WARNING: RISK OF FIRE
• To reduce the risk of severe injury or death, follow all installation
instructions.
$SSOLDQFHLQVWDOODWLRQPXVWEHSHUIRUPHGE\DTXDOL¿HGLQVWDOOHU
• Install the appliance according to these instructions and in accordance
with local codes.
• This appliance must be exhausted to the outdoors.
• Use only 4” rigid metal ducting for exhausting the clothes dryer to the
outdoors.
• DO NOTLQVWDOODFORWKHVGU\HUZLWKÀH[LEOHSODVWLFGXFWLQJPDWHULDOV
,I ÀH[LEOH PHWDO VHPLULJLG RU IRLOW\SH GXFW LV LQVWDOOHG LW PXVW EH
UL listed and installed in accordance with the instructions found
in “Connecting The Dryer To House Vent” on page 8 of this manual.
Flexible venting materials are known to collapse, be easily crushed,
DQGWUDSOLQW7KHVHFRQGLWLRQVZLOOREVWUXFWGU\HUDLUÀRZDQGLQFUHDVH
WKHULVNRI¿UH
• Do not install or store this appliance in any location where it could be
exposed to water and or weather.
6DYHWKHVHLQVWUXFWLRQV,QVWDOOHUV%HVXUHWROHDYHWKHVHLQVWUXFWLRQV
ZLWKWKHFXVWRPHU
NOTE: Installation and service of this appliance requires basic
mechanical and electrical skills. It is your responsibility to
FRQWDFWDTXDOL¿HGLQVWDOOHUWRPDNHWKHHOHFWULFDOFRQQHFWLRQV
Installation
Instructions
Unitized Electric
Washer/Dryer
Questions on Installation? Call: 1-800-GECARES (US) RU9LVLWRXU:HEVLWHDWwww.GEAppliances.com (US).
In Canada, call 800.561.3344 or visit www.GEAppliances.ca
BEFORE YOU BEGIN
Read these instructions completely and
carefully.
• IMPORTANT- Save these instructions for
local inspector’s use.
• IMPORTANT- Observe all governing codes
and ordinances.
• Note to Installer - %H VXUH WR OHDYH WKHVH
instructions with the customer.
• Note to Customer - Keep these instructions with
your Owner’s Manual for future reference.
%HIRUHWKHDSSOLDQFHLVUHPRYHGIURPVHUYLFHRU
discarded, remove the washer and dryer doors.
• Inspect the dryer exhaust outlet and straighten
the outlet walls if they are bent.
• Service information and the wiring diagram are
located at the access panel.
• Do not allow children on or in the appliance.
Close supervision of children is necessary when
the appliance is used near children.
• Install the appliance where the temperature is
above 50°F
&
for satisfactory operation of
the control system.
• Product failure due to improper installation is not
covered under the Warranty.
TOOLS YOU WILL NEED
Slip Pliers
Phillips Screwdriver
)ODWEODGH6FUHZGULYHU
µ1XWGULYHU
Level
GLOVES
SAFETY
GLASSES
APPLIANCE POWER
CORD KIT
(NOT PROVIDED)
4" DUCT
CLAMPS (2)
OR
4" SPRING
CLAMPS (2)
EXHAUST
HOOD
3/4" STRAIN
RELIEF
UL RECOGNIZED
4" DIA. METAL
ELBOW
DUCT TAPE
UL RATED
120/240V,30A
WITH 3 OR 4 PRONGS.
IDENTIFY THE PLUG
TYPE AS PER THE
HOUSE RECEPTACLE
BEFORE PURCHASING
LINE CORD.
4" DIA. FLEXIBLE METAL (SEMI-RIGID)
UL LISTED TRANSITION DUCT
(IF NEEDED)
KIT WX08X10077 (INCLUDES 2 ELBOWS)
4" DIA. METAL DUCT
(RECOMMENDED)
4" DIA. FLEXIBLE METAL (FOIL TYPE)
UL LISTED TRANSITION DUCT
(IF NEEDED.)
4" COVER PLATE (IF NEEDED)
(KIT WE1M454)
PARTS SUPPLIED
2 Rubber
Washers
6WDLQHU6FUHHQV
Rubber Washers
ZDVKHUVPD\EHLQZDWHUKRVHV
2 Washer Hoses
&DEOH7LH
MATERIALS YOU WILL NEED
233D1835P004
31-16728 12-14 GE Printed in Mexico
