MCM302
Register your product and get support at
www.philips.com/welcome
EN User manual
DA Brugervejledning
DE Benutzerhandbuch
ES Manual del usuario
FR Mode d’emploi
IT Manuale utente
NL Gebruiksaanwijzing
SV Användarhandbok
3
6 Adjust volume level and sound effect
18
Adjust volume level 18
Select a preset sound effect 18
Enhance bass 18
Select automatic loudness control 18
Mute sound 18
7 Tune to FM radio stations 19
Program radio stations automatically 19
Program radio stations manually 19
Tune to a preset radio station 19
Show RDS information 19
Set RDS clock 20
8 Use more of your unit 21
Set the alarm timer 21
Set the sleep timer 21
Connect other devices 21
Listen to other devices 21
9 Product information 22
Specifi cations 22
Amplifi er 22
Disc 22
Tuner (FM) 22
Speakers 22
General information 22
USB playability information 22
Supported MP3 disc formats 23
RDS program types 23
10 Troubleshooting 24
Contents
1 Important 4
Safety 4
Important Safety Instructions 4
Safety-Important notes for users in the
U.K. 4
Hearing safety 5
Notice 6
Recycling 6
2 Your Micro Hi-Fi System 8
Introduction 8
What’s in the box 8
Overview of the main unit 9
Overview of the remote control 10
3 Get started 12
Connect speakers 12
Connect FM antenna 12
Connect power 13
Prepare the remote control 13
Set clock 13
Turn on 13
Switch to standby mode 13
4 Play disc/USB 15
Play from disc 15
Play from USB 15
5 Control play 16
Skip to a track 16
Pause/resume play 16
Search within a track 16
Display play information 16
Repeat play 16
Random play 16
Program tracks 16
English
EN
4
l Unplug this apparatus during lightning
storms or when unused for long periods
of time.
m Refer all servicing to qualifi ed service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
n Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
Install all batteries correctly, + and - as •
marked on the unit.
Do not mix batteries (old and new or •
carbon and alkaline, etc.).
Remove batteries when the unit is not •
used for a long time.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid fi lled objects,
lighted candles).
q This product may contain lead and
mercury. Disposal of these materials
may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local
authorities or the Electronic Industries
Alliance: www.eiae.org.
Safety-Important notes for users in
the U.K.
Mains plug
This apparatus is fi tted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1 Important
Safety
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifi ers) that
produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
j Only use attachments/accessories
specifi ed by the manufacturer.
k Use only with the cart, stand, tripod,
bracket, or table specifi ed by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
EN
5
This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The ‘exclamation point’ calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of fi re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids,
such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Warning
Never remove the casing of this unit. •
Never lubricate any part of this unit.•
Place this unit on a fl at, hard and stable surface.•
Never place this unit on other electrical equipment.•
Only use this unit indoors. Keep this unit away from •
water, moisture and liquid-fi lled objects.
Keep this unit away from direct sunlight, naked fl ames
•
or heat.
Never look into the laser beam inside the unit.
•
Hearing safety
Listen at a moderate volume.
Using headphones at a high volume can •
impair your hearing. This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person,
even for exposure less than a minute. The
higher decibel ranges are offered for those
that may have already experienced some
hearing loss.
a Remove fuse cover and fuse.
b Fix new fuse which should be a BS1362 5
Amp, A.S.T.A. or BSI approved type.
c Refi t the fuse cover.
If the fi tted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fi tted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board should
not be greater than 5 Amp.
Note: The severed plug must be disposed off
to avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N), brown
= live (L).
As these colours may not correspond with the
colour markings identifying the terminals in your
plug, proceed as follows:
Connect the blue wire to the terminal •
marked N or coloured black.
Connect the brown wire to the terminal •
marked L or coloured red.
Do not connect either wire to the earth •
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath of
the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require
consent. see Copyright Act 1956 and The
performer’s Protection Acts 1958 to 1972.
Know these safety symbols
English
EN
6
Notice
Any changes or modifi cations made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
This product complies with the radio
interference requirements of the European
Community.
This product complies with the requirements
of the following directives and guidelines:
2004/108/EC, 2006/95/EC
Recycling
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When you see the crossed-out wheel bin
symbol attached to a product, it means the
product is covered by the European Directive
2002/96/EC:
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products. The correct
disposal of your old product helps prevent
potentially negative consequences on the
environment and human health.
Sound can be deceiving. Over time your •
hearing ‘comfort level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can actually
be loud and harmful to your hearing. To
guard against this, set your volume to a safe
level before your hearing adapts and leave
it there.
To establish a safe volume level:
Set your volume control at a low setting. •
Slowly increase the sound until you can •
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
Prolonged exposure to sound, even at •
normally ‘safe’ levels, can also cause hearing
loss.
Be sure to use your equipment reasonably •
and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
Listen at reasonable volumes for •
reasonable periods of time.
Be careful not to adjust the volume as your •
hearing adapts.
Do not turn up the volume so high that •
you can’t hear what’s around you.
You should use caution or temporarily •
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffi c
hazard and is illegal in many areas.
Norge
Typeskilt fi nnes på apparatens bakside.
Observer: Nettbryteren er sekundert innkoplet.
Den innebygde netdelen er derfor ikke
fraktoplet nettet så lenge apparatet er tilsluttet
nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet, ikke utsettes for regn eller
fuktighet.
EN
7
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed of with normal household waste.
When you see the crossed-out wheel bin
symbol with the chemical symbol ‘Pb’, it means
that the batteries comply with the requirement
set by the directive for lead:
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Recording and playback of material might
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
Windows Media and the Windows logo
are trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, inc.
This unit includes this label:
Pb
English
EN
8
What’s in the box
Check and identify the contents of your
package:
Main unit•
Loudspeaker boxes x 2•
Power cord•
Remote control with battery•
FM wire antenna•
2 Your Micro Hi-
Fi System
Congratulations on your purchase, and
welcome to Philips! To fully benefi t from the
support that Philips offers, register your product
at www.Philips.com/welcome.
Introduction
With this unit, you can:
enjoy music from audio discs and USB •
devices directly
listen to FM radio stations•
You can enrich sound output with these
sound effects:
Digital Sound Control (DSC)•
Dynamic Bass Boost (DBB) •
Bass/treble enhancement•
The unit supports these media formats:
EN
9
Overview of the main unit
o
n
p
a
b
c
d
e
k
m
f
h
g
i
j
l
English
EN
10
Overview of the remote
control
x
v
r
p
o
n
q
u
t
s
w
c
b
a
e
f
g
i
j
k
l
m
h
d
a
Connect headphones.•
b STANDBY-ON
Turn on the unit, switch to standby •
mode, or switch to Eco Power
Standby.
c MP3 LINK
Jack for an external audio device.•
d OPEN/CLOSE
Open or close the disc compartment.•
e DBB
Turns on or off dynamic bass •
enhancement.
f SOURCE
Select a source: CD/MP3, USB, •
TUNER (FM) or AUX (MP3 link).
g
/
Skip to the previous/next track.•
Fast reverse or fast forward within a •
track or disc.
Tune to a radio station.•
h PRESET/ALBUM +/-
Skip to the previous/next album.•
Select a preset radio station.•
i
Start or pause play.•
j STOP
Stop play or erase a program.•
k MODE
Select repeat play or random play.•
l VOLUME + / -
Adjust volume.•
Adjust time.•
m USB DIRECT
Jack for a USB mass storage device. •
n IR sensor
o Disc compartment
p Display panel
Show current status.•
EN
11
n PROG
Program tracks or browse the •
program.
Program radio stations.•
o Numeric keypad
Select a track from a disc directly.•
p PRESET/ALBUM +/-
Skip to the previous/next album.•
Select a preset radio station.•
q
Stop play or erase a program.•
r CLOCK
Set the clock.•
s
/
Fast reverse or fast forward within a •
track or disc.
Tune to a radio station.•
t
Start or pause play.•
u
/
Skip to the previous/next track.•
Select a preset radio station.•
v OPEN/CLOSE
Open or close the disc tray.•
w SHUFFLE
Play tracks randomly.•
x REPEAT/ST.
Select a repeat play mode.•
Select stereo or mono sound output •
for an FM radio station.
a
Turn on the unit, switch to standby •
mode, or switch to Eco Power
Standby.
b Source selection keys ( CD , USB, FM,
AUX/MP3 LINK )
Select a source: CD/MP3, USB, •
TUNER (FM) or AUX (MP3 link).
c SLEEP
Set the sleep timer.•
d TIMER
Set the alarm timer.•
e DISPLAY
During play, select display information.•
f RDS
Display available RDS (Radio Data •
System) information of an FM radio
station.
g VOL +/-
Adjust volume.•
Adjust time.•
h MUTE
Mute volume.•
i DIM
Adjust brightness of the display panel.•
j LOUD
Enable or disable automatic loudness •
adjustment for bass and treble
enhancement.
k DSC
Select a preset sound setting.•
l DBB
Turns on or off dynamic bass •
enhancement..
m SHIFT
Enter a 2 or 3-digit number (used •
together with the numeric keypad).
English
EN
12
Connect FM antenna
Tip
For optimal reception, fully extend and adjust the •
position of the antenna.
For better FM stereo reception, connect an outdoor
•
FM antenna to the FM AERIAL jack.
The unit does not support MW radio reception.
•
1 Connect the supplied FM antenna to the
FM AERIAL jack on the main unit.
abc
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for
the model and serial number of your unit. The
model number and serial number are on the
bottom of your unit. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Connect speakers
Note
Ensure that the colors of the speaker wires and •
terminals are matched.
For optimal sound, use the supplied speakers only.
•
Connect only speakers with impedance that is the •
same or higher than the supplied speakers. Refer to the
Specifi cations section of this manual.
1 Hold down the socket fl ap.
2 Insert the stripped part of the wire
completely.
Insert the right speaker wires to “ • R”,
left speaker wires to “ L”.
Insert the red wires to “ • +”, black wires
to “ -”.
3 Release the socket fl ap.
EN
13
Note
Before you press any function button on the remote •
control, fi rst select the correct source with the remote
control instead of the main unit.
If you are not going to use the remote control for a
•
long time, remove the battery.
Set clock
1
In the standby mode, press and hold
CLOCK to activate the clock setting
mode.
The hour digits are displayed and begin »
to blink.
If the hour digits are not displayed, »
press and hold
for more than 2
seconds to switch to standby mode,
then repeat step 1.
2 Press + VOL - to set the hour.
The minute digits are displayed and »
begin to blink.
3 Press + VOL - to set the minute.
4 Press CLOCK to confi rm the clock setting.
Turn on
1
Press .
The unit switches to the last selected »
source.
Switch to standby mode
1 Press to switch the unit to Eco Power
Standby mode.
The backlight on the display panel »
turns off.
The blue Eco Power indicator turns on.»
Connect power
Caution
Risk of product damage! Ensure that the power supply •
voltage corresponds to the voltage printed on the back
or the underside of the unit.
Risk of electric shock! When you unplug the AC power
•
cord, always pull the plug from the socket. Never pull
the cord.
Before you connect the AC power cord, ensure that
•
you have completed all other connections.
1 Connect the power cord to the AC~ jack
on the main unit.
2 Connect the power plug to the wall outlet.
Prepare the remote control
Caution
Risk of explosion! Keep batteries away from heat, •
sunshine or fi re. Never discard batteries in fi re.
For fi rst-time use:
1 Remove the protective tab to activate the
remote control battery.
To replace the remote control batteries:
1 Open the battery compartment.
2 Insert one lithium CR2025 battery with
correct polarity (+/-) as indicated.
3 Close the battery compartment.
English
EN
14
To switch the unit to standby mode:
1 In Eco Power Standby mode, press and
hold
for more than 3 seconds.
The clock (if set) appears on the »
display panel.
The blue Eco Power indicator turns off.»
EN
15
5 Press / to select a fi le.
6 Press to start play.
4 Play disc/USB
Play from disc
1
Press CD to select the CD source.
2 Press OPEN/CLOSE.
The disc tray opens.»
3 Place a disc onto the tray and press
OPEN/CLOSE.
Ensure that the label is facing upwards.»
4 Play starts automatically.
If play does not start, press •
/ to select a
track and then press
.
Play from USB
Note
Ensure that the USB device contains playable music .•
1 Flip open the cover marked USB
DIRECT
on the top panel.
2 Insert the USB plug of a USB device into
the exposed socket.
3 Press USB to select the USB source.
The total number of tracks is displayed.»
4 Press PRESET/ALBUM +/- to select a
folder.
English
EN
16
The track number and total remaining »
play time
For MP3 disc:
1 Press DISPLAY to display ID3 information
(if available).
Repeat play
1
During play, press REPEAT/ST. repeatedly
to select:
» [REPEAT] (repeat): play the current
track repeatedly.
» [REPEAT ALL] (repeat all): play all
tracks repeatedly.
2 To return to normal play, press REPEAT/
ST. until the selected function is no longer
displayed.
Random play
1
Press SHUFFLE.
All tracks are played randomly.»
2 To return to normal play, press SHUFFLE
again.
Tip
The repeat and shuffl e functions cannot be activated at •
the same time.
Program tracks
You can program a maximum of 20 tracks.
1 Press PROG to activate the programming
mode.
A track number fl ashes.»
2 Press / to select a track number to
program, then press PROG to confi rm.
5 Control play
Skip to a track
For CD:
1 Press / to select another track.
To select a track directly, you can also •
press a key on the numerical keypad.
Tip
To enter a 2 or 3-digit number, press • SHIFT, then enter
the number.
For MP3 disc and USB:
1 Press PRESET/ALBUM +/- to select an
album or folder.
2 Press / to select select a track or fi le.
Pause/resume play
1
During play, press to pause/resume
play.
Search within a track
1
During play, press and hold / .
2 Release to resume normal play.
Display play information
For CD:
1 Press DISPLAY repeatedly to see the
following information.
The track number and elapsed play »
time of the current track
The track number and remaining play »
time of the current track
EN
17
To select a track in an MP3 disc or •
USB device, fi rst press PRESET/
ALBUM +/- to select the album
where the track is located.
• [P-X] is displayed, where “X” is the
next position in the program.
3 Repeat steps 2 to 3 to select and store all
tracks to program.
4 Press PROG to complete.
» [PROG] (program) is displayed.
5 Press to play the programmed tracks.
To erase the program, press •
.
English
EN
18
1 During play, press LOUD to enable/disable
automatic loudness control.
Mute sound
1
During play, press MUTE to mute/unmute
sound.
6 Adjust volume
level and sound
effect
Note
You cannot use the DSC, DBB and Loudness features •
at the same time.
Adjust volume level
1
During play, press VOL +/- to increase/
decrease the volume level.
Select a preset sound effect
1
During play, press DSC repeatedly to
select:
• [ROCK] (rock)
• [CLASSIC] (jazz)
• [POP] (pop)
• [CLASSIC] (classic)
• [FLAT] (fl at).
Enhance bass
1
During play, press DBB to enable/disable
bass enhancement.
Select automatic loudness
control
The loudness feature enables the system to
increase the treble and bass sound effect at low
volume automatically (the higher the volume,
the lower the treble and bass increase).
EN
19
Program radio stations
manually
Note
You can program a maximum of 20 preset radio •
stations.
1 Tune to a radio station.
2 Press PROG to activate programming.
3 Press PRESET/ALBUM +/- to allocate a
number from 1 to 20 to this radio station,
then press PROG to confi rm.
The preset number and the frequency »
of the preset station are displayed.
4 Repeat the above steps to program other
stations.
Note
To overwrite a programmed station, store another •
station in its place.
Tune to a preset radio station
1
Press PRESET/ALBUM +/- to select a
preset number that you want.
Tip
You can also use the numerical keypad to select a •
preset station directly.
To enter a 2 or 3-digit number, press
• SHIFT, then enter
the number.
Show RDS information
RDS (Radio Data System) is a service
that allows FM stations to show additional
information. If you tune to a RDS station, a RDS
icon and the station name are displayed.
7 Tune to FM
radio stations
1 Ensure that you have connected and fully
extended the supplied FM antenna.
2 Press FM.
3 Press and hold / .
4 When [SEARCH] (search) is displayed,
release the button.
The FM tuner tunes to a station with »
strong reception automatically.
5 Repeat steps 3-4 to tune to more stations.
To tune to a weak station:
Press
/ repeatedly until you fi nd optimal
reception.
Program radio stations
automatically
Note
You can program a maximum of 20 preset radio •
stations.
1 Press PRESET/ALBUM +/- to select a
preset number to start programing.
2 Press and hold / for 2 seconds to
activate automatic programming.
» [AUTO] (auto) appears.
All available stations are programmed »
in the order of waveband reception
strength.
The last programed radio station is »
played automatically.
English
EN
20
When automatic programming is used, RDS
stations are programmed fi rst.
1 Tune to a RDS station.
2 Press RDS repeatedly to scroll through the
following information (if available):
Station name»
Program type such as » [NEWS] (news(,
[SPORT] (sport), [POP M] (pop
music). ..
Frequency»
Note
See• RDS program types (see ‘RDS program types’ on
page 23) for detailed defi nition of each possible RDS
program type.
Set RDS clock
You can use time signal broadcast together
with the RDS signal to set the clock of the unit
automatically.
1 Tune to a RDS radio station that transmits
time signals.
The unit reads the RDS time and sets »
the clock automatically.
Note
The accuracy of the transmitted time depends on the •
RDS station that transmits the time signal.
EN
21
Connect other devices
Caution
Before you connect other devices to the unit, ensure •
that the AC power is unplugged.
Note
If the device only provides a mono jack, connect it to •
the left jack on the unit. Alternatively, you can also use a
“single to double” cinch cable.
Listen to other devices
You can listen to other devices through this unit.
1 Connect the audio output sockets to the
AUX IN (L/R) sockets on this unit.
8 Use more of
your unit
Set the alarm timer
1
Ensure that you have set the clock
correctly.
2 In standby mode, press and hold TIMER.
The hour digits are displayed and begin »
to blink.
3 Press + VOL - to set the hour.
The minute digits are displayed and »
begin to blink.
4 Press + VOL - to set the minute.
5 Press TIMER to confi rm.
6 To activate the wake-up timer, press + VOL
- to select [ON] (on).
A clock icon appears on the display.»
The unit turns on automatically at »
the set time and switches to the last
selected source.
To deactivate the alarm timer, select • [OFF]
(off) at step 6.
Set the sleep timer
1
When the unit is turned on, press SLEEP
repeatedly to select a set period of time
(in minutes).
The unit turns off automaticaly after »
the set period of time.
English
EN
22
Tuner (FM)
Tuning Range 87.5 - 108MHz
Tuning grid 50KHz
Sensitivity
- Mono, 26dB S/N Ratio
- Stereo, 46dB S/N Ratio
<22 dBf
>43 dBf
Search Selectivity >28dBf
Total Harmonic Distortion <3%
Signal to Noise Ratio >55dB
Speakers
Speaker Impedance 4ohm
Speaker Driver 4”
Sensitivity >80dB/m/W±4dB/m/W
General information
AC power 230V, 50Hz
Operation Power
Consumption
20W
Standby Power
Consumption
<4W
Eco Standby Power
Consumption
<1W
Audio Ouput 1Vpp±0.1Vpp3.5kohm
USB Direct Version 2.0
Dimensions
- Main Unit (W x H
x D)
- Speaker Box (W x
H x D)
200 x 120 x 265mm
150 x 250 x 165mm
Weight
- With Packing
- Main Unit
- Speaker Box
7.5 kg
2.55 kg
2 x 1.4 kg
USB playability information
Compatible USB devices:
USB fl ash memory (USB 2.0 or •
USB1.1)
9 Product
information
Note
Product information is subject to change without prior •
notice.
Specifi cations
Amplifi er
Rated Output Power 2X25W RMS
Frequency Response 20 -20000 Hz, -3dB
Signal to Noise Ratio >65dB
Aux Input 0.5 V RMS 20kohm
Disc
Laser Type Semiconductor
Disc Diameter 12cm/8cm
Support Disc CD-DA, CD-R, CD-RW,
MP3-CD, WMA-CD
Audio DAC 24Bits / 44.1kHz
Total Harmonic
Distortion
<1%
Frequency
Response
50Hz - 20kHz (44.1kHz)
S/N Ratio >65dBA
EN
23
RDS program types
NO TYPE No RDS programme
type
NEWS News services
AFFAIRS Politics and current affairs
INFO Special information
programs
SPORT Sports
EDUCATE Education and advanced
training
DRAMA Radio plays and literature
CULTURE Culture, religion and
society
SCIENCE Science
VARIED Entertainment programs
POP M Pop music
ROCK M Rock music
MOR M Light music
LIGHT M Light classical music
CLASSICS Classical music
OTHER M Special music programs
WEATHER Weather
FINANCE Finance
CHILDREN Children’s programs
SOCIAL Social Affairs
RELIGION Religion
PHONE IN Phone In
TRAVEL Travel
LEISURE Leisure
JAZZ Jazz Music
COUNTRY Country Music
NATION M National Music
OLDIES Oldies Music
FOLK M Folk Music
DOCUMENT Documentary
TES Alarm Test
ALARM Alarm
USB fl ash players (USB 2.0 or USB1.1)•
memory cards (requires an additional •
card reader to work with this unit)
Supported formats:
USB or memory fi le format FAT12, •
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps •
and variable bit rate
WMA v9 or earlier•
Directory nesting up to a maximum •
of 8 levels
Number of albums/ folders: maximum •
99
Number of tracks/titles: maximum 999•
ID3 tag v2.0 or later•
File name in Unicode UTF8 •
(maximum length: 128 bytes)
Unsupported formats:
Empty albums: an empty album is an •
album that does not contain MP3/
WMA fi les, and is not be shown in the
display.
Unsupported fi le formats are skipped. •
For example, Word documents (.doc)
or MP3 fi les with extension .dlf are
ignored and not played.
AAC, WAV, PCM audio fi les•
DRM protected WMA fi les (.wav, •
.m4a, .m4p, .mp4, .aac)
WMA fi les in Lossless format•
Supported MP3 disc formats
ISO9660, Joliet•
Maximum title number: 512 (depending on •
fi le name length)
Maximum album number: 255•
Supported sampling frequencies: 32 kHz, •
44.1kHz, 48 kHz
Supported Bit-rates: 32~256 (kbps), •
variable bit rates
English
EN
24
Reduce the distance between the remote •
control and the unit.
Insert the battery with its polarities (+/– •
signs) aligned as indicated.
Replace the battery.•
Aim the remote control directly at the •
sensor on the front of the unit.
No disc detected
Insert a disc.•
Check if the disc is inserted upside down.•
Wait until the moisture condensation at •
the lens has cleared.
Replace or clean the disc.•
Use a fi nalized CD or correct format disc.•
Cannot display some fi les in USB device
The number of folders or fi les in the USB •
device has exceeded a certain limit. This
phenomenon is not a malfunction.
The formats of these fi les are not •
supported.
USB device not supported
The USB device is incompatible with the unit.
Try another one.
Poor radio reception
Increase the distance between the unit and •
your TV or VCR.
Fully extend the FM antenna.•
Connect an outdoor FM antenna instead.•
Timer does not work
Set the clock correctly.•
Switch on the timer.•
Clock/timer setting erased
Power has been interrupted or the power •
cord has been disconnected.
Reset the clock/timer.•
10 Troubleshooting
Caution
Never remove the casing of this unit. •
To keep the warranty valid, never try to repair
the unit yourself.
If you encounter problems when using this unit,
check the following points before requesting
service. If the problem remains unsolved, go to
the Philips web site (www.Philips.com/support).
When you contact Philips, ensure that your
unit is nearby and the model number and serial
number are available .
No power
Ensure that the AC power cord of the unit •
is connected properly.
Ensure that there is power at the AC •
outlet.
As a power-saving feature, the system •
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
No sound or poor sound
Adjust the volume.•
Disconnect the headphones.•
Check that the speakers are connected •
correctly.
Check if the stripped speaker wires are •
clamped.
Left and right sound outputs reversed
Check the speaker connections and location.
No response from the unit
Disconnect and reconnect the AC power •
plug, then turn on the unit again.
As a power-saving feature, the system •
switches off automatically 15 minutes after
track play reaches the end and no control
is operated.
Remote control does not work
Before you press any function button, fi rst •
select the correct source with the remote
control instead of the main unit.
EN
© 2008 Koninklijke Philips Electronics N.V.
All rights reserved.
