#1 How to Installation Leveling System?
1: Lay refrigerator & freezer on its back on packaging material or a drop cloth to prevent damage. Remove all four rear leg levelers by unscrewing counterclockwise. Remove all four front leg levelers by unscrewing the outer peg and two bolts on each front leveler with a 5/16" nut driver. Remove the hinge cover if installed (Figure 1, right detail).
2: Lay the parts out on a cleared area face down. Be sure to place a drop cloth over the floor to prevent scratching trim kit and/or floor.
3: Fit the first Leveler ASsembly onto a refrigerator/freezer.
Using the 4H bolts from step 1, fasten the front of the Leveler Assembly to the refrigerator/freezer using a 5/16" Nut Driver (Figure 4). If more fastening space is required, rotate the bolt labeled "F" clockwise (Figure 5) using a flat head screwdriver or a 3/8" socket wrench. Using a 5H bolt and a power drill, fasten the bottom of the Leveler Assembly with a 3/8" Hex drill bit in whichever hole overlaps the screw hole. Attach remaining 3 Leveler Assemblies as described in the previous 3 steps. With the unit(s) still on their backs, adjust all leveling wheels to approximately the orientation
