IMPORTANT SAFETY INFORMATION
3
This appliance contains a small amount of isobutane refrigerant (R600a),
natural gas with high environmental compatibility, but it is also combustible.
When transporting and installing the appliance, care should be taken to ensure
that no parts of the refrigerating circuit are damaged. Refrigerant squirting out
of the pipes could ignite or cause an eye injury. if a leak is detected, avoid any
naked flames or potential sources of ignition and air the room in which the
appliance is standing for several minutes.
WARNING
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartment of the
appliance, unless they are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the appliance require
special disposal procedures. When disposal, please consult with services
agent or a similarly qualified person.
In order to avoid the creation of a flammable gas air mixture if a leak in the
refrigerating circuit occurs, the size of the room in which the appliance
may be sited depends on the amount of refrigerant used. The room must be
2
1 m in size for every 8g of R600a refrigerant inside the appliance. The amount
of refrigerant in your particular appliance is shown on the identification plate
inside the appliance. Never start up an appliance showing any signs of damage.
if in doubt, consult your dealer.
IMPORTANT SAFETY INFORMATION
4
This guide contains many important safety messages. Always read and obey all safety
This is the safety alert symbol. It alerts you to safety messages that inform you of hazard
that can hurt you or others or cause damage to the product. All safety messages will be
preceded by the safety alert symbol and the hazard signal word WARNING, or CAUTION.
These words mean:
WARNING
You can be hurt or seriously injured if you don't follow instructions.
CAUTION
indicates an imminently hazardous situation which, if not avoided, may
result in minor or moderate injury, or product damage only.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell
you what canhappen if the instructions are not followed.
BASIC SAFETY PRECAUTIONS
messages.
• Using several devices from one
power outlet may cause fire.
• The electric leakage
breaker may trip and
cause food to spoil and
contaminate the refrigerator.
Do not allow the power plug to face upward
or to be compressed at
the back of the
refrigerator.
This could damage the
plug causing fire and
electric shock.
1. When connecting the power
To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety
WARNING
Do not allow the power cord to be bent, kinked,
or crushed by heavy objects.
It may damage the power
cord and cause fire or
electric shock.
precautions should be followed, including the following.
Read all instructions before using this appliance. This appliance is intended for domestic, indoor use
only.
Prevent the power cord from being
squeezed or imprinted if the refrigerator is
pushed in after the power plug is extracted
during the installation.
It becomes the cause of fire or electric shock.
Do not use many power outlets.
IMPORTANT SAFETY INFORMATION
5
Unplug the power plug when cleaning,
handling or replacing the interior lamp of the
refrigerator.
• Not doing so may cause electric shock or injury.
• When replacing the interior lamp
of the refrigerator, make sure
that the rubber ring for
preventing an electric spark
within the socket is not taken off.
D
o not pull out the cord or touch the power
plug with wet hands.
• It may cause electric
shock or injury.
1. When connecting the power
Remove water or dust from the power plug
and insert it with the ends of the pins
securely connected.
Dust, water or an unstable
connection into the wall may
cause fire and electric shock.
Make sure of grounding.
Make sure that the earth
pin on the power plug
is not missing or damaged. Poor earthing can
When the power cord or the power plug is
damaged or the holes of
the outlet are damaged or
worn, do not use them.
It may cause electric shock or
short circuit and cause a fire.
wait for 5 minutes or longer before
reconnecting the plug.
It may cause the operation
of the freezer to fail.
After
5minutes
Do not remove the power plug with wet
hands or by grasping the
end and pulling on it.
It may cause electric shock,
fire, short circuit or an electric
Do not extend or modify the length of the
power cord or power plug.
It can cause electric shock and/
or fire and damage the
refrigerator.
Be sure to use grounded exclusive proper
voltage consent for the power plug.
Be sure to use grounded extension consents
when extension consents are used.
may cause breakdown
It becomes the cause of fire
cause a malfunction, sand electric shock.
After disconnecting the power plug,
shock hazard.
IMPORTANT SAFETY INFORMATION
6
Do not place heavy, or dangerous objects
or any containers containing
It may fall or spill and cause
injury, fire or electric shock when
Do not use or store inflammable materials
ether, benzene, alcohol, medicine, LP gas,
spray or cosmetics
near or in the
refrigerator.
It may cause explosion
or fire.
fluids on top of the
Benzene
Ether
Thinner
Do not store medicine, scientific material, paint
or living compounds inside the refrigerator.
Such materials can cause
dangers and hazards,
and result in malfunction
or serious injury.
The Academic
Medicine
The Medicine
Do not place a flower vase, cup, cosmetics,
medicine or any container
with water on the
refrigerator.
It may cause damage, fire,
electric shock or injury if it spills
2. When using the refrigerator
Do not swing on any of the doors, or step on
the door shelves for any reason.
It may cause the refrigerator
to lean and fall over causing
serious injury or death. Do
not allow children to play
with the refrigerator or any
Prevent children from entering the product.
It may endanger the life of a
child if the child enters the
refrigerator.
Do not install the refrigerator outdoors,
in direct Sunlight, or where it
can be exposed to
This could cause malfunction,
corrosion, fire and electric
shock.
Opening and closing the door of the
refrigerator vigorously may cause the stored
food in the refrigerator basket to fall by
shock and hurt the foot, so take
precautions.
refrigerator.
opening or closing the door.
of its parts.
environmental conditions, or
in wet place or area.
over.
IMPORTANT SAFETY INFORMATION
7
Do not use drier to dry the inside, nor light a
candle to remove odor.
It may cause an
explosion or fire.
2. When using the refrigerator
There is a danger of
electric shock or fire.
Do not use any combustible spray near the
refrigerator.
It may cause fire and
Do not spray water directly inside or on to the
outside of the refrigerator, or clean it with
abrasive caustic based
liquids or pads, or solvents
This can cause damage to
the units finish, corrosion,
ThinnerThinner
and deterioration of electrical
In case of thunder and lightning, or not in
use for a long
period of time,
detach the power
plug.
Avoid direct heat sources.
It may cause damage,
When gas is leaked, do not touch the
refrigerator or the outlet and ventilate the
room immediately.
- The explosion by spark may cause fire or burn.
- Because this refrigerator uses natural gas as the
environtment-friendly refrigerant, even as small
amount is combustible. When the gas is leaked
by the severe damage during delivering,
installing or using the refrigerator, any spark may
cause fire or burn.
affect the refrigerator's
finish.
malfunction, and fire.
of any kind.
parts causing electric shock
or malfunction.
Do not use the refrigerator if it has been
submerged in water
It may cause electric
shock or fire.
without having it checked
by a qualified electrician.
IMPORTANT SAFETY INFORMATION
8
2. When using the refrigerator
Down-block
office
Do not allow any person except a qualified
engineer to disassemble, repair or alter the
refrigerator.
It may cause injury,
electric shock or fire.
When disposing the refrigerator, remove the
door seals from both doors
or remove the doors
Not doing so may cause
children to suffocate if they
Do not use the refrigerator for commercial
based purposes including mobile
appliactions.
A hazard or danger may
result from it's non intended
purpose such as electric
shock, fire or unwarranted
malfunction.
Install the refrigerator on the solid and level
floor.
Installing it on an unstable
surface could cause it to
fall or tip over when opening
the door causing serious
injury or death.
Do not obstruct the cold air outlets with
hands or objects. Do not obstruct the rear
lower ventilation grill.
It may cause overheating, electric shock
or injury.
What to do with your old refrigerator,
Your refrigerator contain liquid (refrigerant,
lubricant) made of recylable
materials. All these materials
must bes sent to a recycling
waste disposal site as they can
be reused after a specific
recycling process. Refrigerator
Contact local authoritie.
Completely empty inside before taking out
the container from the door.
When any strange smell or smoke is
detected from the refrigerator, disconnect
the power plug
immediately and
contact to the
service center.
Service
center
completely.
become trapped inside.
IMPORTANT SAFETY INFORMATION
2. When using the refrigerator
Do not remove the cover
on the back.
Do not touch food or containers in the
freezer with wet
hands.
It may cause frostbite
CAUTION
Violating this direction may cause injury or damage to your house or furniture.
Place all the components in the right places
before connecting the power.
Do not use an Adapter
on the back.
OK
Do not place the food in disorder inside the
refrigerator.
The food may fall during opening and closing the door
of the refrigerator and hurt people.
Do not store or place any sealed
The bottle may explode
when frozen and cause
damage and injury.
Do not insert or place hands
into the bottom of
the refrigerator.
The steel plate underneath
the refrigerator may cause injury.
e bottom of
Please use caution when opening or closing
the doors.
Children or pets should be
kept clear of the
refrigerator when opening
or closing the doors
to avoid injury.
Never leave lit candles or incense on the
fridge, at risk of
causing fire or
product damage.
Carry the refrigerator using the in built
recessed handles both at the rear
at the top, and underneath
Not doing so could
cause the unit to slip and
cause serious personal
Because the product is
heavy, carrying it alone
may hurt people or
accidents may occur.
9
Always be careful, please.
or full bottles in the freezer.
at the front.
injury and damage the unit.
IMPORTANT SAFETY INFORMATION
Do not put any living matter, animals,
refrigerator.
Do not use products such as grinding
sponge, brush, iron, or even special
products to clean stainless steel, soap
products such as alcohol, kerosene,
gasoline, wax, or solvent, or strong
chemicals such as chlorine, detergent, or
vinegar, for the purpose of gloss. These
products may damage the protective
lacquer, and
they may
cause risk or
stain on the
for steelfor steel
ProductsProducts
Strong
surface of the
Chemicals
refrigerator.
Avoid the contact of oil or fat on the plastic
Do not apply oil in the door connection part
parts. They may cause damage.
in any circumstances. It may cause damage
to the plastic
When the power cord is damaged, let a
parts.
technician to replace
it to remove the
danger of an
oiloiloil
accident.
Technician
Do not lean on the doors, Hinges may
Use only water. If any other liquid is used,
deregulate
the operation of the system may be
Themselves, harming
deteriorated. If a problem occurs by using
seal cooler and
any liquid other than
compromising
water, the
performance.
Only water
manufacturer will not
be responsible.
Water Tank
WARNING
Please do not use a dishwasher to clean the lower drawers; the high temperature may cause
damage to the baskets which make them unusable.
Do not use the carbonated water. The gas
pressure may cause
leakage.
Water Tank
Carbonated
Water
10
pets or children,
in or on the
It may cause the
died.
animal
Water Tank
Clean the water tank according to the
instruction before using the Water Dispenser
Do not store explosive substances
such as aerosol cans with a flammable
propellant in this appliance
Fill with potable water only.
INSTALLATION
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE
LATEST IN TECHNOLOGY.
WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE
AND RELIABILITY.
BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY
.
IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND
MAINTENANCE, AND ALSO SUPPLIES SOOME USEFUL HINTS.
1. Select a good location.
Place your refrigerator where it is easy to
use.
2.
Avoid placing the unit near or next to heat
sources, direct sunlight or moisture.
3 To ensure proper air circulation around the
fridge - freezer, please maintain sufficient
space on both the sides as well as top and
maintain at least 2 inches (5 cm) from the
rear wall.
4.
To avoid vibrations, the unit must be level.
If required, adjust the leveling screws to
compensate for unevenness of the floor.
The front should be slightly higher than the
rear to aid in door closing.
The front leveling screws can be turned easily
by tipping the cabinet slightly.
Turn the leveling screws clockwise( ) to
raise the unit, counterclockwise( ) to
lower it.
5.
Don't install this appliance in an environment
below
5 °C. as it may cause malfunction or
NEXT
1. Clean your refrigerator thoroughly and wipe
off all dust accumulated during shipping.
2. Install accessories such as ice cube box, etc,
in their proper places. They are packed
together to prevent possible damage during
shipment.
3. Connect the power supply cord (or plug) to
the outlet. Don't double up with other
appliances on the same outlet.
4. Prior to storing food, leave your refrigerator
on for 2 or 3 hours.
Check the flow of cold air in the freezer
compartment to ensure proper cooling.
Your refrigerator is now ready for use.
11
.
Do not install the refrigerator in an open or
sheltered outdoor environment.
poor operation.
See page 18 for recommended temperature
settings.
INNER PARTS
12
- This guide covers several different models. The refrigerator you have
purchased may have some or all of the features shown above.
- To keep a position of inner parts like as baskets, drawers and shelves
supplied by manufactureris the most efficient usage for energy saving.
NOTE
SUGGESTION FOR ENERGY SAVING
- Please do not keep the door open for a long time, close door in the shortest time.
- Too much food are not advised to be put in. Enough space should be kept for cool air
- Do not set the temperature of refrigerator lower than needed. Do not put the food near the
temperature sensor.
- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other
food, and lead to higher electric bills.
- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer
- Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer,
and cause temperature to rise.
NON DISPENSER MODEL
circulating freely.
temperature even.
Twisting Ice Serve
FREEZER
Type Ice Making
COMP
ARTMENT
Lamp
Shelf
Freezer Temperature
Freezer Door Rack
Control Dial
REFRIGERATOR
COMPARTMENT
Deodorizer
(Optional)
Refrigerat
or
Temperature
Control
Refrigerator Door
Rack
Lamp
Shelves
Refrigerator Door
Rack
Vegetable Drawer
Vegetable Partitioner
Levelling Screw
Egg Tray
INNER PARTS
13
- This guide covers several different models. The refrigerator you have
purchased may have some or all of the features shown above.
- To keep a position of inner parts like as baskets, drawers and shelves
supplied by manufactureris the most efficient usage for energy saving.
NOTE
DISPENSER MODEL
SUGGESTION FOR ENERGY SAVING
- Please do not keep the door open for a long time, close door in the shortest time.
- Too much food are not advised to be put in. Enough space should be kept for cool air
- Do not set the temperature of refrigerator lower than needed. Do not put the food near the
temperature sensor.
- Allow hot food to cool prior to storing. Placing hot food in the fridge-freezer could spoil other
food, and lead to higher electric bills.
- Do not block air vents with food. Smooth circulation of cold air keeps fridge-freezer
- Do not open the door frequently. Opening the door lets warm air enter the fridge-freezer,
and cause temperature to rise.
circulating freely.
temperature even.
Twisting Ice Serve
FREEZER
Type Ice Making
COMPARTMENT
Lamp
Shelf
Freezer Door Rack
Freezer Temperature
Control Dial
REFRIGERATOR
COMPARTMENT
Deodorizer
Water Tank
(Optional)
Lamp
Tray Snack (optional)
Shelves
Refrigerator Door
Rack
V
egetable Drawer
Vegetable Partitioner
Levelling Screw
Hygiene Fresh
(Optional)
Egg Tray
Refrigerator
Temperature Control
OPERATIONS
14
STARTING
When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures
prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.
BEFORE SETTING THE TEMPERATURE
●
The temperature of the refrigerator is kept constant regardless of changes in room temperature.
It is recommended that, once set, the temperature settings(the controls for the refrigerator and
freezer compartments) not be changed unless necessary.
●
This refrigerator has one temperature control button for the refrigerator compartment and one
temperature control dial for the freezer compartment.
●
The default setting of the temperature control button for the refrigerator compartment is ‘3°C’.
●
The default setting of the temperature control dial for the freezer compartment is '3'.
●
This refrigerator has a temperature sensor in the refrigerator compartment. It will start and stop
the compressor automatically as needed.
DOOR ALARM
When the door of the refrigerator or the freezer is open for 1 minute, an alarm will sound three times.
It the door remains open, the alarm will repeat every 30 seconds.
SELF TEST
●
Your refrigerator contains a built in diagnostic capability. If it develops a malfunction in certain areas,
it will display an error code to assist the repair technician. While an error code is displayed, other
control and display functions will not operate.
●
If an error code is displayed, contact a service center. Do not disconnect the power cord from
the outlet.
FOR INTERNAL CONTROLLER MODEL
cooling.(MIN = warmest, MAX = coldest temperature)
CONTROLS FOR REFRIGERATOR COMPARTMENT
The default setting of the temperature control button for
the refrigerator compartment is NORMAL (middle LED).
To control the refrigerator temperature, press the REF.
TEMP CONTROL button.
Whenever pressing the button, LED emitting the light.
The temperature is set in 7 steps, from MIN to MAX.
Ref. Temp Control Button
REF.TEMP.COMTROL
Display graphic can be different, depend on the type of your refrigerator.
●
Press 'REFRIGERATOR' button to control refrigerator temperature.
●
Whenever pressing the button, the LED emits light.
●
Press ‘HYGIENE FRESH’ button to operate hygiene motor (optional).
● The number showing up on the LED luminesce indicate the temperature of refrigerator compartment.
o
●
You can select the desired setting point seven steps, from '0 C' to '6
o
C'.
- Press
ⓐ
button, refrigerator temperature will be down each 1 C.
-
Press
ⓑ
button, Hygiene Fresh motor will be on, power mode, off.
-
Press button for 5 seconds, then hygiene filter replacement periode is RESET.
FOR EXTERNAL CONTROLLER MODEL
OPERATIONS
FAST FREEZING
●
The FAST FREEZING feature operates
when the refrigerator first turn on.
The compressor and circulating fan
operate at maximum cooling capacity to
quickly lower the refrigerator temperature.
It shuts off automatically.
●
If warm food is placed into the refrigerator, FAST FREEZING can be started with the button
on the control panel. FAST FREEZING will shut off when the temperature reaches
the proper level or it can be shut off manually by pressing the FAST FREEZING button.
CHILD LOCK (OPTIONAL)
15
Type a
a
b
a
b
●
- Press
ⓐ
button, refrigerator temperature will be down each 1 C.
-
Press
ⓑ
Type a
Type b
●
- The RESET icon will turn on if hygiene filter need to be changed, please contact service center.
o
button, refrigerator temperature will be up each 1 C.
o
o
●
CHILD LOCK
Press and hold the CHILD LOCK button
for 3 seconds to lock the child lock.
When it is locked, the Lock LED will be on
and the other button will not operate. To
unlock, press and hold the CHILD LOCK
button for 3 seconds again.
●
Type b
●
ⓐ
OPERATIONS
HYGIENE FRESH (OPTIONAL)
Life of the filter is about 1 to 2 years. (The life of the filter may vary by the environment of the
consumer.)
How to remove existing filter
When the RESET lamp is turned on, replace the filter.
When the “RESET” lamp is turned on, replace the
filter to maintain the performance of the HYGIENE
FRESH filter.
To replace the filter, press the
to switch to OFF mode.
Hold the filter cover and rotate counterclockwise to
separate the cover. Pull out the HYGIENE FRESH
filter inserted inside the filter cover.
How to install the new filter
Install the new filter.
Insert the new HYGIENE FRESH filter in the separated
filter cover so that the hooks around the filter are visible..
(If the filter is inserted in reverse direction, it will not be
assembled.)
Insert the filter cover to its original position and then turn
clockwise by 30 degrees to lock the filter cover.
You can purchase the HYGIENE FRESH filter at the nearest distributor or the service center.
During use notify
time to RESET
When switched
over to OFF mode
CAUTION
Before installing or using the product, make sure to read the owner's manual carefully to use the product
accurately as intended. This HYGIENE FRESH filter has the antibacterial function of removing the virus
or bacteria inside the refrigerator and the deodorizer function to remove the scent.
The function has tested and has been certificated by authorized institutions
Intertek
button
ww
*
●
•
•
•
●
•
•
16
OPERATIONS
Set replacement timing (Initialization)
After the user replaces the filter, the user can set the
time for the next replacement.
Close the refrigerator door and press the
button on the display panel on the front side of the he front side of the
door for more than 5 seconds to check that the
RESET lamp on the display panel is turned off.
Switch over to use mode
Switch over to use mode.
To use the HYGIENE FRESH filter, press the
of the door and switch over to the AUTO or POWER mode.
(Whenever you press the button, the HYGIENE FRESH filter will be switched to OFF
POWER OFF.)
CAUTION
When the user switches to AUTO or POWER mode, the LED around the filter is also turned on. Open
the door to check whether the LED around the filter is also turned on. Do not put in your finger or alien
particles inside the fan. It can be caused of an injury or malfunction.
You can purchase the HYGIENE FRESH filter at the nearest distributor or the service center.
During use notify
time to RESET
When switched
over to OFF mode
OFF AUTO POWER OFF
CAUTION
Do not wash the HYGIENE FRESH filter by using water because It can be caused of malfunction.
If the user continuously use the filter after the time to RESET, It can be caused of malfunction.
This filter may not be effective for all types of bacteria and virus.
This is effective to remove the bacteria which is not on the food in the refrigerator.
button on the display panel on the front side
AUTO
●
●
ww
ww
•
•
•
•
•
•
17
OPERATIONS
CONTROLS FOR FREEZER COMPARTMENT
●
To lower the temperature in the freezer, turn the knob
counter-clockwise and set to a higher number.
To raise the temperature in the freezer, turn the knob
clockwise and set to a smaller number.
●
When the freezer compartment is not cold enough in
●
sufficient freezing effect, so it is recommended to set the Knob at NORMAL.
ICE MAKING
Twisting Ice Serve Type
●
To make ice cubes, fill the ice tray with water and
insert in its position.
●
To remove ice cubes, hold the lever of the tray and
pull turn gently. Then, ice cubes drop in to the ice
cube box.
You can disassemble the Ice Maker to
secure space in the freezer.
• Twisting Ice Serve Type: Remove 1 and 2.
1. Ice Tray
2. Ice Cube Box.
WARNING
• Do not use anything other than water.
• Fill the water up to the marked line..
NOTE
●
The refrigerator can be operated continuously or the
refrigerator compartment can be warmer. When the quick
freezing is finished, please return to set the Knob at Normal.
summer, djust the control for the freezer to High ( 6 ~ 8 ).
Knob 8 is for quick freezing in the freezer compartment.
Setting the Freezer Knob at 8 will satisfy 4 STAR. Setting the Freezer Knob at NORMAL will have
Fridge temperature would be warmer when the Freezer
colder.
temperature set to be
Ice Trays
Ice Cube Box
DEFROSTING
●
Defrosting takes place automatically.
●
The defrosted water flows down to the evaporating tray which located in
the lower back side of the refrigerator and is evaporated automatically.
1
2
243
<Twisting Ice Serve Type>
18
OPERATIONS
19
DEODORIZER (OPTIONAL)
●
Unpleasant odor of food in fresh food
compartment is deodorized with no harm to
you and the food.
How to use
• As the Deodorizer is a passive component, there is no need to move around as it is located in
optimum place for the best result possible.
• Do not hit or poke at the deodorizer with any object as it may damage it.
• When storing food with a strong odor, wrap it or store it in a container with a lid because odor may
be passed on to other foods.
Re-Using of Deodorizer
• The deodorizer should be cleaned periodically, especially
if odors have been present in the refrigerator.
• Remove the Deodorizer from the ceiling of
the refrigerator compartment by gently pushing
forward on the front clips and lowering the
deodorizer body. Soak the deodorizer in warm
VEGETABLE DRAWER
Vegetable Partitioner
●
Fix the partitioner by inserting it at the rear side of vegetable box as shown in the figure.
How to use
●
Vegetable drawer can be used through the control of knob.
●
Check the position of knob prior to store the food.
●
Do not locate the knob on the middle point.
Partitioner
REFRESHMENT CENTER (OPTIONAL)
1. Tilting: Grasp the front pocket and slightly lift it up
Then pull it forward to tilt the transparent door bin.
2. Closing: Then place the door bin in its original
position until you hear a "click"
Tilt
Click
phosphate based soapy water, then rinse off
and allow to dry in direct sunlight before reinstalling.
OPERATIONS
20
WATER DISPENSER
●
Putting water in the water tank
1. Open the cover cap and pour water into the
water tank.
2. Close the cover cap.
3. The water tank is optional removable part
which can be applied to enlarge the storage
●
Drinking
1. Press the dispenser pad with cup.
2. The water is released when the dispenser pad is
pressed. The pad returns to its original position when
the cup is removed and the water stops its flow.
●
Put water after the water tank being in position. Necessarilly separate the water tank to
clean it or not use it.
When the water tank is not position after filling it with water, water can leak out by the
valve pushed.
Caution
Do not use anything other than water including.
Hot water needs to be cooled before being put
in the water tank.
Cover Cap
WATER
PUSH
Cover Cap
NOTE
●
capacity. You can use the upper basket after
removing the water tank and closing up
the hole with a plug.
The plug is enclosed with the egg tray.
SUGGESTIONS ON FOOD STORAGE
21
STORING FOOD
●
Store fresh food in the refrigerator compartment. How food is frozen and thawed is an
important factor in maintaining its freshness and flavor.
●
Do not store food which goes bad easily at low temperatures, such as bananas, pineapples,
and melons.
●
Allow hot food to cool prior to storing. Placing hot food in the refrigerator could spoil other
food, and lead to higher electric bills!
●
When storing the food, cover it with vinyl wrap or store in a container with a lid. This prevents
moisture from evaporating, and helps food to keep its taste and nutrients.
Do not block air vents with food. Smooth circulation of chilled air keeps refrigerator temperatures
●
Do not open the door frequently. Opening the door lets warm air enter the refrigerator, and
causes temperatures to rise.
REFRIGERATOR COMPARTMENT
●
Avoid placing moist food deeply positioned on the
refrigerator shelf, it could freeze upon direct contact
with chilled air. To avoid this it is better to store food in
a covered container.
●
It is desirable to store moist food (especially vegetable
and fruit) in the vegetable storage compartment. If it is
necessary to store on a shelf of the refrigerator, put it
close to the door away from the back wall of the
refrigerator to avoid being frozen by the cool circulating air in the refrigerator.
●
Always clean food prior to refrigeration. Vegetables and fruits should be washed and wiped,
and packed food should be wiped clean, to prevent adjacent food from spoiling.
●
When storing eggs in their storage rack, ensure that they are fresh, and always store them
in a up-right position, which keeps them fresh longer.
FREEZER COMPARTMENT
●
Do not store bottles in the freezer compartment - they may break when frozen.
●
Do not refreeze food that has been thawed. This causes loss of taste and nutrition.
●
When storing frozen food like ice cream for a long period, place it on the freezer shelf, not in
the door rack.
●
It is recomended to load food at least 15mm against back of freezer wall, it will keep good air
circulation in the freezer compartment.
● Loading for Freezing - It is recommended to load newly introduced foods in the following
freezer location for freezing:
even.
even.
●
●
CLEANING
22
WARNING
Always remove power cord from the wall
outlet prior to cleaning in the vicinity of
electrical parts(lamps, switches, controls, etc.).
Wipe up excess moisture with a sponge or
cloth to prevent water or liquid from getting
into any electrical part and causing electric
shock. Do not use flammable or toxic cleaning
liquids.
• Caution for Cleaning Not in use : Surface
active agent, Car wax, Anticorrosive, All sorts
of oil, Gasoline, Acids, Wax.
• Usable Detergent Vegetable dish washable
solution, Soapy water.
• When careless using, it can occur a color
change.
It is important that your refrigerator be kept clean
to prevent undesirable odors. Spilled food should
be wipe up immediately, since it may acidify and
stain plastic surfaces if allowed to settle.
Never use metallic scouring pads, brushes,
coarse abrasive cleaners or strong alkaline
solutions on any surface.
Before you clean, however, remember that damp
objects will stick or adhere to extremely cold
surfaces. Do not touch frozen surfaces with wet
or damp hands.
INTERIOR - Regular cleaning of the interior and
interior parts is recommended. Use a lukewarm
solution of mild soap or dish washable solution to
clean the durable finish of your refrigerator. Wipe
with a clean, damp cloth and then dry.
INTERIOR PARTS - Wash compartment
shelves, door racks, storage trays and magnetic
door seals etc. Use a lukewarm solution of mild
soap or dish washable solution to clean
the durable finish of your refrigerator. Wipe
with a clean damp cloth and then dry.
EXTERIOR - Use a lukewarm solution of mild
soap or dish washable solution to clean the
durable finish of your refrigerator. Wipe with a
clean, damp cloth and then dry.
For products with a stainless steel exterior, use a clean
sponge or soft cloth and a mild Detergent in warm water.
Do not use abrasive or harsh cleaners. Dry thoroughly
with a Soft cloth. Do not use appliance wax, bleach, or
other products containing chlorine on stainless steel.
CLEANING
WATER DISPENSER
WATER
PUSH
Grille -
Wipe with a wet cloth, and dry with a dry cloth.
Water Tank -
1. Remove the tank cover.
2. Clean the inside and outside of the water tank
with diswashing detergent and rinse
throughly under running water. Dry the water
with a cloth.
3. Clean the inside and outside of the cap
with diswashing detergent and rinse
throughly under running water. Dry the water
with a cloth.
Water Tank -
1. Putting the Water
Is not necessary to remove the water tank in order to supply
it (it could be filled like shows fig. 1 pulling the tank gate).
- Before closing door, close the cap and clamp tightly.
- Do not use liquids containing sugar or carbonated drinks like soda.
2. Disassembly
Lift the water tank, gripping a side and bottom of water tank.
When disassemble Water Tank, use all waterinside dispenser first.
3. Assembly
If by some cause removes the water tank, place again the water
tank on its original position. Verify that the valve assembly
correctly in the hole of the door (fig. 3,4). Once assembled push
down and check the tank position with line.
23
NOTE
NOTE
Caution
1. Use lukewarm water when cleaning.
2. Do not use anything other than water. If it is
used with soft drinks,put water in the water
tank and discharge three or four cups of
water shortly.
GENERAL INFORMATION
VACATION TIME
During average length vacations, you will probably
find it best to leave the refrigerator in operation.
Place freezable items in freezer for longer life.
When you plan to be away for an extended period,
remove all food, disconnect the power cord, clean
the interior thoroughly, and leave each door OPEN
to prevent odor formation.
POWER FAILURE
Most power failures are corrected in an hour or two
and will not affect your refrigerator temperatures.
However, you should minimize the number of door
openings while the power is off. During power
failures of longer duration, place a block of dry ice on
top of your frozen packages.
IF YOU MOVE
Remove or securely fasten down all loose items
inside the refrigerator.
To avoid damaging the leveling screw(s), turn them
all the way into the base.
ANTI-CONDENSATION PIPE
The outside wall of the refrigerator cabinet may
sometimes get warm,
especially just after
installation.
Don't be alarmed.
This is due to the anti-
condensation pipe, which
pumps hot refrigerant to
prevent "sweating" on the
outer cabinet wall.
Caution
Electrical Shock Hazard
Before replacing a burned-out light bulb,
either unplug the refrigerator or turn off
power at the circuit breaker or fuse box.
NOTE :Moving the control to the OFF position
does not remove power to the light circuit.
24
NOTE
● This product applies LED Lamp which can not be replaced by the user.
LAMP REPLACEMENT
Please contact authorized service centre for the lamp replacement.
This appliance is intended to be used in
household and similar applications such as:
- Staff kitchen areas in shops, offices and
other working environments.
- Farm houses and by clients in hotels, motels
and other residential type environments.
- Bed and breakfast type environments.
- Catering and similar non-retail applications.
IMPORTANT WARNINGS
25
DO NOT USE AN EXTENSION CORD
If possible, connect the refrigerator to its own
individual electrical outlet to prevent it and other
appliances or household lights from causing an
overload that could cause a power outage.
ACCESSIBILITY OF SUPPLY PLUG
The refrigerator-freezer should be so positioned that
the supply plug is accessible for quick disconnection
should an accident happen
SUPPLY CORD REPLACEMENT
If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
ABOUT GROUNDING (EARTHING)
In the event of an electric short circuit, grounding
(earthing) reduces the risk of electric shock by
providing an escape wire for the electric current.
In order to prevent possible electric shock, this
appliance must be grounded.
Improper use of the grounding plug can result in
an electric shock. Consult a qualified electrician
or service person if the grounding instructions
are not completely understood, or if you have
doubts on whether the appliance is properly
DO NOT MODIFY OR EXTEND THE
POWER CORD LENGTH.
It will cause electric shock
or fire.
VERY DANGEROUS ATTRACTION
An empty refrigerator can be a dangerous
attraction to children. Remove either gaskets,
latches, lids or the entire door from your
unused appliance, or take some other action
to make it harmless.
This appliance must be grounded (earthed).
DON'T WAIT! DO IT NOW!
Do not store inflammable materials, explosives
or chemicals in the refrigerator.
DISPOSAL OF THE OLD APPLIANCE
WARNING
This appliance contains fluid (refrigerant, lubricant) and is made of parts and materials which are
reusable and/or recyclable.
All the important materials should be sent to the collection center of waste material and can be
reused after rework (recycling). When disposing any appliance, always call your local council for
This appliance is not intended for use by person (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
grounded.
advise or possible collection options.
BEFORE CALLING FOR SERVICE
26
SERVICE CALLS CAN OFTEN BE AVOIDED!
IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE
POSSIBLE CAUSES FIRST :
PROBLEM POSSIBLE CAUSES
REFRIGERATOR DOES
NOT OPERATE
REFRIGERATOR OR FREEZER
COMPARTMENT TEMPERATURE
TOO WARM
ABNORMAL NOISE(S)
REFRIGERATOR
HAS ODOR
DEW FORMS ON THE
CABINET OR INSIDE SURFACE
●
Has a house fuse blown or circuit breaker tripped?
●
Has the power cord plug been removed or loosened
from the electrical wall outlet?
●
Temperature control not set on proper position.
●
Appliance is placed close to wall or heat source.
●
Warm weather-frequent door openings.
●
Door left open for a long time.
●
Large amount of foods are kept in the refrigerator.
●
Refrigerator is installed in a weak or uneven place, or
leveling the front feet may be necessary.
●
Unnecessary objects placed in or on the rear side of
the refrigerator.
●
Foods with strong odors should be tightly covered or
wrapped.
●
Interior or deodorizer needs cleaning.
●
Not unusual during periods of high humidity.
●
Door may have been left ajar.
27
It is recommended to install the earth to prevent electric shock in
case of electricity leakage.
How to connect the earth wire:
• Connect the earth wire's metal ring end to the earth screw
on the back of the refrigerator.
Do not connect the earth wire to the following locations.
• Gas pipe
It could produce sparks which lead to fire and explosion.
• Telephone earth wire and lightning rod
It is dangerous during lightning.
• Water pipe and water tap
The earth wire connection will not work when the middle of the water pipe is made of plastic.
When installing the product in a humid or wet location, you must install the earth wire.
Ex) • Unfloored or dirt floored room (Room with dirt and no floor), concrete floor
• Location where it can get wet such as near the sink
• Location where water can leak or is humid such as basement
• Other wet or humid location
Especially, for locations where it always get wet such as near the restaurant sink, you are obligated by
the law to install a circuit breaker in addition to the earth wire.
After consulting with your retailer or electric construction company, you must do the earth wire
construction (Type 3 earth construction). Please note that earth construction could incur extra fees.
• Peel off the cable sheath/insulation at the other end of the earth wire. Attach the peeled wire
to a metal screw/nail and then drive it through the wall or ground.
If it is connected to a metal water pipe, it could cause someone to be electrocuted.
P/No.: MFL67239949
