Kit Number Description
RAK204U NON-ELECTRICAL SUB-BASE
RAK204E15 265/277V 15A
RAK204E20 265/277V 20A
RAK204E30 265/277V 30A
RAK204D15P 230/208V 15A
RAK204D20P 230/208V 20A
RAK204D30P 230/208V 30A
RAK204D15PA 230/208V 15A
RAK204D15C 230/208V 15A
RAK204D20PA 230/208V 20A
RAK204D20C 230/208V 20A
RAK204D30PA 230/208V 30A
RAK204D30C 230/208V 30A
RAK205CW CHASEWAY
(For use with RAK204U)
RAK4002A JUNCTION BOX
RAK4002C JUNCTION BOX
Tools Needed
• 5/16" nut driver
• Pliers
• Slotted screwdriver
Important Notes
• This unit must be properly grounded.
• Read this instruction before installing the
sub-base to the molded or metal case.
• CAUTION: The sub-base must be assembled to
the case before securing the case in the wall.
• ELECTRICAL REQUIREMENTS:
1. Electrical wiring may enter the sub-base
through any of the knockout holes provided in
the sub-base bottom or rear.
2. Refer to the unit nameplate for branch circuit
requirements.
3. All wiring should be done in accordance with
the local electrical codes and regulations.
4. Not approved for aluminum wire application.
5. If electrical wiring is placed in or against
the sub-base enclosure, the sub-base must
be grounded. Grounding holes have been
provided in the back surface of the enclosure.
See diagram. Green grounding screws and
securing nuts are included.
Parts Included In Bag with Sub-Base
Type A
10 required
Type B
2 required
Type C
2 required
Type D
2 mounting clips
for metal case
Type E
2 mounting clips
for molded case
4 nuts
Chaseway
and cover
Installation Instructions
for your new
Before you begin - Read these instructions completely and carefully.
IMPORTANT – OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer – Be sure to leave these instructions with the Consumer.
Note to Consumer – Keep these instructions with your Owner’s Manual for future reference.
RAK204U, RAK204E15, RAK204E20,
RAK204E30, RAK204D15P, RAK204D20P,
RAK204D30P, RAK204D15PA, RAK204D15C,
RAK204D20PA, RAK204D20C, RAK204D30PA,
RAK204D30C
Sub-base
Pub No. 30-7774-6 03-16 GE
