20L Dehumidifier with WiFi
Operating Instructions
Model: GPDH420
CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: You must not cover this appliance. Covering this appliance
presents fire risk and will activate the safety fuse; permanently disabling the
unit.
WARNING: Do not use this appliance in small rooms when they are
occupied by persons not capable of leaving the room on their own, unless
constant supervision is provided.
WARNING: To reduce the risk of fire, keep textiles, curtains, or any
flammable material a minimum distance of 1 metre from the air outlet.
General Care and Safety Guide
• Use only the voltage specified on the rating label of the appliance.
• Keep all objects at least 1 metre from the front, sides and rear of the
appliance.
• This appliance is intended for household use only and not for commercial or
industrial use.
• Indoor use only.
• Use this appliance only as described in this manual. Any other use is not
recommended by the manufacturer and may cause fire, electric shock or
injury.
• Do not use the appliance if it has been dropped or damaged.
• The common cause of overheating is deposits of dust or fluff in the appliance.
Ensure these deposits are removed regularly by unplugging the appliance and
vacuum cleaning the air vents and grills.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE
INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.
• Never use the appliance to dry clothes.
• Always unplug appliance when not in use.
• When the appliance has been unpacked, check it for transport damage and
ensure all parts have been delivered. If parts are missing or the appliance has
been damaged, contact the Customer Services Team.
• Do not use if there are visible signs of damage to the appliance.
• Do not connect the appliance to mains supply until completely assembled and
adjusted.
• Ensure hands are dry before handling the plug or main unit.
• Ensure appliance is on a flat, stable, heat-resistant surface.
• Do not operate with cord set coiled up as a heat build up is likely, which could
be sufficient to become a hazard.
• Carry out regular checks of the supply cord to ensure no damage is evident
• Do not operate this appliance with a damaged cord, plug or after the appliance
malfunctions or has been dropped or damaged in any manner. Take to a
qualified electrical person for examination, electrical service or repair.
• Do not twist, kink or wrap the cord around the appliance, as this may cause the
insulation to weaken and split. Always ensure that all cord has been removed
from any cord storage area and is unrolled before use.
• It is recommended that this appliance is plugged directly into the wall socket.
Power boards are not rated to supply power to high wattage appliances.
• A correctly specified, undamaged extension cord may be used with this
appliance provided it is used in a safe manner.
• Do not remove plug from power socket until the appliance has been switched
off.
• Do not remove plug from power socket by pulling cord; always grip plug.
• Do not place cord under carpet or cover with rugs or furniture. Arrange the cord
so it cannot be tripped over.
• Don’t place appliance on bedding or on thick & long carpet where the openings
may get blocked.
• Switch off and use handle provided when moving
• Do not place appliance close to radiant heat source.
• Do not insert or allow foreign objects to enter any ventilation or exhaust
opening, as this may cause an electric shock, fire or damage to the appliance.
• Do not sit on the appliance.
• Do not use abrasive cleaning products on this appliance. Clean with a damp
cloth (not wet) rinsed in hot soapy water only. Always remove plug from the
mains supply before cleaning.
• Do not operate in areas where petrol, paint or other flammable liquids are used
or stored.
• Do not use this appliance in the immediate surrounds of a bath, a shower, or a
swimming pool or other liquids.
General Care and Safety Guide
• The appliance must not be immersed in any liquids.
• There are no user serviceable parts installed in the unit.
• Do not place the unit in wardrobes or other enclosed spaces as this may cause
fire hazards.
• This unit is not supposed to be used in or around locations where foodstuffs,
works of art or delicate articles of science, etc. are stored.
• If your appliance does not work, or is not working properly, contact the place of
purchase or the Customer Services Team.
General Care and Safety Guide
Any repairs required, contact the nearest authorised Service
Centre and strictly follow the manufacturer’s instruction only.
Appliance is filled with flammable gas R290.
Before using the appliance, read the manual.
Before installing the appliance, read the installation manual.
Caution, risk of fire
WARNING: Appliance shall be installed, operated and stored in a room
with a floor area larger than 4m
2
.
Do not use any means to accelerate the defrosting process or to clean ,other than
those recommended by the manufacturer.
The appliance shall be stored in a room without continuously operating ignition
sources. (example: open flames, an operating gas appliance or an operating electric
heater).
Do not pierce or burn.
Be aware that refrigerants do not have any odour.
Operating Your Dehumidifier
Always choose a safe location for the dehumidifier, keeping in mind the safety
precautions outlined. Ensure all packaging has been removed from the unit before
use. Please follow the below instructions.
WARNING: In order to avoid overheating or fire, do not cover the
dehumidifier.
WARNING: Keep all objects at least 200mm from all sides of the
appliance.
WARNING: Do not use this dehumidifier with a programmer, separate
timer, remote-control system or any other device that switches the
dehumidifier on automatically, since a fire risk exists if the dehumidifier is
covered or positioned incorrectly.
WARNING:Never leave this dehumidifier unattended.
Ensure dehumidifier is on a flat, stable, heat-resistant surface.
Once the dehumidifier is in a safe operating position and all switches are in
the off position, insert the power plug into the mains outlet and switch on.
CAUTION: Ensure the power cord is not tight because if pulled it may
partially pull the plug from the socket. A partially inserted plug will overheat
the plug and socket and could result in fire.
Leave the appliance to stand for one hour after transport or after the unit has
been on its side before connecting it to the mains supply to let the refrigerant
settle.
Ensure all external windows and doors are closed before turning on the unit.
Ensure that the water container is positioned correctly.
Operating Your Dehumidifier
POWER BUTTON
Press this button to turn the appliance On or Off. When turned on, the
illuminating LED will automatically display the Relative Humidity of the room.
HUMIDITY SETTING
Relative humidity can be set from 30% to 80% by pressing the Humidity
Setting button during normal dehumidification mode. The % indicator will
flash when changes are being made.
The dehumidifier will turn off when the room reaches the set humidity.
To see the current room temperature, press and hold the Humidity Setting
button for 5 seconds until the temperature indicator (
o
C) is on.
MODES
The dehumidifier can be set to 4 modes:
• Normal: Allows manual setting of both fan speed and target humidity %
• Low Power: Automatically sets the fan speed to low. Target humidity % is
disabled and the dehumidifier will run continuously.
• High Power: Automatically sets the fan speed to high. Target humidity % is
disabled and the dehumidifier will run continuously.
• Dry Clothes: For use in the laundry when drying clothes. Target humidity %
is disabled and the dehumidifier will run continuously.
FAN SPEED
Press this button to select between low and high fan speed when in normal
mode.
Operating Your Dehumidifier
TIMER
The appliance is fitted with a timer that will turn the unit on or off after the
desired set time has elapsed.
• Turn On Timer: When the dehumidifier is off, press the timer button
repeatedly to select the desired number of hours between 1-24 hours before
the dehumidifier turns on. The “Hr” light will illuminate when the time is set.
• Turn Off Timer: When the dehumidifier is on, press the timer button
repeatedly to select the desired number of hours between 1-24 hours before
the dehumidifier turns off. The “Hr” light will illuminate when the time is set.
CHILD LOCK
Press the Child Lock button for 5 seconds to lock the control panel.
To unlock the control panel press the Child Lock button again for 5 seconds.
AIR CLEAN
This mode will filter particles and dust from the air via the washable filter.
Note: This mode will only operate the fan; dehumidifying functions cannot be
selected.
SLEEP
The Sleep Mode allows you to turn off the bright LED display panel. Press the
Sleep button once to activate Sleep Mode, the button will illuminate and the unit
will continue to operate, but the remainder of the LED display will turn off. If you
would like to adjust the settings whilst in sleep mode, press the relevant buttons
and the display will illuminate for 5 seconds and then return back to sleep mode.
Press Sleep Mode button again to reset the LED control panel back to normal.
DEFROST
When operating the unit, the evaporator will accumulate frost which will effect
the efficiency of the dehumidifier. When this happens the machine will go into
periodic defrost mode automatically and the indicator light will illuminate.
During defrost mode; the dehumidifying function and air purification function
may run intermittently – this is normal. Do not switch off unit when running in
defrost mode.
Note: Do not use the dehumidifier in temperatures less than 5
o
C. Should the
dehumidifier freeze-up switch off the appliance, allow the temperature to rise
and then restart.
Operating Your Dehumidifier
TANK FULL INDICATOR
When the water tank is full, the dehumidifier will automatically stop operating
and the full water tank indicator will illuminate. Remove the water tank carefully
with both hands and discard the water. Replace the water tank in the correct
position. The dehumidifier will automatically begin operating again.
Note: If the water tank is not installed correctly, the unit will not operate.
Always ensure that water tank is installed correctly.
REMOVING AND EMPTYING THE WATER TANK
1. To remove the water tank, gently pull the water tank out of the back of the
dehumidifier.
2. Use the handle on top of the tank to help you to empty the tank.
3. Once empty, slot the tank back into the back of the dehumidifier.
CONTINUOUS DRAINAGE
If you would like to use the dehumidifier over a long period of time whilst away
from the home, you can use the continuous drainage feature.
1. Connect the drainage hose (supplied) into the drainage point of the
dehumidifier.
2. Feed other end of the drainage hose into a suitable drainage point.
Note: When using the continuous drainage feature, the hose must be placed
below the drainage outlet without knots or kinks.
Note: When the continuous drain feature is not being used, remove the drain
hose from the drainage point, and ensure water tank is installed correctly.
CONTINUOUS DRAINAGE
REMOVING AND EMPTYING THE WATER TANK
WiFi – Downloading and Setting up APP
For WiFi, the APP is supported only on 2.4GHz WiFi channels.
Please ensure your phone is 2.4GHz capable.
Read and agree to the Privacy Policy.
Tap REGISTER in the centre of the screen.
If you already have an existing account, then you
can Log In.
Download Goldair mobile APP
• Open the APP Store or Google Play on your
mobile phone.
• Open 'Search' and enter 'Goldair'
• Click 'GET' and begin to download and install.
Once downloaded to your phone open the APP
WiFi – Downloading and Setting up APP
You need to register an email address.
Enter you email address then press 'Get authentication code'.
Pairing APP to Fan
Enter the verification code that you will receive by email
Next you will be prompted to Set a Password. The password must contain 6 - 20 characters and must be a
mix of letters and numbers.
Plug the fan into the mains power and make sure
the mains power switch is on.
On your phone open the Goldair app.
Then tap the '+' button at the top right of the screen.
Pairing APP to Fan
Your appliance should be ready to connect to your
smart phone from when you first turn it on.
Tap ‘Confirm indicator rapidly blink’ on the phone.
Press the POWER button on the dehumidifier and
the WiFi symbol starts flashing.
AIR CLEAN
Pairing APP to Fan
Choose/confirm which WiFi to connect to.
Note: your phone may pick up other WiFi signals
(e.g. neighbours) so you will need to choose.
Enter your WiFi password
The phone will then connect to the fan.
Ensure you have a good strong signal from your
WiFi router.
Note: The WiFi indicator on the fan may go off
during this pairing process.
Once complete the screen showing 'device added
successfully' will appear.
Rename the fan if desired.
Tap 'Completed' to continue.
When the phone interface shows the addition is
successful, and the WIFI indicator on the dehumidifier
will stop flashing.
The dehumidifier pairing is complete and the main
control screen on your phone will appear showing
the dehumidifier as ON.
If the phone and dehumidifier fail to connect, then you will need to try to connect again as per the
above process.
Pairing APP to Dehumidifier
Operating your dehumidifier from the APP
You can rename the dehumidifier.
Tap the ‘pen’ icon on the top right of the control
screen of the APP to take you to the next page.
Click “Device Location” and assign a location to the
dehumidifier. Example: Bedroom 1, Dining Room
etc. and tap save.
Use the arrow on top left to return to the
operation screen.
DEVICE SHARING SET UP
The person you add will need to have the Goldair
APP installed on their phone.
Open the ‘APP and choose the appliance. Tap the
‘pen’ icon in the top right of the screen.
Tap ‘Shared Devices’ to enter the number of the
person you want to include or tap the phone icon
to select the persons phone number from your
contacts.
Tap “Confirm” to complete the addition.
DEVICE SHARING CANCELLATION
Tap ‘Shared Devices’ to delete the number of the
person you want to cancel
Tap “Confirm” to complete the addition.
NOTE: There can only be one user operating the
dehumidifier at a time. The APP needs to be
closed on all other devices to enable the sharing
to work.
NOTE: If someone else sets up their phone on the
same dehumidifier without using the “Device
Sharing” the original phone will be disconnected
and the dehumidifier will disappear from the
device list.
XXXXXX
Operating your Dehumidifier from the APP
Mobile phone remote operation (connect
dehumidifier power and turn on the switch, so
that the dehumidifier is in standby mode).
Open the “GOLDAIR" APP to select the
dehumidifier (when using one mobile phone to
control multiple dehumidifier, you need to select
the dehumidifier to be operated).
• Select the dehumidifier to be operated and
enter the operation interface.
If the phone interface color is dark grey, this
indicates that the dehumidifier is in the OFF
standby setting.
• Tap the ‘POWER’ icon and the dehumidifier will
turn on.
The display will change to bright green.
• You can now control the dehumidifier.
• To turn the dehumidifier off again tap the
power icon and the dehumidifier will revert to
the dark screen.
TARGET HUMIDITY SETTING:
The required target humidity can be set from 30-
80%.
• Tap the ‘+’ or ‘-’ button to set the required
humidity.
• When the set target humidity is lower than the
relative humidity, the dehumidifier begins to
operate.
• If the set target humidity is above the relative
humidity the dehumidifier will be in standby
mode and will not operate until the relative
humidity increases above the set target
humidity.
Dark – Unit is Off
Bright Green – Unit is On
DEHUMIDIFY MODE
Press the Dehumidify icon and you can select
between Normal, Continuous, Strong and Dry
Clothes.
• Normal: Allows manual setting of both fan
speed and target humidity %
• Continuous: Automatically sets the fan speed
to low. Target humidity % is disabled and the
dehumidifier will run continuously.
• Strong: Automatically sets the fan speed to
high. Target humidity % is disabled and the
dehumidifier will run continuously.
• Dry Clothes: For use in the laundry when drying
clothes. Target humidity % is disabled and the
dehumidifier will run continuously.
FAN SPEED
Press the FAN SPEED button to switch between
HIGH & LOW fan speed. The set level will be shown
under the humidity setting on the APP
You can only adjust the fan speed in NORMAL
mode.
Operating your Dehumidifier from the APP
Operating your Dehumidifier from the APP
FUNCTION
SLEEP
The Sleep Mode allows you to turn off the bright
LED display panel. Press the Sleep button once
to activate Sleep Mode, the button will
illuminate and the unit will continue to operate,
but the remainder of the LED display will turn
off. If you would like to adjust the settings whilst
in sleep mode, press the relevant buttons and
the display will illuminate for 5 seconds and
then return back to sleep mode. Press Sleep
Mode button again to reset the LED control
panel back to normal.
AIR CLEAN
This mode will filter particles and dust from the
air via the washable filter.
Note: This mode will only operate the fan;
dehumidifying functions cannot be selected.
CHILD LOCK
Press the Child Lock button to lock the control
panel.
To unlock the control panel press the Child Lock
button again.
Operating your Dehumidifier from the APP
TIMER
The Timer in the APP has far more functionality
than the dehumidifier control panel buttons.
Sleep Timer Off
You can choose whether to turn the dehumidifier
off by selecting Add Timer and setting a specific
Time and day. Confirm the choices you select OK-
Save to activate your options.
Important Note: Make sure the Smartphone or
Tablet Clock that you are using has the right time
you are providing from the connection network to
the Internet. Possible delay or non-activation of
the timer may be
caused by an incorrect time setting on the device
you are using.
Sleep Timer On
The turn on timer can be set up to different
‘Dehumidify, ‘Fan Speed’ & ‘Target Humidity’
settings than what the dehumidifier was last set to.
• Dehumidification mode (Normal, Automatic,
Strong, Drying)
• Fan Speed (Low, High)
• Target Humidity Level (30% to 80%)
To delete a set timer, long press on the timer
and select Confirmation to delete them.
Operating Your Dehumidifier
SAFETY DEVICES
This appliance has two protection devices:
• Resettable Thermal Link - this will automatically disconnect the power to the
appliance at a pre-set overheat temperature. After cooling down it will reset and
power on again. If this occurs, investigate what is causing the appliance to overheat.
• Thermal Fuse - this disconnects the appliance permanently in case of overheating. (It
is non resettable).
CARE AND CLEANING
The dehumidifier requires regular cleaning to ensure trouble free operation:
• Unplug the dehumidifier from the mains supply before cleaning.
• Ensure that the dehumidifier has been allowed to cool down completely before
cleaning.
• The common cause of overheating is deposits of dust or fluff in the appliance. Ensure
these deposits are removed regularly by unplugging the appliance and vacuum
cleaning the air vents and grills.
The air filter should also be cleaned regularly (every 2 weeks). To remove the filter:
• Place finger in the recess area at the base of the Air Outlet Filter and gently pull
towards you and then down, the filter will now be released from the unit.
• To dislodge any dust from the filter; you can either tap filter lightly over a dustbin or
use a vacuum cleaner to remove all dirt.
• If the filter contains excessive debris which is hard to dislodge, you can remove the
carbon filter from the filter bracket and wash the filter in warm soapy water (using a
neutral detergent), rinse well with clean water and then leave until dry. Once filter is
dry, reinsert into the filter bracket.
• Replace filter back on to the unit and clip into place.
• Use a damp cloth (not wet) to wipe the exterior of the dehumidifier to remove dust
and dirt.
• Never use solutions such as petrol, thinners or polishing agents.
• Ensure the dehumidifier is dry before plugging back into the mains supply.
Washable Filter
Washable Filter Holder
Caring and Cleaning
CARE AND CLEANING CONTINUED…
• The water tank should be cleaned every few weeks to prevent growth of mould,
mildew, and bacteria.
• Partially fill the tank with clean water and add a little mild detergent. Swish it around
and then empty the tank and rinse.
To thoroughly clean and dry the tank, you can remove the handle and lid to gain access
to the inside of the tank by following these instructions:
Note: After cleaning, drying, and reassembling the water tank, it must be reinserted
securely into dehumidifier in order to restart operation.
STORAGE
If you plan on not using your dehumidifier for a long time, store your dehumidifier by
following these instructions:
1. Switch off the unit and unplug it from the mains socket.
2. Empty and clean the water tank.
3. Clean the unit and the filters (Please refer to the Care and Cleaning Section).
4. Cover the unit and keep it in a dry place.
Troubleshooting
Problem Possible Cause Possible Solution
Both fan and compressor
are not working.
No power to the unit. Check the mains power
supply. Check the control
panel is switch to “ON”.
Not collecting water. Room temperature and
humidity may be too low.
The dehumidifier will not
operate if the room
humidity is already below
the level set.
Air intake filter may be
blocked.
Clean the filter of any
obstructions.
Unit is making loud noise. Floor may be uneven. Re-position the unit on an
even stable surface.
Leaking from the unit. The water tank may not
be installed correctly.
Remove the tank and re-
fit correctly.
Unit may have frozen. Unplug the unit and allow
the temperature to rise.
SUPPORT AND TECHNICAL ADVICE
Goldair – New Zealand
Monday – Friday 8am-5pm
Phone +64 (0)9 917 4000
Phone 0800 232 633
Goldair – Australia
Monday – Friday 8am-5pm
Phone +61 (0)3 9365 5100
Phone 1300 465 324
TECHNICAL SPECIFICATION
Model No: GPDH420
Supply: 220-240VAC 50Hz
Rated Input Power: 320W (27°C/60%RH)
Max Rated Input Power: 420W (32°C/90%RH)
Rated Input Current: 1.48A (27°C/60%RH)
Max Rated Input Current: 1.91A (32°C/90%RH
Unit Capacity: 20L/day max (30°C/80%RH)
Water Tank Capacity: 5.5L
Refrigerant/Charge: R290/60g
Sound Pressure Level: 48db(A)
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.
Thank you for purchasing this Goldair Platinum product. Your product is warranted against faults and manufacture when used in
normal domestic use for a period of three years. In non-domestic use Goldair limits the voluntary warranty to three months.
Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the
warranty period.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work carried out by anyone
other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
The benefits given to you by this warranty are in addition to other rights and remedies available to you under law in relation to the
goods or services to which this warranty relates.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
In New Zealand this warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
Three Year Warranty
Goldair Three Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase Date Of Purchase
Name Of Product Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the actual product.
Goldair – New Zealand
CDB Goldair
PO Box 100-707
N.S.M.C
Auckland
Phone +64 (0)9 917 4000
Phone 0800 232 633
www.goldair.co.nz
Goldair – Australia
CDB Goldair Australia Pty
PO Box 574
South Morang
Victoria, 3752
Phone +61 (0)3 9365 5100
Phone 1300 GOLDAIR (1300 465 324)
www.goldair.com.au
New Zealand
PO Box 100707,
North Shore Mail Centre,
Auckland, 0745
www.goldair.co.nz
Australia
PO Box 574,
South Morang,
Victoria, 3752
www.goldair.com.au
