Dyson 278176-01 V7 Motorhead Cordless Vacuum Cleaner

User Manual - Transcript

• Page 1 - English - : click click click click Operating manual Assembly S V11 Wash filter Wash filter with cold water at least once every month Ensure the filter is completely dry before refitting Register today 3 easy ways to register your Dyson 2 year guarantee Powerful suction Max mode 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 2 - English - : REGISTER ONLINE Visit our website to register your Dyson full parts and labour guarantee online AU wwwdysoncomauregister NZ wwwdysonconzregister REGISTER BY PHONE Call our dedicated Helpline AU 1800 239 766 NZ 0800 397 667 REGISTER BY MAIL Complete and return the form to Dyson in the envelope supplied Dyson customer care THANK YOU FOR CHOOSING TO BUY A DYSON APPLIANCE Your Dyson appliance will be covered for parts and labour excluding replacement filters where there is no defect for 2 years from the date of purchase as detailed in the terms of the Dyson guarantee in this Dyson Operating Manual If you have a query about your Dyson appliance contact us via the website Alternatively call the Dyson Customer Care Helpline quoting your serial number and details of where and when you bought the appliance Visit our website to register your Dyson full parts and labour guarantee online and for online help support videos general tips and useful information about Dyson AU wwwdysoncomausupport NZ wwwdysonconzsupport This illustration is for example purposes only Your serial number can be found on your rating plate which is on the base of the appliance 3 EASY WAYS TO REGISTER YOUR DYSON 2 YEAR GUARANTEE DYSON CUSTOMER CARE Australia Website wwwdysoncomau Email aucustomercaredysoncom Dyson Customer Care 1800 239 766 MonFri 800am to 600pm EST SatSun 830am to 400pm EST Address Dyson Appliances Aust Pty Limited PO Box 2835 Taren Point NSW 2229 Australia New Zealand Website wwwdysonconz Email dysonaveryrobinsonconz Dyson Customer Care 0800 397 667 MonFri 830am to 500pm Address Avery Robinson Ltd Unit 6 99 Carbine Road Mount Wellington Auckland 1060 New Zealand IMPORTANT SAFETY INSTRUCTIONS BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN THIS MANUAL AND ON THE APPLIANCE When using an electrical appliance basic precautions should always be followed including the following WARNING These warnings apply to the appliance and also where applicable to all tools accessories chargers or mains adaptors TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK OR INJURY 1 This Dyson appliance can be used by children aged from 8 years and above and persons with reduced physical sensory or reasoning capabilities or lack of experience and knowledge only if they have been given supervision or instruction by a responsible person concerning use of the appliance in a safe way and understand the hazards involved Cleaning and user maintenance should not be performed by children without supervision 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 3 - English - : 2 Do not allow to be used as a toy Close attention is necessary when used by or near children Children should be supervised to ensure that they do not play with the appliance 3 Use only as described in this Dyson Operating Manual Do not carry out any maintenance other than that shown in this manual or advised by the Dyson Helpline 4 Suitable for dry locations ONLY Do not use outdoors or on wet surfaces 5 Do not handle any part of the plug or appliance with wet hands 6 Do not use with a damaged cable or plug If the supply cable is damaged it must be replaced by Dyson its service agent or similarly qualified person in order to avoid a hazard 7 If the appliance is not working as it should has received a sharp blow has been dropped damaged left outdoors or dropped into water do not use and contact the Dyson Helpline 8 Contact the Dyson Helpline when service or repair is required Do not disassemble the appliance as incorrect reassembly may result in an electric shock or fire 9 Do not stretch the cable or place the cable under strain Keep the cable away from heated surfaces Do not close a door on the cable or pull the cable around sharp edges or corners Arrange the cable away from traffic areas and where it will not be stepped on or tripped over Do not run over the cable 10 Do not unplug by pulling on the cable To unplug grasp the plug not the cable The use of an extension cable is not recommended 11 Do not use to pick up water 12 Do not use to pick up flammable or combustible liquids such as petrol or use in areas where they or their vapours may be present 13 Do not pick up anything that is burning or smoking such as cigarettes matches or hot ashes 14 Keep hair loose clothing fingers and all parts of the body away from openings and moving parts such as the brush bar Do not point the hose wand or tools at your eyes or ears or put them in your mouth 15 Do not put any object into openings Do not use with any opening blocked keep free of dust lint hair and anything that may reduce airflow 16 Use only Dyson recommended accessories and replacement parts 17 Do not use without the clear bin and filter in place 18 Unplug when not in use for extended periods and before maintenance or servicing 19 Use extra care when cleaning on stairs 20 Do not install charge or use this appliance outdoors in a bathroom or within 3 metres 10 feet of a pool Do not use on wet surfaces and do not expose to moisture rain or snow 21 Use only Dyson chargers for charging this Dyson appliance Use only Dyson batteries other types of batteries may burst causing injury to persons and damage 22 FIRE WARNING Do not place this product on or near a cooker or any other hot surface and do not incinerate this appliance even if it is severely damaged The battery might catch fire or explode 23 Always turn OFF the appliance before connecting or disconnecting the motorised brush bar 24 FIRE WARNING Do not apply any fragrance or scented product to the filters of this appliance The chemicals in such products are known to be flammable and can cause the appliance to catch fire READ AND SAVE THESE INSTRUCTIONS This Dyson appliance is intended for household use only Do not use near naked flames Do not store near heat sources Do not pick up water or liquids Do not pick up burning objects Do not put hands near the brush bar when the appliance is in use Do not place on or near the cooker 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 4 - English - : 35 hrs click click click click click click Power mode and runtime Emptying the clear bin 20 minutes Powerful suction Max mode Up to 6 minutes 30 minutes 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 5 - English - : 35 hrs click click click click click click Using the dock Lights during use Light during charging Solid blue ON Flashing amber No power temporary fault eg too hotcold Flashing red Fault contact Dyson helpline Flashing blue No power charge battery Solid amber Fault contact Dyson helpline Solid blue Charging Lights off Charging complete Solid amber Fault if this persists contact the Dyson Helpline Flashing red Fault contact Dyson helpline Flashing blue Not charging Refit charger or try another socket If warning light persists contact the Dyson Helpline 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 7 - English - : 1 2 3 click click Direct drive cleanerhead Clearing obstructions Important Wash filter Wash filter with cold water at least once every month Ensure the filter is completely dry before refitting 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 8 - English - : 1 2 3 Using your Dyson appliance Please read the Important Safety Instructions in this Dyson operating manual before proceeding Operation Do not use outdoors or on wet surfaces or to vacuum water or other liquids electric shock could occur Ensure the appliance remains upright in use and in storage Dirt and debris may be released if it is turned upside down Do not operate while checking for blockages For domestic indoor and car use only Do not use it whilst the car is in motion or while driving To operate the Max mode locate the switch on the top of the appliance Slide the switch to the Max mode position To switch off Max mode slide the switch back to the Powerful Suction mode position This appliance has carbon fibre brushes Take care if coming into contact with them as they may cause minor skin irritation Wash your hands after handling the brushes Docking station installation Use appropriate mounting hardware for your wall type and ensure that the docking station is mounted securely Ensure no pipe work gas water air or electrical cables wires or ductwork are located directly behind the mounting area The docking station must be mounted in accordance with regulations and applicable codesstandards state and local laws may apply Dyson recommends the use of protective clothing eyeware and materials when installing the docking station Carpets or hard floors Before vacuuming your flooring rugs and carpets check the manufacturers recommended cleaning instructions The brush bar on the appliance can damage certain carpet types and floors Some carpets will fuzz if a rotating brush bar is used when vacuuming If this happens we recommend vacuuming without the motorised floor tool and consulting with your flooring manufacturer Before vacuuming highly polished floors such as wood or lino first check that the underside of the floor tool and its brushes are free from foreign objects that could cause marking Looking after your Dyson appliance Do not carry out any maintenance or repair work other than that shown in this Dyson Operating Manual or advised by the Dyson Helpline Only use parts recommended by Dyson If you do not this could invalidate your guarantee Store the appliance indoors Do not use or store it below 3C 374F Ensure the appliance is at room temperature before operating Clean the appliance only with a dry cloth Do not use any lubricants cleaning agents polishes or air fresheners on any part of the appliance Check the brush bar regularly and clear away any debris such as hair Debris left on the brush bar may cause damage to flooring when vacuuming Vacuuming Do not use without the clear bin and filters in place Fine dirt such as flour should only be vacuumed in very small amounts Do not use the appliance to pick up sharp hard objects small toys pins paper clips etc They may damage the appliance When vacuuming certain carpets may generate small static charges in the clear bin These are harmless and are not associated with the mains electricity supply To minimise any effect from this do not put your hand or insert any object into the clear bin unless you have first emptied it Clean the clear bin with a damp cloth only See Cleaning the clear bin Use extra care when cleaning on stairs Do not rest the appliance on chairs tables etc Do not press down on the nozzle with excessive force when using the appliance as this may cause damage Do not leave the cleaner head in one place on delicate floors On waxed floors the movement of the cleaner head may create an uneven lustre If this happens wipe with a damp cloth polish the area with wax and wait for it to dry Emptying the clear bin Empty as soon as the dirt reaches the level of the MAX mark do not overfill Ensure the appliance is disconnected from the charger before emptying the clear bin Be careful not to pull the ON trigger To make emptying the clear bin easier it is advisable to remove the wand and floor tool To minimise dustallergen contact when emptying encase the clear bin tightly in a plastic bag and empty To release the dirt hold the appliance by the handle pull the red lever back and lift upwards to release the cyclone Continue until the bin base automatically opens and releases the dirt Remove the clear bin carefully from the bag Seal the bag tightly dispose as normal To close push the cyclone downwards until it is in the normal position and manually close the base of the bin the base will click when it is securely in place Cleaning the clear bin Ensure the appliance is disconnected from the charger before removing the clear bin Be careful not to pull the ON trigger Remove the wand and floor tool To remove the cyclone hold the appliance by the handle pull the red lever towards you and lift upwards until the bin opens then push in the red button located behind the cyclone and lift the cyclone out To detach the clear bin from the appliance pull back on the red catch located at the base slide the clear bin down and carefully remove forwards from the main body Clean the clear bin with a damp cloth only Do not use detergents polishes or air fresheners to clean the clear bin Do not put the clear bin in a dishwasher Ensure the clear bin is completely dry before replacing To replace the clear bin align the tabs on the clear bin with the grooves on the main body and slide upwards into place until the catch clicks Slide the cyclone into the grooves of the main body and push downwards until it is in its normal position and manually close the base of the bin the base will click when it is securely in place Washable parts Your appliance has washable parts which require regular cleaning Follow the instructions below Washing your filter Ensure the appliance is disconnected from the charger before removing the filter Be careful not to pull the ON trigger Your appliance has one washable filter located as shown To remove the filter lift it out of the top of the appliance Check and wash the filter regularly according to instructions to maintain performance The filter may require more frequent washing if vacuuming fine dust or if used mainly in Powerful suction mode Wash the filter with cold water only No hot water and no detergents Run water over the outside of the filter until the water runs clear Squeeze and twist with both hands to make sure the excess water is removed Leave the filter to dry completely for a minimum of 24 hours Do not put the filter in a dishwasher washing machine tumble dryer oven microwave or near a naked flame To refit place the dry filter back into the top of the appliance Make sure it is seated properly Blockages automatic cutout This appliance is fitted with an automatic cutout If any part becomes blocked the appliance may automatically cut out This will happen after the motor pulses a number of times ie switches on and off in quick succession Leave to cool down before looking for blockages Ensure the appliance is disconnected from the charger before looking for blockages Failure to do so could result in personal injury Clear any blockage before restarting Refit all parts securely before using Clearing blockages is not covered by your guarantee Looking for blockages The motor will pulse when there is a blockage Please follow the instructions below to locate the blockage Ensure the appliance is disconnected from the charger before looking for blockages Be careful not to pull the ON trigger Do not operate while checking for blockages Doing so could result in personal injury Beware of sharp objects when checking for blockages To check for blockages in the main body of the appliance remove the clear bin and cyclone as per the instructions in the cleaning the clear bin section and remove the blockage Please consult the Stubborn blockages section of the illustrations for further guidance If you cannot clear an obstruction you may need to remove the brush bar Use a coin to unlock the fastener slide the brush bar out of the cleanerhead and remove the obstruction Replace the brush bar and secure it by tightening the fastener Ensure it is fixed firmly before operating the appliance This appliance has carbon fibre brushes Take care if coming into contact with them as they may cause minor skin irritation Wash your hands after handling the brushes Refit all parts securely before using Clearing blockages is not covered by your guarantee Charging and storing This appliance will switch OFF if the battery temperature is below 3C 374F This is designed to protect the motor and battery Do not charge the appliance and then move it to an area with a temperature below 3C 374F for storage purposes To help prolong battery life avoid recharging immediately after a full discharge Allow to cool for a few minutes Avoid using the appliance with the battery flush to a surface This will help it run cooler and prolong battery run time and life 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 9 - English - : 1 2 3 Clearing mini motorised tool brush bar obstructions Battery safety instructions If the battery needs replacing please contact the Dyson Helpline Use only Dyson chargers for charging this Dyson appliance The battery is a sealed unit and under normal circumstances poses no safety concerns In the unlikely event that liquid leaks from the battery do not touch the liquid and observe the following precautions Skin contact can cause irritation Wash with soap and water Inhalation can cause respiratory irritation Expose to fresh air and seek medical advice Eye contact can cause irritation Immediately flush eyes thoroughly with water for at least 15minutes Seek medical attention Disposal wear gloves to handle the battery and dispose of immediately following local ordinances or regulations Caution The battery used in this device may present a risk of fire or chemical burn if mistreated Do not disassemble short contacts heat above 60C140F or incinerate Keep away from children Do not disassemble and do not dispose of in fire Disposal information Dyson products are made from high grade recyclable materials Please dispose of this product responsibly and recycle where possible When your Dyson appliance reaches the end of its life we are responsible for its safe disposal You can send your old Dyson appliance back to us at our cost and we will organise for it to be recycled Please note that not all parts are recyclable Recycling of parts is subject to the capabilities of 3rd party suppliers Available in Australia only Simply 1 Box up your old Dyson appliance 2 Take the package to your local post office and send to the address below Dyson We Recycle Reply Paid 83215 Dyson Service Centre 810 Mangrove Lane Taren Point NSW 2229 Keep the used batteries away from children as these can still harm children if swallowed Your filter unit is nonwashable and nonrecyclable To dispose of your old filter unit remove it from the appliance and place it in your household waste bin The battery should be removed from the product before disposal ONLINE SUPPORT For online help general tips videos and useful information about Dyson AU wwwdysoncomausupport NZ wwwdysonconzsupport Dyson customer care Thank you for choosing to buy a Dyson appliance After registering your 2 year Dyson guarantee your Dyson appliance will be covered for parts and labour for 2 years from the date of purchase subject to the terms of the guarantee If you have any questions about your Dyson appliance call the Dyson Helpline with your serial number and details of wherewhen you bought the appliance Most questions can be solved over the phone by one of our trained Dyson Helpline staff Australian consumer law The details of the Dyson guarantee are set out below In addition to your rights under the Dyson guarantee we also provide the following statement as required by the Australian Consumer Law In Australia your Dyson appliance comes with statutory guarantees that cannot be excluded under the Australian Consumer Law You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage You are also entitled to have your Dyson appliance repaired or replaced if it fails to be of acceptable quality and the failure does not amount to a major failure If your Dyson appliance needs a service call the Dyson Customer Care Helpline so we can discuss the available options Limited 2 year guarantee Terms and conditions of the Dyson 2 year limited guarantee What is covered The repair or replacement of your Dyson appliance at Dysons discretion if it is found to be defective due to faulty materials workmanship or function within 2 years of purchase or delivery if any part is no longer available or out of manufacture Dyson will replace it with a functional replacement part This Dyson guarantee will only be valid if the appliance is used in the country in which it was sold What is not covered Under your Dyson guarantee Dyson shall not be liable for costs of repair or replacement of a product incurred as a result of Accidental damage faults caused by negligent use or care misuse neglect careless operation or handling of the Dyson appliance which is not in accordance with this Dyson Operating Manual Use of the Dyson appliance for anything other than normal domestic purposes in the country of purchase Use of parts not assembled or installed in accordance with the instructions of Dyson Use of parts and accessories other than those produced or recommended by Dyson Repairs or alterations carried out by parties other than Dyson or its authorised agents Damage from external sources such as transit weather electrical outages or power surges Failures caused by circumstances outside Dysons control Blockages please refer to the illustrations and the section Looking for Blockages in this Dyson Operating Manual for details of how to look for and clear blockages Normal wear and tear eg fuse brush bar etc Use of this appliance on rubble ash plaster Reduction in battery discharge time due to battery age or use cordless machines only If your Dyson guarantee does not apply you may have statutory rights and remedies available to you as a consumer If your Dyson guarantee does not apply you may have statutory rights and remedies available to you as a consumer If you are in any doubt as to what is covered by your Dyson guarantee please call the Dyson Customer Care Helpline 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 10 - English - : Dyson 2 year guarantee Terms and conditions of your Dyson 2 year guarantee The Dyson guarantee becomes effective from the date of purchase All work will be carried out by Dyson Appliances Aust Pty Limited Avery Robinson Ltd NZ or their authorised agents Any parts replaced by Dyson or its service agents will become the property of Dyson Appliances Aust Pty Limited or Avery Robinson Ltd NZ The repair or replacement of your Dyson appliance under the Dyson guarantee will not extend the period of the Dyson guarantee The Dyson guarantee provides benefits which are additional to and do not affect your statutory rights as a consumer You must provide proof of both the original and any subsequent deliverypurchase before any work can be carried out on your Dyson appliance Without this proof any work carried out pursuant to the Dyson guarantee and any associated delivery charges both to and from us will be at your cost subject to your statutory rights and remedies as a consumer Please keep your receipt or delivery note About your privacy When registering your Dyson Product You will need to provide us with basic contact information to register your product and enable us to support your Dyson guarantee When you register you will have the opportunity to choose whether you would like to receive communications from us If you optin to communications from Dyson we will send you details of special offers and news of our latest innovations We never sell your information to third parties and only use information that you share with us as defined by our privacy policies which are available on our website privacydysoncom 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 14 - English - : JN85061 PN2325401202 160317 Important Wash filter Wash filter with cold water at least once every month Ensure the filter is completely dry before refitting wwwdysoncom Dyson customer care Your Dyson appliance will be covered for parts and labour for 2 years from the date of purchase as detailed in the terms of the Dyson guarantee in this Dyson Operating Manual If you have a query about your Dyson appliance contact us via the website Alternatively call the Dyson Customer Care Helpline quoting your serial number and details of where and when you bought the appliance Most queries can be solved over the phone by one of our Dyson Customer Care Helpline staff DYSON CUSTOMER CARE Australia Website wwwdysoncomau Email aucustomercaredysoncom Dyson Customer Care 1800 239 766 MonFri 800am to 600pm EST SatSun 830am to 400pm EST Address Dyson Appliances Aust Pty Limited PO Box 2835 Taren Point NSW 2229 Australia New Zealand Website wwwdysonconz Email dysonaveryrobinsonconz Dyson Customer Care 0800 397 667 MonFri 830am to 500pm Address Avery Robinson Ltd Unit 6 99 Carbine Road Mount Wellington Auckland 1060 New Zealand 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
• Page 16 - English - : REGISTER ONLINE Visit our website to register your Dyson full parts and labour guarantee online AU wwwdysoncomauregister NZ wwwdysonconzregister REGISTER BY PHONE Call our dedicated Helpline AU 1800 239 766 NZ 0800 397 667 REGISTER BY MAIL Complete and return the form to Dyson in the envelope supplied Date of purchase Country of purchase Australia New Zealand Serial number Privacy Act Dyson may use this information for future marketing and research purposes including sending commercial electronic messages and may disclose it to third parties for the purposes of providing the services you have requested or to our business partners or professional advisers If you wish to access your personal information or see our full privacy policy please contact us at aucustomercaredysoncom If you wish to receive marketing information by these methods from Dyson please tick this box Title Surname First name Telephone email Postcode Address Mobile Store of purchase GUARANTEE FORM 20032017 1010 C85061SV11OPMANANZX285AV7ANM85061indd154c0s
