DVD
PLAYER
OWNER'S
MANUAL
MODEL
:
LDA-511
Before
connecting,
operating
or
adjusting
this
product,
please
read
this
instruction
booklet
carefully
and
completely.
DF9921NH_HA1ULL_ENG
ⓒ
Copyright
2005,
LG
Electronics
U.S.A.,
Inc.
For
service/
support
Call:
Toll
Free
Number
1-800-243-0000
2
This
lightning
flash
with
arrowhead
symbol
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
dangerous
voltage
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
important operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
the
product.
WARNING:
Do
not
install
this
equipment
in
a
confined
space
such
as
a
bookcase
or
similar
unit.
CAUTION:
This
product
employs
a
Laser
System.
To
ensure
proper
use
of
this
product,
please
read
this
owner
's
manual
carefully
and
retain
it
for
future
reference.
Should
the
unit
require
maintenance,
contact
an
authorized
service
center.
Performing
controls,
adjustments,
or
carrying
out
procedures
other
than
those
specified
herein
may
result
in
hazardous
radiation
exposure.
To
prevent
direct
exposure
to
laser
beam,
do
not
try
to
open
the
enclosure.
Visible
laser
radiation
when
open.
DO
NOT
STARE
INTO
BEAM.
CAUTION:
The
apparatus
should
not
be
exposed
to
water
(dripping
or
splashing)
and
no
objects
filled
with
liquids,
such
as
vases,
should
be
placed
on
the
apparatus.
CAUTION:
VISIBLE
AND
INVISIBLE
LASER
RADIATION
WHEN
OPEN
AND
INTERLOCKS
DEFEATED.
FCC
WARNING:
This
equipment
may
generate
or
use
radio
frequency
energy.
Changes
or
modifications
to
this
equipment
may
cause
harmful
interference
unless
the
modifications
are
expressly
approved
in
the
instruction
manual.
The
user
could
lose
the
authority
to
operate
this
equipment
if
an
unauthorized
change
or
modification
is
made.
REGULATORY
INFORMATION:
FCC
Part
15
This
epuipment
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B
digital
device,
pursuant
to
Part
15
of
the
FCC
Rules.
These
limits
are
designed
to
provide
reasonable
protection
against
harmful
interference
when
the
product
is
operated
in
a
residential
installation.
This
product
generates,
uses,
and
can
radiate
radio
frequency
energy
and,
if
not
installed
and
used
in
accordance
with
the
instruction
manual,
may
cause
harmful
interference
to
radio
communications.
However,
there
is
no
guarantee
that
interference
will
not
occur
in
a
particular
installation.
If
this
product
does
cause
harmful
interference
to
radio
or
television
reception,
which
can
be
determined
by
turning
the
product
off
and
on,
the
user
is
encouraged
to
try
to
correct
the
interference
by
one
or
more
of
the
following
measures:
?
Reorient
or
relocate
the
receiving
antenna.
?
Increase
the
separation
between
the
product
and
receiver.
?
Connect
the
product
into
an
outlet
on
a
circuit
different
from
that
to
which
the
receiver
is
connected.
?
Consult
the
dealer
or
an
experienced
radio/TV
technician
for
help.
FCC
COMPLIANCE:
The
responsible
party
for
this
product's
compliance
is:
LG
Electronics
U.S.A.,
Inc.,
1000
Sylvan
Avenue,
Englewood
Cliffs,
NJ
07632
Phone:
1-201-816-2000
CAUTION
concerning
the
Power
Cord
Most
appliances
recommend
they
be
placed
upon
a
dedicated
circuit;
That
is,
a
single
outlet
circuit
which
powers
only
that
appliance
and
has
no
additional
outlets
or
branch
circuits.
Check
the
specification
page
of
this
owner's
manual
to
be
certain.
Do
not
overload
wall
outlets.
Overloaded
wall
outlets,
loose
or
damaged
wall
outlets,
extension
cords,
frayed
power
cords,
or
damaged
or
cracked
wire
insulation
are
dangerous.
Any
of
these
conditions
could
result
in
electric
shock
or
fire.
Periodically
examine
the
cord
of
your
appliance,
and
if
its
appearance
indicates
damage
or
deterioration,
unplug
it,
discontinue
use
of
the
appliance,
and
have
the
cord
replaced
with
an
exact
replacement
part
by
an
authorized
servicer.
Protect
the
power
cord
from
physical
or
mechanical
abuse,
such
as
being
twisted,
kinked,
pinched,
closed
in
a
door,
or
walked
upon.
Pay
particular
attention
to
plugs,
wall
outlets,
and
the
point
where
the
cord
exits
the
appliance.
SERIAL
NUMBER:
The
serial
number
is
found
on
the
back
of
this
unit.
This
number
is
for
this
unit
only.
You
should
record the
serial
number
in
the
space
provided
and
retain
this
guide
as
a
permanent
record
of
your
purchase.
Model
No.
LDA-511
Serial
No.
CAUTION
WARNING:
TO PREVENT
FIRE
OR
ELECTRIC
SHOCK
HAZARD,
DO
NOT
EXPOSE
THIS
PRODUCT
TO
RAIN
OR
MOISTURE.
CAUTION:
TO
REDUCE
THE
RISK
OF
ELECTRIC
SHOCK
DO
NOT
REMOVE
COVER
(OR
BACK)
NO
USER-SERVICEABLE
PARTS
INSIDE
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
3
Contents
Introduction...................4
SymbolusedinthisManual..............4
AbouttheSymbolDisplay............4
NotesonDiscs........................4
HandlingDiscs......................4
StoringDiscs........................4
CleaningDiscs......................4
TypesofPlayableDiscs.................5
Regionalcode........................5
Disc-relatedterms.....................6
FrontPanel...........................7
RearPanel............................8
RemoteControl........................9
RemoteControlOperation..............9
Remote
Control
Battery
Installation
. . . . . .
.9
InstallationandSetup
. . . . . . . . .
.10
SettingupthePlayer..................10
DVDPlayerConnections...............10
Video
and
Audio
Connections
to
Your
TV
.
.10
HDMIconnection....................11
Audio
Connection
to
Optional
Equipment
.
.12
On-ScreenDisplay....................13
Playback
Status/Restrictions
. . . . . . . . . .
.13
InitialSettings........................14
GeneralOperation...................14
LANGUAGE.......................14
?MenuLanguage...................14
?DiscAudio/Subtitle/Menu
. . . . . . . . .
.14
DISPLAY..........................14
?TVAspect.......................15
?DisplayMode.....................15
AUDIO...........................15
?DolbyDigital/DTS/MPEG.
. . . . . . . . .
.15
?SampleFreq.(Frequency).
. . . . . . . . . .
.15
?
Dynamic
Range
Control
(DRC)
. . . . . .
.15
?Vocal............................15
OTHERS..........................16
?PBC............................16
?AutoPlay........................16
?
B.L.E.
(Black
Level
Expansion)
. . . . . . .
.16
?DivX(R)VOD......................16
LOCK(ParentalControl)..............17
?Rating..........................17
?Password(SecurityCode).
. . . . . . . . . .
.17
?AreaCode.......................17
Operation....................18
PlayingaDVDorVideoCD.............18
PlaybackSetup...................18
GeneralFeatures.....................18
Moving
to
another
TITLE/GROUP
. . . . . .
.18
Moving
to
another
CHAPTER/TRACK
. . .
.18
Search............................18
ChangingtheAudioChannel
. . . . . . . . .
.18
Still
and
Frame-by-Frame
Playback
. .
.19
SlowMotion........................19
Random...........................19
RepeatA-B........................19
Repeat............................19
3DSurround......................19
TimeSearch........................19
Zoom...........................20
MarkerSearch...................20
Pause............................20
SpecialDVDFeatures.................20
Checking
the
contents
of
DVD
discs:
Menus
.20
TitleMenu........................20
DiscMenu........................20
CameraAngle.....................20
ChangingtheAudioLanguage
. . . . . . . . .
.20
Subtitles.........................20
DVDAudioDiscs......................21
MovingtoanotherGROUP.............21
ViewinganotherPAGE................21
PlayinganMemoryCard...............22
Playing
an
Audio
CD
or
MP3/WMA
Disc
. .
.23
Audio
CD
and
MP3
/
WMA
Disc
Features
.
.24
Pause............................24
MovingtoanotherTrack..............24
RepeatTrack/All/Off.................24
Search...........................24
Random..........................24
RepeatA-B........................24
3DSurround.......................24
ProgrammedPlayback................25
RepeatProgrammedTracks
. . . . . . . . . .
.25
Erasing
a
Track
from
Program
List
. . . . .
.25
Erasing
the
Complete
Program
List
. . . . .
.25
ViewingaJPEGDisc..................26
SlideShow........................26
StillPicture.........................26
MovingtoanotherFile................26
Zoom.............................26
Torotatepicture.....................26
To
listen
to
MP3/WMA
music
watching
picture............................26
MaintenanceandService...............27
PlayingaDivXMovieDisc..............28
AdditionalFeatures...................29
LastSceneMemory..................29
ScreenSaver.......................29
VideoModeSetting....................29
Reference....................30
Controlling
Your
TV
with
the
Supplied
Remote
.30
LanguageCodes.......................31
AreaCodes...........................31
Troubleshooting.......................32
Specifications.........................33
4
To
ensure
proper
use
of
this
product,
please
read
this
owner's
manual
carefully
and
retain
for
future
reference.
This
manual
provides
information
on
the
operation
and
maintenance
of
your
DVD
player.
Should
the
unit
require
service,
contact
an
authorized
service
location.
Symbol
Used
in
this
Manual
The
lightning
flash
symbol
alerts
you
to
the
presence
of
dangerous
voltage
within
the
product
enclosure
that
may
constitute
a
risk
of
electric
shock.
The
exclamation
point
alerts
you
to
the
presence
of
important operating
and
maintenance
/
servicing
instructions.
Indicates
hazards
likely
to
cause
harm
to
the
unit
itself
or
other
material
damage.
Note:
Indicates
special
notes
and
operating
features.
Tip:
Indicates
tips
and
hints
for
making
the
task
easier.
A
section
whose
title
has
one
of
the
following
symbols
is
applicable only
to
the
disc
represented
by
the
symbol.
DVD
and
finalized
DVD±R/RW
DVD
Audio
discs
Video
CDs
Audio
CDs
MP3
Discs
WMA
Discs
JPEG
Discs
DivX
Discs
Memory
Card
About
the
Symbol
Display
"
"
may
appear
on
your
TV
display
during
operation
and
indicates
that
the
function
explained
in
this
owner's
manual
is
not
available
on
that
specific
DVD
video
disc.
Notes
on
Discs
Handling
Discs
Do
not
touch
the
playback
side
of
the
disc.
Hold
the
disc
by
the
edges
so
that
fingerprints
do
not
get
on
the
surface.
Never
stick
paper
or
tape
on
the
disc.
Storing
Discs
After
playing,
store
the
disc
in
its
case.
Do
not
expose
the
disc
to
direct
sunlight
or
sources
of
heat
and
never
leave
it
in
a
parked
car
exposed
to
direct
sunlight.
Cleaning
Discs
Fingerprints
and
dust
on
the
disc
can
cause
poor
quality
and
sound
distortion.
Before
playing,
clean
the
disc
with
a
clean
cloth.
Wipe
the
disc
from
the
center
out.
Do
not
use
strong
solvents
such
as
alcohol,
benzine,
thinner,
commercially
available
cleaners,
or
anti-static
spray
intended
for
older
vinyl
records.
M/C
DivX
JPEG
WMA
MP3
CD
VCD
DVD-A
DVD-V
Introduction
5
Types
of
Playable
Discs
DVD
(8cm/12cmdisc)
DVD
audio
discs
(8cm/12cmdisc)
Video
CD
(VCD)
(8cm/12cmdisc)
Audio
CD
(8cm/12cmdisc)
In
addition,
this
unit
plays
Memory
Card,
DivX
file,
DVD
-R,
DVD
+R,
DVD
-RW,
DVD
+RW,
SVCD,
and
CD-R
/
CD-RW
that
contains
audio
titles,
MP3,
WMA,
and/or
JPEG
files.
Notes:
?
Depending
on
the
conditions
of
the
recording
equipment
or
the
CD-R/RW
(or
DVD
-R,
DVD
+R,
DVD
-RW,
DVD
+RW)
disc
itself,
some
CD-R/RW
(or
DVD
-R,
DVD
+R,
DVD
-RW,
DVD
+RW)
discs
cannot
be
played
on
the
unit.
?
Do
not
attach
any
seal
or
label
to
either
side
(the
labeled
side
or
the
recorded
side)
of
a
disc.
?
Do
not
use
irregularly
shaped
CDs
(e.g.,
heart-
shaped
or
octagonal)
since
they
may
result
in
malfunctions.
Notes
on
DVDs
and
Video
CDs
Some
playback
operations
of
DVDs
and
Video
CDs
may
be
intentionally
programmed
by
software
manufacturers.
This
unit
plays
DVDs
and
Video
CDs
according
to
disc
content
designed by
the
software
manufacturer,
therefore
some
playback
features
may
not
be
available
or
other
functions
may
be
added.
Manufactured
under
license
from
Dolby
Laboratories.
"Dolby",
"Pro
Logic",
and
the
double-D
symbol
are
trademarks
of
Dolby
Laboratories.
DTS
and
DTS
Digital
Out
are
trademarks
of
Digital
Theater
Systems,
Inc.
Regional
code
This
DVD
player
is
designed
and
manufactured
for
playback
of
region
"1"
encoded
DVD
software.
This
unit
can
play only
DVD
discs
labeled
"1"
or
"ALL".
Notes
on
Regional
Codes
?
Most
DVD
discs
have
a
globe
with
one
or
more
numbers
in
it
clearly
visible
on
the
cover.
This
number
must
match
your
DVD
player's
regional
code
or
the
disc
cannot
play.
?
If
you
try
to
play
a
DVD
with
a
different
region
code
from
your
player,
the
message
"Check
Regional
Code"
appears
on
the
TV
screen.
Notes
on
Copyrights:
It
is
forbidden
by
law
to
copy,
broadcast,
show,
broadcast
via
cable,
play
in
public,
or
rent
copyrighted
material
without
permission.
This
product
features
the
copy
protection
function
developed
by
Macrovision.
Copy
protection
signals
are
recorded
on
some
discs.
When
recording
and
playing
the
pictures
of
these
discs
noise
will
appear.
This
product
incorporates
copyright
protection
technology
that
is
protected
by
method
claims
of
certain
U.S.
patents
and
other
intellectual
property
rights
owned
by
Macrovision
Corporation
and
other
rights
owners.
Use
of
this
copyright
protection
technology
must
be
authorized
by
Macrovision
Corporation,
and
is
intended
for
home
and
other
limited
viewing
uses
only
unless
otherwise
authorized
by
Macrovision
Corporation.
Reverse
engineering
or
disassembly
is
prohibited.
CONSUMERS
SHOULD
NOTE
THAT
NOT
ALL
HIGH
DEFINITION
TELEVISION
SETS
ARE
FULLY
COMPATIBLE
WITH
THIS
PRODUCT
AND
MAY
CAUSE
ARTIFACTS
TO
BE
DISPLAYED
IN
THE
PICTURE.
IN
CASE OF
525
PROGRESSIVE
SCAN
PROBLEMS,
IT IS
RECOMMENDED
THAT
THE
USER
SWITCH
THE
CONNECTION
TO THE
'STANDARD
DEFINITION'
OUTPUT.
IF
THERE
ARE
QUESTIONS
REGARDING
OUR
TV
SET
COMPATIBILITY
WITH
THIS
MODEL
525p
DVD
PLAYER,
PLEASE
CONTACT
OUR
CUSTOMER
SERVICE
CENTER.
1
6
Disc-related
terms
DVD±R/DVD±RW
DVD
-R
and
DVD
+R
are
two
different
standards
for
recordable
DVD
drives
and
discs.
This
format
allows
information
to
be
recorded
onto
the
DVD
disc
only
once.
DVD
+RW
and
DVD
-RW
are
two
standards
for
re-writable
media,
meaning
the
DVD
content
can
be
erased
and
re-recorded.
VCD
(Video
CD)
A
VCD
holds
up
to
74
minutes
(650
MB
disc)
or
80
minutes
(700
MB
disc)
of
MPEG-1
full-motion
video
along
with
quality
stereo
sound.
MPEG
MPEG
is
an
international
standard
for
video
and
audio
compression.
MPEG-1
is
used
in
encoding
video
for
VCD
and
provides
for
multichannel
surround
sound
coding
such
as
PCM,
Dolby
Digital,
DTS
and
MPEG
audio.
MP3
MP3
is
a
popular
compression
format
used
for
digital
audio
files
that
yields
very
high
near-CD
quality.
WMA
Windows
media
audio
file.
A
type
of
coding
/
decoding
developed
by
Microsoft
Corp.
JPEG
Joint
Pictures
Expert
Group.
JPEG
is
a
compressed
file
format
that
allows
you
to
save
images
with
no
limit
on
the
number
of
colors.
DivX
DivX
is
the
name
of
a
revolutionary
new
video
codec
which
is
based
on
the
new
MPEG-4
compression
standard
for
video.You
will
be
able
to
play
DivX
movies
using
this
DVD
player.
PBC:
Playback
Control
(Video
CD
only)
Playback
control
is
available
for
Video
CD
(VCD)
version
2.0
disc
formats.
PBC
allows
you
to
interact
with
the
system
via
menus,
search
functions,
or
other
typical
computer-like
operations.
Moreover,
still
pictures
of
high
resolution
can
be
played
if
they
are
included
in
the
disc.
Video
CDs
not
equipped
with
PBC
(Version
1.1)
operate
in
the
same
way
as
audio
CDs.
Title
(DVD
video
discs
only)
A
title is
generally
a
distinct
section
of
a
DVD
disc.
For
example
the
main
feature
could
be
title
1,
a
documentary
describing
how
the
film
was
made
could
be
title
2,
and
cast
interviews
could
be
title
3.
Each
title
is
assigned
a
reference
number
enabling
you
to
locate
it
easily.
Chapter
(DVD
video
discs
only)
A
chapter
is
a
segment
of
a
title
such
as a
scene
in
a
film
or
one
interview
in
a
series.
Each
chapter
is
assigned
a
chapter
number,
enabling
you
to
locate
the
chapter
you
want.
Depending
on
the
disc,
chapters
may
not
be
recorded.
Group
(DVD
audio
discs
only)
The
main
audio
content
or
accompanying
feature
content
or
additional
feature
content,
or
music
album.Each
group
is
assigned
a
group
reference
number
enabling
you
to
locate
it
easily.
Scene
(VCD)
On
a
video
CD
with
PBC
(playback
control)
functions,
moving
pictures
and
still
pictures
are
divided
into
sections
called
"scenes".
Each
scene
is
displayed
in
the
menu
screen
and
assigned
a
scene
number,
enabling
you
to
locate
the
scene
you
want.
A
scene
is
composed
of
one
or
several
tracks.
Track
A
distinct
element
of
audiovisual
information,
such
as
the
or
sound
track
for
a
specific
language
(DVD),
or
a
musical
piece
on
a
video
or
audio
CD.
Each
track
is
assigned
a
track
number,
enabling
you
to
locate
the
track
you
want.
DVD
discs
allow
one
track
of
video
(with
multiple
angles)
and
several
tracks
of
audio.
7
Front
Panel
3D
SOUND
Selects
3DSURROUND
during
playback.
RESOLUTION
You
can
change
the
resolution
depending
on
your
TV.
STOP
(
x
)
Stops
playback.
PLAY(N)
Starts
playback.
OPEN/CLOSE(Z)
Opens
or
closes
the
disc
Disc
slot
Insert
a
disc
here.
POWER
Switches
the
player
ON
and
OFF.
Remote
Sensor
Point
the
DVD
Player
remote
control
here.
Display
window
Shows
the
current
status
of
the
player.
MEMORY
CARD
Accesses
the
menu
for
memory
card.
MEMORY
CARD
Slot
Insert
a
memory
card.
(CF,
MD,
MMC,
SD,
MS,
MS-Pro
or
xD).
8
Rear
Panel
COAXIAL
(Digital
audio
out
jack)
Connect
to
digital
(coaxial)
audio
equipment.
AUDIO
OUT
(Left/Right)
Connect
to
an
amplifier,
receiver,
or
stereo
system.
VIDEO
OUT
Connect
to
a
TV
with
video
inputs.
OPTICAL
(Digital
audio
out
jack)
Connect
to
digital
(optical)
audio
equipment.
AC
Power
Cord
Plug
into
the
power
source.
S-VIDEO
OUT
Connect
to
a
TV
with
S-Video
inputs.
COMPONENT
VIDEO
OUT
/
(480p
/
720p
/
1080i)
Connect
to
a
TV
with
Y
Pb
Pr
inputs.
HDMI
OUT
HDMI
output
providing
a
high
quality
interface
for
digital
audio
and
video.
9
Remote
Control
Remote
Control
Operation
Point
the
Remote
Control
at
the
remote
sensor
and
press
the
buttons.
Do
not
mix
old
and
new
batteries
and
never
mix
different
types
of
batteries
such
as
standard,
alkaline,
etc.
Remote
Control
Battery
installation
Detach
the
battery
cover
on
the
rear
of
the
remote
control,
and
insert
two
batteries
(size
AAA)
with
and
aligned
correctly.
AAA AAA
TV
Control
Buttons
TV
POWER:
Turns
the
TV
on
or
off.
TV
PR/CH
+/--:
Selects
TV's
channel.
TV
VOL
+/--:
Adjusts
TV's
volume.
AV:
Selects
the
TV's
source.
SKIP(./>)
Go
to
next
chapter
or
track.
Returns
to
beginning
of
current
chapter
or
track
or
go
to
previous
chapter
or
track.
STOP(x)
Stops
playback.
TITLE
Displays
title
menu,
if
available.
RETURN
Removes
the
setup
menu,
displays
the
video
CD
with
PBC.
?
MARKER
Marks
any
point
during
playback.
?
SEARCH
Displays
MARKER
SEARCH
menu.
?
PROGRAM
Places
a
track
on
the
program
list.
?
ZOOM
Enlarges
video
image.
?
REPEAT
Repeat
chapter,
track,
title,
group,
all.
?
A-B
Repeat
sequence.
?
RANDOM
Plays
tracks
in
random
order.
?
*
This
button
is
not
available.
OPEN
/
CLOSE
Opens
or
closes
the
disc.
POWER
Switches
DVD
Player
ON
and
OFF.
0-9
number
buttons
Selects
numbered
items
in
a
menu.
CLEAR
Removes
a
track
number
on
the
program
list
or
a
mark
on
the
MARKER
SEARCH
menu.
SCAN(m/M)
Search
backward
or
forward.
PAUSE/STEP(X)
Pauses
playback
temporarily/
press
repeatedly
for
frame-by-frame
playback.
PLAY(N)
Starts
playback.
DVD
MENU
Accesses
menu
on
a
DVD
disc.
bBvV(left/right/up/down)
?
Selects
an
item
in
the
menu.
ENTER
?
Confirms
menu
selection.
DISPLAY
Accesses
On-Screen
display.
AUDIO
?
Selects
an
audio
language
(DVD).
SUBTITLE
?
Selects
a
subtitle
language.
ANGLE
?
Selects
a
DVD
camera
angle
if
available
SETUP
?
Accesses
or
removes
setup
menu.
10
Setting
up
the
Player
The
and
sound
of
a
nearby
TV,
VCR,
or
radio
may
be
distorted
during
playback.
If
this
occurs,
position
the
player
away
from
the
TV,
VCR,
or
radio,
or
turn
off
the
unit
after
removing
the
disc.
DVD
Player
Connections
Depending
on
your
TV
and
other
equipment
there
are
various
ways
you
can
connect
the
player.
Please
refer
to
the
manuals
of
your
TV,
stereo
system
or
other
devices
as
necessary
for
additional
connection
information.
Video
and
Audio
Connections
to
Your
TV
Make
sure
the
DVD
player
is
connected
directly
to
the
TV
and
not
to
a
VCR,
otherwise
the
DVD
could
be
distorted
by
the
copy
protection
system.
Audio:
Connect
the
left
and
right
AUDIO
OUT
jacks
of
the
DVD
Player
to
the
audio
left
and
right
IN
jacks
on
the
TV
(A)
using
the
audio
cables.
Do
not
connect
the
DVD
Player's
AUDIO
OUT
jack
to
the
phone
in
jack
(record
deck)
of
your
audio
system.
Video:
Connect
the
VIDEO
OUT
jack
on
the
DVD
player
to
the
video
in
jack
on
the
TV
using
the
video cable
(V).
S-Video:
Connect
the
S-VIDEO
OUT
jack
on
the
DVD
Player
to
the
S-Video
in
jack
on
the
TV
using
the
S-Video
cable
(S)
Component
Video
:
Connect
the
COMPONENT
VIDEO
OUT
/
(480p
/
720p
/
1080i)
jacks
on
the
DVD
Player
to
the
corresponding
in
jacks
on
the
TV
using
an
Y
Pb
Pr
cable
(C).
?
If
your
television
is
a
high-definition
or
"digital
ready"
television,
you
may
take
advantage
of
displaying
the
highest
video
resolution
possible.
?
If
your
TV
does
not
accept
your
resolution
setting,
abnormal
appears
on
the
screen.
Please
read
TV's owner's
manual
then
set
the
resolution
that
your
TV
can
accept.
Resolution
setting
You
can
change
the
resolution
for
the
COMPONENT
VIDEO
OUT
/
(480p
/
720p
/
1080i)
video
output
by
pressing
RESOLUTION
on
the
front
panel.
Available
resolution
settings
are
as
shown
below.
OUTPUT
Available
CONNECTION
Resolution
HDMI
1920
x
1080i
VIDEO
OUT
1280
x
720p
720
x
480p
1440
x
480i
COMPONENT
1920
x
1080i
VIDEO
OUT
1280
x
720p
720
x
480p
720
x
480i
VIDEO
OUT
720
x
480i
S-VIDEO
720
x
480i
Notes:
?
For
720p
and
1080i
resolution
on
the
component
video
out,
only
non-copy
protected
discs
can
be
played
back.
If
the
disc
is
copy
protected,
it
will
be
displayed
at
the
480p
resolution.
?
1080i,
720p
and
480p
do
not
work
with
the
analog
video
connections
(VIDEO
OUT
&
S-VIDEO).
Installation
and
Setup
11
Installation and Setup
HDMI
connection
If
you
have
an
HDMI
TV
or
monitor,
you
can
connect
it
to
this
player
using
an
HDMI
cable.
1.
Connect
the
HDMI
OUT
jack
on
the
player
to
the
HDMI
jack
on
an
HDMI
compatible
TV
or
monitor
(H).
2.
Set
the
TV's
source
to
HDMI
(refer
to
TV's
Owner's
manual).
3.
Press
RESOLUTION
repeatedly
to
select
the
resolution
you
wish
to
change
to,
then
press
PLAY.
Notes
:
?
Both
PCM
and
Bitstream
Audio
out
is
available,
when
the
sample
frequency
is
set
to
48kHz
in
HDMI
connection.
?
If
Audio
setup
is
set
to
bitstream
and
your
TV
does
not
support
Bitstream
Audio
out
in
HDMI
connection,
audio
sound
is
converted
to
PCM.
?
If
Audio
setup
is
set
to
bitstream
and
the
sound
is
distorted,
check
your
TV's
audio
capability
and
set
the
Audio
setup
to
PCM.
?
The
arrow
on
the
cable
connector
body
should
face
up
for
correct
alignment
with
the
connector
on
the
player.
?
If
there
is
noise
or
lines
on
the
screen,
please
check
the
HDMI
cable.
?
Not
all
HDCP-compatible
DVI
devices
will
work
with
this
DVD
player.
?
If
TV
does
not
support
HDCP,
snow
noise
appears
on
the
screen.
Tip:
When
you
use
HDMI
connection,
you
can
change
the
resolution
(480i,
480p,
720p,
1080i)
for
the
HDMI
output
by
pressing
the
RESOLUTION
button
on
the
front
panel.
About
HDMI
HDMI
(High
Definition
Multimedia
Interface)
supports
both
video
and
audio
on
a
single
digital
connection
for
an
easy
all-
digital
output
to
an
HDMI
or
DVI-equipped
TV.
Connection
to
an
HDMI
TV
requires
an
HDMI
cable
while
connection
to
a
DVI-equipped
TV
requires
an
HDMI
to
DVI
adapter.
HDMI
has
the
capability
to
support
standard,
enhanced,
or
high-definition
video
plus
standard
to
multi-channel
surround-sound
audio.
HDMI
features
include
uncompressed
digital
video,
a
bandwidth
of
up
to
5
gigabytes
per
second,
one
connector
(instead
of
several
cables
and
connectors):
communication
between
the
AV
source
and
AV
devices
such
as
Digital
Televisions.
HDMI,
the
HDMI
logo
and
High-Definition
Multimedia
Interface
are
trademarks
or
registered
trademarks
of
HDMI
licensing
LLC.
HDMI
compatible
TV
Rear
of
DVD
player
HDMI
H
12
Audio
Connection
to
Optional
Equipment
Connect
the
DVD
player
to
your
optional
equipment
for
audio
output.
Amplifier
equipped
with
2-channel
analog
stereo
or
Dolby
Pro
Logic
ll
/
Pro
Logic:
Connect
the
left
and
right
AUDIO
OUT
jacks
on
the
DVD
Player
to
the
audio
left
and
right
IN
jacks
on
your
Amplifier,
Receiver,
or
Stereo
System,
using
the
audio
cables
(A).
Amplifier
equipped
with
2-channel
digital
stereo
(PCM)
or
Audio
/
Video
Receiver
equipped
with
a
multi-channel
decoder
(Dolby
DigitalTM,
MPEG
2,
or
DTS):
Connect
one
of
the
DVD
Player's
DIGITAL
AUDIO
OUT
jacks
(OPTICAL
O
or
COAXIAL
X)
to
the
corresponding
in
jack
on
your
Amplifier.
Use
an
optional
digital
(optical
O
or
coaxial
X)
audio
cable.
Digital
Multi-channel
sound
A
digital
multi-channel
connection
provides
the
best
sound
quality.
For
this
you
need
a
multi-channel
Audio
/
Video
Receiver
that
supports
one
or
more
of
the
audio
formats
supported
by
your
DVD
Player
such
as
MPEG
2,
Dolby
Digital
and
DTS.
Check
the
Receiver
manual
and
the
logos
on
the
front
of
the
Receiver.
Notes:
?
If
the
audio
format
of
the
digital
output
does
not
match
the
capabilities
of
your
Receiver,
the
Receiver
produces
a
strong,
distorted
sound
or
no
sound
at
all.
?
Six
Channel
Digital
Surround
Sound
via
a
digital
connection
can
only
be
obtained
if
your
Receiver
is
equipped
with
a
Digital
Multi-channel
decoder.
?T
o
see
the
audio
format
of
the
current
DVD
in
the
on-screen
display,
press
AUDIO
button.
Amplifier
(Receiver)
Rear
of
DVD
player
A
X
AUDIO
INPUT
DIGITAL
INPUT
COAXIAL
OPTICAL
DIGITAL
INPUT
O
13
On-Screen
Display
You
can
display
the
general
playback
status
on
the
TV
screen.
Some
items
can
be
changed
using
the
menu.
To
use
the
on-screen
display:
1.
Press
DISPLAY
during
playback.
2.
Press
v
/
V
to
select
an
item.
The
selected
item
is
highlighted.
3.
Press
b
/
B
to
change
the
setting.
You
can
also
use
the
number
buttons
if
appropriate
(e.g.
inputting
the
title
number).
For
some
functions,
press
ENTER
to
execute
the
setting.
Notes:
?
Some
discs
may
not
provide
all
of
the
features
shown
below.
?
If
no
button
is
pressed
for
10
seconds,
the
on-
screen
display
disappears.
Playback
Status/Restrictions
Repeat
title
Repeat
sequence
Enter
a
Marker
Marker
Search
menu
Resume
play
from
this
point
Action
prohibited
or
not
available
MARKER
SEARCH
1/9
A-B
Title
Example:
On-Screen
Display
during
playing
VCD
Items
Title
Number
Chapter
Number
Time
search
Audio
language
and
Digital
Audio
Output
mode
Subtitle
language
Angle
Sound
Selection
Method
b
/
B,
Numbers
ENTER
b
/
B,
Numbers
ENTER
Numbers,
ENTER
b/Bor
AUDIO
b/Bor
SUBTITLE
b/Bor
ANGLE
b/B
1/3
1/12
0:20:09
ABC
1
ENG
1/3
3D
SUR
Example:
On-Screen
Display
during
playing
DVD
Video
Items
Track
Number
(or
PBC
mode)
Time
search
Audio
Channel
Sound
Selection
Method
b
/
B,
Numbers
ENTER
Numbers
ENTER
b/Bor
AUDIO
b/B
1/3
0:20:09
3D
SUR
Items
Track
Number
Time
search
Audio
language
and
Digital
Audio
Output
mode
Subtitle
language
Sound
Selection
Method
b
/
B,Numbers
ENTER
Numbers,
ENTER
b/Bor
AUDIO
b/Bor
SUBTITLE
b/B
1/3
0:20:09
MP3
1
ABC
ENG
3D
SUR
Example:
On-Screen
Display
during
playing
divx
movie
disc
Items
Group
Number
Track
Number
Time
search
DVD
Audio
Output
mode
Subtitle
language
Page
(or
Angle)
Selection
Method
b
/
B,
Numbers
ENTER
b
/
B,
Numbers
ENTER
Display
only
b/Bor
AUDIO
Display
only
b/Bor
ANGLE
0:20:09
OFF
ABC
Example:
On-Screen
Display
during
playing
DVD
Audio
1/3
or
Installation and Setup
14
Initial
Settings
By
using
the
Setup
menu,
you
can
make
various
adjustments
to
items
such
as
and
sound.
You
can
also
set
a
language
for
the
subtitles
and
the
Setup
menu,
among
other
things.
For
details
on
each
Setup
menu
item,
see
pages
14
to
17.
To
display
and
exit
the
Menu:
Press
SETUP
to
display
the
menu.
A
second
press
of
SETUP
will
take
you
back
to
initial
screen.
To
go
to
the
next
level:
Press
B
on
the
Remote
Control.
To
go
back
to
the
previous
level:
Press
b
on
the
Remote
Control.
General
Operation
1.
Press
SETUP.
The
Setup
menu
appears.
2.
Use
v
/
V
to
select
the
desired
option
then
press
B
to
move
to
the
second
level.
The
screen
shows
the
current
setting
for
the
selected
item,
as
well
as
alternate
setting(s).
3.
Use
v
/
V
to
select
the
second
desired
option
then
press
B
to
move
to
the
third
level.
4.
Use
v
/
V
to
select
the
desired
setting
then
press
ENTER
to
confirm
your
selection.
Some
items
require
additional
steps.
5.
Press
SETUP
or
PLAY
to
exit
the
Setup
menu.
LANGUAGE
Menu
Language
Select
a
language
for
the
Setup
menu
and
on-screen
display.
Disc
Audio
/
Subtitle
/
Menu
Select
the
language
you
prefer
for
the
audio
track
(disc
audio),
subtitles,
and
the
disc
menu.
Original:
Refers
to
the
original
language
in
which
the
disc
was
recorded.
Other:
To
select
another
language,
press
number
buttons
then
ENTER
to
enter
the
corresponding
4-digit
number
according
to
the
language
code
list
in
the
reference
chapter.
If
you
enter
the
wrong
language
code,
press
CLEAR.
DVD-A
DVD-V
Menu
Language
Original
English
Off
Original
Disc
Audio
Disc
Subtitle
Disc
Menu
Move
Select
LANGUAGE
15
Installation and Setup
DISPLAY
TV
Aspect
4:3:
Select
when
a
standard
4:3
TV
is
connected.
16:9:
Select
when
a
16:9
TV
is
connected.
Display
Mode
Display
Mode
setting
works
only
when
the
TV
Aspect
mode
is
set
to
"4:3".
Letterbox:
Displays
a
wide
with
bands
on
the
upper
and
lower
portions
of
the
screen.
Panscan:
Automatically
displays
the
wide
on
the
entire
screen
and
cuts
off
the
portions
that
do
not
fit.
AUDIO
Each
DVD
disc
has
a
variety
of
audio
output
options.
Set
the
player's
AUDIO
options
according
to
the
type
of
audio
system
you
use.
Dolby
Digital
/
DTS
/
MPEG
Bitstream:
Select
"Bitstream"
if
you
connect
the
DVD
Player's
DIGITAL
OUT
jack
to
an
Amplifier
or
other
equipment
with
a
Dolby
Digital,
DTS
or
MPEG
decoder.
PCM:
Select
when
connected
to
a
two-channel
digital
stereo
amplifier.
DVDs
encoded
in
Dolby
Digital
or
MPEG
will
be
automatically
downmixed
to
two-channel
PCM
audio.
Off
(for
DTS):
If
you
select
"Off",
the
DTS
signal
is
not
output
through
the
DIGITAL
OUT
jack.
Sample
Freq.
(Frequency)
If
your
Receiver
or
Amplifier
is
NOT
capable
of
handling
96
kHz
signals,
select
48
kHz.
When
this
choice
is
made,
this
unit
automatically
converts
any
96
kHz
signals
to
48
kHz
so
your
system
can
decode
them.
If
your
Receiver
or
Amplifier
is
capable
of
handling
96
kHz
signals,
select
96
kHz.
When
this
choice
is
made,
this
unit
passes
each
type
of
signal
through
without
any
further
processing.
Check
the
documentation
for
your
Amplifier
to
verify
its
capabilities.
Dynamic
Range
Control
(DRC)
With
the
DVD
format,
you
can
hear
a
program's
soundtrack
in
the
most
accurate
and
realistic
presentation
possible,
thanks
to
digital
audio
technology.
However,
you
may
wish
to
compress
the
dynamic
range
of
the
audio
output
(the
difference
between
the
loudest
sounds and
the
quietest
ones).
This
allows
you
to
listen
to
a
movie
at
a
lower
volume
without
losing
clarity
of
sound.
Set
DRC
to
On
for this
effect.
Vocal
Set
to
On
only
when
a
multi-channel
karaoke
DVD
is
playing.
The
karaoke
channels
on
the
disc
mix
into
normal
stereo
sound.
DVD-V
DivX
DVD-A
DVD-V
DVD-A
DVD-V
DivX
DVD-A
DVD-V
DVD-A
DVD-V
DVD-A
DVD-V
Dolby
Digital
Bitstream
PCM
48
kHz
Bitstream
DTS
MPEG
Sample
Freq.
On
DRC
On
Vocal
Move
Select
AUDIO
DISPLAY
TV
Aspect
Widescreen
16:9
Display
Mode
Move
Select
16
OTHERS
The
PBC,
Auto
Play,
B.L.E.
and
DivX(R)
VOD
settings
can
be
changed.
PBC
Set
Playback
Control
(PBC)
to
On
or
Off.
On:
Video
CDs
with
PBC
are
played
according
to
the
PBC.
Off:
Video
CDs
with
PBC
are
played
the
same
way
as
Audio
CDs.
Auto
Play
You
can
set
up
the
DVD
Player
so a
DVD
disc
automatically
starts
playing
whenever
the
DVD
is
inserted.
If
Auto
Play
mode
is
set
to
On,
this
DVD
player
will
search
for
title
that
has
the
longest
playback
time
and
then
play
back
the
title
automatically.
On:
Auto
Play
function
is
active.
Off:
Auto
Play
function
is
not
active.
Note:
The
Auto
Play
function
may
not
work
for
some
DVDs.
B.L.E.
(Black
Level
Expansion)
To
select
the
black
level
of
playback
pictures.
Set
your
preference
and
monitor's
ability.
On:
Expanded
grey
scale.
(0
IRE
cut
off)
Off:
Standard
grey
scale.
(7.5
IRE
cut
off)
DivX(R)
VOD
You
can
display
the
DivX
DRM
(Digital
Rights
Management)
Registration
code
for
your
unit.
The
Registration
code
is
used
for
VOD
(Video-On-
Demand)
service
agent.
You
can
purchase
or
rent
an
encrypt
movie
file.
Notes:
If
you
rent
the
DivX
VOD
file,
it
has
several
options
of
viewing
limits
as
shown
below.
?
Display
the
number
which
you
can
watch
the
file.
?
The
rental
has
been
expired.
?
Display
the
authorization
error.
DivX
DVD-V
VCD
PBC
Off
Move
Auto
Play
OTHERS
On
Select
On
B.L.E.
Select
DivX(R)
VOD
17
Installation and Setup
LOCK
(Parental
Control)
Rating
Some
movies
contain
scenes
that
may
not
be
suitable
for
children
to
view.
Many
of
these
discs
contain
parental
control
information
that
applies
to
the
complete
disc
or
to
certain
scenes
on
the
disc.
Movies
and
scenes
are
rated
from
1
to
8,
depending
on
the
country.
Some
discs
offer
more
suitable
scenes
as
an
alternative.
The
parental
control
feature
allows
you
to
block
access
to
scenes
below
the
rating
you
input,
thereby
preventing
your
children
from
being
able
to
view
material
you
believe
is
unsuitable.
1.
Select
"Rating"
on
the
LOCK
menu
then
press
B.
2.
To
access
the
Rating,
Password
and
Area
Code
features,
you
must
input
the
4-digit
security
code
you
created.
If
you
have
not
yet
entered
a
security
code
you
are
prompted
to
do
so.
Input
a
4-digit
code
and
press
ENTER.
Enter
it
again
and
press
ENTER
to
verify.
If
you
make
a
mistake
before
pressing
ENTER,
press
CLEAR.
3.
Select
a
rating
from
1
to
8
using
the
v
/
V
buttons.
Rating
1-8:
Rating
one
(1)
has
the
most
restrictions
and
rating
eight
(8)
is
the
least
restrictive.
Unlock
If
you
select
unlock,
parental
control
is
not
active
and
the
disc
plays
in
full.
Note:
If
you
set
a
rating
for
the
player,
all
disc
scenes
with
the
same
rating
or
lower
are
played.
Higher
rated
scenes
are
not
played
unless
an
alternate
scene
is
available
on
the
disc.
The
alternative
must
have
the
same
rating
or
a
lower
one.
If
no
suitable
alternative
is
found,
playback
stops.
You
must
enter
the
4-digit
password
or
change
the
rating
level
in
order
to
play
the
disc.
4.
Press
ENTER
to
confirm
your
rating
selection,
then
press
SETUP
to
exit
the
menu.
Password
(Security
Code)
You
can
enter
or
change
password.
1.
Select
Password
on
the
LOCK
menu
then
press
B.
2.
Follow
step
2
as
shown
left
(Rating).
"Change"
or
"New"
is
highlighted.
3.
Enter
the
new
4-digit
code,
then
press
ENTER.
Input
it
again
to
verify.
4.
Press
SETUP
to
exit
the
menu.
If
you
forget
your
Security
Code
If
you
forget
your
security
code
you
can
clear
it
using
the
following
steps:
1.
Remove
any
disc
from
the
unit.
2.
Press
SETUP
to
display
the
Setup
menu.
3.
Input
the
6-digit
number
"210499"
and
the
security
code
is
cleared.
4.
Enter
a
new
code
as
described
above.
Area
Code
Enter
the
code
of
the
area
whose
standards
were
used
to
rate
the
DVD
video
disc,
based
on
the
list
in
the
reference
chapter.
1.
Select
"Area
Code"
on
the
LOCK
menu
then
press
B.
2.
Follow
step
2
as
shown
left
(Rating).
3.
Select
the
first
character
using
v
/
V
buttons.
4.
Press
ENTER
and
select
the
second
character
using
v
/
V
buttons.
5.
Press
ENTER
to
confirm
your
area
code
selection.
DVD-V
DVD-V
LOCK
Rating
New
Unlock
Password
Area
Code
Move
Select
US
18
Operation
Playing
a
DVD
or
Video
CD
Playback
Setup
1.
Turn
on
the
TV
and
select
the
video
input
source
connected
to
the
DVD
Player.
2.
Turn
on
the
Audio
System
(if
applicable)
and
select
the
input
source
connected
to
the
DVD
player.
3.
Insert
your
chosen
disc
to
the
disc
slot
with
the
playback
side
down.
Playback
starts
automatically.
If
playback
does
not
start,
press
PLAY.
In
some
cases,
the
disc
menu
might
appear
instead:
Use
the
bBvVbuttons
to
select
the
title/chapter
you
want
to
view,
then
press
ENTER
to
start.
Press
TITLE
or
DVD
MENU
to
return
to
the
menu
screen.
Use
the
1 2
3
4
buttons
to
select
an
option
you
want,
then
press
ENTER
to
view
the
option.
Use
the
number
buttons
to
select
the
track
you
want
to
view
and
press
RETURN
to
return
to
the
menu
screen.
Menu
settings
and
operating
procedures
may
differ.
Follow
the
instructions
on
the
each
menu
screen.
You
also
may
set
PBC
to
Off
(See
"PBC"
on
page
16).
Notes:
?
If
parental
control
is
set
and
the
disc
is
not
within
the
rating
settings
you
must
input
the
password.
(See
"Lock
Menu"
on
page
17.)
?
DVDs
may
have
a
region
code.
Your
player
does
not
play
discs
that
have
a
region
code
different
from
your
player.
The
region
code
for
this
player
is
1
(one).
General
Features
Note:
Unless
stated
otherwise,
all
operations
described
use
the
Remote
Control.
Some
features
may
also
be
available
on
the
Setup
menu.
Moving
to
another
TITLE/GROUP
When
a
disc
has
more
than
one
title/group,
you
can
move
to
another
title/group.
Press
DISPLAY
while
playback
is
stopped
then
the
appropriate
number
(0-9)
or
use
b
/
B
to
move
to
another
title/group.
You
can
play
any
title
by
inputting
its
number
while
playback
is
stopped.
Moving
to
another
CHAPTER/TRACK
When
a
title
on
a
disc
has
more
than
one
chapter
or
a
disc
has
more
than
one
track,
you
can
move
to
another
chapter/track
as
follows:
?
Press
SKIP
.
or
>
briefly
during
playback
to
select
the
next
chapter/track
or
to
return
to
the
beginning
of
the
current
chapter/track.
?
Press
SKIP
.
twice
briefly
to
step
back
to
the
previous
chapter/track.
?T
o
go
directly
to
any
chapter
during
DVD
playback,
press
DISPLAY
and
press
v
/
V
to
select
the
chapter/track
icon.
Then,
input
the
chapter/track
numberoruseb/B.
Search
1.
Press
SCAN
(m
or
M)
during
playback.
2.
Press
SCAN
(m
or
M)
repeatedly
to
select
the
required
speed.
DVD,
DivX
disc;
X2, X4,
X16
or
X100
Video
CD;
X2,
X4
or
X8
3.
To
exit
SEARCH
mode,
press
PLAY.
Note:
When
using
a
DVD
audio
disc
that
includes
pictures,
this
operation
may
be
permitted
in
some
segments.
Changing
the
Audio
Channel
Press
AUDIO
repeatedly
during
playback
to
hear
a
different
audio
channel
(Stereo,
Left,
or
Right).
20
Zoom
Use
zoom
to
enlarge
the
video
image.
1.
Press
ZOOM
during
playback
or
still
playback
to
activate
the
Zoom
function.
The
square
frame
appears
briefly
in
the
right
bottom
of
the
picture.
2.
Each
press
of
the
ZOOM
button
changes
the
TV
screen
in
the
sequence:
100%
size
→
400%
size
→
1600%
size
→
screen
fit
mode
→
100%
size
Screen
fit
mode:
You
can
change
the
way
the
appears
on
the
screen
when
you're
playing
a
DVD
movie.
Press
3/4
to
select
between
Normal,
Enhanced,
and
Maximum.
3.
Use
the
bBvVbuttons
to
move
through
the
zoomed
picture.
4.
To
resume
normal
playback,
press
CLEAR.
Notes:
?
Zoom
may
not
work
on
some
DVDs.
?
Screen
fit
mode
is
available
for
playing
the
DVD
disc
and
movie
file.
Marker
Search
To
enter
a
Marker
You
can
start
playback
from
up
to
nine
memorized
points.
To
enter
a
marker,
press
MARKER
at
the
desired
point
on
the
disc.
The
Marker
icon
appears
on
the
TV
screen
briefly.
Repeat
to
enter
up
to
nine
markers.
To
Recall
or
Clear
a
Marked
Scene
1.
During
disc
playback,
press
SEARCH.
The
marker
search
menu
appears
on
the
screen.
2.
Within
10
seconds,
press
b
/
B
to
select
a
marker
number
that
you
want
to
recall
or
clear.
3.
Press
ENTER
and
playback
starts
from
the
marked
scene.
Or,
Press
CLEAR
and
the
marker
number
is
erased
from
the
list.
4.
You
can
play
any
marker
by
inputting
its
number
on
the
marker
search
menu.
Pause
1.
Press
PAUSE/STEP
during
playback.
2.
To
return
to
playback,
press
PLAY.
Special
DVD
Features
Checking
the
contents
of
DVD
discs:
Menus
DVDs
may
offer
menus
that
allow
you
to
access
special
features.
To
use
the
disc
menu,
press
DVD
MENU.
Input
the
corresponding
number
or
use
the
bBvVbuttons
to
highlight
your
selection.
Then
press
ENTER.
Title
Menu
1.
Press TITLE.
If
the
current
title
has
a
menu,
the
menu
appears
on
the
screen.
Otherwise,
the
disc
menu
may
appear.
2.
The
menu
offers
features
such
as
camera
angles,
spoken
language
and
subtitle
options,
and
chapters
for
the
title.
3.
Press
TITLE
to
exit.
Disc
Menu
Press
DVD
MENU
and
the
disc
menu
is
displayed.
Press
DVD
MENU
again
to
exit.
Camera
Angle
If
the
disc
contains
scenes
recorded
at
different
camera
angles,
you
can
change
to
a
different
camera
angle
during
playback.
Press
ANGLE
repeatedly
during
playback
to
select
a
desired
angle.
Note
that
the
number
of
the
current
angle
appears
on
the
display.
Tip:
The
angle
indicator
will
blink
on
the
TV
screen
during
scenes
recorded
at
different
angles
as
an
indication
that
angle
switching
is
possible.
Changing
the
Audio
Language
Press
AUDIO
repeatedly
during
playback
to
hear
a
different
audio
language
or
audio
track.
Subtitles
Press
SUBTITLE
repeatedly
during
playback
to
see
the
different
subtitle
languages.
Note:
If
there
is
no
information
or
there
is
a
code
that
can
not
read
in
the
DivX
file,
"
1
"
etc
are
displayed.
21
Operation
DVD
Audio
Discs
DVD
Audio
is
a
new
disc
format
building
on
the
success
of
DVD
to
provide
high
quality,
uncompressed,
multi-channel
audio
for
a
new
experience
in
audio
quality.
A
DVD
Audio
disc
can
be
identified
by
the
DVD
audio
logo
on
the
disc
jacket
or
on
the
disc
itself.
DVD
Audio
can
provide
higher
quality
stereo
than
Audio
CDs
with
a
sampling
rate
of
up
to
192kHz
(compared
to
44.1kHz
for
CDs).
DVD
Audio
digital
sound
can
be
delivered
with
up
to
24
bits
of
data
(compared
to
16
bits
for
a
standard
CD).
A
typical
DVD
Audio
disc
contains
up
to
seven
times
the
data
capacity
of
a
CD.
This
additional
space
is
used
for
music,
either
Advanced
Resolution
multi-
channel
sound
quality
that
is
closer
to
the
artist's
master
recording
or
for
longer
recordings.
Many
DVD
Audio
discs
contain
on-screen
text,
such
as
artist
biographies,
playlists,
or
lyrics.
Some
DVD
Audio
discs
contain
galleries
or
video
clips.
Moving
to
another
GROUP
Some
DVD
Audio
discs
divide
content
into
different
groups.
Your
player
enables
you
to
quickly
access
different
groups
during
playback
via
the
on-screen
display.
1.
Press
DISPLAY
during
playback
on
in
stop
mode.
2.
Press
3/4
to
select
Group
icon.
3.
Press
1/2
or
the
numbered
buttons
(0-9)
to
select
a
group
number.
Note:
Sometimes
the
author
of
the
disc
creates
hidden
content
that
can
only
be
accessed
by
entering
a
password.
If
the
lock icon
appears
on
the
TV
screen,
enter
the
password
(sometimes
you'll
find
it
on
the
disc's
jacket
cover
or
on
a
web
site).
This
password
control
isn't
dictated
by
your
DVD
Player
---
it
is
a
function
of
the
disc.
Since
the
authoring
of
DVD
Audio
Discs
varies,
some
of
the
on-screen
display
choices
might
not
be
available
for
the
disc
you're
playing.
Viewing
another
PAGE
Since
DVD
Audio
discs
can
hold
a
lot
of
content,
there
are
various
ways
to
see
what's
available
on
the
disc.
1.
Press
DISPLAY
during
playback.
2.
Press
3/4
to
select
Page
icon.
3.
Press
1/2
to
select
a
page
number.
What
appears
on
the
screen
will
vary
from
disc
to
disc
because
the
information
available
depends
upon
the
way
the
disc
was
created.
Note:
Since
the
authoring
of
DVD
Audio
Discs
varies,
some
of
the
on-screen
display
choices
might
not
be
available
for
the
disc
you're
playing.
22
Playing
an
Memory
Card
You
can
play
Photo,
Music,
and
MOVIE
files
in
Memory
Cards
with
this
DVD
player.
1.
Insert
a
Memory
Card
until
it
fits
into
place.
2.
Press
MEMORY
CARD
on
the
front
panel.
The
Memory
Card
slot
choice
menu
appears
on
the
TV
screen.
Note:
If
both
slots
are
connected
with
Memory
Card,
use
b
/
B
to
select
the
desired
Memory
Card
slot.
3.
Press
ENTER.
The
menu
appears.
MUSIC
Menu
Menu
MOVIE
Menu
4.
Press
MEMORY
CARD
or
RETURN
to
exit
the
menu.
For
details
on
each
operation
item,
refer
to
relevant
page.
Cards
capable
of
displaying
Readable
Cards
?
Compact
Flash
Card
(CFC)
?M
icro
Drive
(MD)
?
Secure
Digital
Card
(SD)
?
Multi
Media
Card
(MMC)
?M
emory
Stick
(MS)
?M
emory
Stick
Pro
(MS-Pro)
?
eXtreme
Digital
Card
(xD)
-
Compatible
with:
FAT
12,
FAT
16,
or
FAT
32
-
Only
use
the
memory
cards
recommended.
Regarding
Write
Protect
For
cards
that
have
a
write
protect
switch,
if
the
switch
is
on
it
will
not
be
possible
to
write
or
erase
the
contents
of
the
card.
Notes:
?
Keep
the
memory
card
out
of
reach
of
children.
If
swallowed,
seek
medical
advice
immediately.
?
This
player
can
not
format
a
memory
card.
?
If
you
insert
two
memory
cards
simultaneously
into
the
MS,
MMC,
SD,
MS-Pro
and
xD
memory
cards
compatible
slot,
files
in
the
memory
cards
cannot
be
played.
?
The
reading
time
depends
on
file
size
or
resolution.
?
If
a
folder
in
your
memory
cards
have
more
than
645
files,
the
whole
files
are
not
available
to
read.
Caution
Before
you
extract
your
memory
cards,
you
should
press
the
MEMORY
CARD
button
to
display
the
DVD
menu
screen.
Otherwise
you
will
lose
your
data
in
your
memory
card
or
the
memory
card
can
be
damaged.
M/C
1
2
Program
List
0:00:00
Clear
All
PROGRAM
Edit
DISPLAY
Info
MUSIC
Music1
Music2
Music3
Music4
Music5
Preview
List
JPEG
Folder
1
JPEG
Folder 2
JPEG
Folder
3
JPEG
Folder 4
JPEG
Folder
5
>>>
List
Movie
Folder
1
Movie
Folder 2
Movie
Folder
3
MOVIE
0:00:00
23
Operation
Playing
an
Audio
CD
or
MP3/WMA
Disc
The
DVD
player
can
play
MP3/WMA
formatted
recordings
on
CD-ROM,
CD-R,
or
CD-RW
discs.
Audio
CD
Once
you
insert
an
audio
CD
a
menu
appears
on
the
TV
screen.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER
and
playback
starts.
MP3
/
WMA
1.
Press
v
/
V
to
select
a
folder,
and
press
ENTER
to
see
the
folder
contents.
2.
Press
v
/
V
to
select
a
track
then
press
PLAY
or
ENTER.
Playback
starts.
ID3
TAG
?
When
playing
a
file
containing
information
such
as
track
titles,
you
can see
the
information
by
pressing
DISPLAY.
[
Title,
Artist,
Album,
Year,
Comment
]
?
If
there
is
no
information,
"No
ID3
TAG"
appear
on
the
display.
Tips:
?
If
you
are
in
a
file
list
on
the
MUSIC
menu
and
want
to
return
to
the
Folder
list,
use
the
v
/
V
to
highlight
and
press
ENTER.
?
Press
DVD
MENU
to
move
to
the
next
page.
?
On
a
CD
with
MP3/WMA
and
JPEG
you
can
switch
MP3/WMA
and
JPEG.
Press
TITLE
and
MUSIC
or
word
on
top
of
the
menu
is
highlighted.
Program
List
Track1
Track2
Track3
Track4
Track5
Track6
Track7
Track8
AUDIO
CD
0:52:07
1/12
Clear
All
PROGRAM
Edit
Program
List
0:00:00
1/12
Clear
All
PROGRAM
Edit
DISPLAY
Info
MUSIC
2-Music2
1-Music1
3-Music3
4-Music4
5-Music5
6-Music6
7-Music7
MP3
/
WMA
disc
compatibility
with
this
player
is
limited
as
follows:
?
Sampling
frequency:
within
8
-
48
kHz
(MP3),
within
32
-
48kHz
(WMA)
?
Bit
rate:
within
8
-
320kbps
(MP3),
32
-
192kbps
(WMA)
?
The
player
cannot
read
an
MP3/WMA
file
that
has
a
file
extension
other
than
".mp3"
/
".wma".
?
CD-R
physical
format
should
be
ISO
9660
?
If
you
record
MP3
/
WMA
files
using
software
that
cannot
create
a
file
system
(eg.
Direct-CD)
it
is
impossible
to
playback
MP3
/
WMA
files.
We
recommend
that
you
use
Easy-CD
Creator,
which
creates
an
ISO
9660
file
system.
?
File
names
should
have
a
maximum
of
8
letters
and
must
incorporate
an
.mp3
or
.wma
extension.
?
They
should
not
contain
special
letters
such
as
/
?*:"<>letc.
?
The
total
number
of
files
on
the
disc
should
be
less
than
650.
This
DVD
Player
requires
discs
and
recordings
to
meet
certain
technical
standards
in
order
to
achieve
optimal
playback
quality.
Pre-recorded
DVDs
are
automatically
set
to
these
standards.
There
are
many
different
types
of
recordable
disc
formats
(including
CD-R
containing
MP3
or
WMA
files)
and
these
require
certain
pre-existing
conditions
(see
above)
to
ensure
compatible
playback.
Customers
should
note
that
permission
is
required
in
order
to
download
MP3
/
WMA
files
and
music
from
the
Internet.
Our
company
has
no
right
to
grant
such
permission.
Permission
should
always
be
sought
from
the
copyright
owner.
24
Audio
CD
and
MP3
/
WMA
Disc
Features
Pause
1.
Press
PAUSE/STEP
during
playback.
2.
To
return
to
playback,
press
PLAY,
ENTER
or
press
PAUSE/STEP
again.
Moving
to
another
Track
1.
Press
SKIP
(.
or
>)
briefly
during
playback
to
go
to
the
next
track
or
to
return
to
the
beginning
of
the
current
track.
2.
Press
SKIP
.
twice
briefly
to
go
back
to
the
previous
track.
3.
You
can
play
any
track
by
inputting
its
number.
(AUDIO
CD
only)
Repeat
Track/All/Off
You
can
play
a
track/all
on
a
disc.
1.
Press
REPEAT
when
playing
a
disc.
The
repeat
icon
appears.
2.
Press
REPEAT
to
select
a
desired
repeat
mode.
?
Track:
repeats
the
current
track
?
All:
repeats
all
the
tracks
on
a
disc.
?
Off(No
display):
does
not
play
repeatedly.
Note:
If
you
press
SKIP
(>)
once
during
Repeat
Track
playback,
the
repeat
playback
cancels.
Search
1.
Press
SCAN
(m
or
M)
during
playback.
2.
Press
SCAN
(m
or
M)
repeatedly
to
select
the
required
speed:
X2,
X4,
X8
backward
or
forward.
3.
To
exit
SEARCH
mode,
press
PLAY.
Random
1.
Press
RANDOM
during
playback.
Random
Playback
begins
immediately
and
RANDOM
appears
on
the
menu
screen.
2.
To
return
to
normal
playback,
press
RANDOM
repeatedly
until
RANDOM
disappears
from
the
menu
screen.
Tip:
By
pressing
SKIP
>
during
random
playback,
the
unit
selects
another
track
and
resumes
random
playback.
Repeat
A-B
1.
To
repeat
a
sequence
during
disc
playback
press
A-B
at
your
chosen
starting
point.
The
Repeat
icon
and
"A"
appear
on
the
menu
screen.
2.
Press
A-B
again
at
your
chosen
end
point.
The
Repeat
icon
and
"A-B"
appear
on
the
menu
screen,
and
the
sequence
begins
to
play
repeatedly.
3.
To
exit
the
sequence
and
return
to
normal
play,
press
A-B
again.
The
Repeat
icon
disappears
from
the
menu
screen.
3D
Surround
To
produce
a
3D
surround
effect
that
simulates
multi-channel
audio
from
two
stereo
speakers
(instead
of
the
five+
speakers
normally
required
for
multi-channel
audio
from
a
home
theater
system).
1.
Press
AUDIO
during
playback.
"3D
SUR."
appears
on
the
menu
screen.
2.
To
return
to
normal
playback,
press
AUDIO
repeatedly
until
"3D
SUR."
disappears
from
the
menu
screen.
25
Operation
Programmed
Playback
The
program
function
enables
you
to
store
your
favorite
tracks
from
any
disc
in
the
player
memory.
A
program
can
contain
30
tracks.
1.
Insert
a
disc.
Audio
CD
or
MP3/WMA
Discs:
AUDIO
CD
or
MUSIC
menu
appears.
2.
Press
PROGRAM.
The
mark
will
appear
to
the
right
of
the
word
"Program"
on
the
right
side
of
the
menu
screen.
Note:
Press
PROGRAM
again,
then
the
mark
will
disappear
to
exit
the
Program
Edit
mode.
AUDIO
CD
Menu
MUSIC
Menu
Video
CD:
Press
PROGRAM
while
playback
is
stopped.
The
program
menu
appears.
Press
PROGRAM
again
to
exit
the
menu.
Note:
On
a
Video
CD
with
PBC,
you
must
set
PBC
to
Off
on
the
setup
menu
to
use
the
programmed
playback
(See
"PBC"
on
page
16).
VIDEO
CD
Menu
3.
Select
a
track
on
the
"List",
then
press
ENTER
to
place
the
selected
track
on
the
"Program"
list.
Repeat
to
place
additional
tracks
on
the
list.
4.
Press
B.
Select
the
track
you
want
to
start
playing
on
the
"Program"
list.
5.
Press
PLAY
or
ENTER
to
start.
Playback
begins
in
the
order
in
which
you
programmed
the
tracks.
Playback
stops
after
all
of
the tracks
on
the
"Program"
list
have
played
once.
6.
To
resume
normal
playback
from
programmed
playback,
select
a
track
of
AUDIO
CD
(or
MUSIC)
list
and
then
press
PLAY.
Repeat
Programmed
Tracks
1.
Press
REPEAT
when
playing
a
disc.
The
repeat
icon
appears.
2.
Press
REPEAT
to
select
a
desired
repeat
mode.
?
Track:
repeats
the
current
track
?
All:
repeats
all
the
tracks
on
programmed
list.
?
Off(No
display):
does
not
play
repeatedly.
Note:
If
you
press
>
once
during
Repeat
Track
playback,
the
repeat
playback
cancels.
Erasing
a
Track
from
"Program"
List
1.
Use
vVBto
select
the
track
that
you
wish
to
erase
from
the
Program
list.
2.
Press
CLEAR.
Repeat
to
erase
additional
tracks
on
the
list.
Erasing
the
Complete
Program
List
1.
Press
B
to
move
to
the
"Program"
list.
2.
Use
v
/
V
to
select
"Clear
All",
then
press
ENTER.
Note:
The
programs
are
also
cleared
when
the
disc
is
removed.
E
E
Program
List
Tr
ack1
Tr
ack1
Tr
ack4
Tr
ack7
Tr
ack5
Tr
ack2
Tr
ack3
Tr
ack4
Tr
ack5
Tr
ack6
Tr
ack7
Tr
ack8
AUDIO
CD
0:52:07
1/12
Clear
All
PROGRAM
Edit
E
Program
List
Track1
Track1
Track3
Track2
Track5
Track2
Track3
Track4
Track5
Clear
All
E
VIDEO
CD
Program
List
0:00:00
1/12
Clear
All
PROGRAM
Edit
E
MUSIC
DISPLAY
Info
2-Music2
2-Music2
4-Music4
6-Music6
1-Music1
1-Music1
3-Music3
4-Music4
5-Music5
6-Music6
7-Music7
26
Viewing
a
JPEG
Disc
Using
this
DVD
Player
you
can
view
discs
with
JPEG
files.
1.
Insert
a
disc.
The
menu
appears
on
the
TV
screen.
2.
Press
v
/
V
to
select
a
folder,
and
press
ENTER.
A
list
of
files
in
the
folder
appears.
If
you
are
in
a
file
list
and
want
to
return
to
the
previous
Folder
list,
use
the
v
/
V
buttons
on
the
remote
to
highlight
and
press
ENTER.
3.
If
you
want
to
view
a
particular
file,
press
v
/
V
to
highlight
a
file
and
press
ENTER
or
PLAY.
Viewing
the
file
proceeding
starts.
While
viewing
a
file,
you
can
press
STOP
to
move
to
the
previous
menu
(PHOTO
menu).
Tips:
?
Press
DVD
MENU
to
move
to
the
next
page.
?
There
are
three
Slide
Speed
options
:
>>>
(Fast),
>>
(Normal)
and
>
(Slow).
Use
vVbBto
highlight
the
Speed.
Then,
use
b
/
B
to
select
the
option
you
want
to
use
then
press
ENTER.
?
On
a
disc
with
MP3/WMA
and
JPEG
you
can
switch
MP3/WMA
and
JPEG.
Press
TITLE
and
MUSIC
or
word
on
top
of
the
menu
is
highlighted.
?
Press
RETURN,
information
of
file
is
hidden.
Slide
Show
Use
vVbBto
highlight
the
(Slide
Show)
then
press
ENTER.
Still
1.
Press
PAUSE/STEP
during
slide
show.
The
player
will
now
go
into
PAUSE
mode.
2.
To
return
to
the
slide
show,
press
PLAY
or
press
PAUSE/STEP
again.
Moving
to
another
File
Press
SKIP
(.
or
>)
or
cursor
(b
or
B)
once
while
viewing
a
to
advance
to
the
next
or
previous
file.
Zoom
Use
Zoom
to
enlarge
the
image.
(see
page
20)
To
rotate
Press
v
/
V
during
showing
a
to
rotate
the
clockwise
or
counter
clockwise.
To
listen
to
MP3/WMA
music
watching
You
can
display
files
while
listering
to
MP3/WMA
music
files
recorded
on
the
same
disc.
1.
Insert
the
disc
containing
the
two
types
of
file
in
the
player.
2.
Press
TITLE
to
display
menu.
3.
Press
v
/
V
to
select
a
file.
4.
Use
B
to
select
icon
then
press
ENTER.
Playback
starts.
The
playback
will
continue
until
STOP
is
pressed.
Tip:
To
listen
to
only
the
desired
music
watching
picture,
programmed
the
desired
tracks
from
the
"MUSIC"
menu
and
then
proceed
as
above.
Note:
The
files
on
a
memory
card
are
not
available
for this
function.
JPEG
M/C
JPEG
M/C
JPEG
M/C
JPEG
M/C
JPEG
Preview
List
JPEG
Folder
1
JPEG
Folder
2
JPEG
Folder
3
JPEG
Folder
4
JPEG
Folder
5
JPEG
Folder
6
JPEG
Folder
7
JPEG
Folder
8
>>>
JPEG
disc
compatibility
with
this
player
is
limited
as
follows:
?
Depending
upon
the
size
and
number
of
JPEG
files,
it
could
take
a
long
time
for
the
DVD
player
to
read
the
disc's
contents.
If
you
don't
see
an
on-
screen
display
after
several
minutes,
some
of
the
files
may
be
too
large
---
reduce
the
resolution
of
the
JPEG
files
to
less
than
2M
pixels
as
2760
x
2048
pixels
and
burn
another
disc.
?
The
total
number
of
files
and
folders
on
the
disc
should
be
less
than
650.
?
Some
discs
may
be
incompatible
due
to
a
different
recording
format
or
the
condition
of
disc.
?
Ensure
that
all
the
selected
files
have
the
".jpg"
extensions
when
copying
into
the
CD
layout.
?
If
the
files
have
".jpe"
or
".jpeg"
extensions,
please
rename
them
as
".jpg"
file.
?
File
names
without
".jpg"
extension
will
not
be
able
to
be
read
by
this
DVD
Player.
Even
though
the
files
are
shown
as
JPEG
files
in
Windows
Explorer.
27
Maintenance
and
Service
Refer
to
the
information
in
this
chapter
before
contacting
a
service
technician.
Handling
the
Unit
When
shipping
the
unit
Please
save
the
original
shipping
carton
and
packing
materials.
If
you
need
to
ship
the
unit,
for
maximum
protection,
re-pack
the
unit
as
it
was
originally
packed
at
the
factory.
Keeping
the
exterior
surfaces
clean
?
Do
not
use
volatile
liquids
such
as
insecticide
spray
near
the
unit.
?
Do
not
leave
rubber
or
plastic
products
in
contact
with
the
unit
for
a
long
period
of
time.
since
they
leave
marks
on
the
surface.
Cleaning
the
unit
To
clean
the
player,
use
a
soft,
dry
cloth.
If
the
surfaces
are
extremely
dirty,
use
a
soft
cloth
lightly
moistened
with
a
mild
detergent
solution.
Do
not
use
strong
solvents
such
as
alcohol,
benzine,
or
thinner,
as
these
might
damage
the
surface
of
the
unit.
Maintaining
the
Unit
The
DVD
player
is
a
high-tech,
precision
device.
If
the
optical
pick-up
lens
and
disc
drive
parts
are
dirty
or
worn,
the
quality
could
be
diminished.
Depending
on
the
operating
environment,
regular
inspection
and
maintenance
are
recommended
after
every
1,000
hours
of
use.
For
details,
please
contact
your
nearest
authorized
service
center.
28
Playing
a
DivX
Movie
Disc
Using
this
DVD
Player
you
can
play
DivX
disc.
1.
Insert
a
disc.
The
MOVIE
menu
appears
on
the
TV
screen.
2.
Press
v
/
V
to
select
a
folder,
and
press
ENTER.
A
list
of
files
in
the
folder
appears.
If
you
are
in
a
file
list
and
want
to
return
to
the
Folder
list,
use
the
v
/
V
buttons
on
the
remote
to
highlight
and
press
ENTER.
3.
If
you
want
to
view
a
particular
file,
press
v
/
V
to
highlight
a
file
and
press
ENTER
or
PLAY.
4.
Press
STOP
to
exit.
Tips:
?
Press
DVD
MENU
to
move
to
the
next
page.
?
On
a
CD
with
MP3/WMA,
JPEG
and
MOVIE
file,
you
can
switch
MUSIC,
and
MOVIE
menu.
Press
TITLE
and
MUSIC,
and
MOVIE
word
on
top
of
the
menu
is
highlighted.
?
The
disc
subtitle
may
not
be
displayed
properly,
if
a
DivX
subtitle
is
downloaded
through
the
internet.
?
If
the
Disc
Subtitle
setup
menu
does
not
have
the
DivX
subtitile
language
you
are
going
to
play,
the
subtitle
may
not
be
displayed
properly.
Note:
When
the
bitrate
of
video
signal
on
a
DivX
file
stored
in
a
memory
card
is
over
2Mbps,
it
can
be
displayed
like
a
still
image.
List
Movie
Folder
1
Movie
Folder
2
Movie
Folder
3
Movie
Folder
4
Movie
Folder
5
Movie
Folder
6
Movie
Folder
7
Movie
Folder
8
MOVIE
0:00:00
DivX
disc
compatibility
with
this
player
is
limited
as
follows:
?A
vailable
resolution
size
of
the
DivX
file
is
under
720x576
(W
x
H)
pixel.
?
The
file
name
of
the
DivX
subtitle
is
limited
to
characters.
?
If
there
is
impossible
code
to
express
in
the
DivX
file,
it
may
be
displayed
as
"
_
"
mark
on
the
display.
?
If
the
number
of
the
screen
frame
is
over
30
frames
per
second,
this
unit
may
not
operate
normally.
?
If
the
video
and
audio
structure
of
recorded
file
is
not
interleaved,
either
video
or
audio
is
outputted.
?
If
the
file
is
recorded
with
GMC,
the
unit
supports
only
1-point
of
the
record
level.
*
GMC?
GMC
is
the
acronym
for
Global
Motion
Compensation.
It
is
an
encoding
tool
specified
in
MPEG4
standard.
Some
MPEG4
encoders,
like
DivX
or
Xvid,
have
this
option.
There
are
different
levels
of
GMC
encoding,
usually
called
1-point,
2-point,
or
3-point
GMC.
Playable
DivX
file
z
".avi
",
".mpg
",
".mpeg
"
Playable
Subtitle
format
z
SubRip(*.srt/*.txt)
SAMI(*.smi)
SubStation
Alpha(*.ssa/*.txt)
MicroDVD(*.sub/*.txt)
SubViewer
2.0(*.sub/*.txt)
TMPlayer(*.txt)
Dvd
Subtitle
System(*.txt)
VobSub
(*.sub)
b
Sub/idx,
stream
based
format.
Playable
Codec
format
z
"DIVX3.xx
",
"DIVX4.xx
",
"DIVX5.xx
",
"XVID
",
"MP43
",
"3IVX
".
Playable
Audio
format
z
"Dolby
Digital
",
"DTS
",
"PCM
",
"MP3
",
"WMA
".
?
Sampling
frequency:
within
8
-
48
kHz
(MP3),
within
32
-
48kHz
(WMA)
?
Bit
rate:
within
8
-
320kbps
(MP3),
32
-
192kbps
(WMA)
29
Additional
Features
Last
Scene
Memory
This
player
memorizes
last
scene
from
the
last
disc
that
is
viewed.
The
last
scene
remains
in
memory
even
if
you
remove
the
disc
from
the
player
or
switch
off
the
player.
If
you
load
a
disc
that
has
the
scene
memorized,
the
scene
is
automatically
recalled.
Note:
This
player
does
not
memorize
the
scene
of
a
disc
if
you
switch
off
the
player
before
commencing
to
play
the
disc.
The
last
scene
memory
willl
change
once
a
new
disc
is
inserted.
Screen
Saver
The
screen
saver
appears
when
you
leave
the
DVD
player
in
Stop
mode
for
about
five
minutes.
If
the
Screen
Saver
is
displayed
for five
minutes,
the
DVD
Player
automatically
turns
itself
off.
Video
Mode
Setting
?
With
certain
discs,
the
playback
may
be
flickering
or
Dot
Crawl
is
shown
on
straight
lines.
That
means
Vertical
interpolation
or
De-interlace
is
not
perfectly
matched
with
the
disc.
In
this
case,
the
quality
may
be
improved
by
changing
the
video
mode.
?
To
change
the
video
mode,
press
and
hold
DISPLAY
about
3
seconds
during
disc
playback.
The
new
video
mode
number
selected
is
displayed
on
the
TV
screen.
Check
whether
the
video
quality
has
improved.
If
not,
repeat
the
above
procedure
until
quality
is
improved.
?
Video
mode
change
sequence:
MODE1
→
MODE2
→
MODE3
→
MODE1
?
If
you
turn
off
the
power,
the
video
mode
will
revert
back
to
the
initial
state
(MODE1).
Detailed
Descriptions
for
Video
Modes
MODE1:
The
source
material
of
the
DVD
video
(film
material
or
video
material)
is
determined
from
disc
information.
MODE2:
Suitable
for
playing
film
based
content
or
video
based
material
recorded
by
the
progressive
scan
method.
MODE3:
Suitable
for
playing
video
based
content
with
comparatively
little
motion.
Note:
The
video
mode
setting
only
works
in
progressive
scan
mode
(
720p
or
480p).
30
Reference
You
can
control
the
sound
level,
input
source,
and
power
switch
of
your
LG
TV
with
the
supplied
remote.
You
can
control
your
TV
using
the
buttons
below.
By
pressing
You
can
POWER
Turn
the
TV
on
or
off.
AV
Switch
the
TV's
input
source
between
the
TV
and
other
input
sources.
PR/CH
+/--
Scans
up
or
down
through
memorized
channels.
VOL
+/--
Adjust
the
volume
of
the
TV.
Note:
Depending
on
the
unit
being
connected,
you
may
not
be
able
to
control
your
TV
using
some
of
the
buttons.
Controlling
other
TVs
with
the
remote
You
can
control
the
sound
level,
input
source,
and
power
switch
of
non-LG
TVs
as
well.
If
your
TV
is
listed
in
the
table
below,
set
the
appropriate
manufacturer
code.
1.
While
holding
down
TV
POWER
button,
press
the
number
buttons
to
select
the
manufacturer
code
for
your
TV
(Refer
to
table
on
the
right
column).
2.
Release
TV
POWER
button.
Code
numbers
of
controllable
TVs
If
more
than
one
code
number
is
listed,
try
entering
them
one
at
a
time
until
you
find
the
one
that
works
with
your
TV.
Notes:
?
Depending
on
your
TV,
some
or
all
buttons
may
not
function
on
the
TV,
even
after
entering
the
correct
manufacturer
code.
?
If
you
enter
a
new
code
number,
the
code
number
previously
entered
will
be
erased.
?
When
you
replace
the
batteries
of
the
remote,
the
code
number
you
have
set
may
be
reset
to
the
default
setting.
Set
the
appropriate
code
number
again.
TV
Control
Buttons
Manufacturer
Code
Number
ADMIRAL
16,33,37,44,45
AIWA
70
AKAI
01
AMARK
09
AOC
01
BELL
&
HOWELL
33
BROKSONIC
18,19
CANDLE
51
CCE
07
CENTURION
08
CINERAL
43
CITIZEN
49,50,51,52,53,54,55
CORONADO
09
CROWN
09
CURTIS
MATHES
01,03,08,33,35,37,44
DAEWOO
16,38,39,40,41,42,43
DAYTRON
01,08
EMERSON
01,09,16,17,18,19
FISHER
28,29
FUNAI
46,47
GENERAL
ELECTRIC
03,10,11,13,37,44
GRADIENTE
01,56,57,63,67
HITACHI
09,14,15,43
JC
PENNEY
01,08,10,27,35
JVC
20,21,63,67
KIOTE
43
KMC
09
KTV
01,08,09,31
LG
(GOLDSTAR)
01,07,08,09,35,39,40
LODGENET
33
LOGIK
33
LXI
09,24,25,26,27,28,29
MAGNAVOX
01,02,04,05,06,
07,08,09,20,
34,35,43,51,61,62,65
MAJESTIC
33
MARANTZ
01,32
MEMOREX
33
MGA/MITSUBISHI
01,08,32,34
Manufacturer
Code Number
MONTGOMERY
01,06,08,09
WARD
23,24,32,33,34
NEC
01,08
NOBLEX
07
PACKARD
BELL
43
PANASONIC
07,11,13,25,35,36
PHILCO
01,06,07,08,09,
15,38,43,58
PHILIPS
06,07,43,61,62,65
PIONEER
30
PORTLAND
09
PROSCAN
03,37,44
QUASAR
11,13
RADIO
SHACK
16,17,23
RCA
01,03,37,44,69
REALISTIC
16,17,23
SAMPO
08
SAMSUNG
01,08,09,25,68
SANYO
28,29
SCOTT
01,08
SEARS
09,25,26,27,28,29
SEMP
64
SHARP
09,22,23,24,60,66
SIGNATURE
2000
01,06,08,09,10,
23,24,33,34
SONY
12,62
SOUNDESIGN
51
SYLVANIA
01,04,05,06,07,
08,35,51
SYMPHONIC
46,47
TATUNG
11
TEKNIKA
07,09,16,33,51
TELERENT
09,33
THOMSON
69
YORX
08
TOSHIBA
01,25,26,27,64
WARDS
01,06,08,09,10,33,34
XR1000
48
ZENITH
01,
02,33,59
Controlling
Your
TV
with
the
Supplied
Remote
31
Area
Code
Afghanistan
AF
Argentina
AR
Australia
AU
Austria
AT
Belgium
BE
Bhutan
BT
Bolivia
BO
Brazil
BR
Cambodia
KH
Canada
CA
Chile
CL
China
CN
Colombia
CO
Congo
CG
Costa
Rica
CR
Croatia
HR
Czech
Republic
CZ
Denmark
DK
Ecuador
EC
Egypt
EG
El
Salvador
SV
Area
Code
Ethiopia
ET
Fiji
FJ
Finland
FI
France
FR
Germany
DE
Great
Britain
GB
Greece
GR
Greenland
GL
Heard
and
McDonald
Islands
HM
Hong
Kong
HK
Hungary
HU
India
IN
Indonesia
ID
Israel
IL
Italy
IT
Jamaica
JM
Japan
JP
Kenya
KE
Kuwait
KW
Libya
LY
Luxembourg
LU
Area
Code
Malaysia
MY
Maldives
MV
Mexico
MX
Monaco
MC
Mongolia
MN
Morocco
MA
Nepal
NP
Netherlands
NL
Netherlands
Antilles
AN
New
Zealand
NZ
Nigeria
NG
Norway
NO
Oman
OM
Pakistan
PK
Panama
PA
Paraguay
PY
Philippines
PH
Poland
PL
Portugal
PT
Romania
RO
Russian
Federation
RU
Area
Code
Saudi
Arabia
SA
Senegal
SN
Singapore
SG
Slovak
Republic
SK
Slovenia
SI
South
Africa
ZA
South
Korea
KR
Spain
ES
Sri
Lanka
LK
Sweden
SE
Switzerland
CH
Thailand
TH
Taiwan
TW
Turkey
TR
Uganda
UG
Ukraine
UA
United
States
US
Uruguay
UY
Uzbekistan
UZ
Vietnam
VN
Zimbabwe
ZW
Area
Codes
Choose
an area
code
from
this
list.
Language
Code
Abkhazian
6566
Afar
6565
Afrikaans
6570
Albanian
8381
Ameharic
6577
Arabic
6582
Armenian
7289
Assamese
6583
Aymara
6588
Azerbaijani
6590
Bashkir
6665
Basque
6985
Bengali;
Bangla
6678
Bhutani
6890
Bihari
6672
Breton
6682
Bulgarian
6671
Burmese
7789
Byelorussian
6669
Cambodian
7577
Catalan
6765
Chinese
9072
Corsican
6779
Croatian
7282
Czech
6783
Danish
6865
Dutch
7876
English
6978
Esperanto
6979
Estonian
6984
Faroese
7079
Language
Code
Fiji
7074
Finnish
7073
French
7082
Frisian
7089
Galician
7176
Georgian
7565
German
6869
Greek
6976
Greenlandic
7576
Guarani
7178
Gujarati
7185
Hausa
7265
Hebrew
7387
Hindi
7273
Hungarian
7285
Icelandic
7383
Indonesian
7378
Interlingua
7365
Irish
7165
Italian
7384
Japanese
7465
Javanese
7487
Kannada
7578
Kashmiri
7583
Kazakh
7575
Kirghiz
7589
Korean
7579
Kurdish
7585
Laothian
7679
Latin
7665
Latvian,
Lettish
7686
Language
Code
Lingala
7678
Lithuanian
7684
Macedonian
7775
Malagasy
7771
Malay
7783
Malayalam
7776
Maltese
7784
Maori
7773
Marathi
7782
Moldavian
7779
Mongolian
7778
Nauru
7865
Nepali
7869
Norwegian
7879
Oriya
7982
Panjabi
8065
Pashto,
Pushto
8083
Persian
7065
Polish
8076
Portuguese
8084
Quechua
8185
Rhaeto-Romance
8277
Rumanian
8279
Russian
8285
Samoan
8377
Sanskrit
8365
Scots
Gaelic
7168
Serbian
8382
Serbo-Croatian
8372
Shona
8378
Sindhi
8368
Language
Code
Singhalese
8373
Slovak
8375
Slovenian
8376
Somali
8379
Spanish
6983
Sudanese
8385
Swahili
8387
Swedish
8386
Tagalog
8476
Tajik
8471
Tamil
8465
Tatar
8484
Telugu
8469
Thai
8472
Tibetan
6679
Tigrinya
8473
Tonga
8479
Turkish
8482
Turkmen
8475
Twi
8487
Ukrainian
8575
Urdu
8582
Uzbek
8590
Vietnamese
8673
Volapuk
8679
Welsh
6789
Wolof
8779
Xhosa
8872
Yiddish
7473
Yoruba
8979
Zulu
9085
Language
Codes
Use
this
list
to
input
your
desired
language
for
the
following
initial
settings:
Disc
Audio,
Disc
Subtitle,
Disc
Menu.
32
Symptom
No
power.
The
power
is
on,
but
the
DVD
player
does
not
work.
No
picture.
No
sound.
The
DVD
player
does
not
start
playback.
The
Remote
Control
does
not
work
properly.
Possible
Cause
?
The
power
cord
is
disconnected.
?
No
disc
is
inserted.
?
The
TV
is
not
set
to
receive
DVD
signal
output.
?
The
video cable
is
not
connected
securely.
?
Unit
output
setting
and
TV
resolution
capabilities
mismatch.
?
The
equipment
connected
with
the
audio
cable
is
not
set
to
receive
DVD
signal
output.
?
The
power
of
the
equipment
connected
with
the
audio
cable
is
turned
off.
?
The
AUDIO
options
are
set
to
the
wrong
position.
?
The
Digital
Audio
Output
mismatch
with
the
amplifier.
?
An
unplayable
disc
is
inserted.
?
The
rating
level
is
set.
?
The
Remote
Control
is
not
pointed
at
the
remote
sensor on
the
DVD
player.
?
The
Remote
Control
is
too
far
from
the
DVD
player.
Correction
?
Plug
the
power
cord
into
the
wall
outlet
securely.
?
Insert
a
disc.
(Check
that
the
DVD
or
audio
CD
indicator
in
the
display
window
is
lit.)
?
Select
the
appropriate
video
input
mode
on
the
TV.
?
Connect
the
video cable
securely.
?
Check
TV
capability.
?
Check
mode
of
connections
(eg.
S-Video,
Component
etc.).
?
Check
unit
Resolution
setting
according
to
TV
capability
and
mode
of
connection.
?
Select
the
correct
input
mode
of
the
audio
receiver
so
you
can
listen
to
the
sound
from
the
DVD
player.
?T
urn
on
the
equipment
connected
with
the
audio
cable.
?
Set
the
Digital
Audio
Output
to
the
correct
position,
then
turn
on
the
DVD
player
again
by
pressing
POWER.
?
Select
the
proper
audio
setting
in
AUDIO
setup.
?
Insert
a
playable
disc.
(Check
the
disc
type,
color
system,
and
regional
code.)
?
Cancel
the
rating
function
or
change
the
rating
level.
?
Point
the
Remote
Control
at
the
remote
sensor
of
the
DVD
player.
?
Operate
the
Remote
Control
closer
to
the
DVD
player.
Tr
oubleshooting
This
LG
Electronics
product,
will
be
repaired
or
replaced,
at
LG's
option,
if
it
proves
to
be
defective
in
material
or
workmanship,
under
normal
use,
during
the
warranty
period
("Warranty
Period")
listed
below,
effective
from
the
date
("Date
of
Purchase")
of
original
consumer
purchase
of
the
product.
This
warranty
is
good
only
to
the
original
purchaser
of
the
product
and
effective
only
when
used
in
the
United
States,
excluding
U.S.
Territories.
THIS
WARRANTY
IS
IN
LIEU
OF
ANY
OTHER
WARRANTIES,
EXPRESS
OR
IMPLIED,
INCLUDING
WITHOUT
LIMITATION,
ANY
WARRANTY
OF
MERCHANTABILITY
OR
FITNESS
FOR
A
PARTICULAR
PURPOSE.
TO
THE
EXTENT
ANY
IMPLIED
WARRANTY
IS
REQUIRED
BY
LAW,
IT
IS
LIMITED
IN
DURATION
TO
THE
EXPRESS
WARRANTY
PERIOD
ABOVE.
LG
ELECTRONICS
WILL
NOT
BE
LIABLE
FOR
ANY
INCIDENTAL,
CONSEQUENTIAL,
INDIRECT,
SPECIAL
OR
PUNITIVE
DAMAGES
OF
ANY
NATURE,
EVEN
IF
ADVISED
OF
THE
POSSIBILITY
OF
SUCH
DAMAGES,
INCLUDING
WITHOUT
LIMITATION,
LOST
REVENUES
OR
PROFITS,
LOST
OR
CORRUPTED
PROGRAMMING
OR
DATA,
OR
ANY
OTHER
DAMAGE
WHETHER
BASED
IN
CONTRACT,
TORT
OR
OTHERWISE.
Some
states
do
not
allow the
exclusion
or
limitation
of
incidental
or
consequential
damages
or
limitation
on
how
long
an
implied
warranty
lasts,
so
the
above
exclusion
or
limitation
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
rights
and
you
may
also
have
other
rights
that
may
vary
from
state
to
state.
THIS
LIMITED
WARRANTY
DOES
NOT
APPLY
TO:
?
Damages
or
operating
problems
that
result
from
shipping,
installation,
adjustment
of
user
controls,
calibration,
maintenance
or
failure
to
maintain,
or
separate
system
components;
and
?
Damages
or
operating
problems
that
result
from
normal
wear
and
tear,
misuse,
abuse,
operation
outside
environmental
specifications
or
contrary
to
the
requirements
or
precautions
in
the
Operating
Guide,
accident,
lightning
strikes
or
other
natural
causes,
unauthorized
modification
or
alteration,
incorrect
electrical
current
or
voltage,
signal
reception
or
input,
software
not
licensed
directly
by
LG,
software
errors
that
do
not
disable
functionality,
operating
and
software
protocols
adopted
after
the
date
of
manufacture
or
for
outside
the
US,
institutional
or
commercial
use,
or
other
causes
not
arising
out
of
defect
in
material
or
workmanship.
The
cost
of
repair
or
replacement
under
these
excluded
circumstances
shall
be
borne
by
the
consumer.
CUSTOMER
INTER-ACTIVE
CENTER
NUMBERS:
WARRANTY
PERIOD:
LABOR:
90
days
from
the
Date
of
Purchase.
PARTS:
One
Year
from
the
Date
of
Purchase.
*
Parts
replaced
are
warranted
for
the
remaining
portion
of
the
original
warranty
period.
HOW
SERVICE
IS
HANDLED:
Call
1-800-243-0000
for
instructions
on
getting
the
defective
unit
repaired
or
replaced.
Please
retain
dated
sales
receipt
and
your
box
to
return
the
unit
to
LG
for
repair
or
replacement.
Shipping
both
ways
will
be
paid
by
LG
during
the
first
90
days
of
the
Warranty
Period.
During
the
remainder
of
the
Warranty
Period
(91~365
days),
you pay
inbound
shipping
charges
and
LG
pays
return
shipping
charges.
Visit
our
website
at:
http://www.lgservice.com
For
Warranty
Service,
Where
to
buy,
Product
Assistance,
or
Customer
Assistance
Call
1-800-243-0000
(24
hours
a
day,
365
days
per
year)
and
select
appropriate
options
from
the
menu.
Or
visit
our
website
at
http://www.lgservice.com
LG
ELECTRONICS
U.S.A.,
INC.
1000
SYLVAN
AVENUE
ENGLEWOOD
CLIFFS,
NJ
P/N
:
3834RD0068W
Issue
O
Printed
in
China
