Location of Controls
Unit (Top)
Unit (Front)
Rear
Remote
XM
XL
XK
XI
XH
XG
XE
RK
RL
RM
X
XB
XT
is manual mainly explains operations using the
remote, but the same operations can also be performed
using the buttons on the unit having the same or similar
names.
To use the remote
Slide and remove the battery compartment lid, and insert
the two R6 (size AA) batteries (not supplied), side
rst, matching the polarities shown below.
Notes on using the remote
With normal use, the batteries should last for about six months.
Do not mix an old battery with a new one or mix dierent types of
batteries.
If you do not use the remote for a long period of time, remove the
batteries to avoid damage from battery leakage and corrosion.
OperationsGetting Started
To use the iPod/iPhone
Push up the panel
and insert a Dock Adapter into the
Dock before using. When using an iPod model, use the
Dock Adapter supplied with your iPod. When using an
iPhone model, use the Dock Adapter supplied with the
system. For details on the Dock Adapters, refer to the
instructions supplied with the Dock Adapters.
Dock Adapter
iPod/iPhone
Connector
Playing a CD/MP3 disc
1 Select the CD function.
Press FUNCTION +/
repeatedly.
2 Insert a disc.
Insert a disc in the disc slot with the label side facing
forward.
Insert a disc with the
label side facing forward.
Eject a disc
3 Start playback.
Press (play)
.
Notes
When you turn on the system, the disc is not pulled into the disc slot
until “No Disc” appears in the display. Do not attempt to push in the
disc until “No Disc” appears.
Do not insert a disc with non-standard shapes (e.g., heart, square,
star). e disc may fall into the system and cause irreparable
damage.
When pressing (eject) on the unit and then reinserting the disc
that appears in the disc slot, do not simply push in the disc. Remove
the disc from the disc slot and then reinsert it.
Do not turn o the system with a disc halfway inserted in the disc
slot. Doing so may cause the disc to fall.
Do not use a disc with tape, seals or paste on it as this may cause
malfunction.
When you eject a disc, handle the disc by its edge. Do not touch the
surface.
Do not push a disc into the disc slot when the system is o. Doing so
may cause the system to malfunction.
Do not insert an 8 cm disc with an adapter. Doing so may cause the
system to malfunction.
Other operations
To Press
Pause playback
(pause)
. To resume play, press
the button again.
Stop playback
(stop)
.
Select a folder on
an MP3 disc
(select folder) +/
repeatedly.
Select a track or
le
(go back)/ (go forward)
.
Find a point in a
track or le
Hold down (rewind)/ (fast
forward)
during playback, and
release the button at the desired
point.
Select Repeat Play
REPEAT
repeatedly until “REP”
or “REP1” appears.
Eject a disc
on the unit
.
To change the play mode
Press PLAY MODE
repeatedly while the player is
stopped. You can select Normal Play mode (“ ” for all
MP3 les in the folder on the disc), Shue Play mode
(“SHUF” or “ SHUF*” for folder shue), or Program
Play mode (“PGM”).
* When playing a CD-DA (audio) disc, (SHUF) Play performs the
same operation as normal (SHUF) Play.
Note on Repeat Play
“REP1” indicates that a single track or le is repeated until you stop
playback.
Notes on Shue Play mode
When Shue Play mode is set to “SHUF,” the system shue-plays
all tracks or les on the disc. When Shue Play mode is set to “
SHUF,” the system shue-plays all tracks or les in selected folder.
When you turn o the system, the selected Shue Play mode
(“SHUF” or “ SHUF”) is cleared and the play mode returns to
Normal Play mode (“ ”).
Notes on playing MP3 discs
Do not save other types of tracks or les, or unnecessary folders on a
disc that has MP3 les.
Folders that have no MP3 les are skipped.
MP3 les are played back in the order that they are recorded onto
the disc.
e system can only play MP3 les that have a le extension of
“.mp3”.
Even when le name has the “.mp3” le extension, if the actual
le diers, playing this le may generate a loud noise which could
damage the speaker system and the system may malfunction.
e maximum number of:
folders is 255 (including the root folder).
MP3 les is 511.
MP3 les and folders that can be contained on a single disc is 512.
folder levels (the tree structure of les) is 8.
Compatibility with all MP3 encoding/writing soware, recording
device, and recording media cannot be guaranteed. Incompatible
MP3 discs may produce noise or interrupted audio or may not play
at all.
Notes on playing multisession discs
If the rst session on the disc is a CD-DA session, the other sessions
on the disc cannot be recognized regardless of the session format;
only CD-DA tracks in the rst session can be played back.
If the session format for the rst session is CD-ROM and the
following sessions are recorded in the same format, the system will
continue to play back MP3 les accordingly in multiple sessions
until the system encounters another session recorded in a dierent
format.
Creating your own program
(Program Play)
1 Select the CD function.
Press FUNCTION +/
repeatedly.
2 Select the play mode.
Press PLAY MODE
repeatedly until “PGM”
appears while the player is stopped.
3 Select the desired track or le number.
Press /
repeatedly until the desired track
or le number appears.
When programming audio les, press +/
repeatedly to select the desired folder, and then select
the desired le.
Selected track or le number Total playing time of the selected
track or le
4 Program the selected track or le.
Press
to enter the selected track or le.
5 Repeat steps 3 through 4 to program additional
tracks or les, up to a total of 25 tracks or les.
6 To play your program of tracks or les, press
.
e program remains available until you remove the
disc from the disc slot or unplug the power cord.
To play the same program again, press
.
To cancel Program Play
Press PLAY MODE
repeatedly until “PGM”
disappears while the player is stopped.
To delete the last track or le of the program
Press CLEAR
while the player is stopped.
To view program information
Press DISPLAY
repeatedly.
Listening to the radio
1 Select the TUNER function.
Press FUNCTION +/
repeatedly.
2 Perform tuning.
For automatic scanning
Press TUNING MODE
repeatedly until “AUTO”
appears, and then press +/
. Scanning stops
automatically when a station is tuned in, and
“TUNED” and “STEREO” (for stereo programs only)
light up in the display.
If “TUNED” does not light up and the scanning
for an FM station does not stop, press
to stop
scanning, then perform manual tuning (below).
When you tune in an FM station that provides RDS
services, information such as the service name or
station name is provided by broadcasts.
For manual tuning
Press TUNING MODE
repeatedly until “AUTO”
and “PRESET” disappear, and then press +/
repeatedly to tune in the desired station.
Tip
To reduce static noise on a weak FM stereo station, press FM MODE
repeatedly until “MONO” appears to turn o stereo reception.
Presetting radio stations
1 Tune in the desired station.
2 Press TUNER MEMORY
to select the tuner
memory mode.
3 Press +/
repeatedly to select the desired preset
number.
If another station is already assigned to the selected
preset number, the station is replaced by the new
station.
4 Press
to store the station.
5 Repeat steps 1 through 4 to store other stations.
You can preset up to 20 FM stations.
6 To call up a preset radio station, press TUNING
MODE
repeatedly until “PRESET” appears, and
then press +/
repeatedly to select the desired
preset number.
FM antenna
Find a location and an orientation that provide good
reception, and then set up the antenna.
Keep the antennas away from the speaker cords and the
power cord to avoid picking up noise.
Speakers
Connect the speaker cords to the SPEAKERS jacks on
the unit.
Power
1 Connect the power cord to the AC adapter.
2 Connect the AC adapter to the unit, and then plug
the power cord in to a wall outlet.
e demonstration appears in the display. When
you press
, the system turns on and the
demonstration automatically ends. When you turn o
the system, the demonstration appears again on the
display.
When you set the clock, the system goes to Power
Saving mode and the demonstration is canceled.
When not using an iPod/iPhone, keep the panel closed.
To remove the Dock Adapter, pull it up with your
ngernail or a at object using the slot inside the adapter.
About Dock Adapters for iPhone models
e adapter number is shown on the bottom of Dock
Adapter.
For iPod models, use the Dock Adapter supplied with
your iPod, or purchase a compatible dock adapter from
Apple Inc.
: For iPhone
: For iPhone 3G and iPhone 3GS
: For iPhone 4
Installations
Attaching the stand to the system
Tabs
Tabs
Tabs
Removing
Stand
1 Insert the tabs of the stand into the grooved section
of the unit.
2 While holding down bottom of the stand, insert the
tabs of the stand into the grooved section.
To remove the stand from the system
While holding down bottom of the stand, pull up the tabs
of the stand from the unit.
Hanging the system on a wall
You can install the system on a wall. Before installing,
remove the stand from the unit.
Notes
Make sure that the power cord is disconnected from the wall outlet
before installing the system.
Use screws that are suitable for the wall material and strength.
Contact a screw shop or professional installer regarding the
installation, wall material, or screws.
Insucient wall strength or use of inappropriate screws may cause
the system to fall and be damaged and may result in personal injury.
1 Attach the supplied pads to the rear of the speakers
and unit.
Location for
pasting on the
pads
2 Prepare screws (not supplied) that are suitable for
the holes on the back of the unit and speakers. See
the illustrations below.
Holes on the back of the unit
and speakers
4.6 mm
(/ inch)
10 mm
(/ inch)
3 Fasten the screws to the wall. The commercially
available screws should protrude 3 to 4 mm (/ to
/ inch).
Install the system on a vertical and at reinforced area
of the wall.
3 to 4 mm (/ to
/ inch)
190 mm
(7 / inches)
Tips
When installing the speakers and unit close together, fasten the
screws to the wall according to the marks on the lower side, as
illustrated in this manual.
e distance between the screw of the unit and a speaker is
90 mm (3
/ inches) minimum. To install the system leaving
space between the unit and speakers, adjust the length of the
speaker cord before installing the system.
You can wrap the speaker cord around the protruding on the
rear of the unit, as illustrated.
4 Hang the system onto the screws.
Align the holes the back of the system to the screws,
then hang the system onto 4 screws.
Rear of the speaker
Notes
Make sure the screws are properly aligned, with their heads evenly
protruding enough to engage the holes on the back of the unit and
speakers.
Be aware that is a person or object happens to hit the system hanging
on a wall, it may fall.
Do not hang or put anything on the system hanging on a wall.
Depending on the materials of the wall, heat from the system or dust
may cause peeling or discoloration of wallpaper.
Sony is not responsible for accidents or damage caused by improper
installation, insucient wall strength or improper screw installation,
natural calamity, etc.
To enjoy better sound quality
You can get better sound quality with optimal location of
the speakers.
For better sound quality, install the system according to
the reference below.
It is better to arrange le-right placement of the
speakers according to the usual orientation of the
listener in the room.
Speakers are better installed at usual ear level in a room.
To set the clock
1 Press
to turn on the system.
2 Press TIMER MENU
to select the clock set mode.
If “PLAY SET?” ashes, press /
repeatedly to
select “CLOCK SET?,” and then press (enter)
.
3 Press /
repeatedly to set the hour, then press
(enter)
.
4 Use the same procedure to set the minutes.
Note
e clock settings are reset when you disconnect the power cord or if
a power failure occurs.
To display the clock when the system is o
Press DISPLAY
. e clock is displayed for about
8 seconds.
FM lead antenna (Extend it
horizontally.)
Speaker cord (right)
Speaker cord (left)
To AC Adapter
Screw Screw Screw Screw
Right Speaker
(Center)
Left Speaker Main unit
4-278-002-13 (1)
Micro HI-FI
Component System
GB
Operating Instructions
©2011 Sony Corporation Printed in China
CMT-CX4iP
Loading ...
