D HDTV:

1. Verify that the external device has one of the following types of video ports

available:

3FRVJSFE%FWJDF1PSUT

HDMI 3(#

3'"OUFOOB$PNQPOFOU

2. Ensure the TV has a matching available port.

3. Ensure you have a cable that matches the available port. For example, if

you are connecting a Blu-ray player with an HDMI port, be sure you have

an HDMI cable.

Choosing the Correct Connection

Use the table below to choose the connection with the highest possible picture

quality. Use a digital connection when possible.

1JDUVSF2VBMJUZ$POOFDUPS*NBHF$POOFDUPS/BNF%JHJUBM"OBMPH

BEST

HDMI Digital

RGB Digital

RF/Coaxial Digital

BETTER

RF/Coaxial Analog

Component Analog

Connecting Your Devices to the TV

XVT3D650SV

Connecting Your Devices

Once you have determined the best available connection type on both your

device and the TV, ensure you have the corresponding cable.

To connect a device to the TV:

1. Ensure both the TV and your device are off.

2. Connect the device and the TV. Use the best available connection.

See

Choosing the Correct Connection

on page 11 and the Device

Connection Chart at right.

Ensure each end of the cable is securely connected.

3. Turn the TV on by pressing the Power/Standby button on the remote.

4. Turn your device on.

5. When you are ready to use your newly connected device, press the INPUT

button on the remote and select the connection type (HDMI, RGB, etc) from

the on-screen menu. Press OK.

6. Check the list of devices/connection types below for special instructions:

Cable TV (without cable box/directly from wall)

Perform a channel scan. See

Scanning for Channels

on page 19.

RGB

Make sure the desktop resolution on the PC is set to 1920 x 1080. Set the

Screen Mode to Normal. See .

DVD Player with DVI

Connect left (white) and right (red) audio cables to the L and R ports next to

the HDMI ports on the TV.

%FWJDF$POOFDUJPO$IBSU

XVT3D650SV

Setting Up Your Network Connection

Your TV is internet-ready, and can be connected to your home network in two

ways:

r8JSFEVTJOHUIF3+FUIFSOFUDPOOFDUPSPOUIFCBDLQBOFM

r8JSFMFTTMZVTJOHZPVSIPNFXJSFMFTTOFUXPSL

Once you have connected to your home network and the Internet, you can use

VIA apps to deliver popular online content to your TV.

Connecting to A Wired Network

To connect to a wired network:

1. Ensure you have:

r"OFUIFSOFUDBCMFMPOHFOPVHIUPSFBDIZPVS57

r"SPVUFSPSNPEFNXJUIBOBWBJMBCMFFUIFSOFUQPSU

r"IJHITQFFEJOUFSOFUDPOOFDUJPO

2. Connect your ethernet cable to the router and to the ethernet port on the

back of the TV.

3. Use the Guided Network Setup to conﬁgure the TV. See

Using Guided

Setup

on page 31.

Connecting to a Wireless Network

To connect to a wireless network:

1. Ensure you have:

r"SPVUFSCSPBEDBTUJOHBIJHITQFFEXJSFMFTTTJHOBMXJSFMFTTO

SFDPNNFOEFE

r"IJHITQFFEJOUFSOFUDPOOFDUJPO

2. Use the Guided Network Setup to conﬁgure the TV. See

Using Guided

Setup

on page 31.



XVT3D650SV

From the TV Settings Menu, you can:

Change the input source

Adjust the picture settings

Adjust the audio settings

Adjust the tuner settings

Name device inputs

Activate Game Mode

Set the parental controls

Change the on-screen menu language

Set the time

Changing the Input Source

External devices such as DVD players, Blu-Ray Players, and video game consoles

can be connected to your TV. To use one of these devices with your TV, you must

ﬁrst change the input source in the on-screen menu.

For instructions on connecting external

devices, see

Connecting Your Devices to

the TV

on page 11.

To change the input device:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Up/Down Arrow buttons on

the remote to highlight the input source

and press OK. The Input Source

Selection menu is displayed.

4. Use the Up/Down Arrow buttons on

the remote to highlight the input source

you wish to display. Press OK, then

press EXIT.

Adjusting the Picture Settings

Your TV display can be adjusted to suit your preferences and viewing conditions.

To adjust the picture settings:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Up/Down Arrow buttons on

the remote to highlight Picture and

press OK. The Picture Settings menu

is displayed.

4. Use the Arrow buttons on the remote

to highlight Picture Mode, then use

the Left/Right Arrow buttons to

change the picture mode:

t4UBOEBSENPEF sets the various

picture settings to values that

will produce the best picture

in the most cases. This is the

recommended setting.

r.PWJFNPEF sets the picture settings to values perfect for watching a

movie in a dark room.

t(BNFNPEF optimizes the picture settings for displaying game

console output.

r7JWJENPEF sets the picture settings to values that produce a brighter,

more vivid picture.

t'PPUCBMM, (PMG, #BTLFUCBMM, and #BTFCBMM modes optimize the picture

settings for their respective sports. Also try these modes for other

sports.

r$VTUPN picture mode allows you to manually change each of the

picture settings:

Backlight - Adjusts the LED brightness to affect the overall

brilliance of the picture. This option is not available unless Ambient

Adjusting the TV Settings

XVT3D650SV

Light Sensor is set to OFF. See

Adjusting the Advanced Picture

Settings

on page 16.

Brightness - Adjusts the black level of the picture. When this

setting is too low, the picture may be too dark to distinguish details.

When this setting is too high, the picture may appear faded or

washed out.

Contrast - Adjusts the white level of the picture. When this setting

is too high, the picture may appear dark. When this setting is too

low, the picture may appear faded or washed out. If the setting is

too high or too low, detail may be difﬁcult to distinguish in dark or

bright areas of the picture.

Color - Adjusts the intensity of the picture colors.

Tint - Adjusts the hue of the picture. This setting is useful in

adjusting the ﬂesh tones in the picture. If ﬂesh appears too orange,

reduce the level of color before adjusting tint.

Sharpness - Adjusts the edge sharpness of picture elements. It can

be used to sharpen non-HD (high deﬁnition) content; however, it will

not produce detail that does not otherwise exist.

"EKVTUJOHUIF"EWBODFE1JDUVSF4FUUJOHT

To adjust the advanced picture settings:

1. From the Picture Settings menu, use

the Arrow buttons on the remote to

highlight More, then press OK.

2. Use the Arrow buttons on the remote

to highlight Advanced Picture, then

press OK. The Advanced Picture menu

is displayed.

3. Use the Arrow buttons to highlight

the setting you wish to adjust, then

press Left/Right Arrow to change the

setting:

r

r4NPPUI.PUJPO&GGFDU - Activates Smooth Motion™ motion

estimation/motion compensation, which suppresses motion judder,

or “stuttering” of the image when the camera moves across a scene

horizontally. Select Off, Low, Middle, or High.

r3FBM$JOFNB.PEF - Allows selection of the type of compensation

used for the Smooth Motion™ effect. Select Off, Precision or Smooth.

t/PJTF3FEVDUJPO - Diminishes artifacts in the image caused by the

digitizing of image motion content. Select Off, Low, Medium, or High.

r$PMPS&OIBODFNFOU - Reduces oversaturation of some colors and

improves esh tones. Select Off, Normal, Rich Color, Green/Flesh, and

Green/Blue.

t"EBQUJWF-VNB - Adjusts the average brightness of the picture to

compensate for large areas of brightness. Select Off, Low, Medium,

Strong, or Extend.

t'JMN.PEF - Optimizes the picture for watching lm. Select Auto or Off.

t4NBSU%JNNJOH - Improves the contrast ratio of the screen by

adjusting the backlight intelligently. Select Off or On.

t"NCJFOU-JHIU4FOTPS - Detects the light levels in the room to optimize

the brightness of the TV’s backlight. Select Low, Middle, High, or Off.

When the Ambient Light Sensor is on, you will be unable to manually

adjust the backlight.

4. When you have ﬁnished adjusting the Advanced Picture Settings, press the

EXIT button on the remote.

XVT3D650SV

"EKVTUJOHUIF$PMPS5FNQFSBUVSF

Adjusting the color temperature will change the “warmness” or “coolness” of the

white areas of the picture.

To adjust the color temperature:

1. From the Picture Settings Menu, use

the Arrow buttons to highlight More,

then press OK.

2. Use the Arrow buttons on the remote

to highlight Color Temperature, then

press OK. The Color Temperature

menu is displayed.

3. Use the Arrow buttons on the remote

to highlight Color Temperature, then

use the Left/Right Arrow buttons to

change the color temperature preset:

t/PSNBM is optimized for television

viewing.

t$PPM produces a blue-hued

picture.

t$PNQVUFS optimizes the picture

for use as a PC monitor.

rCustom allows you to manually change each of the color temperature

settings:

Red/Green/Blue Gain - Adjusts the amount of each color in the

display.

Red/Green/Blue Offset - Adjusts the position of each color in the

display.

4. If you want to reset the color temperatures to the factory default settings,

highlight Reset Color Temperature and press OK.

5. When you have ﬁnished adjusting the color temperature, press the EXIT

button on the remote.

"EKVTUJOHUIF1JDUVSF4J[FBOE1PTJUJPO

When displaying an image from the HDMI or RGB input, the size and position of

the display image can be adjusted.

To adjust the picture size and position:

1. Ensure the input is set to HDMI or RGB.

2. From the Picture Settings menu, use the Arrow buttons on the remote to

highlight More, then press OK.

3. Use the Arrow buttons on the remote to highlight Size & Position, then

press OK. The Size & Position menu is displayed.

4. Use the Arrow buttons to highlight the setting you wish to adjust, then

press Left/Right Arrow to change the setting:

t"VUP"EKVTU - Automatically adjusts display image to optimal size and

position. (RGB input only.)

t)PSJ[1PTJUJPO - Adjusts the horizontal (left/right) position of the

display image.

t7FSUJDBM1PTJUJPO - Adjusts the vertical (up/down) position of the

display image.

t)PSJ[POUBM4J[F - Adjusts the width of the display image.

t'JOF5VOF - Adjusts the height of the display image. (RGB input only.)

5. When you have ﬁnished adjusting the color temperature, press the EXIT

button on the remote.

3FTFUUJOHUIF1JDUVSF4FUUJOHT

To reset the picture settings to the factory default settings:

1. From the Picture Settings menu, use the Arrow buttons to highlight More,

then press OK.

2. Use the Arrow buttons on the remote to highlight Reset Picture Mode,

then press OK. The TV displays, “Are you sure you want to RESET Picture

Settings to the factory defaults?”

3. Highlight Yes and press OK.

4. Press the EXIT button on the remote.

XVT3D650SV

Adjusting the Audio Settings

To adjust the audio settings:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Arrow buttons on the remote

to highlight Audio and press OK. The

Audio Settings menu is displayed.

4. Use the Arrow buttons to highlight

the setting you wish to adjust, then

press Left/Right Arrow to change the

setting:

t"VEJP.PEF - Change the preset

equalizer. Select Flat, Rock, Pop,

Classical, or Jazz.

t#BMBODF - Adjusts the loudness of

the audio output from the left and

right speakers.

t-JQ4ZOD - Adjusts the synchronization between the display image and

the accompanying audio track.

t574QFBLFST - Turns the built-in speakers on or off.

t"EWBODFE"VEJP - See

Adjusting the Advanced Audio Settings

page 18.

t#MVFUPPUI"VEJP - Turns the built-in Bluetooth transmitter on or off

t&RVBMJ[FS4FUUJOHT - Adjusts the boost or attenuation of different

frequencies. (This setting is only available when SRS TruSurround HD is

set to Off.)

t3FTFU"VEJP.PEF - Restores the audio settings to the factory

defaults. See

Resetting the Audio Settings

on page 19.

5. When you have ﬁnished adjusting the audio settings, press the EXIT button

on the remote.

"EKVTUJOHUIF"EWBODFE"VEJP4FUUJOHT

To adjust the advanced audio settings:

1. From the Audio Settings Menu, use the

Arrow buttons to highlight Advanced

Audio, then press OK. The Advanced

Audio menu is displayed.

2. Use the Arrow buttons to highlight

the setting you wish to adjust, then

press Left/Right Arrow to change the

setting:

t4345SV4VSSPVOE)% -

TruSurround HD™ is a robust

multichannel virtualization

technology developed by SRS

Labs that provides an enhanced

listening experience unlike any

other technology that has been

offered for a two speaker playback

environment. Select On or Off.

t4345SV7PMVNF - TruVolume™

intelligently normalizes volume

uctuations due to television

commercials or channel changes.

Select On or Off.

t%JHJUBM"VEJP0VU - Changes the type of processing for the Optical

output when connected to a home theater audio system. Select Dolby

Digital, PCM, or Off.

t"OBMPH"VEJP0VU - Sets the volume control properties for the analog

RCA (red/white) connectors when connected to a home theater audio

system. Select Variable to control the external speakers’ volume

from the TV’s volume controls, or select Fixed to control the external

speakers’ volume from your home theater system controls.

t"VEJP$POUSPMT - Select the device controlled by the VIZIO remote.

Select TV to force the remote to control the TV’s audio, or select

External to force the remote to control the external audio device.

3. When you have ﬁnished adjusting the advanced audio settings, press the

EXIT button on the remote.

XVT3D650SV

3FTFUUJOHUIF"VEJP4FUUJOHT

To reset the audio settings to the factory default settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight the TV Settings icon and

press OK. The TV Settings menu is displayed.

3. Use the Arrow buttons on the remote to highlight Audio and press OK. The

Audio Settings menu is displayed.

4. Use the Arrow buttons to highlight Reset Audio Mode and press OK. The

TV displays, “Are you sure you want to RESET Audio Settings to the factory

defaults?”

5. Highlight Yes and press OK.

6. Press the EXIT button on the remote.

Adjusting the Tuner Settings

The Tuner Settings Menu can be used to perform channel scans or make

adjustments when the TV is receiving channels from an antenna, cable, or satellite.

4FUUJOHUIF5VOFS.PEF

If you are using a device that is connected to the RF input, such as an external

antenna or cable TV connection, you must set the tuner mode.

To set the tuner mode:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight the TV Settings icon and

press OK. The TV Settings menu is displayed.

3. Use the Arrow buttons on the remote to highlight Tuner Settings and

press OK. The Tuner Settings menu is displayed.

4. Highlight Tuner Mode and press OK. The Tuner Mode menu is displayed.

5. Highlight Antenna or Cable and press OK.

6. Press the EXIT button on the remote.

4DBOOJOHGPS$IBOOFMT

Before the TV can detect and display channels and their associated information,

you must scan for channels. A channel scan may also be necessary when the

TV has been moved to an area where different free-to-air broadcast television

channels are available.

1. From the Tuner Settings menu, highlight Auto Channel Scan. The auto

channel scan begins.

2. Wait until the channel scan is 100% complete. Highlight Done and press

OK.

3. Press the EXIT button on the remote.

"EEJOH/FX$IBOOFMT

Occasionally, you may need to add a new analog channel or add a new range of

channels. You can do this by using the Partial Channel Search and Add Analog

Channel options.

To add a range of new channels:

1. From the Tuner Settings menu,

highlight Partial Channel Search.

The Partial Channel Search menu is

displayed.

2. Highlight Scan Mode and select

the type of channel you are adding:

Analog, Digital, or Analog/Digital.

3. Highlight From Channel and enter the

channel from which you want to begin

the scan. (Use the Number Pad on the

remote to enter the channel.)

4. Highlight To Channel and enter the

channel to which you want to end the

scan. (Use the Number Pad on the

remote to enter the channel.)

5. Highlight Start and press OK. The

partial channel search begins.

6. Wait until the partial channel search is 100% complete. Highlight Done and

press OK.

7. Press the EXIT button on the remote.

XVT3D650SV

To add a single new analog channel:

1. From the Tuner Settings menu,

highlight Add Analog Channel.

The Add Analog Channel menu is

displayed.

2. Highlight Enter Channel # and use the

Number Pad on the remote to enter

the number of the channel you are

adding.

3. Highlight Add Channel and press OK.

The TV scans for the channel.

4. When the TV is done scanning for the

channel, press the EXIT button on the

remote.

4LJQQJOH$IBOOFMT

After a channel scan is completed, you may ﬁnd that some channels are too weak

to watch comfortably. There may also be some channels you do not want to view.

You can remove these channels from the TV’s memory with the Skip Channel

feature.

Channels that have been removed with the Skip Channel feature can

still be viewed if the channel is entered using the Number Pad. If

you wish to completely block a channel from being viewed, use the

parental controls. See

Using the Parental Controls

on page 22.

To remove a channel:

1. From the Tuner Settings menu,

highlight Skip Channel. The Skip

Channel menu is displayed.

2. For each channel you wish to remove,

use the Up/Down Arrow buttons on

the remote to highlight the channel and

press OK. An X appears to the right of

each channel you select.

3. When you have selected all of the

channels you wish to remove, press

the EXIT button on the remote.

XVT3D650SV

$IBOHJOHUIF"VEJP-BOHVBHF

Some digital free-to-air and cable channels broadcast programs in more than one

language. The TV’s MTS (Multichannel Television Sound) feature allows you to

listen to audio in your preferred language.

Not all programs are broadcast in multiple languages. The MTS

feature only works when the program being viewed is being

broadcast in the language you select.

To use the Analog MTS feature:

1. From the Tuner Settings menu,

highlight Analog MTS and press OK.

The Analog MTS menu is displayed.

2. Select Mono, Stereo, or SAP

(secondary audio programming). Press

OK.

3. Press the EXIT button on the remote.

To use the Digital MTS feature:

1. From the Tuner Settings menu,

highlight Digital MTS and press OK.

The Digital MTS menu is displayed.

2. Select your preferred language:

English, French, or Spanish. Press

OK.

3. Press the EXIT button on the remote.

$IBOHJOHUIF/BNFTPGUIF*OQVUT

To make it easier to recognize the different devices attached to the inputs on your

TV, you can rename the inputs. For example, if you have a DVD player connected

to the Component input, you can rename that input to display “DVD Player”.

To change the name of an input:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Arrow buttons on the remote

to highlight Name Input and press OK.

The Name Input menu is displayed.

4. Highlight Input Source and press OK.

Highlight the input you want to rename

and press OK.

5. If you would like to use a preset input

label, highlight Input Labels and press

OK. Highlight the input label you want

to use and press OK.

If you would like to name the input

yourself, highlight the ﬁeld below Input

Labels and enter your custom label

using the QUERTY Keypad on the

remote and press OK. (If you would

like to use the on-screen keyboard

instead, highlight Show Keyboard and

press OK.)

6. When you have ﬁnished naming your input, press the EXIT button on the

remote.

XVT3D650SV

Activating Game Mode

Game mode optimizes the TV for use as a video game display. When Game Mode

is on, the video and audio synchronization is improved for video games.

To turn Game Mode on or off:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight the TV Settings icon and

press OK. The TV Settings menu is displayed.

3. Use the Arrow buttons on the remote to highlight Game Mode and press

OK. The Game Mode menu is displayed.

4. Select Off or On and press OK.

5. Press the EXIT button on the remote.

Using the Parental Controls

The TV’s parental controls allow you to prevent the TV from displaying certain

channels or programs without a password.

"DDFTTJOHUIF1BSFOUBM$POUSPMT.FOV

To access the Parental Controls menu:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Arrow buttons on the remote

to highlight Parental Controls and

press OK.

4. Enter the Parental Control Passcode

and press OK. (If you have not yet

changed the passcode, the default is

0000.) The Parental Controls menu is

displayed.

&OBCMJOHPS%JTBCMJOH1SPHSBN3BUJOHT

To manage program content according to its rating, you must enable the Program

Rating feature.

To enable or disable the Program Rating feature:

1. From the Parental Controls menu, highlight Rating Enable and press OK.

The Rating Enable menu is displayed.

2. Select On or Off and press OK.

-PDLJOHBOE6OMPDLJOH$IBOOFMT

When a channel is locked, it will be inaccessible. Locking a channel is a good way

to prevent children from viewing inappropriate material.

To lock or unlock a channel:

1. From the Parental Controls menu, highlight Channel Locks and press OK.

The Channel Locks menu is displayed.

2. Highlight the channel you want to lock or unlock and press OK.

3. When a channel is locked, the Lock icon appears locked. The channel is

not accessible unless the parental passcode is entered.

4. When a channel is unlocked, the Lock icon appears unlocked. The

channel is accessible.

#MPDLJOHBOE6OCMPDLJOH$POUFOUCZ3BUJOH

A channel may sometimes broadcast programs that are meant for children, and

at other times broadcast programs that are meant for mature audiences. You may

not want to block the channel completely using a channel lock, but you may wish

to block certain programs from being viewed.

When this is the case, you can use the TV’s Rating Block feature to block content

based on its rating.

For a list of content ratings and their deﬁnitions, visit

www.tvguidelines.org.

To block or unblock content by its rating:

1. From the Parental Controls menu, highlight the content type you want to

adjust and press OK:

XVT3D650SV

USA - TV - USA television program broadcasts.

USA - Movie - USA movie broadcasts.

CAN - English - Canadian English television program broadcasts.

CAN - French - Canadian French television program broadcasts.

2. For each rating type you want to block or unblock, use the Up/Down and

Left/Right Arrow buttons on the remote to highlight the rating type and

press OK.

3. When the rating type is blocked, the Lock icon appears locked. Content

with this rating cannot be viewed.

4. When the rating type is unblocked, the Lock icon appears unlocked.

Content with this rating can be viewed.

5. If you want to block all unrated content, highlight Block Unrated Shows

and use the Arrow buttons on the remote to select On.

6. When you are ﬁnished adjusting the rating level blocks, press the EXIT

button on the remote.

$IBOHJOHUIF1BSFOUBM$POUSPM1BTTDPEF

If you use the parental controls, you should change the passcode to prevent

children from accessing inappropriate material.

1. From the Parental Controls menu, highlight Change PIN and press OK. The

Change PIN menu is displayed.

2. In the New Pin ﬁeld, use the Number Pad on the remote to enter your new

4-digit parental control passcode.

3. In the Conﬁrm Pin ﬁeld, use the Number Pad on the remote to re-enter

your new 4-digit parental control passcode.

4. Write down your new parental control passcode and save it in a secure

location.

5. Press the EXIT button on the remote.

3FTFUUJOHUIF$POUFOU-PDLT

To reset the content locks to the factory-default settings:

1. From the Parental Controls menu, highlight RESET LOCKS and press OK.

The TV displays, “Are you sure you want to RESET ALL LOCKS SETTINGS

to the factory defaults?”

2. Highlight Yes and press OK.

Changing the On-Screen Menu Language

Your TV can display the on-screen menu in different languages.

To change the on-screen menu language:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Arrow buttons on the remote

to highlight Menu Language and

press OK. The Menu Language menu

is displayed.

4. Highlight your preferred language

(English, French, or Spanish) and

press OK.

5. Press the EXIT button on the remote.

XVT3D650SV

Setting the Time Zone

To ensure the correct time is displayed when you press the INFO button, set the

TV’s time zone:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the TV Settings icon and

press OK. The TV Settings menu is

displayed.

3. Use the Arrow buttons on the remote

to highlight Time & Local Settings

and press OK. The Time & Local

Settings menu is displayed.

4. Highlight Time Zone and press OK.

The Time Zone menu is displayed.

5. Highlight your time zone and press OK.

6. Highlight Daylight Savings and press

OK. The Daylight Savings menu is

displayed.

7. Highlight Off or On and press OK.

8. Press the EXIT button on the remote.

Your TV features an easy-to-use on-screen menu.

To open the on-screen menu, press the MENU button on the remote. You can

also open the on-screen menu by pressing the VIA button and selecting HDTV

Settings from the VIA Dock, then pressing OK.

From this menu, you can:

r$IBOHFUIF%NPEF

r$IBOHFUIFTDSFFOBTQFDUSBEJP

r4FUVQDMPTFEDBQUJPOJOH

r"DUJWBUFUIFTMFFQUJNFS

r"EKVTU1*11JDUVSFJO1JDUVSFDPOUSPMT

r"EKVTU/FUXPSL4FUUJOHT

r1BJS#MVFUPPUIEFWJDFT

r"DDFTTUIF)FMQNFOV

While navigating the on-screen menu, you can press the BACK

button at any time to return to the previous menu screen.

Changing the 3D Mode

To correctly view 3D content, you must set the 3D mode to match the 3D format

of the content.

To change the 3D mode:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the 3D icon and press OK.

The Output Mode menu is displayed.

3. If viewing 2D content, highlight 2D and press OK. The menu closes.

If viewing 3D content, highlight 3D and press OK. Go to step 4.

4. Select the 3D mode to match the content you are watching:

tSBS%JTQMBZTTJEFCZTJEF%

tTB%JTQMBZTUPQCPUUPN%

tSensio%JTQMBZT4FOTJP%

5. The TV displays, “3D viewing mode enabled. Please wear 3D glasses.” Put

on your 3D glasses.

You can also quickly change the 3D display mode by pressing the

3D button on the remote.

Changing the Screen Aspect Ratio

The TV can display images in four different modes: Wide, Zoom, Normal, and

Stretch. Each mode displays the picture differently.

To change the screen aspect ratio:

1. Press the MENU button on the remote.

2. Use the Arrow buttons to highlight the

Wide icon. Press OK.

3. Use the Arrow buttons to highlight your desired screen mode and press

OK:

r8JEFNPEFTUSFUDIFTBBTQFDUSBUJPQJDUVSFUPUIFFEHFTPGUIF

TDSFFO4JODFUIFQJDUVSFJTCFJOHTUSFUDIFEUIFEJTQMBZJNBHFNBZ

BQQFBSEJTUPSUFE*GUIFQSPHSBNJTBMSFBEZGPSNBUUFEGPSXJEFTDSFFO

WJFXJOHPSUIFOCMBDLCBSTXJMMBQQFBSPOUIFUPQBOE

CPUUPNPGUIFEJTQMBZJNBHF

r;PPNNPEFFYQBOETJNBHFTXJUICMBDLCBSTUPàUUIFTDSFFO

r/PSNBMNPEFQSFTFSWFTBOPSJHJOBMBTQFDUSBUJP4JODFUIF

BTQFDUSBUJPJTOPUMBSHFFOPVHIUPàMMUIF57TTDSFFOCMBDLCBSTBSF

BEEFEUPUIFMFGUBOESJHIUPGUIFEJTQMBZJNBHF

r4USFUDINPEFFYQBOETUIFEJTQMBZJNBHFUPàMMUIFTDSFFO*NBHFT

NBZBQQFBSXJEFSUIBOJOUFOEFE*GZPVBSFXBUDIJOHXJEFTDSFFO

PSDPOUFOUCMBDLCBSTXJMMTUJMMBQQFBSPOUIFUPQBOE

CPUUPNPGUIFEJTQMBZJNBHF

Using the Other TV Settings

975%47

Setting Up Closed Captioning

Your TV can display closed captions for programs that include them. Closed

captions display a transcription of a program’s dialogue.

If the program you are viewing is not being broadcast with closed

captions, the TV will not display them.

To activate or deactivate closed captions:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the CC icon and press OK.

The Closed Caption menu is displayed.

3. Use the Arrow buttons on the remote

to highlight the type of closed captions

you wish to see:

t"OBMPH$MPTFE$BQUJPOGPS

BOBMPH/54$57DIBOOFMT

t%JHJUBM$MPTFE$BQUJPOGPS

EJHJUBM"54$57DIBOOFMT

4. After highlighting the type of closed

captions you wish to see, use the Left/

Right Arrow buttons on the remote to

select the caption channel you wish to

display, then press EXIT.

Caption channels usually display different languages. For example,

CC1 may display English captions and CC2 may display Spanish

captions.

$IBOHJOHUIF"QQFBSBODFPG%JHJUBM$MPTFE$BQUJPOT

Digital closed captions can be displayed according to your preference.

To change the appearance of digital closed captions:

1. From the Closed Caption menu, use

the Arrow buttons to highlight Digital

CC Style.

2. Use the Left/Right Arrow buttons on

the remote to select Custom, then

press OK. The Digital CC Style menu

appears.

3. Use the Up/Down Arrow buttons on

the remote to highlight the setting you

wish to change, then use the Left/

Right Arrow buttons to change the

setting:

t$BQUJPO4UZMF$IPPTF"VUPUP

LFFQEFGBVMUTFUUJOHTPS$VTUPNUP

NBOVBMMZDIBOHFFBDITFUUJOH

t5FYU4J[F"EKVTUUIFTJ[FPGUIF

UFYU

t$PMPS$IBOHFUIFDPMPSPGUIF

UFYU

t0QBDJUZ$IBOHFUIFUSBOTQBSFODZPGUIFUFYU

t#($PMPS$IBOHFUIFCBDLHSPVOEDPMPS

t#(0QBDJUZ$IBOHFUIFUSBOTQBSFODZPGUIFCBDLHSPVOE

t8JOEPX$PMPS$IBOHFUIFFEHFDPMPS

t8JOEPX0QBDJUZ$IBOHFUIFFEHFUZQF

4. When you are satisﬁed with the

appearance of the closed

captions, press the EXIT button on the

remote.

975%47

6TJOHUIF4MFFQ5JNFS

When activated, the TV’s sleep timer will turn the TV off after a set period of time.

To use the sleep timer:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the Sleep Timer icon and

press OK. The Sleep Timer menu is

displayed.

3. Use the Up/Down Arrow buttons

on the remote to highlight Timer

and press OK. The Timers menu is

displayed.

4. Use the Up/Down Arrow buttons on

the remote to highlight the period of

time after which you want the TV to

turn off. Press OK, then press EXIT.

Using Picture-In-Picture (PIP) / Picture-Outside-Picture (POP)

Your TV features PIP and POP modes. These features allow you to watch two

input sources at the same time. When using PIP, the main input is displayed on

the full screen, and the secondary is displayed in a smaller window. When using

POP, the two inputs are displayed side by side.

PIP is only available when the Rating Enable option in the Parental

Controls menu is set to Off. See “Enabling or Disabling Program

Ratings” on page 22.

To enable or disable PIP/POP:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight the PIP icon and press

OK. The PIP Controls menu is displayed.

3. Highlight PIP Mode and press OK. The PIP Controls menu is displayed.

4. Highlight Off, PIP, or POP. Press OK.

5. If PIP is the PIP Mode selected, use the Arrow buttons to adjust each of

the PIP settings:

tPosition5IFMPDBUJPOPGUIF1*1XJOEPXPOUIFTDSFFO4FMFDU5PQ

3JHIU#PUUPN3JHIU5PQ-FGUPS5PQ3JHIU

t4J[F5IFTJ[FPGUIF1*1XJOEPX4FMFDU4NBMM.FEJVNPS-BSHF

tAudio5IFJOQVUGPSXIJDIUIF57PVUQVUTTPVOE4FMFDU.BJOPSPIP

6. Press the EXIT button on the remote.

$IPPTJOH*OQVUTGPSUIF.BJOBOE4FDPOEBSZ8JOEPXT

Not all inputs can be displayed using PIP/POP. Use the table below to determine

which inputs can be displayed using PIP/POP. (A green box with a  between two

inputs denotes compatibility.)

$PNQPTJUF

$PNQPOFOU)%.*3(#



$PNQPTJUF



$PNQPOFOU



HDMI

   

RGB





975%47

Using the Network Connection Menu

Your TV is internet-ready, featuring both an ethernet port and built-in high-speed

wireless-N.

$POOFDUJOHUPB8JSFMFTT/FUXPSL

To connect to a wireless network whose network name (SSID) is being broadcast:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the Network icon and press

OK. The Network Connection menu is

displayed.

3. Highlight More Access Points and

press OK. The More Access Points

menu, which is a list of available

wireless networks, is displayed.

4. Highlight the name of your wireless

network (this is the network’s SSID)

and press OK.

5. Using the QUERTY Keypad on

the remote, enter your network’s

password, then highlight Connect and

press OK. (If you would like to use the

on-screen keyboard instead, highlight

Show Keyboard and press OK.)

6. Press the EXIT button on the remote.

To connect to a wireless network whose network name (SSID) is not being

broadcast:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the Network icon and

press OK. The Network Connection

menu is displayed.

3. Highlight Enter Access Point Name

and press OK.

4. Using the QUERTY Keypad on the

remote, enter your network’s name

(SSID), then highlight Connect and

press OK. (If you would like to use the

on-screen keyboard instead, highlight

Show Keyboard and press OK.)

5. Using the QUERTY Keypad on

the remote, enter your network’s

password, then highlight Connect and

press OK. (If you would like to use the

on-screen keyboard instead, highlight

Show Keyboard and press OK.)

6. Press the EXIT button on the remote.

975%47

$IBOHJOHUIF"EWBODFE/FUXPSL4FUUJOHT

Advanced users can ﬁne-tune the network settings using the Manual Setup

feature.

To change advanced network settings:

7. From the Network Connection menu,

highlight Manual Setup and press

OK. The Change Settings menu is

displayed.

8. Use the Arrow and OK buttons to

adjust each setting:

t%)$1%ZOBNJD)PTU

$POàHVSBUJPO1SPUPDPM5IJTTFUUJOH

NVTUCFUVSOFE0GGUPDIBOHFBOZ

PGUIFPUIFSTFUUJOHT

t*1"EESFTT5IF*1BEESFTT

BTTJHOFEUPUIF57

t4VCOFU.BTL5IFTVCOFUNBTL

t%FGBVMU(BUFXBZ:PVSOFUXPSLT

EFGBVMUHBUFXBZBEESFTT

t1SFG%/44FSWFS:PVSQSFGFSSFE

EPNBJOOBNFTFSWFSBEESFTT

t"MU%/44FSWFS:PVSBMUFSOBUFEPNBJOOBNFTFSWFSBEESFTT

9. If you need the RJ45 (ethernet) MAC address or the Wireless MAC address

to set up your network, these are displayed at the bottom of the Change

Settings menu.

10. Press the EXIT button on the remote.

5FTUJOH:PVS/FUXPSL$POOFDUJPO

To test your network connection:

1. From the Network Connection menu, highlight Test Connection and press

OK.

2. The Test Connection screen displays the connection method, network

name, signal strength, and download speed of your network connection.

3. Press the EXIT button on the remote.

Setting Up a Bluetooth Device

To pair a Bluetooth device with your TV:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the Bluetooth icon and

press OK. The Bluetooth menu is

displayed.

3. Highlight Pair Device and press OK.

4. If you are pairing the included

Bluetooth remote, hold down both the

Green VIA Shortcut button and the

Record button for 5 seconds.

If you are pairing a different

Bluetooth device, place the device in

“discoverable” mode as per the device

instructions.

5. Highlight Start searching for devices

and press OK. If the pairing is

successful, the device will appear in

the list of connected devices.

6. Press the EXIT button on the remote.



975%47

Using the Help Menu

You can use the TV’s Help menu to:

r%JTQMBZTZTUFNJOGPSNBUJPO

r3FTFUUIF57TFUUJOHT

r3FTUPSFUIF57UPJUTGBDUPSZ

EFGBVMUTFUUJOHT

r(FUHVJEFETFUVQIFMQGPSUIF

SFNPUFUVOFSEFWJDFTBOE

OFUXPSL

%JTQMBZJOH4ZTUFN*OGPSNBUJPO

To display a summary of the TV settings:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the Help icon and press

OK. The Help menu is displayed.

3. Highlight System Info and press OK.

4. Use the Up/Down Arrow buttons to scroll through the system information.

5. When you are ﬁnished reviewing the system information, press the EXIT

button on the remote.

3FTFUUJOHUIF574FUUJOHT

To reset the TV’s picture and audio settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight the Help icon and press

OK. The Help menu is displayed.

3. Highlight Reset TV Settings and press OK. The TV displays, “Are you sure

you would like to Restore Defaults? This will erase any custom settings.”

4. Highlight Yes and press OK.

5. Press the EXIT button on the remote.

3FTUPSJOHUIF57UP'BDUPSZ%FGBVMU4FUUJOHT

All of the on-screen menu settings can be reset to the factory defaults.

If you restore the TV to the factory default settings, all changes you

have made to the settings will be lost!

To restore the TV to its factory default settings:

1. Press the MENU button on the remote. The on-screen menu is displayed.

2. Use the Arrow buttons on the remote to highlight the Help icon and press

OK. The Help menu is displayed.

3. Highlight Clear Memory (Factory Default) and press OK.

4. Enter your parental control passcode. The TV displays, “Are you sure you

would like to Restore Defaults? This will erase any custom settings.”

5. Highlight Yes and press OK. The TV displays “Memory is being cleared.

The TV will reset shortly.”

6. Wait for the TV to turn off. The TV will turn back on shortly afterward and

the Setup App will begin. See “Completing the First-Time Setup” on page

9



975%47

6TJOH(VJEFE4FUVQ

The TV’s Setup App can be used to easily set up the Bluetooth remote, the TV

tuner, your external devices, and to connect the TV with your network.

To access guided setup:

1. Press the MENU button on the remote.

The on-screen menu is displayed.

2. Use the Arrow buttons on the remote

to highlight the Help icon and press

OK. The Help menu is displayed.

3. Highlight Guided Setup and press OK.

4. Highlight the guided setup you want to

access and press OK:

t3FNPUF4FUVQ4FUVQUIF

#MVFUPPUISFNPUF

t5VOFS4FUVQ4FUVQUIF57UVOFS

t%FWJDF4FUVQ4FUVQZPVS

FYUFSOBMEFWJDFT

t/FUXPSL4FUVQ$POOFDUUIF57

UPZPVSOFUXPSL

5. Follow the on-screen instructions.

When ﬁnished, press the EXIT button

on the remote.



975%47

Using the Digital Episode Guide

Your TV features an on-screen digital episode guide. This guide displays program

information broadcast by digital television stations as well as the current time and

date.

To use the digital episode guide, press the GUIDE button on the remote.

While viewing the digital episode guide, use the Left/Right Arrow buttons to

change the channel.

6TJOHUIF*OGP8JOEPX

The Info Window can be displayed by pressing the INFO button on the remote:

r1SFTTUIF*/'0CVUUPOPOFUJNFUPEJTQMBZDIBOOFMBOEJOQVU

JOGPSNBUJPO

r1SFTTUIF*/'0CVUUPOUXPUJNFTUPEJTQMBZUIFQSPHSBNUJUMFBOE

DMPTFEDBQUJPOJOHJOGPSNBUJPO

r1SFTTUIF*/'0CVUUPOUISFFUJNFTUPEJTQMBZUIFQSPHSBNEFTDSJQUJPO

%JHJUBM&QJTPEF(VJEF*OGP8JOEPX

1SPHSBN%FTDSJQUJPO

6QDPNJOH1SPHSBNT

$MPTFE$BQUJPOJOH

$IBOOFM-PDL

*OGPSNBUJPO

%BUF5JNF

/FYU$IBOOFM

1SFWJPVT$IBOOFM

$VSSFOU$IBOOFM

1SPHSBN%FTDSJQUJPO

1SPHSBN5JUMF$$*OGPSNBUJPO

$IBOOFM*OQVU*OGPSNBUJPO

Using VIZIO Internet Apps

VIZIO Internet Apps (VIA) delivers popular online content to your TV. VIA features

a selection of Apps that allow you to watch movies and TV shows, listen to music,

get weather and news information, and more–all on demand!

A high-speed internet connection is required to receive product

updates and to access online content.

See

Setting Up Your Network Connection

on page 13 if your TV is not yet

connected to your home network.

Using the VIA Shortcut Buttons

Use the four colored buttons on the remote to perform common VIA tasks:

Yellow - Move or delete an App

from the VIA Dock. In some Apps,

this button is also used to create a

“snippet”. For these Apps, the snippet

is available from the App Dock by

highlighting the App and pressing Up/

:emd7hhem.

Blue - Change the size of the main

display window when an App is open

in the sidebar.

Red - Exit from an open App or to

close the App Dock.

=h[[d - View settings for an open App.

Using the VIA Dock

The VIA Dock is where all of your VIA Apps are accessed.

To use the VIA Dock and launch an App:

1. Press the L?7 button on the remote.

2. Highlight a VIA App by scrolling

left and right using the B[\j%H_]^j

7hhem buttons on the remote. (The

highlighted App is in the lower left

corner of the screen.)

3. Launch a VIA App by highlighting it

and pressing the OK button on the

remote.

Moving an App on the VIA Dock

You can personalize your VIA Dock by moving Apps.

To move an App:

1. Press the L?7 button on the remote.

2. Highlight a VIA App by scrolling left and right using the B[\j%H_]^j7hhem

buttons on the remote. (The highlighted App is in the lower left corner of

the screen.)

3. Press the O[bbemL?7I^ehjYkj button.

4. Conﬁrm that you want to move the App by pressing the 8bk[L?7I^ehjYkj

button.

5. Use the B[\j%H_]^j7hhem buttons to move the App to the new location on

the VIA Dock.

6. Press the O[bbemL?7I^ehjYkj button to drop the App in the new location.

XVT3D650SV

Adding a New App to the VIA Dock

Though your TV arrives pre-loaded with featured VIA Apps, new Apps are

continually being added to the Widget Gallery. The VIA Dock can hold a total of

17 Apps.

To add a new App:

1. Press the L?7 button on the remote.

2. Highlight the M_Z][j=Wbb[ho App by scrolling left and right using the Left/

H_]^j7hhem buttons on the remote. (The highlighted App is in the lower left

corner of the screen.)

3. Select M_Z][j=Wbb[ho by pressing the OK button. The Yahoo! Widget

Gallery is displayed.

4. Use the 7hhem and OK buttons to select a new App.

5. Highlight7ZZM_Z][jjeCoFheÓb[ and press OK.

Removing an App from the VIA Dock

To remove an App:

1. Press the L?7 button on the remote.

2. Highlight the App you want to delete by scrolling left and right using the

B[\j%H_]^j7hhem buttons on the remote. (The highlighted App is in the

lower left corner of the screen.)

3. Press the O[bbemL?7I^ehjYkj button.

4. Press the H[ZL?7I^ehjYkj button. The TV displays, “Permanently delete

Widget?”

5. Press the H[ZL?7I^ehjYkj button to conﬁrm that you want to delete.

6. Press the EXIT button.

Creating and Managing User Proﬁles

User proﬁles allow you to keep a customized set of Apps in the VIA Dock. For

each proﬁle you create, a different set of Apps and App settings are saved.

Creating an Owner PIN

Creating an owner PIN allows you to restrict access to the Administrative Controls

menu in the Proﬁle App. You can also restrict other proﬁles from installing new

Apps.

To create an owner PIN:

1. Press the L?7 button on the remote.

2. Highlight the FheÓb[ App by scrolling left and right using the B[\j%H_]^j

7hhem buttons on the remote. (The highlighted App is in the lower left

corner of the screen.)

3. Select the App by pressing the OK button. The Proﬁle App is displayed.

4. Highlight 7Zc_d_ijhWj_l[9edjhebi and press OK. The Administrative

Controls menu is displayed.

5. Highlight 9h[Wj[Emd[hF_d and press OK. The Owner PIN menu is

displayed.

6. Highlight 9h[Wj[Emd[hF_d and press OK. The PIN Creation menu is

displayed.

7. Enter a 4-digit passcode using the DkcX[hFWZ on the remote or the

on-screen number pad. Write down your passcode and save it in a secure

location.

8. Highlight OK and press OK. The PIN Conﬁrmation menu is displayed.

9. Re-enter your 4-digit passcode. Highlight OK and press OK. The Security

Question dialog is displayed. Press OK.

10. Highlight a security question and press OK. The Security Answer menu is

displayed.

11. Enter your security answer using the GK;HJOA[oXeWhZ and press OK.

The Create Proﬁle menu is displayed.

12. Highlight Done and press OK.

XVT3D650SV

Creating a New User Proﬁle

To create a new user proﬁle:

1. Press the L?7 button on the remote.

2. Highlight the FheÓb[ App by scrolling left and right using the B[\j%H_]^j

7hhem buttons on the remote. (The highlighted App is in the lower left

corner of the screen.)

3. Select the App by pressing the OK button. The Proﬁle App is displayed.

4. Highlight 7Zc_d_ijhWj_l[9edjhebi and press OK. (If you have an Owner

PIN, you must enter it now.) The Administrative Controls menu is displayed.

5. Highlight 9h[Wj[FheÓb[ and press OK. The Create Proﬁle menu is

displayed.

6. Highlight the DWc[ ﬁeld and press OK.

7. Enter your name using the GK;HJOA[oXeWhZ on the remote or the

on-screen keyboard, then press OK. The Create Proﬁle menu is displayed.

8. Highlight 7lWjWh and press OK. The Avatar menu is displayed.

9. Highlight a picture for your proﬁle and press OK. The Create Proﬁle menu is

displayed.

10. Highlight 9h[Wj[FheÓb[F?D and press OK. The PIN Creation menu is

displayed.

11. Enter a 4-digit passcode using the Number Pad on the remote or the

on-screen number pad. Write down your passcode and save it in a secure

location.

12. Highlight OK and press OK. The PIN Conﬁrmation menu is displayed.

13. Re-enter your 4-digit passcode. Highlight OK and press OK. The Security

Question dialog is displayed. Press OK.

14. Highlight a security question and press OK. The Security Answer menu is

displayed.

15. Enter your security answer using the GK;HJOA[oXeWhZ and press OK.

The Create Proﬁle menu is displayed.

16. If you would like to prevent the user of this new proﬁle from installing new

Apps, turn B_c_jFheÓb[ to On. (You need an Owner PIN. Enter it after

turning Limit Proﬁle to On.)

17. Highlight Done and press OK.

Removing a User Proﬁle

To remove a user proﬁle:

1. Press the L?7 button on the remote.

2. Highlight the FheÓb[ App by scrolling left and right using the B[\j%H_]^j

7hhem buttons on the remote. (The highlighted App is in the lower left

corner of the screen.)

3. Select the App by pressing the OK button. The Proﬁle App is displayed.

4. Highlight 7Zc_d_ijhWj_l[9edjhebi and press OK. (If you have an Owner

PIN, you must enter it now.) The Administrative Controls menu is displayed.

5. Highlight H[cel[FheÓb[ and press OK. The Remove Proﬁle menu is

displayed.

6. Highlight the name of the proﬁle you want to remove and press OK. The

TV displays, “Are you sure you want to delete this proﬁle? This operation

cannot be undone.”

7. Highlight OK and press OK.

XVT3D650SV

Restoring the VIA Dock to the Factory Default Settings

The VIA Dock, and all of its installed Widgets can be restored to the factory default

settings.

If you restore the VIA dock to the factory-default settings, all changes

you have made to the VIA dock will be lost!

To restore the VIA Dock to the factory default settings:

1. Press the L?7 button on the remote.

2. Highlight the FheÓb[ App by scrolling left and right using the B[\j%H_]^j

7hhem buttons on the remote. (The highlighted App is in the lower left

corner of the screen.)

3. Select the App by pressing the OK button. The Proﬁle App is displayed.

4. Highlight Ioij[cI[jj_d]i and press OK. The System Settings menu is

displayed.

5. Highlight H[ijeh[<WYjehoI[jj_d]i and press OK. The TV displays, “Are

you sure you want to proceed?”

6. Select H[ijeh[<WYjehoI[jj_d]i and press OK. The TV displays, “Are you

sure?”

7. Highlight H[ijeh[<WYjehoI[jj_d]i and press OK.

8. Wait 5 seconds for the TV to restart.

Viewing Theater 3D

How Theater 3D Works

Our eyes have space between them, so when we look around, we see two slightly

different pictures. We never notice, because we are able to combine these pictures

into one three-dimensional image.

The VIZIO Theater 3D HDTV takes advantage of this phenomenon to create a

stunning 3D image. When displaying 3D content, the 3D HDTV actually displays

two separate images at the same time—one for each eye.

Because the glasses only allow each eye to see one of the two images, your brain

is able to process the picture as it would any other object you see. The ﬁnal result

is a stunning, life-like 3D picture.

What You Need to View 3D Content

To view 3D content, you will need:

 +/+;=

 +)S\YH`WSH`LY^P[OH)S\YH`+KPZJZVSKZLWHYH[LS`

 =0A06;OLH[LY+.SHZZLZ

 +JVTWSPHU[/+40JHISLZVSKZLWHYH[LS`

VIZIO 3D HDTV

3D Blu-ray Player

High-Speed HDMI CableBlu-ray 3D DiscVIZIO Theater 3D Glasses

What You Need

Watching Blu-ray 3D Content

To view Blu-ray 3D content:

1. Ensure you have the following equipment:

 +)S\YH`WSH`LY

 =0A06;OLH[LY+.SHZZLZ

 )S\YH`+KPZJ

 /PNOZWLLK/+40JHISL

2. Ensure the 3D Blu-ray player and your TV are connected with the

3D-compliant HDMI cable.

3. Ensure the 3D Blu-ray player is off. Press the Power/Standby button on

the remote to turn the TV on.

4. Press the INPUT button on the remote and select the input to which the

Blu-ray player is connected (HDMI-1, HDMI-2, etc).

5. Turn the 3D Blu-ray player on. Insert the Blu-ray 3D disc into the player.

6. When the disc is loaded, select the Play Movie option in the disc’s main

menu.

7. The TV displays, “3D Content detected. Select YES to switch to 3D, NO to

display in 2D.” Highlight Yes and press OK.

8. Put on your Theater 3D glasses.

XVT3D650SV

Watching SBS, TB, or Sensio 3D Content

Some broadcast television is broadcast in side-by-side (SBS), top/bottom (TB),

or Sensio format.

To view SBS, TB, or Sensio 3D content:

1. Ensure the program you are watching is broadcast in SBS, TB, or Sensio.

2. Press the 3D button on the remote. The Output Mode menu is displayed.

3. Highlight 3D and press OK.

4. Select the 3D mode to match the content you are watching: SBS, TB, or

Sensio.

5. The TV displays, “3D viewing mode enabled. Please wear 3D glasses.” Put

on your Theater 3D glasses.

Products are often returned due to a technical problem rather than due to a

defect. If you are experiencing a problem when using your TV, try to ﬁx the issue

using this troubleshooting guide.

If, after using this troubleshooting guide, you are still experiencing an issue with

your TV, contact VIZIO’s Support Department. Quality customer support and

service are integral parts of VIZIO’s commitment to service excellence.

The TV displays “No Signal.”

 7YLZZ[OL057<;I\[[VUVU[OLYLTV[LJVU[YVS[VZLSLJ[HKPMMLYLU[

PUW\[ZV\YJL

 0M`V\HYL\ZPUNJHISL;=ZH[LSSP[LVYHU[LUUHJVUULJ[LKKPYLJ[S`[V

[OL;=ZJHUMVYJOHUULSZ:LL

:JHUUPUNMVY*OHUULSZ

VUWHNL

There is no power.

 ,UZ\YL[OL;=PZWS\NNLKPU[VH^VYRPUNLSLJ[YPJHSV\[SL[

 ,UZ\YL[OLWV^LYJHISLPZZLJ\YLS`H[[HJOLK[V[OL;=

 7YLZZ[OL7V^LY:[HUKI`I\[[VUVU[OLYLTV[LVYWYLZZ[OL1HN

>OLLSVU[OLZPKLVM[OL;=[V[\YU[OL;=VU:LL

<ZPUN[OL1HN

>OLLS

VUWHNL

There is no sound.

 7YLZZ=VS\TL<WVU[OLYLTV[LJVU[YVS

 7YLZZ[OL4<;,I\[[VUVU[OLYLTV[L[VLUZ\YLT\[LPZVMM

 *OLJR[OLH\KPVZL[[PUNZ:LL

(KQ\Z[PUN[OL(\KPV:L[[PUNZ

VUWHNL

 ,UZ\YL[OLZWLHRLYZHYLZL[[V6U

 ,UZ\YLUVOLHKWOVULZHYLJVUULJ[LK[V[OL;=

 *OLJR[OLH\KPVJVUULJ[PVUZVML_[LYUHSKL]PJLZ)S\YH`WSH`LY

NHTLJVUZVSLJHISLZH[LSSP[LIV_[OH[HYLJVUULJ[LK[V[OL;=

 0M`V\HYL\ZPUNHUHU[LUUH[OLZPNUHSZ[YLUN[OVM[OLJOHUULSTH`IL

SV^,UZ\YL`V\YHU[LUUHPZJVUULJ[LKZLJ\YLS`[V[OL;=HUKTV]L

[OLHU[LUUHHYV\UK[OLYVVTVYJSVZL[VH^PUKV^MVY[OLILZ[ZPNUHS

The power is on, but there is no image on the screen.

 ,UZ\YLHSSJHISLZHYLZLJ\YLS`H[[HJOLK[V[OL;=

 ,UZ\YLHSSKL]PJLZHYLJVUULJ[LKJVYYLJ[S`+L]PJLZKPMMLY"ZLL`V\Y

KL]PJL»Z\ZLYTHU\HSMVYKL[HPSZ

 (KQ\Z[)YPNO[ULZZ*VU[YHZ[VY)HJRSPNO[:LL

(KQ\Z[PUN[OL7PJ[\YL

:L[[PUNZ

VUWHNL

 7YLZZ[OL057<;I\[[VUVU[OLYLTV[L[VZLSLJ[HKPMMLYLU[PUW\[

ZV\YJL

The colors on the TV don’t look right.

 (K\Z[[OL*VSVYHUK;PU[ZL[[PUNZPU[OL7PJ[\YLTLU\:LL

(KQ\Z[PUN

[OL7PJ[\YL:L[[PUNZ

VUWHNL

 9LZL[[OLWPJ[\YLZL[[PUNZ:LL

9LZL[[PUN[OL7PJ[\YL:L[[PUNZ

VU

WHNL 

 *OLJRHSSJHISLZ[VLUZ\YL[OL`HYLZLJ\YLS`H[[HJOLK

The buttons on the remote aren’t working.

 ,UZ\YL`V\HYL VUS`WYLZZPUNVULI\[[VUH[H[PTL

 7VPU[[OLYLTV[LKPYLJ[S`H[[OL;=^OLUWYLZZPUNHI\[[VU

 9LWSHJL[OLYLTV[LIH[[LYPLZ^P[OUL^VULZ:LL

9LWSHJPUN[OL

)H[[LYPLZ

VUWHNL

The image quality is not good.

 -VY[OLILZ[PTHNLX\HSP[`]PL^OPNOKLÄUP[PVUWYVNYHTZ\ZPUNKPNP[HS

ZV\YJLZ*VUULJ[`V\YKL]PJLZ^P[O/+40JHISLZ

 0M`V\HYL\ZPUNHUHU[LUUH[OLZPNUHSZ[YLUN[OVM[OLJOHUULSTH`IL

SV^,UZ\YL`V\YHU[LUUHPZJVUULJ[LKZLJ\YLS`[V[OL;=HUKTV]L

[OLHU[LUUHHYV\UK[OLYVVTVYJSVZL[VH^PUKV^MVY[OLILZ[ZPNUHS

The picture is distorted.

 5LHYI`LSLJ[YPJHSKL]PJLZTH`ILPU[LYMLYPUN^P[O[OL;=:LWHYH[L[OL

;=MYVTLSLJ[YPJHSHWWSPHUJLZJHYZVYÅV\YLZJLU[SPNO[Z

 ,UZ\YLHSSJHISLZHYLZLJ\YLS`H[[HJOLK

Troubleshooting & Technical Support

Address: 39 Tesla Irvine,

CA 92618, USA

Phone: (877) 698-4946

Fax: (949) 585-9563

Email: techsupport@vizio.com

Web: www.VIZIO.com

Hours of operation:

Monday - Friday: 6 am to 9 pm (PST)

Saturday - Sunday: 8 am to 4pm (PST)

The display image does not cover the entire screen.

 0M`V\HYLPU9.)TVKLJVTW\[LYLUZ\YL[OH[/:PaLHUK=7VZP[PVU

PU[OLVUZJYLLUTLU\HYLZL[JVYYLJ[S`

 0M`V\HYL\ZPUN;=(=(=VY*VTWVULU[^P[OPPUW\[WYLZZ

[OL>0+,I\[[VUVU[OLYLTV[L[VJOHUNL[OLZJYLLUTVKL

The TV has pixels (dots) that are always dark or always lit.

 @V\Y/+;=PZWYLJPZPVUTHU\MHJ[\YLK\ZPUNHUL_[YLTLS`OPNOSL]LS

VM[LJOUVSVN`/V^L]LYZVTL[PTLZWP_LSZTH`UV[KPZWSH`JVYYLJ[S`

;OLZL[`WLZVMVJJ\YLUJLZHYLPUOLYLU[[V[OPZ[`WLVMWYVK\J[HUKKV

UV[JVUZ[P[\[LHKLMLJ[P]LWYVK\J[

I see “noise” or static on the screen.

 >OLU`V\Y;=»ZKPNP[HSJHWHIPSP[PLZL_JLLKHKPNP[HSIYVHKJHZ[ZPNUHS

[OLZPNUHSPZ\WJVU]LY[LKPTWYV]LK[VTH[JO`V\Y;=»ZKPZWSH`

JHWHIPSP[PLZ;OPZ\WJVU]LY[PUNJHUZVTL[PTLZJH\ZLPYYLN\SHYP[PLZPU

[OLPTHNL

 0M`V\HYL\ZPUNHUHU[LUUH[OLZPNUHSZ[YLUN[OVM[OLJOHUULSTH`IL

SV^,UZ\YL`V\YHU[LUUHPZJVUULJ[LKZLJ\YLS`[V[OL;=HUKTV]L

[OLHU[LUUHHYV\UK[OLYVVTVYJSVZL[VH^PUKV^MVY[OLILZ[ZPNUHS

When I change input source, the volume changes.

 ;OL;=YLTLTILYZ[OL]VS\TLSL]LSVULHJOPUW\[ZV\YJL0M[OL

]VS\TLSL]LSVU[OLUL^PUW\[ZV\YJLPZOPNOLYVYSV^LY[OHU[OLSL]LS

VU[OLZV\YJL`V\Z^P[JOMYVT[OLKPMMLYLUJLTH`ILUV[PJHISL

 <ZL[OL=VS\TL<W+V^UI\[[VUZVU[OLYLTV[L[VHKQ\Z[[OL

]VS\TL

When I change input source, the display image changes size.

 ;OL;=YLTLTILYZ[OL]PL^PUNTVKLVULHJOPUW\[ZV\YJL0M[OL

]PL^PUNTVKLVU[OLUL^PUW\[ZV\YJLKPMMLYZMYVT[OLVULVU[OL

PUW\[ZV\YJL`V\Z^P[JOMYVT[OLKPMMLYLUJLTH`ILUV[PJHISL

 :LL

*OHUNPUN[OL:JYLLU(ZWLJ[9H[PV

VUWHNL

Screen Size 65” Class

Viewable Area 64.5”

Dimensions w/ Stand

w/o Stand

60.87(W) x 40.87(H) x 16.10(D)”

60.87(W) x 38.46(H) x 2.25(D)”

Weight w/ Stand

w/o Stand

104.9 lbs

92.81 lbs

TV Type Edge-lit Razor LED

™

Refresh Rate 120 Hz

Maximum Resolution 1920 x 1080

Colors 1.07 Billion

Smart Dimming 32 Zones

Display Compatibility 1080p

Smooth Motion Yes

Dynamic Contrast Ratio 1,000,000:1

Response Time 5 ms

Brightness 450 nits

HDMI Inputs 5

Component Video Inputs 1

Composite Inputs 1 (Shared with Component Y Pb R)

RF Antenna Input 1

Viewing Angle 178/178

USB 2.0 Ports 3

RGB Inputs 1

Ethernet 10/100 Base-TX

OSD Language English, Spanish, French

HD Gameport Yes

Outputs Optical Digital Audio Out (SPDIF) 5.1

Picture In Picture (PIP) Yes

Ambient Light Sensor Yes

Bluetooth HID (Remote), A2DP/AVRCP (Headset)

Wireless (WiFi) 802.11n Dual-Band

Theater 3D Yes

Mercury-Free Yes

Remote Control Model VUR10 3D

Glasses 4 Polarized Glasses Included

Certications

CSA, CSA-US, FCC Class B, BQB,

HDMI 1.4 3D

Compliance

Energy Star 4.1, ATSC Spec A/65, EIA/CEA-

766-A

Power Consumption 256.6W

Standby Power <1W

Speciﬁcations

ON PARTS AND LABOR

Covers units purchased as new in United States and Puerto Rico Only.

VIZIO provides a warranty to the original purchaser of a new Product against

defects in materials and workmanship for a period of one year of non-commercial

usage and ninety (90) days of commercial use. If a Product covered by this

warranty is determined to be defective within the warranty period, VIZIO will either

repair or replace the Product at its sole option and discretion.

To obtain warranty service, contact VIZIO Technical Support via e-mail:

TechSupport@VIZIO.com or via phone at 877 MY VIZIO (877.698.4946) from

6:00AM to 9:00PM Monday through Friday and 8:00AM to 4:00PM Saturday and

Sunday, Paciﬁc Time, or visit www.VIZIO.com. PRE-AUTHORIZATION MUST BE

OBTAINED BEFORE SENDING ANY PRODUCT TO A VIZIO SERVICE CENTER.

Proof of purchase in the form of a purchase receipt or copy thereof is required to

show that a Product is within the warranty period.

Parts and Labor

There will be no charge for parts or labor during the warranty period. Replacement

parts and Products may be new or recertiﬁed at VIZIO’s option and sole discretion.

Replacement parts and Products are warranted for the remaining portion of the

original warranty or for ninety (90) days from warranty service or replacement,

whichever is greater.

Type of Service

Defective Products must be sent to a VIZIO service center to obtain warranty

service. VIZIO is not responsible for transportation costs to the service center,

but VIZIO will cover return shipping to the customer. PRE-AUTHORIZATION IS

REQUIRED BEFORE SENDING ANY PRODUCT TO A VIZIO SERVICE CENTER

FOR WARRANTY SERVICE.

Product returns to VIZIO’s service centers must utilize either the original carton

box and shipping material or packaging that affords an equal degree of protection.

VIZIO Technical Support will provide instructions for packing and shipping the

covered Product to the VIZIO service center.

Limitations and Exclusions

VIZIO’s one-year limited warranty only covers defects in materials and

workmanship. This warranty does not cover, for example: cosmetic damage,

normal wear and tear, improper operation, improper voltage supply or power

surges, signal issues, damages from shipping, acts of God, any type of customer

misuse, modiﬁcations or adjustments, as well as installation and set-up issues

or any repairs attempted by anyone other than by a VIZIO authorized service

center. Products with unreadable or removed serial numbers, or requiring routine

maintenance are not covered. This one year limited warranty does not cover

Products sold “AS IS”, “FACTORY RECERTIFIED”, or by a non-authorized reseller.

THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED OR

DESCRIBED ABOVE. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED

WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET

FORTH ABOVE. VIZIO’S TOTAL LIABILITY FOR ANY AND ALL LOSSES AND

DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER INCLUDING VIZIO’S

NEGLIGENCE, ALLEGED DAMAGE, OR DEFECTIVE GOODS, WHETHER SUCH

DEFECTS ARE DISCOVERABLE OR LATENT, SHALL IN NO EVENT EXCEED THE

PURCHASE PRICE OF THE PRODUCT. VIZIO SHALL NOT BE RESPONSIBLE

FOR LOSS OF USE, LOSS OF INFORMATION OR DATA, COMMERCIAL

LOSS, LOST REVENUE OR LOST PROFITS, OR OTHER INCIDENTAL OR

CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS

ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OF

INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS

OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU

SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH

VARY FROM STATE TO STATE. THIS WARRANTY IS SUBJECT TO CHANGE

WITHOUT NOTICE.

CHECK WWW.VIZIO.COM FOR THE MOST CURRENT VERSION.

Personal Data

If your VIZIO product is capable of storing personal data and other information, ALL

CONTENTS AND INFORMATION WILL BE DELETED IN THE COURSE OF SOME

IN-HOME AND ALL SHIP-IN WARANTY SERVICE. If this occurs, your product will

be restored to you conﬁgured as originally purchased. You will be responsible for

restoring all applicable data and passwords. Recovery and reinstallation of user

data is not covered under this Limited Warranty. In order to protect your personal

information, VIZIO recommends that you always clear all personal information

from the unit before it is serviced, regardless of the servicer.

Zero Bright Pixel Defect Guarantee

This policy covers “zero bright pixel” defects for the duration of the limited

“ONE YEAR WARRANTY” on select new product purchases. To determine if

this guarantee applies to your product, refer to the “DETAILS” tab of the model’s

product information page (www.VIZIO.com) or look for the “zero bright pixel”

guarantee on the box.

Warranty Information

FCC Class B Radio Interference Statement

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiate radio

frequency energy, and if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Notice

1. The changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

2. Shielded interface cables and AC power cord, if any, must be used in

order to comply with the emission limits.

3. The manufacturer is not responsible for any radio or TV interference

caused by unauthorized modication to this equipment. It is the

responsibilities of the user to correct such interference.

FCC warning

Changes or modiﬁcations not expressly approved by the party responsible for

compliance with the FCC Rules could void the user’s authority to operate this

equipment.

Caution

Always use an AC/DC power adapter that is properly grounded. Use the AC cords

listed below for each area.

USA: UL

Canada: CSA

Germany: VDE

UK: BASE/BS

Japan: Electric Appliance Control Act

Open Source Software Notice

Your VIA device may contain GPL executables and LGPL libraries that are subject

to the PL2.0/LGPL2.1 License Agreements. VIZIO offers to provide source code

to you on CD-ROM for a processing fee covering the cost of performing such

distribution, such as the cost of media, shipping and handling upon request made

to VIZIO at www.vizio.com.

This offer is valid for a period of three (3) years from the date of the distribution of

this VIA device by VIZIO.

You can obtain a copy of the GPL, LGPL licenses from http://www.gnu.org/

licenses/old-licenses/gpl-2.0.html and http://www.gnu.org/licenses/oldlicenses/

lgpl-2.1.html.

You can also obtain a copy of gSOAP public license from http://www.cs.fsu.

edu/~engelen/license.html.

Please visit www.vizio.com for attribution of copyrights to any open source

software on your VIZIO VIA device.

Permission is hereby granted, free of charge, to any person obtaining a copy of any

such software and associated documentation ﬁles (the “Open Source Software”),

to deal in the Open Source Software without restriction, including without limitation

the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell

copies of the Open Source Software, and to permit persons to whom the Open

Source Software is furnished to do so, subject to the following conditions:

THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND,

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES

OF ERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONIN-

FRINGEMENT. IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS

BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN

ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT OF OR

IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS

IN THE SOFTWARE.

Legal & Compliance

XVT3D650SV

TRADEMARKS SHOWN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. VIZIO,

THE V LOGO, WHERE VISION MEETS VALUE, AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT

101019ST-NC

Vizio XVT3D650SV 65-Inch Theater 3D Edge Lit Razor LED LCD HDTV

Product's Documents

User Manual

Specifications

Vizio XVT3D650SV Questions and Answers

Related Products

Vizio E3D420VX Class Theater 3D LCD HDTV

Vizio M651d-A2R - 65-Inch 1080p 3D Smart LED HDTV

Angrox DH-965 Universal Remote Control for Samsung LCD LED HDTV 3D Smart TVs Versatile Compatibility and User-Friendly Design

Mitsubishi WD-60738 60-Inch 3D DLP HDTV

Mitsubishi WD-82738 82-Inch 3D DLP HDTV Home Cinema Television

Sony HMZ-T3W Wearable Hdtv, 2d/3d, Virtual 7.1 Surround Sound
