WASHING MACHINE EVOGT 14064D3
B1 B2 I V G D B3 A
C1 C2 C3 C4 C5 C6 H C7 p
A PROGRAMME SELECTOR
Use this control to select the desired wash
programme. Turn the selector (it can be
turned in both directions) so that the
programme is opposite the reference
indicator (p). The temperature selected will
depend on the programme. (See the
Programme
Table).
B1 SPIN SPEED SELECTOR
B2 WASH TEMPERATURE
B
3 DELAY START
C1 CHILDREN'S SAFETY
C2 PRE-WASH
C3 STAIN BUSTER
C4 STOP WITH WATER
C
5 AQUAPLUS (SENSITIVE KEY)
C
6 EASY IRON
C
7 DEGREE OF SOILING
G DOOR - PROGRAMME START
LIGHT
H START/PAUSE KEY
I KG. MODE LIGHT
D DELAY START LIGHT
V “DIGITAL” LCD
The display’s indicator system allows you to be
constantly informed about the status of the machine
p CONTROL POSITION INDICATOR
“Gentle Touch Opening” is an innovative braking system enabling the washing machine to be loaded safely and
easily. Thanks to the two buffers at each end, the drum can be opened in 2 seconds by lightly pressing the central
key.
This washing machine has a device that ensures that the drum is right-side-up and ready for loading/ unloading
clothes when the selected programme is completed.
IMPORTANT:
Do not use liquid detergent for programs with a prewash cycle and/or timed start.
