Honeywell 17000-S True HEPA Air Purifiers

Owner’s Guide - Transcript

• Page 1: Portable HEPA Air Cleaners READ AND SAVE THESE INSTRUCTIONS Owners Guide For Model Series 17000 Air Cleaners The Science of Clean Air
• Page 2 - English - : PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT Save these instructions for easy reference When using electrical appliances basic precautions should always be followed to reduce breakage risk of fire electric shock and injury to persons including the following 1 Read all instructions before operating the air cleaner 2 Place air cleaner where it is not easily knocked over by persons in the household 3 Always unplug when not in use 4 Do not use any product with a damaged cord or plug or if product malfunctions is dropped or damaged in any manner Keep the cord away from heated surfaces 5 Do not use air cleaner outdoors 6 Never use air cleaner unless it is fully assembled 7 Do not run power cord under carpets and do not cover with throw rugs Arrange cord such that it will not be tripped over 8 Do not use air cleaner where combustible gases or vapors are present 9 Do not expose the air cleaner to rain or use near water in a bathroom laundry area or other damp location 10 To disconnect the air cleaner first turn the air cleaner OFF and remove plug from the outlet 11 The air cleaner must be used in its upright position 12 Do not allow foreign objects to enter ventilation or exhaust opening as this may cause electric shock or damage to the air cleaner Do not block air outlets or intakes 13 Locate air cleaner near power outlet and avoid using an extension cord 14 The air cleaner has a polarized plug one blade is wider than the other To reduce risk of shock this plug is intended to fit in a polarized outlet only one way If the plug does not fit fully in the outlet reverse the plug If it still does not fit contact a qualified electrician DO NOT attempt to defeat this safety feature 15 A loose fit between the plug and the AC outlet receptacle may cause overheating and a distortion of the plug Contact a qualified electrician to replace loose or worn receptacles 16 Do not sit stand or place heavy objects on the air cleaner 17 Disconnect power supply before servicing WARNING To reduce risk of fire or electric shock do not use this product with any solidstate speed control device Important Safety Instructions
• Page 3 - English - : Congratulations You now own a quality portable HEPA air cleaner that has been engineered and crafted for your satisfaction Honeywell air cleaners incorporate a true HEPA filter HEPA is an acronym for High Efficiency Particulate Air Our Consumer Relations representatives will be pleased to help with any questions or concerns you may have about your Honeywell air cleaner Please call our Consumer Relations Dept at 800 3321110 for assistance For Best Performance We recommend that you operate your Honeywell air cleaner 24 hours a day because indoor air can be quickly contaminated by activity in a room and infiltration of outside air While all the air in a room will not be processed by the air cleaner the more air circulated through the filter the more filtered air returned to the room Portable air cleaners will be much more effective in rooms where all doors and windows are closed For models that include a CPZ odor and gas adsorbing filter17250 and 17450 series carefully remove the plastic bag which protects the CPZ filter during shipment before operating your air cleaner Your air cleaner will not operate properly with the plastic bag in place and it may damage the air cleaner The plastic bag may contain small particles and dust caused by vibration of the CPZ filter during shipment Use care to avoid soiling clothing carpets and other furnishings with the particles or dust The Honeywell HEPA air cleaner can be placed on the floor in almost any location However for best performance the air outlet slot should not be blocked for at least 3 feet 1 meter in all directions Due to the large volume of air drawn towards the air cleaner surrounding areas should be cleaned andor vacuumed frequently to prevent build up This may help keep your home cleaner and may extend the life of your prefilter If the unit is placed on a light colored carpeting a small mat or rug should be used to ease cleaning and prevent any permanent staining This is particularly important in homes with heavier contamination from smoking or fireplaces Your Honeywell air cleaner has five basic components the locking mechanism the endcap the HEPA filter the activated carbon prefilter and the base assembly with controls and motor Construction Models 17250 17450 Series Your Honeywell air cleaner has six basic components the locking mechanism the endcap HEPA filter CPZ odor and gas adsorbing filter activated carbon prefilter and the base assembly with controls and motor Base Assembly Endcap Activated Carbon Prefilter HEPA Filter Locking Mechanism CPZ Odor and Gas Adsorbing filter CPZ filter Filter Assembly Base Assembly Endcap Activated Carbon Prefilter HEPA Filter Locking Mechanism
• Page 4 - English - : The Honeywell 17000 series air cleaners are 3 speed air cleaners operated by turning the unit on high for a few seconds and then leaving it on high for faster more powerful air circulation or moving it to a lower setting as desired The 17000 series air cleaner is equipped with electronic controls and IntelliCheck Filter Monitors to serve as a convenient reminder when to replace the prefilter and HEPA filter The filter monitors will begin counting the hours of use once the unit is powered on The IntelliCheck Filter Monitors will count the hours of filter use based on the units operating speed and will indicate when the filters expected life has been reached This is beneficial because the expected life of a filter depends on the amount of air and contaminants drawn through it Once each filter has reached its expected life its light will remain on until it is RESET You may unplug the air cleaner without interrupting the hours counted CHECK Expected Filter Life Usage To check the amount of expected filter life used quickly press the filter monitor button when the unit is turned on It will flash up to 3 or 4 times depending upon how much expected filter life has been used The filter monitors are intended as guidelines only as individual use may vary Check Prefilter life used by quickly pressing the prefilter monitor button NEW 23 life 13 life left Replace remains remains 900 Hours Check HEPA filter life used by quickly pressing the HEPA filter monitor button NEW 34 life 12 life left 14 life left Replace remains remains remains 6000 Hours If operated an average of 12 hours a day on medium speed the filter monitor light will indicate replacement in about 3 months for the prefilter and about 1 year and 9 months for the HEPA filter NOTE If operated on a higher speed for a greater number of hours each day the filter light monitors will indicate replacement sooner than if operated on a lower speed for fewer hours each day RESET Filter Monitor After Filter Replacement When the filter monitor light remains on it is time to replace the filter Once the filter has been replaced you must reset the filter monitor With the unit powered on press the filter monitor button down for a 5 second delay The light will turn off 17000 Series Filter CheckReset Monitors POWER HIGH MEDIUM LOW FILTER CHECKRESET PREFILTERHEPA 1 Flash 2 Flashes 3 Flashes 1 Flash 2 Flashes 3 Flashes 4 Flashes
• Page 5 - English - : Replacement Filters Use only genuine Honeywell replacement filters designed for these units Select the proper replacement filter for your Honeywell HEPA Air Cleaner from the chart below Replacement filters may be purchased from the retail store or ordered from the dealer where you purchased the product If you cannot locate one in your area please call our Consumer Relations Dept at 800 3321110 for assistance HEPA Filter Carbon Prefilter CPZ Kit Model No Part Number Part Number includes 2 prefilters 17000 20500 32002 38002 NA 17200 21500 32000 38002 NA 17250 28720 32002 38002 21200 17400 22500 33002 38002 NA 17440 22500 33002 38002 NA 17450 28725 33002 38002 22200 When to Replace Filters RESET THE FILTER MONITOR ONCE EACH FILTER HAS BEEN REPLACED See Filter CheckReset Monitors section for further details For model 17250 and 17450 series after replacing the CPZ filter use the enclosed CPZ filter reminder label to indicate the next time the filter is to be replaced approximately every six months CAUTION Do not attempt to wash either the activated carbon prefilter the HEPA filter or the CPZ filter They are not washable and washing will damage the filters With proper maintenance your Honeywell air cleaner is designed to provide years of high efficiency air cleaningYour Honeywell air cleaner contains two filters one activated carbon prefilter and one primary HEPA filter Models 17250 and 17450 contains three filters one activated carbon prefilter one primary HEPA filter and a CPZ odor and gas adsorbing filter The activated carbon prefilter captures lint and other large particles and helps protect the HEPA filter It also helps reduce common household odors The prefilter should be replaced at least every 3 months You may need to replace the prefilter more often if the unit is used in a smoking environment or if unpleasant odors persist We DO NOT recommend operating the air cleaner without the activated carbon prefilter or without following the filter replacement guidelines The primary HEPA filter should remain effective for 1 to 3 years depending upon the environment in which the air cleaner is operating Honyewell recommends changing the HEPA filter based upon operation conditionsevery 3 years for light usage 2 years for normal usage and 1 year for heavy usage The CPZ Filter Cartridge should be replaced at least every 6 months Filter life depends upon condition of use Our recommendations regarding filter replacement intervals are intended as guidelines only Life expectancy of any filter media is dependent on the concentration of the contaminants to which the system is exposed If there are sources of large amounts of contaminant generation such as woodworking or heavy smoking the useful life of the filter media in your air cleaner may be reduced Whenever the air resistance of the HEPA filter becomes excessive due to the amount of contaminants it has captured the air volume output will begin to reduce and the sound level of the air cleaner will increase somewhat A completely blocked filter will cause a loud rumbling sound and almost no airflow
• Page 6 - English - : How to Change the Filters The only two parts requiring any service are the activated carbon prefilter and the HEPA filter also CPZ filter on 17250 and 17450 model series No tools are needed To change either filter disassemble the unit as shown 1 Turn off the air cleaner and disconnect from power supply 2 Loosen the locking mechanism by turning it counterclockwise and remove the endcap from the unit Fig 1 3 Remove the HEPA filter CPZ filter on 17250 and 17450 model series and activated carbon prefilter from the base assembly Fig 2 4 Remove the fasteners from the activated carbon prefilter and remove it from the HEPA filter cartridge Fig 3 5 Replace filters as needed and discard used filters 6 Wrap the activated carbon prefilter around the HEPA filter cartridge and secure it with the fasteners provided Reassemble your Honeywell air cleaner as described below 1 Place the assembled HEPA filter CPZ filter on 17250 and 17450 model series and the activated carbon prefilter in the base assembly 2 Replace the endcap onto the unit 3 Reattach the locking mechanism and turn it clockwise until securely tightened 4 Plug into a wall outlet 5 Turn unit ON and RESET filter monitors for filters replaced by pressing the appropriate filter reset buttons for a 5 second delay Fig 4 Note For model 17250 and 17450 series after replacing the CPZ filter use the enclosed CPZ filter reminder label to indicate the next time the filter is to be replaced If you store your Honeywell HEPA air cleaner for more than 30 days we recommend Remove both the primary HEPA filter and the activated carbon prefilter from the unit Also remove CPZ filter in model 17250 and 17450 series Discard the prefilter Discard the CPZ filter in model 17250 and 17450 series only Wrap the HEPA filter in an airtight plastic bag or plastic wrap Be sure that the filter is totally sealed To restore the air cleaner to service unwrap the HEPA filter install a new activated carbon prefilter and CPZ filter model 17250 and 17450 series and replace the filters in the air cleaner See quotHow to Change the Filtersquot section for proper installation CAUTION TURN OFF THE AIR CLEANER AND DISCONNECT FROM POWER SUPPLY BEFORE SERVICING Storage Check to make sure that the power cord is correctly connected to the outlet Test that the outlet is functioning properly using another appliance or lamp Check the fuse or circuit breaker The outlet may be overloaded if other appliances are also in use Determine and correct the cause of the overload If none of the above procedures restore operation return your unit to the store or if the stores return policy does not allow return the complete unit per the instructions in the warranty section of this owners guide Do not attempt to repair the unit yourself If the Air Cleaner Does Not Operate FIG 1 FIG 2 FIG 3 HEPA PREFILTER FILTER CHECKRESET FIG 4
• Page 7 - English - : 5 Year Limited Warranty Honeywell HEPA Air Cleaners Model Nos 17000 Series This product has been engineered and crafted with great care for your satisfaction Be sure to fill out and return the enclosed card within 7 days of purchase A This limited warranty applies to repair or replacement of product found to be defective in material or workmanship within 5 years of the date of purchase This warranty does not apply to damage resulting from commercial abusive unreasonable use or supplemental damage Defects that are the result of normal wear and tear will not be considered manufacturing defects under this warranty HONEYWELL IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE ANY IMPLIED WARRANTY INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS LIMITED WARRANTY Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts so the above limitations or exclusions may not apply to you This warranty gives you specific legal rights and you also may have other rights which vary from jurisdiction to jurisdiction This warranty applies only to the original Purchaser of this product B At its option Honeywell will repair or replace this product if it is found to be defective in material or workmanship within the limited warranty period Defective product should be returned to the place of purchase in accordance with store policy or to Honeywell C This warranty does not cover damage resulting from unauthorized attempts to repair or from any use not in accordance with this manual D This warranty DOES NOT cover the prefilter HEPA filter or CPZ filter except for material or workmanship defects E Return defective product to the following address with a brief description of the problem Include proofof purchase and a US 1000 Canadian 1300 check or money order for handling return packing and shipping charges Please include your name address and daytime phone number You must prepay shipping charges Mark carton quotAttention Repair Departmentquot Ship to Honeywell Consumer Products 4755 Southpoint Drive Southpoint Distribution Center Memphis TN 38118 USA Honeywell Consumer Products Canada 510 Bronte St South Milton Ontario Canada L9T 2X6 If you experience a problem with your air cleaner please see owners guide for instructions Please do not attempt to repair the air cleaner yourself Doing so may void the warranty and could cause damage or personal injury If the problem still persists please call Honeywell Inc Consumer Relations Dept Toll Free 18003321110 Mail Questions or Comments to Honeywell Inc Consumer Relations Dept 250 Turnpike Road Southborough MA 01772 USA 1999 Honeywell Inc All Rights Reserved AC700299 03502305002
