1
EN Operating instructions
2 3
INSTALLATION
PRIOR TO CONNECTING
• Position the oven at a distance from
otherheatingsources.Forsufcient
ventilation there must be a space of
at least 30 cm above the oven.
• The microwave oven should not be
placed in a cabinet. This oven is not
intended to be placed or used on a
working surface lower than 850 mm
abovetheoor.
• Check that the voltage on the rating plate
corresponds to the voltage in your home.
• Place the oven on a stable, even surface that
is strong enough to hold the oven and the food
utensils you put in it. Use care when handling.
• Ensure that the space underneath,above and
around the oven is empty to allow for proper
airow.
• Ensure that the appliance is not damaged.
Checkthattheovendoorclosesrmlyagainst
the door support and that the internal door seal
is not damaged. Empty the oven and clean the
interior with a soft, damp cloth.
• Do not operate this appliance if it has a
damaged mains cord or plug, if it is not working
properly, or if it has been damaged or dropped.
Do not immerse the mains cord or plug in
water. Keep the cord away from hot surfaces.
Electricalshock,reorotherhazardsmay
result.
• Do not use extension cord: If the power supply
cordistooshort,haveaqualiedelectricianor
serviceman install an outlet near the appliance.
• WARNING:Improper use of the grounding plug
can result in a risk of electric shock.
• Consultaqualiedelectricianorservicemanif
the grounding instructions are not completely
understood, or if you have doubt as to whether
the microwave oven is properly grounded.
• Priortousingthemicrowaveforthersttime,it
isrecommendedtoremovetheprotectivelm
from the control panel and the cable tie from the
power cord.
AFTER CONNECTING
• The oven can be operated only if the oven door
isrmlyclosed.
• Poor television reception and radio interference
may result if the oven is located close to a TV,
radio or aerial.
• The earthing of this appliance is compulsory.
The manufacturer will accept no responsibility
for injury to persons, animals or damage to
objects arising from the non-observance of this
requirement.
• The manufacturers are not liable for any
problems caused by the users failure to observe
these instructions.
IMPORTANT SAFETY INSTRUCTIONS
• READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE
• If material inside / outside the oven
should ignite or smoke is emitted,
keep oven door closed and turn the
oven off. Disconnect the power cord
or shut off power at the fuse or circuit
breaker panel.
• Do not leave the oven unattended,
especially when using paper, plastic
or other combustible materials in the
cooking process. Paper can char or
burn and some plastics can melt if
used when heating foods.
• WARNING: The appliance and its
accessible parts become hot during
use.Care should be taken to avoid
touching heating elments inside the
oven.
Children less then 8 years of
age shall be kept away unless
continuously supervised.
• The Microwave oven is intended for
heating food and beverages. Drying
of food or clothing and heating of
warming pads, slippers, sponges,
damp cloth and similar may lead to
riskofinjury,ignitionorre.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazardsinvolved.Cleaninganduser
maintenance shall not be made by
children unless they are aged from 8
years and above and supervised.
• Children should be supervised to
ensure that they do not play with the
appliance. Keep the appliance and
its cord out of reach of children less
than 8 years.
• WARNING: Do not use your
microwave oven for heating
anything in airtight sealed
containers. The pressure increases
and may cause damage when
opening or may explode.
• WARNING: The door seals and the
door seal areas must be regularly
inspected for damage. If these
areas are damaged the appliance
should not be operated until it has
been repaired by a trained service
technician.
• Do not use your microwave oven
for cooking or reheating whole eggs
with or without shell since they
may explode even after microwave
heating has ended.
• The appliances are not intended
to be operated by means of an
external timer or separate remote-
control system.
• Do not leave the oven unattended if you are
using a lot of fat or oil since they can overheat
andcauseare!
• Donotheat,oruseammablematerialsinor
neartheoven.Fumescancreatearehazard
or explosion.
• Do not use your microwave oven for drying
textiles,paper,spices,herbs,wood,owersor
other combustible materials. Fire could result.
• Do not use corrosive chemicals or vapors in
thisappliance.Thistypeofovenisspecically
designed to heat or cook food. It is not designed
for industrial or laboratory use.
• Do not hang or place heavy items on the door as
this can damage the oven opening and hinges.
The door handle should not be used for hanging
things on.
TROUBLE SHOOTING GUIDE
If the oven does not work, do not make a service call
until you have made the following checks:
• The Plug is properly inserted in the wall socket.
• The Door is properly closed.
• Check your Fuses and ensure that there is
power available.
• Check that the oven has ample ventilation.
• Wait for 10 minutes, then try to operate the oven
once more.
• Open and then close the door before you try
again.
2 3
INSTALLATION
PRIOR TO CONNECTING
• Position the oven at a distance from
otherheatingsources.Forsufcient
ventilation there must be a space of
at least 30 cm above the oven.
• The microwave oven should not be
placed in a cabinet. This oven is not
intended to be placed or used on a
working surface lower than 850 mm
abovetheoor.
• Check that the voltage on the rating plate
corresponds to the voltage in your home.
• Place the oven on a stable, even surface that
is strong enough to hold the oven and the food
utensils you put in it. Use care when handling.
• Ensure that the space underneath,above and
around the oven is empty to allow for proper
airow.
• Ensure that the appliance is not damaged.
Checkthattheovendoorclosesrmlyagainst
the door support and that the internal door seal
is not damaged. Empty the oven and clean the
interior with a soft, damp cloth.
• Do not operate this appliance if it has a
damaged mains cord or plug, if it is not working
properly, or if it has been damaged or dropped.
Do not immerse the mains cord or plug in
water. Keep the cord away from hot surfaces.
Electricalshock,reorotherhazardsmay
result.
• Do not use extension cord: If the power supply
cordistooshort,haveaqualiedelectricianor
serviceman install an outlet near the appliance.
• WARNING:Improper use of the grounding plug
can result in a risk of electric shock.
• Consultaqualiedelectricianorservicemanif
the grounding instructions are not completely
understood, or if you have doubt as to whether
the microwave oven is properly grounded.
• Priortousingthemicrowaveforthersttime,it
isrecommendedtoremovetheprotectivelm
from the control panel and the cable tie from the
power cord.
AFTER CONNECTING
• The oven can be operated only if the oven door
isrmlyclosed.
• Poor television reception and radio interference
may result if the oven is located close to a TV,
radio or aerial.
• The earthing of this appliance is compulsory.
The manufacturer will accept no responsibility
for injury to persons, animals or damage to
objects arising from the non-observance of this
requirement.
• The manufacturers are not liable for any
problems caused by the users failure to observe
these instructions.
IMPORTANT SAFETY INSTRUCTIONS
• READ CAREFULLY AND KEEP
FOR FUTURE REFERENCE
• If material inside / outside the oven
should ignite or smoke is emitted,
keep oven door closed and turn the
oven off. Disconnect the power cord
or shut off power at the fuse or circuit
breaker panel.
• Do not leave the oven unattended,
especially when using paper, plastic
or other combustible materials in the
cooking process. Paper can char or
burn and some plastics can melt if
used when heating foods.
• WARNING: The appliance and its
accessible parts become hot during
use.Care should be taken to avoid
touching heating elments inside the
oven.
Children less then 8 years of
age shall be kept away unless
continuously supervised.
• The Microwave oven is intended for
heating food and beverages. Drying
of food or clothing and heating of
warming pads, slippers, sponges,
damp cloth and similar may lead to
riskofinjury,ignitionorre.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazardsinvolved.Cleaninganduser
maintenance shall not be made by
children unless they are aged from 8
years and above and supervised.
• Children should be supervised to
ensure that they do not play with the
appliance. Keep the appliance and
its cord out of reach of children less
than 8 years.
• WARNING: Do not use your
microwave oven for heating
anything in airtight sealed
containers. The pressure increases
and may cause damage when
opening or may explode.
• WARNING: The door seals and the
door seal areas must be regularly
inspected for damage. If these
areas are damaged the appliance
should not be operated until it has
been repaired by a trained service
technician.
• Do not use your microwave oven
for cooking or reheating whole eggs
with or without shell since they
may explode even after microwave
heating has ended.
• The appliances are not intended
to be operated by means of an
external timer or separate remote-
control system.
• Do not leave the oven unattended if you are
using a lot of fat or oil since they can overheat
andcauseare!
• Donotheat,oruseammablematerialsinor
neartheoven.Fumescancreatearehazard
or explosion.
• Do not use your microwave oven for drying
textiles,paper,spices,herbs,wood,owersor
other combustible materials. Fire could result.
• Do not use corrosive chemicals or vapors in
thisappliance.Thistypeofovenisspecically
designed to heat or cook food. It is not designed
for industrial or laboratory use.
• Do not hang or place heavy items on the door as
this can damage the oven opening and hinges.
The door handle should not be used for hanging
things on.
TROUBLE SHOOTING GUIDE
If the oven does not work, do not make a service call
until you have made the following checks:
• The Plug is properly inserted in the wall socket.
• The Door is properly closed.
• Check your Fuses and ensure that there is
power available.
• Check that the oven has ample ventilation.
• Wait for 10 minutes, then try to operate the oven
once more.
• Open and then close the door before you try
again.
4 5
This is to avoid unnecessary calls for which you will
be charged.
When calling for Service, please give the serial
number and type number of the oven (see Service
label).
Consult your warranty booklet for further advice.
If the mains cord needs replacing it
should be replaced by the original mains
cord, which is available via our service
organization.Themainscordmust
only be replaced by a trained service
technician.
WARNING: Service only to be carried
out by a trained service technician. It
ishazardousforanyoneotherthana
trained person to carry out any service
or repair operation, Which involves
the removal of any cover, which
gives protection against exposure to
microwave energy.
Do not remove any cover.
PRECAUTIONS
GENERAL
• This appliance is intended
to be used in household and
similar applications such as :
-Staffkitchenareasinshops,ofce
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential environments;
- Bed and breakfast type environments.
No other use is permitted (e.g.heating
rooms).
• The appliance should not be operated without
food in the oven when using microwaves.
Operation in this
manner is likely to damage the appliance.
• The ventilation openings on the oven must not
be covered. Blocking the air intake or exhaust
vents may cause damage to the oven and poor
cooking results.
WARNING : Liquids must not be heated in
sealed containers.
LIQUIDS
e.g. beverages or water. Overheating
the liquid beyond boiling point can
occur without evidence of bubbling. This
could result in a sudden boil over of the
hot Liquid.
To prevent this possibility the following steps should
be taken:
1. Avoid using straight-sided containers with
narrow necks.
2. Stir the liquid before placing the container in the
oven.
3. After heating, allow standing for a short time,
stirring again before carefully removing the
container from the oven.
• If you practice operating the oven, put a glass
of water inside. The water will absorb the
microwave energy and the oven will not be
damaged.
• Do not store or use this appliance outdoors.
• Do not use this product near a kitchen sink, in
a wet basement, or near a swimming pool, or
similar.
• Do not use the cavity for any storage purposes.
• Remove wire twist-ties from paper or plastic
bags before placing bag in the oven.
• Do not use your microwave oven for deep-
frying, because the oil temperature cannot be
controlled.
• Use hot pads or oven mitts to prevent burns,
when touching containers, oven parts, and pan
after cooking.
CAREFUL
• After heating baby food or liquids
in a baby bottle or in a baby food
jar, always stir and check the
temperature before serving. This
will ensure that the heat is evenly
distributed and the risk of scalding
or burns can be avoided.
• Always refer to a microwave cookbook for
details. Especially, if cooking or reheating food
that contains alcohol.
• Ensure the Lid and the Teat is removed before
heating!
ACCESSORIES
GENERAL
There are a number of accessories
available on the market. Before you
buy, ensure they are suitable for
microwave use.
Ensure that the utensils you use are oven proof
and allow microwaves to pass through them before
cooking.
When you put food and accessories in the microwave
oven, ensure that they do not come in contact with
the interior of the oven.
This is especially important with accessories made of
metal or metal parts.
If accessories containing metal comes into contact
with the oven interior, while the oven is in operation,
sparking can occur and the oven could be damaged.
Metallic containers for food and beverage are not
allowed during microwave cooking.
WIRE RACK
•UsetheWirerackwithGrill&Combi
Microwave+Grill functions.
MAINTENANCE & CLEANING
Failure to maintain the oven in
a clean condition could lead to
deterioration of the surface that
could adversely affect the life of the
appliance and possibly result in a
hazardoussituation.
Do not use metal scouring pads,
abrasive cleansers, steel-wool pads,
gritty washcloths, etc. which can
damage the control panel, and the
interior and exterior oven surfaces.
Use a cloth with a mild detergent or a
paper towel with spray glass cleaner.
Apply spray glass cleaner to a paper
towel.
Use a soft and damp cloth with
mild detergent to clean the interior
surfaces, front and rear of the door
and the door opening.
Do not use steam cleaning
appliances when cleaning your
microwave oven.The oven should
be cleaned regularly and any food
deposits removed.
Cleaning is the only maintenance normally required.
It must be carried out with the microwave oven
disconnected.
Do not spray directly on the oven.This oven is
designed to operate without the turntable in place.
Do not allow grease or food particles to build up
around the door.
This product offers an AUTO CLEAN
function,which allows for easy
cleaning of the microwave cavity.
For more details,please refer to the
AUTO CLEAN section on page 22.
The Grill element does not need cleaning since the
intense heat will burn off any splashes, but the ceiling
beneath it may need regular cleaning. This should be
done with a soft and damp cloth with mild detergent.
If the Grill is not used regularly, it should be run for 10
minutes a month to burn off any splashes, in order to
reduce the risk of fire.
4 5
This is to avoid unnecessary calls for which you will
be charged.
When calling for Service, please give the serial
number and type number of the oven (see Service
label).
Consult your warranty booklet for further advice.
If the mains cord needs replacing it
should be replaced by the original mains
cord, which is available via our service
organization.Themainscordmust
only be replaced by a trained service
technician.
WARNING: Service only to be carried
out by a trained service technician. It
ishazardousforanyoneotherthana
trained person to carry out any service
or repair operation, Which involves
the removal of any cover, which
gives protection against exposure to
microwave energy.
Do not remove any cover.
PRECAUTIONS
GENERAL
• This appliance is intended
to be used in household and
similar applications such as :
-Staffkitchenareasinshops,ofce
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential environments;
- Bed and breakfast type environments.
No other use is permitted (e.g.heating
rooms).
• The appliance should not be operated without
food in the oven when using microwaves.
Operation in this
manner is likely to damage the appliance.
• The ventilation openings on the oven must not
be covered. Blocking the air intake or exhaust
vents may cause damage to the oven and poor
cooking results.
WARNING : Liquids must not be heated in
sealed containers.
LIQUIDS
e.g. beverages or water. Overheating
the liquid beyond boiling point can
occur without evidence of bubbling. This
could result in a sudden boil over of the
hot Liquid.
To prevent this possibility the following steps should
be taken:
1. Avoid using straight-sided containers with
narrow necks.
2. Stir the liquid before placing the container in the
oven.
3. After heating, allow standing for a short time,
stirring again before carefully removing the
container from the oven.
• If you practice operating the oven, put a glass
of water inside. The water will absorb the
microwave energy and the oven will not be
damaged.
• Do not store or use this appliance outdoors.
• Do not use this product near a kitchen sink, in
a wet basement, or near a swimming pool, or
similar.
• Do not use the cavity for any storage purposes.
• Remove wire twist-ties from paper or plastic
bags before placing bag in the oven.
• Do not use your microwave oven for deep-
frying, because the oil temperature cannot be
controlled.
• Use hot pads or oven mitts to prevent burns,
when touching containers, oven parts, and pan
after cooking.
CAREFUL
• After heating baby food or liquids
in a baby bottle or in a baby food
jar, always stir and check the
temperature before serving. This
will ensure that the heat is evenly
distributed and the risk of scalding
or burns can be avoided.
• Always refer to a microwave cookbook for
details. Especially, if cooking or reheating food
that contains alcohol.
• Ensure the Lid and the Teat is removed before
heating!
ACCESSORIES
GENERAL
There are a number of accessories
available on the market. Before you
buy, ensure they are suitable for
microwave use.
Ensure that the utensils you use are oven proof
and allow microwaves to pass through them before
cooking.
When you put food and accessories in the microwave
oven, ensure that they do not come in contact with
the interior of the oven.
This is especially important with accessories made of
metal or metal parts.
If accessories containing metal comes into contact
with the oven interior, while the oven is in operation,
sparking can occur and the oven could be damaged.
Metallic containers for food and beverage are not
allowed during microwave cooking.
WIRE RACK
•UsetheWirerackwithGrill&Combi
Microwave+Grill functions.
MAINTENANCE & CLEANING
Failure to maintain the oven in
a clean condition could lead to
deterioration of the surface that
could adversely affect the life of the
appliance and possibly result in a
hazardoussituation.
Do not use metal scouring pads,
abrasive cleansers, steel-wool pads,
gritty washcloths, etc. which can
damage the control panel, and the
interior and exterior oven surfaces.
Use a cloth with a mild detergent or a
paper towel with spray glass cleaner.
Apply spray glass cleaner to a paper
towel.
Use a soft and damp cloth with
mild detergent to clean the interior
surfaces, front and rear of the door
and the door opening.
Do not use steam cleaning
appliances when cleaning your
microwave oven.The oven should
be cleaned regularly and any food
deposits removed.
Cleaning is the only maintenance normally required.
It must be carried out with the microwave oven
disconnected.
Do not spray directly on the oven.This oven is
designed to operate without the turntable in place.
Do not allow grease or food particles to build up
around the door.
This product offers an AUTO CLEAN
function,which allows for easy
cleaning of the microwave cavity.
For more details,please refer to the
AUTO CLEAN section on page 22.
The Grill element does not need cleaning since the
intense heat will burn off any splashes, but the ceiling
beneath it may need regular cleaning. This should be
done with a soft and damp cloth with mild detergent.
If the Grill is not used regularly, it should be run for 10
minutes a month to burn off any splashes, in order to
reduce the risk of fire.
6 7
CONTROL PANEL DESCRIPTION
10
11
1
3
4
5
6
7
8
9
2
Microwave button
Defrost Menu buttons
Auto Cook Menu button
Clock button
Silent Mode button
Auto Clean button
Knob
Ok / Jet Start button
Stop button
Combi Microwave + Grill button
Grill button
2
1
3
4
5
6
11
7
8
9
10
* This icon is not available in some models.
Please check the control panel of your microwave on the previous page.
DISPLAY DESCRIPTION
1
10
12
16
15
14
13
11
9
8
7
6
5
4
3
2
Silent Mode icon
Start Protection / Child Lock icon
Microwave Power (watt)
Weight (grams)
Stir indication
Turn indication
Running cycle animation
Grill icon*
Defrost icon
Automatic Defrost icons (Meat - Poultry - Fish)
Weight selection
Clock setting / Time selection
Auto Cook recipe selection
Auto Cook Menu icon
Microwave icon
Microwave Power level
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
6 7
CONTROL PANEL DESCRIPTION
10
11
1
3
4
5
6
7
8
9
2
Microwave button
Defrost Menu buttons
Auto Cook Menu button
Clock button
Silent Mode button
Auto Clean button
Knob
Ok / Jet Start button
Stop button
Combi Microwave + Grill button
Grill button
2
1
3
4
5
6
11
7
8
9
10
* This icon is not available in some models.
Please check the control panel of your microwave on the previous page.
DISPLAY DESCRIPTION
1
10
12
16
15
14
13
11
9
8
7
6
5
4
3
2
Silent Mode icon
Start Protection / Child Lock icon
Microwave Power (watt)
Weight (grams)
Stir indication
Turn indication
Running cycle animation
Grill icon*
Defrost icon
Automatic Defrost icons (Meat - Poultry - Fish)
Weight selection
Clock setting / Time selection
Auto Cook recipe selection
Auto Cook Menu icon
Microwave icon
Microwave Power level
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
8 9
STAND-BY MODE
After 6 minutes since the microwave oven is plugged
to a power outlet, if there are no operations carried
out, it will automatically enter Stand-by mode.
As soon as the product enters Stand-by mode, the
display will show the clock (or, if the clock has not
been set, the display will show “:”) and the Start
Protection / Child Lock icon.
In daily use, the microwave oven will automatically
enter Stand-by Mode when the door is closed and
the product is not in use after 6 minutes.
To exit Stand-by mode, simply open the door.
START PROTECTION / CHILD LOCK
This automatic safety function is activated, after 6
minutes from the last interaction with the microwave
oven, when the product is not in use and the door is
closed.
When the Start Protection / Child Lock is active, the
dedicated icon is shown on the display and it is not
possible to use the Control Panel. Open and close
the door to unlock the Control Panel.
Depending on the selected function, it could be
needed to stir / turn food during cooking. In these
cases the oven will pause cooking and it will ask you
to perform the needed action.
When required, you should:
q
Open the door.
w
Stir or Turn the food (depending on the required
action).
e
Close the door and restart by pressing Ok / Jet
Start button.
Notes: if the door is not opened within 2 minutes
from the request to Stir or Turn the food, the oven will
continuethecookingprocess(inthiscasethenal
result may not be the optimal one).
STIR/ TURN FOOD
i
PAUSE OR STOP COOKING
To pause cooking:
The cooking can be paused to check, turn or stir
the food by opening the door. The setting will be
maintained for 5 minutes.
To continue cooking:
Close the door and press the Ok / Jet Start button.
The cooking is resumed from where it was paused.
If you don’t want to continue cooking you can:
Remove the food, close the door and press the Stop
button.
When the cooking is finished:
The display will show the text “End”. An acoustic
beep will signal once a minute for 10 minutes, this is
normal behaviour intended for cooling the product.
Depending on the product, the cooling fan or the
internal lamp may continue to operate.
If desired, simply press the STOP button or open
the door to cancel the signal and stop the cooling
time. Please note that reducing or stopping this
programmed cooling cycle will not have a negative
impact on the functioning of the product.
CLOCK
To set the Clock of your appliance:
q
Press the Clock button.
w
Rotate the knob to set the hours.
e
Press the Clock button again.The minutes will start
blinking.
r
Rotate the knob to set the minutes.
t
Press the Clock button.The clock is set.
•If the clock has not been set after plug in, the display will show “:”.
•During the setting of the clock, if you press the Stop button or if the setting is not completed after a long
time, the oven will exit from setting mode and the setting will be invalid, display will show “:”.
Tips and suggestions:
Note:
Thersttimetheapplianceispluggedin(orafterapower
failure), the product will automatically enter the Clock
Setting mode. Please follow the above procedure starting
from step No.2.
8 9
STAND-BY MODE
After 6 minutes since the microwave oven is plugged
to a power outlet, if there are no operations carried
out, it will automatically enter Stand-by mode.
As soon as the product enters Stand-by mode, the
display will show the clock (or, if the clock has not
been set, the display will show “:”) and the Start
Protection / Child Lock icon.
In daily use, the microwave oven will automatically
enter Stand-by Mode when the door is closed and
the product is not in use after 6 minutes.
To exit Stand-by mode, simply open the door.
START PROTECTION / CHILD LOCK
This automatic safety function is activated, after 6
minutes from the last interaction with the microwave
oven, when the product is not in use and the door is
closed.
When the Start Protection / Child Lock is active, the
dedicated icon is shown on the display and it is not
possible to use the Control Panel. Open and close
the door to unlock the Control Panel.
Depending on the selected function, it could be
needed to stir / turn food during cooking. In these
cases the oven will pause cooking and it will ask you
to perform the needed action.
When required, you should:
q
Open the door.
w
Stir or Turn the food (depending on the required
action).
e
Close the door and restart by pressing Ok / Jet
Start button.
Notes: if the door is not opened within 2 minutes
from the request to Stir or Turn the food, the oven will
continuethecookingprocess(inthiscasethenal
result may not be the optimal one).
STIR/ TURN FOOD
i
PAUSE OR STOP COOKING
To pause cooking:
The cooking can be paused to check, turn or stir
the food by opening the door. The setting will be
maintained for 5 minutes.
To continue cooking:
Close the door and press the Ok / Jet Start button.
The cooking is resumed from where it was paused.
If you don’t want to continue cooking you can:
Remove the food, close the door and press the Stop
button.
When the cooking is finished:
The display will show the text “End”. An acoustic
beep will signal once a minute for 10 minutes, this is
normal behaviour intended for cooling the product.
Depending on the product, the cooling fan or the
internal lamp may continue to operate.
If desired, simply press the STOP button or open
the door to cancel the signal and stop the cooling
time. Please note that reducing or stopping this
programmed cooling cycle will not have a negative
impact on the functioning of the product.
CLOCK
To set the Clock of your appliance:
q
Press the Clock button.
w
Rotate the knob to set the hours.
e
Press the Clock button again.The minutes will start
blinking.
r
Rotate the knob to set the minutes.
t
Press the Clock button.The clock is set.
•If the clock has not been set after plug in, the display will show “:”.
•During the setting of the clock, if you press the Stop button or if the setting is not completed after a long
time, the oven will exit from setting mode and the setting will be invalid, display will show “:”.
Tips and suggestions:
Note:
Thersttimetheapplianceispluggedin(orafterapower
failure), the product will automatically enter the Clock
Setting mode. Please follow the above procedure starting
from step No.2.
10 11
This function allows to start the Microwave function at
maximum power for 30 seconds, simply pressing the Jet
Start button. It is suggested for quick reheating of food
with a high water content such as clear soups, coffee or
tea.
q Press the Jet Start Button.
Pressing the Jet Start button the Microwave function
will start at maximum microwave power (800W) for
30 seconds.
JET START
•Itispossibletochangethepowerlevelandthedurationtimeevenafterthecookingprocesshasbeen
already started. To adjust the power level, simply press the Microwave button repeatedly. To change the
duration time, please rotate the knob, or press the Ok / Jet Start button to increase the duration time of
30 seconds.
Tips and suggestions:
q
Press the Microwave button. The maximum power
level (800W) will be shown on the display and the
watt icons starts blinking.
w
Rotate the knob to adjust the power value, then
press OK / Jet Start button. Alternatively ,it is
possible to adjust the power value by pressing
repeatedly the Microwave button, then pressing OK
/Jet Start button.
e
The display will show the default cooking time (30
seconds). Rotate the knob to adjust the cooking
time.
r
Press Ok / Jet Start button to start the cooking
cycle.
MICROWAVE
Microwave function allows to quickly cook or reheat food
and beverages.
Suggested
Accessory:
Plate Cover
(sold separately)
*The picture above is referred to the MWA 23 model only.
You can find the position of the Microwave button of your
model on page 6 "Control panel Description".
•TousetheMicrowavefunctionatmaximumpower,yourproductisprovidedwiththeJet Start function.
You can easily start the Microwave function at maximum power by simply pressing the Jet Start button.
Each additional touch of the Jet Start button will increase the duration of the function of 30 seconds.
For more details, please see the Jet Start function on page 10.
•Itispossibletochangethepowerlevelandthedurationtimeevenafterthecookingprocesshasbeen
already started. To adjust the power level, simply press the Microwave button repeatedly.To change the
duration time, please rotate the knob, or press the Ok / Jet Start button to increase the duration time of
30 seconds.
Tips and suggestions:
10 11
This function allows to start the Microwave function at
maximum power for 30 seconds, simply pressing the Jet
Start button. It is suggested for quick reheating of food
with a high water content such as clear soups, coffee or
tea.
q Press the Jet Start Button.
Pressing the Jet Start button the Microwave function
will start at maximum microwave power (800W) for
30 seconds.
JET START
•Itispossibletochangethepowerlevelandthedurationtimeevenafterthecookingprocesshasbeen
already started. To adjust the power level, simply press the Microwave button repeatedly. To change the
duration time, please rotate the knob, or press the Ok / Jet Start button to increase the duration time of
30 seconds.
Tips and suggestions:
q
Press the Microwave button. The maximum power
level (800W) will be shown on the display and the
watt icons starts blinking.
w
Rotate the knob to adjust the power value, then
press OK / Jet Start button. Alternatively ,it is
possible to adjust the power value by pressing
repeatedly the Microwave button, then pressing OK
/Jet Start button.
e
The display will show the default cooking time (30
seconds). Rotate the knob to adjust the cooking
time.
r
Press Ok / Jet Start button to start the cooking
cycle.
MICROWAVE
Microwave function allows to quickly cook or reheat food
and beverages.
Suggested
Accessory:
Plate Cover
(sold separately)
*The picture above is referred to the MWA 23 model only.
You can find the position of the Microwave button of your
model on page 6 "Control panel Description".
•TousetheMicrowavefunctionatmaximumpower,yourproductisprovidedwiththeJet Start function.
You can easily start the Microwave function at maximum power by simply pressing the Jet Start button.
Each additional touch of the Jet Start button will increase the duration of the function of 30 seconds.
For more details, please see the Jet Start function on page 10.
•Itispossibletochangethepowerlevelandthedurationtimeevenafterthecookingprocesshasbeen
already started. To adjust the power level, simply press the Microwave button repeatedly.To change the
duration time, please rotate the knob, or press the Ok / Jet Start button to increase the duration time of
30 seconds.
Tips and suggestions:
12 13
MICROWAVE
POWER
SUGGESTED USE:
90 W Softening of ice cream and keep warming.
160 W Softening of butter and cheese.
350 W More careful cooking, simmering stew and melting of butter and chocolate.
500 W Cooking of meat sauce,cheese and egg dishes and to finish cooking casseroles.
600 W Cooking dishes and plated meals, not possible to stir.
700 W
Cooking of fish, meat, vegetables.
800 W
You can use it to reheat beverages, water, clear soup, coffee,tea or other food with a high
water content.If the food contains egg or cream choose a lower power.
Microwave - Power selection
Microwave - Cooking guide
Microwave - Reheating guide
Type of food Amount Power level Time Standing time Instructions
Chicken fillets
400g 700W 6½mins-7mins 3mins
Arrange chicken fillets with thin layers
on the microwave safe dish.
Bacon
4 slices 800W 3mins-3½mins -
Arrange the bacon slices separated
onto a bacon plate or microwave safe
dish.
Vegetables
(fresh)
400g 700W 5½mins-6½mins 1min
Add two tablespoons of fresh water
before start cooking. Stir at half time
during cooking.
Vegetables
(frozen)
400g 700W 6½mins-8mins 1min
Add two tablespoons of fresh water
before start cooking. Stir at half time
during cooking.
Jacket
potatoes
4 800W 20mins-22mins 5mins
1kgofpotatoesmediumsizewithskin
(choosepotatoeswithsimilarsizes),
pinch them with a fork.
Meat loaf
900g 700W 16mins-17mins 5mins
Prepare the recipe you prefer and pack
the mixture into a microwave safe dish
avoiding air pockets.
Fish (whole)
600g 700W 5½mins-6½mins 3mins
Pinch the fish skin with fork in order
to allow the steam to escape during
cooking.
Fishllets
400g 700W 6½mins-7½mins 3mins
Arrange fish fillets with thin layers on a
microwave safe dish.
Type of food Amount Power level Time Standing time Instructions
Plated meal
400-450g 700-800W 4½mins-5mins 1min
For better results arrange the
thicker,denser food to the outside of the
plate and the thinner or less dense food in
the middle.
Rice mixed
350g 800W 4½mins-5mins 1min
Removefrozenfoodpackage,stirduring
half time.
Beverage
2 cups 800W 3
1
/6mins-3½mins -
Put a metal spoon in the cup to prevent
liquid overheating.
Soup
2 cups 800W 4mins-5mins 3mins
Cover the dish with film, while leaving
air ventilation holes to allow the steam
to escape during reheating. Stir after
cooking.
Sauce
2 cups 500W 6½mins-8½mins 3mins
Cover the dish with film, while leaving air
ventilation holes to cook. Reheat from
room temperature. Stir after cooking.
Frozen
Lasagna
500g 600W 15mins-16mins 1min Use a microwave and oven safe dish.
12 13
MICROWAVE
POWER
SUGGESTED USE:
90 W Softening of ice cream and keep warming.
160 W Softening of butter and cheese.
350 W More careful cooking, simmering stew and melting of butter and chocolate.
500 W Cooking of meat sauce,cheese and egg dishes and to finish cooking casseroles.
600 W Cooking dishes and plated meals, not possible to stir.
700 W
Cooking of fish, meat, vegetables.
800 W
You can use it to reheat beverages, water, clear soup, coffee,tea or other food with a high
water content.If the food contains egg or cream choose a lower power.
Microwave - Power selection
Microwave - Cooking guide
Microwave - Reheating guide
Type of food Amount Power level Time Standing time Instructions
Chicken fillets
400g 700W 6½mins-7mins 3mins
Arrange chicken fillets with thin layers
on the microwave safe dish.
Bacon
4 slices 800W 3mins-3½mins -
Arrange the bacon slices separated
onto a bacon plate or microwave safe
dish.
Vegetables
(fresh)
400g 700W 5½mins-6½mins 1min
Add two tablespoons of fresh water
before start cooking. Stir at half time
during cooking.
Vegetables
(frozen)
400g 700W 6½mins-8mins 1min
Add two tablespoons of fresh water
before start cooking. Stir at half time
during cooking.
Jacket
potatoes
4 800W 20mins-22mins 5mins
1kgofpotatoesmediumsizewithskin
(choosepotatoeswithsimilarsizes),
pinch them with a fork.
Meat loaf
900g 700W 16mins-17mins 5mins
Prepare the recipe you prefer and pack
the mixture into a microwave safe dish
avoiding air pockets.
Fish (whole)
600g 700W 5½mins-6½mins 3mins
Pinch the fish skin with fork in order
to allow the steam to escape during
cooking.
Fishllets
400g 700W 6½mins-7½mins 3mins
Arrange fish fillets with thin layers on a
microwave safe dish.
Type of food Amount Power level Time Standing time Instructions
Plated meal
400-450g 700-800W 4½mins-5mins 1min
For better results arrange the
thicker,denser food to the outside of the
plate and the thinner or less dense food in
the middle.
Rice mixed
350g 800W 4½mins-5mins 1min
Removefrozenfoodpackage,stirduring
half time.
Beverage
2 cups 800W 3
1
/6mins-3½mins -
Put a metal spoon in the cup to prevent
liquid overheating.
Soup
2 cups 800W 4mins-5mins 3mins
Cover the dish with film, while leaving
air ventilation holes to allow the steam
to escape during reheating. Stir after
cooking.
Sauce
2 cups 500W 6½mins-8½mins 3mins
Cover the dish with film, while leaving air
ventilation holes to cook. Reheat from
room temperature. Stir after cooking.
Frozen
Lasagna
500g 600W 15mins-16mins 1min Use a microwave and oven safe dish.
14 15
This function uses a powerful grill to brown foods,
creating a grill or a gratin effect.
Grill function allows to brown foods like cheese toast,
hot sandwiches, potato croquettes, sausages, and
vegetables.
GRILL
q
Press the Grill button.
w
Rotate the knob to set the cooking time.
e
Press Ok / Jet Start button to start cooking.
•Forfoodlikecheese,toast,steaksandsausages,placefoodontheWireRack.
•Ensurethattheutensilsusedareheatresistantwhenyouusethisfunction.
•Donotuseplasticutensilswhengrilling.Theywillmelt.Itemsofwoodorpaperarenotsuitableeither.
•Becareful,donottouchtheceilingbeneaththegrillelement.
•It is possible to change the duration time even after the cooking process has been already started.
To change the duration time, please rotate the knob, or press the Ok / Jet Start button to increase the
duration time of 30 seconds.
Tips and suggestions:
Dedicated
Accessory:
Wire Rack
This function combines Microwave and Grill heating,
allowing you to cook gratin in less time.
COMBI MICROWAVE + GRILL
q
Press the Combi button.
w
Rotate the knob to set the cooking time.
e
Press Ok / Jet Start button to start cooking.
•Ensure that the utensils used are microwave safe and heat resistant when you use this function.
•Donotuseplasticutensilswhengrilling.Theywillmelt.Itemsofwoodorpaperarenotsuitableeither.
•Becareful,donottouchtheceilingbeneaththegrillelement.
•Itispossibletochangethedurationtimeevenafterthecookingprocesshasbeenalreadystarted.
To change the duration time, please rotate the knob, or press the Ok / Jet Start button to increase the
duration time of 30 seconds.
Tips and suggestions:
Once the cooking process has been started:
-to increase or decrease the cooking time: rotate the
knob, or press repeatedly OK / Jet Start button.
Dedicated
Accessory:
Wire Rack
14 15
This function uses a powerful grill to brown foods,
creating a grill or a gratin effect.
Grill function allows to brown foods like cheese toast,
hot sandwiches, potato croquettes, sausages, and
vegetables.
GRILL
q
Press the Grill button.
w
Rotate the knob to set the cooking time.
e
Press Ok / Jet Start button to start cooking.
•Forfoodlikecheese,toast,steaksandsausages,placefoodontheWireRack.
•Ensurethattheutensilsusedareheatresistantwhenyouusethisfunction.
•Donotuseplasticutensilswhengrilling.Theywillmelt.Itemsofwoodorpaperarenotsuitableeither.
•Becareful,donottouchtheceilingbeneaththegrillelement.
•It is possible to change the duration time even after the cooking process has been already started.
To change the duration time, please rotate the knob, or press the Ok / Jet Start button to increase the
duration time of 30 seconds.
Tips and suggestions:
Dedicated
Accessory:
Wire Rack
This function combines Microwave and Grill heating,
allowing you to cook gratin in less time.
COMBI MICROWAVE + GRILL
q
Press the Combi button.
w
Rotate the knob to set the cooking time.
e
Press Ok / Jet Start button to start cooking.
•Ensure that the utensils used are microwave safe and heat resistant when you use this function.
•Donotuseplasticutensilswhengrilling.Theywillmelt.Itemsofwoodorpaperarenotsuitableeither.
•Becareful,donottouchtheceilingbeneaththegrillelement.
•Itispossibletochangethedurationtimeevenafterthecookingprocesshasbeenalreadystarted.
To change the duration time, please rotate the knob, or press the Ok / Jet Start button to increase the
duration time of 30 seconds.
Tips and suggestions:
Once the cooking process has been started:
-to increase or decrease the cooking time: rotate the
knob, or press repeatedly OK / Jet Start button.
Dedicated
Accessory:
Wire Rack
16 17
This function allows you to quickly defrost food.
q
Press the Manual Defrost button.
w
Rotate the knob to set the duration of the function.
e
Press the Ok / Jet Start button.The function will
start.
MANUAL DEFROST
(
DEFROST MENU
)
•Forbestresultwerecommendtodefrostdirectlyonthecavitybottom.Ifneeded,itispossibletousea
container of light plastic suitable for microwave.
•Boiledfood,stewsandmeatsaucesdefrostisbetterifstirredduringdefrostingtime.
•Separate pieces as they begin to defrost. Individual slices defrost more easily
•Turn/Stirlargeportionsoffoodhalfwaythroughthedefrostingprocess.
•Whendefrostingitisbettertounderthawthefoodslightlyandallowtheprocesstofinishduringstanding
time.
•Itispossibletochangethedurationtimeevenafterthecookingprocesshasbeenalreadystarted.
To change the duration time, please rotate the knob, or press the Ok / Jet Start button to increase the
duration time of 30 seconds.
Tips and suggestions:
This function allows you to quickly defrost food
automatically.Use this function to defrost Meat, Poultry
or Fish.
q
Press any Auto Defrost button (Meat, Poultry or
Fish) to select the food type (see the table below).
w
Rotate the knob to set the weight.
e
Press the Ok / Jet Start button. The function
will start.The duration of the function will be
automatically Calculated on the basis of the
selected food and weight.
AUTOMATIC DEFROST
(
DEFROST MENU
)
•Forbestresultwerecommendtodefrostdirectlyonthecavitybottom.Ifneeded,itispossibletousea
container of light plastic suitable for microwave.
•Forfoodnotlistedinthistableandiftheweightislessormorethanrecommendedweight,youshould
choose the Manual Defrost (see page 16).
•Ifthefoodiswarmerthandeep-freezetemperature(-18°C),chooselowerweightofthefood.
•Ifthefoodiscolderthandeep-freezetemperature(-18°C),choosehigherweightofthefood.
•Separatepiecesastheybegintodefrost.Individualslicesdefrostmoreeasily.
•Standingtimeafterdefrostingalwaysimprovestheresultsincethetemperaturewillthenbeevenly
distributed throughout the food.
Tips and suggestions:
Note: after a certain time, the display could ask you to
turn or stir the food for a better defrost. See “Stir / Turn
food” chapter on page 8.
FOOD TYPE WEIGHT HINT
Meat
100-2000g
Minced meat. cutlets , steak
or roast. After cooking, it is
recommended to allow meat
to rest for at least 5 minutes
for better results.
Poultry
100-2000g
Whole chicken,pieces,or
llets.Aftercooking,itis
recommended to allow food to
rest for 5-10 minutes.
Fish
100-2000g
Wholesh,steaksor
llets,whennsihed
cooking,please wait at least
5 mins.
16 17
This function allows you to quickly defrost food.
q
Press the Manual Defrost button.
w
Rotate the knob to set the duration of the function.
e
Press the Ok / Jet Start button.The function will
start.
MANUAL DEFROST
(
DEFROST MENU
)
•Forbestresultwerecommendtodefrostdirectlyonthecavitybottom.Ifneeded,itispossibletousea
container of light plastic suitable for microwave.
•Boiledfood,stewsandmeatsaucesdefrostisbetterifstirredduringdefrostingtime.
•Separate pieces as they begin to defrost. Individual slices defrost more easily
•Turn/Stirlargeportionsoffoodhalfwaythroughthedefrostingprocess.
•Whendefrostingitisbettertounderthawthefoodslightlyandallowtheprocesstofinishduringstanding
time.
•Itispossibletochangethedurationtimeevenafterthecookingprocesshasbeenalreadystarted.
To change the duration time, please rotate the knob, or press the Ok / Jet Start button to increase the
duration time of 30 seconds.
Tips and suggestions:
This function allows you to quickly defrost food
automatically.Use this function to defrost Meat, Poultry
or Fish.
q
Press any Auto Defrost button (Meat, Poultry or
Fish) to select the food type (see the table below).
w
Rotate the knob to set the weight.
e
Press the Ok / Jet Start button. The function
will start.The duration of the function will be
automatically Calculated on the basis of the
selected food and weight.
AUTOMATIC DEFROST
(
DEFROST MENU
)
•Forbestresultwerecommendtodefrostdirectlyonthecavitybottom.Ifneeded,itispossibletousea
container of light plastic suitable for microwave.
•Forfoodnotlistedinthistableandiftheweightislessormorethanrecommendedweight,youshould
choose the Manual Defrost (see page 16).
•Ifthefoodiswarmerthandeep-freezetemperature(-18°C),chooselowerweightofthefood.
•Ifthefoodiscolderthandeep-freezetemperature(-18°C),choosehigherweightofthefood.
•Separatepiecesastheybegintodefrost.Individualslicesdefrostmoreeasily.
•Standingtimeafterdefrostingalwaysimprovestheresultsincethetemperaturewillthenbeevenly
distributed throughout the food.
Tips and suggestions:
Note: after a certain time, the display could ask you to
turn or stir the food for a better defrost. See “Stir / Turn
food” chapter on page 8.
FOOD TYPE WEIGHT HINT
Meat
100-2000g
Minced meat. cutlets , steak
or roast. After cooking, it is
recommended to allow meat
to rest for at least 5 minutes
for better results.
Poultry
100-2000g
Whole chicken,pieces,or
llets.Aftercooking,itis
recommended to allow food to
rest for 5-10 minutes.
Fish
100-2000g
Wholesh,steaksor
llets,whennsihed
cooking,please wait at least
5 mins.
18 19
AUTO COOK MENU
A selection of automatic recipes with preset values to
offer optimal cooking results.
q
Press the Auto Cook button.
w
Rotate the knob to select the desired recipe (see
the below table).
e
Press the Ok / Jet Start button. The function will
start.
Note: according to the selected recipe, after a certain
time, the display could ask you to turn or stir the food.
See “Stir / Turn food” chapter on page 8.
RECIPE INGREDIENTS PROCEDURE
COOKING
TIME
1
Bolognese
Meat
(4 servings)
•300gbeefminced
meat
•340gtomatosauce
•4tablespoons
olive oil
•½teaspoondried
basil
•1bouillontablets
•apinchofsalt
•Inapyrexcasseroledishwithlid,dissolvethebouillon
tablets in olive oil to form a paste.
•Addtheremainingingredientsandmixwell.
•Coverthedishwiththelid.
•PresstheAutoCookbuttononcetoselectrecipe
number 1, then press the Ok / Jet Start button.
•Whenpromptedbytheuserinterface,removethedish
from the microwave and stir well,then place back in the
microwave.
•PressOk/JetStartbuttontocontinuethecookingcycle.
14mins
RECIPE INGREDIENTS PROCEDURE
COOKING
TIME
2
Meat cake
(4 servings)
•800gofgroundbeef
•2slicesofbread
•4tablespoonsof
tomato sauce
•1beatenegg
•50ggratedmozzarella
•1smallonion
•8choppedgreen
olives
•4tablespoons
Worcestershire sauce
•2tablespoons
chopped parsley
•Garlic,oregano,salt
and pepper
•Grindthebread,onion,garlicandparsley.Mixthe
meat with egg and spices.
•Addthemixtoagreasedmould,llingtheedgesand
sides well. Spread the tomato sauce and the cheese
evenly over the top.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 2, then press the Ok / Jet Start button.
17mins
(MWH2621)
15mins
(MWH2622)
3
Salmon with
vegetables
(4 servings)
•800gofsalmoncut
intoslices of 3 cm
•150gcherry
tomatoes,halved
•100gbroccoli
•100gcauliower
•20gleek
•2tablespoonsextra
virgin olive oil
•Juiceof1lemon
•Saltandpepper
•Inadishsuitableformicrowaves,seasonthe
salmon and vegetables with salt, pepper, olive oil
and lemon.
•Coverthedish,leavingalittlespacetoallowsteam
to escape.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 3, then press the Ok / Jet Start button.
•Attheendofthecookingcycle,removethecover
carefully in order to allow the steam to escape from
the dish.
15mins
4
Vegetables
cream soup
(2 servings)
•200gpotatoescutinto
cubes
•100gbroccoli
•1ripetomato,diced
•200mlofwater
•Salt,pepperand
grated parmesan
cheese
•Inadishsuitableformicrowaves,mixallingredients
together, excluding the cheese.
•Coverthedish,leavingalittlespacetoallowsteam
to escape.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 4, then press the Ok / Jet Start button.
•Attheendofthecookingcycle,beatallingredients
in a blender and serve while still hot with parmesan
cheese on top.
15mins
5
Vegetables
(2 servings)
•350gofyourfavorite
vegetable, cut into
small cubes
•100mlwateratroom
temperature
•1tablespoonoliveoil
•1teaspoonsalt
•Inadishsuitableformicrowaves,addallingreduents
and mix well.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 5,then press the Ok/Jet Start button.
•Attheendofthecookingcycle,removethedish
using heat resistant gloves,being careful of the
steam.
•Removegarlicbeforeserving(ifdesired).
9mins
18 19
AUTO COOK MENU
A selection of automatic recipes with preset values to
offer optimal cooking results.
q
Press the Auto Cook button.
w
Rotate the knob to select the desired recipe (see
the below table).
e
Press the Ok / Jet Start button. The function will
start.
Note: according to the selected recipe, after a certain
time, the display could ask you to turn or stir the food.
See “Stir / Turn food” chapter on page 8.
RECIPE INGREDIENTS PROCEDURE
COOKING
TIME
1
Bolognese
Meat
(4 servings)
•300gbeefminced
meat
•340gtomatosauce
•4tablespoons
olive oil
•½teaspoondried
basil
•1bouillontablets
•apinchofsalt
•Inapyrexcasseroledishwithlid,dissolvethebouillon
tablets in olive oil to form a paste.
•Addtheremainingingredientsandmixwell.
•Coverthedishwiththelid.
•PresstheAutoCookbuttononcetoselectrecipe
number 1, then press the Ok / Jet Start button.
•Whenpromptedbytheuserinterface,removethedish
from the microwave and stir well,then place back in the
microwave.
•PressOk/JetStartbuttontocontinuethecookingcycle.
14mins
RECIPE INGREDIENTS PROCEDURE
COOKING
TIME
2
Meat cake
(4 servings)
•800gofgroundbeef
•2slicesofbread
•4tablespoonsof
tomato sauce
•1beatenegg
•50ggratedmozzarella
•1smallonion
•8choppedgreen
olives
•4tablespoons
Worcestershire sauce
•2tablespoons
chopped parsley
•Garlic,oregano,salt
and pepper
•Grindthebread,onion,garlicandparsley.Mixthe
meat with egg and spices.
•Addthemixtoagreasedmould,llingtheedgesand
sides well. Spread the tomato sauce and the cheese
evenly over the top.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 2, then press the Ok / Jet Start button.
17mins
(MWH2621)
15mins
(MWH2622)
3
Salmon with
vegetables
(4 servings)
•800gofsalmoncut
intoslices of 3 cm
•150gcherry
tomatoes,halved
•100gbroccoli
•100gcauliower
•20gleek
•2tablespoonsextra
virgin olive oil
•Juiceof1lemon
•Saltandpepper
•Inadishsuitableformicrowaves,seasonthe
salmon and vegetables with salt, pepper, olive oil
and lemon.
•Coverthedish,leavingalittlespacetoallowsteam
to escape.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 3, then press the Ok / Jet Start button.
•Attheendofthecookingcycle,removethecover
carefully in order to allow the steam to escape from
the dish.
15mins
4
Vegetables
cream soup
(2 servings)
•200gpotatoescutinto
cubes
•100gbroccoli
•1ripetomato,diced
•200mlofwater
•Salt,pepperand
grated parmesan
cheese
•Inadishsuitableformicrowaves,mixallingredients
together, excluding the cheese.
•Coverthedish,leavingalittlespacetoallowsteam
to escape.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 4, then press the Ok / Jet Start button.
•Attheendofthecookingcycle,beatallingredients
in a blender and serve while still hot with parmesan
cheese on top.
15mins
5
Vegetables
(2 servings)
•350gofyourfavorite
vegetable, cut into
small cubes
•100mlwateratroom
temperature
•1tablespoonoliveoil
•1teaspoonsalt
•Inadishsuitableformicrowaves,addallingreduents
and mix well.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 5,then press the Ok/Jet Start button.
•Attheendofthecookingcycle,removethedish
using heat resistant gloves,being careful of the
steam.
•Removegarlicbeforeserving(ifdesired).
9mins
20 21
RECIPE INGREDIENTS PROCEDURE
COOKING
TIME
6
Jacket
potatoes
(4 servings)
•1kgofmedium
sizedpotatoes
•4tablespoonbutter
•100ggratedcheese
of your choice
•Salt,pepperand
cheese to sprinkle
•Washanddrythepotatoes,prickthemwithafork.
•Placethepotatoesinadishsuitableformicrowaves.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 6, then press the Ok / Jet Start button.
•Whenpromptedbytheuserinterface,rotatethe
potatoes - being careful as the potatoes will be hot.
•Attheendofthecookingcycle,allowthepotatoes
to cool down, then cut them in half and remove the
potato from the skin - set the skin aside for later.
•Kneadthepotatotoformapuree,andmixwiththe
remaining ingredients.
•Fillthepotatoskinswiththemixture,sprinklethe
top with cheese and place in the microwave for 5
minutes, to melt.
12mins
7
Rice
(2 servings)
•1cupporboiled
white rice(180g)
•3cupsof
water(540ml)at room
temperature
•1teaspoonsalt
•1tablespoonolive
oil
•Inadishsuitableformicrowaveswithhighedges
(approx. 10cm), combine all ingredients.
•Placethedishuncoveredinthemicrowave.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 7, then press the Ok / Jet Start button.
•Attheendofthecookingcycle,removethe
container from the microwave using heat resistant
gloves.
•Ifthereiswaterremaininginthedish,mixvigorously,
then leave covered for 2 minutes before serving.
18mins
8
Pop Corn
(2 servings)
•Thisfunctionis
suitable for the
preparation of 100g
pop corn bag.
•Placethepackageofpopcorninthecenterofthe
cavity.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 8, then press the Ok / Jet Start button.
2mins30s
(MWH2621)
2mins15s
(MWH2622)
9
Bruschetta
(2 servings)
(only available
on model
MWH2622)
•2sliceofItalian
bread approximately
1.5 cm thick
•30mlextravirgin
olive oil
•10cherrytomatoes
peeled and diced
•3tablespoons
chopped fresh basil
•Salt,pepperand
garlic
•Dicedmozzarella
•PlacetheslicesofbreadontheWireRack.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 9, then press the Ok / Jet Start button.
•Whenpromptedbytheuserinterface,removethe
Wire Rack and carefully rotate the bread - then place
back in the microwave and press the Ok / Jet Start
button.
•Turn food when oven prompts.
•Meanwhile,seasonthetomatoeswiththesalt,black
pepper and olive oil.
•Attheendofthecookingcycle,removethebread
from the microwave, rub the garlic cloves on the
bread, place the tomatoes and basil on top and serve
immediatelywiththedicedmozzarella.
8mins
This function allows to deactivate all the sounds played by
the appliances
SILENT MODE
q
Press Silent Mode button to deactivate all the sounds.
To restore the sounds, press the Silent Mode button
again.
20 21
RECIPE INGREDIENTS PROCEDURE
COOKING
TIME
6
Jacket
potatoes
(4 servings)
•1kgofmedium
sizedpotatoes
•4tablespoonbutter
•100ggratedcheese
of your choice
•Salt,pepperand
cheese to sprinkle
•Washanddrythepotatoes,prickthemwithafork.
•Placethepotatoesinadishsuitableformicrowaves.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 6, then press the Ok / Jet Start button.
•Whenpromptedbytheuserinterface,rotatethe
potatoes - being careful as the potatoes will be hot.
•Attheendofthecookingcycle,allowthepotatoes
to cool down, then cut them in half and remove the
potato from the skin - set the skin aside for later.
•Kneadthepotatotoformapuree,andmixwiththe
remaining ingredients.
•Fillthepotatoskinswiththemixture,sprinklethe
top with cheese and place in the microwave for 5
minutes, to melt.
12mins
7
Rice
(2 servings)
•1cupporboiled
white rice(180g)
•3cupsof
water(540ml)at room
temperature
•1teaspoonsalt
•1tablespoonolive
oil
•Inadishsuitableformicrowaveswithhighedges
(approx. 10cm), combine all ingredients.
•Placethedishuncoveredinthemicrowave.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 7, then press the Ok / Jet Start button.
•Attheendofthecookingcycle,removethe
container from the microwave using heat resistant
gloves.
•Ifthereiswaterremaininginthedish,mixvigorously,
then leave covered for 2 minutes before serving.
18mins
8
Pop Corn
(2 servings)
•Thisfunctionis
suitable for the
preparation of 100g
pop corn bag.
•Placethepackageofpopcorninthecenterofthe
cavity.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 8, then press the Ok / Jet Start button.
2mins30s
(MWH2621)
2mins15s
(MWH2622)
9
Bruschetta
(2 servings)
(only available
on model
MWH2622)
•2sliceofItalian
bread approximately
1.5 cm thick
•30mlextravirgin
olive oil
•10cherrytomatoes
peeled and diced
•3tablespoons
chopped fresh basil
•Salt,pepperand
garlic
•Dicedmozzarella
•PlacetheslicesofbreadontheWireRack.
•PresstheAutoCookbuttonrepeatedlytoselect
recipe number 9, then press the Ok / Jet Start button.
•Whenpromptedbytheuserinterface,removethe
Wire Rack and carefully rotate the bread - then place
back in the microwave and press the Ok / Jet Start
button.
•Turn food when oven prompts.
•Meanwhile,seasonthetomatoeswiththesalt,black
pepper and olive oil.
•Attheendofthecookingcycle,removethebread
from the microwave, rub the garlic cloves on the
bread, place the tomatoes and basil on top and serve
immediatelywiththedicedmozzarella.
8mins
This function allows to deactivate all the sounds played by
the appliances
SILENT MODE
q
Press Silent Mode button to deactivate all the sounds.
To restore the sounds, press the Silent Mode button
again.
22 23
Tips and suggestions:
•Forabettercleaningresult, it is recommended to use a container with a diameter of 17-20cm,and a
height that is lower than 6.5cm.
•Itisrecommendedtouseacontaineroflightplasticmaterialthatissuitableforthemicrowave.
•Asthecontainerwillbehotafterthecleaningcycleiscomplete,itisrecommendedtouseaheat
resistant glove when removing the container from the microwave.
•Forabettercleaningeffectandremovalofunpleasantodors,addsomelemonjuicetothewater.
•TheGrillelementdoesnotneedcleaningsincetheintenseheatwillburnoffanysplashes,butthe
ceiling beneath it may need regular cleaning. This should be done with a soft and damp cloth with mild
detergent.
•IftheGrillisnotusedregularly,itshouldberunfor10minutesamonthtoburnoffanysplashes,inorder
to reduce the risk of fire.
AUTO CLEAN
This automatic cleaning cycle will help you to to clean the
microwave oven cavity and to remove unpleasant odors.
bEFORE sTARTiNG THE CYCLE:
q
Put 200ml water into a container (see our
recommendations in the below section “Tips and
suggestions”).
w
Place the container directly on the middle of cavity
bottom.
wHEN THE CYCLE is FiNisHED:
q
Press the Stop button.
w
Wait for 3-5 minutes before opening the door.
e
Remove the container.
r
Use a soft cloth or a paper towel with mild
detergent to clean the interior surfaces.
TO sTART THE CYCLE:
q
Press the Auto Clean button, the cleaning cycle
duration will be visible on the display.
w
Press the Ok / Jet Start button to start the function.
TEST AMOUNT
POWER LEVEL
APPROX. TIME
Egg custard
(12.3.1)
750 G 800w 11mins
Sponge cake
(12.3.1)
475 G 700w 6mins-9mins
Meat loaf
(12.3.3)
900 G 800w 15mins-16mins
Minced meat defrost
(13.3)
500 G 160w 12mins-13mins.
Potato gratin
(12.3.4)
1100 G Grill Combi 33mins
The International Electrotechnical Commission has developed a standard for comparative testing of heating
performance of different microwave ovens. We recommend the following for this oven:
In accordance with IEC 60705:2010 and IEC 60350-1:2011
TECHNICAL SPECIFICATION
Data Description MwA23b
Supply Voltage 240V~50 Hz
Rated Input Power 1350 w
Grill 950-1050 w
Oven Fuse 8A
UK Plug Fuse 13A
Outer dimensions (HxWxD) 320 x 490 x 426
Inner dimensions (HxWxD) 214 x 320 x 329
TEST PREHEAT
FUNCTION
APPROX. TIME
Toast
(9.1)
- Grill 6mins
Hamburger
(9.2)
- Grill 68mins-71mins
22 23
Tips and suggestions:
•Forabettercleaningresult, it is recommended to use a container with a diameter of 17-20cm,and a
height that is lower than 6.5cm.
•Itisrecommendedtouseacontaineroflightplasticmaterialthatissuitableforthemicrowave.
•Asthecontainerwillbehotafterthecleaningcycleiscomplete,itisrecommendedtouseaheat
resistant glove when removing the container from the microwave.
•Forabettercleaningeffectandremovalofunpleasantodors,addsomelemonjuicetothewater.
•TheGrillelementdoesnotneedcleaningsincetheintenseheatwillburnoffanysplashes,butthe
ceiling beneath it may need regular cleaning. This should be done with a soft and damp cloth with mild
detergent.
•IftheGrillisnotusedregularly,itshouldberunfor10minutesamonthtoburnoffanysplashes,inorder
to reduce the risk of fire.
AUTO CLEAN
This automatic cleaning cycle will help you to to clean the
microwave oven cavity and to remove unpleasant odors.
bEFORE sTARTiNG THE CYCLE:
q
Put 200ml water into a container (see our
recommendations in the below section “Tips and
suggestions”).
w
Place the container directly on the middle of cavity
bottom.
wHEN THE CYCLE is FiNisHED:
q
Press the Stop button.
w
Wait for 3-5 minutes before opening the door.
e
Remove the container.
r
Use a soft cloth or a paper towel with mild
detergent to clean the interior surfaces.
TO sTART THE CYCLE:
q
Press the Auto Clean button, the cleaning cycle
duration will be visible on the display.
w
Press the Ok / Jet Start button to start the function.
TEST AMOUNT
POWER LEVEL
APPROX. TIME
Egg custard
(12.3.1)
750 G 800w 11mins
Sponge cake
(12.3.1)
475 G 700w 6mins-9mins
Meat loaf
(12.3.3)
900 G 800w 15mins-16mins
Minced meat defrost
(13.3)
500 G 160w 12mins-13mins.
Potato gratin
(12.3.4)
1100 G Grill Combi 33mins
The International Electrotechnical Commission has developed a standard for comparative testing of heating
performance of different microwave ovens. We recommend the following for this oven:
In accordance with IEC 60705:2010 and IEC 60350-1:2011
TECHNICAL SPECIFICATION
Data Description MwA23b
Supply Voltage 240V~50 Hz
Rated Input Power 1350 w
Grill 950-1050 w
Oven Fuse 8A
UK Plug Fuse 13A
Outer dimensions (HxWxD) 320 x 490 x 426
Inner dimensions (HxWxD) 214 x 320 x 329
TEST PREHEAT
FUNCTION
APPROX. TIME
Toast
(9.1)
- Grill 6mins
Hamburger
(9.2)
- Grill 68mins-71mins
24 25
ENVIRONMENTAL HINTS
The packing box maybefullyrecycledasconrmed
by the recycling symbol. Follow local disposal
regulations.Keeppotentiallyhazardouspackaging
(plastic bags, polystyrene etc.) out of the reach of
children.
This appliance is marked according to the European
directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE). By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
The symbol on the product, or on the documents
accompanying the product, indicates that this
appliance may not be treated as household waste.
Instead it shall be handed over to the applicable
collection point for the
recycling of electrical and electronic equipment.
Disposal must be carried out in accordance with local
environmental regulations for waste
disposal.
For more detailed information about treatment,
recovery and recycling of this product, please
contactyourlocalcityofce,yourhouseholdwaste
disposal service or the shop where you
purchased the product.
Before scrapping, cut off the mains cord so that the
appliance cannot be connected to the mains.
MWA 23 B
01 /2 01 6- ver. 1.0
432E14A002484
24 25
ENVIRONMENTAL HINTS
The packing box maybefullyrecycledasconrmed
by the recycling symbol. Follow local disposal
regulations.Keeppotentiallyhazardouspackaging
(plastic bags, polystyrene etc.) out of the reach of
children.
This appliance is marked according to the European
directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE). By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
The symbol on the product, or on the documents
accompanying the product, indicates that this
appliance may not be treated as household waste.
Instead it shall be handed over to the applicable
collection point for the
recycling of electrical and electronic equipment.
Disposal must be carried out in accordance with local
environmental regulations for waste
disposal.
For more detailed information about treatment,
recovery and recycling of this product, please
contactyourlocalcityofce,yourhouseholdwaste
disposal service or the shop where you
purchased the product.
Before scrapping, cut off the mains cord so that the
appliance cannot be connected to the mains.
MWA 23 B
01 /2 01 6- ver. 1.0
432E14A002484
