en Safety
2
Table of contents
USER MANUAL
1 Safety....................................................................2
2 Preventing material damage ...............................4
3 Environmental protection and saving en-
ergy .......................................................................5
4 Familiarising yourself with your appliance ........6
5 Accessories..........................................................8
6 Before using for the first time ...........................10
7 Basic operation ..................................................10
8 Time-setting options..........................................11
9 Childproof lock...................................................12
10 Rapid heating .....................................................12
11 Sabbath mode ....................................................13
12 Basic settings.....................................................13
13 HomeConnect ...................................................14
14 Cleaning and servicing......................................16
15 Cleaning functions.............................................18
16 Shelf supports....................................................20
17 Appliance door...................................................20
18 Troubleshooting.................................................24
19 Disposal..............................................................26
20 Customer Service...............................................26
21 How it works.......................................................27
22 INSTALLATION INSTRUCTIONS .......................30
22.1 General installation instructions....................
...30
1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡ To prepare meals and drinks.
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 4000m above
sea level.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
Always place accessories in the cooking com-
partment the right way round.
→"Accessories", Page8
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
▶
Never store combustible objects in the
cooking compartment.
▶
If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order
to stifle any flames.
Loose food remnants, fat and meat juices
may catch fire.
▶
Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.
Safety en
3
Opening the appliance door creates a
draught. Greaseproof paper may come into
contact with the heating element and catch
fire.
▶
Never place greaseproof paper loosely
over accessories when preheating the ap-
pliance and while cooking.
▶
Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶
Caution should be exercised here in order
to avoid touching heating elements.
▶
Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
▶
Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire.
▶
Only use small quantities of drinks with a
high alcohol content in food.
▶
Open the appliance door carefully.
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶
Never touch these hot parts.
▶
Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, de-
pending on the temperature.
▶
Open the appliance door carefully.
▶
Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶
Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶
Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
▶
Keep your hands away from the hinges.
Components inside the appliance door may
have sharp edges.
▶
Wear protective gloves.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
▶
Only use genuine spare parts when repair-
ing the appliance.
▶
If the power cord of this appliance is dam-
aged, it must be replaced by trained spe-
cialist staff.
If the insulation of the power cord is dam-
aged, this is dangerous.
▶
Never let the power cord come into contact
with hot appliance parts or heat sources.
▶
Never let the power cord come into contact
with sharp points or edges.
▶
Never kink, crush or modify the power
cord.
An ingress of moisture can cause an electric
shock.
▶
Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the appliance or the power cord is dam-
aged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked
or fractured surface.
▶
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶
If the appliance or the power cord is dam-
aged, immediately unplug the power cord
or switch off the fuse in the fuse box.
▶
Call customer services. →Page26
WARNING‒Danger: Magnetism!
Permanent magnets are used in the control
panel or in the controls. These may affect
electronic implants, e.g. heart pacemakers or
insulin pumps.
▶
Wearers of electronic implants must stay at
least 10 cm away from the control panel.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶
Keep packaging material away from chil-
dren.
en Preventing material damage
4
▶
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
1.5 Halogen bulb
WARNING‒Risk of burns!
The bulbs in the cooking compartment get
very hot. There is still a risk of burning for
some time after they have been switched off.
▶
Do not touch the glass cover.
▶
Avoid contact with your skin when cleaning.
WARNING‒Risk of electric shock!
When changing the bulb, the bulb socket con-
tacts are live.
▶
Before replacing the bulb, ensure that the
appliance is switched off in order to pre-
vent a potential electric shock.
▶
Also unplug the appliance from the mains
or switch off the circuit breaker in the fuse
box.
1.6 Cleaning function
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices
may catch fire when the cleaning function is in
progress.
▶
Before you start the cleaning function, al-
ways remove coarse dirt from the cooking
compartment.
▶
Never clean accessories at the same time.
The outside of the appliance gets very hot
when the cleaning function is in progress.
▶
Never hang combustible objects, e.g. tea
towels, on the door handle.
▶
Leave the front of the appliance clear.
▶
Keep children at a safe distance.
If the door seal is damaged, a large amount
of heat is generated around the door.
▶
Do not scrub or remove the seal.
▶
Never operate the appliance if the seal is
damaged or missing.
WARNING‒Risk of serious harm to
health!
The appliance gets very hot when the clean-
ing function is in progress. The non-stick coat-
ing on baking trays and tins is destroyed and
noxious gases are released.
▶
Never clean non-stick baking trays or bak-
ing tins using the cleaning function.
▶
Never clean accessories at the same time.
WARNING‒Risk of harm to health!
The cleaning function heats up the cooking
compartment to a very high temperature so
that food left over from roasting, grilling and
baking will burn off. This process releases va-
pours, which can irritate mucous membranes.
▶
Keep the kitchen well ventilated while the
cleaning function is running.
▶
Do not remain in the room for long periods.
▶
Keep children and pets away.
WARNING‒Risk of burns!
The cooking compartment gets very hot when
the cleaning function is in progress.
▶
Never open the appliance door.
▶
Allow the appliance to cool down.
▶
Keep children at a safe distance.
The outside of the appliance gets very hot
when the cleaning function is in progress.
▶
Never touch the appliance door.
▶
Allow the appliance to cool down.
▶
Keep children at a safe distance.
2 Preventing material damage
2.1 General
ATTENTION!
Objects on the cooking compartment floor at over
50°C will cause heat to build up. The baking and
roasting times will no longer be correct and the enamel
will be damaged.
▶
Do not place any accessories, greaseproof paper or
foil of any kind on the cooking compartment floor.
▶
Only place cookware on the cooking compartment
floor if a temperature above 50°C has been set.
When the cooking compartment is hot, any water in-
side it will create steam. The change in temperature
may cause damage.
▶
Never pour water into the cooking compartment
when it is still hot.
▶
Never place cookware containing water on the
cooking compartment floor.
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶
Allow the cooking compartment to dry after use.
▶
Do not keep moist food in the cooking compartment
for a long time with the door closed.
Environmental protection and saving energy en
5
▶
Do not store food in the cooking compartment.
Leaving the appliance to cool down with the door open
will damage the front of neighbouring kitchen units over
time.
▶
Always allow the cooking compartment to cool
down with the door closed after cooking at high
temperatures.
▶
Take care not to trap anything in the appliance
door.
▶
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced during
operation.
Fruit juice dripping from the baking tray leaves stains
that cannot be removed.
▶
When baking very juicy fruit flans, do not pack too
much on the baking tray.
▶
If possible, use the deeper universal pan.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶
Never use oven cleaner in the cooking compartment
when it is still warm.
▶
Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
If the seal is very dirty, the appliance door will no
longer close properly during operation. This may dam-
age the front of adjacent kitchen units.
▶
Keep the seal clean at all times.
▶
Never operate the appliance if the seal is damaged
or missing.
Sitting or placing objects on the appliance door may
damage it.
▶
Do not place or hang objects on the appliance door.
▶
Do not place cookware or accessories on the appli-
ance door.
With certain models, accessories may scratch the door
pane when closing the appliance door.
▶
Always push accessories fully into the cooking com-
partment.
3 Environmental protection and saving energy
Help protect the environment by using your appliance
in a way that conserves resources and by disposing of
reusable materials properly.
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
Information about current disposal methods are
available from your specialist dealer or local author-
ity.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Only preheat the appliance if the recipe or the recom-
mended settings tell you to do so.
¡
Not preheating the appliance can reduce the en-
ergy used by up to 20%.
Use dark-coloured, black-coated or enamelled baking
tins.
¡
These types of baking tin absorb the heat particu-
larly well.
Open the appliance door as little as possible during
operation.
¡
This will maintain the temperature in the cooking
compartment and eliminate the need for the appli-
ance to reheat.
When baking multiple dishes, do so in succession or
in parallel.
¡
The cooking compartment is heated after baking
the first dish. This reduces the baking time for the
second cake.
If the cooking time is relatively long, you can switch
the appliance off 10minutes before the cooking time
ends.
¡
There will be enough residual heat to finish cooking
the dish.
Remove any accessories that are not being used from
the cooking compartment.
¡
Accessories that are not being used do not need to
be heated.
Allow frozen food to defrost before cooking.
¡
This will save the energy that would otherwise be
required to defrost it.
en Familiarising yourself with your appliance
6
4 Familiarising yourself with your appliance
4.1 Controls
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
1
2 3 4
1
Buttons
→"Buttons", Page6
2
Function selector
You can turn the function selector clockwise or
anti-clockwise from the zero setting.
→"Types of heating", Page7→"Functions",
Page7
3
Display
→"Display", Page6
4
Temperature selector
Use the temperature selector to set the temper-
ature for the type of heating or select the set-
ting for other functions. You can turn the tem-
perature selector clockwise and anti-clockwise.
→"Temperature and setting levels", Page7
Note:Depending on the appliance type, the control
knobs can be pushed in. To click it in or out, push the
control knob in when it is in the off position.
4.2 Buttons
The buttons are touch-sensitive surfaces. Press the corresponding button to select a function.
Symbol Name Use
Time-setting options Sets the time, timer, cooking time or end time
→"Time-setting options", Page11
Left arrow Decreases the adjustment values
Right arrow Increases the adjustment values
Rapid heating Starts or cancels rapid heating
→"Rapid heating", Page12
Information ¡ Displays the current cooking compartment temperature
¡ Set basic settings
→"Basic settings", Page13
4.3 Display
The display shows the current settings, options or relevant information.
The red bar above or below a symbol indicates which value is active or can be changed.
Symbol Name Use
Temperature too high The temperature in the cooking compartment is too high for the operating mode;
leave the appliance to cool down
→"Residual heat", Page8
Sabbath mode Sabbath mode activated
→"Sabbath mode", Page13
Childproof lock activ-
ated
The childproof lock is activated
→"Childproof lock", Page12
Door lock Appliance door is locked
→"Childproof lock", Page12
→"Pyrolytic self-cleaning ", Page18
Familiarising yourself with your appliance en
7
Symbol Name Use
Temperature display Appliance is heating
→"Temperature display", Page8
4.4 Types of heating
Here you can find an overview of the types of heating. You can find recommendations on using the types of heating.
Use the function selector to set the types of heating.
Symbol Type of heating and
temperature range
What it's used for/how it works
CircoTherm hot air
30-200°C
Bake and roast on one or more levels.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment.
CircoTherm gentle
125-200°C
Cook selected dishes gently on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back
wall evenly around the cooking compartment. The food is cooked in phases us-
ing residual heat.
Always keep the appliance door closed when cooking.
This type of heating is used to determine the energy consumption in air recircu-
lation mode and the energy efficiency class.
Bread baking setting
180-240°C
For baking bread, bread rolls and baked goods that require high temperatures.
Pizza setting
30-275°C
Cook pizza or dishes that require a lot of heat from below.
The bottom heating element and the ring-shaped heating element in the back
wall heat the cooking compartment.
Bottom heating
30-250°C
Final baking or cooking food in a bain marie.
Heat is emitted from below.
Full-surface grill
30-275°C
From 275°C:
Grill flat items such as steak and sausages, or make toast. Gratinate food.
The entire area underneath the grill element becomes hot.
Circo-roasting
30-250°C
Roast poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the
hot air around the food.
Top/bottom heating
30-275°C
Traditionally bake or roast on one level. This type of heating is ideal for cakes
with moist toppings.
The heat is emitted evenly from above and below.
This type of heating is used to measure the energy consumption in the conven-
tional mode.
4.5 Functions
Here you can find an overview of the functions. Use the function selector to set the functions.
Note:If you operate your appliance with the HomeConnect app, even more functions are available for you. You can
find more information about this in the app.
Symbol Name Use
Oven light Illuminate the cooking compartment without heating.
→"Lighting", Page8
Remote start
Start and operate the appliance via the Home Connect app. →Page14
Cleaning functions
¡ EasyClean removes light dirt from the cooking compartment. →"Cleaning
aid EasyClean ", Page19
¡ Pyrolytic self-cleaning cleans the cooking compartment almost by itself.
→"Pyrolytic self-cleaning ", Page18
4.6 Temperature and setting levels
There are different settings for the types of heating and
functions.
The settings appear in the display.
The temperature can be set in 1 degree increments up
to 100°C, and in 5 degree increments thereafter.
en Accessories
8
Note:For temperature settings above 275°C for the
Grill type of heating, the appliance reduces the temper-
ature to approx. 250°C after approx. 20minutes.
Temperature display
The temperature display shows you the temperature in
the cooking compartment.
Notes
¡ The temperature indicator only shows the temperat-
ure increasing for operating modes for which you
can set a temperature, e.g. for cleaning functions,
the temperature display is filled immediately.
¡ Due to thermal inertia, the temperature displayed
may differ slightly from the actual temperature inside
the cooking compartment.
As soon as the appliance heats up, the symbol ap-
pears in the display.
The lines are filled from the bottom to the top as the
cooking compartment heats up.
When you are preheating the appliance, the optimal
time to place your food in the cooking compartment is
when the symbol first goes out.
Residual heat
When the appliance is switched off, the temperature in-
dicator shows the residual heat in the cooking com-
partment.
The further the temperature drops, the more lines go
out.
If flashes in the display, the temperature in the cook-
ing compartment is too high for the selected operating
mode. Switch the appliance off, wait until it has cooled
down and then switch it back on again.
4.7 Cooking compartment
The functions in the cooking compartment make your
appliance easier to use.
Rails
The rails in the cooking compartment enable you to
place accessories at different heights.
→"Accessories", Page8
Your appliance has four shelf positions. The shelf posi-
tions are numbered from bottom to top.
You can remove the rails, e. g. for cleaning.
→"Shelf supports", Page20
Lighting
The oven light lights up the cooking compartment.
With most types of heating and functions, the lighting
lights up during operation. When the function selector
is turned to bring operation to an end, the lighting goes
out.
The Oven light setting on the function selector can be
used to switch on the light without heating.
Cooling fan
The cooling fan switches on and off depending on the
appliance's temperature. The hot air escapes above
the door.
ATTENTION!
Do not cover the ventilation slot above the appliance
door. The appliance overheats.
▶
Ensure that the ventilation slots are unobstructed.
To ensure that the appliance cools down more quickly
after operation, the cooling fan continues to run for a
certain period afterwards.
Appliance door
If you open the appliance door during operation, the
operation continues.
5 Accessories
Use original accessories. These have been made espe-
cially for your appliance.
Note:Accessories may become deformed if they get
hot. Deformation has no effect on function. As the ac-
cessory cools down, it will regain its original shape.
The accessories supplied may differ depending on the
appliance model.
Accessories en
9
Accessories Use
Wire rack ¡ Cake tins
¡ Ovenproof dishes
¡ Cookware
¡ Meat, e.g. roasting joints or steak
¡ Frozen meals
Universal pan ¡ Moist cakes
¡ Baked items
¡ Bread
¡ Large roasts
¡ Frozen meals
¡ Catching dripping liquids, e.g. fat when
grilling food on the wire rack.
5.1 Locking function
The locking function prevents the accessories from tilt-
ing when they are pulled out.
You can pull out the accessories approximately halfway
without them tipping. The accessories must be inserted
into the cooking compartment correctly for the tilt pro-
tection to work properly.
5.2 Sliding accessories into the cooking
compartment
Always slide accessories into the cooking compartment
correctly. This is the only way to ensure that accessor-
ies can be pulled out approximately halfway without tip-
ping.
1.
Turn the accessories so that the notch is at the
rear and is facing downwards.
2.
Insert accessories between the two guide rods for
the shelf position.
Wire rack Insert the wire rack with the open
side facing the appliance door and
the curved lip facing downwards.
Baking tray
E.g. univer-
sal pan or
baking tray
Slide the tray, e.g. the universal pan,
in with the sloping edge facing the
appliance door.
3.
Push the accessory all the way in, making sure that
it does not touch the appliance door.
Note:Take any accessories that you will not be using
out of the cooking compartment while the appliance is
in operation.
Combining accessories
You can combine the wire rack with the universal pan
to catch any liquid that drips down.
1.
Place the wire rack on the universal pan so that
both spacers are on the rear edge of the univer-
sal pan.
2.
Insert the universal pan between the two guide rods
for a shelf position. In so doing, the wire rack is on
top of the upper guide rod.
Wire rack
on univer-
sal pan
5.3 Other accessories
You can purchase other accessories from our after-
sales service, specialist retailers or online.
You will find a comprehensive range of products for
your appliance in our brochures and online:
www.neff-international.com
Accessories vary from one appliance to another. When
purchasing accessories, always quote the exact
product number (E no.) of your appliance.
You can find out which accessories are available for
your appliance in our online shop or from our after-
sales service.
en Before using for the first time
10
6 Before using for the first time
Configure the settings for initial start-up. Clean the ap-
pliance and accessories.
6.1 Initial use
You need to make settings for initial use before you
can use your appliance.
Setting the time on the clock
Once the appliance has been connected to the mains
or following a power failure, the time flashes on the dis-
play. The time starts at "12:00". Set the current time.
Requirement:The function selector must be set to the
"Off" position .
1.
Use the or button to set the time.
2.
Press the button.
a The time that is set appears on the display.
Tip:You can go to the basic settings →Page13 to
specify whether or not the time should be shown on
the display.
6.2 Cleaning the appliance before using it
for the first time
Clean the cooking compartment and accessories be-
fore using the appliance to prepare food for the first
time.
1.
Remove any accessories and leftover packaging,
such as polystyrene pellets, from the cooking com-
partment.
2.
Before heating the appliance, wipe the smooth sur-
faces in the cooking compartment with a soft, damp
cloth.
3.
Keep the room ventilated while the appliance is
heating.
4.
Set the type of heating and temperature.
→"Basic operation", Page10
Type of heat-
ing
CircoTherm hot air
Temperature Maximum
Cooking time 1 hour
5.
Switch off the appliance after the specified cooking
time.
6.
Wait until the cooking compartment has cooled
down.
7.
Clean the smooth surfaces with soapy water and a
dish cloth.
8.
Clean the accessories using soapy water and a dish
cloth or soft brush.
7 Basic operation
7.1 Switching on the appliance
▶
Turn the function selector to any position other than
the "Off" position .
a The appliance is switched on.
7.2 Switching off the appliance
▶
Turn the function selector to the "Off" position .
a The appliance is switched off.
7.3 Setting the type of heating and
temperature
1.
Use the function selector to set the type of heating.
2.
Use the temperature selector to set the temperature
or grill setting.
a The appliance starts heating after a few seconds.
3.
When your food is ready, switch off the appliance.
Tips
¡ The most suitable type of heating for your food can
be found in the description of the type of heating.
→"Types of heating", Page7
¡ You can also set a cooking time and end time on
the appliance.
→"Time-setting options", Page11
Changing the type of heating
You can change the type of heating at any time.
▶
Use the function selector to set the required type of
heating.
Changing the temperature
You can change the temperature at any time.
▶
Use the temperature selector to set the required
temperature.
Time-setting options en
11
8 Time-setting options
Your appliance has different time-setting options, with
which you can control its operation.
8.1 Overview of the time-setting options
With the button, select the different time-setting op-
tions.
Time-setting
option
Use
Timer The timer can be set independently
of the appliance when it is in opera-
tion. It does not affect the appliance.
Cooking time If you set a cooking time, operation
of the appliance stops automatically
once this time has elapsed.
End time For the cooking time, you can set the
time at which operation ends. The
appliance starts up automatically so
that it finishes cooking at the re-
quired time.
Time You can set the time.
8.2 Setting the timer
The timer runs independently of the appliance when it
is in operation. The timer can be set when the appli-
ance is switched on or off, up to 23 hours and 59
minutes. The timer has its own audible signal so that
you can tell whether it is the timer or a cooking time
which has elapsed.
1.
Press the button repeatedly until is highlighted
in the display.
2.
Use the or button to set the timer duration.
Button Default value
5minutes
10 minutes
The timer duration can be set in 30-second incre-
ments up to 10 minutes. Above 10 minutes, the
time increments become longer the higher the
value.
a The timer starts and the timer duration begins to
count down after a few seconds.
a An audible signal sounds and the timer duration is
zero in the display when the timer duration has
elapsed.
3.
Once the timer duration has elapsed:
‒ Press any button to switch off the timer.
Changing the timer
You can change the timer duration at any time.
Requirement: is highlighted on the display.
▶
Use the or button to change the timer duration.
a The appliance applies the change after a few
seconds.
Cancelling the timer
You can cancel the timer duration at any time.
Requirement: is highlighted on the display.
▶
Use the button to reset the timer duration to zero.
a After a few seconds, the appliance applies the
change and goes out.
8.3 Setting the cooking time
You can set a cooking time for operation of up to 23
hours 59 minutes.
Requirement:The type of heating and temperature or
setting are set.
1.
Press the button repeatedly until is highlighted
in the display.
2.
Use the or button to set the cooking time.
Button Default value
10 minutes
30minutes
The cooking time can be set in 1-minute increments
up to 1 hour, and then in 5-minute increments.
a The appliance starts heating and the cooking time
counts down after a few seconds.
a If the cooking time has elapsed, an audible signal
sounds and the display shows the cooking time as
zero.
3.
When the cooking time has elapsed:
‒ Press any button to end the audible signal before
it sounds.
‒ To set a cooking time again, press the button.
‒ When your food is ready, switch off the appli-
ance.
Changing the cooking time
You can change the cooking time at any time.
Requirement: is highlighted on the display.
▶
Change the cooking time using the or button.
a The appliance applies the change after a few
seconds.
Cancelling the cooking time
You can cancel the cooking time at any time.
Requirement: is highlighted on the display.
▶
Reset the cooking time to zero using the button.
a After a few seconds, the appliance applies the
change and continues to heat without a cooking
time.
8.4 Setting the end time
You can delay the time at which cooking is due to fin-
ish by up to 23 hours and 59 minutes.
Notes
¡ In order to achieve a good cooking result, do not
delay the end time once the appliance is already in
operation.
¡ Food will spoil if you leave it in the oven cavity too
long.
Requirements
¡ The type of heating and temperature or setting are
set.
¡ A cooking time is set.
en Childproof lock
12
1.
Press the button repeatedly until is highlighted
in the display.
2.
Press the or button.
a The display shows the calculated end time.
3.
Use the or button to delay the end time.
a After a few seconds, the appliance applies the set-
ting and the display shows the set end time.
a Once the calculated start time has been reached,
the appliance starts heating up and the cooking
time starts counting down.
a Once the time has elapsed, an audible signal
sounds and the display shows the cooking time as
zero.
4.
When the cooking time has elapsed:
‒ Press any button to end the signal prematurely.
‒ To set another cooking time, press the button.
‒ When your food is ready, switch off the appli-
ance.
Changing the end time
In order to achieve a good cooking result, you can only
change the set end time before operation starts and
the cooking time starts counting down.
Requirement: is highlighted on the display.
▶
Use the or button to delay the end time.
a The appliance applies the change after a few
seconds.
Cancelling the end time
You can delete the set end at any time.
Requirement: is highlighted on the display.
▶
Reset the end time to the current time plus the set
cooking time using the button.
a After a few seconds, the appliance applies the
change and starts heating up. The cooking time
counts down.
8.5 Setting the time on the clock
Once the appliance has been connected to the mains
or following a power failure, the time flashes on the dis-
play. The time starts at "12:00". Set the current time.
Requirement:The function selector must be set to the
"Off" position .
1.
Use the or button to set the time.
2.
Press the button.
a The time that is set appears on the display.
Tip:You can go to the basic settings →Page13 to
specify whether or not the time should be shown on
the display.
Changing the time on the clock
You can change the time on the clock at any time.
Requirement:The function selector must be set to the
"Off" position .
1.
Press the button repeatedly until is highlighted
in the display.
2.
Use the or button to change the time.
a The appliance applies the change after a few
seconds.
9 Childproof lock
You can secure your appliance to prevent children
from accidentally switching it on or changing the set-
tings.
Note:You can go to the basic settings →Page13 to
specify whether you want the option to set the child-
proof lock.
You can only use the childproof lock to lock the control
elements of the appliance. In addition, you can lock the
appliance door.
→"Basic settings", Page13
9.1 Automatic childproof lock
When the appliance is switched off, it locks automatic-
ally. You need to pause the automatic childproof lock
before you switch on the appliance.
You can activate and deactivate the automatic child-
proof lock in the basic settings.
→"Basic settings", Page13
Pausing the automatic childproof lock
Requirement:The automatic childproof lock is activ-
ated in the basic settings.
→"Basic settings", Page13
▶
Press and hold the button until goes out on
the display.
9.2 Childproof lock
If you activate the childproof lock, the appliance is
locked until you deactivate the childproof lock. If you
switch off the appliance after the next operation, the
childproof lock is not activated automatically.
Activating the childproof lock
▶
Press and hold the button until appears on the
display.
Deactivating the childproof lock
▶
Press and hold the button until goes out on
the display.
10 Rapid heating
To save time, you can shorten the preheating time for
set temperatures over 100°C.
You can use rapid heating for the following types of
heating:
¡ CircoTherm hot air
¡ Bread baking setting
¡ Top/bottom heating
Sabbath mode en
13
10.1 Setting rapid heating
To ensure an even cooking result, do not place the
food in the cooking compartment until rapid heating
has come to an end.
Note:Do not set a cooking time until rapid heating has
come to an end.
1.
Set a suitable type of heating and a temperature of
at least 100°C.
2.
Press the button.
a appears in the display and the arrows are filled
from the bottom to the top.
a Rapid heating starts after a few seconds.
a Once rapid heating has ended, an audible signal
sounds and the symbol goes out in the display.
3.
Place the food in the cooking compartment.
11 Sabbath mode
You can set a time of over 70hours using Sabbath
mode. You can use Top/bottom heating to keep food
warm between 85°C and 140°C during this time
without having to switch the appliance on or off.
11.1 Starting Sabbath mode
Notes
¡ If you open the appliance door during operation, the
appliance does not interrupt the operation.
¡ Once it has started, you can no longer change or in-
terrupt Sabbath mode.
¡ You cannot delay the end time for Sabbath mode.
Requirement:Sabbath mode is activated in the basic
settings.
→"Basic settings", Page13
1.
Use the function selector to set the type of heating
.
a appears in the display.
2.
Use the temperature selector to set the temperature.
3.
Use the or button to set the time.
a After a few seconds, the appliance starts heating
and the time counts down.
a Once the time has elapsed, the display shows the
time as zero.
4.
Switch off the appliance.
12 Basic settings
You can configure the appliance to meet your needs.
12.1 Overview of the basic settings
Here you can find an overview of the basic settings and factory settings. The basic settings depend on the features
of your appliance.
Display Basic setting Selection
Automatic childproof lock = no
1
= yes
Signal duration upon completion of a cook-
ing time or timer period
= 10 seconds
= 30 seconds
1
= 2 minutes
Waiting time until a setting is adopted = 3 seconds
1
= 6 seconds
= 10 seconds
Button tone when pressing a button = off
= on
1
Brightness of the display illumination = dark
= medium
1
= bright
Time display = hide the time
= display the time
1
Childproof lock can be adjusted = no
= yes
1
= yes, with locked door
Interior lighting during operation = no
= yes
1
1
Factory setting (may vary according to model)
2
Depending on the appliance specifications
en HomeConnect
14
Display Basic setting Selection
Cooling fan run-on time = short
= medium
1
= long
= extra long
Telescopic shelves retrofitted
2
= no
1
(for rails and 1-level pull-out)
= yes (for 2- and 3-level pull-out)
Sabbath mode available = no
1
= yes
Reset all values to factory settings = no
1
= yes
.. HomeConnect Settings
→"HomeConnect ", Page14
1
Factory setting (may vary according to model)
2
Depending on the appliance specifications
12.2 Changing basic settings
Requirement:The appliance is switched off.
1.
Press and hold the button for approximately
fourseconds.
a The first basic setting appears in the display,
e.g. .
2.
Use the temperature selector to change the setting.
3.
Use the or button to switch to the next basic set-
ting.
4.
To save the changes, press and hold the button
for approx. fourseconds.
Note:Your changes to the basic settings will be re-
tained even after a power failure.
12.3 Discarding changes to the basic
settings
▶
Turn the function selector.
a All changes are discarded and not saved.
13 HomeConnect
This appliance is network-capable. Connecting your ap-
pliance to a mobile device lets you control its functions
via the HomeConnect app, adjust its basic settings
and monitor its operating status.
The HomeConnect services are not available in every
country. The availability of the HomeConnect function
depends on the availability of HomeConnect services
in your country. You can find information about this at:
www.home-connect.com.
The HomeConnect app guides you through the entire
login process. Follow the instructions in the HomeCon-
nect app to configure the settings.
Tips
¡ Please consult the documents supplied by
HomeConnect.
¡ Please also follow the instructions in the HomeCon-
nect app.
Notes
¡ Please note the safety precautions in this instruction
manual and make sure that they are also observed
when operating the appliance via the HomeCon-
nect app.
→"Safety", Page2
¡ Operating the appliance on the appliance itself al-
ways takes priority. During this time it is not possible
to operate the appliance using the HomeConnect
app.
¡ In networked standby mode, the appliance requires
a maximum of2W.
13.1 Setting up HomeConnect
Requirements
¡ The appliance is connected to the power supply and
is switched on.
¡ You have a smartphone or tablet with a current ver-
sion of the iOS or Android operating system.
¡ The smartphone and the appliance are within range
of your home network's Wi-Fi signal.
1.
Download the HomeConnect app.
2.
Open the HomeConnect app and scan the follow-
ing QR code.
3.
Follow the instructions in the HomeConnect app.
HomeConnect en
15
13.2 HomeConnect Settings
You can adjust the settings and network settings for HomeConnect in the basic settings for your appliance.
Setting Selection or display Explanation
Connection to the network
– Not connected
– Connect automatically
– Connect manually
– Connected
and are displays that you cannot set.
Connection to the HomeConnect
app
– Ready
– Connect
– Connected
and are displays that you cannot set.
Wi-Fi
– Off
– Activate
– On
If Wi-Fi is activated, you can use HomeConnect.
In networked standby mode, the appliance requires a max-
imum of 2W.
is a display that you cannot set.
Remote start
– Deactivated
– Manual
1
– Permanent
When remote start is deactivated, you can only view the oper-
ating status of the appliance in the app.
For manual remote start, you must activate the remote start
each time before you can start the appliance via the app. If
you open the appliance door within 15minutes of activating
remote start or of the operation ending, remote start is deactiv-
ated.
For permanent remote start, you can start and operate the ap-
pliance remotely at any time.
Software update
– Update available
– Start update
The setting is only displayed if an update is available.
is a display that you cannot set.
Remote Diagnostics
– Not authorised
1
– Authorised
The setting is only displayed if after-sales service is attempting
to access the appliance.
1
Factory setting
13.3 Operating the appliance with the
HomeConnect app
You can use the HomeConnect app to set and start
the appliance remotely.
WARNING‒Risk of fire!
Combustible objects that are left in the cooking com-
partment may catch fire.
▶
Never store combustible objects in the cooking
compartment.
▶
Never open the appliance door if there is smoke in-
side.
▶
Switch off the appliance and unplug it from the
mains or switch off the circuit breaker in the fuse
box.
Requirements
¡ The appliance is switched on.
¡ The appliance is connected to your home network
and to the HomeConnect app.
¡ In order to be able to set the appliance via the app,
the manual or permanent remote start must be se-
lected in the basic setting.
1.
To activate the remote start, set the function selector
to .
2.
Implement a setting in the app and send it to the ap-
pliance.
13.4 Software update
Your appliance's software can be updated using the
software update function, e.g. for the purposes of op-
timisation, troubleshooting or security updates.
To do this, you must be a registered HomeCon-
nectuser, have installed the app on your mobile device
and be connected to the HomeConnectserver.
As soon as a software update is available, you will be
informed via the HomeConnectapp and will be able to
start the software update via the app. Once the update
has been successfully downloaded, you can start in-
stalling it via the HomeConnectapp if you are in your
local area network. The HomeConnectapp will inform
you once installation is successful.
Notes
¡ You can continue to use your appliance as normal
while updates are downloading. Depending on your
personal settings in the app, software updates can
also be set to download automatically.
¡ We recommend that you install security updates as
soon as possible.
en Cleaning and servicing
16
13.5 Remote diagnostics
Customer Service can use Remote Diagnostics to ac-
cess your appliance if you contact them, have your ap-
pliance connected to the HomeConnect server and if
Remote Diagnostics is available in the country in which
you are using the appliance.
Tip:For further information and details about the avail-
ability of Remote Diagnostics in your country, please
visit the service/support section of your local website:
www.home-connect.com
13.6 Data protection
Please see the information on data protection.
The first time your appliance is registered on a home
network connected to the Internet, your appliance will
transmit the following types of data to the
HomeConnect server (initial registration):
¡ Unique appliance identification (consisting of appli-
ance codes as well as the MAC address of the Wi-Fi
communication module installed).
¡ Security certificate of the Wi-Fi communication mod-
ule (to ensure a secure data connection).
¡ The current software and hardware version of your
appliance.
¡ Status of any previous reset to factory settings.
This initial registration prepares the HomeConnect
functions for use and is only required when you want to
use the HomeConnect functions for the first time.
Note:Please note that the HomeConnect functions
can only be utilised with the HomeConnect app. In-
formation on data protection can be retrieved in the
HomeConnect app.
13.7 Declaration of Conformity
Constructa Neff Vertriebs-GmbH hereby declares that
the appliance with Home Connect functionality meets
the essential requirements and other relevant provi-
sions of the Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found
online at www.neff-international.com among the addi-
tional documents on the product page for your appli-
ance.
2.4GHz band: 100mW max.
5GHz band: 100mW max.
BE BG CZ DK DE EE IE EL
ES FR HR IT CY LV LT LU
HU MT NL AT PL PT RO SI
SK FI SE UK NO CH TR
5GHz WLAN (Wi-Fi): For indoor use only.
14 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
14.1 Cleaning products
In order to avoid damaging the various oven surfaces
on the appliance, do not use unsuitable cleaning
products.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶
Do not use steam- or high-pressure cleaners to
clean the appliance.
ATTENTION!
Unsuitable cleaning products may damage the sur-
faces of the appliance.
▶
Do not use harsh or abrasive cleaning products.
▶
Do not use cleaning products with a high alcohol
content.
▶
Do not use hard scouring pads or cleaning
sponges.
▶
Do not use any special cleaners for cleaning the ap-
pliance while it is hot.
Using oven cleaner in a hot cooking compartment
damages the enamel.
▶
Never use oven cleaner in the cooking compartment
when it is still warm.
▶
Remove all food remnants from the cooking com-
partment and the appliance door before you next
heat up the appliance.
New sponge cloths contain residues from production.
▶
Wash new sponge cloths thoroughly before use.
Suitable cleaning agents
Only use cleaning agents that are suitable for the differ-
ent surfaces on your appliance.
Follow the instructions on cleaning the appliance.
→"Cleaning the appliance", Page17
Cleaning and servicing en
17
Appliance front
Surface Suitable cleaning agents Notes
Stainless steel ¡ Hot soapy water
¡ Special stainless steel
cleaning products
suitable for hot sur-
faces
To prevent corrosion, remove any limescale, grease, starch or albu-
min (e.g. egg white) stains on stainless steel fronts immediately.
Apply a thin layer of the stainless steel cleaning product with a soft
cloth.
Plastic or painted
surfaces
E.g. control panel
¡ Hot soapy water Do not use glass cleaner or a glass scraper.
Appliance door
Area Suitable cleaning agents Notes
Door panels ¡ Hot soapy water Do not use a glass scraper or a stainless steel wool.
Tip:Remove the door panels in order to clean them thoroughly.
→"Appliance door", Page20
Door cover ¡ Made of stainless
steel:
Stainless steel cleaner
¡ Made of plastic:
Hot soapy water
Do not use glass cleaner or a glass scraper.
Tip:Remove the door cover for thorough cleaning.
→"Appliance door", Page20
Door handle ¡ Hot soapy water To avoid permanent stains, remove descaling agents from the door
handle immediately.
Door seal ¡ Hot soapy water Do not remove or scrub.
Cooking compartment
Area Suitable cleaning agents Notes
Enamel surfaces ¡ Hot soapy water
¡ Vinegar water
¡ Oven cleaner
Soak any heavily soiled areas and use a brush or steel wool.
Leave the appliance door open to dry the cooking compartment
after cleaning it.
Tip:It is best to use the cleaning function.
→"Pyrolytic self-cleaning ", Page18
Notes
¡ Enamel burns at very high temperatures, causing minor discol-
ouration. The functionality of your appliance is not affected by
this.
¡ The edges of thin trays cannot be completely enamelled and may
be rough. This does not impair corrosion protection.
¡ Food residues will leave a white coating on the enamel surfaces.
The coating does not pose a health risk. The functionality of your
appliance is not affected by this. You can remove residues with
lemon juice.
Glass cover for
the oven light
¡ Hot soapy water Use oven cleaner to remove very heavy soiling.
Rails ¡ Hot soapy water Soak any heavily soiled areas and use a brush or steel wool.
Tip:Remove the shelf supports for cleaning.
→"Shelf supports", Page20
AccessorIes ¡ Hot soapy water
¡ Oven cleaner
Soak any heavily soiled areas and use a brush or steel wool.
Enamelled accessories are dishwasher-safe.
14.2 Cleaning the appliance
In order to avoid damaging the appliance, you must
clean your appliance only as specified, and with suit-
able cleaning products.
WARNING‒Risk of burns!
The appliance and its parts that can be touched be-
come hot during use.
▶
Caution should be exercised here in order to avoid
touching heating elements.
▶
Young children under 8 years of age must be kept
away from the appliance.
WARNING‒Risk of fire!
Loose food remnants, fat and meat juices may catch
fire.
en Cleaning functions
18
▶
Before using the appliance, remove the worst of the
food residues and remnants from the cooking com-
partment, heating elements and accessories.
Requirement:Read the information on cleaning
products.
→"Cleaning products", Page16
1.
Clean the appliance using hot soapy water and a
dish cloth.
‒ For some surfaces, you can use alternative
cleaning agents.
→"Suitable cleaning agents", Page16
2.
Dry with a soft cloth.
14.3 Checking the cooking compartment
seal after cleaning
▶
If the cooking compartment seal is on the left or
right of the spacer , slide the cooking compart-
ment seal inwards until it is beside the spacer .
15 Cleaning functions
Use the cleaning functions to clean the appliance.
15.1 Pyrolytic self-cleaning
The Pyrolytic self-cleaning cleaning function cleans
the cooking compartment almost by itself.
Use the cleaning function to clean the cooking com-
partment every two to three months. If required, you
can use the cleaning function more frequently. The
cleaning function requires approx.2.5–4.8 kilowatt
hours.
Preparing the appliance for the cleaning
function
In order to achieve a good cleaning result, prepare the
appliance carefully.
WARNING‒Risk of fire!
Combustible objects that are left in the cooking com-
partment may catch fire.
▶
Never store combustible objects in the cooking
compartment.
▶
If smoke is emitted, the appliance must be switched
off or the plug must be pulled out and the door
must be held closed in order to stifle any flames.
Loose food remnants, fat and meat juices may catch
fire when the cleaning function is in progress.
▶
Before you start the cleaning function, always re-
move coarse dirt from the cooking compartment.
▶
Never clean accessories at the same time.
The outside of the appliance gets very hot when the
cleaning function is in progress.
▶
Never hang combustible objects, e.g. tea towels, on
the door handle.
▶
Leave the front of the appliance clear.
▶
Keep children at a safe distance.
If the door seal is damaged, a large amount of heat is
generated around the door.
▶
Do not scrub or remove the seal.
▶
Never operate the appliance if the seal is damaged
or missing.
1.
Remove accessories and cookware from the cook-
ing compartment.
2.
Unhook the shelf supports and remove them from
the cooking compartment.
→"Shelf supports", Page20
3.
Remove heavy soiling from the cooking compart-
ment.
4.
Use a detergent solution and a soft cloth to clean
the surfaces at the edges of the cooking compart-
ment around the door seal.
Do not remove or scrub the door seal.
Use oven cleaner to remove stubborn dirt from the
inner door pane.
5.
Remove any objects from the cooking compartment.
The cooking compartment must be empty.
Setting the cleaning function
Ventilate the kitchen while the cleaning function is run-
ning.
WARNING‒Risk of harm to health!
The cleaning function heats up the cooking compart-
ment to a very high temperature so that food left over
from roasting, grilling and baking will burn off. This pro-
cess releases vapours, which can irritate mucous mem-
branes.
▶
Keep the kitchen well ventilated while the cleaning
function is running.
▶
Do not remain in the room for long periods.
▶
Keep children and pets away.
WARNING‒Risk of burns!
The cooking compartment gets very hot when the
cleaning function is in progress.
▶
Never open the appliance door.
▶
Allow the appliance to cool down.
▶
Keep children at a safe distance.
The outside of the appliance gets very hot when the
cleaning function is in progress.
▶
Never touch the appliance door.
▶
Allow the appliance to cool down.
▶
Keep children at a safe distance.
Cleaning functions en
19
Note:The oven light does not come on during the
cleaning function.
Requirement:Prepare the appliance for the cleaning
function. →Page18
1.
Use the function selector to set the cleaning
functions .
a The symbol and the cleaning functions appear in
the display. The first cleaning function is highlighted.
2.
Press the or button repeatedly until the symbol
is highlighted.
a appears in the display.
3.
Use the temperature selector to set the cleaning set-
ting.
Cleaning set-
ting
Cleaning
level
Duration in hours
1 Lightly soiled Approx. 1:15
2 Medium Approx. 1:30
3 High Approx. 2:00
Select a higher cleaning setting for very heavy or
older soiling.
The duration cannot be changed.
a The cleaning function starts after a few seconds and
the time counts down.
a For safety reasons, the appliance door locks auto-
matically once a certain temperature is reached in
the cooking compartment. appears in the display.
a Once the cleaning function has ended, an audible
signal sounds and the display shows the duration
as zero.
4.
Switch off the appliance.
Once the appliance has cooled down sufficiently,
the appliance door unlocks and goes out.
5.
Prepare the appliance for use. →Page19
Preparing the appliance for use following the
cleaning function
1.
Allow the appliance to cool down.
2.
Wipe off any ash that has been left behind in the
cooking compartment and around the appliance
door with a damp cloth.
3.
Remove white residues with lemon juice.
Note:White residues on the enamel surfaces may
be caused by heavy soiling. These food residues
are harmless. The deposits do not compromise the
functionality of the appliance.
4.
Attach the shelf supports.
→"Shelf supports", Page20
15.2 Cleaning aid EasyClean
Use the cleaning aid EasyClean for intermediate clean-
ing of the cooking compartment. The cleaning aid
EasyClean softens dirt by vaporising the soapy water.
The dirt can then be removed more easily.
Setting the cleaning aid EasyClean
WARNING‒Risk of scalding!
If there is water in the cooking compartment when it is
hot, this may create hot steam.
▶
Never pour water into the cooking compartment
when the cooking compartment is hot.
Notes
¡ The interior lighting remains off while the cleaning
aid is running.
¡ You cannot delay the end time.
¡ The length of time has been preset and cannot be
changed.
Requirements
¡ You can only start the cleaning aid once the cooking
compartment is cold (room temperature) and the ap-
pliance door is closed.
¡ Do not open the appliance door while the appliance
is in operation. Otherwise, the appliance will stop the
cleaning aid.
¡ To remove particularly stubborn dirt, leave the soapy
water to work for some time before starting the
cleaning aid.
¡ To remove particularly stubborn dirt, rub soapy water
onto the dirt on smooth surfaces before starting the
cleaning aid.
1.
Remove the accessories from the cooking compart-
ment.
2.
ATTENTION!
Distilled water in the cooking compartment leads to
corrosion.
▶
Do not use distilled water.
Mix 0.4litres water with a drop of washing-up liquid
and pour into the centre of the cooking compart-
ment floor.
3.
Use the function selector to set the cleaning
functions .
a The symbol and the cleaning functions appear in
the display. The first cleaning function is highlighted.
4.
Press the or button repeatedly until the symbol
is highlighted.
a appears in the display.
5.
Turn the temperature selector.
a appears in the display.
a The cleaning aid starts after a few seconds. The
duration counts down in the display.
a Once the cleaning aid has run through to the end,
an audible signal sounds.
Note:If flashes in the display when the cleaning aid
is switched on, this indicates that the cooking compart-
ment has not completely cooled down. Switch off the
appliance. Wait until the cooking compartment has
cooled down and switch the cleaning aid back on.
Recleaning the cooking compartment
ATTENTION!
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶
After using the cleaning aid, wipe the cooking com-
partment clean and allow it to dry fully.
1.
Open the appliance door and remove the remaining
water with an absorbent sponge cloth.
2.
Clean the smooth surfaces in the cooking compart-
ment with a dish cloth or a soft brush. Stubborn
residues can be removed using a stainless steel
scouring pad.
3.
Remove limescale with a cloth soaked in vinegar.
Then wipe with clean water and rub dry with a soft
cloth (including under the door seal).
en Shelf supports
20
4.
If you are unable to remove stubborn dirt, repeat the
cleaning aid after the cooking compartment has
cooled down.
5.
To switch off, turn the function selector to the zero
setting.
6.
Lower the appliance door and leave it open for ap-
prox. one hour to allow the surfaces in the cooking
compartment to dry thoroughly.
16 Shelf supports
To clean the rails and the cooking compartment, or to
replace the rails, you can remove these.
16.1 Detaching the shelf supports
WARNING‒Risk of burns!
The shelf supports get very hot
▶
Never touch the shelf supports when hot.
▶
Always allow the appliance to cool down.
▶
Keep children at a safe distance.
1.
Lift the rail forwards slightly and detach it .
2.
Pull the whole rail to the front and remove it.
3.
Clean the rail.
→"Cleaning products", Page16
16.2 Attaching the shelf supports
Notes
¡ The rails only fit on the right or left.
¡ For both rails, ensure that the curved rods are at the
front.
1.
First, push the rail into the middle of the rear
socket until the rail rests against the cooking
compartment wall, and then push this back .
2.
Push the rail into the front socket until the rail
also rests against the cooking compartment wall,
and then press this downwards .
17 Appliance door
To ensure that your appliance retains its appearance
and remains fully functioning for a long time, you can
detach the appliance door and clean it.
WARNING‒Risk of injury!
If the hinges are not secured due to an incomplete
lock, they can snap shut with great force.
▶
To detach or attach the appliance door, always turn
the two locks as far as they will go.
▶
If the hinge snaps closed when detaching or attach-
ing the appliance door, do not reach into the hinge
– call the after-sales service.
17.1 Detaching the appliance door
Requirements
¡ Have a torch ready.
¡ Have a screwdriver ready.
¡ Have a coin ready.
1.
To make it easier to see the door lock, shine the
torch into the gap beside the appliance door.
Appliance door en
21
2.
Hold the screwdriver horizontally and use it to
push the door lock (black component) on each side
of the door upwards as far as it will go .
Door lock open
Door lock closed
3.
Open the appliance door approx. 45° wide.
4.
Insert the coin in the gap in the lock and rotate as
far as it will go .
‒ Turn the lock on the left-hand side in a clockwise
direction.
‒ Turn the lock on the right-hand side in an anti-
clockwise direction.
Left-hand lock secured
The arrows point to
each other
Left-hand lock released
a The lock audibly engages.
5.
ATTENTION!
Opening and closing the appliance door when it is
in the lock position damages the door hinges.
▶
Never force the appliance door open or closed.
▶
If the door hinge has been damaged, call the
after-sales service.
Move the appliance door up and down until you
hear a quiet click. You can still only move the appli-
ance door slightly.
a The appliance door is in the lock position.
en Appliance door
22
6.
WARNING‒Risk of injury!
The appliance door has a weight of 7–10 kg and
may fall if it is not handled carefully.
▶
Handle the appliance door carefully.
The door handle is not suitable for carrying the ap-
pliance door. The door handle may break off.
▶
Never carry the appliance door by the door
handle.
▶
Grab hold of the appliance door with both hands
on the left and right to carry it.
Take hold of the appliance door with both hands,
one on the left and one on the right, and rotate the
door handle upwards until you are able to pull up
the appliance door and remove it .
7.
Set the appliance door down on a flat, soft, clean
surface.
17.2 Attaching the appliance door
1.
Tip:Ensure that the appliance door is not wedged
at an angle and that it is properly fitted in place.
Attach the appliance door via the left- and right-hand
guide rollers simultaneously .
2.
Rotate the door handle upwards slightly .
a The appliance door will slide the short distance re-
maining to the bottom .
3.
Use a coin to release both locks on the appliance
door. Insert the coin in the gap in the lock and ro-
tate as far as it will go .
‒ Turn the lock on the left-hand side in an anti-
clockwise direction.
‒ Turn the lock on the right-hand side in a clock-
wise direction.
4.
Open the appliance door slightly until you hear a
quiet click, and then close the appliance door.
5.
WARNING‒Risk of injury!
If the door locks are unsecured, the appliance door
may become detached.
▶
After attaching the appliance door, close the left-
and right-hand door locks.
Hold the screwdriver horizontally and use it to
push the door lock (black component) on each side
of the door downwards as far as it will go .
a The door lock is closed.
Appliance door en
23
17.3 Removing the door panes
To facilitate cleaning, you can remove the door pane.
WARNING‒Risk of injury!
Components inside the appliance door may have sharp
edges.
▶
Wear protective gloves.
Requirement:The appliance door is detached.
→"Detaching the appliance door", Page20
1.
Lay the appliance door with the front side facing
down on a flat surface that is soft and clean.
2.
Push on the left- and right-hand side of the appli-
ance door from the outside until the inner pane is
released on both sides.
3.
Carefully lift the inner pane and remove it in the dir-
ection of the arrow .
4.
Push down on the intermediate pane in the area of
, and carefully lift the retainer until you are able
to pull it out.
5.
Lift the first and second intermediate panes from be-
low and remove them in the direction of the arrow
.
6.
Remove the spacers and seals for cleaning, if
required.
7.
WARNING‒Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
▶
Do not use glass scrapers, sharp or abrasive
cleaning aids, or harsh cleaning products.
Clean the door panes on both sides with glass
cleaner and a soft cloth.
8.
Dry the door panes and refit them.
→"Fitting the door panes", Page23
17.4 Fitting the door panes
WARNING‒Risk of injury!
If a door pane or appliance door has not been installed
correctly, this is dangerous.
▶
Make sure that all of the door panes and the appli-
ance door have been correctly fitted before you
switch the appliance back on again.
1.
Tip:When fitting the door panes, make sure that
they are in the original order.
Insert the intermediate pane so that the arrow on
the right-hand side is pointing upwards.
en Troubleshooting
24
2.
Check the fit of the four spacers and two seals.
‒ Place the spacers on the centre of the lines .
‒ Secure the seals at the corners .
3.
Insert the intermediate pane with spacers and seals
in the direction of the arrow .
The arrow on the intermediate pane must line up
with the arrow on the frame .
4.
Insert the second intermediate pane without the
spacers and seals, and slide it in the direction of the
arrow until it is inserted in the frame .
The arrow on the intermediate pane must line up
with the arrow on the frame .
5.
Push down on the intermediate pane around ,
slide the retainer in at an angle and push down
until it clicks into place.
a The retainer has been inserted.
6.
Insert the inner pane into the fixing rail at an angle
towards the back .
7.
Push the inner pane downwards until it locks into
place .
18 Troubleshooting
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
If the appliance is defective, call Customer Service.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
Only use genuine spare parts when repairing the
appliance.
▶
If the power cord of this appliance is damaged, it
must be replaced by trained specialist staff.
Troubleshooting en
25
18.1 Malfunctions
Fault Cause and troubleshooting
The appliance is not working. The circuit breaker is faulty.
▶
Check the circuit breaker in the fuse box.
There has been a power cut.
▶
Check whether the lighting in your kitchen or other appliances are working.
The appliance does not heat up;
lights up in the display.
Demo mode is activated.
1.
Briefly disconnect the appliance from the power supply by switching the cir-
cuit breaker in the fuse box off and back on again.
2.
Deactivate demo mode within fiveminutes by changing the basic setting
to .
→"Basic settings", Page13
The appliance door cannot be
opened; lights up in the dis-
play.
The childproof lock locks the appliance door.
▶
Use the button to deactivate the childproof lock.
→"Childproof lock", Page12
The appliance door cannot be
opened; lights up in the dis-
play.
The cleaning function locks the appliance door.
▶
Allow the appliance to cool down until goes out in the display.
→"Pyrolytic self-cleaning ", Page18
The time flashes in the display. There has been a power cut.
▶
Reset the time.
→"Setting the time on the clock", Page12
The time does not appear in the
display when the appliance is
switched off.
The basic setting has been changed.
▶
Change the basic setting for the time display.
→"Basic settings", Page13
lights up in the display and no
settings can be made on the ap-
pliance.
Childproof lock is activated.
▶
Use the button to deactivate the childproof lock.
→"Childproof lock", Page12
flashes in the display and the
appliance does not start.
The cooking compartment is too hot for the selected operation.
1.
Switch off the appliance and allow it to cool down.
2.
Restart the operation.
appears in the display. The maximum cooking time has been reached. To prevent an unwanted per-
manent operation, the appliance automatically stops heating after several hours
if the settings are unchanged.
▶
Switch off the appliance.
You can configure new settings if required.
Tip:To prevent the appliance from switching off when you do not want it to,
e.g. for an extremely long preparation time, set a cooking time.
→"Time-setting options", Page11
A message with appears in the
display, e.g. - .
Electronics fault
1.
Press the button.
‒ If required, reset the time.
a If the fault was a one-off, the error message disappears.
2.
If the error message appears again, call the after-sales service. Quote the ex-
act error message and the E no. of your appliance.
→"Customer Service", Page26
HomeConnect is not working cor-
rectly.
Different causes are possible.
▶
Go to www.home-connect.com.
18.2 Replacing the oven light bulb
If the light in the cooking compartment fails, change
the oven light bulb.
Note:Heat-resistant, 40-watt, 230 V halogen bulbs are
available from the after-sales service or specialist retail-
ers. Only use these bulbs. Hold the new halogen bulbs
only with a clean, dry towel. This increases the service
life of the bulb.
WARNING‒Risk of burns!
The appliance gets very hot.
▶
Never touch the inside surfaces of the cooking com-
partment or the heating elements while they are hot.
▶
Always allow the appliance to cool down.
▶
Keep children at a safe distance.
en Disposal
26
WARNING‒Risk of electric shock!
When changing the bulb, the bulb socket contacts are
live.
▶
Before replacing the bulb, unplug the appliance
from the mains or switch off the circuit breaker in
the fuse box.
Requirements
¡ The appliance is disconnected from the power sup-
ply.
¡ The cooking compartment has cooled down.
¡ You have a new halogen bulb to replace the old one.
1.
Place a tea towel in the cooking compartment to
prevent damage.
2.
Turn the glass cover anti-clockwise to remove it .
3.
Pull out the halogen bulb without turning it .
4.
Insert the new halogen lamp and press it firmly into
the socket.
Make sure the pins are positioned correctly.
5.
Depending on the appliance model, the glass cover
may have a sealing ring. Put the sealing ring in posi-
tion.
6.
Screw the glass cover on.
7.
Take the tea towel out of the cooking compartment.
8.
Connect the appliance to the power supply.
19 Disposal
Find out here how to dispose of old appliances cor-
rectly.
19.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local author-
ity.
This appliance is labelled in accord-
ance with European Directive
2012/19/EU concerning used elec-
trical and electronic appliances
(waste electrical and electronic equip-
ment - WEEE).
The guideline determines the frame-
work for the return and recycling of
used appliances as applicable
throughout the EU.
20 Customer Service
If you have any queries on use, are unable to rectify
faults on the appliance yourself or if your appliance
needs to be repaired, contact Customer Service.
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our after-
sales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
20.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the pro-
duction number (FD) on the appliance's rating plate.
The rating plate bearing these numbers can be found
on the base of the appliance when you open the appli-
ance door.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
How it works en
27
21 How it works
Here, you can find the ideal settings for various types
of food as well as the best accessories and cookware.
We have perfectly tailored these recommendations to
your appliance.
21.1 Cooking tips
Observe this information when preparing food.
¡ The temperature and cooking time depend on the
amount of food and the recipe. Settings ranges are
specified for this reason. Try using the lower values
to start with.
¡ The setting values apply to food placed in the cook-
ing compartment while the cooking compartment is
still cold. Do not slide the accessory into the cook-
ing compartment until it has finished preheating.
¡ Remove any accessories that are not being used
from the cooking compartment.
21.2 Notes on baking
When baking, use the shelf positions indicated.
Baking on one level Height
Deep baked goods or tin on wire rack 2
Flat baked goods or goods in a baking
tray
3
Baking on two levels Height
Universal pan
Baking tray
3
1
Baking tins/dishes on the wire rack:
First wire rack
Second wire rack
Height
3
1
Baking on three levels Height
Baking tray
Universal pan
Baking tray
4
3
1
Notes
¡ When baking on several layers, always use hot air.
Baked goods that are placed in the oven at the
same time will not necessarily be ready at the same
time.
¡ Position baking tins/dishes either next to one an-
other or offset on different shelves so that they are
not directly one above the other in the cooking com-
partment.
¡ For best results, we recommend using dark-col-
oured metal bakeware.
21.3 Notes on roasting and grilling
The setting values are based on the assumption that
unstuffed, chilled, ready-to-roast poultry, meat or fish is
placed into a cold cooking compartment.
¡ The larger the poultry, meat or fish, the lower the
cooking temperature and the longer the cooking
time.
¡ Turn the poultry, meat or fish after approx. 1/2 to
2/3 of the time listed.
¡ Add a little liquid to the poultry in the cookware.
Cover the bottom of the cookware with approx.1–
2cm of liquid.
¡ When you turn poultry, ensure that the breast side
or skin side is underneath to begin with.
¡ Cooking time calculation (e.g. 20+35): To calculate
the cooking time, assume 20 minutes per 500g of
meat plus an extra 35minutes. For 1.5kg, the
cooking time is then 95 minutes.
¡ Cooking time range (e.g. 10–15): Your food will be
ready within the specified range of time.
Roasting and grilling on the wire rack
Roasting on the wire rack works particularly well for
large poultry or for multiple pieces at the same time.
¡ Depending on the size and type of the food to be
roasted, add up to 1/2litre water to the universal
pan.
You can make a sauce from the juices that are
caught. This also means that less smoke is pro-
duced and the cooking compartment becomes less
dirty.
¡ Keep the appliance door closed when using the
grill.
Never grill with the appliance door open.
¡ Place the food to be grilled on the wire rack. In ad-
dition, slide the universal pan in at least one shelf
position lower, with the slanted edge facing the ap-
pliance door. This means that any dripping fat is
caught.
Roasting in cookware
When preparing food in cookware with a lid, the cook-
ing compartment remains cleaner.
Follow the manufacturer's instructions for your roasting
dishes. Glass cookware is best.
Cookware without lid
¡ Use a deep roasting dish.
¡ Place the cookware onto the wire rack.
¡ If you do not have any suitable cookware, use the
universal pan.
Cookware with lid
¡ Place the cookware onto the wire rack.
¡ Meat, poultry and fish can also become crispy in a
covered roasting dish. Use a roasting dish with a
glass lid. Set a higher temperature.
WARNING‒Risk of injury!
If hot glass cookware is placed on a wet or cold sur-
face, the glass may shatter.
▶
Place hot glass ovenware on a dry mat after cook-
ing.
WARNING‒Risk of scalding!
Very hot steam may escape when the lid is opened
after cooking. Steam may not be visible, depending on
the temperature.
▶
Lift the lid at the rear, so that the hot steam can es-
cape away from you.
▶
Keep children at a safe distance.
en How it works
28
21.4 Food selection
Food Accessories/cookware Shelf pos-
ition
Type of
heating
Temperature
in °C/grill set-
ting
Cooking
time in mins
Victoria sponge cake 2 pcs
Ø20cm cake tin
2 150-170
1
15-25
Rich fruit cake Deep 23 cm diameter
tin
2 140-150 180-210
Fruit pie 20 cm diameter plate or
pie tin
2 160-170 60-70
Quiche Quiche tin (dark-coated) 3 180-200 40-55
(White) bread Loaf tin (1 x900g or 2
x450g)
2 190-210
1
25-40
Scones Baking sheet on wire
rack
3 190-200
2
10-15
Biscuits Baking sheet on wire
rack
3 140-160
1
10-20
Small cakes 12-cup tin 3 150
3
25-35
Pavlova Baking sheet on wire
rack
3 100-110
4
150-180
Yorkshire pudding 12-cup tin 3 200-220
5
15-25
Pizza, home-made Baking tray 3 190-210 20-30
Pizza, home-made, thin base Round pizza tray 2 250-270 8-13
Victoria sponge cake, 2 levels 4 pcs
Ø20cm cake tin
3+1 150-160
2
20-30
Biscuits, 2 or 3levels Baking sheet on wire
rack
3+1
4+3+1
140-160
2
15-25
Beef, top side/top rump Cookware without lid 2 170 40+30
Lamb leg (on the bone) Cookware without lid 2 160-170 25+15
Pork belly Cookware without lid 2 1.
2.
1. 170-180
2. 250
1. 30+30
6
2. 3-5
Chicken, whole Wire rack 2 170-180 25+15
7
Turkey, crown Wire rack 2 140-150 20+25
Turkey, whole, 4–8kg Wire rack 1 150-160 12+12
8
Fish, braised, whole 300g, e.g. trout Cookware with lid 2 170-190 25-35
Diced meat (beef, pork, lamb), 500g Cookware with lid 2 140 120-140
Complete meal with chicken Wire rack
+
Wire rack
+
Universal pan
4+1 180, then
200 (York-
shire pud-
ding)
Chicken:
(25+25) +
20 for York-
shire pud-
ding
Bacon rashers Wire rack 3 /
9
1 side 4–5
2 side 3–4
Sausages, thickness 2–4cm Wire rack 3 /
10
10-15
11
Pork, gammon joint Cookware without lid 2 170-180 25+20
6
Chicken, whole Cookware without lid 2 170-180 20+20
7
1
Preheat the appliance. Do not use the rapid heating function.
2
Preheat the appliance.
3
Preheat the appliance for five minutes. Do not use the rapid heating function.
4
Preheat the appliance to 150°C using HotAir.
5
Preheat the appliance for 20 minutes.
6
Do not turn the food.
7
Slide the universal pan underneath the wire rack.
8
Add the food after approx. one hour.
9
Preheat the appliance for 5 minutes.
10
Preheat the appliance for three minutes.
11
Turn the food occasionally.
How it works en
29
21.5 Yoghurt
You can use your appliance to make your own yoghurt.
Preparing yoghurt
1.
Remove the accessories and shelf supports from
the cooking compartment.
2.
Pour the previously prepared yoghurt mixture into
small containers, e.g. into cups or small jars.
3.
Cover the containers with foil, e. g. with cling film.
4.
Place the containers on the cooking compartment
floor.
5.
Set the appliance according to the recommended
setting.
6.
After making the yoghurt, leave it to cool in the refri-
gerator.
Yoghurt
Food Accessories/cookware Shelf position Type of
heating
Temperature in
°C
Cooking
time in
mins
Yoghurt Individual moulds Cooking compartment
floor
40-45 8–9 hrs
21.6 Test dishes
These overviews have been produced for test institutes
to facilitate appliance testing in accordance with EN
60350-1.
Baking
Observe this information when baking test dishes.
General information
¡ The settings apply to food that is placed into a cold
cooking compartment.
¡ Observe the notes about preheating in the tables.
These setting values apply without rapid heating.
¡ When baking, use the lower of the listed temperat-
ures to begin with.
Shelf positions
Shelf positions for baking on two levels:
Note:Items that are placed in the oven on baking trays
or in baking tins/dishes at the same time will not ne-
cessarily be ready at the same time.
¡ Universal pan: Level 3
Baking tray: Level 1
¡ Baking tins/dishes on the wire rack
First wire rack: Level 3
Second wire rack: Level 1
Shelf positions for baking on three levels:
¡ Baking tray: Level 4
Universal pan: Level 3
Baking tray: Level 1
Baking with two springform cake tins:
Position baking tins/dishes either next to one another
or offset on different shelves so that they are not dir-
ectly one above the other in the cooking compartment.
Baking
Food Accessories/cookware Shelf pos-
ition
Type of
heating
Temperature in
°C
Cook-
ing time
in mins
Viennese whirls Baking tray 3 140-150
1
25-35
Viennese whirls Baking tray 3 140-150
1
20-30
Viennese whirls, 2levels Universal pan
+
Baking tray
3 + 1 140-150
1
25-35
Viennese whirls, 3levels Universal pan
+
Baking tray
4 + 3 + 1 130-140
1
35-55
Small cakes Baking tray 3 150
1
25-35
Small cakes Baking tray 3 140
1
25-35
1
Preheat the appliance for five minutes. Do not use the rapid heating function.
2
Preheat the appliance. Do not use the rapid heating function.
en Installation instructions
30
Food Accessories/cookware Shelf pos-
ition
Type of
heating
Temperature in
°C
Cook-
ing time
in mins
Small cakes, 2levels Universal pan
+
Baking tray
3 + 1 140
1
30-40
Small cakes, 3levels Universal pan
+
Baking tray
4 + 3 + 1 140
1
30-40
Hot water sponge cake Springform cake tin,
diameter 26 cm
2 160-170
2
25-35
Hot water sponge cake Springform cake tin,
diameter 26 cm
2 160-170 30-35
Hot water sponge cake, 2levels Springform cake tin,
diameter 26 cm
3 + 1 150-160
2
35-50
1
Preheat the appliance for five minutes. Do not use the rapid heating function.
2
Preheat the appliance. Do not use the rapid heating function.
Grilling
Food Accessories/cookware Shelf pos-
ition
Type of
heating
Temperature in
°C/grill setting
Cook-
ing time
in mins
Toasting bread Wire rack 4 /
1
5–6
1
Do not preheat the appliance.
22 Installation instructions
Observe this information when installing the appliance.
22.1 General installation instructions
Follow these instructions before you start with
the installation of the appliance.
¡ The safe operation of this appliance can
only be guaranteed if it has been installed
to a professional standard in accordance
with these installation instructions. The in-
staller shall be liable for damages incurred
as a result of incorrect installation.
¡ Do not use the door handle for the trans-
port or installation.
¡ Check the appliance for damage after un-
packing it. Do not connect the appliance if
it has been damaged in transit.
¡ Before starting up the appliance, remove
any packaging material and adhesive film
from the cooking compartment and the
door.
¡ Proceed in accordance with the installation
sheets for installing accessories.
¡ Fitted units must be heat-resistant up to
95°C, and adjacent unit fronts up to
70°C.
¡ Do not install the appliance behind a decor-
ative door or the door of a kitchen unit.
There is a risk of overheating.
¡ Cut-out work on the units should be carried
out before installing the appliance. Remove
any shavings. Otherwise, the correct opera-
tion of electrical components may be ad-
versely affected.
¡ The mains socket for the appliance must
either be located in the hatched area or
outside of the area where the appliance is
installed.
Any unsecured units must be secured to
the wall using a standard bracket .
Installation instructions en
31
¡ Wear protective gloves so that you do not
cut yourself. Parts that are accessible dur-
ing installation may have sharp edges.
¡ Dimensions of the figures in mm.
WARNING‒Risk of fire!
It is dangerous to use an extended power
cord and non-approved adapters.
▶
Do not use extension cables or multiple
socket strips.
▶
If the power cord is too short, contact Cus-
tomer Service.
▶
Only use adapters approved by the manu-
facturer.
ATTENTION!
Carrying the appliance by the door handle could break
it. The door handle cannot support the weight of the
appliance.
▶
Do not carry or hold the appliance by the
door handle.
22.2 Appliance dimensions
You will find the dimensions of the appliance here
22.3 Installation below a worktop
Observe the installation dimensions and the installation
instructions when installing below a worktop.
¡ To ventilate the appliance, the intermediate floor
must have a ventilation cut-out.
¡ In combination with induction hobs, the gap
between the worktop and appliance must not be
sealed using additional strips.
¡ The worktop must be secured to the built-in unit.
¡ Observe any available installation instructions for the
hob.
22.4 Installing below a hob
If the appliance is installed below a hob, the following
minimum dimensions must be adhered to (including
substructure, if applicable).
The minimum worktop thickness is based on the re-
quired minimum clearance .
en Installation instructions
32
Hob type a raised in mm a flush in mm b in mm
Induction hob 37 38 5
Full-surface induction hob 47 48 5
Gas hob 30 38 5
Electric hob 27 30 2
22.5 Installation in a tall unit
Observe the installation dimensions and the installation
instructions when installing in a tall unit.
¡ To ventilate the appliance, the intermediate floors
must have a ventilation cut-out.
¡ If the tall unit has another back panel in addition to
the element back panels, this must be removed.
¡ Only fit the appliance up to a height which allows
accessories to be easily removed.
22.6 Corner installation
Observe the installation dimensions and the installation
instructions when installing in a corner.
¡ To ensure that the appliance door can be opened,
you must take the minimum dimensions into consid-
eration when installing in a corner. The dimension
is dependent on the thickness of the unit front and
the handle.
22.7 Electrical connection
In order to safely connect the appliance to the elec-
trical system, follow these instructions.
¡ The appliance corresponds to protection class I and
must only be operated with a protective earth con-
nection.
¡ The fuse protection must correspond to the power
rating specified on the appliance's rating plate and
to local regulations.
¡ The appliance must be disconnected from the
power supply whenever installation work is being
carried out.
¡ The appliance must only be connected using the
power cable provided.
¡ The power cable must be plugged in at the rear of
the appliance until you hear a clicking sound. A 3 m
power cable can be obtained from the after-sales
service.
¡ The power cable must only be replaced with a cable
from the original manufacturer. This is available from
after-sales service.
¡ Contact protection must be ensured during the in-
stallation.
Electrically connect the appliance with the
protective contact plug
Note:The appliance must only be connected to a pro-
tective contact socket that has been correctly installed.
▶
Insert the plug into the protective contact socket.
When the appliance is installed, the mains plug of
the power cord must be freely accessible. If free ac-
cess to the mains plug is impossible, an all-pole
isolating switch must be integrated into the perman-
ent electrical installation in accordance with the in-
stallation regulations.
Electrically connecting an appliance without a
protective contact plug
Note:Only a licensed professional may connect the ap-
pliance. Damage caused by incorrect connection is not
covered under the warranty.
An all-pole isolating switch must be integrated into the
permanent electrical installation according to the install-
ation regulations.
1.
Identify the phase and neutral conductors in the
socket.
The appliance may be damaged if it is not connec-
ted correctly.
2.
Connect the hob in accordance with the connection
diagram.
See the rating plate for the voltage.
3.
Connect the wires of the mains power cable accord-
ing to the colour coding:
‒ Green/yellow = Protective conductor
‒ Blue = Neutral conductor
‒ Brown = Phase (external conductor)
22.8 Installing the appliance
Note:Do not use a cordless screwdriver to secure the
panels. This may damage the panels.
Installation instructions en
33
1.
If required, you can adjust the gap between the ap-
pliance door and the panels using the adjustment
screws on the left and right.
Turning the screws clockwise makes the gap larger
Turning the screws anti-clockwise makes the gap
smaller
2.
Push the appliance in fully.
Do not kink or trap the connecting cable, or route it
over sharp edges.
3.
Centre the appliance.
There must be an air gap of at least 4mm between
the appliance and adjacent unit fronts.
4.
Open the appliance door slightly and unscrew pan-
els on the left and right.
5.
Close the appliance door.
6.
If required, you can adjust the height of the appli-
ance door using the adjustment screws on the left
and right.
Turning the screws clockwise makes the gap smal-
ler
Turning the screws anti-clockwise makes the gap
larger
7.
Screw the appliance into place.
8.
Open the appliance door slightly, then refit the pan-
els and screw them in place, first at the top and
then at the bottom.
Note:The gap between the worktop and the appliance
must not be closed by additional battens.
Thermal insulation strips must not be fitted to the side
panels of the surround unit.
22.9 Removing the appliance
1.
Disconnect the appliance from the power supply.
2.
Undo the fastening screws.
3.
Lift the appliance slightly and pull it out completely.
Constructa-Neff Vertriebs-GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
*9001580263*
9001580263
010121
en
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
