4-170-644-12(1)
English
WARNING
Always keep a screwdriver away from children.
Use a screwdriver carefully to avoid injury.
(1) Replacing batteries and settings must be performed
by an adult.
(2) Do not mix old and new batteries.
(3) Do not use any other type of battery such as carbon
zinc or rechargeable.
(4) For children ages 3 and up. Children under 3 years
old should not use the RM-KZ1.
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Features
Designed in a cute style for safe and easy use by
children ages 3 and up.
Offers a simple means of controlling what
channels your child is able to watch.
Allows you to assign desired TV or set top box
channels to the favorite buttons, enabling your
child to select any channel directly with a single
button.
Location of Controls
LED indicator
Lights or flashes during settings.
Lights during IR signal transmission.
(power) button
Press to turn on/off the TV (factory setting).
Favorite buttons
Press to select a channel.
VOLUME –/+ buttons
Press to adjust the volume.
Numeric buttons
Press to enter numbers required for setup.
SET button
Use for setup mode.
ENT (enter) button
Press to apply setting.
Remote Commander
RM-KZ1
©2010 Sony Corporation Printed in China
Operating Instructions
Manual de instrucciones (parte posterior)
Before Use
The RM-KZ1 can perform the following functions
on these devices:
TV: power on/off, channel switching and volume
level adjustment
Cable set top box or satellite receiver: power on/
off
and channel switching
Available after changing the setup of “Setting the
power button functions” in “Additional Settings.”
Be sure to complete setting the
manufacturer’s code(s) and assigning
channels before you use the RM-KZ1.
Opening the Setup
Button Cover
First, you need to open the setup button cover to
install the batteries and set up the RM-KZ1.
What you need
– Phillips-head screwdriver #1
– Two size AAA (LR03) alkaline batteries
Opening the setup button
cover
1
Using a screwdriver, loosen the screw.
Loosen the screw to slide the setup button
cover. The screw does not remove from the
setup button cover completely.
2
Slide the setup button cover, then lift to open.
Installing the batteries
To install the batteries, you need to open the
battery cover after opening the setup button cover.
1
Slide the battery cover, then lift to open.
2
Insert two size AAA (LR03) alkaline batteries
(not supplied), negative end first, through the
guide clamp within each compartment.
3
Close the battery cover.
Leave the setup button cover open to continue
to set up the RM-KZ1.
Battery life
Under normal conditions, size AAA (LR03)
alkaline batteries will last up to one year. If the
RM-KZ1 does not operate properly, the batteries
might be drained. Replace the batteries with new
ones.
Notes
Do not use an old battery with a new one, or use any
other type of battery such as carbon zinc or
rechargeable.
If the electrolyte inside the battery should leak, wipe
the contaminated area of the battery compartment
with a cloth and replace the old batteries with new
ones. To prevent electrolyte leakage, remove the
batteries if you plan not to use the RM-KZ1 for a long
period of time.
Setting the
Manufacturer’s Code
Before assigning channels, you need to set the
manufacturer’s code for your TV or set top box.
If you want to switch to TV channels, perform the
procedure of “Setting the manufacturer’s code for
TV.”
If you want to switch to set top box channels,
perform the procedure of “Setting the
manufacturer’s code for set top box” after “Setting
the manufacturer’s code for TV.”
Setting the manufacturer’s
code for TV
Example: To set up a Philips TV
1
Find the manufacturer’s code in
“Manufacturer’s Code List.”
4-170-644-11(1)
English
WARNING
ˎ
Always keep a screwdriver away from children.
ˎ
Use a screwdriver carefully to avoid injury.
(1) Replacing batteries and settings must be performed
by an adult.
(2) Do not mix old and new batteries.
(3) Do not use any other type of battery such as carbon
zinc or rechargeable.
(4) For children ages 3 and up. Children under 3 years
old should not use the RM-KZ1.
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
ˎ
Reorient or relocate the receiving antenna.
ˎ
Increase the separation between the equipment and
receiver.
ˎ
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
ˎ
Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Features
ˎ
Designed in a cute style for safe and easy use by
children ages 3 and up.
ˎ
Offers a simple means of controlling what
channels your child is able to watch.
ˎ
Allows you to assign desired TV or set top box
channels to the favorite buttons, enabling your
child to select any channel directly with a single
button.
Location of Controls
˫ LED indicator
Lights or flashes during settings.
Lights during IR signal transmission.
ˬÆ (power) button
Press to turn on the TV and switch to the
channel assigned to /turn off the TV.
˭ Favorite buttons
Press to select a channel.
ˮ VOLUME –/+ buttons
Press to adjust the volume.
˯ Numeric buttons
Press to enter numbers required for setup.
˰ SET button
Use for setup mode.
˱ ENT (enter) button
Press to apply setting.
Remote Commander
RM-KZ1
©2010 Sony Corporation Printed in China
Operating Instructions
Manual de instrucciones (parte posterior)
Before Use
The RM-KZ1 can perform the following functions
on these devices:
TV: power on/off, channel switching and volume
level adjustment
Cable set top box or satellite receiver: power on/
off
ˈ
and channel switching
ˈ
Available after changing the setup of “Setting the
power button functions” in “Additional Settings.”
Be sure to complete setting the
manufacturer’s code(s) and assigning
channels before you use the RM-KZ1.
Opening the Setup
Button Cover
First, you need to open the setup button cover to
install the batteries and set up the RM-KZ1.
What you need
– Phillips-head screwdriver #1
– Two size AAA (LR03) alkaline batteries
Opening the setup button
cover
1
Using a screwdriver, loosen the screw.
The screw does not remove from the setup
button cover completely.
2
Slide the setup button cover, then lift to open.
Installing the batteries
To install the batteries, you need to open the
battery cover after opening the setup button cover.
1
Slide the battery cover, then lift to open.
2
Insert two size AAA (LR03) alkaline batteries
(not supplied), negative end first, through the
guide clamp within each compartment.
3
Close the battery cover.
Leave the setup button cover open to continue
to set up the RM-KZ1.
Battery life
Under normal conditions, size AAA (LR03)
alkaline batteries will last up to one year. If the
RM-KZ1 does not operate properly, the batteries
might be drained. Replace the batteries with new
ones.
Notes
ˎ
Do not use an old battery with a new one, or use any
other type of battery such as carbon zinc or
rechargeable.
ˎ
If the electrolyte inside the battery should leak, wipe
the contaminated area of the battery compartment
with a cloth and replace the old batteries with new
ones. To prevent electrolyte leakage, remove the
batteries if you plan not to use the RM-KZ1 for a long
period of time.
Setting the
Manufacturer’s Code
Before assigning channels, you need to set the
manufacturer’s code for both TV and set top box
in the following order.
Set the manufacturer’s code for the TV.
Operate the TV to check the code you have set is
correct. (Up to this step when assigning TV channels
to favorite buttons)
Set the manufacturer’s code for the set top box.
Operate the set top box to check the code you have set
is correct. (Up to this step when assigning set top box
channels to favorite buttons)
Note
If you assign TV channels to favorite buttons, there is no
need to set the manufacturer’s code for the set top box.
The following procedure covers both TV and set
top box setup.
Set the manufacturer’s code
Example: To set up a Philips TV
1
Find the manufacturer’s code in
“Manufacturer’s Code List.”
TBD
If your device is not listed, try the Search
function (see “Searching for the correct
code” in “Additional Settings”).
2
Hold down SET and press numeric button 1.
+
The LED indicator lights up.
3
Release both buttons.
4
Press the numeric buttons to enter the
manufacturer’s code.
Example: 00037
p p p p
The LED indicator flashes 3 times and turns
off.
Operate the device
1
Turn on the TV and set top box.
2
Aim the RM-KZ1 directly at the device.
3
For TV,
1 Press Æ to check that the TV turns off.
2 Press Æ to turn on the TV again.
3 Press VOLUME −/+ to check that the TV
operates correctly.
For set top box,
1 Press the numeric buttons.
Example: 298
p p
2 Press ENT to check that the desired
channel can be selected.
If the RM-KZ1 does not seem to be working…
ˎ
Check that you have set the correct manufacturer’s
code.
ˎ
Start again from step 1 of “Set the manufacturer’s
code.”
ˎ
Try repeating the setup procedure using another
manufacturer’s code (if listed for your device). If you
still cannot operate the RM-KZ1 after trying all the
listed codes, try the Search function (see “Searching
for the correct code” in “Additional Settings”).
Note
If you assign set top box channels to the favorite buttons,
be sure to set up the set top box after completing TV
code setup.
Assigning a
Channel
Channel selecting procedures can be assigned to
the favorite buttons ( - ), allowing your child
to select any channel directly with a single press of
a favorite button.
You can assign either TV or set top box channels
to the favorite buttons.
Assign a channel
Example: To assign channel number 298 to
1
Hold down SET and press numeric button 3.
+
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press .
4
Press the numeric buttons (up to 4) to enter the
desired channel number.
Example: 298
p p
5
Press ENT.
The LED indicator flashes 3 times.
To assign to other favorite buttons, repeat steps
3 – 5.
6
Press SET to complete.
The LED indicator turns off.
Check the setting
1
Turn on the TV and set top box, and set your
TV’s input to the set top box by using the TV’s
remote control.
2
Press a favorite button to check that the desired
channel number is selected.
Note
If you assign TV channels to favorite buttons, turn on
the TV in step 1 of “Check the setting.”
Clearing an assigned channel
1
Hold down SET and press numeric button 3.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press the favorite button to clear the setting.
4
Press VOLUME –.
5
Press SET to complete.
The LED indicator turns off.
Note
If you assign TV channels to favorite buttons, see
“Assigning the TV channels to the favorite buttons” in
“Additional Settings.”
Closing the Setup
Button Cover
Using a screwdriver, close the setup button cover
by securing the screw.
Be sure that the battery cover is closed properly
beforehand.
Using the RM-KZ1
After setting up the RM-KZ1, your child needs
only to perform the following operations.
Do this To
Press Æ
turn on the TV and
switch to the channel
assigned to /turn off
the TV.
Press the favorite
button
select a channel.
Press VOLUME −/+
adjust the volume.
To change the Power button setting
See “Setting the power button functions” in “Additional
Settings.”
Note
If the set top box can control volume, be sure to set its
volume to a moderate level. If the volume on the set top
box is turned down completely, you will not be able to
adjust your TV’s volume with the RM-KZ1.
Additional Settings
This section describes functions for more
convenient use of the RM-KZ1.
Searching for the correct code
You can set the manufacturer’s code using the
Search function.
1
Turn on the device by its power switch.
2
Aim the RM-KZ1 at the device you want to set.
3
Hold down SET and press numeric button 2.
The LED indicator lights up.
4
Release both buttons.
5
For TV, press numeric button 0.
For the set top box, press numeric button 1.
6
Press ENT.
The LED indicator flashes 3 times.
7
Press and hold ENT to start searching.
8
When the device turns off, release the button.
If you overshoot the required code, you can
search for the next or previous code using
or .
To continue searching, press and hold ENT.
9
Press SET to complete.
The LED indicator flashes 3 times and the
indicator turns off.
Check if the device works correctly with the
manufacturer’s code you entered.
If you still cannot operate the device, repeat the
procedure to search for another code that
works for the most functions for your device.
To cancel the process
Press SET for more than 3 seconds.
The LED indicator turns off.
Checking the manufacturer’s
code you have set
1
Hold down SET and press numeric button 6.
The LED indicator lights up.
2
Release both buttons.
3
For TV, press numeric button 0.
For the set top box, press numeric button 1.
The LED indicator flashes 3 times.
4
Press ENT.
The LED indicator turns off momentarily.
5
When the LED indicator starts flashing, count
the number of flashes and determine the 5-
digit code number.
Short flash(es) indicate which digit (first,
second, etc.), followed by long flash(es) to
indicate the digit number (e.g., 2 long flashes
represent the number 2). “0” is indicated by
rapid flashing. To recheck, press ENT.
6
Press SET to complete.
The LED indicator turns off.
To cancel the process
Press SETany time.
The LED indicator turns off.
Setting the volume button
functions
The RM-KZ1 is factory-set to limit volume up and
down to prevent the TV volume becoming too
loud or too quiet (as a result, for example, of
children pressing VOLUME −/+ continuously).
You can remove the volume limitation or
deactivate VOLUME −/+.
1
Hold down SET and press numeric button 8.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button (1,2 or 3) to select one
of the following.
Do this To
Press 1
limit volume up and down.
ˈ
If you hold down VOLUME
−/+ continuously, the volume
will not be turned up/down
beyond a certain level.
Press 2
remove the volume limitation
(standard operation).
Press 3 deactivate VOLUME −/+.
ˈ
Factory setting
The LED indicator flashes 3 times and the
indicator turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Setting the power button
functions
When Æ is pressed, the RM-KZ1 is factory-set to
turn on the TV and switch to the channel assigned
to .
You can change this consecutive procedure set on
Æ according to your preference.
1
Hold down SET and press numeric button 4.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1- 5) to select one of
the following.
Do this To
Press 1
turn on TV ~ switch to the
channel on .
ˈ
(When Æ is pressed with TV on,
the TV is turned off.)
Press 2
turn on TV.
(When Æ is pressed with TV on,
the TV is turned off.)
Press 3
turn on TV ~ turn on set top box
~ switch to the channel on
.
(When Æ is pressed with TV
and set top box on, both are
turned off.)
Press 4
turn on TV ~ turn on set top
box.
(When Æ is pressed with TV
and set top box on, both are
turned off.)
Press 5
deactivate Æ.
ˈ
Factory setting
The LED indicator flashes 3 times and turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
If the channel assigned to cannot be
selected correctly when you press
Æ
You can set an interval before the channel
switches.
1
Hold down SET and press numeric button 5.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1-5) to select one of
the following.
Do this To
Press 1
insert 0.2 second interval.
ˈ
Press 2
insert 0.4 second interval.
Press 3
insert 0.6 second interval.
Press 4
insert 0.8 second interval.
Press 5
insert 1 second interval.
ˈ
Factory setting
The LED indicator flashes 3 times and turns
off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Assigning the TV channels to
the favorite buttons
ˎ
At the factory settings, without setting the
manufacturer’s code for the set top box of
“Setting the Manufacturer’s Code,” go to the
next step “Assigning a Channel.”
ˎ
If you change all favorite button assignments
from set top box channels to TV channels,
perform steps 2 - 4 of “Set the manufacturer’s
code” of “Setting the Manufacturer’s Code,” and
press “19999” in step 4. Then assign the TV
channels. (It is recommended that you clear
unused favorite buttons.)
Restoring the factory settings
You can clear all settings, and reset the RM-KZ1
to its factory settings.
1
Hold down SET and press numeric button 0.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button 1 to reset all settings,
including TV/set top box manufacturer codes
and assigned channels.
4
Press ENT.
When all settings have been reset, the LED
indicator flashes 3 times and turns off.
To cancel the process
Press any button other than is used for this setting.
The LED indicator turns off.
Help
If you have problems setting up or using the
RM-KZ1:
ˎ
Carefully apply the setup procedure of “Setting
the Manufacturer’s Code.” If the RM-KZ1 does
not work, apply the procedure repeatedly, using
another code listed for your device. If you still
cannot operate the RM-KZ1, try the Search
function.
ˎ
Aim the RM-KZ1 directly at the device.
ˎ
Remove any obstacles in the path between the
RM-KZ1 and the device.
ˎ
Be sure that the device has infrared remote
capability. For example, if your device did not
come with a remote control, it probably is not
capable of being controlled by the RM-KZ1.
ˎ
The batteries are weak, or not inserted correctly.
Replace them with new ones or insert them
correctly.
ˎ
If the favorite button does not seem to be
working:
– Check that the desired channel is properly
assigned (see “Assigning a Channel”).
– Try to insert an interval (see “If the channel
assigned to
cannot be selected correctly
when you press Æ”).
ˎ
If the volume button does not seem to be
working, carefully apply the procedure of
“Setting the volume button in “Additional
Settings.”
ˎ
If the power button does not seem to be
working, carefully apply the procedure of
“Setting the power button in “Additional
Settings.”
Notes on setting the RM-KZ1
ˎ
If the setting is incomplete, the LED indicator flashes
once and turns off. Start again from the beginning.
ˎ
If no operations are performed for 3 minutes while
setting, the setting will be canceled, and must be
restarted.
For the customers in the U.S.A.
Customer Support Information
After you have read through this manual, if you still
cannot get the RM-KZ1 to work properly, call the Sony
Customer Support Helpline at 1-800-822-2217.
Specifications
Operating distance Approx. 11 m (36 ft) (varies depending on
devices of different manufacturers)
Power requirements Two size AAA (LR03) alkaline batteries
(not supplied)
Battery life Approx. 1 year when using size AAA
(LR03) alkaline batteries (varies
depending on frequency of button use -
up to approx. 50 times per day.)
Dimensions Approx. 52 mm × 168 mm × 31 mm
(2
1
/
8
in × 6
5
/
8
in × 1
1
/
4
in) (w/h/d)
Mass Approx. 92 g (3.2 oz) (not including
batteries)
Design and specifications are subject to change without
notice.
Continued on reverse side
TV / TV
Brand Code No.
888 00264, 00412
Abex 00032
Accurian 01803
Acer 01339
Action 00650, 00873
Addison 00092, 00108, 01224
Admiral 00093, 01463, 00179
Advent 00761, 00108, 01284, 01570, 01037
Aftron 01549
Aiko 00092, 01579
Aiwa 00032, 00701, 01911, 01914, 01955
Akai 01675, 00702, 01240, 02232, 01670, 01692, 01327,
01688, 01676, 01413, 01385, 01207, 00672, 00602,
00412, 00264
Akira 01814, 00858, 01243, 01037
Alaron 00179
Albatron 00843
Alfide 00672
America Action 00180
Anam 00250, 00180, 00009, 00426
Anam National 00250, 00650
Anhua 00051
AOC 01661, 00093, 00180, 01503, 01240, 00092, 02087,
01341, 01590, 01365, 00179, 00108, 00018, 00009
Aolingpu 00858
Aolinpike 00264, 00412
Aomni 01623
Apex Digital 01549, 00879, 00890, 01217, 01243, 01531
Astar 01531, 01555
Audinac 00180
Audiovox 01661, 00180, 00092, 00802, 00846, 00875, 01284,
01766, 01769, 01803, 01951, 01952
AUO 01581
Aurora Systems 00801
Aventura 01665
Baihe 00009, 00264, 00412
Baile 00001, 00009, 00661
Baohuashi 00264, 00412
Baosheng 00009, 00108
Barco 01080
Baysonic 00236, 01463, 00180
Beijing 00702, 00001, 00009, 01009, 00226, 00264, 00412,
00482, 00661, 00108, 01243
Bell & Howell 00154, 00016
BenQ 01327, 01315, 01562
Bestwell 01326
BGH 00876, 01314
Blue Sky 01080, 01341, 02153
Boigle 01696
BPL 01009, 00373, 00896, 01476
Bradford 00180
Brillian 01007
Broksonic 00236, 01463, 00426, 01911, 01670
Bush 00698, 01441
Byd:sign 01309
C-Tech 00858, 01549, 00896
Cadia 01283
Caihong 00009, 00108
Cailing 01549
Caishi 01549
Candle 01240, 00056, 00186
Carnivale 01240
Carver 00054, 00170
Casio 00611, 01205
CCE 00037
Celebrity 00000
Celera 01243
Changcheng 00051, 00001, 00009, 00264, 00412, 00661, 00108
Changfei 00009, 00108
Changfeng 00264, 00412, 01814, 00108
Changhai 00009, 00108
Changhong 01243, 00009, 00264, 00108, 00819, 00820
Chengdu 00009, 00108
Chimei 01852
Ching Tai 00092, 00009, 00179
Chun Yun 00000, 00180, 00092, 00698, 00009, 00179, 00843,
01687, 01327
Chunfeng 00009, 00264
Chung Hsin 00180, 00053, 00108
Chungfeng 00412
Chunsun 00009, 00108
Cinema 00672
Cineral 01661, 00092
Citizen 01661, 01503, 01240, 00092, 00056, 00186, 00280,
00561, 01669, 01671, 01672, 01670
Clarion 00180
Classic 01984
Coby 01538, 01634, 02017, 01531, 02315, 02326, 02340,
02344, 02345, 02347, 01555, 02351, 02560
Commercial Solutions 00047
Concerto 00056
Conrowa 01243, 00145, 00009, 00264, 00412, 00698, 01814
Contec 00180
Continental 02357
Craig 00180
Crosley 00000, 00054, 00074
Crown 00180, 00009, 00672
Crown Mustang 00672
Curtis 02352, 02466
Curtis Mathes 00047, 00054, 00154, 00093, 01503, 00702, 01240,
00145, 00166, 01661, 00016, 00056, 01824, 00747,
01959
CWN 01367
CXC 00180
CyberHome 00794
Cytron 01326
Daenyx 00180, 00179, 00672
Daewoo 00154, 00180, 01240, 00092, 01661, 00032, 00056,
00108, 00170, 00661, 00672, 01909
Daytron 00180
Dayu 00661
Dell 01264, 01080, 01240
Delta 01369
Denon 00145
Denstar 00180
Dewo 00180
Diamond Vision 01996
Digisonic 01826
Digistar 01565
Digital Lifestyles 01546, 01822
DirecTV 01501
Disney 02152
Dongda 00009
Donghai 00009
Drean 00037
DSE 01565
Dumont 00017
Durabrand 01463, 00180, 01240, 01665, 01034
Dwin 00747
DX Antenna 01864
Dynex 01564, 01463
ECE 00037, 01549, 01555
Elba 01557
Electroband 00000
Electrograph 01755, 01623
Electrohome 01463, 01570, 01670, 01672
Elektra 00017, 01661
Element 01687, 01240
Emerson 01864, 00154, 00236, 01463, 00180, 01240, 01661,
00179, 00280, 01665, 01909, 01911, 01913, 01963
Emprex 01422, 01546
Brand Code No.
Encross 00876
Envision 01240, 00813, 01365, 01506, 01341, 02087
Epson 01122
Erae 01222
ESA 00702, 01665, 01963
Ether 01240, 00009
Etron 00009
Feilang 00009
Feilu 00009, 00108
Feiyan 00264, 00412
Feiyue 00009, 00108
Firstar 00236, 00009
Firstline 00037
Fisher 00154
Fortress 00093
Frigidaire 01597, 01826
Fujimaro 01498, 01687
Fujimaru 01687
Fujitsu 00809, 00179, 00186, 00683, 02008
Fujitsu General 00186
Funai 00000, 00180, 01665, 00179, 00264, 01864, 01904,
01913, 01963
Furi 00145, 00264, 00412, 00108
Futuretech 00180
Ganxin 00108
Gateway 01755, 01327
GE 00047, 00051, 01661, 00180, 01240, 00092, 00279,
00747, 01922
General 00186
General Electric 00047, 00180
GFM 01665, 01963
Gibralter 00017, 01240
Gibson 01597, 01826
Global Home 01565
Go Video 00886, 01314, 01385
Goldi 01559
GoldStar 00154, 01240, 00001, 00032, 00037, 00056
GPX 00179
Gradiente 00053, 00056, 00170, 01804
Grundig 00037, 00070, 00672, 00683
Grunpy 00180, 00179
Haier 01034, 00037, 01243, 00587, 00698, 00768, 00761,
01549, 00896, 01009, 01238, 01560, 01570, 01240,
02449
Haihong 00009
Haiyan 00264, 00412, 00108
Hallmark 01240
Hankook 00180, 01240, 00056
Hanns.G 01783
Hannspree 01348, 01745, 01783, 01826
Harley Davidson 00179, 01904
Harman/Kardon 00054
Harvard 00180
Havermy 00093
Helios 00865
Hello Kitty 01661
Heran 01826, 01852
Herosonic 01826
Hewlett Packard 01494, 01088, 01365, 01101
Hikato 00180
Himitsu 00180, 00761
HiPlus 01420, 01435, 01826
Hisense 01243, 01549, 00145, 00009, 01080, 01814, 01314,
01660, 02098, 01240
Hitachi 01243, 01240, 00145, 00092, 02215, 01904, 01576,
01345, 01037, 00797, 00723, 00679, 00413, 00279,
00186, 00179, 00165, 00056, 00032, 00016, 00009
Hitec 00698
Hitech 01814
HomeTech 02462
Hongmei 00093, 00009, 00264, 00108
Hongyan 00264, 00412, 00108
HP 01494, 01088, 01365, 01101
Hua Tun 00009
Huafa 00145, 00009
Huanghaimei 00009
Huanghe 00009, 00108
Huanglong 00009
Huangshan 00009, 00264, 00412, 00108
Huanyu 00264, 00108
Huaqiang 00264, 00412
Huari 00145, 00264, 00412
Humax 01501
Huodateji 00051
Hyundai 00849, 01219, 01294, 01468, 01814, 02454
I-Inc 01746
Igo 01224
iLo 01286, 01603, 01665, 01684, 01990
Imperial Crown 00001, 00009, 00264, 00412, 00661
Infinity 00054
Initial 01603, 01990
Innova 00037
Insignia 01564, 01665, 01204, 01326, 01385, 01284, 01660,
01463, 01963, 02002, 01603
Inteq 00017
iRIS 02189
IRT 01661, 00180, 00698
ITT Nokia 00180
IX 01783
JBL 00054
JCB 00000
Jean 01243, 00051, 00236, 00092, 00009, 00179
Jensen 00761, 00108, 01299, 01037
Jiahua 00051
JiaLiCai 00009, 00264, 00412
Jinfeng 00051, 01009, 00226, 00108
Jinque 00009, 00264, 00412, 00108
Jinta 00009, 00264, 00412
Jinxing 00054, 01243, 00145, 00009, 00037, 00264, 01080,
00698, 00108
Juhua 00264, 00412, 00108
JVC 01463, 00053, 00160, 00371, 01243, 00650, 01224,
00731
Kaige 00009, 00264, 00412, 00108
Kanghua 00896
Kangli 00001, 00009, 00264, 00661, 00108
Kangyi 00009, 00264, 00412
KDS 01498, 01687
KEC 00180
Ken Brown 00236, 01463, 01321
Kenia 01240
Kenstar 01236
Kenwood 01240
Khind 00698, 00896
Kioto 00054, 00698, 01080, 00180, 00761
KLH 01243
KLL 00037
KMDS 02278
Kolin 01610, 01755, 00180, 00053, 00037, 00108, 01549,
01217, 01240
Kongque 00009, 00264, 00108
Konka 01549, 00037, 00587, 00180, 00632, 00638, 00707,
00761, 00795, 00108, 01385, 01243, 01939
Kost 01262, 01314
Kreisen 00876
KTV 00180, 01240, 00280
Kuaile 00009, 00264, 00412
Kulun 00009
Kunlun 00051, 01009, 00226, 00264, 00661, 00108
LG 00017, 01503, 01240, 00001, 00032, 00037, 00056,
00108, 00856, 01530, 01556
Lihua 00108
LiteOn 01088
Lloyd’s 01904
Loewe 01037
Logik 00016
Longjiang 00264, 00412, 00108
Luce 00813, 01031
Luxman 00056
LXI 00047, 00054, 01243, 00154, 01240, 00747
Lynx 01565
M&S 00054, 00236
MAG 01498, 01687
Magnasonic 01913
Magnavox 01755, 00054, 00051, 01240, 01665, 00698, 01990,
01963, 01913, 01904, 01525, 01506, 01365, 01341,
01198, 00802, 01549, 00186, 00179
Majestic 00016
Malata 01769
Marantz 00054, 01240, 00037, 00854, 01811, 02447
Mastro 00053, 00698, 01549, 01556, 01558
Matsushita 00250, 00650
Maxent 01755, 01597, 01811, 01757
Meck 00698, 01549, 01558, 01571
Megatron 01240, 00145
Meile 00264, 00412, 00108
Memorex 00154, 00108, 01240, 00016, 00179, 01783, 01037,
01570, 01670, 01463, 01911, 01985
Mercury 00001
Mermaid 00037
Brand Code No.
MGA 00108, 01240
Midland 00047, 00017, 00051, 00032, 00747
Mintek 01603, 01990
Mitsubishi 00250, 00154, 01250, 00093, 00236, 00180, 01240,
00056, 00108, 00179, 01037
Monivision 00843
Monix 01549
Moserbaer 01149
Motorola 00093, 01498
Moxell 01498
MTC 01503, 01240, 00056
Mudan 00051, 00009, 01009, 00226, 00264, 00412, 00108
Multitech 00180
NAD 01243, 01240, 00037, 00056
Nakamichi 01493
Nanbao 00009, 00264, 00412
Nansheng 00264, 00412, 00108
National 00051, 01009, 00226, 01243
Naxa 01998
NEC 01243, 00154, 00051, 00053, 01240, 01783, 01852,
01797, 01546, 00108, 00412, 00264, 00186, 00170,
00165, 00056, 00009
Netsat 00037
NetTV 01755
Newave 00093, 01240, 00092, 00009
NewSonic 01826
NEX 01814
Nexus Electronics 01240
Nikko 01240, 00092
Niko 01581
Nimbro 01531
Noblex 00154, 00018, 00037, 00264, 00482
Nokia 00180
Norcent 01549, 00824, 01365, 01590, 01581
Norwood Micro 01286
Noshi 00018
NTC 00092
NuVision 01284, 02158
Olevia 01610, 01144, 01240
One 01284
Onida 00053, 01224
Onking 00280
Onwa 00180
Optimus 00250, 00154, 00166, 00650, 01913
Optoma 00887, 01348
Optonica 00093, 00165
Orbit 01696
Orion 00236, 01463, 00179, 01911
Packard Bell 00092
Panasonic 00250, 01457, 00054, 00051, 00037, 01009, 00226,
01243, 00650, 00896
Panda 00051, 00009, 01009, 00226, 00264, 00412, 01243,
00698, 01549, 00108
PARK 01531
Peng Sheng 01549
Penney 00047, 01243, 00051, 01503, 01240, 00018, 00032,
00747
Performance Teknique 00806
Petters 01523
Philco 00054, 01463, 00180, 01240, 00145, 00092, 01661,
01963, 01911, 01665, 00786, 00747, 00032, 00186,
00037, 00179, 00056, 00074
Philips 00000, 00054, 00051, 01240, 00092, 00037, 00032,
00056, 00108, 00186, 01037, 01080, 00747, 01314,
01506, 01744, 01815
Pilot 01240
Pioneer 01457, 00166, 00679, 00698, 01260
Planar 01496
Polaroid 01523, 02117, 02063, 02002, 01243, 01769, 01767,
01766, 01763, 01762, 01687, 01565, 01538, 01498,
01385, 01341, 01282, 01327, 01326, 01316, 01314,
01286, 01284, 01262, 00865
Polyvision 00889, 01144
Portland 00092, 01661
Prima 00761, 00108, 01284, 01037
Princeton 00685, 00717
Prism 00051
Proscan 00047, 01240, 01824, 00747, 01922, 02147, 02256
Proton 01240, 00001, 00009, 00056, 01824, 01546
Protron 01320, 01323
Proview 01498, 01687
Pulsar 00017
Puneet 01546
Punktal 00602
Pvision 01222
Pye 00412
Qingdao 00051, 01009, 00226, 00264, 00412, 00108
Quasar 00250, 00051, 00165, 00650
RadioShack 00047, 00154, 00180, 01240, 00032, 00056, 00165,
00747, 01904
Ranser 00001
RCA 00000, 00047, 00051, 00093, 01503, 01240, 00092,
01661, 00090, 00018, 00679, 00747, 01922, 01953,
02002, 02403, 02414
Realistic 00154, 00180, 01240, 00032, 00056, 00165
Recco 00698
Relon 01826
Reoc 00714
RevolutionHD 01623
Rowa 01549, 00009, 00037, 00712, 00108
Runco 00017, 01240, 00612
Ruyi 00108
Saige 00009, 00108
Sampo 01755, 00154, 00093, 01240, 01665, 00092, 00009,
00032, 00650, 01385, 01597
Samsung 01243, 00154, 01503, 00702, 01240, 00092, 01959,
00108, 00814, 00766, 00747, 00650, 00587, 00482,
00264, 00226, 01009, 00179, 00090, 00056, 00037,
00032, 00009
Sanjian 00264, 00412
Sansei 01661, 00092
Sansui 01665, 00165, 00371, 01236, 01413, 01670, 01463,
01904, 01911
Sanyo 00054, 01243, 00154, 00180, 00145, 00088, 01009,
00264, 00280, 00412, 00798
Sanyuan 00093, 00009, 00108
Sceptre 00878, 01217, 01360, 01599, 02293
Scotch 01240
Scott 00236, 00180, 01240, 00179, 01711
Sears 00047, 00054, 01243, 00154, 01240, 01665, 00056,
00179, 00747, 01007, 01904
Semivox 00236, 01463, 00180
Semp 01243
Serie Dorada 01243, 00180, 01240, 00056
Shancha 00264, 00412, 00108
Shanghai 00009, 01009, 00226, 00264, 00412, 00108
Shaofeng 00145, 00108
Sharp 00093, 01240, 00009, 00032, 00165, 00650, 00854,
01193, 01407
Sharper Image 01950
Shen Ying 00092, 00009, 00179
Shencai 00145, 00009, 00264, 00412
Sheng Chia 00093, 00236, 00009, 00179
Shenyang 00009, 00264, 01814, 00108
Sherwood 00009
Shinco 01990
Siam 00037
Signal 00145, 01955
Signature 00054, 00016
Signet 01530, 00844, 01262
Simpson 00186
SKY 00037
Skygiant 00180
Skyworth 01549, 00009, 00037, 00264, 00698, 01814, 00805,
00108, 01799
Solarism 01220
Sole 01031, 01377, 01314, 01530, 01623, 01555, 02076
Songba 00009
Sony 00000, 00650, 00834, 01300, 01685, 01825, 01904
Soundesign 00180, 01240, 00179, 00186
Sova 01320, 01952
Sowa 01243, 00051, 01503, 01240, 00092, 00226
Soyo 01546, 01746, 01824, 01826, 01828, 01830, 01385
Space Tek 01696
Spectroniq 01498, 01687
Squareview 01665
SSS 00180
Starlite 00180
Studio Experience 00843
SunBrite 01420, 01435, 02293
Superscan 00093, 00864
Supreme 00000
SVA 01549, 00587, 00768, 00865, 00871, 00872, 01963
Sylvania 01864, 00054, 01240, 00587, 01314, 01665, 01913,
01963
Symphonic 00180, 01665, 01904, 01913
Synco 01755, 00000, 01661, 00093, 01503, 01240, 00092,
01826
Syntax 01610, 01144, 01240
Tacico 01240, 00092, 00009, 00179
Tai Yi 00009
Taishan 00009, 00108
Brand Code No.
Talent 01240
Tandy 00093, 00218
Tashiko 00092, 00650
Tatung 00054, 01243, 00154, 00051, 00009, 00180, 01101,
01341, 01286, 01287, 01288, 01361, 01503, 01687,
01327
TCC 00698
TCL 00412, 00698, 00761, 00806, 01314, 02403, 02414
Technics 00250, 00051
Technol Ace 00179
Techview 02004
Techwood 00051, 00056
Teco 00051, 00093, 00053, 01240, 00092, 00009, 00218,
00264, 00280, 00180, 01224, 00761, 01687
Teknika 00054, 00180, 00108, 01503, 00092, 00016, 00056,
00179, 00186
Telefunken 00702, 00056, 00074
Tera 01240, 00092, 01824
Texla 01549
Thomas 01904
Thomson 00560, 01814
Tiane 00093, 00108
TMK 01240, 00056
TNCi 00017
Tobo 01549, 00009, 00264, 00412
Tongguang 00264, 00412
Tophouse 00180, 00672, 01385
Toshiba 01243, 00154, 00093, 01240, 01503, 00145, 01959,
01670, 01369, 01343, 00650, 00412, 00264, 00070,
00009
TruTech 01723, 02066
Tuntex 01240, 00092, 00009
TVS 01463
Ultra 01323
US Logic 01286
UTI Technology 02244
Vector Research 01240
Venturer 01240
VEOS 01007
Victor 00250, 00053, 00160, 00650, 01224
Videocon 00037, 01243, 00805, 02436
Vidikron 00054
Vidtech 01240
Viewsonic 01755, 00797, 00857, 00864, 00885, 01330, 01365,
01578, 01627, 01742, 01341, 02087, 02111
Viore 01207, 01684, 01811, 01531, 02352
Visart 01336
Vision 01826
Vistron 02142
Vito 01852
Vizio 01240, 00864, 00885, 01327
VU 02098
Wards 00000, 00047, 00054, 00017, 01243, 00154, 00051,
00180, 01503, 01240, 00186, 00179, 00165, 00056,
00018, 00016
Warumaia 00661
Waycon 01243
Weipai 00009
Westinghouse 01755, 01661, 00885, 00889, 00890, 01217, 01282,
01300, 01577, 01597, 01826, 02293
White Westinghouse 01463, 01661, 00186, 01909
WinBook 01503
Winco 00412
Wyse 01365
Xiahua 00009, 00264, 00412, 00698, 01565, 00761, 00108
Xianghai 00009
Xiangyang 00264, 00412
Xiangyu 00009
Xihu 00264, 00412, 00108
Xinaghai 00412
Xingfu 00009
Xinghai 00264
Xoceco 00761
Yamaha 01240, 00797, 01407
Yapshe 00250
Yingge 00009
Yonggu 00009
Youlanasi 00108
Yousida 00009
Yuhang 00009
Zenith 00000, 00047, 00017, 01463, 01240, 00145, 00092,
01661, 01911, 01909, 01904, 01365, 00160, 00037,
00016
ZhuHai 00009
Zonda 00698, 00761
Satellite receiver / Receptor de satélite
Brand Code No.
ACT Television 12506
Airtel 12243, 12248
Astro 11816, 10099, 12600, 12627
Bang & Olufsen 11897
Bast 11799
Bastide 11799
Bell ExpressVu 10775, 11170
BIG TV 12452
Bush 12376
Century 10856
Cisco 12506
CNS 11230
Coship 12674, 11674, 12525
Cromus 12511
Crossdigital 11109
Crown 11764
Daeryung 10396
DialogTV 12469
DirecTV 11377, 10392, 11639, 10247, 10749, 11856, 10099,
11109, 11414, 11442, 11443, 11444, 11276, 11708
Dish Network 10775, 11505, 11170, 11775
Dishpro 10775, 11505, 11775
DishTV 10128, 11300, 12604
Draco 11375
DSTV 11433
Eastern 11643
Echostar 10775, 11505, 10396, 11170, 11775, 12262, 12527
Expressvu 10775, 11775
Fortec Star 11664
Fresat 10119, 10634, 10885
GE 10392
General Instrument 10869, 10891, 10892
GOI 10775, 11775
Goodmans 12376
Gradiente 10856, 10099, 10887
Grundig 10173, 12376
Handan 10128
Homecast 12525
Hot Sat 12403
HTS 10775, 11775
Hughes Network Systems 10749, 11442, 11443, 11444
Humax 11989
Hwalin 10885
Hyundai 11159, 12452
Indovision 10856, 10887, 11255, 11989, 12108, 12239
Innova 10099
ISkyB 10887
J-Point 10099
Jerrold 10869
JVC 10775, 11170, 11775
Kaon 11300
Kathrein 12263
LG 11414
Marantz 10200
Mitsubishi 10749
Moserbaer 11251
Motorola 10869, 10856
Movistar 12262, 12263, 12527, 11804
NET 11883
Net Brazil 11883, 12262
Netsat 10099, 10887
Next Level 10869, 10891, 10892
Nextvision 11845
Pace 10887
Panarex 11159
Panasonic 10247
Pansat 11159
Philips 10749, 10856, 10099, 10200, 10887, 11442
Pioneer 10329
Proscan 10392
QNS 11230, 11404
RadioShack 10869
Radix 11255
RCA 10392, 12108
Reliance 12452
Samsung 11377, 11276, 11109, 10563, 11442, 11708
Manufacturer’s Code List
Lista de códigos del fabricante
English
The following tables show brand names (Brand)
and their corresponding code numbers (Code
No.).
Español
La siguiente tabla muestra los nombres de las
marcas (Brand) y el número de código
correspondiente (Code No.).
4-170-644-11(1)
English
WARNING
ˎ
Always keep a screwdriver away from children.
ˎ
Use a screwdriver carefully to avoid injury.
(1) Replacing batteries and settings must be performed
by an adult.
(2) Do not mix old and new batteries.
(3) Do not use any other type of battery such as carbon
zinc or rechargeable.
(4) For children ages 3 and up. Children under 3 years
old should not use the RM-KZ1.
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
ˎ
Reorient or relocate the receiving antenna.
ˎ
Increase the separation between the equipment and
receiver.
ˎ
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
ˎ
Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Features
ˎ
Designed in a cute style for safe and easy use by
children ages 3 and up.
ˎ
Offers a simple means of controlling what
channels your child is able to watch.
ˎ
Allows you to assign desired TV or set top box
channels to the favorite buttons, enabling your
child to select any channel directly with a single
button.
Location of Controls
˫ LED indicator
Lights or flashes during settings.
Lights during IR signal transmission.
ˬ Æ (power) button
Press to turn on the TV and switch to the
channel assigned to
/turn off the TV.
˭ Favorite buttons
Press to select a channel.
ˮ VOLUME –/+ buttons
Press to adjust the volume.
˯ Numeric buttons
Press to enter numbers required for setup.
˰ SET button
Use for setup mode.
˱ ENT (enter) button
Press to apply setting.
Remote Commander
RM-KZ1
©2010 Sony Corporation Printed in China
Operating Instructions
Manual de instrucciones (parte posterior)
Before Use
The RM-KZ1 can perform the following functions
on these devices:
TV: power on/off, channel switching and volume
level adjustment
Cable set top box or satellite receiver: power on/
off
ˈ
and channel switching
ˈ
Available after changing the setup of “Setting the
power button functions” in “Additional Settings.”
Be sure to complete setting the
manufacturer’s code(s) and assigning
channels before you use the RM-KZ1.
Opening the Setup
Button Cover
First, you need to open the setup button cover to
install the batteries and set up the RM-KZ1.
What you need
– Phillips-head screwdriver #1
– Two size AAA (LR03) alkaline batteries
Opening the setup button
cover
1
Using a screwdriver, loosen the screw.
The screw does not remove from the setup
button cover completely.
2
Slide the setup button cover, then lift to open.
Installing the batteries
To install the batteries, you need to open the
battery cover after opening the setup button cover.
1
Slide the battery cover, then lift to open.
2
Insert two size AAA (LR03) alkaline batteries
(not supplied), negative end first, through the
guide clamp within each compartment.
3
Close the battery cover.
Leave the setup button cover open to continue
to set up the RM-KZ1.
Battery life
Under normal conditions, size AAA (LR03)
alkaline batteries will last up to one year. If the
RM-KZ1 does not operate properly, the batteries
might be drained. Replace the batteries with new
ones.
Notes
ˎ
Do not use an old battery with a new one, or use any
other type of battery such as carbon zinc or
rechargeable.
ˎ
If the electrolyte inside the battery should leak, wipe
the contaminated area of the battery compartment
with a cloth and replace the old batteries with new
ones. To prevent electrolyte leakage, remove the
batteries if you plan not to use the RM-KZ1 for a long
period of time.
Setting the
Manufacturer’s Code
Before assigning channels, you need to set the
manufacturer’s code for both TV and set top box
in the following order.
Set the manufacturer’s code for the TV.
Operate the TV to check the code you have set is
correct. (Up to this step when assigning TV channels
to favorite buttons)
Set the manufacturer’s code for the set top box.
Operate the set top box to check the code you have set
is correct. (Up to this step when assigning set top box
channels to favorite buttons)
Note
If you assign TV channels to favorite buttons, there is no
need to set the manufacturer’s code for the set top box.
The following procedure covers both TV and set
top box setup.
Set the manufacturer’s code
Example: To set up a Philips TV
1
Find the manufacturer’s code in
“Manufacturer’s Code List.”
TBD
If your device is not listed, try the Search
function (see “Searching for the correct
code” in “Additional Settings”).
2
Hold down SET and press numeric button 1.
+
The LED indicator lights up.
3
Release both buttons.
4
Press the numeric buttons to enter the
manufacturer’s code.
Example: 00037
p p p p
The LED indicator flashes 3 times and turns
off.
Operate the device
1
Turn on the TV and set top box.
2
Aim the RM-KZ1 directly at the device.
3
For TV,
1 Press Æ to check that the TV turns off.
2 Press Æ to turn on the TV again.
3 Press VOLUME −/+ to check that the TV
operates correctly.
For set top box,
1 Press the numeric buttons.
Example: 298
p p
2 Press ENT to check that the desired
channel can be selected.
If the RM-KZ1 does not seem to be working…
ˎ
Check that you have set the correct manufacturer’s
code.
ˎ
Start again from step 1 of “Set the manufacturer’s
code.”
ˎ
Try repeating the setup procedure using another
manufacturer’s code (if listed for your device). If you
still cannot operate the RM-KZ1 after trying all the
listed codes, try the Search function (see “Searching
for the correct code” in “Additional Settings”).
Note
If you assign set top box channels to the favorite buttons,
be sure to set up the set top box after completing TV
code setup.
Assigning a
Channel
Channel selecting procedures can be assigned to
the favorite buttons (
-
), allowing your child
to select any channel directly with a single press of
a favorite button.
You can assign either TV or set top box channels
to the favorite buttons.
Assign a channel
Example: To assign channel number 298 to
1
Hold down SET and press numeric button 3.
+
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press .
4
Press the numeric buttons (up to 4) to enter the
desired channel number.
Example: 298
p p
5
Press ENT.
The LED indicator flashes 3 times.
To assign to other favorite buttons, repeat steps
3 – 5.
6
Press SET to complete.
The LED indicator turns off.
Check the setting
1
Turn on the TV and set top box, and set your
TV’s input to the set top box by using the TV’s
remote control.
2
Press a favorite button to check that the desired
channel number is selected.
Note
If you assign TV channels to favorite buttons, turn on
the TV in step 1 of “Check the setting.”
Clearing an assigned channel
1
Hold down SET and press numeric button 3.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press the favorite button to clear the setting.
4
Press VOLUME –.
5
Press SET to complete.
The LED indicator turns off.
Note
If you assign TV channels to favorite buttons, see
“Assigning the TV channels to the favorite buttons” in
“Additional Settings.”
Closing the Setup
Button Cover
Using a screwdriver, close the setup button cover
by securing the screw.
Be sure that the battery cover is closed properly
beforehand.
Using the RM-KZ1
After setting up the RM-KZ1, your child needs
only to perform the following operations.
Do this To
Press Æ
turn on the TV and
switch to the channel
assigned to
/turn off
the TV.
Press the favorite
button
select a channel.
Press VOLUME −/+
adjust the volume.
To change the Power button setting
See “Setting the power button functions” in “Additional
Settings.”
Note
If the set top box can control volume, be sure to set its
volume to a moderate level. If the volume on the set top
box is turned down completely, you will not be able to
adjust your TV’s volume with the RM-KZ1.
Additional Settings
This section describes functions for more
convenient use of the RM-KZ1.
Searching for the correct code
You can set the manufacturer’s code using the
Search function.
1
Turn on the device by its power switch.
2
Aim the RM-KZ1 at the device you want to set.
3
Hold down SET and press numeric button 2.
The LED indicator lights up.
4
Release both buttons.
5
For TV, press numeric button 0.
For the set top box, press numeric button 1.
6
Press ENT.
The LED indicator flashes 3 times.
7
Press and hold ENT to start searching.
8
When the device turns off, release the button.
If you overshoot the required code, you can
search for the next or previous code using
or
.
To continue searching, press and hold ENT.
9
Press SET to complete.
The LED indicator flashes 3 times and the
indicator turns off.
Check if the device works correctly with the
manufacturer’s code you entered.
If you still cannot operate the device, repeat the
procedure to search for another code that
works for the most functions for your device.
To cancel the process
Press SET for more than 3 seconds.
The LED indicator turns off.
Checking the manufacturer’s
code you have set
1
Hold down SET and press numeric button 6.
The LED indicator lights up.
2
Release both buttons.
3
For TV, press numeric button 0.
For the set top box, press numeric button 1.
The LED indicator flashes 3 times.
4
Press ENT.
The LED indicator turns off momentarily.
5
When the LED indicator starts flashing, count
the number of flashes and determine the 5-
digit code number.
Short flash(es) indicate which digit (first,
second, etc.), followed by long flash(es) to
indicate the digit number (e.g., 2 long flashes
represent the number 2). “0” is indicated by
rapid flashing. To recheck, press ENT.
6
Press SET to complete.
The LED indicator turns off.
To cancel the process
Press SET any time.
The LED indicator turns off.
Setting the volume button
functions
The RM-KZ1 is factory-set to limit volume up and
down to prevent the TV volume becoming too
loud or too quiet (as a result, for example, of
children pressing VOLUME −/+ continuously).
You can remove the volume limitation or
deactivate VOLUME −/+.
1
Hold down SET and press numeric button 8.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button (1, 2 or 3) to select one
of the following.
Do this To
Press 1
limit volume up and down.
ˈ
If you hold down VOLUME
−/+ continuously, the volume
will not be turned up/down
beyond a certain level.
Press 2
remove the volume limitation
(standard operation).
Press 3 deactivate VOLUME −/+.
ˈ
Factory setting
The LED indicator flashes 3 times and the
indicator turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Setting the power button
functions
When Æ is pressed, the RM-KZ1 is factory-set to
turn on the TV and switch to the channel assigned
to
.
You can change this consecutive procedure set on
Æ according to your preference.
1
Hold down SET and press numeric button 4.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1 - 5) to select one of
the following.
Do this To
Press 1
turn on TV ~ switch to the
channel on .
ˈ
(When Æ is pressed with TV on,
the TV is turned off.)
Press 2
turn on TV.
(When Æ is pressed with TV on,
the TV is turned off.)
Press 3
turn on TV ~ turn on set top box
~ switch to the channel on
.
(When Æ is pressed with TV
and set top box on, both are
turned off.)
Press 4
turn on TV ~ turn on set top
box.
(When Æ is pressed with TV
and set top box on, both are
turned off.)
Press 5
deactivate Æ.
ˈ
Factory setting
The LED indicator flashes 3 times and turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
If the channel assigned to cannot be
selected correctly when you press
Æ
You can set an interval before the channel
switches.
1
Hold down SET and press numeric button 5.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1 - 5) to select one of
the following.
Do this To
Press 1
insert 0.2 second interval.
ˈ
Press 2
insert 0.4 second interval.
Press 3
insert 0.6 second interval.
Press 4
insert 0.8 second interval.
Press 5
insert 1 second interval.
ˈ
Factory setting
The LED indicator flashes 3 times and turns
off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Assigning the TV channels to
the favorite buttons
ˎ
At the factory settings, without setting the
manufacturer’s code for the set top box of
“Setting the Manufacturer’s Code,” go to the
next step “Assigning a Channel.”
ˎ
If you change all favorite button assignments
from set top box channels to TV channels,
perform steps 2 - 4 of “Set the manufacturer’s
code” of “Setting the Manufacturer’s Code,” and
press “19999” in step 4. Then assign the TV
channels. (It is recommended that you clear
unused favorite buttons.)
Restoring the factory settings
You can clear all settings, and reset the RM-KZ1
to its factory settings.
1
Hold down SET and press numeric button 0.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button 1 to reset all settings,
including TV/set top box manufacturer codes
and assigned channels.
4
Press ENT.
When all settings have been reset, the LED
indicator flashes 3 times and turns off.
To cancel the process
Press any button other than is used for this setting.
The LED indicator turns off.
Help
If you have problems setting up or using the
RM-KZ1:
ˎ
Carefully apply the setup procedure of “Setting
the Manufacturer’s Code.” If the RM-KZ1 does
not work, apply the procedure repeatedly, using
another code listed for your device. If you still
cannot operate the RM-KZ1, try the Search
function.
ˎ
Aim the RM-KZ1 directly at the device.
ˎ
Remove any obstacles in the path between the
RM-KZ1 and the device.
ˎ
Be sure that the device has infrared remote
capability. For example, if your device did not
come with a remote control, it probably is not
capable of being controlled by the RM-KZ1.
ˎ
The batteries are weak, or not inserted correctly.
Replace them with new ones or insert them
correctly.
ˎ
If the favorite button does not seem to be
working:
– Check that the desired channel is properly
assigned (see “Assigning a Channel”).
– Try to insert an interval (see “If the channel
assigned to
cannot be selected correctly
when you press Æ”).
ˎ
If the volume button does not seem to be
working, carefully apply the procedure of
“Setting the volume button in “Additional
Settings.”
ˎ
If the power button does not seem to be
working, carefully apply the procedure of
“Setting the power button in “Additional
Settings.”
Notes on setting the RM-KZ1
ˎ
If the setting is incomplete, the LED indicator flashes
once and turns off. Start again from the beginning.
ˎ
If no operations are performed for 3 minutes while
setting, the setting will be canceled, and must be
restarted.
For the customers in the U.S.A.
Customer Support Information
After you have read through this manual, if you still
cannot get the RM-KZ1 to work properly, call the Sony
Customer Support Helpline at 1-800-822-2217.
Specifications
Operating distance Approx. 11 m (36 ft) (varies depending on
devices of different manufacturers)
Power requirements Two size AAA (LR03) alkaline batteries
(not supplied)
Battery life Approx. 1 year when using size AAA
(LR03) alkaline batteries (varies
depending on frequency of button use -
up to approx. 50 times per day.)
Dimensions Approx. 52 mm × 168 mm × 31 mm
(2
1
/
8
in × 6
5
/
8
in × 1
1
/
4
in) (w/h/d)
Mass Approx. 92 g (3.2 oz) (not including
batteries)
Design and specifications are subject to change without
notice.
Continued on reverse side
TV / TV
Brand Code No.
888 00264, 00412
Abex 00032
Accurian 01803
Acer 01339
Action 00650, 00873
Addison 00092, 00108, 01224
Admiral 00093, 01463, 00179
Advent 00761, 00108, 01284, 01570, 01037
Aftron 01549
Aiko 00092, 01579
Aiwa 00032, 00701, 01911, 01914, 01955
Akai 01675, 00702, 01240, 02232, 01670, 01692, 01327,
01688, 01676, 01413, 01385, 01207, 00672, 00602,
00412, 00264
Akira 01814, 00858, 01243, 01037
Alaron 00179
Albatron 00843
Alfide 00672
America Action 00180
Anam 00250, 00180, 00009, 00426
Anam National 00250, 00650
Anhua 00051
AOC 01661, 00093, 00180, 01503, 01240, 00092, 02087,
01341, 01590, 01365, 00179, 00108, 00018, 00009
Aolingpu 00858
Aolinpike 00264, 00412
Aomni 01623
Apex Digital 01549, 00879, 00890, 01217, 01243, 01531
Astar 01531, 01555
Audinac 00180
Audiovox 01661, 00180, 00092, 00802, 00846, 00875, 01284,
01766, 01769, 01803, 01951, 01952
AUO 01581
Aurora Systems 00801
Aventura 01665
Baihe 00009, 00264, 00412
Baile 00001, 00009, 00661
Baohuashi 00264, 00412
Baosheng 00009, 00108
Barco 01080
Baysonic 00236, 01463, 00180
Beijing 00702, 00001, 00009, 01009, 00226, 00264, 00412,
00482, 00661, 00108, 01243
Bell & Howell 00154, 00016
BenQ 01327, 01315, 01562
Bestwell 01326
BGH 00876, 01314
Blue Sky 01080, 01341, 02153
Boigle 01696
BPL 01009, 00373, 00896, 01476
Bradford 00180
Brillian 01007
Broksonic 00236, 01463, 00426, 01911, 01670
Bush 00698, 01441
Byd:sign 01309
C-Tech 00858, 01549, 00896
Cadia 01283
Caihong 00009, 00108
Cailing 01549
Caishi 01549
Candle 01240, 00056, 00186
Carnivale 01240
Carver 00054, 00170
Casio 00611, 01205
CCE 00037
Celebrity 00000
Celera 01243
Changcheng 00051, 00001, 00009, 00264, 00412, 00661, 00108
Changfei 00009, 00108
Changfeng 00264, 00412, 01814, 00108
Changhai 00009, 00108
Changhong 01243, 00009, 00264, 00108, 00819, 00820
Chengdu 00009, 00108
Chimei 01852
Ching Tai 00092, 00009, 00179
Chun Yun 00000, 00180, 00092, 00698, 00009, 00179, 00843,
01687, 01327
Chunfeng 00009, 00264
Chung Hsin 00180, 00053, 00108
Chungfeng 00412
Chunsun 00009, 00108
Cinema 00672
Cineral 01661, 00092
Citizen 01661, 01503, 01240, 00092, 00056, 00186, 00280,
00561, 01669, 01671, 01672, 01670
Clarion 00180
Classic 01984
Coby 01538, 01634, 02017, 01531, 02315, 02326, 02340,
02344, 02345, 02347, 01555, 02351, 02560
Commercial Solutions 00047
Concerto 00056
Conrowa 01243, 00145, 00009, 00264, 00412, 00698, 01814
Contec 00180
Continental 02357
Craig 00180
Crosley 00000, 00054, 00074
Crown 00180, 00009, 00672
Crown Mustang 00672
Curtis 02352, 02466
Curtis Mathes 00047, 00054, 00154, 00093, 01503, 00702, 01240,
00145, 00166, 01661, 00016, 00056, 01824, 00747,
01959
CWN 01367
CXC 00180
CyberHome 00794
Cytron 01326
Daenyx 00180, 00179, 00672
Daewoo 00154, 00180, 01240, 00092, 01661, 00032, 00056,
00108, 00170, 00661, 00672, 01909
Daytron 00180
Dayu 00661
Dell 01264, 01080, 01240
Delta 01369
Denon 00145
Denstar 00180
Dewo 00180
Diamond Vision 01996
Digisonic 01826
Digistar 01565
Digital Lifestyles 01546, 01822
DirecTV 01501
Disney 02152
Dongda 00009
Donghai 00009
Drean 00037
DSE 01565
Dumont 00017
Durabrand 01463, 00180, 01240, 01665, 01034
Dwin 00747
DX Antenna 01864
Dynex 01564, 01463
ECE 00037, 01549, 01555
Elba 01557
Electroband 00000
Electrograph 01755, 01623
Electrohome 01463, 01570, 01670, 01672
Elektra 00017, 01661
Element 01687, 01240
Emerson 01864, 00154, 00236, 01463, 00180, 01240, 01661,
00179, 00280, 01665, 01909, 01911, 01913, 01963
Emprex 01422, 01546
Brand Code No.
Encross 00876
Envision 01240, 00813, 01365, 01506, 01341, 02087
Epson 01122
Erae 01222
ESA 00702, 01665, 01963
Ether 01240, 00009
Etron 00009
Feilang 00009
Feilu 00009, 00108
Feiyan 00264, 00412
Feiyue 00009, 00108
Firstar 00236, 00009
Firstline 00037
Fisher 00154
Fortress 00093
Frigidaire 01597, 01826
Fujimaro 01498, 01687
Fujimaru 01687
Fujitsu 00809, 00179, 00186, 00683, 02008
Fujitsu General 00186
Funai 00000, 00180, 01665, 00179, 00264, 01864, 01904,
01913, 01963
Furi 00145, 00264, 00412, 00108
Futuretech 00180
Ganxin 00108
Gateway 01755, 01327
GE 00047, 00051, 01661, 00180, 01240, 00092, 00279,
00747, 01922
General 00186
General Electric 00047, 00180
GFM 01665, 01963
Gibralter 00017, 01240
Gibson 01597, 01826
Global Home 01565
Go Video 00886, 01314, 01385
Goldi 01559
GoldStar 00154, 01240, 00001, 00032, 00037, 00056
GPX 00179
Gradiente 00053, 00056, 00170, 01804
Grundig 00037, 00070, 00672, 00683
Grunpy 00180, 00179
Haier 01034, 00037, 01243, 00587, 00698, 00768, 00761,
01549, 00896, 01009, 01238, 01560, 01570, 01240,
02449
Haihong 00009
Haiyan 00264, 00412, 00108
Hallmark 01240
Hankook 00180, 01240, 00056
Hanns.G 01783
Hannspree 01348, 01745, 01783, 01826
Harley Davidson 00179, 01904
Harman/Kardon 00054
Harvard 00180
Havermy 00093
Helios 00865
Hello Kitty 01661
Heran 01826, 01852
Herosonic 01826
Hewlett Packard 01494, 01088, 01365, 01101
Hikato 00180
Himitsu 00180, 00761
HiPlus 01420, 01435, 01826
Hisense 01243, 01549, 00145, 00009, 01080, 01814, 01314,
01660, 02098, 01240
Hitachi 01243, 01240, 00145, 00092, 02215, 01904, 01576,
01345, 01037, 00797, 00723, 00679, 00413, 00279,
00186, 00179, 00165, 00056, 00032, 00016, 00009
Hitec 00698
Hitech 01814
HomeTech 02462
Hongmei 00093, 00009, 00264, 00108
Hongyan 00264, 00412, 00108
HP 01494, 01088, 01365, 01101
Hua Tun 00009
Huafa 00145, 00009
Huanghaimei 00009
Huanghe 00009, 00108
Huanglong 00009
Huangshan 00009, 00264, 00412, 00108
Huanyu 00264, 00108
Huaqiang 00264, 00412
Huari 00145, 00264, 00412
Humax 01501
Huodateji 00051
Hyundai 00849, 01219, 01294, 01468, 01814, 02454
I-Inc 01746
Igo 01224
iLo 01286, 01603, 01665, 01684, 01990
Imperial Crown 00001, 00009, 00264, 00412, 00661
Infinity 00054
Initial 01603, 01990
Innova 00037
Insignia 01564, 01665, 01204, 01326, 01385, 01284, 01660,
01463, 01963, 02002, 01603
Inteq 00017
iRIS 02189
IRT 01661, 00180, 00698
ITT Nokia 00180
IX 01783
JBL 00054
JCB 00000
Jean 01243, 00051, 00236, 00092, 00009, 00179
Jensen 00761, 00108, 01299, 01037
Jiahua 00051
JiaLiCai 00009, 00264, 00412
Jinfeng 00051, 01009, 00226, 00108
Jinque 00009, 00264, 00412, 00108
Jinta 00009, 00264, 00412
Jinxing 00054, 01243, 00145, 00009, 00037, 00264, 01080,
00698, 00108
Juhua 00264, 00412, 00108
JVC 01463, 00053, 00160, 00371, 01243, 00650, 01224,
00731
Kaige 00009, 00264, 00412, 00108
Kanghua 00896
Kangli 00001, 00009, 00264, 00661, 00108
Kangyi 00009, 00264, 00412
KDS 01498, 01687
KEC 00180
Ken Brown 00236, 01463, 01321
Kenia 01240
Kenstar 01236
Kenwood 01240
Khind 00698, 00896
Kioto 00054, 00698, 01080, 00180, 00761
KLH 01243
KLL 00037
KMDS 02278
Kolin 01610, 01755, 00180, 00053, 00037, 00108, 01549,
01217, 01240
Kongque 00009, 00264, 00108
Konka 01549, 00037, 00587, 00180, 00632, 00638, 00707,
00761, 00795, 00108, 01385, 01243, 01939
Kost 01262, 01314
Kreisen 00876
KTV 00180, 01240, 00280
Kuaile 00009, 00264, 00412
Kulun 00009
Kunlun 00051, 01009, 00226, 00264, 00661, 00108
LG 00017, 01503, 01240, 00001, 00032, 00037, 00056,
00108, 00856, 01530, 01556
Lihua 00108
LiteOn 01088
Lloyd’s 01904
Loewe 01037
Logik 00016
Longjiang 00264, 00412, 00108
Luce 00813, 01031
Luxman 00056
LXI 00047, 00054, 01243, 00154, 01240, 00747
Lynx 01565
M&S 00054, 00236
MAG 01498, 01687
Magnasonic 01913
Magnavox 01755, 00054, 00051, 01240, 01665, 00698, 01990,
01963, 01913, 01904, 01525, 01506, 01365, 01341,
01198, 00802, 01549, 00186, 00179
Majestic 00016
Malata 01769
Marantz 00054, 01240, 00037, 00854, 01811, 02447
Mastro 00053, 00698, 01549, 01556, 01558
Matsushita 00250, 00650
Maxent 01755, 01597, 01811, 01757
Meck 00698, 01549, 01558, 01571
Megatron 01240, 00145
Meile 00264, 00412, 00108
Memorex 00154, 00108, 01240, 00016, 00179, 01783, 01037,
01570, 01670, 01463, 01911, 01985
Mercury 00001
Mermaid 00037
Brand Code No.
MGA 00108, 01240
Midland 00047, 00017, 00051, 00032, 00747
Mintek 01603, 01990
Mitsubishi 00250, 00154, 01250, 00093, 00236, 00180, 01240,
00056, 00108, 00179, 01037
Monivision 00843
Monix 01549
Moserbaer 01149
Motorola 00093, 01498
Moxell 01498
MTC 01503, 01240, 00056
Mudan 00051, 00009, 01009, 00226, 00264, 00412, 00108
Multitech 00180
NAD 01243, 01240, 00037, 00056
Nakamichi 01493
Nanbao 00009, 00264, 00412
Nansheng 00264, 00412, 00108
National 00051, 01009, 00226, 01243
Naxa 01998
NEC 01243, 00154, 00051, 00053, 01240, 01783, 01852,
01797, 01546, 00108, 00412, 00264, 00186, 00170,
00165, 00056, 00009
Netsat 00037
NetTV 01755
Newave 00093, 01240, 00092, 00009
NewSonic 01826
NEX 01814
Nexus Electronics 01240
Nikko 01240, 00092
Niko 01581
Nimbro 01531
Noblex 00154, 00018, 00037, 00264, 00482
Nokia 00180
Norcent 01549, 00824, 01365, 01590, 01581
Norwood Micro 01286
Noshi 00018
NTC 00092
NuVision 01284, 02158
Olevia 01610, 01144, 01240
One 01284
Onida 00053, 01224
Onking 00280
Onwa 00180
Optimus 00250, 00154, 00166, 00650, 01913
Optoma 00887, 01348
Optonica 00093, 00165
Orbit 01696
Orion 00236, 01463, 00179, 01911
Packard Bell 00092
Panasonic 00250, 01457, 00054, 00051, 00037, 01009, 00226,
01243, 00650, 00896
Panda 00051, 00009, 01009, 00226, 00264, 00412, 01243,
00698, 01549, 00108
PARK 01531
Peng Sheng 01549
Penney 00047, 01243, 00051, 01503, 01240, 00018, 00032,
00747
Performance Teknique 00806
Petters 01523
Philco 00054, 01463, 00180, 01240, 00145, 00092, 01661,
01963, 01911, 01665, 00786, 00747, 00032, 00186,
00037, 00179, 00056, 00074
Philips 00000, 00054, 00051, 01240, 00092, 00037, 00032,
00056, 00108, 00186, 01037, 01080, 00747, 01314,
01506, 01744, 01815
Pilot 01240
Pioneer 01457, 00166, 00679, 00698, 01260
Planar 01496
Polaroid 01523, 02117, 02063, 02002, 01243, 01769, 01767,
01766, 01763, 01762, 01687, 01565, 01538, 01498,
01385, 01341, 01282, 01327, 01326, 01316, 01314,
01286, 01284, 01262, 00865
Polyvision 00889, 01144
Portland 00092, 01661
Prima 00761, 00108, 01284, 01037
Princeton 00685, 00717
Prism 00051
Proscan 00047, 01240, 01824, 00747, 01922, 02147, 02256
Proton 01240, 00001, 00009, 00056, 01824, 01546
Protron 01320, 01323
Proview 01498, 01687
Pulsar 00017
Puneet 01546
Punktal 00602
Pvision 01222
Pye 00412
Qingdao 00051, 01009, 00226, 00264, 00412, 00108
Quasar 00250, 00051, 00165, 00650
RadioShack 00047, 00154, 00180, 01240, 00032, 00056, 00165,
00747, 01904
Ranser 00001
RCA 00000, 00047, 00051, 00093, 01503, 01240, 00092,
01661, 00090, 00018, 00679, 00747, 01922, 01953,
02002, 02403, 02414
Realistic 00154, 00180, 01240, 00032, 00056, 00165
Recco 00698
Relon 01826
Reoc 00714
RevolutionHD 01623
Rowa 01549, 00009, 00037, 00712, 00108
Runco 00017, 01240, 00612
Ruyi 00108
Saige 00009, 00108
Sampo 01755, 00154, 00093, 01240, 01665, 00092, 00009,
00032, 00650, 01385, 01597
Samsung 01243, 00154, 01503, 00702, 01240, 00092, 01959,
00108, 00814, 00766, 00747, 00650, 00587, 00482,
00264, 00226, 01009, 00179, 00090, 00056, 00037,
00032, 00009
Sanjian 00264, 00412
Sansei 01661, 00092
Sansui 01665, 00165, 00371, 01236, 01413, 01670, 01463,
01904, 01911
Sanyo 00054, 01243, 00154, 00180, 00145, 00088, 01009,
00264, 00280, 00412, 00798
Sanyuan 00093, 00009, 00108
Sceptre 00878, 01217, 01360, 01599, 02293
Scotch 01240
Scott 00236, 00180, 01240, 00179, 01711
Sears 00047, 00054, 01243, 00154, 01240, 01665, 00056,
00179, 00747, 01007, 01904
Semivox 00236, 01463, 00180
Semp 01243
Serie Dorada 01243, 00180, 01240, 00056
Shancha 00264, 00412, 00108
Shanghai 00009, 01009, 00226, 00264, 00412, 00108
Shaofeng 00145, 00108
Sharp 00093, 01240, 00009, 00032, 00165, 00650, 00854,
01193, 01407
Sharper Image 01950
Shen Ying 00092, 00009, 00179
Shencai 00145, 00009, 00264, 00412
Sheng Chia 00093, 00236, 00009, 00179
Shenyang 00009, 00264, 01814, 00108
Sherwood 00009
Shinco 01990
Siam 00037
Signal 00145, 01955
Signature 00054, 00016
Signet 01530, 00844, 01262
Simpson 00186
SKY 00037
Skygiant 00180
Skyworth 01549, 00009, 00037, 00264, 00698, 01814, 00805,
00108, 01799
Solarism 01220
Sole 01031, 01377, 01314, 01530, 01623, 01555, 02076
Songba 00009
Sony 00000, 00650, 00834, 01300, 01685, 01825, 01904
Soundesign 00180, 01240, 00179, 00186
Sova 01320, 01952
Sowa 01243, 00051, 01503, 01240, 00092, 00226
Soyo 01546, 01746, 01824, 01826, 01828, 01830, 01385
Space Tek 01696
Spectroniq 01498, 01687
Squareview 01665
SSS 00180
Starlite 00180
Studio Experience 00843
SunBrite 01420, 01435, 02293
Superscan 00093, 00864
Supreme 00000
SVA 01549, 00587, 00768, 00865, 00871, 00872, 01963
Sylvania 01864, 00054, 01240, 00587, 01314, 01665, 01913,
01963
Symphonic 00180, 01665, 01904, 01913
Synco 01755, 00000, 01661, 00093, 01503, 01240, 00092,
01826
Syntax 01610, 01144, 01240
Tacico 01240, 00092, 00009, 00179
Tai Yi 00009
Taishan 00009, 00108
Brand Code No.
Talent 01240
Tandy 00093, 00218
Tashiko 00092, 00650
Tatung 00054, 01243, 00154, 00051, 00009, 00180, 01101,
01341, 01286, 01287, 01288, 01361, 01503, 01687,
01327
TCC 00698
TCL 00412, 00698, 00761, 00806, 01314, 02403, 02414
Technics 00250, 00051
Technol Ace 00179
Techview 02004
Techwood 00051, 00056
Teco 00051, 00093, 00053, 01240, 00092, 00009, 00218,
00264, 00280, 00180, 01224, 00761, 01687
Teknika 00054, 00180, 00108, 01503, 00092, 00016, 00056,
00179, 00186
Telefunken 00702, 00056, 00074
Tera 01240, 00092, 01824
Texla 01549
Thomas 01904
Thomson 00560, 01814
Tiane 00093, 00108
TMK 01240, 00056
TNCi 00017
Tobo 01549, 00009, 00264, 00412
Tongguang 00264, 00412
Tophouse 00180, 00672, 01385
Toshiba 01243, 00154, 00093, 01240, 01503, 00145, 01959,
01670, 01369, 01343, 00650, 00412, 00264, 00070,
00009
TruTech 01723, 02066
Tuntex 01240, 00092, 00009
TVS 01463
Ultra 01323
US Logic 01286
UTI Technology 02244
Vector Research 01240
Venturer 01240
VEOS 01007
Victor 00250, 00053, 00160, 00650, 01224
Videocon 00037, 01243, 00805, 02436
Vidikron 00054
Vidtech 01240
Viewsonic 01755, 00797, 00857, 00864, 00885, 01330, 01365,
01578, 01627, 01742, 01341, 02087, 02111
Viore 01207, 01684, 01811, 01531, 02352
Visart 01336
Vision 01826
Vistron 02142
Vito 01852
Vizio 01240, 00864, 00885, 01327
VU 02098
Wards 00000, 00047, 00054, 00017, 01243, 00154, 00051,
00180, 01503, 01240, 00186, 00179, 00165, 00056,
00018, 00016
Warumaia 00661
Waycon 01243
Weipai 00009
Westinghouse 01755, 01661, 00885, 00889, 00890, 01217, 01282,
01300, 01577, 01597, 01826, 02293
White Westinghouse 01463, 01661, 00186, 01909
WinBook 01503
Winco 00412
Wyse 01365
Xiahua 00009, 00264, 00412, 00698, 01565, 00761, 00108
Xianghai 00009
Xiangyang 00264, 00412
Xiangyu 00009
Xihu 00264, 00412, 00108
Xinaghai 00412
Xingfu 00009
Xinghai 00264
Xoceco 00761
Yamaha 01240, 00797, 01407
Yapshe 00250
Yingge 00009
Yonggu 00009
Youlanasi 00108
Yousida 00009
Yuhang 00009
Zenith 00000, 00047, 00017, 01463, 01240, 00145, 00092,
01661, 01911, 01909, 01904, 01365, 00160, 00037,
00016
ZhuHai 00009
Zonda 00698, 00761
Satellite receiver / Receptor de satélite
Brand Code No.
ACT Television 12506
Airtel 12243, 12248
Astro 11816, 10099, 12600, 12627
Bang & Olufsen 11897
Bast 11799
Bastide 11799
Bell ExpressVu 10775, 11170
BIG TV 12452
Bush 12376
Century 10856
Cisco 12506
CNS 11230
Coship 12674, 11674, 12525
Cromus 12511
Crossdigital 11109
Crown 11764
Daeryung 10396
DialogTV 12469
DirecTV 11377, 10392, 11639, 10247, 10749, 11856, 10099,
11109, 11414, 11442, 11443, 11444, 11276, 11708
Dish Network 10775, 11505, 11170, 11775
Dishpro 10775, 11505, 11775
DishTV 10128, 11300, 12604
Draco 11375
DSTV 11433
Eastern 11643
Echostar 10775, 11505, 10396, 11170, 11775, 12262, 12527
Expressvu 10775, 11775
Fortec Star 11664
Fresat 10119, 10634, 10885
GE 10392
General Instrument 10869, 10891, 10892
GOI 10775, 11775
Goodmans 12376
Gradiente 10856, 10099, 10887
Grundig 10173, 12376
Handan 10128
Homecast 12525
Hot Sat 12403
HTS 10775, 11775
Hughes Network Systems 10749, 11442, 11443, 11444
Humax 11989
Hwalin 10885
Hyundai 11159, 12452
Indovision 10856, 10887, 11255, 11989, 12108, 12239
Innova 10099
ISkyB 10887
J-Point 10099
Jerrold 10869
JVC 10775, 11170, 11775
Kaon 11300
Kathrein 12263
LG 11414
Marantz 10200
Mitsubishi 10749
Moserbaer 11251
Motorola 10869, 10856
Movistar 12262, 12263, 12527, 11804
NET 11883
Net Brazil 11883, 12262
Netsat 10099, 10887
Next Level 10869, 10891, 10892
Nextvision 11845
Pace 10887
Panarex 11159
Panasonic 10247
Pansat 11159
Philips 10749, 10856, 10099, 10200, 10887, 11442
Pioneer 10329
Proscan 10392
QNS 11230, 11404
RadioShack 10869
Radix 11255
RCA 10392, 12108
Reliance 12452
Samsung 11377, 11276, 11109, 10563, 11442, 11708
Manufacturer’s Code List
Lista de códigos del fabricante
English
The following tables show brand names (Brand)
and their corresponding code numbers (Code
No.).
Español
La siguiente tabla muestra los nombres de las
marcas (Brand) y el número de código
correspondiente (Code No.).
4-170-644-11(1)
English
WARNING
ˎ
Always keep a screwdriver away from children.
ˎ
Use a screwdriver carefully to avoid injury.
(1) Replacing batteries and settings must be performed
by an adult.
(2) Do not mix old and new batteries.
(3) Do not use any other type of battery such as carbon
zinc or rechargeable.
(4) For children ages 3 and up. Children under 3 years
old should not use the RM-KZ1.
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
ˎ
Reorient or relocate the receiving antenna.
ˎ
Increase the separation between the equipment and
receiver.
ˎ
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
ˎ
Consult the dealer or an experienced radio/TV
technician for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Features
ˎ
Designed in a cute style for safe and easy use by
children ages 3 and up.
ˎ
Offers a simple means of controlling what
channels your child is able to watch.
ˎ
Allows you to assign desired TV or set top box
channels to the favorite buttons, enabling your
child to select any channel directly with a single
button.
Location of Controls
˫ LED indicator
Lights or flashes during settings.
Lights during IR signal transmission.
ˬ Æ (power) button
Press to turn on the TV and switch to the
channel assigned to
/turn off the TV.
˭ Favorite buttons
Press to select a channel.
ˮ VOLUME –/+ buttons
Press to adjust the volume.
˯ Numeric buttons
Press to enter numbers required for setup.
˰ SET button
Use for setup mode.
˱ ENT (enter) button
Press to apply setting.
Remote Commander
RM-KZ1
©2010 Sony Corporation Printed in China
Operating Instructions
Manual de instrucciones (parte posterior)
Before Use
The RM-KZ1 can perform the following functions
on these devices:
TV: power on/off, channel switching and volume
level adjustment
Cable set top box or satellite receiver: power on/
off
ˈ
and channel switching
ˈ
Available after changing the setup of “Setting the
power button functions” in “Additional Settings.”
Be sure to complete setting the
manufacturer’s code(s) and assigning
channels before you use the RM-KZ1.
Opening the Setup
Button Cover
First, you need to open the setup button cover to
install the batteries and set up the RM-KZ1.
What you need
– Phillips-head screwdriver #1
– Two size AAA (LR03) alkaline batteries
Opening the setup button
cover
1
Using a screwdriver, loosen the screw.
The screw does not remove from the setup
button cover completely.
2
Slide the setup button cover, then lift to open.
Installing the batteries
To install the batteries, you need to open the
battery cover after opening the setup button cover.
1
Slide the battery cover, then lift to open.
2
Insert two size AAA (LR03) alkaline batteries
(not supplied), negative end first, through the
guide clamp within each compartment.
3
Close the battery cover.
Leave the setup button cover open to continue
to set up the RM-KZ1.
Battery life
Under normal conditions, size AAA (LR03)
alkaline batteries will last up to one year. If the
RM-KZ1 does not operate properly, the batteries
might be drained. Replace the batteries with new
ones.
Notes
ˎ
Do not use an old battery with a new one, or use any
other type of battery such as carbon zinc or
rechargeable.
ˎ
If the electrolyte inside the battery should leak, wipe
the contaminated area of the battery compartment
with a cloth and replace the old batteries with new
ones. To prevent electrolyte leakage, remove the
batteries if you plan not to use the RM-KZ1 for a long
period of time.
Setting the
Manufacturer’s Code
Before assigning channels, you need to set the
manufacturer’s code for both TV and set top box
in the following order.
Set the manufacturer’s code for the TV.
Operate the TV to check the code you have set is
correct. (Up to this step when assigning TV channels
to favorite buttons)
Set the manufacturer’s code for the set top box.
Operate the set top box to check the code you have set
is correct. (Up to this step when assigning set top box
channels to favorite buttons)
Note
If you assign TV channels to favorite buttons, there is no
need to set the manufacturer’s code for the set top box.
The following procedure covers both TV and set
top box setup.
Set the manufacturer’s code
Example: To set up a Philips TV
1
Find the manufacturer’s code in
“Manufacturer’s Code List.”
TBD
If your device is not listed, try the Search
function (see “Searching for the correct
code” in “Additional Settings”).
2
Hold down SET and press numeric button 1.
+
The LED indicator lights up.
3
Release both buttons.
4
Press the numeric buttons to enter the
manufacturer’s code.
Example: 00037
p p p p
The LED indicator flashes 3 times and turns
off.
Operate the device
1
Turn on the TV and set top box.
2
Aim the RM-KZ1 directly at the device.
3
For TV,
1 Press Æ to check that the TV turns off.
2 Press Æ to turn on the TV again.
3 Press VOLUME −/+ to check that the TV
operates correctly.
For set top box,
1 Press the numeric buttons.
Example: 298
p p
2 Press ENT to check that the desired
channel can be selected.
If the RM-KZ1 does not seem to be working…
ˎ
Check that you have set the correct manufacturer’s
code.
ˎ
Start again from step 1 of “Set the manufacturer’s
code.”
ˎ
Try repeating the setup procedure using another
manufacturer’s code (if listed for your device). If you
still cannot operate the RM-KZ1 after trying all the
listed codes, try the Search function (see “Searching
for the correct code” in “Additional Settings”).
Note
If you assign set top box channels to the favorite buttons,
be sure to set up the set top box after completing TV
code setup.
Assigning a
Channel
Channel selecting procedures can be assigned to
the favorite buttons (
-
), allowing your child
to select any channel directly with a single press of
a favorite button.
You can assign either TV or set top box channels
to the favorite buttons.
Assign a channel
Example: To assign channel number 298 to
1
Hold down SET and press numeric button 3.
+
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press .
4
Press the numeric buttons (up to 4) to enter the
desired channel number.
Example: 298
p p
5
Press ENT.
The LED indicator flashes 3 times.
To assign to other favorite buttons, repeat steps
3 – 5.
6
Press SET to complete.
The LED indicator turns off.
Check the setting
1
Turn on the TV and set top box, and set your
TV’s input to the set top box by using the TV’s
remote control.
2
Press a favorite button to check that the desired
channel number is selected.
Note
If you assign TV channels to favorite buttons, turn on
the TV in step 1 of “Check the setting.”
Clearing an assigned channel
1
Hold down SET and press numeric button 3.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press the favorite button to clear the setting.
4
Press VOLUME –.
5
Press SET to complete.
The LED indicator turns off.
Note
If you assign TV channels to favorite buttons, see
“Assigning the TV channels to the favorite buttons” in
“Additional Settings.”
Closing the Setup
Button Cover
Using a screwdriver, close the setup button cover
by securing the screw.
Be sure that the battery cover is closed properly
beforehand.
Using the RM-KZ1
After setting up the RM-KZ1, your child needs
only to perform the following operations.
Do this To
Press Æ
turn on the TV and
switch to the channel
assigned to
/turn off
the TV.
Press the favorite
button
select a channel.
Press VOLUME −/+
adjust the volume.
To change the Power button setting
See “Setting the power button functions” in “Additional
Settings.”
Note
If the set top box can control volume, be sure to set its
volume to a moderate level. If the volume on the set top
box is turned down completely, you will not be able to
adjust your TV’s volume with the RM-KZ1.
Additional Settings
This section describes functions for more
convenient use of the RM-KZ1.
Searching for the correct code
You can set the manufacturer’s code using the
Search function.
1
Turn on the device by its power switch.
2
Aim the RM-KZ1 at the device you want to set.
3
Hold down SET and press numeric button 2.
The LED indicator lights up.
4
Release both buttons.
5
For TV, press numeric button 0.
For the set top box, press numeric button 1.
6
Press ENT.
The LED indicator flashes 3 times.
7
Press and hold ENT to start searching.
8
When the device turns off, release the button.
If you overshoot the required code, you can
search for the next or previous code using
or
.
To continue searching, press and hold ENT.
9
Press SET to complete.
The LED indicator flashes 3 times and the
indicator turns off.
Check if the device works correctly with the
manufacturer’s code you entered.
If you still cannot operate the device, repeat the
procedure to search for another code that
works for the most functions for your device.
To cancel the process
Press SET for more than 3 seconds.
The LED indicator turns off.
Checking the manufacturer’s
code you have set
1
Hold down SET and press numeric button 6.
The LED indicator lights up.
2
Release both buttons.
3
For TV, press numeric button 0.
For the set top box, press numeric button 1.
The LED indicator flashes 3 times.
4
Press ENT.
The LED indicator turns off momentarily.
5
When the LED indicator starts flashing, count
the number of flashes and determine the 5-
digit code number.
Short flash(es) indicate which digit (first,
second, etc.), followed by long flash(es) to
indicate the digit number (e.g., 2 long flashes
represent the number 2). “0” is indicated by
rapid flashing. To recheck, press ENT.
6
Press SET to complete.
The LED indicator turns off.
To cancel the process
Press SET any time.
The LED indicator turns off.
Setting the volume button
functions
The RM-KZ1 is factory-set to limit volume up and
down to prevent the TV volume becoming too
loud or too quiet (as a result, for example, of
children pressing VOLUME −/+ continuously).
You can remove the volume limitation or
deactivate VOLUME −/+.
1
Hold down SET and press numeric button 8.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button (1, 2 or 3) to select one
of the following.
Do this To
Press 1
limit volume up and down.
ˈ
If you hold down VOLUME
−/+ continuously, the volume
will not be turned up/down
beyond a certain level.
Press 2
remove the volume limitation
(standard operation).
Press 3 deactivate VOLUME −/+.
ˈ
Factory setting
The LED indicator flashes 3 times and the
indicator turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Setting the power button
functions
When Æ is pressed, the RM-KZ1 is factory-set to
turn on the TV and switch to the channel assigned
to
.
You can change this consecutive procedure set on
Æ according to your preference.
1
Hold down SET and press numeric button 4.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1 - 5) to select one of
the following.
Do this To
Press 1
turn on TV ~ switch to the
channel on .
ˈ
(When Æ is pressed with TV on,
the TV is turned off.)
Press 2
turn on TV.
(When Æ is pressed with TV on,
the TV is turned off.)
Press 3
turn on TV ~ turn on set top box
~ switch to the channel on
.
(When Æ is pressed with TV
and set top box on, both are
turned off.)
Press 4
turn on TV ~ turn on set top
box.
(When Æ is pressed with TV
and set top box on, both are
turned off.)
Press 5
deactivate Æ.
ˈ
Factory setting
The LED indicator flashes 3 times and turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
If the channel assigned to cannot be
selected correctly when you press
Æ
You can set an interval before the channel
switches.
1
Hold down SET and press numeric button 5.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1 - 5) to select one of
the following.
Do this To
Press 1
insert 0.2 second interval.
ˈ
Press 2
insert 0.4 second interval.
Press 3
insert 0.6 second interval.
Press 4
insert 0.8 second interval.
Press 5
insert 1 second interval.
ˈ
Factory setting
The LED indicator flashes 3 times and turns
off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Assigning the TV channels to
the favorite buttons
ˎ
At the factory settings, without setting the
manufacturer’s code for the set top box of
“Setting the Manufacturer’s Code,” go to the
next step “Assigning a Channel.”
ˎ
If you change all favorite button assignments
from set top box channels to TV channels,
perform steps 2 - 4 of “Set the manufacturer’s
code” of “Setting the Manufacturer’s Code,” and
press “19999” in step 4. Then assign the TV
channels. (It is recommended that you clear
unused favorite buttons.)
Restoring the factory settings
You can clear all settings, and reset the RM-KZ1
to its factory settings.
1
Hold down SET and press numeric button 0.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button 1 to reset all settings,
including TV/set top box manufacturer codes
and assigned channels.
4
Press ENT.
When all settings have been reset, the LED
indicator flashes 3 times and turns off.
To cancel the process
Press any button other than is used for this setting.
The LED indicator turns off.
Help
If you have problems setting up or using the
RM-KZ1:
ˎ
Carefully apply the setup procedure of “Setting
the Manufacturer’s Code.” If the RM-KZ1 does
not work, apply the procedure repeatedly, using
another code listed for your device. If you still
cannot operate the RM-KZ1, try the Search
function.
ˎ
Aim the RM-KZ1 directly at the device.
ˎ
Remove any obstacles in the path between the
RM-KZ1 and the device.
ˎ
Be sure that the device has infrared remote
capability. For example, if your device did not
come with a remote control, it probably is not
capable of being controlled by the RM-KZ1.
ˎ
The batteries are weak, or not inserted correctly.
Replace them with new ones or insert them
correctly.
ˎ
If the favorite button does not seem to be
working:
– Check that the desired channel is properly
assigned (see “Assigning a Channel”).
– Try to insert an interval (see “If the channel
assigned to
cannot be selected correctly
when you press Æ”).
ˎ
If the volume button does not seem to be
working, carefully apply the procedure of
“Setting the volume button in “Additional
Settings.”
ˎ
If the power button does not seem to be
working, carefully apply the procedure of
“Setting the power button in “Additional
Settings.”
Notes on setting the RM-KZ1
ˎ
If the setting is incomplete, the LED indicator flashes
once and turns off. Start again from the beginning.
ˎ
If no operations are performed for 3 minutes while
setting, the setting will be canceled, and must be
restarted.
For the customers in the U.S.A.
Customer Support Information
After you have read through this manual, if you still
cannot get the RM-KZ1 to work properly, call the Sony
Customer Support Helpline at 1-800-822-2217.
Specifications
Operating distance Approx. 11 m (36 ft) (varies depending on
devices of different manufacturers)
Power requirements Two size AAA (LR03) alkaline batteries
(not supplied)
Battery life Approx. 1 year when using size AAA
(LR03) alkaline batteries (varies
depending on frequency of button use -
up to approx. 50 times per day.)
Dimensions Approx. 52 mm × 168 mm × 31 mm
(2
1
/
8
in × 6
5
/
8
in × 1
1
/
4
in) (w/h/d)
Mass Approx. 92 g (3.2 oz) (not including
batteries)
Design and specifications are subject to change without
notice.
Continued on reverse side
TV / TV
Brand Code No.
888 00264, 00412
Abex 00032
Accurian 01803
Acer 01339
Action 00650, 00873
Addison 00092, 00108, 01224
Admiral 00093, 01463, 00179
Advent 00761, 00108, 01284, 01570, 01037
Aftron 01549
Aiko 00092, 01579
Aiwa 00032, 00701, 01911, 01914, 01955
Akai 01675, 00702, 01240, 02232, 01670, 01692, 01327,
01688, 01676, 01413, 01385, 01207, 00672, 00602,
00412, 00264
Akira 01814, 00858, 01243, 01037
Alaron 00179
Albatron 00843
Alfide 00672
America Action 00180
Anam 00250, 00180, 00009, 00426
Anam National 00250, 00650
Anhua 00051
AOC 01661, 00093, 00180, 01503, 01240, 00092, 02087,
01341, 01590, 01365, 00179, 00108, 00018, 00009
Aolingpu 00858
Aolinpike 00264, 00412
Aomni 01623
Apex Digital 01549, 00879, 00890, 01217, 01243, 01531
Astar 01531, 01555
Audinac 00180
Audiovox 01661, 00180, 00092, 00802, 00846, 00875, 01284,
01766, 01769, 01803, 01951, 01952
AUO 01581
Aurora Systems 00801
Aventura 01665
Baihe 00009, 00264, 00412
Baile 00001, 00009, 00661
Baohuashi 00264, 00412
Baosheng 00009, 00108
Barco 01080
Baysonic 00236, 01463, 00180
Beijing 00702, 00001, 00009, 01009, 00226, 00264, 00412,
00482, 00661, 00108, 01243
Bell & Howell 00154, 00016
BenQ 01327, 01315, 01562
Bestwell 01326
BGH 00876, 01314
Blue Sky 01080, 01341, 02153
Boigle 01696
BPL 01009, 00373, 00896, 01476
Bradford 00180
Brillian 01007
Broksonic 00236, 01463, 00426, 01911, 01670
Bush 00698, 01441
Byd:sign 01309
C-Tech 00858, 01549, 00896
Cadia 01283
Caihong 00009, 00108
Cailing 01549
Caishi 01549
Candle 01240, 00056, 00186
Carnivale 01240
Carver 00054, 00170
Casio 00611, 01205
CCE 00037
Celebrity 00000
Celera 01243
Changcheng 00051, 00001, 00009, 00264, 00412, 00661, 00108
Changfei 00009, 00108
Changfeng 00264, 00412, 01814, 00108
Changhai 00009, 00108
Changhong 01243, 00009, 00264, 00108, 00819, 00820
Chengdu 00009, 00108
Chimei 01852
Ching Tai 00092, 00009, 00179
Chun Yun 00000, 00180, 00092, 00698, 00009, 00179, 00843,
01687, 01327
Chunfeng 00009, 00264
Chung Hsin 00180, 00053, 00108
Chungfeng 00412
Chunsun 00009, 00108
Cinema 00672
Cineral 01661, 00092
Citizen 01661, 01503, 01240, 00092, 00056, 00186, 00280,
00561, 01669, 01671, 01672, 01670
Clarion 00180
Classic 01984
Coby 01538, 01634, 02017, 01531, 02315, 02326, 02340,
02344, 02345, 02347, 01555, 02351, 02560
Commercial Solutions 00047
Concerto 00056
Conrowa 01243, 00145, 00009, 00264, 00412, 00698, 01814
Contec 00180
Continental 02357
Craig 00180
Crosley 00000, 00054, 00074
Crown 00180, 00009, 00672
Crown Mustang 00672
Curtis 02352, 02466
Curtis Mathes 00047, 00054, 00154, 00093, 01503, 00702, 01240,
00145, 00166, 01661, 00016, 00056, 01824, 00747,
01959
CWN 01367
CXC 00180
CyberHome 00794
Cytron 01326
Daenyx 00180, 00179, 00672
Daewoo 00154, 00180, 01240, 00092, 01661, 00032, 00056,
00108, 00170, 00661, 00672, 01909
Daytron 00180
Dayu 00661
Dell 01264, 01080, 01240
Delta 01369
Denon 00145
Denstar 00180
Dewo 00180
Diamond Vision 01996
Digisonic 01826
Digistar 01565
Digital Lifestyles 01546, 01822
DirecTV 01501
Disney 02152
Dongda 00009
Donghai 00009
Drean 00037
DSE 01565
Dumont 00017
Durabrand 01463, 00180, 01240, 01665, 01034
Dwin 00747
DX Antenna 01864
Dynex 01564, 01463
ECE 00037, 01549, 01555
Elba 01557
Electroband 00000
Electrograph 01755, 01623
Electrohome 01463, 01570, 01670, 01672
Elektra 00017, 01661
Element 01687, 01240
Emerson 01864, 00154, 00236, 01463, 00180, 01240, 01661,
00179, 00280, 01665, 01909, 01911, 01913, 01963
Emprex 01422, 01546
Brand Code No.
Encross 00876
Envision 01240, 00813, 01365, 01506, 01341, 02087
Epson 01122
Erae 01222
ESA 00702, 01665, 01963
Ether 01240, 00009
Etron 00009
Feilang 00009
Feilu 00009, 00108
Feiyan 00264, 00412
Feiyue 00009, 00108
Firstar 00236, 00009
Firstline 00037
Fisher 00154
Fortress 00093
Frigidaire 01597, 01826
Fujimaro 01498, 01687
Fujimaru 01687
Fujitsu 00809, 00179, 00186, 00683, 02008
Fujitsu General 00186
Funai 00000, 00180, 01665, 00179, 00264, 01864, 01904,
01913, 01963
Furi 00145, 00264, 00412, 00108
Futuretech 00180
Ganxin 00108
Gateway 01755, 01327
GE 00047, 00051, 01661, 00180, 01240, 00092, 00279,
00747, 01922
General 00186
General Electric 00047, 00180
GFM 01665, 01963
Gibralter 00017, 01240
Gibson 01597, 01826
Global Home 01565
Go Video 00886, 01314, 01385
Goldi 01559
GoldStar 00154, 01240, 00001, 00032, 00037, 00056
GPX 00179
Gradiente 00053, 00056, 00170, 01804
Grundig 00037, 00070, 00672, 00683
Grunpy 00180, 00179
Haier 01034, 00037, 01243, 00587, 00698, 00768, 00761,
01549, 00896, 01009, 01238, 01560, 01570, 01240,
02449
Haihong 00009
Haiyan 00264, 00412, 00108
Hallmark 01240
Hankook 00180, 01240, 00056
Hanns.G 01783
Hannspree 01348, 01745, 01783, 01826
Harley Davidson 00179, 01904
Harman/Kardon 00054
Harvard 00180
Havermy 00093
Helios 00865
Hello Kitty 01661
Heran 01826, 01852
Herosonic 01826
Hewlett Packard 01494, 01088, 01365, 01101
Hikato 00180
Himitsu 00180, 00761
HiPlus 01420, 01435, 01826
Hisense 01243, 01549, 00145, 00009, 01080, 01814, 01314,
01660, 02098, 01240
Hitachi 01243, 01240, 00145, 00092, 02215, 01904, 01576,
01345, 01037, 00797, 00723, 00679, 00413, 00279,
00186, 00179, 00165, 00056, 00032, 00016, 00009
Hitec 00698
Hitech 01814
HomeTech 02462
Hongmei 00093, 00009, 00264, 00108
Hongyan 00264, 00412, 00108
HP 01494, 01088, 01365, 01101
Hua Tun 00009
Huafa 00145, 00009
Huanghaimei 00009
Huanghe 00009, 00108
Huanglong 00009
Huangshan 00009, 00264, 00412, 00108
Huanyu 00264, 00108
Huaqiang 00264, 00412
Huari 00145, 00264, 00412
Humax 01501
Huodateji 00051
Hyundai 00849, 01219, 01294, 01468, 01814, 02454
I-Inc 01746
Igo 01224
iLo 01286, 01603, 01665, 01684, 01990
Imperial Crown 00001, 00009, 00264, 00412, 00661
Infinity 00054
Initial 01603, 01990
Innova 00037
Insignia 01564, 01665, 01204, 01326, 01385, 01284, 01660,
01463, 01963, 02002, 01603
Inteq 00017
iRIS 02189
IRT 01661, 00180, 00698
ITT Nokia 00180
IX 01783
JBL 00054
JCB 00000
Jean 01243, 00051, 00236, 00092, 00009, 00179
Jensen 00761, 00108, 01299, 01037
Jiahua 00051
JiaLiCai 00009, 00264, 00412
Jinfeng 00051, 01009, 00226, 00108
Jinque 00009, 00264, 00412, 00108
Jinta 00009, 00264, 00412
Jinxing 00054, 01243, 00145, 00009, 00037, 00264, 01080,
00698, 00108
Juhua 00264, 00412, 00108
JVC 01463, 00053, 00160, 00371, 01243, 00650, 01224,
00731
Kaige 00009, 00264, 00412, 00108
Kanghua 00896
Kangli 00001, 00009, 00264, 00661, 00108
Kangyi 00009, 00264, 00412
KDS 01498, 01687
KEC 00180
Ken Brown 00236, 01463, 01321
Kenia 01240
Kenstar 01236
Kenwood 01240
Khind 00698, 00896
Kioto 00054, 00698, 01080, 00180, 00761
KLH 01243
KLL 00037
KMDS 02278
Kolin 01610, 01755, 00180, 00053, 00037, 00108, 01549,
01217, 01240
Kongque 00009, 00264, 00108
Konka 01549, 00037, 00587, 00180, 00632, 00638, 00707,
00761, 00795, 00108, 01385, 01243, 01939
Kost 01262, 01314
Kreisen 00876
KTV 00180, 01240, 00280
Kuaile 00009, 00264, 00412
Kulun 00009
Kunlun 00051, 01009, 00226, 00264, 00661, 00108
LG 00017, 01503, 01240, 00001, 00032, 00037, 00056,
00108, 00856, 01530, 01556
Lihua 00108
LiteOn 01088
Lloyd’s 01904
Loewe 01037
Logik 00016
Longjiang 00264, 00412, 00108
Luce 00813, 01031
Luxman 00056
LXI 00047, 00054, 01243, 00154, 01240, 00747
Lynx 01565
M&S 00054, 00236
MAG 01498, 01687
Magnasonic 01913
Magnavox 01755, 00054, 00051, 01240, 01665, 00698, 01990,
01963, 01913, 01904, 01525, 01506, 01365, 01341,
01198, 00802, 01549, 00186, 00179
Majestic 00016
Malata 01769
Marantz 00054, 01240, 00037, 00854, 01811, 02447
Mastro 00053, 00698, 01549, 01556, 01558
Matsushita 00250, 00650
Maxent 01755, 01597, 01811, 01757
Meck 00698, 01549, 01558, 01571
Megatron 01240, 00145
Meile 00264, 00412, 00108
Memorex 00154, 00108, 01240, 00016, 00179, 01783, 01037,
01570, 01670, 01463, 01911, 01985
Mercury 00001
Mermaid 00037
Brand Code No.
MGA 00108, 01240
Midland 00047, 00017, 00051, 00032, 00747
Mintek 01603, 01990
Mitsubishi 00250, 00154, 01250, 00093, 00236, 00180, 01240,
00056, 00108, 00179, 01037
Monivision 00843
Monix 01549
Moserbaer 01149
Motorola 00093, 01498
Moxell 01498
MTC 01503, 01240, 00056
Mudan 00051, 00009, 01009, 00226, 00264, 00412, 00108
Multitech 00180
NAD 01243, 01240, 00037, 00056
Nakamichi 01493
Nanbao 00009, 00264, 00412
Nansheng 00264, 00412, 00108
National 00051, 01009, 00226, 01243
Naxa 01998
NEC 01243, 00154, 00051, 00053, 01240, 01783, 01852,
01797, 01546, 00108, 00412, 00264, 00186, 00170,
00165, 00056, 00009
Netsat 00037
NetTV 01755
Newave 00093, 01240, 00092, 00009
NewSonic 01826
NEX 01814
Nexus Electronics 01240
Nikko 01240, 00092
Niko 01581
Nimbro 01531
Noblex 00154, 00018, 00037, 00264, 00482
Nokia 00180
Norcent 01549, 00824, 01365, 01590, 01581
Norwood Micro 01286
Noshi 00018
NTC 00092
NuVision 01284, 02158
Olevia 01610, 01144, 01240
One 01284
Onida 00053, 01224
Onking 00280
Onwa 00180
Optimus 00250, 00154, 00166, 00650, 01913
Optoma 00887, 01348
Optonica 00093, 00165
Orbit 01696
Orion 00236, 01463, 00179, 01911
Packard Bell 00092
Panasonic 00250, 01457, 00054, 00051, 00037, 01009, 00226,
01243, 00650, 00896
Panda 00051, 00009, 01009, 00226, 00264, 00412, 01243,
00698, 01549, 00108
PARK 01531
Peng Sheng 01549
Penney 00047, 01243, 00051, 01503, 01240, 00018, 00032,
00747
Performance Teknique 00806
Petters 01523
Philco 00054, 01463, 00180, 01240, 00145, 00092, 01661,
01963, 01911, 01665, 00786, 00747, 00032, 00186,
00037, 00179, 00056, 00074
Philips 00000, 00054, 00051, 01240, 00092, 00037, 00032,
00056, 00108, 00186, 01037, 01080, 00747, 01314,
01506, 01744, 01815
Pilot 01240
Pioneer 01457, 00166, 00679, 00698, 01260
Planar 01496
Polaroid 01523, 02117, 02063, 02002, 01243, 01769, 01767,
01766, 01763, 01762, 01687, 01565, 01538, 01498,
01385, 01341, 01282, 01327, 01326, 01316, 01314,
01286, 01284, 01262, 00865
Polyvision 00889, 01144
Portland 00092, 01661
Prima 00761, 00108, 01284, 01037
Princeton 00685, 00717
Prism 00051
Proscan 00047, 01240, 01824, 00747, 01922, 02147, 02256
Proton 01240, 00001, 00009, 00056, 01824, 01546
Protron 01320, 01323
Proview 01498, 01687
Pulsar 00017
Puneet 01546
Punktal 00602
Pvision 01222
Pye 00412
Qingdao 00051, 01009, 00226, 00264, 00412, 00108
Quasar 00250, 00051, 00165, 00650
RadioShack 00047, 00154, 00180, 01240, 00032, 00056, 00165,
00747, 01904
Ranser 00001
RCA 00000, 00047, 00051, 00093, 01503, 01240, 00092,
01661, 00090, 00018, 00679, 00747, 01922, 01953,
02002, 02403, 02414
Realistic 00154, 00180, 01240, 00032, 00056, 00165
Recco 00698
Relon 01826
Reoc 00714
RevolutionHD 01623
Rowa 01549, 00009, 00037, 00712, 00108
Runco 00017, 01240, 00612
Ruyi 00108
Saige 00009, 00108
Sampo 01755, 00154, 00093, 01240, 01665, 00092, 00009,
00032, 00650, 01385, 01597
Samsung 01243, 00154, 01503, 00702, 01240, 00092, 01959,
00108, 00814, 00766, 00747, 00650, 00587, 00482,
00264, 00226, 01009, 00179, 00090, 00056, 00037,
00032, 00009
Sanjian 00264, 00412
Sansei 01661, 00092
Sansui 01665, 00165, 00371, 01236, 01413, 01670, 01463,
01904, 01911
Sanyo 00054, 01243, 00154, 00180, 00145, 00088, 01009,
00264, 00280, 00412, 00798
Sanyuan 00093, 00009, 00108
Sceptre 00878, 01217, 01360, 01599, 02293
Scotch 01240
Scott 00236, 00180, 01240, 00179, 01711
Sears 00047, 00054, 01243, 00154, 01240, 01665, 00056,
00179, 00747, 01007, 01904
Semivox 00236, 01463, 00180
Semp 01243
Serie Dorada 01243, 00180, 01240, 00056
Shancha 00264, 00412, 00108
Shanghai 00009, 01009, 00226, 00264, 00412, 00108
Shaofeng 00145, 00108
Sharp 00093, 01240, 00009, 00032, 00165, 00650, 00854,
01193, 01407
Sharper Image 01950
Shen Ying 00092, 00009, 00179
Shencai 00145, 00009, 00264, 00412
Sheng Chia 00093, 00236, 00009, 00179
Shenyang 00009, 00264, 01814, 00108
Sherwood 00009
Shinco 01990
Siam 00037
Signal 00145, 01955
Signature 00054, 00016
Signet 01530, 00844, 01262
Simpson 00186
SKY 00037
Skygiant 00180
Skyworth 01549, 00009, 00037, 00264, 00698, 01814, 00805,
00108, 01799
Solarism 01220
Sole 01031, 01377, 01314, 01530, 01623, 01555, 02076
Songba 00009
Sony 00000, 00650, 00834, 01300, 01685, 01825, 01904
Soundesign 00180, 01240, 00179, 00186
Sova 01320, 01952
Sowa 01243, 00051, 01503, 01240, 00092, 00226
Soyo 01546, 01746, 01824, 01826, 01828, 01830, 01385
Space Tek 01696
Spectroniq 01498, 01687
Squareview 01665
SSS 00180
Starlite 00180
Studio Experience 00843
SunBrite 01420, 01435, 02293
Superscan 00093, 00864
Supreme 00000
SVA 01549, 00587, 00768, 00865, 00871, 00872, 01963
Sylvania 01864, 00054, 01240, 00587, 01314, 01665, 01913,
01963
Symphonic 00180, 01665, 01904, 01913
Synco 01755, 00000, 01661, 00093, 01503, 01240, 00092,
01826
Syntax 01610, 01144, 01240
Tacico 01240, 00092, 00009, 00179
Tai Yi 00009
Taishan 00009, 00108
Brand Code No.
Talent 01240
Tandy 00093, 00218
Tashiko 00092, 00650
Tatung 00054, 01243, 00154, 00051, 00009, 00180, 01101,
01341, 01286, 01287, 01288, 01361, 01503, 01687,
01327
TCC 00698
TCL 00412, 00698, 00761, 00806, 01314, 02403, 02414
Technics 00250, 00051
Technol Ace 00179
Techview 02004
Techwood 00051, 00056
Teco 00051, 00093, 00053, 01240, 00092, 00009, 00218,
00264, 00280, 00180, 01224, 00761, 01687
Teknika 00054, 00180, 00108, 01503, 00092, 00016, 00056,
00179, 00186
Telefunken 00702, 00056, 00074
Tera 01240, 00092, 01824
Texla 01549
Thomas 01904
Thomson 00560, 01814
Tiane 00093, 00108
TMK 01240, 00056
TNCi 00017
Tobo 01549, 00009, 00264, 00412
Tongguang 00264, 00412
Tophouse 00180, 00672, 01385
Toshiba 01243, 00154, 00093, 01240, 01503, 00145, 01959,
01670, 01369, 01343, 00650, 00412, 00264, 00070,
00009
TruTech 01723, 02066
Tuntex 01240, 00092, 00009
TVS 01463
Ultra 01323
US Logic 01286
UTI Technology 02244
Vector Research 01240
Venturer 01240
VEOS 01007
Victor 00250, 00053, 00160, 00650, 01224
Videocon 00037, 01243, 00805, 02436
Vidikron 00054
Vidtech 01240
Viewsonic 01755, 00797, 00857, 00864, 00885, 01330, 01365,
01578, 01627, 01742, 01341, 02087, 02111
Viore 01207, 01684, 01811, 01531, 02352
Visart 01336
Vision 01826
Vistron 02142
Vito 01852
Vizio 01240, 00864, 00885, 01327
VU 02098
Wards 00000, 00047, 00054, 00017, 01243, 00154, 00051,
00180, 01503, 01240, 00186, 00179, 00165, 00056,
00018, 00016
Warumaia 00661
Waycon 01243
Weipai 00009
Westinghouse 01755, 01661, 00885, 00889, 00890, 01217, 01282,
01300, 01577, 01597, 01826, 02293
White Westinghouse 01463, 01661, 00186, 01909
WinBook 01503
Winco 00412
Wyse 01365
Xiahua 00009, 00264, 00412, 00698, 01565, 00761, 00108
Xianghai 00009
Xiangyang 00264, 00412
Xiangyu 00009
Xihu 00264, 00412, 00108
Xinaghai 00412
Xingfu 00009
Xinghai 00264
Xoceco 00761
Yamaha 01240, 00797, 01407
Yapshe 00250
Yingge 00009
Yonggu 00009
Youlanasi 00108
Yousida 00009
Yuhang 00009
Zenith 00000, 00047, 00017, 01463, 01240, 00145, 00092,
01661, 01911, 01909, 01904, 01365, 00160, 00037,
00016
ZhuHai 00009
Zonda 00698, 00761
Satellite receiver / Receptor de satélite
Brand Code No.
ACT Television 12506
Airtel 12243, 12248
Astro 11816, 10099, 12600, 12627
Bang & Olufsen 11897
Bast 11799
Bastide 11799
Bell ExpressVu 10775, 11170
BIG TV 12452
Bush 12376
Century 10856
Cisco 12506
CNS 11230
Coship 12674, 11674, 12525
Cromus 12511
Crossdigital 11109
Crown 11764
Daeryung 10396
DialogTV 12469
DirecTV 11377, 10392, 11639, 10247, 10749, 11856, 10099,
11109, 11414, 11442, 11443, 11444, 11276, 11708
Dish Network 10775, 11505, 11170, 11775
Dishpro 10775, 11505, 11775
DishTV 10128, 11300, 12604
Draco 11375
DSTV 11433
Eastern 11643
Echostar 10775, 11505, 10396, 11170, 11775, 12262, 12527
Expressvu 10775, 11775
Fortec Star 11664
Fresat 10119, 10634, 10885
GE 10392
General Instrument 10869, 10891, 10892
GOI 10775, 11775
Goodmans 12376
Gradiente 10856, 10099, 10887
Grundig 10173, 12376
Handan 10128
Homecast 12525
Hot Sat 12403
HTS 10775, 11775
Hughes Network Systems 10749, 11442, 11443, 11444
Humax 11989
Hwalin 10885
Hyundai 11159, 12452
Indovision 10856, 10887, 11255, 11989, 12108, 12239
Innova 10099
ISkyB 10887
J-Point 10099
Jerrold 10869
JVC 10775, 11170, 11775
Kaon 11300
Kathrein 12263
LG 11414
Marantz 10200
Mitsubishi 10749
Moserbaer 11251
Motorola 10869, 10856
Movistar 12262, 12263, 12527, 11804
NET 11883
Net Brazil 11883, 12262
Netsat 10099, 10887
Next Level 10869, 10891, 10892
Nextvision 11845
Pace 10887
Panarex 11159
Panasonic 10247
Pansat 11159
Philips 10749, 10856, 10099, 10200, 10887, 11442
Pioneer 10329
Proscan 10392
QNS 11230, 11404
RadioShack 10869
Radix 11255
RCA 10392, 12108
Reliance 12452
Samsung 11377, 11276, 11109, 10563, 11442, 11708
Manufacturer’s Code List
Lista de códigos del fabricante
English
The following tables show brand names (Brand)
and their corresponding code numbers (Code
No.).
Español
La siguiente tabla muestra los nombres de las
marcas (Brand) y el número de código
correspondiente (Code No.).
If your device is not listed, try the Search
function (see “Searching for the correct
code” in “Additional Settings”).
2
While holding down SET, press numeric
button 1.
+
The LED indicator lights up.
3
Release both buttons.
4
Press the numeric buttons to enter the
manufacturer’s code.
Example: 00037
The LED indicator flashes 3 times and turns
off.
Operate the device
1
Turn on the TV.
2
Aim the RM-KZ1 directly at the device.
3
Press to check that the TV turns off.
4
Press to turn on the TV again.
5
Press VOLUME −/+ to check that the TV
operates correctly.
If the RM-KZ1 does not seem to be working…
Check that you have set the correct manufacturer’s
code.
Start again from step 1 of “Setting the manufacturer’s
code for TV.”
Try repeating the setup procedure using another
manufacturer’s code (if listed for your device). If you
still cannot operate the RM-KZ1 after trying all the
listed codes, try the Search function (see “Searching
for the correct code” in “Additional Settings”).
Notes
If you assign set top box channels to the favorite
buttons, be sure to set up the set top box after
completing TV code setup.
The RM-KZ1 is factory-set to limit volume up and
down to prevent the TV volume becoming too loud or
too quiet (as a result, for example, of children pressing
VOLUME −/+ continuously).
Setting the manufacturer’s
code for set top box
After setting the manufacturer’s code for TV, set
the manufacturer’s code for set top box in the
same way.
Operate the device
1
Turn on the TV and set top box.
2
Aim the RM-KZ1 directly at the device.
3
Press the numeric buttons.
Example: 298
4
Press ENT to check that the desired channel
can be selected.
Note
If you set the manufacture’s code for set top box, the
RM-KZ1 has a priority to operate set top box channels
(you will not be able to operate TV channels). If you
want to switch back to TV channels, see “Assigning the
TV channels to the favorite buttons” in “Additional
Settings.”
Assigning a
Channel
Channel selecting procedures can be assigned to
the favorite buttons (
- ), allowing your child
to select any channel directly with a single press of
a favorite button.
You can assign either TV or set top box channels
to the favorite buttons.
Assign a channel
Example: To assign channel number 298 to
1
While holding down SET, press numeric
button 3.
+
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press after checking that the LED indicator
has flashed.
4
Press the numeric buttons (up to 4) to enter the
desired channel number.
Example: 298
5
Press ENT.
The LED indicator flashes 3 times.
To assign to other favorite buttons, repeat steps
3 – 5.
6
Press SET to complete.
The LED indicator turns off.
Check the setting
1
Turn on the TV and set top box, and set your
TV’s input to the set top box by using the TV’s
remote control.
2
Press a favorite button to check that the desired
channel number is selected.
Note
If you assign TV channels to favorite buttons, turn on
the TV in step 1 of “Check the setting.”
Clearing an assigned channel
1
While holding down SET, press numeric
button 3.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press the favorite button to clear the setting.
4
Press VOLUME –.
5
Press SET to complete.
The LED indicator turns off.
Note
If you assign TV channels to favorite buttons, see
“Assigning the TV channels to the favorite buttons” in
“Additional Settings.”
Closing the Setup
Button Cover
Using a screwdriver, close the setup button cover
by securing the screw.
Be sure that the battery cover is closed properly
beforehand.
Using the RM-KZ1
After setting up the RM-KZ1, your child needs
only to perform the following operations.
Do this To
Press
turn on the TV and
switch to the channel
assigned to /turn off
the TV.
Press the favorite
button
select a channel.
Press VOLUME −/+
adjust the volume.
To change the Power button setting
See “Setting the power button functions” in “Additional
Settings.”
Note
If the set top box can control volume, be sure to set its
volume to a moderate level. If the volume on the set top
box is turned down completely, you will not be able to
adjust your TV’s volume with the RM-KZ1.
Additional Settings
This section describes functions for more
convenient use of the RM-KZ1.
Searching for the correct code
You can set the manufacturer’s code using the
Search function.
1
Turn on the device by its power switch.
2
Aim the RM-KZ1 at the device you want to set.
3
While holding down SET, press numeric
button 2.
The LED indicator lights up.
4
Release both buttons.
5
For TV, press numeric button 0.
For the set top box, press numeric button 1.
6
Press ENT.
The LED indicator flashes 3 times.
7
Press and hold ENT to start searching.
8
When the device turns off, release the button.
If you overshoot the required code, you can
search for the next or previous code using
or .
To continue searching, press and hold ENT.
9
Press SET to complete.
The LED indicator flashes 3 times and the
indicator turns off.
Check if the device works correctly with the
manufacturer’s code you entered.
If you still cannot operate the device, repeat the
procedure to search for another code that
works for the most functions for your device.
To cancel the process
Press SET for more than 3 seconds.
The LED indicator turns off.
Checking the manufacturer’s
code you have set
1
While holding down SET, press numeric
button 6.
The LED indicator lights up.
2
Release both buttons.
3
For TV, press numeric button 0.
For the set top box, press numeric button 1.
The LED indicator flashes 3 times.
4
Press ENT.
The LED indicator turns off momentarily.
5
When the LED indicator starts flashing, count
the number of flashes and determine the 5-
digit code number.
Short flash(es) indicate which digit (first,
second, etc.), followed by long flash(es) to
indicate the digit number (e.g., 2 long flashes
represent the number 2). “0” is indicated by
rapid flashing. To recheck, press ENT.
6
Press SET to complete.
The LED indicator turns off.
To cancel the process
Press SET any time.
The LED indicator turns off.
Setting the volume button
functions
The RM-KZ1 is factory-set to limit volume up and
down to prevent the TV volume becoming too
loud or too quiet (as a result, for example, of
children pressing VOLUME −/+ continuously).
You can remove the volume limitation or
deactivate VOLUME −/+.
1
While holding down SET, press numeric
button 8.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button (1, 2 or 3) to select one
of the following.
Do this To
Press 1
limit volume up and down.
If you hold down VOLUME
−/+ continuously, the volume
will not be turned up/down
beyond a certain level.
Press 2
remove the volume limitation
(standard operation).
Press 3 deactivate VOLUME −/+.
Factory setting
The LED indicator flashes 3 times and the
indicator turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Setting the power button
functions
When is pressed, the RM-KZ1 is factory-set to
turn on the TV.
You can change this consecutive procedure set on
according to your preference.
1
While holding down SET, press numeric
button 4.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1 - 5) to select one of
the following.
Do this To
Press 1
turn on TV.
(When is pressed with TV on,
the TV is turned off.)
Press 2
turn on TV switch to the
channel on .
(When is pressed with TV on,
the TV is turned off.)
Press 3
turn on TV turn on set top box
switch to the channel on .
(When is pressed with TV
and set top box on, both are
turned off.)
Press 4
turn on TV turn on set top
box.
(When is pressed with TV
and set top box on, both are
turned off.)
Press 5
deactivate .
Factory setting
The LED indicator flashes 3 times and turns off.
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
If the channel assigned to cannot be
selected correctly when you press
You can set an interval before the channel
switches.
1
While holding down SET, press numeric
button 5.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press a numeric button (1 - 5) to select one of
the following.
Do this To
Press 1
insert 0.2 second interval.
Press 2
insert 0.4 second interval.
Press 3
insert 0.6 second interval.
Press 4
insert 0.8 second interval.
Press 5
insert 1 second interval.
Factory setting
The LED indicator flashes 3 times and turns off.
Continued on reverse side
TV / TV
Brand Code No.
888 00264, 00412
Abex 00032
Accurian 01803
Acer 01339
Action 00650, 00873
Addison 00092, 00108, 01224
Admiral 00093, 01463, 00179
Advent 00761, 00108, 01284, 01570, 01037
Aftron 01549
Aiko 00092, 01579
Aiwa 00032, 00701, 01911, 01914, 01955
Akai 01675, 00702, 01240, 02232, 01670, 01692, 01327,
01688, 01676, 01413, 01385, 01207, 00672, 00602,
00412, 00264
Akira 01814, 00858, 01243, 01037
Alaron 00179
Albatron 00843
Alfide 00672
America Action 00180
Anam 00250, 00180, 00009, 00426
Anam National 00250, 00650
Anhua 00051
AOC 01661, 00093, 00180, 01503, 01240, 00092, 02087,
01341, 01590, 01365, 00179, 00108, 00018, 00009
Aolingpu 00858
Aolinpike 00264, 00412
Aomni 01623
Apex Digital 01549, 00879, 00890, 01217, 01243, 01531
Astar 01531, 01555
Audinac 00180
Audiovox 01661, 00180, 00092, 00802, 00846, 00875, 01284,
01766, 01769, 01803, 01951, 01952
AUO 01581
Aurora Systems 00801
Aventura 01665
Baihe 00009, 00264, 00412
Baile 00001, 00009, 00661
Baohuashi 00264, 00412
Baosheng 00009, 00108
Barco 01080
Baysonic 00236, 01463, 00180
Beijing 00702, 00001, 00009, 01009, 00226, 00264, 00412,
00482, 00661, 00108, 01243
Bell & Howell 00154, 00016
BenQ 01327, 01315, 01562
Bestwell 01326
BGH 00876, 01314
Blue Sky 01080, 01341, 02153
Boigle 01696
BPL 01009, 00373, 00896, 01476
Bradford 00180
Brillian 01007
Broksonic 00236, 01463, 00426, 01911, 01670
Bush 00698, 01441
Byd:sign 01309
C-Tech 00858, 01549, 00896
Cadia 01283
Caihong 00009, 00108
Cailing 01549
Caishi 01549
Candle 01240, 00056, 00186
Carnivale 01240
Carver 00054, 00170
Casio 00611, 01205
CCE 00037
Celebrity 00000
Celera 01243
Changcheng 00051, 00001, 00009, 00264, 00412, 00661, 00108
Changfei 00009, 00108
Changfeng 00264, 00412, 01814, 00108
Changhai 00009, 00108
Changhong 01243, 00009, 00264, 00108, 00819, 00820
Chengdu 00009, 00108
Chimei 01852
Ching Tai 00092, 00009, 00179
Chun Yun 00000, 00180, 00092, 00698, 00009, 00179, 00843,
01687, 01327
Chunfeng 00009, 00264
Chung Hsin 00180, 00053, 00108
Chungfeng 00412
Chunsun 00009, 00108
Cinema 00672
Cineral 01661, 00092
Citizen 01661, 01503, 01240, 00092, 00056, 00186, 00280,
00561, 01669, 01671, 01672, 01670
Clarion 00180
Classic 01984
Coby 01538, 01634, 02017, 01531, 02315, 02326, 02340,
02344, 02345, 02347, 01555, 02351, 02560
Commercial Solutions 00047
Concerto 00056
Conrowa 01243, 00145, 00009, 00264, 00412, 00698, 01814
Contec 00180
Continental 02357
Craig 00180
Crosley 00000, 00054, 00074
Crown 00180, 00009, 00672
Crown Mustang 00672
Curtis 02352, 02466
Curtis Mathes 00047, 00054, 00154, 00093, 01503, 00702, 01240,
00145, 00166, 01661, 00016, 00056, 01824, 00747,
01959
CWN 01367
CXC 00180
CyberHome 00794
Cytron 01326
Daenyx 00180, 00179, 00672
Daewoo 00154, 00180, 01240, 00092, 01661, 00032, 00056,
00108, 00170, 00661, 00672, 01909
Daytron 00180
Dayu 00661
Dell 01264, 01080, 01240
Delta 01369
Denon 00145
Denstar 00180
Dewo 00180
Diamond Vision 01996
Digisonic 01826
Digistar 01565
Digital Lifestyles 01546, 01822
DirecTV 01501
Disney 02152
Dongda 00009
Donghai 00009
Drean 00037
DSE 01565
Dumont 00017
Durabrand 01463, 00180, 01240, 01665, 01034
Dwin 00747
DX Antenna 01864
Dynex 01564, 01463
ECE 00037, 01549, 01555
Elba 01557
Electroband 00000
Electrograph 01755, 01623
Electrohome 01463, 01570, 01670, 01672
Elektra 00017, 01661
Element 01687, 01240
Emerson 01864, 00154, 00236, 01463, 00180, 01240, 01661,
00179, 00280, 01665, 01909, 01911, 01913, 01963
Emprex 01422, 01546
Brand Code No.
Encross 00876
Envision 01240, 00813, 01365, 01506, 01341, 02087
Epson 01122
Erae 01222
ESA 00702, 01665, 01963
Ether 01240, 00009
Etron 00009
Feilang 00009
Feilu 00009, 00108
Feiyan 00264, 00412
Feiyue 00009, 00108
Firstar 00236, 00009
Firstline 00037
Fisher 00154
Fortress 00093
Frigidaire 01597, 01826
Fujimaro 01498, 01687
Fujimaru 01687
Fujitsu 00809, 00179, 00186, 00683, 02008
Fujitsu General 00186
Funai 00000, 00180, 01665, 00179, 00264, 01864, 01904,
01913, 01963
Furi 00145, 00264, 00412, 00108
Futuretech 00180
Ganxin 00108
Gateway 01755, 01327
GE 00047, 00051, 01661, 00180, 01240, 00092, 00279,
00747, 01922
General 00186
General Electric 00047, 00180
GFM 01665, 01963
Gibralter 00017, 01240
Gibson 01597, 01826
Global Home 01565
Go Video 00886, 01314, 01385
Goldi 01559
GoldStar 00154, 01240, 00001, 00032, 00037, 00056
GPX 00179
Gradiente 00053, 00056, 00170, 01804
Grundig 00037, 00070, 00672, 00683
Grunpy 00180, 00179
Haier 01034, 00037, 01243, 00587, 00698, 00768, 00761,
01549, 00896, 01009, 01238, 01560, 01570, 01240,
02449
Haihong 00009
Haiyan 00264, 00412, 00108
Hallmark 01240
Hankook 00180, 01240, 00056
Hanns.G 01783
Hannspree 01348, 01745, 01783, 01826
Harley Davidson 00179, 01904
Harman/Kardon 00054
Harvard 00180
Havermy 00093
Helios 00865
Hello Kitty 01661
Heran 01826, 01852
Herosonic 01826
Hewlett Packard 01494, 01088, 01365, 01101
Hikato 00180
Himitsu 00180, 00761
HiPlus 01420, 01435, 01826
Hisense 01243, 01549, 00145, 00009, 01080, 01814, 01314,
01660, 02098, 01240
Hitachi 01243, 01240, 00145, 00092, 02215, 01904, 01576,
01345, 01037, 00797, 00723, 00679, 00413, 00279,
00186, 00179, 00165, 00056, 00032, 00016, 00009
Hitec 00698
Hitech 01814
HomeTech 02462
Hongmei 00093, 00009, 00264, 00108
Hongyan 00264, 00412, 00108
HP 01494, 01088, 01365, 01101
Hua Tun 00009
Huafa 00145, 00009
Huanghaimei 00009
Huanghe 00009, 00108
Huanglong 00009
Huangshan 00009, 00264, 00412, 00108
Huanyu 00264, 00108
Huaqiang 00264, 00412
Huari 00145, 00264, 00412
Humax 01501
Huodateji 00051
Hyundai 00849, 01219, 01294, 01468, 01814, 02454
I-Inc 01746
Igo 01224
iLo 01286, 01603, 01665, 01684, 01990
Imperial Crown 00001, 00009, 00264, 00412, 00661
Infinity 00054
Initial 01603, 01990
Innova 00037
Insignia 01564, 01665, 01204, 01326, 01385, 01284, 01660,
01463, 01963, 02002, 01603
Inteq 00017
iRIS 02189
IRT 01661, 00180, 00698
ITT Nokia 00180
IX 01783
JBL 00054
JCB 00000
Jean 01243, 00051, 00236, 00092, 00009, 00179
Jensen 00761, 00108, 01299, 01037
Jiahua 00051
JiaLiCai 00009, 00264, 00412
Jinfeng 00051, 01009, 00226, 00108
Jinque 00009, 00264, 00412, 00108
Jinta 00009, 00264, 00412
Jinxing 00054, 01243, 00145, 00009, 00037, 00264, 01080,
00698, 00108
Juhua 00264, 00412, 00108
JVC 01463, 00053, 00160, 00371, 01243, 00650, 01224,
00731
Kaige 00009, 00264, 00412, 00108
Kanghua 00896
Kangli 00001, 00009, 00264, 00661, 00108
Kangyi 00009, 00264, 00412
KDS 01498, 01687
KEC 00180
Ken Brown 00236, 01463, 01321
Kenia 01240
Kenstar 01236
Kenwood 01240
Khind 00698, 00896
Kioto 00054, 00698, 01080, 00180, 00761
KLH 01243
KLL 00037
KMDS 02278
Kolin 01610, 01755, 00180, 00053, 00037, 00108, 01549,
01217, 01240
Kongque 00009, 00264, 00108
Konka 01549, 00037, 00587, 00180, 00632, 00638, 00707,
00761, 00795, 00108, 01385, 01243, 01939
Kost 01262, 01314
Kreisen 00876
KTV 00180, 01240, 00280
Kuaile 00009, 00264, 00412
Kulun 00009
Kunlun 00051, 01009, 00226, 00264, 00661, 00108
LG 00017, 01503, 01240, 00001, 00032, 00037, 00056,
00108, 00856, 01530, 01556
Lihua 00108
LiteOn 01088
Lloyd’s 01904
Loewe 01037
Logik 00016
Longjiang 00264, 00412, 00108
Luce 00813, 01031
Luxman 00056
LXI 00047, 00054, 01243, 00154, 01240, 00747
Lynx 01565
M&S 00054, 00236
MAG 01498, 01687
Magnasonic 01913
Magnavox 01755, 00054, 00051, 01240, 01665, 00698, 01990,
01963, 01913, 01904, 01525, 01506, 01365, 01341,
01198, 00802, 01549, 00186, 00179
Majestic 00016
Malata 01769
Marantz 00054, 01240, 00037, 00854, 01811, 02447
Mastro 00053, 00698, 01549, 01556, 01558
Matsushita 00250, 00650
Maxent 01755, 01597, 01811, 01757
Meck 00698, 01549, 01558, 01571
Megatron 01240, 00145
Meile 00264, 00412, 00108
Memorex 00154, 00108, 01240, 00016, 00179, 01783, 01037,
01570, 01670, 01463, 01911, 01985
Mercury 00001
Mermaid 00037
Brand Code No.
MGA 00108, 01240
Midland 00047, 00017, 00051, 00032, 00747
Mintek 01603, 01990
Mitsubishi 00250, 00154, 01250, 00093, 00236, 00180, 01240,
00056, 00108, 00179, 01037
Monivision 00843
Monix 01549
Moserbaer 01149
Motorola 00093, 01498
Moxell 01498
MTC 01503, 01240, 00056
Mudan 00051, 00009, 01009, 00226, 00264, 00412, 00108
Multitech 00180
NAD 01243, 01240, 00037, 00056
Nakamichi 01493
Nanbao 00009, 00264, 00412
Nansheng 00264, 00412, 00108
National 00051, 01009, 00226, 01243
Naxa 01998
NEC 01243, 00154, 00051, 00053, 01240, 01783, 01852,
01797, 01546, 00108, 00412, 00264, 00186, 00170,
00165, 00056, 00009
Netsat 00037
NetTV 01755
Newave 00093, 01240, 00092, 00009
NewSonic 01826
NEX 01814
Nexus Electronics 01240
Nikko 01240, 00092
Niko 01581
Nimbro 01531
Noblex 00154, 00018, 00037, 00264, 00482
Nokia 00180
Norcent 01549, 00824, 01365, 01590, 01581
Norwood Micro 01286
Noshi 00018
NTC 00092
NuVision 01284, 02158
Olevia 01610, 01144, 01240
One 01284
Onida 00053, 01224
Onking 00280
Onwa 00180
Optimus 00250, 00154, 00166, 00650, 01913
Optoma 00887, 01348
Optonica 00093, 00165
Orbit 01696
Orion 00236, 01463, 00179, 01911
Packard Bell 00092
Panasonic 00250, 01457, 00054, 00051, 00037, 01009, 00226,
01243, 00650, 00896
Panda 00051, 00009, 01009, 00226, 00264, 00412, 01243,
00698, 01549, 00108
PARK 01531
Peng Sheng 01549
Penney 00047, 01243, 00051, 01503, 01240, 00018, 00032,
00747
Performance Teknique 00806
Petters 01523
Philco 00054, 01463, 00180, 01240, 00145, 00092, 01661,
01963, 01911, 01665, 00786, 00747, 00032, 00186,
00037, 00179, 00056, 00074
Philips 00000, 00054, 00051, 01240, 00092, 00037, 00032,
00056, 00108, 00186, 01037, 01080, 00747, 01314,
01506, 01744, 01815
Pilot 01240
Pioneer 01457, 00166, 00679, 00698, 01260
Planar 01496
Polaroid 01523, 02117, 02063, 02002, 01243, 01769, 01767,
01766, 01763, 01762, 01687, 01565, 01538, 01498,
01385, 01341, 01282, 01327, 01326, 01316, 01314,
01286, 01284, 01262, 00865
Polyvision 00889, 01144
Portland 00092, 01661
Prima 00761, 00108, 01284, 01037
Princeton 00685, 00717
Prism 00051
Proscan 00047, 01240, 01824, 00747, 01922, 02147, 02256
Proton 01240, 00001, 00009, 00056, 01824, 01546
Protron 01320, 01323
Proview 01498, 01687
Pulsar 00017
Puneet 01546
Punktal 00602
Pvision 01222
Pye 00412
Qingdao 00051, 01009, 00226, 00264, 00412, 00108
Quasar 00250, 00051, 00165, 00650
RadioShack 00047, 00154, 00180, 01240, 00032, 00056, 00165,
00747, 01904
Ranser 00001
RCA 00000, 00047, 00051, 00093, 01503, 01240, 00092,
01661, 00090, 00018, 00679, 00747, 01922, 01953,
02002, 02403, 02414
Realistic 00154, 00180, 01240, 00032, 00056, 00165
Recco 00698
Relon 01826
Reoc 00714
RevolutionHD 01623
Rowa 01549, 00009, 00037, 00712, 00108
Runco 00017, 01240, 00612
Ruyi 00108
Saige 00009, 00108
Sampo 01755, 00154, 00093, 01240, 01665, 00092, 00009,
00032, 00650, 01385, 01597
Samsung 01243, 00154, 01503, 00702, 01240, 00092, 01959,
00108, 00814, 00766, 00747, 00650, 00587, 00482,
00264, 00226, 01009, 00179, 00090, 00056, 00037,
00032, 00009
Sanjian 00264, 00412
Sansei 01661, 00092
Sansui 01665, 00165, 00371, 01236, 01413, 01670, 01463,
01904, 01911
Sanyo 00054, 01243, 00154, 00180, 00145, 00088, 01009,
00264, 00280, 00412, 00798
Sanyuan 00093, 00009, 00108
Sceptre 00878, 01217, 01360, 01599, 02293
Scotch 01240
Scott 00236, 00180, 01240, 00179, 01711
Sears 00047, 00054, 01243, 00154, 01240, 01665, 00056,
00179, 00747, 01007, 01904
Semivox 00236, 01463, 00180
Semp 01243
Serie Dorada 01243, 00180, 01240, 00056
Shancha 00264, 00412, 00108
Shanghai 00009, 01009, 00226, 00264, 00412, 00108
Shaofeng 00145, 00108
Sharp 00093, 01240, 00009, 00032, 00165, 00650, 00854,
01193, 01407
Sharper Image 01950
Shen Ying 00092, 00009, 00179
Shencai 00145, 00009, 00264, 00412
Sheng Chia 00093, 00236, 00009, 00179
Shenyang 00009, 00264, 01814, 00108
Sherwood 00009
Shinco 01990
Siam 00037
Signal 00145, 01955
Signature 00054, 00016
Signet 01530, 00844, 01262
Simpson 00186
SKY 00037
Skygiant 00180
Skyworth 01549, 00009, 00037, 00264, 00698, 01814, 00805,
00108, 01799
Solarism 01220
Sole 01031, 01377, 01314, 01530, 01623, 01555, 02076
Songba 00009
Sony 00000, 00650, 00834, 01300, 01685, 01825, 01904
Soundesign 00180, 01240, 00179, 00186
Sova 01320, 01952
Sowa 01243, 00051, 01503, 01240, 00092, 00226
Soyo 01546, 01746, 01824, 01826, 01828, 01830, 01385
Space Tek 01696
Spectroniq 01498, 01687
Squareview 01665
SSS 00180
Starlite 00180
Studio Experience 00843
SunBrite 01420, 01435, 02293
Superscan 00093, 00864
Supreme 00000
SVA 01549, 00587, 00768, 00865, 00871, 00872, 01963
Sylvania 01864, 00054, 01240, 00587, 01314, 01665, 01913,
01963
Symphonic 00180, 01665, 01904, 01913
Synco 01755, 00000, 01661, 00093, 01503, 01240, 00092,
01826
Syntax 01610, 01144, 01240
Manufacturer’s Code List
Lista de códigos del fabricante
English
The following tables show brand names (Brand)
and their corresponding code numbers (Code
No.).
Español
La siguiente tabla muestra los nombres de las
marcas (Brand) y el número de código
correspondiente (Code No.).
To cancel the process
Press any button other than one used for this setting.
The LED indicator turns off.
Assigning the TV channels to
the favorite buttons
After setting the manufacture’s code for TV,
without setting the manufacturer’s code for set
top box, go to the next step, “Assigning a
Channel.”
If you change all favorite button assignments
from set top box channels to TV channels,
perform the procedure of “Setting the
manufacturer’s code for TV” of “Setting the
Manufacturer’s Code,” and press “19999” in step
4. Then assign the TV channels. (It is
recommended that you clear unused favorite
buttons.)
Restoring the factory settings
You can clear all settings, and reset the RM-KZ1
to its factory settings.
1
While holding down SET, press numeric
button 0.
The LED indicator lights up.
2
Release both buttons.
The LED indicator flashes 3 times.
3
Press numeric button 1 to reset all settings,
including TV/set top box manufacturer codes
and assigned channels.
4
Press ENT.
When all settings have been reset, the LED
indicator flashes 3 times and turns off.
To cancel the process
Press any button other than is used for this setting.
The LED indicator turns off.
Help
If you have problems setting up or using the
RM-KZ1:
Carefully apply the setup procedure of “Setting
the Manufacturer’s Code.” If the RM-KZ1 does
not work, apply the procedure repeatedly, using
another code listed for your device. If you still
cannot operate the RM-KZ1, try the Search
function.
Aim the RM-KZ1 directly at the device.
Remove any obstacles in the path between the
RM-KZ1 and the device.
Be sure that the device has infrared remote
capability. For example, if your device did not
come with a remote control, it probably is not
capable of being controlled by the RM-KZ1.
The batteries are weak, or not inserted correctly.
Replace them with new ones or insert them
correctly.
If the favorite button does not seem to be
working:
– Check that the desired channel is properly
assigned (see “Assigning a Channel”).
– Try to insert an interval (see “If the channel
assigned to cannot be selected correctly
when you press ”).
If the volume button does not seem to be
working, carefully apply the procedure of
“Setting the volume button functions” in
“Additional Settings.”
If the power button does not seem to be
working, carefully apply the procedure of
“Setting the power button functions” in
“Additional Settings.”
Notes on setting the RM-KZ1
If the setting is incomplete, the LED indicator flashes
once and turns off. Start again from the beginning.
If no operations are performed for 3 minutes while
setting, the setting will be canceled, and must be
restarted.
For the customers in the U.S.A.
Customer Support Information
After you have read through this manual, if you still
cannot get the RM-KZ1 to work properly, call the Sony
Customer Support Helpline at 1-800-822-2217.
Specifications
Operating distance Approx. 11 m (36 ft) (varies depending on
devices of different manufacturers)
Power requirements
Two size AAA (LR03) alkaline batteries
(not supplied)
Battery life
Approx. 1 year when using size AAA
(LR03) alkaline batteries (varies
depending on frequency of button use -
up to approx. 50 times per day.)
Dimensions
Approx. 52 mm × 168 mm × 31 mm
(2
1
/
8
in × 6
5
/
8
in × 1
1
/
4
in) (w/h/d)
Mass
Approx. 92 g (3.2 oz) (not including
batteries)
Design and specifications are subject to change without
notice.
Loading ...
