VIZIO VF551XVT User Manual
Version 7/17/2009 1
www.VIZIO.com
Dear VIZIO Customer,
Congratulations on your new VIZIO VF551XVT television purchase. Thank
you for your support. For maximum benefit of your HDTV, please read
these instructions before making any adjustments, and retain them for
future reference. We hope you will experience many years of enjoyment
from your new VIZIO HDTV High Definition Television.
For assistance, please call (877) 668-8462 or e-mail us at
www.vizio.com.
To purchase or inquire about accessories and installation services for your
VIZIO HDTV, please visit our website at
www.vizio.com or call toll free at
(888) 849-4623.
We recommend you register your VIZIO HDTV either at our website
www.VIZIO.com or fill out and mail your registration card. For peace of
mind and to protect your investment beyond the standard warranty, VIZIO
offers on-site extended warranty service plans. These plans give
additional coverage during the standard warranty period. Visit our website
or call us to purchase a plan.
Write down the serial number located on the back of your HDTV.
__ __ __ __ __ __ __ __ __ __ __ __ __
Purchase Date _____________________
VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.
HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
and are trademarks of SRS Labs, Inc.
TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED ARE FOR
ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION MEETS VALUE AND OTHER VIZIO
TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC. PRODUCT SPECIFICATIONS ARE SUBJECT TO
CHANGE WITHOUT NOTICE OR OBLIGATION. © 2008 VIZIO INC. ALL RIGHTS RESERVED.
VIZIO VF551XVT User Manual
2
www.VIZIO.com
Important Safety Instructions
Your HDTV is designed and manufactured to operate within defined design limits, and misuse
may result in electric shock or fire. To prevent your HDTV from being damaged, the following
rules should be observed for the installation, use, and maintenance of your HDTV. Read the
following safety instructions before operating your HDTV. Keep these instructions in a safe place
for future reference.
x To reduce the risk of electric shock or component damage, switch off the power before
connecting other components to your HDTV.
x Unplug the power cord before cleaning your HDTV. A damp cloth is sufficient for cleaning your
HDTV. Do not use a liquid or a spray cleaner for cleaning your HDTV. Do not use abrasive
cleaners.
x Always use the accessories recommended by the manufacturer to insure compatibility.
x When moving your HDTV from an area of low temperature to an area of high temperature,
condensation may form in the housing. Wait before turning on your HDTV to avoid causing fire,
electric shock, or component damage.
x Use only with the cart, stand, tripod, bracket, or table specified by manufacturer or sold with your
HDTV. When a cart is used, use caution when moving the cart/HDTV combination to avoid injury
from tip-over. Do not place your HDTV on an unstable cart, stand, or table. If your HDTV falls, it
can injure a person and cause serious damage to your HDTV. Use only a cart or stand
recommended by the manufacturer or sold with your HDTV.
x A distance of at least 3 feet should be maintained between your HDTV and any heat source, such
as a radiator, heater, oven, amplifier etc. Do not install your HDTV close to smoke. Operating
your HDTV close to smoke or moisture may cause fire or electric shock.
x Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure
reliable operation of your HDTV and to protect it from overheating, be sure these openings are
not blocked or covered. Do not place your HDTV in a bookcase or cabinet unless proper
ventilation is provided.
x Never push any object into the slots and openings on your HDTV cabinet. Do not place any
objects on the top of your HDTV. Doing so could short circuit parts causing a fire or electric shock.
Never spill liquids on your HDTV.
x Your HDTV should be operated only from the type of power source indicated on the label. If you
are not sure of the type of power supplied to your home, consult your dealer or local power
company.
x Do not apply pressure or throw objects at your HDTV. This may compromise the integrity of the
display. The manufacturer’s warranty does not cover user abuse or improper installations.
x The power cord must be replaced when using different voltage than the voltage specified. For
more information, contact your dealer.
x Your HDTV is equipped with a three-pronged grounded plug (a plug with a third grounding
pin). This plug will fit only into a grounded power outlet. This is a safety feature. If
your outlet does not accommodate the three-pronged, have an electrician install
the correct outlet, or use an adapter to ground your HDTV safely. Do not defeat
the safety purpose of the grounded plug.
x When connected to a power outlet, power is always flowing into your HDTV. To
totally disconnect power, unplug the power cord.
x The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-isolated, dangerous
voltage within the inside of your HDTV that may be of
sufficient magnitude to constitute a risk of electric shock to
persons.
x The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and servicing instructions in the literature
accompanying your HDTV.
VIZIO VF551XVT User Manual
Version 7/17/2009 3
www.VIZIO.com
x Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
x The wall socket should be installed near your HDTV and easily accessible.
x Only power of the marked voltage can be used for your HDTV. Any other voltage than the
specified voltage may cause fire or electric shock
x Do not touch the power cord during lightning. To avoid electric shock, avoid handling the power
cord during electrical storms.
x Unplug your HDTV during a lightning storm or when it will not be used for long period of time.
This will protect your HDTV from damage due to power surges.
x Do not attempt to repair or service your HDTV yourself. Opening or removing the back cover may
expose you to high voltages, electric shock, and other hazards. If repair is required, contact your
dealer and refer all servicing to qualified service personnel.
x Keep your HDTV away from moisture. Do not expose your HDTV to rain or moisture. If water
penetrates into your HDTV, unplug the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.
x Do not use your HDTV if any abnormality occurs. If any smoke or odor becomes apparent, unplug
the power cord and contact your dealer immediately. Do not try to repair your HDTV yourself.
x Avoid using dropped or damaged appliances. If your HDTV is dropped and the housing is
damaged, the internal components may function abnormally. Unplug the power cord immediately
and contact your dealer for repair. Continued use of your HDTV may cause fire or electric shock.
x Do not install your HDTV in an area with heavy dust or high humidity. Operating your HDTV in
environments with heavy dust or high humidity may cause fire or electric shock.
x Follow instructions for moving your HDTV. Ensure that the power cord and any other cables are
unplugged before moving your HDTV.
x When unplugging your HDTV, hold the power plug, not the cord. Pulling on the power cord may
damage the wires inside the cord and cause fire or electric shock. When your HDTV will not be
used for an extended period of time, unplug the power cord.
x To reduce risk of electric shock, do not touch the connector with wet hands.
x Insert batteries in accordance with instructions. Incorrect polarities may cause the batteries to
leak which can damage the remote control or injure the operator.
x If any of the following occurs, contact the dealer:
o The power cord fails or frays.
o Liquid sprays or any object drops into your HDTV.
o Your HDTV is exposed to rain or other moisture.
o Your HDTV is dropped or damaged in any way.
o The performance of your HDTV changes substantially.
VIZIO VF551XVT User Manual
4
www.VIZIO.com
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during
a lightning storm or when it is left
unattended or unused for long periods
of time, unplug the TV from the wall
outlet and disconnect the antenna or
cable system.
Power Lines
Do not locate the antenna near
overhead light or power circuits, or
where it could fall into such power
lines or circuits.
Remember, the screen of the coaxial cable is intended to be connected to earth in the building
installation.
VIZIO VF551XVT User Manual
Version 7/17/2009 5
www.VIZIO.com
Advisory of the DTV Transition
The nationwide switch to digital television broadcasting will be complete on June 12, 2009, but your local
television stations may switch sooner. After the switch, analog-only television sets that receive TV
programming through an antenna will need a converter box to continue to receive over-the-air TV. Watch
your local stations to find out when they will turn off their analog signal and switch to digital-only
broadcasting. Analog-only TVs should continue to work as before to receive low power, Class A or
translator television stations and with cable and satellite TV services, gaming consoles, VCRs, DVD
players, and similar products.
For additional information, please contact the parties listed below, as appropriate:
FCC (US Federal Communications Commission)
http://www.fcc.gov/
Phone: 1-888-CALL-FCC (1-888-225-5322)
TTY: 1-888-TELL-FCC (1-888-835-5322)
Fax: 1-866-418-0232
E-mail: [email protected]
NTIA (National Telecommunications and Information Administration)
http://www.ntia.doc.gov/
1-888-DTV-2009
Listings of US Television Stations
http://www.high-techproductions.com/usTVstations.htm
Note: Your VIZIO HDTV is capable of receiving Digital Broadcasts, and no Digital Converter Box is
required.
VIZIO VF551XVT User Manual
6
www.VIZIO.com
Table of Contents
Important Safety Instructions.....................................................................................................................2
Television Antenna Connection Protection ...............................................................................................4
Advisory of the DTV Transition..................................................................................................................5
Setting Up Your HDTV ............................................................................................................................10
Wall Mounting your HDTV.......................................................................................................................10
Attaching the safety strap........................................................................................................................11
CHAPTER 1 BASIC CONTROLS AND CONNECTIONS..........................................................................12
Front Panel ..............................................................................................................................................12
Side Panel Controls.................................................................................................................................12
Rear Panel Connections..........................................................................................................................13
Right-Side Panel Connection ..................................................................................................................14
VIZIO Remote Control.............................................................................................................................15
Insertion of Batteries in the Remote Control........................................................................................17
Remote Control Range ........................................................................................................................17
VIZIO Remote Control Precautions .....................................................................................................17
CHAPTER 2 CONNECTING EQUIPMENT................................................................................................18
Which Video Connection Should I Use? .................................................................................................18
Connecting Your Cable or Satellite Box..................................................................................................19
Using HDMI (Best)...............................................................................................................................19
HDMI Connections for Cable or Satellite Boxes with DVI ...................................................................20
Using Component Video (Better).........................................................................................................20
Using S-Video (Compatible) ................................................................................................................21
Using Composite Video (Compatible)..................................................................................................21
Using Coaxial (Antenna) (Compatible) ................................................................................................21
Connecting Coaxial (RF) .........................................................................................................................22
Using Your Antenna or Digital Cable for Standard TV or Digital TV ...................................................22
Using the Antenna or Cable through Your VCR ..................................................................................22
Connecting Your DVD Player..................................................................................................................23
Using HDMI (Best)...............................................................................................................................23
HDMI Connections for DVD Players with DVI .....................................................................................23
Using Component Video (Better).........................................................................................................24
Using S-Video (Compatible) ................................................................................................................24
Using Composite (AV) Video (Compatible) .........................................................................................25
Connecting Your VCR or Video Camera.................................................................................................25
Connecting an External Receiver/Amp ...................................................................................................26
Optical Output of audio received with HD Programs...............................................................................26
Connecting a Computer...........................................................................................................................27
Preset PC Resolutions.........................................................................................................................28
Resolution through RGB Input.............................................................................................................28
CHAPTER 3 USING THE MULTI MEDIA PORT .......................................................................................29
Supported File Formats...........................................................................................................................29
Viewing Multimedia Content....................................................................................................................30
Picture Settings .......................................................................................................................................31
Slideshow Mode...................................................................................................................................31
Slideshow with Music...........................................................................................................................31
Music file browser ................................................................................................................................31
Audio Mode..........................................................................................................................................31
Repeat..................................................................................................................................................31
Sort By .................................................................................................................................................31
Duration ...............................................................................................................................................32
Slideshow Effect ..................................................................................................................................32
VIZIO VF551XVT User Manual
Version 7/17/2009 7
www.VIZIO.com
Thumbnail Size ....................................................................................................................................32
Info .......................................................................................................................................................32
Music Settings .........................................................................................................................................32
Sort By .................................................................................................................................................32
Play Mode ............................................................................................................................................32
Repeat..................................................................................................................................................32
Audio Mode..........................................................................................................................................32
Info .......................................................................................................................................................32
Video Settings ......................................................................................................................................... 33
Sort By .................................................................................................................................................33
Play Mode ............................................................................................................................................33
Repeat..................................................................................................................................................33
Picture Mode........................................................................................................................................33
Wide Format ........................................................................................................................................33
Audio Mode..........................................................................................................................................33
Info .......................................................................................................................................................33
CHAPTER 4 USING YOUR HDTV THE FIRST TIME................................................................................34
Setup Wizard ........................................................................................................................................... 34
Select Input Source .................................................................................................................................36
Fine Tuning the picture............................................................................................................................37
Setting the Time Zone ............................................................................................................................37
Watching a TV Program ..........................................................................................................................38
Adjusting Basic HDTV Settings ...............................................................................................................39
Program Information................................................................................................................................39
CHAPTER 5 ADVANCED ADJUSTMENT OF HDTV................................................................................40
Using the On Screen Display (OSD).......................................................................................................40
Picture Menu ........................................................................................................................................... 41
Picture Mode........................................................................................................................................41
Backlight ..............................................................................................................................................41
Brightness ............................................................................................................................................41
Contrast ...............................................................................................................................................41
Color.....................................................................................................................................................41
Tint .......................................................................................................................................................41
Sharpness............................................................................................................................................41
Advanced Video...................................................................................................................................42
Reset Picture Mode .............................................................................................................................43
Audio Menu ............................................................................................................................................. 43
Audio Mode..........................................................................................................................................43
Equalizer ..............................................................................................................................................43
Balance ................................................................................................................................................43
SRS TSHD...........................................................................................................................................43
SRS TruVolume ...................................................................................................................................43
Digital Audio Out ..................................................................................................................................43
Speakers..............................................................................................................................................44
Analog Audio Out.................................................................................................................................44
Lip Sync ...............................................................................................................................................44
Reset Audio Mode ...............................................................................................................................44
TV Menu ..................................................................................................................................................45
Tuner Mode..........................................................................................................................................45
Auto Search .........................................................................................................................................45
Partial Channel Search........................................................................................................................45
Skip Channel........................................................................................................................................45
MTS......................................................................................................................................................45
Time Zone............................................................................................................................................45
VIZIO VF551XVT User Manual
8
www.VIZIO.com
Daylight Saving....................................................................................................................................45
Channel Info.........................................................................................................................................46
Setup Menu .............................................................................................................................................46
Language .............................................................................................................................................46
PIP .......................................................................................................................................................46
Sleep Timer..........................................................................................................................................47
Tech Logo ............................................................................................................................................47
Wide.....................................................................................................................................................47
Input Naming........................................................................................................................................48
CC (Closed Caption)............................................................................................................................48
H/V Position .........................................................................................................................................49
Parental................................................................................................................................................49
System Info ..........................................................................................................................................51
System Reset.......................................................................................................................................51
CHAPTER 6 UNDERSTANDING VIEWING FEATURES..........................................................................52
Viewing Modes ........................................................................................................................................52
CHAPTER 7 PROGRAMMING THE VIZIO UNIVERSAL REMOTE CONTROL ......................................53
Using a Cable or Satellite Box Remote...................................................................................................53
Programming other devices ....................................................................................................................53
Programming your DVD Player ...........................................................................................................53
Programming your Home Theater System ..........................................................................................53
Programming your Cable or Satellite Set-Top Box..............................................................................54
Searching for Component Codes ........................................................................................................54
Remote Control Codes ........................................................................................................................ 55
CHAPTER 8 MAINTENANCE AND TROUBLESHOOTING ..................................................................... 65
Maintenance............................................................................................................................................65
Troubleshooting Guide ............................................................................................................................66
Telephone & Technical Support .............................................................................................................. 68
Compliance..............................................................................................................................................69
FCC Class B Radio Interference Statement ...........................................................................................69
SPECIFICATIONS ......................................................................................................................................70
LIMITED PRODUCT WARRANTY............................................................................................................. 72
VIZIO RETURN POLICY ............................................................................................................................73
Index........................................................................................................................................................75
VIZIO VF551XVT User Manual
Version 7/17/2009 9
www.VIZIO.com
Opening the Package
Your HDTV and its accompanying accessories are carefully packed in a cardboard carton that has been
designed to protect it from transportation damage. Once you have opened the carton, check that your
HDTV is in good condition and that all of the contents are included.
The screen can easily be scratched or broken, so handle your HDTV gently and never place your HDTV
with the screen facing downwards on a surface without protective padding.
IMPORTANT: Save the carton and packing material for future shipping.
Package Contents
x VIZIO VF551XVT
x VIZIO remote control VUR8M
x AA batteries for the remote control (2)
x Power cord
x Safety Strap
x Cleaning Cloth
x Quick
Setup Guide
x Registration Card
Additional certified accessories for your HDTV are sold separately:
x Wall mounts
x High Definition cables
x Extra or replacement remote control
VIZIO also offers installation services and extended warranty services for your HDTV.
To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our web site
at www.VIZIO.com or call us toll free at 888-VIZIOCE (888-849-4623)
Caution:
Do not apply pressure or throw objects at your HDTV. This may compromise the integrity
of the display. The manufacturer’s warranty does not cover user abuse or improper installations.
VIZIO VF551XVT User Manual
10
www.VIZIO.com
Setting Up Your HDTV
Note: We strongly recommend that two people perform the setup and assembly due to the weight and
size of the TV.
x Read this user manual carefully before installing your HDTV.
x The power consumption of your HDTV is about 154W (AVG). Use the included power cord. When
an extension cord is required, use one with the correct power rating. The cord must be grounded
and the grounding feature must not be compromised.
x Your HDTV should be installed on a flat surface to avoid tipping.
x For proper ventilation, you must allow space between the back of your HDTV and the wall.
x If you want to mount your HDTV on the wall, see below for additional information.
x Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the
service life of the electronic components.
x Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent
poor ventilation and excessive component damage.
VIZIO offers professional installation services. Contact VIZIO for more information on these services at
888-VIZIOCE (888-849-4623) or www.VIZIO.com.
Wall Mounting your HDTV
Your HDTV can be mounted on the wall for viewing.
If you choose to mount your HDTV on the wall,
follow the instructions below.
Remove the stand:
a. Disconnect the cables from your HDTV.
b. Place your HDTV face down on a soft, flat
surface to prevent damage to the screen.
c. Remove the eight (8) screws holding the stand,
then pull downward on the stand and lift the
stand off your HDTV.
Note: Use M8x 25M 1.25 pitch screws for wall
mounting.
VIZIO VF551XVT User Manual
Version 7/17/2009 11
www.VIZIO.com
Attaching the safety strap
When your HDTV is not mounted on the wall, use the included safety strap to attach the HDTV to the wall
to reduce the chance of the HDTV being pulled over. The Safety Strap should be used with common
sense practice such as ensuring that children (or adults) do not climb up, grabbing the top of the HDTV
and pulling it onto themselves.
1. Attach one end of the strap to the wall:
x If you have a drywall finish attach it to a stud, using a
washer underneath the screw head.
x If you have a solid wall you should use a lag bolt, again
using a washer under the nut.
2. Attach the other end of the Safety Strap to
one of the upper wall mounting holes on
the back of the HDTV, using a washer
under the screw head.
VIZIO VF551XVT User Manual
12
www.VIZIO.com
Chapter 1 Basic Controls and Connections
Front Panel
POWER ‘VIZIO’ LIGHT! The VIZIO name lights
white when powered on and orange when
powered off.
REMOTE CONTROL SENSOR ! Point the remote
control directly at this window for the best
response to the remote signal.
TECH LOGO ! Lights up in sequence highlighting
the technology features of the TV.
Side Panel Controls
POWER (
) ! Switch the HDTV on by pressing the button once. Press the button
again to turn the HDTV off.
MENU ! This button activates the On Screen Display (OSD). If a sub-menu is active,
pressing this button will proceed to the next level.
INPUT (ENTER) !
x Repeated pressing of this button steps through the input sources in the
following sequence: TV, AV1, AV2, Component1, Component2, RGB, HDMI1,
HDMI2, HDMI3, HDMI4 and HDMI SIDE. Once you have stepped through the
entire sequence, you will return to the beginning.
x If a sub-menu is active, pressing this button will return to the previous menu
level.
Additionally, when the OSD is active, this button confirms the menu function to be
adjusted.
CH
ʆ/ ʈ ! Use these buttons to step up or down the TV channels. While the OSD
is active, these buttons function as up and down controls in the OSD menus.
VOL
ʆ/ ʈ ! Use these buttons to increase or decrease the speaker volume. While
the OSD is active, these buttons function as left and right controls in the OSD menus.
VIZIO VF551XVT User Manual
Version 7/17/2009 13
www.VIZIO.com
Rear Panel Connections
1. HDMI 1, 2 & 3 ! Connect digital video devices such as DVD multimedia players or set top box
through these all digital connectors. There is an additional HDMI port on the side of the HDTV.
2. RGB PC ! Connect the video and audio from a computer here. A cable with a 1/8" mini plug
stereo connector at the end connecting to the TV is needed if sound is also transmitted with this
signal.
3. S-VIDEO/AV1 ! Connect composite or S-Video video devices, such as a VCR or video game.
Use the white and red connectors to connect the external audio from the same source. There is
an additional AV port on the side of the HDTV.
4. DTV/TV ! Connect to an antenna or digital cable (not a cable box) for Digital TV. For digital TV
stations in your area visit www.antennaweb.org.
5. AUDIO OUT !
a. (OPTICAL) The audio associated with the programming will be available on the SPDIF
Optical connector for connection to your home theater system.
b. (ANALOG L/R) Connect the audio from the HDTV to an external device, such as a home
theater system, external amplifier or stereo. Speakers can not be connected directly here.
6. HDMI 4 - Connect another digital video device such as a DVD multimedia player or set top box
through this all digital connector. For users who want to connect to a DVI enabled device, use a
DVI-HDMI cable and connect the analog audio output of the device to the L+R AUDIO here.
Your VIZIO Certified HDMI and HDMI-DVI cables are available for purchase from
www.VIZIO.com or by calling 888-VIZIOCE (888-849-4623).
7. COMPONENT 1 (YPb/CbPr/Cr with Audio L/R) ! Connect component video devices such as
a DVD Player or set top box here. There is an additional Component port on the side of the
HDTV.
VIZIO VF551XVT User Manual
14
www.VIZIO.com
Right-Side Panel Connection
1. AV2 ! Connect the secondary source for composite
video devices, such as a VCR or video game. Use
the white and red connectors to connect the external
audio from the same source, and then use the yellow
connector to connect the external video from the
same source.
Note: The red and white audio connectors are shared
between AV2 and COMPONENT2.
2. COMPONENT2 (YPb/CbPr/Cr with Audio L/R) -
Connect the secondary source for component video
devices such as a DVD Player or set top box here.
Note: The red and white audio connectors are shared
between AV2 and COMPONENT2.
3. HDMI SIDE - Connect another digital video device
such as a DVD multimedia player or set top box
through this all digital connector.
4. MEDIA PORT – Insert a FAT/FAT32 formatted USB
drive to view pictures, listen to music, or watch
movies.
VIZIO VF551XVT User Manual
Version 7/17/2009 15
www.VIZIO.com
VIZIO Remote Control
In addition to your HDTV, your Vizio remote control is programmable and supports up to three different
devices: a DVD player, a Home Theater System or Audio Amplifier, and a Cable or Set-Top Box. See
“Programming the VIZIO Universal Remote Control” at the back of this manual for step-by-step
instructions on how to program the remote.
SET – This button starts all programming of the Remote Control.
Remote LED – Blinks when the remote operates.
POWER (
) – Press this button to turn the TV on from the Standby
mode. Press it again to return to the Standby mode.
DVD – This button selects a DVD player that has been programmed to work
with this remote.
AUDIO – This button selects a Home Theater System or Audio Amplifier
that has been programmed to work with this remote.
CABLE – This button selects a cable or satellite set-top box that has been
programmed to work with this remote.
TV – Press this button to return TV mode. If the remote is not working, press
this button to return the functions back to TV.
NUMBER BUTTON PAD – Use these buttons to select a channel or enter a
password.
INPUT – Repeatedly pressing this button will step you through the input
sources in the following sequence: TV, AV1, AV2, Component1,
Component2, RGB, HDMI1, HDMI2, HDMI3, HDMI4 and HDMI SIDE. Once
you have stepped through the entire sequence, you will return to the
beginning.
- (DASH) – When selecting a digital channel directly, use this button
between the main and sub-channels. For example, channel 28-2 would be
selected by the button sequence 2, 8, DASH, 2.
MENU – Use this button to open the On-Screen Display (OSD) menu. Press
repeatedly to go back to the previous menu screen or to return to your
program.
INFO – This button displays program information.
OK
– Press this button to display the Channel List. In Multi Media mode,
press this button to select folders and files and to play/pause a slideshow,
playing music, or movies.
ʆʈʉ ʇ
-- These buttons are used to navigate the OSD menu. They will
also be used as value settings when the slide bar is shown on the screen
and option settings to turn a feature off or on.
GUIDE – This button displays detailed program information when viewing a
digital TV program.
EXIT
– Press this button to exit from the On-Screen Display (OSD) menu.
VOL Ÿ/ź – This button turns the volume up or down.
LAST – This button recalls the previously viewed channel.
MUTE – This button turns the sound on and off.
CH Ÿ/ź – This button changes the channels up or down.
VIZIO VF551XVT User Manual
16
www.VIZIO.com
PIP/A ! Pressing this button will activate the picture-in-picture feature. The screen will display the sub-
screen in the corner over the main screen. Pressing it again will display the POP (Picture Outside Picture)
option. This button also performs the same function as the “A” button on your Cable or Satellite box when
using the remote to control your pre-programmed Cable/Satellite Box DVR.
P.SIZE/B – Repeatedly press this button to set the size of the PIP screen to
small, medium, or large. This button also performs the same function as the “B”
button on your Cable or Satellite box when using the remote to control your pre-
programmed Cable/Satellite Box DVR.
P.INPUT/C ! Press the button to choose the input source for the PIP screen.
This button also performs the same function as the “C” button on your Cable or
Satellite box when using the remote to control your pre-programmed
Cable/Satellite Box DVR.
P.CH/D – Press this button change the channels in the PIP screen when TV is
selected as PIP Input. This button also performs the same function as the “D”
button on your Cable or Satellite box when using the remote to control your pre-
programmed Cable/Satellite Box DVR.
TV INPUT ! Press this button to select TV mode.
AV INPUT ! Press this button to select AV1 and AV2 (either Composite or S-
Video) input.
COMPONENT INPUT ! Press this button to select Component 1 and
Component 2 inputs.
HDMI INPUT ! Press this button to select the HDMI input. By pressing it
repeatedly you will go through all HDMI inputs in sequence.
WIDE/RECORD – This button cycles through the available screen formats:
Normal, Panoramic, Zoom, Full, and Stretch. This button also begins recording
when using the remote to control your pre-programmed DVD Player or
Cable/Satellite Box DVR.
SLEEP/PAUSE ! This button cycles through the sleep options from 30-120
minutes. This button also pauses playback when using the remote to control
your pre-programmed DVD Player or Cable/Satellite Box DVR.
MTS/PLAY ! This button selects Stereo, SAP, or Mono in standard TV mode
and alternate audio channels, where available when viewing digital channels.
This button also starts Playback when using the remote to control your pre-
programmed DVD Player or Cable/Satellite Box DVR.
CC/STOP ! Repeatedly press this button to select OFF, CC1, CC2, CC3, or
CC4 in standard TV mode and Service1 through Service6 when viewing a digital
channel. This button also Stops playback/recording when using the remote to
control your pre-programmed DVD Player or Cable/Satellite Box DVR.
MEDIA/PREV ! Press this button to view pictures, listen to music, or watch
movies on a USB drive connected to the Multi Media port on the side of the
HDTV. This button also skips to the previous track when using the remote to
control your pre-programmed DVD Player or Cable/Satellite Box DVR.
FREEZE/REV – Press this button to “Freeze-Frame” the current screen. Press this button again to
continue playing. This button also reverses playback when using the remote to control your pre-
programmed DVD Player or Cable/Satellite Box DVR.
AUDIO/FF – Press this button to switch the audio from the main screen to the sub-screen while in PIP or
POP mode. This button also fast forwards playback when using the remote to control your pre-
programmed DVD Player or Cable/Satellite Box DVR.
SWAP/NEXT– While in PIP/POP mode; pressing SWAP will switch the displays from the main screen to
the sub-screen or vice versa. This button also skips to the next chapter when using the remote to control
your pre-programmed DVD Player or Cable/Satellite Box DVR.
VIZIO VF551XVT User Manual
Version 7/17/2009 17
www.VIZIO.com
Insertion of Batteries in the Remote Control
Insert two AA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the
batteries with the (+) and (-) symbols inside the battery compartment. Re-attach the battery cover.
Precautionary Tips for Inserting the Batteries:
x Only use the specified AA batteries.
x Do not mix new and old batteries. This may result in
cracking or leakage that may pose a fire risk or lead to
personal injury.
x Inserting the batteries incorrectly may also result in
cracking or leakage that may pose a fire risk or lead to
personal injury.
x Dispose of the batteries in accordance with local laws and
regulations.
x Keep the batteries away from children and pets.
Remote Control Range
Point the remote control at the remote control sensor to transmit the commands.
Do not place any obstacles between the remote control and the receiver window.
The effective range of the remote control is approximately 30 feet (9.1 meters) from the front of the
receiver window, 30° to the left and right, 20° up and down.
VIZIO Remote Control Precautions
The remote control should be kept dry and away from heat sources. Avoid humidity.
If the TV responds erratically to the remote control or does not respond at all, check the batteries. If the
batteries are low or exhausted, replace them with fresh batteries.
When not using the remote control for a long period of time, remove the batteries.
Do not take the batteries apart, heat them, or throw them into a fire.
Do not subject the remote control to undue physical stress, such as striking or dropping it.
Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean, damp cloth.
VIZIO VF551XVT User Manual
18
www.VIZIO.com
Chapter 2 Connecting Equipment
Which Video Connection Should I Use?
The VIZIO HDTV has six different ways to connect your video equipment from a basic connection to the
most advanced for digital displays.
Connection
Quality (type)
Connector Description
Best
(digital)
HDMI provides an interface between any audio/video source, such as
a set-top box, DVD player, or A/V receiver and a digital television
(DTV), over a single cable.
Best
(digital)
- - - - - - - - - - -
Compatible
(analog)
Connect a digital or analog antenna cable or coaxial cable to watch TV
programming.
Best
(analog)
RGB PC (VGA) ! This is most commonly used for PC input.
Better
(analog)
Component - Component video provides a sharper image than
composite video and S-video because the three video signals are
transmitted via three separate channels.
Compatible
(analog)
S-Video (AV1) - Combining the three video signals into two channels,
S-Video provides a sharper image than Composite video, but is not as
good as Component video.
Composite (AV1 & 2) - All three video signals are combined into one
channel, thus making the image less sharp than Component or
S-Video.
VIZIO VF551XVT User Manual
Version 7/17/2009 19
www.VIZIO.com
SET TOP BOX
Connecting Your Cable or Satellite Box
You have four options for connecting your cable or satellite box to your HDTV: HDMI, Component,
Composite, or Coax (RF). Based on your home theater configuration, you can decide which option is the
right one for you. Refer to your set-top box user manual for more information about the video output
requirements or consult your cable or satellite operator.
Using HDMI (Best)
Cable and Satellite Boxes that have an HDMI digital interface should be connected to the HDMI input of
the HDTV for optimal results.
Note: To maintain the display quality, use a VIZIO certified HDMI cable. This cable is available in 6, 15,
and 30 foot lengths. See www.vizio.com or call 1-888-VIZIOCE (1-888-849-4623) for details.
1. Turn off the power to the HDTV and HDTV Set-Top Box.
2. Connect an HDMI cable to the HDMI output of your HDTV Set-Top Box and the other end to an
HDMI input on the back or side of the HDTV.
3. Turn on the power to the HDTV and HDTV Set-Top Box.
4. Select HDMI 1, HDMI 2, HDMI 3, HDMI 4 or HDMI SIDE using the INPUT button on the remote
control, or directly by pressing the HDMI button on the remote control.
Note:
x The HDMI input on the HDTV supports High-bandwidth Digital Content Protection (HDCP).
HDCP encrypts the transmission between the video source and the digital display for added
security and protection.
x If you are already using the HDMI1 input for another device, or you do not want to use the HDMI1
input for the Set-Top Box, you can connect the Set-Top Box to another HDMI connection.
x Refer to your HDTV Set-Top Box user manual for more information about the video output
requirements of the product or consult your cable or satellite operator.
VIZIO VF551XVT User Manual
20
www.VIZIO.com
SET TOP BOX
SET TOP BOX
HDMI Connections for Cable or Satellite Boxes with DVI
1. Turn off the power to the HDTV and HDTV Set-Top Box.
2. Using a HDMI-DVI cable, connect the DVI end to your HDTV Set-Top Box and the HDMI end
to the HDMI 4 input on the back of the HDTV.
3. Using an audio cable, connect the cable to the audio output connectors associated with the
DVI output on your HDTV Set-Top Box and connect the other end to the audio connectors
associated with the HDMI input on the back of the HDTV.
4. Turn on the power to the HDTV and HDTV Set-Top Box.
5. Select HDMI 4 using the INPUT button on the remote control, or directly by pressing the
HDMI button on the remote control.
Note:
x The HDMI input on the HDTV supports High-bandwidth Digital Content Protection (HDCP).
HDCP encrypts the transmission between the video source and the digital display for added
security and protection.
x Refer to your HDTV Set-Top Box user manual for more information about the video output
requirements of the product or consult your cable or satellite operator.
Using Component Video (Better)
1. Turn off your HDTV and set-top box.
2. Connect the component cables (green, blue, and red) from your set-top box to the
COMPONENT jacks on the back or side of your HDTV.
3. Connect the audio cables (white and red) from your set-top box to the adjacent
COMPONENT L and R Audio jacks on the back or side of your HDTV.
4. Turn on your HDTV and set-top box.
5. Select COMPONENT 1 or COMPONENT 2 using the INPUT button on the remote control, or
directly by pressing the COMPONENT button on the remote control.
VIZIO VF551XVT User Manual
Version 7/17/2009 21
www.VIZIO.com
Using S-Video (Compatible)
1. Turn off your HDTV and set-top box.
2. Connect the S-VIDEO cable from your set-top box to the S-VIDEO jack on the back of your HDTV.
3. Connect the audio cables (white and red) on your set-top box to the corresponding L and R
AUDIO jacks on the back of your HDTV.
4. Turn on your HDTV and set-top box.
5. Press AV on the remote control to view the content.
Using Composite Video (Compatible)
1. Turn off your HDTV and set-top box.
2. Connect the video cable (yellow) from your set-top box to the AV jack (yellow) on the back of your
HDTV.
3. Connect the audio cables (white and red) on your set-top box to the corresponding L and R
AUDIO jacks on the back of your HDTV.
4. Turn on your HDTV and set-top box.
5. Select AV1 using the INPUT button on the remote control, or directly by pressing the AV button
on the remote control.
Using Coaxial (Antenna) (Compatible)
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or digital cable to the DTV/TV
CABLE/ANTENNA connector on the back of the HDTV.
3. Turn on the power to the HDTV.
4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button
on the remote control.
SET TOP BOX
SET TOP BOX
SET TOP BOX
VIZIO VF551XVT User Manual
22
www.VIZIO.com
CABLE BOX
Connecting Coaxial (RF)
Using Your Antenna or Digital Cable for Standard TV or Digital TV
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or cable to the DTV/TV
CABLE/ANTENNA connector on the back of the HDTV
3. Turn on the power to the HDTV.
4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button
on the remote control.
Using the Antenna or Cable through Your VCR
1. Turn off the power to the HDTV and VCR.
2. Connect the “Output to TV”, “RF Out” or “Antenna Out” connector on the rear of your VCR to
the DTV/TV CABLE/ANTENNA connector on the back of the HDTV.
3. Turn on the power to the HDTV and VCR.
4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button
on the remote control.
Note: If you have an off-air antenna or cable TV, connect it to the “Antenna In” connector on the rear of
your VCR.
VCR
VIZIO VF551XVT User Manual
Version 7/17/2009 23
www.VIZIO.com
CD DVD
CD DVD
Connecting Your DVD Player
You have several options for connecting your DVD player to your HDTV: HDMI, Component, S-Video and
Composite (AV) inputs. Based on your home theater configuration, you can decide which option is the
right one for you.
Using HDMI (Best)
For optimal results, DVD players that have a digital interface such as HDMI should be connected to the
HDMI input on your HDTV.
1. Turn off your HDTV and DVD player.
2. Connect a HDMI cable to the HDMI output of your DVD player and the other end to an HDMI
input on the back of the HDTV.
3. Turn on the power to the HDTV and your DVD player.
4. Select HDMI 1, HDMI 2, HDMI 3, HDMI 4 or HDMI SIDE using the INPUT button on the
remote control, or directly by pressing the HDMI button on the remote control.
HDMI Connections for DVD Players with DVI
1. Turn off your HDTV and DVD player.
2. Using a HDMI-DVI cable, connect the DVI end to your DVD player and the HDMI end to the
HDMI 4 Input on the back of the HDTV.
3. Connect the audio cables (white and red) from the DVI audio output jacks on the DVD player
to the adjacent HDMI 4 L and R AUDIO jacks on the back of the HDTV.
4. Turn on the power to the HDTV and your DVD player.
5. Select HDMI 4 using the INPUT button on the remote control, or directly by pressing the
HDMI button on the remote control.
Note: To maintain the display quality, use a VIZIO certified HDMI cable. This cable is available in 6, 15,
and 30 foot lengths. See www.vizio.com or call 1-888-VIZIOCE (1-888-849-4623) for details.
VIZIO VF551XVT User Manual
24
www.VIZIO.com
CD DVD
CD DVD
Using Component Video (Better)
1. Turn off the power to the HDTV and DVD player.
2. Connect the component cable (green, blue, and red) from your DVD player to an available
set of COMPONENT jacks on the back or side of the HDTV.
3. Connect the audio cables (white and red) from your DVD player to the COMPONENT L and
R AUDIO jacks on the back or side of the HDTV.
4. Turn on the power to the HDTV and DVD player.
5. Select COMPONENT 1 or COMPONENT 2 using the INPUT button on the remote control, or
directly by pressing the COMPONENT button on the remote control.
Using S-Video (Compatible)
1. Turn off the power to the HDTV and DVD player.
2. Connect the S-VIDEO cable from your DVD player to the S-VIDEO jack on the back of the
HDTV.
3. Connect the audio cables (white and red) on your DVD player to the corresponding L and R
AUDIO jacks on the back of your HDTV.
4. Turn on the power to the HDTV and DVD player.
5. Select AV1 using the INPUT button on the remote control, or directly by pressing the AV
button on the remote control.
VIZIO VF551XVT User Manual
Version 7/17/2009 25
www.VIZIO.com
CD DVD
VCR
Using Composite (AV) Video (Compatible)
1. Turn off the power to the HDTV and DVD player.
2. Connect the video cable (yellow) from your DVD player to the S-VIDEO/AV1 jack on the back
of your HDTV or the AV2 jack on the side of your HDTV.
3. Connect the audio cables (white and red) on your DVD player to the S-VIDEO/AV1 L and R
AUDIO jacks on the back of your HDTV or the AV2 jacks on the side of your HDTV.
4. Turn on the power to the HDTV and DVD Player.
5. Select AV1 or AV2 using the INPUT button on the remote control, or directly by pressing the
AV button on the remote control.
Connecting Your VCR or Video Camera
1. Turn off the power to the HDTV and VCR or Video Camera.
2. Connect the S-VIDEO cable from your VCR or video camera to the S-VIDEO jack on the
back of your HDTV.
3. Connect the audio cables on your set-top box to the corresponding L and R AUDIO jacks on
the back of your HDTV.
4. Turn on the power to the HDTV and VCR or Video Camera.
5. Select AV1 using the INPUT button on the remote control, or directly by pressing the AV
button on the remote control.
Note: Refer to your VCR or Video Camera user manual for more information about the video output
requirements of the product.
Note: You can also connect the VCR or Video Camera to the AV2 connection on the side of the HDTV if
you are using the composite connections.
VIZIO VF551XVT User Manual
26
www.VIZIO.com
STEREO SYSTEM
Connecting an External Receiver/Amp
1. Turn off the power to the HDTV and Receiver/Amp.
2. Using an audio cable (white and red connectors), connect the
cable to the audio input connectors on the Receiver/Amp and
connect the other end to the AUDIO OUT audio connectors on the
back of the HDTV.
3. Turn on the power to the HDTV and Receiver/Amp.
4. Press the MENU button on the remote control to open the On-
Screen Display (OSD) menu.
5. Press
ź on the remote control to highlight the Audio menu, and
then press OK to select.
6. Press
ź on the remote control to select SPEAKERS.
7. Press Ź on the remote control to select OFF so the sound from
the HDTV will be routed through your Receiver/Amp system.
Note:
x Refer to your Receiver/Amp user manual to select the corresponding audio input.
x The audio output is not amplified and cannot be connected directly to external speakers.
Optical Output of audio received with HD Programs
If your sound system has a SPDIF (optical) digital audio input
you can connect it from your sound system to the OPTICAL
digital audio out on the back of the HDTV. This is active when
receiving audio with the programs being viewed no matter
what input is being used.
VIZIO VF551XVT User Manual
Version 7/17/2009 27
www.VIZIO.com
COMPUTER
Connecting a Computer
1. Turn off the power to the HDTV and Computer.
2. Connect the VGA cable from your computer to the RGB PC jack on the back of the HDTV.
3. Connect the 1/8-inch audio cable from your computer to the RGB PC Audio jack on the back
of the HDTV. This step is optional and only needed if you want to transmit audio from the
computer through the TV.
4. Turn on the power to the HDTV and Computer.
5. Select RGB using the INPUT button on the remote control.
Note:
x For a better picture quality when connecting a PC computer through RGB PC, set your PC
computer timing mode to VESA 1920 x 1080 at 60Hz.
x Refer to your PC computer user manual for more information about the video output requirements
of the product.
x A RGB (VGA) cable and stereo mini jack cable are not included and can be purchased at an
electronics store.
VIZIO VF551XVT User Manual
28
www.VIZIO.com
Preset PC Resolutions
If connecting to a PC through the RGB PC input, set the TV timing mode to VESA 1920x1080 at 60Hz for
better picture quality (refer to the graphic card’s user guide for questions on how to set this timing mode).
See the table below for the factory preset resolutions. Also see Resolution through RGB Input chart below
for the best resolution available through RGB PC input when video card supports 1920x1080 resolution.
Mode No. Resolution
Refresh
Rate
(Hz)
Horiz. Freq
(KHz)
Vert Freq
(Hz)
Horiz
Sync
Polarity
(TTL)
Vert Sync
Polarity
(TTL)
Pixel
Rate
(MHz)
Remark
1 640 x 480 60 31.469 59.941 N N 25.175 Windows
2 640 x 480 75 37.500 75.000 N N 31.500 Windows
3 800 x 600 60 37.879 60.317 P P 40.000 Windows
4 800 x 600 72 48.077 72.188 P P 50.000 Windows
5 800 x 600 75 46.875 75.000 P P 49.500 Windows
6 1024 x 768 60 48.363 60.004 N N 65.000 Windows
7 1024 x 768 70 56.476 70.069 N N 75.000 Windows
8 1024 x 768 75 60.023 75.029 P P 78.750 Windows
9 720 x 400 70 31.469 70.087 N P 28.322 DOS
10
Ϩ1920 x 1080
60 66.587 59.934 P N 138.50 Windows
Note: P: positive, N: negative, Ϩ: Primary mode
Resolution through RGB Input
If your PC supports VESA Reduced Blanking timing via the VGA card drive program (usually offered by
the VGA Card Manufacturer), your TV set is equipped to have the 1920 x 1080 resolution display through
this connection using the following timing 138.5MHz. The following parameters are often the values
required by the software or programs to set up the display:
Parameters Horizontal
Values (Pixels)
V
ertical Values
(Lines)
Address
1920 1080
Front Porch
48 3
Sync Width
32 5
Back Porch
80 23
Total
2080 1111
Frequency
66.587 kHz 58.934 Hz
Sync Polarity
P
N
Pixel Rate (MHz)
138.5
Refresh Rate (Hz)
59.934
VIZIO VF551XVT User Manual
Version 7/17/2009 29
www.VIZIO.com
Chapter 3 Using the Multi Media Port
With the Multi Media port you can enjoy digital content such as photos, music, and movies on your HDTV
using a USB flash drive connected to the Multi Media port on the left-hand side of the TV.
USB drives that are USB 2.0 and FAT or FAT32 are supported but the Multi Media port t does not support
hard drives or USB hubs.
If your USB drive is oversized and does not physically fit in the Multi Media port, use a USB extension
cable. Connect one end of the cable to your USB drive and the other end to the Multi Media port.
Multimedia Viewer Specifications
Supported File Extensions
Video: .asf, .wmv, .avi, .mp4, .mov, .mpg, .mpeg, .vob (DVD)
Audio: .mp3
Image: .jpg, .jpeg (up to 17,000 x 10,000 pixels)
Readable Data Format
FAT and FAT32
Maximum folder depth
Folders can be up to 20 levels deep. The first folder on the drive is Level 1. A folder
within that folder is Level 2, a folder within that folder is Level 3, etc.
Display Limits
The Multimedia Viewer will show the first 1000 folders and 1000 files in the list
Supported File Formats
The following are the supported file formats that can be played on your HDTV. Media server content
protected by digital rights management such as WMDRM10 (Windows Media Digital Rights Management
10), may not play.
File
Extension
Video Encoding
Supported
Audio Encoding
Supported
Resolutions
Supported
H.264/AVC AAC Up to 1920 x 1080
.avi
.mp4
MPEG 4 ASP AAC Up to 1280 x 720
.asf
.wmv
WMV7 (WMV1)
WMV8 (WMV2)
VC-1/WMV9 (WMV3/WVC1)
WMA7(V1)
WMA8(V2)
Up to 1920 x 1080
.mov H.264/AVC AAC Up to 1920 x 1080
.mpg
.mpeg
MPEG2 AC3 Up to 1920 x 1080
.vob MPEG2 AC3 Up to 1920 x 1080
Note: Even the supported format files listed above may or may not play properly or completely,
depending on the USB device, bit rate stream and other content characteristics, as well as other factors.
VIZIO VF551XVT User Manual
30
www.VIZIO.com
Viewing Multimedia Content
1. Insert a USB device with digital content such as photos, music, and movies into the Multi Media
port on the left-hand side of your HDTV. If a USB device is already connected, press the MEDIA
button on the remote control. A message will appear asking if you want to play multimedia
content.
2. Press Ż or Ź to highlight OK,
and then press OK to select it.
3. Press Ż or Ź to highlight the
folder that contains the
content you want to see or
hear, and then press OK to
select it. A sub-menu will be
displayed, showing the folders
and files that are on your USB
device.
4. Press Ż or Ź to highlight the
folder or file you want to play,
and then press OK to select it.
The file will being playing.
5. While playing videos or music,
fast forward or fast reverse by
pressing Ż or Ź.
a. Press Ż or Ź to
increase the playback
speed forward or
reverse 2X. The
display at the bottom
will show
or .
b. Press Ż or Ź again
to increase the
playback speed
forward or reverse 4X,
8X, 16X or 32X. The
display at the bottom
will show
or .
c. Press Ż or Ź again
to resume normal
playback.
6. When finished, press EXIT
once to return to the previous
screen or repeatedly to return
to the main menu.
VIZIO VF551XVT User Manual
Version 7/17/2009 31
www.VIZIO.com
Picture Settings
When viewing pictures you can adjust various settings, including slideshow, picture duration, etc.
1. Insert a USB device and select the Picture Folder.
2. Press the MENU button on the remote control. The Picture menu will be displayed.
3. Press
Ÿ or ź on the remote control to highlight Picture menu option, and then press Ż or Ź to
adjust the setting.
4. Press the MENU button once to close the menu.
Slideshow Mode
Choose from Shuffle, Single, and Sequence to set the slideshow mode. Single will show all of the pictures
once and stop the slideshow after displaying the last picture, Sequence will show your pictures in the
order they are listed on your USB device until you stop the slideshow, and Shuffle will show your pictures
in random order until you stop the slideshow.
Press OK to begin the slideshow. Press EXIT to stop the slideshow.
Slideshow with Music
Choose from Off, Single, Sequence, and Shuffle to set the slideshow with
music mode. The music will automatically stop when the slideshow stops.
Press OK to begin the slideshow. Press EXIT to stop the slideshow.
Music file browser
Select the slideshow music. Press OK to browse for music on your USB
device that you want playing during the slideshow. The Slideshow with Music
option above must be set to Single, Sequence, and Shuffle for this option to
work.
Audio Mode
Choose from Flat, Rock, Pop, Classic, or Jazz to adjust the overall quality of the audio being played
during the slideshow. Press OK to enter the Audio sub menus for additional adjustments to audio. See
Audio Menu adjustment section on page 43. Turn SRS TruVolume Off when listening to music.
Repeat
Choose from On or Off to repeat the slideshow.
Sort By
You can choose to sort the pictures on the USB device by Photo Date, File Date, or alphabetically (File A-
Z).
VIZIO VF551XVT User Manual
32
www.VIZIO.com
Duration
Set the amount of time the picture will remain on the screen during the
slideshow. Choose a time between 5 seconds and 32 seconds.
Slideshow Effect
Choose from Random, Dissolve, Wipe Right, Wipe Left, Wipe Up, Wipe Down,
Box In, or Box Out to set the transition type when changing from one picture to
another during a slideshow.
Thumbnail Size
Set the size of the preview pictures (thumbnails) in the menu. Choose from
Small, Medium, or Large.
Info
When set to on, information about the picture briefly appears on the TV.
Music Settings
When listening to music you can adjust various settings, including selecting an
audio mode, choosing repeat options, etc.
1. Insert a USB device and select the Music Folder.
2. Press the MENU button on the remote control. The Music menu will be
displayed.
3. Press
Ÿ or ź on the remote control to highlight Music menu option, and
then press Ż or Ź to adjust the setting.
4. Press the MENU button once to close the menu.
Sort By
You can choose to sort the songs by File/Title, Genre, Artist, or Album.
Play Mode
Choose from Shuffle, Single, and Sequence to set the play sequence mode. Single will play a single song
once and stop playing at the end of that song, Sequence will play the songs in the order they are listed on
your USB device until you stop it, and Shuffle will play the songs in random order until you stop it.
Repeat
When set to On, the music will continue playing until you stop it.
Audio Mode
Choose from Flat, Rock, Pop, Classic, and Jazz to adjust the overall quality of the audio being played.
Info
When set to on, information about the song briefly appears on the TV.
VIZIO VF551XVT User Manual
Version 7/17/2009 33
www.VIZIO.com
Video Settings
When watching videos you can adjust various settings, including selecting an audio mode, setting to a
wider format, etc.
1. Insert a USB device and select the Video Folder.
2. Press the MENU button on the remote control. The Video menu will be displayed.
3. Press
Ÿ or ź on the remote control to highlight Video menu option, and then press Ż or Ź to adjust
the setting.
4. Press the MENU button once to close the menu.
Sort By
You can choose to sort the videos by Type, Date, or, File Name.
Play Mode
Choose from Shuffle, Single, and Sequence to set the video sequence mode.
Single will play a video once and stop playing at the end of that song.
Sequence will play the videos in the order they are listed on your USB device
until you stop it. Shuffle will play the videos in random order until you stop it.
Repeat
When set to On, the video(s) will continue playing until you stop it.
Picture Mode
Choose from Custom, Standard, Movie, Game, Vivid, Football, Golf,
Basketball and Baseball to adjust the overall quality of the picture. Press OK to
enter the Picture sub menus for additional adjustments to video. See Picture
Menu adjustment section below.
Wide Format
Set the way the picture looks on the screen:
x 4:3 videos: choose Normal, Panoramic, Zoom1, or Zoom2.
x 16:9 videos: choose Stretch, Zoom1, or Zoom2
Audio Mode
Choose from Flat, Rock, Pop, Classic, Jazz, and Soft to adjust the overall
quality of the audio being played.
Info
When set to on, information about the video briefly appears on the TV.
VIZIO VF551XVT User Manual
34
www.VIZIO.com
Chapter 4 Using your HDTV the first time
Setup Wizard
1. Connect the Power Cable
Connect the power cord to the power cord
connector on the back of the HDTV, and
then plug the power cord into an AC wall
socket.
2. Connect Audio and Video Cables to the
HDTV
(see Chapter 2 for detailed steps)
3. Turn Power On
Once all the components are connected,
press the Power ON button on the remote
control or on the side of your HDTV.
4. Initial Setup
a. After powering on the TV set, the
Initial Setup Welcome screen will
come up. Press the OK button on
the remote control.
b. The Language choice screen will
be displayed; the default English
option is highlighted. If you wish
to change the OSD language to
Español or Français, press the
ź
button on the remote control to
select the language you want.
c. Press the OK button on the
remote control to go to the next
screen.
d. The next screen will display the
options Home Mode and Retail
Mode. Selecting Home Mode will
give you an opportunity to save
energy.
e. Press the OK button on the
remote control to go to the next
screen.
f. If Retail Mode is selected by
mistake, the next option will allow
you to switch your selection back
to Home Mode.
g. Press the OK button on the
remote control to go to the next
screen.
VIZIO VF551XVT User Manual
Version 7/17/2009 35
www.VIZIO.com
h. The Tuner screen will be
displayed. If you are using Cable
Service (not a box), press the
ź
button on the remote control to
choose CABLE.
i. Press the OK button on the
remote control to go to the next
screen.
j. The Channel Scan screen will be
displayed; default choice is Scan.
Note:
If a set-top box from your cable or satellite
service company is being used you do not need to
scan for channels. Press the OK button on the
remote control and select Skip Scan.
k. Press the OK button on the
remote control to start the search
for available channels. The screen
will show the progress of the
search for Analog (NTSC) and
Digital (ATSC) channels.
Note: If you select Skip Scan, you can scan
channels at a later time by selecting the TV input,
then going to the Menu and selecting the Auto
Search option in the TV menu.
Refer to www.antennaweb.org to get information
about availability in your area, type of antenna and
in which direction to point your antenna. The
channel availability through cable depends upon
which channels your cable operator supplies DTV
digital content in Clear QAM; consult your cable
operator for more information.
l. When finished, the Complete
screen will be displayed to inform
you that the HDTV has completed
the Initial Setup. Press the OK
button on the remote control to
exit and begin watching TV.
VIZIO VF551XVT User Manual
36
www.VIZIO.com
Select Input Source
Select the Input Source for the HDTV by
pressing the INPUT button on the remote control.
Pressing this button will cycle you through the
following options: TV, AV1, AV2, Component1,
Component2, RGB, HDMI1, HDMI2, HDMI3,
HDMI 4 and HDMI SIDE.
Turn on your Cable Box, VCR, External TV
Tuner or Satellite Receiver and you will see a
picture on your HDTV. If there is no picture,
make sure you have selected the correct input
on the HDTV.
If the selected input is RF, set the HDTV to
either Channel 3 or Channel 4 matching the
channel which has been selected on the back of the VCR, Cable Box, External TV Tuner or Satellite
Receiver; please refer to Owner or User’s Manual of such equipment for details.
Note: Your HDTV will display the television station or program selected by the cable box, VCR, external
tuner, or satellite receiver. Use the remote control that came with that component to change programs or
channels. If the service being used is the one which setup includes a box with two outputs for two
different (distant) rooms, then scanning channels will help you to find the signal. The channel to be
selected varies from provider to provider. You may have to call your provider to get the specific channel
when using your HDTV. Some examples of these channels are 105, 106, 115, and 116.
VIZIO VF551XVT User Manual
Version 7/17/2009 37
www.VIZIO.com
Fine Tuning the picture
1. Press the MENU button to bring up the Menu display. The Picture
Menu is highlighted. Press OK to select it. Use the Ÿ or ź buttons to
scroll to the Advanced Video option.
2. Press the Ź button to select it.
3. Use either Ÿ or
ź to scroll to the Color Temperature option.
4. Press the Ź button to select it.
5. Press either Ż or Ź to change setting to Normal, and then press the
MENU button repeatedly until the Picture Mode is displayed.
6. Press either Ż or Ź to change the Picture mode option to Standard.
7. Press either Ÿ or ź to scroll to the TV option, and then press OK to
select it.
8. Press the MENU button repeatedly to exit the menu.
Setting the Time Zone
1. Select TV using the INPUT button on the remote control, or directly by
pressing the TV button on the remote control.
2. Press the MENU button to bring up the Menu display. The Picture
Menu is highlighted.
3. Press
Ÿ or ź to highlight the TV menu, and then press OK to select it.
4. Press either Ÿ or ź to scroll to Time Zone, and then press either Ż or
Ź to set the proper Time Zone of your area.
5. Press
ź to scroll down to Daylight Saving, and then press either Ż or
Ź to set to On or Off.
6. Press the MENU button once to return to the previous screen or
repeatedly to return to your program if task has been completed.
Your new HDTV is now ready to use. Enjoy your TV watching!!
VIZIO VF551XVT User Manual
38
www.VIZIO.com
Watching a TV Program
Before you start watching TV, please make sure that any cable, satellite or off-air antenna connections
are secure. Also, verify that the power cord is plugged into a correctly grounded electrical outlet or surge
protector.
1. Press the power button on the remote control. The VIZIO logo on the front will change from
orange to white.
2. There are 3 options for selecting your programming:
a. If you are using an antenna or cable connected through the DTV/TV CABLE/ANTENNA
input, you can select TV directly by pressing the TV button on the remote control or by
selecting TV from the Input menu after pressing INPUT on the remote control.
b. If you are watching broadcasts through a cable or satellite set-top box connected by an
HDMI cable, select HDMI directly by pressing the HDMI button on the remote control, or
by selecting HDMI from the Input menu after pressing INPUT on the remote control.
c. If you are watching broadcasts through a cable or satellite set-top box connected by a
Component (YPbPr) cable, select Component directly by pressing the COMP button on
the remote control or by selecting Component from the Input menu after pressing INPUT
on the remote control.
Note:
You should be able to see a picture. If you do not, make sure that all of the HDTV connections are
secure and you have selected the correct video input source. Each press of the HDMI or COMP button on
the remote control will cycle through the available inputs. Press the button until the input associated with
the device you wish to view is shown in the Info box at the upper right corner of the screen.
3. When using option 2a, press the Channel buttons on the remote control or the CH Ÿ or
źbuttons to change the channel. The Channel buttons and on the remote control, control will
not work if you are watching a program using HDMI, Component, or AV (S-Video or
Composite) inputs.
VIZIO VF551XVT User Manual
Version 7/17/2009 39
www.VIZIO.com
Adjusting Basic HDTV Settings
Volume
To adjust the volume, press and hold the VOL+ or VOL- button or remote control until
the desired level is reached.
TV Channels
To step up or down through the available TV channels, press the CH Ÿ or ź button on
the remote control once for the next or previous channel, or hold it depressed until the
desired channel is reached.
Note: Channel up and down will only operate in TV mode.
Program Information
When watching a digital TV program, the On Screen Display will function as follows:
x When a channel is selected, an information header is shown over the picture for a few seconds.
x When you press the INFO button on the remote control, the information header and a short
summary of the program content, when available from the broadcaster, is displayed.
This information consists of the channel number and name, the format in which the program is broadcast
(480i SD, 480P SD, 720P HD, 1080i HD), audio channel 1/2 or 2/2 (omitted if alternate channel is not
broadcast), language, program title, program start and end time, program rating and if CC is available.
x Press the INFO button one more time to close the display
VIZIO VF551XVT User Manual
40
www.VIZIO.com
Chapter 5 Advanced Adjustment of HDTV
Using the On Screen Display (OSD)
The remote control or the control buttons on the left hand side of the TV can control all the function
settings. The On Screen Display (OSD) allows you to adjust contrast, brightness and other settings. The
TV will save changes made to the settings, even if the TV is turned off.
The OSD consists of several menu options: Picture, Audio Mode, TV, and Setup. The main menu options
may vary depending on your selected input source.
Note: Some of the main menu options may have additional submenus, for example, the TV Rating
submenu for Parental Controls.
1. Press the MENU button on the remote control and the Picture menu
will be shown on the screen.
2. Press either
Ÿ or ź on the remote control to select one of the other
menu options:
x Picture (Picture Adjust)
x Audio Mode (Audio Adjust)
x TV (TV Tuner Setup)
x Setup (Global Settings)
3. Press OK to select the option or feature you want to adjust.
4. Once the menu option is displayed, press
Ÿ or ź on the remote
control to select one of the items to adjust.
5. Press OK to select, and then press Ż or Ź to adjust the selection.
6. Press the MENU button once to return to the previous screen or
repeatedly to return to your program if adjustments have been completed.
VIZIO VF551XVT User Manual
Version 7/17/2009 41
www.VIZIO.com
Picture Menu
1. Press the MENU button on the remote control.
2. Press
Ÿ or ź on the remote control to highlight the Picture menu, and then press OK to select it.
3. Press
Ÿ or ź on the remote control to select a Picture menu option.
4. Once the menu option is highlighted, press Ż or Ź on the remote control to adjust the setting.
5. Press the MENU button once to return to the previous screen or repeatedly to return to your
program if the task has been completed.
Picture Mode
When Picture is highlighted, press Ż or Ź to choose from Custom, Standard, Movie, Game, Vivid,
Football, Golf, Basketball and Baseball.
Backlight
The Backlight level adjusts the LEDs and this affects the overall brilliance of
the picture but does not affect the Brightness (black level) or Contrast (white
level) of the picture.
Brightness
The Brightness adjusts the black levels in the picture. If the brightness is too
low you will not be able to see the detail in darker parts of the picture and if the
brightness is too high the picture will look washed out.
Contrast
The Contrast adjusts the white levels in the picture. If the contrast is too low
the picture will look washed out and if the contrast is too high you will not be
able to see any detail in the bright parts of a picture.
Color
Color adjusts the amount of color in the picture.
Tint
The Tint adjusts the hue of the picture. The easiest way to set tint is to look at flesh tones and adjust for a
realistic appearance. In most cases, the default middle position is correct. If people’s faces look too
orange try reducing the level of color first.
Sharpness
The Sharpness adjustment adjusts the sharpness of the edges of elements in the picture. It does not
produce detail that otherwise does not exist. This adjustment is helpful when viewing (Standard
Definition) sources.
VIZIO VF551XVT User Manual
42
www.VIZIO.com
Advanced Video
To select the options in the Advanced Video sub-menu, press the OK button or the Ź button. A new
menu will be displayed showing the advanced functions available for fine tuning of the picture.
Noise Reduction
This feature diminishes picture artifacts caused by the digitizing of image motion content that may
be present in the picture. Choose from the Off, Low, Medium, or Strong setting.
MPEG NR
Reduces picture noise in solid colored areas of the picture.
Color Enhancement
This feature increases the picture reproduction performance of the picture by reducing
oversaturation of certain colors and improving flesh tones. Choose from Off, Normal, Rich Color,
Green/Flesh, and Green/Blue setting.
Advanced Adaptive Luma
Large areas of brightness in the picture will result in a higher Average Picture Level (APL) and the
overall picture will look too light. This feature will lower the APL to counteract this effect. Choose
from Off, Normal, High, or Extend.
Smart Dimming Setting
This menu controls the Smart Dimming functions. Press Ź to enter
the submenu.
Smart Dimming
Provides true black for the highest quality picture. Choose
On or Off.
Smart Dimming Demo
Demonstration of the Smart Dimming Effect. The demo turns
Smart Dimming On, then Off at three second intervals. Press
Ź to initiate the demo. Press MENU to exit the demo.
Color Temperature
Color Temperature is the “warmness” or “coolness” of the white areas of the picture. Choose from
Normal, Custom, Cool, Computer, or R G and B Offset. Normal is the setting for television
broadcasting. Custom allows you to set a preset calibrated for a white point to suit individual
preferences. Cool produces a blue-hued image. The Computer setting sets the white point at the
established setting for a PC display (9300K). Each preset may also be adjusted for a customized
setting. R G and B Offset allows professional grade calibration of grayscale tracking.
Smooth Motion
The Smooth Motion
TM
Effect option activates Motion Estimation/Motion Compensation (ME/MC),
which suppresses motion judder, or “stuttering” of the image when the camera pans across a
scene, or there is horizontal motion in the scene. Choose from Off, Low, Middle or High.
Film Mode
Enable or disable the detection and processing of film materials. Choose Auto or Off.
VIZIO VF551XVT User Manual
Version 7/17/2009 43
www.VIZIO.com
Reset Picture Mode
Return all Picture settings to factory default. A screen will come up to confirm your selection or to cancel it.
Press either Ż or Ź to make the selection, and then press OK to accept it.
Note: Only settings under the Picture menu will be reset.
Audio Menu
1. Press the MENU button on the remote control and the Picture menu will be shown on the screen.
2. Press
Ÿ or ź on the remote control to highlight the Audio menu, and then press OK to select it.
3. Press
Ÿ or ź on the remote control to select an Audio menu option.
4. Once the menu option is highlighted, press Ż or Ź on the remote control to adjust the setting.
5. Press the MENU key once to return to the previous screen or repeatedly to return to your program if
the task has been completed.
Audio Mode
Choose from Flat, Rock, Pop, Classic or Jazz.
Equalizer
To select the options in the Equalizer sub-menu,
press the OK button. A new menu will be displayed
showing the volumes of different frequencies.
Starting from lowest to the highest, they are 120 Hz,
500Hz, 1.5 kHz, 5 kHz and 10 kHz.
1. Press Ż or Ź to select the frequency to be
adjusted.
2. Use Ÿ or ź to adjust to adjust the selected
frequency to your preference. Values above
0 will boost the frequency and values below
0 will attenuate the frequency.
Note:
The Equalizer adjustment will only be available when SRS TSHD is set to Off.
Balance
Adjust the sound to the left or the right.
SRS TSHD
This option sets the SRS True Surround HD surround sound process. Choose from On or Off.
Note: When SRS TSHD is ON, Equalizer adjustments are not available.
SRS TruVolume
When the programming switches to a commercial or when changing from channel to channel, volume
fluctuations occur. When turned ON, SRS TruVolume
TM
provides the listener with a comfortable and
consistent volume level. Turn this option Off when listening to music.
Digital Audio Out
This option allows selection of the type of processing for the SPDIF (Optical connector) when used with a
Receiver/Amplifier/Home Theater system. Select to choose from OFF, Dolby Digital or PCM.
VIZIO VF551XVT User Manual
44
www.VIZIO.com
Speakers
Turn the internal speakers On or Off. You may want to turn the internal speakers off when listening to the
audio through your Home Theater System.
Analog Audio Out
This option sets the volume control properties when using the RCA (white and red) connectors as audio
line out to connect a Receiver/Amplifier/Home Theater system. Choose from Fixed or Variable. When set
to Variable, volume from the external speakers will change according to the volume setting on the TV. If it
is set to Fixed, the volume can only be changed by the settings on the external stereo system.
Lip Sync
Lip Sync is designed to adjust the audio of the program being viewed so that it matches the movement of
the lips of someone talking on the screen.
Reset Audio Mode
Return all Audio settings to factory default. A screen will come up to confirm your selection or to cancel it.
Press Ż or Ź to make the selection, and then press OK to accept it.
Note: Only settings under the Audio menu will be reset.
VIZIO VF551XVT User Manual
Version 7/17/2009 45
www.VIZIO.com
TV Menu
When you first turned on your HDTV you set up your TV for DTV / TV channels using the Initial Setup
screens. If you did not do this or if your setup has changed, you can do this from the TV
menu.
1. Press the MENU button on the remote control and the Picture menu will be shown on the screen.
2. Press
Ÿ or ź on the remote control to highlight the TV menu, and then press OK to select it.
3. Press
Ÿ or ź on the remote control to select a TV menu option.
4. Once the menu option is highlighted, press Ż or Ź on the remote control to adjust the setting.
5. Press the MENU key once to return to the previous screen or repeatedly to return to your program if
the task has been completed.
Tuner Mode
Select Cable or Antenna depending upon which
equipment you have attached to the DTV / TV Input.
Auto Search
Automatically search for TV channels that are
available in your area. The TV will search for analog
and digital channels.
Partial Channel Search
If you believe channels are missed from the auto
search, you can do a partial channel search to look
for channel in a certain channel range again. Select
to scan for Analog, Digital, or both Analog/Digital
channels, then press the
ź button to highlight the
“From” and “To” selection. Press the Ź button to
select the range of channel numbers you want to start searching in. Press OK to start channel search.
Skip Channel
After the TV has stored all of the available channels in memory you will find that some channels are too
weak to watch comfortably or they may be channels you do not want to see when using the CH
Ÿ or
CH
ź buttons. You will still be able to select this channel using the number buttons on the remote control.
Scroll through the channels listed using
Ÿ or ź or scroll a page at a time by pressing Ż or Ź. Press the
OK button to select the channel to be skipped.
MTS
This feature allows you to select the different languages the broadcaster is transmitting the audio with the
program you are watching. This signal is usually Spanish.
Time Zone
Setting the correct Time Zone for your area will ensure that the correct program times are shown after
pressing the INFO button on the remote control.
Daylight Saving
Setting the daylight saving time for your area will ensure that the correct program times are shown after
pressing the INFO button on the remote control.
VIZIO VF551XVT User Manual
46
www.VIZIO.com
Channel Info
Channel Info displays the technical information of the channel including channel number, frequency,
modulation type, status, SNR (signal noise ratio), and signal strength.
Setup Menu
1. Press the MENU button on the remote control and the Picture menu will be shown on the screen.
2. Press
Ÿ or ź on the remote control to highlight the Setup menu, and then press OK to select it.
3. Press
Ÿ or ź on the remote control to select Setup menu option.
4. Once the menu option is highlighted, press Ż or Ź on the remote control to adjust the setting.
5. Press the MENU key once to return to the previous screen or repeatedly to return to your program if
the task has been completed.
Language
Select to change the Language of the OSD. The default is English. You can
also select Español or Français.
PIP
Your TV features PIP mode so you can watch two pictures at the same time.
One picture is displayed as the full screen (main screen) and the other picture
is displayed in a small window (sub screen).
Note: PIP is only available when the Rating Enable option in the Parental
Controls Menu is OFF.
To select the options in the PIP sub-menu, press the OK button. A new menu
will be displayed showing the following PIP settings:
PIP Mode
Select from Off, PIP or POP (Picture-outside picture). In PIP mode a smaller sub-screen is
displayed on top of the main screen. In POP mode the main screen and sub-screen are of equal
size and are positioned side-by-side.
VIZIO VF551XVT User Manual
Version 7/17/2009 47
www.VIZIO.com
PIP Source
Select the input source for the sub-screen. The input sources available will vary according to
which input is used for the main screen.
SUB
MAIN
TV AV1 AV2
Component
1
Component
2
HDMI1,
HDMI2,
HDMI3,
HDMI4.
HDMI
SIDE
RGB
DTV
9 9 9 9
TV
9 9 9 9
AV1
9 9 9 9
AV2
9 9 9 9
Component 1 9
9 9
9
Component 2 9
9 9
9
HDMI 1 9
9 9 9 9
9
HDMI 2
9 9 9 9 9
9
HDMI 3
9 9 9 9 9
9
HDMI 4
9 9 9 9 9
9
HDMI SIDE
9 9 9 9 9
9
RGB 9
9 9
9
“9” – Indicates which inputs are available for PIP and POP modes.
PIP Position
Select where you want the PIP screen positioned over the main screen.
Size
Set the size of the PIP window. Choose from Small, Medium or Large.
Audio Source
Select the audio source associated with the main screen or the sub screen.
Sleep Timer
Select the timer to turn off the TV in 30, 60, 90 or 120 minutes.
Tech Logo
Set the animated illumination of the Tech Logo in the glass above the left speaker. Choose from On or Off.
Wide
Select how the picture displays on the screen. As you select an option, you will see the screen adjusting
to the different sizes. Refer to Chapter 6 for additional details.
VIZIO VF551XVT User Manual
48
www.VIZIO.com
Input Naming
This feature helps you identify the input being
watched. You can use up to 8 characters; either
letters or numbers or combinations of both, to add a
name that will make it easier for you to recognize the
input.
1. Press the Ź button to go to the next screen
that shows the different inputs.
2. Press the
ź button to select the desired
input which you want to label.
3. Press the OK button to go to the first space
in the bracket.
4. Press either the
Ÿ or ź button and select a
desired letter or number.
5. Press the Ź button to go to the next space
and select a second character.
6. Repeat the step 4 and 5 until the name of the input is complete.
7. Press the OK button to accept the name of the input or the MENU key to cancel the setting.
CC (Closed Caption)
To select the options in the CC sub-menu, press the OK button or the Ź button.
A new menu will be displayed showing the following CC settings:
CC
The CC feature is available when watching regular analog (NTSC) TV.
Select from CC1, CC2, CC3, CC4, Service1, Service2, Service3,
Service4, Service5, or Service6. Closed Caption for regular TV is
usually CC1 or CC2.
Digital CC Style
The Digital CC Style feature is available when watching digital TV.
Select either As Broadcaster or Custom. If Custom is selected then
you can customize the way Closed Caption is displayed. The options
available are:
x Font Size (letter size)
x Font Color (letter color)
x Font Opacity (letter transparency)
x Background Color (color of the background where Closed
Caption is displayed)
x Background Opacity (sets the transparency of the
background)
x Window Color (color of the area where characters are
displayed)
x Window Opacity (transparency of the area where characters
are displayed)
VIZIO VF551XVT User Manual
Version 7/17/2009 49
www.VIZIO.com
H/V Position
To select the options in the H/V Position sub-menu, press the MENU button or the Ź button. A new menu
will be displayed showing the following H/V Position settings:
H-Position
Adjust the horizontal position of the picture.
V-Position
Adjust the vertical position of the picture.
H-SIZE
Adjust the horizontal size of the picture.
V-SIZE
Adjust the vertical size of the picture.
Auto Phase (for Component input only)
The TV will automatically look for the phase of the signal to fine tune the picture.
Note: The H/V Position function is only available in HDMI, Component, or RGB modes.
Parental
If you want to restrict certain channel and program viewing, you can do this by turning on the Parental
Control. Selected programs, movies and channels can then be made available only after an authorized
password has been entered and accepted by the TV.
To select the options in the Parental sub-menu, press OK. Enter a password to access the Parental menu.
The default password set in the factory is 0 0 0 0.
Note: The Parental menu does not appear when the input mode is set to HDMI.
A new menu will be displayed showing the following Parental settings:
Rating Enable
Select from ON or OFF. If set to OFF, you will not be able to set the
US TV, US Movie, Canadian English, or Canadian French Ratings.
Channel Block
Block individual channels from being displayed.
VIZIO VF551XVT User Manual
50
www.VIZIO.com
US TV Rating
Note: When Rating Enable is OFF, US TV Rating adjustments are not available.
Press the OK button to block (locked) or allow (unlocked) channels by the following US TV
ratings:
Y ! All children
Y7 ! Older children
G ! General audience
PG ! Guidance suggested
14 ! Strongly cautioned
MA ! Mature audience
You can also customize the TV ratings for the following content:
A ! All sub-ratings
D ! Sexual dialog
L ! Adult language
S ! Sexual situations
V - Violence
FV ! Fantasy violence
US Movie Rating
Note: When Rating Enable is OFF, US Movie Rating adjustments are not available.
Press the OK button to block (locked) or allow (unlocked) channels by
the following US Movie ratings:
G ! General audience
PG ! Parental guidance suggested
PG-13 ! Recommended for children 13 years of age or older
R ! Mature audience
NC-17 ! No one under 17 years of age
X ! No one under 17 years of age
Canadian English Rating
Note: When Rating Enable is OFF, Canadian English Rating
adjustments are not available.
Press the OK button to block (locked) or allow (unlocked) channels by
the following Canadian English ratings:
C ! Children
C8+ ! Children 8 years or older
G ! General Programming, suitable for all audiences
PG ! Parental guidance
14+ ! Viewers 14 years or older
18+ ! Adult programming
VIZIO VF551XVT User Manual
Version 7/17/2009 51
www.VIZIO.com
Canadian French Rating
Note: When Rating Enable is OFF, Canadian French Rating adjustments are not available.
Press the OK button to block (locked) or allow (unlocked) channels by the following Canadian
French ratings:
G ! General audience
8 ans+ ! General ! not recommended for young children
13 ans+ ! Not suitable for children under 13 years of age
16 ans+ ! Not suitable for under 16 years of age
18 ans+ ! Adults only
DTV Rating
This option updates the TV or Movie rating table for digital programs in your local or regional area.
It will allow the parental guidance control feature in your TV to have the most current parental
control database for a digital signal. If Not Available appears at the bottom of the menu, then no
update is available (the option is not activated in your area). This option may be available in the
future for activation.
Block Unrated TV
Block programming that does not have a rating.
Change the Password
Select Access Code Edit to enter a new, 4-digit password using the
number buttons on the remote control. Enter it a second time to
confirm you entered it correctly.
Note:
Make sure you write down and store the new password in a
secure place. The System Reset feature (see page 44) does NOT
reset the password.
System Info
Display the technical information including model name, version and revision of firmware, source type,
and resolution.
System Reset
To select the options in the System Reset sub-menu, press the OK button or the Ź button. A new menu
will be displayed showing the following System Reset settings:
Setup Wizard
Use this function to return to the Initial Setup menu. Use this function if you want to have a guided
setup when you move your TV. Please refer to Chapter 3 for more information.
Note: Previously scanned channels will be removed.
Reset All Settings
Use this function to reset the TV to the default factory settings.
The screen will display a message to confirm that you want to reset the values to factory settings.
Note: This does NOT reset the Parental Control Password.
VIZIO VF551XVT User Manual
52
www.VIZIO.com
Chapter 6 Understanding Viewing Features
Your HDTV features the following viewing modes. You can switch viewing modes using the remote
control, please follow the instructions on page 39.
Viewing Modes
Normal Mode
The original 4:3 aspect ratio (1.33:1 source) is preserved, so black bars are
added to the left and right of the display image. Standard TV broadcasts are
displayed with a 4:3 Aspect Ratio. Movies in 4:3 Aspect Ratio may be referred
to as pan-and-scan or full frame. These movies were originally filmed in 16:9
(widescreen), and then modified to fit a traditional TV screen (4:3).
Full
Full mode allows you to view the entire picture. Recommended for HDMI and RGB / Computer viewing so
you can see the complete picture without the image overstretching beyond the viewing area. If you
experience “noise” along the border switch to Zoom 1. For 720p, 1080i, 1080p only.
Zoom 1
When watching a standard broadcast or full-frame movie in this mode,
the display image is stretched proportionately to fill the TV screen.
When watching a widescreen (1.78:1 source) program or movie, the
display image fills the TV screen. If you are watching a widescreen
(1.85:1 or 2.35:1 source) program or movie, there will still be black
bars at the top and bottom.
Zoom 2
Zooms in by 14% to crop the top and bottom bars for 2.35:1 film resolutions. For 480i/p, 4:3 only.
Stretch Mode
When watching a widescreen program (1.78:1 source) with black bars on
the sides, the display image will stretch to fill the TV screen. People will
appear wider than they really are. If you are watching a widescreen
(1.85:1 or 2.35:1 source) program or movie, there will still be black bars
at the top and bottom. This mode is available only when watching a
widescreen program.
Panoramic Mode
When watching a standard broadcast or full frame movie in this mode,
the 4:3 Aspect Ratio (1.33:1 source) display image is stretched
horizontally on the left and right sides to fill the TV screen. The center
of the image is not stretched.
VIZIO VF551XVT User Manual
Version 7/17/2009 53
www.VIZIO.com
Chapter 7 Programming the VIZIO Universal Remote Control
Using a Cable or Satellite Box Remote
Your VIZIO remote uses codes 000, 047, 050, 067, 329, 331 and 339 to work your HDTV. To use a cable
or satellite remote to work the HDTV, refer to your cable or satellite remote user guide for more
information on how to program the remote.
If your cable or satellite remote uses a 5-digit code (like most Direct TV units), first try 11758 and then, if
that does not work, 10178. If your cable or satellite remote uses a 4-digit code, try 1758 and then 0178 as
an alternative. If your cable or satellite remote uses a 3-digit code (Echostar or Dish Network for example),
use code 627.
Note: Some buttons may not function as expected on your cable or satellite remote. Typically power,
volume and mute will work.
Programming other devices
Your remote control is programmable and supports up to three different devices. Listed below are the
steps for programming your DVD player, Home Theater System, and a Cable or Satellite box. Once you
find your codes, write them in the table provided.
Programming your DVD Player
1. Turn on the DVD player.
2. Press and release the DVD button on the remote control.
3. Press and hold the SET button until the LED flashes twice.
4. Find the programming code for your DVD player in the code list below and enter it using the
number buttons. If the code is accepted, the LED flashes twice after the last digit is entered. If
the LED does not flash twice, repeat Steps 2 through 4 with the next code listed.
5. Point the remote control at the DVD player and press the POWER button. The DVD player will
turn off. If the DVD player does not turn off, repeat Steps 2 through 4 with the next code listed for
the component and manufacturer.
Notes:
x If the codes do not work or your brand is not listed, see “Searching for Component Codes.”
x Sometimes a code listed will only include limited functions. Try other codes that may include
more functionality.
Programming your Home Theater System
1. Turn on the home theater system.
2. Press and release the AUDIO button on the remote control.
3. Press and hold the SET button until the LED flashes twice.
4. Find the programming code for your home theater system in the code list below and enter it using
the number buttons. If the code is accepted, the LED flashes twice after the last digit is entered.
If the LED does not flash twice, repeat Steps 2 through 4 with the next code listed.
5. Point the remote control at the Home Theater System and press the POWER button. The Home
Theater System will turn off. If the Home Theater System does not turn off, repeat Steps 2
through 4 with the next code listed for the component and manufacturer.
Notes:
x If the codes do not work or your brand is not listed, see “Searching for Component Codes.”
x Sometimes a code listed will only include limited functions. Try other codes that may include
more functionality.
VIZIO VF551XVT User Manual
54
www.VIZIO.com
My Codes
DVD Player
Home Theater
Cable Box
Satellite Box
VCR
Other
Other
Other
Programming your Cable or Satellite Set-Top Box
1. Turn on the Cable or Satellite Set-Top Box.
2. Press and release the CABLE button on the remote control.
3. Press and hold the SET button until the
LED flashes twice.
4. Find the programming code for your Cable
or Satellite Set-Top Box in the code list
below and enter it using the number buttons.
If the code is accepted, the LED flashes
twice after the last digit is entered. If the
LED does not flash twice, repeat Steps 2
through 4 with the next code listed.
5. Point the remote control at the Cable or
Satellite Set-Top Box and press the
POWER button. The Cable or Satellite Set-
Top Box will turn off. If the Cable or Satellite
Set-Top Box does not turn off, repeat Steps
2 through 4 with the next code listed for the
component and manufacturer.
Notes:
x If the codes do not work or your brand is not listed, see •Searching for Component Codes.•
x Sometimes a code listed will only include limited functions. Try other codes that may include
more functionality.
Searching for Component Codes
If you cannot find the manufacturer in the component list or the program code does not work, you can use
the remote control to search for the correct component code.
1. Turn on the component.
2. Press the matching component button on the remote control.
3. Press and hold the SET button until the LED flashes twice.
4. Press 9 9 1. The LED flashes twice.
5. Point the remote control at the component and then alternate between pressing the POWER
button and the component button on the remote control until the component turns off. If the
component still does not respond.
VIZIO VF551XVT User Manual
Version 7/17/2009 55
www.VIZIO.com
Remote Control Codes
Cable Box Codes
(including Cable / PVR Boxes)
A-Mark 00008, 00144
ABC 00237, 00003,
00008, 00014,
00017
Accuphase 00003, 00014,
00017
Acorn 00237
Action 00237
Active 00237
Americast 00899
Amino 01822
Archer 00237
BCC 00276
Bell & Howell 00014
Bell South 00899
British
Telecom
00003
Century 00008
Citation 00017
Clearmaster 00883
ClearMax 00883
Cool Box 00883
Coolmax 00883
Digeo 01187
Digi 00637
Director 00476
Dumont 00637
DX Antenna 01500
Emerson 00014
Fosgate 00276
Fujitsu 01497
GE 00144
General
Instrument
00476, 00810,
00276, 00003,
00012, 00014
Gibralter 00003
GMI 00883
Cable Box Codes
(including Cable / PVR Boxes)
GoldStar 00144
Hamlin
00009, 00273
Hitachi 00003, 00008,
00009
Insight 00476, 00810
Jebsee 00014
Jerrold 00476, 00810,
00276, 00003,
00012, 00014
Maspro 01510
Memorex 00000
Mitsubishi 00003
Motorola 01376, 00476,
00810, 00276,
01187, 01254,
00014, 01106
Multitech 00883
Myrio 01822
NEC 01496
Nova Vision 00008
Novaplex 00008, 00017
NSC 00012, 00637
Oak 00017
Pace 01877, 00877,
00237, 00008
Panasonic 00000, 00008,
00144, 00107,
01488
Panther 00637
Paragon 00000, 00008,
00525
Penney 00000, 00637
Philips 01305, 00317
Pioneer 01877, 00877,
00144, 00533,
01500
Prism 00012
Pulsar 00000
Quasar 00000
Cable Box Codes
(including Cable / PVR Boxes)
RadioShack 00883
RCA 01256
Regal 00276, 00279,
00273
Runco 00000
Samsung 00003, 00144
Scientific
Atlanta
01877, 00877,
00477, 00237,
00003, 00000,
00008, 00012,
00000, 00525,
00899, 00017
Sony 01006, 01460
Sprucer 00144
Starcom 00003, 00014
Stargate 00014
Storm 00637
Sumitomo 01500
Supercable 00276
Supermax 00883
Thomson 01256
Tocom 00012
Torx 00003
Toshiba 00000, 01509
Tristar 00883
United Cable 00276, 00003,
00014
US Electronics 00276, 00003,
00008, 00017
V2 00883
Videoway 00000
Viewmaster 00883
Vision 00883
Vortex View 00883
Zenith 00000, 00525,
00899, 00017
VIZIO VF551XVT User Manual
Version 7/17/2009 56
www.VIZIO.com
Satellite Receiver Codes
(including Sat / PVR Boxes)
Aiwa 01514
AlphaStar 00772
Bell ExpressVu 00775
Chaparral 00216
Coolsat 01806
Crossdigital 01109
DirecTV 01377, 00392,
00566, 00639,
01639, 01142,
00247, 00749,
01749, 00724,
00819, 01856,
01076, 01108,
00099, 01109,
01392, 01414,
01442, 01443,
01444, 01609,
01640
Dish Network
System
01505, 01005,
00775, 01170,
01775
Dishpro 01505, 01005,
00775, 01775
DX Antenna 01530
Echostar 01505, 01005,
00775, 01170,
01775
Expressvu 00775, 01775
Fortec Star 01821
Funai 01377
GE 00392, 00566
General
Instrument
00869
GOI 00775, 01775
Hisense 01535
Hitachi 00749, 00819,
01518
Houston 00775
HTS 00775, 01775
Hughes
Network
Systems
01142, 00749,
01749, 01442,
01443, 01444,
20739
Humax 01790
Satellite Receiver Codes
(including Sat / PVR Boxes)
iLo 01535
Innova 00099
Jerrold 00869
JVC 00775, 01170,
01507, 01775
LG 01226, 01414
Magnavox 00724, 00722
Maspro 01530
McIntosh 00869
Memorex 00724
Mitsubishi 00749
Motorola 00869
NEC 01519
Netsat 00099
Next Level 00869
Optimus 00724
Panasonic 00247, 00701,
01508
Pansat 01807
Paysat 00724
Philips 01142, 00749,
01749, 00775,
00724, 00819,
01076, 00722,
00099, 01442,
20739
Pioneer 01142, 01442
Primestar 00869
Proscan 00392, 00566
Proton 01535
RadioShack 00566, 00775,
00869
RCA 00392, 00566,
01142, 00775,
00855, 00143,
01392, 01442
Samsung 01377, 01142,
01276, 01108,
01109, 01442,
01609, 20739
Sharp 01489
Satellite Receiver Codes
(including Sat / PVR Boxes)
SKY 00099
Sony 00639, 01639,
01524, 01640
Star Choice 00869
Star Trak 00772, 00869
Thomson 00392, 00566
Tivo 01142, 01442,
01443, 01444
Toshiba 00749, 01749,
00790, 00819,
01285, 01501,
01530
UltimateTV 01392, 01640
Ultrasat 01806
Uniden 00724, 00722
US Digital 01535
USDTV 01535
Voom 00869
Zenith 01856
PVR Codes
ABS 21972
Alienware 21972
CyberPower 21972
Dell 21972
DirecTV 20739
Gateway 21972
Hewlett Packard
21972
Howard
Computers
21972
Hughes Network
Systems
20739
Humax 20739
Hush 21972
iBUYPOWER 21972
Linksys 21972
Media Center PC
21972
Microsoft 21972
VIZIO VF551XVT User Manual
Version 7/17/2009 57
www.VIZIO.com
PVR Codes
Mind 21972
Niveus Media 21972
Northgate 21972
Panasonic 20616
Philips 20618, 20739
RCA 20880
ReplayTV 20614, 20616
Samsung 20739
Sonic Blue 20614, 20616
Sony 20636, 21972
Stack 9 21972
Systemax 21972
Tagar Systems 21972
Tivo 20618, 20636,
20739
Toshiba 21008, 21972,
21996
Touch 21972
Viewsonic 21972
Voodoo 21972
ZT Group 21972
Blu-Ray DVD Player Codes
Insignia 22428
Panasonic 21641
Philips 22084
Pioneer 20142
Samsung 20199
Sharp 22250
Sony 21516
Vizio 22553
DVD / PVR Combo Codes
Emerson 20675, 20000
Go Video 21730
Hitachi 21764
Mitsubishi 21403
Panasonic 20490, 21632
Pioneer 20631
RCA 20522, 20880
Sharp 20630, 21256,
21642
Sony 21033
Sylvania 20675, 20000
Toshiba 21503, 21639,
21008, 21996
Victor 21597
DVD Player Codes
3D LAB 20503, 20539
Accurian 21072, 21416
Acoustic
Solutions
20730
Advent 21016
Afreey 20698
Aiwa 20641
Akai 20695, 20705,
20770, 20899,
21089
Alba 20672, 20717
Alco 20790
Allegro
20869
Amphion Media
Works
20872
AMW 20872
Apex Digital 20533, 20672,
20717, 20755,
20794, 20796,
20797, 20830,
21004, 21020,
21056, 21061,
21100
Arrgo 21023
DVD Player Codes
Aspire Digital 21168, 21407
Audiovox 20717, 20790,
21041, 21071,
21072, 21121,
21122
Awa 20730
Axion 21071, 21072
Blaupunkt 20717
Blue Parade 20571
Blue Sky 20695
Bose 21895
Brandt 20651
Broksonic 20695, 20868
Byd:sign 20872
California
Audio Labs
20490
Celestial 21020
Centrex 20672, 21004
Cinea 20831
CineVision 20876, 20833,
20869
Citizen 21003, 21277
Clairtone 20571
Coby 20778, 21086,
21107, 21177
Craig 20831
Creative 20503, 20539
Curtis Mathes 21087
CyberHome 20816, 20874,
21023, 21024,
21117, 21129,
21502
Cytron 20705
Daewoo 20784, 20705,
20770, 20833,
20869, 21169,
21172, 21234,
21242
Dansai 20770
Daytek 20872
Decca 20770
Denon 20490, 20634
VIZIO VF551XVT User Manual
Version 7/17/2009 58
www.VIZIO.com
DVD Player Codes
Denver 20778
Desay 21407
Digitrex 20672
Disney 20675, 21270
DiViDo 20705
Dual 20675, 21068,
21085
Durabrand 21127
DVD2000 20521
Electrohome 21003
Emerson 20591, 20675,
20821, 21268
Enterprise 20591
Entivo 20503, 20539
Enzer 20770
ESA 20821, 21268
Firstline 20651
Fisher 20670
Funai 20675, 21268,
21334
Gateway 21073, 21158
GE 20522, 20815,
20717
Go Video 20573, 20744,
20717, 20715,
20741, 20783,
20833, 20869,
21044, 21075,
21099, 21158,
21304, 21730
Go Vision 21071, 21072
GoldStar 20741, 20801,
20869
Goodmans 20790
Gradiente 20490, 20651
Greenhill 20717
Grundig 20539, 20705
Harman/Kardon 20582, 20702
Hitachi 20573, 20664,
21247, 21764
Hiteker 20672
DVD Player Codes
Humax 21588
iLo 21348
Initial 20717
Insignia 21268
Integra 20571, 20627
IRT 20783
JBL 20702
Jensen 21016
JMB 20695
JVC 20558, 20623,
20867, 21164
Kawasaki 20790
Kenwood 20490, 20534
KLH 20717, 20790,
21020, 21149
Kloss 20533
Koss 20651, 21061
Lasonic 20627, 20798
Lecson 21533
Lenoxx 21127
LG 20591, 20741,
20801, 20869
LiteOn 21058, 21158,
21416, 21440
Loewe 20511, 20741
Logix 20783
Magnasonic 20651, 20675
Magnavox 20503, 20539,
20646, 20675,
20821, 21268
Malata 20782, 21159
Marantz 20503, 20539,
20675
McIntosh 21533
Medion 20651
Memorex 20695, 20831,
21270
Microsoft 20522, 21708
Minato 20752
Mintek 20839, 20717
DVD Player Codes
Mitsubishi
21521, 20521,
21403
Momitsu 21082
Mustek 20730
NAD 20591, 20741
Naiko 20770
NEC 20785, 20869
Nesa 20717
NexxTech 21402
Norcent 21003, 20872,
21107, 21265
Onkyo 20503, 20627,
20792
Optimus 20571
Oritron 20651
Palsonic 20672
Panasonic 20503, 20490,
20571, 20703,
21362, 21462,
21490, 21632,
21762
Philips 20503, 20539,
20646, 20675,
20854, 21260,
21267, 21354
PianoDisc 21024
Pioneer 20525, 20571,
20631
Polaroid 21020, 21061,
21086
Polk Audio 20539
Portland 20770
Presidian 20675, 21072
Prima 21016
Proceed 20672
Proscan 20522
ProVision 20778
Qwestar 20651
Radionette 20741
RadioShack 20571
RCA 20522, 20571,
20717, 20790,
VIZIO VF551XVT User Manual
Version 7/17/2009 59
www.VIZIO.com
DVD Player Codes
20822, 21022,
21132
Realistic 20571
Reoc 20752
Rio 20869
Rotel 20623
Rowa 20823, 21004
Saba 20651
Sampo 20698, 20752
Samsung 20490, 20573,
20744, 20820,
20899, 21044,
21075
Sansui 20695
Sanyo 20670, 20675,
20695, 20873,
21334
Schneider 20783
Schwaiger 20752
Sensory
Science
21158
Sharp 20630, 20675,
20752, 21256,
21642
Sharper Image 21117
Sherwood 20770, 21043
Shinsonic 20533, 20839
Slim Art 20784
SM Electronic 20730
Sonic Blue 20573, 20715,
20783, 20869,
21099
Sony 20533, 21533,
20864, 21033,
21070, 21431
Sova 21122
Superscan 20821
SVA 20717, 20860
Sylvania 20675, 20821,
21268
Symphonic 20675, 20821,
21268, 21334
Tatung 20770
DVD Player Codes
Teac 20571, 20717,
20790
Technics 20490, 20703
Technika 20770
Technosonic 20730
Tevion 20651
Theta Digital 20571
Thomson 20522, 20511
Tivo 21503, 21588
Toshiba 20503, 20573,
20539, 20695,
21045, 21154,
21503, 21588,
21639
Tredex 20800
Unimax 20770
United 20730
Universum 20591
Urban
Concepts
20503, 20539
US Logic 20839
V 21064, 21226
V
enturer 20790
V
ictor 21597
V
izio 21064, 21226
Xbox 20522, 21708
Yamaha 20490, 20539,
20545
Yamakawa 20872
Zenith 20503, 20591,
20741, 20869
Zeus 20784
Zoece 21265
Amplifier / Receiver / Tuner
Codes
ADC 30531
Adcom 30616
Aiwa 31405, 30189,
30121, 31388,
31641
Akai
30244, 31512
Alco 31390
AMC 31077
Amphion
Media Works
31563, 31615
AMW 31563, 31615
Anam 31609, 31074
Apex Digital 31257, 31430,
31774
Arcam 31189
Audiotronic 31189
Audiovox 31390, 31627
B & K 30701, 30702,
30820, 30840
BK 30702
Bose 31229, 30639,
31253, 31841,
31933
Brix 31602
Cairn 30189
Cambridge
Soundworks
31370
Capetronic 30531
Carver 31189, 30189,
30121, 31289
Classic 31352
Coby 31389
Criterion 31420
Curtis Mathes 30014
Daewoo 31250
Delphi 31414
Denon 31360, 30121,
30771, 31142,
31306
Emerson 30531
VIZIO VF551XVT User Manual
Version 7/17/2009 60
www.VIZIO.com
Amplifier / Receiver / Tuner
Codes
Fisher 31801
Garrard 30463
Gateway 31517
Go Video 31532
Grundig 30189
Harman/Kardon
30110, 30189,
30891, 31289,
31304, 31306
Hitachi 31273, 31801
Initial 31426
Inkel 30491
Insignia 31030
Integra 30135, 30842,
31298, 31320
JBL 30110, 31306
JVC 31058, 30074,
31374, 31495,
31811
Kawasaki 31390
Kenwood 31313, 31570,
31569, 30186
KLH 31390, 31412,
31428
Koss 31366, 31497
Lasonic 31798
Lenoxx 31437
Lexicon 31076
LG 31293
Linn 30189
Liquid Video 31497
Magnavox 31189, 31269,
30189, 30391,
30531, 31266,
31514
Marantz 31189, 31269,
30189, 30891,
31289
McIntosh 31289
Micromega 31189, 30189
Mitsubishi 31393
Myryad 31189
Amplifier / Receiver / Tuner
Codes
Nakamichi 31313, 30097
New Castle 30502
Norcent 31389
Nova 31389
Onkyo 30135, 30380,
30842, 31298,
31320, 31531
Optimus 31023, 30074,
30014, 30121,
30186, 30502,
30531, 30670,
31074
Oritron 31366, 31497
Outlaw 30391
Panasonic 31308, 31518,
30309, 30367,
31288, 31316,
31548, 31633,
31763, 31764
Philips 31189, 31269,
30189, 30391,
30891, 31266
Pioneer 31023, 30014,
30150, 30244,
30531, 30630,
31384
Polaroid 31508
Polk Audio 30189, 31289,
31414
Proscan 31254
RadioShack 31609
RCA 31023, 31609,
31254, 30531,
31074, 31390,
31511
Realistic 31609, 30121,
30186
Regent 31437
Revox 30189
Rio 31869
Saba 31519
Samsung 31295, 31304,
31500
Sansui 31189, 30189,
Amplifier / Receiver / Tuner
Codes
31764
Sanyo 31251, 31469,
31801
Sharp 30186, 30771,
31286
Sharper Image 31556
Sherwood 30491, 30502,
31077, 31423,
31517, 31653
Shinsonic 31426
Sirius 31602, 31627,
31811, 31987
Sonic Blue 31532, 31869
Sony 31058, 31441,
31258, 31759,
31622, 30168,
30474, 31406,
31558, 31658,
31758, 31858
Soundesign 30670
Stereophonics 31023
Sunfire 31313
Teac 30463, 31074,
31390, 31528
Technics 31308, 31518,
30309, 31384,
31633
Thorens 31189
Toshiba 30135, 30842,
31788
Venturer 31390
Victor 30074
Waitec 31352
Wards 30189, 30014
XM 31406, 31414
Yamaha 31023, 30176,
30186, 31176,
31276, 31331,
31375, 31476
Zenith 30857, 31293
VIZIO VF551XVT User Manual
Version 7/17/2009 61
www.VIZIO.com
Audio Accessory Codes
Accurian 31106
Altec Lansing 31056, 31485
Apple 31115, 31644
Cambridge
Soundworks
31530
Creative 30872
D-Link 31522
Imerge 31491
Integra 31789
iPort 31917
Marantz 31491
Motorola 31464
NaviPod 31644
Netgear 31785
Omnifi 31605
Onkyo 31789
Roku 31828
Russound 32019
Slim Devices 31844
Sonance 31917
SSI 31522
Vizio 31517, 32454
Yamaha 31809, 31810
VCR Codes
A-Mark 20037, 20240,
20000, 20278,
20046
ABS 21972
Admiral 20060, 20048,
20039, 20047,
20104, 20209,
20020, 20062,
20479
Adventura 20037, 20240,
20000
Adyson 20072
Aiko 20278
Aiwa 20037, 20000,
20124, 20307,
VCR Codes
20479
Akai 20041, 20061,
20106, 20175
Alba 20209, 20072,
20278
Alienware 21972
Allegro 20039
America Action 20278
American High 20035, 20081
Amstrad 20000
Asha 20240
Astra 20035, 20240
Audiovox 20037, 20278,
20038
Avis 20000, 20072
Beaumark 20240
Bell & Howell 20035, 20048,
20039, 20000,
20104, 20046,
20479
Broksonic 20184, 20121,
20209, 20002,
20208, 20479,
21479
Calix 20037
Candle 20037, 20038
Canon 20035
Capehart 20002, 20020,
20062
Carrera 20240
Carver 20035, 20081
CCE 20072, 20278
Cineral 20278
Citizen 20035, 20037,
20240, 20000,
20209, 20278,
20479, 21278
Classic 20037
Colortyme 20060, 20035,
20045, 20278
Colt 20000, 20072
Craig 20037, 20047,
20240, 20072,
VCR Codes
20271
Criterion 20000, 20072
Crosley 20035, 20081,
20000, 20149
Crown 20072, 20278
Curtis Mathes 20060, 20035,
20162, 20240,
20000, 20041,
20278, 20432,
20760, 21035
Cybernex 20240
CyberPower 21972
Daewoo 20037, 20045,
20278, 20020,
20046, 20561,
21278
Daytron 20037, 20278,
20020
Dell 21972
Denon 20081, 20042
Derwent 20041
DirecTV 20739
Dual 20000
Durabrand 20039, 20038
Dynatech 20240, 20000
Electrohome 20060, 20037,
20240, 20000,
20043, 20209,
20061
Electrophonic 20037
Emerald 20184, 20121
Emerex 20032
Emerson 20037, 20184,
20240, 20000,
20121, 20043,
20209, 20002,
20278, 20202,
20208, 20061,
20479, 20561,
20593, 21278,
21479, 21593
Fisher 20039, 20047,
20000, 20104,
20046
Fuji 20035, 20033
Fujitsu 20045, 20000
VIZIO VF551XVT User Manual
Version 7/17/2009 62
www.VIZIO.com
VCR Codes
Funai 20037, 20000,
20072, 20278,
20593, 21593
Garrard 20000
Gateway 21972
GE 20060, 20035,
20048, 20240,
20000, 20149,
20202, 20760,
20807, 21035,
21060
Gemini 20060
General 20045
Genexxa 20037, 20000,
20278
Go Video 20240, 20432,
20526, 20614
GoldStar 20035, 20037,
20039, 20000,
20278, 20038,
21237
Goodmans 20037, 20081,
20000, 20072,
20278, 20020,
20062
Gradiente 20000, 20008
Granada 20081, 20042
Grundig 20081
Harley
Davidson
20000
Harman/Kardon
20081, 20038
Harvard 20072
Harwood 20072
Headquarter 20046
Hewlett
Packard
21972
HI-Q 20035, 20047,
20000
Hitachi 20035, 20037,
20045, 20000,
20042, 20041,
20089, 20105,
21037
Howard
Computers
21972
Hughes Systems
VCR Codes
Network 20042, 20739
Humax 20739
Hush 21972
Hytek 20047, 20000,
20072
iBUYPOWER 21972
ITT Nokia 20240, 20041
Janeil 20240
Jensen 20067, 20041
JVC 20067, 20041,
20008, 20061,
21162
KEC 20037, 20278
Kenwood 20067, 20041,
20038, 20046
KLH 20072
Kodak 20035, 20037
KTV 20000
LG 20037, 20240,
20038, 21037
Linksys 21972
Lloyd's 20240, 20000,
20072, 20038,
20208
Loewe 20081
Logik 20240, 20000,
20072
Lumatron 20278
Luxor 20046, 20106
LXI 20037, 20000,
20042, 20067
M Electronic 20240
Magnasonic 20037, 20240,
20000, 20072,
20278, 20020,
20593, 21278
Magnavox 20035, 20037,
20048, 20039,
20081, 20240,
20000, 20149,
20563, 20593,
20618, 21593,
21781
Magnin 20240
VCR Codes
Marantz 20035, 20081,
20038, 20062
Marta 20037
Matsui 20037, 20209
Matsushita 20035, 20162,
20081, 21162
Media Center
PC
21972
MEI 20035
Memorex 20035, 20162,
20037, 20048,
20039, 20047,
20240, 20000,
20104, 20209,
20072, 20278,
20062, 20046,
20307, 20479,
21037, 21162,
21237, 21262
Metz 20037
MGA 20060, 20240,
20043, 20061
MGN
Technology
20240
Microsoft 21972
Midland 20240
Mind 21972
Minolta 20042, 20105
Mitsubishi 20060, 20048,
20047, 20000,
20042, 20067,
20043, 20041,
20061, 20807
Motorola 20035, 20048
Movie Walker 20072
MTC 20240, 20000,
20072
MTX 20000
Multitech 20039, 20000,
20072
NAD 20240, 20104
NEC 20104, 20067,
20041, 20038
New Tech 20072
Nikko 20037, 20278
VIZIO VF551XVT User Manual
Version 7/17/2009 63
www.VIZIO.com
VCR Codes
Nikkodo 20037, 20278
Nishi 20240
Niveus Media 21972
Noblex 20240
Northgate 21972
Olympus 20035, 20162,
20104
Onkyo 20222
Optimus 21062, 20035,
20162, 20037,
20048, 20047,
20240, 20000,
20104, 20062,
20432, 20593,
21048, 21162,
21262
Optonica 20062
Orion 20184, 20240,
20000, 20104,
20121, 20209,
20002, 20278,
20208, 20479,
21479
Panama 20035
Panasonic 21062, 20035,
20162, 20000,
20020, 20225,
20614, 20616,
21035, 21162,
21262
Penney 20035, 20162,
20037, 20047,
20081, 20240,
20000, 20042,
20067, 20038,
21035, 21237
Pentax 20042, 20105
Philco 20035, 20081,
20000, 20209,
20479
Philips 20035, 20162,
20048, 20081,
20045, 20000,
20209, 20062,
20616, 20618,
20739, 21081,
2118
Pilot 20037
Pioneer 20162, 20081,
VCR Codes
20042, 20067
Polk Audio 20081
Portland 20278, 20020
Presidian 21593
Profitronic 20240
Proscan 20060, 20202,
20760, 21060
Protec 20000, 20072
Protech 20072
Pulsar 20039, 20240,
20278
Pulser 20240
Quarter 20046
Quartz 20035, 20047,
20046
Quasar 20035, 20162,
20002, 21035,
21162
RadioShack 20035, 20162,
20037, 20048,
20047, 20240,
20000, 20104,
20046, 20062,
21037, 21162
Radix 20037
Randex 20037
RCA 20060, 20035,
20048, 20240,
20045, 20000,
20042, 20149,
20105, 20106,
20202, 20760,
20807, 20880,
21035, 21060
Realistic 20035, 20162,
20037, 20048,
20047, 20240,
20000, 20104,
20121, 20278,
20046, 20062,
21162
ReplayTV 20614, 20616
Ricavision 21972
Runco 20039
Samsung 20060, 20240,
20045, 20000,
20038, 20432,
VCR Codes
20739, 21014
Samtron 20240
Sanky 20048, 20039
Sansui 20240, 20000,
20067, 20209,
20041, 20072,
20002, 20271,
20479, 21479
Sanyo 20047, 20240,
20000, 20104,
20046, 20159,
20479
Scientific
A
tlanta
20008
Scott 20184, 20045,
20121, 20043,
20208
Sears 20060, 20035,
20162, 20037,
20048, 20039,
20047, 20033,
20045, 20000,
20042, 20104,
20067, 20043,
20209, 20041,
20072, 20046,
20105, 21237
Sharp 20048, 20047,
20032, 20000,
20062, 20807,
20848
Shintom 20039, 20240,
20000, 20072,
20208
Shogun 20240
Siemens 20037, 20104
Signature 20060, 20035,
20037, 20048,
20000, 20149,
20046, 20479
Singer 20037, 20240,
20072
Sonic Blue 20614, 20616
Sonographe 20046
Sony 20035, 20047,
20032, 20033,
20000, 20067,
20046, 20636,
21032, 21232,
21972
VIZIO VF551XVT User Manual
Version 7/17/2009 64
www.VIZIO.com
VCR Codes
Stack 9 21972
Soundmaster 20000
STS 20042, 20105
SV2000 20000, 20072
SVA 20000
Sylvania 20035, 20081,
20000, 20043,
20593, 21593,
21781
Symphonic 20240, 20000,
20002, 20593,
21593
Systemax 21972
Tagar Systems 21972
Tandy 20000, 20104
Tatung 20048, 20081,
20000, 20067,
20041, 20008
Teac 20000, 20067,
20041
Technics 20035, 20162,
20037, 20000
Teknika 20035, 20037,
20000
Telecorder 20240
Telefunken
20041, 20208
Tevion
20479
Thomas
20000, 20002
Thomson
20060, 20041,
20202
Tisonic
20278
Tivo
20618, 20636,
20739, 21996
TMK
20240, 20000,
20208
TNIX
20037
Tocom
20240
Toshiba 20240, 20045,
20000, 20042,
20043, 20209,
20041, 20062,
20845, 21008,
21145, 21972,
21996
VCR Codes
Tosonic
20278
Totevision
20037, 20240
Touch
21972
Trix
20037
Ultra
20045, 20278,
20020
Unitech
20240
V
ector
20045
Vector
Research
20184, 20038
Vextra
20072
V
ictor
20067, 20041,
20008
Video
Concepts
20045, 20061
V
ideomagic
20037
V
ideosonic
20240, 20000,
20072
Viewsonic
21972
V
illain
20000
V
oodoo
21972
Wards 20060, 20035,
20037, 20048,
20047, 20081,
20033, 20240,
20045, 20000,
20042, 20043,
20041, 20072,
20038, 20149,
20046, 20062,
20479, 20760
Wharfedale
20593
White
Westinghouse
20000, 20209,
20072, 20278,
20479
World
20209, 20002,
20479
XR-1000
20035, 20240,
20000, 20072,
20208
Yamaha
20041, 20038
Zenith 20037, 20039,
20033, 20000,
20209, 20041,
20278, 20479,
21139, 21479
VCR Codes
ZT Group
21972
VIZIO VF551XVT User Manual
Version 7/17/2009 65
www.VIZIO.com
Chapter 8 Maintenance and Troubleshooting
Maintenance
Important
1. Make sure that the power cable is removed from the socket before cleaning the TV.
2. Do not use volatile solvent (such as toluene, rosin and alcohol) to clean the TV. Such
chemicals may damage the housing, screen and remote control, and cause paint to peel.
Cleaning the Housing and Remote Control
1. Use a soft cloth for cleaning.
2. If the housing or remote control is seriously contaminated, use a soft cloth moistened with
diluted neutral cleaner to clean the display. Wring water out of the cloth before cleaning to
prevent water from penetrating into the housing. Wipe the display with a dry cloth after
cleaning.
Cleaning the Screen
1. Use a soft cloth to gently clean the screen.
2. The screen is very fragile. Do not scrape it with any sharp object. Do not press or tap the
screen to avoid cracking. When the screen is seriously contaminated, use a soft cloth
moistened with diluted neutral cleaner to clean the display. Wring water out of the cloth
before cleaning to prevent water from penetrating into the housing. Wipe the display with a
dry cloth after cleaning.
VIZIO VF551XVT User Manual
66
www.VIZIO.com
Troubleshooting Guide
If the TV fails or the performance changes dramatically, check following troubleshooting guide for
possible solutions. Remember to check the peripherals to pinpoint the source of the failure. If the display
still fails to perform as expected, contact the VIZIO for assistance by calling 1-877-MYVIZIO (698-4946)
or e-mail us at
General TV Problems Solution
Receive the error message
“No Signal.”
x Press the INPUT button on the remote control to select a different input source.
x
If you are using cable connected directly to the TV or an antenna, scan for
channels from the Tuner menu in the OSD.
x
Press the TV button on the top of the remote to return to the TV mode.
No power.
x Make sure the power button is ON (VIZIO logo glows white).
x Make sure AC power cord is securely connected to the AC socket.
x Plug another electrical device to the power outlet to verify that the outlet is working.
No sound.
x Press Volume + (Up) on the remote control.
x Press MUTE on the remote control to make sure that MUTE is not ON.
x Check your audio settings. The audio may be set to SAP, or the speakers are set
to off.
x Check the audio connections of external devices that may be connected to the
HDTV.
x If you are using an antenna, the signal strength of the channel may be low. Make
sure your antenna is connected securely to the TV and move the antenna around
the room or close to a window.
If the screen is black.
x Make sure the power button is ON (VIZIO Logo glows white).
x Press the INPUT button on the remote control to select a different input source.
x Check the connections of external devices that may be connected to the HDTV.
x
Press the TV button on the top of the remote to return to the TV mode.
Power is ON but there is no
image on the screen.
x Make sure all cables attached to the HDTV are connected to the correct output on
the external device.
x Adjust brightness, contrast or backlight.
x Press the INPUT button on the remote control to select a different input source.
x
Press the TV button on the top of the remote to return to the TV mode.
Wrong or abnormal colors
appear.
x Check Color and Tint settings in Picture Menu.
x Reset Picture settings.
x Check the video cables to make sure they are securely connected.
x If you are using an antenna, the signal strength of the channel may be low. Make
sure your antenna is connected securely to the TV and move the antenna around
the room or close to a window.
Control buttons do not work.
x Press only one button at a time.
x
Press the TV button on the top of the remote to return to the TV mode.
Remote control does not
work.
x Point the remote control directly at the remote sensor on your TV.
x Remove any obstacles between the remote control and the remote sensor.
x Replace dead batteries with new ones.
x
Press the TV button on the top of the remote to return to the TV mode.
There appear to be image
quality issues.
x If you are using an antenna, the signal strength of the channel may be low. Make
sure your antenna is connected securely to the TV and move the antenna around
VIZIO VF551XVT User Manual
Version 7/17/2009 67
www.VIZIO.com
General TV Problems Solution
the room or close to a window.
x For best image quality, view HD wide-screen programs where possible.
x If HD content is not available view “Standard Definition” from a digital source.
x Standard, analog TV will always be noticeably inferior to HD because your digital
flat panel TV has video that is many times better than old TV so you will see
interference and deficiencies you did not know you had.
You cannot see a picture.
x Make sure the power button is ON (VIZIO logo glows white).
x Make sure AC power cord is securely connected to the AC socket.
x Press the INPUT button on the remote control to select a different input source.
x
Press the TV button on the top of the remote to return to the TV mode.
x Check the connections of external devices that may be connected to the HDTV.
x If your HDTV is connected to a computer, press any button on your keyboard to
“wake” your computer.
x If you are using an antenna, the signal strength of the channel may be low. Make
sure your antenna is connected securely to the TV and move the antenna around
the room or close to a window.
You see a distorted picture or
hear unusual sound.
x You may be getting interference from electrical appliances, cars, motorcycles, or
fluorescent lights. If you have not mounted it on the wall, try moving your HDTV to
another location to see if this is the cause of the problem.
The picture has abnormal
patterns.
x Check the connections of external devices that may be connected to the HDTV.
x Make sure the specifications of external devices meet the specifications of your
HDTV (i.e. resolution).
x If you are using an antenna, the signal strength of the channel may be low. Make
sure your antenna is connected securely to the TV and move the antenna around
the room or close to a window.
The display image does not
cover the entire screen.
x If you are in RGB mode (Computer), make sure that H-Size and V-Position in the
On Screen Display (OSD) are set correctly.
x If you are using TV, AV1, AV2 or Component with 480i input, press WIDE button
on the remote control to scroll through various screen modes.
You can see a picture but you
cannot hear sound.
x Press Volume + (Up) on the remote control.
x Press MUTE on the remote control to make sure that MUTE is not ON.
x Check your audio settings. The audio may be set to SAP, or the speakers are set
to off.
x Check the audio connections of external devices that may be connected to the
HDTV.
The TV has pixels (dots) that
are always dark or colored.
x Your HDTV is manufactured using an extremely high level of precision technology,
however, sometimes some pixels of your HDTV may not display. Pixel defects
within industry specifications are inherent to this type of product and do not
constitute a defective product.
You see “noise” or “trash” on
the screen.
x When your HDTV#s digital capabilities exceed a digital broadcast signal, the signal
is up-converted (increased) to match your TV#s display capabilities. Up-converting
can cause noise or trash.
x If you are using an antenna, the signal strength of the channel may be low. Make
sure your antenna is connected securely to the TV and move the antenna around
the room or close to a window.
You switch to a different input
and the volume changes.
x The TV remembers the volume level from the last time you adjusted it. If the
sound level is higher or lower from another source, then the volume will change.
You switch to a different input
x The TV remembers the viewing mode from the last time you used a particular input
VIZIO VF551XVT User Manual
68
www.VIZIO.com
General TV Problems Solution
and the screen size changes. (AV-1, AV-2, Component, HDMI and TV).
Tips for High-Definition Users.
x Your HDTV is an ideal platform for viewing High Definition Content.
x Best image quality will be achieved by HDMI. The next best is Component,
followed by Composite.
x Due to variances in broadcast practices, it is possible some image distortions can
occur.
Tips for Letterbox Content
Users.
x Some Letterboxed (or “Widescreen”) versions of DVD movies are formatted for
standard 4:3 Televisions. Your HDTV has the ability to expand this content so the
entire screen is filled at the expense of image accuracy. To use this function, press
ZOOM on the remote control to cycle among the options.
Media Viewer
Problems
Solution
USB device is not recognized.
x Make sure the device is correctly inserted.
x Make sure the device is FAT or FAT32
x Make sure it contains the supported files.
Image or sound is interrupted
or distorted.
x Make sure the device is correctly inserted.
x Make sure that the file complies with the supported format, bit rate and/or profile.
Also check the file for damage.
x Some files that comply with the supported format may not play back or display
properly.
Slideshow doesn#t start.
x Make sure the viewer isn#t in pause, rotation, or zoom mode.
Telephone & Technical Support
Products are often returned due to a technical problem rather than a defective product that may result in
unnecessary shipping charges billed to you. Our trained support personnel can often resolve the problem
over the phone. For more information on warranty service or repair, after the warranty period, please
contact our Support Department at the number below.
Customer support and quality service are integral parts of VIZIO#s commitment to service excellence.
For technical assistance contact our VIZIO Technical Support Department via email or phone.
Email
(877) 698-4946 Fax: (949) 585-9563
Hours of operation: Monday - Friday: 6 am to 9 pm
Saturday $ Sunday: 8 am to 4 pm
Please have your VIZIO model number, serial number, and date of purchase available before you call.
VIZIO
Address:
39 Tesla
Irvine, CA 92618, USA
Telephone: (949) 428-2525 Fax: 949-585-9514
Web:
www.vizio.com
VIZIO VF551XVT User Manual
Version 7/17/2009 69
www.VIZIO.com
Compliance
Caution: Always use a power cable that is properly grounded. Please use the AC cords listed below for
each area.
USA UL
Canada CSA
Germany VDE
UK BASE/BS
Japan Electric Appliance Control Act
FCC Class B Radio Interference Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Notice:
1. The changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
2. Shielded interface cables and AC power cord, if any, must be used in order to comply with
the emission limits.
3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modification to this equipment. It is the responsibilities of the user to correct such
interference.
VIZIO VF551XVT User Manual
70
www.VIZIO.com
Specifications
Specifications
Panel 54.64” Diagonal, 16:9 Aspect Ratio
Resolution 1920 x 1080 pixels
Pixel (Dot) Pitch 0.630mm(H) x 0.630mm(V)
Display Compatibility FHDTV (1080P)
Colors 1.06 Billion
Brightness
cd/m
2
(typical)
500nits
Contrast 1400:1
Smart Dimming: 2 Million:1
Response Time 5ms (typical)
Viewing Angle 178° (horizontal/vertical)
Inputs 1x RF
2x Composite Video and stereo audio (one
stereo audio shared with Component input)
1 back, 1 side
1x S-Video
2x Component and stereo audio (one stereo
audio shared with Composite input) 1 back, 1
side
5x HDMI, 4 back, 1 side
1x RGB
1x Media Port (USB)
Outputs 1x SPDIF Optical Digital Audio, 1x Stereo Audio
Features 1080P FHDTV, HDMI v1.3,3D comb filter, Zero bright pixel guarantee Smart Dimming Function
technology, HD game port, Noise reduction, 10-bit(D) panel, 10-bit video processing, MTS
stereo decoder, Dolby Digital for ATSC/QAM, Signal Compatibility:480i (SDTV), 480P (EDTV),
720P (HDTV), 1080i (HDTV), 1080P (FHDTV), Channel skip/add, Video/input naming
capability, Closed caption, Parental control/V-Chip 2.0, Programmable Timer, Freeze,
PIP/POP, VESA mount compatible, SRS TSHD/TruVolume. ATSC/Clear QAM tuner, NTSC
video decoding, 3:2 or 2:2 reverse pull-down, Motion adaptive de-interlace, Progressive video
scan via Component/VGA/HDMI, FHDTV via HDMI or Component, Color temperature
adjustments of 6500K/9300K/11000K, Independent Red/Green/Blue adjustments for color
temperature fine tuning, Computer support at 640x480/800x600/1024x768/1920x1080 via
VGA/HDMI.
Special Features
x MEMC, 240Hz Panel
x SRS TruVolume, SRS TSHD
x Multi Media port
Speakers 2xBuilt-in, 15W Speakers
Panel Life 40,000 hours to half the original brightness
Power
Input IEC Connector for direct power line connection
Voltage Range 100~240Vac at 50/60Hz
Power Consumption 154W (Avg), 0.37W standby
Environmental Conditions
Operating Temperature: 5°C~35°C, Relative Humidity: 20~80%, Altitude: 0~14,000 ft
Non-Operating Temperature: -20°C~50°C, Relative Humidity: 10~70%, Altitude: 0~40,000 ft
VIZIO VF551XVT User Manual
Version 7/17/2009 71
www.VIZIO.com
Dimensions 51.5” W x 35.9” H x 13.5” D with stand; 51.5” W x 33.9” H x 5” D without stand
Net Weight 77.96 lbs without stand, 90.25 lbs with stand
Gross Weight 110.87 lbs
Certifications CSA, CSA-US, FCC Class B, Bets-7, AV Safety certificate 60065
Compliances Energy Star 3.0. ATSC Spec A/65, EIA/CEA-766-A
*Product specifications may change without notice or obligation.
Note: The Federal Communications Commission (FCC), the Consumer Electronics Association (CEA)
and the Consumer Electronics Retailers Coalition (CERC) have made a new tip sheet available for digital
television (DTV) retailers to reproduce and distribute to consumers on the sales floor. The file may be
downloaded online at www.dtv.gov. While you’re there, check out the other useful information in the FCC
is making available to consumers interested in learning more about the analog to digital transition.
VIZIO VF551XVT User Manual
72
www.VIZIO.com
Limited Product Warranty
VIZIO provides a “ONE-YEAR LIMITED WARRANTY” against manufacturing defects in materials and
workmanship to the original purchaser of a new VIZIO display purchased from an authorized VIZIO U.S.
reseller and used in the fifty (50) United States or Puerto Rico.
VIZIO's Responsibility
VIZIO displays purchased new from an authorized VIZIO U.S. reseller and that are used in the fifty (50)
United States or Puerto Rico are warranted to be free from manufacturing defects in materials and
workmanship for one (1) year from the date of the original retail purchase. If the display fails to conform to
this limited warranty, VIZIO will, at its option and sole discretion, repair or replace the display.
Labor
During the one-year limited warranty period, VIZIO will provide, when needed, service labor to repair a
manufacturing defect. Repairs required on displays which are thirty (30) inches and larger generally will
be made “on-site” where the display is installed. The determination for performing the on-site repair is
dependent upon the manufacturing defect and is at VIZIO's option and sole discretion. Repairs required
on displays which are less than thirty (30) inches generally will be performed at a VIZIO service center.
Parts
Repairs may be made with new or recertified parts, or the entire unit may be replaced with a new or
recertified unit, at VIZIO's option and sole discretion. Replacement parts or replacement units provided
under this limited warranty are warranted for the remaining portion of the original warranty period, or for
ninety (90) days from warranty service or replacement, whichever is later.
How to Obtain Warranty Service
To obtain warranty service, contact VIZIO Technical Support via email at [email protected], via
phone at 877-MYVIZIO (877-698-4946), or via postal mail at VIZIO Technical Support, 39 Tesla, Irvine,
CA 92618. You must provide the model, serial number, and date of purchase. VIZIO Technical Support is
available from 6:00AM to 9:00PM Pacific Time, Monday through Friday, and 10:00AM to 2:00PM Pacific
Time, Saturday and Sunday. Please note that holiday hours may vary. For up to date information, please
visit www.VIZIO.com.
VIZIO reserves the right to assess all warranty claims and to determine if defects or damages are covered
by this limited warranty. In case of a claim that is not covered by this warranty, you will be contacted to
determine whether VIZIO should repair the damage for a fee or whether the product should be returned to
you as received by the service technician or service center.
Parts and service labor that are VIZIO's responsibility under this limited warranty will be provided without
charge. All other service is at the customer's expense. VIZIO reserves the right to charge the customer for
any service call for anything not covered by this limited warranty. Before you ask for warranty service,
please review your User Manual. You may avoid a service call and a service charge.
Please refer to the reverse side of this page for additional information regarding how to obtain warranty
service.
PLEASE DO NOT RETURN YOUR UNIT TO VIZIO WITHOUT PRIOR
AUTHORIZATION.
Not Covered
This limited warranty does not cover the following: cosmetic defects; damage, malfunctions or failures
resulting from shipping or transit, improper or faulty installation, abuse, operation contrary to furnished
instructions, operation on incorrect power supplies, products not supplied by VIZIO, modification,
alteration, improper servicing or tampering; damage from fire, water, lightning, power surges, abnormal
environmental conditions or other acts of nature; normal wear and tear; unsatisfactory visual or audio
performance not caused by a manufacturing defect; or displays with a missing or unreadable serial
number. Operation of the display for commercial purposes or in applications or uses for which the display
is not intended is not covered by this limited warranty. "Image Sticking", caused by static images on the
screen for extended periods and or excessive brightness and contrast levels, is not covered by this
VIZIO VF551XVT User Manual
Version 7/17/2009 73
www.VIZIO.com
limited warranty. Installation, removal, transportation and reinstallation of a display, and routine
maintenance and cleaning, are not covered by this limited warranty.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED OR DESCRIBED ABOVE.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF
TIME SET FORTH ABOVE. VIZIO'S TOTAL LIABILITY FOR ANY AND ALL LOSSES AND DAMAGES
RESULTING FROM ANY CAUSE WHATSOEVER, INCLUDING VIZIO'S NEGLIGENCE, ALLEGED
DAMAGE, OR DEFECTIVE GOODS, WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT,
SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE DISPLAY. VIZIO SHALL NOT BE
RESPONSIBLE FOR LOSS OF USE, COMMERCIAL LOSS, LOST REVENUE OR LOST PROFITS, OR
OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY MENUS OR THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to
state. This is the only warranty applicable; no one is authorized to extend or modify it or to grant any other
warranty on VIZIO's behalf.
Owner's Responsibility
To ensure warranty service, keep the dated bill or sales receipt as evidence of the purchase date and
location. This limited warranty applies only to original purchaser and is non-transferable.
Note: Warranty service conditions are subject to change. For the latest Warranty Terms and Conditions
and additional information regarding VIZIO's Limited Product Warranty, please see complete details
online at www.VIZIO.com.
VIZIO Return Policy
VIZIO's return policy allows for products purchased directly from VIZIO to be returned by the original
purchaser during the initial thirty (30) day period following the date of purchase. A VIZIO return
authorization number must first be obtained as provided below. The refund will be the purchase price
actually paid by the purchaser less a ten percent (10%) restocking fee per each item returned. Shipping
and handling are not refundable.
The return authorization number must first be obtained from VIZIO's Customer Service by emailing
through Friday, and 10:00AM to 2:00PM Pacific Time, Saturday and Sunday. Please note that holiday
hours may vary. For up to date information, please visit www.VIZIO.com.
Products must be returned to the address specified by VIZIO Customer Service and must be shipped in
the original packaging, with freight prepaid to VIZIO, and must be received in new and unused condition.
The return authorization number must be included in the packaging. VIZIO reserves the right to assess
fees for any damaged or missing parts in addition to the ten percent (10%) restocking fee.
Return authorization numbers are valid for only fifteen (15) days from issuance. The customer is
responsible for and must prepay all shipping charges and shall assume all risk of loss or damage to the
product while in transit to VIZIO. If the product is returned to VIZIO (i) without a VIZIO return authorization
number, and/or (ii) beyond the fifteen (15) day period, and/or (iii) without proper packaging, VIZIO retains
the right to refuse delivery of such return or may return the unit to the customer at the customer's expense
and with no refund issued. This return policy does not apply to defective products. Please read VIZIO's
Limited Product Warranty for warranty terms and conditions.
VIZIO VF551XVT User Manual
74
www.VIZIO.com
On-Site Warranty Repair Procedure
On-Site Warranty Repair generally is performed on repairable displays which are 30 inches and
larger.
If VIZIO Technical Support determines that a problem with a display unit may be within the terms and
conditions of the VIZIO Limited Product Warranty and that an on-site repair may be performed, the
customer will be provided with an on-site repair authorization number and on-site repair instructions. The
determination for performing the on-site repair may be dependent upon the manufacturing defect and is at
VIZIO's option and sole discretion. Proof of purchase is required to confirm the product is within the one-
year limited warranty period and meets the terms and conditions of the VIZIO Limited Product Warranty.
On-site repair service is requested through VIZIO's third-party service provider. After VIZIO provides the
customer with the on-site repair (OSR) authorization number, the third-party service provider will contact
the customer and will schedule the repair at the customer's location. The total approximate time for the
repair process, which includes the repair diagnosis, dispatching the technician, shipping the replacement
part(s), and arranging the appointment with the customer, is completed within approximately 3 to 5
business days, pending availability of these factors.
If it is determined the product can not be repaired on-site, the customer will be required to ship the unit to
VIZIO's service center, per the below warranty replacement procedure.
VIZIO is not responsible for the de-installation or re-installation of the product. However, some standard
installation may be performed during the on-site repair, at VIZIO's option and sole discretion. Please read
VIZIO's Limited Product Warranty for warranty terms and conditions.
Warranty Replacement Procedure
Warranty Replacement generally is performed on displays which are determined to be
economically unrepairable.
If VIZIO Technical Support determines that a problem with a display unit may be within the terms and
conditions of the VIZIO Limited Product Warranty and that a repair is not economically possible, based on
certain manufacturing defects in materials and/or workmanship, and/or at VIZIO's option and sole
discretion, the customer will be provided with a return authorization number and replacement instructions.
Proof of purchase is required to confirm the product is within the one-year limited warranty period and
meets the terms and conditions of the VIZIO Limited Product Warranty.
For displays forty-two inches (42") and larger, VIZIO will generally cover the transportation charges to
perform an on-site swap of the original unit with the replacement unit. For displays under forty-two inches
(42"), the customer is responsible for the transportation charges to VIZIO's service center. VIZIO will be
responsible for the return transportation charges from the service center to the customer. Please read
VIZIO's Limited Product Warranty for warranty terms and conditions.
Mail-In Warranty Repair Procedure
Mail-In Warranty Repair generally is performed on displays which are smaller than 30 inches.
If VIZIO Technical Support determines that a problem with a display unit may be within the terms and
conditions of the VIZIO Limited Product Warranty and that a mail-in repair may be performed, the
customer will be provided with a return authorization number and mail-in repair instructions. Proof of
purchase is required to confirm the product is within the one-year limited warranty period and meets the
terms and conditions of the VIZIO Limited Product Warranty.
The customer will be provided with instructions for packing and shipping the unit to the VIZIO service
center. The original carton box and packing material, or an equivalent as designated by VIZIO, must be
utilized. The cost of shipping to VIZIO's service center is at the customer's expense. After the product is
repaired and tested, the VIZIO service center will ship the unit back to the customer at VIZIO's expense.
VIZIO is not responsible for the de-installation or re-installation of the product. Please read VIZIO's
Limited Product Warranty for warranty terms and conditions.
PLEASE DO NOT RETURN YOUR UNIT TO VIZIO WITHOUT PRIOR
AUTHORIZATION.
VIZIO VF551XVT User Manual
Version 7/17/2009 75
www.VIZIO.com
Index
Accessories................................................................9
Adjustments
Advanced .............................................................40
Channel................................................................12
Closed Caption.....................................................16
Selecting the Screen Size ..............................16, 52
Volume.................................................................12
Antenna....................................................................18
Audio Menu..............................................................43
Analog Audio Out adjustments.............................44
Audio Mode adjustments......................................43
Balance adjustments............................................43
Digital Audio Out ..................................................43
Equalizer adjustments..........................................43
Lip Sync adjustments ...........................................44
Reset Audio Mode................................................44
Speaker adjustments ...........................................43
SRS TruVolume ...................................................43
SRS TSHD (surround sound) adjustments ..........43
Black bars ................................................................52
Blocking Channels ...................................................49
Brightness ................................................................41
Cable Box
Connecting...........................................................19
Camcorder
Connecting...........................................................25
CC Closed Caption ............................................16, 48
Changing Channels..................................................39
Channel information .................................................46
Cleaning your VIZIO TV ...........................................65
Coaxial connection
Satellite box..........................................................22
Coaxial Connection
cable TV...............................................................22
Color ........................................................................41
Component Connector .............................................18
Composite Connector ..............................................18
Computer
Connecting...........................................................27
Connecting Equipment
Cable....................................................................19
Computer .............................................................27
DVD .....................................................................23
Rear Panel Connections ......................................13
Satellite Box .........................................................19
Side Panel Connections.......................................14
Sound system ......................................................26
Stereo ..................................................................26
VCR .....................................................................25
Video Camera ......................................................25
Contents.....................................................................9
Contrast ...................................................................41
Controls
Front Panel...........................................................12
Side Panel............................................................12
Daylight Savings ......................................................45
DTV Transition ...........................................................5
DVD Player
Connecting...........................................................23
DVI
Cable Box ............................................................20
DVD Player ..........................................................23
Satellite Box .........................................................20
Fine Tuning the picture ............................................37
GUIDE Button ..........................................................39
HDMI........................................................................18
Horizontal/Vertical Position adjustments ..................49
INFO Button .............................................................39
Inputs
Antenna..................................................................4
Connectors...........................................................18
Installation services....................................................9
Maintenance of TV ...................................................65
Media Port................................................................29
Music Settings......................................................32
Picture Settings ....................................................31
Video Settings ......................................................33
Naming Inputs..........................................................48
On Screen Display ...................................................40
Parental Controls .....................................................49
Block Unrated Programming ................................51
Canadian English Rating......................................50
Canadian French Rating ......................................51
Change the Password..........................................51
Channel Block ......................................................49
DTV Rating...........................................................51
Rating Enable.......................................................49
US Movie Rating
..................................................50
US TV Rating .......................................................50
Picture Menu............................................................41
Adaptive Luma .....................................................42
Advanced Video ...................................................42
Backlight ..............................................................41
Brightness ............................................................41
Color ....................................................................41
Color Enhancement .............................................42
Color Temperature ...............................................42
Contrast ...............................................................41
Noise Reduction...................................................42
Picture Mode ........................................................41
Reset Picture Mode..............................................42
Sharpness............................................................41
Smooth Motion .....................................................42
Tint .......................................................................41
PIP ...........................................................................46
Remote ....................................................................15
Batteries...............................................................17
Programming........................................................53
Programming Cable Box ......................................54
Programming DVD Player....................................53
Programming Home Theater System...................53
Programming Satellite Box...................................54
Range ..................................................................17
Reset All Settings.....................................................51
RGB .........................................................................18
Connecting your PC .............................................27
Safety Instructions......................................................2
Safety Strap .............................................................11
Satellite Box
Connecting...........................................................19
Screen Size explanation ..........................................52
Search for channels .................................................45
VIZIO VF551XVT User Manual
76
www.VIZIO.com
Select Language (MTS) ...........................................45
Setting up.................................................................10
Setup Menu..............................................................46
CC........................................................................48
Language setup ...................................................46
Parental Controls .................................................49
PIP .......................................................................46
Setup Wizard........................................................51
System Menu .......................................................51
Wide.....................................................................47
Sharpness................................................................41
Skip Channel............................................................45
Sleep timer...............................................................47
Specifications
Media Port............................................................29
TV ........................................................................70
Stereo
Connecting...........................................................26
S-Video ....................................................................18
Technical Support ....................................................68
Time Zone................................................................45
Time Zone................................................................37
Tint ...........................................................................41
Troubleshooting .......................................................66
TV Menu ..................................................................45
Auto Search adjustments .....................................45
Partial Channel Search ........................................45
Skip Channel........................................................45
Tuner Mode adjustments .....................................45
VCR
Connecting...........................................................25
Viewing Modes.........................................................52
Volume.....................................................................39
Wall mounting ..........................................................10
Warranty ..................................................................72
Warranty services ......................................................9
Watching TV
Basic Adjustments................................................39
Basic connections ................................................34
First Startup..........................................................34
Getting your Programs .........................................38
Program Information ............................................39
Wide.........................................................................47
Wizard......................................................................
51
