en Safety
2
Table of contents
1 Safety......................................................................2
2 Preventing material damage .................................5
3 Childproof lock
1
.....................................................5
4 Environmental protection and saving energy......6
5 Installation and connection...................................6
6 Familiarising yourself with your appliance ..........8
7 Programmes .........................................................10
8 Additional functions ............................................12
9 Features................................................................12
10 Before using for the first time .............................16
11 Water softening system.......................................16
12 Rinse aid system..................................................18
13 Detergent ..............................................................19
14 Tableware .............................................................20
15 Basic operation ....................................................21
16 Basic settings.......................................................22
17 Cleaning and servicing........................................23
18 Troubleshooting...................................................25
19 Transportation, storage and disposal ................33
20 Customer Service.................................................34
21 Technical specifications......................................35
1 Safety
Please read the safety information to ensure
that you use the appliance safely.
1.1 General information
¡ Read this instruction manual carefully. Only
this will ensure you use the appliance
safely and efficiently.
¡ Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡ Check the appliance after unpacking it. Do
not connect the appliance if it has been
damaged in transit.
1.2 Intended use
Read the information on intended use to en-
sure that you use the appliance correctly and
safely.
Only use this appliance:
¡ For cleaning household tableware.
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 4000m above
sea level.
1.3 Restriction on user group
Avoid risks to children and vulnerable per-
sons.
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be
performed by children unless they are being
supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe installation
Follow these safety instructions when in-
stalling the appliance.
WARNING‒Risk of injury!
Improper installation may cause injury.
▶
When installing and connecting the appli-
ance, follow the instructions in the manual
and installation instructions.
WARNING‒Risk of electric shock!
Improper installation is dangerous.
▶
Connect and operate the appliance only in
accordance with the specifications on the
rating plate.
▶
Connect the appliance to a power supply
with alternating current only via a properly
installed socket with earthing.
▶
The protective conductor system of the do-
mestic electrical installation must be prop-
erly installed.
1
Depending on the appliance specifications
Safety en
3
▶
Never equip the appliance with an external
switching device, e.g. a timer or remote
control.
▶
When the appliance is installed, the mains
plug of the power cord must be freely ac-
cessible. If free access is not possible, an
all-pole isolating switch must be installed in
the permanent electrical installation accord-
ing to the installation regulations.
▶
When installing the appliance, check that
the power cable is not trapped or dam-
aged.
Cutting through the supply hose or immersing
the Aqua-Stop valve in water is dangerous.
▶
Never immerse the plastic housing in wa-
ter. The plastic housing on the supply hose
contains an electric valve.
▶
Never cut through the supply hose. The
supply hose contains electric power cables.
WARNING‒Risk of fire!
It is dangerous to use an extended power
cord and non-approved adapters.
▶
Do not use extension cables or multiple
socket strips.
▶
If the power cord is too short, contact Cus-
tomer Service.
▶
Only use adapters approved by the manu-
facturer.
WARNING‒Risk of injury!
Hinges move when opening and closing the
appliance door and can cause injury.
▶
If built-under or integrable appliances are
not in a cavity so that one side is access-
ible, the hinge area must be covered at the
side. Covers are available from Customer
Service or specialist outlets.
WARNING‒Risk of tipping!
Improper installation may cause the appliance
to tip up.
▶
Only install built-under or integrable appli-
ances under a continuous worktop that is
securely connected to adjacent cabinets.
WARNING‒Risk of burns!
If the appliance is not installed properly, this
may result in burns.
▶
With free-standing appliances, ensure that
they are installed with the back panel
against a wall.
1.5 Safe use
WARNING‒Risk of serious harm to
health!
Failure to comply with safety instructions and
directions for use on packagings of detergent
and rinse aid products may cause serious
harm to health.
▶
Follow the safety instructions and directions
for use on the packagings of detergent and
rinse aid products.
WARNING‒Risk of explosion!
Adding solvents to the interior of the appli-
ance may cause explosions.
▶
Never add solvents to the interior of the ap-
pliance.
Highly caustic alkaline or highly acidic clean-
ing agents in conjunction with aluminium parts
in the interior of the appliance may cause ex-
plosions.
▶
Never use highly caustic alkaline or highly
acidic cleaning agents, in particular com-
mercial or industrial products, in conjunc-
tion with aluminium parts (e.g. grease filters
of extractor hoods or aluminium pans), e.g.
for the Machine Care programme.
WARNING‒Risk of injury!
Leaving the appliance door open may result
in injury.
▶
Only open the appliance door to load or
unload tableware in order to prevent acci-
dents, e.g. through tripping.
▶
Do not sit or stand on the appliance door
when open.
Knives and utensils with sharp points can
cause injuries.
▶
Arrange knives and utensils with sharp
points in the cutlery basket with the points
downwards, on the knife shelf or in the cut-
lery drawer.
WARNING‒Risk of scalding!
If you open the appliance door while the pro-
gramme is running, hot water may splash out
of the appliance.
▶
Open the appliance door carefully if the
programme is still running.
WARNING‒Risk of tipping!
Overfilling the Baskets may cause the appli-
ance to tip up.
en Safety
4
▶
Never overfill the Baskets with free-standing
appliances.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric
shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat
or humidity.
▶
Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the insulation of the power cord is dam-
aged, this is dangerous.
▶
Never let the power cord come into contact
with hot appliance parts or heat sources.
▶
Never let the power cord come into contact
with sharp points or edges.
▶
Never kink, crush or modify the power
cord.
1.6 Damaged appliance
Follow the safety instructions if the appliance
is damaged.
WARNING‒Risk of electric shock!
If the appliance or the power cord is dam-
aged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked
or fractured surface.
▶
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶
If the appliance or the power cord is dam-
aged, immediately unplug the power cord
or switch off the fuse in the fuse box and
turn off the water tap.
▶
"Call Customer Service." →Page34
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
▶
Only use genuine spare parts when repair-
ing the appliance.
▶
If the power cord of this appliance is dam-
aged, it must be replaced with a special
connection cable, which is available from
the manufacturer or his Customer Service.
1.7 Risk to children
Follow the safety instructions if there are chil-
dren in your home.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶
Keep packaging material away from chil-
dren.
▶
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
WARNING‒Risk of harm to health!
Children can lock themselves in the appli-
ance, thereby putting their lives at risk.
▶
With redundant appliances, unplug the
power cord. Then cut through the cord and
damage the lock on the appliance door
beyond repair so that the appliance door
will no longer close.
WARNING‒Risk of crushing!
With higher-level appliances, children can be-
come crushed between the appliance door
and cabinet doors underneath.
▶
Keep an eye on children when opening and
closing the appliance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical
burns to the mouth, throat and eyes.
▶
Keep children away from detergent and
rinse aid products.
▶
Keep children away from the appliance
when open. The water in the interior of the
dishwasher is not drinking water. It may
contain residues of detergents and rinse
aid.
WARNING‒Risk of injury!
Children may get their fingers caught in the
slots of the tablet collecting tray and injure
themselves.
▶
Keep children away from the appliance
when open.
Preventing material damage en
5
WARNING‒Risk of suffocation!
Children may become trapped in the appli-
ance and suffocate.
▶
Use the childproof lock if fitted.
▶
Never let children play with or operate the
appliance.
1.8 Safety systems
Protect children from possible hazards result-
ing from the appliance.
Depending on the features of the model, the
appliance comes with a
→"Childproof lock", Page5.
2 Preventing material damage
2.1 Safe installation
Follow the instructions when installing the appliance.
ATTENTION!
Improper installation of the appliance may cause dam-
age.
▶
If the dishwasher is installed above or below other
domestic appliances, follow the information on in-
stallation in combination with a dishwasher in the in-
stallation instructions for the individual appliances.
▶
If there is no information or if the installation instruc-
tions do not include the relevant information, contact
the manufacturer of these appliances to check that
the dishwasher can be installed above or below
these appliances.
▶
If no information is available from the manufacturer,
the dishwasher should not be installed above or be-
low such appliances.
▶
To ensure the safe operation of all domestic appli-
ances, continue following the installation instructions
for the dishwasher.
▶
Do not install the dishwasher under a hob.
▶
Do not install the dishwasher near heat sources,
e.g. radiators, heat storage tanks, ovens or other ap-
pliances that generate heat.
Modified or damaged water hoses may result in mater-
ial damage and damage to the appliance.
▶
Never kink, crush, modify or cut through water
hoses.
▶
Only use the water hoses supplied with the appli-
ance or genuine spare hoses.
▶
Never re-use water hoses that have been used be-
fore.
If the water pressure is too high or too low, this may
impair functioning of the appliance.
▶
Make sure that the water pressure in the water sup-
ply system is min. 50kPa (0,5bar) and max.
1000kPa (10bar).
▶
If the water pressure exceeds the maximum value
specified, a pressure-reducing valve must be in-
stalled between the drinking water connection and
the hose set of the appliance.
2.2 Safe use
Follow the instructions when using the appliance.
ATTENTION!
Escaping water vapour can damage fitted units.
▶
When the programme ends, leave the appliance to
cool down for a while before opening the door.
Special salt can damage the tub due to corrosion.
▶
To make sure that any special salt that escapes is
washed out of the tub, add the special salt to the
dispenser for special salt immediately before the
programme starts.
Detergent may damage the water softening system.
▶
Only fill the dispenser of the water softening system
with special dishwasher salt.
Unsuitable cleaning agents may damage the appliance.
▶
Do not use a steam cleaner.
▶
So as not to scratch the finish on the appliance, do
not use sponges with a rough surface or abrasive
cleaning agents.
▶
To prevent corrosion, do not use sponge cloths on
dishwashers with a stainless steel front or rinse
such cloths thoroughly several times before using
them for the first time.
3 Childproof lock
1
The childproof lock lets you protect children from pos-
sible hazards resulting from the appliance.
Depending on the features of the model, the appliance
comes with a door lock.
3.1 Door lock
The door lock is a mechanical safety system and
makes it more difficult to open the appliance door.
You can activate or deactivate the door lock.
WARNING‒Risk of suffocation!
Children may become trapped in the appliance and
thus suffocate.
▶
Activate the door lock and close the appliance door.
→"Opening appliance door", Page21
Activating the door lock
Note:The door lock remains activated until it is deactiv-
ated manually.
1.
Open the appliance door.
1
Depending on the appliance specifications
en Environmental protection and saving energy
6
2.
Pull the catch of the childproof lock forwards and
close the appliance door .
1
2
Deactivating the door lock
1.
Open the appliance door.
2.
Push the catch of the childproof lock to the right
and slide it backwards .
1
2
3.
Close the appliance door.
4 Environmental protection and saving energy
Help protect the environment by using your appliance
in a way that conserves resources and by disposing of
reusable materials properly.
4.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
Information about current disposal methods are
available from your specialist dealer or local author-
ity.
4.2 Saving energy
If you follow these instructions, your appliance will use
less electricity and less water.
Use the Eco 50° programme.
¡
The Eco 50° programme is energy efficient and en-
vironmentally friendly.
→"Programmes", Page10
If you do not have much tableware to wash, use the
additional Half Load function.
1
¡
The programme will adjust to a lower load and con-
sumption will be reduced.
→"Additional functions", Page12
4.3 AquaSensor
1
The AquaSensor is an optical measuring device (light
barrier) which measures the turbidity of the washing
water. You can save water with the AquaSensor.
Use of the AquaSensor depends on the programme. If
the soiling level is low, the washing water is used in the
next wash cycle, so reducing water consumption by
3-6 litres. If the soiling level is is greater, the washing
water is drained off and replaced with fresh water. In
the automatic programmes the temperature and run-
ning time are additionally adjusted to the level of soil-
ing.
5 Installation and connection
5.1 Scope of supply
After unpacking all parts, check for any damage in
transit and completeness of the delivery.
If you have any complaints, contact the dealer who
sold you the appliance or our Customer Service.
Note:The appliance was tested at the factory to check
it is in working order. It is possible that water has left
marks on the appliance. These marks will disappear
after the first wash cycle.
The delivery consists of the following:
¡ Dishwasher
¡ Instruction manual
¡ Installation instructions
¡ Warranty
1
¡ Installation material
¡ Steam guard plate
1
¡ Rubber apron
1
¡ Mains cable
¡ Quick reference guide
1
5.2 Installing and connecting the appliance
You can position your built-under or integrable appli-
ance in a fitted kitchen between wooden and plastic
walls. If you subsequently install your dishwasher as a
free-standing appliance, you must stop it from tipping
1
Depending on the appliance specifications
Installation and connection en
7
over, e.g. by screwing it to the wall or installing it under
a continuous worktop that is securely connected to ad-
jacent cabinets.
1.
"Follow the safety instructions." →Page2
2.
"Follow the instructions for electrical connection."
→Page7
3.
Check the "Scope of supply" →Page6 and the con-
dition of the appliance.
4.
Consult the installation instructions for the installa-
tion dimensions required.
5.
Make the appliance level using the height-adjustable
feet.
Make sure that the appliance is standing on the
floor securely.
6.
"Install the drainage connection." →Page7
7.
"Install the drinking water connection." →Page7
8.
Connect the appliance to the power supply.
5.3 Drainage connection
Connect your appliance to drainage connection so dirty
water is discharged via the wash cycle.
Installing the drainage connection
1.
Consult the installation instructions supplied for the
steps required here.
2.
Connect the wastewater hose to the outlet connec-
tion of the siphon using the enclosed parts.
3.
When doing so, check that the wastewater hose is
not kinked, crushed or twisted.
4.
Also check that there is no cover in the drainage
system preventing the wastewater from being dis-
charged.
5.4 Drinking water connection
Connect your appliance to a drinking water connection.
Installing the drinking water connection
Note:
¡ If you are replacing the appliance, you must use a
new water supply hose.
1.
Consult the installation instructions supplied for the
steps required here.
2.
Connect the appliance to the drinking water connec-
tion using the enclosed parts.
Observe the "Technical data" →Page35.
3.
When doing so, check that the drinking water con-
nection is not kinked, crushed or twisted.
5.5 Electrical connection
Connect your appliance to the power supply.
Connecting the appliance to the electricity supply
Notes
¡ Follow the "Safety instructions" →Page2.
¡ Connect the appliance to alternating current only, in
the range of 220 - 240V and 50Hz or 60Hz.
¡ Please note that the water safety system is only
functional if there is a power supply.
1.
Insert the non-heating appliance plug of the power
cable into the appliance.
2.
Insert the mains plug of the appliance into a nearby
socket.
The connection data for the appliance can be found
on the rating plate.
3.
Check that the mains plug is inserted properly.
en Familiarising yourself with your appliance
8
6 Familiarising yourself with your appliance
6.1 Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
Rating plate
Rating plate with "E number and FD number" →Page34.
The data you need for "Customer Service" →Page34.
2
Detergent dispenser
"Detergent" →Page19 is added to the detergent dispenser.
3
Bottom basket
"Bottom basket" →Page13
4
Dispenser for special salt
Add special salt for the "Water softening system" →Page16
to the dispenser for special salt.
1
Depending on the appliance specifications
Familiarising yourself with your appliance en
9
5
Lower spray arm The lower spray arm washes the tableware in the bottom bas-
ket.
If the tableware has not been washed properly, clean the spray
arms.
→"Cleaning spray arms", Page25
6
Tablet collecting tray During the wash cycle tablets automatically fall out of the de-
tergent dispenser into the tablet collecting tray where they can
fully dissolve.
7
Top basket
"Top basket" →Page12
8
Cutlery drawer
1
"Cutlery drawer" →Page14
9
EmotionLight
1
Interior lighting of the appliance.
→"Overview of basic settings", Page22
10
Etagere
"Etagere" →Page14
11
Upper spray arm The upper spray arm washes the tableware in the top basket.
If the tableware has not been washed properly, clean the spray
arms.
→"Cleaning spray arms", Page25
12
Filter system
"Filter system" →Page24
13
Cutlery basket
1
"Cutlery basket" →Page14
14
Dispenser for rinse aid
Add rinse aid for the "Rinse aid system" →Page18 to the
dispenser for rinse aid.
1
Depending on the appliance specifications
6.2 Controls
The controls are used to configure all functions of your appliance and to obtain information about the operating
status.
With some buttons you can perform different functions.
10
A B C
1 2 3 54 6 7
89
1
ON/OFF button
"Switching on the appliance" →Page21
"Switching off the appliance" →Page22
2
Programme buttons
"Programmes" →Page10
3
Water supply display
"Display for water supply lights up" →Page26
1
Depending on the appliance specifications
en Programmes
10
4
Special salt refill indicator
"Water softening system" →Page16
5
Rinse aid refill indicator
"Rinse aid system" →Page18
6
Programme buttons and additional functions
"Programmes" →Page10
"Additional functions" →Page12
7
Start button and reset button
"Starting the programme" →Page22
"Terminating the programme" →Page22
8
Timer programming
"Setting timer programming" →Page22
9
Door opener
1
"Opening the appliance door" →Page21
10
Display The display shows information about the remaining run-
ning time or the basic settings. You can change the ba-
sic settings via the display and the setting buttons.
→"Changing basic settings", Page23
1
Depending on the appliance specifications
7 Programmes
You can find an overview of the programmes that can
be selected here. Different programmes, which can be
found on the control panel of your appliance, are avail-
able depending on the appliance configuration.
The running time may vary depending on the pro-
gramme selected. The running time depends on the
water temperature, the quantity of dishes, the level of
soiling and the "Additional function" →Page12 selec-
ted. The running time will change if the rinse aid sys-
tem is switched off or rinse aid needs to be added.
The consumption values can be found in the quick ref-
erence guide. The consumption values relate to normal
conditions and a water hardness of 16-20°E. Differ-
ent influencing factors such as water temperature or
pipe pressure may result in deviations.
Programme Use Programme sequence Additional functions
Chef 70
Tableware:
¡ Washing pots and pans,
non-fragile tableware
and cutlery.
Level of soiling:
¡ Removing stubborn
burned or dried-on food
remnants containing
starch and protein.
When using powder deter-
gent, you can also apply a
little to the inside of the ap-
pliance door.
Intensive:
¡ PreRinse
¡ Cleaning 70°C
¡ Intermediate rinse
¡ Rinsing 72°C
¡ Drying
All
→"Additional functions",
Page12
Auto 45-65°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Sensor-controlled:
¡ Optimised by sensors
depending on the soil-
ing of the washing wa-
ter.
All
→"Additional functions",
Page12
Eco 50°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Most economical pro-
gramme:
¡ Pre-Rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 66°C
¡ Drying
All
→"Additional functions",
Page12
Programmes en
11
Programme Use Programme sequence Additional functions
Silence 50
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Reduced noise:
¡ PreRinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 65°C
¡ Drying
IntensiveZone
Half Load
HygienePlus
ExtraDry
Shine & Dry
→"Additional functions",
Page12
Glass 40°
Tableware:
¡ Cleaning delicate table-
ware, cutlery, temperat-
ure-sensitive plastics,
glasses and stemware
in the stemware basket.
Level of soiling:
¡ Removing lightly adher-
ing fresh food remnants.
Particularly gentle:
¡ PreRinse
¡ Cleaning 40°C
¡ Intermediate rinse
¡ Rinsing 60°C
¡ Drying
IntensiveZone
VarioSpeedPlus
Half Load
ExtraDry
Shine & Dry
→"Additional functions",
Page12
Quick 65°
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Time-optimised:
¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 70°C
¡ Drying
ExtraDry
Shine & Dry
→"Additional functions",
Page12
1 hr Programme
Tableware:
¡ Cleaning mixed table-
ware and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-on.
Time-optimised:
¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 70°C
¡ Drying
ExtraDry
Shine & Dry
→"Additional functions",
Page12
Quick 45°
Tableware:
¡ Cleaning delicate table-
ware, cutlery, temperat-
ure-sensitive plastics
and glasses.
Level of soiling:
¡ Removing lightly adher-
ing fresh food remnants.
Time-optimised:
¡ Cleaning 45°C
¡ Intermediate rinse
¡ Rinsing 55°C
ExtraDry
Shine & Dry
→"Additional functions",
Page12
PreRinse
Tableware:
¡ Cleaning all types of
tableware.
Level of soiling:
¡ Cold rinsing, intermedi-
ate cleaning.
Cold rinse suitable:
¡ Pre-Rinse
None
Easy Clean
- Machine Care 70°C None
7.1 Information for test institutes
Test institutes are provided with information for com-
parability tests, e.g. according to EN60436.
These are the conditions for conducting the tests, how-
ever they are not the results or consumption values.
E-mail enquiries to: [email protected]
The product number (E-Nr.) and the production number
(FD) are required here. They can be found on the rat-
ing plate on the appliance door.
en Additional functions
12
8 Additional functions
You can find an overview of the additional functions
that can be selected here. Different additional func-
tions, which can be found on the control panel of your
appliance, are available depending on the appliance
configuration.
Additional function Use
VarioSpeedPlus
¡ The running time is
shortened by 20% to 66%
depending on the washing
programme.
¡ Energy and water consump-
tion are increased.
Half Load
¡ Switch on with small loads.
¡ It is recommended adding
less detergent to the deter-
gent dispenser than for a full
machine load.
¡ The running time is
shortened.
¡ Energy and water consump-
tion are reduced.
HygienePlus
¡ To ensure a higher hygiene
status for the appliance and
dishes, the temperature is
raised and maintained for
an extra-long period.
¡ Especially suitable for clean-
ing chopping boards or
baby bottles.
¡ Continuous use of this func-
tion increases the hygiene
status.
¡ This will increase the run-
ning time and energy con-
sumption.
Additional function Use
IntensiveZone
¡ Switch on with mixed loads
containing tableware with
different soiling levels, e.g.
place very soiled pots and
pans in the bottom basket
and normally soiled table-
ware in the top basket.
¡ The spray pressure in the
bottom basket is increased
and the maximum pro-
gramme temperature held
longer. This will increase the
running time and energy
consumption.
ExtraDry
¡ For a better drying result the
final rinse temperature is in-
creased and the drying
phase extended.
¡ Especially suitable for drying
plastic parts.
¡ There is a slight increase in
energy consumption and the
running time is extended.
Shine & Dry
¡ To avoid marks and improve
drying, the quantity of water
is increased and the drying
phase extended.
¡ Energy consumption in-
creases.
¡ Use rinse aid.
9 Features
You can find an overview of the possible features of
your appliance and how to use them here.
These features depend on the model of your appliance.
9.1 Top basket
Arrange cups and glasses in the top basket.
a
Knife shelf
1
1
Depending on the appliance specifications
Features en
13
You can adjust the height of the top basket to make
room for larger items of tableware.
Adjusting top basket with side levers
To wash large items of tableware in the baskets, adjust
the shelf position of the top basket.
1.
Pull out the top basket.
2.
To prevent the basket from suddenly dropping
down, hold the side of the basket by the top edge.
3.
Press in the levers on the right and left on the out-
side of the basket.
The basket can then slip down slightly.
4.
Raise or lower the basket evenly to the right level.
→"Basket heights", Page15
Check that the basket is level on both sides.
5.
Slide the basket back in.
Adjusting top basket with pairs of rollers
To wash large items of tableware in the baskets, adjust
the shelf position of the top basket.
1.
Pull out the top basket.
2.
Remove the basket.
3.
Insert the basket at the right basket height.
→"Basket heights", Page15
Check that the basket is level on both sides.
4.
Slide the basket back in.
9.2 Bottom basket
Arrange pans and plates in the bottom basket.
a
Cutlery basket
1
Large plates up to a diameter of 31/34cm
1
can be ar-
ranged as shown.
1
Depending on the appliance specifications
en Features
14
9.3 Cutlery basket
Arrange cutlery in the cutlery basket, always without
sorting it and with the sharp points downwards.
9.4 Cutlery drawer
Arrange cutlery in the cutlery drawer.
Arrange cutlery with the points and sharp edges down-
wards.
You can reorganise the cutlery drawer to make more
space for longer/wider items of cutlery.
1
Reorganising cutlery drawer
1
You can fold down the side shelves and front prongs to
make more space for longer/wider items of cutlery.
1.
To fold down a side shelf, push the lever forwards
and fold down the side shelf .
2.
To fold down the front prongs, push the lever for-
wards and fold down the prongs .
1
2
3
Tip
If you want to return the cutlery drawer to the original
position, fold the side shelf back up until it clicks into
position.
9.5 Etagere
Use the etagere and space underneath for small cups
and glasses or for large items of cutlery, e.g. wooden
spoons or serving cutlery.
You can adjust the height of the etagere.
1
If you do not need the etagere, you can fold it up.
Adjusting etagere
1
You can adjust the height of the etagere.
1.
Position the etagere vertically and pull it upwards .
2
3
1
1
2
2.
Position the etagere at a slight angle and move to
the right height .
3.
Push the etagere down.
a The etagere clicks into position.
1
Depending on the appliance specifications
Features en
15
9.6 Folding prongs
Use the folding prongs to position tableware securely,
e.g. plates.
You can fold the prongs down to position pans, bowls
and glasses better.
1
Folding down prongs
1
If you do not need the prongs, fold them down.
1.
Push the lever forwards and fold down the
prongs .
1
2
2.
To use the folding prongs again, fold them back up.
a The folding prongs click in position.
9.7 Small items holder
Use the small items holder to position small items of
tableware, e.g. light plastic parts.
9.8 Knife shelf
Use the knife shelf for long, sharp objects and long
items of cutlery.
9.9 Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 22 cm 31 cm
2 max. ø 24.5 cm 27.5 cm
3 max. ø 27 cm 25 cm
Appliance height 81.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 16 cm 31 cm
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm
1
Depending on the appliance specifications
en Before using for the first time
16
Appliance height 86.5cm with cutlery basket
Level Top basket Bottom basket
1 max. ø 24 cm 34 cm
2 max. ø 26.5 cm 30.5 cm
3 max. ø 29 cm 28 cm
Appliance height 86.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 18 cm 34 cm
2 max. ø 20.5 cm 30.5 cm
3 max. ø 23 cm 28 cm
10 Before using for the first time
Configure the settings for initial start-up.
10.1 Performing initial start-up
On initial start-up or after a reset to the factory settings,
you will need to make settings.
Requirement:"The appliance has been installed and
connected." →Page6
1.
"Add special salt." →Page17
2.
"Add rinse aid." →Page18
3.
"Switch on the appliance." →Page21
4.
"Set the water softening system." →Page16
5.
"Set the amount of rinse aid to be dispensed."
→Page18
Tip:You can change these settings and other "Basic
settings" →Page22 at any time.
11 Water softening system
Hard water leaves limescale on the tub and tableware
and parts of the appliance may become blocked.
To ensure good dishwashing results, you can treat the
water with special salt and the water softening system.
To avoid damage to the appliance, water with a hard-
ness above 9 °E must be softened.
11.1 Overview of water hardness settings
You can find an overview of the water hardness values that can be selected here.
You can find out how hard your water is from your local water company or by using a water hardness tester.
Water hardness °E Hardness range mmol/l Setting value
0 - 8 Soft 0 - 1.1 H:00
9 - 10 Soft 1.2 - 1.4 H:01
11 - 12 Medium 1.5 - 1.8 H:02
13 - 15 Medium 1.9 - 2.1 H:03
16 - 20 Medium 2.2 - 2.9 H:04
21 - 26 Hard 3.0 - 3.7 H:05
27 - 38 Hard 3.8 - 5.4 H:06
39 - 62 Hard 5.5 - 8.9 H:07
Note:Set the water hardness determined on your appli-
ance.
→"Setting water softening system", Page16
With a water hardness of 0 - 8°E you can dispense
with special salt and switch off the water softening sys-
tem.
→"Switching off water softening system", Page17
11.2 Setting water softening system
Set the water hardness on your appliance.
1.
Determine the water hardness and the appropriate
setting value.
→"Overview of water hardness settings", Page16
2.
Press .
Water softening system en
17
3.
Hold programme button A and press re-
peatedly until the display shows H:xx.
4.
Release programme button A and .
a Programme button A flashes and the display shows
H:04.
5.
Press programme button C repeatedly until the right
water hardness has been set.
6.
Press to save the setting.
11.3 Special salt
You can use special salt to soften water.
Adding special salt
If the special salt refill indicator lights up, add special
salt to the dispenser for special salt just before the pro-
gramme starts. The amount of special salt required de-
pends on the water hardness: the higher the water
hardness, the greater the amount of special salt re-
quired.
ATTENTION!
Detergent may damage the water softening system.
▶
Only fill the dispenser of the water softening system
with special dishwasher salt.
Special salt can damage the tub due to corrosion.
▶
To make sure that any special salt that escapes is
washed out of the tub, add the special salt to the
dispenser for special salt immediately before the
programme starts.
1.
Unscrew the lid of the dispenser for special salt and
remove.
2.
On initial start-up: Fill the dispenser right up with wa-
ter.
3.
Note:Only use special salt for dishwashers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dispenser.
a
Funnel
1
Fill the dispenser right up with special salt. The wa-
ter in the dispenser is displaced and forced out.
4.
Place the lid back on the dispenser and turn to
close.
11.4 Switching off water softening system
Note:
To avoid damage to the appliance, only switch off the
water softening system in the following cases:
¡ The water hardness is max. 26°E and you are us-
ing combined detergents with salt replacement sub-
stances. According to manufacturers, combined de-
tergents with salt replacement substances can gen-
erally only be used up to a water hardness of 26°E
without adding special salt.
¡ The water hardness is 0 - 8°E. You do not need to
use special salt.
1.
Press .
2.
Hold programme button A and press re-
peatedly until the display shows H:xx.
3.
Release programme button A and .
a Programme button A flashes and the display shows
H:04.
4.
Press programme button C repeatedly until the dis-
play shows H:00.
5.
Press to save the setting.
a The water softening system is switched off and the
salt refill indicator is deactivated.
11.5 Regeneration of the water softening
system
In order to obtain fault-free function of the water soften-
ing system, the appliance performs reheating of the wa-
ter softening system at regular intervals.
Regeneration of the water softening system takes place
before the end of the main rinse cycle in all pro-
grammes. It will increase the run time and consumption
values, e.g. water and electricity.
Overview of consumption values with regeneration the water softening system
Here you can find an overview of the maximum additional running time and consumption values during regeneration
of the water softening system.
You can find the column applicable to your model in the quick reference guide according to its water consumption in
the Eco50° programme.
1
Depending on the appliance specifications
en Rinse aid system
18
Water consumption
in litres (depending
on model)
Regeneration of the
water softening sys-
tem after x rinse
cycles
Additional running
time in minutes
Additional water con-
sumption in litres
Additional power
consumption in kWh
6.5 / 6.7 8 7 5 0.05
7.5 / 7.7 7 7 5 0.05
9.5 6 7 5 0.05
above 10.5 5 7 5 0.05
The consumption values specified are laboratory meas-
urements determined in accordance with the currently
applicable standard and using the Eco 50° programme
and the factory value of the water hardness is set to 16
- 20°E.
12 Rinse aid system
You can use the rinse aid system and rinse aid to get
tableware and glasses rinsed perfectly without marks.
12.1 Rinse aid
For optimum drying results, use rinse aid.
Only use rinse aid for domestic dishwashers.
Adding rinse aid
If the rinse aid refill indicator lights up, top up with rinse
aid. Only use rinse aid for domestic dishwashers.
1.
Press the catch on the lid of the dispenser for rinse
aid and lift .
1
2
2.
Add rinse aid up to the max mark.
max
3.
If rinse aid spills out, remove it from the tub.
Spilled rinse aid can cause excessive frothing dur-
ing the wash cycle.
4.
Close the lid of the dispenser for rinse aid.
a The lid clicks into position.
12.2 Setting the amount of rinse aid
If there are streaks or water marks on tableware,
change the amount of rinse aid.
1.
Press .
2.
Hold programme button A and press re-
peatedly until the display shows H:xx.
3.
Release programme button A and .
a Programme button A flashes and the display shows
H:04.
4.
Press programme button A repeatedly until the dis-
play shows the value set at the factory r:05.
5.
Press programme button C repeatedly until the right
amount of rinse aid has been set.
– A low setting adds less rinse aid during the wash
cycle and reduces streaking on tableware.
– A higher setting adds more rinse aid during the
wash cycle, reduces water marks and improves
the drying result.
6.
Press to save the setting.
12.3 Switching rinse aid system off
If you find the rinse aid refill indicator irritating, e.g.
when using combined detergents with a rinse aid com-
ponent, you can switch the rinse aid system off.
Tip:The function of rinse aid is limited with combined
detergents. You will generally get better results using
rinse aid.
1.
Press .
2.
Hold programme button A and press re-
peatedly until the display shows H:xx.
3.
Release programme button A and .
a Programme button A flashes and the display shows
H:04.
4.
Press programme button A repeatedly until the dis-
play shows the value set at the factory r:05.
5.
Press programme button C repeatedly until the dis-
play shows r:00.
6.
Press to save the setting.
a The rinse aid system is switched off and the rinse
aid refill indicator is deactivated.
Detergent en
19
13 Detergent
Find out which detergents are suitable for your appli-
ance.
13.1 Suitable detergents
Only use detergents that are suitable for dishwashers.
Both separate and combined detergents are suitable.
For optimum washing and drying results, use separate
detergent, adding "Special salt" →Page17 and "Rinse
aid" →Page18 separately.
Modern, powerful detergents mainly use a low-alkaline
formulation with enzymes. Enzymes break down starch
and remove protein. Oxygen-based bleaching agents
are generally used to remove coloured marks, e.g. tea
or ketchup.
Note:Follow the manufacturer's instructions for each
detergent.
Detergent Description
Tabs Tabs are suitable for all clean-
ing functions and do not need
to be measured out.
With shorter Programmes tabs
sometimes do not dissolve en-
tirely and leave residues of de-
tergent. This may impair the
cleaning effect.
Powder detergent Powder detergent is recom-
mended for shorter Pro-
grammes.
The dosage can be adjusted to
the level of soiling.
Liquid detergent Liquid detergent works faster
and is recommended for
shorter Programmes without
PreRinse.
Sometimes liquid detergent
may leak out despite the deter-
gent dispenser being closed.
This is not a fault and is non-
critical if you remember the fol-
lowing:
¡ Only choose a programme
without PreRinse.
¡ Do not select timer pro-
gramming for starting the
programme.
The dosage can be adjusted to
the level of soiling.
Tip:Suitable detergents are available online via our
website or from "Customer Services" →Page34.
Separate detergents
Separate detergents are products that do not contain
components other than detergent, e.g. powder deter-
gent or liquid detergent.
With powder and liquid detergent the dosage can be
individually adjusted to the level of soiling of the table-
ware.
For better washing and drying results and to avoid
damage to the appliance, please additionally use "Spe-
cial salt" →Page17 and "Rinse aid" →Page18.
Combined detergent
Besides conventional separate detergents, a number of
products are available with additional functions. These
products contain not only detergent but also rinse aid
and salt replacement substances (3in1) and, depend-
ing on the combination (4in1, 5in1,...), additional com-
ponents such as glass protection or stainless steel
cleaner.
According to manufacturers, combined detergents gen-
erally only function up to a water hardness of 26°E.
With a water hardness above 26°E you will need to
add special salt and rinse aid. For the best washing
and drying results we recommend using special salt
and rinse aid from a water hardness of 17°E. If you
are using combined detergent, the washing pro-
gramme is adjusted automatically to ensure the best
possible washing and drying result.
13.2 Unsuitable detergents
Do not use detergent which could cause damage to
the appliance or present a risk to health.
Detergent Description
Hand washing-up li-
quid
Hand washing-up liquid can
cause increased frothing and
damage the appliance.
Detergent contain-
ing chlorine
Chlorine residue on tableware
may present a risk to health.
13.3 Information on detergents
Follow the instructions on detergents in everyday use.
¡ Detergents marked as "organic" or "ecological" (en-
vironmentally friendly) generally contain lower levels
of active agents or completely dispense with certain
substances. The cleaning effect may be restricted
here.
¡ Set the rinse aid and the water softening system to
the separate detergent or combined detergent in
use.
¡ According to manufacturers, combined detergents
with salt replacement substances can only be used
up to a certain water hardness, usually 26°E,
without adding special salt. For the best washing
and drying results we recommend using special salt
from a water hardness of 17°E.
¡ To prevent sticking, only touch detergents in a wa-
ter-soluble pouch with dry hands and only ever
place them in a dry detergent dispenser.
¡ Even if the rinse aid and special salt refill indicators
light up, washing programmes will run properly with
combined detergents.
¡ The function of rinse aid is limited with combined
detergents. You will generally get better results us-
ing rinse aid.
¡ Use tablets with a special drying performance.
13.4 Adding detergent
1.
To open the detergent dispenser, press the locking
latch.
en Tableware
20
2.
Add the detergent to the dry detergent dispenser.
15 ml
25 ml
50 ml
If you are using tablets, one is enough. Insert the
tablets in a horizontal position.
If you are using powder or liquid detergent, follow
the manufacturer's instructions and quantities for
dosage in the detergent dispenser.
20ml–25ml detergent is sufficient for normal soil-
ing. If tableware is only lightly soiled, slightly less
than the amount of detergent specified is usually
sufficient.
3.
Close the lid of the detergent dispenser.
a The lid clicks into position.
a The detergent dispenser will open automatically at
the optimum time during the programme. Powder or
liquid detergent will spread around the washing tank
and dissolve there. Tablets will fall into the tablet
collecting tray and dissolve in the right dosage. In
order to ensure that tablets can dissolve evenly, do
not place any other objects in the tablet collecting
tray.
14 Tableware
Only clean tableware that is suitable for dishwashers.
Note:Decorated glassware and parts made of alu-
minium or silver may fade or discolour with dishwash-
ing. Delicate types of glass may turn cloudy after a few
washing cycles.
14.1 Damage to glass and tableware
Avoid damage to glass and tableware.
Cause Recommendation
The following tableware is
not dishwasher-safe:
¡ Items of cutlery and
tableware made from
wood
¡ Decorated glassware,
antique and hand-craf-
ted tableware
¡ Plastic parts not resist-
ant to heat
¡ Tableware made from
copper or tin
¡ Tableware soiled with
ash, wax, lubricating
grease or paint
¡ Very small items of
tableware
Only put tableware in the
dishwasher if it is marked
as dishwasher-safe by the
manufacturer.
Glass and tableware was
not dishwasher-safe.
Only put glasses and
china in the dishwasher if
it is marked as dish-
washer-safe by the manu-
facturer.
The chemical composition
of the detergent causes
damage.
Use a detergent marked
as gentle on tableware by
the manufacturer.
Cause Recommendation
Highly caustic alkaline or
highly acidic cleaning
agents, in particular com-
mercial or industrial
cleaning agents, are not
suitable for dishwashers
in conjunction with alu-
minium.
If you are using highly
caustic alkaline or highly
acidic cleaning agents, in
particular commercial or
industrial cleaning agents,
do not put aluminium
parts in the dishwasher in-
terior.
The water temperature of
the programme is too
high.
Select a programme with
lower temperatures.
After the programme has
ended, take glassware
and cutlery out of the ap-
pliance without delay.
14.2 Arrange tableware
Arrange the tableware correctly to optimise the dish-
washing result and prevent damage to both the appli-
ance and tableware.
Tips
¡ Using the appliance allows you to save energy and
water compared to washing-up by hand.
¡ See our website for examples of how to load your
appliance efficiently, free of charge.
¡ To save energy and water, load the machine with
the number of place settings specified.
→"Technical specifications", Page35
Basic operation en
21
¡ For better washing and drying results, position items
with curves or recesses at an angle so the water
can run off.
1.
Remove large remnants of food from your table-
ware.
To save resources, do not pre-rinse tableware under
running water.
2.
Observe the following when arranging tableware:
– Put heavily soiled tableware in the bottom bas-
ket, e.g. pans. The more powerful the spray jet,
the better the dishwashing result will be.
– To prevent damage to tableware, arrange it so it
is stable and cannot tip over.
– To prevent injury, arrange cutlery with the points
and sharp edges downwards.
– Position containers with the openings facing
down so no water can collect in them.
– Do not block the spray arms - make sure that
they can turn freely.
– Do not place small parts in the tablet collecting
tray and do not block it with tableware so as not
to obstruct the lid of the detergent dispenser.
14.3 Removing tableware
WARNING‒Risk of injury!
Hot tableware can cause burns to the skin. When hot,
tableware is sensitive to shock, may crack and can res-
ult in injury.
▶
When the programme has ended, do not empty the
appliance until the tableware has cooled down for a
while.
1.
To prevent water dripping on the tableware, unload
it starting at the bottom and working up.
2.
Check the washing tank and accessories for soiling
and clean if necessary.
→"Cleaning and servicing", Page23
15 Basic operation
15.1 Opening appliance door
1.
If the childproof lock
1
is not activated, open the ap-
pliance door.
2.
If the childproof lock
1
is activated, press the catch of
the lock to the right and open the appliance door
.
2
1
15.2 Switching on the appliance
▶
Press .
The Eco 50° programme is set by default.
The Eco 50° programme is an especially environ-
mentally friendly programme and ideal for normally
soiled tableware. It is the most efficient programme
for the combination of energy/water consumption
for this type of tableware and evidences conformity
with the EU Ecodesign Directive.
If you do not perform any actions on the appliance
for 15 minutes, the appliance will automatically
switch off.
15.3 Setting a programme
To adjust the wash cycle to the soiling level of the
tableware, select a suitable programme.
▶
Press the right programme button.
→"Programmes", Page10
a The programme is set and the programme button
flashes.
15.4 Setting additional functions
You can set additional functions to complete the wash-
ing programme selected.
Note:The additional functions which can be used de-
pend on the programme selected.
→"Programmes", Page10
1
Depending on the appliance specifications
en Basic settings
22
▶
Press the button for the relevant additional function.
→"Additional functions", Page12
a The additional function is set and the additional
function button flashes.
15.5 Setting timer programming
You can delay the start of the programme by up to
24hours.
1.
Press .
a "h:01" appears in the display.
2.
Use or to set the required start time for the pro-
gramme.
3.
Press .
a This activates timer programming.
Tip:To deactivate timer programming, press or
repeatedly until "h:00" appears in the display.
15.6 Starting the programme
▶
Press .
a The programme has ended when the display shows
"0:00".
Notes
¡ If you want to add more tableware while the appli-
ance is running, do not use the tablet collecting tray
as a handle for the top basket. You might touch the
partially dissolved tablet.
¡ You can only change a programme when running if
you cancel it.
→"Terminate programme", Page22
¡ The appliance switches off automatically 1minute
after the end of the programme to save energy. If
you open the appliance door immediately after the
programme has ended, the appliance will switch off
after 4 seconds.
15.7 Interrupting programme
Note:When you open the appliance door once the ap-
pliance has heated up, leave the door slightly ajar for a
few minutes and then close it. This will help prevent ex-
cess pressure building up in the appliance and stop
the appliance door bursting open.
1.
Press .
a The programme is saved and the appliance
switches off.
2.
Press to resume the programme.
15.8 Terminate programme
To end a programme early or to switch from a pro-
gramme that has already started, you will need to can-
cel it first.
1.
Open the appliance door.
2.
Press for approx. 3seconds.
3.
Close the appliance door.
a The programme is cancelled and ends after approx.
1minute.
15.9 Switching off appliance
1.
Please note the information on "Safe use"
→Page5.
2.
Press .
3.
To prevent damage from dripping water, turn the
water tap off tight (not applicable to appliances with
Aqua-Stop).
Tip:If you press during the wash cycle, the pro-
gramme currently running will be interrupted. When you
switch the appliance back on, the programme contin-
ues automatically.
16 Basic settings
You can configure the appliance to meet your needs.
16.1 Overview of basic settings
The basic settings depend on the features of your appliance.
Basic setting Display text Selection Description
Water hardness H:04
1
H:00 - H:07 Set the water softening system to your wa-
ter hardness.
→"Setting water softening system",
Page16
Level H:00 switches the water softening
system off.
Rinse aid dispensing r:05
1
r:00 - r:06 Set the amount of rinse aid to be dis-
pensed.
→"Setting the amount of rinse aid",
Page18
Switch the rinse aid system off with level
r:00.
1
Factory setting (may vary according to model)
Cleaning and servicing en
23
Basic setting Display text Selection Description
Intensive drying d:00
1
d:00 - d:01 The temperature is increased during the fi-
nal rinse, which improves the drying result.
This may increase the run time slightly.
Note:Not suitable for delicate items of
tableware.
Switch Extra Dry on "d:01" or off "d:00".
Hot water A:00
1
A:00 - A:01 Set cold water or hot water connection.
Only set the appliance to hot water if this
can be prepared with little energy and a
suitable installation is available, e.g. solar
heating system with circulation line. The
water temperature should be at least
40°C and max. 60°C.
Switch hot water on "A:01" or off "A:00".
TimeLight S:01
1
S:00 - S:02 Switch TimeLight on or off.
While the programme is running, status in-
formation is projected onto the floor below
the appliance door relating to timer pro-
gramming, the programme or the time re-
maining. If the base panel is pulled for-
wards or if the appliance is installed at eye
level with the cabinet front fitted flush, the
display is not visible.
Level "S:00" switches TimeLight off.
InfoLight I:01
1
I:00 - I:01 Switch InfoLight on or off.
While the programme is running, a spot of
light is projected onto the floor below the
appliance door. This light will not be visible
if the appliance is installed at eye level
with the cabinet front fitted flush. If the ap-
pliance door is not completely closed, the
spot of light will flash. The programme has
ended when the spot of light is no longer
visible on the floor.
Level "I:00" switches InfoLightoff.
Tone volume b:02
1
b:00 - b:03 Adjustment of tone volume.
End of programme indicated by an audible
signal tone.
Level "b:00" switches the signal tone off.
1
Factory setting (may vary according to model)
16.2 Changing basic settings
1.
Open the appliance door.
2.
Press .
3.
Hold programme button A and press re-
peatedly until the display shows H:xx.
4.
Release programme button A and .
a Programme button A flashes and the display shows
H:04.
5.
Press programme button A repeatedly until the dis-
play shows the required setting.
6.
Press programme button C repeatedly until the dis-
play shows the right value.
You can change several settings.
7.
Press to save the setting.
8.
Close the appliance door.
17 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
17.1 Cleaning the tub
WARNING‒Risk of harm to health!
Using detergents containing chlorine may result in
harm to health.
▶
Never use detergents containing chlorine.
1.
Remove any coarse soiling in the interior with a
damp cloth.
2.
Add detergent to the detergent dispenser.
3.
Select the programme with the highest temperature.
→"Programmes", Page10
4.
"Start the programme without tableware."
→Page22
en Cleaning and servicing
24
17.2 Self-cleaning interior
1
To remove deposits, the appliance self-cleans the in-
terior at regular intervals.
The programme sequence is automatically adjusted for
self-cleaning, e.g. the cleaning temperature is briefly in-
creased. Consumption values, e.g. water and electri-
city, may also increase.
If the interior is no longer self-cleaned adequately and
deposits occur, see this information:
→"Cleaning the tub", Page23.
17.3 Cleaning products
Only use suitable cleaning products to clean your ap-
pliance.
→"Safe use", Page5
17.4 Tips on appliance care
Follow the tips on appliance care to make sure your
appliance functions properly at all times.
Action Benefit
Wipe the door seals, the
front of the dishwasher
and the control panel reg-
ularly using a damp cloth
and washing-up liquid.
This ensures the parts of
the appliance will remain
clean and hygienic.
If the appliance is not go-
ing to be used for a while,
leave the door slightly
ajar.
This will prevent unpleas-
ant odours.
17.5 Easy Clean
1
Deposits can cause your dishwasher to malfunction,
e.g. due to grease or limescale. To avoid such faults
and reduce odours, we recommend cleaning your ap-
pliance at regular intervals.
Easy Clean used in combination with commercially
available machine care products is a suitable pro-
gramme for cleaning your dishwasher.
Run Easy Clean without tableware if the indicator for
Easy Clean lights up on the control panel or if advised
to do so by the display. The indicator will go out after
you have run Easy Clean. If your appliance does not
have a reminder function, follow the directions for use
on the machine care products.
Performing Easy Clean
Run the Easy Clean programme if the indicator for
Easy Clean lights up on the control panel or if advised
to do so by the display.
Notes
¡ Run the Easy Clean programme without any table-
ware in the dishwasher.
¡ Only use suitable machine care products specially
designed for dishwashers and not dishwasher deter-
gent. Observe the manufacturer's instructions.
¡ Make sure that there are no aluminium parts in the
interior of the appliance.
¡ If you have not run Easy Clean after 3 washing
cycles, the indicator for Easy Clean will go out auto-
matically.
¡ Follow the safety instructions and the directions for
use on the packagings of the machine care
products.
1.
Remove any coarse soiling in the interior with a
damp cloth.
2.
Clean filters.
3.
Add the machine care product to the appliance.
4.
Press .
5.
Press .
a Easy Clean is run.
a As soon as machine care has finished, the indicator
for Easy Clean goes out.
17.6 Filter system
The filter system removes coarse soiling from the dish-
washing cycle.
1
2
3
1
Micro filter
2
Fine filter
3
Coarse filter
Cleaning filters
Soiling in the dishwashing water may block the filters.
1.
After each wash check the filters for residue.
2.
Turn the coarse filter anticlockwise and remove
the filter system .
‒ Check that no foreign objects fall into the sump.
1
2
1
Depending on the appliance specifications
Troubleshooting en
25
3.
Pull down the micro filter to remove.
4.
Press the locking catches together and lift the
coarse filter out .
1
2
5.
Clean the filter elements under running water.
Carefully clean the rim of dirt between the coarse
and the fine filter.
6.
Re-assemble the filter system.
Make sure that the locking catches on the coarse fil-
ter click into position.
7.
Insert the filter system into the appliance and turn
the coarse filter clockwise.
Make sure that the arrow markings match up.
17.7 Cleaning spray arms
Limescale and soiling in the dishwashing water may
block the nozzles and bearings on the spray arms.
Clean the spray arms regularly.
1.
Unscrew the upper spray arm and pull down to
remove .
1
2
2.
Pull up the lower spray arm to remove.
3.
Check the outlet nozzles on the spray arms for
blockages under running water and remove any for-
eign bodies.
4.
Insert the lower spray arm.
a The spray arm clicks into position.
5.
Insert the upper spray arm and screw it firmly in
place.
18 Troubleshooting
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
Customer Service. This will avoid unnecessary costs.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
Only use genuine spare parts when repairing the
appliance.
▶
If the power cord of this appliance is damaged, it
must be replaced with a special connection cable,
which is available from the manufacturer or his Cus-
tomer Service.
18.1 Appliance safety
Fault Cause and troubleshooting
Appliance door will not open or
cannot be opened easily.
Childproof lock is activated.
▶
"Open the appliance door." →Page21
en Troubleshooting
26
18.2 Error code / Fault display / Signal
Fault Cause and troubleshooting
E:12 lights up. Heating element is furred up.
1.
Descale the appliance.
2.
Operate the appliance with the Water softening system.
E:14 lights up. Water protection system is activated.
1.
Turn off the water tap.
2.
Call "Customer Service" →Page34.
E:15 lights up. Water protection system is activated.
1.
Turn off the water tap.
2.
Call "Customer Service" →Page34.
E:16 lights up. Water is continuously running into the appliance.
1.
Turn off the water tap.
2.
Call "Customer Service" →Page34.
E:18 or indicator for water supply
lights up.
Supply hose is kinked.
▶
Install the supply hose without kinks.
Water tap is turned off.
▶
Turn on the water tap.
Water tap is jammed or furred up.
▶
Turn on the water tap.
The flow rate must be at least 10 l/min when the water supply is open.
Filter in the water supply is blocked.
1.
Switch off the appliance.
2.
Pull out the mains plug.
3.
Turn off the water tap.
4.
Unscrew the water connection.
5.
Remove the filter from the supply hose
6.
Clean the filter.
7.
Re-insert the filter in the supply hose.
8.
Screw the water connection back on.
9.
Check the water connection for leaks.
10.
Restore the power supply.
11.
Switch the appliance on.
E:22 lights up.
1
Filters are soiled or blocked.
▶
Clean the filters.
→"Cleaning filters", Page24
1
Depending on the appliance specifications
Troubleshooting en
27
Fault Cause and troubleshooting
E:24 lights up. Wastewater hose is blocked or kinked.
1.
Reposition the wastewater hose without kinks.
2.
Remove residues.
Siphon connection is still sealed.
▶
Check the connection to the siphon and open if necessary.
Cover of the wastewater pump is loose.
▶
Secure the cover of the "Wastewater pump " →Page33 so it clicks into po-
sition.
E:25 lights up. Wastewater pump is blocked.
▶
Clean the wastewater pump.
→"Clean wastewater pump", Page33
Cover of the wastewater pump is loose
▶
Secure the cover of the "Wastewater pump " →Page33 so it clicks into po-
sition.
E:27 lights up. Mains voltage is too low.
This is not a fault on the appliance.
1.
Contact an electrician.
2.
Have the mains voltage and electrical installation checked by an electrician.
Another error code appears on
the display.
E:01 to E:30
A technical fault is present.
1.
Press .
2.
Unplug the appliance or switch off the fuse.
3.
Wait at least 2minutes.
4.
Insert the mains plug of the appliance in a socket or switch on the fuse.
5.
Switch the appliance on.
6.
If the problem occurs again:
‒ Press .
‒ Turn off the water tap.
‒ Pull out the mains plug.
‒ Contact "Customer Service" →Page34 and give the error code.
18.3 Washing results
Fault Cause and troubleshooting
Tableware is not dry. No rinse aid used or dosage set too low.
1.
Add "Rinse aid" →Page18.
2.
Set the amount of rinse aid to be dispensed.
Selected programme has no drying phase
▶
Select a programme with drying.
en Troubleshooting
28
Fault Cause and troubleshooting
Tableware is not dry. Water collects in recesses of the tableware or cutlery.
▶
Position tableware at an angle where possible.
The combined detergent used has a poor drying performance.
1.
Use rinse aid to improve drying performance.
2.
Use a different combined detergent with a better drying performance.
Extra Dry not activated to improve drying performance.
▶
Activate Extra Dry.
Tableware removed too early or drying process not yet ended.
1.
Wait until the programme ends.
2.
Only remove tableware 30minutes after the programme has ended.
Rinse aid used has a limited drying performance.
▶
Use a name-brand rinse aid.
Eco products may have limited effectiveness.
Plastic tableware is not dry. Not a fault. As plastic does not store heat so well, it also does not dry as well.
▶
No remedial action possible.
Cutlery is not dry. Cutlery not arranged properly in the cutlery basket or cutlery drawer.
1.
Arrange the cutlery properly.
→"Arrange tableware", Page20
2.
Arrange cutlery individually where possible.
3.
Avoid points of contact.
Appliance interior still wet after
wash cycle.
Not a fault. The condensation drying principle causes water droplets in the tub –
they are indeed desirable here. The moisture in the air condenses on the inside
walls, runs off and is pumped out.
No action required.
Remnants of food on tableware. Tableware was placed too close together.
1.
Arrange tableware with sufficient space in between.
The spray jets must reach the surfaces of the tableware.
2.
Avoid points of contact.
Basket is overfilled.
1.
Arrange tableware with sufficient space in between.
The spray jets must reach the surfaces of the tableware.
2.
Avoid points of contact.
Spray arm rotation is blocked.
▶
Arrange tableware so that it does not obstruct spray arm rotation.
Spray arm nozzles are blocked.
▶
Clean the "Spray arms" →Page25.
Filters are soiled.
▶
Clean the filters.
→"Cleaning filters", Page24
Troubleshooting en
29
Fault Cause and troubleshooting
Remnants of food on tableware. Filters are inserted incorrectly and/or not engaged.
1.
Insert the filters properly.
→"Filter system", Page24
2.
Engage the filters.
Washing programme selected too weak.
▶
Select a more intensive washing programme.
▶
Adjust the sensitivity of the sensors.
Tableware has been precleaned too intensely. The sensors chose a weaker pro-
gramme. Stubborn soiling cannot be entirely removed.
▶
Only remove large remnants of food and do not prerinse tableware.
Tall narrow receptacles in corner areas are not rinsed adequately.
▶
Do not position tall narrow receptacles at too great an angle or in corner
areas.
Top baskets on right and left are not set to same height.
▶
Set the top baskets on the left and right to the same level.
→"Top basket", Page12
Detergent residue in the appli-
ance
Lid of the detergent dispenser is blocked by items of tableware parts and will
not open.
1.
Arrange tableware in the top basket tableware so the tab collecting tray is
not obstructed by tableware.
→"Arrange tableware", Page20
Items of tableware are blocking the dispenser lid.
2.
Do not place tableware or fragrance dispensers in the tablet collecting tray.
The lid of the detergent dispenser is blocked by the tab and will not open.
▶
Position the tab in the detergent dispenser crosswise, not vertically.
Tabs are used in the quick or short programme. Dissolving time of the tab is not
attained.
▶
Select a more intensive Programme or use "Powder detergent" →Page19.
Washing effect and dissolving performance are reduced after a prolonged stor-
age time or detergent is very lumpy.
▶
Change your "detergent" →Page19.
Water marks on plastic parts. Due to laws of physics droplet formation on plastic surfaces is unavoidable.
After drying water marks are visible.
▶
Select a more intensive programme.
▶
Position tableware at an angle.
→"Arrange tableware", Page20
▶
Use rinse aid.
→"Rinse aid", Page18
▶
Set the water softening system higher.
Wipeable or water-soluble coat-
ings are present inside the appli-
ance or on the door.
Detergent substances are deposited there. These coatings cannot generally be
removed with chemicals.
▶
Change your "detergent" →Page19.
▶
Clean the appliance mechanically.
White coating is deposited in the appliance interior.
1.
Set the water softening system correctly.
In most cases you will need to increase the setting.
2.
Change your detergent if required.
Special salt dispenser is not screwed tight.
▶
Screw the special salt dispenser tight.
Stubborn white coatings are
present on tableware, inside the
appliance or the door.
Detergent substances are deposited there. These coatings cannot generally be
removed with chemicals.
▶
Change your "detergent" →Page19.
▶
Clean the appliance mechanically.
en Troubleshooting
30
Fault Cause and troubleshooting
Stubborn white coatings are
present on tableware, inside the
appliance or the door.
The hardness range is set incorrectly or the water hardness is greater than
62°E (8,9mmol/l).
▶
Set the "Water softening system" →Page16 to the water hardness or add
special salt.
3in1/organic/eco detergent is not effective enough.
▶
Set the "Water softening system" →Page16 to the water hardness and use
separate detergents (proprietary detergent, special salt, rinse aid).
Too little detergent is being used.
▶
Increase the amount of detergent used or change "Detergent " →Page19.
Washing programme selected too weak.
▶
Select a more intensive washing programme.
▶
Adjust the sensitivity of the sensors.
Tea residue or lipstick marks on
tableware.
Washing temperature is too low.
▶
Select a programme with a higher washing temperature.
Too little detergent is being used or is unsuitable.
▶
Use a suitable "Detergent " →Page19 and follow the manufacturer's instruc-
tions for the amount to be used.
Tableware has been precleaned too intensely. The sensors chose a weaker pro-
gramme. Stubborn soiling cannot be entirely removed.
▶
Only remove large remnants of food and do not prerinse tableware.
Coloured coatings (blue, yellow,
brown) that are difficult or im-
possible to remove are present
inside the appliance or on stain-
less steel tableware.
The formation of films is due to substances contained in vegetables (cabbage,
celery, potatoes, noodles, etc.) or tap water (manganese).
▶
Clean the appliance.
You can remove deposits with "Mechanical cleaning" →Page23 or a ma-
chine cleaning product. It may not always be possible to completely remove
deposits but they are harmless to health.
The formation of films is due to metal components on silver or aluminium table-
ware.
▶
Clean the appliance.
You can remove deposits with "Mechanical cleaning" →Page23 or a ma-
chine cleaning product. It may not always be possible to completely remove
deposits but they are harmless to health.
Coloured deposits (yellow, or-
ange, brown) that are easy to re-
move are present inside the ap-
pliance (mainly at the bottom).
The formation of films is due to ingredients of food remnants and tap water
(limescale) "soaplike".
1.
Check the setting of the water softening system.
→"Setting water softening system", Page16
2.
Add special salt.
→"Adding special salt", Page17
3.
If you are using combined detergents (tabs), activate the water softening sys-
tem.
Follow the information about detergents.
→"Information on detergents", Page19
Plastic parts inside the appliance
are discoloured.
Plastic parts inside the appliance may become discoloured during the life of the
dishwasher.
▶
Discolouration can come about and will not impair functioning of the appli-
ance.
Plastic parts are discoloured. Washing temperature is too low.
▶
Select a programme with a higher washing temperature.
Tableware has been precleaned too intensely. The sensors chose a weaker pro-
gramme. Stubborn soiling cannot be entirely removed.
▶
Only remove large remnants of food and do not prerinse tableware.
Removable streaks are present
on glasses, glassware with a
metallic appearance and cutlery.
Amount of rinse aid to be dispensed is set too high.
▶
Set the rinse aid system to a lower setting.
No rinse aid has been added.
▶
→"Adding rinse aid", Page18
Troubleshooting en
31
Fault Cause and troubleshooting
Removable streaks are present
on glasses, glassware with a
metallic appearance and cutlery.
Detergent residue is present in the final rinse. Lid of the detergent dispenser is
blocked by tableware items and will not open fully.
1.
Arrange tableware in the top basket tableware so the tab collecting tray is
not obstructed by tableware.
→"Arrange tableware", Page20
Items of tableware are blocking the dispenser lid.
2.
Do not place tableware or fragrance dispensers in the tablet collecting tray.
Tableware has been precleaned too intensely. The sensors chose a weaker pro-
gramme. Stubborn soiling cannot be entirely removed.
▶
Only remove large remnants of food and do not prerinse tableware.
▶
Adjust the sensitivity of the sensors.
Irreversible clouding of glass-
ware.
Glasses are not dishwasher-proof, only suitable for dishwashers.
▶
Use dishwasher-proof glasses.
▶
Avoid a lengthy steam phase (standing time after wash cycle ends).
▶
Use a programme with a lower temperature.
▶
Set the softening system to the water hardness.
▶
Use detergent with a glass protection component.
Rust spots on cutlery. Cutlery is not sufficiently rust-resistant. Knife blades are often more severely af-
fected.
▶
Use rust-resistant tableware.
Cutlery may also rust if washed together with rusting items.
▶
Do not wash rusting items.
Salt content in washing water is too high.
1.
Remove any spilled special salt from the tub.
2.
Screw the cap of the special salt dispenser on tight.
Detergent residue is present in
the detergent dispenser or the
tablet collecting tray.
Spray arms were blocked by tableware so detergent was not rinsed out.
▶
Check that the spray arms are not blocked and can rotate freely.
Detergent dispenser was damp when detergent was added.
▶
Only add detergent to a detergent dispenser when dry.
Excessive formation of foam oc-
curs.
Hand washing-up liquid is present in dispenser for rinse aid.
▶
Immediately add rinse aid to the dispenser.
→"Adding rinse aid", Page18
Rinse aid has been spilled.
▶
Remove the rinse aid with a cloth.
Detergent or appliance care product used causes excessive foaming.
▶
Change the brand of detergent.
18.4 Information on display panel
Fault Cause and troubleshooting
Special salt refill indicator lights
up.
Insufficient special salt.
▶
Add "Special salt" →Page17.
Sensor does not detect special salt tablets.
▶
Do not use special salt tablets.
Refill indicator for special salt
does not light up.
Water softening system is switched off.
▶
"Setting water softening system" →Page16
Refill indicator for rinse aid lights
up.
Insufficient rinse aid.
1.
Add "Rinse aid" →Page18.
2.
Set the amount of rinse aid to be dispensed.
Refill indicator for rinse aid does
not light up.
Rinse aid system is switched off.
▶
→"Setting the amount of rinse aid", Page18
en Troubleshooting
32
Fault Cause and troubleshooting
Display flashes. Appliance door is not closed properly.
▶
Close the appliance door.
‒ Arrange the tableware so that no parts project beyond the basket and pre-
vent the appliance door from closing properly.
18.5 Malfunctions
Fault Cause and troubleshooting
Water is left in the appliance at
the end of the programme.
Filter system or area under the filters is blocked.
1.
Clean the "Filters" →Page24.
2.
Clean the "Wastewater pump" →Page33.
Programme has not yet ended.
▶
Wait until the programme ends or cancel the programme with reset.
▶
→"Terminate programme", Page22
Appliance cannot be switched on
or operated.
Appliance functions have failed.
1.
Pull out the mains plug or switch off the fuse.
2.
Wait at least 2minutes.
3.
Connect the appliance to the power supply.
4.
Switch the appliance on.
Appliance does not start. The mains fuse has tripped.
▶
Check the relevant fuse.
Mains cable is not inserted.
1.
Check whether the socket works.
2.
Check whether the mains cable is properly inserted in the socket and on the
rear of the appliance.
Appliance door is not closed properly.
▶
Close the appliance door.
Programme starts automatically. You did not wait until programme ended.
▶
→"Terminate programme", Page22
Appliance stops during the pro-
gramme or cuts out.
Appliance door is not closed properly.
▶
Close the appliance door.
Power and/or water supply has been interrupted.
1.
Check the power supply.
2.
Check the water supply.
Top basket is pressing against inner door and preventing appliance door from
being closed securely.
▶
Check whether the rear panel of the appliance is being pressed in by a
socket or hose holder that has not been removed.
▶
Arrange the tableware so that no parts project beyond the basket and pre-
vent the appliance door from closing properly.
18.6 Mechanical damage
Fault Cause and troubleshooting
Appliance door cannot be
closed.
Door lock has been activated.
▶
Close the appliance door with greater force.
Door cannot be closed due to installation method.
▶
Check whether the appliance has been installed properly.
When closed, the appliance door, its decor or attached parts should not
knock against adjacent cabinets or the worktop.
Lid on the detergent dispenser
cannot be closed.
Detergent dispenser or lid are blocked by sticky detergent residue.
▶
Remove detergent residue.
Transportation, storage and disposal en
33
18.7 Noise
Fault Cause and troubleshooting
Filling valves making knocking
noises.
Caused by the domestic installation. No appliance fault present. Does not affect
functioning of the appliance.
▶
Can only be remedied in the domestic installation.
Knocking or rattling noise. Spray arm is striking tableware.
▶
Arrange tableware so that the spray arms do not strike tableware.
With a small load the water jets directly strike against the tub.
▶
Distribute the tableware evenly.
▶
Load the appliance with more tableware.
Light items of tableware move about during the wash cycle.
▶
Position light items of tableware securely.
18.8 Clean wastewater pump
Large remnants of food or foreign bodies can block the
wastewater pump. As soon as the washing water no
longer drains properly, the wastewater pump must be
cleaned.
WARNING‒Risk of injury!
Sharp and pointed objects or fragments of glass may
block the waste water pump and cause injury.
▶
Remove any foreign bodies carefully.
1.
Disconnect the appliance from the power supply.
2.
Remove the top and bottom basket.
3.
Remove the filter system.
4.
Scoop out any water.
Use a sponge if necessary.
5.
Prise off the pump cover using a spoon and grip it
by the crosspiece.
6.
Lift the pump cover inwards at an angle and re-
move.
7.
Remove any remnants of food and foreign bodies in
the area of the impeller.
8.
Insert the pump cover and press down .
1
2
a The pump cover clicks into position.
9.
Install the filter system.
10.
Insert the top and bottom basket.
19 Transportation, storage and disposal
You can find out here how to prepare your appliance
for transportation and storage. You will also find out
how to dispose of old appliances.
19.1 Removing the appliance
1.
Disconnect the appliance from the power supply.
2.
Turn off the water tap.
3.
Detach the drainage connection.
4.
Detach the drinking water connection.
5.
Loosen any screws fastening the appliance to cab-
inet parts.
6.
Remove the base panel if fitted.
7.
Pull the appliance out carefully, along with the hose
behind it.
19.2 Protect appliance from frost
If there is a risk of frost where the appliance will be
standing, e.g. in a holiday home, empty the appliance
completely.
▶
"Empty the appliance." →Page34
en Customer Service
34
19.3 Transporting the appliance
To avoid damage to the appliance, empty it before
transporting.
Note:Always transport the dishwasher upright to pre-
vent residual water getting into the machine's controls
and damaging the appliance.
1.
Remove tableware from the appliance.
2.
Secure loose parts.
3.
Turn on the water tap.
4.
"Switch on appliance." →Page21
5.
Select the programme with the highest temperature.
→"Programmes", Page10
6.
"Start the programme." →Page22
7.
To drain the appliance, terminate the programme
after approx. 4minutes.
→"Terminate programme", Page22
8.
"Switch off the appliance." →Page22
9.
Turn off the water tap.
10.
To empty the residual water out of the appliance,
detach the supply hose and let the water drain out.
19.4 Disposing of old appliance
Valuable raw materials can be reclaimed by recycling.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby
putting their lives at risk.
▶
With redundant appliances, unplug the power cord.
Then cut through the cord and damage the lock on
the appliance door beyond repair so that the appli-
ance door will no longer close.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
This appliance is labelled in accord-
ance with European Directive
2012/19/EU concerning used elec-
trical and electronic appliances
(waste electrical and electronic equip-
ment - WEEE).
The guideline determines the frame-
work for the return and recycling of
used appliances as applicable
throughout the EU.
20 Customer Service
If you have any queries, are unable to rectify faults on
the appliance yourself or if your appliance needs to be
repaired, contact Customer Service.
You can solve many problems yourself by consulting
the information on troubleshooting in these instructions
or on our website. If this is not the case, contact our
after-sales service.
With any warranty claims, we will make sure that your
appliance is repaired by trained after-sales technicians
using genuine spare parts, including after the manufac-
turer's warranty has expired.
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our after-
sales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
20.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the pro-
duction number (FD) on the appliance's rating plate.
The rating plate is located inside the appliance door.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
20.2 AQUA-STOP guarantee
1
In addition to warranty claims against the seller under
the purchase agreement and in addition to our manu-
facturer's warranty, we will provide a replacement un-
der the following conditions.
¡ If our Aqua-Stop system is defective and causes wa-
ter damage, we will make good the damage for
private users. To ensure protection from water dam-
age, the appliance must be connected to the power
supply.
¡ The liability guarantee is valid for the service life of
the appliance.
¡ A claim can only be made under the guarantee if
the appliance has been correctly installed and con-
nected with Aqua-Stop according to our instructions;
this also includes correctly fitting the Aqua-Stop ex-
tension (genuine accessory). Our guarantee does
not cover defective supply lines or fittings up to the
Aqua-Stop connection on the tap.
1
Depending on the appliance specifications
Technical specifications en
35
¡ If your appliance is fitted with Aqua-Stop, you can
leave your appliance unattended during operation
and the tap turned on afterwards. The tap only
needs to be turned off if you are away from home
for a long period, e.g. on holiday for several weeks.
21 Technical specifications
Facts and figures for your appliance can be found
here.
Weight Max.: 60kg
Voltage 220 - 240V, 50Hz or
60Hz
Power rating 2000 - 2400W
Fuse 10 - 16A
Power consumption Off mode/standby mode:
0.10W
Left-on mode: 0.10W
Networked standby: -W
Time in left-on mode:
0min
Time after which appli-
ance is switched to net-
worked standby mode: -
min
Complies with the latest
regulations (EU) for en-
ergy labels and eco-
design at the time of pla-
cing on the market.
Additional functions and
settings may increase
power consumption and
times.
Water pressure ¡ Min. 0.05MPa
(0.5bar)
¡ Max. 1MPa (10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.
Hot water max.: 60°C
Capacity 12-15place settings
This product contains light sources from energy effi-
ciency class G. These light sources are available as a
spare part and should only be replaced by trained spe-
cialist staff.
1
More information about your model can be found on-
line at https://energylabel.bsh-group.com
2
. This web
address is linked to the official EU EPREL product
database. At the time of printing its web address had
not yet been published. Please then follow the instruc-
tions on searching for models. The model identifier is
made up of the characters before the slash in the
product number (E-Nr.) on the rating plate. Alternatively
you can also find the model identifier in the first line of
the EU energy label.
1
Depending on the appliance specifications
2
Only applies to countries in the European Economic Area
Constructa-Neff Vertriebs-GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
*9001433602*
9001433602
010303
en( 642 MV)
