User Manual JBL On Time 400ihd High Performance Loudspeaker Dock For Ipod With Hd Radio

JBL On Time 400ihd High Performance Loudspeaker Dock For Ipod With Hd Radio - Use Manual - Use Guide PDF.
Documents: Go to donwload!
User Manual
  • Owner's manual - (English)
Other Documents
  • Owners Manual English - (English)
  • Product Brochures English - (English)
  • Product Information Sheet English - (English)

User manual of JBL ON TIME 400IHD (67 pages)
file thumbnail

• Read these instructions. heed all warnings and keep for future reference.

• Do not use this apparatus near water.

• Clean only with a dry cloth.

• Do not block any ventilation openings; a minimum distance of 10mm around the entire apparatus is required for sufficient ventilation.

• No naked flame sources. such as lighted candles. should be placed on or near the apparatus.

• Attention should be drawn to the environmental aspects of battery disposal.

• The apparatus is to be used in moderate climates only.

• Do not install near any heat sources such as radiators. heat registers. stoves or other apparatuses (including amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarizing plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or third prong is provided for safety. If the provided plug does not fit into your outlet. consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched. particularly at the plugs and convenience receptacles. and at the point where they exit from the apparatus.

• Only use attachments/accessories specified by the manufacturer.

• Unplug this apparatus during lightning storms or when unused for long periods of time.

• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way. such as the power-supply cord or plug is damaged. liquid has been spilled or objects have fallen into the apparatus. or the apparatus has been exposed to rain or moisture. does not operate normally. or has been dropped.

• To be completely disconnected from the power input. the main plug of the AC/DC adapter shall be disconnected from the main.

• The main plug of the AC/DC adapter should not be obstructed OR should be easily accessed during intended use.

• The marking information is located at the bottom of the apparatus.

• The battery shall not be exposed to excessive heat such as sunshine. fire or the like.

• The apparatus and AC/DC adapter shall not be exposed to dripping or splashing. and no objects filled with liquids. such as vases. shall be placed on the apparatus and AC/DC adapter.

• THERE IS A RISK OF EXPLOSION IF THE BATTERY IS REPLACED WITH AN INCORRECT TYPE OF BATTERY.

• TO PREVENT THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE THE COVER (OR BACK). THERE ARE NO USER-SERVICEABLE PARTS INSIDE THIS UNIT.

PLEASE REFER SERVICING TO QUALIFIED HARMAN CONSUMER GROUP. INC. SERVICE PERSONNEL.

• Never remove grille covers in order to service the speaker system. The speaker system does not contain any user-serviceable parts.

CSK - JBL On Time 400iHD Samlet v9.indd 2 15/08/08 12:35:36

CAUTION

THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU TO IMPORTANT INSTRUCTIONS ACCOMPANYING THE PRODUCT.

CAUTION: TO REDUCE THE RISK OF SHOCK. DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE LIGHTNING FLASH AND ARROWHEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU TO DANGEROUS VOLTAGE INSIDE THE PRODUCT.

RiSK OF ElECTRiC SHOCK — DO nOT OPEn

FCC STATEMEnT AnD wARninG

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference. and 2) this device must accept any interference received. including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device. pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates. uses and can radiate radio frequency energy and. if not installed and used in accordance with the instructions. may cause harmful interference to radio communications. However. there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception. which can be determined by turning the equipment off and on. the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Any special accessories needed for compliance must be specified in the instruction manual.

MODIFICATIONS NOT EXPRESSLY APPROVED BY THE MANUFACTURER COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT UNDER FCC RULES.

English

CSK - JBL On Time 400iHD Samlet v9.indd 3 15/08/08 12:35:36

HD/am/fm sPeaKer DOcK fOr iPod

The compact JBL On Time 400IHD speaker dock is an aesthetically pleasing. high-performance digital sound center that will revolution ize the way you discover music. listen to your radio and use your iPod.

The JBL On Time 400IHD system allows you to discover new music through the “TAG” feature. When using the HD Radio feature. simply press the illuminated TAG button and the JBL On Time 400IHD system will capture the song title. artist. album and all other data associated with the song that the radio station is broadcasting. The tagged information will be transferred to your iPod; when you sync your iPod to your iTunes library. you will have full access to all of the song information that you tagged.

The JBL On Time 400IHD speaker dock has full ability to navigate your iPod. both on the speaker dock itself and via IR remote. The system also lets you wake up to your favorite radio station or iPod playlist. With the multiple-alarm option. you can set “his” and “hers” alarms for whatever day or frequency you need.

EvERCHARGE TOPOlOGy The JBL On Time 400IHD speaker dock charges your iPod. even when the system is off.

The system’s memory is maintained by a backup battery. Even with the power out. it will provide the alarm function.

COE (COMPUTER-OPTiMizED EqUAlizATiOn) The JBL On Time 400IHD system equalization is computer-optimized to provide a rich. complete soundstage.

OCT (OPTiMizED COMPRESSiOn TOPOlOGy) The JBL On Time 400IHD radio and speaker dock utilizes a proprietary compression technology to ensure clean. accurate sound at high output levels.

CSK - JBL On Time 400iHD Samlet v9.indd 4 15/08/08 12:35:36

ENTER

DC In aux-in FM AM antenna

AM antenna

DC In aux-in FM AM antenna

DC In Aux In

UnPACKinG yOUR jbl On TiME 400iHD

Carefully unpack your speaker system and identify all its components:

Adapters for iPod

IR remote

Audio cable

JBL On Time 400IHD FM antenna Power supply AM antenna

English

CSK - JBL On Time 400iHD Samlet v9.indd 5 15/08/08 12:35:37

Power

Enter

UniT COnTROlS AT A GlAnCE

TAG The TAG feature is a music exploratory feature allowing you to capture information about a song and artist playing through an HD channel. Press the TAG button. and the song title and artist information currently broadcast from the HD radio station will be transferred to your docked iPod. The next time you sync your iPod to your iTunes library. all the information that you’ve tagged can be accessed.

HD Scan The HD Scan feature will surf all available HD stations until you find the station you would like to listen to.

Preset The Preset feature allows you to select or store your favorite stations. Push the “PS” button and a screen will come up to give you the option of selecting a stored favorite or storing a new favorite station.

Mode The Mode button allows you to select AM. FM. AUX or iPod listening preferences.

Volume Up Volume Down

Select both Volume + and Volume – buttons to mute.

Snooze The Snooze feature allows you to set the amount of time you would like to snooze before the alarm sounds again. Push and hold this button and you will be prompted to select a snooze duration.

Menu Up Step back one menu per button push.

Scroll Down

Scroll Up

Alarm Setting Push this button and you will be prompted to set an alarm or turn on or off an existing alarm. The alarm feature allows you to set multiple alarms at frequency ranging from daily to weekly (or limit it to just weekdays and weekends).

Sleep Mode Sleep mode allows you to fall asleep to your favorite radio station or iPod playlist.

Push this button and select a Sleep mode option.

CSK - JBL On Time 400iHD Samlet v9.indd 6 15/08/08 12:35:38

ENTER

REMOTE COnTROlS AT A GlAnCE

Power On/Power Off

HD Scan

Pause/Mute

Fast Forward

Fast Reverse

Tune/Seek Up

Snooze Recalls Snooze menu screen.

Top Menu

Preset Recalls and sets Preset stations.

Top Menu

TAG Captures song and title information when you are listening to an HD station.

Sleep Mode Hot Key

Volume Up

Volume Down

Tune/Seek Down

Mode

Scroll Down Scroll Up

English

CSK - JBL On Time 400iHD Samlet v9.indd 7 15/08/08 12:35:39

TOP MEnU

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will allow the user to select the desired setting.

Clock Setting

Alarm Setting

Preset Setting

Sleep Setting

Date Setting

Brightness/Contrast

Snooze Setting

Language Setting

Dimmer Setting

Version Info

Top Menu

1/28/09 10:34am 790am KABC

CSK - JBL On Time 400iHD Samlet v9.indd 8 15/08/08 12:35:39

6:30 AM

These buttons allow the user to scroll up and down through the highlighted text.

The Enter button allows the user to select the desired setting.

Alarm Settings See page 13

Clock Settings See page 11

Date Settings See page 12

Language Settings See page 20

AM/FM Preset Settings See page 14

Snooze Settings See page 16

Sleep Settings See page 16

Brightness/Contrast Settings See page 17 Mode Settings See page 18

HD Scan See page 18

Tag Information See page 19

Clock Setting

Alarm Setting

Preset Setting

Sleep Setting

Date Setting

Brightness/Contrast

Snooze Setting

Language Setting

Dimmer Setting

Version Info

Top Menu

1/28/09 10:34am 790am KABC

TOP MEnU

1/28/09 10:34am 1 - HD)))

790 AM KABC

Joe Smith Talk Show

Artist. song title. commercial information. etc.

1 MAin SCREEn — FM/AM

To Top Menu – See page 8

Alarm Settings See page 13

AM/FM Preset Settings See page 14

Snooze Settings See page 16

Sleep Settings See page 16

Mode Settings See page 18

HD Scan See page 18

Tag Information See page 19

CSK - JBL On Time 400iHD Samlet v9.indd 10 15/08/08 12:35:40

ClOCK SETTinG inSTRUCTiOnS

Clock setting controls can be accessed through the top menu. Push the Menu Up button until you get to the top menu screen.

Use the Scroll Up and Down buttons to highlight Clock Settings. then press Enter. Now you will be prompted to set the clock settings.

Use the Scroll Up and Scroll Down keys to highlight the desired settings and press Enter. See below for details.

Scroll Up and Down but tons are used to highlight desired setting.

The Enter button will select the desired setting.

The Menu Up button will step back the highlighted item. See Illustration A.

The Menu Up button will step back the highlighted item.

Set Clock

12:45 pm

Set Clock

12:45 pm

To Here

From Here

English

CSK - JBL On Time 400iHD Samlet v9.indd 11 15/08/08 12:35:41

DATE SETTinG inSTRUCTiOnS

Date setting controls can be accessed through the top menu. Push the Menu Up button until you get to the top menu screen.

Use the Scroll Up and Down buttons to highlight Date Settings. then press Enter. Now you will be prompted to set the date. Use the Scroll Up and Scroll Down keys to highlight the desired settings and press Enter. See below for details.

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

1 DATE SETTinG inSTRUCTiOnS — EnGliSH

2 DATE SETTinG inSTRUCTiOnS — FREnCH AnD SPAniSH

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

Set Date

Month/Day/Year

01/25/2009

Set Date

Day/Month/Year

25/01/2009

CSK - JBL On Time 400iHD Samlet v9.indd 12 15/08/08 12:35:41

AlARM SETTinG inSTRUCTiOnS

Alarm setting controls can be accessed by selecting the Alarm hot key or through the top menu. Push the Menu Up button until you get to the top menu screen.

SET nEw AlARM OR CHAnGE ExiSTinG AlARM Highlight an alarm slot and press Enter. You will now be prompted to set the wake time. alarm frequency and mode to wake to.

See illustrations.

AlARM On A full alarm bell icon indicates that the alarm is active.

AlARM OFF An empty alarm bell icon indicates that the alarm is not active.

Push the Alarm hot key button to toggle the alarm on and off.

TOGGlE AlARM On AnD OFF

SET AlARM wAKE TiME

Weekdays

Choose Alarm Frequency

Once

Weekends

Set Alarm Wake Time

11:45am Daily

Choose Wake Mode

Choose Channel

98.7 FM

12:00pm Once

11:45am Daily

8:30am Weekends

Choose Alarm

7:30am Weekdays

TOGGlE AlARM On AnD OFF Use the Scroll Up and Down buttons to highlight an alarm. then push the Alarm hot key to turn the alarm on or off. A solid alarm icon indicates that the alarm is on and an empty alarm icon indicates that the alarm is off.

English

CSK - JBL On Time 400iHD Samlet v9.indd 13 15/08/08 12:35:42

AM/FM PRESET inSTRUCTiOnS

The Preset Station menu can be accessed by selecting the PS hot key or through the top menu. Push the Menu Up button until you get to the top menu screen.

SET nEw PRESET STATiOn Push and hold the PS button and then the Place Preset menu will pop up. Next. use the Scroll Up and Scroll Down buttons to choose a slot to place the Preset station. See below.

CHOOSE OR MODiFy PRESET STATiOn Push the PS button and then use the Scroll Up and Scroll Down buttons to choose the Preset station to play. See below.

CHOOSE OR MODiFy PRESET STATiOn

SET nEw PRESET STATiOn

Empty

106.7 FM KROQ

Empty

Place Preset 100.3 FM KRBV

98.7 FM WRIF

790 AM KLOS

The Scroll buttons will allow the user to select the slot where he or she would like to place the Preset.

To overwrite an existing Preset. select the slot where you would like the new Preset to reside.

The Enter button will place the Preset or overwrite an existing Preset.

These buttons will allow the user to scroll up and down through the list of available selections.

The Enter button will select the highlighted setting.

106.7 FM KROQ

790 AM KLOS

98.7 FM WRIF

Empty

Choose Preset

Modify Preset

CSK - JBL On Time 400iHD Samlet v9.indd 14 15/08/08 12:35:42

106.7 FM KROQ

790 AM KLOS

Empty

Choose Preset To Modify

Modify Preset

98.7 FM WRIF

Select the station to modify.

Press Enter to select a station to be modified.

CHOOSE bAnD FREqUEnCy

Choose Band Frequency

Use the Scroll buttons to highlight AM or FM.

Press Enter to make your selection.

SET STATiOn

Set Station

640 AM Use the Scroll buttons to tune to the desired station.

Press Enter to select the station.

English

CSK - JBL On Time 400iHD Samlet v9.indd 15 15/08/08 12:35:43

SlEEP SETTinG inSTRUCTiOnS

The Sleep setting menu can be accessed by selecting the Sleep (ZZZ) hot key or through the top menu. Push the Menu Up button until you get to the top menu screen.

SET SlEEP TiMER Push and hold the ZZZ button and the Sleep setting menu will pop up. Next. use the Scroll Up and Scroll Down buttons to select the length of the sleep timer. See below.

SlEEP SETTinG TiMER

Set Sleep Time

10 Min

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

SnOOzE SETTinG inSTRUCTiOnS

The Snooze setting menu can be accessed by selecting the Snooze hot key or through the top menu. Push the Menu Up button until you get to the top menu screen.

SET SlEEP TiMER Push and hold the Snooze button and the Snooze setting menu will pop up. Next. use the Scroll Up and Scroll Down buttons to select the length of the snooze timer. See below.

SnOOzE SETTinG

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

Set Snooze Time

10 - 20 - 30 - 45 - 60

CSK - JBL On Time 400iHD Samlet v9.indd 16 15/08/08 12:35:43

COnTRAST AnD bRiGHTnESS

SETTinG inSTRUCTiOnS

The Contrast and Brightness setting menu can be accessed through the top menu. Push the Menu Up button until you get to the top menu screen.

SET bRiGHTnESS Use the Scroll Up and Down keys to highlight the Brightness icon. then press Enter. Next. use the Scroll Up and Scroll Down buttons to set the brightness and push Enter. See below.

COnTRAST SETTinG inSTRUCTiOnS

Set Brightness

Brightness

Contrast

Set Contrast

Brightness

Contrast

Set Brightness

Set Contrast

SET COnTRAST Use the Scroll Up and Down keys to highlight the Contrast icon. then press Enter. Next. use the Scroll Up and Scroll Down buttons to set the contrast and push Enter. See below.

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

English

CSK - JBL On Time 400iHD Samlet v9.indd 17 15/08/08 12:35:44

MODE SElECTiOn inSTRUCTiOnS

The Mode selection menu can be accessed by selecting the Mode hot key or through the top menu. Push the Menu Up button until you get to the top menu screen.

MODE SElECTiOn Use the Scroll Up and Scroll Down buttons to select the desired mode and then push Enter. See below.

HD SCAn inSTRUCTiOnS

Push the HD Scan button to scan available HD stations; once you’ve arrived at a desired station. press the Enter button.

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

MODE inSTRUCTiOnS

HD SCAn bUTTOn DEFiniTiOn

Mode Display

HD Scanning

100.3 FM

/////////////////////

1/28/09 10:34am 1 - HD)))

CSK - JBL On Time 400iHD Samlet v9.indd 18 15/08/08 12:35:44

TAG inSTRUCTiOnS

When tuned to an HD station. the TAG button can be selected to capture artist and song information.

TAGGinG A SOnG Push the TAG button and wait for the unit to confirm that information has been “Tagged.” If the iPod is docked. the “Tagged” information will be passed to the iPod and then can be accessed through iTunes the next time the iPod is synced to iTunes through your computer.

See below.

1 TAG bUTTOn DEFiniTiOn

When the TAG button is selected. the broadcasted information will be saved and transferred to the iPod.

2 TAG bUTTOn DEFiniTiOn — COnFiRMATiOn

When “Tagged” information is captured. the unit will confirm that data is captured.

TAGGING

[Artist and song title]

1/28/09 10:34am 1 - HD)))

TAGGED

Tagged Information Confirmed

1/28/09 10:34am 1 - HD)))

English

CSK - JBL On Time 400iHD Samlet v9.indd 19 15/08/08 12:35:44

Language setting menu can be accessed through the top menu. Push the Menu Up button until you get to the top menu screen.

SET lAnGUAGE Use the Scroll Up and Down keys to highlight the language preference. then press Enter. The language you select will automatically default the date settings to the regional preference. See below for details.

DATE SETTinG DEFAUlT — EnGliSH

DATE SETTinG DEFAUlT — FREnCH AnD SPAniSH

Choose Display Language

English

French

Spanish

English

French

Spanish

Choose Display Language

English

French

Spanish

Date Settings

Month/Day/Year

Day/Month/Year

Month/Day/Year

Day/Month/Year

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

Date Settings

Choose Display Language

These buttons will allow the user to scroll up and down through the highlighted text.

The Enter button will select the highlighted setting.

CSK - JBL On Time 400iHD Samlet v9.indd 20 15/08/08 12:35:45

SPECiFiCATiOnS TROUblESHOOTinG jbl On Time 400iHD sOunD QualiTY

Symptom Possible Problem Solution Note

No sound from the JBL On Time 400IHD speaker dock

No power to the unit Make sure the wall power outlet or power strip has power. Make sure all switches for outlet/power strip are on and that all switches for speaker system are on.

Is the display on? If not. power is not getting to your JBL On Time 400IHD unit; try the solutions shown.

Incorrect source selection Ensure that the correct source is selected; choose FM radio as a source. Turn up the volume. Check the system with a known good source. such as your iPod. Connect the Aux In cable to the headphone jack on your iPod.

No sound or weak signal from the AM/FM radio Bad reception from current location

Interference

Reposition your JBL On Time 400IHD unit until you find better reception.

Check surrounding area for any possible interference; wrap up any excess cables.

If you are still getting a weak signal from AM broadcasts. connect the external AM antenna to the AM antenna jack.

Sound comes only from one side/channel iPod or audio cable is not seated properly Make sure the iPod or Aux In cable is seated all the way into the JBL On Time 400IHD unit.

If you are using an extension cable or a third-party cable. make sure it’s a 3.5mm stereo male-to-male cable.

Distortion (static. crackling or hissing sounds) Noise may be caused by interference from a monitor. cell phone or other transmitting device

JBL On Time 400IHD unit is being over driven by an amplified audio source

Volume level may be too high

Turn monitor off to see whether noise is eliminated.

Move JBL On Time 400IHD unit’s cables farther away from monitor.

Ensure that the unit is connected to an appropriate source device. Make sure that all signal cables are inserted snugly into receptacles.

Check volume of source device; some devices will distort the output signal if the volume is set to Maximum.

Too much bass or treble Check the EQ setting on your iPod or source device We recommend that the source device EQ be set to Flat or Off.

JBL On Time 400IHD unit emits a loud hum or buzzing noise Input cables not plugged in properly Check input cable connection.

Speaker system experiences radio frequency interference or picks up a radio station

Input cable may be picking up interference Wrap up excess input cable to make it as short as possible.

Purchase a ferrite clamp and attach it over the input cable; a clamp can be purchased at your local electronics store.

Frequency Response: 75Hz – 20kHz

Power Consumption: 30 Watts maximum

JBL On Time 400IHD Transducer: Phoenix SE 1-3/4" (45mm) x 2 (full range per channel)

Power: 6 Watts x 2 < 1% THD

Input Impedance: >5k Ohms

Signal-to-Noise Ratio: >75dB

Input Sensitivity: 500mV RMS for rated power output

Power (USA/Canada): 120 Volts. 60Hz AC

UL/CUL/CE-Approved

Dimensions: 14-3/16" x 5" x 3-1/16" (W x D x H) (361mm x 128mm x 79mm)

Weight: 2 lb (0.9kg)

DiSPoSal: Do not dispose of this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. imPortaNt: Use UM4/AAA/LR03 alkaline-type nonrechargeable batteries only.

English

CSK - JBL On Time 400iHD Samlet v9.indd 21 15/08/08 12:35:45

TROUblESHOOTinG clOcK seT anD clOcK memOrY

Symptom Possible Problem Solution Note

Incorrect clock time when Auto Clock setting is used The local radio station sends out the time signal. but the station’s time is incorrect

Use Manual Clock setting.

Auto Clock setting does not set the clock No local station is sending the RDS time signal Use Manual Clock setting.

JBL On Time 400IHD unit does not retain memory settings when there is a power outage or if the unit is unplugged

There are no batteries installed in the unit

Batteries may be low

Make sure you install three AAA batteries in the base of the JBL On Time 400IHD unit.

If you have installed three AAA batteries. replace them. as they may be defective.

CSK - JBL On Time 400iHD Samlet v9.indd 22 15/08/08 12:35:45

JBL is a trademark of Harman International Industries. Incorporated. registered in the United States and/or other countries.

JBL On Time is a trademark of Harman International Industries. Incorporated.

HD Radio technology manufactured under license from iBiquity Digital Corporation. U.S. and foreign patents. HD Radio and the HD Radio logo are proprietary trademarks of iBiquity Digital Corp.

JBL est une marque commerciale de Harman International Industries. Incorporated. déposée aux États-Unis et/ou dans d’autres pays.

JBL On Time est une marque commerciale de Harman International Industries. Incorporated.

La technologie HD Radio fabriqué sous la licence de iBiquity Digital Corporation.

Les brevets des Etats-Unis et étrangers. La HD Radio et le logo de la HD Radio sont des marques déposées de iBiquity Digital Corp.

JBL es una marca de Harman International Industries. Incorporated. registrada en los Estados Unidos y/u otros países. JBL On Time es una marca de Harman International Industries. Incorporated.

Tecnología HD Radio desarrollada bajo licencia de iBiquity Digital Corporation. con patente en Estados Unidos y en el extranjero. HD Radio y el logo HD Radio son marcas propiedad de iBiquity Digital Corp.

Harman Consumer Group. inc.

8500 Balboa Boulevard. Northridge. CA 91329 USA 516.255.4525 (Seuls le USA) www.jbl.com

+ 2008 Harman International Industries. Incorporated. All rights reserved. Tous droits réservés.

Document Number: 950-0229-001 Rev. B

CSK - JBL On Time 400iHD Samlet v9.indd 68 15/08/08 12:36:04



Newest Added: UA TRUE WIRELESS STREAK BAR 2.1 ES90 SCS 140 FLIP 5

Tags: JBL Audio Use Manual, JBL Charge 5 Blue Tooth Speaker, Jbl Tune 510 Bt, JBL 510BT, Jbl Flip 5, Jbl Tune510, Jbl Streak

JBL ON TIME 400IHD | Pages: 67 | Created on: 2009-04-14 | File type: PDF | Filename: 57661902_on-time-400ihd.pdf | Size: 2.97 MB | Language: English | Other documents: 3 files.

Download User Manual

Product Infomation and Reviews - ON TIME 400IHD photo

ON TIME 400IHD Photo

T: @manualsFile

https://manualsFile.com

JBL ON TIME 400IHD Questions and Answers


JBL

JBL

Owner manual PDF of JBL On Time 400ihd High Performance Loudspeaker Dock For Ipod With Hd Radio.

Use manuals file type: PDF. JBL - Audio
