WDH-610HE
WARNING / CAUTION
CAUTIONS
DESCRIPTION OF COMPONENTS
FUNCTION EXPLANATION
OPERATING INSTRUCTIONS
EMERGENCY
CONTINUOUS DRAINAGE
MAINTENANCE / TROUBLESHOOTING
WARNING
CAUTION
-1-
Make sure the plug
is clear.
Do not fold the power
cord as shown below.
Make sure the plug is
placed fully & firm into
the socket.
Do not use multiple
sockets as shown below.
After turning the unit off,
please take plug out of the
socket.
Do not have wet hands
when connecting the
power plug.
If the power cord on this unit is damaged it must be replaced by the manufacturer,
it's service agent or qualified persons in order to avoid a hazard.
Do not place anything
on top of the control
panel.
Do not place anything over
the air inlet or air outlet.
Do not let children play
with the unit or control
panel.
Do not wet the machine
or the control panel.
Keep flammable gas/oil
away from the machine.
Ask professionals to do
the service and repair.
Keep the unit 20cm away from the wall
to dissipate the heat properly.
CAUTIONS
-2-
Do not pull the power cord,
which may break and cause
danger.
Do not use insect, oil or paint spray
around the machine. They might
cause damage to the plastic parts
or start a fire.
Do not place the machine on
uneven ground. This may cause
shaking, noise and leakage of
water.
Close all windows and doors to
assist with the efficiency of
removing moisture.
When moving or storing the
dehumidifier do not place it
sideways or upside down. Avoid
shaking.
It is dangerous to put anything into
the machine.
Keep the machine away from any
type of heat sources.
DRAIN BUCKET
HANDLE
CONTROL PANEL
DEHUMIDIFIED
DRY AIR VENT
DESCRIPTION OF COMPONENTS
FUNCTION EXPLANATION
40% 50%
60%
BUCKET
FULL
DEFROSTCONTINUOUS
CONTINUOUS
MOIST AIR
INTAKE
AIR FILTER
When the bucket is full of
water,the dehumidifier will
stop operating automatically
and the bucket full light will
be ON.
The light is ON when
the dehumidifieris in
operation.
-3-
OPERATING INSTRUCTIONS
BUCKET
FULL
DEFROST
EMERGENCY
-4-
1) Ensure that the unit is connected to the power socket.
Start Operation
2) Make sure the water tank is placed in proper position. (When plugged
in for the first time the full tank lamp may light up. If so, just pull out
the water tank then push it back to the proper position.)
3) Press the power control to turn on the machine. Press to select humidity setting.
4) If the indoor humidity is over the set humidity, the machine will start removing moisture. When
the humidity in the room has reached the set humidity, the machine will stop operating. When
the indoor humidity is greater than the set humidity, the machine will start removing moisture
again.
When “Bucket Full” Lamp Is On
When the water tank is full, the indication lamp will light up and the dehumidifier will stop
operating. Remove the water from the tank, then place the water tank back to it's proper
position. The machine will start operating again.
DEFROST
When operating in low temperatures the surface of the dehumidifier's coil may accumulate
ice, which will affect the efficiency of the dehumidifier. When this happens, the machine will
go into periodic defrost mode automatically. This is quite normal. Defrost lamp will come on
and the machine will stop operating until the ice has melted. As soon as the ice has melted,
the machine will restart and continue the dehumidifying process. Defrost time may vary
depending on the room temperature and humidity.
The dehumidifier will operate in temperatures down to 5ºC, however it is not recommended
to use the dehumidifier in temperatures below 5ºC. If the dehumidifier freezes up, turn the
machine off for a few hours and then restart.
If a problem occurs, switch off and unplug the unit immediately. For all troubleshooting
please contact Ausclimate (www.ausclimate.com.au) and for your own safety do not
disassemble the dehumidifier.
CONTINUOUS DRAINAGE
-5-
Drain hose Back of the unit
Drain hose
The function of continuous drainage can be started in the following steps when there are good
conditions for drainage near the dehumidifier.
1. To save having to periodically empty the water
tank, this unit can be configured for continuous
drainage. You can use a PVC hose to drain out
the water - use hose with inner diameter of 13mm.
2. Remove drain cap of the drainage outlet.
3. Connect the drain hose to the drainage outlet.
Drain cap
INSTALLING DRAINAGE PVC HOSE
When using the function of continuous drainage, the PVC hose must be placed horizontally
below the level of the drainage hole. Avoid uneven ground and kinking the hose.
Continuous drainage outlet
Air filter cleans the dust and impurities from the air which may hinder the dehumidifying
function, these should be regularly cleaned. The filter is located behind the rear grill and
should be pulled outwards from the top to remove. Clean with a vacuum cleaner or wash
it with clean water and dry with a dry cloth. Replace filter and continue to operate the
dehumidifier.
Switch off and wait for temperature to rise
Seek Ausclimate advice.
Contact Ausclimate.
Contact Ausclimate.
Contact Ausclimate.
Seek Ausclimate advice.
Contact Ausclimate.
Seek Ausclimate advice.
MAINTENANCE
TROUBLESHOOTING
-6-
WDH-610HE
195 W
9.5 kg
315 x 467 x 194 mm
SPECIFICATION
If the power cord on this unit is damaged it must be replaced by the manufacturer, it's service
agent of qualified persons in order to avoid a hazard
This appliance is not intended for use by children or other persons without assistance or
supervision if their physical, sensory or mental capabilities prevent them from using it safely.
Children should be supervised to ensure that they do not play with the appliance.
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check your local authority of retailer for recycling advice.
