Sharp XL-DV60 DVD Micro System User Manual

Thank you for purchasing this SHARP product.

To obtain the best performance from this product, please read this

manual carefully. It will guide you in operating your SHARP product.

MODEL

XL-DV60

OPERATION MANUAL

XL-DV60 DVD Micro System consisting of XL-DV60 (main unit), CP-

DV60F (front speakers) and CP-DV60SW (subwoofer).

DVD MICRO SYSTEM

XL-DV60

Important Instruction

SPECIAL NOTES

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVIC-

ING TO QUALIFIED SERVICE PERSONNEL.

Explanation of Graphical Symbols:

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s en-

closure that may be of sufficient magnitude

to constitute a risk of electric shock to per-

sons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and main-

tenance (servicing) instructions in the lit-

erature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR

MOISTURE.

THIS PRODUCT IS A CLASS 1 LASER PRODUCT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY

RESULT IN HAZARDOUS RADIATION EXPOSURE.

AS THE LASER BEAM USED IN THIS PRODUCT IS HARMFUL TO

THE EYES, DO NOT ATTEMPT TO DISASSEMBLE THE CABINET.

REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION:

Note to CATV system installer:

This reminder is provided to call the CATV system installer's at-

tention to Article 820-40 of the National Electrical Code that

provides guidelines for proper grounding and, in particular,

specifies that the cable ground shall be connected to the

grounding system of the building, as close to the point of cable

entry as practical.

Note:

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency en-

ergy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interfer-

ence to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

●

Reorient or relocate the receiving antenna.

●

Increase the separation between the equipment and receiver.

●

Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

●

Consult the dealer or an experienced radio/TV technician for help.

WARNING

FCC Regulations state that any unauthorized changes or modifications

to this equipment not expressly approved by the manufacturer could

void the user's authority to operate this equipment.

FOR YOUR RECORDS

For your assistance in reporting this unit in case of loss or theft,

please record below the model number and serial number which

are located on the rear of the unit.

Please retain this information.

Model number .......................................................

Serial number .......................................................

Date of purchase .......................................................

Place of purchase .......................................................

XL-DV60

Important Instruction

IMPORTANT SAFETY INSTRUCTIONS

Read Instructions - All the safety and operating instructions should

be read before the product is operated.

Retain Instructions - The safety and operating instructions should be

retained for future reference.

Heed Warnings - All warnings on the product and in the operating

instructions should be adhered to.

Follow Instructions - All operating and use instructions should be

followed.

Cleaning - Unplug this product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning.

Attachments - Do not use attachments not recommended by the prod-

uct manufacturer as they may cause hazards.

Water and Moisture - Do not use this product near water - for ex-

ample, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a

wet basement; or near a swimming pool; and the like.

Accessories - Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing serious injury to

a child or adult, and serious damage to the product. Use only with a

cart, stand, tripod, bracket, or table recommended by the manufac-

turer, or sold with the product. Any mounting of the product should

follow the manufacturer’s instructions, and should use a mounting ac-

cessory recommended by the manufacturer.

A product and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces

may cause the product and cart combination to over-

turn.

Ventilation - Slots and openings in the cabinet are provided for venti-

lation and to ensure reliable operation of the product and to protect it

from overheating, and these openings must not be blocked or cov-

ered. The openings should never be blocked by placing the product on

a bed, sofa, rug, or other similar surface. This product should not be

placed in a built-in installation such as a bookcase or rack unless proper

ventilation is provided or the manufacturer’s instructions have been

adhered to.

Power Sources - This product should be operated only from the type

of power source indicated on the marking label. If you are not sure of

the type of power supply to your home, consult your product dealer or

local power company. For products intended to operate from battery

power, or other sources, refer to the operating instructions.

Grounding or Polarization - This product may be equipped with a

polarized alternating-current line plug (a plug having one blade wider

than the other). This plug will fit into the power outlet only one way.

This is a safety feature. If you are unable to insert the plug fully into the

outlet, try reversing the plug. If the plug should still fail to fit, contact

your electrician to replace your obsolete outlet. Do not defeat the safety

purpose of the polarized plug.

Alternate Warnings - This product is equipped with a three-wire

grounding-type plug, a plug having a third (grounding) pin. This plug

will only fit into a grounding-type power outlet. This is a safety feature.

If you are unable to insert the plug into the outlet, contact your electri-

cian to replace your obsolete outlet. Do not defeat the safety purpose

of the grounding-type plug.

Power-Cord Protection - Power-supply cords should be routed so

that they are not likely to be walked on or pinched by items placed

upon or against them, paying particular attention to cords at plugs,

convenience receptacles, and the point where they exit from the product.

Protective Attachment Plug - The product is equipped with an at-

tachment plug having overload protection. This is a safety feature. See

Instruction Manual for replacement or resetting of protective device. If

replacement of the plug is required, be sure the service technician has

used a replacement plug specified by the manufacturer that has the

same overload protection as the original plug.

XL-DV60

Important Instruction

IMPORTANT SAFETY INSTRUCTIONS

(continued)

Outdoor Antenna Grounding - If an outside antenna or cable system

is connected to the product, be sure the antenna or cable system is

grounded so as to provide some protection against voltage surges and

built-up static charges. Article 810 of the National Electrical Code, ANSI/

NFPA 70, provides information with regard to proper grounding of the

mast and supporting structure, grounding of the lead-in wire to an an-

tenna discharge unit, size of grounding conductors, location of antenna

discharge unit, connection to grounding electrodes, and requirements

for the grounding electrode.

Lightning - For added protection for this product during a lightning

storm, or when it is left unattended and unused for long periods of

time, unplug it from the wall outlet and disconnect the antenna or cable

system. This will prevent damage to the product due to lightning and

power-line surges.

Power Lines - An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or power circuits,

or where it can fall into such power lines or circuits. When installing an

outside antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them might be

fatal.

Overloading - Do not overload wall outlets, extension cords, or integral

convenience receptacles as this can result in a risk of fire or electric shock.

Object and Liquid Entry - Never push objects of any kind into this

product through openings as they may touch dangerous voltage points

or short-out parts that could result in a fire or electric shock. Never spill

liquid of any kind on the product.

Servicing - Do not attempt to service this product yourself as opening

or removing covers may expose you to dangerous voltage or other

hazards. Refer all servicing to qualified service personnel.

Damage Requiring Service - Unplug this product from the wall outlet

and refer servicing to qualified service personnel under the following

conditions:

a) When the power-supply cord or plug is damaged,

b) If liquid has been spilled, or objects have fallen into the product,

c) If the product has been exposed to rain or water,

d) If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the op-

erating instructions as an improper adjustment of other controls may

result in damage and will often require extensive work by a qualified

technician to restore the product to its normal operation,

e) If the product has been dropped or damaged in any way, and

f) When the product exhibits a distinct change in performance - this

indicates a need for service.

Replacement Parts - When replacement parts are required, be sure

the service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

Safety Check - Upon completion of any service or repairs to this prod-

uct, ask the service technician to perform safety checks to determine

that the product is in proper operating condition.

Wall or Ceiling Mounting - The product should be mounted to a wall

or ceiling only as recommended by the manufacturer.

Heat - The product should be situated away from heat sources such

as radiators, heat registers, stoves, or other products (including ampli-

ANTENNA LEAD IN WIRE

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

NEC - NATIONAL ELECTRICAL CODE

S2898A

ELECTRIC

SERVICE

EQUIPMENT

GROUND

CLAMP

Example of antenna grounding as per

National Electrical Code, ANSI/NFPA 70

ANTENNA DISCHARGE UNIT

(NEC SECTION 810-20)

fiers) that produce heat.

0304

XL-DV60

General Information

Accessories

Please confirm that the following accessories are included.

Caution:

Do not use the supplied AC power cord for other equipment. Fire or

electric shock may result.

Note:

Only the above accessories are included.

"DTS" and "DTS Digital Out" are trademarks of Digital Theater Sys-

tems, Inc.

Manufactured under license from Dolby Laboratories. "Dolby" and

the double-D symbol are trademarks of Dolby Laboratories.

NOTES

Licensed under one or more of U.S. Pat. 4,972,484, 5,214,678,

5,323,396, 5,530,655, 5,539,829, 5,544,247, 5,606,618, 5,610,985,

5,740,317, 5,777,992, 5,878,080 or 5,960,037.

Supply of this product does not convey a license nor imply any

right to distribute content created with this product in revenue-

generating broadcast systems (terrestrial, satellite, cable and/or

other distribution channels), revenue-generating streaming

applications (via Internet, intranets and/or other networks), other

revenue-generating content distribution systems (pay-audio or

audio-on-demand applications and the like) or on revenue-

generating physical media (compact discs, digital versatile discs,

semiconductor chips, hard drives, memory cards and the like). An

independent license for such use is required. For details, please

visit http://mp3licensing.com.

MPEG Layer-3 audio coding technology licensed from Fraunhofer

IIS and Thomson.

ENERGY STAR

Program Information

Products that have earned

the ENERGY STAR

are

designed to protect the

environment through

superior energy efficiency.

To comply with the ENERGY STAR

standards mentioned above,

please cancel the demonstration mode, as described on page 18.

ENERGY STAR

is a U.S. registered mark.

Remote control 1 FM/AM loop antenna 1

(RRMCGA007SJSA) (QANTL0009SJZZ)

AC power cord 1 Video cable 1

(QACCU0003SJ00) (QCNWGA004SJZZ)

Icons used in this operation manual

Some functions may not be available depending on discs. The fol-

lowing icons indicate the discs that can be used in the section.

... Indicates DVDs.

... Indicates video CDs.

... Indicates audio CDs.

... Indicates CD-R/RW with MP3 recording.

... Indicates CD-R/RW with JPEG recording.

! Some operations may not be performed depending on discs

even if they are described in this manual.

! During operation, " " may be displayed on the screen. This

means that the operations described in this manual are prohib-

ited by the disc.

XL-DV60

General Information

Contents

Page

" General Information

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 10

Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 13

" Preparation for Use

System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 - 18

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

" DVD Operation

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 - 24

Basic operation

To locate the beginning of a chapter/track (skip) . . . . . . . . . . 25

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . 25

To start playback from the desired point (direct play) . . . 26, 27

Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Useful operation

To change the audio language (audio output) . . . . . . . . . . . . . 28

To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . 29

To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

To select a title, subtitle or audio language, etc.

from the top menu or menu of the disc . . . . . . . . . . . . . . . . . . 29

To zoom in on an image (zoom) . . . . . . . . . . . . . . . . . . . . . . . . 30

To brighten an image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

To improve the image quality . . . . . . . . . . . . . . . . . . . . . . . . . . 31

To change the display on TV screen . . . . . . . . . . . . . . . . . . . . 32

To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . 33

To play the contents between the specified points

repeatedly (A-B repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Page

" Video CD Operation

Playing a video CD

To play a video CD with P. B. C. (playback control) . . . . . . . . 35

" Audio CD Operation

Playing an audio CD

To play in random order (random play) . . . . . . . . . . . . . . . . . . 36

To start playback from the desired point (direct play) . . . . . . 36

To play in the desired order (programmed playback) . . . . . . . 37

" MP3 and JPEG Disc Operation

Playing an MP3 and JPEG disc . . . . . . . . . . . . . . . . . . . . . . 38, 39

" Radio

Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40, 41

" Advanced Features

Changing the initial setting of DVD . . . . . . . . . . . . . . . . . 42 - 47

Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . 48 - 50

Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

" References

Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52, 53

Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . 53

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54, 55

CONSUMER LIMITED WARRANTY . . . . . . . . . . . . . . .Back cover

! Unauthorized copying, broadcast, public display, transmission,

public performance and rental (regardless of whether or not

such activities are for profit) of disc contents are prohibited by

law.

! This system is equipped with copy protection technology that

causes substantial degradation of images when the contents of

a disc are copied to a video tape.

XL-DV60

General Information

Precautions

" General

! Please ensure that the equipment is positioned in a well-venti-

lated area and ensure that there is at least 4" (10 cm) of free

space along the sides, top and back of the equipment.

! Do not place anything on top of the unit.

! Do not expose the unit to moisture, to temperatures higher than

140°F (60°C) or to extremely low temperatures.

! If your system does not work properly, disconnect the AC power

cord from the AC outlet. Plug the AC power cord back in, and

then turn on your system.

! This unit should only be used within the range of 41°F - 95°F

(5°C - 35°C).

Warning:

The voltage used must be the same as that specified on this unit.

Using this product with a higher voltage other than that which is

specified is dangerous and may result in a fire or other type of acci-

dent causing damage. SHARP will not be held responsible for any

damage resulting from use of this unit with a voltage other than that

which is specified.

" Volume control

The sound level at a given volume setting depends on speaker effi-

ciency, location and various other factors. It is advisable to avoid

exposure to high volume levels, which occurs while turning the unit

on with the volume control setting up high, or while continually lis-

tening at high volumes.

! Use the unit on a firm, level surface free from

vibration.

! Keep the unit away from direct sunlight,

strong magnetic fields, excessive dust,

humidity and electronic/electrical equip-

ment (home computers, facsimiles, etc.)

which generate electrical noise.

! In case of an electrical storm, unplug the

unit for safety.

4" (10 cm)

4" (10 cm) 4" (10 cm)

4" (10 cm)

! Hold the AC power plug by the head when

removing it from the AC outlet, as pulling

the cord can damage internal wires.

! Do not remove the outer cover, as this

may result in electric shock. Refer inter-

nal service to your local SHARP service

facility.

XL-DV60

General Information

Controls and indicators

" Front panel

Reference page

1. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

2. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

3. DVD/CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 18

5. Timer Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

6. Stop or Tuning Down Button . . . . . . . . . . . . . . . . . . . . . 23, 40

7. Play or Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . . 23, 40

8. Extra Bass/Demo Mode Button . . . . . . . . . . . . . . . . . . . 18, 20

9. Equalizer Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . 20

10. Headphone Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

11. Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

12. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 23

13. Chapter (Track) Skip Down or Fast Reverse,

Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . 25, 41

14. Chapter (Track) Skip Up or Fast Forward,

Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . 25, 41

15. Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

16. Disc Compartment Open/Close Button . . . . . . . . . . . . . . . 22

17. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

18. Disc Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

" Display

Reference page

1. Disc Number Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

2. Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3. Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4. Repeat Play Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 33, 34

5. Disc Type Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6. Extra Bass Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

7. Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

8. Timer Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

9. Sound Mode Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

10. Memory Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37, 41

11. Angle Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

12. Surround Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

13. FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 40

14. FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 40

321 4 5 6 7 8

13 1410 11 12

XL-DV60

General Information

" Rear panel

Reference page

1. AC Power Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3. Component Video Output Jacks . . . . . . . . . . . . . . . . . . . . . 17

4. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

5. FM/AM Loop Antenna Jack . . . . . . . . . . . . . . . . . . . . . . . . . 15

6. Video/Auxiliary (Audio Signal) Input Jacks . . . . . . . . . . . . 51

7. Video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

8. S-video Output Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

9. Optical Digital Audio Output Jack . . . . . . . . . . . . . . . . . . . 51

" Front speaker

1. Semi Dome Tweeter

2. Woofer

3. Bass Reflex Duct

4. Speaker Wire

" Subwoofer

1. Sub Duct Pipe

2. Subwoofer

3. Speaker Wire

XL-DV60

General Information

Controls and indicators (continued)

" Remote control

Reference page

1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 19

2. DVD Setup Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

3. Power On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 19

4. Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5. Chapter (Track) Skip Down or Fast Reverse,

Tuner Preset Down, Time Down Button . . . . . . . . . 21, 25, 41

6. Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 42

7. Zoom or Audio Select Button . . . . . . . . . . . . . . . . . 28, 30, 39

8. Repeat Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

9. Frame Advance or Pause Button . . . . . . . . . . . . . . . . . 23, 27

10. A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

11. Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . 21, 37, 41

12. Top Menu or Return Button . . . . . . . . . . . . . . . . . . . . . . 29, 42

13. Subtitle or Surround Mode Select Button . . . . . . . . . . 20, 29

14. Shift Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

15. Extra Bass or Digital Picture Select Button . . . . . . . . . 20, 31

16. DVD/CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

17. Equalizer Mode Select or Digital Gamma Button . . . . 20, 31

18. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

19. Menu or On Screen Display Select Button . . . . . . . . . . 29, 32

20. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . 23

21. Direct or Video Mode Select Button . . . . . . . . . . . . . . . 17, 26

22. Chapter (Track) Skip Up or Fast Forward,

Tuner Preset Up, Time Up Button . . . . . . . . . . . . . . 21, 25, 41

23. Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 42

24. Angle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

25. Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

26. Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

27. Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

28. Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

29. Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48, 50

30. Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

31. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

32. Volume or Subwoofer Level Up and Down Buttons . . . . . 20

XL-DV60

General Information

Description of discs

" Types of playable discs

The unit can play back discs bearing any of the following marks:

! For unplayable discs, see page 13.

Copy Protection:

This unit supports Macrovision copy protection.

On DVD discs that include a copy protection code, if the contents of

the DVD disc are copied using a VCR, the copy protection code pre-

vents the videotape copy from playing normally.

Disc type Disc contents Disc size

DVD Video Disc for NTSC

system

Audio and video

(movies)

5" (12 cm)

3" (8 cm)

Or DVD-R/DVD-RW/DVD+R/

DVD+RW recorded in video

mode (*1)

Video CD for NTSC system Audio and video

(movies)

5" (12 cm)

3" (8 cm)

Audio CD Audio 5" (12 cm)

3" (8 cm)

Or CDV (*2)

CD-R/CD-RW (*3) Audio and picture 5" (12 cm)

3" (8 cm)

CD-R/CD-RW re-

corded in MP3 for-

mat (*4), JPEG

format (*5)

(*1): Discs including DVD-R/DVD-RW/DVD+R/DVD+RW may not be

played back due to properties and scratches on the disc, dirty

optical pickup lens, etc.

(*2): Only the audio on the CDV can be played.

(*3): The CD-R/CD-RW may not be played back properly depending

on the recording equipment or the disc.

(*4): If the sampling frequency is 44.1 or 48.1 kHz and the fixed bit

rate is 128 kbps or higher, MPEG 1 Audio Layer 3 (MP3) files

can be played. However, some of them may not be played de-

pending on their conditions or formats.

(*5): JPEG or JPG picture discs also play on this unit. However, pic-

tures may not be clear (depends on resolution and recording

method).

Apparatus Claims of U.S.Patent Nos. 4,631,603, 4,577,216,

4,819,098 and 4,907,093 licensed for limited viewing uses only.

This product incorporates copyright protection technology that is

protected by method claims of certain U.S. patents and other

intellectual property rights owned by Macrovision Corporation

and other rights owners. Use of this copyright protection

technology must be authorized by Macrovision Corporation, and

is intended for home and other limited viewing uses only unless

otherwise authorized by Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

0403E

XL-DV60

General Information

Description of discs (continued)

" DVD-Video

A popular type of DVD disc of the same size as a CD, mainly con-

taining video images.

Region number

Title and chapter

DVD-Video discs are divided into "titles" and "chapters". If the disc

has more than one movie on it, each movie is a separate "title".

"Chapters" are subdivisions of titles.

" DVD-R/DVD-RW/DVD+R/DVD+RW

! You can play DVD-R/DVD-RW/DVD+R/DVD+RW discs recorded

in the video mode.

! Before playing DVD-R/DVD-RW/DVD+R/DVD+RW discs with

this unit, finalize them with the equipment used for record-

ing.

" Video CD/audio CD

Track

Video CD and audio CD are composed of "tracks". Tracks are equiv-

alent to songs on a CD.

" MP3/JPEG format on CD-R/CD-RW

An MP3 file is audio data compressed in the MPEG 1 audio layer 3

format. MP3 files have the extension ".mp3". (Files with the exten-

sion ".mp3" may not play, or noise may occur during playback if not

recorded in the MP3 format.)

A JPEG file is still image data compressed in the JPEG (Joint Pho-

tographic Experts Group) format. JPEG files have the extension

".jpg".

Folder and file

MP3/JPEG discs consist of "folders" and "files".

DVD discs are programmed with region

numbers indicating countries in which

they can be played. This system can

play discs with region number "1" or

"ALL".

Region number

(playable area number)

ALL

Chapter 1

Title 1 Title 2

Chapter 2 Chapter 3 Chapter 1 Chapter 2

Track 1 Track 2 Track 3 Track 4

MP3

disc

JPEG

disc

File 1

Folder 1

File 2 File 1

Folder 2

File 2File 3

XL-DV60

General Information

" Icons used on DVD discs

Check the icons of the DVD jacket before playing your discs.

" Discs that cannot be played

Notes:

! The discs above cannot be played at all, or no sound is heard

although images appear on the screen or vice versa.

! Faulty playback may damage the speakers and can have an

adverse effect on your hearing when played at high volume set-

tings.

! You cannot play illegally produced discs.

! A disc with scratches or fingerprints may not play properly. Refer

to "Care of discs" (page 54) and clean the disc.

Display Description

Format recorded on the DVD Select a type according to the

connected TV type.

Type of subtitles recorded Recorded subtitle languages.

Example: You can select a subtitle lan-

guage.

1. English

2. German

Number of camera angles Number of angles recorded on

the DVD.

You can view scenes from dif-

ferent angles.

Number of audio tracks and au-

dio recording systems

The number of audio tracks

and audio recording systems

are indicated.

Example:

1: Original <English>

(Dolby Digital 5.1 Sur-

round)

! You can change the audio

language.

! Audio and recording sys-

tem vary depending on the

DVD. Check them in the

DVD's manual.

2. German (Dolby Dig-

ital 2 ch)

! DVDs without the region num-

ber "1" or "ALL".

! DVD-Audio

! CDG

! DVDs with SECAM system ! Photo CD

! DVDs with MPEG sound ! CD-ROM

! DVD-ROM ! SACD

! DVD-RAM ! Discs recorded in special for-

mats, etc.

XL-DV60

Preparation for Use

System connections

Front speaker (left)Front speaker (right)Subwoofer

AC outlet

(AC 120 V, 60 Hz)

Speaker connection (see page 15)

FM antenna

Make sure to unplug the AC power cord before making any connections.

FM/AM loop antenna connection (see page 15)

TV connection

(see pages 16 - 17)

Connecting the AC power cord (see page 18)

AM loop antenna

XL-DV60

Preparation for Use

" FM/AM loop antenna connection

Connect the FM/AM loop antenna to the ANTENNA jack.

Position the FM antenna wire and rotate the AM loop antenna for

optimum reception. Place the AM loop antenna on a shelf, or attach

it to a stand or a wall.

Notes:

! Placing the antenna on the stereo system or near the AC power

cord may cause noise pickup. Place the antenna away from the

stereo system for better reception.

! Do not connect the attached FM antenna to an external antenna

as this may cause trouble.

Installing the AM loop antenna:

" Speaker connection

Insert the front speaker plugs (black) into the FRONT terminals.

Insert the subwoofer plug (red) into the SUBWOOFER terminal.

Caution:

" Front speaker grills are removable

< Assembling > < Attaching to the wall >

Wall Screws (not supplied)

! The supplied speakers are exclusively for the XL-DV60. Do

not connect them to other equipment, and do not connect

other speakers to the XL-DV60. It may cause malfunction.

! Use speakers with an impedance of 6 ohms or more, as lower im-

pedance speakers can damage the unit.

! Do not mistake the right and the left channels. The right speaker

is the one on the right side when you face the unit.

! Do not allow any objects to fall into or to be placed in the bass re-

flex ducts of the speakers.

! Do not stand or sit on the speakers. You may be injured.

Make sure nothing comes into contact with the

speaker diaphragm when you remove the

speaker grilles.

Front speaker

(left)

Speaker or subwoofer plug in with the rising

side facing to the right.

Black

Red

Front speaker

(right)

Subwoofer

XL-DV60

Preparation for Use

System connections (continued)

" Placing the speaker system

Notes:

! Place the TV halfway between the front speakers.

! The bass sound from the subwoofer is omni-directional, however,

it is recommended to place it as close as left and right speakers.

! Place the subwoofer on a sturdy and stable surface as it tends to

vibrate while reproducing bass sounds.

! Keep the free space of at least 4" (10 cm) along the right side of

the subwoofer.

" Magnetically shielded speakers

The speakers are magnetically shielded.

Therefore, they do not affect the display even if you use them near

the TV. However, some color variation may occur, depending on the

type of TV used.

If color variation occurs...

Turn off the TV (from the power switch).

After 15 - 30 minutes, turn the TV on again.

If the color variation is still present...

Move the speakers further away from the TV.

If any kind of magnet or an electromagnet is placed too close to the

TV and the system, irregular colors may appear on the TV screen.

" TV connection

Three types of jacks (VIDEO OUT, S-VIDEO OUT and COMPO-

NENT VIDEO OUT) are available for connection of a TV and this

unit. Connect according to your TV.

Connecting to a TV with a video input jack:

You can enjoy DVD images by connecting your TV and this unit with

the supplied video cable.

Front speaker

(left)

Subwoofer

Same distance

Front speaker

(right)

Set the video mode to "Interlace" (default setting). For the proce-

dure, refer to "Changing the video mode" on page 17.

Notes:

! Change the TV input in accordance with the connected jack.

! Do not connect other equipment (VCR, etc.) between the TV

and this unit. Pictures may be distorted.

! Refer to the operation manual of the equipment to be connect-

ed.

! Insert the plugs fully to avoid fuzzy pictures or noise.

To video

input jack

Video signal

Video cable

(supplied)

XL-DV60

Preparation for Use

Connecting to a TV with an S-video input jack:

If your TV is equipped with an S-video input jack, you can enjoy higher

quality images by connecting it with an S-video cable (not supplied).

Note:

When the video and S-video cables are both connected, the images

from the S-video input jack appears on your TV.

Connecting to a TV with component video input jacks:

If your TV is equipped with component video input jacks, purchase a

component video cable to enjoy higher quality images.

Notes:

! If your TV has different indications for the component video inputs

(Y, B-Y and P-Y), connect jacks with its matching color.

! Some component video jacks designed for the high-vision sys-

tem are not compatible with DVD. Do not connect this unit to

those component video input jacks. (Images may appear dis-

torted or may not appear due to the system difference.)

What is progressive scanning?

The conventional TV system displays 30 frames of still images per

second to perform a series of movements (interlaced scanning).

Whereas, progressive scanning displays one frame every 1/60th of

a second (60 frames per second) to ensure less flickers and high-

density images.

Set the video mode to "Interlace" (default setting). For the proce-

dure, refer to "Changing the video mode".

Changing the video mode:

1 Insert a DVD disc (steps 1 - 6, pages 22 - 23).

2 While in the stop mode, press the SHIFT button and DIRECT/

VIDEO MODE button on the remote control.

Each time these buttons are pressed, the mode will change in

the following order:

Caution:

To enjoy images on a TV, make sure to select the right items

for the following four: video cable, TV's video input jack, and

this unit's video output jack and video mode. Otherwise, im-

ages do not appear properly.

To S-video

input jack

Video signal

S-video cable

(commercially available)

Interlace

Progressive

Select this for a non-progressive scan TV

(use a video cable, S-video cable, or component

video cable).

Select this for a progressive scan TV

(use a component video cable).

For a progressive scan TV, set the video mode to "Progressive".

Select "Interlace" for a non-progressive scan TV.

To component

video input jacks

Video signal

Component video cable

(commercially available)

XL-DV60

Preparation for Use

System connections (continued)

" Connecting the AC power cord

After checking all the connections have been made correctly, con-

nect the AC power cord to the AC power input jack, then plug the AC

power cord of this unit into the AC outlet. If you plug in the unit first,

the unit will enter the demonstration mode.

Notes:

! Never use a power cord other than the one supplied. Otherwise,

a malfunction or an accident may occur.

! Unplug the AC power cord from the AC outlet if the unit will not be

in use for a prolonged period of time.

" Demonstration mode

" To turn the power on

Cooling fan:

A cooling fan is built into this unit for better heat radiation. Do not

cover the opening in this section with any obstacles to avoid dam-

age to the unit.

AC outlet

(AC 120 V, 60 Hz)

When you plug the unit in for the first time,

the unit will enter the demonstration

mode. You will see words scroll.

To cancel the demonstration

mode:

When the unit is in the power stand-

by mode (demonstration mode),

press the X-BASS/DEMO button.

The unit will enter the low power

consumption mode.

To return to the demonstration mode:

When the unit is in the power stand-by mode, press the X-BASS/

DEMO button again.

Note:

When the power is on, the X-BASS/DEMO button can be used to se-

lect the extra bass mode.

Press the ON/STAND-BY but-

ton to turn the power on.

After use:

Press the ON/STAND-BY button to enter the power stand-by

mode.

XL-DV60

Preparation for Use

Remote control

" Battery installation

Precautions for battery use:

! Replace all old batteries with new ones at the same time.

! Do not mix old and new batteries.

! Remove the batteries if the unit will not be used for long periods

of time. This will prevent potential damage due to battery leak-

age.

Caution:

! Do not use rechargeable batteries (nickel-cadmium battery, etc.).

! Installing the batteries incorrectly may cause the unit to malfunc-

tion.

Battery removal:

Remove the battery cover. Push each battery toward the battery

terminal and take them out.

Notes concerning use:

! Replace the batteries if the operating distance is reduced or if the

operation becomes erratic.

! Periodically clean the transmitter on the remote control and the

sensor on the unit with a soft cloth.

! Exposing the sensor on the unit to strong light may interfere with

operation. Change the lighting or the direction of the unit if this

occurs.

! Keep the remote control away from moisture, heat, shock, and

vibrations.

" Test of the remote control

Check the remote control after checking all the connections (see

pages 14 - 18).

Point the remote control directly at the remote sensor on the unit.

The remote control can be used within the range shown below:

Press the ON/STAND-BY button. Does the power turn on? Now, you

can enjoy music.

Use 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).

Batteries are not included.

1 Remove the battery cover.

2 Insert the batteries according to the direction indicated in

the battery compartment.

When inserting or removing the batteries, push them toward the

battery terminals.

3 Replace the cover.

8" - 20'

(0.2 m - 6 m)

Remote sensor

XL-DV60

Preparation for Use

General control

" Volume control

" Subwoofer volume control

" Bass control (X-BASS)

" Equalizer

When the EQUALIZER (EQ-MODE) button is pressed, the current

mode setting will be displayed. To change to a different mode, press

the EQUALIZER (EQ-MODE) button repeatedly until the desired

sound mode appears.

" Surround

Note:

When the input source is "TUNER" or "AUX", the surround mode is

not available.

Main unit operation:

When the VOLUME control is turned

clockwise, the volume will increase.

When it is turned counterclockwise,

the volume will decrease.

Remote control operation:

Press the VOLUME (+ or -) button to increase or decrease the volume.

Press the SHIFT button on the re-

mote control, and adjust the volume.

(

MAXIMUM

)

290

.....

(

MAXIMUM

)

290

.....

When the power is first turned on,

the unit will enter the extra bass

mode which emphasizes the bass

frequencies, and "X-BASS" will ap-

pear. To cancel the extra bass

mode, press the X-BASS/DEMO (X-

BASS) button.

To enter the surround mode, press

the SHIFT button and SUB TITLE/

SURROUND button on the remote

control. Repeat this operation to exit.

ROCK

FLAT

CLASSIC

The sound is not modified.

For rock music.

POPS

For pop music.

JAZZ

For jazz.

For classical music.

VOCAL

Vocals are enhanced.

XL-DV60

Preparation for Use

Setting the clock

In this example, the clock is set for the 12-hour (AM 12:00) display.

To confirm the time display:

Note:

The "CLOCK" or time will flash at the push of the CLOCK button

when the AC power supply is restored after a power failure or

unplugging the unit.

Readjust the clock as follows.

To readjust the clock:

Perform "Setting the clock" from step 1. If the "CLOCK" is not flash-

ing in step 1, step 2 (for selecting the 12-hour or 24-hour display) will

be skipped.

To change the 12-hour or 24-hour display:

Press the CLOCK button and within 8 seconds, press the

MEMORY/SET button.

Within 30 seconds, press the PRESET ( or ) button to

select 12-hour or 24-hour display and then press the MEM-

ORY/SET button.

"AM 12:00" The 12-hour display will appear.

(AM 12:00 - PM 11:59)

"0:00" The 24-hour display will appear.

(0:00 - 23:59)

Within 30 seconds, press the PRESET ( or ) button to

adjust the hour and then press the MEMORY/SET button.

Press the PRESET ( or ) button once to advance the time

by 1 hour. Hold it down to advance continuously.

Within 30 seconds, press the PRESET ( or ) button to

adjust the minutes and then press the MEMORY/SET but-

ton.

Press the PRESET ( or ) button once to advance the time

by 1 minute. Hold it down to advance continuously.

Press the CLOCK button.

The time display will appear for

about 8 seconds.

1 Clear all the programmed contents. [Refer to "Clearing all the

memory (reset)" on page 53 for details.]

2 Perform "Setting the clock" from step 1.

XL-DV60

DVD Operation

Playing a disc

Turn on the TV, and switch the input to the "VIDEO 1" or "VIDEO 2",

etc. accordingly.

Press the ON/STAND-BY button to turn the power on.

Press the DVD/CD button.

Press the OPEN/CLOSE button

to open the disc compartment.

All trays open in tiers.

Place the disc on the disc tray 1, label side up.

Be sure to place 3" (8 cm) discs in the middle of the disc trays.

To place discs in the trays 2 - 5.

1. Slide in the tray with a disc to-

ward the unit.

2. Place a disc in an empty tray.

5" (12 cm) 3" (8 cm)

XL-DV60

DVD Operation

To stop playback:

DVD:

Press the button twice.

VCD/CD/MP3/JPEG:

Press the button.

To play from a specified disc:

Note:

If a disc tray with no disc is selected, playback will not start, and only

parentheses of the indicator "( )" disappear.

To remove the discs:

Note:

DVD discs cannot be removed in the resume play mode. Press the

button and then remove the disc.

Press the OPEN/CLOSE button to close the disc compart-

ment.

Discs supporting auto start will start to play once you close the

disc tray even if you do not press the (play) button.

If playback does not start, press the (play) button.

When playing a DTS on this unit, sound is not heard from the

speakers. To listen to the sound, select another audio output in

the "To change the audio language (audio output)" on page 28.

When the menu appears on the TV screen:

On DVD, select an item by using the cursor ( , , or ) button

and press the ENTER button.

On video CD, select an item by using the direct number buttons.

To interrupt playback:

Press the STILL/PAUSE button on the remote

control.

To resume playback from the same point, press

the (play) button.

Pause indicator

Chapter or

track number

The sound mode in use appears during DVD playback.

Play indicator Selected disc type Playing time

1. Press the 1 - 5 button.

2. Press the (play) button.

Selected disc number

1. In the stop mode, press the OPEN/CLOSE

button.

All trays open in tiers.

2. Remove the disc in the tray 1.

3. Slide in the tray 1 toward the unit. In the

same way, remove discs in the trays 2 - 5.

4. After removing the discs, press the OPEN/

CLOSE button again.

Compatibility of the progressive scan TV

Some progressive scan TVs are not fully compatible with this prod-

uct, which may cause image distortion. In this case, switch the vid-

eo mode from "Progressive" to "Interlace" (see page 17).

XL-DV60

DVD Operation

Playing a disc (continued)

Caution:

Notes:

! When the unit is turned on, no operation is possible for 10 sec-

onds as the unit is performing the initial setting.

! Stop positions may be recorded on some discs. When you play

such a disc, playback stops there.

! During an operation, " " may appear indicating that the opera-

tion is disabled by the disc.

" To resume playback after stopping

(resume play)

You can resume playback from the point playback is stopped.

To cancel resume play:

Press the button again while " Pre-Stop" is lit.

Notes:

! The resume play feature is disabled on some discs.

! Depending on the disc, playback may resume slightly before the

position where it was stopped.

! Do not place two discs in one disc tray.

! Do not play discs with special shapes (heart

or octagon shaped) as it may cause malfunc-

tions.

! Do not push the disc compartment while it is moving.

! If the power fails while the disc compartment is open, wait until the

power is restored.

! If the disc compartment is stopped with force, the unit will not func-

tion. If this occurs, press the ON/STAND-BY button to enter the

power stand-by mode and then turn the power on again.

! If a disc is damaged, dirty, or loaded upside down, the disc will

skip or not play.

! When attempting to play discs with scratches or of a different re-

gion number, or unplayable or restricted (*1) discs, an error mes-

sage will appear on the TV display and the disc will not play.

(*1) Viewing is prohibited on some DVDs according to the audi-

ence age.

While the disc is playing, press

the button.

The system stores the point you stopped.

To restart play, press the

(play) button.

Playback resumes from the point you left off.

Pre-Stop

Play

Stop

XL-DV60

DVD Operation

Basic operation

" To locate the beginning of a chapter/track (skip)

You can skip the current chapter (track) to the next or previous.

Notes:

! Some discs do not display the chapter (track) and the skip feature

is disabled.

! On a DVD, you cannot skip across titles.

! When operating video CD with the P.B.C. function, set the P.B.C.

to off (see page 35).

" Fast forward/Fast reverse (search)

You can search the desired point as you play the disc.

Notes:

! On some discs, the search function is disabled.

! On DVD, search does not operate across titles.

! While searching on a DVD or video CD, the sound is not heard

and the subtitles will not appear.

! When a search is performed during DVD playback, pictures may

not be forwarded or reversed in the search speed specified in this

manual, depending on the disc or the scene being played.

While a disc is playing, press the

or button.

! Press the button to skip to the next chapter (track).

! Press the button to skip to the beginning of the current

chapter (track). Press the button again to skip to the be-

ginning of the previous chapter (track).

While a disc is playing, hold

down the or button for 2

seconds or more.

The scanning speed will change as follows at each press of the

button.

The speed changed as follows on DVD/video CD/audio CD:

! The speed cannot be changed on MP3 discs.

! The disc is forwarded by the button and reversed by the

button.

Press the (play) button to return to the normal playback.

Fast Forward 2x

Fast Reverse 2x

Fast Reverse 8x

Fast Reverse 30x

Play

Fast Forward 2x

Fast Forward 8x

Fast Forward 30x

Play

XL-DV60

DVD Operation

Basic operation (continued)

" To start playback from the desired point

(direct play)

To select and play the desired title and chapter:

Notes:

! Direct play feature is disabled on some discs.

! Some discs may not display the chapter number.

! With DVDs, you can specify the desired point only in the current

title and not in another title.

While in the stop or playback mode, press the DIRECT but-

ton.

Within 10 seconds, select the title or chapter by pressing

the cursor ( or ) button and enter the title or chapter

number by using the direct number buttons.

Title number Chapter number

If the title or chapter number is 2 digits or more, press "+10" and

enter the number.

Example:

To select chapter 1, press "1".

To select chapter 12, press "+10" and "2".

To select chapter 22, press "+10", "+10" and "2".

Within 10 seconds, press the ENTER button.

1 / 0801 001 / 010 --:--:--

XL-DV60

DVD Operation

To play by specifying time (time search):

Notes:

! Some discs cannot play from the specified point.

! Time search feature is disabled on some discs.

" Still picture/Frame advance

You can freeze the image and advance frame by frame.

Note:

Still picture and frame advance features are disabled on some discs.

" Slow-motion play

You can slow down the playback speed.

Note:

On some discs, slow-motion play functions are disabled.

While a disc is playing, press the DIRECT button.

Within 10 seconds, select the time by pressing the cursor (

or ) button and specify the time by using the direct number

buttons.

Time

! To specify 1 hour 23 minutes and 40 seconds, enter

"012340".

! If you enter the wrong number, start over from step 1.

Within 10 seconds, press the ENTER button.

While a disc is playing, press the

STILL/PAUSE button.

Each press of the STILL/PAUSE button advances the frame in

the still mode.

Press the (play) button to return to the normal playback.

1 01/ 08 001 / 010 --:--:--

Pause

While a disc is playing, press the STILL/PAUSE button.

Hold down the or button

for 2 seconds or more.

Press the (play) button to return to the normal playback.

Slow Forward

Slow ForwardSlow Backward /

XL-DV60

DVD Operation

Useful operation

The subtitle language and the audio language you select during

playback are reset each time you set this unit to the stand-by mode

or change the disc. To keep your preferred languages, set them in

the initial setting screen (see page 42).

" To change the audio language (audio output)

During playback, you can change the audio language (audio out-

put).

Notes:

! The audio language on some DVDs may not be changed.

! For audio language and audio system, refer to the manual of the

disc.

! When playing a DTS on this unit, sound is not heard from the

speakers. To listen to the sound, change the audio language.

(Example: Dolby Digital 5.1-channel, Dolby Digital 2-channel,

etc.) However, only the 2.1-channel sound can be reproduced.

Alternatively, connect to a DTS digital surround amplifier, etc.

(see page 51).

While a disc is playing, press

the SHIFT button, and then

press the ZOOM/AUDIO but-

ton.

Audio language information

Repeat step 1 to select the desired audio number.

When playing DVD, the language changes as follows:

When playing video CD, audio CD and MP3, the sound chang-

es as follows:

Audio 1/3: AC-3 5.1 English

1: Original <English>

(Dolby Digital 5.1

Surround)

2: English

(Dolby Digital 2 ch Surround)

Audio 1/3: AC-3 5.1 English

Audio 2/3: AC-3 2 English

Mono Left

Mono Right

Stereo

XL-DV60

DVD Operation

" To change the subtitle language

You can change the subtitle language or hide subtitles during play-

back.

Notes:

! Some DVDs prohibit changing the subtitle language.

! If no subtitles are recorded on the disc, " " is displayed.

! It may take a little time to switch the subtitle language to the

selected one.

! The subtitle cannot be hidden on some DVDs.

" To change the angle

You can change the angle of view when playing a DVD video disc

that contains scenes recorded from multiple angles.

Notes:

! Some DVDs prohibit changing the angle.

! Refer to the manual of the disc as the operation may vary

depending on the disc.

" To select a title, subtitle or audio language, etc.

from the top menu or menu of the disc

You can select a title, subtitle or audio language on your DVD if it

has a disc menu.

Notes:

! The procedure shown here provides only general steps. The

actual procedure for using the title menu depends on the disc you

are using. See the disc jacket for details.

! If the disc you are using does not have a title menu, nothing

appears on the screen.

While the disc is playing, press

the SUB TITLE/SURROUND but-

ton.

Within 3 seconds, press the

SUB TITLE/SURROUND button

repeatedly to select the desired

subtitle language.

When " " is displayed in the upper right corner of the TV

screen, press the ANGLE button repeatedly to select the de-

sired angle number.

TV screen On the unit

Subtitle 01/09: English

Subtitle 02/09: Spanish

While the disc is stopped or

played, press the TOP MENU/

RETURN button to display the

top menu or press the MENU/

OSD button to display the menu.

Example

Press the cursor ( , , or ) button to change the setting

and press the ENTER button.

You can also use the direct number buttons for some discs.

TOP MENU

1. Title

2. Subtitle

3. Audio language

XL-DV60

DVD Operation

Useful operation (continued)

" To zoom in on an image (zoom)

You can magnify images during playback.

To return to normal view:

Press the ZOOM button. Repeat this to select "Zoom off".

When you cancel the zoom function, you cannot shift the view.

Notes:

! An image may become distorted when zoomed.

! Subtitles cannot be zoomed.

! For the part currently viewed, refer to the indication in the lower

left section of the screen.

While a disc is playing, press

the ZOOM/AUDIO button.

Each press of the ZOOM button cycles through the zoom set-

tings as follows:

To shift the view and display the desired part of a zoomed

image, press the cursor ( , , or ) button repeatedly.

Zoom x 1.5

Zoom x 1.5 Zoom x 2 Zoom x 3 Zoom off

XL-DV60

DVD Operation

" To brighten an image

To restore the original brightness:

In step 2, select "OFF".

" To improve the image quality

To restore the original image quality:

In step 2, select "OFF".

During playback, press the

SHIFT button, and then press

the DIGITAL GAMMA button.

Within 10 seconds, press the

cursor ( or ) button to set the

level.

Level Setting Level Setting

OFF Normal image ON Brighter

ON Slightly brighter ON A lot brighter

OFF

During playback, press the

SHIFT button, and then press

the DIGITAL PICTURE button.

Within 10 seconds, press the

cursor ( or ) button to set the

level.

Level Setting Level Setting

OFF Normal ON Clearer

ON Slightly clearer ON A lot clearer

OFF

XL-DV60

DVD Operation

Useful operation (continued)

" To change the display on TV screen

When playing DVD, the display changes as follows:

When playing video CD and audio CD, the display changes as fol-

lows:

Note:

On video CD, total playing time or remaining total playing time

appears when P.B.C is off (see page 35).

You can display or hide the operation indicators on the TV screen.

While the disc is playing, press the SHIFT button, and then

press the MENU/OSD button. (The display is changed at each

operation of these two buttons.)

Title playing time

Total number of chapters

Current chapter number

Total number of titles

Current title number

Disc number

Disc type

Chapter playing time

Remaining playing time of

the current title

Remaining playing time of

the current chapter

Angle information

Repeat mode information

Audio language information

Subtitle information

1 1 / 8 2 / 10 00:38:58

1 / 8 2 / 101 -01:09:50

1 / 8 2 / 101 00:07:43

1 / 8 2 / 101 -00:02:38

DEF 1/9 DEF 1/3 1 / 3

DVD

VCD 2.0

CDDA

40:47

58:03

Titles, 10 Chapters

Tracks,

35 Files

23 Files

Data Disc

3 1 / 19 -03:14

3 1 / 19 58:03

3 1 / 19 -40:37

3 1 / 19 01:02

Track playing time

Repeat mode information

PBC information (VCD)

Audio information

Remaining track playing time

Total playing time

Remaining total playing time

DVD

VCD 2.0

CDDA

40:47

58:03

Titles, 10 Chapters

Tracks,

35 Files

23 Files

Data Disc

XL-DV60

DVD Operation

" To play repeatedly (repeat play)

You can play a chapter (track) or a title repeatedly by specifying it

during playback.

Caution:

After performing repeat play, be sure to press the button. Other-

wise, the disc will play continuously.

Notes:

! Repeat play is not available on some discs.

! If you press another button during the repeat play, the playback

may be canceled.

! Repeat play is not possible during random play.

! When operating video CD with the P.B.C. function, set the P.B.C.

to off (see page 35).

While the disc is playing, press the REPEAT button.

TV screen On the unit

Each time the button is pressed, the repeat play mode changes

in the following order.

Chapter Repeat on

Title Repeat on

Repeat off

, CHAP

, TITLE

Disappear

Repeats the chapter

currently playing.

Repeats the title

currently playing.

The normal playback.

File Rep

Folder Rep

Disc Rep

Rep off

Disappear

Repeats the file currently

playing. (Only for MP3)

Repeats the folder

(directory) currently playing.

Repeats the disc

currently playing.

The normal playback.

Track Repeat on

Disc Repeat on

Repeat off

Disappear

Repeats the track

currently playing.

Repeats the disc

currently playing.

The normal playback.

For video CD/audio CD, the mode changes as follows:

For DVD, the mode changes as follows:

For MP3/JPEG discs, the mode changes as follows:

Select "Repeat off" by pressing the REPEAT button repeat-

edly to return to the normal playback.

XL-DV60

DVD Operation

Useful operation (continued)

" To play the contents between the specified

points repeatedly (A-B repeat)

You can play the desired portion repeatedly by specifying it during

playback.

Notes:

! A-B repeat play is disabled on some discs.

! Some scenes in DVD may not allow A-B repeat play.

! A-B repeat play for DVD is possible only within a title.

! A-B repeat play for video CD and audio CD are possible only

within a track.

While the disc is playing, press the A-B button.

TV screen On the unit

This registers the start point (A).

Press the A-B button again.

A-B repeat starts from the start point (A) to the end point (B).

Press the A-B button to return to the normal playback.

A-B Set A

A-B Repeat on

XL-DV60

Video CD Operation

Playing a video CD

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 - 24

To locate the beginning of a chapter/track (skip) . . . . . . . . . . 25

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . 25

Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

To change the audio language (audio output) . . . . . . . . . . . . 28

To zoom in on an image (zoom) . . . . . . . . . . . . . . . . . . . . . . . . 30

To brighten an image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

To improve the image quality . . . . . . . . . . . . . . . . . . . . . . . . . . 31

To change the display on TV screen . . . . . . . . . . . . . . . . . . . . 32

To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . 33

To play the contents between the specified points

repeatedly (A-B repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

To play in random order (random play) . . . . . . . . . . . . . . . . . . 36

To start playback from the desired point (direct play) . . . . . . 36

To play in the desired order (programmed playback) . . . . . . . 37

" To play a video CD with P. B. C.

(playback control)

To scroll the menu screen (menu screen with more than 1

page):

Press the or button.

To stop playback:

Press the button.

To play without activating the playback control function:

You can play a video CD with P.B.C. without activating the playback

control function.

In this case, the menu screen will not appear, and the disc will play

in the same way as a video CD without P.B.C.

Note:

Some video CDs with P.B.C. cannot be played back when the P.B.C.

mode is off.

Load a video CD with P.B.C.

The menu will appear on the

TV and playback will be

paused.

Example

Select the desired menu number by using the direct num-

ber buttons (1 - +10).

Example:

To select track 14, press "+10" and "4".

! Playback starts.

! After playback stops, the menu will reappear, then select the

menu number you want to play.

While in the stop mode, press the

MENU/OSD button to cancel the

P.B.C. mode.

Playback starts.

Each time you press the button, the setting switches on and off.

PBC offPlay

XL-DV60

Audio CD Operation

Playing an audio CD

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 - 24

To locate the beginning of a chapter/track (skip) . . . . . . . . . . 25

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . 25

To change the audio language (audio output) . . . . . . . . . . . . . 28

To change the display on TV screen . . . . . . . . . . . . . . . . . . . . 32

To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . 33

To play the contents between the specified points

repeatedly (A-B repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

" To play in random order (random play)

The tracks on the disc can be played in random order automatically.

To cancel random play:

Press the button.

Notes:

! On some discs, this function cannot be used.

! You cannot set the random play while in the playback or pause

mode.

! When operating video CD with the P.B.C. function, set the P.B.C.

to off (see page 35).

" To start playback from the desired point

(direct play)

To select and play the desired track:

Notes:

! Direct play feature is disabled on some discs.

! When operating video CD with the P.B.C. function, set the P.B.C.

to off (see page 35).

To play by specifying time (time search):

You can play tracks from the desired time point during playback.

Note:

Time search feature is disabled on some discs.

In the stop mode, press the RANDOM button.

TV screen Unit display

RandomPlay

While in the stop or playback mode, press the

direct number buttons to select the track num-

ber.

TV screen Unit display

If the track number is 2 digits or more, press "+ 10" and enter the

number.

Example:

To select track 14, press "+10" and "4".

To select track 24, press "+10", "+10" and "4".

While the disc is playing, press the DIRECT button.

Time

Specify the time with the direct number buttons.

! Enter minutes and seconds.

! To specify 1 hour 23 minutes and 40 seconds, enter "8340".

! If you enter the wrong number, start over from step 1.

Within 10 seconds, press the ENTER button.

Select: 14

3 1 / 19 MAX [04:56]

- -:- -

XL-DV60

Audio CD Operation

" To play in the desired order

(programmed playback)

You can play back the desired tracks in the sequence you want.

Maximum of 40 tracks can be programmed.

To change the programmed contents:

Note:

On some discs, programmed play does not work.

In the stop mode, press the MEMORY/SET button.

Information on all loaded discs is read, and then the program-

ming screen appears.

Press the cursor ( or ) button

to select "Add" and press the

ENTER button.

Press the cursor ( or ) button

to select a disc number and

press the ENTER button.

Press the cursor ( or ) button

to select a track number and

press the ENTER button.

Repeat steps 3 - 4 for other

tracks. Up to 40 tracks can be

programmed.

If you make a mistake, the pro-

grammed tracks can be cleared by

pressing the CLEAR button.

No. INDEX

Add

Insert

Modify

Delete

Clear All

Exit

PROGRAM LIST

DISC No.

No. INDEX

Disc-1

Disc-2

Disc-3

Disc-4

Disc-5

PROGRAM LIST

DISC No.

No. INDEX

Track1

Track2

Track3

Track4

Track5

Track6

1 Disc-2

PROGRAM LIST

DISC No.

No. INDEX

Disc-1

Disc-2

Disc-3

Disc-4

Disc-5

1 Disc-2 Track2

2 Disc-3 Track12

3 Disc-4 Track8

PROGRAM LIST

DISC No.

Press the cursor ( ) button to

finish programming.

Use the cursor ( or ) button to

select a track to start with, and

press the (play) button.

! Playback starts from the select-

ed track and ends after the last

track in the program.

! "MEMORY" lights up on the

main unit during programmed

play.

! Programmed tracks are stored until a disc is removed or you

turn the power off.

1 While stopped, press the MEMORY/SET button to show the pro-

gramming screen.

2 Use the cursor ( or ) button to select an item and then press the

cursor ( ) button.

3 Use the cursor ( or ) button to select the desired command and

then press the ENTER button.

"Add" Adds a track to the program.

"Insert" Inserts a track between programmed tracks. The

track is inserted above (before) the selected track.

"Modify" Modifies the track.

"Delete" Deletes the selected track.

"Clear All" Deletes the program.

"Exit" Turn off the programming screen.

No. INDEX

1 Disc-2 Track2

2 Disc-3 Track12

3 Disc-4 Track8

PROGRAM LIST

DISC No.

No. INDEX

1 Disc-2 Track2

2 Disc-3 Track12

3 Disc-4 Track8

PROGRAM LIST

DISC No.

XL-DV60

MP3 and JPEG Disc Operation

Playing an MP3 and JPEG disc

Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 - 24

To locate the beginning of a chapter/track (skip) . . . . . . . . . . 25

Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . 25

To change the audio language (audio output) . . . . . . . . . . . . . 28

To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . 33

To play in random order (random play) . . . . . . . . . . . . . . . . . . 36

To start playback from the desired point (direct play) . . . . . . 36

You can play CD-R/RW recorded in the MP3 and JPEG formats.

Selecting a folder/file on the menu screen:

In the stop mode, press the cursor ( or ) button to select a folder/

file and press the ENTER button.

Caution:

If you convert MP3 data to "audio CD" data when recording on a

CD-R/RW, play it as an audio CD. The MP3 operation cannot be

performed.

Note:

Up to 20 characters can be displayed for a folder name and a file

name. Underlines, asterisks, and spaces may not be displayed.

Load a disc containing MP3 and

JPEG files.

A menu screen appears and playback

starts automatically.

Example of playback sequence

! Playback is performed in the

order of 1 to 11 in this exam-

ple.

! Files on some discs cannot

be played in order.

When playing JPEG files

! Playback skips to the next file approx. every 5 seconds.

! To return to the menu screen, press the button.

1 1/19 00:00:00Stereo

ROOT

ALBUM01

ALBUM02

ALBUM03

ALBUM04

ALBUM05

ALBUM06

ALBUM07

Folder

MP3 File

JPEG File

Folder

ROOT

File

Playback

sequence

XL-DV60

MP3 and JPEG Disc Operation

" Zoom function

To return to normal view:

Press the ZOOM/AUDIO button again, "Zoom off" will show on the

screen.

" Rotating a picture

While playback, press the

ZOOM/AUDIO button.

Hold down the or button

for 2 seconds or more.

Use the or button to switch the zoom setting as follows:

To shift the view and display the desired part of a zoomed

image, press the cursor ( , , or ) button repeatedly.

Zoom on

Zoom 150 Pct

Zoom 025 Pct Zoom 050 Pct Zoom 100 Pct Zoom 150 Pct Zoom 200 Pct

Press the button.

After pressing the STILL/PAUSE button, press the cursor ( ,

, or ) button.

The image rotates as shown below.

button : 90º rotation in a clockwise direction.

button : 90º rotation in a counterclockwise direction.

button : Vertical mirror image.

button : Horizontal mirror image.

XL-DV60

Radio

Listening to the radio

" Tuning

Notes:

! When radio interference occurs, auto scan tuning may stop auto-

matically at that point.

! Auto scan tuning will skip weak signal stations.

! To stop the auto tuning, press the TUNING button again.

To receive an FM stereo transmission:

Press the TUNER (BAND) button to display the "ST" indicator.

! " " will appear when an FM broadcast is in stereo.

! If the FM reception is weak, press the TUNER (BAND) button to

extinguish the "ST" indicator. The reception changes to monau-

ral, and the sound becomes clearer.

Press the ON/STAND-BY button to turn the power on.

Press the TUNER (BAND) button repeatedly to select the

desired frequency band (FM or AM).

Press the TUNING ( or ) button to tune in to the desired

station.

Manual tuning:

Press the TUNING button as many times as required to tune in

to the desired station.

Auto tuning:

When the TUNING button is pressed for more than 0.5 sec-

onds, scanning will start automatically and the tuner will stop at

the first receivable broadcast station.

FM stereo mode indicator

FM stereo receiving indicator

XL-DV60

Radio

" Memorizing a station

You can store 40 AM and FM stations in memory and recall them at

the push of a button. (Preset tuning)

Note:

The backup function protects the memorized stations for a few hours

should there be a power failure or the AC power cord get discon-

nected.

" To recall a memorized station

" To scan the preset stations

The stations saved in memory can be scanned automatically. (Pre-

set memory scan)

" To erase entire preset memory

Perform steps 1 - 3 in "Tuning" on page 40.

Press the MEMORY/SET button to enter the preset tuning

saving mode.

Within 30 seconds, press the PRESET ( or ) button to

select the preset channel number.

Store the stations in memory, in order, starting with preset

channel 1.

Within 30 seconds, press the MEMORY/SET button to store

that station in memory.

If the "MEMORY" and preset number indicators go out before

the station is memorized, repeat the operation from step 2.

Repeat steps 1 - 4 to set other stations, or to change a pre-

set station.

When a new station is stored in memory, the station previously

memorized will be erased.

Press the PRESET ( or ) button for less than 0.5 seconds to se-

lect the desired station.

1 Press the PRESET ( or ) button for more than 0.5 seconds.

The preset number will flash and the programmed stations will be

tuned in sequentially, for 5 seconds each.

2 Press the PRESET ( or ) button again when the desired sta-

tion is located.

1 Press the ON/STAND-BY button to enter the stand-by mode.

2 While pressing down the TUNER(BAND) button and the 2 but-

ton, press the ON/STAND-BY button until "TUNER CL" appears.

XL-DV60

Advanced Features

Changing the initial setting of DVD

Note:

Settings are retained even if the unit is set to the stand-by mode.

After pressing the button, press the SET UP button.

Press the cursor ( or )

button to select the main

menu and press the ENTER

button.

Press the cursor ( or )

button to select the sub-

menu and press the ENTER

button.

To return to the previous dis-

play, press the cursor ( ) but-

ton, or press the SHIFT button

and then the RETURN button.

Submenu

Press the cursor ( or ) button to change the setting and

press the ENTER button.

! To return to the previous display, press the cursor ( ) button,

or press the SHIFT button and then the RETURN button.

! To change other settings, begin from step 2.

Press the SET UP button.

The new setting is memorized.

Audio Setup

Video Setup

Language

Setup

Display Setup

System Setup

Language Setup

OSD Language

Audio

Subtitle

Disc Menu

English

Enter

XL-DV60

Advanced Features

Setting Selectable parameters

(* indicates initial settings.)

Description Reference

page

Language Setup OSD Language English*

Français

Español

Selects the initial or playback setting language. P. 46

Audio English*

French

Select a language to play. P. 46

Subtitle English*

French

Selects the subtitle displayed on the TV screen. P. 46

Disc menu English*

French

Selects the disc menu language. P. 46

Audio Setup Digital output BitStream*

LPCM

Select a type of signal sent from the digital audio output jack. P. 51

LPCM output 48 kHz

96 kHz*

PCM sound signals recorded in 96 kHz are converted to 48

kHz.

Analog output Surround

2.1Ch*

Select a type of signal sent to the speaker.

Surround: 2 channel (video CD/audio CD) or 5.1 channel

(DVD) sound are converted to 2.1 channel

sound (virtual speaker surround sound).

2.1ch: 2 channel (video CD/audio CD) or 5.1 channel

(DVD) sound are converted to 2.1 channel

sound (with the subwoofer sound increased).

Compression On

Off*

Set to on to enjoy the realistic sound as recorded on the

disc.

On: Realistic sound is produced as recorded on

DVD/video CD/audio CD.

Off: The range of signal levels is reduced to moder-

ate sudden increase in playback volume.

XL-DV60

Advanced Features

Changing the initial setting of DVD (continued)

Setting Selectable parameters

(* indicates initial settings.)

Description Reference

page

Video Setup TV screen 4:3 PS*

4:3 LB

16:9

The screen mode should be set according to the connected

TV type.

P. 46

TV type NTSC*

Auto

Selects the correct color system (TV standard).

NTSC: Select this mode for the NTSC TV.

Auto: Select this mode for the multi-system TV.

Video output Interlace*

Progressive

The video output mode should be set according to the con-

nected TV type.

P. 17

Interlace: Select this for a non-progressive scan TV

(use a video cable, S-video cable, or compo-

nent video cable).

Progressive: Select this for a progressive scan TV (use a

component video cable).

Picture mode Auto

Film

Video

Smart*

For optimize the TV picture when DVD or video CD play-

back.

Auto: Images are automatically optimized accord-

ing to the video source.

Film: Suitable for progressive video output. Select

this setting for DVD movies, etc.

Video: Suitable for interlaced video output. Select

this setting for DVD karaoke, etc.

Smart: Optimize special effects for progressive vid-

eo output.

XL-DV60

Advanced Features

Setting Selectable parameters

(* indicates initial settings.)

Description Reference

page

Display Setup Angle mark On*

Off

Select whether to display " " (On) or not (Off). P. 29

Screensaver On

Off*

Select whether to use a screen saver (On) or not (Off).

On: Press the button. After 5 minutes or more of inactiv-

ity, a screen saver appears.

To turn off the screen saver on the screen, press any

button on the main unit or remote control.

Off: Cancel the screen saver setting.

Closed caption On

Off*

Select whether to display the closed caption (On) or not

(Off).

On: The closed caption data (subtitles) appear on the TV

screen automatically.

You can see the closed caption data when playing

DVD discs (with "CC" on the jacket) on this unit.

Off: Cancel the closed caption setting.

System Setup Rating Level 1G

3 PG

4 PG 13

6 PG-R*

7 NC-17

8 Adult

No Limit

Sets a restriction level for DVD viewing. P. 47

Please enter a 4-digit

password.

(Default setting: 6629)

Password ---------- Password setting. P. 47

Restore Info ---------- This resets all settings, except for "Rating Level" and "Pass-

word", to the factory defaults.

P. 47

XL-DV60

Advanced Features

Changing the initial setting of DVD (continued)

" Language " Video format

Note:

When playing the disc with a fixed video format, it will not change

even if the TV screen size is changed.

Indicator Setting

OSD Lan-

guage

A language for screen display can be set, such as for

initial settings or messages.

Audio A language for audio can be set.

You can specify a language for conversation and nar-

ration.

Subtitle A language for subtitle can be set.

The subtitles are displayed in a specified language.

Disc

A language for disc menus can be set.

Menu screens are displayed in a specified language.

English

French

Fermer

English

French

ank

English

French

Merci

Thank you

English

French

CAST

STAFF

ACTEURS

PERSONNEL

Indicator Setting

4:3 LB When playing a wide image

(16:9) disc, black bands are

inserted at the top and bot-

tom and you can enjoy full

wide images (16:9) on a 4:3

size TV.

A 4:3 disc is played in 4:3.

4:3 PS When playing a wide image

(16:9) disc, the left and right

sides of the image are cut

(pan scan) to display a natu-

ral-looking 4:3 size image.

A wide image disc without

pan scan is played back

in 4:3 letterbox.

A 4:3 disc is played in 4:3.

16:9 A wide image (16:9) is dis-

played when playing a wide

image (16:9) disc.

! When playing a 4:3 image disc, the image size de-

pends on the setting of the connected TV.

! If you play back a wide image (16:9) disc with the

unit connected to a 4:3 TV, images appear

stretched vertically.

XL-DV60

Advanced Features

" Rating level setting

Notes:

! To change the rating level, enter a 4-digit password. It is set to

6629 by default.

! While playing a disc with parental lock, the display may appear

requesting a password in order to watch some restricted scenes.

In such a case, enter the password to temporarily change the

parental level.

" To change the password

When you forget your password

Indicator Setting

1 G Only DVD software intended for children can be

played back.

3 PG

4 PG 13

6 PG-R

7 NC-17

Only DVD software intended for general use and

children can be played back.

8 Adult DVD software of any grade (adult/general/children)

can be played back.

No Limit Rating level control is canceled.

After pressing the button, press the SET UP button.

Press the cursor ( or ) button to select "System Setup"

and press the ENTER button.

Press the cursor ( or ) button to select "Password" and

press the ENTER button.

Enter a 4-digit old password with the direct number but-

tons on the remote control.

(Default setting: 6629)

Enter a 4-digit new password with the direct number but-

tons on the remote control.

Enter the new password again for confirmation.

Press the SET UP button.

1 After pressing the button, press the SET UP button.

2 Press the cursor ( or ) button to select "System Setup" and

press the ENTER button.

3 Press the cursor ( or ) button to select "Restore Info" and press

the ENTER button.

4 Enter 2486 with the direct buttons and then press the ENTER but-

ton.

When reset is done according to this method, all settings, includ-

ing the settings for password and rating level, will be reset to the

factory defaults.

XL-DV60

Advanced Features

Timer and sleep operation

Timer playback:

The unit turns on and plays the desired source (DVD, video CD,

audio CD, MP3 disc, tuner) at the preset time.

Sleep operation:

You can set the system to the power stand-by mode at the specified

time.

" Timer playback

Before setting timer:

1 Press the CLOCK button to check that the clock is set to the cor-

rect time. (Refer to page 21.)

2 Load the discs to be played.

Press the ON/STAND-BY button to turn the power on.

Press the DVD/CD or TUNER (BAND) button to select the

desired function.

When you select the TUNER (BAND), tune into the desired sta-

tion.

Adjust the volume using the VOLUME buttons.

Do not turn the volume up too high.

Press the TIMER/SLEEP button repeatedly until " " is dis-

played and then within 8 seconds, press the MEMORY/SET

button.

Within 30 seconds, press the PRESET ( or ) button to

specify the hour to start, then press the MEMORY/SET but-

ton.

XL-DV60

Advanced Features

To reset or change the timer setting:

Perform "Timer playback" from the beginning.

Within 30 seconds, press the PRESET ( or ) button to

specify the minute to start, then press the MEMORY/SET

button.

! Settings are displayed in order and the unit will enter the tim-

er stand-by mode.

! Timer set indicator will light up.

To cancel the timer playback:

Press the ON/STAND-BY button to turn the power on.

When the preset time is reached, playback will start.

The volume will increase gradually until it reaches the volume

you were listening to before your system entered the timer

stand-by mode.

The unit will enter the power stand-by mode one hour after

the timer playback starts.

Note:

When performing timer playback using an-

Sharp XL-DV60 DVD Micro System

Product's Documents

OPERATION MANUAL

Specifications

Sharp XL-DV60 Questions and Answers

Related Products

Sharp XL-E80 MICRO COMPONENT SYSTEM

Sharp XL-DK227N Micro Component System

Sharp DKKP80PH iPod Dock Slim Micro System

Sharp XL-HP707 CD AM/FM Stereo Micro Component System
