English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (fig. 1)
1 Trimming guard
2 Cutting unit
3 On/off button
4 Socket for small plug
5 Small plug
6 Battery charge indcator
7 Supply unit
not shown: cleaning brush
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry (Fig.
2).
Warning
- To charge the battery, only
use the detachable supply
unit (A00390) provided with
the appliance.
- The supply unit contains a
transformer. Do not cut off
the supply unit to replace it
with another plug, as this
causes a hazardous situation.
- This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
- Always check the appliance
before you use it. Do not use
the appliance if it is damaged,
as this may cause injury.
Always replace a damaged
part with one of the original
type.
- This appliance contains
batteries that are non-
replaceable.
- Do not open the appliance to
replace the rechargeable
battery.
1
2
7
5
3
4
6
1
Caution
- This appliance is not
washable.Never immerse the
appliance in water and do not
rinse it under the tap (Fig. 2).
- Only use this appliance for its
intended purpose as shown
in the user manual.
- For hygienic reasons, the
appliance should only be
used by one person.
- Never use compressed air,
scouring pads, abrasive
cleaning agents or aggressive
liquids such as petrol or
acetone to clean the
appliance.
- Do not use the supply unit in
or near wall sockets that
contain an electric air
freshener to prevent
irreparable damage to the
supply unit.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
- Maximum noise level: Lc = 75dB(A).
Charging
Charge the appliance fully before you use it for the
first time and after a long period of disuse.
It takes approximately 10 hours to fully charge the
appliance. When it is fully charged, the appliance
has a cordless operating time of up to 45 minutes.
1 Make sure the appliance is switched off.
2 Insert the small plug into the appliance (Fig. 3).
3 Put the supply unit in the wall socket.
- The charging light on the supply unit lights up
green to indicate that the product is charging.
Note: The charging light on the supply unit does
not change color and does not go out when the
product is fully charged.
4 After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Optimizing the lifetime of the
rechargeable battery
When you have charged the appliance for the first
time, we advise you to use it until the battery is
completely empty. Continue to use the appliance
until the motor almost stops running during a
session. Then recharge the battery. Follow this
procedure at least twice a year.
- Slide the on/off button up to switch the
product on or off (Fig. 4).
Using the appliance
Note: Switch off and clean the appliance after each
use.
Always comb the beard and/or moustache with a
fine comb before you start trimming.
Be careful when you trim for the first time. Do
not move the trimmer too fast. Make smooth
and gentle movements.
Trimming with comb
Note: When you trim for the first time, start at the
highest length setting to familiarize yourself with
the appliance.
Use the trimming comb attached to the cutting
element to trim your beard and moustache in your
preferred style. Turn the zoom wheel to choose
from 11 length settings ranging from 0.5mm to
10mm (1/32in. to 13/32in.).
1 Slide the trimming comb straight into the
guiding groove of the appliance (Fig. 5).
2 Turn the zoom wheel to the desired setting (Fig.
6). The desired hair length setting is shown in
the center of the zoom wheel.
3 Switch on the appliance.
4 To trim most effectively, move the appliance
against the hair growth direction. Make sure
that the surface of the comb always stays in
contact with the skin.
Note: Since all hairs do not grow in the same
direction, you may want to try different
trimming positions (i.e. upwards, downwards, or
across). Practice is best for optimum results.
5 Regularly remove cut hair from the comb. If a lot
of hair has accumulated in the comb, remove it
from the appliance and blow and/or shake out
the hairs (Fig. 7). The selected hair length setting
does not change when the comb is removed.
6 Switch off and clean the appliance after each
use.
Trimming for 'stubble look'
1 Be certain trimming comb is attached to the
appliance and use setting 0.5mm (1/32in.) to
create a 'stubble look' trim (Fig. 8).
Trimming without comb
Use the trimmer without the trimming comb to trim
the edges and single hairs.
Be careful when you trim without the comb as
the cutting unit will remove every hair it
touches.
1 Pull the trimming guard straight off the
appliance (Fig. 10).
2 Switch the appliance on.
3 Make well-controlled movements. Touch the
hair lightly with the trimmer (Fig. 9).
Cleaning
Never use scouring pads, abrasive cleaning agents
or aggressive liquids such as gasoline or acetone
to clean the product.
Never dry the trimmer teeth with a towel or tissue,
as this may damage the trimmer teeth.
Caution: Never use scouring pads, abrasive
cleaning agents or aggressive liquids such as
petrol or acetone to clean the appliance.
1 Switch off the appliance and disconnect it from
the power outlet.
2 Wipe the housing of the appliance with a dry
cloth.
Caution: Never immerse the appliance in water,
or rinse it under the tap. Only the cutting unit
can be rinsed under the tap.
3 Remove the comb (Fig. 10) and clean it with the
cleaning brush and/or rinse it under the tap.
4 Remove the cutting unit by pushing against the
teeth of the cutting unit (Fig. 11) and clean it with
the brush or rinse it under the tap.
5 Carefully shake off excess water and let air dry
completely.
6 Insert the lug of the cutting unit into the guiding
slot and push the cutting unit back onto the
appliance (Fig. 12).
Ordering accessories
To buy accessories or spare parts, visit
www.philips.com/parts-and-accessories or go to
your Philips dealer. You can also contact the
Philips Consumer Care Center in your country (see
the international warranty leaflet for contact
details).
Recycling
- This symbol means that this product shall not
be disposed of with normal household waste
(2012/19/EU).
- This symbol means that this product contains a
built-in rechargeable battery which shall not be
disposed of with normal household waste
(2006/66/EC). Please take your product to an
official collection point or a Philips service
center to have a professional remove the
rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product. Before you remove
the battery, make sure that the product is
disconnected from the wall socket and that
the battery is completely empty.
Take any necessary safety precautions when
you handle tools to open the product and
when you dispose of the rechargeable battery.
1 Check if there are screws in the back or front of
the appliance. If so, remove them.
2 Remove the back and/or front panel of the
appliance with a screwdriver. If necessary, also
remove additional screws and/or parts until you
see the printed circuit board with the
rechargeable battery.
3 Remove the rechargeable battery.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
