CART ASSEMBLY
30” CSS GRILL CART
INSTALLATION INSTRUCTIONS
CONTENTS QTY.
1
1
TOOLS REQUIRED
Eye Goggles
Work Gloves
Power
Screwdriver
or Variable
Speed Drill with
Phillips -tip #2
Attachment
10mm Wrench
or Socket
3/32” Allen
Wrench
CONTENTS QTY.
5
5
1
5
5
Machined
Philip screws
10-24X1/2”
Screw
1/4-20X1/2”
Screw
1/4-20X2”
Keps Nut
1/4-20
Rubber
Bumper
30” Grill Cart
Instruction
IMPORTANT!
SAVE THESE INSTRUCTIONS
●
Before you begin, read these instructions completely and carefully. Do not jump ahead or skip any step.
●
Some parts have sharp edges; care must be taken when handling the various components to avoid injury.
●
Please, read safety information provided in these instructions before beginning assembly. Wear gloves when handling.
●
Two or more people should work together to assemble the cart and grill head.
●
NOTE: Avoid using side shelf to move cart. Push or pull cart by grasping corners of grill head.
●
Remove packaging.
●
Remove side shelf and side tray from inside and discard packing.
Contents Included:
Your cart is packaged in one box. The box contains your 30” grill
cart and a universal hardware kit to be used for BGB30-BQR grill
installation and may contain extra hardware for your convenience.
GETTING STARTED
