EN
WARRANTY
LG Electronics Inc., will repair or at its option replace, without charge, your product if it proves to be
defective in material or workmanship under normal use during the warranty period set forth below, effective
from the date of original consumer purchase of the product. This limited warranty is good only to the original
purchaser of the product and effective only when used in the United States including Alaska, Hawail, and
U.S. Territories; and Canada.
WARRANTY PERIOD HOW SERVICE IS HANDLED
1 Year from the Date of Purchase
Call 1-800-243-0000 (USA) or 1-888-542-2623 (CANADA) and choose
the appropriate prompt. Please have product type, model number,
serial number, and ZIP code ready.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED
IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. LG WILL NOT BE LIABLE FOR
ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST
REVENUSE OR PROFITS, IN CONNECTION WITH THE PRODUCT.
SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY DOES NOT APPLY TO:
1. Service trips to your home to deliver, pick up, and/or install the product, instruct, or replace house fuses
or correct wiring, or correction of unauthorized repairs; and
2. Damages or operating problems that result from misuse, abuse, operation outside environmental
specifications or contrary to the requirements or precautions in the Operating Guide, accident, vermin, fire,
flood, improper installation, acts of God, unauthorized modification or alteration, incorrect electrical current
or voltage, or commercial use, or use for other than intended purpose.
3. Therefore, the cost of repair or replacement of such a defective product shall be borne by the consumer.
CUSTOMER INFORMATION CENTER NUMBERS
To Prove Warranty Coverage
Retain your Sales Receipt to prove date of purchase.
A copy of your Sales Receipt must be submitted at the time warranty
service is provided.
To Obtain Nearest Authorized
Service Center or Sales Dealer,
or to Obtain Product,Customer,
or Service Assistance
Call 1-800-243-0000 or 1-888-542-2623 (CANADA) and choose the
appropriate prompt from the menu, and have your product type, model
number, serial number, and ZIP Code; or visit our website at http://
www.lgservice.com
EN
CAUTION
• Do not install a dryer pedestal between a
stacked washer and dryer.
6 7
EN
EN EN
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen risks
or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’
messages as described below.
Safety Messages
This symbol is displayed to indicate matters and operations
that can cause risk. Read the text marked with this symbol
carefully and follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can cause
serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can cause
minor injury or damage to the product.
WARNING
WARNING
To reduce the risk of explosion, fire, death, electric shock,
injury or scalding to persons when using this product, follow
basic precautions, including the following:
• This appliance should only be installed and transported by two or
more people holding the pedestal securely.
• Unplug the front-loading washing machine or dryer before stacking it
on top of the pedestal.
• Keep flammable materials and vapors, such as gasoline, away from
dryer.
• Place dryer at least 18 inches above the floor for a garage
installation.
INSTALLATION
Parts and Dimensions
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Front View
Included Accessories
a
a
Bracket (for Dryer) : 4 EA
Bracket (for Dryer) : 4 EA
b
b
M 4 X 20 Screws : 18 EA
M 4 X 20 Screws : 18 EA
Tools Needed
a
a
Wrench
Wrench
b
b
Screwdriver
Screwdriver
Dimensions
D
W
H
W 27" 690 mm
D 27" 690 mm
H 5 1/8" 130 mm
2 3 4
EN
5
Securely attach the two products at the
corners using screws.
• First, insert screws on each side. Then
insert screws on the front and back side.
• Tighten screws to assemble the stacking
brackets.
− For washer: 16 screws
− For dryer: 8 screws
6
Extend all 4 feet
a
of the washing machine
slightly until it is snugged up against the
pedestal. Then tighten the four lock nuts
b
.
540˚
540˚
180˚
7
Turn all 4 leveling feet
a
in one direction to
raise the pedestal or the other direction to
lower it. Then tighten the locknuts
b
.
5
Stacking Pedestal
Before Installation
• If the washer or combo was previously
installed, unplug it, disconnect the inlet hose(s)
from the faucet(s), disconnect the drain hose,
and drain all hoses.
• If dryer was previously installed, uninstall it as
follows:
− Uninstalling an electric dryer:
1) Unplug the power supply cord.
2) Pull the dryer away from the wall enough
to loosen the vent clamp. Loosen the clamp
and carefully remove the exhaust vent from
the dryer exhaust outlet.
− Uninstalling a gas dryer:
1) Unplug the power supply cord,
2) Turn off the gas supply.
3)Pull the dryer away from the wall enough to
loosen the vent clamp. Loosen the clamp and
carefully remove the exhaust vent from the
dryer exhaust outlet.
How to Stack
1
Check the fastening structure at the bottom on
the side of the product. Go to Step 2 for dryer
and Step 4 for washer.
2
Tilt and hold product.
3
Insert the T-clip
a
of the bracket
b
into the
dryer base as shown. Press up on the back of
the clip and pull outward to lock into place.
4
Place the product on top of the pedestal.
• Make sure the 4 legs are totally locked
and the holes in the pedestal align with the
holes in the washing machine.
for washer/
combo
for dryer
for dryer
for washer/
combo
Memo
Copyright © 2020 LG Electronics Inc. Todos los derechos reservados
INSTRUCCIONES DE INSTALACIÓN
PEDESTAL
Antes de comenzar con la instalación, lea atentamente estas
instrucciones. Esto simplificará el trabajo y garantizará que el producto
esté instalado de manera correcta y segura. Después de la instalación,
deje estas instrucciones cerca del producto para futuras consultas.
ESPAÑOL
WDPS1*
www.lg.com
