2-680-136-11(1)
© 2006 Sony Corporation
Digital Still Camera
Cyber-shot
Handbook
Handbook
Before operating the unit, please read this handbook and
“Instruction Manual” (separate volume) thoroughly, and
retain them for future reference.
Owner’s Record
The model and serial numbers are located on the bottom.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your Sony
dealer regarding this product.
Model No. DSC-S45
Serial No. ___________________________
DSC-S45
“Instruction Manual” (separate volume)
Explains the set-up and basic operations
for shooting/playback with your camera.
Instruction Manua
l
Digital Still Camera
Enjoying the
camera
Using the menu
Using the Setup screen
Using your computer
Printing still images
Connecting your
camera to your TV
Troubleshooting
Others
Index
2
To reduce fire or shock hazard, do
not expose the unit to rain or
moisture.
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any
interference received, including interference that
may cause undesired operation.
CAUTION
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.
Note:
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV
technician for help.
The supplied interface cable must be used with the
equipment in order to comply with the limits for a
digital device pursuant to Subpart B of Part 15 of
FCC Rules.
WARNING
For Customers in the U.S.A.
This symbol is intended to
alert the user to the presence
of uninsulated “dangerous
voltage” within the product's
enclosure that may be of
sufficient magnitude to
constitute a risk of electric
shock to persons.
This symbol is intended to
alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
3
Notes on using your camera
Types of “Memory Stick” that can be used
(not supplied)
The IC recording medium used by this
camera is a “Memory Stick Duo”. There are
two types of “Memory Stick”.
“Memory Stick Duo”: you can use a
“Memory Stick Duo” with your camera.
“Memory Stick”: you cannot use
a
“Memory Stick” with your camera.
Other memory cards cannot be used.
• For details on “Memory Stick Duo”, see page
83.
When using a “Memory Stick Duo” with
“Memory Stick” compatible equipment
You can use the “Memory Stick Duo” by
inserting it into the Memory Stick Duo
Adaptor (not supplied).
Memory Stick Duo Adaptor
No compensation for contents of the
recording
• The contents of the recording cannot be
compensated for if recording or playback is not
possible due to a malfunction of your camera or
recording media, etc.
Internal memory and “Memory Stick Duo”
back up
• Do not turn off the camera or remove the battery
pack or “Memory Stick Duo” while the access
lamp is lighted, as the internal memory data or
“Memory Stick Duo” data may be destroyed.
Always protect your data by making a back up
copy. See page 22 for the data back up method.
Notes on recording/playback
• This camera is neither dust-proof, nor splash-
proof, nor water-proof. Read “Precautions”
(page 87) before operating the camera.
• Before you record one-time events, make a trial
recording to make sure that the camera is
working correctly.
• Be careful not to get the camera wet. Water
entering the inside of the camera may cause
malfunctions which in some cases may not be
repairable.
• Do not aim the camera at the sun or other bright
light. This may cause irrecoverable damage to
your eyes. Or it may cause the malfunction of
your camera.
• Do not use the camera near a location that
generates strong radio waves or emits radiation.
The camera may not be able to record or play
back properly.
• Using the camera in sandy or dusty locations
may cause malfunctions.
• If moisture condensation occurs, remove it
before using the camera (page 87).
• Do not shake or strike the camera. In addition to
malfunctions and an inability to record images,
this may render the recording medium unusable,
or cause image data breakdown, damage or loss.
• Clean the flash surface before use. The heat of
flash emission may cause dirt on the flash
surface to become discolored or to stick to the
flash surface, resulting in insufficient light
emission.
Notes on the LCD screen and lens
• The LCD screen is manufactured using
extremely high-precision technology so over
99.4% of the pixels are operational for effective
use. However, there may be some tiny black
points and/or bright points (white, red, blue, or
green in color) that constantly appear on the
LCD screen. These points are normal in the
manufacturing process and do not affect the
recording in any way.
Black, white, red,
blue and green
points
4
• Exposing the LCD screen or the lens to direct
sunlight for long periods may cause
malfunctions. Be careful when placing the
camera near a window or outdoors.
• Do not press against the LCD screen. The screen
may be discolored and that may cause a
malfunction.
• Images may trail across on the LCD screen in a
cold location. This is not a malfunction.
• This camera is equipped with a power zoom
lens. Be careful not to bump the lens, and be
careful not to apply force to it.
On image data compatibility
• This camera conforms with DCF (Design rule
for Camera File system) universal standard
established by JEITA (Japan Electronics and
Information Technology Industries
Association).
• Playback of images recorded with your camera
on other equipment and playback of images
recorded or edited with other equipment on your
camera are not guaranteed.
Warning on copyright
Television programs, films, videotapes, and other
materials may be copyrighted. Unauthorized
recording of such materials may be contrary to the
provisions of the copyright laws.
The pictures used in this manual
The photographs used as examples of pictures in
this manual are reproduced images, and are not
actual images shot using this camera.
5
For full use of the digital still camera
Prepare the camera and shoot images easily
“Instruction Manual”(Separate Volume)
Get more friendly with your camera
This manual
• Shoot with your favorite settings (Program auto shooting)
t page 24
• Enjoy various shooting/playback using the menu t page 26
• Change the default settings t page 37
Connect your camera to a PC or a printer
This manual
• Copy your images to a computer and enjoy editing them in
various ways t page 46
• Print images by connecting your camera directly to a printer
(PictBridge compliant printers only) t page 63
Instruction Manua
l
Dig
ita
l S
till C
a
me
ra
2
1
6
Table of contents
Notes on using your camera ..................................................................... 3
Basic techniques for better images........................................................... 9
Focus – Focusing on a subject successfully..................................................... 9
Exposure – Adjusting the light intensity........................................................... 10
Color – On the effects of lighting ..................................................................... 11
Quality – On “image quality” and “image size” ............................................... 12
Identifying parts....................................................................................... 14
Indicators on the screen.......................................................................... 16
Changing the screen display................................................................... 20
Number of still images and recording time of movies ............................. 21
When you do not have a “Memory Stick Duo” (Recording with the internal
memory).................................................................................................. 22
Battery life and number of images that can be recorded/viewed............ 23
Using the mode dial ................................................................................ 24
Using menu items .............................................................................. 26
Menu items .......................................................................................... 27
Shooting menu........................................................................................ 28
(EV)
(Metering Mode)
WB (White Bal)
ISO
(P.Quality)
Mode (REC Mode)
PFX (P.Effect)
(Saturation)
(Sharpness)
(Setup)
Enjoying the camera
Using the menu
7
Viewing menu..........................................................................................32
(Folder)
- (Protect)
DPOF
(Print)
(Slide)
(Resize)
(Rotate)
(Setup)
Using Setup items..............................................................................37
Camera ..............................................................................................38
Digital Zoom
Date/Time
Red Eye Reduction
Auto Review
Internal Memory Tool ........................................................................40
Format
Memory Stick Tool.............................................................................41
Format
Create REC. Folder
Change REC. Folder
Copy
Setup 1 ...............................................................................................43
LCD Backlight
Beep
Initialize
Setup 2 ...............................................................................................44
File Number
USB Connect
Video Out
Clock Set
Enjoying your Windows computer ...........................................................46
Installing the software (supplied).............................................................48
Copying images to your computer...........................................................49
Using the Setup screen
Using your computer
1
2
8
Viewing image files stored on a computer with your camera (using a
“Memory Stick Duo”) ............................................................................... 55
Using the “Cyber-shot Viewer” (supplied) ............................................... 56
Using your Macintosh computer ............................................................. 60
How to print still images .......................................................................... 62
Printing images directly using a PictBridge compliant printer ................. 63
Printing at a shop .................................................................................... 66
Viewing images on a TV screen ............................................................. 68
Troubleshooting ...................................................................................... 70
Warning messages ................................................................................. 81
On the “Memory Stick” ............................................................................ 83
On the batteries ...................................................................................... 85
Precautions ............................................................................................. 87
Printing still images
Connecting your camera to your TV
Troubleshooting
Others
Index
...................................................................................................... 88
9
Enjoying the camera
Enjoying the camera
Basic techniques for better images
When you press the shutter button halfway down, the camera adjusts the focus automatically
(Auto Focus). Remember to press the shutter button only halfway down.
If the image looks blurred even after focusing, it may be because of camera shake.
t See
“Hints for preventing blur” (below).
Focus
Focusing on a subject successfully
Press the shutter
button fully down
straight away.
Press the shutter
button halfway
down.
AE/AF lock indicator
Flashing,lit/beeps
Then press the
shutter button
fully down.
Hints for preventing blur
Hold the camera steadily, keeping your arms at your side. Also, you can stabilize the
camera by leaning against a tree or a building beside you. Using a tripod, and using the
flash in dark places are also recommended.
Focus Exposure Color Quality
This section describes the basics so you can
enjoy your camera. It tells you how to use
various camera functions such as the mode
dial (page 24), the menus (page 26), and so
on.
30
VGA
FINE
F2.833
10
You can create various images by adjusting the exposure and the ISO sensitivity. Exposure is
the amount of light that the camera will receive when you release the shutter.
Exposure
Adjusting the light intensity
Overexposure
= too much light
Whitish image
The exposure is automatically set to the
proper value in the auto adjustment mode.
However, you can adjust it manually using
the functions below.
[EV]:
Allows you to adjust the exposure that has
been determined by the camera.
t
page 28
[Metering Mode]:
Allows you to change the part of the
subject to be measured to determine the
exposure. t page 28
Correct exposure
Underexposure
= too little light
Darker image
Shutter speed = Length of time the camera receives
light
Aperture = Size of the opening allowing light to pass
through
ISO =
Recording sensitivity
Exposure:
11
Enjoying the camera
Adjusting the ISO sensitivity
ISO is unit of measurement (sensitivity), estimating how much light an image pickup device
(equivalent to photo films) receives. Even when the exposure is the same, images differ
depending on the ISO sensitivity.
[ISO] adjusts the sensitivity t page 29
The apparent color of the subject is affected by the lighting conditions.
Example: The color of an image affected by light sources
The color tones are adjusted automatically in the auto adjustment mode.
However, you can adjust color tones manually with [White Bal] (page 29).
High ISO sensitivity
Records a bright image even when shooting in a dark location. However, the
image tends to become noisy.
Low ISO sensitivity
Records a smoother image.
However, the image may become darker.
Color
On the effects of lighting
Weather/lighting
Daylight Cloudy Fluorescent Incandescent
Characteristics of
light
White (standard) Bluish Blue-tinged Reddish
12
A digital image is made up of a collection of small dots called pixels.
If it contains a large number of pixels, the picture becomes large, it takes up more memory,
and the image is displayed in fine detail. “Image size” is shown by the number of pixels.
Although you cannot see the differences on the screen of the camera, the fine detail and data
processing time differ when the image is printed or displayed on a computer screen.
Description of the pixels and the image size
Quality
On “image quality” and “image size”
1 Image size: 5M
2,592 pixels×1,944 pixels = 5,038,848 pixels
2 Image size: VGA(E-Mail)
640 pixels×480 pixels = 307,200 pixels
640
480
2592
1944
Pixels
13
Enjoying the camera
Selecting the image size for use
The default settings are marked with .
* Images are recorded in the same 3:2 aspect ratio as photograph printing paper or postcards, etc.
Selecting the image quality (compression ratio) in combination (page 29)
You can select the compression ratio when digital images are saved. When you select a high
compression ratio, the image lacks the fineness of detail, but has a smaller file size.
Pixel
Many (Fine image
quality and large file
size)
Example: Printing in up to A4
size
Few (Rough image
quality but small file
size)
Example: An attached image
to be sent by e-mail
Image size Usage guidelines
5M (2592×1944) Larger
Smaller
For printing in A4 size or high density images in A5
size
3:2 (2592×1728)
3M (2048×1536)
1M (1280×960) For printing in postcard size
For recording a large number of images
For attaching images to e-mail or creating web pages
VGA (E-Mail)
(640×480)
14
Identifying parts
See the pages in parentheses for details of
operation.
A Shutter button
B Mode dial (24)
C Microphone
D Lens
E POWER button / lamp
F Flash
G Self-timer lamp
H Buzzer
I USB jack
J A/V OUT jack
K Tripod receptacle
• Use a tripod with a screw length of less than
5.5mm (7/32 inch). You will be unable to
firmly secure the camera to tripods having
screws longer than 5.5mm (7/32 inch), and
may damage the camera.
L Battery/“Memory Stick Duo” cover
M AC Adaptor cord cover
To use the AC-LS5K AC Adaptor (not
supplied)
qa
qs
qd
6
7
8
9
1
2
3
4
5
q;
4
5
1
2
3
Do not pinch the cord when you close
the cover.
15
Enjoying the camera
N LCD screen (20)
O For shooting: Zoom (W/T) button
For viewing: / (Playback zoom)
button/ (Index) button
P Screen status button (20)
Q Hook for wrist strap
R MENU button (26)
S Control button
Menu on: v/V/b/B/
z
Menu off: / / /
T Access lamp
U (Image Size/Delete) button
N
Q
S
P
O
R
U
T
16
Indicators on the screen
See the pages in parentheses for details of
operation.
When shooting still images
When shooting movies
A
B
+2.0
EV
F2.833
101
VGA
30
30
+2.0
EV
F2.833
101
VGA
30
30
101
+
[00:00:30]00:00:00
STBY
+2.0
EV
Display Indication
Battery remaining
z AE/AF lock
Recording mode (24, 30)
White balance (29)
STBY
REC
Standby/Recording a movie
Mode dial (Scene
Selection)
Mode dial (24)
Flash mode
Flash charging
Red-eye reduction (39)
Sharpness (31)
5 Saturation (31)
Metering mode (28)
Picture effect (30)
Display Indication
Macro
SL
17
Enjoying the camera
CD
E
Display Indication
Image size
FINE STD Image quality (29)
Recording folder (41)
• This does not appear when
using the internal memory.
Remaining internal
memory capacity (21)
Remaining “Memory Stick
Duo” capacity (21)
00:00:00
[00:00:30]
Recording time [maximum
recordable time] (21)
30 Remaining number of
recordable images (21)
Self-timer
Date/Time (39)
ISO number (29)
3:2
3M5M
1M VGA
320
101
Display Indication
E Low battery warning (23,
81)
+ Spot metering cross hair
(28)
AF range finder frame (9)
Display Indication
33 Shutter speed
F2.8 Aperture value
+2.0EV EV level value (28)
(not displayed
on the screen
on the previous
page)
Menu / Guide Menu (26)
18
When playing back still images
When playing back movies
A
B
C
101
VGA
1.3
101
12/12
+2.0EV
F2.833
BACK/NEXT
Display Indication
Battery remaining
Image size
Recording mode (24, 30)
N Playback
- Protect (33)
Print order (DPOF) mark
(66)
Change folder (32)
• This does not appear when
using the internal memory.
Zoom scaling
Display Indication
101-0012 Folder-file number (32)
Playback bar
Display Indication
PictBridge connecting (63)
Recording folder (41)
• This does not appear when
using the internal memory.
Playback folder (32)
• This does not appear when
using the internal memory.
Remaining internal
memory capacity (21)
Remaining “Memory Stick
Duo” capacity (21)
8/8 12/12 Image number/Number of
images recorded in selected
folder
00:00:12 Counter
3:2
3M5M
1M VGA
320
1.3
101
101
19
Enjoying the camera
D
E
Display Indication
Do not disconnect the USB
cable (65)
+2.0EV EV level value (28)
ISO number (29)
Metering mode (28)
Flash
White balance (29)
33 Shutter speed
F2.8 Aperture value
Playback image
Display Indication
2006 1 1
Recording date/time of the
playback image
Menu / Guide Menu (26)
BACK/
NEXT
Select images
DPOF
20
Changing the screen display
Each time you press the Screen status
button, the display changes as follows.
30
VGA
Indicators on
Indicators off
21
Enjoying the camera
Number of still images and recording time of
movies
The tables show the approximate number of still images and the length of time for movies that
can be recorded on a “Memory Stick Duo” and internal memory (10 MB) formatted with this
camera. The values may vary depending on the shooting conditions.
The number of still images (The image quality is [Fine] on the upper line and
[Standard] on the lower line.)
• The number of images listed is for when [Mode] is set to [Normal].
• When the number of remaining shootable images is greater than 9,999, the “>9999” indicator appears.
• You can resize the images later ([Resize], (page 35)).
The recording time of movies (hour : minute : second)
• For image size and image quality, see page 12.
• When images recorded using earlier Sony models are played back on this camera, the display may differ
from the actual image size.
Capacity
Size
Internal
Memory
32MB 64MB 128MB 256MB 512MB 1GB 2GB
5M 312245096191391797
7 23 46 95 182 360 736 1501
3:2 3 12 24 50 96 191 391 797
7 23 46 95 182 360 736 1501
3M 6 19 39 81 155 308 629 1282
11 35 72 148 283 560 1143 2330
1M 15 48 98 201 384 759 1550 3159
28 91 184 375 715 1414 2886 5880
VGA(E-Mail) 60 191 387 789 1503 2972 6065 12355
147 463 935 1879 3630 7167 14643 29830
Capacity
Size
Internal
Memory
32MB 64MB 128MB 256MB 512MB 1GB 2GB
320×240
0:00:30 0:01:37 0:03:17 0:06:38 0:12:50 0:25:24 0:51:50 1:45:38
22
When you do not have a “Memory Stick Duo”
(Recording with the internal memory)
The camera has 10 MB of internal memory. This memory is not removable. Even when there
is no “Memory Stick Duo” inserted in the camera, you can record images using this internal
memory.
We recommend that you copy (back up) data without fail using one of the following methods.
To copy (back up) data on a “Memory Stick Duo”
Prepare a “Memory Stick Duo” with a capacity of 16 MB or more, then perform the procedure
explained in [Copy] (page 42).
To copy (back up) data on a hard disc of your computer
Perform the procedure on pages 49 to 51 without a “Memory Stick Duo” inserted in the
camera.
• You cannot move image data on a “Memory Stick Duo” to the internal memory.
• By connecting the camera and a computer with a USB cable, you can copy data stored in the internal
memory to a computer, but you cannot copy data on a computer to the internal memory.
When a “Memory Stick Duo” (not supplied)
is inserted
[Recording]: Images are recorded on the “Memory Stick
Duo”.
[Playback]: Images on the “Memory Stick Duo” are
played back.
[Menu, Setup, etc.]: Various functions can be performed
on images on the “Memory Stick Duo”.
When there is no “Memory Stick Duo”
inserted
[Recording]: Images are recorded using the internal
memory.
[Playback]: Images stored in the internal memory are
played back.
[Menu, Setup, etc.]: Various functions can be performed
on images in the internal memory.
On image data stored in the internal memory
Internal
memory
B
B
23
Enjoying the camera
Battery life and number of images that can be
recorded/viewed
The tables show the approximate number of
images that can be recorded/viewed and the
battery life when you shoot images in
[Normal] mode with batteries at full
capacity and at an ambient temperature of
25°C (77°F). The numbers of images that
can be recorded or viewed take into account
changing the “Memory Stick Duo” as
necessary.
Note that the actual numbers may be less
than those indicated depending on the
conditions of use.
• The battery capacity decreases as the number of
uses increases and also over time (page 85).
• The number of images that can be recorded/
viewed and the battery life are decreased under
the following conditions:
– The surrounding temperature is low
– The flash is used
– The camera has been turned on and off many
times
– The zoom is used frequently
– [LCD Backlight] is set to [Bright]
– The battery power is low
When shooting still images
• Shooting in the following situations:
– (P.Quality) is set to [Fine]
– Shooting once every 30 seconds
– The zoom is switched alternately between the
W and T ends
– The flash strobes once every two times
– The power turns on and off once every ten
times
• The measurement method is based on the CIPA
standard.
(CIPA: Camera & Imaging Products
Association)
• Number of shooting images/battery life does not
change depending on the image size.
When viewing still images
• Viewing single images in order at about three
second intervals
When shooting movies
• Shooting movies continuously with an image
size of [320]
Battery
No. of images
(Approx.)
Battery life
(min.) (Approx.)
Alkaline 90 45
NH-AA-DB
(Ni-MH)
350 170
Battery
No. of images
(Approx.)
Battery life
(min.)
(Approx.)
Alkaline 1800 90
NH-AA-DB
(Ni-MH)
4800 240
Battery
Battery life (min.) (Approx.)
Alkaline 40
NH-AA-DB
(Ni-MH)
120
24
Using the mode dial
Set the mode dial to the desired function.
Still image shooting modes
In this Cyber-shot Handbook, the available!mode dial setting is shown as follows.
: Auto adjustment mode
Allows easy shooting with the settings adjusted automatically.
: Scene Selection mode
Allows you to shoot with preset settings according to the scene.
P: Program auto shooting mode
Allows you to shoot with the exposure adjusted automatically (both the shutter
speed and the aperture value). Also you can select various settings using the
menu.
(For details on the functions available t page 27)
Control button
Mode dial
: Shooting movies
: Playback/Edit
Unavailable Available
25
Enjoying the camera
Scene Selection
For shooting an image appropriately according to the scene condition, a combination of
functions is determined by the camera.
( : you can select the desired setting)
Macro Flash White Balance Burst
——
Auto —
——
/
— /
SL
26
Using the menu
Using menu items
1 Turn on the power and set the mode dial.
Items available vary depending on the mode dial position.
2 Press MENU to display the menu.
3 Select the desired menu item with b/B
on the control button.
• If the desired item is invisible, keep pressing b/B
until it appears on the screen.
• Press z after selecting an item when the mode dial
is set to .
4 Select the setting with v/V.
The setting you select is zoomed and is set.
5 Press MENU to turn off the menu.
• If there is an item that is not displayed, an v/V mark appears on the edges of the location where menu
items usually appear. To display an item that is not displayed, select the mark with the control button.
• You cannot select items that are grayed out.
v/V/b/B button
z button
Mode dial
Control button
MENU button
80
100
400
200
Auto
ISO
WB
ISO
27
For details on the operation
t
page 26
Using the menu
Menu items
The menu items available vary depending on the mode dial position. Only the available items
are displayed on the screen.
Menu for viewing (page 32)
* The operation is limited according to the Scene mode (page 25).
( : available)
Mode dial position: P Scene
Menu for shooting (page 28)
(EV) — —
(Metering Mode) — —
WB (White Bal) — —
ISO — — —
(P.Quality) — — —
Mode (REC Mode) — —
PFX (P.Effect) — —
(Saturation) — — — —
(Sharpness) — — — —
(Setup)
—
(Folder) ————
- (Protect) ————
DPOF ————
(Print) ————
(Slide) ————
(Resize) ————
(Rotate) ————
(Setup) ————
28
For details on the operation
t
page 26
Shooting menu
The default settings are marked with .
Manually adjusts the exposure.
Toward – Toward +
• For details on the exposure t page 10
• The compensation value can be set in 1/3EV increments.
• If a subject is being shot in extremely bright or dark conditions, or the flash is used, the exposure
adjustment may not be effective.
Selects the metering mode that sets which part of the subject to measure to determine the
exposure.
• For details on the exposure t page 10
(EV)
M +2.0EV
Toward +: Brightens an image.
0EV
The exposure is determined automatically by the camera.
m –2.0EV
Toward –: Darkens an image.
(Metering Mode)
Spot (Spot metering)
()
Measures only a part of the subject.
• This function is useful when the subject is backlit or when there
is strong contrast between the subject and the background.
Multi (Multi-pattern
metering)
Divides into multiple regions and measures each region. The
camera determines a well-balanced exposure.
VGA
F2.833
30
FINE
P
Spot metering cross hair
Positions on the subject.
29
Using the menu
For details on the operation
t
page 26
Adjusts the color tones according to the lighting condition in a situation, for example, when
the colors of a image look strange.
• For details on [WB] t page 11
• Under fluorescent lights that flicker, the white balance function may not work correctly even though you
select (Fluorescent).
Selects a luminous sensitivity with units of ISO. The larger the number, the higher the
sensitivity.
• For details on the [ISO] sensitivity t page 11
• Note that the image tends to become noisier as the ISO sensitivity number increases.
• [ISO] is set to [Auto] in the Scene mode.
Selects the still image quality.
• For details on the image quality t page 12
WB (White Bal)
n (Incandescent)
Adjusts for places where the lighting conditions change
quickly such as a party hall, or under bright lighting such as
photography studios.
(Fluorescent)
Adjusts for fluorescent lighting.
(Cloudy)
Adjusts for a cloudy sky.
(Daylight)
Adjusts for outdoors, shooting night scenes, neon signs,
fireworks, or sunrise, or conditions before and after sundown.
Auto
Adjusts the White Balance automatically.
ISO
400
Select a large number when shooting in dark locations or
shooting a subject moving at high speed, or select a small
number to obtain high image quality.
200
100
80
Auto
(P.Quality)
Fine (FINE)
Records with high quality (low compression).
Standard (STD)
Records with standard quality (high compression).
W
B
W
B
30
For details on the operation
t
page 26
Selects whether the camera performs continuous shooting or not when you press the shutter
button.
On the [Burst]
• The flash is set to (No flash).
• When recording with the self timer, a series of a maximum of three images is recorded.
• When the battery level is low, or when the internal memory or “Memory Stick Duo” is full, the [Burst]
stops.
• You may not be able to shoot images in the [Burst] mode depending on the Scene mode (page 25).
The maximum number of continuous shots
(Units: images)
Allows you to shoot an image with special effects.
Mode (REC Mode)
Burst ( )
Records the maximum number of images in succession (refer
to the following table) when you press and hold down the
shutter button.
• When “Recording” disappears, you can shoot the next image.
Normal
Does not shoot continuously.
Quality
Size
Fine
Standard
6M33
3:2 3 3
3M 3 3
2M33
VGA(E-Mail) 3 3
PFX (P.Effect)
B & W ( )
Records the image in monochrome (black and white).
Sepia ( )
Records the image in sepia (like an old photograph).
Off
No effect.
31
Using the menu
For details on the operation
t
page 26
Adjusts the saturation of the image.
Adjusts the sharpness of the image.
See page 37.
(Saturation)
+ ( )
Toward +: Brightens the color.
Normal
– ( )
Toward –: Darkens the color.
(Sharpness)
+ ( )
Toward +: Sharpens the image.
Normal
– ( )
Toward –:Softens the image.
(Setup)
32
For details on the operation
t
page 26
Viewing menu
The default settings are marked with .
Selects the folder containing the image you want to play back when using a “Memory Stick
Duo”.
1 Select the desired folder with b/B on the control button.
2 Select [OK] with v, then press z.
z On the [Folder]
The camera stores images in a specified folder of a “Memory Stick Duo” (page 41). You can change the
folder or create a new one.
• To create a new folder t [Create REC. Folder] (page 41)
• To change the folder for recording images t [Change REC. Folder] (page 42)
• When multiple folders are created in the “Memory Stick Duo” and the first or last image in the folder is
displayed, the following indicators appear.
: Moves to the previous folder.
: Moves to the next folder.
: Moves to either the previous and next folders.
(Folder)
OK
See the following procedure.
Cancel
Cancels the selection.
BACK/NEXT
Select Folder
Cancel
OK
Folder Name:
102 2/2
Created:
No. Of Files:
2006
102MSDCF
9
111::05:34
AM
33
Using the menu
For details on the operation
t
page 26
Protects images against accidental erasure.
To protect images in single-image mode
1 Display the image you want to protect.
2 Press MENU to display the menu.
3 Select [-] (Protect) with b/B on the control button, then press z.
The image is protected and the - (protect) indicator appears on the image.
4 To protect other images, select the desired image with b/B, then press z.
To protect images in index mode
1 Press (index) to display the index screen.
2 Press MENU to display the menu.
3 Select [-] (Protect) with b/B on the control button, then press z.
4 Select [Select] with v/V, then press z.
5 Select the image you want to protect with v/V/b/B, then press z.
A green - indicator appears on the selected image.
6 Repeat step 5 to protect other images.
7 Press MENU.
8 Select [OK] with B, then press z.
The - indicator turns white. The selected images are protected.
• To protect all images in the folder, select [All In This Folder] in step 4, and press z. Select [On] with B,
then press z.
- (Protect)
Protect (-)
See the following procedure.
Exit
Exits the Protection function.
VGA
2/9
Protect
Exit
BACK/NEXT
-
TO NEXT
MENU
•
SELECT
- (green)
34
For details on the operation
t
page 26
To cancel the protection
In single-image mode
Press z in step 3 or 4 of “To protect images in single-image mode.”
In index mode
1 Select the image for which you want to remove protection in step
5 of “To protect images in
index mode
.”
2 Press z to turn the - indicator gray.
3 Repeat the operation above for all images to be unprotected.
4 Press MENU, select [OK] with B, and then press z.
To cancel protection of all images in the folder
Select [All In This Folder] in step 4 of “To protect images in index mode,” and press z.
Select [Off] with
B, then press z.
• Note that formatting the internal memory or “Memory Stick Duo” erases all the data stored on the
recording media, even if images are protected, and these images cannot be recovered.
• It may take some time to protect an image.
Adds a (Print order) mark to images you want to print (page 66).
See page 63.
Plays back recorded images in order (Slide show).
Interval
DPOF
(Print)
(Slide)
3 sec
Sets the slide show interval.
5 sec
10 sec
30 sec
1 min
35
Using the menu
For details on the operation
t
page 26
Repeat
1 Select [Interval], [Image] and [Repeat] with v/V/b/B on the control button.
2 Select [Start] with V/B, then press z.
The slide show starts.
To end the slide show, press z, select [Exit] with B, then press z.
• During a slide show, you can display the previous/next image with b/B.
• The [Interval] time is just a guideline, so it may vary depending on the image size, etc.
You can change the image size of a recorded image (Resize), and save it as a new file. The
original image is retained even after resizing.
1 Display the image you want to resize.
2 Press MENU to display the menu.
3 Select [ ] (Resize) with b/B, then press z.
4 Select the desired size with v/V, then press z.
The resized image is recorded in the recording folder as the newest file.
• For details on [Image Size], see page 13.
• When you change from a small size to a large size, the image quality deteriorates.
• You can not resize the image size to [3:2].
Folder
Plays back all images in the selected folder.
All
Plays back all images stored on the “Memory Stick Duo”.
On
Plays back images in a continuous loop.
Off
After all the images have been played back, the slide show
ends.
Start
See the following procedure.
Cancel
Cancels the slide show.
(Resize)
5M
The setting size is just a guideline. (see page 13)
3M
1M
VGA
Cancel
Cancels resizing.
36
For details on the operation
t
page 26
Rotates a still image.
1 Display the image to be rotated.
2 Press MENU to display the menu.
3 Select [ ] (Rotate) with b/B on the control button, then press z.
4 Select [ ] with v, then rotate the image with b/B.
5 Select [OK] with v/V, then press z.
• You may not be able to rotate images shot with other cameras.
• When viewing images on a computer, the image rotation information may not be reflected depending on
the software.
See page 37.
(Rotate)
Rotates an image. See the following procedure.
OK
Determines the rotation. See the following procedure.
Cancel
Cancels rotation.
(Setup)
37
Using the Setup screen
Using the Setup screen
Using Setup items
You can change the default settings using the Setup screen.
1 Turn on the power.
2 Press MENU to display the menu.
3 After pressing B on the control button,
!
go to the (Setup) setting, then
!
press B again.
4 Press v/V/b/B on the control button to select the item you want to set.
The frame of the selected item turns yellow.
5 Press z to enter the setting.
To turn off the (Setup) screen, press MENU.
To return to the menu from the (Setup) screen, press b on the control button repeatedly.
To cancel the (Setup) setting
Select [Cancel] if it appears, then press z on the control button. If it does not appear, select
the previous setting again.
• This setting is maintained even when the power is turned off.
v/V/b/B button
Mode dial
Control button
MENU button
z button
38
For details on the operation
t
page 37
Camera
The default settings are marked with .
Selects the digital zoom mode. The camera enlarges the image using optical zoom (up to 3×).
When the zoom scale exceeds 3×, the camera uses either smart or precision digital zoom.
Image size and maximum zoom scale using Smart zoom
• When you press the zoom button, the zoom scaling indicator appears as follows.
• The maximum zoom scale of smart zoom/precision zoom includes the scale of the optical zoom.
• When using the smart zoom, the image on the screen may look rough. However, this phenomenon has no
effect on the recorded image.
Digital Zoom
Smart
(Smart zoom)
()
Enlarges the image digitally with almost no distortion. This is
not available when the image size is set to [5M] or [3:2].
• The maximum zoom scale of Smart zoom is shown in the
following table.
Precision
(Precision digital zoom)
()
Enlarges all image sizes up to a maximum of 6×, but the
image quality deteriorates.
Off ( )
Does not use the digital zoom.
Size Maximum zoom scale
3M Approx. 3.7
1M Approx. 6.0
VGA(E-Mail) Approx. 12.0
The W side of this line is the optical zoom area,
and the T side is the digital zoom area
Zoom scaling indicator
39
Using the Setup screen
For details on the operation
t
page 37
Selects how to superimpose the date or time onto the image. Select this before shooting.
• The date and time do not appear during shooting, instead, the indicator appears. The date and time
appear in red on the lower-right corner of the screen during playback only.
• You cannot insert the data and time into movies.
• The date and time superimposed cannot be removed later.
Reduces the red-eye phenomenon when using the
flash. Select this before shooting.
• Because it takes about a second until the shutter clicks, hold the camera firmly to prevent the effects of
vibration. Also, do not let the subject move.
• Red-eye reduction may not produce the desired effects depending on individual differences, the distance
to the subject, if the subject does not see the pre-strobe, or other conditions.
Displays the recorded image on the screen for approximately two seconds immediately after
shooting a still image.
• You cannot shoot the next image during the Auto Review display. If you press the shutter button halfway
down during this period, the recorded image display disappears and you can immediately shoot the next
image.
Date/Time
Day&Time
Superimposes the date, hour, and minute.
Date
Superimposes the year, month and day.
• The date is inserted in the order you select.
Off
Does not superimpose the date and time.
Red Eye Reduction
On ( )
Reduces the red-eye phenomenon.
• The flash pre-strobes twice or more before shooting.
Off
Does not use Red Eye Reduction.
Auto Review
On
Use the Auto Review.
Off
Does not use Auto Review.
40
For details on the operation
t
page 37
Internal Memory Tool
This item does not appear when a “Memory Stick Duo” is inserted in the camera.
The default settings are marked with .
Formats the internal memory.
• Note that formatting irrevocably erases all data in the internal memory, including even protected images.
1 Select [OK] with v on the control button, then press z.
The message “All data in internal memory will be erased Ready?” appears.
2 Select [OK] with v, then press z.
The format is complete.
Format
OK
See the following procedure.
Cancel
Cancels the formatting.
41
Using the Setup screen
For details on the operation
t
page 37
Memory Stick Tool
This item appears only when a “Memory Stick Duo” is inserted in the camera.
The default settings are marked with .
Formats the “Memory Stick Duo”. A commercially available “Memory Stick Duo” is already
formatted, and can be used immediately.
• Note that formatting irrevocably erases all data on a “Memory Stick Duo”, including even protected
images.
1 Select [OK] with v on the control button, then press z.
The message “All data in Memory Stick will be erased Ready?” appears.
2 Select [OK] with v, then press z.
The format is complete.
Creates a folder in a “Memory Stick Duo” for recording images.
1 Select [OK] with v on the control button, then press z.
The folder creation screen appears.
2 Select [OK] with v, then press z.
A new folder is created with a number incremented one higher than the largest number, and the
folder becomes the current recording folder.
• For details on the folder, see page 32.
• When not creating a new folder, the “101MSDCF” folder is selected as the recording folder.
• You can create folders designated up to “999MSDCF.”
• Images are recorded in the newly created folder until a different folder is created or selected.
• You cannot delete a folder with the camera. To delete a folder, use your computer, etc.
• Up to 4,000 images can be stored in one folder. When the folder capacity is exceeded, a new folder is
automatically created.
• For more information, see “Image file storage destinations and file names” (page 54).
Format
OK
See the following procedure.
Cancel
Cancels the formatting.
Create REC. Folder
OK
See the following procedure.
Cancel
Cancels folder creation.
Create REC. Folder
Creating REC. folder
102MSDCF
Ready?
OK
Cancel
42
For details on the operation
t
page 37
Changes the folder currently used for recording images.
1 Select [OK] with v on the control button, then press z.
The folder selection screen appears.
2 Select the desired folder with b/B, and [OK] with v, then z.
• You cannot select the “100MSDCF” folder as a recording folder.
• You cannot move recorded images to a different folder.
Copies all images in the internal memory to a “Memory Stick Duo”.
1 Insert a “Memory Stick Duo” having 16 MB or larger capacity.
2 Select [OK] with v on the control button, then press z.
The message “All data in internal memory will be copied Ready?” appears.
3 Select [OK] with v, then press z.
Copying starts.
• Use batteries with enough capacity or the AC Adaptor (not supplied). If you attempt to copy image files
using batteries with little remaining charge, the batteries may run out, causing copying to fail or possibly
corrupting the data.
• You cannot copy individual images.
• The original images in the internal memory are retained even after copying. To delete the contents of the
internal memory, remove the “Memory Stick Duo” after copying, then execute the [Format] command in
Internal Memory Tool (page 40).
• You cannot select a folder copied on a “Memory Stick Duo”.
• The setting of (Print order) marks is not copied even when you copy data.
Change REC. Folder
OK
See the following procedure.
Cancel
Cancels changing the recording folder.
Copy
OK
See the following procedure.
Cancel
Cancels the copying.
BACK/NEXT
Select REC. Folder
Cancel
OK
Folder Name:
102 2/2
Created:
No. Of Files:
2006
102MSDCF
0
111::05:34
AM
Copying
102_COPY
43
Using the Setup screen
For details on the operation
t
page 37
Setup 1
1
The default settings are marked with .
Selects the brightness of the LCD backlight when using the camera with batteries.
• Selecting [Bright] uses up the battery charge faster.
Selects the sound produced when you operate the camera.
Initializes the setting to the default setting.
1 Select [OK] with v on the control button, then press z.
The message “Initialize all settings Ready?” appears.
2 Select [OK] with v, then press z.
The settings are reset to the default setting.
• Make sure that the power is not disconnected during resetting.
LCD Backlight
Bright
Brightens.
Normal
Beep
Shutter
Turns on the shutter sound when you press the shutter button.
On
Turns on the beep/shutter sound when you press the control
button/ press the shutter button.
Off
Turns off the beep/shutter sound.
Initialize
OK
See the following procedure.
Cancel
Cancels the resetting.
44
For details on the operation
t
page 37
Setup 2
2
The default settings are marked with .
Selects the method used to assign file numbers to images.
Selects the USB mode to be used when connecting the camera to a computer or a PictBridge
compliant printer using the USB cable.
Sets the video signal output according to the TV color system of the connected video!
equipment. Different countries and regions use different TV color systems. If you want to!
view images on a TV screen, check page 69 for the TV color system of the country or region
where the camera is used.
File Number
Series
Assigns numbers to files in sequence even if the recording
folder or the “Memory Stick Duo” is changed. (When the
replaced “Memory Stick Duo” contains a file with a number
higher than the last assigned number, a number one higher
than the largest number is assigned.)
Reset
Starts from 0001 each time the folder is changed. (When the
recording folder contains a file, a number one higher than the
largest number is assigned.)
USB Connect
PictBridge
Connects the camera to a PictBridge compliant printer (page
63).
Normal
Connects the camera to a computer.
Video Out
NTSC
Sets the video output signal to NTSC mode (e.g., for the
USA, Japan).
PAL
Sets the video output signal to PAL mode (e.g., for Europe).
45
Using the Setup screen
For details on the operation
t
page 37
Sets the date and time.
Clock Set
OK
Select [OK] with v on the control button, and press z. Then,
perform the procedure explained in “Set the clock”.
Cancel
Cancels setting the clock.
46
Using your computer
Enjoying your Windows computer
For details on using a Macintosh
computer,!refer to “Using your Macintosh
computer”!(page 60).
This section describes the English version!
screen contents.
Install the software (supplied) first (page 48)
Copying images to your computer (page 49)
Viewing images saved on your computer
Enjoying images using the “Cyber-shot Viewer” (page 56)
• Viewing images saved on your computer
• Viewing photos organized by date
• Editing images
Printing images
47
Using your computer
The following environment is
recommended for a computer connected to
the camera.
Recommended environment for
copying images
OS (pre-installed): Microsoft Windows
2000 Professional, Windows Millennium
Edition, Windows XP Home Edition or
Windows XP Professional
• Operation is not assured in an environment
based on an upgrade of the operating
systems described above or in a multi-boot
environment.
USB jack: Provided as standard
Recommended environment for using
the Cyber-shot Viewer
OS (pre-installed): Microsoft Windows
2000 Professional, Windows Millennium
Edition, Windows XP Home Edition or
Windows XP Professional
Sound card: 16-bit stereo sound card with
speakers
Processor/Memory: Pentium III 500 MHz
or faster, 128 MB of RAM or more
(Recommended: Pentium III 800 MHz or
faster and 256 MB of RAM or more)
Software:!DirectX 9.0c or later
Hard Disk: Disk space required for
installation—200 MB or more
Display: Screen resolution; 800 × 600 dots
or more Colors; High Color (16-bit color,
65,000 colors) or more
• This software is compatible with DirectX
technology. DirectX must be installed for
use.
Notes on connecting your camera to a
computer
• Operations are not guaranteed for all the
recommended computer environments
mentioned above.
• If you connect two or more USB devices to a
single computer at the same time, some devices,
including your camera, may not operate,
depending on the types of USB devices you are
using.
• Operations are not guaranteed when using a
USB hub.
• The [Normal] (default setting) mode is for a
USB connection when connectiong a computer.
This section describes the [Normal] mode as an
example.
• When your computer resumes from a suspend or
sleep mode, communication between your
camera and your computer may not recover at
the same time.
Recommended computer
environment
48
Installing the software (supplied)
You can install the software (supplied)
using the following procedure.
• When using Windows 2000/Me, do not connect
the camera to the computer before installation.
• In Windows 2000/XP, log on as Administrator.
• When the supplied software is installed, the
USB driver is installed automatically.
1 Turn on your computer, and
insert the CD-ROM (supplied) into
the CD-ROM drive.
The installation menu screen appears.
• If it does not appear, double-click (My
Computer)
t (CYBERSHOTSOFT).
2 Click [Install].
The “Choose Setup Language” screen
appears.
3 Select the desired language, then
click [Next].
The “License Agreement” screen
appears.
Read the agreement carefully. If you
accept the terms of the agreement, click
the radio button next to [I accept the
terms of the license agreement] and then
click [Next].
4 Follow the instructions on the
screen to complete the
installation.
• When the restarting confirmation message
appears, restart the computer following the
instructions on the screen.
• DirectX will be installed if you have not yet
installed them.
5 Remove the CD-ROM after the
installation is complete.
49
Using your computer
Copying images to your computer
This section describes the process using a
Windows computer as an example.
You can copy images from the camera to
your computer as follows.
For a computer with a “Memory Stick”
slot
Remove the “Memory Stick Duo” from the!
camera and insert it in the Memory Stick!
Duo Adaptor!(not supplied). Insert the
Memory Stick Duo!Adaptor!(not supplied)!
in the computer and copy the!images.
If the “Memory Stick PRO Duo” is not
recognized, see page 77.
For a computer without a “Memory
Stick” slot
Follow Stages 1 through 4 on pages 49 to
53 to copy images.
• When using Windows 2000/Me, install the!
supplied software before proceeding. With!
Windows XP, the installation is unnecessary.
• The screen displays shown in this section are the!
examples for copying images from “Memory
Stick Duo”.
1 Insert a “Memory Stick Duo” with
recorded images into the camera.
• When copying images in the internal
memory, this step is unnecessary.
2 Insert the sufficiently charged
battery pack in the camera, or
connect the camera to a wall
outlet (wall socket) with the AC
Adaptor (not supplied).
• When you copy images to your computer
using a battery pack with little remaining
charge, copying may fail or image data may
become corrupted if the battery pack shuts
down too soon.
3 Set the mode dial to , then
press POWER to turn on the
camera and the computer.
Stage 1: Preparing the camera
and the computer
2
3
4
5
1
POWER
50
• With Windows XP, the AutoPlay wizard
appears on the desktop.
“USB Mode Normal” appears on the screen
of the camera.
When a USB connection is established for
the first time, your computer automatically
runs a program to recognize the camera.
Wait for a while.
* During communication, the access indicators
turn red. Do not operate the computer until the
indicators turn white.
• If “USB Mode Normal” does not appear, set
[USB Connect] to [Normal] (page 44).
• For Windows 2000/Me, follow the procedure
explained in “Stage 3-B: Copying images to a
Computer” on page 51.
• For Windows XP, when the wizard screen does
not appear automatically, follow the procedure
explained in “Stage 3-B: Copying images to a
Computer” on page 51.
This section describes an example of
copying images to a “My Documents”
folder.
1 After making a USB connection in
Stage 2, click [Copy pictures to a
folder on my computer using
Microsoft Scanner and Camera
Wizard]
t [OK] as the wizard
screen appears automatically on
the desktop.
The “Scanner and Camera Wizard”
screen appears.
Stage 2: Connecting the camera
and your computer
To a USB jack
To the
!USB jack
USB Mode
MENU
Switch on
Normal
Memory Stick
Access
indicators*
Stage 3-A: Copying images to a
computer
1
2
51
Using your computer
2 Click [Next].
The images saved on the “Memory
Stick Duo” of the camera appear.
• If no “Memory Stick Duo” is inserted,
images in the internal memory appear.
3 Click the check box of unwanted
images to remove the checkmark
so they are not copied, then click
[Next].
The “Picture Name and Destination”
screen appears.
4 Select a name and destination for
the images, then click [Next].
Image copying starts. When the copying
is completed, the “Other Options”
screen appears.
• This section describes an example of
copying images to the “My Documents”
folder.
5 Click the radio button next to
[Nothing. I'm finished working
with these pictures] to select it,
then click [Next].
The “Completing the Scanner and
Camera Wizard” screen appears.
6 Click [Finish].
The wizard screen closes.
• To continue copying other images,
disconnect the USB cable. Then follow the
procedure explained in “Stage 2:
Connecting the camera and your computer”
on page 50.
• For Windows XP, follow the procedure
explained in “Stage 3-A: Copying images to a
computer” on page 50.
This section describes an example of
copying images to the “My Documents”
folder.
1
2
1
2
Stage 3-B: Copying images to a
Computer
1
2
52
1 Double-click [My Computer] t
[Removable Disk] t [DCIM].
• If the “Removable Disk” icon is not
displayed, see page 76.
2 Double-click the folder where the
image files you want to copy are
stored.
Then, right-click an image file to
display the menu and click
[Copy].
• On the storage destination of the image
files, see page 54.
3 Double-click the [My Documents]
folder. Then, right-click on the
“My Documents” window to
display the menu and click
[Paste].
The image files are copied to the “My
Documents” folder.
• When an image with the same file name
exists in the copy destination folder, the
overwrite confirmation message appears.
When you overwrite an existing image with
a new one, the original file data is deleted.
To copy an image file to the computer
without overwriting, change the file name to
a different name and then copy the image
file. However, note that if you change the
file name (page 55), you may not be able to
play back that image with your camera.
2
1
1
2
53
Using your computer
This section describes the procedure for
viewing copied images in the “My
Documents” folder.
1 Click [Start] t [My Documents].
The contents of the “My Documents”
folder are displayed.
• If you are not using Windows XP,
double-click [My Documents] on the
desktop.
2 Double-click the desired image
file.
The image is displayed.
Perform the procedures listed below
beforehand when:
• Disconnecting the USB cable
• Removing a “Memory Stick Duo”
• Inserting a “Memory Stick Duo” into the
camera after copying images from the internal
memory
• Turning off the camera
x For Windows 2000/Me/XP
1 Double-click on the tasktray.
2 Click (Sony DSC)
t [Stop].
3 Confirm the device on the confirmation
window, then click [OK].
4 Click [OK].
The device is disconnected.
• Step 4 is unnecessary for Windows XP.
Stage 4: Viewing images on
your computer
1
2
To delete the USB connection
Double-click here
54
The image files recorded with your camera
are grouped as folders on the “Memory
Stick Duo”.
Example: viewing folders on Windows XP
A Folder containing image data recorded
using a camera not equipped with the
folder creating function
B Folder containing image data recorded
using this camera
When no new folders are created, there are
folders as follows:
– “Memory Stick Duo”; “101MSDCF” only
– Internal memory; “101_SONY” only
• You cannot record any images to the
“100MSDCF” folder. The images in these
folders are available only for viewing.
• You cannot record/playback any images to the
“MISC” folder.
• Image files are named as follows. ssss
stands for any number within the range from
0001 to 9999. The numerical portions of the
name of a movie file recorded in movie mode
and its corresponding index image file are the
same.
– Still image files: DSC0ssss.JPG
– Movie files: MOV0ssss.AVI
– Index image files that are recorded when you
record movies: MOV0ssss.THM
• For more information about folders, see pages
32 and 41.
Image file storage destinations
and file names
A
B
55
Using your computer
Viewing image files stored on a computer with
your camera (using a “Memory Stick Duo”)
This section describes the process using a
Windows computer as an example.
When an image file copied to a computer
no longer remains on a “Memory Stick
Duo”, you can view that image again on the
camera by copying the image file on the
computer to a “Memory Stick Duo”.
• Step 1 is not necessary if the file name set with
your camera has not been changed.
• You may be unable to play back some images
depending on the image size.
• When an image file has been processed by a
computer or when the image file was recorded
using a model other than that of your camera,
playback on your camera is not guaranteed.
• When there is no folder, first create a folder with
your camera (page 41) and then copy the image
file.
1 Right-click the image file, then
click [Rename]. Change the file
name to “DSC0ssss.”
Enter a number from 0001 to 9999 for
ssss.
• If the overwrite confirmation message
appears, enter a different number.
• An extension may be displayed depending
on the computer settings. The extension for
still images is JPG, and the extension for
movies is AVI. Do not change the
extension.
2 Copy the image file to the
“Memory Stick Duo” folder in the
following order.
1Right-click the image file, then click
[Copy].
2Double-click [Removable Disk] or
[Sony Memory Stick Duo] in [My
Computer].
3Right-click the [sssMSDCF] folder
in the [DCIM] folder, then click [Paste].
• sss stands for any number within the
range from 100 to 999.
1
2
56
Using the “Cyber-shot Viewer” (supplied)
You can use still images and movies from
the camera more than ever by taking
advantage of the software.
This section summarizes the “Cyber-shot
Viewer” and gives basic instructions.
With the “Cyber-shot Viewer” you can:
• Import images shot with the camera and display
them on the monitor.
• Organize images on the computer on a calendar
by shooting date to view them.
• Retouch, print, and send still images as e-mail
attachments, change the shooting date, and
more.
• For details on the “Cyber-shot Viewer”, refer to
the Help.
To access the Help, click [Start] t
[Programs] (in Windows XP, [All
Programs]) t [Sony Picture Utility] t
[Help] t [Cyber-shot Viewer].
Starting the “Cyber-shot Viewer”
Double-click the (Cyber-shot Viewer)
icon on the desktop.
Or, from the Start menu: Click [Start] t
[Programs] (in Windows XP, [All
Programs]) t [Sony Picture Utility] t
[Cyber-shot Viewer].
Exiting the “Cyber-shot Viewer”
Click button in the top right corner of
the screen.
Follow these steps to import and view
images from the camera.
Importing images
1 Make sure “Media Check Tool”*
is running.
* “Media Check Tool” is a program that
automatically detects and imports images
when a “Memory Stick” is inserted or when
the camera is connected.
Look for a (Media Check Tool) icon
in the taskbar.
• If there is no icon: Click [Start] t
[Programs] (in Windows XP, [All
Programs]) t [Sony Picture Utility] t
[Cyber-shot Viewer] t [Tools] t [Media
Check Tool].
2 Connect the camera to your
computer with the USB cable.
After the camera is automatically
detected, the [Import Images] screen is
displayed.
• If you will use the “Memory Stick” slot,
first refer to page page 49.
• In Windows XP, if the AutoPlay Wizard
appears, close it.
“Cyber-shot Viewer” overview
Starting and exiting the “Cyber-
shot Viewer”
Basic instructions
57
Using your computer
3 Import the images.
To start importing images, click the
[Import] button.
By default, images are imported into a
folder created in “My Pictures” that is
named with the date of importing.
• For instructions on changing the “Folder to
be imported”, refer to page 59.
Viewing images
1 Checking imported images
When importing is complete, the
“Cyber-shot Viewer” starts. Thumbnails
of the imported images are displayed.
• The “My Pictures” folder is set as the
default folder in “Viewed folders”.
• You can double-click a thumbnail to display
the image by itself.
2 Viewing images in “Viewed
folders” arranged by shooting
date on a calendar
1Click the [Calendar] tab.
Years when images were shot are listed.
2Click the year.
Images shot that year are displayed,
arranged on the calendar by shooting
date.
3To display images by month, click the
desired month.
Thumbnails of images shot that month
are displayed.
4To display images by time, click the
desired date.
Thumbnails of images shot that day are
displayed, arranged by hour.
Year display screen
Month display screen
1
2
3
4
58
Hour display screen
• To list images from a particular year or
month, click that period on the left of the
screen.
3 Displaying individual images
On the hour display screen, double-click
a thumbnail to display the image by
itself in a separate window.
• You can edit displayed images by clicking
the toolbar button.
Displaying images in full-screen
mode
To display a slide show of current images in
full-screen mode, click the button.
• To play or pause the slide show, click the
button on the lower left of the screen.
• To stop the slide show, click the button on
the lower left of the screen.
59
Using your computer
Preparing images stored on the
computer for viewing
To view them, register the folder that
contains the images as one of the “Viewed
folders”.
From the [File] menu, choose [Register
Viewed Folders...] to display the settings
screen for “Viewed folders” registration.
Click the [Add...] button, and then specify
the folder with images for importing to
register the folder as a “Viewed folder.”
• Images in any subfolders of “Viewed folders”
are also registered.
Changing the “Folder to be imported”
To change the “Folder to be imported”,
access the “Import Settings” screen.
To display the “Import Settings” screen,
choose [Image Import Settings...] from the
[File] menu.
Choose the “Folder to be imported”.
• You can specify the “Folder to be imported”
from folders registered as “Viewed folders.”
Updating image registration
information
To update image information, choose
[Update Database] from the [Tools] menu.
• Updating the database may take a while.
• If you rename image files or folders in “Viewed
folders”, they cannot be displayed with this
software. In this case, update the database.
1 Click [Start] t [Settings] t [Control
Panel]. Double-click [Add/Remove
Programs]. (For Windows XP, click [Start]
t [Control Panel], then double-click
[Add or Remove Programs].)
2 Select [Sony Picture Utility] and click
[Change/Remove] (for Windows XP,
[Remove]) to uninstall.
Other functions
1
2
1
2
Uninstalling “Cyber-shot
!
Viewer”
Technical Support
Additional information on this product
and answers to frequently asked
questions can be found at the Sony
Customer Support Website.
http://www.sony.net/
60
Using your Macintosh computer
You can copy images to your computer.
• The supplied software is not compatible with
Macintosh computers.
The following environment is
recommended for a computer connected to
the camera.
Recommended environment for
copying images
OS (pre-installed): Mac OS 9.1, 9.2 or Mac
OS X (v10.0 or later)
USB jack: Provided as standard
Notes on connecting your camera to a
computer
• Operations are not guaranteed for all the
recommended computer environments
mentioned above.
• If you connect two or more USB devices to a
single computer at the same time, some devices,
including your camera, may not operate
depending on the types of USB devices you are
using.
• Operations are not guaranteed when using a
USB hub.
• The [Normal] (default setting) mode is for a
USB connection when connectiong a computer.
This section describes the [Normal] mode as an
example.
• When your computer resumes from the suspend
or sleep mode, communication between your
camera and your computer may not recover at
the same time.
1 Prepare the camera and a
Macintosh computer.
Perform the same procedure as that
described in “Stage 1: Preparing the
camera and the computer” on page 49.
2 Connect the USB cable.
Perform the same procedure as that
described in “Stage 2: Connecting the
camera and your computer” on page 50.
3 Copy image files to the Macintosh
computer.
1Double-click the newly recognized icon
t [DCIM] t the folder where the
images you want to copy are stored.
2Drag and drop the image files to the
hard disk icon.
The image files are copied to the hard
disk.
• For details on the storage location of the
images and file names, see page 54.
4 View images on the computer.
Double-click the hard disk icon
t the
desired image file in the folder
containing the copied files to open that
image file.
Recommended computer
environment
Copying and viewing images on
a computer
61
Using your computer
Perform the procedures listed below
beforehand when:
• Disconnecting the USB cable
• Removing a “Memory Stick Duo”
• Inserting a “Memory Stick Duo” into the
camera after copying images from the internal
memory
• Turning off the camera
Drag and drop the drive icon or the
icon of the “Memory Stick Duo” to the
“Trash” icon.
The camera is disconnected from the
computer.
• If you are using Mac OS X v10.0, perform the
procedure above after you have turned your
computer off.
To delete the USB connection
Technical Support
Additional information on this product
and answers to frequently asked
questions can be found at the Sony
Customer Support Website.
http://www.sony.net/
62
Printing still images
How to print still images
Printing directly using a PictBridge compliant printer (page 63)
You can print images by connecting the camera directly to a
PictBridge compliant printer.
Printing directly using a “Memory Stick” compliant printer
You can print images with a “Memory Stick” compliant printer.
For details, see the operating instructions supplied with the printer.
Printing using a computer
You can copy images to a computer using the “Cyber-shot Viewer”
software in the supplied CD-ROM and print the images.
Printing at a shop (page 66)
You can take a “Memory Stick Duo” containing images shot with
your camera to a photo printing service shop. You can make a
(Print order) mark on images that you want to print out in advance.
63
Printing still images
Printing images directly using a PictBridge compliant
printer
Even if you do not have a computer, you
can print images shot using your camera by
connecting the camera directly to a
PictBridge compliant printer.
• “PictBridge” is based on the CIPA standard.
(CIPA: Camera & Imaging Products
Association)
In single-image mode
You can print a single image on a printing
sheet.
In index mode
You can print several images at a reduced
size on a printing sheet. You can print a set
of either the same images (1) or different
images (2).
12
• An index print function may not be provided
depending on the printer.
• The quantity of images that can be printed as an
index image differ depending on the printer.
• You cannot print movies.
• If the indicator flashes on the screen of the
camera for about five seconds (error
notification), check the connected printer.
Prepare the camera to connect it to the
printer with the USB cablel.
• It is recommended to use the new battery or AC
Adaptor (not supplied) to prevent the power
from turning off partway through printing.
1 Press MENU to display the menu.
2 Press B on the control button to
select (Setup).
3 Select [ ] (Setup2) with V, then
select [USB Connect] with v/V/B.
4 Select [PictBridge] with B/v, then
press z.
The USB mode is set.
Stage 1: Preparing the camera
Index button
Control Button
MENU button
2
64
1 Connect the (USB) jack on your
camera and the USB jack on the
printer with the supplied USB
cable.
2 Turn on your camera and the
printer.
After the connection is made,
the indicator appears
The camera is set to playback mode,
then an image and the print menu appear
on the screen.
Regardless of what the mode dial is set to,
the print menu appears when you complete
Stage 2.
1 Select the desired printing
method with v/V on the control
button, then press z.
[All In This Folder]
Prints all the images in the folder.
[DPOF image]
Prints all the images with a (Print
order) mark (page 66) regardless of the
displayed image.
[Select]
Selects images and prints all the
selected images.
1Select the image you want to print with
b/B, then press z.
The mark appears on the selected
image.
• To select other images, repeat this
procedure.
2Select [Print] with V, then press z.
[This image]
Prints a displayed image.
• If you select [This image] and set [Index] to
[On] in step 2, you can print a set of the
same images as an index image.
2 Select print settings with v/V/b/B.
[Index]
Select [On] to print as an index image.
Stage 2: Connecting the camera
to the printer
USB cable
To the USB jack
To the (USB)
jack
All In
This Folder
DPOF image
Select
This image
Cancel
Print
Stage 3: Printing
OKExit
1
Off
Default
Size
Date
Quantity
Off
Index
Print
65
Printing still images
[Size]
Select the size of the printing sheet.
[Date]
Select [Day&Time] or [Date] to insert
the date and time on images.
• When you choose [Date], the date will be
inserted in the order you select. This
function may not be provided depending on
the printer.
[Quantity]
When [Index] is set to [Off]:
Select the number of sheets of an image
that you want to print. The image will
be printed as a single image.
When [Index] is set to [On]:
Select the number of sets of images that
you want to print as an index image.
If you selected [This image] in step 1,
select the number of the same image
you want to print side by side on a sheet
as an index image.
• The designated number of images may not
all fit onto a single sheet depending on the
quantity of images.
3 Select [OK] with V/B, then press
z.
The image is printed.
• Do not disconnect the USB cable while the
indicator appears on the screen.
To print other images
After step 3, select [Select] and the desired
image with v/V, then perform from step 1.
To print images on the index screen
Perform “Stage 1: Preparing the camera”
(page 63) and “Stage 2: Connecting the
camera to the printer” (page 64), then
proceed with the following.
When you connect the camera to a printer,
the print menu appears. Select [Cancel] to
turn off the print menu, then proceed as
follows.
1 Press (Index).
The index screen appears.
2 Press MENU to display the menu.
3 Select [ ] (Print) with B, then press z.
4 Select the desired printing method with
b/B, then press z.
[Select]
Selects images and prints all the selected
images.
Select the image you want to print with v/
V/b/B, then press z to display the
mark. (Repeat this procedure to select
other images.) Then, press MENU.
[DPOF image]
Prints all the images with a (Print
order) mark regardless of the displayed
image.
[All In This Folder]
Prints all the images in the folder.
5 Perform steps 2 and 3 of “Stage 3:
Printing” (page 64).
Exit
Printing
2/3
indicator
All In
This Folder
DPOF image
Select
Cancel
Print
66
Printing at a shop
You can take a “Memory Stick Duo”
containing images shot with your camera to
a photo printing service shop. As long as
the shop supports photo printing services
conforming to the DPOF, you can make a
(Print order) mark on images in
advance so that you do not need to reselect
them when you print them out at the shop.
• You cannot print images stored in the internal
memory at a print shop directly from the
camera. Copy the images to a “Memory Stick
Duo”, then take the “Memory Stick Duo” to the
print shop.
What is DPOF?
DPOF (Digital Print Order Format) is a
function allowing you to make a (Print
order) mark on images of “Memory Stick
Duo” that you want to print out later.
• You can also print the images with the
(Print order) mark using a printer that conforms
to the DPOF (Digital Print Order Format)
standard or using a PictBridge compliant
printer.
• You cannot mark movies.
When taking a “Memory Stick Duo” to
a shop
• Consult your photo printing service shop as to
what types of “Memory Stick Duo” they handle.
• If a “Memory Stick Duo” is not handled by your
photo printing service shop, copy the images
you want to print out to other medium such as a
CD-R and take it to the shop.
• When taking a “Memory Stick Duo”, be sure to
prepare the Memory Stick Duo Adaptor (not
supplied) with it.
• Before you take image data to a shop, always
copy (back up) your data to a disk.
• You cannot set the number of prints.
1 Display the image you want to
print.
2 Press MENU to display the menu.
3 Select DPOF with b/B, then press
z.
A (Print order) mark is marked on
the image.
4 To mark other images, display the
desired image with b/B, then
press z.
To remove the mark in single-image
mode
Press z in step 3 or 4.
Marking in single-image mode
Control button
MENU button
VGA
2/9
DPOF
Exit
BACK/NEXT
101
67
Printing still images
1 Display the index screen.
2 Press MENU to display the menu.
3 Select DPOF with b/B, then press
z.
4 Select [Select] with v/V, then
press z.
• You cannot add a mark in [All In This
Folder].
5 Select the image you want to
mark with v/V/b/B, then press z.
A green mark appears on the
selected image.
6 Repeat step 5 to mark other
images.
7 Press MENU.
8 Select [OK] with B, then press z.
The mark turns white.
To cancel, select [Cancel] in step 4 or select
[Exit] in step 8, then press z.
To remove the mark in index mode
Select the images from which you want to
remove the mark in step 5, then press z.
To remove all the marks in the folder
Select [All In This Folder] in step 4, then
press z. Select [Off], then press z.
Marking in index mode
TO NEXT
MENU
SELECT
Green
mark
68
Connecting your camera to your TV
Viewing images on a TV screen
You can view images on a TV screen by
connecting the camera to a TV.
Turn off both your camera and the TV
before connecting the camera and the TV
with the A/V cable.
1 Connect the A/V cable (supplied)
to the A/V OUT (MONO) jack of
the camera and the audio/video
input jacks of a TV.
• If your TV has stereo input jacks, connect the
audio plug (white) of the A/V cable to the left
audio jack.
2 Turn on the TV and set the TV/
video input switch to “video.”
• For details, see the operating instructions
supplied with the TV.
3 Set the mode dial to , and turn
on the camera.
Images shot with the camera appear on
the TV screen.
Press b/B on the control button to
select the desired image.
• When using your camera abroad, it may be
necessary to switch the video signal output
to match that of your TV system (page 44).
To audio/video input
jacks
To A/V OUT jack
A/V cable
BACK/NEXT
10:30
PM
2006 1 1101-0002
VOLUME
VGA
2/9
Control button
Mode dial
69
Connecting your camera to your TV
On TV color systems
If you want to view images on a TV screen,
you need a TV with a video input jack and
the A/V cable. The color system of the TV
must match that of your digital still camera.
Check the following lists for the color
system of the country or region when the
camera is used.
NTSC system
Bahama Islands, Bolivia, Canada, Central
America, Chile, Colombia, Ecuador,
Jamaica, Japan, Korea, Mexico, Peru,
Surinam, Taiwan, the Philippines, the
U.S.A., Venezuela, etc.
PAL system
Australia, Austria, Belgium, China, Czech
Republic, Denmark, Finland, Germany,
Holland, Hong Kong, Hungary, Italy,
Kuwait, Malaysia, New Zealand, Norway,
Poland, Portugal, Singapore, Slovak
Republic, Spain, Sweden, Switzerland,
Thailand, United Kingdom, etc.
PAL-M system
Brazil
PAL-N system
Argentina, Paraguay, Uruguay
SECAM system
Bulgaria, France, Guiana, Iran, Iraq,
Monaco, Russia, Ukraine, etc.
70
Troubleshooting
Troubleshooting
If you experience trouble with your camera, try the following solutions.
Please understand that you give your consent that the contents of the internal memory may be
checked when you send your camera to be repaired.
1 Check the items on pages 71 to 80.
2 Remove the batteries, and insert the batteries again after about one
minute, and turn on the power.
3 Initialize the settings (pages 43)
4 Consult your Sony dealer or local authorized Sony service facility.
71
Troubleshooting
The battery remaining indicator is incorrect, or sufficient battery remaining
indicator is displayed but the power runs out too quickly.
• This phenomenon occurs when you use the camera in an extremely hot or cold location (page
85).
• When using alkaline batteries/Oxy Nickel Primary Battery (not supplied), the displayed time
remaining may not be correctly indicated.
• The batteries are discharged. Install new batteries or charged Nickel-Metal Hydride batteries
(not supplied).
• When using the Nickel-Metal Hydride batteries (not supplied), the poles of batteries or the
terminals of the battery cover are dirty so the batteries are not charged sufficiently. Clean
them with a cotton swab, etc. (page 85).
• When using the Nickel-Metal Hydride batteries (not supplied), the displayed time remaining
differs from the current one due to the memory effect (page 85), etc. Fully discharge and then
charge the batteries to correct the display.
• The batteries are dead. Replace them with new ones.
The batteries run down too quickly.
• You are using the camera in an extremely cold location (page 85).
• The batteries are dead. Replace them with new ones.
• When using the Nickel-Metal Hydride batteries (not supplied), charge them sufficiently.
Cannot turn on the camera.
• Install the batteries correctly.
• Properly connect the AC Adaptor (not supplied).
• The batteries are discharged. Install new batteries or charged Nickel-Metal Hydride batteries
(not supplied).
• The batteries are dead. Replace them with new ones.
The power turns off suddenly.
• If you do not operate the camera for about three minutes while the power is on, the camera
turns off automatically to prevent wearing down the batteries. Turn on the camera again.
• The batteries are discharged. Install new batteries or charged Nickel-Metal Hydride batteries
(not supplied).
Your camera cannot record images.
• Check the free capacity of the internal memory or “Memory Stick Duo” (page 21). If it is full,
do one of the following:
– Delete unnecessary images.
– Change the “Memory Stick Duo”.
• You are using the “Memory Stick Duo” with the write-protect switch, and the switch is set to
the LOCK position. Set the switch to the recording position (page 83).
Batteries and power
Shooting still images/movies
72
• You cannot record images while charging the flash.
• When shooting a still image, set the mode dial to a position other than .
• Set the mode dial to when shooting movies.
The subject is not visible on the screen.
• Set the mode dial to an other position than (page 24).
The image is out of focus.
• The subject is too close. Record in the close-up (Macro) recording mode. Make sure to
position the lens farther away from the subject than the shortest shooting distance,
approximately 5 cm (2 inches) (W)/35 cm (13 7/8 inches) (T), when shooting.
• (Twilight mode) or (Landscape mode) is selected as the Scene mode when you shoot
still images.
Zoom does not work.
• You cannot change the zoom scale when shooting movies.
Precision digital zoom does not function.
• Set [Digital Zoom] to [Precision] (page 38).
• This function cannot be used while shooting movies.
Smart zoom does not function.
• Set [Digital Zoom] to [Smart] (page 38).
• This function cannot be used when:
– The image size is set to [5M] or [3:2].
– Shooting movies.
The flash does not work.
• The flash is set to (No flash).
• You cannot use the flash when:
– [Mode] (REC Mode) is set to [Burst] (page 30).
– (Twilight mode) or (Candle mode) of the Scene mode, or (movie) is selected.
• Set the flash to (Forced flash) to shoot still images when (Landscape mode), or
(Beach mode) is selected as the Scene mode.
The close-up (Macro) function does not work.
• (Twilight mode), (Landscape mode), or (Candle mode) is selected for the Scene
mode
(page 25).
Fuzzy specks appear in images shot using the flash.
• Dust in the air reflected the flash light and appeared in the image. This is not a malfunction.
73
Troubleshooting
The date and time are not displayed.
• While shooting, the date and time are not displayed. Only during playback, the date and time!
are displayed.
The date and time are recorded incorrectly.
• Set the correct date and time.
The F value and shutter speed flash when you press and hold the shutter
button halfway down.
• The exposure is incorrect. Correct the exposure (page 28).
The image is too dark.
• You are shooting a subject with a light source behind the subject. Select the metering mode
(page 28) or adjust the exposure (page 28).
• The brightness of the screen is too low. Adjust the brightness of the LCD backlight (page 43).
The image is too bright.
• You are shooting a spotlighted subject in a dark location such as on a stage. Adjust the
exposure (page 28).
• The brightness of the screen is too bright. Adjust the brightness of the LCD backlight (page
43).
The image colors are not correct.
• Adjust the [P.Effect] to [Off] (page 30).
Vertical streaks appear when you are shooting a very bright subject.
• The smear phenomenon is occurring. This phenomenon is not a malfunction.
Noise appears in the image when you view the screen in a dark place.
• The camera is attempting to increase the visibility of the screen by temporarily brightening
the image under conditions of low illumination. There is no effect on the recorded image.
The eyes of the subject come out red.
• Set [Red Eye Reduction] in the (Setup) menu to [On] (page 39).
• Shoot the subject at a distance closer than the recommended shooting distance using the flash.
• Light the room and shoot the subject.
Dots appear and remain on the screen.
• This is not a malfunction. These dots are not recorded.
74
Cannot shoot images in succession.
• The internal memory or the “Memory Stick Duo” is full. Delete unnecessary images.
• The battery level is low. Install charged batteries or replace with new ones.
Refer to “Computers” (page 75) in conjunction with the following items.
Your camera cannot play back images.
• Set the mode dial to (page 24).
• The folder/file name has been changed on your computer.
• When an image file has been processed by a computer or when the image file was recorded
using a model other than that of your camera, playback on your camera is not guaranteed.
• The camera is in USB mode. Delete the USB communication (page 53).
The date and time are not displayed.
• !(Screen status) button is turned off (page 20).
The image appears rough right after playback starts.
• The image may appear rough right after playback starts due to image processing. This is not a
malfunction.
The image does not appear on the TV screen.
• Check [Video Out] to see if the video output signal of your camera is set to the color system
of your TV (page 44).
• Check whether the connection is correct (page 68).
• The USB cable is connected to the USB jack. Disconnect it according to the correct procedure
(page 53).
The image does not appear on the screen.
• If the A/V cable is connected, disconnect it (page 68).
No recorded sound is played back with movies on the camera.
• The sound recorded with moives can only be played back on TV, PC.
Viewing images
75
Troubleshooting
Your camera cannot delete an image.
• Cancel the protection (page 34).
• Set the write-protect switch on the “Memory Stick Duo” to the recording position (page 83).
You have deleted an image by mistake.
• Once you have deleted an image, you cannot restore it. We recommend that you set protection
on an image (page 33), or set the write-protect switch on the “Memory Stick Duo” to the
LOCK position (page 83) to prevent accidental erasure.
You cannot display a DPOF (Print order) mark.
• You cannot display DPOF (Print order) marks on movies.
You do not know if the OS of your computer is compatible with the camera.
• Check “Recommended computer environment” on page 47 for windows and page 60 for
Macintosh.
Your computer does not recognize your camera.
• Turn on the camera.
• When the battery level is low, install the charged batteries, replace the batteries with new
ones, or use the AC Adaptor (not supplied).
• Use the supplied USB cable.
• Disconnect the USB cable from both the computer and the camera, and connect it again
firmly. Make sure that “USB Mode Normal” is displayed (page 50).
• Set [USB Connect] to [Normal] in the (Setup) menu (page 44).
• Disconnect all equipment other than the camera, the keyboard and the mouse from the USB
connectors of your computer.
• Connect the camera directly to your computer without passing through a USB hub or other
device (page 50).
Deleting/Editing images
Computers
76
You cannot copy images.
• Connect the camera and your computer correctly using the USB cable (page 50).
• Follow the designated copy procedure for your OS (pages 50, 60).
• When you shoot images with a “Memory Stick Duo” formatted by a computer, you may not!
be able to copy the images to a computer. Shoot using a “Memory Stick Duo” formatted by!
your camera (page 41).
After making a USB connection, “Cyber-shot Viewer” does not start
automatically.
• Start “Media Check Tool” (page 56).
• Make the USB connection after the computer is turned on (page 50).
The image cannot be played back on a computer.
• If you are using “Cyber-shot Viewer”, refer to the Help.
• Consult the computer or software manufacturer.
The image and sound are interrupted by noise when you view a movie on a
computer.
• You are playing back the movie directly from the internal memory or the “Memory Stick
Duo”. Copy the movie to the hard disk of your computer, then play back the movie from the
hard disk (page 49).
You cannot print an image.
• Check the printer settings.
Images once copied to a computer cannot be viewed on the camera.
• Copy them to a folder recognized by the camera, such as “101MSDCF” (page 54).
• Operate correctly (page 55).
77
Troubleshooting
Images are not displayed correctly with “Cyber-shot Viewer”.
• Make sure the folder of the images is registered in “Viewed folders”. If the images are not
displayed even if the folder is registered in “Viewed folders”, update the database (page 59).
You cannot find images imported with “Cyber-shot Viewer”.
• Look in the “My Pictures” folder.
• If you have changed the default settings, refer to (page 59) and check what folder is used for
importing.
You want to change the “Folder to be imported”.
• Access the “Import Settings” screen to change “Folder to be imported”. You can specify a
different folder after using “Cyber-shot Viewer” to register it in “Viewed folders” (page 59).
All imported images are displayed on the calendar with the date January 1.
• The date has not been set on the camera. Set the date on the camera.
Cannot insert a “Memory Stick Duo”.
• Insert it in the correct direction.
Cannot record on a “Memory Stick Duo”.
• Set the write-protect switch on the “Memory Stick Duo” to the recording position (page 83).
• The “Memory Stick Duo” is full. Delete unnecessary images.
Cannot format a “Memory Stick Duo”.
• You are using the “Memory Stick Duo” with the write-protect switch, and the switch is set to!
the LOCK position. Set the switch to the recording position (page 83).
You have formatted a “Memory Stick Duo” by mistake.
• All the data on the “Memory Stick Duo” is deleted by formatting. You cannot restore it. We
recommend that you set the write-protect switch on the “Memory Stick Duo” to the LOCK
position to prevent accidental erasure (page 83).
“Memory Stick PRO Duo” is not recognized by a computer with a “Memory
Stick” slot.
• Check whether the computer and the card reader support “Memory Stick PRO Duo”. Users of!
computers and card readers made by companies other than Sony should contact those!
manufacturers.
“Cyber-shot Viewer”
“Memory Stick Duo”
78
• If “Memory Stick PRO Duo” is not supported, connect the camera to the computer (page 50).!The
computer recognizes the “Memory Stick PRO Duo”.
The camera or your computer cannot play back the data in the internal memory.
• There is a “Memory Stick Duo” inserted in the camera. Remove it.
Cannot record images using the internal memory.
• There is a “Memory Stick Duo” inserted in the camera. Remove it.
The free capacity of the internal memory does not increase even when you
copy the data stored in the internal memory to a “Memory Stick Duo”.
• The data is not deleted after copying. Execute the [Format] command (page 40) to format the
internal memory after copying the data.
Cannot copy the data stored in the internal memory to a “Memory Stick Duo”.
• The “Memory Stick Duo” is full. Check the capacity.
Cannot copy the data on the “Memory Stick Duo” or the computer to the
internal memory.
• Data on a “Memory Stick Duo” or a computer cannot be copied to the internal memory.
Also see “PictBridge compliant printer” (as follows) in conjunction with the following items.
Images are printed with both edges cut off.
• When printing images using your own printer, try canceling the trimming or borderles!settings.
Consult the printer manufacturer as to whether the printer provides these functions or!not.
• When having images printed at a digital print shop, ask the shop whether they can print the!images
without cutting off both edges.
A connection cannot be established.
• The camera cannot be connected directly to a printer that is not compliant with the PictBridge
standard. Consult the printer manufacturer as to whether the printer is compliant with
PictBridge or not.
• Check that the printer is turned on and can be connected to the camera.
• Set [USB Connect] to [PictBridge] in the (Setup) menu (page 44).
• Disconnect and connect the USB cable again. If an error message is indicated on the printer,
refer to the operating instructions supplied with the printer.
Internal memory
Printing
PictBridge compliant printer
79
Troubleshooting
Cannot print images.
• Check that the camera and the printer are properly connected using the USB cable.
• Turn on the printer. For further information, refer to the operating instructions supplied with
it.
• If you select [Exit] during printing, images may not print. Disconnect and connect the USB
cable again. If you still cannot print your images, disconnect the cable, turn the printer off and
then on, then connect the cable again.
• Movies cannot be printed.
• Images shot using cameras other than this camera or images modified with a computer may
not be printed.
Printing is canceled.
• You disconnected the USB cable before the (Do not disconnect the USB cable) mark
disappears.
Cannot insert the date or print images in the index mode.
• The printer does not provide these functions. Consult the printer manufacturer as to whether
the printer provides these functions or not.
• The date may not be inserted in the index mode depending on the printer. Consult the printer
manufacturer.
“---- -- --” is printed on the date-inserted part of the image.
• Images that do not have the recording data cannot be printed with the date inserted. Set [Date]
to [Off] and print the image again (page 65).
Cannot select the print size.
• Consult the printer manufacturer as to whether the printer can provide the desired size.
Cannot print the image at the size selected.
• If you have changed the paper size after having the USB cable connected, then connect the
printer again.
• The print setting of the camera differs from that of the printer. Change the setting of either the
camera (page 65) or the printer.
Cannot operate the camera after canceling printing.
• Wait for a while as the printer is carrying out the cancellation. It may take some time
depending on the printer.
80
Your camera does not work.
• Use the type of batteries you can use with this camera (page 85).
• The battery level is low (The E indicator appears). Install new batteries or charged Nickel-
Metal Hydride batteries(not supplied).
The power is on, but the camera does not work.
• The built-in microcomputer is not working properly. Remove the batteries, and then, after one
minute, insert the batteries and turn on the camera.
Cannot identify an indicator on the screen.
• See page 16.
The lens gets fogged.
• Moisture condensation has occurred. Turn off the camera and leave it for about an hour before
using it (page 87).
The camera becomes warm when you use it for a long time.
• This is not a malfunction.
The lens does not move when you turn off the camera.
• The batteries are discharged. Install new batteries or charged Nickel-Metal Hydride batteries
(not supplied) or use the AC Adaptor (not supplied).
The Clock Set screen appears when you turn on the camera.
• Set the date and time again.
The power of camera is turned off automatically when you remove the Memory
Stick Duo under power on status.
• This is not a malfunction. Turn off the camera before you remove the Memory Stick Duo.
Others
81
Troubleshooting
Warning messages
If the following messages appear, follow
the instructions.
Turn the power off and on again
• A problem with the lens has caused an
error.
E
• The battery level is low. Install new
ones or charged Nickel-Metal Hydride
batteries (not supplied). Depending on
the conditions of use or the type of
battery, the indicator may flash even
though there are still 5 to 10 minutes of
remaining battery time left.
System error
• Turn the power off and then on again.
Internal memory error
• Turn the power off and then on again .
Reinsert the Memory Stick
• Insert the “Memory Stick Duo”
correctly.
• The inserted “Memory Stick Duo”
cannot be used in your camera (page
83).
• The “Memory Stick Duo” is damaged.
• The terminal section of the “Memory
Stick Duo” is dirty.
Memory Stick type error
• The inserted “Memory Stick Duo”
cannot be used in your camera (page
83).
Format error
• Format the media again (pages 41).
Memory Stick locked
• You are using the “Memory Stick Duo”
with the write-protect switch, and the
switch is set to the LOCK position. Set
the switch to the recording position
(page 83).
No memory space in internal
memory
No memory space in Memory Stick
• Delete unnecessary images or files.
Read only memory
• Your camera cannot record or delete
images on this “Memory Stick Duo”.
No file
• No images have been recorded in the
internal memory.
No file in this folder
• No images have been recorded in this
folder.
• You did not operate correctly when
copying images from your computer
(page 55).
Folder error
• A folder with the same first three digit
number already exists on the “Memory
Stick Duo”. (For example: 123MSDCF
and 123ABCDE) Select other folders,
or create a new folder (page 41).
Cannot create more folders
• The folder with a name beginning with
“999” exists on the “Memory Stick
Duo”. You cannot create any folders if
this is the case.
Messages
82
Cannot record
• The camera cannot record images in the
selected folder. Select a different folder
(page 42).
File error
• An error occurred while the image was
playing back.
File protect
• Release the protection (page 34).
Image size over
• You are playing back an image of a size
that cannot be played back on your
camera.
Invalid operation
• You are trying to play back a file that is
not compatible with the camera.
Enable printer to connect
• [USB Connect] is set to [PictBridge],
however the camera is connected to a
non-PictBridge compliant device.
Check the device.
• The connection is not established.
Disconnect and connect the USB cable
again. If an error message is indicated
on the printer, refer to the operating
instructions supplied with the printer.
Connect to PictBridge device
• You tried to print images before the
printer connection was established.
Connect to a PictBridge compliant
printer.
No printable image
• You tried to execute [DPOF image]
without placing a DPOF (Print order)
mark on the image(s).
• You tried to execute [All In This
Folder] while a folder that holds only
movies was selected. You cannot print
movies.
Printer busy
Paper error
No Paper
Ink error
Low Ink
No Ink
• Check the printer.
Printer error
• Check the printer.
• Check if the image you want to print is
corrupted.
• The data transmission to the printer may
not be completed yet. Do not disconnect
the USB cable.
Processing
• The printer is canceling the current print
job. You cannot print until it is finished.
This may take time, depending on the
printer.
83
Others
Others
On the “Memory Stick”
A “Memory Stick” is a compact, portable
IC recording medium. The types of
“Memory Stick” that can be used with this
camera are listed in the table below.
However, proper operation cannot be
guaranteed for all “Memory Stick”
functions.
*1
“Memory Stick Duo”, “MagicGate Memory
Stick Duo” and “Memory Stick PRO Duo” are
equipped with MagicGate functions.
MagicGate is copyright protection technology
that uses encryption technology. Data
recording/playback that requires MagicGate
functions cannot be performed with this
camera.
*2
Supports high-speed data transfer using a
parallel interface.
• A “Memory Stick Duo” formatted with a
computer is not guaranteed to operate with this
camera.
• Data read/write speeds differ depending on the
combination of the “Memory Stick Duo” and
the equipment used.
Notes on using a “Memory Stick Duo”
(not supplied)
• You cannot record, edit or delete images if you
slide the write-protect switch to LOCK with a
fine-tipped object.
Some “Memory Stick Duo” cards do not
have a write-protect switch. On “Memory
Stick Duo” with this switch, the position
and shape may vary depending on the
“Memory Stick Duo”.
• Do not remove the “Memory Stick Duo” while
reading or writing data.
• Data may be corrupted in the following cases:
– When the “Memory Stick Duo” is removed or
the camera is turned off during a read or write
operation
– When the “Memory Stick Duo” is used in
locations subject to static electricity or
electrical noise
• We recommend backing up important data.
• Do not press down hard when you write down
on the memo area.
• Do not attach a label on the “Memory Stick
Duo” itself nor on a Memory Stick Duo Adaptor
(not supplied).
• When you carry or store the “Memory Stick
Duo”, put it in the case supplied with it.
• Do not touch the terminal section of the
“Memory Stick Duo” with your hand or a metal
object.
• Do not strike, bend or drop the “Memory Stick
Duo”.
• Do not disassemble or modify the “Memory
Stick Duo”.
• Do not expose the “Memory Stick Duo” to
water.
• Do not leave the “Memory Stick Duo” within
the reach of small children. They might
accidentally swallow it.
“Memory Stick” type Recording/
Playback
Memory Stick
(without MagicGate)
—
Memory Stick
(with MagicGate)
—
Memory Stick Duo
(without MagicGate)
a
Memory Stick Duo
(with MagicGate)
a
*1*2
MagicGate Memory Stick —
MagicGate Memory Stick
Duo
a
*1
Memory Stick PRO —
Memory Stick PRO Duo
a
*1*2
Terminal
Write-protect
switch
Memo area
84
• Do not use or store the “Memory Stick Duo”
under the following conditions:
– High temperature locations such as the hot
interior of a car parked in direct sunlight
– Locations exposed to direct sunlight
– Humid locations or locations with corrosive
substances present
Notes on using the Memory Stick Duo
Adaptor (not supplied)
• To use a “Memory Stick Duo” with a “Memory
Stick” compliant device, be sure to insert the
“Memory Stick Duo” into a Memory Stick Duo
Adaptor. If you insert a “Memory Stick Duo”
into a “Memory Stick” compliant device
without a Memory Stick Duo Adaptor, you
might not be able to remove it from the device.
• When inserting a “Memory Stick Duo” into a
Memory Stick Duo Adaptor, make sure the
“Memory Stick Duo” is inserted facing in the
correct direction, then insert it all the way in.
Incorrect insertion may result in a malfunction.
• When using a “Memory Stick Duo” inserted
into a Memory Stick Duo Adaptor with a
“Memory Stick” compliant device, make sure
that the Memory Stick Duo Adaptor is inserted
facing the correct direction. Note that improper
use may damage the equipment.
• Do not insert a Memory Stick Duo Adaptor into
a “Memory Stick” compliant device without a
“Memory Stick Duo” attached. Doing so may
result in malfunction of the unit.
Notes on using “Memory Stick PRO
Duo” (not supplied)
“Memory Stick PRO Duo” with a capacity up to
2 GB have been confirmed to operate properly
with this camera.
85
Others
On the batteries
Batteries you can use with your
camera
LR6 (size AA) alkaline batteries (2) (supplied /
non-rechargeable)
HR 15/51:HR6 (size AA) Nickel-Metal Hydride
batteries (2) (not supplied / rechargeable)
• NH-AA-2DB twin pack, etc.
ZR6 (size AA) Oxy Nickel Primary Battery (2)
(not supplied / non-rechargeable)
Batteries you cannot use with your
camera
Manganese batteries
Lithium batteries
Ni-Cd batteries
If you use the above batteries, we cannot
guarantee full performance of the camera by
property of the batteries, such as brownout of the
batteries.
On alkaline batteries/Oxy Nickel
Primary Battery
• Alkaline batteries/Oxy Nickel Primary Battery
have a shorter life compared to the Nickel-Metal
Hydride batteries. For this reason, the power
may turn off even though the battery remaining
indicator shows sufficient battery life
remaining.
• Battery performance differs greatly depending
on the manufacturer and the type of battery, and
in some cases the battery life may be extremely
short. This is especially true at low
temperatures, and you may not be able to shoot
at temperatures below 5°C (41°F).
• Do not mix new and old batteries.
• The battery remaining indicator may not display
the correct information when using alkaline
batteries/Oxy Nickel Primary Battery.
• Due to characteristics of alkaline batteries/Oxy
Nickel Primary Battery, there is a large
difference between the available shooting time
and the available playback time. For this reason,
the camera may turn off with the lens portion
extended when you switch the mode dial. In this
case, replace the batteries with new ones or fully
charged Nickel-Metal Hydride batteries.
On Nickel-Metal Hydride batteries
• Do not peel off the external seals or damage the
batteries. Never use batteries from which the
seals have been partially or completely
removed, or batteries that have been split in any
way. These may cause leakage, explosion, or
heat-up of the battery, and personal scald or
injury may be caused. These may cause a
malfunction of the battery charger.
• Always carry the Nickel-Metal Hidride batteries
in the battery case. Otherwise, metallic objects
may short the + and - ends, resulting in the risk
of heating or fire.
• If the poles of the Nickel-Metal Hydride
batteries are dirty, the batteries may not charge
properly. Wipe them with a dry cloth, etc.
• At the time of purchase, or when the Nickel-
Metal Hydride batteries have not been used for a
long time, they may not full charge. This is
typical of this type of battery, and is not a
malfunction. If this happens, repeatedly using
up the batteries fully, and then recharging them
should correct the problem.
• If you recharge Nickel-Metal Hydride batteries
before fully using up the existing charge, the
low battery warning may be displayed sooner
than expected. This is called the “memory
effect.”* If this problem occurs, charging the
batteries only after using up the existing charge
will correct it.
* The “memory effect” - the situation in which
the capacity of the battery is temporarily
lowered.
• To use up the batteries completely, put the
camera in the slide show mode (page 34) and
leave it that way until the batteries are used up.
• Do not mix new and used batteries.
• Do not expose the battery to water. The battery
is not water-resistant.
86
Effective use of Nickel-Metal Hydride
batteries
• Batteries are discharged even when they are not
used. We recommend you charge the batteries
just before using them.
• Battery performance decreases in low-
temperature surroundings, and the battery life is
shortened under such circumstances. To use the
battery longer, we recommend you keep the
battery in its case in a pocket close to your body
to warm it, and insert it in your camera just
before you start shooting.
• If the poles of the batteries and the terminals on
the battery cover of the camera are dirty, the
battery life may be extremely shortened.
Occasionally wipe them with a dry cloth, etc. to
keep them clean.
• If you shoot a lot using the flash and the zoom,
the battery power will be used up faster.
• We recommend having spare batteries handy for
two or three times the expected shooting time,
and try test shooting before actually using the
camera.
Battery life of Nickel-Metal Hydride
batteries
• The battery life is limited. The battery capacity
decreases little by little as you use it more and
more, and as time passes. When the battery
operating time seems to have been considerably
shortened, a probable cause is that the batteries
have reached the end of their life.
• The battery life varies depending on storage,
operating conditions, and environment, and is
different for each battery.
87
Others
Precautions
x Do not leave the camera in the
following places
• In an extremely hot place
In places such as in a car parked in the sun, the
camera body may become deformed and this
may cause a malfunction.
• Under direct sunlight or near a heater
The camera body may become discolored or
deformed, and this may cause a malfunction.
• In a location subject to rocking vibration
• Near strong magnetic place
• In sandy or dusty places
Be careful not to let sand or dust get into the
camera. This may cause the camera to
malfunction, and in some cases this malfunction
cannot be repaired.
x On cleaning
Cleaning the LCD screen
Wipe the screen surface with an LCD cleaning kit
(not supplied) to remove fingerprints, dust, etc.
Cleaning the lens
Wipe the lens with a soft cloth to remove
fingerprints, dust, etc.
Cleaning the camera surface
Clean the camera surface with a soft cloth slightly
moistened with water, then wipe the surface with
a dry cloth. Do not use the following as they may
damage the finish or the casing.
• Chemical products such as thinner, benzine,
alcohol, disposable cloths, insect repellent,
sunscreen or insecticide, etc.
• Do not touch the camera with the above on your
hand.
• Do not leave the camera in contact with rubber
or vinyl for a long time.
x On operating temperatures
Your camera is designed for use under the
temperatures between 0°C and 40°C (32°F and
104°F). (In case of alkaline batteries/Oxy Nickel
Primary Battery, the temperatures are between
5°C and 40°C (41°F and 104°F).) Shooting in
extremely cold or hot places that exceed this range
is not recommended.
x On moisture condensation
If the camera is brought directly from a cold to a
warm location, moisture may condense inside or
outside the camera. This moisture condensation
may cause a malfunction of the camera.
Moisture condensation occurs easily
when:
• The camera is brought from a cold location such
as a ski slope into a warmly heated room
• The camera is taken from an air-conditioned
room or car interior to the hot outdoors, etc.
How to prevent moisture condensation
When bringing the camera from a cold place to a
warm place, seal the camera in a plastic bag and
allow it to adapt to conditions at the new location
over about an hour.
If moisture condensation occurs
Turn off the camera and wait about an hour for the
moisture to evaporate. Note that if you attempt to
shoot with moisture remaining inside the lens, you
will be unable to record clear images.
x On the internal rechargeable
battery
This camera has an internal rechargeable battery
for maintaining the date and time and other
settings regardless of whether the power is on or
off.
This rechargeable battery is continually charged
as long as you are using the camera. However, if
you use the camera for only short periods, it
discharges gradually, and if you do not use the
camera at all for about one week it becomes
completely discharged. In this case, be sure to
charge this rechargeable battery before using the
camera.
However, even if this rechargeable battery is not
charged, you can still use the camera as long as
you do not record the date and time.
Charging method
Insert batteries with enough capacity in the
camera, or connect the camera to a wall outlet
(wall socket) using the AC Adaptor (not
supplied), and leave the camera for 24 hours or
more with the power off.
88
Index
Index
A
A/V cable..............................68
Aperture................................10
Auto Focus .............................9
Auto Review.........................39
AVI.......................................54
B
Back up.................................22
Beep......................................43
Blur .........................................9
Burst .....................................30
C
Camera..................................38
CD-ROM ..............................48
Change REC. Folder.............42
Cleaning................................87
Clock Set ..............................45
Cloudy ..................................29
Color .....................................11
Compression ratio.................13
Computer
Copying images.............49
Recommended
environment...................47
Software ........................48
Viewing image files stored
on a computer with your
camera ...........................55
Windows .......................46
Connecting
Computer.......................50
Printer............................64
TV .................................68
Copy .....................................42
Copying images to your
computer........................49
Create REC. Folder ..............41
Cyber-shot Viewer ...............56
D
Date...................................... 39
Date/Time ............................ 39
Day&Time ........................... 39
Daylight ............................... 29
Delete ................................... 15
Digital Zoom........................ 38
DPOF ................................... 66
E
Enlarging an image .............. 38
EV ........................................ 28
Exposure .............................. 10
Extension ............................. 55
F
File name.............................. 54
File Number ......................... 44
File storage destination ........ 54
Fine ...................................... 29
Fluorescent........................... 29
Focus ...................................... 9
Folder ................................... 32
Changing....................... 42
Creating ........................ 41
Format.................................. 41
I
Identifying parts ................... 14
Image file storage destinations
and file names............... 54
Image quality ................. 12, 29
Image size ............................ 12
Incandescent......................... 29
Index mode .......................... 63
Index screen ......................... 33
Indicator ...............see “Screen”
Initialize ............................... 43
Install ................................... 48
Internal memory................... 22
Internal Memory Tool ..........40
Internal rechargeable battery 87
ISO ........................... 10, 11, 29
J
JPG ....................................... 54
L
LCD Backlight .....................43
LCD screen.......... see “Screen”
M
Macintosh computer
Recommended
environment ..................60
“Memory Stick Duo” ........... 83
Format ........................... 41
Number of images/
recording time ...............21
Write-protect switch...... 83
Memory Stick Tool .............. 41
Menu..................................... 26
Items..............................27
Shooting ........................28
Viewing......................... 32
Metering Mode ..................... 28
Mode..................................... 30
Moisture condensation .........87
Monochrome ........................ 30
Multi-pattern metering .........28
N
NTSC.................................... 44
Number of images/Recording
time ...............................21
O
Optical zoom ........................ 38
OS......................................... 47
Overexposure ....................... 10
89
Index
P
P.Effect .................................30
PAL.......................................44
PC ...................see “Computer”
PFX .......................................30
PictBridge .............................63
Picture effect.........................30
Pixel ......................................12
Playback............ see “Viewing”
Playback/Edit........................24
Precautions............................87
Precision digital zoom ..........38
Pressing halfway down ...........9
Print ......................................62
Index mode ....................63
Single-image mode........63
Print order mark....................66
Printing at a shop ..................66
Printing directly ....................63
Program auto shooting..........24
Protect...................................33
R
REC Mode ............................30
Red Eye Reduction ...............39
Resize....................................35
Rotate....................................36
S
Saturation..............................31
Screen
Changing the display .....20
Indicator.........................16
LCD Backlight ..............43
Sepia .....................................30
Setup .........................31, 36, 37
Camera...........................38
Memory Stick Tool .......41
Setup 1...........................43
Setup 2...........................44
Setup 1.................................. 43
Setup 2.................................. 44
Sharpness ............................. 31
Shooting menu ..................... 28
Shooting movies................... 24
Single-image mode .............. 63
Slide ..................................... 34
Smart zoom .......................... 38
Software ............................... 48
Spot metering ....................... 28
Spot metering cross hairs ..... 28
Standard ............................... 29
T
Tripod receptacle.................. 14
Troubleshooting ................... 70
TV ........................................ 68
U
Underexposure ..................... 10
USB cable ............................ 19
USB Connect........................ 44
V
Video Out ............................. 44
Viewing
Movie ............................ 56
Still image ..................... 56
Viewing menu ...................... 32
W
Warning indicators and
messages ....................... 81
WB ....................................... 29
White balance....................... 29
Windows computer .............. 46
Recommended
environment .................. 47
Write-protect switch............. 83
90
Trademarks
• is a trademark of Sony
Corporation.
• “Memory Stick”, , “Memory Stick PRO”,
, “Memory Stick Duo”,
, “Memory Stick PRO
Duo”, , “MagicGate”,
and are trademarks of Sony
Corporation.
• Microsoft, Windows and DirectX are either
registered trademarks or trademarks of
Microsoft Corporation in the United States and/
or other countries.
• Macintosh and Mac OS are trademarks or
registered trademarks of Apple Computer, Inc.
• Intel, MMX, and Pentium are trademarks or
registered trademarks of Intel Corporation.
• In addition, system and product names used in
this manual are, in general, trademarks or
registered trademarks of their respective
developers or manufacturers. However, the ™
or ® marks are not used in all cases in this
manual.
Additional information on this product and answers
to frequently asked questions can be found at our
Customer Support Website.
