Dji OSMO+ Handheld Gimbal with 4K Zoom Camera User Manual

2017.04

V1.0

User Manual

Using this Manual

Legend

Important Tips

Install the DJI GO App

Search for ‘DJI GO’ on the App Store or Google Play and install

the app on your mobile device.

DJI GO supports iOS 8.0 (or later) or Android 4.3 (or later).

Searching for Keywords

Search for keywords such as “battery” and “install” to nd a topic. If you are using Adobe

Acrobat Reader to read this document, press Ctrl+F on Windows or Command+F on Mac to

begin a search.

Navigating to a Topic

View a complete list of topics in the table of contents. Click on a topic to navigate to that

section.

Printing this Document

This document supports high resolution printing.

Contents

Using this Manual

 Legend

 InstalltheDJIGOApp

Introduction

Getting Started

 IntelligentBattery

 MountingyourMobileDevice

 RemovingtheMobileDeviceHolder

 OptionalAccessories

 UnlockingtheGimbal

 LockingtheGimbal

Using the Osmo+

 ControlsandOperations

 OperationModes

DJI GO App

 Download

 ConnectingtotheDJIGOApp

 KeyPages

Upgrading the Firmware

 UsingtheDJIGOApp

 UsingaMicroSDCard

Maintenance

Specifications

Troubleshooting

Introduction

The OSMO

+ is a professional handheld gimbal camera that combines mobility and stability

in one device. Its camera features an optical zoom lens providing 3.5x optical zoom and 2x

lossless digital zoom*. It shoots sharp 12MP still photos and stable video at up to 4K. A light

and ergonomic design places buttons at your fingertips, forming a powerful and personal

one-handed filmmaking device. The DJI GO app complements the Osmo+ with shooting

modes such as motion timelapse and 9-shot panorama.

Equipped with 3-axis stabilization and SmoothTrack technology, the Osmo+ compensates for

natural arm movements and smooths out transitions. Finer operations can be done with the

joystick, while instant positioning of the camera can be made directly with your other hand.

The camera tilts across a 170-degree range and has a pan rotation of 640 degrees. The DJI

Rosette Mount on the side of the handle allows your mobile device to be mounted as a live

HD view nder, and supports external devices including vehicle mounts and tripods for spe-

cialized lmmaking applications.

At a Glance:

17 Built-in Microphone

18 External Microphone Input

19 Trigger

20 DJI Rosette Mount

21 Lanyard Hole

22 Battery Cover

23 Flexi Microphone

1 Camera

2 Roll Motor

3 Pan Axis Lock

4 Camera Status LED

5 Joystick

6 Shutter Button

7 Mobile Device Holder

8 Record Button

9 Power Switch

10 System Status LED

11 Gimbal Securing Ring

12 Pan Motor

13 Camera Micro USB Port

14 Micro SD Card Slot

15 Tilt Motor

16 Air Vents

*Digitallosslesszoomonlyavailablewhenshootingat1080p.

Getting Started

Intelligent Battery

The 1225 mAh Intelligent Battery can power the Osmo+ for about 114 minutes.

Charging the Battery

Connect the battery charger to a power outlet using the provided cable.

Place the battery into the battery charger. It will take approximately 110 minutes for the

battery to be fully charged, refer to the "Status LED Indicator Descriptions" section below for

more information about the Status LED Indicator's blinking patterns.

Status LED Indicator Descriptions

—

Solid Yellow No battery detected

......

Blinking Green

(within a

certain time)

Blinks once < 25%

Blinks twice 25% to 49%

Blinks three times 50% to 74%

Blinks four times 75% to 99%

—

Solid Green Fully charged

—

Solid Red Charger error, check the connection to the Battery Charger

Intelligent Battery Functions

Battery Balancing Balances the voltage of each cell during charging.

Overcurrent Protection Stops charging if the charging current is too large.

Overcharge Protection Stops charging if its voltage is too high.

Over-discharge Protection Stops discharging if its voltage is too low.

Short Circuit Protection Cuts the power supply if a short circuit is detected.

Temperature Control

Stops charging if the core temperature falls below 41°F (5°C)

or exceeds 104°F (40°C).

Battery Level Display The battery level is displayed in the DJI GO app.

OSMO+ User Manual

Inserting the Battery

Slide the locking switch at the base of the Osmo+ to open the

battery cover. Insert the battery and lock the battery cover.

Battery Charger Specications

Model OS1C11

Input 100-240 V

50/60 Hz

Output 12.6 V

/13.2 V; 0.8 A

Only charge the battery with the provided battery charger. DJI takes no responsibility

for accidents caused by the use of non-DJI battery chargers.

Remove the battery from the charger unless it is charging to prevent battery discharging.

Removing the Battery

Slide the locking switch at the base of the Osmo+ to open the battery cover. Push the red

safety hook away from the battery to let it pop up, and then remove the battery.

Be sure to fully charge the Intelligent Battery for the rst time to activate it.

Read the user manual, Intelligent Battery Safety Guidelines before use. The user

takes full responsibility for all operations and usage.

Battery Specications

Model HB02-542465

Type LiPo

Capacity 1225 mAh

Energy 14.1 Wh

Voltage 11.1 V

Charging Temperature 41° to 104° F (5° to 40° C)

Operating Temperature 32° to 104° F (0° to 40° C)

OSMO+ User Manual

Mounting your Mobile Device

1. Unfold the two arms on the mobile device holder.

2. Adjust the pads to the desired position.

3. Place one end of your mobile device into the arms.

4. Extend the arms so that your entire mobile device is seated in the mobile device holder.

5. Rotate your mobile device to the desired position.

OSMO+ User Manual

Removing the Mobile Device Holder

1. The mobile device holder can be removed by rotating the knob counterclockwise.

2. It is recommended to install the cap for the DJI Rosette Mount when it is not in use.

Optional Accessories

DJI provides various optional accessories for the Osmo+.

Z-Axis

The Osmo Z-Axis can signicantly reduce vertical shaking

from natural arm movements when walking and jogging.

Universal Mount

Used to mount external devices such as a microphone or

ashlight.

Extension Rod

Good for taking group seles, overhead shots or reaching

into small spaces.

Tripod

For stationary shots that require steady footage. It must

be used with the Extension Rod.

Bike Mount

Used to mount the Osmo+ on a bicycle.

OSMO+ User Manual

Visit the ofcial DJI Store (http://store.dji.com) to learn more.

Vehicle Mount

Triple suction cup mount makes it ideal for mounting on

top of or on the rear window of moving vehicles.

Straight Extension Arm

Used to attach up to three other mounts at the same time.

Unlocking the Gimbal

To protect the gimbal, the motor axes are locked in place. To unlock the gimbal:

1. Gently rotate the roll motor until it can rotate freely.

Rotate the motor just enough to allow free motion.

2. Slide the Pan Axis Lock upwards to unlock the pan axis.

Pan Axis Lock

OSMO+ User Manual

You can choose to unlock the gimbal before or after the Osmo+ is turned on. It is

recommended to unlock the gimbal before powering on the Osmo+.

The Osmo+ will beep slowly if the gimbal is locked after it is turned on. This means

the camera is working normally but the gimbal is shut off.

If you need to unlock the gimbal after it is turned on, you must rotate the pan motor

to reactivate the gimbal.

Using the Osmo+

Controls and Operations

The gimbal anticipates handle movement to smooth out pan and tilt transitions, and uses

SmoothTrack technology to reduce camera shakes from natural arm movements.

The camera can be position directly by hand.

Locking the Gimbal

Pull the pan axis lock down and rotate the pan axis to the locked position (until it cannot

rotate any further), and then adjust the roll motor in order to lock it in place.

Do not lock the gimbal during recording, otherwise the recording will stop.

Hold the Osmo+ steady and upright while it is starting up.

PowerSwitch

[1] Power Switch

To turn on the Osmo+, pull the power switch down and then release it.

Pulling the power switch again will cause the Osmo+ to go in or out of sleep mode.

To turn off the Osmo+, pull the power switch down and hold for 1.5 seconds.

Additionally, there are buttons on the front and back of the handle that allow for ner control

over the gimbal and camera. All of the buttons and controls are described below.

OSMO+ User Manual

RecordButton

ShutterButton

[2] Joystick

Vertical movement tilts the camera. Horizontal movement pans the camera. Joystick

Control Direction can be changed in the DJI GO app.

[3] Shutter Button

Press this button to take photos based on your settings in the DJI GO app. Hold down

shutter button to capture continuous photo.

[4] Record Button

Press this button once to start recording video, and again to stop recording.

[5] Camera Status Indicator

Indicates the camera’s system status. Refer to the table below for details.

Blinking Pattern Description

LED Off Camera is functioning normally.

Blinks Green Shooting photo.

Blinks Green slowly Self-timer.

Blinks Green for each shot Burst shooting.

—

Solid Green Firmware upgrade successful.

Blinks Red slowly

Recording video.

/ Blinks Red and Green alternately Upgrading rmware.

—

Solid Red

Camera is not mounted on the Osmo+ properly /

Firmware upgrade failed or system error.

×2 Blinks Red twice Camera error.

Blinks Yellow Micro SD card busy.

—

Solid Yellow Micro SD card error.

CameraStatusIndicator

Joystick

OSMO+ User Manual

[6] System Status Indicator

Indicates the status of the Osmo+. Refer to the table below for details.

SystemStatusIndicator

System Status Indicator Description

Blinks Green quickly The Osmo+ is initializing / Exiting sleep mode.

Blinks Red slowly Low battery level warning.

Blinks Red quickly Critical low battery level warning.

—

Solid Yellow

The trigger is tapped and the gimbal is in lock

mode.

—

Solid Red Non-DJI battery detected.

Breathing Green (high battery level)

Breathing Red (low battery level)

The Osmo+ is in

sleep mode

[7] Trigger

Hold down the trigger and push the joystick up and down to

zoom.

Hold down the Trigger to enable Lock Mode. The camera will

stay in its current position regardless of handle movement.

The Osmo+ will return to SmoothTrack Mode once the

Trigger is released.

Quickly tap the Trigger twice to center the camera.

When the Osmo+ is in Upright Mode and Underslung Mode,

quickly tapping the Trigger three times will enter Sele

Mode.

[8] External Microphone Input

Connect the provided Flexi Microphone to record audio.

[9] Built-in Microphone

Records audio for general use. You can turn off the

microphone in the DJI GO app.

External

MicrophoneInput

Built-in

Microphone

Trigger

OSMO+ User Manual

The external microphone will override audio reception of the built-in microphone.

[10] Key Combination

Restore Default Wi-Fi Settings:

Hold down the Trigger and Shutter Button at the same

time. Then, pull the power switch down until the System Status Indicator blinks green.

Release the power button before releasing the Trigger. The default SSID, password and

frequency for the Wi-Fi connection will be restored.

Turn on/off the Osmo+'s Wi-Fi:

Press and hold the trigger, then pull down the power

switch, then release both power switch and trigger. Wi-Fi is off when the system status

LED blinks twice. Repeat to turn on Wi-Fi.

Operation Modes

Upright Mode

Upright Mode can be used without any user input. In this mode, quickly tap the trigger twice

to center the camera.

OSMO+ User Manual

Underslung Mode

Holding the Osmo+ upside down will cause it to enter Underslung Mode, in which the camera

can easily capture images from a lower position. Quickly tapping the trigger twice will center

the camera.

Flashlight Mode

Rotate the Osmo+ forward 90 degrees to go from Upright Mode to Flashlight Mode. In

Flashlight Mode, pushing the joystick up and down will tilt the camera, pushing the joystick

left and right will have no effect.

OSMO+ User Manual

Portrait Mode

Rotate the Osmo+ 90 degrees to the left or right to go from Upright Mode to Portrait Mode.

DJI GO App

Watch a live HD video feed on your mobile screen through the DJI GO app. The Osmo+ is

complemented by the DJI GO app, which provides shooting modes such as motion timelapse

and 9-shot panorama.

The app also allows you to congure camera and gimbal settings in just a few taps.

Download

Search ‘DJI GO’ on the App Store or Google Play and download the app to your mobile device.

Connecting to the DJI GO App

1. Turn on the Osmo+. Hold the handle still and avoid touching the gimbal while the Osmo+

starts up.

OSMO+ User Manual

3. If you are using the Osmo+ for the rst time, follow the on-screen instructions to activate it.

You will need to log in to your DJI account through an Internet connection. Re-connect to

the Osmo+ Wi-Fi network after the activation is complete.

4. Enter Camera View. You will see what the camera captures in real time if it is connected

successfully.

2. On your mobile device, connect to the ‘OSMO_XXXXXX’ Wi-Fi network and enter the

default password 12341234. Then launch the DJI GO app.

Key Pages

1. Equipment

Camera

Wi-Fi

Settings

Wi-Fi

CHOOSE A NETWORK...

OSMO_XXXXXX

Other...

Ask to Join Networks...

Known networks will be joined automatically. If no

known networks are available, you will have to manually

select a network.

EnableWi-Fi

There will be a tutorial on how to use your Osmo+ after entering the camera view.

00 | 01

ISO:100 1/25

2.8

EV:

0 JPEG 453 89%

SAFE TO FLY GPS

61%

P-GPS

15:43

22:02

LOG

1080P

ISO

1600

2.8

2.0

1/50

[13]

[12]

[11]

[10]

[7]

[6]

[5]

[4]

[3]

[1][2]

[9][8]

OSMO+ User Manual

[1]

ISO:100 1/25

2.8

EV:

0 JPEG 453 89%

Information Bar

Displays the camera parameters, current battery level, and Wi-Fi signal strength.

[2] / :

Auto Focus / Metering Mode

Tap to switch between Auto Focus and Metering Mode.

[3]

Photo/Video Toggle

Slide to switch between photo and video mode.

[4]

Photo/Video Settings

Photo Modes

Single Shot

Normal, 5s or 10s delayed shot, HDR.

Multiple Shots

Burst shooting 3/5/7 frames, Auto Exposure Bracketing (AEB) 3/5 bracketed frames at

0.7EV Bias.

Panorama

Forward: The camera will rotate 180 degrees and render a panorama.

Auto: The camera will rotate 360 degrees and render a panorama.

Sele: The camera will point at you, pan 180 degrees and render a panorama.

Manual: The camera will pan a specied degree each time you tap the shutter button.

Up to 8 photos can be taken in manual mode to create a panorama. Always keep

objects in the right side of the shear.

9-Shot Panorama (Matrix): The camera will pan and tilt to capture a 9-shot grid, creating

a large multi-image photo.

Interval Timer

5s, 10s or 30s intervals.

Timelapse

There are Regular and Motion Timelapse Mode. In Motion Timelapse Mode, use up to 5

camera positions to create a moving timelapse.

1) Choosing to store timelapse in ‘JPEG

Video’ format limits the minimum interval to 2

seconds. Disabling this option reduces the minimum interval to 1 second.

2) If the timelapse interval is 2 seconds or more, the camera will apply digital stabilization

to the live HD video on your mobile device.

Video Modes

Auto: Normal video based on your camera settings.

Slow Motion: Recorded at 1080p and 100fps.

OSMO+ User Manual

[5] :

Shutter/Record Button

Shoots photos in photo mode and records video in video mode.

[6] :

Camera Parameters

Choose the shooting mode, ISO, shutter speed and exposure value.

[7] :

Playback

Tap to view photos and videos on the Micro SD card.

[8] :

Zoom Button

Tap T to zoom in and W to zoom out.

[9]

00:00:00 | 01:25:45

Recording Status Bar

Displays the current recording time, remaining recording time and microphone volume.

[10] :

Settings

Camera Settings

Here you can select the output formats for photos, video recording, and enable on-

screen displays such as histogram. Some of these options are explained below.

• Video Caption

If you enable this option, a .srt le containing on-screen information will be created with

the video le.

• Timelapse Format

Choosing ‘JPEG+Video’ will save the timelapse photos as well as the video.

• Anti-Flicker

Select the frequency that matches the current cycle in your country to prevent the

ickering of lights.

• File Index Mode

If you select ‘Reset’, the camera will write the photo and video les starting from the

smallest available index. If you select ‘Continuous’, the camera will continue the index

from the last written le.

Gimbal Settings

• Proles

Select the ‘Fast’, ‘Medium’ or ‘Slow’ profile depending on how responsive you want

the gimbal to be. Alternatively, create a custom profile by selecting C1 or C2 and

conguring the settings below.

• SmoothTrack Settings

The pan and tilt axes can be adjusted separately.

Speed: Determines how fast the gimbal will catch up with the translated pan/tilt handle

movement.

OSMO+ User Manual

Deadband: A larger deadband requires more pan/tilt handle movement to translate into

gimbal motion.

Acceleration: Determines how closely the camera will follow the translated pan/tilt

handle movement.

• Joystick Settings

Smoothing: Controls the deceleration of the gimbal. A small value will cause the gimbal

to stop abruptly.

Speed: Controls the movement speed of the tilt and pan axes when controlled by the

joystick.

Control Direction: The Osmo+'s tilt and pan axis can be controlled simultaneously by

setting joystick control direction to Free.

Invert Joystick Left/Right Operation: Inverts left and right joystick directions, so that

pushing right turns the camera left andvice versa.

Invert Joystick Up/Down Operation: Invert up and down joystick directions, so that

pushing the joystick up tilts the camera down.

• Horizontal Calibration

You may have to calibrate the roll axis if the camera’s horizon level is not perfectly level

by setting a positive or negative value.

• Auto Calibration

Reduces the drift caused by magnetic interference in the surroundings or human error.

Hold the Osmo+ still and upright during the calibration.

• Reset Gimbal

Tap to reset the gimbal to the default settings.

General Settings

Here you can change the Wi-Fi password, clear the video cache.

Livestream

Livestream to YouTube Live.

[11] :

Gimbal Functions

Scene Mode: SmoothTrack speed varies depending on the Scene Mode. In Sport Mode,

it moves faster, while in Walk Mode it is slower.

When using the Osmo's Wear Mode with the Osmo+, vertical movements created by

wearing the Osmo are minimized.

Tap to recenter the camera.

Tap enable Lock Mode.

Tap

to enter Sele Mode.

Tilt Axis Lock: Locks the tilt axis at the current angle when enabled.

Zoom Adjusted SmoothTrack: After enabling this function, SmoothTrack speed will auto

OSMO+ User Manual

2. Editor

View, edit and share your masterpieces all in one place. The Editor has a range of simple

but powerful tools that let you edit your videos and photos before sharing them online,

minutes after they are captured.

Once you login or register your DJI account, you will be able to conveniently upload

and share your creations. The saved photos and videos can be uploaded to Skypixel

(www.skypixel.com) and shared on social networks such as Facebook, Twitter, WeChat,

Moments and Sina Weibo.

Video

All of your recorded video footage will appear in ‘Original Footage’. You can trim footage

and save it to ‘Create Movie’. Then, select multiple clips to create a movie quickly with the

built-in editing tools and templates.

Photos

Edit your photos by adjusting the parameters, editing the photo size, adding watermarks

and applying lters.

3. Skypixel

View and share photos and videos to the Skypixel network.

4. Me

If you already have a DJI account, you will be able to participate in forum discussions.

adjust according to the level of zoom.

Focus when Gimbal stops: Enable this function to allow auto focus after the gimbal has

stopped moving.

Set Gimbal Attitude: Set gimbal tilt and pan angle manually.

[12] : Camera Quick Settings

A shortcut for changing the video resolution, photo format and photo color; select a

predefined or custom white balance; choose style settings for adjusting sharpness,

saturation and contrast. Adjust the microphone volume under Audio Volume Control.

[13] : Home

Tap to navigate to the home screen.

Drag Focus

In Camera View, touch the screen and hold until a blue circle appears. Then, drag the circle

to control the camera.

Upgrading the Firmware

Ensure that the battery has at least 50% power. It will take approximately 20 minutes to

complete the upgrade. It is recommended to lock the gimbal and place the handle on a at

surface during the upgrade process.

The camera status indicator will blink green and red alternately during the upgrade process,

and become solid green when the firmware upgrade is complete. If the Osmo+ upgrade

is successful, you will hear a beeping pattern consisting of 1 long beep followed by 2 short

beeps. If the upgrade is unsuccessful, the camera status indicator will become solid red and

the Osmo+ will emit a fast beeping sound, in which case you should reattempt the upgrade.

Using the DJI GO App

Connect the Osmo+ to your mobile device and then launch the DJI GO app. You will be

reminded if a new rmware upgrade is available. To start upgrading, connect your mobile

device to the internet and follow the on-screen instructions.

A Micro SD card must be inserted into the Osmo+ for the upgrade to start.

Restart the Osmo+ and ensure the Camera Status Indicator is off for normal use.

Using a Micro SD Card

1. Download the latest rmware update package from the product page on the ofcial DJI

website.

2. Copy the .bin file to the root directory of your Micro SD card (ensure there is enough

storage), and insert the card into the Micro SD card slot on the camera while the Osmo+ is

powered off.

3. Power on the Osmo+ to begin upgrading.

Read the .txt le on the root directory of the Micro SD card to conrm the upgrade result.

Maintenance

When transporting the Osmo+, keep it locked, in order to protect the gimbal, as shown below.

The Osmo+ is not water resistant. Keep it away from sand and dust during use. After use, it

is recommended to wipe the Osmo+ down with a soft dry cloth. Never spray any cleaning

liquids onto the Osmo+.

Specications

Handle

Dimensions 2.4×1.9×6.4 inches (61.8×48.2×161.5 mm)

Weight (including battery) 201 g

Gimbal

Model Zenmuse X3 Zoom

Weight 268 g

Output Power (with camera) 8 W

Angular Vibration Range ±0.02°

Mount Detachable

Controllable Range

Tilt: -35° to +135°

Pan: ±320°; Roll: ±30°

Mechanical Range

Tilt: -50° to +140°

Pan: ±330°; Roll: -50° to +90°

Max Controllable Speed 120°/s

OSMO+ User Manual

Camera

Model X3 ZOOM / FC350Z

Sensor

1/2.3” CMOS

Effective pixels:12.40 M

(Total pixels: 12.76 M)

Lens

3.5× Optical Zoom

22 - 77mm Equivalent

F2.8 (Wide) - F5.2 (Tele)

FOV 92° (Wide)- 35° (Tele)

Focus: 0.5 m to innity

ISO Range 100 - 3200 (video); 100 - 1600 (photo)

Electronic Shutter Speed 8 s - 1/8000 s (up to 30 s when camera is in M mode)

Max. Image Size 4000×3000 pixels

Still Photography Modes

Single Shot

Photo Burst Mode: 3

7 shots

Auto Exposure Bracketing

(

AEB

)

3/5 bracketed frames @ 0.7 EV bias

Interval

Auto Panorama

Sele Panorama

9-Shot Panorama

Motion Timelapse

Regular Timelapse

Video Resolution

C4K: 4096×2160

25p

4K: 3840×2160

24/25

30p

2.7K: 2704×1520

24/25

30p

FHD: 1920×1080 24/25/30/48/50/60/100p

Video Recording Modes

Auto

Slow Motion

Max. Video Bitrate 60 Mbps

Supported File Systems

FAT32

(

≤ 32 GB)

exFAT

(

> 32 GB)

Photo Formats JPEG, DNG

(

RAW)

Video Formats

MP4/MOV (MPEG-4 AVC/H.264)

Supported SD Cards

Micro SD

Max. Capacity: 64 GB

Class 10 or UHS-1

Operating Temperature 32° to 104° F (0° to 40° C

)

OSMO+ User Manual

Audio Output

48 kHz

AAC

Wi-Fi Video Link

Operating Frequency

2.412

–

2.462 GHz

5.180

–

5.805 GHz

Max Transmission Distance 82 feet

(

25 m

)

Transmitter Power (EIRP)

2.4 GHz: 8 dBm

5 GHz: 12 dBm

Intelligent Battery

Model HB02-542465

Type LiPo

Capacity 1225 mAh

Energy 14.1 Wh

Voltage 11.55 V

Charging Temperature

41° to 104° F (5° to 40° C)

Operating Temperature 32° to 104° F (0° to 40° C)

Battery Charger

Model OS1C11

Input 100

–

240 V, 50

60 Hz

Output 12.6/13.2 V, 0.8 A

Flexi Microphone

Sensitivity -32 ± 3 dB (0 dB =1 V/Pa)

Frequency Response 100 - 10000 Hz

Signal-to-Noise Ratio 60 dBA

Pin Diameter 3.5 mm

Length 88 mm

Weight 4 g

Troubleshooting

1. Why can’t I connect to the Osmo+?

•

Check your mobile device’s Wi-Fi settings to make sure it is connected to the Osmo+’s

Wi-Fi network.

•

If the Osmo+’s Wi-Fi network does not appear in your phone’s Wi-Fi settings, make sure

your mobile device is operating at either the 2.4GHz or 5.8GHz channel and try again.

•

If you still cannot connect to the Osmo+ even though your mobile device is connected

to the Osmo+’s Wi-Fi network, restart the Osmo+ and try again.

If the problem persists, reset the Osmo+’s Wi-Fi network to its default settings by using the

key combination and try again. (Key combination: Hold down the Trigger and Shutter Button

at the same time. Then, pull the power switch down until the System Status Indicator blinks

green. Release the power button before releasing the Trigger

)

Still can’t connect? You can contact our online support at www.dji.com/support to get

more help.

2. Why doesn’t the gimbal work out of the box?

Ensure you have activated the Osmo+ by linking it to your DJI account. Connect your

mobile device to the dedicated Osmo+ Wi-Fi network, launch the DJI GO app, and then

follow the on-screen instructions to activate the device.

3. Why does the Osmo+ keep beeping after I turn it on?

The gimbal is locked. Rotate the tilt and roll axes until they can move freely. If the pan axis

is locked, slide the Pan Axis Lock up to free the pan axis.

4. What should I do if the battery depletes while I am recording video?

Do not remove the Micro SD card from the camera. Recharge the battery or insert a new

one into the handle. The Osmo+ will automatically recover the video le when it starts up.

5. How do I shoot amazing long exposure shots?

Long exposures can be produced by setting a slow shutter speed. In the DJI GO app,

choose ‘S’ mode (Shutter Priority) or ‘M’ (Manual Mode) and adjust the shutter speed to the

desired value. Make sure you hold the camera still for the entire shutter duration.

6. Can I close the DJI GO app or disconnect my mobile device while the Osmo+ is

recording video?

Yes. The Osmo+ will continue recording video and still be able to capture photos, but you

will lose the ability to preview the shots on your mobile device.

OSMO is a trademark of DJI.

This content is subject to change.

Download the latest version from

http://www.dji.com/product/osmo-plus

If you have any questions about this document, please contact DJI by

sending a message to

[email protected]

Dji OSMO+ Handheld Gimbal with 4K Zoom Camera

Product's Documents

User Manual

Specifications

Dji OSMO+ Questions and Answers

Related Products

DJI OSMO POCKET Handheld 3-Axis Gimbal Stabilizer

Dji CP.OS.00000146.01 Pocket 2 - Handheld 3-Axis Gimbal Stabilizer

Dji CP.OS.00000108.01 OM 4 - Handheld 3-Axis Smartphone Gimbal Stabilizer

Dji RONIN-S Camera Stabilizer 3-Axis Gimbal Handheld

Dji CP.RN.00000040.01 Ronin-SC - Camera Stabilizer, 3-Axis Handheld Gimbal
