Installation Instructions – ZUG30 Heater Kit/Cover
TO BE USED WITH HOUSEHOLD REFRIGERATORS
30" BUILT-IN
BOTTOM-FREEZER, 2 DRAWER
ALL REFERENCES TO ASSEMBLY ARE FROM THE FRONT OF THE UNITS
PARTS PROVIDED:
Installation Instructions (1)
Heater (1)
Transformer (1)
Plastic Cover (1)
Brackets (2)
Tools Required:
#2 Phillips Head Screw Driver
Step Ladder
Open Wrench Set
5 mm. Allen Wrench
IMPORTANT SAFETY NOTICE:
This kit is to be installed by a qualied service technician only. Any attempt to repair a major appliance may result in
personal injury and property damage. Neither the manufacturer nor the seller can be responsible for the interpretation
of this information or assume any liability in connection with its use.
197D9290P001 31-45446-1 05-12 GE
Unit 1 - Spacer Clips Installed
Unit 1
Unit 2
Unit 2 - Heater Installed
Spacer Clips (8)
Strain Relief (1)
Screw, 4.8 x 13 (4)
Bolt, M4 x 18 (2)
Nut, M4 (2)
Washer, star (4)
Bolt, M6 x 45 (3)
Nut, M6 (3)
Washer, at (6)
Wiring 'Y' Splitter (1)
NOTE: WHILE PERFORMING INSTALLATIONS
DESCRIBED IN THIS BOOK, SAFETY GLASSES OR
GOGGLES SHOULD BE WORN.
PPE Required:
Safety Glasses
Safety Gloves
BEFORE YOU BEGIN
Read these instructions
completely and carefully.
Disconnect power to the appliance before beginning installation.
Do not operate the refrigerator until the installation is complete.
WARNING
WARNING
This refrigerator is top heavy and must be handled with care.
Failure to do so can result in the unit tipping over and re
sult in death or serious injury.
Do not cut lower banding on units.
Do not remove foam base pad from front of units.
STOP
