DVD/SACD VIDEO PLAYER
DVP9000S
User manual
Thank you for choosing Philips.
Need help fast?
Read your User’s Manual first for quick tips that make using
your Philips product more enjoyable.
If you have read your instructions and still need assistance,
you may access our online help at www.philips.com/support
01-41 DVP900_00A31 13/01/2005, 09:571
/00_3139 246 13873
2
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1 Remove fuse cover and fuse.
2 Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A. or BSI approved type.
3 Refit the fuse cover.
If the fitted plug is not suitable for your socket
outlets, it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5 Amp. If a plug without a fuse
is used, the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed of to
avoid a possible shock hazard should it be
inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code: blue = neutral (N),
brown = live (L).
¶ As these colours may not correspond with the
colour markings identifying the terminals in
your plug, proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover, make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent. See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous
radiation exposure or other unsafe
operation.
VAROITUS
Muiden kuin tässä esitettyjen
toimintojen säädön tai asetusten
muutto saattaa altistaa vaaralliselle
säteilylle tai muille vaarallisille
toiminnoille.
01-41 DVP900_00A31 13/01/2005, 09:572
/00_3139 246 13873
3
DK
Advarsel: Usynlig laserstråling ved
åbning når sikkerhedsafbrydere er ude
af funktion. Undgå utsættelse for
stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen
fra nettet. Den indbyggede netdel er
derfor tilsluttet til lysnettet så længe
netstikket sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på
annat sätt än i denna bruksanvisning
specificerats, kan användaren utsättas
för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är
därför ansluten till elnätet så länge
stickproppen sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen muulla
kuin tässä käyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu
verkko-osa on kytkettynä
sähköverkkoon aina silloin, kun pistoke
on pistorasiassa.
‘CONSUMERS SHOULD NOTE THAT NOT
ALL HIGH DEFINITION TELEVISION SETS
ARE FULLY COMPATIBLE WITH THIS
PRODUCT AND MAY CAUSE ARTIFACTS
TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE
CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE
QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 525p
AND 625p DVD PLAYER, PLEASE CONTACT
OUR CUSTOMER SERVICE CENTER.’
The apparatus shall not be exposed to dripping
or splashing and that no objects filled with
liquids, such as vases, shall be placed on
apparatus.
Due to the inconsistency of disc formats
provided by various disc manufacturers, your
DVD system may require a playability
enhancement or upgrade. As DVD technology
advances, these enhancements will become
common and will be easy to complete.
Go to www.philips.com/support for
software upgrade.
01-41 DVP900_00A31 13/01/2005, 09:573
/00_3139 246 13873
4
General Information
LASER
Type Semiconductor laser
GaAlAs
Wave length 650 nm (DVD)
780 nm (VCD/CD)
Output Power 7 mW (DVD)
10 mW (VCD/CD)
Beam divergence 60 degree
For Customer Use:
Read carefully the information located at
the rear of your DVD Player and enter
below the Serial No. Retain this
information for future reference.
Model No. DVP 9000S
Serial No. _______________
Environmental Information
All unnecessary packaging has been
omitted. The packaging has been made
easy to separate into three materials:
cardboard (box), polystyrene foam
(buffer) and polyethylene (bags, protective
foam sheet).
Your DVD player consists of materials
which can be recycled and reused if
disassembled by a specialized company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
“DCDi” is a trademark of
Faroudja, a division of
Genesis Microchip, Inc.
CAUTION
(WARNING LOCATION: ON THE
BACKPLATE OF THE SET)
NEVER MAKE OR CHANGE
CONNECTIONS WITH THE
POWER SWITCHED ON.
Laser safety
This unit employs a laser. Due to possible
eye injury, only a qualified service person
should remove the cover or attempt to
service this device.
NOTE:
PICTURES SHOWN MAY BE
DIFFERENT BETWEEN
COUNTRIES.
Important Note:
Due to the numerous versions of new
CD-Audio copy protection or
enhanced CD-Audio protection
recently available on certain discs,
Philips is unable to guarantee that
this DVD Player is fully compatible
with such new discs. Should you have
difficulty playing any such CD-Audio
discs, kindly refer them to your CD-
Audio disc retailer.
The apparatus shall not be exposed to dripping
or splashing and that no objects filled with
liquids, such as vases, shall be placed on
apparatus.
Manufactured under license from Dolby
Laboratories “Dolby”, “Pro-Logic” and the
double-D symbol are trademarks of Dolby
Laboratories.
“DTS” and “DTS DIGITAL SURROUND” are
registered trademarks of Digital Theater
Systems, Inc.
01-41 DVP900_00A31 13/01/2005, 09:574
/00_3139 246 13873
5
English
Français
Deutsch
Nederlands
Italiano Español
Svenska
Français------------------------------------ 42
English --------------------------------------- 8
Index
Deutsch------------------------------------ 78
Nederlands ------------------------------114
CAUTION
VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
ADVARSEL
SYNLIG OG USYNLIG
LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÅLING
VARNING
SYNLIG OCH OSYNLIG
LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD BETRAKTA EJ STRÅLEN
VARO!
AVATTAESSA OLET ALTTIINA
NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASER SÄTEILYLLE. ÄLÄ KATSO
SÄTEESEEN
VORSICHT
GEFAHR VON SICHTBARER UND
UNSICHTBARER LASERSTRAHLUNG
BEI GEÖFFNETEM GEHÄUSE.
ATTENTION
RAYONNEMENT LASER VISIBLE ET
INVISIBLE EN CAS D’OUVERTURE
EXPOSITION DANGEREUSE AU
FAISCEAU
This DVD player is in conformity
with the EMC directive and low-
voltage directive.
Español -----------------------------------150
Italiano------------------------------------186
Svenska -----------------------------------222
01-41 DVP900_00A31 13/01/2005, 09:575
/00_3139 246 13873
English
6
Introduction
Supplied accessories .......................................8
Care and safety information.......................... 8
Connections
Connecting TV ............................................9-11
Using SCART jack........................................... 9
Using Composite Video jack (CVBS) ......... 9
Using S-Video jack........................................ 10
Using Component Video jacks (Pr Pb Y) .10
Scan Mode (Progressive/Interlace selector)
..........................................................................11
Using an accessory RF modulator ............11
Connecting the power cord........................12
Optional: Connecting to a HDMI/DVI Device
.....................................................................12-13
Using HDMI (High Definition Multimedia
Interface) sockets .................................. 12-13
Optional: Connecting to a Multi-channel
Receiver ...........................................................13
Receiver has multi-channel audio input jack
..........................................................................13
Optional : Connecting to an Audio System .14
Stereo has Dolby Pro Logic or Right / Left
Audio In jacks ................................................14
Optional: Connecting to a Digital Receiver .. 14
Receiver has a PCM, Dolby Digital, or
MPEG2 decoder............................................ 14
Functional Overview
Front Panels ....................................................15
Rear Panels......................................................16
Remote Control ............................................17
Getting Started
Step 1: Inserting batteries into the
Remote Control ............................................18
Using the Remote Control to operate the
Player ............................................................... 18
Step 2: Setting up the TV........................18-19
Selecting the colour system that
corresponds to your TV.............................. 19
Selecting the TV Shape ................................ 19
Step 3: Setting language preferences .........20
Setting the Menu Language......................... 20
Setting the Default Audio and Default
Subtitle languages.......................................... 20
Step 4: Setting the speakers’ channels.......21
Advance Bass Management ........................ 21
– Movie Mode .............................................. 21
– Music Mode............................................... 21
Disc Operations
Playable Discs .................................................22
Region Codes .................................................22
Playing discs.....................................................23
Display on LCD..............................................23
Using the Disc Menu.....................................23
Playback controls .....................................24-27
Pausing playback............................................24
Selecting a title (track) /chapter................24
Zoom .............................................................. 24
Resuming playback from the last stopped
point ................................................................24
Shuffle.............................................................. 24
Repeat .............................................................25
Repeat A-B ..................................................... 25
Scan.................................................................. 25
Time Search ................................................... 25
Slow Motion .................................................. 26
Searching......................................................... 26
Still Picture and Frame-by-frame playback . 26
Program playback .........................................27
Special DVD features....................................27
Selecting a Title .............................................27
Camera Angle ................................................ 27
Changing the Audio Language.................... 27
Subtitles ..........................................................27
Playing MP3/JPEG/Kodak Picture CD........28
Special features for picture disc playback.....
.....................................................................28-29
Slide show playback setting ........................28
Rotating the picture..................................... 28
Zoom picture ................................................29
Playback with multi-angles ..........................29
Scan Effect ......................................................29
Playing MP3 music or JPEG picture ..........29
Playing Super Audio CD (SACD) ...............29
Contents
01-41 DVP900_00A31 13/01/2005, 09:576
/00_3139 246 13873
English
7
DVD Menu Options
Preferences ...............................................30-31
Picture............................................................. 30
– Color Settings........................................... 30
– Saturation/ Contrast/ Brightness ......... 30
– Sharpness...................................................30
– Video Shift..................................................30
Advance Picture..................................... 31-32
– TrueLife....................................................... 31
– DCDi ..........................................................31
– Gamma....................................................... 31
– Chroma Delay .......................................... 31
– 4:3 Aspect ..................................................31
– HiVideoDef ............................................... 31
– Content Mode.......................................... 32
Sound .............................................................. 32
– Night Mode ...............................................32
– Analog Output ..........................................32
– CD Up-sample.......................................... 32
– Clear Voice ................................................ 32
– Karaoke Vocal ...........................................32
Features ..........................................................33
– Wakeup timer ........................................... 33
– Helpline ...................................................... 33
– Status Window ......................................... 33
Setup...........................................................33-35
Language ......................................................... 34
– Menu Language.........................................34
– Default Subtitle/ Default Audio ............34
– Country ..................................................... 34
TV .................................................................... 34
– TV System .................................................. 34
– TV Shape .................................................... 34
Audio Menu .............................................34-35
– Digital Output .......................................... 34
– Subwoofer frequency .............................. 35
– SACD Direct ............................................ 35
– HDMI audio .............................................. 35
– PCM Output .............................................35
Contents
Speakers (Advance Bass Management).... 35
Features .......................................................... 35
– PBC (Playback Control) ......................... 35
– Sleep Timer ...............................................35
Access ...................................................... 36-37
– Enter PIN................................................... 36
– Disc Lock................................................... 36
– Parental Level............................................ 37
– Change PIN ...............................................37
Troubleshooting ......................... 38–39
Specifications ......................................40
Glossary......................................................................41
01-41 DVP900_00A31 13/01/2005, 09:577
/00_3139 246 13873
English
8
Care and safety information
● Power consumption
– When the system is switched to
Standby mode, it is still consuming power.
To disconnect the system from the power
supply completely, remove the AC power
plug from the wall jack.
Supplied accessories
Remote Control
and two AA
batteries
Introduction
● Avoid high temperatures, moisture,
water and dust
– Do not expose the player, batteries or
discs to humidity, rain, sand or excessive
heat (caused by heating equipment or
direct sunlight).
● Avoid condensation
– The lens may cloud over when the
player is suddenly moved from cold to
warm surroundings, making it impossible
to play a disc. Leave the player in the
warm environment until the moisture
evaporates.
● Do not block the vents
– Do not operate the DVD Player in an
enclosed cabinet. Allow about 10 cm (4
inches) of free space around the player for
adequate ventilation.
10 cm
(4 inches)
10 cm
(4 inches)
10 cm
(4 inches)
PHILIPS
● Care of the cabinet
– Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits,
ammonia or abrasives.
● Finding a suitable location
– Place the player on a flat, hard, and
stable surface.
● Disc handling
– To clean a CD, wipe it in a
straight line from the center
toward the edge using a soft,
lint-free cloth. A cleaning
agent may damage the disc.
– Write only on the printed
side of a CD-R/CD-RW and only with a
soft felt-tipped pen.
– Handle the disc by its edge; do not
touch the surface.
SCART cable
(black)
AC power cable
01-41 DVP900_00A31 13/01/2005, 09:578
/00_3139 246 13873
English
9
Connections
Connecting TV
S-VIDEO
YPbPr
MIXED 2CH
MAIN
CENT
E
SUB WO
O
6CH DISC
R
LL
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
AV
AUDIO
OUT
S-VIDEO
IN
VIDEO IN
SCART/RGB IN
AUDIO
IN
S-VIDEO
IN
VIDEO IN
SCART/RGB IN
1
IMPORTANT!
– You only need to make
one video
connection from the following
options, depending on the
capabilities of your TV system.
– Connect the DVD system directly
to the TV.
– RGB connection will let you use
the features of both the Audio and
Video in the DVD Player.
Using SCART jack
● Use the SCART cable (black) to connect
the DVD Player’s SCART jack (AV) to the
corresponding Scart input jacks on the TV
(cable supplied).
Helpful Hint:
– Ensure that the “TV” indication on
SCART cable is connected to the TV
set and “DVD” indication on SCART
cable is connected to the DVD Player.
S-VIDEO
YPbPr
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURRO
LL
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
AV
AUDIO
IN
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
IN
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
IN
IN
3
1
2
Back of TV
IMPORTANT!
– You only need to make
one video
connection from the following
options, depending on the
capabilities of your TV.
– Connect the DVD Player directly
to the TV.
Using Composite Video jack
(CVBS)
1 Use the supplied composite video cable
(yellow) to connect the DVD Player’s
yellow VIDEO OUT (CVBS) jack to
the VIDEO IN jack (labeled as Video In,
Composite, CVBS, or Baseband) on the
TV (cable not supplied).
2 Set the SCAN MODE switch to
INTERLACE.
3 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT (L/
R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable not supplied).
01-41 DVP900_00A31 13/01/2005, 09:579
/00_3139 246 13873
English
10
S-VIDEO
YPbPr
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SUR
R
LL
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
AV
AUDIO
IN
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
IN
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
IN
IN
3
1
2
Back of TV
IMPORTANT!
– S-Video provides better picture
quality. This option must be available
on your TV.
Using S-Video jack
1 Use the S-video cable to connect the
DVD Player’s S-VIDEO OUT jack to the
S-Video in jack (labeled as Y/C or S-VHS)
on the TV (cable not supplied).
2 Set the SCAN MODE switch to
INTERLACE.
3 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT
(L/R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable not supplied).
Connections
S-VIDEO
YPbPr
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURROU
LL
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
AV
AUDIO
IN
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
IN
Pr/Cr
Pb/Cb
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
IN
IN
3
1
2
Back of TV
IMPORTANT!
– The progressive scan video quality
is only possible when using Y Pb Pr
and a progressive scan TV is
required.
– DO NOT connect both video and
Y Pb Pr to a TV, it may affect the
picture quality.
Using Component Video jacks
(Pr Pb Y)
1 Use the component video cables
(yellow, red, white) to connect the DVD
Player’s Pr Pb Y jacks to the
corresponding Component video in jacks
(labeled as Pr/Cr Pb/Cb Y or YUV) on
the TV (cable not supplied).
2 Set the SCAN MODE switch to
PROGRESSIVE.
3 To hear the sound of this DVD Player
through your TV, use the audio cables
(white/red) to connect AUDIO OUT
(L/R) jacks of the DVD Player to the
corresponding AUDIO IN jacks on the TV
(cable not supplied).
01-41 DVP900_00A31 13/01/2005, 09:5710
/00_3139 246 13873
English
11
Connections
S-VIDEO
YPbPr
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
HDMI
PCM
/
D
COAXI
A
DI
G
AV
Scan Mode
(Progressive/Interlace selector)
This switch will change the type of signal
output from the Component Video Out
on the DVD player.
Interlace:
Select this setting when connected to a
standard (interlace format) TV.
Progressive:
Select progressive when you have a TV
that can accept progressive signals (480/
525p) to enjoy accurate colour
reproduction and high quality images.
Helpful hints:
– During Progressive mode, 4:3 aspect
images are distorted when TV Shape is set to
‘16:9’ . Change the TV screen’s aspect ratio
settings to AUTO to avoid image distortion.
(see page 31 “4:3 Aspect”).
– Some TVs and projectors are not
compatible with this DVD Player. If picture
distorted during progressive signals, switch
the SCAN MODE to Interlace.
IMPORTANT!
– If your TV only has a single
Antenna In jack (labeled as 75 ohm
or RF In), you will need an RF
modulator in order to view DVD
playback on the TV. The RF
modulator is not supplied with the
DVD Player. See your electronics
retailer or contact Philips for details
on RF modulator availability and
operations.
Using an accessory RF modulator
1 Use the composite video cable (yellow) to
connect the DVD Player’s CVBS jack to
the video input jack on the RF modulator.
2 Use the RF coaxial cable (not supplied) to
connect the RF modulator to your TV’s
RF jack.
S-VIDEO
YPbPr
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURROUND
LL
R
L
R
COMPONENT
CE
SIVE
VIDEO
VIDEO OUT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
~ AC
MAINS
AV
AUDIO IN
R L
VIDEO
IN
TO TVANT IN
CH3 CH4
3
1
2
4
ANT IN
RF coaxial cable to TV
Back of RF Modulator
(example only)
Antenna or
Cable TV signal
01-41 DVP900_00A31 13/01/2005, 09:5711
/00_3139 246 13873
English
12
Connections
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURROUND
LL
R
L
R
TAL/
G
P
TICAL
U
T
R
AUDIO OUT
~ AC
MAINS
~ AC MAINS
AUDIO
OUT
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
After everything is connected
properly, plug the AC power cord
into the power outlet.
Never make or change any connections
with the power switched on.
When no disc is loaded, press
STANDBY ON on the DVD Player
to turn it on.
Connecting the power cord
Using HDMI (High Definition
Multimedia Interface) sockets
● HDMI connects untouched and
uncompressed digital transmissions for
the highest and cripest sound/image
quality.
● It has plug and play capability using only
one cable for both audio/video output.
● Use HDMI connection (cable not supplied)
if you have a valid HDMI input devices
(eg.; LCD/Projector/Plasma/Projection TV,
or HDTV).
➜ Playback starts automatically.
OR
● The DVD Player’s {HIVIDEODEF} menu
will appear on the TV screen (see page 31
{HIVIDEODEF}).
S-VIDEO
YPbPr
MIXED 2CH
MA
LL
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
HDMI
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO
AV
AUDIO
IN
COAXIAL
OPTICAL
TV/Display
HDMI
Optional audio cable
Optional: Connecting to a
HDMI/DVI Device
01-41 DVP900_00A31 13/01/2005, 09:5712
/00_3139 246 13873
English
13
Connections
Receiver has multi-channel audio
input jack
1 Select one of the video connections
(CVBS VIDEO IN, S-VIDEO IN, SCART or
COMPONENT VIDEO IN) depending on
the options available on your TV.
2 Set the PROGRESSIVE/INTERLACE
switch to INTERLACE for CVBS or S-
VIDEO connections.
3 Set the PROGRESSIVE/INTERLACE
switch to PROGRESSIVE for
COMPONENT VIDEO IN connection
with a Progressive Scan TV.
4 Use the audio cables (white/red) to
connect AUDIO OUT (Front L&R,
Center, Surr L&R, Sub Woofer) jacks of
the DVD Player to the corresponding
AUDIO IN jacks on the receiver
(cable not supplied).
VIDEO
Y
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURROUND
LL
R
L
R
NT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
~ A
MA
AV
MULTICHANNEL AUDIO IN
SUBW.
AV Receiver
REARFRONT
CENTER REARFRONT
LL
RR
Optional: Connecting to a Multi-
channel Receiver
● The HDMI is backward compatible with
many DVI devices using an appropriate
adaptor plug.
➜ If a DVI device is connected, an
additional audio cable will be needed for
audio transmission.
➜ Audio transmission is possible when
{HDMI Audio} is switch to on.
➜ This DVD Player will support HDCP
compliance only.
Helpful hint:
– Set the SCAN MODE switch to
PROGRESSIVE.
Optional: Connecting to a HDMI/
DVI Device - cont’d
Using HDMI (High Definition
Multimedia Interface) sockets
01-41 DVP900_00A31 13/01/2005, 09:5713
/00_3139 246 13873
English
14
Connections
Optional: Connecting to a Digital
Receiver
S-VIDEO
YPbPr
MIXED 2CH
LL
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
HDMI
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AU
AV
AUDIO
IN
COAXIAL
OPTICAL
Receiver
OR
Receiver has a PCM, Dolby Digital,
or MPEG2 decoder
1 Select one of the video connections to
your TV (CVBS VIDEO IN, S-VIDEO IN,
or COMPONENT VIDEO IN) depending
on the options available on your TV.
2 Connect either the COAXIAL or
OPTICAL jack of the DVD Player to the
corresponding Digital Audio In jack on
your Receiver (cable not supplied).
3 Set the DVD Player’s Digital Output to
PCM-ONLY or ALL depending on the
capabilities of your Receiver (see page 34
{DIGITAL OUTPUT}).
Helpful Hints:
– If the audio format of the digital output
does not match the capabilities of your
receiver, the receiver will produce a strong,
distorted sound or no sound at all.
Stereo has Dolby Pro Logic or Right
/ Left Audio In jacks
1 Select one of the video connections to
your TV (CVBS VIDEO IN, S-VIDEO IN,
or COMPONENT VIDEO IN) depending
on the options available on your TV.
2 Set the PROGRESSIVE/INTERLACE
switch to INTERLACE for CVBS or S-
VIDEO connections.
3 Set the PROGRESSIVE/INTERLACE
switch to PROGRESSIVE for
COMPONENT VIDEO IN connection
with a Progressive Scan TV.
4 Use the audio cables (white/red) to
connect AUDIO OUT (L/R) jacks of
the DVD Player to the corresponding
AUDIO IN jacks on the stereo system
(cable not supplied).
Helpful Hint:
– For optimum stereo sound quality, always
connect Left and Right channel from the
multi-channel output and set [Analog
Output] setting to ‘STEREO’, see page 32).
S-VIDEO
YPb
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURROUND
LL
R
L
R
COMPONENT
E
O
V
IDEO OUT
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
AV
AUDIO
IN
STEREO
DIGITAL
OPTICAL
Optional: Connecting to an
Audio System
01-41 DVP900_00A31 13/01/2005, 09:5814
/00_3139 246 13873
English
15
Functional Overview
Front Panel
SYSTEM MENU
DISC MENU
STOPPLAY
OPEN/CLOSE
SOUND MODE
AUDIO DIRECT
STANDBY-ON
OK
DVP 9000S
STANDBY-ON B
– To switch the DVD Player to Standby
mode or ON
Display
– Shows the current status of the DVD
Player
IR Sensor
– Point the remote control towards this
sensor
SYSTEM MENU
– Access or exit DVD Player’s system menu
OK/Cursor (1 2 3 4)
– Acknowledge menu selection/
– Selects an item in the menu/
fast forward/backward, slow forward/
backward
OPEN/CLOSE /
– Open/Close the disc tray
Disc tray
– Strip lights up when playback SACDs.
SOUND MODE
– LED lights up when the SOUND MODE
is applied
– Selects required sound mode
• for SACD: In Stop Mode, selects either a
CD Layer or SACD layer for hybrid discs.
During playback, allows you to select CD,
Stereo or Multi-channel (if available).
• for DVDs/VCDs: to select either Stereo,
Dolby Surround-compatible, 3D sound or
Multi-channel
AUDIO DIRECT
– LED lights up when the AUDIO DIRECT
is applied
– Switches video output on and off during
audio disc playback.
PLAY B
– To start playback
STOP 9
– To stop playback
DISC MENU
– Enters the disc contents menu
01-41 DVP900_00A31 13/01/2005, 09:5815
/00_3139 246 13873
English
16
Mains (AC Power Cord)
– Connect to a standard AC outlet
MULTICHANNEL AUDIO OUT
(For connection to a stereo and
multichannel receiver)
– center speaker, subwoofer, front and
surround speakers connection
Audio Out (Left/Right)
– Connect to AUDIO inputs to a stereo TV
S-VIDEO
YPbPr
MIXED 2CH
MAIN
CENTER
SUB WOOFER
6CH DISCRETE
SURROUND
LL
R
L
R
COMPONENT
SCAN MODE
INTERLACE
PROGRESSIVE
VIDEO
VIDEO OUT
HDMI
PCM / DIGITAL/
DTS / MPEG
COAXIAL OPTICAL
DIGITAL OUT
R
AUDIO OUT
~ AC
MAINS
AV
HDMI (High Definition
Multimedia Interface)
– Connect to a valid HDMI device (eg.;
LCD/Projector/Plasma/Projection TV,
HDTV or receiver)
SCAN MODE
(Interlace/Progressive)
– To switch between Progressive or
interlace
Component Y Pb Pr
– Connect to Y Pb Pr input of a TV
Caution: Do not touch the inner pins of the jacks on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
Functional Overview
Rear Panel
S-Video Out
– Connect to S-Video input of a TV
VIDEO OUT (CVBS)
– Connect to CVBS Video input of a TV
TV OUT (VIDEO OUT)
– Connect to a TV with SCART inputs
COAXIAL (Digital audio out)
– Connect to the coaxial AUDIO input of a
digital audio equipment
OPTICAL (Digital audio out)
– Connect to the optical AUDIO input of a
digital audio equipment
01-41 DVP900_00A31 13/01/2005, 09:5816
/00_3139 246 13873
English
17
Functional Overview
Remote Control
AUDIO DIRECT
– Switches video output on and off
during audio disc playback.
SELECT
– Selects the relevant device to
control: DVD, RECVR, TV, DVD+RW
DIM
– To select 3 different brightnesses
for the display
RETURN
– Return to the previous menu on a
video CD (VCD) or some DVDs
SYSTEM MENU
– Access or exit DVD Player’s system
menu
Cursor
– Selects up (3), down (4), left (1) and
right (2) direction in the menu
OK
– Acknowledge menu selection
S
– To search or select previous chapter
or track
9 (STOP)
– To stop playback
B (PLAY)
– To start playback
; (PAUSE)
– To pause playback temporarily /
frame-by-frame playback
REPEAT
– Selects various repeat modes
REPEAT (A-B)
– Repeats playback a specific section on
a disc
SHUFFLE
– Plays tracks/chapter in random order
SCAN
– Plays the first 10 seconds of each track/
chapter within a disc
POWER B
– To switch the DVD player to
standby mode or ON
LCD Screen
– Indicates active source mode.
(See important note below)
Numerical keypad (0-9)/
– Selects numbered items in a menu
DISPLAY
– Displays information on TV screen
during playback
DISC MENU
– Enters the disc contents menu
T
– To search or select next chapter or
track
VOL (+ / –), MUTE and
TV CH (+/-)
– Not applicable for this model.
SUBTITLE
– To access subtitle language system
menu
ANGLE
– Selects a DVD camera angle
ZOOM
– Enlarge a picture on the TV screen
AUDIO
– To access audio language system
menu
FTS
– Activate/deactivate Favorite Track
Selection
SOUND MODE
– Selects required sound mode
• for SACD: In Stop Mode, selects
either a CD Layer or SACD layer
for hybrid discs.
During playback, allows you to
select CD, Stereo or Multi-channel
(if available).
• for DVDs/VCDs: to select either
Stereo, Dolby Surround-compatible,
3D sound or Multi-channel
Important!
– This RC is a Philips system remote which is capable of
controlling other Philips equipment (eg., Recorder, TV
or DVD-RW player).
– Refer to manuals for other equipment as necessary.
01-41 DVP900_00A31 13/01/2005, 09:5817
/00_3139 246 13873
English
18
Getting Started
Step 1: Inserting batteries into
the Remote Control
1 Open the battery compartment.
2 Insert two batteries type R06 or AA,
following the indications (+-) inside
the compartment.
3 Replace the cover.
Using the Remote Control to
operate the Player
1 Aim the Remote
Control directly at the
remote sensor (iR) on
the front panel of the
DVD Player.
2 Do not put any objects
between the Remote
Control and the DVD
Player while operating
the DVD Player.
CAUTION!
– Remove batteries if they are
exhausted or if the Remote Control
will not be used for a long time.
– Do not use old and new or
different types of batteries in
combination.
– Batteries contain chemical
substances, so they should be
disposed properly.
Step 2: Setting up the TV
IMPORTANT!
Make sure you have completed all
the necessary connections. (See
pages 9-11 “Connecting TV”).
1 Turn on the TV and set it to the correct
Video-In channel. You should see the blue
Philips DVD background screen on the
TV.
2 Usually these channels are between the
lowest and highest channels and may be
called FRONT, A/V IN, or VIDEO. See your
TV manual for more details.
➜Or, you may go to channel 1 on your
TV, then press the Channel down button
repeatedly until you see the Video In
channel.
➜Or, the TV Remote Control may have a
button or switch that chooses different
video modes.
➜Or, set the TV to channel 3 or 4 if you
are using an RF modulator.
3 If you are using other external equipment
(audio system or receiver), turn it on and
select the appropriate input source for
the DVD Player. Refer to the equipment
owner’s manual for details.
SOUN
D
AUDIO DIRECT
01-41 DVP900_00A31 13/01/2005, 09:5818
/00_3139 246 13873
English
19
Selecting the color system that
corresponds to your TV
This DVD Player is compatible with both
NTSC and PAL. In order for a DVD to
play on this Player, the color system of the
Disc, the TV and the DVD Player should
match.
Use ↓ or ↑ to change the values, OK to confirm, ← to leave the
submenu
TV
TV System
TV Shape
Setup
TV System
PAL
NTSC
Auto
1 Press SYSTEM MENU.
2 Press 4 to select {SETUP}.
3 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {TV} and press 4.
Move to {TV SYSTEM} and press 2.
PAL – Select this if the connected TV has
the PALcolor system. It will change the
video signal of an NTSC disc and output it
in PAL format.
NTSC – Select this if the connected TV
has the NTSC color system. It will change
the video signal of a PAL disc (VCD only)
and output it in NTSC format.
Auto – Select this if the connected TV is
compatible with both NTSC and PAL
(multi-system). The output format will be
in accordance with the video signal of the
disc.
4 Select an item and press OK.
Helpful Hint:
– Some image distortion occurs when
switching NTSC and PAL mode.
– AUTO will be selected during progressive
or HDMI mode.
Getting Started
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Selecting the TV Shape
Set the aspect ratio of the DVD Player
according to the TV you have connected.
The format you select must be available
on the disc. If it is not, the setting for TV
display will not affect the picture during
playback.
Use ↓ or ↑ to change the values, OK to confirm, ← to leave the
submenu
TV
TV System
TV Shape
Setup
TV Shape
4:3 Pan Scan
4:3 Letterbox
Widescreen
1 Press SYSTEM MENU.
2 Press 4 to select {SETUP}.
3 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {TV} and press 4.
Move to {TV SHAPE} and press 2.
4:3 Pan Scan
➜If you have a regular
TV and want both
sides of the picture to
be trimmed or
formatted to fit your TV
screen.
4:3 Letter Box
➜If you have a standard
TV. In this case, a wide
picture with black bands on the upper and
lower portions of the TV screen will be
displayed.
Widescreen
➜If you have a wide
screen TV.
4 Select an item and press OK.
01-41 DVP900_00A31 13/01/2005, 09:5819
/00_3139 246 13873
English
20
Step 3: Setting language
preferences
You can select your preferred language
settings.This DVD Player will
automatically switch to the language for
you whenever you load a disc.
Setting the Menu Language
The On-screen language for the system
menu will remain as you set it, regardless
of various disc languages.
Use ↓ or ↑ to change the values, OK to confirm, ← to leave the
submenu
Language
Menu Language
Setup
Menu Language
Svenska
English
Español
Français
Português
Default Subtitle
Default Audio
1 Press SYSTEM MENU.
2 Press 4 to select {SETUP}.
3 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {LANGUAGE} and press 4.
Move to {MENU LANGUAGE} and press
2.
4 Select a language and press OK.
Getting Started
Setting the Default Audio and
Default Subtitle languages
You can select the audio language spoken
and subtitle languages in a video disc. If
the language selected is not available on
the disc, the disc’s default setting language
will be used instead.
Use ↓ or ↑ to change the values, OK to confirm, ← to leave the
submenu
Language
Menu Language
Setup
Default Audio
Svenska
English
Español
Français
Português
Default Subtitle
Default Audio
1 Press SYSTEM MENU.
2 Press 4 to select {SETUP}.
3 Press 3 4 to highlight one of the
following:
– {DEFAULT AUDIO} (disc’s soundtrack)
– {DEFAULT SUBTITLE} (disc’s subtitles)
4 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
5 Select a language and press OK.
6 Repeat steps 3~5 for other language
settings.
Helpful Hint:
– Some discs (example Karaoke discs) are
recorded on multiple audio channels.
Press AUDIO repeatedly during playback to
choose LR to hear both channels, LL to hear
left channel (only music) and RR to hear
right channel (only vocal).
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
01-41 DVP900_00A31 13/01/2005, 09:5820
/00_3139 246 13873
English
21
Getting Started
Step 4: Setting the speakers’
channels
You can adjust the delay times (centre
and surround only) and volume level for
individual speakers. These adjustments let
you optimize the sound according to
your surroundings and setup.
IMPORTANT!
The speaker settings only available on
Multi-channel audio outputs. You can
also press SOUND MODE button to
select Multi-channel.
1 Press SYSTEM MENU.
2 Press 4 to select {SETUP}.
3 Press 1 2 to highlight {SPEAKERS}, then
press 4.
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Speakers Movie Mode Music Mode
Front Size
Surround Size
Centre Size
Setup
Subwoofer
4 Press 34 to highlight one of the options,
then press 2.
{FRONT SIZE, CENTER SIZE,
SURROUND SIZE}
OFF – when no speaker is connected.
LARGE – when connected speakers can
produce low frequency signals below
120Hz.
SMALL – when connected speakers
cannot produce low frequency signals
below 120Hz.
{SUBWOOFER}
ON – when a subwoofer is connected.
OFF – when no subwoofer is connected.
{FRONT DISTANCE}
– Sets the distance from your listening
place to the front speakers (1 ~ 11.8m).
{CENTER/REAR DISTANCE}
– Sets the distance from your listening
place to the center/rear speakers. (choices
different depending on the {FRONT
DISTANCE} setting).
5 Press 1 2 3 4 to adjust the setting that
best suit your surround sound needs.
6 Press OK to confirm.
Helpful Hints:
– Use the longer delay time settings when
the surround/rear speakers are closer to the
listener than the front speakers.
Advance Bass Management
Movie Mode
This menu allows you to adjust each
speaker volume for playing all discs
except SACD audio playback.
➜ The volume balance value ranges from
-6dB to +7dB.
Music Mode
When music mode is set, speaker settings
will be applied during SACD playback
only.
Additional adjustments available in SACD
bass managements are:
– Cut-off frequency adjustment:
60Hz, 80Hz, 100Hz and 120Hz
– Slope adjustment:
12dB/oct, 18dB/oct and 24dB/oct
Helpful Hint:
– These additional adjustments are
available in the subwoofer adjustments.
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
01-41 DVP900_00A31 13/01/2005, 09:5821
/00_3139 246 13873
English
22
Disc Operations
IMPORTANT!
– Depending on the DVD or VIDEO
CD, some operations may be
different or restricted.
– Do not push on the disc tray or
put any objects other than discs in
the disc tray. Doing so may cause
the disc player to malfunction.
Playable Discs
Your DVD Player will play:
– Digital Versitile Discs (DVDs)
– Digital Versitile Audio Discs (DVD-A)
– standard defination layer
– Video CDs (VCDs)
– Super Video CDs (SVCDs)
– Super Audio CDs (SACDs)
– Digital Video Discs + Recordable
[Rewritable] (DVD+R[W])
– Compact Discs (CDs)
– MP3 discs, picture (Kodak, JPEG) files
on CD-R(W).
– JPEG/ISO 9660 format
–Maximum 30 characters display.
–Supported sampling frequencies :
32 kHz, 44.1 kHz, 48 kHz (MPEG-1)
16 kHz, 22.05 kHz, 24 kHz (MPEG-2)
–Supported Bit-rates : 32~256 kbps
(MPEG-1), 8~160 kbps (MPEG-2)
variable bitrates
SUPER VIDEO
Helpful Hints:
– It may not be possible to play CD-R/RW
or DVD-R/RW in all cases due to the type of
disc or condition of the recording.
– If you are having trouble playing a
certain disc, remove the disc and try a
different one. Improperly formatted disc will
not play on this DVD Player.
Region Codes
This DVD Player is designed to support
the Region Management System. Check
the regional code number on the disc
package. If the number does not match
the Player’s region number (see table
below), the Player may be unable to
playback the disc.
Region
Region
number of
the unit
Discs that can
be played
(Example)
U.S.A. and
Canada regions
U.K and
Europe regions
General regions
Australia region
1
2
3
ALL
4
ALL
ALL
ALL
1
2
3
4
01-41 DVP900_00A31 13/01/2005, 09:5822
/00_3139 246 13873
English
23
IMPORTANT!
If the inhibit icon (X) appears on the
TV screen when a button is pressed,
it means the function is not available
on the current disc or at the current
time.
Playing discs
1 Press SELECT button until “DVD” is
lighted on the remote control display
panel (see remote control, page 17).
2 Turn on the TV and set it to the correct
Video In channel. (See page 18 “Setting up
the TV”).
3 Press STANDBY-ON B on the front of
the DVD Player.
➜You should see the Philips DVD
background screen on the TV.
4 Press OPEN/CLOSE 0 to open the disc
tray and load a disc. Press again to close
the disc tray.
➜Make sure the label is facing up. For
double-sided discs, make sure the label of
the side you want to play is facing up.
5 Playback may start automatically
(depending on the disc type).
➜If a disc menu appears on the TV, see
“Using the Disc Menu”.
➜If the disc is locked by parental control,
you must enter your four-digit password.
(See pages 36-37).
6 At any time, simply press STOP 9 to
stop playback.
Disc Operations
Using the Disc Menu
Depending on the disc, a menu may
appear on the TV screen once you load
the disc.
To select a playback feature or item
● Use the 1 2 3 4 or numeric keypad
(0-9) on the Remote Control, then press
PLAY B or OK to start playback.
To access the menu
● Press DISC MENU on the Remote
Control.
Display on LCD
Area 1
– Currently playing logo or media will be
lit during playback.
Area 2A
– Indicates current information in the
disc or media during playback.
Area 2B
– Indicates current disc or media elapsed
time.
Area 3
– Indicates current mode of the DVD
Player.
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
Area 1
Area 2A
Area 2B
Area 3
01-41 DVP900_00A31 13/01/2005, 09:5823
/00_3139 246 13873
English
24
Disc Operations
Resuming playback from the last
stopped point
(DVD/DVD-A/VCD/CD)
Resume playback of the last five discs,
even if the disc was remove from the
Player.
1 Load one of the last five discs.
➜ “READING” appears.
2 Press PLAY B and the disc will play from
the last point.
To cancel resume mode
● While play is stopped, press STOP 9
again.
Shuffle (DVD/DVD-A/VCD/CD/
SACD/MP3)
On a DVD/DVD-A disc - this shuffles the
playing order of chapters within a title, if
the title has more than one chapter.
On an Audio CD, Video CD, SACD - this
shuffles all the tracks in random order
within a disc.
1 Press SHUFFLE during playback.
➜ SHUFFLE appears on the TV screen for
about two seconds.
2 To return to normal playback, press
SHUFFLE again.
Helpful Hint:
– For SACD, shuffle functions works in the
currently selected area only.
Playback controls
Unless otherwise stated, all operations
described are based on Remote Control
use. Some operations can be carried out
using the DVD system Menu.
Pausing playback
(DVD/DVD-A/VCD/CD)
1 During playback, press PAUSE ;.
➜Play will pause and sound will be mute.
2 Press PAUSE ; repeatedly to select the
previous or next picture frame.
3 To return to normal playback, press
PLAY B.
Selecting a title (track) /chapter
(DVD/DVD-A/VCD/CD)
1 Press T or S briefly during
playback to go to the next chapter/track
or to return to the beginning of the
currect chapter/track respectively.
2 Press S twice briefly to step back to
the previous chapter/track.
3 To go directly to any chapter/track, enter
the chapter/track number using the
numerical keys (0-9).
Zoom (DVD/DVD-A/VCD/JPEG)
Zooming allows you to enlarge the video
image during playback.
1 Press ZOOM during playback to select
the zoom factor.
2 Press 1 2 3 4 to move through the
zoomed image.
3 Press ZOOM repeatedly to increase and
decrease the zoom factor.
➜Playback will continue.
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
01-41 DVP900_00A31 13/01/2005, 09:5824
/00_3139 246 13873
English
25
Scan (DVD/DVD-A/VCD/CD/MP3/
SACD)
Scanning plays the first 10 seconds of each
chapter/track on the disc. You can activate
scan playback by pressing SCAN button.
OR
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {VIEW} and press 4.
Move to {CHAPTER PREVIEW} and press
2 to select {ON or OFF}.
Time Search
(DVD/DVD-A/VCD/CD/SACD/MP3)
The Time Search function allows you to
start playback at any chosen time on the
disc.
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {SEARCH} and press 4.
Move to {TIME} and press 2.
➜ Playback will pause.
3 Enter hours, minutes and seconds in the
time edit box using Remote Control
numerical key pad.
4 Press OK to confirm.
➜Playback starts from the selected time
on the disc.
5 To remove the menu, press SYSTEM
MENU.
Helpful Hint:
– This feature will not applicable to VCD
discs with Playback control in PBC ON.
Disc Operations
Repeat (DVD/DVD-A/VCD/CD/
MP3/SACD/JPEG)
You can play a chapter, track, title or
entire disc repeatedly.
● Press REPEAT continuously to choose a
Repeat mode during playback appears on
the TV screen.
➜ DVD
‘
CHAPTER /TITLE /DISC /OFF’.
➜ VCD / CD
‘
TRACK /DISC /OFF’.
➜ MP3
‘
TRACK /ALBUM /DISC /OFF’.
➜ SACD
‘
TRACK /AREA /OFF’.
➜ JPEG
‘
REPEAT ROLL/REPEAT DISC’.
Repeat A-B (DVD/DVD-A/VCD/CD)
You can play only a specific portion of a
Title/Track or Chapter repeatedly.
1 During playback, press REPEAT A-B at
your chosen starting point.
➜‘REPEAT A’ appears on the TV screen.
2 When the disc reaches your selected
ending point, press REPEAT A-B again.
➜‘A-B’ appears on the TV screen, and the
repeat sequence begins.
3 To resume regular playback, press
REPEAT A-B again.
➜‘A/B OFF’ appears on the TV screen.
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
01-41 DVP900_00A31 13/01/2005, 09:5825
/00_3139 246 13873
English
26
Disc Operations
Still Picture and Frame-by-frame
playback (DVD/DVD-A/VCD)
You can activate frame by frame playback
by pressing PAUSE ; or 3 button on
the remote control repeatedly.
OR
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {SEARCH} and press 4.
Move to {FRAME BY FRAME} and press 2.
➜ Playback will pause.
3 Use the cursor keys 1 2 to select the
previous or next picture frame.
4 To exit frame by frame playback, press
PLAY B.
Slow Motion
(DVD/DVD-A/VCD/SVCD)
Slow motion can be activated by pressing
the 4 button. To exit slow motion mode,
press PLAY B.
OR
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {SEARCH} and press 4.
Move to {SLOW} and press 2.
➜ Sound will be muted.
3 Press 1 2 to select the required speed:
<1/8, <1/4, <1/2 or <1 (backward), or >1/
8, >1/4, >1/2 or >1 (forward).
➜ Select 1 to play the disc at normal
speed again.
4 To return to normal speed, press PLAY B.
Searching (DVD/DVD-A/VCD/
SVCD/CD/MP3/SACD)
For DVD/DVD-A/VCD/SVCD
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {SEARCH} and press 4.
Move to {FAST} and press 2.
➜ Sound will be muted.
3 Use 1 2 to select the required speed:
<<4, <<8 or <<32 (backward), or >>4,
>>8 or >>32 (forward).
4 To return to normal speed, press PLAY B.
● You can also hold down T or S
keys for more than two seconds to
activate fast search.
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
For CD/MP3/SACD
1 Use the 1 2 keys to select the required
speed: <<32, <<8 or <<4 (backward), or
>>4 or >>8, >>32 (forward).
2 You can also hold down T or S
keys for more than two seconds to
activate fast search.
01-41 DVP900_00A31 13/01/2005, 09:5826
/00_3139 246 13873
English
27
Disc Operations
Special DVD features
Selecting a title
Some DVDs may contain several titles. If
the disc has a title menu recorded on it,
you can start playback from the selected
movie title.
1 Press RETURN.
➜The disc title menu appears on the TV
screen.
2 Use 3 4 1 2 or the numeric keypad
(0-9) to select a play option.
3 Press OK to confirm.
Camera Angle
If the disc contains sequences recorded
from different angle, this allows you to
view picture from different angle.
● Press ANGLE repeatedly to select a
different desire angle.
➜Playback changes to the selected angle.
Changing the Audio Language
● Press AUDIO repeatedly to select
different audio languages.
Subtitles Language
● Press SUBTITLE repeatedly to select
different subtitle languages.
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
Program Playback
(DVD/DVD-A/VCD/CD/SACD/MP3)
You can play the contents of the disc in
the order you want by programming the
tracks to be played. Up to 20 tracks can
be stored.
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {PROGRAM} and press 4.
Move to {TRACKS} and press 2.
➜ The ‘Program’ menu appears.
3 Use 3 or 4 to select your preferred Title
or Chapter number.
4 Press OK to confirm selection.
➜ The selection of Title or Chapter
numbers will appear in the {PLAYLIST}.
Erasing a selection in a Program
1 Press 4 to select the {PLAYLIST}.
2 Press 2 to display the {PLAYLIST} and use
3 or 4 to select the item you want to
erase.
3 Press OK to erase the selection.
Erasing all selections
● Use 4 to select {CLEAR ALL} and press
2 to select confirm.
➜ All selections will be erased.
To list the programmed item(s)
● While play is stopped, press SYSTEM
MENU.
Select {PROGRAM} and set it to ON,
then press B.
01-41 DVP900_00A31 13/01/2005, 09:5827
/00_3139 246 13873
English
28
Playing MP3/JPEG/Kodak Picture
CD
This player can playback MP3, JPEG, or
Kodak Picture CD files on a personally
recorded CD-R/RW disc or commercial
CD.
IMPORTANT!
You have to turn on your TV and set to
the correct Video In channel. (See page 18
“Setting up the TV”).
1 Load a disc.
➜The disc reading time may exceed 30
seconds due to the complexity of the file
configuration.
➜Playback starts and the playlist appears
automatically. If the disc includes both
MP3 and picture files, the selection of
menu appears on the TV screen.
2 Use 3 4 to select a album/track and
press OK to open the folder.
3 Use 1 2 to select a album/track in the
next layer to playback.
4 Playback will start at the selected file and
continue to the end of the folder.
5 To stop playback, press STOP 9.
● Press DISC MENU to return to the
thumbnail screen (for JPEG files).
Special features for picture disc
playback
IMPORTANT!
You have to turn on your TV and set to
the correct Video In channel. (See page 18
“Setting up the TV”).
Slide show playback setting
You can set the duration of each picture
time playback.
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {SLIDE SHOW} and press 4.
Move to {PICTURE TIME} and press 2.
Slow – Picture playback for 8 seconds.
Medium – Picture playback for 5
seconds.
Fast – Picture playback for 2 seconds.
3 Select an item and press OK.
Rotating the picture
1 Press SYSTEM MENU and press 3 4
to select {TOOLBAR} option.
2 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
Move to {VIEW} and press 2.
Move to {ROTATE} and press 2 to
choose the following: {- 180 to + 180}.
3 Select an item and press OK.
Helpful hint:
– Rotate function is not available during slide
show playback.
Disc Operations
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
01-41 DVP900_00A31 13/01/2005, 09:5828
/00_3139 246 13873
English
29
Disc Operations
Zoom picture
● During playback, press ZOOM repeatedly
to display the picture with different scales.
● Use
1 2 3 4 to view the zoomed picture.
Playback with multi-angles
● During playback, press 3 4 1 2 to rotate
the picture on the TV screen.
3: flip the picture vertically
4: flip the picture horizontally
1: rotate the picture anti-clockwise
2: rotate the picture clockwise
Scan Effect
● Press ANGLE repeatedly to choose a
different scan effect.
Playing MP3 music or JPEG picture
It is possible to playback discs that
contains both MP3 music and JPEG
picture files.
1 Load a disc that contains music and
picture.
➜The disc menu appears on the TV.
Play Contents
1. Pictures
2. MP3
2 Select an MP3 track or a JPEG picture file.
➜The music tracks or picture files will be
played back one after another until end of
the folder.
3 To return to disc menu, press STOP Ç
followed by 1.
Helpful Hint:
– Some files on Kodak or JPEG disc may
be distorted during playback due to the
configuration and characteristics of the disc.
Playing Super Audio CD (SACD)
There are three types of SACD discs:
single layer, double layer or hybrid disc.
The hybrid disc contains both Super
Audio CD and standard audio CD layers,
only the SACD layer is possible to
playback on this DVD player.
1 Load a SACD.
➜The disc menu appears on the TV
screen.
2 Playback will start automatically.
➜If the SACD consists of mulit-channel
and stereo tracks, the setting will
automatically switch according to the
{Analogue Output} selection.
➜To playback stereo tracks, use 3 4
keys to make your selection from the disc
menu, then press PLAY B.
TIPS:
The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
01-41 DVP900_00A31 13/01/2005, 09:5829
/00_3139 246 13873
English
30
This DVD Player setup is carried out via
the TV, enabling you to customize the
DVD player setting to suit your own
requirements.
Preferences
1 Press SYSTEM MENU.
2 Press 3 4 to select {PREFERENCES}.
3 In {PREFERENCES}, press 1 2 to highlight
one of the preferred option.
4 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
5 Press OK to confirm.
Use ↓ or ↑ to select other options, → to enter options,
RETURN to leave the menu
Picture Adv.Picture Sound
Setup
Preferences
DVD Menu Options
NOTE:
Some of the features in the DVD
Menu Options are described in
“Getting Started”.
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Use ↓ or ↑ to change the values, OK to confirm, ← to leave the
submenu
Color Setting
Contrast
Brightness
Preference
Sharpness
Colour Setting
Animation
Rich
Natural
Soft
Personal
Color Settings (not applicable for
Component Video Output)
You can select from one of five predefined
sets of color settings and one set
{PERSONAL} which you can define
yourself.
1 When {PERSONAL} is selected, it allows
you to fine-tune saturation, brightness,
contrast and sharpness.
2 Press 3 4 to adjust the values of these
parameters.
3 Press OK or 1 to exit.
Saturation/ Contrast/ Brightness
(not applicable for Component
Video Output)
Adjust the video color saturation/
contrast and brightness.
➜Use 1 2 to select the following option;
{-7 to +7}.
Sharpness (for all video output)
Adjust the sharpness of the video.
➜Use 1 2 to select the following option;
{0 to +7}.
Video Shift
Video shift can be used to adjust the
horizontal position of the picture on the
TV screen by scrolling the slider to the
left or right.
➜Use 1 2 to select the following option;
{+1 to +7}.
01-41 DVP900_00A31 13/01/2005, 09:5830
/00_3139 246 13873
English
31
Advance Picture
Allows you to fine-tune the following
video parameters.
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Adv.Picture Sound Features
TrueLife
Gamma
DCDi
Preferences
Chroma Delay
TrueLife (for Progressive Scan
output only)
Produces a more dynamic picture by
increasing the contrast and color
intensity.
➜ Use 1 2 to select the following option;
{0 to +7}.
DCDi (for Progressive Scan output
only)
DCDi (Directional Correction
Deinterlacing) computes and tracks the
angle of edge to fill in the missing pixels
on the TV screen.
➜
On – Optimize the picture quality
significantly, especially during the slow
motion playback.
➜
Off – Select this to disable DCDi
function.
Gamma (for Component output
only)
Enables you to adjust the intensity of the
picture non-linearly. A positive value
enables you to bring out low level detail
in dark scenes, while a negative value
emphasizes contrast.
➜ Use 1 2 to select the following option;
{-7 to +7}.
DVD Menu Options
Chroma Delay (for Component
output only)
The chroma (color) and luma (brightness)
signals are not synchronized. This setting
allows you to adjust the advance delay of
the chroma signal to yield a perfectly clear
picture.
➜ Use 1 2 to select the following option;
{-3 to +3}.
4:3 Aspect (for Progressive Scan
output only)
To adjust the ratio of the pictures on the
TV screen.
➜
4:3 Pillarbox – For display of 4:3
picture on 16:9 TV screen without
stretching.
➜
NL Stretch – For display of 4:3 image
on 16:9 TV with non-linear stretching
(center portion of screen is stretch less
then the side).
➜
Auto – No aspect ratio adjustment
HiVideoDef (for HDMI/DVI output
only)
You are able to select the resolution for
finer color selection when picture appears
on the TV screen. The available options
will be displayed once you have connected
the HDMI connection (see page 12).
➜ Use 1 2 to select the following option;
{480p, 576p, 720p, 1080i, AUTO}.
Helpful Hints:
– If no display appears on the TV screen
due to unsupported resolution, reconnect any
available interlace video output to you
monitor to re-adjust the resolution settings.
– Only 480p and 576p are available for
progressive scan analogue output.
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
01-41 DVP900_00A31 13/01/2005, 09:5831
/00_3139 246 13873
English
32
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Sound
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Sound Features
Night Mode
CD Upsample
Analog Output
Preferences
ClearVoice
Night Mode
High volume outputs are softened,
enabling you to watch your favorite action
movie without disturbing others.
➜
On – The dynamics of your sound
output are optimized.
➜
Off – To enjoy the surround sound
with its full dynamic range.
Analog Output
Allows you to set the stereo analog
output of your DVD Player.
➜
Stereo – Select this to change channel
output to stereo that delivers sound from
only the two front speakers and
subwoofer.
DVD Menu Options
➜Dolby Surround-compatible – Use
this option when your DVD Player’s
AUDIO OUT jacks are connected to a
Dolby Pro Logic decoder.
➜
3D Sound – 3D Sound provides a
virtual surround sound experience using
just two speakers. Use this option
connecting directly to a TV or stereo.
➜
Multi-channel – Select this to enable
Multi-channel output. Dolby Pro Logic II
will be activated if a 2channel recorded
disc is being played back.
Helpful Hints:
– Multi-channel and downmixed stereo
output are not available simultaneously.
– You can also use SOUND MODE
button to select this options.
CD Up-sampling
Allows you to convert your music CD
from 44.1kHz/16 bit to various higher
sampling rate for superior sound quality.
➜ Use 1 2 to select the following option;
{88.2kHz, DSD, OFF}.
Helpful hints:
– CD Up-sampling will be disabled when
{MULTICHANNEL} is selected.
– You can also use AUDIO button to
select this options.
Clear Voice
Increases the volume of dialog for easy
listening at night. This function is only
available for certain multi-channel discs.
➜Use 3 4 to select the {ON or OFF}.
Content Mode
This setting allows you to select the
optimum of video output to maximise the
video quality.
➜
Video – Select this to have a more
stable and less of an action of video
content.
➜
Film – Film mode is adapted best for
movies.
➜
Auto – The video output will be in
accordance with the video contents for
most disc.
01-41 DVP900_00A31 13/01/2005, 09:5832
/00_3139 246 13873
English
33
Features
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Features
Wakeup timer
Status window
Help line
Preferences
Dimmer
Wakeup timer
The DVD Player will turn on automatically
after the preset time. Pressing any button
during standby mode will cancel the
wakeup timer mode.
➜ Use 1 2 to select the following option;
{0 to 600} minutes.
Helpline
On – Helpline appears on the TV screen
with a brief description of the selected
option.
Off – If you no longer require the help-
line.
Status Window
On – Displays the current play state and
time information on the TV screen.
Off – No information shown on the TV
screen.
DVD Menu Options
Setup
● Playback will stop when {SETUP} menu is
selected.
1 Press SYSTEM MENU.
2 Press 3 4 to select {SETUP}.
3 In {SETUP}, press 1 2 to highlight one of
the preferred option.
4 Use the 1 2 3 4 keys on the Remote
Control to navigate in the menu.
5 Press OK to confirm.
Use ↓ or ↑ to select other options, → to enter options,
RETURN to leave the menu
Language TV Audio Menu
Setup
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Karaoke Vocal
Enables you to play multi-channel karaoke
DVDs.
➜
On – Karaoke channels on the disc will
be mixed into normal stereo, allowing you
to hear both the lyrics and music
together.
➜
Off – The sound from lyrics will be
muted.
Dimmer
To adjust the brightness of front panel
display.
➜
Low – Set to the lowest level of
brightness.
➜
Medium – Set to the medium level of
brightness.
➜
Normal – Set to the normal level of
brightness.
Helpful hint:
– You can also use DIM button to select
this options.
01-41 DVP900_00A31 13/01/2005, 09:5833
/00_3139 246 13873
English
34
DVD Menu Options
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Language
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Language TV Audio Menu
Menu Language
Setup
Default Subtitle
Default Audio
Menu Language
This menu contains various language
options for display language on the TV
screen. For details, see page 20.
Default Subtitle/ Default Audio
This menu contains various language
options for subtitle or audio language
which may be recorded on the DVD. For
details, see page 20.
TV
TV System
This menu contains the options for
selecting the color system that matches
the connected TV. For details, see page 19.
TV Shape
This menu contains the options for
setting the aspect ratio of the DVD Player
according to the connected TV. For details,
see page 19.
Audio Menu
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Audio Menu Speakers Movie Mode
Digital Output
SACD Direct
Subwfr freq
Setup
Plug And Play
Digital Output
Digital output selection enables you to
specify the type of digital output suitable
for your AV receiver.
➜
All – If you connected the DVD
Player’s Digital (Coaxial or Optical) jack
to a multi-channel decoder/receiver.
➜
PCM Only – If you receiver is not
capable of decoding a multi-channel audio.
➜
Off – Select this to deactivate the
digital output.
Helpful Hint:
– Digital output is not available for SACD
due to copy-protection.
01-41 DVP900_00A31 13/01/2005, 09:5834
/00_3139 246 13873
English
35
Subwoofer frequency
Enables you to select Subwoofer
frequency output between 120Hz {LOW}
and 200Hz {HIGH}.
SACD Direct
Enables you (with a suitable speaker
system where the satelite speaker has
sufficient bass response to 40Hz) to
bypass the bass management system for
multi-channel SACD playback. This helps
to preserve maximum sound quality of
your SACD.
➜
On – Select this to enjoy pure SACD
quality.
➜
Off – When set to OFF, the speaker
settings will applied during multi-channel
SACD playback (see page 21).
HDMI audio
This feature is available for automatic
audio selection only when HDMI devices
is connected and recognised.
➜
On – HDMI will output whatever is on
the SPDIF connector (depending on the
setting of ‘Digital Output’ and the disc.
➜
Off – HDMI audio stream muted.
PCM Output
Allows you to select PCM digital output
between 48kHz and 96kHz.
➜
48kHz – A 96kHz PCM data disc will
be converted to 48kHz.
➜
96kHz – 96kHz PCM audio on non-
copy protected DVD discs will be played
back at 96kHz. For copy protected discs,
the digital output will be downsampled to
48kHz.
Speakers (Advance Bass
Management)
This menu contains setup options for
your audio output which makes the
speaker setup system reproduce high
quality surround sound. For details, see
page 21.
DVD Menu Options
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Features
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Features Access
PBC
Sleeptimer
Setup
PBC (Playback Control)
Playback Control feature (only for VCD
2.0) can be set to {ON or OFF}.
If ‘ON’ is selected, the disc menu (if
available on the disc) will appear on the
TV.
Sleep Timer
Sleep timer turns this DVD Player to
standby mode when playback is stopped
for 20 minutes.
➜
On – DVD Player will go to standby
after a pre-defined time.
➜
Off – Select this to disable the {SLEEP
TIMER}.
01-41 DVP900_00A31 13/01/2005, 09:5835
/00_3139 246 13873
English
36
DVD Menu Options
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
Access
Use ← or → to select other options, ↓ to enter the submenu,
RETURN to leave the menu.
Access
Enter PIN
Parental Level
Setup
Country
Change PIN
Enter PIN
1 Press SYSTEM MENU and press 4 to
select {SETUP}.
2 Press 2 to select {ACCESS}.
➜Playback will stop.
3 Move to {ENTER PIN} and enter the four-
digit PIN.
4 Enter the four-digit PIN again to unlock
the disc or the display the {ACCESS}
menu.
Disc Lock
Not all discs are rated or coded by the
disc maker. You can prevent a specific disc
from playing by locking the disc.
➜
On – You will need to enter the four-
digit password before you can play the
disc.
➜
Off – Select this to unlock the disc and
allow future playback.
Helpful hints:
– When a locked disc is loading, the DVD
Player will prompt the four-digit password
(“0000” is the default password).
– To change the password, refer to option
{CHANGE PIN}.
Enabling Play once/Play Always
1 Insert a disc.
➜The ‘child safe’ dialog appears on the
TV screen.
2 Press 3 4 to select {Play once} or {Play
always}. Then, enter the four-digit code.
➜{Play once} – the disc can play as long
as it is in the disc tray and the DVD
system power is on.
➜{Play always} – the disc will play always.
even the Child Lock is set to Ç (lock).
3 If you later want to lock the disc so it will
not play always, insert the disc and press
Ç while the safe { icon appears on the
TV screen.
➜Locked | icon will appear. You may
need to remove the disc or turn off the
power before the disc is completely
locked. The next time when you insert
the disc, it will not play unless you enter
the four-digit code.
Country
● Parental Level codings are applicable only
for the country specified on the disc set
by the disc manufacturer.
● So, for some discs, you may need to
choose the country for which the disc is
coded in order to play at the Parental
Level you select.
01-41 DVP900_00A31 13/01/2005, 09:5836
/00_3139 246 13873
English
37
TIPS: To return to the previous menu, press 1.
To remove the menu, press SYSTEM MENU.
DVD Menu Options
Change PIN
1 Press SYSTEM MENU and press 4 to
select {SETUP} menu.
2 Press 2 to select {ACCESS}.
➜Playback will stop.
3 Enter your four-digit password.
4 Press 4 to {CHANGE PIN}, then press 2
to enter the four-digit password again.
5 Enter the new four-digit password.
6 Enter the new four-digit password a
second time to confirm.
➜The new four-digit password will take
effect.
7 Press SYSTEM MENU again to exit the
{SETUP} menu.
Helpful Hint:
– If you forget the password, you can press
STOP key four times to reset the password
to the default settings (0000).
Parental Level
Some DVDs may have a parental level
assigned to the complete disc or to
certain scenes on the disc. This feature
lets you set playback limitation level. The
rating levels are from 1 to 8 and are
country dependant. You can prohibit the
playing of certain discs that are not
suitable for your children or have certain
discs played with alternative scenes (if
available on disc).
● VCD, SVCD, CD have no level indication,
so parental control has no effect on those
kinds of discs. This also applies to most
illegal DVDs.
● Press 4 to {PARENTAL LEVEL}, then
press 1 2 to select a rating from 1 to 8
for the disc inserted.
➜Select “0” to deactivate Parental Level
➜Select a rating from 1 to 8; discs or
scenes with the same rating or lower will
play. Higher rated discs or scenes will not
play unless you enter your 4-digit
password.
Helpful Hint:
– Some DVDs are not encoded with a
rating though the movie rating may be
printed on the Disc cover. The rating level
feature does not prohibit play of such Discs.
Rating explanations
8 ADULT
– Mature material; should be viewed only by
adults due to graphic sexual material, violence or
language.
7 NC-17
– No children under age 17; not recommended
viewing for children under age 17.
5-6 PG-R
– Parental Guidance - Restricted; recommended
that parents restrict children under 17 from
viewing or allow to view only when supervised by
a parent or adult guardian.
4 PG13
– Material is unsuitable for children under age 13.
3 PG
– Parental Guidance suggested.
1-2G
– General Audience; recommended as acceptable
for viewers of all ages.
0 NO PARENTAL
– It will play all discs.
01-41 DVP900_00A31 13/01/2005, 09:5837
/00_3139 246 13873
English
38
Problem Solution
No power – Check if the AC power cord is properly connected.
– Press the STANDBY ON B on the front of the
DVD Player to turn on the power.
No picture – Refer to your TV’s manual for correct Video In
channel selection. Change the TV channel until you
see the DVD screen.
– Check if the TV is switched on.
Distorted picture – Sometimes a small amount of picture distortion may
appear, depending on the disc being played. This is
not a malfunction.
‘Snowing’ effect when using HDMI – Check if your HDMI is faulty or properly connected.
or DVI connection – Check if your device supports HDCP.
TV display a ‘blank’ or ‘distorted’ screen – TV is incompitable with the resolution you chose.
after you switch the resolution on the – You may change to resolution of the player by
{High Def-Video}. connecting your TV to any of the interlace connector
of the DVD player.
Completely distorted picture or – Connect DVD Player directly to the TV.
black/white picture with DVD – Make sure the disc is compatible with the DVD
Player.
– Ensure that the DVD Player’s TV System is set to
match that of the Disc and your TV.
No sound or distorted sound – Adjust the volume.
– Check the audio cables and make sure both are
connected secured to the TV or Stereo Audio In jacks.
Picture freezes momentarily – Check the disc for fingerprints/scratches and
during playback clean with a soft cloth wiping from center to edge.
No audio at digital output – Check the digital connections.
– Check if your receiver can decode MPEG-2 or DTS.
Make sure digital output is set to PCM Only.
– Check if the audio format of the selected audio
language matches your receiver capabilities.
Troubleshooting
WARNING
Under no circumstances should you try to repair the system yourself, as this will
invalidate the warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If
you are unable to remedy a problem by following these hints, consult your dealer or
Philips for help.
Visit us at www.philips.com/support for service support
01-41 DVP900_00A31 13/01/2005, 09:5838
/00_3139 246 13873
English
39
Disc can’t play – A DVD+R/DVD+RW/CD-R must be finalized.
– Ensure the disc label is facing up.
– Check if the disc is defective by trying another disc.
– If you have recorded a Picture CD or MP3 CD
yourself, ensure that your disc contains at least 10
pictures or 5 MP3 tracks.
– Check the Disc’s Region Code.
No return to start-up screen when – Reset the unit by switching the player off, then on
disc is removed again.
The player does not respond to – Aim the Remote Control directly at the sensor
the Remote Control on the front of the player.
– Reduce the distance to the player.
– Replace the batteries in the Remote Control.
– Re-insert the batteries with their polarities (+/–
signs) as indicated.
Buttons do not work – To completely reset the player, unplug the AC
cord from the AC outlet for 5-10 seconds.
Player does not respond to some – Operations may not be permitted by the disc.
operating commands during playback. Refer to the instructions of the disc jacket.
DVD Player cannot read – Use a commonly available cleaning CD/DVD to
CDs/DVDs clean the lens before sending the DVD Player for
repair.
Menu items cannot be selected – Press STOP twice before selecting the System Menu.
– Depending on the disc availability, some menu items
cannot be selected.
Troubleshooting
Problem Solution
Visit us at www.philips.com/support for service support
01-41 DVP900_00A31 13/01/2005, 09:5839
/00_3139 246 13873
English
40
Specifications
TV STANDARD (PAL/50Hz) (NTSC/60Hz)
Number of lines 625 525
Playback Multistandard (PAL/NTSC)
VIDEO PERFORMANCE
Component video Y: 1 Vpp into 75 ohm
output PbPr: 0.7 Vpp into 75 ohm
Video output 1 Vpp into 75 ohm
S-Video output Y: 1 Vpp into 75 ohm
C: 0.3 Vpp into 75 ohm
Video Shift Left/Right
AUDIO FORMAT
Digital MPEG Compressed
Digital
Dolby Digital 16, 20, 24 bits
PCM fs, 44.1, 48, 96 kHz
MP3 (ISO 9660) 96, 112, 128, 256 kpps
& variable bit rate
fs, 32, 44.1, 48kHz
Analog Stereo Sound
Dolby Surround-compatible downmix from Dolby Digital
multi-channel sound
3D Sound for virtual surround sound on 2 speakers
PiCTURE FORMAT
Digital Images .JPG, .JPEG
Maximum resolution 5 Mega Pixels
AUDIO PERFORMANCE
DA Converter 24 bits
DVD fs 96 kHz 4 Hz - 44 kHz
fs 48 kHz 4 Hz - 22 kHz
CD/Video CD fs 44.1kHz4 Hz - 20 kHz
S-Video CD fs 48 kHz 4 Hz - 22 kHz
fs 44.1kHz4 Hz - 20 kHz
Signal-Noise (1kHz) 115 dB
Dynamic Range (1kHz) 95 dB
Crosstalk (1kHz) 110 dB
Distortion and Noise (1kHz) 95 dB
MPEG MP3 MPEG Audio Layer 3
CONNECTIONS
Scart Output Euroconnector
Y Pb Pr output (480i/p) Cinch 3x (green, blue, red)
Video output Cinch (yellow)
S-Video output Mini DIN, 4 pins
Audio L+R output Cinch (white/red)
Digital Output 1 coaxial, 1 optical
IEC60958 for CDDA / LPCM
IEC61937 for MPEG 1/2,
Dolby Digital, DTS
CABINET
Dimensions (w x h x d) 435 x 79 x 315 mm
Weight Approximately 5.3 kg
POWER SUPPLY (UNIVERSAL)
Power inlet
U.S.A and Canada models 120V, 60Hz
Australia models 240V; 50Hz
U.K and Europe models 230V; 50Hz
General model 110-240V; 50/60Hz
Power usage Approx. 25 W
Power usage standby > 1 W
Specifications subject to change without prior notice
01-41 DVP900_00A31 13/01/2005, 09:5840
/00_3139 246 13873
English
41
Analog: Sound that has not been turned into
numbers. Analog sound varies, while digital
sound has specific numerical values. These
jacks send audio through two channels, the left
and right.
Aspect ratio: The ratio of vertical and
horizontal sizes of a displayed image. The
horizontal vs. vertical ratio of conventional TVs.
is 4:3, and that of wide-screens is 16:9.
AUDIO OUT Jacks: Red and white jacks on
the back of the DVD Player that send audio to
another system (TV, Stereo, etc.).
Bit Rate: The amount of data used to hold a
given length of music; measured in kilobits per
second, or kbps. Or, the speed at which you
record. Generally, the higher the bit rate, or the
higher the recording speed, the better the
sound quality. However, higher bit rates use
more space on a Disc.
Chapter: Sections of a movie or a music
piece on a DVD that are smaller than titles. A
title is composed of several chapters. Each
chapter is assigned a chapter number enabling
you to locate the chapter you want.
Component Video Out Jacks: Red, blue
and green jacks on the back of the DVD
System that send high-quality video to a TV
that has Component Video In jacks (R/G/B, Y/
Pb/Pr, YUV, etc.).
Digital: Sound that has been converted into
numerical values. Digital sound is available
when you use the DIGITAL AUDIO OUT
(COAXIAL or OPTICAL) jacks. These jacks
send audio through multiple channels, instead
of just two channels as analog does.
DCDi™ by Faroudja : Digital Crystal Clear is
a package of picture innovations that digitally
adjusts and optimizes picture quality to optimal
contrast, color and sharpness level.
Disc menu: A screen display prepared for
allowing selection of images, sounds, subtitles,
multi-angles, etc recorded on a DVD.
Dolby Digital: A surround sound system
developed by Dolby Laboratories containing up
to six channels of digital audio (front left and
right, surround left and right, center and
subwoofer).
DTS: Digital Theater Systems. This is a
surround sound system, but it is different from
Dolby Digital. The formats were developed by
different companies.
HDMI: HDMI is a direct digital connection
that can carry digital HD video as well as digital
multi-channel audio. By eliminating the
conversion to analog signals, it delivers perfect
picture and sound quality, completely free from
noise. HDMI is fully backward-compatible with
DVI.
JPEG: A very common digital still picture
format. A still-picture data compression system
proposed by the Joint Photographic Expert
Group, which features small decrease in image
quality in spite of its high compression ratio.
MP3: A file format with a sound data
compression system. “MP3” is the abbreviation
of Motion Picture Experts Group 1 (or MPEG-
1) Audio Layer 3. By using the MP3 format. One
CD-R or CD-RW can contain about 10 times
more data then a regular CD.
Multichannel: DVDs are formatted to have
each sound track constitute one sound field.
Multichannel refers to a structure of sound
tracks having three or more channels.
Parental level: Limits Disc play according to
the age of the users or the limitation level in
each country. The limitation varies from disc to
disc; when it is activated, playback will be
prohibited if the software’s level is higher than
the user-set level.
PCM (Pulse Code Modulation): A system
for converting analog sound to digital sound for
later processing, with no data compression
used in conversion.
Playback control (PBC): Refers to the
signal recorded on video CDs or SVCDs for
controlling playback. By using menu screens
recorded on a Video CD or SVCD that
supports PBC, you can enjoy interactive
playback and searching.
Progressive Scan: It displays all the
horizontal lines of a picture at one time, as a
single frame. This system can convert the
interlaced video from DVD into progressive
format when the DVD Player is connected to a
Progressive Scan TV. It dramatically increases
the vertical resolution and provides the best
picture.
Region code: A system allowing discs to be
played only in the region designated. This unit
will only play discs that have compatible region
codes. You can find the region code of your
unit by looking on the product label. Some
discs are compatible with more than one
region (or ALL regions).
S-Video: Produces a clear picture by sending
separate signals for the luminance and the
color. You can use S-Video only if your TV has
an S-Video In jack.
Title: The longest section of a movie or music
feature on DVD. Each title is assigned a title
number, enabling you to locate the title you
want.
VIDEO OUT jack: Yellow jack on the back
of the DVD Player that sends the DVD picture
video to a TV.
Glossary
01-41 DVP900_00A31 13/01/2005, 09:5841
