GE - General Electric JGBP79CEBCC GE Profile Spectra 30" User Manual

183D5580P144     49-85057-1 08-03 JR
JGBP79
Ranges
Safety Instructions . . . . . .2–8
Operating Instructions
Aluminum Foil  . . . . . . . . . . . .19
Clock and Timer  . . . . . . . . . .21
Electric Warming
Drawer  . . . . . . . . . . . . . . . .24, 25
Oven  . . . . . . . . . . . . . . . . .11–23
Baking and Roasting  . . . . . .19
Broiling, Broiling Guide . . . .20
Electric Ignition  . . . . . . .18, 43
Oven Control  . . . . . . . . .11, 12
Preheating  . . . . . . . . . . . . . .19
Sabbath Feature  . . . . . . .15–17
Self-Cleaning
Instructions . . . . . . . . . . . . . .26
Shelves  . . . . . . . . . . . . . . . . .18
Special Features  . . . . . . .13, 14
Thermostat Adjustment  . . . .23
Timed Baking
and Roasting . . . . . . . . . . . . .22
Surface Cooking . . . . . . . . .9, 10
Control Settings  . . . . . . . . . . .9
Care and Cleaning
Broiler Pan and Grid  . . . . . . .30
Burner Assembly . . . . . . . .27, 28
Burner Grates . . . . . . . . . . . . .29
Control Panel and Knobs . . . .32
Cooktop  . . . . . . . . . . . . . . . . .29
Door Removal  . . . . . . . . . . . .30
Oven Bottom  . . . . . . . . . . . . .29
Oven Light Replacement  . . . .31
Oven Vents  . . . . . . . . . . . . . . .32
Self-Cleaning Instructions  . . .26
Shelves and Racks . . . . . . . . . .33
Stainless Steel Surfaces . . . . . .33
Storage Drawer . . . . . . . . . . . .31
Top Light  . . . . . . . . . . . . . . . .32
Warming Drawer  . . . . . . . . . .31
Installation
Instructions
 . . . . . . . . . .34–46
Air Adjustment  . . . . . . . . . . . .44
Anti-Tip Device . . . . . . . . .37, 46
Checking Burner Ignition 42, 43
Connecting the Range
to Gas  . . . . . . . . . . . . . . . .38–40
Dimensions and
Clearances  . . . . . . . . . . . . . . .36
Electrical Connections  . . .41, 42
Leveling the Range  . . . . . . . .45
LP  . . . . . . . . . . . . . . . . . . . . . .46
Troubleshooting
Tips
 . . . . . . . . . . . . . . . . .47–50
Consumer Support
Consumer
Support  . . . . . . . . . .Back Cover
Product Registration . . . . .51, 52
Warranty for Customers
in Canada  . . . . . . . . . . . . . . . .55
Warranty for Customers
in the U.S.A.   . . . . . . . . . . . . .54
Owner’s Manual
& Installation
Instructions
XL44
™
Self-Cleaning Gas
Write the model and serial
numbers here:
Model #______________________
Serial #    ____________________
You can find them on a label on
the front of the range behind the
warming drawer or storage drawer.
GEAppliances.com

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

— Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

■ Do not try to light any appliance.

■ Do not touch any electrical switch;

do not use any phone in your building.

■ Immediately call your gas supplier

from a neighbor’s phone. Follow the

gas supplier’s instructions.

■ If you cannot reach your gas supplier,

call the fire department.

— Installation and service must be

performed by a qualified installer,

service agency or the gas supplier.

WARNING: If the information in this

manual is not followed exactly, a fire or

explosion may result causing property

damage, personal injury or death.

WARNING!

ANTI-TIP DEVICE

■ ALL RANGES CAN TIP

■ INJURY TO PERSONS

COULD RESULT

■ INSTALL ANTI-TIP

DEVICES PACKED WITH

RANGE

■ SEE INSTALLATION

INSTRUCTIONS

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,

electric shock, or to prevent property damage, personal injury, or loss of life.

All ranges can tip and injury could result.

To prevent accidental tipping of the range, attach it to the wall by installing the Anti-Tip device supplied.

To check if the device is installed and engaged properly, carefully tip the range forward. The Anti-Tip

device should engage and prevent the range from tipping over.

If you pull the range out from the wall for any reason, make sure the device is properly engaged

when you push the range back against the wall. If it is not, there is a possible risk of the range

tipping over and causing injury if you or a child stand, sit or lean on an open door.

Please refer to the Anti-Tip device information in this manual. Failure to take this precaution

could result in tipping of the range and injury.

WARNING ANTI-TIP DEVICE

GEAppliances.com

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Have the installer show you the location of the range gas shut-off valve and how to shut it off if

necessary.

■ Have your range installed and properly

grounded by a qualified installer,

in accordance with the Installation

Instructions. Any adjustment and service

should be performed only by qualified

gas range installers or service technicians.

■ Do not attempt to repair or replace any

part of your range unless it is specifically

recommended in this manual. All other

service should be referred to a qualified

technician.

■ Plug your range into a 120-volt grounded

outlet only. Do not remove the round

grounding prong from the plug. If in doubt

about the grounding of the home electrical

system, it is your personal responsibility and

obligation to have an ungrounded outlet

replaced with a properly grounded, 3-prong

outlet in accordance with the National

Electrical Code. Do not use an extension

cord with this appliance.

SAFETY PRECAUTIONS

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to

publish a list of substances known to the state to cause birth defects or other reproductive harm, and

requires businesses to warn customers of potential exposure to such substances.

Gas appliances can cause minor exposure to four of these substances, namely benzene, carbon

monoxide, formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or

LP fuels. Properly adjusted burners, indicated by a bluish rather than a yellow flame, will minimize

incomplete combustion. Exposure to these substances can be minimized by venting with an open

window or using a ventilation fan or hood.

Fluorescent light bulbs and safety valves on standing pilot ranges contain mercury. If your model has

these features, they must be recycled according to local, state and federal codes.

■ Locate the range out of kitchen traffic path

and out of drafty locations to prevent pilot

outage (on standing pilot models) and poor

air circulation.

■ Be sure all packaging materials are removed

from the range before operating it to

prevent fire or smoke damage should the

packaging material ignite.

■ Be sure your range is correctly adjusted by

a qualified service technician or installer for

the type of gas (natural or LP) that is to be

used. Your range can be converted for use

with either type of gas. See the Installation of

the range section.

■

WARNING: These adjustments must

be made by a qualified service technician in

accordance with the manufacturer’s

instructions and all codes and requirements

of the authority having jurisdiction. Failure

to follow these instructions could result in

serious injury or property damage. The

qualified agency performing this work

assumes responsibility for the conversion.

■ After prolonged use of a range, high floor

temperatures may result and many floor

coverings will not withstand this kind of use.

Never install the range over vinyl tile or

linoleum that cannot withstand such type

of use. Never install it directly over interior

kitchen carpeting.

■ Do not leave children alone or unattended

where a range is hot or in operation.

They could be seriously burned.

■ Do not allow anyone to climb, stand or hang

on the oven door, storage drawer, warming

drawer or cooktop. They could damage the

range and even tip it over, causing severe

personal injury.

■

CAUTION: Items of interest to

children should not be stored in cabinets

above a range or on the backsplash of a

range—children climbing on the range to

reach items could be seriously injured.

■ For your safety, never use your appliance

for warming or heating the room.

■ Never wear loose fitting or hanging

garments while using the appliance. Be

careful when reaching for items stored in

cabinets over the range. Flammable material

could be ignited if brought in contact with

flame or hot oven surfaces and may cause

severe burns.

■ Do not store flammable materials in an

oven, a range storage drawer, a warming

drawer or near a cooktop.

■ Do not store or use combustible materials,

gasoline or other flammable vapors and

liquids in the vicinity of this or any other

appliance.

■ Do not let cooking grease or other

flammable materials accumulate in or

near the range.

■ Do not use water on grease fires. Never pick

up a flaming pan. Turn the controls off.

Smother a flaming pan on a surface burner

by covering the pan completely with a

well-fitting lid, cookie sheet or flat tray.

Use a multi-purpose dry chemical or

foam-type fire extinguisher.

■ Flaming grease outside a pan can be put

out by covering it with baking soda or,

if available, by using a multi-purpose dry

chemical or foam-type fire extinguisher.

■ Flame in the oven or warming drawer can

be smothered completely by closing the oven

door or drawer and turning the control to

off or by using a multi-purpose dry chemical

or foam-type fire extinguisher.

■ Let the burner grates and other surfaces

cool before touching them or leaving them

where children can reach them.

■ Never block the vents (air openings) of the

range. They provide the air inlet and outlet

that are necessary for the range to operate

properly with correct combustion. Air

openings are located at the rear of the

cooktop, at the top and bottom of the

oven door, and at the bottom of the range

under the storage drawer or kick panel.

■ Large scratches or impacts to glass doors

can lead to broken or shattered glass.

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

SAFETY PRECAUTIONS

GEAppliances.com

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Use proper pan size—avoid pans that are unstable or easily tipped. Select cookware having flat bottoms

large enough to cover burner grates. To avoid spillovers, make sure cookware is large enough to contain

the food properly. This will both save cleaning time and prevent hazardous accumulations of food, since

heavy spattering or spillovers left on range can ignite. Use pans with handles that can be easily grasped

and remain cool.

WARNING!

SURFACE BURNERS

■ Always use the LITE position (on electric

ignition models) or the HI position (on

standing pilot models) when igniting the top

burners and make sure the burners have ignited.

■ Never leave the surface burners unattended at

high flame settings. Boilovers cause smoking and

greasy spillovers that may catch on fire.

■ Adjust the top burner flame size so it does

not extend beyond the edge of the cookware.

Excessive flame is hazardous.

■ Use only dry pot holders—moist or damp

pot holders on hot surfaces may result in

burns from steam. Do not let pot holders

come near open flames when lifting cookware.

Do not use a towel or other bulky cloth in

place of a pot holder.

■ When using glass cookware, make sure it

is designed for top-of-range cooking.

■ To minimize the possibility of burns, ignition

of flammable materials and spillage, turn

cookware handles toward the side or back

of the range without extending over

adjacent burners.

■ Carefully watch foods being fried at a high

flame setting.

■ Always heat fat slowly, and watch as it heats.

■ Do not leave any items on the cooktop. The

hot air from the vent may ignite flammable

items and will increase pressure in closed

containers, which may cause them to burst.

■ If a combination of oils or fats will be used

in frying, stir together before heating or

as fats melt slowly.

■ Use a deep fat thermometer whenever

possible to prevent overheating fat beyond

the smoking point.

■ Use the least possible amount of fat for

effective shallow or deep-fat frying. Filling

the pan too full of fat can cause spillovers

when food is added.

■ When flaming foods are under the hood,

turn the fan off. The fan, if operating,

may spread the flames.

■ Do not use a wok on the cooking surface if the

wok has a round metal ring that is placed over

the burner grate to support the wok. This ring

acts as a heat trap, which may damage the

burner grate and burner head. Also, it may

cause the burner to work improperly. This may

cause a carbon monoxide level above that

allowed by current standards, resulting in a

health hazard.

■ Foods for frying should be as dry as possible.

Frost on frozen foods or moisture on fresh

foods can cause hot fat to bubble up and

over the sides of the pan.

■ Never try to move a pan of hot fat, especially

a deep fat fryer. Wait until the fat is cool.

■ Do not leave plastic items on the cooktop—

they may melt if left too close to the vent.

■ Keep all plastics away from the surface burners.

■ To avoid the possibility of a burn, always be

certain that the controls for all burners are

at the OFF position and all grates are cool

before attempting to remove them.

■ If range is located near a window, do not hang

long curtains that could blow over the surface

burners and create a fire hazard.

■ When a pilot goes out (on standing pilot

models), you will detect a faint odor of gas

as your signal to relight the pilot. When

relighting the pilot, make sure burner controls

are in the OFF position, and follow instructions

in this manual to relight.

■ If you smell gas, and you have already made

sure pilots are lit (on standing pilot models),

turn off the gas to the range and call a

qualified service technician. Never use an

open flame to locate a leak.

■ Be careful when you clean the cooktop

because the area over the pilot (on standing

pilot models) will be hot.

■ Always turn the surface burner controls off

before removing cookware.

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

■ Do not use the oven for a storage area.

Items stored in the oven can ignite.

■ Keep the oven free from grease buildup.

■ Place the oven shelves in the desired

position while the oven is cool.

■ Pulling out the shelf to the stop-lock is a

convenience in lifting heavy foods. It is also

a precaution against burns from touching

hot surfaces of the door or oven walls. The

lowest position “R” is not designed to slide.

■ Do not heat unopened food containers.

Pressure could build up and the container

could burst, causing an injury.

■ Never use aluminum foil to line the oven

bottom. Improper use of foil could start

a fire.

■ Do not use aluminum foil anywhere in the

oven except as described in this manual.

Misuse could result in a fire hazard or

damage to the range.

■ When using cooking or roasting bags in the

oven, follow the manufacturer’s directions.

■ Do not use your oven to dry newspapers.

If overheated, they can catch fire.

■ Use only glass cookware that is

recommended for use in gas ovens.

■ Always remove the broiler pan from range as

soon as you finish broiling. Grease left in the

pan can catch fire if oven is used without

removing the grease from the broiler pan.

■ When broiling, if meat is too close to the

flame, the fat may ignite. Trim excess fat to

prevent excessive flare-ups.

■ Make sure the broiler pan is in place

correctly to reduce the possibility of

grease fires.

■ If you should have a grease fire in the broiler

pan, press the CLEAR/OFF pad, and keep

the oven door closed to contain fire until

it burns out.

Stand away from the range when opening the door of a hot oven. The hot air and steam that escape

can cause burns to hands, face and eyes.

OVEN

■ Be sure to wipe up excess spillage before

self-cleaning operation.

■ Before self-cleaning the oven, remove the

broiler pan, grid and other cookware.

■ Do not clean the door gasket. The door

gasket is essential for a good seal. Care

should be taken not to rub, damage or

move the gasket.

■ Clean only parts listed in this Owner’s

Manual.

■ If the self-cleaning mode malfunctions,

turn the oven off and disconnect the power

supply. Have it serviced by a qualified

technician.

■ Do not use oven cleaners. No commercial

oven cleaner or oven liner of any kind

should be used in or around any part of

the oven. Residue from oven cleaners will

damage the inside of the oven when the

self-clean cycle is used.

SELF-CLEANING OVEN

Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry to at least an

INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against foodborne illness.

COOK MEAT AND POULTRY THOROUGHLY…

GEAppliances.com

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

■ The purpose of the warming drawer

is to hold hot cooked foods at serving

temperature. Always start with hot food;

cold food cannot be heated or cooked in

the warming drawer.

■ Do not use the warming drawer to dry

newspapers. If overheated, they can catch

on fire.

■ Do not leave paper products, cooking

utensils or food in the warming drawer

when not in use.

■ Never leave jars or cans of fat drippings in

or near your warming drawer.

■ Always keep wooden and plastic utensils and

canned food a safe distance away from your

warming drawer.

■ Do not warm food in the warming drawer

for more than two hours.

■ Do not touch the heating element or the

interior surface of the warming drawer.

These surfaces may be hot enough to

burn.

REMEMBER: The inside surface of the

warming drawer may be hot when the

drawer is opened.

■ Use care when opening the drawer. Open

the drawer a crack and let hot air or steam

escape before removing or replacing food.

Hot air or steam which escapes can cause

burns to hands, face and/or eyes.

■ Do not use aluminum foil to line the

drawer. Foil is an excellent heat insulator

and will trap heat beneath it. This will

upset the performance of the drawer and

it could damage the interior finish.

ELECTRIC WARMING DRAWER (on some models)

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

Using the surface burners.

Throughout this manual, features and appearance may vary from your model.

How to Light a Surface Burner

Push the control knob in and turn it to

the LITE position.

You will hear a little clicking noise—

the sound of the electric spark igniting

the burner.

Turn the knob to adjust the flame size.

If the knob stays at LITE, it will continue

to click.

When one burner is turned to LITE,

all the burners spark. Do not attempt to

disassemble or clean around any burner

while another burner is on. An electric

shock may result, which could cause you

to knock over hot cookware.

Push the control knob in and turn it

to the LITE position.

How to Select Flame Size

For safe handling of cookware, never let the flames

extend up the sides of the cookware.

Watch the flame, not the knob, as you

reduce heat. The flame size on a gas burner

should match the cookware you are using.

Any flame larger than the bottom of the

cookware is wasted and only serves to heat

the handle.

In Case of Power Failure

In case of a power failure, you can light

the surface burners on your range with

a match. Hold a lit match to the burner,

then push in and turn the control knob

to the LITE position. Use extreme caution

when lighting burners this way.

Surface burners in use when an electrical

power failure occurs will continue to

operate normally.

Before Lighting a Burner

■ If drip pans are supplied with your range,

they should be used at all times.

■ Make sure all grates on the range are

in place before using any burner.

After Lighting a Burner

■ Do not operate the burner for an

extended period of time without

cookware on the grate. The finish on

the grate may chip without cookware to

absorb the heat.

■ Be sure the burners and grates are cool

before you place your hand, a pot holder,

cleaning cloths or other materials on

them.

On Ranges With Sealed Burners

The smaller burner (right rear position)

will give the best simmer results. It offers

precise cooking performance for delicate

foods, such as sauces or foods which need

to cook over low heat for a long time.

It can be turned down to a very low simmer

setting.

The largest burners are higher powered

than the others and will bring liquids to

a boil quicker.

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

GEAppliances.com

Using the surface burners.

Wok This Way (on models with sealed burners)

We recommend that you use a flat-bottomed wok. They

are available at your local retail store.

A traditional round bottom wok can be

used with Wok Holder accessory, model

JXWK which can be ordered from your

appliance dealer. The Wok Holder fits on

top of the range grate to provide support

and proper air circulation for traditional

round bottom woks only. Do not use flat-

bottomed woks with the Wok Holder.

Do not use a wok on any other support

ring. Placing the ring over the burner grate

may cause the burner to work improperly,

resulting in carbon monoxide levels above

allowable current standards. This could be

dangerous to your health. Do not try to use

such woks without the ring unless you are

using the Wok Holder. You could be

seriously burned if the wok tipped over.

Use a flat-bottomed wok.

Stove Top Grills (on models with sealed burners)

Do not use stove top grills on your sealed

gas burners. If you use the stove top grill

on the sealed gas burner, it will cause

incomplete combustion and can result

in exposure to carbon monoxide levels

above allowable current standards.

This can be hazardous to your health.

Top-of-Range Cookware

Aluminum: Medium-weight cookware is

recommended because it heats quickly

and evenly. Most foods brown evenly in

an aluminum skillet. Use saucepans with

tight-fitting lids when cooking with

minimum amounts of water.

Cast-Iron: If heated slowly, most skillets

will give satisfactory results.

Enamelware: Under some conditions,

the enamel of some cookware may melt.

Follow cookware manufacturer’s

recommendations for cooking methods.

Glass: There are two types of glass

cookware—those for oven use only and

those for top-of-range cooking (saucepans,

coffee and teapots). Glass conducts heat

very slowly.

Heatproof Glass Ceramic: Can be used for

either surface or oven cooking. It conducts

heat very slowly and cools very slowly. Check

cookware manufacturer’s directions to be

sure it can be used on gas ranges.

Stainless Steel: This metal alone has poor

heating properties and is usually combined

with copper, aluminum or other metals for

improved heat distribution. Combination

metal skillets usually work satisfactorily if

they are used with medium heat as the

manufacturer recommends.

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

Using the oven controls.

Throughout this manual, features and appearance may vary from your model.

Oven Control, Clock and Timer Features and Settings

BAKE Pad

Press this pad to select the bake function.

BROIL HI/LO Pad

Press this pad to select the broil function.

Function Indicators

Light up to show whether the oven is in the

bake, broil or self-clean mode.

Oven Temperature and Broil Display

Shows the oven temperature or the broil

setting selected.

Time Display

Shows the time of day, the times set for the

timer or automatic oven operation.

Program Status

Words light up in the display to indicate

what is in the time display. Programmed

information can be displayed at any time by

touching the pad of the operation you want

to see. For example, you can display the

current time of day while the timer is

counting down by pressing the CLOCK pad.

If “F—and a number or letter” flash in the display

and the oven control signals, this indicates a function

error code.

On models with an oven door latch, if the function error

code appears during the self-cleaning cycle, check the oven

door latch. The latch handle may have been moved, even if

only slightly, from the latched position. Make sure the latch

is moved to the right as far as it will go.

Press the CLEAR/OFF pad. Allow the oven to cool for one

hour. Put the oven back into operation. If the function error

code repeats, disconnect the power to the range and call

for service.

If a flashing time of day is in the display, you have

experienced a power failure. Reset the clock.

If your oven was set for a timed oven operation when

the power outage occurred, the clock and all programmed

functions must be reset.

COOKING TIME Pad

Press this pad and then press the INCREASE

or DECREASE pads to set the amount of time

you want your food to cook. The oven will

shut off when the cooking time has run out.

START TIME Pad

Use along with the COOKING TIME or SELF

CLEAN pad to set the oven to start and stop

automatically at a time you set.

CLOCK Pad

Press this pad before setting the clock. The

time of day will flash in the display when the

oven is first turned on.

KITCHEN TIMER ON/OFF Pad

Press this pad to select the timer feature.

START Pad

Must be pressed to start any cooking or

cleaning function.

DECREASE Pad

Short taps to this pad will decrease the time

or temperature by small amounts. Press and

hold the pad to decrease the time or

temperature by larger amounts.

INCREASE Pad

Short taps to this pad will increase the time

or temperature by small amounts. Press

and hold the pad to increase the time or

temperature by larger amounts

CLEAR/OFF Pad

Press this pad to cancel ALL oven operations

except the clock and timer.

SELF CLEAN Pad

Press this pad to select the self-cleaning

function. See the Using the self-cleaning oven

section.

(on models with INCREASE [+] and DECREASE [–] pads only)

GEAppliances.com

Using the oven controls.

Oven Control, Clock and Timer Features and Settings

BAKE Pad

Press this pad to select the bake function.

BROIL HI/LO Pad

Press this pad to select the broil function.

Function Indicators

Light up to show whether the oven is in the

bake, broil or self-clean mode.

Oven Temperature and Broil Display

Shows the oven temperature or the broil

setting selected.

Time Display

Shows the time of day, the times set for the

timer or automatic oven operation.

Program Status

Words light up in the display to indicate

what is in the time display. Programmed

information can be displayed at any time by

touching the pad of the operation you want

to see. For example, you can display the

current time of day while the timer is

counting down by pressing the CLOCK pad.

If “F—and a number or letter” flash in the display

and the oven control signals, this indicates a function

error code.

On models with an oven door latch, if the function error

code appears during the self-cleaning cycle, check the oven

door latch. The latch handle may have been moved, even if

only slightly, from the latched position. Make sure the latch

is moved to the right as far as it will go.

Press the CLEAR/OFF pad. Allow the oven to cool for one

hour. Put the oven back into operation. If the function error

code repeats, disconnect the power to the range and call

for service.

If a flashing time of day is in the display, you have

experienced a power failure. Reset the clock.

If your oven was set for a timed oven operation when

the power outage occurred, the clock and all programmed

functions must be reset.

COOKING TIME Pad

Press this pad and then press the number pads

to set the amount of time you want your food

to cook. The oven will shut off when the

cooking time has run out.

DELAY START Pad

Use along with the COOKING TIME or SELF

CLEAN pad to set the oven to start and stop

automatically at a time you set.

CLOCK Pad

Press this pad before setting the clock. The

time of day will flash in the display when the

oven is first turned on.

KITCHEN TIMER ON/OFF Pad

Press this pad to select the timer feature.

START Pad

Must be pressed to start any cooking or

cleaning function.

CLEAR/OFF Pad

Press this pad to cancel ALL oven operations

except the clock and timer.

Number Pads

Use to set any function requiring numbers

such as the time of day on the clock, the

timer, the oven temperature, the internal

food temperature, the start time and length

of operation for timed baking and self-

cleaning.

TOP LIGHT Pad

Press this pad to turn the surface light on

or off.

SELF CLEAN Pad

Press this pad to select the self-cleaning

function. See the Using the self-cleaning oven

section.

(on models with number pads only)

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Special features of your oven control. (on some models) GEAppliances.com

Your new control has a cook and hold feature that

keeps cooked foods warm for up to 3 hours after the

cooking function is finished. You can only use Cook

and Hold with timed cooking features.

To activate this feature, follow the steps

below.

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the COOKING TIME pad. The

display will show Hld OFF.

Press the COOKING TIME pad again to

activate the feature. The display will

show Hld ON.

Press the START pad to activate the

cook and hold feature and leave the

control set in this special features

mode.

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Your new touch pad control has additional features that you may choose to use. The following are the features and how

you may activate them.

The special feature modes can only be activated while the display is showing the time of day clock. They remain in the

control’s memory until the steps are repeated.

When the display shows your choice, press the START pad. The special features will remain in memory after a power failure.

12-Hour Shut-Off

With this feature, should you forget and leave the

oven on, the control will automatically turn off the

oven after 12 hours during baking functions or after

3 hours during a broil function.

If you wish to turn off this feature, follow

the steps below.

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the START TIME or DELAY START

pad. The display will show 12 shdn

(12-hour shutoff). Press the START

TIME or DELAY START pad again and

the display will show no shdn (no

shutoff).

Press the START pad to activate the no

shutoff and leave the control set in this

special features mode.

Fahrenheit or Centigrade Temperature Selection

Your oven control is set to use the Fahrenheit

temperature selections but you may change this

to use the Centigrade selections.

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the BROIL HI/LO and COOKING

TIME pads at the same time. The

display will show F (Fahrenheit).

Press the BROIL HI/LO and COOKING

TIME pads at the same time again.

The display will show C (Celsius).

Press the START pad.

Control Lockout

Your control will allow you to lock down the touch

pads so they cannot be activated when pressed.

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the SELF CLEAN pad. The display

will show LOC OFF.

Press the SELF CLEAN pad again. The

display will show LOC.

Press the START pad to activate the

control lockout feature and leave

the control set in this special features

mode.

When this feature is on and the touch pads

are pressed the control will beep and the

display will show LOC.

NOTE: The control lockout mode will not affect the

CLOCK, KITCHEN TIMER ON/OFF and OVEN LIGHT

touch pads.

Appearance may vary.

Cook and Hold

Appearance may vary.

Special features of your oven control. (on some models)

Tones at the End of a Timed Cycle

At the end of a timed cycle, 3 short beeps will

sound followed by one beep every 6 seconds until

the CLEAR/OFF pad is pressed. This continuous

6 second beep may be canceled.

To cancel the 6-second beep:

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the KITCHEN TIMER ON/OFF

pad. The display shows CON BEEP

(continuous beep). Press the KITCHEN

TIMER ON/OFF pad again. The display

shows BEEP. (This cancels the one

beep every 6 seconds.)

Press the START pad.

12-Hour, 24-Hour or Clock Blackout

Your control is set to use a 12-hour clock.

If you would prefer to have a 24-hour

military time clock or black out the clock

display, follow the steps below.

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the CLOCK pad once. The display

will show 12 hr. If this is the choice you

want, press the START pad.

Press the CLOCK pad again to change

to the 24-hour military time clock.

The display will show 24 hr. If this is the

choice you want, press the START pad.

Press the CLOCK pad again to black out

the clock display. The display will show

OFF. If this is the choice you want,

press the START pad.

NOTE: If the clock is in the blackout mode you will

not be able to use the Delay Start function.

Appearance may vary.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Changing the Speed of the Increase or Decrease Pads

(on some models)

As you use the INCREASE or DECREASE pads when

setting a time or temperature, you may notice the

display changes slowly. This special feature allows

you to change the speed.

To set the speed you prefer, follow the steps

below.

Press the BAKE and BROIL HI/LO pads

at the same time for 3 seconds until

the display shows SF.

Press the INCREASE pad. The display

will show you a set speed between

1 and 5.

Press the INCREASE pad to increase

the speed up to the number 5.

Press the DECREASE pad to decrease

the speed down to the number 1.

Press START to activate the setting and

leave the control set in this special

features mode.

GEAppliances.com

Using the Sabbath Feature—models with number pads.

(on some models) (Designed for use on the Jewish Sabbath and Holidays)

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning, or

Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the door

is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch on the

control panel, the oven light may be turned on and left on.

How to Set for Regular Baking/Roasting

Make sure the clock shows the correct time of day and

the oven is off.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the DELAY START pad until SAb bAtH

appears in the display.

Touch the START pad and ⊃ will appear

in the display.

Touch the BAKE pad. No signal will

be given.

Using the number pads, enter the desired

temperature between 170° and 550°.

No signal or temperature will be given.

Touch the START pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃ will appear in the display indicating

that the oven is

baking/roasting.

If ⊃

doesn’t appear in the display, start

again at Step 4.

To adjust the oven temperature, touch the

BAKE pad, enter the new temperature using

the number pads, and touch the START pad.

NOTE: The CLEAR/OFF and COOKING TIME pads

are active during the Sabbath feature.

⊃

How to Set for Timed Baking/Roasting – Immediate Start and Automatic Stop

Make sure the clock shows the correct time of day and the

oven is off.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the DELAY START pad until SAb bAtH

appears in the display.

Touch the START pad and ⊃ will appear in

the display.

Touch the COOKING TIME pad.

Touch the number pads to set the desired

length of cooking time between 1 minute

and 9 hours and 99 minutes. The cooking

time that you entered will be displayed.

Touch the START pad.

Touch the BAKE pad. No signal will be

given.

Using the number pads, enter the desired

temperature. No signal or temperature will

be given.

Touch the START pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃ will appear in the display indicating

that the oven is

baking/roasting.

If ⊃

doesn’t appear in the display, start

again at Step 7.

To adjust the oven temperature, touch the

BAKE pad, enter the new temperature using the

number pads, and touch the START pad.

When cooking is finished, the display will

change from ⊃ to ⊃ and 0:00 will appear,

indicating that the oven has turned OFF but is

still set in Sabbath. Remove the cooked food.

⊃

How to Exit the Sabbath Feature

Touch the CLEAR/OFF pad.

If the oven is cooking, wait for a random

delay period of approximately 30 seconds

to 1 minute, until only ⊃ is in the display.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the DELAY START pad until 12 shdn

or no shdn appears in the display.12 shdn

indicates that the oven will automatically

turn off after 12 hours. no shdn indicates

that the oven will not automatically

turn off.

Touch the START pad.

NOTE: If a power outage occurred while

the oven was in Sabbath, the oven will

automatically turn off and stay off even

when the power returns. The oven

control must be reset.

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃ the oven is

baking/roasting.

⊃

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃ the oven is

baking/roasting.

⊃

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

How to Set for Timed Baking/Roasting – Immediate Start and Automatic Stop

NOTE: To understand how the oven control works,

practice using regular (non-Sabbath) Immediate Start and

Automatic Stop before entering the Sabbath mode.

Make sure the clock shows the correct time of day and

the oven is off.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the START TIME pad until SAb bAtH

appears in the display.

Press the START pad and ⊃ will appear in

the display.

Press the COOKING TIME pad.

Press the INCREASE or DECREASE pads to

set the desired length of cooking time

between 1 minute and 9 hours and 59

minutes. The cooking time that you

entered will be displayed.

Press the START pad.

Press the BAKE pad. No signal will be given.

The preset starting temperature will

automatically be set to 350°. Tap the

INCREASE or DECREASE pads to

increase or decrease the temperature in

5° increments. The temperature can be

set between 170° and 550°. No signal or

temperature will be given.

Press the START pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃ will appear in the display indicating

that the oven is baking/roasting. If ⊃

does not appear in the display, start again

at step 7.

To adjust the oven temperature, press the

BAKE pad and tap the INCREASE or DECREASE

pads to increase or decrease the temperature

in 5° increments. Press the START pad.

When cooking is finished, the display will

change from ⊃ to ⊃ and 0:00 will appear,

indicating that the oven has turned OFF but is

still set in Sabbath. Remove the cooked food.

⊃

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃ the oven is

baking/roasting.

⊃

Using the Sabbath Feature—

models with INCREASE/DECREASE pads.

(on some models) (Designed for use on the Jewish Sabbath and Holidays)

The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning, or

Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the door

is closed. The bulb may be removed. See the Oven Light Replacement section. On models with a light switch on the

control panel, the oven light may be turned on and left on.

How to Set for Regular Baking/Roasting

NOTE: To understand how the oven control works,

practice using regular baking (non-Sabbath) before

entering Sabbath mode.

Make sure the clock shows the correct time of day and the

oven is off.

Press and hold both the BAKE and BROIL

HI/LO pads, at the same time, until the

display shows SF.

Tap the START TIME pad until SAb bAtH

appears in the display.

Press the START pad and ⊃ will appear

in the display.

Press the BAKE pad. No signal will

be given.

The preset starting temperature will

automatically be set to 350°. Tap the

INCREASE or DECREASE pads to

increase or decrease the temperature in

5° increments. The temperature can be

set between 170° and 550°. No signal

or temperature will be given.

Press the START pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃ will appear in the display indicating

that the oven is baking/roasting. If ⊃

does not appear in the display, start again

at step 4.

To adjust the oven temperature, press

the BAKE pad and tap the INCREASE or

DECREASE pads to increase or decrease the

temperature in 5° increments. Press the

START pad.

NOTE: The CLEAR/OFF and COOKING TIME pads

are active during the Sabbath feature.

⊃

When the display shows ⊃ the

oven is set in Sabbath. When the

display shows ⊃ the oven is

baking/roasting.

⊃

GEAppliances.com

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

How to Exit the Sabbath Feature

Press the CLEAR/OFF pad.

If the oven is cooking, wait

for a random delay period of

approximately 30 seconds to 1 minute,

until only ⊃ is in the display.

Press and hold both the BAKE and

BROIL HI/LO pads, at the same time,

until the display shows SF.

Tap the START TIME pad until 12 shdn

or no shdn appears in the display.

12 shdn indicates that the oven will

automatically turn off after 12 hours.

no shdn indicates that the oven will

not automatically turn off.

Press the START pad.

NOTE: If a power outage occurred while

the oven was in Sabbath mode, the oven

will automatically turn off and the oven

control must be reset.

Using the oven.

To avoid possible burns, place the shelves in the desired position before you turn the oven on.

Before you begin…

The shelves have stop-locks, so that when

placed correctly on the supports, they will

stop before coming completely out, and

will not tilt.

When placing and removing cookware,

pull the shelf out to the bump on the

shelf support.

To remove a shelf, pull it toward you,

tilt the front end up and pull it out.

To replace, place the end of the shelf

(stop-locks) on the support, tilt up the

front and push the shelf in.

The oven has 5 shelf positions.

It also has a special low shelf

position (R) for roasting extra large

items, such as a large turkey.

Power Outage for Electric Ignition Models

CAUTION: Do not make any attempt to operate the

electric ignition oven during an electrical power

failure.

The oven or broiler cannot be lit during a

power failure. Gas will not flow unless the

glow bar is hot.

If the oven is in use when a power failure

occurs, the oven burner shuts off and

cannot be re-lit until power is restored. This

is because the flow of gas is automatically

stopped and will not resume when power

is restored until the glow bar has reached

operating temperature.

Oven Light

Use the switch on the lower control panel

to turn the light on or off.

Oven Vent

Your oven is vented through ducts at the

rear of the range. Do not block these ducts

when cooking in the oven—it is important

that the flow of hot air from the oven and

fresh air to the oven burner be

uninterrupted. Avoid touching the vent

openings or nearby surfaces during oven or

broiler operation—they may become hot.

■ Handles of pots and pans on the cooktop may

become hot if left too close to the vent.

■ Do not leave plastic items on the cooktop—

they may melt if left too close to the vent.

■ Do not leave any items on the cooktop. The hot

air from the vent may ignite flammable items and

will increase pressure in closed containers, which

may cause them to burst.

■ Metal items will become very hot if they are left

on the cooktop, and could cause burns.

Plastic items on the cooktop may

melt if left too close to the vent.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

If your model has a door latch, do not lock the oven door with the latch during baking or roasting. The latch is used for

self-cleaning only.

How to Set the Oven for Baking or Roasting

Press the BAKE pad.

Press the + or – pad (on some

models) or the number pads (on

some models) until the desired

temperature is displayed.

The oven will start automatically. The word

ON and 100° will be displayed. As the oven

heats up, the display will show the changing

temperature. When the oven reaches the

temperature you set, a tone will sound.

To change the oven temperature during BAKE cycle,

press the BAKE pad and then the + or – or number

pads to get the new temperature.

Press the CLEAR/OFF pad when baking

is finished and then remove the food

from the oven.

Type of Food Shelf Position

Frozen pies (on cookie sheet) B or C

Angel food cake, A

bundt or pound cakes

Biscuits, muffins, brownies, B or C

cookies, cupcakes,

layer cakes, pies

Casseroles B or C

Roasting R, A or B

Preheating and Pan Placement

Preheat the oven if the recipe calls for it.

To preheat, set the oven at the correct

temperature. Preheating is necessary for

good results when baking cakes, cookies,

pastry and breads.

For ovens without a preheat indicator light or tone,

preheat 10 minutes.

Baking results will be better if baking pans

are centered in the oven as much as

possible. Pans should not touch each other

or the walls of the oven. If you need to use

two shelves, stagger the pans so one is not

directly above the other, and leave

approximately 1

⁄

″ between pans, from

the front, back and sides of the wall.

Aluminum Foil

Never cover the oven bottom with

aluminum foil.

You can use aluminum foil to line the

broiler pan and broiler grid. However,

you must mold the foil tightly to the grid

and cut slits in it just like the grid.

Aluminum foil may also be used to catch a spillover.

Never entirely cover a shelf with aluminum

foil. This will disturb the heat circulation

and result in poor baking.

A smaller sheet of foil may be used to catch

a spillover by placing it on a lower shelf

several inches below the food.

Cut slits in the foil just like the grid.

Oven Moisture

As your oven heats up, the temperature

change of the air in the oven may cause

water droplets to form on the door glass.

These droplets are harmless and will

evaporate as the oven continues to heat up.

The oven has a special low shelf (R)

position just above the oven bottom.

Use it when extra cooking space is

needed, for example, when roasting

a large turkey. The shelf is not

designed to slide out at this position.

GEAppliances.com

Using the oven.

If your model has a door latch, do not lock the oven door with the latch during broiling.

The latch is used for self-cleaning only.

Broiling Guide

Quantity and/ Shelf First Side Second Side

Food or Thickness Position Time (min.) Time (min.) Comments

Bacon 1/2 lb. C 4 3 Arrange in single layer.

(about 8 thin slices)

Ground Beef 1 lb. (4 patties) D 10–11 7 Space evenly. Up to 8

Well Done 1/2 to 3/4″ thick patties take about the

same time.

Beef Steaks

Rare

†

1″ thick C 9 7 Steaks less than 1″ thick cook

Medium 1 to 1

⁄

lbs. C 12 5–6 through before browning.

Well Done C 13 8–9 Pan frying is recommended.

Slash fat.

Rare

†

⁄

″ thick C 10 6–7

Medium 2 to 2

⁄

lbs. C 12–15 10–12

Well Done C 25 16–18

Chicken 1 whole B 30–35 15–20 Brush each side with melted

2 to 2

⁄

lbs., butter. Broil skin-side-down

split lengthwise first.

4 bone-in breasts B 25–30 10–15

Lobster Tails 2–4 C 13–16 Do not Cut through back of shell.

6 to 8 oz. each turn Spread open. Brush with

over. melted butter before broiling

and after half of broiling

time.

Fish Fillets 1/4 to 1/2″ thick D 6 6 Handle and turn very

carefully. Brush with lemon

butter before and during

cooking, if desired. Preheat

broiler to increase browning.

Ham Slices 1″ thick C 8 8

(precooked)

1/2″ thick D 6 6

Pork Chops 2 (1/2″ thick) D 10 8 Slash fat.

Well Done 2 (1″ thick) about 1 lb. D 15 8

Lamb Chops

Medium 2 (1″ thick) about 10 D 8 4–7 Slash fat.

Well Done to 12 oz. D 10 10

Medium 2 (1

⁄

″ thick) about 1 lb. D 10 4–6

Well Done D 17 12–14

How to Set the Oven for Broiling

Place the meat or fish on the broiler

grid in the broiler pan.

Follow suggested shelf positions in the

Broiling Guide.

The oven door must be closed during

broiling.

Press the BROIL HI/LO pad once for

HI Broil.

To change to LO Broil, press the BROIL

HI/LO pad again.

Press the START pad.

When broiling is finished, press the

CLEAR/OFF pad.

Serve the food immediately, and leave the

pan outside the oven to cool during the

meal for easiest cleaning.

Always use the broiler pan and grid

that came with your oven. It is

designed to minimize smoking and

spattering by trapping juices in the

shielded lower part of the pan.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

The size, weight, thickness,

starting temperature, and

your preference of

doneness will affect broiling

times. This guide is based

on meats at refrigerator

temperature.

†The U.S. Department of Agriculture

says “Rare beef is popular, but you

should know that cooking it to only

140°F. means some food poisoning

organisms may survive.” (Source:

Safe Food Book, Your Kitchen

Guide, USDA Rev. June 1985.)

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Using the clock and timer.

Not all features are on all models.

To Set the Clock

The clock must be set to the correct time

of day for the automatic oven timing

functions to work properly. The time of day

cannot be changed during a timed baking

or self-cleaning cycle.

Press the CLOCK pad.

Depending on which model you have,

you will set the clock by pressing either

the number pads or + or – pads.

Press the number pads the same way you

read them. For example, to set 12:34, press

the number pads 1, 2, 3 and 4 in that order.

If number pads are not pressed within one

minute after you press the CLOCK pad, the

display reverts to the original setting. If this

happens, press the CLOCK pad and reenter

the time of day.

Press the START pad. This enters the

time and starts the clock.

To check the time of day when the display is

showing other information, simply press the CLOCK

pad. The time of day shows until another pad is

pressed.

Make sure the clock is set to the

correct time of day.

To Set the Timer

The timer does not control oven operations.

The maximum setting on the timer is 11 hours

and 59 minutes.

Press the KITCHEN TIMER ON/OFF pad.

Press the + or – or number pads to

set the time. For example, to enter 2

hours and 45 minutes, touch 2, 4 and 5

in that order.

If you make a mistake, press the KITCHEN TIMER

ON/OFF pad and begin again.

Press the START pad. After pressing

the START pad, SET disappears; this

tells you the time is counting down,

although the display does not change

until one minute has passed.

When the timer reaches :00, the

control will beep 3 times followed by

one beep every 6 seconds until the

KITCHEN TIMER ON/OFF pad is pressed.

The 6-second tone can be canceled by following

the steps in the Special features of your oven

control section under Tones at the End of a Timed

Cycle. Display then shows the time of day.

The timer is a minute timer only.

The CLEAR/OFF pad does not affect

the timer.

Power Outage

If a flashing time is in the display, you have

experienced a power failure. Reset the clock.

To reset the clock, press the CLOCK pad.

Enter the correct time of day by pressing

the + or – or the appropriate number pads.

Press the START pad.

GEAppliances.com

Using the timed baking and roasting features.

If your model has a door latch, do not lock the oven door with the latch during timed cooking. The latch is used for

self-cleaning only.

NOTE: Foods that spoil easily–such as milk, eggs, fish, stuffings, poultry and pork–should not be allowed to sit for more

than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that the oven

light is off because heat from the bulb will speed harmful bacteria growth.

The low temperature zone of this range (between 150°F and 200°F) is available to keep hot cooked foods warm.

Food kept in the oven longer than 2 hours at these low temperatures may spoil.

How to Set an Immediate Start and Automatic Stop

The oven will turn on immediately and cook for a

selected length of time. At the end of the cooking

time the oven will turn off automatically.

Make sure the clock shows the correct

time of day.

Press the BAKE pad.

Press the + or – or number pads to

set the oven temperature.

Press the COOKING TIME pad.

Press the + or – or number pads to

set the baking time.

The oven temperature and the cooking

time that you entered will be displayed.

Press the START pad. The display

shows the oven temperature that you

set and the cooking time countdown.

(The display starts changing once

the temperature reaches 100°F.)

The oven will continue to cook for the

programmed amount of time, then shut

off automatically.

Press the CLEAR/OFF pad to clear the

display if necessary.

Remove the food from the oven. Remember, even

though the oven shuts off automatically, foods

continue cooking after controls are off.

How to Set a Delayed Start and Automatic Stop

You can set the oven control to delay-start the oven,

cook for a specific length of time and then turn off

automatically.

Make sure the clock shows the correct time

of day.

Press the BAKE pad.

Press the + or – or number pads to

set the temperature.

Press the COOKING TIME pad.

Press the + or – or number pads to

set the baking time.

Press the DELAY START or START TIME

pad.

Press the + or – or number pads to set

the time of day you want the oven to

turn on and start cooking.

Press the START pad.

If you would like to check the times you

have set, press the DELAY START or START

TIME pad to check the start time you have

set or press the COOKING TIME pad to check

the length of cooking time you have set.

When the oven turns on at the time of day

you have set, the display will show the

changing temperature (starting at 100°F)

and the cooking time countdown.

At the end of cooking time the oven will

turn off and the end of cycle tone will

sound.

Press the CLEAR/OFF pad to clear the

end of cycle tone if necessary.

Remove the food from the oven. Remember, even

though the oven shuts off automatically, foods

continue cooking after controls are off.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Adjust the oven thermostat—Do it yourself!

You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to

become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat yourself.

Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven.

These thermometers may vary 20–40°F.

To Adjust the Thermostat (on models with number pads only)

Press the BAKE and BROIL HI/LO pads

at the same time for 2 seconds until

the display shows SF.

Press the BAKE pad. A two digit

number shows in the display. Press

the BAKE pad once to increase (+)

the oven temperature, or twice to

decrease (–).

The oven temperature can be adjusted

up to (+) 35°F hotter or (–) 35°F

cooler. Press the number pads the

same way you read them. For example,

to change the oven temperature 15°F,

press 1 and 5.

When you have made the adjustment,

press the START pad to go back to the

time of day display. Use your oven as

you would normally.

NOTE: This adjustment will not affect the broiling

or self-cleaning temperatures. It will be retained in

memory after a power failure.

To Adjust the Thermostat (on models with + or – pads only)

Press the BAKE and BROIL HI/LO pads

at the same time for 2 seconds until

the display shows SF.

Press the BAKE pad. A two digit

number shows in the display.

The oven temperature can be adjusted

up to (+) 35°F hotter or (–) 35°F

cooler. Press the + pad to increase the

temperature in 1 degree increments.

Press the – pad to decrease the

temperature in 1 degree increments.

When you have made the adjustment,

press the START pad to go back to the

time of day display. Use your oven as

you would normally.

NOTE: This adjustment will not affect the broiling

or self-cleaning temperatures. It will be retained in

memory after a power failure.

GEAppliances.com

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Using the electric warming drawer.

The warming drawer will keep hot, cooked foods at serving temperature. Always start with hot food. Do not use to

heat cold food other than crisping crackers, chips or dry cereal.

Control Knob

Push and turn the control knob to any

desired setting.

NOTE: The warming drawer cannot be

used during a self-clean cycle.

ON Signal Light

The ON signal light is located above the

control knob and glows when the knob is

in the on position. It stays on until the

knob is moved to the OFF position.

WARMING DRAWER

Rack

■ Use in the warming drawer only.

■ Rack will fit from front to back.

■ Preheat with the rack in place.

■ Using the rack allows for double stacking

of items.

When Using the Warming Drawer

The warming drawer will keep hot, cooked

foods at serving temperature. Always start

with hot food. Do not use to heat cold

food other than crisping crackers, chips

or dry cereal.

Do not line the warming drawer with

aluminum foil.

■ Allow time for the drawer to be

preheated:

LO.........................................10 minutes

Medium.............................25–30 minutes

HI......................................25–35 minutes

■ Food in heat-safe glass and glass-ceramic

utensils may need a higher thermostat

setting as compared to food in metal

utensils.

■ Repeated opening of the drawer

allows the hot air to escape and the

food to cool. Allow extra time for the

temperature inside the drawer to

stabilize after adding items.

■ With large loads it may be necessary to

use a higher thermostat setting and cover

some of the cooked food items.

■ Food should be kept hot in its cooking

container or transferred to a heat-safe

serving dish.

■ Aluminum foil may be used to cover food

to prevent it from drying out.

CAUTION: Plastic containers or plastic wrap will

melt if in direct contact with the drawer or a hot

utensil. Melted plastic may not be removable and

is not covered under your warranty.

■ Remove serving spoons, etc., before

placing containers in warming drawer.

LO.........................................140–170°F

Medium.................................170–210°F

HI..........................................210–250°F

Temperature Selection Chart

To keep several different foods hot, set

the temperature to the food needing the

highest setting. Place the items needing the

highest setting on the bottom of the drawer

and items needing less heat on the rack.

Tips:

■ Do not put liquid or water in the

warming drawer.

■ For moist foods, cover them with a lid or

aluminum foil.

■ For crisp foods, leave them uncovered.

■ Do not use plastic containers or plastic

wrap.

■ Preheat prior to use according to

recommended times.

■ The temperature, type and amount of

food, and the time held may affect the

quality of the food.

CAUTION: Do not warm food in the warming

drawer for more than two hours.

Food Type Control Setting

Bacon HI

Eggs HI

Fish HI

Gravy, sauces HI

Ham HI

Onion rings HI

Pies LO

Pizza HI

Potatoes, baked HI

Potatoes, mashed LO

Tortilla Chips LO

To Crisp Stale Items

■ Place food in low-sided dishes or pans.

■ Preheat on LO setting.

■ Check crispness after 45 minutes.

Add time as needed.

To Warm Serving Bowls and Plates

To warm serving bowls and plates, set the

control on LO.

■ Use only heat-safe dishes.

■ Place the empty dishes on the rack to

raise them off the bottom of the drawer.

If you want hotter dishes or want to heat

fine china, please check with the

manufacturer of the dishes for their

maximum heat tolerance.

■ Preheat empty serving dish while

preheating the drawer.

■ When holding hot, cooked foods and

warming empty serving dishes at the

same time, place the serving dishes on

the high rack position and the food on

the bottom of the drawer.

CAUTION: Dishes may be hot. Use pot holders or

mitts when removing hot dishes.

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

GEAppliances.com

Using the self-cleaning oven.

If your model has a door latch, never force the latch handle. Forcing the handle will damage the door lock mechanism.

Before a Clean Cycle

The range must be completely cool in order to set

the self-clean cycle.

We recommend venting your kitchen with

an open window or using a ventilation fan

or hood during the first self-clean cycle.

Remove the broiler pan, broiler grid, all

cookware and any aluminum foil from the

oven—they cannot withstand the high

cleaning temperatures.

NOTE: Take the shelves out of the oven before you

begin the self-clean cycle.

Do not use commercial oven cleaners or

oven protectors in or near the self-cleaning

oven. A combination of any of these

products plus the high clean cycle

temperatures may damage the porcelain

finish of the oven.

Do not use abrasives or oven cleaners.

Clean the top, sides and outside of the

oven door with soap and water.

Make sure the oven light bulb cover is in

place and the oven light is off.

IMPORTANT: The health of some birds is

extremely sensitive to the fumes given off

during the self-cleaning cycle of any oven.

Move birds to another well-ventilated room.

Wipe up heavy soil on the oven

bottom.

How to Set the Oven for Cleaning

Latch the door.

Press the SELF CLEAN pad.

Press the + or – or number pads until

the desired Clean Time is displayed.

The Clean Time is normally 4 hours. You can change

the Clean Time to any time between 3 and 5 hours,

depending on the amount of soil in your oven.

Press the START pad.

The self-clean cycle will automatically begin

after CLEAN is displayed and the word ON

appears in the display.

When the LOCKED DOOR light is off,

slide the latch handle to the left as far

as it will go and open the door. If your

range does not have a latch, the door

will unlock automatically.

How to Delay the Start of Cleaning

Latch the door.

Press the SELF CLEAN pad.

Press the + or – or number pads to set

the Clean Time.

The Clean Time is preset for 4 hours. You can change

the Clean Time to any time between 3 and 5 hours,

depending on the amount of soil in your oven. If a

different Clean Time is desired, press the + or – or

number pads until the desired Clean Time is

displayed.

Press the DELAY START or START TIME

pad.

Change the Start Time by pressing the + or – or

number pads. The words “DELAY CLEAN” will

appear in the display.

Press the START pad.

The self-clean cycle will automatically begin

after CLEAN is displayed and the word ON

appears in the display.

When the LOCKED DOOR light is off,

slide the latch handle to the left as far

as it will go and open the door. If your

range does not have a latch, the door

will unlock automatically.

After a Clean Cycle

You may notice some white ash in the oven.

Wipe it up with a damp cloth after the oven

cools.

If white spots remain, remove them with a soap-

filled steel wool pad and rinse thoroughly with a

vinegar and water mixture.

These deposits are usually a salt residue that

cannot be removed by the clean cycle.

If the oven is not clean after one clean

cycle, repeat the cycle.

■ You cannot set the oven for cooking until

the oven is cool enough for the door to

be unlatched.

■ While the oven is self-cleaning, you can

press the CLOCK pad to display the time

of day. To return to the clean countdown,

press the COOKING TIME pad.

■ If the shelves become hard to slide, wipe

the shelf supports with cooking oil.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Care and cleaning of the range.

Be sure electrical power is off and all surfaces are cool before cleaning any part of the range.

If your range is removed for cleaning, servicing or any reason, be sure the anti-tip device

is re-engaged properly when the range is replaced. Failure to take this precaution could

result in tipping of the range and cause injury.

Standard Twin Burner Assemblies (on some models)

On models with standard twin burners, the cooktop

lifts up for easy access.

Turn all controls OFF before removing

burner parts and drip pans (if so equipped).

The burner grates and drip pans (if so

equipped) can be lifted off, making them

easy to clean.

The holes in the surface burners of your

range must be kept clean at all times for

proper ignition and an even, unhampered

flame.

You should clean the surface burners

routinely, especially after bad spillovers,

which could clog these holes.

Wipe off surface burners. If heavy spillover

occurs, remove the surface burners from

the range. Burners lift out for cleaning. Lift

up the cooktop and then lift out the surface

burners.

To remove burned-on food, soak the

surface burner in a solution of mild liquid

detergent and hot water. Soak the surface

burner for 20 to 30 minutes.

For more stubborn stains, use a cleanser

like Soft Scrub

brand or Bon Ami

brand.

Rinse well to remove any traces of the

cleanser that might clog the surface burner

openings.

Do not use steel wool because it will clog

the surface burner openings and scratch

the surface burners. If the holes become

clogged, clean them with a sewing needle

or twist-tie.

Before putting the surface burner back,

shake out excess water and then dry it

thoroughly by setting it in a warm oven

for 30 minutes. Then place it back in the

range, making sure it is properly seated

and level.

Check the flame pattern of each burner.

If the flames are “jumpy” (not steady),

clean the holes again with a sewing needle

or twist-tie.

Drip Pans (on some models)

Remove the grates and lift out the drip

pans. Drip pans can be cleaned in a

dishwasher or by hand.

When replacing the drip pans, make sure

they are in the correct position.

To get rid of burned-on food, place them

in a covered container (or plastic bag) with

1/4 cup ammonia to loosen the soil. Then

scrub with a soap-filled scouring pad if

necessary.

CAUTION: Do not clean the drip pans in a

self-cleaning oven.

Grate

Drip pan (on some models)

Surface burner

CAUTION: Do not operate the

burner without all burner parts and

drip pans (if so equipped) in place.

Clean these holes thoroughly on

each burner.

GEAppliances.com

Care and cleaning of the range.

Sealed Burner Assemblies (on some models)

Turn all controls OFF before removing the

burner parts and drip pans (if so equipped).

The burner grates, caps, burner heads and

drip pans (if so equipped) can be lifted off,

making them easy to clean.

The electrode of the spark igniter is

exposed when the burner head is

removed. When one burner is turned

to LITE, all the burners spark. Do not

attempt to disassemble or clean

around any burner while another

burner is on. An electric shock may

result, which could cause you to

knock over hot cookware.

Burner Heads (on sealed burners only)

For proper ignition, make sure the

small hole in the section that fits over the

electrode is kept open. A sewing needle or

wire twist-tie works well to unclog it.

The slits in the burner heads of your range

must be kept clean at all times for an even,

unhampered flame.

You should clean the surface burners

routinely, especially after bad spillovers,

which could clog these openings.

To remove burned-on food, soak the

burner heads in a solution of mild liquid

detergent and hot water for 20-30 minutes.

For more stubborn stains, use a toothbrush.

Before putting the burner head back, shake

out excess water and then dry it thoroughly

by setting it in a warm oven for 30 minutes.

Replace the burner heads and caps. Make

sure that the heads and caps are replaced

in the correct location. There is one small,

2 medium and one large head and cap.

NOTE: On some models there are 2 large,

one medium and one small head and cap.

NOTE: Before removing the burner heads and

caps, remember their size and location. Replace

them in the same location after cleaning.

Burner Caps (on sealed burners only)

Lift off when cool. Wash burner caps in hot,

soapy water and rinse with clean water.

You may scour with a plastic scouring pad

to remove burned-on food particles.

Dry them in a warm oven or with a cloth—

don’t reassemble them wet. Replace the

burner caps.

Make sure that caps are replaced on the

correct size burner. There is one small,

2 medium and one large cap.

NOTE: On some models there are 2 large, one

medium and one small head and cap.

CAUTION: Do not operate the

burner without all burner parts and

drip pans (if so equipped) in place.

Use a sewing needle or twist-tie

to unclog the small hole in the

burner head.

After cleaning, make sure the slot

in the burner head is positioned

over the electrode.

Grate

Burner cap

Drip pan (on some models)

Small

Medium

Large

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Electrode

Burner head

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

Burner Grates

Lift out when cool. Grates should be

washed regularly and, of course, after

spillovers. Wash them in hot, soapy water

and rinse with clean water. After cleaning,

dry them thoroughly by putting them in a

warm oven for a few minutes. Don’t put the

grates back on the range while they are wet.

When replacing the grates, be sure they’re

positioned securely over the burners.

To prevent rusting on cast iron grates, apply

a light coating of cooking oil on the bottom

of the grates.

Do not operate a burner for an extended

period of time without cookware on the

grate. The finish on the grate may chip

without cookware to absorb the heat.

To get rid of burned-on food, place the

grates in a covered container (or plastic

bag) with 1/4 cup ammonia to loosen the

soil. Let sit overnight (or approximately

12 hours), then scrub with a soap-filled

scouring pad if necessary. Rinse grates

thoroughly and dry completely before

replacing them on the range top.

Although they’re durable, the grates will

gradually lose their shine, regardless of

the best care you can give them. This is

due to their continual exposure to high

temperatures. You will notice this sooner

with lighter color grates.

CAUTION: Do not clean the grates in a dishwasher

or in a self-cleaning oven.

Cooktop Surface

To avoid damaging the porcelain enamel

surface of the cooktop and to prevent it

from becoming dull, clean up spills right

away. Foods with a lot of acid (tomatoes,

sauerkraut, fruit juices, etc.) or foods with

high sugar content could cause a dull spot

if allowed to set.

When the surface has cooled, wash and

rinse. For other spills such as fat spatterings,

etc., wash with soap and water once the

surface has cooled. Then rinse and polish

with a dry cloth.

NOTE: Do not store flammable materials in an

oven or near the cooktop. Do not store or use

combustible materials, gasoline or other

flammable vapors and liquids in the vicinity of

this or any other appliance.

Oven Bottom

The oven bottom has a porcelain enamel

finish. To make cleaning easier, protect the

oven bottom from excessive spillovers by

placing a cookie sheet on the shelf below

the shelf you are cooking on. This is

particularly important when baking a fruit

pie or other foods with a high acid content.

Hot fruit fillings or other foods that are

highly acidic (such as tomatoes, sauerkraut,

and sauces with vinegar or lemon juice)

may cause pitting and damage to the

porcelain enamel surface and should be

wiped up immediately.

We don’t recommend using aluminum

foil on the oven bottom. It can affect air

flow if the holes are blocked and it can

concentrate heat at the bottom of the

oven, resulting in poor baking

performance.

To clean up spillovers, use soap and water,

an abrasive cleaner or soap-filled steel wool

pad. Rinse well to remove any soap before

self-cleaning.

GEAppliances.com

Care and cleaning of the range.

Lift-Off Oven Door

The oven door is removable, but it is heavy. You may

need help removing and replacing the door.

To remove the door, open it a few inches to

the special stop position that will hold the

door open. Grasp firmly on each side and

lift the door straight up and off the hinges.

NOTE: Be careful not to place hands between the

hinge and the oven door frame as the hinge could

snap back and pinch fingers.

To replace the door, make sure the hinges

are in the special stop position. Position the

slots in the bottom of the door squarely

over the hinges. Then lower the door slowly

and evenly over both hinges at the same

time. If the hinges snap back against the

oven frame, pull them back out.

To clean the inside of the door:

■ Do not immerse the door in water.

■ Because the area inside the gasket is

cleaned during the self clean cycle, you

do not need to clean this by hand. Any

soap left on the liner causes additional

stains when the oven is heated.

■ The area outside the gasket can be

cleaned with a soap-filled steel wool or

plastic pad.

To clean the outside of the door:

■ Use soap and water to thoroughly clean

the top, sides and front of the oven door.

Rinse well. You may also use a glass

cleaner to clean the glass on the outside

of the door.

■ Spillage of marinades, fruit juices, tomato

sauces and basting materials containing

acids may cause discoloration and should

be wiped up immediately. When the

surface is cool, clean and rinse.

■ Do not use oven cleaners, cleansing

powders or harsh abrasives on the

outside of the door.

Broiler Pan and Grid

After broiling, remove the broiler pan from

the oven. Remove the grid from the pan.

Carefully pour out grease from the pan into

a proper container. Wash and rinse the

broiler pan and grid in hot water with a

soap-filled or plastic scouring pad.

If food has burned on, sprinkle the grid

with detergent while hot and cover with wet

paper towels or a dishcloth. Soaking the

pan will remove burned-on foods.

The broiler pan and grid may be cleaned

with a commercial oven cleaner.

Both the broiler pan and grid can also be

cleaned in a dishwasher.

Do not store a soiled broiler pan and grid

anywhere in the range.

CAUTION: Do not clean the broiler pan or grid in

a self-cleaning oven.

Lift the door straight up and off the

hinges.

The gasket is designed with a gap

at the bottom to allow for proper air

circulation.

Do not rub or clean the door

gasket—it has an extremely low

resistance to abrasion.

If you notice the gasket becoming

worn, frayed or damaged in any

way or if it has become displaced

on the door, you should have it

replaced.

Grid

Pan

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

Oven Light Replacement (on some models)

CAUTION: Before replacing your oven light bulb,

disconnect the electrical power to the range at the

main fuse or circuit breaker panel. Be sure to let the

light cover and bulb cool completely.

The oven light bulb is covered with a

removable glass cover that is held in place

with a bail-shaped wire. Remove the oven

door, if desired, to reach cover easily.

To remove:

Hold a hand under the cover so it

doesn’t fall when released. With

fingers of the same hand, firmly push

back the wire cover holder. Lift off

the cover.

Do not remove any screws to remove

the cover.

Do not touch hot bulb with a wet

cloth. Replace bulb with a 40-watt

household appliance bulb.

To replace cover:

Place it into the groove of the light

receptacle. Pull the wire forward to the

center of the cover until it snaps into

place. When in place, the wire holds

the cover firmly. Be certain the wire

is in the depression in the center of

the cover.

Connect electrical power to the range.

Wire cover holder.

Removable Storage Drawer (on some models)

The storage drawer is a good place to store

cookware and bakeware. Do not store plastics and

flammable material in the drawer.

The storage drawer may be removed for

cleaning under the range. Clean the

storage drawer with a damp cloth or

sponge. Never use harsh abrasives or

scouring pads.

To remove storage drawer:

Pull drawer straight out until it stops.

Tilt the front of the drawer up and

free of the range.

To replace storage drawer:

Set the stops on the back of the

drawer over the stops in the range.

Slide drawer evenly and straight back,

so that the rails in the range are

engaged.

The storage drawer may be

removed for cleaning under the

range.

Removable Warming Drawer (on some models)

Most cleaning can be done with the

drawer in place. However, the drawer may

be removed if further cleaning is needed.

Use soap and warm water to thoroughly

clean.

To remove the warming drawer:

Pull the drawer straight out until it

stops.

Press the left rail release up and press

the right rail release down, while

pulling the drawer forward and free.

To replace the warming drawer:

Place the left drawer rail around

the inner left rail guide and slide it

in slightly to hook it.

Place the right drawer rail around the

inner right rail guide and slide it in

slightly to hook it.

Slide the drawer all the way in.

Before performing any adjustments,

cleaning or service, disconnect the range

electrical power supply at the household

distribution panel by removing the fuse or

switching off the circuit breaker. Make

sure the warming drawer heating element

is cool.

GEAppliances.com

Care and cleaning of the range.

Oven Air Vents

Never block the vents (air openings) of the

range. They provide the air inlet and outlet

that are necessary for the range to operate

properly with correct combustion.

Air openings are located at the rear of

the cooktop, at the top and bottom of the

oven door, and at the bottom of the range,

under the kick panel or storage drawer

(depending on the model).

Lift-Up Cooktop (on models with standard twin burners)

Clean the area under the cooktop often.

Built-up soil, especially grease, may catch

on fire.

To make cleaning easier, the cooktop may

be lifted up.

To raise the cooktop:

Be sure the burners are turned off.

Remove the grates.

Grasp the two front burner wells and

lift up.

Clean under the cooktop with hot, soapy

water and a clean cloth. If you removed

your surface burners while cleaning,

make sure they are properly seated when

replacing them.

After cleaning, lower the cooktop (be

careful not to pinch your fingers).

Vent appearance and location vary.

Some models have dual support

rods that will hold the cooktop up

while you clean underneath it.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Fluorescent Top Light

(on some models)

CAUTION: Do not touch the bulb with wet hands or

when the bulb is hot. Never wipe the light area with

a wet cloth. Electrical power must be shut off if you

have to replace the bulb.

Raise the clips on the back, on both

sides, and free the back of the canopy.

Roll the canopy up and off.

Remove the fluorescent light bulb.

Replace the bulb with one of the same

length and wattage.

Replace the canopy by placing the

front in the groove and rolling it back.

Snap it into place over the back clips

on both sides.

Control Panel and Knobs

It’s a good idea to wipe the control panel

after each use of the oven. Clean with

mild soap and water or vinegar and water,

rinse with clean water and polish dry with

a soft cloth.

Do not use abrasive cleansers, strong liquid

cleaners, plastic scouring pads or oven

cleaners on the control panel—they will

damage the finish. A 50/50 solution of

vinegar and hot water works well.

The control knobs may be removed for

easier cleaning. To remove a knob, pull it

straight off the stem. If knob is difficult to

remove, place a towel or dishcloth between

the knob and control panel and pull gently.

Wash the knobs in soap and water or a

vinegar and hot water solution.

Metal parts can be cleaned with soap and

water. Do not use steel wool, abrasives,

ammonia, acids or commercial oven

cleaners. Dry with a soft cloth.

Pull the knob straight off the stem.

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

Oven Shelves

Clean the shelves with an abrasive cleanser

or steel wool. After cleaning, rinse the

shelves with clean water and dry with

a clean cloth.

NOTE: Take the shelves out of the oven before you

begin the self-clean cycle.

Brushed Chrome Cooktop (on some models)

Clean the brushed chrome top with warm,

soapy water or Bon Ami

brand cleanser

and immediately dry it with a clean, soft

cloth. Take care to dry the surface following

the “grain.”

To help prevent finger marks after

cleaning, spread a thin film of baby oil on

the surface. Wipe away excess oil with a

clean, soft cloth.

Warming Drawer Rack

Clean the rack with detergent and water.

After cleaning, rinse the rack with clean

water and dry with a clean cloth.

GEAppliances.com

Do not use a steel-wool pad; it will

scratch the surface.

To clean the stainless steel surface,

use warm sudsy water, a stainless steel

cleaner such as Kleen King

, or an

all-purpose liquid or spray cleaner.

Always scrub in the direction of the

grain. Rinse thoroughly with a sponge or

cloth and clean water. Dry with a soft,

clean cloth.

After cleaning, use a stainless steel

polish, such as Stainless Steel Magic

Revere Copper and Stainless Steel

Cleaner

, or Wenol All Purpose

Metal Polish

. Follow the product

instructions for cleaning the stainless

steel surface.

Stainless Steel Surfaces

(on some models)

Installation of the range.

Read these instructions completely and carefully.

BEFORE YOU BEGIN

Installation of this range must conform with local codes, or in the absence of local codes, with the

National Fuel Gas Code, ANSI Z223.1, latest edition. In Canada, installation must conform with the current

Natural Gas Installation Code, CAN/CGA-B149.1 or the current Propane Installation Code, CAN/CGA-

B149.2, and with local codes where applicable. This range has been design-certified by the American

Gas Association according to ANSI Z21.1, latest edition and Canadian Gas Association according to

CAN/CGA-1.1 latest edition.

As with any appliance using gas and generating

heat, there are certain safety precautions you

should follow. You will find these precautions in

the Important Safety Information section in the

front of this manual. Read them carefully.

IMPORTANT: Save these instructions for the local

electrical inspector’s use.

NOTE TO INSTALLER: Leave these instructions with

the appliance after installation is completed.

NOTE TO CONSUMER: Keep this Owner’s Manual

and Installation Instructions for future use.

NOTE: This appliance must be properly grounded.

FOR YOUR SAFETY

Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity

of this or any other appliance.

If you smell gas:

Open windows.

Don’t touch electrical switches.

Extinguish any open flame.

Immediately call your gas supplier.

TOOLS YOU WILL NEED

■ Phillips and flat-blade screwdrivers

■ Pencil and ruler

■ Two pipe wrenches (one for backup)

■ Open-end or adjustable wrench

■ Nut drivers or wrenches: 3/16 ″ and 1/4 ″

ADDITIONAL MATERIALS YOU MAY NEED:

■ Gas line shut-off valve

■ Pipe joint sealant or UL-approved pipe thread

tape with Teflon* that resists action of natural

and LP gases

■ Flexible metal appliance connector (1/2 ″ I.D.)

A 5-foot length is recommended for ease of

installation but other lengths are acceptable.

Never use an old connector when installing a

new range.

■ Flare union adapter for connection to gas supply

line (3/4 ″ or 1/2 ″ NPT x 1/2″ I.D.)

■ Flare union adapter for connection to pressure

regulator on range (1/2 ″ NPT x 1/2 ″ I.D.)

*Teflon: Registered trademark of DuPont

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

WARNING! INSTALLATION SAFETY INSTRUCTIONS

Improper installation, adjustment, alteration, service or maintenance can cause injury or property

damage. Refer to this manual. For assistance or additional information, consult a qualified installer,

service agency, manufacturer (dealer) or the gas supplier.

Never reuse old flexible connectors. The use

of old flexible connectors can cause gas leaks

and personal injury. Always use NEW flexible

connectors when installing a gas appliance.

IMPORTANT: Remove all packing material and

literature from oven before connecting gas and

electrical supply to range.

CAUTION: Do not attempt to operate the oven

of this range during a power failure (Electric

Ignition models only).

■ Have your range installed by a qualified

installer.

■ Your range must be electrically grounded

in accordance with local codes or, in the

absence of local codes, in accordance with

the National Electrical Code (ANSI/NFPA

70, latest edition). In Canada, electrical

grounding must be in accordance with the

current CSA C22.1 Canadian Electrical Code

Part 1 and/or local codes. See Electrical

Connections in this section.

■ Before installing your range on linoleum or

any other synthetic floor covering, make sure

the floor covering can withstand 180°F

without shrinking, warping or discoloring.

Do not install the range over carpeting

unless a sheet of 1/4″ thick plywood or

similar insulator is placed between the range

and carpeting.

■ Make sure the wall coverings around the

range can withstand heat generated by the

range up to 200°F.

■ Avoid placing cabinets above the range.

To reduce the hazard caused by reaching

over the open flames of operating burners,

install a ventilation hood over the range that

projects forward at least 5″ beyond the front

of the cabinets.

■ The ventilating hood must be constructed

of sheet metal not less than 0.0122″ thick.

Install above the cooktop with a clearance of

not less than 1/4″ between the hood and the

underside of the combustible material or

metal cabinet. The hood must be at least as

wide as the appliance and centered over the

appliance. Clearance between the cooking

surface and the ventilation hood surface

MUST NEVER BE LESS THAN 24 INCHES.

EXCEPTION: Installation of a listed microwave

oven or cooking appliance over the cooktop

shall conform to the installation instructions

packed with that appliance.

■ If cabinets are placed above the range,

allow a minimum clearance of 30″ between

the cooking surface and the bottom of

unprotected cabinets.

■ If a 30″ clearance between cooking surface

and overhead combustible material or metal

cabinets cannot be maintained, protect the

underside of the cabinets above the cooktop

with not less than 1/4″ insulating millboard

covered with sheet metal not less than

0.0122″ thick.

■ Clearance between the cooking surface and

protected cabinets MUST NEVER BE LESS

THAN 24 INCHES. The vertical distance from

the plane of the cooking surface to the

bottom of adjacent overhead cabinets

extending closer than 1″ to the plane of

the range sides must not be less than 18″.

(See the Dimensions and Clearances

illustration in this section.)

■ CAUTION: Items of interest to children

should not be stored in cabinets above a

range or on the backsplash of a range—

children climbing on the range to reach

items could be seriously injured.

Installation of the range.

Read these instructions completely and carefully.

DIMENSIONS AND CLEARANCES

Provide adequate clearances between the range and adjacent combustible surfaces. These dimensions

must be met for safe use of your range. The location of the electrical outlet and pipe opening (see Gas

Pipe and Electric Outlet Locations) may be adjusted to meet specific requirements.

The range may be placed with 0 ″ clearance (flush) at the back wall and side walls of the range.

⁄

” to 29”

Depth with door closed (includes door handle)

Depth varies depending on model.

See specifications sheet for your model.

30”

⁄

” ± 1⁄4”

To cabinets below

cooktop and at the

range back

30”

1”

2”

Minimum

13”

To wall on either side

standard burner models

To wall on either side

sealed burner models

Maximum depth

for cabinets above

countertops

Front edge of

the range side

panel forward

from cabinet

18”

0”

1/4”

Minimum to

cabinets on

either side of

the range

36”

Height

⁄

”

Depth with door open:

⁄

”

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

IMPORTANT!

Remove all tape and packaging. Lift up the cooktop (on models with standard twin burners) and remove

any packing material under it. Make sure the standard twin burners are properly seated and level.

Take the accessory pack out of the oven.

Check to be sure that no range parts have come loose during shipping.

LOCATION

Do not locate the range where it may be subject to strong drafts. Any openings in the floor or wall behind

the range should be sealed. Make sure the openings around the base of the range that supply fresh air

for combustion and ventilation are not obstructed by carpeting or woodwork.

Your range, like many other household items,

is heavy and can settle into soft floor coverings

such as cushioned vinyl or carpeting. Use

care when moving the range on this type

of flooring. It is recommended that the

following simple and inexpensive instructions

be followed to protect your floor.

The range should be installed on a sheet of

plywood (or similar material). When the floor

covering ends at the front of the range, the

area that the range will rest on should be built

up with plywood to the same level or higher

than the floor covering.

This will allow the range to be moved for

cleaning or servicing. Also, make sure your

floor covering will withstand 180°F. (See the

Installation Safety Instructions section.)

Make sure the wall coverings around your

range can withstand the heat generated (up to

200°F) by the range. (See the Installation Safety

Instructions section.)

All ranges can tip and injury could result.

To prevent accidental tipping of the range, attach an approved Anti-Tip device to the wall. (See Installing

the Anti-Tip Device in this section.) To check if the device is installed and engaged properly, carefully tip

the range forward. The Anti-Tip device should engage and prevent the range from tipping over.

If you pull the range out from the wall for any reason, make sure the Anti-Tip device is engaged when

you push the range back against the wall.

■ For your safety, never use your range for warming or heating the room. Your oven and cooktop

are not designed to heat your kitchen. Top burners should not be operated without cookware

on the grate. Such abuse could result in fire and damage to your range and will void your

warranty.

■ Do not store or use combustible materials, gasoline or other flammable vapors and liquids in

the vicinity of this or any other appliance. Explosions or fires could result.

■ Do not use oven for a storage area. Items stored in the oven can ignite.

■ Do not let cooking grease or other flammable materials accumulate in or near the range.

WARNING! ANTI-TIP DEVICE

Installation of the range.

Read these instructions completely and carefully.

Provide Adequate Gas Supply

Your range is designed to operate at a pressure of 4 ″ of water column on natural gas or, if designed for

LP gas (propane or butane), 10 ″ of water column.

Make sure you are supplying your range with the

type of gas for which it is designed.

This range is convertible for use on natural or

propane gas. If you decide to use this range on

LP gas, conversion must be made by a qualified

LP installer before attempting to operate the range

on that gas.

For proper operation, the pressure of natural gas

supplied to the regulator must be between 4″ and

13″ of water column.

For LP gas, the pressure supplied must be between

10″ and 13″ of water column.

When checking for proper operation of the

regulator, the inlet pressure must be at least 1″

greater than the operating (manifold) pressure

as given above.

The pressure regulator located at the inlet of the

range manifold must remain in the supply line

regardless of whether natural or LP gas is being

used.

A flexible metal appliance connector used to

connect the range to the gas supply line should

have an I.D. of 1/2″ and be 5 feet in length for ease

of installation. In Canada, flexible connectors must

be single wall metal connectors no longer than

6 feet in length.

Connect the Range to Gas

Shut off the main gas supply valve before disconnecting the old range and leave it off until the new

hook-up has been completed. Don’t forget to relight the pilot on other gas appliances when you turn

the gas back on.

Because hard piping restricts movement of the

range, the use of an A.G.A.-certified flexible metal

appliance connector is recommended unless local

codes require a hard-piped connection.

Never use an old connector when installing a new

range. If the hard piping method is used, you must

carefully align the pipe; the range cannot be moved

after the connection is made.

To prevent gas leaks, put pipe joint compound on,

or wrap pipe thread tape with Teflon* around, all

male (external) pipe threads.

Install a manual gas line shut-off valve in the

gas line in an easily accessed location outside

of the range. Make sure everyone operating

the range knows where and how to shut off

the gas supply to the range.

Install male 1/2″ flare union adapter to the

1/2″ NPT internal thread elbow at inlet of

regulator. On models equipped with standard

twin burners, install the male pipe thread end

of the 1/2″ flare union adapter to the 1/2″

NPT internal thread at inlet of pressure

regulator. Use a backup wrench on the

regulator fitting to avoid damage.

When installing the range from the front,

remove the 90° elbow for easier installation.

Install male 1/2″ or 3/4″ flare union adapter

to the NPT internal thread of the manual

shut-off valve, taking care to back-up the

shut-off valve to keep it from turning.

Connect flexible metal appliance connector

to the adapter on the range. Position range

to permit connection at the shut-off valve.

When all connections have been made,

make sure all range controls are in the off

position and turn on the main gas supply

valve. Use a liquid leak detector at all joints

and connections to check for leaks in the

system.

When using test pressures greater than 1/2 psig to

pressure test the gas supply system of the residence,

disconnect the range and individual shut-off valve

from the gas supply piping. When using test

pressures of 1/2 psig or less to test the gas supply

system, simply isolate the range from the gas supply

system by closing the individual shut-off valve.

*Teflon: Registered trademark of DuPont

CAUTION: DO NOT USE A FLAME TO

CHECK FOR GAS LEAKS.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

Gas Pipe and Electrical Outlet Locations for Models with Sealed Burners

Gas Pipe and Electrical Outlet Locations for Models with Standard Twin Burners

This area allows for flush range

installation with through-the-wall

connection of pipe stub/shutoff

valve and rear wall 120V outlet.

This area allows for flush range

installation with through-the-wall

connection of pipe stub/shutoff

valve and rear wall 120V outlet.

This area allows for flush range

installation with through-the-floor

connection of pipe stub/shutoff valve.

This area allows for flush range

installation with through-the-floor

connection of pipe stub/shutoff valve.

Shortest connection from hard pipe

stub location to range hookup.

Shortest connection from hard pipe stub

location to range hookup.

Installation of the range.

Read these instructions completely and carefully.

Rigid Pipe Hookup Options

Installer: Inform the

consumer of the location

of the gas shutoff valve.

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Pressure

regulator

Gas Flow into Range

Flex

connector

(6 ft. max.)

Adapter

1/2″ or 3/4″

Gas pipe

Adapter

Gas

shut-off

valve

Pressure

regulator

45° Elbow

Nipple

Union

90° Elbow

Black

iron pipe

Union

Nipple

Gas

shut-off

valve

1/2″ or 3/4″

Gas pipe

Gas Flow into Range

Gas

shut-off

valve

1/2″ or 3/4″

Gas pipe

Pressure

regulator

Nipple

90° Elbow

Adapter

90° Elbow

Quick connect

or union

Alternate Hookup

Nipple

90°

Elbow

Installer: Inform the

consumer of the location

of the gas shutoff valve.

Flexible Connector Hookup

Installer: Inform the

consumer of the location

of the gas shutoff valve.

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Electrical Connections (on some models)

Electrical Requirements

120-volt, 60 Hertz, properly grounded branch

circuit protected by a 15-amp or 20-amp circuit

breaker or time delay fuse.

Extension Cord Cautions

Because of potential safety hazards associated

with certain conditions, we strongly recommend

against the use of an extension cord. However,

if you still elect to use an extension cord, it is

absolutely necessary that it be a UL-listed, 3-wire

grounding-type appliance extension cord and

that the current carrying rating of the cord in

amperes be equivalent to, or greater than,

the branch circuit rating.

Grounding

IMPORTANT—(Please read carefully)

FOR PERSONAL SAFETY, THIS APPLIANCE

MUST BE PROPERLY GROUNDED.

The power cord of this appliance is equipped with

a three-prong (grounding) plug which mates with

a standard three-prong grounding wall receptacle

to minimize the possibility of electric shock hazard

from this appliance.

The customer should have the wall receptacle and

circuit checked by a qualified electrician to make

sure the receptacle is properly grounded.

Where a standard two-prong wall receptacle is

encountered, it is the personal responsibility and

obligation of the customer to have it replaced with

a properly grounded three-prong wall receptacle.

DO NOT, UNDER ANY CIRCUMSTANCES, CUT

OR REMOVE THE THIRD (GROUND) PRONG

FROM THE POWER CORD.

Usage Situations where Appliance

Power Cord will be Disconnected

Infrequently.

An adapter may be used only on a 15-amp circuit.

Do not use an adapter on a 20-amp circuit. Where

local codes permit, a TEMPORARY CONNECTION

may be made to a properly grounded two-prong

wall receptacle by the use of a UL-listed adapter,

available at most hardware stores. The larger slot in

the adapter must be aligned with the larger slot in

the wall receptacle to provide proper polarity in the

connection of the power cord.

When disconnecting the power cord from the

adapter, always hold the adapter with one hand.

If this is not done, the adapter ground terminal is

very likely to break with repeated use. Should this

happen, DO NOT USE the appliance until a proper

ground has again been established.

CAUTION: Attaching the adapter ground

terminal to the wall receptacle cover screw does

not ground the appliance unless the cover screw

is metal, and not insulated, and the wall

receptacle is grounded through the house

wiring. The customer should have the circuit

checked by a qualified electrician to make sure

the receptacle is properly grounded.

Preferred Method

Temporary Method

Ensure proper ground exists

before use

Ensure proper ground

and firm connection

before use

(Adapter plugs not permitted in Canada)

Align large prongs/slots

Installation of the range.

Read these instructions completely and carefully.

Electrical Connections (on some models)

Usage Situations where Appliance

Power Cord will be Disconnected

Frequently.

Do not use an adapter plug in these situations

because disconnecting of the power cord places

undue strain on the adapter and leads to eventual

failure of the adapter ground terminal. The

customer should have the two-prong wall receptacle

replaced with a three-prong (grounding) receptacle

by a qualified electrician before using the

appliance.

The installation of appliances designed for mobile

home installation must conform with the

Manufactured Home Construction and Safety

Standard, Title 24 CFR, Part 3280 (formerly the

Federal Standard for Mobile Home Construction

and Safety, Title 24, HUD, Part 280) or, when such

standard is not applicable, the Standard for

Manufactured Home Installations, latest edition

(Manufactured Home Sites, Communities and

Set-Ups), ANSI A225.1, latest edition, or with local

codes. In Canada, mobile home installation must

be in accordance with the current CAN/CSA

Z240/MH Mobile Home Installation Code.

Electric Disconnect

■ Locate disconnect plug on the range back.

■ Pinch sides of connector and pull out of range

back.

Seal the Openings

Seal any openings in the wall behind the range and

in the floor under the range when hookups are

completed.

Check Ignition of Surface Burners

Operation of all cooktop and oven burners should

be checked after the range and gas supply lines

have been carefully checked for leaks.

Electric Ignition Models

Select a top burner knob and simultaneously

push in and turn to LITE position. You will hear

a clicking sound indicating proper operation of the

spark module. Once the air has been purged from

the supply lines, burners should light within

4 seconds. After burner lights, rotate knob out of

the LITE position. Try each burner in succession

until all burners have been checked.

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Quality of Flames

The combustion quality of burner flames needs to

be determined visually.

If burner flames look like (A), call for service. Normal burner

flames should look like (B) or (C), depending on the type of

gas you use.

With LP gas, some yellow tipping on outer cones is

normal.

Normal for

natural gas

(B) Yellow tips on

outer cones –

Normal for LP gas

(A) Yellow flames –

Call for service

Check Ignition of Oven Burner

The oven is designed to operate quietly and

automatically. To operate the oven, press the BAKE

pad and then press the +/– or number pads until

350° appears in the display. Press the START pad.

After 30–90 seconds, the oven burner will ignite

and burn until the set temperature is reached. The

oven burner will continue to cycle on and off as

necessary to maintain the oven at the temperature

indicated by the display.

To check ignition of the broil burner, press the

BROIL HI/LO pad and then the START pad. After

30–90 seconds, the broil burner will ignite.

Electric ignition models require electrical power

to operate. In case of a power outage, the oven

burners on these models cannot be lit manually

with a match. Gas will not flow unless the glow bar

is hot.

If the oven is in use when a power outage occurs,

the burner will shut off and cannot be re-lit until

power is restored.

Installation of the range.

Read these instructions completely and carefully.

Adjust Broil and Oven Burner Air Adjustment Shutters if Necessary

Air adjustment shutters for the top and bottom burners

regulate the flow of air to the flames.

The air adjustment shutter for the top (broil)

burner is in the center of the rear wall of the oven.

The shutter for the bottom (oven) burner is near

the back wall behind the storage drawer or the

warming drawer (depending on the model).

Remove the drawer. See the Care and cleaning

of the range section.

To adjust the flow of air to either burner, loosen the Phillips

head screw and rotate the shutter toward open or closed

position as needed.

The flames for the top (broil) burner should be

steady with approximately 1″ blue cones and should

not extend out over the edges of the burner baffle.

To determine if the bottom burner flames are

burning properly, remove the oven bottom. Flames

should have approximately 1″ blue cones and, if

range is supplied with natural gas, should burn

with no yellow tipping. (With most LP gas, small

yellow tips at the end of outer cones are normal.)

Flames should not lift off burner ports. If lifting is

observed, gradually reduce air shutter opening

until flames are stabilized.

To remove the oven bottom:

Remove the knurled screws holding down

rear of the oven bottom.

Grasp the oven bottom at finger slots on

each side.

Lift the rear of the oven bottom enough to

clear the lip of the range frame, then pull out.

Oven bottom

Air adjustment

shutter

Loosen

Air adjustment

shutter

Loosen

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Leveling the Range

Install the oven shelves in the oven and

position the range where it will be installed.

Check for levelness by placing a spirit level or

a cup, partially filled with water, on one of the

oven shelves. If using a spirit level, take two

readings—with the level placed diagonally

first in one direction and then the other.

Remove the storage drawer or warming

drawer. See the Care and cleaning of the range

section. The front leveling legs can be adjusted

from the bottom and the rear legs can be

adjusted from the top or the bottom.

Using an open-end or adjustable wrench,

adjust the leveling legs until the range is level.

After the range is level, slide the range away

from the wall so that the Anti-Tip device

can be installed.

Raise

range

Lower

range

Leg

leveler

Lower

range

Raise

range

(on some models)

Operating Instructions

Safety Instructions

Installation Instructions

Troubleshooting TipsConsumer Support

Installation of the range.

Converting to LP Gas (or converting back to natural gas from LP)

This range leaves the factory set for use with natural gas.

If you want to convert to LP gas, the conversion must be

performed by a qualified LP gas installer.

The conversion instructions and LP orifices can be

found attached to the range next to the pressure

regulator.

Keep these instructions and the orifices in case you

want to convert back to natural gas.

Installing the Anti-Tip Device

Mark the wall where the RIGHT EDGE of the

range is to be located. Be sure to allow for the

countertop overhang if you intend to install

the range next to cabinets.

Locate the outside edge of the device 2

⁄

″

toward the center of the range from the

marked edge of the range.

Using the device as a template, mark the

position of the hole for the screw.

For wood construction, drill a pilot hole at an

angle of 20 degrees from the horizontal. A nail

or awl may be used if a drill is not available.

Mount the Anti-Tip device with the screw provided.

For cement or concrete construction, you

will need a 1/4″ x 1

⁄

″ lag bolt and a 1/2″ O.D.

sleeve anchor, which are not provided. Drill

the recommended size hole for the hardware.

Install the sleeve anchor into the drilled hole and

then install the lag bolt through the device. The

bolts must be properly tightened as recommended

for the hardware.

Slide the range against the wall, and check for

proper installation by grasping the front edge

of the cooktop and carefully attempting to tilt

the range forward.

WARNING:

■ Range must be secured with an approved

Anti-Tip device.

■ Unless properly installed, the range could be

tipped by you or a child standing, sitting or

leaning on an open door.

■ After installing the Anti-Tip device, verify that

it is in place by carefully attempting to tilt the

range forward.

■ This range has been designed to meet all

recognized industry tip standards for all

normal conditions.

■ The use of this device does not preclude

tipping of the range when not properly

installed.

■ If the Anti-Tip device supplied with the range

does not fit this application, use the universal

Anti-Tip device WB02X7909.

When All Hookups Are Completed:

MAKE SURE ALL CONTROLS ARE LEFT IN THE OFF

POSITION.

MAKE SURE THE FLOW OF COMBUSTION AND

VENTILATION AIR TO THE RANGE IS UNOBSTRUCTED.

Back of rangeWallboard

Wood screw

Anti-Tip

device

Slotted head screw

Wallplate

Approx.

20°

⁄

”

Marked edge of range

Anti-Tip

device

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

Troubleshooting Tips

Save time and money! Review the charts on the following

pages first and you may not need to call for service.

Problem Possible Causes What To Do

Top burners do not light Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

or do not burn evenly inserted in the electrical outlet. grounded outlet.

Burner holes on the side or • Remove the burners (on models with standard twin

around the top of the burner burners) or burner heads (on models with sealed

may be clogged. burners) or burner caps on spill-proof models, and clean

them with a sewing needle or twist-tie. Make sure you do

not enlarge the holes. On spill-proof models, check the

electrode area for burned-on food or grease.

Improper burner assembly. • Make sure the drip pans are installed correctly.

See the Care and cleaning of the range section.

Burner flames very Improper air to gas ratio. • If range is connected to LP gas, contact the person

large or yellow who installed your range or made the conversion.

Surface burners light The oven gas shut-off valve • To check the oven gas shut-off valve, remove the

but oven does not may have accidentally been storage drawer (see the Care and cleaning of the range

moved during cleaning or section) and look for the gas shut-off lever at the

moving. back of the range.

Fluorescent top light Fluorescent bulb is loose • Adjust or replace.

does not work or defective.

Switch operating the light • Call for service.

is broken.

Before you call for service… GEAppliances.com

Lever is

shown closed.

PULL TO OPEN.

Problem Possible Causes What To Do

Control signals after You forgot to enter a bake • Press the BAKE pad and desired temperature or

entering cooking time temperature or cleaning time. the SELF CLEAN pad and desired clean time.

or start time

Food does not bake Oven controls improperly set. • See the Using the oven section.

or roast properly

Shelf position is incorrect. • See the Using the oven section.

Incorrect cookware or cookware • See the Using the oven section.

of improper size being used.

Oven thermostat needs • See the Adjust the oven thermostat—Do it yourself!

adjustment. section.

Clock not set correctly. • See the Using the clock and timer section.

Aluminum foil used improperly • See the Care and cleaning of the range section.

in the oven.

Oven bottom not securely • See the Installation of the range section.

seated in position.

Food does not Oven controls improperly set. • Make sure you press the BROIL HI/LO pad.

broil properly

Oven door not closed. • See the Using the oven section.

Improper shelf position • See the Broiling Guide.

being used.

Food being cooked in a hot pan. • Use the broiling pan and grid that came with your

range. Make sure it is cool.

Cookware not suited for broiling. • Use the broiling pan and grid that came with your

range.

Aluminum foil used on the • See the Using the oven section.

the broiling pan and grid has

not been fitted properly and

slit as recommended.

Oven bottom not securely • See the Installation of the range section.

seated in position.

Oven temperature too Oven thermostat • See the Adjust the oven thermostat—Do it yourself!

hot or too cold needs adjustment. section.

Clock and timer Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

do not work inserted in the electrical outlet. grounded outlet.

A fuse in your home may be • Replace the fuse or reset the circuit breaker.

blown or the circuit breaker

tripped.

Oven controls improperly set. • See the Using the clock and timer section.

Oven light does not work Light bulb is loose or defective. • Tighten or replace the bulb.

Switch operating light • Call for service.

is broken.

Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

inserted in the electrical outlet. grounded outlet.

Before you call for service…

Operating Instructions

Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Troubleshooting Tips

Consumer SupportInstallation Instructions Troubleshooting TipsOperating InstructionsSafety Instructions

GEAppliances.com

Problem Possible Causes What To Do

Oven will not self-clean The oven temperature is too • Allow the range to cool to room temperature and

high to set a self-clean operation. reset the controls.

Oven controls improperly set. • See the Using the self-cleaning oven section.

On models with a door latch, • Make sure you move the door latch handle all the

the oven door is not in the way to the right.

locked position.

“Crackling” or This is the sound of the • This is normal.

“popping” sound metal heating and cooling

during both the cooking and

cleaning functions.

Excessive smoking Excessive soil. • Press the CLEAR/OFF pad. Open the windows to

rid the room of smoke. Wait until the LOCKED DOOR

light goes off. Wipe up the excess soil and reset the

clean cycle.

Oven door will not open Oven too hot. • Allow the oven to cool below locking temperature.

after a clean cycle

Oven not clean after a Oven controls not properly set. • See the Using the self-cleaning oven section.

clean cycle

Oven was heavily soiled. • Clean up heavy spillovers before starting the clean

cycle. Heavily soiled ovens may need to self-clean

again or for a longer period of time.

“LOCK DOOR” flashes The self-clean cycle has been • Close the oven door.

in the display selected but the door is not

closed.

LOCKED DOOR light The oven door is locked • Press the CLEAR/OFF pad. Allow the oven to cool,

is on when you want because the temperature and then, on models with a door latch, unlock

to cook inside the oven has not the door.

dropped below the

locking temperature.

“F—and a number or On models with a door latch, • The latch may have been moved, even if only slightly,

letter” flash in the display if a function error code appears from the locked position. Make sure the latch is moved

during the self-cleaning cycle, to the right as far as it will go.

check the oven door latch.

You have a function error code. • Press the CLEAR/OFF pad. Allow the oven to cool for one

hour. Put the oven back into operation.

If the function code repeats. • Disconnect all power to the range for 5 minutes

and then reconnect power. If the function error

code repeats, call for service.

Oven door will not Oven is too hot. • Allow the oven to cool below locking temperature.

unlock (on models with Do not lock the door with the door latch except when

a door latch) using the self-clean feature.

“Door” appears in the Self-cleaning cycle has been •Move the latch handle all the way to the right.

display (on models with selected but the latch handle

a door latch) was not moved all the way

to the right.

Latch handle was moved to •Move the latch handle to the right only when setting

the right but a program other the self-cleaning cycle.

than self-cleaning was selected.

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Problem Possible Causes What To Do

Display goes blank A fuse in your home may be • Replace the fuse or reset the circuit breaker.

blown or the circuit

breaker tripped.

The clock is in the • See the Special features of your oven control section.

black-out mode.

Display flashes Power failure. • Reset the clock.

Unable to get the Oven control pads were • The BAKE and BROIL HI/LO pads must be pressed at

display to show “SF” not pressed properly. the same time and held for 3 seconds.

Power outage, Power outage or surge. • Reset the clock. If the oven was in use, you must reset

clock flashes it by pressing the CLEAR/OFF pad, setting the clock

and resetting any cooking function.

“Burning” or “oily” This is normal in a new oven • To speed the process, set a self-clean cycle for a

odor emitting from and will disappear in time. minimum of 3 hours. See the Using the self-

the vent cleaning oven section.

Strong odor An odor from the insulation • This is temporary.

around the inside of the oven

is normal for the first few times

the oven is used.

Fan noise A cooling fan may • This is normal. The cooling fan will turn off and on.

automatically turn on and

off to cool internal parts.

Drawer does not slide The drawer is out of alignment. • Fully extend the drawer and push it all the way in.

smoothly or drags See the Care and cleaning of the range section.

Drawer is over-loaded or load • Reduce weight. Redistribute drawer contents.

is unbalanced.

Warming drawer will A fuse in your home may be • Replace the fuse or reset the circuit breaker.

not work blown or the circuit breaker

tripped.

The oven is self-cleaning. • Wait for the self-clean cycle to finish and the oven

to cool.

Controls improperly set. • See the Electric warming drawer section.

Excessive condensation Liquid in warming drawer. • Remove liquid.

in the warming drawer

Uncovered foods. • Cover food with lid or aluminum foil.

Temperature setting too high. • Reduce temperature setting.

Food dries out in the Moisture escaping. • Cover food with lid or aluminum foil.

warming drawer

Before you call for service…

Troubleshooting Tips

General Electric Company

Warranty Registration Department

P.O. Box 32150

Louisville, KY 40232-2150

GE Service Protection Plus

™

GE, a name recognized worldwide for quality and dependability, offers you

Service Protection Plus

™

—comprehensive protection on all your appliances—

No Matter What Brand!

Benefits Include:

• Backed by GE

• All brands covered

• Unlimited service calls

• All parts and labor costs included

• No out-of-pocket expenses

• No hidden deductibles

• One 800 number to call

You will be completely satisfied with our service protection or you may request your money back

on the remaining value of your contract. No questions asked. It’s that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!

Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker

coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable

household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224

for more information.

*All brands covered, up to 20 years old, in the continental U.S.

We’ll Cover Any Appliance.

Anywhere. Anytime.*

Please place in envelope and mail to:

✁

Cut here

Consumer Product Ownership Registration

General Electric Company

Louisville, Kentucky

GEAppliances.com

First

Name

Mr. ■■ Ms. ■■ Mrs. ■■ Miss ■■

Street

Address

City

State

Date Placed

In Use

Month

Day

Year

Zip

Code

Apt. #

Last

Name

Phone

Number

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product and thank you for placing your confidence in us.

We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Important: If you did not get a registration card with your

product, detach and return the form below to

ensure that your product is registered, or register

online at GEAppliances.com.

Model Number Serial Number

✁

Cut here

Complete and mail

your Consumer

Product Ownership

Registration today.

Have the peace of

mind of knowing we

can contact you in

the unlikely event of

a safety modification.

After mailing the

registration below,

store this document

in a safe place. It

contains information

you will need should

you require service.

Our service number is

800.GE.CARES

(800.432.2737).

Read your Owner’s

Manual carefully.

It will help you

operate your new

appliance properly.

Model Number Serial Number

E-mail Address*

* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important

communications from GE Appliances (GEA).

■■ Check here if you do not want to receive communications from GEA’s carefully selected partners.

Notes.

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

GE Gas Range Warranty. (For customers in the United States)

All warranty service provided by our Factory Service Centers,

or an authorized Customer Care

technician. To schedule service,

on-line, 24 hours a day, visit us at GEAppliances.com, or call

800.GE.CARES (800.432.2737).

For The Period Of: GE Will Replace:

One Year Any part of the range which fails due to a defect in materials or workmanship.

From the date of the During this full one-year warranty, GE will also provide, free of charge, all labor

original purchase and in-home service to replace the defective part.

■ Service trips to your home to teach you how to use

the product.

■ Improper installation.

■ Failure of the product if it is abused, misused, or used for

other than the intended purpose or used commercially.

■ Replacement of house fuses or resetting of circuit

breakers.

■ Damage to the product caused by accident, fire, floods or

acts of God.

■ Incidental or consequential damage caused by possible

defects with this appliance.

What GE Will Not Cover:

This warranty is extended to the original purchaser and any succeeding owner for products purchased for home

use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives

you specific legal rights, and you may also have other rights which vary from state to state. To know what your

legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

Operating Instructions Safety InstructionsInstallation InstructionsTroubleshooting Tips

Consumer Support

Staple your receipt here.

Proof of the original purchase

date is needed to obtain service

under the warranty.

Consumer SupportOperating InstructionsSafety Instructions Installation Instructions Troubleshooting Tips

GE Gas Range Warranty. (For customers in Canada)

All warranty service provided by our Factory Service Centers

or an authorized Customer Care

technician. For service,

call 1.800.361.3400.

For The Period Of: GE Will Replace:

One Year Any part of the range which fails due to a defect in materials or workmanship.

From the date of the During this full one-year warranty, GE will also provide, free of charge, all labor

original purchase and in-home service to replace the defective part.

■ Service trips to your home to teach you how to use

the product.

■ Improper installation.

■ Failure of the product if it is abused, misused, or used for

other than the intended purpose or used commercially.

■ Replacement of house fuses or resetting of circuit

breakers.

■ Damage to the product caused by accident, fire, floods or

acts of God.

■ Incidental or consequential damage caused by possible

defects with this appliance.

What Is Not Covered:

WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.

Warrantor: CAMCO INC.

Staple your receipt here.

Proof of the original purchase

date is needed to obtain service

under the warranty.

Consumer Support.

GE Appliances Website

In the U.S.: GEAppliances.com

Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,

any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,

order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts

™

” your questions,

and so much more... In Canada: geappliances.ca

Schedule Service In the U.S.: GEAppliances.com

Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your

convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.

In Canada, call 1.800.361.3400

Real Life Design Studio In the U.S.: GEAppliances.com

GE supports the Universal Design concept—products, services and environments that can be used by people of all

ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities and

impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with

disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.GEAC (800.833.4322).

In Canada, contact: Manager, Consumer Relations, Camco, Inc.

Suite 310, 1 Factory Lane

Moncton, N.B. E1C 9M3

Extended Warranties In the U.S.: GEAppliances.com

Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still

in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours. GE Consumer

Home Services will still be there after your warranty expires. In Canada, call 1.888.261.2133

Parts and Accessories In the U.S.: GEAppliances.com

Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes

(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at

800.626.2002 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should be

referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe operation.

Customers in Canada should consult the yellow pages for the nearest Camco service center, or call 1.888.261.3055.

If you are not satisfied with the service you receive from GE, contact us on our Website with all the details

including your phone number, or write to: General Manager, Customer Relations

GE Appliances, Appliance Park

Louisville, KY 40225

In Canada: www.geappliances.ca, or write to: Director, Consumer Relations, Camco, Inc.

Suite 310, 1 Factory Lane

Moncton, N.B. E1C 9M3

communication and prompt service under the terms of your warranty, should the need arise. You may also mail

in the pre-printed registration card included in the packing material. In Canada: geappliances.ca

This book is printed on recycled paper.

Printed in Mexico

GE - General Electric JGBP79CEBCC GE Profile Spectra 30" Free-Standing Gas Range

Product's Documents

User Manual

Specifications

GE - General Electric JGBP79CEBCC Questions and Answers

Related Products

GE - General Electric GE Profile Spectra' 30" Free-Standing Gas Range

GE - General Electric GE Profile' 30" Spectra' Free-Standing Gas Range

GE - General Electric GE Profile Spectra' 30" Free-Standing Gas Range

GE - General Electric GE Profile' 30" Spectra' Free-Standing Gas Range

GE - General Electric GE Profile Spectra' 30" Free-Standing Gas Range

GE - General Electric GE Profile Spectra' 30" Free-Standing Gas Range
