38MAQ
Outdoor Unit Single Zone Ductless System
Sizes 09 to 30
Installation Instructions
NOTE: The unit image is for illustration purposes only. The
actual model may differ slightly.
NOTE: Read the entire instruction manual before starting the
installation.
TABLE OF CONTENTS
PAGE
SAFETY CONSIDERATIONS 2.........................
PARTS LIST 3.......................................
SYSTEM REQUIREMENTS 4...........................
DIMENSIONS − OUTDOOR 5..........................
CLEARANCES − OUTDOOR 5.........................
INSTALLATION TIPS 6................................
OUTDOOR UNIT INSTALLATION 6.....................
ELECTRICAL DATA 8................................
CONNECTION DIAGRAMS 8..........................
START−UP 10........................................
TROUBLESHOOTING 10..............................
