Philips BT6900P/00 Wireless Portable Speaker

User Manual - Transcript

• Page 1: Register your product and get support at wwwphilipscomsupport User manual
• Page 2 - English - : 1EN Contents 1 Important 1 Safety 1 Notice 1 2 Your Bluetooth speaker 3 Introduction 3 Whats in the box 3 Overview of the speaker 3 3 Get started 4 Turn ono 4 Check the battery level 4 Charge the builtin battery 4 4 Play from Bluetooth devices 6 Connect a Bluetooth device 6 Play from a connected Bluetooth device 6 Disconnect a device 7 Reconnect a device 7 Clear pairing information 7 Control your phone call 7 5 Other features 8 Listen to an external device 8 Adjust volume 8 Attach the lanyard cable 8 6 Speci cations 9 7 Trouble shooting 10 General 10 About Bluetooth device 10
• Page 3 - English - : 2 EN 1 Important Safety Warning Never remove the casing of this speaker Never place this speaker on other electrical equipment Keep this speaker away from direct sunlight naked ames or heat Only use attachments or accessories specied by the manufacturer The battery shall not be exposed to excessive heat such as sunshine re or the like Do not place any sources of danger on the speaker eg lighted candles The speaker can meet IP57 waterproof standard only when the USBAUDIO IN socket cover is covered seamlessly The operation temperature of the product is from 10 C to 40 C For safety reasons the battery will not be charged if the battery temperature is below 0 C or above 40 C If your speaker gets wet clean with a soft dry cloth and then let it dry completely in a wellventilated place before use next time Note The type plate is located on the left side of the speaker Notice Any changes or modications made to this device that are not expressly approved by Gibson Innovations may void the users authority to operate the equipment Compliance Hereby Gibson Innovations declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 19995EC You can nd the Declaration of Conformity on wwwphilipscomsupport Care of the environment Disposal of your old product and battery Your product is designed and manufactured with high quality materials and components which can be recycled and reused This symbol on a product means that the product is covered by European Directive 201219EU This symbol means that the product contains a builtin rechargeable battery covered by European Directive
• Page 4 - English - : 3EN 201356EU which cannot be disposed of with normal household waste We strongly advise you to take your product to an ocial collection point or a Philips service centre to have a professional remove the rechargeable battery Inform yourself about the local separate collection system for electrical and electronic products and rechargeable batteries Follow local rules and never dispose of the product and rechargeable batteries with normal household waste Correct disposal of old products and rechargeable batteries helps prevent negative consequences for the environment and human health Caution Removal of the builtin battery invalidates the warranty and may destroy the product Always bring your product to a professional to remove the builtin battery Environmental information All unnecessary packaging has been omitted We have tried to make the packaging easy to separate into three materials cardboard box polystyrene foam buer and polyethylene bags protective foam sheet Your system consists of materials which can be recycled and reused if disassembled by a specialized company Please observe the local regulations regarding the disposal of packaging materials exhausted batteries and old equipment Trademark notice The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG Inc and any use of such marks by Gibson Innovations Limited is under license Other trademarks and trade names are those of their respective owners Qualcomm is a trademark of Qualcomm Incorporated registered in the United States and other countries Quick Charge is a trademark of Qualcomm Incorporated All Qualcomm Incorporated trademarks are used with permission
• Page 5 - English - : 4 EN 2 Your Bluetooth speaker Congratulations on your purchase and welcome to Philips To fully benet from the support that Philips oers register your product at wwwphilipscomwelcome Introduction With this speaker you can enjoy audio from Bluetoothenabled devices or other external audio devices through a 35mm audioin cable Whats in the box Check and identify the contents of your package Speaker USB lanyard cable Printed materials Quick Start Guide BT6900 Portable speaker Register your product and get support at wwwphilipscomsupport Overview of the speaker a Adjust volume b Battery level indicators Show the charging progress Show the battery level c Enter Bluetooth pairing mode Clear Bluetooth pairing information d Turn the speaker on or o Check the battery level Show the Bluetooth status e In Bluetooth mode press to pause or resume play In Bluetooth mode press twice to play the next track Respond to an incoming call through Bluetooth connection f AUDIO IN Connect an external audio device g Charge the builtin battery
• Page 6 - English - : 5EN 3 Get started Always follow the instructions in this chapter in sequence Turn ono To turn the speaker on press and hold for over two seconds The Bluetooth indicator starts ashing The battery level indicators light up briey The speaker beeps To turn the speaker o press and hold for two seconds again Note When there is no Bluetooth connection for 15 minutes or the battery is at low level the speaker turns o automatically to save power Check the battery level The speaker is powered by the builtin rechargeable battery After poweron the speaker shows the battery level immediately and the battery indication disappears in ve seconds To manually check the battery level briey press in either poweron or powero mode The dierent behavior of the four LEDs indicates dierent battery levels LED indication Battery power LED 1 LED 2 LED 3 LED 4 Full Solid white gt 8 Solid white O 50 80 Solid white O 20 50 Solid white O Low battery lt20 Flash red O Charge the builtin battery Note It takes you approximately three hours to fully charge the battery The micro USB socket is for charging only Rechargeable battery has a limited number of charge cycles Battery life and number of charge cycles vary by use and settings You can use a power adaptor compatible with Quick Charge 30 not supplied 5V 2A output recommended to speed up the charging process LED 1 LED 3 LED 4 LED 2
• Page 7 - English - : 6 EN When the battery level is low LED 1 ashes red as illustrated To charge the builtin battery Pull out the USB cable from the USB lanyard cable as illustrated Connect the speaker to AC power by using a power adaptor not supplied 5V 2A adaptor recommended System status Battery status System behavior On During charging Beep once without charging indication System status Battery status System behavior O During charging Shows the charging indication O Fully charged All LEDs are on then turn o after three minutes Check the charging progress During charging you can press to check the charging progress Battery level LED 1 LED 2 LED 3 LED 4 lt20 charged Flash white O 20 50 charged Solid white Flash white O 50 80 charged Solid white Flash white O gt 80 charged Solid white Flash white Fully charged Solid white turn o in 3 minutes
• Page 8 - English - : 7EN 4 Play from Bluetooth devices With this speaker you can listen to audio from Bluetoothenabled devices and control the incoming call through Bluetooth Connect a Bluetooth device Note Make sure that Bluetooth function is enabled on your device and your device is set as visible to all other Bluetooth devices Any obstacle between this speaker and a Bluetooth device can reduce the operational range Keep away from any other electronic device that may cause interference The operational range between this speaker and a Bluetooth device is approximately 30 meters 1 Make sure that the speaker is in Bluetooth pairing mode The Bluetooth LED ashes blue quickly If the LED ashes blue slowly press and hold for two seconds to enter pairing mode 2 On your Bluetooth device enable Bluetooth and search for Bluetooth devices that can be paired see the user manual of the device 3 Select Philips BT6900 displayed on your device for pairing If necessary input 0000 as the pairing password After successful connection the speaker beeps twice and the LED turns solid blue LED behavior Description Flashing blue quickly Ready for pairing Flashing blue slowly Reconnecting the last connected device Waiting for connection from the paired device Solid blue Connected Play from a connected Bluetooth device Note Music play pauses when there is an incoming call and resumes when your phone call ends
• Page 9 - English - : 8 EN After successful Bluetooth connection play audio on the connected device Audio streams from your Bluetooth device to the speaker To pause or resume play press To play the next track press twice Tip You can also use your Bluetooth device to control play Disconnect a device Press and hold for two seconds Turn o the speaker Disable Bluetooth on your device or Move the device beyond the communication range Reconnect a device When you turn on the speaker it tries to reconnect the last connected device automatically If not successful select Philips BT6900 on your Bluetooth menu to start reconnection Clear pairing information Press and hold for 10 seconds Control your phone call After Bluetooth connection you can control an incoming call with this speaker Button Function Press to answer an incoming call Press and hold for two seconds to reject an incoming call During a call press to end the current call During a call press and hold for two seconds to transfer the call to your mobile device
• Page 10 - English - : 9EN 5 Other features Listen to an external device With this speaker you can also listen to an external audio device such as an MP3 player Note Make sure that music playback through Bluetooth is stopped 1 Connect an audio input cable not supplied with a 35 mm connector on both ends to the AUDIO IN socket on this speaker and the headphone socket on the external device 2 Play audio on the external device refer to its user manual Tip When you start music streaming from a connected Bluetooth device the speaker switches to the Bluetooth source automatically Adjust volume During music playback press to increase or decrease volume Tip You can press and hold to increase or decrease volume continuously When the volume reaches the maximum the speaker beeps twice Attach the lanyard cable For easy carrying attach the supplied USB lanyard cable to this speaker as illustrated
• Page 11 - English - : 10 EN 6 Specif ications Note Product information is subject to change without prior notice Rated output power Amplier 10W RMS 1 THD Acoustic frequency response 8520000 Hz Speaker driver 1 x 2 full range 4 Ω Bass enhancement 2 x 2 passive radiator Bluetooth version V21 EDR Bluetooth supported proles AVRCP V14 A2DP V12 HFP V15 Bluetooth frequency band Output power 2402GHz 2480GHz ISM Band 4dBm Class 2 AUX input level 500mV100mV Durability IP57 Builtin battery Liion battery 36 V 2200 mAh Play time in battery mode Approx 10 hours Charging time Approx 3 hours with 5V 2A power adaptor Approx 15 hours with Quick Charge power adaptor USB charging 5V 2A Micro USB socket supporting Quick Charge 30 Dimensions Main unit W x H x D 160 x 71 x 72 mm Weight Main unit 031 kg
• Page 12 - English - : If the issue remains when the speaker is switched on hold both the and keys at the same time for 7 seconds until the speaker is o Then wait for the speaker to reset and switch on again automatically About Bluetooth device The audio quality is poor after connection with a Bluetoothenabled device The Bluetooth reception is poor Move the device closer to this product or remove any obstacle between them Fail to nd Philips BT6900 on your device for pairing Press and hold for two seconds to enter pairing mode and then try again Cannot connect with the device The Bluetooth function of the device is not enabled Refer to the user manual of the device for how to enable the function This product is already connected with another Bluetoothenabled device Disconnect that device and then try again The paired device connects and disconnects constantly The Bluetooth reception is poor Move the device closer to this product or remove any obstacle between them For some devices Bluetooth connection may be deactivated automatically as a powersaving feature This does not indicate any malfunction of this product 7 Trouble shooting Warning Never remove the casing of this device To keep the warranty valid never try to repair the system yourself If you encounter problems when using this device check the following points before requesting service If the problem remains unsolved go to the Philips Web page wwwphilipscomsupport When you contact Philips make sure that the device is nearby and the model number and serial number are available General No power Recharge the speaker No sound Adjust volume on this product Adjust volume on the connected device In AUDIO IN mode make sure that music playback through Bluetooth is stopped Make sure that your Bluetooth device is within the eective operational range No response from the speaker when pressing any key The speaker is in demo mode To exit this mode press and hold for 20 seconds EN
• Page 13 - English - : 2017 Gibson Innovations Limited All rights reserved This product has been manufactured by and is sold under the responsibility of Gibson Innovations Ltd and Gibson Innovations Ltd is the warrantor in relation to this product Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips NV and are used under license BT690000 UMV10
