WV 5 Premium *AU
The WV 5 Premium will leave windows gleaming with streak & drip free cleaning.
1 2 3 4
1
2
3
4
Removable battery
Thanks to the removable and optional replacement battery, all win-
dows can be cleaned without interruption.
Exchangeable suction nozzle
Choose between a large or small suction nozzle, based on the size of
the cleaning surface.
Convenient edge cleaning
The manually adjustable distance holders enable perfect streak-free
cleaning results right up to the edges.
Comfortable handle with battery level indicator
The soft grip handle makes the device even more comfortable to use.
3 LEDs indicate the current battery charging status.
WV 5 Premium *AU, 1.633-454.0, 2019-08-29
WV 5 Premium *AU, 1.633-454.0, 2019-08-29
TECHNICAL DATA AND EQUIPMENT
WV 5 Premium *AU
Removable battery
Soft grip handle
Technical data
Order No. 1.633-454.0
EAN code
4054278253442
Working width of suction nozzle mm
280
Waste water container capacity ml
100
Battery running time min.
35
Battery charge time min.
185
Cleaning performance per battery
charge
Approx. 105 m² = 35 windows
Type of current V / Hz
100–240 / 50–60
Weight incl. battery kg
0,7
Dimensions (L x W x H) mm
125 × 280 × 325
Equipment
Window cleaner concentrate (1 × 20 ml)
Removable lithium-ion battery
Battery charger
Exchangeable suction nozzle
Included in delivery.
WV 5 PREMIUM *AU
1.633-454.0
1 2 3 4 5 6 7
8 9 10 11 12
WV 5 Premium *AU, 1.633-454.0, 2019-08-29
Order No. Quantity Price Description
Power supplies
WV replacement charger
1
2.633-136.0 1 piece(s)
Nozzles
Suction nozzle, 170 mm
2
2.633-112.0 1 piece(s)
Base stations
WV5 Charging station and replace
-
able battery
3
2.633-116.0 1 piece(s)
4
2.633-125.0 1 piece(s)
Suction lips
Pull-off lip, wide
5
2.633-005.0 2 piece(s) To replace pull off lips of Window Vacuums. For a streak-
free nish on all even surfaces - without any dripping.
Pull-off lip, narrow
6
2.633-104.0 2 piece(s)
Extensions
WV Extension Pole
7
2.633-111.0 1 piece(s) The Kärcher Window Vac extension pole is compatible with
any Window Vac model, allowing you to clean high windows
and hard to reach areas.
WV Evolution Extension Set
8
2.633-144.0 1 piece(s)
Spray bottle
Spray bottle premium accessories
9
2.633-129.0 1 piece(s)
Replacement cloths
Pad inside accessories
10
2.633-130.0 2 piece(s)
Pad external accessories
11
2.633-131.0 2 piece(s)
Replacement batteries
Replaceable accumulator for WV 5
12
2.633-123.0 1 piece(s)
Included in delivery.
Available accessories.
