INSTALLATION GUIDE
for the
SB-F-EXPEDEL/10W3v3
SB-F-EXPEDEL/10W3v3
2007 - Up Ford Expedition EL (long wheel base)
2007 - Up Ford Expedition EL (long wheel base)
Thank you for choosing a JL Audio Stealthbox
®
for your automotive sound system. With proper
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
®
installed by your authorized JL Audio
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 2 years if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox
®
be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
STEP 1
Collapse the third row seating.
Bring the lift tray to the up positions.
Remove the rear most storage cover.
Continued on Next Page
STEP 2
Remove the front storage cover
STEP 3
Remove the tailgate’s lower sill plate.
SB-F-EXPED2/10W3v3_INSTR_SKU#011237
SB-F-EXPED2/10W3v3_INSTR_SKU#011237
INSTALLATION
DIFFICULTY:
2
5
OUT
OF
ESTIMATED TIME:
12 HOURS
12 HOURS
