Chapter 1 - Introduction
1.1 - Before Use
Congratulations on your VIZIO L15 15” LCD Television purchase. Thank you for your support of
VIZIO and its LCD Television product line. The L15 is a precise electronic product and you
should read the following instructions carefully to maximize the performance of the product. It has
passed regulatory safety certifications and you can be assured of the highest quality display with
the utmost reliability. After you have finished reading the instructions, put them away in a safe
place for future reference.
1.2 – Specifications*
Panel: 15" Diagonal, 4:3 Aspect Ratio, TFT Panel
Resolution: 1024 x 768 pixels
Display Compatibility: SDTV (480i) Native
Signal Compatibility: 480i (SDTV)
Response Time: 25mS (typical)
Brightness: 300 nits (typical)
Contrast: 450:1 (typical)
Viewing Angle: 150 degrees (H) / 110 degrees (V) for CR>5
Inputs:
1 x RF (1 x F Connector for internal NTSC Tuner), 1 x Composite Video (1 x RCA), 1 x
RGB D-Sub (1 x analog RGB), 1 x S-Video (1xDIN) plus 2 x Audio (2 x RCA, L+R)
Features:
CC, V-Chip, Comb Filter, Scalar and De-Interlacer, NTSC Video Decoding via RF
Antenna, Cable or Satellite (Set Top Box may be required)
Speakers: Built-in 2 x 2 W
Lamp Life: 50,000 hours (typical)
Operating Environment:
Temperature: 5~35°C (41~95°F)
Humidity: 10%~90% (no-condensation)
Altitude: 0~10,000 ft.
Storage Environment:
Temperature: -20~60°C (-4~140°F)
Humidity: 10%~90% (no-condensation)
Altitude: 0~40,000 ft.
Power Input: IEC connector for power line connection.
Voltage Range: 100-240 Vac at 50/60 Hz
Power consumption: 60W
Dimensions: 18.5" (w) x 11.4" (h) x 3.33" (d) without Stand, 18.5”(w) x 13.05” (h) x 6.9” (d) with Stand
Net Weight: 10.14 lbs (4.6 kg) with stand
Gross Weight: 15.4 lbs (7.0 kg)
Certifications: UL, C-UL, FCC Class B
*Product specifications are subject to change without notice or obligation.
Note: In some countries or regions, the shape of the power plug and power outlet may
sometimes differ from that shown in the explanatory drawings. However, the method of
connecting and operating the unit is the same.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
3
1.3 - Opening the Package
• The VIZIO L15 is packaged in a carton together with other standard accessories. Any
optional accessories are packed separately in another carton.
• Never place the unit on a surface with the glass facing downwards unless it is on protective
padding.
• When opening the carton, check that the product is in good condition and that all standard
accessories and items are included.
• Save the original box and all packing materials for future shipping needs.
1.4 - Installation
• Please read the user manual carefully before performing the installation.
• The power consumption of the display is approximately 60 Watts. Please use the power cord
designated for the product. When an extension cord is required, use one with the correct
power rating. The cord must be grounded and the grounding feature must not be defeated.
• The product should be installed on a flat surface to avoid tipping. Space should be
maintained between the back of the product and the wall for proper ventilation. See Section
3.2 - Installation of Wall Mount, page 17, for additional information.
• Please ensure the product is installed with the screen in landscape orientation. Any 90°
clockwise or counterclockwise installation may induce poor ventilation and subsequent
component damage.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
4
1.5 - Important Safety Guidelines
This product is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire.
To prevent the product from being damaged, the following rules should be observed for the installation, use and maintenance of the
product. Read the following safety instructions before operating the display. Keep these instructions in a safe place for future
reference.
• To avoid the risk of electric shock or component damage, switch off the power before connecting other components to the L15
LCD TV.
• Unplug the power cord before cleaning the L15 LCD TV. A damp cloth is sufficient for cleaning the L15 LCD TV. Do not use a
liquid or a spray cleaner for cleaning the product. Do not use abrasive cleaners.
• Always use the accessories recommended by the manufacturer to insure compatibility.
• When moving the L15 LCD TV from an area of low temperature to an area of high temperature, condensation may form on the
housing. Do not turn on the L15 LCD TV immediately after this to avoid causing fire, electric shock or component damage.
• Do not place the L15 LCD TV on an unstable cart, stand, or table. If the L15 LCD TV falls, it can injure a person and cause
serious damage to the appliance.
• A distance of at least 2 feet should be maintained between the L15 LCD and any heat source, i.e. radiator, heater, oven,
amplifier etc. Do not install the product close to smoke. Operating the product close to smoke or moisture may cause fire or
electric shock.
• Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of the L15
LCD TV and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the L15 LCD TV
in a bookcase or cabinet unless proper ventilation is provided.
• Never push any object into the slot on the L15 LCD TV cabinet. Do not place any objects on the top of the product. It could
short circuit parts causing a fire or electric shock. Never spill liquids on the L15 LCD TV.
• The L15 LCD TV should be operated only from the type of power source indicated on the label. If you are not sure of the type
of power supplied to your home, consult your dealer or local power company.
• The power cable must be replaced when using different voltage from that specified in the User Manual. For more information,
contact your dealer.
• The L15 LCD TV is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into
a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician
install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded
plug.
• Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
• The wall socket shall be installed near the equipment and shall be easily accessible.
• Only the marked power source can be used for the product. Any power source other than the specified one may cause fire or
electric shock.
• Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power cord during electrical storms.
• Unplug the unit during a lightening storm or when it will not be used for long period of time. This will protect the L15 LCD TV
from damage due to power surges.
• Do not attempt to repair or service the product yourself. Opening or removing the back cover may expose you to high
voltages, the risk of electric shock, and other hazards. If repair is required, please contact your dealer and refer all servic
ing to
qualified service personnel.
• Keep the product away from moisture. Do not expose this appliance to rain or moisture. If water penetrates into the product,
unplug the power cord and contact your dealer. Continuous use in this case may result in fire or electric shock.
• Do not use the product if any abnormality occurs. If any smoke or odor becomes apparent, unplug the power cord and contact
your dealer immediately. Do not try to repair the product yourself.
• Avoid using dropped or damaged appliances. If the product is dropped and the housing is damaged, the internal components
may function abnormally. Unplug the power cord immediately and contact your dealer for repair. Continued use of the
product may cause fire or electric shock.
• Follow instructions for moving the product. Ensure that the power connector and any other cables are unplugged before
moving the product.
• Hold the power connector when removing the power cable. Pulling the power cable itself may damage the wires inside the
cable and cause fire or electric shock. When the product will not be used for an extended period of time, unplug the power
connector.
• To avoid risk of electric shock, do not touch the connector with wet hands.
• Insert batteries for the remote control in accordance with instructions. Incorrect polarities may cause damage and leakage of
the batteries, operator injury and contamination the remote controller.
• If any of the following occurs please contact the dealer:
o The power connector fails or frays.
o Liquid sprays or any object drops into the L15 LCD TV.
o The display is exposed to rain or other moisture.
o The display is dropped or damaged in any way.
o The performance of the Display changes substantially.
• Operating environment: Temperature: 5°C ~ 35°C (41°F ~ 95°F), Humidity: 10% to 90% non-condensing
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
5
1.6 - Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna or cable system is to be connected to the LCD TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage
surges and static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of the grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements of the grounding electrode. See figure
below for proper configuration.
Lightning Protection
For added protection of the LCD TV during a lightning storm or when it is left unattended or
unused for long periods of time, unplug the LCD TV from the wall outlet and disconnect the
antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such
power lines or circuits.
Note to the CATV system installer: This reminder is provided to call the CATV system installer's
attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as practical.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
6
1.7 - Package Contents
VIZIO L15 15” LCD TV
Standard Remote Control
Power Cord and DC Adapter
Audio Cable and adapter
Video Adapter
Quick Set up Guide
Registration Card
Warranty Information
This User Guide
IMPORTANT: Save the original box and all the packing material for future shipping needs.
Note: Your product may also include various other accessories depending on region of
purchase.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
7
1.8 - Front Panel
Use the buttons on the front panel control to display and adjust the On Screen Display (OSD).
1) Volume - /+ – These buttons are used to increase or decrease the speaker volume. While the
OSD is active, these buttons function as adjustment controls in the OSD menus.
2) Channel d/c – These buttons are used to increase or decrease the selected channels. While
the OSD is active, these buttons function as select controls in the OSD menus.
3) Menu – When this button is pressed, the OSD main menu will appear on the screen. If it is
pressed while the main menu is displayed, the main menu will disappear. If pressed while an
OSD sub menu is displayed, it will exit the sub menu and go back to the last menu.
4) Audio – This button switches between the available audio sources in the following sequence:
TV, Audio 1 (PC), or Audio 2 (AV).
5) Input – This button switches between the available input sources in the following sequence:
AIR (TV), PC Mode (RGB), and Video (AV or S-Video).
6) Power – Switch the TV on by pressing the button once. Press the button again to turn the TV
off. If the TV is plugged in, but powered off, the indicator light will be orange.
7) Remote Control Sensor – This is the window that passes all of the remote signals to the
sensor. Point the remote control directly at this window for the best response to the remote
signal.
Note: In all submenus, the cursor movement is circulatory. For example, if the
d
Ch button is
pressed when the cursor is on the last item in the submenu, the cursor will move to the main
icon.
1 2 3 4 5 6
7
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
8
1.9 - Rear Panel Connections
1. DC In – Connect one end of the DC Adapter here and connect the power cord to a
properly grounded outlet.
2. Analog (RGB) – Connect the analog (RGB) input to external video source such as a PC.
3. Audio Input
a) Audio 1 – Connect the external audio from a PC source.
b) Audio 2 – Connect the external audio from the video source such as a DVD player or
set-top box.
Note: Please use the audio cable adapter supplied by VIZIO when connecting external
audio to the L15 LCD TV.
4. Audio Out – Connect the internal audio to an external amplifier or receiver.
5. TV – Connect to the antenna, satellite or cable service source.
6. S-Video – Connect the S-Video input to external video device such as VCR, DVD and
video games.
7. AV – Connect the composite video input to external video device such as VCR, DVD and
video games.
1 2
3a 3b
4
5
6
7
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
9
Favorites
1.10 - VIZIO L15 Remote Control
1.10.1 - Remote Control Description
1. Video Source - Press this button to select the video input
source: PC mode, Video and TV (AIR).
2. Audio Source - Press this button to select the video input
source: Audio 1: PC, Audio 2: AV and TV.
3. Status - Press this button to display the current system
status (i.e., channel, input source, etc.).
4. Picture/AUTO - Press this button to Auto adjust the PC function. Also press this button
to adjust some of the LCD TV monitor picture menu items. Please see Section 3.4.2.5 –
Image Adjust, page 23 for additional details regarding the PC functions.
5. Sleep - Press this button to set the LCD TV Monitor to turn itself off within a certain time.
Choose from the following options: 30, 60, 90 or 120 minutes. Please see Section
3.4.2.4a- Features for TV and Video Mode, page 22 for additional details.
6. MTS - Press this button to select a sound mode if available with the TV programming:
Mono, Stereo and SAP. Please see Section 3.4.2.3 - Sound, page 21 for additional
details.
7. Mute - Press this button to eliminate or restore the LCD TV Monitor sound. Mute on will
appear on the screen when the sound is muted.
8. VOL (-/+) - Press these buttons to decrease or increase the
sound. Also press to select or adjust items in the OSD (on-
screen display) menu.
9. CH (UP/DN) - Press these buttons to adjust the channel up or
down. Also press to select or adjust items in the OSD (on-
screen display) menu.
10. Menu - Press this button to open the OSD (on-screen display)
menu. Also this button will allow you to exit the OSD menu.
11. Favorites - Press this button to store your favorite channel.
Please see Section 3.4.2.1 – TV Install, page 20 for additional
details.
12. Number buttons - Press this button to select TV channels.
When selecting single-digit channels, then press the number of
the desired channel. Note: The LCD TV monitor will pause for a
few seconds then tune to the selected channel.
13. A/CH button - Press this button to alternate from current
channel selection to previous channel selection.
Note: The remote control layout is for reference only.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
10
1.10.2 - Insertion of Batteries in the Remote Control
Insert two AAA batteries into the remote control. Make sure that you match
the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the
battery compartment. Re-attach the battery cover.
Precautionary Tips for Inserting the Batteries:
• Only use the specified AAA batteries.
• Do not mix new and old batteries. This may result in cracking or
leakage that may pose a fire risk or lead to personal injury.
• Inserting the batteries incorrectly may result in cracking or leakage
that may pose a fire risk or lead to personal injury.
• Dispose of the batteries in accordance with local laws and
regulations.
• Keep the batteries away from children and pets.
1.10.3 - Remote Control Range
• Point the remote control at the remote control sensor to transmit the commands.
• Do not place any obstacles between the remote control and the receiver window.
• The effective range of the remote control is approximately 6 feet (2 meters) from the front
of the receiver window, 30º to the left and right, 20º up and down.
1.10.4 - Precautions for the VIZIO Remote Control
• Remote control should be kept dry and away from heat sources. Avoid humidity.
• If the display responds erratically to the remote control or does not respond at all, check
the batteries. If the batteries are low or exhausted, replace them with fresh batteries.
• When not using the remote control for a long period of time, remove the batteries.
• Do not take apart the batteries, heat them, or throw them into a fire.
• Do not subject the remote control to undue physical stress, such as striking or dropping it.
• Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean,
damp cloth.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
11
Chapter 2 - Connecting Components
2.1 - Which Video Connection Should I Use?
The VIZIO L15 LCD TV has four different ways to connect your video equipment from a basic one
to the most advanced for digital displays.
Connection
Quality
Cable and Connector Description
OK
Coaxial RF. This is the only connection that has the audio
and the video in one cable. If you have an antenna or
cable, this is the only way you can connect it to the LCD
TV. If you have a VCR, you can connect your
antenna/cable to the VCR RF Input and connect the VCR
RF Output to this connector.
Basic
Composite. The complete video signal is carried through
this single pin connector. This is the most commonly used
video connection.
Good
S-Video. The video signal is separated into two signals,
one containing the black-and-white information and the
other containing the color information. Separating the
color in this way avoids ‘cross color’ effects where closely
spaced black and white lines are erroneously displayed in
color. It also enables text to be displayed more sharply.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
12
2.2 - Connecting Your DVD Player
You have several options for connecting your DVD player to your new L15 LCD TV - S-Video and
Composite inputs. Based on your home theater configuration, you can decide which option is the
right one for you.
2.2.1 - Using S-Video
Installation:
1. Turn off the power to the LCD TV and DVD player.
2. Connect the S-Video jack on the rear of your DVD player to the S-Video jack on the back
of your LCD TV.
3. Connect the audio cables (red and white) to the AUDIO OUT (left and right) jacks on the
DVD player.
4. Connect the other end of the cables to the audio cable adapter (provided).
5. Connect the audio cable adapter to the AUDIO 2 jack on the rear of the LCD TV Monitor.
6. Turn on the power to the LCD TV and DVD player.
7. Select “Video” using the Video Source button on the remote control. Then Select “Audio
2: AV” using the Audio Source button on the remote control.
Note: Refer to your DVD player user manual for more information about the video output
requirements of the product.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
13
2.2.2 - Using Composite Video
Installation:
1. Turn off the power to the LCD TV and DVD player.
2. Connect the Video/Composite
(yellow color) connector on the rear of your DVD player to
the Video connector on the back of your LCD TV.
3. Connect the audio cables (red and white) to the AUDIO OUT (left and right) jacks on the
DVD player.
4. Connect the other end of the cables to the audio cable adapter (provided).
5. Connect the audio cable adapter to the AUDIO 2 jack on the rear of the LCD TV Monitor.
6. Turn on the power to the LCD TV and DVD player.
7. Select “Video” using the Video Source button on the remote control. Then Select “Audio
2: AV” using the Audio Source button on the remote control.
2.3 - Connecting Your VCR or Video Camera
Installation:
1. Turn off the power to the LCD TV and VCR or video camera.
2. Connect the S-Video jack on your VCR or video camera to the S-Video jack on the back
of your LCD TV.
3. Connect the audio cables (red and white) to the AUDIO OUT (left and right) jacks on the
VCR or video camera.
4. Connect the other end of the cables to the audio cable adapter (provided).
5. Connect the audio cable adapter to the AUDIO 2 jack on the rear of the LCD TV Monitor.
6. Turn on the power to the LCD TV and VCR or video camera.
7. Select “Video” using the Video Source button on the remote control. Then Select “Audio
2: AV” using the Audio Source button on the remote control.
Note: Refer to your DVD player user manual for more information about the video output
requirements of the product.
Note: Refer to your VCR or video camera user manual for more information about the video
out
p
ut re
q
uirements of the
p
roduct.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
14
2.4 - Connecting Coaxial (RF)
There are several options for connecting your antenna or cable to your new L15 LCD TV –directly
to the TV or through your VCR. Based on your home theater configuration, you can decide which
option is the right one for you.
2.4.1 – Using an Antenna
You can decide to either connect the antenna directly to your TV or through a VCR based on how
you would like to set it up for your home.
2.4.1.1 - Connecting the Antenna to the TV
Installation:
1. Turn off the power to the LCD TV.
2. If your antenna has a round cable
(75 ohm) on the end, then you're
ready to connect it to the LCD TV
Monitor.
Note: If your antenna has flat,
twin-lead wire (300 ohm), you first
need to attach the antenna wires
to the screws on a 300- to 75-ohm
adapter.
3. Connect the antenna (or adapter)
to the TV jack on the rear of the LCD TV Monitor. If the end of the antenna wire is
threaded, screw it down tightly.
4. Turn on the power to the LCD TV.
5. Select “AIR” using the Video Source button on the remote control. Select “TV” using the
Audio Source button on the remote control.
2.4.1.2 – Connecting the Antenna through Your VCR
Installation:
1. Turn off the power to the LCD TV and
VCR.
2. Connect the “Output to TV” (RF Out
or Antenna Out) connector on the
rear of your VCR to the TV connector
on the rear of your LCD TV.
3. Turn on the power to the LCD TV and VCR.
4. Select “AIR” using the Video Source button on the remote control. Select “TV” using the
Audio Source button on the remote control.
5. Select Channel 3 or 4 to match the channel selected on the rear of your VCR.
Note:
a) If you have an off-air antenna or cable TV, connect the off-air antenna or TV cable to
the RF connector on the rear of your VCR.
b) Make sure the antenna or cable TV is correctly grounded.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
15
2.4.2 – Connecting Basic Cable Directly to the TV
Installation:
1. Turn off the power to the LCD TV.
2. Connect the Cable TV signal to the TV
jack on the LCD TV Monitor. Screw it
down tight.
3. Turn on the power to the LCD TV.
4. Select “AIR” using the Video Source
button on the remote control. Select
“TV” using the Audio Source button on the remote control.
2.4.3 - Using Your Cable Box Connections
2.4.3.1 - Cable Box with RF In/Out Jacks
Note: This connection will not supply Stereo sound to the LCD TV Monitor. The sound from the
Cable Box will be monaural (single-channel, not left and right).
Installation:
1. Turn off the power to the LCD TV.
2. Connect the Cable TV signal to the IN jack
(i.e., “RF IN” or “CABLE IN”) on the Cable
Box.
3. Connect the RF coaxial cable to the OUT jack
(i.e., “TO TV” or “RF OUT”) of the Cable Box.
4. Connect the other end of the coaxial cable to
the LCD TV Monitor’s TV jack. Screw it down tightly.
5. Turn on the power to the LCD TV.
6. Set the Channel 3 or 4 (or Output channel) switch of the Cable Box to 3 or 4.
7. Set the TV to the same channel. When watching TV programming, change channels at
the Cable Box, not the LCD TV Monitor.
Note:
a) Make sure the antenna is correctly grounded.
b) See Section 3.4.2.1 – TV Install page 20 for selecting the TV source within the
OSD menus (cable or air (antenna)).
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
16
2.4.3.2 - Cable Box with Audio/Video Out Jacks
Note: This connection will supply Stereo sound to the LCD TV Monitor.
Installation:
1. Turn off the power to the LCD TV.
2. Connect the Cable TV signal to the IN jack (or RF IN or CABLE IN) on the Cable Box.
3. Using an RCA-type video cable, connect one end of the video cable to the Video Out jack
of the Cable Box. Connect the other end of the cable to the yellow VIDEO jack on the
rear of the TV.
4. Connect the audio cables (red and white) to the AUDIO OUT (left and right) jacks on the
cable box.
5. Connect the other end of the cables to the audio cable adapter (provided).
6. Connect the audio cable adapter to the AUDIO 2 jack on the rear of the LCD TV Monitor.
7. Turn on the power to the LCD TV.
8. Select “Video” using the Video Source button on the remote control. Then Select “Audio
2: AV” using the Audio Source button on the remote control.
2.5 - Connecting the Computer
Installation:
1. Turn off the power to the LCD TV and Computer.
2. Connect a 15-pin D-sub RGB cable to the RGB output of your
computer and the other end to the Analog input in the rear of
your LCD TV.
3. Connect the audio to the AUDIO 1 jack on the rear of the LCD
TV Monitor.
4. Turn on the power to the LCD TV and your computer.
5. Select “PC Mode” using the Video Source button on the remote
control. Select “Audio1: PC” using the Audio Source button on
the remote control.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
17
Figure 3.2.a
Figure 3.2.b
Chapter 3 - Getting Started
3.1 - Turning your LCD TV On and Off
1. Plug the DC adapter into the DC IN jack on the back side of the LCD TV Monitor, then
plug the power cable into a properly grounded outlet.
2. Press the POWER button on the front panel or the POWER button on the remote control
to turn on the LCD TV. The POWER indicator on the front panel will light green.
3. Select the input source for the LCD TV using the Video Source button on the remote
control and select the audio source for the LCD TV using the Audio Source button on the
remote control
4. If connecting to antenna, cable or other RF source on TV inputs, see 3.4.2.1 – TV Install
page 20 to configure the product to receive all available channels.
3.2 - Installation of Wall Mount (Optional)
If you would like to mount your L15 LCD TV to the wall, you can contact VIZIO directly at
www.vizioce.com
or your local dealer to obtain the appropriate wall mounting kit. To convert your
LCD TV from a desk-mounted to a wall-mounted display, follow the instructions below.
1. Turn off the LCD TV and disconnect the DC adapter
from the back of the LCD TV.
2. Lay the LCD TV face down on a towel or blanket to
protect the screen from damage.
3. Unscrew the 4 set screws (see Figure 3.2.a) that hold
the stand to the bottom of the LCD TV. Please make
sure to keep a hold of the stand so that it does not
fall once the screws are loosened.
4. Remove the stand carefully from the back of the TV. Please make sure to keep the 4
screws and washers that were removed with the stand in safe place for future use.
5. Place the VESA plate adapter included in the accessory box
to the back of the LCD TV centered over the 4 screw holes
in Figure 3.2.b. This will allow the mount to fit flush on the
back of the LCD TV.
6. Attach the mount to the TV through the VESA plate adapter
by utilizing the 4 screw holes also included in the accessory
box to the center of the back of the LCD TV (see Figure
3.2.b). Please make sure to follow the kit instructions that
shipped with your mount for proper installation.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
18
3.3 - Adjusting Basic LCD TV Settings
Volume
To increase the volume, press and hold the VOL + button on the front panel or remote
control until the desired level is reached.
To decrease the volume, press and hold the - VOL button on the front panel or remote
control until the desired level is reached.
TV Channels
To step up through the available TV channels, press the CH + button on the front panel
or remote control once for the next channel or hold it depressed until the desired channel
is reached.
To step down through the available TV channels, press the - CH button on the front panel
or remote control once for the previous channel or hold it depressed until the desired
channel is reached.
Mute
Press the MUTE button on the remote control to turn off the sound; press the button
again to cancel the MUTE feature and turn the sound on.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
19
3.4 - Using the On-Screen Display (OSD)
The remote control or the control keys on the top panel of the LCD TV can control all the function
settings. The on-screen display (OSD) allows you to adjust and save contrast, brightness and
other settings. The LCD TV will save changes made to the settings even if the LCD TV is turned
off.
3.4.1 - Menu Operations
The OSD consists of a Main Menu of items and each of these items has a Sub Menu associated
with it that the OSD will switch to when the item is selected.
1. Press the MENU button on the remote control and the Main Menu will be displayed on
the screen.
2. Use the c/d buttons on the remote control to
highlight the feature you wish to select within the OSD
menu.
3. Use the e/fbuttons on the remote control to enter or
exit the submenus, featured opposite with the TV
Install Menu highlighted.
4. Use the c/d buttons again on the remote control to
highlight the feature you wish to select within the OSD
menu.
5. Use the e/fbuttons on the remote control to make the
necessary adjustments.
6. Press the MENU button on the remote control to confirm
the desired selection.
7. Repeat steps 3 and 6 to adjust additional options within
the selected OSD menu.
8. Once you have finished making adjustments within the selected OSD menu, press the
MENU button on the remote to move to the next page (for example, Sound Menu).
9. Once all the adjustments are completed, press the Menu button on the remote control
repeatedly to exit the OSD.
NOTE: The OSD menu display will disappear automatically after 30 seconds if no action is taken.
Note: The menu options are determined by the input you have selected as the video source.
For instance, if you have the TV mode selected, you will only see those applicable menus.
Please see Section 3.4.2 - OSD Menus and Options on the following pages for further details.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
20
3.4.2 - OSD Menus and Options
You will see some changes within the OSD Menu options based on the inputs (TV, PC or Video).
If the options are different, it will be noted in the description of each OSD menu on the following
pages.
3.4.2.1 – TV Install
Note: This is only available in TV mode.
Favorite – Sets up channels in a quick viewing list. The button
on the remote control will then be used to switch between
different TV programs.
To program, following the steps below:
1. Tune the specific channel you want to add to the Favorite
Feature.
2. Press the Menu button and highlight the TV Install menu by
using the c/d buttons on the remote control.
3. Press the e/fbuttons on the remote control to enter into the
TV Install Menu.
4. Press the c/d buttons on the remote control to select Favorite.
5. Press the e/fbuttons on the remote control to highlight YES to add the channel to your Favorite
list or No to remove the channel from the listing.
6. Press the Menu button to exit.
Tuner Mode – Allows the user to change the signal input to Cable or Air (antenna). Note: when
cable is selected, channels 1-125 are available. When AIR (antenna) is selected, channels
2-69 are available.
Auto Program – Automatically sets the LCD TV for local area (or cable TV) channels. Note: an
antenna or cable TV signal must first be connected to the LCD TV.
Store – Allows the user to edit the channel listing by manually adding or deleting channels. Note:
If the user would like add or delete a channel, the user must first have the channel selected
on the LCD TV, and then enter the TV Install OSD menu.
To program, following the steps below:
1. Tune the specific channel you want to add to the Store Feature.
2. Press the Menu button and highlight the TV Install menu by using the c/d buttons on the remote
control.
3. Press the e/fbuttons on the remote control to enter into the TV Install Menu.
4. Press the c/d buttons on the remote control to select Store.
5. Press the e/fbuttons on the remote control to highlight YES to add the channel to the Store
memory list or No to remove the channel from the listing.
6. Press the Menu button to exit.
Fine Tune – Allows the user to adjust the television picture reception in areas of weak signal
reception.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
21
3.4.2.2 - Picture
3.4.2.2a – Picture for TV and Video Mode
Note: Below are the options for the TV and Video mode. See Section 3.4.2.2b for options in PC
mode.
Brightness – Adjusts the black levels of the picture. Users may
need to readjust the brightness after the LCD TV warms up.
Color – Adjusts the color saturation to add or reduce the amount
of color from the picture.
Contrast - Adjusts the white levels of the picture. Users may
need to readjust the contrast after the LCD TV warms up.
Tint - Adjusts the color of flesh tones.
Sharpness - Adjust the amount of detail enhancement.
Gamma – Preset contrast scheme to enhance picture quality.
Choose from the following options: Normal, VIVID1 or
VIVID2.
3.4.2.2b - Picture for PC Mode
Note: The below options are only applicable for PC Mode.
Auto Contrast - Automatically adjusts the horizontal phase of the
image for the best contrast.
Contrast – Adjusts to “sharpen” the picture quality. The black
portions of the picture become richer in darkness and the
white become brighter.
Brightness - Adjusts to brighten the darkest parts of the picture.
Backlight – Adjusts the brightness of the picture while
preserving the picture’s color.
3.4.2.3 - Sound
Treble – Adjusts to enhance the high frequency sounds.
Bass – Adjusts to enhance the low frequency sounds.
Balance – Adjusts the level of sounds coming from the left and
right speakers.
Sound Mode – Select from the following: Mono, Stereo or SAP.
Note: these options are only available in TV mode.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
22
3.4.2.4 - Features
3.4.2.4a – Features for TV and Video Mode
Note: This option is different for the PC mode. See Section 3.4.2.4b for additional details.
Sleep Timer – Allows for the user to automatically turn the LCD
TV off at 30 minute increments (30, 60, 90 and 120 minutes).
Note: to see how many minutes remain before the TV shuts
off, press the Sleep button. The setting can be cancelled by
pressing any button during the last minute of operation.
Closed Caption – Allows for the user to read the voice content of
television programming on the TV screen. Options include
NONE, CC1, CC2, Txt1 and Txt2.
Parental Control – Allows for the user to block programming based on movie and television
industry ratings. Note: the user must enter a password to adjust any of these settings. See
Section 3.4.3 - Using the Parental Controls, page 24 for additional details.
Freeze – Allows the user to freeze the picture. Choose either “Freeze On” or “Freeze Off” within
the OSD menu. Note: after freezing a picture on the screen, when the Freeze control is
turned off, the normal signal programming will be shown at present time. The signal that was
being shown while the picture was frozen will not be viewable.
Language – Allows for the user to change the OSD Menu language. Options include either
English or Spanish.
Factory Settings – Resets the TV back to the factory settings, including the Parental Control
feature.
3.4.2.4b – Features for PC Mode
Information – Shows the current PC resolution timing with refresh
rate.
OSD Setting – Allows the user to adjust the position of the
picture, the OSD timer, and the background shading.
Language - Allows for the user to change the OSD Menu
language. Options include either English or Spanish.
Resolution Notice – Shows the current PC resolution timing.
DPMS (Display Power Management Signaling) – when ON, this
makes the screen black when there is not any signal present,
or the screen saver has timed out.
Mode Message – When it is ON, it shows the LCD monitor mode. When it is OFF, it will only
show Video and Cable/Air.
Factory Settings - Resets the TV back to the factory settings, including all picture, sound, and
color settings.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
23
3.4.2.5 – Image Adjust
Note: This is only available in PC mode.
Auto Adjust - The LCD Monitor will automatically adjust to the
best image position, phase, and clock settings.
Horizontal - Adjusts the horizontal position of the picture.
Vertical - Adjusts the vertical position of the picture.
Clock - Adjusts the color when patterns appear.
Phase - Adjusts the picture to remove the noise or fuzziness.
Sharpness - Adjust to improve detail.
3.4.2.6 – Color
Note: This is only available in PC mode.
Color Temp – Choose from Normal, Warm, Cool, or User
preferences.
Red – Adjusts the red color of the picture.
Green – Adjusts the green color of the picture.
Blue – Adjusts the blue color of the picture.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
24
3.4.3 - Using the Parental Controls
The Parental Controls feature prevents viewers from watching programs that are not age-
appropriate, such as programs containing violence or adult language.
1. Press the Input button on the remote control and select TV as the
input source.
2. Press the MENU button four times on the remote control so that the
Setup Menu is displayed on the screen.
3. Press d on the remote control until the Parental Control menu is
highlighted. Then press ENTER.
4. To access the Parental Control Menu, you must first enter in the
default password.
a) Press “9 2 0 3” on the remote control as the default password.
b) Then press ENTER to confirm the selection.
Note: For more information about setting a password, see “Setting
a Password”, page 25.
5. The Block Enable option will already be highlighted. Press the ► button to select “YES”.
6. Press ENTER to confirm.
7. Once you are back into the Parental
Controls, press the ▼ button to highlight the
MOVIE Rating menu. Then press the
ENTER button on the remote control to select this option.
8. Using the e/fbuttons on the remote control, navigate through the following options:
• G (General audience)
• PG (Parental guidance suggested)
• PG-13 (Recommended for children 13 years of age and older)
• R (mature audience)
• NC-17 (no one under 17 years of age)
• X (no one under 17 years of age)
Note: When a rating is chosen to be blocked, any higher level rating will also be blocked from
viewing. Also, when a rating is set to unblock, any rating lower will be automatically set to
unblock.
(3.4.3 - Using the Parental Controls cont’d on following page))
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
25
(3.4.3 - Using the Parental Controls cont’d)
9. Once the text is highlighted, press the ENTER button to switch between B (block) or U
(unblock).
10. Once you are finished setting the MOVIE ratings, press the MENU button to exit.
11. Press the ▼ button to highlight the TV Rating menu. Then press the ENTER button to select
this option on the remote control.
12. Using the e/fbuttons on the remote control, navigate through the following options:
• Y (all children)
• Y7 (older children)
• G (general audience)
• PG (guidance suggested)
• Y14 (strongly cautioned)
• MA (mature audience)
You can also customize the TV ratings for the following content:
• FV (fantasy violence)
• D (sexual dialog)
• L (adult language)
• S (sexual situations)
• V (violence)
13. Once the text is highlighted, press the ENTER button to switch between B (block) or U
(unblock).
14. Once you are finished setting the TV ratings, press the MENU button repeatedly to exit the
OSD.
3.4.4 - Setting a Password
You control access to the Parental Control Menu features with a
password. The default password is “9 2 0 3”. You can change the
password to any four-digit number.
To change the password:
1. Press the Input button on the remote control and select TV as the
input source.
2. Press the MENU button on the remote control so that the Feature Menu is displayed on the
screen.
3. Press d on the remote control until the Parental Control menu is
highlighted. Then press ENTER.
4. To access the Parental Control Menu, you must first enter in the
default password.
a. Press “9 2 0 3” on the remote control as the default password.
b. Then press ENTER to confirm the selection.
5. Press the d button on the remote control to select “Change User
Code”, and then press the ENTER button.
6. Enter in your new 4-digit password. Then press the ENTER button
on the remote control.
7. Confirm the new 4-digit password. Then press the ENTER button on
the remote control.
Note: Please make sure to write down and store the new password in a secured place.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
26
Chapter 4 - Maintenance and Troubleshooting
4.1 - Maintenance
Important
1. Make sure that the power cable is removed from the socket before cleaning the
display.
2. Do not use volatile solvent (such as toluene, rosin and alcohol) to clean the display.
Such chemicals may damage the housing, screen glass and remote control, and
cause the paint to peel.
Cleaning the Housing and the Remote Control
1. Use a soft cotton cloth for cleaning.
2. If the housing or remote control is seriously contaminated, use a soft cloth moistened
with diluted neutral cleaner to clean the display. Wring water out of the cloth before
cleaning to prevent water from penetrating into the housing. Wipe the display with a
dry cloth after cleaning.
Cleaning the Screen
1. Use a soft cotton cloth to gently clean the screen.
2. The screen glass is very fragile. Do not scrape it with any sharp object. Do not press
or tap the screen to avoid cracking. When the screen is seriously contaminated, use
a soft cloth moistened with diluted neutral cleaner to clean the display. Wring water
out of the cloth before cleaning to prevent water from penetrating into the housing.
Wipe the display with a dry cloth after cleaning.
4.2 - Troubleshooting Guide
If the display fails or the performance changes dramatically, check the display in accordance with
the following instructions. Remember to check the peripherals to pinpoint the source of the
failure. If the display still fails to perform as expected, contact the dealer for assistance.
Problem Solution
No Power Check to make sure the power cord is properly connected to
the power adapter and power adapter is connected to the TV.
Disconnect the power cord from the power outlet for 10
seconds, and then reinsert the plug into the outlet. Press
POWER to turn on the TV again.
Make sure the outlet is not on a wall switch.
Make sure a fuse has not blown at the power outlet.
No Picture Check the antenna or Cable TV connections. Connect the
antenna or Cable TV signal securely to the TV’s 75Ω jack
on the rear of the TV.
Activate Tuner Mode to find all available channels. Details are
on page 20.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
27
No Sound Press the VOL+ and VOL- buttons to adjust the volume.
Press the MUTE button on the remote control to cancel or
restore the volume.
If you have connected other equipment to the TV (such as a
VCR or DVD Player), make sure the audio cables are
connected securely between the TV and the other equipment.
Check the SOUND settings. Details are on page 21.
Remote Control does not work. Check the batteries. If necessary, replace them with two AAA
heavy duty (zinc chloride) or alkaline batteries.
Clean the remote control as well as the remote control sensor
on the front of the TV.
Check the TV power cord. Disconnect the power cord from
the power outlet for 10 seconds, and then reinsert the plug
into the outlet. Press POWER to turn on the TV again.
Make sure the outlet is not on a wall switch.
Make sure a fuse has not blown at the power outlet.
Always point the remote control toward the front of the TV
(toward the remote sensor).
TV displays wrong channel or
no channels.
Repeat channel selection.
Add the channel number(s) into the TV’s memory. Use
STORE. Details are on page 20.
Make sure TUNER MODE is set correctly. Details are on
page 20. Then activate AUTO PROGRAM to set up all
available channels. Details are on page 20.
4.3 - Telephone & Technical Support
Products are often returned due to a technical problem rather than a defective product that may
result in unnecessary shipping charges billed to you. Our trained support personnel can often
resolve the problem over the phone. For more information on warranty service or repair, after the
warranty period, please contact our Support Department at the number below.
Quality service and consistent technical support are integral parts of VIZIO’s commitment to
service excellence. VIZIO’s service representatives are dedicated to assist you with the utmost in
customer satisfaction. To better assist you, please call toll free or contact us via email.
Tel: (714) 668-0588, 7:30 am- 5:30 pm PST Mon - Fri
Or E-mail: [email protected]
Corporate Contact Information
VIZIO
320A Kalmus Drive
Costa Mesa, CA 92626
Tel: (714) 668-0588 Fax: (714) 668-9099
Web: www.vizioce.com
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
28
4.4 - Compliance
Caution: Always use a power cable that is properly grounded. Please use the AC cords listed
below for each area.
USA UL
Canada CSA
Germany VDE
Britain BASE/BS
Japan Electric Appliance Control Act
4.5 - FCC Class B Radio Frequency Interference Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
2. Shielded interface cables and AC power cord, if any, must be used in order to comply
with the emission limits.
3. The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modification to this equipment. It is the responsibilities of the user to
correct such interference.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
29
Appendix A: Glossary - Standard Definitions
Analog TV: Today’s TV system using radio frequency waves to transmit and display pictures and sound.
Digital TV (DTV): Television delivered and displayed using radio frequency waves that contain information
that is digitally encoded for improved quality and efficiency.
Standard Definition TV (SDTV): Basic digital television transmission that may be displayed with fewer than
480 progressively scanned lines (480p) in 16 x 9 or 4 x 3 format. 480 interlaced
(480i) is the quality of today’s analog TV system. SDTV provides 150-300,000 pixels.
Enhanced Definition TV (EDTV): A better digital television transmission than SDTV with at least 480p, in a
16 x 9 or 4 x 3 display and Dolby digital surround sound. 480p is the quality used by most DVD players.
EDTV provides 300-400,000 pixels.
High-Definition Television (HDTV): The best quality digital picture, widescreen (16 x 9) display with at least
720 progressively scanned lines (720p) or 1080 interlaced lines (1080i) and Dolby digital surround sound.
HDTV provides 900,000-2.1 million pixels.
HDTV Monitor (sometimes called HDTV Ready): A set that can display HDTV programming if you have a
separate HDTV tuner, HD Cable Set-Top Box or HD Satellite Set-Top-Box Receiver.
HDTV Tuner (also decoder, receiver, set-top box): A device capable of receiving and outputting HDTV
signals for display. It may be stand-alone or integrated in the set.
Integrated HDTV: An HDTV that has the digital tuner built into the set. It does not need a separate set-top
box to receive over-the-air DTV signals.
Plug-and-Play or Digital Cable Ready: A DTV or other device for digital cable customers that plugs directly
into the cable jack and does not require a separate set-top box. Plug and Play TV owners must obtain a
CableCARD from their cable company in order to view scrambled programming services.
Interlace Scan: A way to scan vertical lines onto a TV picture by scanning all the odd lines first, then filling in
the even lines (this happens instantaneously).
Progressive Scan: A way to scan vertical lines onto a TV picture by scanning all the lines consecutively
(progressively).
Aspect ratio (4 X 3): Traditional TV “aspect ratio,” that is, the screen’s width as compared to its height. For
example, a “32 inch TV screen” would be 25 ½ inches wide and 19 inches tall.
Aspect ratio (16 X 9): “Widescreen” TV” aspect ratio” that is more like a movie screen than a traditional TV.
For example, a “32 inch TV screen” would be 28 inches wide and 16 inches tall.
Source: Buying a Digital Television, CEA, HDTV Guide, 2005
Note: The Federal Communications Commission (FCC), the Consumer Electronics Association (CEA) and
the Consumer Electronics Retailers Coalition (CERC) have made a new tip sheet available for digital
television (DTV) retailers to reproduce and distribute to consumers on the sales floor. The file may be
downloaded online at www.dtv.gov. While you’re there, check out the other useful information the FCC is
making available to consumers interested in learning more about the analog to digital transition.
VIZIO L15 User Guide
Version - 4/5/2005
www.vizioce.com
30
Appendix B: VIZIO LCD Television Warranty
VIZIO’s Responsibility
VIZIO Displays purchased in the United States are warranted to be free from defects in materials or workmanship for a period of one (1) year from
the date of their original retail purchase. If the unit fails to conform to this warranty, we will service the monitor using new or refurbished parts.
Service Labor
During a period of one (1) year from the effective warranty date, VIZIO will provide, when needed, service labor to repair a manufacturing defect at
its designated Service Center. To obtain warranty service in the Untied States, you must first call our Customer Support at (714) 668-0588, 7:30 am
– 5:30 pm PST. The determination of service will be made by VIZIO Customer Support. PLEASE DO NOT RETURN YOUR UNIT TO VIZIO
WITHOUT PRIOR AUTHORIZATION.
Parts
New or remanufactured replacements for defective parts will be used for repairs by VIZIO at its designated Service Center for one (1) year from the
effective warranty date. Such replacement parts are warranted for the remaining portion of the original warranty period.
Service
During the one (1) year warranty period, VIZIO will, at its option and sole discretion, repair or replace defective parts, including replacement of the
entire Panel. The Customer will be required to ship the unit to the Service Center indicated at the time Customer Support is contacted to make the
necessary repairs, you are responsible for all transportation charges to and from the service facility. VIZIO is not responsible for the de-installation or
re-installation of the unit.
Packaging and Shipping Instruction
When you send the product to an authorized VIZIO service facility you must use the original carton box and packing material or an equivalent as
designated by VIZIO
Not Covered
This warranty does not cover defects, malfunctions or failures resulting from shipping or transit accidents, abuse, misuse, operation contrary to
furnished instructions, operation on incorrect power supplies, operation with faulty associated equipment, modification, alteration, improper servicing,
tampering or normal wear and tear or TVs on which the serial number has been removed or defaced. Image Sticking caused by operating at
excessive brightness levels for extended periods or mishandling are not covered by this warranty.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME SET FORTH ABOVE. OUR LIABILITY FOR ANY AND ALL LOSSES AND
DAMAGES RESULTING FROM ANY CAUSE WHATSOEVER, INCLUDING OUR NEGLIGENCE, ALLEGED DAMAGE OR DEFECTIVE GOODS,
WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE DISPLAY.
WE SHALL NOT BE RESPONSIBLE FOR LOSS OF USE, COMMERCIAL LOSS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. This is the only warranty applicable; no one is
authorized to extend or modify it or to grant any other warranty.
VIZIO retains the right to assess all warranty claims and to determine if damages are covered by the warranty. In case of a claim that is not covered
by the warranty, you will be contacted to determine whether VIZIO should repair the damage for a fee or whether the product should be returned to
you as received by the repair center.
Owner’s Responsibility
Effective Warranty Date
Warranty begins on the date of sale to the end user. To ensure warranty service, keep the dated bill or sale receipt as evidence of the purchase
date.
User Manual
Read your User Manual carefully so that you will understand the operation of your Display and how to adjust the user controls.
Warranty Service
For warranty service information, contact VIZIO Customer Support at (714) 668-0588, 7:30 am to 5:30 pm PST or visit www.vizioce.com. Parts and
service labor that are VIZIO’s responsibility (see above) will be provided without charge. Other service is at the owner’s expense. You must provide
the model, serial number and date of purchase. Before you ask for warranty service, read your User Manual. You might avoid a service call.
