Express Compact - SV7130
2
3
EN
1. USING YOUR APPLIANCE ........................................................................ 6
1.1 Getting started...................................................................................6
1.2 Filling the water tank .......................................................................9
1.3 Transportation ................................................................................ 10
1.4 Settings .............................................................................................. 11
1.5 Vertical steaming ........................................................................... 12
1.6 Auto-off ............................................................................................. 13
2. MAINTENANCE AND STORAGE ......................................................... 14
2.1 Emptying the anti-calc collector .............................................. 14
2.2 Descaling your generator ...........................................................15
2.3 Cleaning ............................................................................................ 17
2.4 Storage ..............................................................................................18
3. SAFETY INSTRUCTIONS........................................................................ 19
4. TROUBLESHOOTING .............................................................................. 25
5. TEFAL INTERNATIONAL GUARANTEE ............................................. 27
Summary
4
* Depending on the model
x3
STEAMBOOST
5
x3
STEAMBOOST
www.Tefal.co.uk www.calor.fr
6
USING YOUR APPLIANCE
1.1 Getting started
• Plug in your steam
generator.
• Unlock your steam
generator.
Express Compact is
equipped with a lock
system to hold the iron
onto the base for easy
transport and storage.
• Completely unwind the
power cord and take the
water connection cord
out of its storage space.
• Remove the water tank
and fill with tap water
up to the max indication.
Put the water tank back
into the appliance by
pushing in until it locks
into place.
7
USING YOUR APPLIANCE
• Press the «ON-OFF»
button on control panel.
• The «ON-OFF» button
light remains flashing
while the appliance is
warming up.
OK
• To obtain steam, press
the steam trigger under
the iron handle. The
steam will stop when you
release the button.
• The appliance is ready
to use when the button
light stops flashing. The
mode ECO can still be
put even when the light
flashes.
ON
8
USING YOUR APPLIANCE
• To obtain even more
steam, press the steam
trigger under the handle
three times in quick
succession for automatic
sequential steam.
x3
STEAMBOOST
During ironing, do not
place the iron on the
flush accessory. It is
safe to leave the iron
on the soleplate or on
the base of the steam
generator or on the
heel.
OK
OK
OK
NO
9
1.2 Filling the
water tank
• Fill it with untreated tap
water without exceeding
the MAX level.
• Push it back into its
housing until you hear a
«click».
• Remove the removable
water tank using the
handle located at the
front of the steam
generator
• Switch off and unplug
the appliance.
USING YOUR APPLIANCE
10
1.3 Transportation
Your steam generator is
equiped with a lock system
to hold the iron onto the
base for easy transport
and storage.
To transport your steam
generator using the
handle of the iron:
- Put the iron on the
steam generator iron
rest and raise the lock
system over the iron
until it locks into place
(audible click).
- Hold the iron by the
handle to transport your
steam generator.
USING YOUR APPLIANCE
11
USING YOUR APPLIANCE
Changing modes
• Press the « ECO » button
located on the control
panel to go on the ECO
mode, and click again to
remove the ECO mode.
• When you click on ECO
mode the button light
will start flashing while
the steam generator
is adjusting the
temperature and steam
to this mode. The steam
generator is ready when
the light stops flashing.
1.4 Settings
12
1.5 Vertical
steaming
wool - laine
silk - soie
synth. - synth.
USING YOUR APPLIANCE
As steam is very hot:
never attempt to
remove creases from
a garment while it is
being worn, always
hang garments on a
coat hanger.
• Holding the iron in a
vertical position tilted
slightly forwards, press
on the steam control
button (underneath the
iron handle) moving the
iron from top to bottom.
• Hang the garment on a
coat hanger and hold the
fabric slightly taut with
one hand.
NO
13
1.6 Auto-off
• The steam generator is
fitted with an «AUTO-
OFF» monitoring
system, which is
activated automatically
after approximately 8
minutes without use. The
«ON-OFF» button flashes
to indicate that the
appliance is on standby.
• To reactivate the steam
generator, press the
«ON-OFF» button and
you will hear a beep.
• After approximately
38 minutes of non-use,
the «AUTO-OFF» system
switches off your steam
generator.
• To start your ironing
again, press the
«ON-OFF» button and
you will hear a beep.
8
min
ON
ON
OFF
USING YOUR APPLIANCE
38
min
14
2.1 Emptying the
anti-calc collector
OFF
1H
2
1
MAINTENANCE AND STORAGE
• Switch off and unplug
the appliance.
• For long lasting steam
performance, it is
important to empty the
anti-calc collector when
necessary.
• Fully unlock the collector
and pull it out of the base
unit.
Appliance has to be
unplugged for at least
1h and be completely
cool before continuing.
Do not use your steam
generator without
reinserting the anti-
calc collector.
2
1
15
• Move the appliance over
a sink and fill the water
tank.
• Detach the removable
stand from the base of
the appliance.
• Set down the stand near
the sink and place the
iron on top.
• Put back the water tank
in the base.
• Plug in the appliance and
switch it on by pressing
the «On» button.
MAINTENANCE AND STORAGE
OFF
ON
2.2 Descaling your
generator
• The flashing «Anti calc»
indicator light indicates
that descaling is
necessary.
• Switch off the appliance
by pressing the «Off»
button, then unplug the
appliance.
16
• An audio signal (long
beep) sounds at the
end of the descaling
procedure.
• The appliance will shut
down automatically. You
must then unplug the
appliance.
• Unlock and remove the
anti-calc collector in the
back of the iron to rinse
it.
• Next, reposition the
collector, as well as the
removable stand.
• Please be careful to
empty the water tank
before storing back the
removable stand.
• Press and hold the
blinking «Anti calc»
button for 3 seconds.
• The descaling operation is
performed, during which
the iron emits water and
steam for 2 minutes. Be
aware of the heat of the
iron during the descaling
cycle.
MAINTENANCE AND STORAGE
3
sec
2 MIN
OFF
beep
17
MAINTENANCE AND STORAGE
NO
NO
2.3 Cleaning
Appliance has to be
unplugged for at
least 2 hours and be
completely cool before
continuing.
Do not use detergent or
descaling products for
cleaning the soleplate.
Never hold the iron or
the base unit under the
tap.
• Clean soleplate with a
soft damp cloth.
• Clean the plastic
parts of the appliance
occasionally with a soft
cloth.
2H
18
2.4 Storage
• Switch off and unplug
the appliance.
• Store the power cord in
its slide storage place.
• Store the water connection
cord in its slide storage
place without stretching it
too much.
• Store the flush accessory
in its holder placed
underneath the
appliance.
• Leave the steam
generator to cool
(around 1h) then empty
the water tank before
putting it away if you are
storing it in a cupboard
or a confined space.
OFF
MAINTENANCE AND STORAGE
If you store your
steam generator
in a relatively cold
place (approximately
<10 °C), put it in a warm
place before starting
your ironing.
1H
19
SAFETY INSTRUCTIONS
• Please read these instructions carefully before first use.
This product has been designed for domestic indoor use
only. Any commercial use, inappropriate use or failure
to comply with the instructions, the manufacturer
accepts no responsibility and the guarantee will not
apply.
• Never unplug the appliance by pulling the power cord.
Always unplug your appliance:
– before filling the water tank.
– before cleaning the appliance,
– after each use.
• The appliance will not work without the anti-calc
collector (depending on model).
• The appliance must be used and placed on a flat, stable,
heat and water resistant surface. When you place the
iron on the iron rest, make sure that the surface on
which you place it is stable.
• This appliance is not intended to be used by persons
(including children) with reduced or impaired physical,
sensory or mental capabilities or persons lacking
appropriate knowledge or experience, unless a person
responsible for their safety provides either supervision
or appropriate instructions concerning use of the
appliance prior to its use.
• Children should be supervised to ensure they do not
play with the appliance.
Important recommendations
20
• This appliance may be used by children aged 8 or
over and persons lacking appropriate knowledge
or experience or persons with reduced or impaired
physical, sensory or mental capabilities provided that
they have been thoroughly instructed regarding the
use of the appliance, are supervised, and understand
the risks involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be
made by children without supervision. Keep the iron
and its cord out of reach of children less than 8 years of
age when it is plugged in or cooling down.
• The surfaces of your appliance marked by this
symbol can reach very high temperatures when
functioning, which may cause burns. Do not
touch these surfaces before the appliance has
completely cooled down.
• Never leave the appliance unattended when it is
connected to the mains. Before storing the appliance,
once it is unplugged, please wait until it has cooled
down (around 1 hour).
• Never fill your appliance directly from the tap.
• The anti-calc collector must not be opened during use.
• The appliance must not be used if it has been dropped,
if it has any visible damage, if it leaks, or if it functions
abnormally in any way. Do not attempt to dismantle
your appliance: have it examined at an Approved
Service Centre to avoid any danger.
• Check the electrical power and water connection cord
for signs of wear or damage prior to use. If the electrical
power cord or the water connection cord is damaged,
21
it must be replaced by an Approved Service Centre to
avoid any danger.
• All accessories, consumable goods and spare parts
must be purchased exclusively from an Authorised
Service Centre.
• For your safety, this device complies with applicable
standards and regulations (Low Voltage Directives,
Electromagnetic Compatibility, Environment, etc.)
• Your appliance is an electrical appliance: it must be
used under normal conditions of use.
• It is equipped with a thermal fuse to avoid overheating.
• Always plug your steam generator:
– Into an electrical system whose voltage is between
220 and 240 V.
– Into an earthed electrical outlet.
Any connection error may cause irreversible damage
and invalidates the guarantee. Do not use an extension
lead. If you accept liability for doing so, only use an
extension lead which is in good condition, has a plug
with an earth connection and is suited to the power
rating of the appliance.
Always ensure that the base unit is positioned close
enough to the ironing surface to avoid straining and
wear of the steam cord.
• Fully unroll the electrical cord prior to plugging it into
an earthed electrical outlet.
• Do not leave the power or water connection cord close
to or in contact with sources of heat or sharp edges.
• The sole plate of your iron and the iron rest on the
base unit can reach extremely high temperatures, and
22
can cause burns: do not touch them. Never touch the
electrical power cords with the sole plate of the iron.
• Always use a vented/mesh ironing board to prevent
water spots on clothes and to avoid hot steam venting
sideways. Be careful of hot steam when ironing close to
the edges of the board.
• Your appliance produces steam which may cause burns.
– Handle the iron carefully, especially when ironing
vertically.
– Never iron a piece of clothing while it is worn by a
person, but always when it is on a hanger.
– Never iron while in a sitting position with one’s legs
under the ironing board.
– Never point the steam at people or animals.
• Never immerse your appliance in water or any other
liquid. Never place it under a running tap
• During first use, your appliance may give off
smoke, an odour or a discharge of particles, but
this is normal and will disappear quickly.
• If you use the appliance for the first time, if you have
replaced the anti calc cartridge or after filling the water
tank, press the steam control button continuously for
few minutes pointing it away from your linen, in order
to prime the pump and obtain steam.
• When in use, your electric pump injects water into the
iron solepate. It makes a noise but this is normal.
• Safety Instructions for the anti-calc collector (Depending
on Model):
23
– Not for
drinking
– Prior to rinsing the anti-calc
collector (depending on the
model), ensure that the appliance
is unplugged and completely
cool to unscrew the anti-
calc collector. To perform this
operation, the appliance must
be near a sink, since some water
may flow out when opening it.
– Never operate the appliance
without the anti-calc collector.
– Never fill the iron using the anti-
calc collector's opening.
– Keep out of
the reach of
children
– Dispose with
household
refuse
– Keep in cool
dry place
Preparation
What water may be used ?
This appliance has been designed to be used with
untreated tap water.
Heat concentrates the elements contained in water
during evaporation. The types of water listed below may
contain organic waste, mineral or chemical elements
that can cause spitting, brown staining or premature
wear of the appliance: water from clothes dryers, scented
or softened water, water from refrigerators, batteries,
air conditioners, rain water, boiled, filtered or bottled
water. These types of water should not be used in your
appliance.
Do not fill the water tank from the anti-calc collector
opening.
24
Semi-automatic self-cleaning procedure*
Never start the self-cleaning procedure when the
appliance is on its base.
Always place the iron on its cleaning stand, over a sink
drain.
Ensure that the anti-calc collector* is installed in the iron
and properly locked, prior to starting self-cleaning.
Never touch the iron or its cleaning stand during self-
cleaning. The cleaning accessory may still be hot; wait at
least 15 minutes before handling it.
The cleaning stand is only intended for self-cleaning.
Never use this accessory as an iron holder during normal
use.
*depending on the model
PLEASE RETAIN THIS INSTRUCTION
BOOKLET FOR FUTURE REFERENCE
Environment protection first !
Your appliance contains valuable materials which can be
recovered or recycled.
Leave it at a civic waste disposal centre.
25
TROUBLESHOOTING
Problem Possible Causes Solutions
Emission of
water and
steam during
the cleaning
procedure.
Normal cycle of
self cleaning of the
soleplate.
Please let the cleaning cycle
finish until you hear the
final long beep.
Your iron is
producing
little or no
steam.
You have just filled
the tank. You have
just started using it.
Press the steam control
button continuously for few
minutes pointing it away
from your linen, in order to
prime the pump.
The water tank is
empty.
Fill the tank.
Water runs
out of the
holes of the
soleplate.
You are using steam
for the first time or
you have not used
it for some time.
Press on the steam control
button away from your
ironing board until the iron
produces steam.
Water streaks
appear on
the linen.
Your ironing board
is saturated with
water because it is
not suitable for use
with an appliance.
Check that your ironing
board is suitable. We
recommend that you use a
vented/mesh type ironing
board.
26
Problem Possible Causes Solutions
Brown streaks
come through
the holes in
the soleplate
and stain the
linen.
You are using
chemical descaling
agents or additives
in the water ironing.
Never add this type of
product in the water tank
(see "What water may
be used?"). Contact an
Approved Service Centre.
Your linen is not
rinsed sufficiently
or you have ironed
a new garment
before washing it.
Ensure linen is rinsed
thoroughly to remove any
soap deposits or chemicals
on new garments which
may be sucked up by the
iron.
The soleplate
is dirty or
brown and
may stain the
linen.
You are using
starch.
You are ironing
at too high a
temperature.
Always spray starch on the
reverse side of the fabric to
be ironed.
Clean the soleplate as
indicated in the user
manual. Use a lower
temperature.
The soleplate
is scratched
or damaged.
You have
positioned your
iron flat on a
metallic iron
support or ironed
over zips or metal
fasteners.
Always stand the iron
upright or on the iron rest.
* Depending on the model
If you have any problems or queries please call our Customer Relations
team first for expert help and advice.
TEFAL INTERNATIONAL GUARANTEE
Date of purchase
......................................................................................................................................
Retailer name and address
......................................................................................................................................
Product reference
......................................................................................................................................
......................................................................................................................................
......................................................................................................................................
Distributor stamp
TEFAL/T-FAL* INTERNATIONAL LIMITED GUARANTEE
: www.tefal.com
This product is repairable by TEFAL/T-FAL*, during and after the guarantee period.
Accessories, consumables and end-user replaceable parts can be purchased, if locally available, as described on the
TEFAL/T-FAL internet site www.tefal.com
The Guarantee** : TEFAL/T-FAL guarantees this product against any manufacturing defect in materials or
workmanship during the guarantee period within those countries*** as stated in the attached country list, starting
from the initial date of purchase or delivery date. The international manufacturer’s guarantee covers all costs related
to restoring the proven defective product so that it conforms to its original specifications, through the repair or
replacement of any defective part and the necessary labour. At TEFAL/T-FAL’s choice, an equivalent or superior
replacement product may be provided instead of repairing a defective product. TEFAL/T-FAL’s sole obligation and your
exclusive resolution under this guarantee are limited to such repair or replacement.
Conditions & Exclusions : TEFAL/T-FAL shall not be obliged to repair or replace any product which is not accompanied
by a valid proof of purchase. The product can be taken directly in person or must be adequately packaged and
returned, by recorded delivery (or equivalent method of postage), to a TEFAL/T-FAL authorised service centre. Full
address details for each country’s authorised service centres are listed on TEFAL/T-FAL website (www.tefal.com) or by
calling the appropriate consumer Service centre set out in the attached country list. In order to offer the best possible
after-sales service and constantly improve customer satisfaction, TEFAL/T-FAL may send a satisfaction survey to all
customers who have had their product repaired or exchanged in a TEFAL/T-FAL authorised service centre.
This guarantee applies only for products purchased and used for domestic purposes and will not cover any damage
which occurs as a result of misuse, negligence, failure to follow TEFAL/T-FAL instructions, or a modification or
unauthorised repair of the product, faulty packaging by the owner or mishandling by any carrier. It also does not cover
normal wear and tear, maintenance or replacement of consumable parts, or the following:
- using the wrong type of water or consumable - mechanical damages, overloading
- ingress of water, dust or insects into the product (excluding appliances with features specifically designed for insects)
- damage as a result of lightning or power surges - scaling (any de-scaling must be carried out according to the
instructions for use)
- accidents including fire, flood, etc - damage to any glass or porcelain ware in the product
- professional or commercial use - damages or poor results specifically due to wrong voltage or frequency as stamped
on the product ID or specification
Consumer Statutory Rights : This international TEFAL/T-FAL guarantee does not affect the Statutory Rights a
consumer may have or those rights that cannot be excluded or limited, nor rights against the retailer from which the
consumer purchased the product. This guarantee gives a consumer specific legal rights, and the consumer may also
have other legal rights which vary from State to State or Country to Country. The consumer may assert any such rights
at his sole discretion.
***Where a product purchased in a listed country and then used in another listed country, the international TEFAL/T-
FAL guarantee duration is the period for the country of usage, even if the product was purchased in a listed country
with a longer guarantee duration. The repair process may require a longer time if the product is not locally sold by
TEFAL/T-FAL in the country of usage.
If the product is not repairable in the new country of usage, the international TEFAL/T-FAL guarantee is limited to a
replacement by a similar or alternative product at similar cost, where possible.
*TEFAL household appliances appear under the T-FAL brand in some territories like America and Japan. TEFAL/T-FAL
are registered trademarks of Groupe SEB.
Please keep this document for your reference should you wish to make a claim under the guarantee.
**For Australia only:
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
**For India only: Your Tefal product is guaranteed for 2 years. The guarantee covers exclusively the repair of a
defective product, but at TEFAL’s choice, a replacement product may be provided instead of repairing a defective
product. It is mandatory that the consumer, to have his product repaired, has to log a service request on the dedicated
Smartphone application TEFAL SERVICE APP or by calling TEFAL Consumer Care Center at 1860-200-1232, Opening
hours Mon-Sat 09 AM to 06 PM. Products returned by Post will not be covered by the guarantee. As a proof of
purchase consumer needs to provide both this stamped guarantee card and cash memo.
1820001969 - 14/19
