©2017 Sony Corporation
Printed in Thailand
Earbuds / Oreillettes / Almohadillas
Keep earbuds clean. To clean the
earbuds, wash them with a mild
detergent solution.
Note on static electricity
Static electricity accumulated in the body may cause
mild tingling in your ears.
To minimize the effect, wear clothes made from
natural materials.
iPhone is a trademark of Apple Inc., registered in the
U.S. and other countries.
Xperia is a trademark of Sony Mobile
Communications AB.
Android and Google Play are trademarks or registered
trademarks of Google, Inc.
Optional replacement earbuds can be ordered from
your nearest authorized Sony retailer or www.sony.
com.
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.
Precautions
High volume may affect your hearing.
For traffic safety, do not use while
driving or cycling.
Install the earbuds firmly. If an earbud
accidentally detaches and is left in
your ear, it may cause injury.
** Availability of the “VoiceOver” feature depends on
iPhone and its software version.
Specifications
Headphones
Type: Closed, dynamic
Driver unit: 9 mm, dome type (CCAW Voice Coil)
Power handling capacity: 100 mW (IEC*)
Impedance: 16 Ω at 1 kHz
Sensitivity: 103 dB/mW
Frequency response: 5 Hz – 24,000 Hz
Cable: Approx. 1.2 m (47
1
/4 in), Litz wire, Y-type
Plug: L-shaped gold-plated 4-pole mini plug
Mass: Approx. 3 g (0.11 oz) without cable
Microphone
Type: Electret condenser
Directivity: Omni directional
Open circuit voltage level: –40 dB (0 dB = 1 V/Pa)
Effective frequency range: 20 Hz – 20,000 Hz
Supplied accessories
Hybrid silicone rubber earbuds: SS (1 line) (2), S
(2lines) (2), M (3 lines) (attached to the unit at the
factory) (2), L (4 lines) (2) / Cable adjuster (winds cable
up to 50 cm (19
3
/4 in)) (1)
* IEC = International Electrotechnical Commission
Design and specifications are subject to change
without notice.
English Stereo headphones
Compatible products
Use this unit with smartphones.
Notes
If you connect to an unsupported smartphone, the
microphone of this unit may not function, or the
volume level may be low.
This unit is not guaranteed to operate digital music
players.
Using the Multi-function button*
Press once to answer the call, press again to end;
press to play/pause a track.
Available operations for iPhone
Plays/pauses a track of the connected iPhone product
with a single press. Skips to the next track with a
double press. Skips to the previous track with a triple
press. Starts the “VoiceOver**” feature with a long
press (if available).
Hold down for about two seconds to reject an
incoming call. When you let go, two low beeps
confirm the call was rejected.
* The button function may vary depending on the
smartphone.
Multi-function button
Touche multifonctions
Botón multifunción
How to use/Utilisation/Utilización
* Smart Key es una aplicación para Xperia™,
Android™ OS 4.0 y versiones posteriores. Es posible
que la aplicación no esté disponible en algunos
países o regiones y que no pueda utilizarse con
modelos de teléfonos inteligentes no compatibles.
https://play.google.com/store/apps/details?id=com.
sonymobile.extras.liveware.extension.smartkey
If you install the Smart Key app* from Google Play™
store, the track and volume adjustment on your
smartphone will be enabled with multi-function
button.
* Smart Key is an application for Xperia™, Android™
OS 4.0 and above. The app may not be available in
some countries and/or regions, and may not be
used with unsupported smartphone models.
Si vous installez l’application Smart Key* à partir de la
boutique Google Play™, le réglage de la plage et du
volume de votre téléphone intelligent sera activé à
l’aide de la touche multifonctions.
* Smart Key est une application pour Xperia™,
Android™ OS 4.0 et version ultérieure. L’application
pourrait ne pas être disponible dans certains pays
et/ou dans certaines régions et ne pas fonctionner
avec des modèles de téléphone intelligent qui ne
sont pas pris en charge.
Si instala la aplicación* Smart Key desde la tienda
Google Play™, el ajuste de pista y volumen de su
teléfono inteligente se habilitará con el botón
multifunción.
LMSSS
Microphone
Micro
Micrófono
MDR-EX155AP
Stereo Headphones
Operating Instructions
Mode d’emploi
Manual de instrucciones
4-697-552-31(1)
