Sony DSC-H55 Cybershot Digital Still Camera User Manual

Cyber-shot Handbook

DSC-H55

Table of

contents

Operation

MENU/Settings

Index

Table of

contents

Operation

MENU/Settings

Index

How to use this handbook

Click on a button at upper right to jump to the corresponding page.

This is convenient when searching for a function you want to view.

Search for information by function.

Search for information by operation.

Search for information in a listing of

MENU/Settings items.

Search for information by keyword.

Marks and notations used in this handbook

Table of

contents

Operation

MENU/Settings

Index

In this handbook, the sequence of

operations is shown by arrows (t).

Operate the camera in the order indicated.

Marks are shown as they appear in the

camera’s default setting.

The default setting is indicated by .

Indicates cautions and limitations relevant

to the correct operation of the camera.

z Indicates information that is useful to

know.

Table of

contents

Operation

MENU/Settings

Index

Notes on using the camera

Notes on the types of memory card

that you can use (sold separately)

The following memory cards are compatible

with this camera: “Memory Stick PRO Duo”

media, “Memory Stick PRO-HG Duo”

media, “Memory Stick Duo” media, SD

memory cards, SDHC memory cards and

SDXC memory cards. MultiMediaCard is not

compatible.

In this handbook, “Memory Stick PRO Duo”

media, “Memory Stick PRO-HG Duo” media

and “Memory Stick Duo” media are called

“Memory Stick Duo” media and SD memory

cards, SDHC memory cards and SDXC

memory cards are called SD memory cards.

• “Memory Stick Duo” media of up to 32 GB and

SD memory cards of up to 64 GB have been

tested and proven to operate with your camera.

When recording movies, it is recommended

that you use the following memory cards:

– (Mark2) (“Memory

Stick PRO Duo” (Mark2) media)

– (“Memory Stick PRO-

HG Duo” media)

– SD memory card, SDHC memory card or

SDXC memory card (Class 4 or faster)

• For details on “Memory Stick Duo” media, see

page 125.

When using a “Memory Stick Duo”

media with standard sized “Memory

Stick” media slot

You can use the “Memory Stick Duo” media

by inserting it into the “Memory Stick Duo”

media Adaptor (sold separately).

Notes on the battery pack

• Charge the battery pack (supplied) before using

the camera for the first time.

• You can charge the battery pack even if it is not

completely discharged. In addition, even if the

battery pack is not fully charged, you can use the

partially charged capacity of the battery pack as

is.

• If you do not intend to use the battery pack for a

long time, use up the existing charge and

remove it from the camera, then store it in a

cool, dry place. This is to maintain the battery

pack functions.

• For details on the usable battery pack, see

page 127.

Notes on the LCD screen and lens

• The LCD screen is manufactured using

extremely high-precision technology so over

99.99% of the pixels are operational for

effective use. However, some tiny black and/or

bright dots (white, red, blue or green) may

appear on the LCD screen. These dots are a

normal result of the manufacturing process and

do not affect the recording.

• Exposing the LCD screen or the lens to direct

sunlight for long periods may cause

malfunctions. Be careful when placing the

camera near a window or outdoors.

• Do not press against the LCD screen. The screen

may be discolored and that may cause a

malfunction.

• Images may trail across on the LCD screen in a

cold location. This is not a malfunction.

• Be careful not to bump the movable lens, and be

careful not to apply force to it.

“Memory Stick

Duo” media

Adaptor

Black, white, red, blue or

green dots

Continued r

Table of

contents

Operation

MENU/Settings

Index

On moisture condensation

• If the camera is brought directly from a cold to a

warm location, moisture may condense inside or

outside the camera. This moisture condensation

may cause a malfunction of the camera.

• If moisture condensation occurs, turn off the

camera and wait about an hour for the moisture

to evaporate. Note that if you attempt to shoot

with moisture remaining inside the lens, you

will be unable to record clear images.

The images used in this Handbook

The images used as examples in this Handbook are

reproduced images, and are not actual images shot

using this camera.

Table of

contents

Operation

MENU/Settings

Index

Table of contents

Notes on using the camera

How to use this handbook····································· 2

Notes on using the camera ··································· 3

Operation Search ·················································· 8

MENU/Settings Search ······································· 10

Identifying parts··················································· 14

List of icons displayed on the screen ·················· 15

Using the mode dial ············································ 17

Using the internal memory ·································· 18

Shooting

Intelligent Auto Adjustment ································· 19

Easy Shooting ····················································· 20

Program Auto ······················································ 22

Manual Exposure Shooting ································· 23

Sweep Panorama················································ 24

Scene Selection ·················································· 26

Movie Mode························································· 28

Zoom ··································································· 29

DISP (Screen Display Settings) ····························30

Flash ··································································· 32

Smile Shutter······················································· 33

Self-Timer···························································· 34

Table of

contents

Operation

MENU/Settings

Index

Viewing

Viewing still images············································· 35

Playback zoom···················································· 36

Image Index ························································ 37

Delete·································································· 38

Viewing movies ··················································· 39

MENU (Shooting)

MENU items (Shooting) ······································ 10

(Viewing)

MENU items (Viewing) ········································ 11

Settings

Setting items ······················································· 12

Viewing an image on a TV ································ 100

Computer

Using with your computer·································· 103

Using the software ············································ 104

Connecting the camera to the computer···············106

Uploading images to a media service ···················108

Table of

contents

Operation

MENU/Settings

Index

Printing

Printing still images ··········································· 110

Troubleshooting

Troubleshooting ················································ 112

Warning indicators and messages ···················· 120

Others

“Memory Stick Duo” media································ 125

Battery pack ······················································ 127

Battery charger·················································· 128

Index

Index ································································· 129

Table of

contents

Operation

MENU/Settings

Index

Operation Search

Leaving the settings to

the camera

Intelligent Auto Adjustment······························· 19

Scene Selection ··················································· 26

Scene Recognition·············································· 55

Shooting portraits

Soft Snap ······························································· 26

Twilight Portrait ···················································· 26

Smile Shutter ························································ 33

Scene Recognition·············································· 55

Face Detection····················································· 58

Anti Blink ································································ 61

Red Eye Reduction ············································· 78

Shooting in manual

mode

Manual Exposure Shooting ······························ 23

Shooting panoramic

images

Sweep Panorama················································ 24

Shooting best shots of

your pet

Pet············································································ 26

Shooting moving

objects

Movie Mode··························································· 28

Advanced Sports Shooting······························· 26

Burst Settings ······················································· 45

Shooting without blur

High Sensitivity····················································· 26

2-second delay self-timer·································· 34

ISO··········································································· 48

SteadyShot···························································· 62

Shooting with backlight

Forced Flash························································· 32

Scene Recognition·············································· 55

DRO········································································· 60

Table of

contents

Operation

MENU/Settings

Index

Shooting in dark places

High Sensitivity····················································· 26

Slow Synchro························································ 32

ISO··········································································· 48

Adjusting exposure

EV ············································································ 47

Changing focus

position

Focus ······································································ 52

Face Detection····················································· 58

Changing image size

Image Size····························································· 41

Deleting images

Delete································································ 38, 68

Format ···································································· 92

Displaying enlarged

images

Playback zoom····················································· 36

Trimming (Resize)··············································· 67

Editing images

Retouch ·································································· 67

Playing back a series of

images in order

Slideshow ······························································ 63

Shooting/Viewing with

easy-to-see indicators

Easy Shooting ······················································ 20

Printing images with

the date

Using the “PMB (Picture Motion Browser)”

················································································ 104

Changing date and

time settings

Area Setting ·························································· 98

Date & Time Setting············································ 99

Initializing settings

Initialize··································································· 84

Printing images

Print ······································································· 110

Viewing on TVs

Viewing an image on a TV······························ 100

Table of

contents

Operation

MENU/Settings

Index

MENU/Settings Search

You can select the various shooting functions easily from the MENU button.

1 Press the ON/OFF (Power) button and set the

camera to shooting mode.

2 Press the MENU button to display the Menu

screen.

3 Select the desired menu item with v/V/b/B on

the control button.

4 Press the MENU button to turn off the Menu

screen.

In the table below, indicates settings that can be changed, while — indicates settings that

cannot be changed. A setting may be fixed or restricted depending on the shooting mode. For

details, see the page for each item. The icons below indicate the available modes.

• Only the items that are available for each mode are displayed on the screen.

MENU items (Shooting)

Mode dial

Menu items

Scene Selection

————— —

Shooting Direction

———— — —

Image Size

Flash

——————

Burst Settings

—— —

Bracket Settings

—— — —

——

ISO

—— — —

White Balance

——

Focus

—— — —

Metering Mode

—— —

Scene Recognition

———— — —

Smile Detection Sensitivity

—— —

Face Detection

—— —

DRO

—— — — —

Anti Blink

————— —

SteadyShot

————— —

(Settings)

—

Note

Control button

ON/OFF (Power)

button

MENU button

Table of

contents

Operation

MENU/Settings

Index

You can select the various viewing functions easily from the MENU button.

1 Press the (Playback) button to switch to

playback mode.

2 Press the MENU button to display the Menu

screen.

3 Select the desired menu item with v/V/b/B on

the control button.

4 Press z on the center of the control button.

In the table below, indicates settings that can be changed, while

— indicates settings that cannot be changed.

• Only the items that are available for each mode are displayed on the screen.

MENU items (Viewing)

View Mode

Menu items

Memory card

Internal

Memory

Date View Folder view

(Still)

Folder view

(Movie)

Folder View

(Slideshow)

(View Mode)

—

(Retouch) —

(Delete)

(Protect)

DPOF

——

(Print) —

(Rotate) —

(Select Folder) ——

(Settings)

Note

Control button

MENU button

(Playback)

button

Table of

contents

Operation

MENU/Settings

Index

You can change the settings on the (Settings) screen.

1 Press the MENU button to display the Menu

screen.

2 Select (Settings) with V on the control button,

then press z on the center of the control button to

display the setup screen.

3 Select each item with v/V/b/B, then press z.

4 Select the desired setting, then press z.

Setting items

Categories Items

Shooting Settings

AF Illuminator

Grid Line

Disp. Resolution

Digital Zoom

Auto Orientation

Red Eye Reduction

Blink Alert

Main Settings

Beep

Language Setting

Function Guide

Demo Mode

Initialize

COMPONENT

Video Out

USB Connect

LUN Settings

Download Music

Format Music

Power Save

Memory Card Tool

Format

Create REC.Folder

Change REC.Folder

Delete REC.Folder

Copy

File Number

Internal Memory Tool

Format

File Number

Control button

MENU button

Continued r

Table of

contents

Operation

MENU/Settings

Index

• [Shooting Settings] appears only when settings have been entered from shooting mode.

• [Memory Card Tool] appears only when a memory card is inserted in the camera, while [Internal

Memory Tool] appears only when a memory card is not inserted.

Clock Settings

Area Setting

Date & Time Setting

Notes

Categories Items

Table of

contents

Operation

MENU/Settings

Index

Identifying parts

A Shutter button

B Mode dial (17)

C For shooting: W/T (zoom) lever (29)

For viewing: (Playback zoom) lever/

(Index) lever (36, 37)

D Flash

E ON/OFF (Power) button

F Microphone

G Self-timer lamp/Smile Shutter lamp/AF

illuminator

H Lens

I LCD screen

J Hook for wrist strap*

K (Playback) button (35)

L (Delete) button (38)

M MENU button (10)

N Control button

Menu on: v/V/b/B/z

Menu off: DISP/ / /

O Tripod receptacle

P Speaker

Q Multi connector

R Battery/Memory card cover

S Access lamp

T Battery insertion slot

U Battery eject lever

V Memory card slot

* Using the wrist strap

The wrist strap is already attached to the camera at

the factory. Place your hand through the loop to

prevent the camera from damage by being

dropped.

Hook

Table of

contents

Operation

MENU/Settings

Index

List of icons displayed on the

screen

Icons are displayed on the screen to indicate the camera status.

You can change the screen display using DISP (Screen Display Settings) on the control button.

When shooting still images

• The icons are limited in Easy Shooting mode.

When shooting movies

When playing back

Display Indication

Battery remaining

Low battery warning

Image Size

Scene Selection

Mode dial (Intelligent Auto

Adjustment/Movie Mode/Sweep

Panorama/Manual Exposure

Shooting/Program Auto)

Scene Recognition icon

White Balance

Metering Mode

Vibration warning

Scene Recognition

Burst Settings

Bracket Shooting

Bracket Settings

DRO

Smile Detection Sensitivity

indicator

Continued r

Table of

contents

Operation

MENU/Settings

Index

Zoom scaling

PictBridge connecting

Protect

Print order (DPOF)

Playback zoom

View Mode

Display Indication

AE/AF lock

ISO400

ISO number

NR slow shutter

125

Shutter speed

F3.5

Aperture value

+2.0EV

Exposure value

Focus

REC

Standby

Recording a movie/Standby a

movie

0:12

Recording time (m:s)

101-0012

Folder-file number

2010 1 1

9:30 AM

Recorded date/time of the

playback image

Display Indication

Recording folder

Playback folder

Number of recordable images

12/12

Image number/Number of

images recorded in date range,

selected folder

100Min

Recordable time

Recording/Playback Media

(Memory card, internal memory)

Changing folder

AF Illuminator

Red-eye reduction

Metering Mode

Flash mode

Flash charging

Display Indication

White Balance

ISO 400

ISO number

Database file full/Database file

error

Display Indication

Self-timer

C:32:00

Self-diagnosis display

Destination

Overheating warning

Face Detection

Database file full/Database file

error

AF range finder frame

Spot metering cross hair

+2.0EV

Exposure value

500

Shutter speed

F3.5

Aperture value

Playback

Playback bar

00:00:12

Counter

Direction

GPS information

35° 37’ 32” N

139° 44’ 31” E

Latitude and Longitude display

Histogram

• appears when histogram

display is disabled.

Volume

Display Indication

Table of

contents

Operation

MENU/Settings

Index

Using the mode dial

Set the mode dial to the desired function.

(Movie Mode)

Allows you to record movies (page 28).

(Sweep Panorama)

Allows you to shoot a panoramic image after composing images

(page 24).

(Manual Exposure

Shooting)

Allows you to shoot after adjusting the exposure manually (both the

shutter speed and the aperture (F value)) (page 23).

(Program Auto)

Allows you to shoot with the exposure adjusted automatically (both

the shutter speed and the aperture (F value)) (page 22). You can set

various functions using the menu.

(Intelligent Auto

Adjustment)

Allows you to shoot with the settings adjusted automatically

(page 19).

(Easy Shooting)

Allows you to shoot/view still images with easy-to-see indicators

(page 20).

(Scene Selection)

Allows you to shoot with preset settings according to the scene

(page 26).

Mode dial

Table of

contents

Operation

MENU/Settings

Index

Using the internal memory

The camera has approximately 45 MB of internal memory. This memory is not removable.

You can record images on the internal memory when there is no memory card inserted in the

camera.

We recommend that you copy (back up) data without error using one of the following methods.

To copy (back up) data on a hard disk of your computer

Perform the procedure on pages 106 without a memory card inserted in the camera.

To copy (back up) data on a memory card

Prepare a memory card with sufficient free capacity, then perform the procedure explained in

[Copy] (page 96).

• You cannot transfer image data on a memory card to the internal memory.

• By making a USB connection between the camera and a computer with a cable for multi-use terminal,

you can transfer data stored in the internal memory to a computer. However you cannot transfer data on a

computer to the internal memory.

When a memory card is inserted

[Recording]: Images are recorded on the memory card.

[Playback]: Images on the memory card are played back.

[Menu, Settings, etc.]: Various functions can be

performed on images on the memory card.

When there is no memory card inserted

[Recording]: Images are recorded using the internal

memory.

[Playback]: Images stored in the internal memory are played

back.

[Menu, Settings, etc.]: Various functions can be

performed on images in the internal memory.

On image data stored in the internal memory

Notes

Internal

memory

Table of

contents

Operation

MENU/Settings

Index

Intelligent Auto Adjustment

Allows you to shoot still images with the setting adjusted automatically.

1 Set the mode dial to (Intelligent Auto Adjustment).

2 Shoot with the shutter button.

• Flash mode is set to [Auto] or [Off].

Note

zOn Scene Recognition

Scene Recognition operates in Intelligent Auto Adjustment mode. This function lets the

camera automatically recognize the shooting conditions and shoot the image.

• The camera recognizes (Twilight), (Twilight Portrait), (Twilight using a tripod),

(Backlight), (Backlight Portrait), (Landscape), (Macro) or (Portrait), and displays

the corresponding icon and guide on the LCD screen when the scene is recognized.

For details, see page 55.

Scene Recognition icon and guide

zIf you shoot a still image of a subject that is difficult

to focus on

• The shortest shooting distance is approximately 5 cm (2 inches) (W)/100 cm (3 ft 3 3/8 inches) (T).

• When the camera cannot focus on the subject automatically, the AE/AF lock indicator changes to

slowly flashing and the beep does not sound. Either recompose the shot or change the focus setting

(page 52).

• Focusing may be difficult in the following situations:

– It is dark and the subject is distant.

– The contrast between the subject and the background is poor.

– The subject is seen through glass.

– The subject is moving quickly.

– There is reflective light or shiny surfaces.

– The subject is backlit or there is a flashing light.

Table of

contents

Operation

MENU/Settings

Index

Easy Shooting

Allows you to shoot still images using the minimum necessary functions.

The text size increases and indicators become easier to see.

1 Set the mode dial to (Easy Shooting).

2 Shoot with the shutter button.

• The battery charge is used up more quickly because the screen brightness increases automatically.

Note

zFunctions available in Easy Shooting mode

Image Size: MENU t [Image Size] t z on the control button t desired

mode t z

Select between [Large] or [Small] size.

Self-Timer: on the control button t desired mode

Select between [10sec] or [Off] mode.

Flash: on the control button t desired mode

Select between [Auto] or [Off] mode.

MENU t [Flash] t z on the control button t desired mode

t z

Select between [Auto] or [Off] mode.

Smile Shutter: on the control button

zOn Scene Recognition

Scene Recognition operates in Easy Shooting mode. This function lets the camera

automatically recognize the shooting conditions and shoot the image.

• The camera recognizes (Twilight), (Twilight Portrait), (Twilight using a tripod),

(Backlight), (Backlight Portrait), (Landscape), (Macro) or (Portrait), and displays

an icon on the LCD screen when the scene is recognized.

For details, see page 55.

Scene Recognition icon

Continued r

Table of

contents

Operation

MENU/Settings

Index

zOn Easy Viewing mode

When you press the (Playback) button with the mode dial set to (Easy Shooting),

the playback screen text becomes larger and easier to see. In addition, only the deletion

function becomes available.

• [View Mode] is set to [Date View] when using a memory card.

(Delete) button You can delete the currently displayed image.

Select [OK] t z on the control button.

MENU button You can delete the currently displayed image with [Delete Single

Image] and delete all images in the selected date range or internal

memory (if selected) with [Delete All Images].

Table of

contents

Operation

MENU/Settings

Index

Program Auto

Allows you to shoot with the exposure adjusted automatically (both the shutter speed and the

aperture value). Also you can select various settings using the menu.

1 Set the mode dial to (Program Auto).

2 Shoot with the shutter button.

Table of

contents

Operation

MENU/Settings

Index

Manual Exposure Shooting

You can shoot at your favorite exposure by manually setting the shutter speed and aperture

value.

1 Set the mode dial to (Manual Exposure Shooting).

2 Press z on the control button.

3 Select the shutter speed and aperture (F value) using control button.

• Select a shutter speed from 1/1600 to 30 seconds.

• When zoom is set fully to W, you can select an aperture of F3.5 or F8 (when used with the Internal

ND (Neutral Density) Filter).

When zoom is set fully to T, you can select an aperture of F5.5 or F13 (when used with the Internal

ND (Neutral Density) Filter).

4 Press the shutter button to shoot the image.

• If proper exposure is not obtained by your settings, the setting value indicators on the screen will flash

when the shutter button is pressed halfway down. You can shoot in this condition, but exposure

readjustment is recommended.

• The flash is set to [On] or [Off].

• You cannot select the shutter speed and aperture (F value) when the self-timer is set to [Self-portrait One

Person] or [Self-portrait Two People].

Control button Feature

z Return

v V Shutter speed

b B Aperture (F value)

Notes

zSetting the shutter speed and aperture (F value)

The difference between the settings and proper exposure judged by the camera appears as an

EV value on screen.

• When the shutter speed is one second or slower, the shutter speed is indicated by [”], for example,

[1”].

• When you set the shutter speed slower, using a tripod is recommended to prevent the effects of

vibration.

• When the shutter speed becomes slower than a certain speed, the NR slow shutter function is

activated automatically to reduce image noise, and [NR] appears on the screen.

• If you select slow shutter speeds, it takes time to process the data.

Shutter speed/aperture (F value)

Exposure value

0EV is the value judged as the most suitable by the camera.

Table of

contents

Operation

MENU/Settings

Index

Sweep Panorama

Allows you to create a panoramic image from composed images.

1 Set the mode dial to (Sweep Panorama).

2 Point the camera at the edge of the subject, then

press the shutter button fully down.

3 Pan the camera to the end, following the

guidance on the LCD screen.

• If you cannot pan the camera across the entire subject within the given time, a gray area occurs in the

composed image. If this happens, move the camera fast to record a full panoramic image.

• Since several images are stitched together, the stitched part will not be recorded smoothly.

• Under low light conditions, panoramic images may be blurred.

• Under lights that flicker such as fluorescent light, the brightness or color of the combined image is not

always the same.

• When the whole angle of panoramic shooting and the angle in which you fixed the focus and exposure

with AE/AF lock are extremely different in brightness, color and focus, the shooting will not be

successful. If this happens, change the lock angle and shoot again.

• Sweep Panorama is not suitable for the following situations:

– Objects are moving

– Objects are too close to the camera

– Image with a repeating pattern such as tiles and image with little contrast such as sky, sandy beach, or

lawn

– Image with constant change such as waves or water falls

– Image with the sun or electric lights, etc. that are much brighter than surroundings

• You cannot create panoramic images in the following situations:

– You pan the camera too fast or too slow

– There is too much camera shake

Notes

This part will not be taken

Guidance

bar

Continued r

Table of

contents

Operation

MENU/Settings

Index

zChanging the shooting direction or image size of a

panoramic image

Shooting Direction: MENU t [Shooting Direction] t select [Right], [Left], [Up]

and [Down] t z on the control button

Image Size: MENU t [Image Size] t select [Standard] or [Wide] t z

zTips for shooting a panoramic image

Pan the camera in an arc with a constant velocity and in the same direction as the indication

on the LCD screen. Sweep Panorama is better suited for still subjects, rather than moving

ones.

• Determine the scene and press the shutter button halfway, so that you can lock the focus exposure

and white balance.

• Adjust the frame composition so that a portion with greatly varied scenery is in the center of the

image.

Vertical direction Horizontal direction

Radius as short

as possible

zPlaying back scrolling panoramic images

You can scroll panoramic images by pressing z on the control button while panoramic

images are being displayed. Turn the W (zoom) lever to display the whole image again.

• Panoramic images are played back with the supplied software “PMB” (page 104).

• Panoramic images shot with other cameras may not be scrolled correctly.

Operation button/

lever

Description

z Plays back scrolling images/Stops

b/B/v/V Scrolls images

W Displays the whole image

Shows the displayed area of

the whole panoramic image

Table of

contents

Operation

MENU/Settings

Index

Scene Selection

Allows you to shoot with preset settings according to the scene.

1 Set the mode dial to (Scene Selection).

2 Select the desired mode t z on the control button.

If you want to switch to another scene, press the MENU button.

(High Sensitivity)

Allows you to shoot images without a

flash under low light conditions,

reducing blur.

(Soft Snap)

Allows you to shoot images with a softer atmosphere for

portraits and flowers, etc.

(Advanced

Sports Shooting)

Allows you to shoot subjects with fast movements such

as sports. While the shutter is pressed halfway, the

movement of the subject is predicted and the focus will

be adjusted.

(Landscape)

Allows easy shooting of distant scenes by focusing in

the distance. Shoots vivid blue sky and flora colors.

(Twilight Portrait)

Allows you to shoot sharp images of people with the

night view in the background without compromising the

atmosphere.

(Twilight)

Allows you to shoot night scenes at far distance without

losing the dark atmosphere of the surroundings.

(Gourmet)

Shifts to Macro mode, allowing you to shoot food

arrangements in delicious and bright color.

(Pet)

Allows you to shoot images of your pet with the best

settings.

(Beach)

Allows you to record the blue of the water clearly when

shooting seaside or lakeside scenes.

(Snow)

Allows you to record clear images preventing sunken

colors in snowy scenes or other places where the whole

screen appears white.

Continued r

Table of

contents

Operation

MENU/Settings

Index

• When you shoot images using (Twilight Portrait), (Twilight) or (Fireworks) mode, the shutter

speed is slower and the images tend to blur. To prevent blurring, the use of a tripod is recommended.

For shooting an image appropriately according to the scene condition, a combination of

functions is determined by the camera. indicates an available function, — indicates an

unavailable function. The icons below [Flash] and [Self-Timer] indicate the available modes.

Some functions are not available, depending on the Scene Selection mode.

[Flash] for [White Balance] cannot be selected.

[Off] for [Face Detection] cannot be selected.

[White Balance] for [Bracket Settings] cannot be selected.

(Fireworks)

Allows you to record fireworks in all their splendor.

Note

Functions you can use in Scene Selection

Flash

Face Detection/

Smile Shutter

Self-Timer

Burst Settings/

Bracket

Settings

ISO

White

Balance

Anti Blink

——*

—

——

—— *

——

— *

—— —

————

— ————

— —— —

—— —

— ————

Table of

contents

Operation

MENU/Settings

Index

Movie Mode

Allows you to record movies.

1 Set the mode dial to (Movie Mode).

2 Press the shutter button fully down.

3 To stop recording, press the shutter button fully down again.

Table of

contents

Operation

MENU/Settings

Index

Zoom

You can enlarge the image when shooting. The camera’s optical zoom function can enlarge

images up to 10×.

1 Turn the W/T (zoom) lever.

Turn the W/T (zoom) lever to (T) to zoom in, and to (W) to

zoom out.

• Turn the W/T (zoom) lever lightly for a slower zoom. Move it

further for a faster zoom.

• When the zoom scale exceeds 10×, see page 76.

• Zoom is fixed to the W side when shooting in Sweep Panorama mode.

• The operating sound of the lens is recorded when the zoom function operates while shooting a movie.

Notes

T side

W side

Table of

contents

Operation

MENU/Settings

Index

DISP (Screen Display Settings)

1 Press DISP (Screen Display Settings) on the control button.

2 Select the desired mode with the control button.

• If you view images in bright outside light, adjust the screen brightness up. However, the battery power

may decrease faster under such condition.

(Bright +

Image Only)

Sets screen brighter and displays only images.

(Bright +

Exposure Data)

Sets screen brighter and displays the

information.

Displays a recorded image.

A histogram is also displayed.

(Bright) Sets screen brighter and displays the

information.

(Normal) Sets screen to standard brightness and displays

the information.

Note

Table of

contents

Operation

MENU/Settings

Index

A histogram is a graph showing the brightness of an image. The graph display indicates a bright

image when skewed to the right side, and a dark image when skewed to the left side.

1 Press DISP (Screen Display Settings) on the control button, then select

[Bright + Exposure Data].

• The histogram also appears when playing back a single image, but you cannot adjust the exposure.

• The histogram does not appear when:

– Recording movies

– Playing back movies

– Viewing vertical orientation images

– Rotating still images

– Shooting with Sweep Panorama

– Viewing images shot with Sweep Panorama

• A large difference in the histogram displayed during shooting and playback may occur when:

– The flash strobes.

– The shutter speed is slow or fast.

• The histogram may not appear for images recorded using other cameras.

Histogram

Notes

BrightDark

A Number of pixels

B Brightness

Table of

contents

Operation

MENU/Settings

Index

Flash

1 Press (Flash) on the control button.

2 Select the desired mode with the control button.

• The flash strobes twice. The first flash adjusts the light quantity.

• While charging the flash, is displayed.

• You cannot use the flash during burst or bracket.

• In Intelligent Auto Adjustment mode, Easy Shooting mode, you can select only [Auto] or [Off].

• In Manual Exposure Shooting mode, only [On] or [Off] can be selected.

• In Sweep Panorama, flash is set to [Off].

(Auto) Flash automatically operates in dark locations or when there is

backlight.

(On) Flash always operates.

(Slow

Synchro)

Flash always operates.

The shutter speed is slow in a dark place to clearly shoot the

background that is out of flash light.

(Off) Flash does not operate.

Notes

zWhen the “White circular spots” appears in flash

photos

This is caused by particles (dust, pollen, etc.) floating close to the lens. When they are

accentuated by the camera’s flash, they appear as white circular spots.

How can the “White circular spots” be reduced?

• Light the room and shoot the subject without a flash.

• Select (High Sensitivity) mode in Scene Selection. ([Off] is automatically selected.)

Camera

Subject

Particles (dust, pollen, etc.)

in the air

Table of

contents

Operation

MENU/Settings

Index

Smile Shutter

When the camera detects a smile, the shutter is released automatically.

1 Press (Smile) on the control button.

2 Wait for a smile to be detected.

When the smile level exceeds the b point on the indicator, the

camera records images automatically.

If you press the shutter button during Smile Shutter, the camera

shoots the image, then returns to Smile Shutter mode.

3 To stop shooting, press (Smile) again.

• Shooting using the Smile Shutter ends automatically when either the memory card or internal memory

becomes full.

• Smiles may not be detected correctly depending on the conditions.

• You cannot use the digital zoom function.

• If Sweep Panorama or Movie Mode is selected, you cannot use the Smile Shutter function.

Notes

Smile Detection Sensitivity

indicator

Face Detection frame

zHints for better capturing of smiles

• The shutter operates when any person whose face is being detected smiles.

• You can select the priority subject for face detection with [Face Detection]. To perform smile

detection for a different face, change the priority face with z on the control button (page 58).

• If a smile is not detected, set the [Smile Detection Sensitivity] in setting menu.

1 Do not cover the eyes with the bangs.

Do not obscure the face by hat, masks, sunglasses, etc.

2 Try to orient the face in front of the camera and be as

level as possible. Keep the eyes narrowed.

3 Give a clear smile with an open mouth. The smile is

easier to detect when the teeth are shown.

Table of

contents

Operation

MENU/Settings

Index

Self-Timer

1 Press (Self-Timer) on the control button.

2 Select the desired mode with the control button.

• In Easy Shooting mode, you can select only [10sec] or [Off].

• In Movie Mode, [Self-portrait One Person] or [Self-portrait Two People] cannot be selected.

• The self-timer is not valid when shooting in Sweep Panorama mode.

(Off) Does not use the self-timer.

(10sec) Sets the 10-second delay self-timer.

When you press the shutter button, the self-timer lamp flashes and a

beep sounds until the shutter operates.

To cancel, press again.

(2sec) Sets the 2-second delay self-timer.

(Self-portrait

One Person)

Set the self-timer to Self-portrait timer.

When the camera detects the specified number of faces, a beep

sounds, and the shutter operates 2 seconds later. Do not move the

camera during this while.

(Self-portrait

Two People)

Notes

zAutomatic shooting with Self- portrait timer

Point the lens at yourself so your face is reflected in the LCD screen. The camera detects the

subjects, and then the shutter operates. The camera determines the optimal composition and

prevents faces from being cut out of the LCD screen.

• You can also shoot an image by pressing the shutter button during this

operation.

zHints for preventing blur

If your hands or body moves while holding the camera and pressing the shutter button,

“Camera shake” occurs. Camera shake occurs frequently under low-light or slow shutter

speed conditions, such as those encountered in (Twilight Portrait) or (Twilight) mode.

In such a case, shoot with the below tips in mind.

• Shoot with a 2-second delay self-timer and stabilize

the camera by holding your arms firmly at your side

after pressing the shutter button.

• Use a tripod or place the camera on a flat surface to

hold the camera steady.

Table of

contents

Operation

MENU/Settings

Index

Viewing still images

1 Press the (Playback) button to switch to playback mode.

2 Select an image with the control button.

zViewing images taken with a different camera

This camera creates a database file in a memory card and registers every shot image to it for

later playback. If the camera detects images that have not been registered to the database file

in the memory card, the registration screen “Files found which were not recognized Import

files” appears.

If you want to view unregistered images, select [OK] to register the images.

• For registration, use a fully charged battery pack. If you attempt to register unregistered files using a

battery pack with little remaining charge, the battery pack may run out, causing copying to fail or

possibly corrupting the data.

Table of

contents

Operation

MENU/Settings

Index

Playback zoom

Plays back the enlarged image.

1 Turn the (Playback zoom) lever to (T) during still

image playback.

The image is enlarged to twice the previous size, at the center of the

image.

2 Adjust the position with the control button.

3 Change the zoom scale with the (Playback zoom)

lever.

Turn the lever to (T) to zoom in, to (W) to zoom out.

Press z to cancel playback zoom.

Shows the displayed

area of the whole


zTo save enlarged images

You can save an enlarged image by using the trimming function.

Press MENU t [Retouch] t [Trimming (Resize)].

Table of

contents

Operation

MENU/Settings

Index

Image Index

Displays multiple images at the same time.

1 Press the (Playback) button to switch to playback mode.

2 Turn the (Index) lever to (W) to display the image index screen.

Turn the lever again to display an index screen with more images. Turn the lever yet again to

view images with the Calendar while playing back in [Date View].

3 To return to the single-image screen, select an image with the control

button, then press z.

• When the mode dial is set to (Easy Shooting), you cannot view images in index mode.

Note

zDisplaying images of the desired date/folder

Select the left side bar with the control button, then select the

desired date/folder with v/V.

zViewing images with the Calendar

When [View Mode] is set to [Date View], turn the (Index) lever to view images with the

Calendar, while the index displays more images.

• To select the month you want to display, select / with the

control button, then the desired month.

• To view images in selected date in index mode, select the date with

the control button and press z.

• To exit the Calendar, select with the control button, then press

Table of

contents

Operation

MENU/Settings

Index

Delete

Allows you to select unwanted images for deletion. You can also delete images from the MENU

button (page 68).

1 Press the (Playback) button to switch to playback mode.

2 (Delete) button t desired mode t z on the control button

• In Easy Viewing mode, you can delete only the currently displayed image.

• When the internal memory is used to record images, View Mode is set to Folder View.

All in Date Range

All in This Folder

Deletes all images in the selected date range or folder at once.

Press [OK] t z after step 2.

Multiple Images Allows you to select and delete multiple images.

Do as the following after step 2.

1Select an image then press z.

Repeat the above step until there are no more images to be

deleted. Select an image with a mark again to release the

mark.

2MENU t [OK] t z

This Image Deletes the currently displayed image in single-image mode.

Exit Cancels the deletion.

Notes

zYou can switch between index and single-image

mode when selecting images

Turn the lever to (T) of the W/T (zoom) lever in index mode

to return to single-image mode, and turn the (Index) lever to

(W) in single-image mode to return to index mode.

• You can also switch between index and single-image mode in

[Protect], [DPOF] or [Print].

Table of

contents

Operation

MENU/Settings

Index

Viewing movies

1 Press the (Playback) button to switch to playback mode.

2 Select a movie with the control button.

3 Press z.

Movie playback starts.

• You may not be able to play back some images shot using other cameras.

Control button Playback feature

z Play/Stop

B Fast forward

b Fast rewind

V Displays the volume control screen.

• Adjust the volume with v/V on the control button, then press

Note

zOn the movie viewing screen

Select the image you want to display using b/B on the control button, and press z.

The Playback bar appears, you can check a playback position of a movie.

Playback bar

, or appears on the movie viewing screen.

The icon displayed may vary depending on image size and quality.

Table of

contents

Operation

MENU/Settings

Index

Shooting Direction

Sets the direction to pan the camera when you shoot a Sweep Panorama images.

1 MENU t (Shooting Direction) t desired direction

(Right) Pan from left to right.

(Left) Pan from right to left.

(Up) Pan from down to up.

(Down) Pan from up to down.

Table of

contents

Operation

MENU/Settings

Index

Image Size

The image size determines the size of the image file that is recorded when you take a image.

The larger the image size, the more detail will be reproduced when the image is printed on large-

format paper. The smaller the image size, the more images can be recorded.

1 MENU t (Image Size) t desired size

• When you print still images recorded with 16:9 aspect ratio, both edges may be cut off.

When shooting still images

Image size Usage guidelines No. of

images

Printing

(4320×3240) For prints up to A3+ size Less

Fine

Rough

(3648×2736)

(2592×1944) For prints up to L/2L/A4 size

(640×480) For e-mail attachments

(4320×2432) For viewing on a high-definition TV,

and for prints up to A3 size

Less

Fine

Rough

(1920×1080) For viewing on a high-definition TV

Note

Table of

contents

Operation

MENU/Settings

Index

The larger the image size, the higher the image quality. The higher the amount of data used per

second (average bit-rate), the smoother the playback image.

The movies shot with this camera will be recorded in MPEG-4, Approx. 30 fps, Progressive,

AAC, mp4 format.

• A telephoto image results when the [VGA] image size is selected for movies.

In Easy Shooting mode

Large Shoots images in [14M] size.

Small Shoots images in [5M] size.

When shooting Sweep Panorama images

(Standard)

(Vertical: 3424×1920)

(Horizontal: 4912×1080)

Shoots images using standard size.

(Wide)

(Vertical: 4912×1920)

(Horizontal: 7152×1080)

Shoots images using wide size.

When shooting movies

Movie image size Average bit-rate Usage guidelines

1280×720(Fine) 9 Mbps Shoots highest quality movie for display

on HDTV.

1280×720(Standard) 6 Mbps Shoots standard quality movie for

display on HDTV.

VGA 3 Mbps Shoots at an image size suitable for

WEB upload.

Note

Continued r

Table of

contents

Operation

MENU/Settings

Index

zOn “image quality” and “image size”

A digital image is made up of a collection of small dots called pixels.

If it contains a large number of pixels, the image becomes large, it takes up more memory,

and the image is displayed in fine detail. “Image size” is shown by the number of pixels.

Although you cannot see the differences on the screen of the camera, the fine detail and data

processing time differ when the image is printed or displayed on a computer screen.

Description of the pixels and the image size

1 Image size: 14M

4320 pixels × 3240 pixels = 13,996,800 pixels

2 Image size: VGA

640 pixels × 480 pixels = 307,200 pixels

Many pixels

(Fine image quality and large file size)

Few pixels

(Rough image quality but small file size)

Pixels

Pixel

Table of

contents

Operation

MENU/Settings

Index

Flash

In Easy Shooting mode, you can select the Flash setting also from the MENU button.

1 Set the mode dial to (Easy Shooting).

2 MENU t [Flash] t z on the control button

3 Select the desired mode.

Auto Flash automatically operates in dark locations or when there is

backlight.

Off Does not use the flash.

Table of

contents

Operation

MENU/Settings

Index

Burst Settings

You can select single-image mode or burst mode.

1 MENU t (Burst Settings) t desired mode

(Single) Shoots a single image.

(Burst) Shoots up to 100 images in succession when you press and hold

down the shutter button.

• The Burst mode is not available in Easy Shooting mode, Sweep

Panorama, Movie Mode, or smile shutter.

• The flash is set to [Off].

• When recording with the self timer, a series of a maximum of five

images is recorded.

• The recording interval becomes longer, depending on the setting for the

image size.

• When the battery level is low, or when the internal memory or the

memory card is full, the Burst stops.

• [Focus], [White Balance] and [EV] are adjusted for the first image, and

these settings are also used for the other images.

Notes

Table of

contents

Operation

MENU/Settings

Index

Bracket Settings

You can set the type of the bracket shooting. In the bracket shooting mode, you can record a

series of 3 images with the setting changed. You can select the most suitable image afterwards.

1 MENU t (Bracket Settings) t desired mode

• You cannot select [White Balance] when the mode dial is set to (Scene Selection).

• You cannot select [Bracket Settings] in the following cases:

– In Intelligent Auto Adjustment mode

– In Easy Shooting mode

– In Movie Mode

– In Sweep Panorama mode

– When [Burst Settings] is set to [Burst]

– When the Smile Shutter function is activated

(Off) Does not use the bracket shooting.

(EXP±0.3) Records a series of 3 images with the exposure shifted in the

following order: bright, standard, and dark.

The larger the bracket step value, the larger the shift of the

exposure value.

(EXP±0.7)

(EXP±1.0)

(White

Balance)

Records a series of 3 images with the white balance shifted in the

following order: current color tone, toward blue, and toward red.

• When you set [White Balance] to other than [Auto], the color tone is

shifted based on the selected white balance.

Notes

Table of

contents

Operation

MENU/Settings

Index

You can adjust the exposure manually in 1/3 EV steps in a range of –2.0 EV to +2.0 EV.

1 MENU t (EV) t desired EV setting

• In Easy Shooting mode or Manual Exposure Shooting mode, the [EV] setting cannot be adjusted.

• If you shoot a subject in extremely bright or dark conditions, or when you use the flash, the exposure

adjustment may not be effective.

Notes

zAdjusting the exposure for better looking images

Overexposure = too much light

Whitish image

Lower EV setting –

Correct exposure

Higher EV setting +

Underexposure = too little light

Darker image

Table of

contents

Operation

MENU/Settings

Index

ISO

Adjusts the luminous sensitivity when the camera is set to Program Auto, Manual Exposure

Shooting or (Advanced Sports Shooting) in Scene Selection.

1 MENU t (ISO) t desired mode

• You cannot select [ISO AUTO] in Manual Exposure Shooting mode.

• You cannot select ISO settings other than [ISO AUTO], [ISO 80] to [ISO 800] in the following cases:

– When Burst/Bracket mode is selected

– When Scene Selection is set to (Advanced Sports Shooting)

– When [DRO] is set to [DRO plus]

(Auto) Sets the ISO sensitivity automatically.

////

You can reduce image blurring in dark locations or moving subjects

by increasing ISO sensitivity (select a larger number).

Notes

zAdjusting ISO Sensitivity (Recommended Exposure

Index)

ISO sensitivity is a speed rating for recording media that incorporates an image sensor that

receives light. Even when the exposure is the same, images differ depending on the ISO

sensitivity.

High ISO sensitivity

Records a bright image even in dark locations while increasing

shutter speed to reduce blur.

However, the image tends to become noisy.

Low ISO sensitivity

Records a smoother image.

However, when the exposure is insufficient, the image may become

darker.

Continued r

Table of

contents

Operation

MENU/Settings

Index

zHints for preventing blur

Even though the camera is steady, the subject moves during the exposure and is captured

blurred when the shutter button is pressed. Camera shake is reduced automatically,

however, the function does not effectively reduce subject blur.

Subject blur occurs frequently under low-light or slow shutter speed conditions.

In such a case, shoot with the below tips in mind.

• Select a higher ISO sensitivity to make the shutter

speed faster, and press the shutter button before the

subject moves.

• Select (High Sensitivity) mode in Scene

Selection.

Table of

contents

Operation

MENU/Settings

Index

White Balance

Adjusts color tones according to the surrounding light conditions. Use this function if image

color appears unnatural.

1 MENU t (White Balance) t desired mode

• [White Balance] cannot be adjusted in Intelligent Auto Adjustment, or Easy Shooting mode.

• [Flash] in [White Balance] cannot be adjusted in the following situations:

– In Sweep Panorama

– In Movie Mode

– When Scene Selection is set to (High Sensitivity) mode.

• Under fluorescent lights that flicker, the white balance function may not work correctly even though you

select [Fluorescent White Balance 1], [Fluorescent White Balance 2], or [Fluorescent White Balance 3].

• When shooting with a flash in other than [Flash] mode, [White Balance] is set to [Auto].

• When flash is [On] or [Slow Synchro], the white balance can only be adjusted to [Auto], [Flash], [One

Push], or [One Push Set].

• [One Push Set] is unable to be selected while charging the flash.

(Auto) Adjusts the white balance automatically so that the colors appear

natural.

(Daylight) Adjusts for outdoors conditions on a fine day, evening views, night

scenes, neon signs, fireworks, etc.

(Cloudy) Adjusts for a cloudy sky or a shady location.

(Fluorescent

White Balance 1)

(Fluorescent

White Balance 2)

(Fluorescent

White Balance 3)

[Fluorescent White Balance 1]: Adjusts for white fluorescent

lighting.

[Fluorescent White Balance 2]: Adjusts for natural white

fluorescent lighting.

[Fluorescent White Balance 3]: Adjusts for day white fluorescent

lighting.

(Incandescent)

Adjusts for places under incandescent lamp, or under bright

lighting, such as in a photo studio.

(Flash) Adjusts for the flash conditions.

(One Push) Adjusts the white balance depending on the light source. The white

color memorized in [One Push Set] mode becomes the basic white

color. Use this mode when [Auto] or other modes cannot be set the

color properly.

(One Push

Set)

Memorizes the basic white color which will be used in [One Push]

mode.

Notes

Table of

contents

Operation

MENU/Settings

Index

1 Frame a white object such as a piece of paper filling the screen under the

same lighting conditions as you will shoot the subject.

2 MENU t (White Balance) t [One Push Set] t z on the control

button

The screen momentarily turns black, and when the white balance has been adjusted and stored

in the memory, the recording screen is displayed again.

• If the indicator flashes while shooting, the white balance is either not set or cannot be set. Use

automatic white balance.

• Do not shake or strike the camera while [One Push Set] is in progress.

• When flash is set to [On] or [Slow Synchro], the white balance is adjusted to the condition with the flash

emitting.

To capture the basic white color in [One Push

Set] mode

Notes

zEffects of lighting conditions

The apparent color of the subject is affected by the lighting conditions.

The color tones are adjusted automatically, but you can adjust color tones manually using

the White Balance function.

Weather/lighting

Daylight Cloudy Fluorescent Incandescent

Characteristics of

light

White (standard) Bluish Green-tinged Reddish

Table of

contents

Operation

MENU/Settings

Index

Focus

You can change the focus method. Use the menu when it is difficult to get the proper focus in

auto focus mode.

AF stands for “Auto Focus,” a function that adjusts the focus automatically.

1 MENU t (Focus) t desired mode

• When you use [Digital Zoom] or [AF Illuminator], the AF range finder frame is disabled and appears in a

dotted line. In this case, the camera works to focus on the subjects at the center of the screen.

• When the focus mode is set to other than [Multi AF], you cannot use the Face Detection function.

• The focus mode is fixed to [Multi AF] in the following situations:

– In Intelligent Auto Adjustment mode

– In Easy shooting mode

– In Movie Mode

– When the Smile Shutter function is activated

– When the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People]

(Multi AF) Focuses on a subject in all ranges of the

finder frame automatically.

When you press the shutter button halfway

down in still image shooting mode, a green

frame is displayed around the area that is in

focus.

• When the Face Detection function is active, AF

operates with priority on faces.

(Center AF) Focuses on a subject in the center of the

finder frame automatically. Using the AF

lock function together, you can compose the

image the way you want.

(Spot AF) Focuses on an extremely small subject or a

narrow area automatically. Using the AF

lock function together, you can compose the

image the way you want. Hold the camera

steady so as not to misalign the subject and

the AF range finder frame.

Notes

AF range finder frame

Continued r

Table of

contents

Operation

MENU/Settings

Index

zFocusing on subjects near the edge of the screen

If the subject is out of focus, do as follows:

1Recompose the shot so that the subject is centered

in the AF range finder, and press the shutter

button halfway to focus on the subject (AF lock).

2When the AE/AF lock indicator stops flashing and

remains on, return to the fully composed shot, and

press the shutter button fully down.

• As long as you do not press the shutter button fully

down, you can retry the procedure as many times as

necessary.

AF range finder

frame

AE/AF lock

indicator

Table of

contents

Operation

MENU/Settings

Index

Metering Mode

Selects the metering mode that sets which part of the subject to measure to determine the

exposure.

1 MENU t (Metering Mode) t desired mode

• In Movie Mode, [Spot] cannot be selected.

• If you set Metering Mode to other than [Multi], the Face Detection function cannot be used.

• Metering Mode is fixed to [Multi] in the following situations:

– In Intelligent Auto Adjustment

– In Easy Shooting mode

– When the Smile Shutter function is activated

– When the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People]

(Multi) Divides into multiple regions and measures each region. The

camera determines a well-balanced exposure (Multi-pattern

metering).

(Center) Measures the center of the image, and determines the exposure

based on the brightness of the subject there (Center-weighted

metering).

(Spot) Measures only a part of the subject

(Spot metering). This function is useful

when the subject is backlit or when

there is strong contrast between the

subject and the background.

Notes

Spot metering cross

hairs

Positions on the subject

Table of

contents

Operation

MENU/Settings

Index

Scene Recognition

In Intelligent Auto Adjustment mode, the camera automatically detects shooting conditions, and

then takes the shot. When motion is detected, the ISO sensitivity is increased according to the

movement to reduce subject blur (Motion Detection).

1 Set the mode dial to (Intelligent Auto Adjustment).

2 MENU t (Scene Recognition) t desired mode

• Scene Recognition does not function when using digital zoom.

• Scene Recognition is fixed to [Auto] in the following situations:

– During burst shooting

– When the Smile Shutter function is activated

– When the self-timer is set to [Self-portrait One Person] and [Self-portrait Two People]

• The available flash settings are [Auto] and [Off].

• (Twilight using a tripod) scenes sometimes cannot be recognized in an environment where vibrations

are transferred to the camera even though it is fixed on a tripod.

• Sometimes a slow shutter results when a scene is recognized as a (Twilight using a tripod). Keep the

camera still during shooting.

• These scenes may not be recognized depending on the situation.

(Auto) When the camera recognizes the scene, it switches to the optimal

settings and shoots the image.

(Advanced)

When the camera recognizes the scene, it switches to the optimal

settings. If the camera recognizes (Twilight), (Twilight

Portrait), (Twilight using a tripod), (Backlight) or

(Backlight Portrait), it automatically changes the setting and

shoots another image.

• When you shoot two images consecutively, the + mark on the icon

will turn green.

• When two frames are shot, the two images are displayed side by side

immediately after shooting.

• When [Anti Blink] is displayed, 2 images are taken automatically and

the image with eyes are open is selected automatically. For details on the

Anti Blink function, see “What is the Anti Blink function?”.

Notes

Example of an image where

(Backlight) has activated.

Scene Recognition icon and guide

The camera recognizes the following types of scenes.

When the camera determines the optimal scene, it

displays the corresponding icon and guide.

(Twilight), (Twilight Portrait), (Twilight

using a tripod), (Backlight), (Backlight

Portrait), (Landscape), (Macro), (Portrait)

Continued r

Table of

contents

Operation

MENU/Settings

Index

zShooting twice, choosing the best image later - it’s

more convenient! ([Advanced])

In [Advanced], when the camera recognizes a difficult-to-shoot scene ( (Twilight),

(Twilight Portrait), (Twilight using a tripod), (Backlight) and (Backlight

Portrait)), it changes the settings as follows and shoots two images with different effects,

allowing you to select the one you like.

* When flash is set to [Auto].

First Image* Second Image

Shoots in Slow Synchro Shoots with sensitivity increased and shake

reduced

Shoots in Slow Synchro with the face

which the flash strobes on as guide

Shoots with sensitivity increased with the face as

guide and shake reduced

Shoots in Slow Synchro Shoots with even slower shutter speed without

increasing sensitivity

Shoots with the flash Shoots with the brightness and contrast of the

background adjusted (DRO plus)

Shoots with the face which the flash

strobes on as guide

Shoots with the brightness and contrast of the

face and the background adjusted (DRO plus)

zWhat is the Anti Blink function?

When set to [Advanced], the camera automatically shoots two images consecutively* when

it recognizes (Portrait). The camera will select, display, and record the image which the

eyes are not blinked automatically. If the eyes are closed in both images, the message

“Blinked eye detected” is displayed.

* except when the flash strobes/when the shutter speed is slow

Table of

contents

Operation

MENU/Settings

Index

Smile Detection Sensitivity

Sets the sensitivity of the Smile Shutter function for detecting smiles.

1 MENU t (Smile Detection Sensitivity) t desired mode

• Smiles may not be detected correctly depending on the conditions.

• [Smile Detection Sensitivity] cannot be adjusted in the following situations:

– In Easy Shooting mode

– In Sweep Panorama

– In Movie Mode

(Big Smile) Detects a big smile.

(Normal

Smile)

Detects a normal smile.

(Slight Smile) Detects even a slight smile.

Notes

Table of

contents

Operation

MENU/Settings

Index

Face Detection

Detects the faces of your subjects and adjusts the focus, flash, exposure, white balance and red-

eye reduction settings automatically.

1 MENU t (Face Detection) t desired mode

• [Face Detection] cannot be selected in the following situations:

– In Easy Shooting mode

– In Movie Mode

– In Sweep Panorama mode

• You cannot select [Off] when the self-timer is set to [Self-portrait One Person] or [Self-portrait Two

People].

• You can select [Face Detection] only when the focus mode is set to [Multi AF] or the metering mode is

set to [Multi].

• The Face Detection function does not work when using the digital zoom.

• Up to 8 faces of your subjects can be detected.

• Adults and children may not be recognized correctly depending on the conditions.

• During Smile Shutter shooting, [Face Detection] is automatically set to [Auto] even if it is set to [Off].

(Off) Does not use Face Detection function.

(Auto) Selects the face the camera is to automatically focus on.

(Child

Priority)

Detects and shoots with priority on child’s face.

(Adult

Priority)

Detects and shoots with priority on adult’s face.

Notes

Face Detection frame (White)

Face Detection frame (Orange)

When the camera detects more than one subject, the camera will judge which is the main

subject and set focus by priority. The Face Detection frame for the main subject will turn

orange. The frame for which the focus is set will turn green by pressing the shutter button

halfway down.

Continued r

Table of

contents

Operation

MENU/Settings

Index

zSelecting the priority face

Normally the camera automatically selects the face to focus on according to the [Face

Detection] setting, but you can also select a face to be given priority.

1Press z on the control button during Face Detection. The leftmost face is selected as the

priority face, and the frame changes from to an orange frame ( ).

2Each time you press z, the priority face moves one face to the right. Press z repeatedly

until the orange frame ( ) is on the face you want to select.

3To cancel the face selection (Off), move the orange frame to the rightmost face, then

press z again.

• It may not be possible to detect the selected face correctly depending on the surrounding brightness,

the subject’s hairstyle, etc. In this case, select the face again under the conditions where the image

will be shot.

• When the Smile Shutter function is used with the Face Detection frame selected, Smile Detection is

performed only on the selected face.

• You cannot select the priority face in Easy Shooting mode, Manual Exposure Shooting mode or

when the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People].

Face Priority Frame Off

Table of

contents

Operation

MENU/Settings

Index

DRO

In Program Auto or Manual Exposure Shooting mode, the camera analyzes the shooting scene

and automatically corrects the brightness and contrast to improve the image quality.

DRO stands for “Dynamic Range Optimizer,” a function that automatically optimizes the

difference between light and dark parts of an image.

1 MENU t (DRO) t desired mode

• Depending on shooting conditions, it may not be possible to obtain correction effects.

• Only [ISO AUTO] or values from [ISO 80] to [ISO 800] can be set for the ISO value when [DRO plus] is

set.

(Off) Does not adjust.

(DRO

standard)

Adjusts the brightness and contrast of the images automatically.

(DRO plus) Adjusts image brightness and contrast automatically and strongly.

Notes

Table of

contents

Operation

MENU/Settings

Index

Anti Blink

When Scene Selection is set to (Soft Snap) while you are shooting an image, the camera

automatically shoots two images consecutively. The camera will select, display and record the

image which the eyes are not blinked automatically.

1 Set the mode dial to (Scene Selection).

2 Select (Soft Snap).

3 MENU t (Anti Blink) t desired mode

• [Anti Blink] does not function in the following situations:

– When using the flash

– When Burst mode is selected

– When the Face Detection function does not work

– When the Smile Shutter function is activated

• Sometimes the Anti Blink function does not work depending on the situation.

• When the Anti Blink function is set to [Auto] but only images with the subject’s eyes closed are

recorded, the message “Blinked eye detected” is displayed on the LCD screen. Shoot again as necessary.

(Auto)

When Face Detection is active, the Anti Blink function operates so

that images with the subject’s eyes open are recorded.

(Off)

Does not use the Anti Blink function.

Notes

Table of

contents

Operation

MENU/Settings

Index

SteadyShot

In Movie Mode, you can vary the strength of SteadyShot.

1 Set the mode dial to (Movie Mode).

2 MENU t (SteadyShot) t desired mode

(Standard)

Provides the SteadyShot effect under stable recording conditions.

(Active)

Provides a more powerful SteadyShot effect.

Table of

contents

Operation

MENU/Settings

Index

Slideshow

Images are automatically played back in succession.

1 Press the (Playback) button to switch to playback mode.

2 MENU t (Slideshow) t desired slideshow t z on the control

button

1 Select the desired image for playing with the control button.

2 MENU t (Slideshow) t [Continuous Playback] t z

(Continuous Playback) Plays back all the images in succession.

(Slideshow with music) Plays back images in succession, with added effects and

music.

Continuous Playback

Control button Playback feature

z Stop

v Sets the display settings.

V Displays the volume control screen.

• Adjust the volume with v/V on the control button, then press

b Rewinds image.

B Forwards image.

zViewing panoramic images during continuous

playback

The whole panoramic image is displayed for 3 seconds.

You can scroll a panoramic image by pressing z.

Press z again while scrolling, the screen returns to the whole panoramic image.

Table of

contents

Operation

MENU/Settings

Index

1 MENU t (Slideshow) t [Slideshow with music] t z on the control

button

Displays the setting screen.

2 Select a desired setting.

3 [Start] t z

4 Press z to end the slideshow.

• You cannot play back movies or panoramic images.

• Settings other than [Image] are stored until the next time they are changed.

• This setting is fixed to [Folder] when the internal memory is used to record images.

Slideshow with music

Notes


Selects the group of images to be shown.

All Plays a slideshow of all the images in order.

This Date Plays a slideshow of images with the currently selected date range

when View Mode is [Date View].

Folder Plays a slideshow of images in the currently selected folder when

View Mode is Folder View.

Note

Effects

Selects the playback speed and mood for slideshows.

Simple A simple slideshow switching images at a preset interval.

The playback interval is adjustable in [Interval] and you can

thoroughly enjoy your images.

Nostalgic A moody slideshow reproducing the atmosphere of a movie scene.

Stylish A stylish slideshow proceeding at a middle tempo.

Active A high-tempo slideshow suitable for active scenes.

Continued r

Table of

contents

Operation

MENU/Settings

Index

Music

Specifies the music to be played during slideshows. You can select more than one background

music track. Press V on the control button to display the volume control screen, then press

v/V to adjust the volume.

Music1 The default setting for a [Simple] slideshow.

Music2 The default setting for a [Nostalgic] slideshow.

Music3 The default setting for a [Stylish] slideshow.

Music4 The default setting for a [Active] slideshow.

Mute Does not use BGM.

Interval

Sets the screen switching interval. The setting is fixed to [Auto] when [Simple] is not selected

as the [Effects].

1 sec Sets the display interval of images for a [Simple] slideshow.

3 sec

5 sec

10 sec

Auto The interval is set to suit the selected [Effects] item.

Repeat

Turns slideshow repeat on or off.

On Plays back images in a continuous loop.

Off After all the images have been played back, the slideshow ends.

zSelecting background music

You can transfer a desired music file from your CDs or MP3 files to the camera to play back

during slideshow. To transfer music, install the “Music Transfer” software (supplied) to

your computer. For details, see pages 104 and 105.

• You can record up to four pieces of music on the camera (The 4 preset pieces (Music1 – Music4)

can be replaced with the ones you transferred).

• The maximum length of each music file for music playback of the camera is about 5 minutes.

• If you cannot play back a music file due to damage or other malfunctions of the file, execute

[Format Music] (page 90) and transfer the music again.

Table of

contents

Operation

MENU/Settings

Index

View Mode

Allows you to select the display format for images.

1 Press the (Playback) button to switch to playback mode.

2 MENU t (View Mode) t desired mode t z on the control button

• When using the internal memory, the view mode is set to Folder View and still images and movies are

played from the same folder.

• Event View is not available on this camera.

1 MENU t (View Mode) t [Date View] t z on the control button

2 Turn the (Index) lever repeatedly until the Calendar is displayed.

Use the control button to select / , then select the month you want to display. Select the

date and press z to view images of the selected date in index mode.

(Date View) Displays images by the date.

(Folder view

(Still))

Displays only still images.

(Folder view

(Movie))

Displays only movie files.

Notes

Displaying the Calendar

zViewing images taken with a different camera

This camera creates a database file in a memory card and registers every shot image to it for

later playback. If the camera detects images that have not been registered to the database file

in the memory card, the registration screen “Files found which were not recognized Import

files” appears.

If you want to view unregistered images, select [OK] to register the images.

• For registration, use a fully charged battery pack. If you attempt to register unregistered files using a

battery pack with little remaining charge, the battery pack may run out, causing copying to fail or

possibly corrupting the data.

Table of

contents

Operation

MENU/Settings

Index

Retouch

Retouches a recorded image and saves it as a new file. The original image is retained.

1 Press the (Playback) button to switch to playback mode.

2 MENU t (Retouch) t desired mode t z on the control button

3 Perform retouching according to the operation method in each mode.

• You cannot retouch movies or panoramic images.

(Trimming

(Resize))

Records the zoomed playback

image.

1 Turn the lever to (T) to zoom in

and turn to (W) to zoom out.

2 Set the zoom point with the control

button.

3 MENU t select an image size to save t z

4 [OK] t z

• The quality of trimmed images may deteriorate.

• The image size that you can trim may vary depending on the image.

(Red Eye

Correction)

Corrects the red-eye phenomenon

caused by flash.

1 Select [OK] with the control

button t z.

• You may not be able to correct the

red-eye phenomenon depending on the image.

(Unsharp

masking)

Sharpens the image within a

chosen frame.

1 Select the area (frame) of the

desired image to retouch with the

control button t MENU.

2 [OK] t z

• Depending on the image, sufficient

correction may not be applied and

the image quality may deteriorate.

Note

Table of

contents

Operation

MENU/Settings

Index

Delete

Allows you to select unwanted images for deletion.

You can also delete images using the (Delete) button (page 38).

1 Press the (Playback) button to switch to playback mode.

2 MENU t (Delete) t desired mode t z on the control button

3 [OK] t z

• In Easy Viewing mode, you can select between [Delete Single Image] or [Delete All Images].

• When the internal memory is used to record images, View Mode is set to Folder View.

(This Image) Deletes the currently displayed image in single-image mode.

(Multiple Images) You can select and delete multiple images.

Do as the following after step 2.

1Select an image then press z.

Repeat the above step until there are no more images to be

deleted. Select an image with a mark to release the mark.

2MENU t [OK] t z

(All in Date

Range)

(All in This

Folder)

Deletes all images in date range, or the selected folder at once.

Notes

Table of

contents

Operation

MENU/Settings

Index

Protect

Protects recorded images against accidental erasure.

The mark is displayed for registered images.

1 Press the (Playback) button to switch to playback mode.

2 MENU t (Protect) t desired mode t z on the control button

• When the internal memory is used to record images, View Mode is set to Folder View.

(This Image) Protects the currently displayed image in single-image mode.

(Multiple

Images)

You can select and protect multiple images.

Do as the following after step 2.

1Select an image then press z.

Repeat the above step until there are no more images to be

protected. Select an image with a mark to release the

mark.

2MENU t [OK] t z

Note

zTo cancel the protection

Select the image for which you want to cancel protection, and unlock it by pressing z on

the control button as the same procedure to protect it.

The indicator disappears, and the protection is released.

Table of

contents

Operation

MENU/Settings

Index

DPOF

DPOF (Digital Print Order Format) is a function that allows you to specify the images of the

memory card that you want to print out later.

The (Print order) mark is displayed for registered images.

1 Press the (Playback) button to switch to playback mode.

2 MENU t t desired mode t z on the control button

• The (Print order) mark cannot be added to movies or to images in the internal memory.

• You can add a (Print order) mark to a maximum 999 images.

(This Image) Orders printing the currently displayed image in single-image

mode.

(Multiple

Images)

You can select and order printing multiple images.

Do as the following after step 2.

1Select an image then press z.

Repeat the above step until there are no more images to be

printed. Select an image with a mark to release the mark.

2MENU t [OK] t z

Notes

zClearing the DPOF mark

Select the image to clear the DPOF registration, then press z on the control button in the

same procedure as when making a mark.

The mark disappears and the DPOF registration is cleared.

Table of

contents

Operation

MENU/Settings

Index

Rotate

Rotates a still image. Use this to display a horizontal orientation image in vertical orientation.

1 Press the (Playback) button to switch to playback mode.

2 MENU t (Rotate) t z on the control button

3 Rotate the image with [ / ] t b/B.

4 [OK] t z

• You cannot rotate movies or protected still images.

• You may not be able to rotate images shot with other cameras.

• When viewing images on a computer, the image rotation information may not be reflected depending on

the software.

Notes

Table of

contents

Operation

MENU/Settings

Index

Select Folder

When multiple folders are created in a memory card, this selects the folder containing the image

you want to play back.

1 Press the (Playback) button to switch to playback mode.

2 MENU t (View Mode) t [Folder view (Still)] or [Folder view

(Movie)] t z on the control button

3 MENU t (Select Folder) t z

4 Select the folder with b/B.

5 [OK] t z

• This item is not displayed when the internal memory is used to record images.

Note

zViewing images across multiple folders

When multiple folders are created, the following indicators appear on the first and last

images in the folder.

: Moves to the previous folder

: Moves to the next folder

: Moves to either the previous or next folders

Table of

contents

Operation

MENU/Settings

Index

AF Illuminator

The AF illuminator supplies fill light to focus more easily on a subject in dark surroundings.

The AF illuminator emits red light allowing the camera to focus easily when the shutter button is

pressed halfway, until the focus is locked. The indicator appears at this time.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [AF Illuminator] t

desired mode t z on the control button

• Focus is achieved as long as the AF illuminator light reaches the subject, regardless of whether light fails

to reach the center of the subject.

• You cannot use the AF illuminator when:

– In Sweep Panorama mode

– (Advanced Sports Shooting), (Landscape), (Twilight), (Pet) or (Fireworks) mode is

selected in Scene Selection.

– The self-timer is set to [Self-portrait One Person] or [Self-portrait Two People].

• When you use the AF illuminator, the normal AF range finder frame is disabled and a new AF range

finder frame is displayed by a dotted line. AF operates with priority on subjects located near the center of

the frame.

• The AF illuminator emits very bright light. Although there is no health hazard, do not look directly into

the AF illuminator emitter at close range.

Auto Uses the AF illuminator.

Off Does not use the AF illuminator.

Notes

Table of

contents

Operation

MENU/Settings

Index

Grid Line

With reference to the grid lines, you can easily set a subject in a horizontal/vertical position.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [Grid Line] t

desired mode t z on the control button

On Displays the grid lines. The grid lines are not recorded.

Off Does not display the grid lines.

Table of

contents

Operation

MENU/Settings

Index

Disp. Resolution

Selects the display quality on the LCD screen for shooting.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [Disp. Resolution]

t desired mode t z on the control button

• The battery charge is used up more quickly when [Disp. Resolution] is set to [High].

• In Sweep Panorama and Movie Mode, [Disp. Resolution] is set to [High].

• In Easy Shooting mode, [Disp. Resolution] is set to [Standard].

Standard Displays a standard-quality image for shooting.

High Displays a high-quality image for shooting.

Notes

Table of

contents

Operation

MENU/Settings

Index

Digital Zoom

Selects the digital zoom mode. The camera enlarges the image using optical zoom (up to 10×).

When the zoom scale is exceeded, the camera uses either smart or precision digital zoom.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [Digital Zoom] t

desired mode t z on the control button

• The Digital Zoom function does not operate in the following situations:

– When the Scene Selection is set to (Advanced Sports Shooting)

– In Movie Mode

– In Sweep Panorama mode

– When the Smile Shutter function is activated

– When the self-timer is set to [Self-portrait One Person] or [Self-portrait Two People]

• The smart zoom is not available when the image size is set to [14M], or [16:9(11M)].

• The Face Detection function does not work when using the digital zoom.

The supported zoom ratio differs depending on the image size.

Smart ( ) Enlarges the image digitally within the range where the image will

not be distorted, according to the image size (Smart zoom).

Precision ( ) Enlarges all image sizes by the total zoom scale of approximately

20× including the optical zoom 10×. However, note that the image

quality deteriorates when the optical zoom scale is exceeded

(Precision digital zoom).

Off Does not use the digital zoom.

Notes

Total zoom scale when using Smart zoom

(including optical zoom 10×)

Size Total zoom scale

10M

Approx. 11×

Approx. 16×

VGA

Approx. 67×

16:9(2M)

Approx. 22×

Table of

contents

Operation

MENU/Settings

Index

Auto Orientation

When the camera is rotated to shoot a portrait (vertical) image, the camera records its position

change and displays the image in the portrait position.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [Auto Orientation]

t desired mode t z on the control button

• Black is displayed to the left and right of vertical orientation images.

• Depending on the shooting angle of the camera, the orientation of the image may not be recorded

correctly.

• You cannot use Auto Orientation in Movie Mode.

On Records the image with the correct orientation.

Off Does not use Auto Orientation.

Notes

zRotating images after recording

If the orientation of an image is incorrect, you can use the [Rotate] on the Menu screen to

display the image in portrait position.

Table of

contents

Operation

MENU/Settings

Index

Red Eye Reduction

The flash strobes two or more times before shooting to reduce the red-eye phenomenon when

using the flash.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [Red Eye

Reduction] t desired mode t z on the control button

• To avoid blurring of images, hold the camera firmly until the shutter is released. It usually takes a second

until the shutter is released, and also be sure not to allow the subject to move during this period.

• Red Eye Reduction may not produce the desired effects. It depends on individual differences and

conditions, such as distance to the subject, or if the subject looked away from the pre-strobe.

• If you do not use the Face Detection function, Red Eye Reduction does not work, even when you select

[Auto].

• [Red Eye Reduction] is set to [Off] in the following situations:

– When Scene Selection is set to (High Sensitivity) mode

– When the Smile Shutter function is activated

Auto When the Face Detection function is activated, the flash strobes

automatically to reduce the red-eye phenomenon.

On The flash always strobes to reduce the red-eye phenomenon.

Off Does not use Red Eye Reduction.

Notes

zWhat causes the red-eye phenomenon?

Pupils become dilated in dark environments. Flash light is reflected off the blood vessels at

the back of the eye (retina), causing the “red-eye” phenomenon.

Other ways to reduce red-eye

• Select (High Sensitivity) mode in Scene Selection. (The flash is set to [Off] automatically.)

• When the eyes of the subject turn out red, correct the image with [Retouch] t [Red Eye

Correction] on the viewing menu or with the supplied software “PMB”.

Camera

Eye

Retina

Table of

contents

Operation

MENU/Settings

Index

Blink Alert

When an image with the subject’s eyes closed is recorded while Face Detection is activated, the

message “Blinked eye detected” is displayed.

1 Set the camera to shooting mode.

2 MENU t (Settings) t (Shooting Settings) t [Blink Alert] t

desired mode t z on the control button

Auto Displays the “Blinked eye detected” message.

Off Does not display the message.

Table of

contents

Operation

MENU/Settings

Index

Beep

Selects or turns off the sound produced when you operate the camera.

1 MENU t (Settings) t (Main Settings) t [Beep] t desired

mode t z on the control button

Shutter Turns on the shutter sound when you press the shutter button.

High

Turns on the beep/shutter sound when you press the control/shutter

button.

If you want to lower the volume, select [Low].

Low

Off Turns off the beep/shutter sound.

Table of

contents

Operation

MENU/Settings

Index

Language Setting

Selects the language to be used in the menu items, warnings and messages.

1 MENU t (Settings) t (Main Settings) t [Language Setting] t

desired mode t z on the control button

Table of

contents

Operation

MENU/Settings

Index

Function Guide

You can select whether or not the function guide is displayed when you operate the camera.

1 MENU t (Settings) t (Main Settings) t [Function Guide] t

desired mode t z on the control button

On Displays the function guide.

Off Does not display the function guide.

Table of

contents

Operation

MENU/Settings

Index

Demo Mode

You can set whether to use a demonstration of the Smile Shutter and Scene Recognition.

When there is no need to view a demonstration, set to [Off].

1 MENU t (Settings) t (Main Settings) t [Demo Mode] t

desired mode t z on the control button

• Pressing the shutter button during the Smile Shutter demonstration operates the shutter, but no image is

recorded.

Demo Mode1 Demonstrates Scene Recognition mode.

Demo Mode2 Automatically starts the Smile Shutter demonstration when no

operation is performed for 15 seconds.

Off Does not perform a demonstration.

Note

Table of

contents

Operation

MENU/Settings

Index

Initialize

Initializes the setting to the default setting.

Even if you execute this function, the images are retained.

1 MENU t (Settings) t (Main Settings) t [Initialize] t [OK] t

z on the control button

• Be sure not to turn off the camera while initializing.

Note

Table of

contents

Operation

MENU/Settings

Index

COMPONENT

Selects the video output signal type from SD and HD(1080i) when you connect the camera and

TV using an HD Output Adaptor Cable (sold separately), according to the TV connected.

Use a Type2b-compliant HD Output Adaptor Cable (sold separately).

1 MENU t (Settings) t (Main Settings) t [COMPONENT] t

desired mode t z on the control button

• When shooting movies in the condition with the camera and a TV connected using an HD Output

Adaptor Cable (sold separately), the image being shot is not displayed in the TV side.

HD(1080i) Select this item to connect the camera to a 1080i-capable High

Definition TV.

SD Select this item to connect the camera to a TV that is not

compatible with an HD(1080i) signal.

Note

Table of

contents

Operation

MENU/Settings

Index

Video Out

Sets the video signal output according to the TV color system of the connected video equipment.

The TV color systems differ depending on the country and region.

To view images on a TV screen, check the TV color system of the country or region of use

(page 102).

1 MENU t (Settings) t (Main Settings) t [Video Out] t desired

mode t z on the control button

NTSC Sets the video output signal to NTSC mode (e.g., for the USA,

Japan).

PAL Sets the video output signal to PAL mode (e.g., for Europe, China).

Table of

contents

Operation

MENU/Settings

Index

USB Connect

Selects the USB mode when connecting the camera to a computer or a PictBridge-compliant

printer using the cable for multi-use terminal.

1 MENU t (Settings) t (Main Settings) t [USB Connect] t

desired mode t z on the control button

• If you cannot connect the camera to a PictBridge-compliant printer with the [Auto] setting, select

[PictBridge].

• If you cannot connect the camera to a computer or a USB device with the [Auto] setting, select [Mass

Storage].

• When [USB Connect] is set to [PTP/MTP], you cannot export movies to a computer. To export movies to

a computer, set [USB Connect] to [Auto] or [Mass Storage].

Auto The camera recognizes automatically and sets up communication

with a computer or PictBridge-compliant printer.

PictBridge Connects the camera to a PictBridge-compliant printer.

PTP/MTP When you connect the camera to a computer, the AutoPlay Wizard

appears, and the still images in the recording folder on the camera

are imported to the computer. (with Windows 7/Vista/XP,

Mac OS X)

Mass Storage Establishes a Mass Storage connection between the camera and a

computer or other USB device.

Notes

Table of

contents

Operation

MENU/Settings

Index

LUN Settings

Sets the display method for the recording media displayed on a computer screen or other monitor

when the camera is connected with a computer or AV component using a USB connection.

1 MENU t (Settings) t (Main Settings) t [LUN Settings] t

desired mode t z on the control button

• You must always select [Multi] in [LUN Settings] when uploading images to a media service using

“PMB Portable”.

Multi The images both on the memory card and in the internal memory

are displayed. Select this setting when you connect the camera to a

computer.

Single When the memory card is inserted into the camera, the images on

the memory card are displayed; when it is not inserted, the images

in the internal memory are displayed. Select this setting in cases

where the images of both the memory card and the internal memory

are not displayed when the camera is connected to a device other

than a computer.

Note

Table of

contents

Operation

MENU/Settings

Index

Download Music

You can use “Music Transfer” in the CD-ROM (supplied) to change background music tracks.

1 MENU t (Settings) t (Main Settings) t [Download Music] t

z on the control button

The message “Connect to PC” appears.

2 Make a USB connection between the camera and a computer, then start

“Music Transfer”.

3 Follow the instructions on the screen to change music files.

Table of

contents

Operation

MENU/Settings

Index

Format Music

You can delete all the background music files stored in the camera. It can be used in cases such

as when the background music files are damaged and cannot be played.

1 MENU t (Settings) t (Main Settings) t [Format Music] t [OK]

t z on the control button

zRestoring the music preset at the factory to the

camera

You can use “Music Transfer” in the CD-ROM (supplied) to reset music files to the preset

ones.

1Execute [Download Music] and make a USB connection between the camera and a

computer.

2Start “Music Transfer”, then restore the default music.

• For details on using “Music Transfer”, see the help in “Music Transfer”.

Table of

contents

Operation

MENU/Settings

Index

Power Save

Sets the time until the screen darkens, and the camera turns off. If you do not operate the camera

running on a battery pack for a certain amount of time, the brightness level on the LCD screen

becomes dark, and then the camera automatically turns off to prevent wearing down the battery

pack (Auto Power off).

1 MENU t (Settings) t (Main Settings) t [Power Save] t

desired mode t z on the control button

Stamina The LCD screen darkens after about 30 seconds of no operation.

The camera turns off after another 30 seconds of no operation.

Standard The LCD screen darkens after 1 minute of no operation. The

camera turns off after another 1 minute of no operation.

Off The LCD screen does not darken and the camera does not turn off

automatically.

Table of

contents

Operation

MENU/Settings

Index

Format

Formats the memory card or the internal memory. When you use a memory card with this

camera for the first time, it is recommended to format the card using the camera for stable

performance of the memory card before shooting. Note that formatting permanently erases all

data on the memory card, and is unrecoverable. Save precious data on a computer, etc.

1 MENU t (Settings) t (Memory Card Tool) or (Internal

Memory Tool) t [Format] t [OK] t z on the control button

• Note that formatting permanently erases all data including even protected images.

Note

Table of

contents

Operation

MENU/Settings

Index

Create REC.Folder

Creates a folder in the memory card for recording images.

Images are recorded in the newly created folder until you create another folder or select another

recording folder.

1 MENU t (Settings) t (Memory Card Tool) t [Create

REC.Folder] t [OK] t z on the control button

• This item is not displayed when the internal memory is used to record images.

• When you insert a memory card that was used with other equipment into the camera and shoot images, a

new folder may be automatically created.

• Up to 4,000 images can be stored in one folder. When the folder capacity is exceeded, a new folder is

automatically created.

Notes

zOn the folders

After a new folder is created, you can change the storage destination folder (page 94) and

select the folder for viewing images (page 72).

Table of

contents

Operation

MENU/Settings

Index

Change REC.Folder

Changes the folder in the memory card that is currently used for recording images.

1 MENU t (Settings) t (Memory Card Tool) t [Change

REC.Folder]

2 Select a folder with b/B on the control button.

3 [OK] t z

• This item is not displayed when the internal memory is used to record images.

• The following folder cannot be selected as a recording folder.

– “100” folder

– A folder with a number that has only either “sssMSDCF” or “sssMNV01”.

• You cannot move recorded images to another folder.

Notes

Table of

contents

Operation

MENU/Settings

Index

Delete REC.Folder

Deletes a folder for recording images in the memory card.

1 MENU t (Settings) t (Memory Card Tool) t [Delete

REC.Folder]

2 Select a folder with b/B on the control button.

3 [OK] t z

• This item is not displayed when the internal memory is used to record images.

• If you delete the folder set as the recording folder using [Delete REC.Folder], the folder that has the

largest folder number is selected as the next recording folder.

• You can delete only empty folders. If a folder contains images, or files that cannot be played back by the

camera, first delete these images and files, and then delete the folder.

Notes

Table of

contents

Operation

MENU/Settings

Index

Copy

Copies all images in the internal memory to a memory card.

1 Insert a memory card with sufficient free capacity into the camera.

2 MENU t (Settings) t (Memory Card Tool) t [Copy] t [OK]

t z on the control button

• Use a fully charged battery pack. If you attempt to copy image files using a battery pack with little

remaining charge, the battery pack may run out, causing copying to fail or possibly corrupting the data.

• Images cannot be copied individually.

• The original images in the internal memory are retained even after copying. To delete the contents of the

internal memory, remove the memory card after copying, then format the internal memory ([Format] in

[Internal Memory Tool]).

• A new folder is created on the memory card and all the data will be copied to it. You cannot choose a

specific folder and copy images to it.

Notes

Table of

contents

Operation

MENU/Settings

Index

File Number

Selects the method used to assign file numbers to images.

1 MENU t (Settings) t (Memory Card Tool) or (Internal

Memory Tool) t [File Number] t desired mode t z on the control

button

Series Assigns numbers to files in sequence even if the recording folder or

the memory card is changed. (When the replaced memory card

contains a file with a number higher than the last assigned number,

a number one higher than the largest number is assigned.)

Reset Starts from 0001 each time the folder is changed. (When the

recording folder contains a file, a number one higher than the

largest number is assigned.)

Table of

contents

Operation

MENU/Settings

Index

Area Setting

Adjusts the time to the local time of a selected area.

1 MENU t (Settings) t (Clock Settings) t [Area Setting] t

desired setting t z on the control button

Home You use the camera in your area.

When the currently set area differs from your home area, you must

make the Area Setting.

Destination You use the camera set to the time at your destination.

Set the destination area.

zChanging Area Setting

Setting a frequently visited destination lets you easily adjust the time when you visit that

destination.

1Select the area part for [Destination], then press z on the control button.

2Select an area with b/B on the control button, and select Daylight Savings time with

v/V.

Daylight Savings icon

Table of

contents

Operation

MENU/Settings

Index

Date & Time Setting

Sets the date and time again.

1 MENU t (Settings) t (Clock Settings) t [Date & Time Setting]

t desired setting t z on the control button

2 Set the numeric value and desired settings with v/V/b/B.

3 [OK] t z

• The camera does not have a feature for superimposing dates on images. By using “PMB” in the CD-

ROM (supplied), you can print or save images with the date.

Date & Time Format You can select the date and time display format.

Daylight Savings You can select Daylight Savings On/Off.

Date & Time You can set the date and time.

Note

Table of

contents

Operation

MENU/Settings

Index

100

Viewing an image on a TV

You can view images on a TV by connecting the camera to a TV.

Refer also to the operating instructions supplied with the TV.

1 Turn off both the camera and the TV.

2 Connect the camera to the TV with the cable for multi-use terminal

(supplied).

3 Turn on the TV and set the input.

4 Press (Playback) button to turn on the camera.

Images shot with the camera appear on the TV. Select the desired image with the control

button.

• When using the camera abroad, it may be necessary to switch the video signal output to match that of

your TV system (page 86).

• The shooting image will not be displayed on the TV when the movie is shot under the condition of the

camera and TV connected.

• When output to TV, Easy Viewing mode is invalid.

Viewing images by connecting the camera to a TV

with the supplied cable for multi-use terminal

Notes

1 To audio/video input jacks

Cable for multi-use terminal

(Playback) button

2 To the multi connector

Table of

contents

Operation

MENU/Settings

Index

101

You can view an image recorded on the camera by connecting the camera to an HD (High

Definition) TV with the HD Output Adaptor Cable (sold separately). Use a Type2b-compliant

HD Output Adaptor Cable (sold separately).

1 Turn off both the camera and the TV.

2 Connect the camera to the TV with an HD Output Adaptor Cable (sold

separately).

3 Turn on the TV and set the input.

4 Press (Playback) button to turn on the camera.

Images shot with the camera appear on the TV. Select the desired image with the control

button.

• Set [COMPONENT] to [HD(1080i)] (page 85).

• Images shot in [VGA] image size cannot be played back in HD format.

• When shooting movies in the condition with the camera and a TV connected using an HD Output

Adaptor Cable (sold separately), the image being shot is not displayed in the TV side.

• When using the camera abroad, it may be necessary to switch the video signal output to match that of

your TV system (page 86).

• When output to TV, Easy Viewing mode is invalid.

Viewing an image by connecting the camera to an

HD TV

Notes

HD Output

Adaptor Cable

(sold separately)

2 To the multi connector

AUDIO

(Playback) button

COMPONENT

VIDEO IN

White/Red

Green/Blue/Red

1 To audio/video

input jacks

z“PhotoTV HD”

This camera is compatible with the “PhotoTV HD” standard.

By connecting Sony PhotoTV HD-compatible devices using an HD Output Adaptor Cable

(sold separately), whole new world of photos can be comfortably enjoyed in breathtaking

Full HD quality.

• PhotoTV HD allows for a highly-detailed, photo-like expression of subtle textures and colors.

• The settings are also required to be made on the TV. For details, refer to the operating instruction of

the TV.

Table of

contents

Operation

MENU/Settings

Index

102

If you want to view images on a TV screen, you need a TV with a video input jack and the cable

for multi-use terminal. The color system of the TV must match that of the digital still camera.

Check the following lists for the TV color system of the country or region where the camera is

used.

NTSC system

Bahama Islands, Bolivia, Canada, Central America, Chile, Colombia, Ecuador, Jamaica, Japan,

Korea, Mexico, Peru, Surinam, Taiwan, the Philippines, the U.S.A., Venezuela, etc.

PAL system

Australia, Austria, Belgium, China, Croatia, Czech Republic, Denmark, Finland, Germany,

Holland, Hong Kong, Hungary, Indonesia, Italy, Kuwait, Malaysia, New Zealand, Norway,

Poland, Portugal, Rumania, Singapore, Slovak Republic, Spain, Sweden, Switzerland, Thailand,

Turkey, United Kingdom, Viet Nam, etc.

PAL-M system

Brazil

PAL-N system

Argentina, Paraguay, Uruguay

SECAM system

Bulgaria, France, Greece, Guiana, Iran, Iraq, Monaco, Russia, Ukraine, etc.

On TV color systems

Table of

contents

Operation

MENU/Settings

Index

103

Using with your computer

“PMB” and other applications are contained on the CD-ROM (supplied) to allow more versatile

use of images shot with your Cyber-shot camera.

The following computer environment is recommended when using the supplied software

“PMB”, “Music Transfer” or “PMB Portable” and importing images via a USB connection.

64-bit editions and Starter (Edition) are not supported.

Windows Image Mastering API (IMAPI) Ver.2.0 or later is required to use the function for creating

discs.

Starter (Edition) is not supported.

The following computer environment is recommended when using the supplied software,

“Music Transfer” or “PMB Portable” and importing images via a USB connection.

• Operation is not assured in an environment based on an upgrade of the operating systems described

above or in a multi-boot environment.

• If you connect two or more USB devices to a single computer at the same time, some devices, including

the camera, may not operate, depending on the types of USB devices you are using.

• Connecting the camera using a USB interface that is compatible with Hi-Speed USB (USB 2.0

compliant) allows advanced transfer (high speed transfer), as the camera is compatible with Hi-Speed

USB (USB 2.0 compliant).

• When your computer resumes activity from suspend or sleep mode, communication between the camera

and your computer may not recover at the same time.

Recommended computer environment (Windows)

OS (pre-installed) Microsoft Windows XP*

SP3/Windows Vista*

SP2/

Windows7

Others CPU: Intel Pentium III 800 MHz or faster (For playing/

editing the High Definition movies: Intel Core Duo

1.66 GHz or faster/ Intel Core 2 Duo 1.20 GHz or faster)

Memory: 512 MB or more (For playing/ editing the High

Definition movies: 1 GB or more)

Hard Disk: Disk space required for installation—

approximately 500 MB

Display: Screen resolution: 1,024 × 768 dots or more

Recommended computer environment

(Macintosh)

OS (pre-installed) USB Connection: Mac OS X (v10.3 to v10.6)

Music Transfer/PMB Portable: Mac OS X (v10.4 to v10.6)

Notes

Table of

contents

Operation

MENU/Settings

Index

104

Using the software

1 Turn on your computer, and insert the CD-ROM (supplied) into the CD-

ROM drive.

The installation menu screen appears.

• If it does not appear, double-click [Computer] (in Windows XP, [My Computer]) t

(SONYPMB).

• If the AutoPlay screen appears, select “Run Install.exe” and follow the instructions that appear on the

screen to proceed with the installation.

2 Click [Install].

The “Choose Setup Language” screen appears.

3 Select the desired language, then proceed to the following screen.

The “License Agreement” screen appears.

4 Carefully read the agreement, click the radio button ( t ) to accept

the terms of the agreement, and then click [Next].

5 Follow the instructions on the screen to complete the installation.

• For the installation, connect the camera to the computer during the procedure (page 106).

• When the restarting confirmation message appears, restart the computer following the instructions on

the screen.

• DirectX may be installed depending on the system environment of your computer.

6 Remove the CD-ROM after the installation is complete.

7 Start up the software.

• To start up “PMB”, click (PMB) on the desktop.

For the detailed operation method, see “PMB” Support page below (English only) or click (PMB

Help).

http://www.sony.co.jp/pmb-se/

• To start up “PMB” from the Start menu, select [Start] t [All Programs] t (PMB).

• If “PMB” is already installed in your computer, by installing “PMB” from the CD-ROM (supplied),

you can start up all of the application from “PMB Launcher”.

To start up “PMB Launcher”, double-click (PMB Launcher) on the desktop.

• Log on as Administrator.

• When “PMB” is started up for the first time, the confirmation message of the Information tool appears on

the screen. Select [Start].

Installing “PMB (Picture Motion Browser)” and

“Music Transfer” (Windows)

Notes

Table of

contents

Operation

MENU/Settings

Index

105

1 Turn on your Macintosh computer, and insert the CD-ROM (supplied) into

the CD-ROM drive.

2 Double-click (SONYPMB).

3 Double-click the [MusicTransfer.pkg] file in the [Mac] folder.

The installation of the software starts.

• “PMB” is not compatible with Macintosh computers.

• Shut down all other application software before you install “Music Transfer”.

• For installation, you need to log on as Administrator.

Installing “Music Transfer” (Macintosh)

Notes

zIntroduction to “PMB”

• “PMB” allows you to import images shot with the camera to a computer for display. Make a USB

connection between the camera and your computer, and click [Import].

• Images on a computer can be exported to a memory card, and displayed on the camera. Make a USB

connection between the camera and your computer, click [Export] t [Easy Export (PC Sync)] in

the [Manipulate] menu, and click [Export].

• You can save and print images with the date.

• You can display images stored on a computer by shooting date in a calendar display.

• You can correct (Red Eye Reduction, etc.) still images, and change the shooting date and time.

• You can create discs with CD or DVD disc-writing drive.

• You can upload images to media services. (An internet connection environment is required.)

• For other details, see (PMB Help).

zIntroduction to “Music Transfer”

“Music Transfer” allows you to replace the Music files provided in the camera at the factory

with your favorite tracks, and to delete and add Music files.

You can also restore the tracks stored at the factory to your camera.

The following track types can be imported using “Music Transfer”.

– MP3 files stored on the hard disk of your computer

– Music CD tracks

– Preset-music saved on the camera

• Before starting up “Music Transfer”, perform MENU t (Settings) t [Main Settings] t

[Download Music], and connect the camera to a computer.

For other details, see the help in “Music Transfer”.

Table of

contents

Operation

MENU/Settings

Index

106

Connecting the camera to the

computer

1 Insert a sufficiently charged battery pack into the camera, or connect the

camera to a wall outlet (wall socket) using the AC-LS5 AC Adaptor (sold

separately) and the USB/AV/DC IN Cable for multi-use terminal (sold

separately).

• Use a Type2b-compliant USB/AV/DC IN Cable (sold separately).

2 Turn on the computer, then press (Playback) button.

3 Connect the camera to your computer.

• When a USB connection is established for the first time, your computer automatically runs a program

to recognize the camera. Wait for a while.

“PMB” allows you to easily import images.

For details on “PMB” functions, see the “PMB Help”.

Importing images to a computer without using “PMB”

When the AutoPlay Wizard appears after making a USB connection between the camera and a

computer, click [Open folder to view files] t [OK] t [DCIM] or [MP_ROOT] t copy the

desired images to the computer.

Importing images to a computer (Windows)

Cable for multi-use terminal (supplied)

1 To a USB jack of the computer

2 To the multi connector

Table of

contents

Operation

MENU/Settings

Index

107

1 Connect the camera to your Macintosh computer first. Double-click the

newly recognized icon on the desktop t [DCIM] or [MP_ROOT] t the

folder where the images you want to import are stored.

2 Drag and drop the image files to the hard disk icon.

The image files are copied to the hard disk.

3 Double-click the hard disk icon t the desired image file in the folder

containing the copied files.

The image is displayed.

Perform the procedures from step 1 to 3 below before:

• Disconnecting the cable for multi-use terminal.

• Removing a memory card.

• Inserting a memory card into the camera after copying images from the internal memory.

• Turning off the camera.

1 Double-click the disconnect icon on the

tasktray.

2 Click (USB Mass Storage Device) t [Stop].

3 Confirm the device on the confirmation

window, then click [OK].

• Drag and drop the icon of the memory card or the drive icon to the “Trash” icon beforehand when you

use a Macintosh computer, and the camera is disconnected from the computer.

Importing images to a computer (Macintosh)

Deleting the USB connection

Note

Windows Vista

Disconnect icon

Windows XP

Table of

contents

Operation

MENU/Settings

Index

108

Uploading images to a media

service

This camera has a built-in application “PMB Portable”.

You can use this application to do the following:

• You can easily upload images to a blog or other media service.

• You can upload images from a computer connected to the Internet even when you are away from home or

the office.

• You can easily register the media services (such as blogs) you use frequently.

For details on “PMB Portable”, see the “PMB Portable” help.

When using “PMB Portable” for the first time, you must select the language. Follow the

procedure below to make the selection. Once the language selection has been made, steps 3 to 5

are unnecessary the next time you use “PMB Portable”.

1 Make a USB connection between the camera and a computer.

When you connect the camera and your computer, AutoPlay Wizard appears.

Click [×] to close the AutoPlay Wizard for any unnecessary drives.

• If the desired AutoPlay Wizard does not appear, click [Computer] (in Windows XP, [My Computer])

t [PMBPORTABLE], then double-click “PMBP_Win.exe”.

2 Click “PMB Portable”.

(in Windows XP, click “PMB Portable” t [OK])

• If [PMB Portable] is not displayed within the AutoPlay Wizard, click [Computer] t

[PMBPORTABLE], then double-click “PMBP_Win.exe”.

The Language Selection screen appears.

3 Select the desired language, then click [OK].

The Region Selection screen appears.

4 Select the appropriate [Region] and [Country/Area], and then click [OK].

The User Agreement screen appears.

5 Read the agreement carefully. If you accept the terms of the agreement,

click [I Agree].

“PMB Portable” starts up.

Starting up “PMB Portable” (Windows)

Table of

contents

Operation

MENU/Settings

Index

109

1 Make a USB connection between the camera and a Macintosh computer.

When you connect the camera and your computer, [PMB Portable] appears on the desktop.

Click [×] to close any unnecessary drives.

2 Click [PMBPORTABLE] folder, then click [PMBP_Mac].

The Region Selection screen appears.

3 Select the appropriate [Region] and [Country/Area], and then click [OK].

The User Agreement screen appears.

4 Read the agreement carefully. If you accept the terms of the agreement,

click [I Agree].

“PMB Portable” starts up.

• Set [LUN Settings] in [Main Settings] to [Multi].

• Always connect to a network when using “PMB Portable”.

• When uploading images over the Internet, the cache may remain in the computer being used depending

on the service provider. This is also true when this camera is used for this purpose.

• When a bug occurs in “PMB Portable” or you delete “PMB Portable” by mistake, you can repair “PMB

Portable” by downloading the PMB Portable installer from the web site.

“PMB Portable” makes it possible to download the URLs of a number of websites from the

server administered by Sony (the “Sony server”).

In order to use “PMB Portable” to enjoy the benefits of the image uploading service or other

services (the “services”) provided by these and other websites, you must consent to the

following.

• Some websites require registration procedures and/or fees to use their services. In using such services,

you must comply with the terms and conditions established by the websites concerned.

• Services may be terminated or changed in accordance with the convenience of the website operators.

Sony will not be held responsible for any trouble occurring between the users and third parties or any

inconvenience caused to users relating to the utilization of the services inclusive of the termination of or

changes to such services.

• To view a website, you will be redirected to it by the Sony server. There may be times when you cannot

access the website because of server maintenance or for other reasons.

• If the operation of the Sony server is to be terminated, you will be notified of the termination ahead of

time on Sony’s website, etc.

• The URLs to which you are redirected by the Sony server and other information may be recorded for the

purposes of improving Sony’s future products and services. However, no personal data will be recorded

on such occasions.

Starting up “PMB Portable” (Macintosh)

Notes

Notes on “PMB Portable”

Table of

contents

Operation

MENU/Settings

Index

110

Printing still images

You can print still images using the following methods.

• Printing directly using a PictBridge-compliant printer

• Printing directly using a printer which supports your memory card type

For details, see the operating instructions supplied with the printer.

• Printing using a computer

You can import images to a computer using the supplied “PMB” software and print the

images. You can insert the date on the image and print it.

For details, see the “PMB Help”.

• Printing at a shop (page 111)

• When you print still images shot in [16:9] mode, both edges may be cut off.

• You cannot print panoramic images depending on the printer.

Even if you do not have a computer, you can print images shot using the camera by connecting

the camera directly to a PictBridge-compliant printer.

“PictBridge” is based on the CIPA standard. (CIPA: Camera & Imaging

Products Association)

1 Insert a sufficiently charged battery pack into the camera.

2 Connect the camera to the printer.

3 Turn on the camera and the printer.

After the connection is made, the indicator appears on the screen.

If the indicator flashes on the screen of the camera (error notification), check the connected

printer.

Notes

Printing images directly using a PictBridge-

compliant printer

1 To a USB jack of

the printer

2 To the multi connector

Cable for multi-use terminal

Continued r

Table of

contents

Operation

MENU/Settings

Index

111

4 MENU t (Print) t desired mode t z on the control button

5 Desired item t [Start] t z

• Movies cannot be printed.

• If the camera could not be connected to the printer, be sure to set [USB Connect] under (Main

Settings) to [PictBridge].

• Do not disconnect the cable for multi-use terminal while the (PictBridge Connecting) indicator

appears on the screen.

You can take a memory card containing images shot with the camera to a photo printing service

shop. As long as the shop supports photo printing services conforming to DPOF, you can make a

(Print order) mark on images in advance in the playback mode so that you do not have to

reselect them when you print them out at the shop.

• You cannot print images stored in the internal memory at a print shop directly from the camera. Copy the

images to a memory card (page 96), then take the memory card to the print shop.

• Consult your photo printing service shop as to what types of memory card they handle.

• A memory card adaptor (sold separately) may be necessary. Consult your photo printing service shop.

• Before you take image data to a shop, always copy (back up) your data to a disk.

• You cannot set the number of prints.

• If you want to superimpose dates on images, consult your photo printing service shop.

This Image Prints the currently displayed image in single-image mode.

Multiple Images You can select and print multiple images.

After step 4, perform the following.

1Select an image then press z.

Repeat the above step until there are no more images to be

printed. Select an image with a mark again to release the

mark.

2MENU t [OK] t z.

Quantity Selects the number of copies of the specified image to be printed.

• The designated number of images may not all fit onto a single sheet

depending on the quantity of images.

Layout Selects the number of images you want to print side by side on a

sheet.

Size Selects the size of the printing sheet.

Date Selects [Date] or [Day&Time] to insert the date and time on

images.

• When you choose [Date], the date will be inserted in the order you have

selected using [Date & Time Setting] on the camera. This function may

not be available depending on the printer.

Notes

Printing at a shop

Notes

Table of

contents

Operation

MENU/Settings

Index

112

Troubleshooting

If you experience trouble with the camera, try the following solutions.

Be aware that by sending the camera for repair, you give consent that the contents of the internal

memory, music files may be checked.

Cannot insert the battery pack.

• Make sure the direction of the battery is correct, and insert it until the battery eject lever is locked.

Cannot turn on the camera.

• After inserting the battery pack into the camera, it may take a few moments for the camera to power

up.

• Insert the battery pack correctly.

• The battery pack is discharged. Insert a charged battery pack.

• The terminal section of the battery is dirty. Wipe any dust with a soft cloth lightly to clean the battery.

• Use a recommended battery pack.

The power turns off suddenly.

• Depending on the camera and battery temperature, the power may turn off automatically to protect

the camera. In this case, a message is displayed on the LCD screen before the power turns off.

• When [Power Save] is set to [Stamina] or [Standard], if you do not operate the camera for a certain

period of time while the power is on, the camera turns off automatically to prevent wearing down the

battery pack. Turn on the camera again.

1 Check the items on pages 112 to 119.

If a code such as “C/E:ss:ss” appears on the screen, see

page 120.

2 Remove the battery pack, wait for about one minute, re-insert

the battery pack, then turn on the power.

3 Initialize the settings (page 84).

4 Consult your Sony dealer or local authorized Sony service

facility.

Additional information on this product and answers to frequently asked questions can

be found at our Customer Support Website.

http://www.sony.net/

Battery pack and power

Table of

contents

Operation

MENU/Settings

Index

113

The remaining charge indicator is incorrect.

• This phenomenon occurs when you use the camera in an extremely hot or cold location.

• A discrepancy arose between the remaining charge indicator and the actual remaining battery charge.

Fully discharge the battery pack once, then charge it to correct the indication.

• Battery capacity decreases over time and through repeated use. If decreased usage time between

charges becomes significant, it is probably time to replace it with a new one.

Cannot charge the battery pack.

• You cannot charge the battery pack using the AC Adaptor (sold separately). Use the battery charger

to charge the battery.

The CHARGE lamp flashes while charging the battery.

• Remove and reinsert the battery pack, making sure it is installed correctly.

• The temperature may be inappropriate for charging. Try charging the battery pack again within the

proper charging temperature range (10 °C to 30 °C (50 °F to 86 °F)).

• Refer to page 128 for details.

Cannot record images.

• If images are recorded on the internal memory even when a memory card is inserted into the camera,

make sure that the memory card is fully inserted into the camera.

• Check the free capacity of the internal memory or memory card. If it is full, do one of the following:

– Delete unnecessary images (page 38).

– Change the memory card.

• You cannot record images while charging the flash.

• When recording movies, it is recommended that you use the following memory cards:

– “Memory Stick PRO Duo” (Mark2) media, “Memory Stick PRO-HG Duo” media

– SD memory card, SDHC memory card or SDXC memory card (Class 4 or faster)

• Set [Demo Mode] to [Off] (page 83).

Smile Shutter function does not work.

• No image is shot if a smiling face is not detected.

• Set [Demo Mode] to [Off] (page 83).

Anti-blur function does not work.

• The anti-blur function may not work properly when shooting night scenes.

• Shoot after pressing the shutter button halfway down.

• If camera shake is excessive, the anti-blur function may not be effective even when [SteadyShot] is

activated.

Recording takes a long time.

• When the shutter speed becomes slower than a certain speed in low light conditions, the NR (Noise

Reduction) slow shutter function is activated automatically to reduce the image noise. Under such

conditions, recording takes a long time.

• The Anti Blink function is working. Reset [Anti Blink] to [Off] (page 61).

Shooting still images/movies

Table of

contents

Operation

MENU/Settings

Index

114

The image is out of focus.

• The subject is too close. When shooting, make sure to position the lens farther away from the subject

than the shortest shooting distance (approximately 5 cm (2 inches) (W)/100 cm (3ft 3 3/8 inches) (T)

from the lens).

• (Advanced Sports Shooting), (Twilight), (Landscape) or (Fireworks) mode is selected in

the Scene Selection when shooting still images.

Zoom does not work.

• You cannot use the zoom when shooting in Sweep Panorama mode.

• You cannot use the Smart zoom depending on the image size (page 76).

• You cannot use the digital zoom when:

– In Movie Mode

– The Smile Shutter is working.

– When (Advanced Sports Shooting) mode in the Scene Selection is selected

Cannot select the Face Detection function.

• You can select Face Detection only when the focus mode is set to [Multi AF] and the metering mode

is set to [Multi].

The flash does not work.

• You cannot use the flash when:

– Burst mode is selected (page 45).

– (High Sensitivity), (Advanced Sports Shooting), (Twilight) or (Fireworks) mode is

selected in Scene Selection.

– In Sweep Panorama mode

– In Movie Mode

• Set the flash to (On) (page 32) when the Scene Selection mode is set to (Landscape),

(Gourmet), (Pet), (Beach) or (Snow) mode.

Fuzzy white circular spots appear in images shot using the flash.

• Particles (dust, pollen, etc.) in the air reflected the flash light and appeared in the image. This is not a

malfunction.

The close-up shoot function (Macro) does not work.

• The camera automatically adjusts the focus. Press and hold the shutter button halfway down. Focus

adjustment may take some time when shooting a close subject.

• (Advanced Sports Shooting), (Landscape), (Twilight) or (Fireworks) mode is selected in

the Scene Selection.

The date and time are not displayed on the LCD screen.

• While shooting, the date and time are not displayed. They are displayed only during playback.

Cannot insert dates on images.

• This camera does not have a feature for superimposing dates on images. By using “PMB”, you can

print or save images with the date (page 104).

The F value and shutter speed flash when you press and hold the shutter button

halfway down.

• The exposure is incorrect. Correct the exposure (page 47).

Table of

contents

Operation

MENU/Settings

Index

115

The image colors are not correct.

• Adjust the White Balance (page 50).

White or purple streaks appear in bright areas of the subject, or the whole screen

of the image becomes reddish.

• This phenomenon is called smearing. This is not a malfunction. Smearing is not recorded on still

images, but is recorded as streaks or uneven colors on Sweep Panorama images or movies. (“Bright

areas” refers to the sun or electric lights which are much brighter than surroundings.)

Noise appears in the image when you view the screen in a dark place.

• The camera is attempting to increase the visibility of the screen by temporarily brightening the image

under conditions of low illumination. There is no effect on the recorded image.

The eyes of the subject come out red.

• Set [Red Eye Reduction] to [Auto] or [On] (page 78).

• Shoot the subject at a distance closer than the flash range using the flash.

• Light the room and shoot the subject.

• Retouch the image using [Retouch] t [Red Eye Correction] in viewing menu (page 67), or correct

using “PMB”.

Dots appear and remain on the screen.

• This is not a malfunction. These dots are not recorded.

Cannot shoot images in succession.

• The internal memory or memory card is full. Delete unnecessary images (page 38).

• The battery level is low. Insert charged battery pack.

The same image is shot several times.

• Set [Burst Settings] to [Single] (page 45).

• Set [Bracket Settings] to [Off] (page 46).

• [Scene Recognition] is set to [Advanced] (page 55).

Cannot play back images.

• Make sure that the memory card is fully inserted into the camera.

• The folder/file name has been changed on your computer.

• No guarantees are made for playing back, on this camera, files containing images which were

processed on a computer or images which were shot using other cameras.

• The camera is in USB mode. Delete the USB connection (page 107).

• Use “PMB” to play images stored on a PC with this camera.

The date and time are not displayed.

• The screen display is set to display images only. Press the DISP (Screen Display Settings) button to

display information (page 30).

Left and right sides of the screen are shown in black.

• [Auto Orientation] is set to [On] (page 77).

Viewing images

Table of

contents

Operation

MENU/Settings

Index

116

Cannot display images in index mode.

• Cancel the Easy Viewing mode if activated.

Cannot hear music during slideshow.

• Transfer music files to the camera with “Music Transfer” (pages 104, 105).

• Confirm that the volume setting and slideshow setting are correct (page 63).

• Slideshow is played back with [Continuous Playback]. Select [Slideshow with music] and play back.

The image does not appear on the TV.

• Check [Video Out] to see if the video output signal of the camera is set to the color system of your TV

(page 86).

• Check whether the connection is correct (page 100).

• If the USB connector of the cable for multi-use terminal is connected to another device, disconnect it

(page 107).

• When shooting movies with the camera and a TV connected, the image being shot is not displayed on

the TV.

Cannot delete an image.

• Cancel the protection (page 69).

“Memory Stick PRO Duo” media is not recognized by a computer with a “Memory

Stick” media slot.

• Check that the computer and the “Memory Stick” media Reader/Writer support “Memory Stick PRO

Duo” media. Users of computers and “Memory Stick” media Readers/Writers made by manufacturers

other than Sony should contact those manufacturers.

• If “Memory Stick PRO Duo” media is not supported, connect the camera to the computer (pages 106,

107). The computer recognizes the “Memory Stick PRO Duo” media.

Your computer does not recognize the camera.

• When the battery level is low, insert the charged battery pack or use the AC adaptor (sold separately).

• Set [USB Connect] to [Auto] or [Mass Storage] (page 87).

• Use the cable for multi-use terminal (supplied).

• Disconnect the cable for multi-use terminal from both the computer and the camera, and connect it

again firmly.

• Disconnect all equipment other than the camera, the keyboard and the mouse from the USB

connectors of your computer.

• Connect the camera directly to your computer without passing through a USB hub or other device.

Cannot import images.

• Connect the camera and your computer correctly making a USB connection (page 106).

• When you shoot images with a memory card formatted by a computer, you may not be able to import

the images to a computer. Shoot using a memory card formatted by the camera (page 92).

After making a USB connection, “PMB” does not start automatically.

• Make the USB connection after the computer is turned on.

Deleting

Computers

Table of

contents

Operation

MENU/Settings

Index

117

After making a USB connection, “PMB Portable” does not start.

• Set [LUN Settings] to [Multi].

• Set [USB Connect] to [Auto] or [Mass Storage].

• Connect the computer to the network.

Cannot play back images on your computer.

• If you are using “PMB”, refer to “PMB Help” (page 104).

• Consult the computer or software manufacturer.

The image and sound are interrupted by noise when you view a movie on a

computer.

• You are playing back the movie directly from the internal memory or the memory card. Import the

images to your computer using “PMB” and play it back (page 104, 106).

Images once exported to a computer cannot be viewed on the camera.

• Use “PMB” to play images stored on a PC with this camera.

• Register the image to the image database file, then play back in [Date View] (page 66).

• Event View is not available on this camera.

Cannot insert a memory card.

• Insert the memory card in the correct direction.

You have formatted a memory card by mistake.

• All the data on the memory card is deleted by formatting. You cannot restore it.

Images are recorded on the internal memory even when a memory card is

inserted into the camera.

• Make sure that the memory card is fully inserted into the camera.

Cannot play back or record images using the internal memory.

• There is a memory card inserted in the camera. Remove it.

Cannot copy the data stored in the internal memory to a memory card.

• The memory card is full. Copy to a memory card with sufficient capacity.

Cannot copy the data on the memory card or the computer to the internal

memory.

• This feature is not available.

Memory card

Internal memory

Table of

contents

Operation

MENU/Settings

Index

118

See “PictBridge-compliant printer” together with the following items.

Cannot print an image.

• Refer to the operation manual of the printer.

Images are printed with both edges cut off.

• Depending on your printer, all the edges of the image may be cut off. Especially when you print an

image shot with the image size set to [16:9], the lateral end of the image may be cut off.

• When printing images using your printer, cancel the trimming or borderless settings. Consult the

printer manufacturer as to whether the printer provides these functions or not.

• When having images printed at a digital print shop, ask the shop whether they can print the images

without cutting off both edges.

Cannot print images with the date.

• Using “PMB”, you can print images with date (page 104).

• The camera does not have a feature for superimposing dates on images. However, because the images

shot with the camera include information on the recording date, you can print images with the date

superimposed if the printer or the software can recognize Exif information. For compatibility with

Exif information, consult the manufacturer of the printer or the software.

• If you use a photo printing service, ask them to superimpose the dates on images.

A connection cannot be established.

• The camera cannot be connected directly to a printer that is not compliant with the PictBridge

standard. Consult the printer manufacturer as to whether the printer is compliant with PictBridge or

not.

• Check that the printer is turned on and can be connected to the camera.

• Set [USB Connect] to [PictBridge] (page 87).

• Disconnect and connect the cable for multi-use terminal again. If an error message is indicated on the

printer, refer to the operating instructions supplied with the printer.

Cannot print images.

• Check that the camera and the printer are properly connected using the cable for multi-use terminal.

• Turn on the printer. For details, refer to the operating instructions supplied with the printer.

• If you select [Exit] during printing, images may not be printed. Disconnect and connect the cable for

multi-use terminal again. If you still cannot print your images, disconnect the cable for multi-use

terminal, turn the printer off and then on, then connect the cable for multi-use terminal again.

• Movies cannot be printed.

• Images shot using other cameras, or images modified with a computer may not be printed.

• Panoramic images may not be printed depending on the printer or may be printed in cut off panoramic

image.

Printing is canceled.

• Confirm you did not disconnect the cable for multi-use terminal while the (PictBridge

Connecting) mark was displayed.

Printing

PictBridge-compliant printer

Table of

contents

Operation

MENU/Settings

Index

119

Cannot insert the date or print images in the index mode.

• The printer does not provide these functions. Consult the printer manufacturer as to whether the

printer provides these functions or not.

• The date may not be inserted in the index mode depending on the printer. Consult the printer

manufacturer.

“---- -- --” is printed on the date-inserted part of the image.

• The image does not have the recording data so the date cannot be inserted. Set [Date] to [Off] and

print the image again (page 110).

Cannot print the image at the size selected.

• When you use paper of a different size after connecting the printer to the camera, disconnect and then

reconnect the cable for multi-use terminal.

• The print setting of the camera differs from that of the printer. Change the setting of either the camera

(page 110) or the printer.

• Consult the printer manufacturer as to whether the printer can provide the desired size.

Cannot operate the camera after cancelling printing.

• Wait for a while as the printer is carrying out the cancellation. It may take some time depending on

the printer.

The lens gets fogged.

• Moisture condensation has occurred. Turn off the camera and leave it for about an hour before using

it.

The camera turns off with the lens portion extended.

• The battery pack is discharged. Replace it with a charged battery pack, then turn the camera on again.

• Do not attempt to force the lens that has stopped moving.

The camera becomes warm when you use it for a long time.

• This is not a malfunction.

The Clock Set screen appears when you turn on the camera.

• Set the date and time again (page 99).

• The internal rechargeable backup battery has discharged. Insert a charged battery, and set aside for

24 hours or more with the power left off.

The date or time is incorrect.

• The Area Setting is set to a different location than your current location. Change the setting by

MENU t (Settings) t [Clock Settings] t [Area Setting].

Others

Table of

contents

Operation

MENU/Settings

Index

120

Warning indicators and

messages

If a code starting with a letter of the alphabet appears, the self-diagnosis function on the camera

is working. The last two digits (indicated by

ss) will differ depending on the state of the

camera.

If you cannot solve the problem even after trying the following corrective actions a few times,

the camera may need repair.

Contact your Sony dealer or local authorized Sony service facility.

C:32:ss

• There is trouble with the camera’s hardware. Turn the power off and on again.

C:13:ss

• The camera cannot read or write data on the memory card. Try turning off and on the camera again, or

taking out and inserting the memory card several times.

• The internal memory has experienced a format error, or an unformatted memory card is inserted.

Format the internal memory or the memory card (page 92).

• The inserted memory card cannot be used with the camera, or the data is damaged. Insert a new

memory card.

E:61:ss

E:62:ss

E:91:ss

• A camera malfunction has occurred. Initialize the camera (page 84), then turn the power on again.

E:94:ss

• A malfunction that you cannot service has occurred. Contact your Sony dealer or local authorized

Sony service facility. Inform them of the 5-digit code, which starts from “E”.

If the following messages appear, follow the instructions.

• The battery level is low. Charge the battery pack immediately. Depending on the conditions of use or

the type of battery pack, the indicator may flash even though there are still 5 to 10 minutes of

remaining battery time left.

For use with compatible battery only

• The battery inserted is not an NP-BG1 (supplied) or NP-FG1 (sold separately) battery pack.

System error

• Turn the power off and then on again.

Self-diagnosis display

Messages

Table of

contents

Operation

MENU/Settings

Index

121

Camera overheating

Allow it to cool

• The camera temperature has risen. The power may turn off automatically, or you may be unable to

record movies. Leave the camera in a cool location until the temperature goes down.

Internal memory error

• Turn the power off and then on again.

Reinsert the memory card

• The inserted memory card cannot be used in the camera (page 3).

• The terminal section of the memory card is dirty.

• The memory card is damaged.

Memory card type error

• The inserted memory card cannot be used in the camera (page 3).

This memory card may not record or play

• The inserted memory card cannot be used in the camera (page 3).

Error formatting internal memory

Error formatting memory card

• Format the media again (page 92).

Memory card locked

• You are using the memory card with the write-protect switch, and the switch is set to the LOCK

position. Set the switch to the recording position.

Read only memory card

• The camera cannot record or delete images on this memory card.

No images

• No images that can be played back have been recorded in the internal memory.

• No images that can be played back have been recorded in this folder of the memory card.

No still images

• The selected folder or date does not contain a file that can be played back in a slideshow.

File found which was not recognized

• You tried to delete a folder containing a file that cannot be played on this camera. Delete the file with

a computer and then delete the folder.

Folder error

• A folder with the same first three digit number already exists on the memory card (for example:

123MSDCF and 123ABCDE). Select another folder, or create a new folder (pages 93, 94).

Table of

contents

Operation

MENU/Settings

Index

122

Cannot create more folders

• The folder with a name beginning with “999” exists on the memory card. You cannot create any

folders if this is the case.

Empty folder contents

• You tried to delete a folder containing one or more files. Delete all of the files and then delete the

folder.

Folder protected

• You tried to delete a folder that was made read-only by PC or an other device.

File error

• An error occurred while the image was playing back.

No guarantees are made for playing back, on this camera, files containing images which were

processed on a computer or images which were shot using other cameras.

Read only folder

• You have selected a folder that cannot be set as a recording folder on the camera. Select another

folder (page 94).

File protected

• Release the protection (page 69).

Image size over limit

• You are playing back an image with size that cannot be played back on the camera.

Unable to detect face for retouch

• You may not be able to retouch the image depending on the image.

(Vibration warning indicator)

• Camera shake may occur due to insufficient light. Use the flash, or mount the camera on a tripod to

secure the camera.

1280×720 (Fine) is not supported with this memory card

1280×720 (Standard) is not supported with this memory card

• For recording movies, it is recommended that you use a memory card of 1 GB or larger.

Turn the power off and on again

• The lens malfunction.

Maximum number of images already selected

• Up to 100 files can be selected when using [Multiple Images].

• You can add (Print order) marks to up to 999 files. Cancel the selection.

• The data transmission to the printer may not be completed yet. Do not disconnect the cable for multi-

use terminal.

Table of

contents

Operation

MENU/Settings

Index

123

Processing...

• The printer is canceling the current print job. You cannot print until it is finished. This may take time,

depending on the printer.

Error Playing Music

• Delete the Music file, or replace it with an uncorrupted Music file.

• Execute [Format Music], then download new Music files.

Error Formatting Music

• Execute [Format Music].

Operation cannot be executed in unsupported files

• Processing and other editing functions of the camera cannot be performed on image files that have

been processed using a computer or images that were recorded with other cameras.

Preparing Image Database File

• The camera restores the date information etc. in cases where images have been deleted on a PC, etc.

• The camera creates the necessary database files after the memory card is formatted.

• The number of images exceeds that for which date management in a database file by the camera is

possible. To register new image files to the database file, delete unnecessary images from [Date

View].

No internal memory space remaining

Delete images?

• The internal memory is full. To record to the internal memory, select [Yes] and delete unwanted

images.

• Unable to register to the database file or play back in [Date View]. Import all the images to a

computer using “PMB” and recover the memory card or internal memory.

Image Database File error

Cannot recover

• Import all of the images to the computer with “PMB”, and format the memory card or the internal

memory (page 92).

When you cannot import all of the images to the computer with “PMB”, import all of the images to

the computer without using “PMB” (page 106).

To view the images again with the camera, export the imported images to the camera with “PMB”.

Recording function unavailable due to high internal temperature

• The camera temperature has risen. You cannot record images until the temperature has dropped.

Recording has stopped due to increased camera temperature

• Recording has stopped due to a rise in temperature while recording a movie. Please wait until the

temperature goes down.

Table of

contents

Operation

MENU/Settings

Index

124

• When you record movies for a long time, the camera temperature rises. In this case, stop recording

movies.

Table of

contents

Operation

MENU/Settings

Index

125

“Memory Stick Duo” media

A “Memory Stick Duo” media is a compact, portable IC recording medium. The types of

“Memory Stick Duo” media that can be used with the camera are listed in the table below.

However, proper operation cannot be guaranteed for all “Memory Stick Duo” media functions.

High-speed data transfer using a parallel interface is not supported.

“Memory Stick Duo” media, “MagicGate Memory Stick Duo” media and “Memory Stick PRO Duo”

media are equipped with MagicGate functions. MagicGate is copyright protection technology that uses

encryption technology. Data recording/playback that requires MagicGate functions cannot be performed

with the camera.

[1280×720] movies cannot be recorded to internal memory or a “Memory Stick” media other than a

“Memory Stick PRO Duo” media, “Memory Stick PRO-HG Duo” media.

This camera does not support 8-bit parallel data transfer. It performs the same 4-bit parallel data transfer

as the “Memory Stick PRO Duo” media.

• This product is compatible with “Memory Stick Micro” media (“M2”). “M2” is an abbreviation for

“Memory Stick Micro” media.

• A “Memory Stick Duo” media formatted with a computer is not guaranteed to operate with the camera.

• Data read/write speeds differ depending on the combination of the “Memory Stick Duo” media and the

equipment used.

• Do not remove the “Memory Stick Duo” media while reading or writing data.

• Data may be corrupted in the following cases:

– When the “Memory Stick Duo” media is removed or the camera is turned off during a read or write

operation

– When the “Memory Stick Duo” media is used in locations subject to static electricity or electrical noise

• We recommend backing up important data.

• Do not attach a label on the “Memory Stick Duo” media itself nor on a “Memory Stick Duo” media

Adaptor.

• Do not touch the terminal section of the “Memory Stick Duo” media with your hand or a metal object.

• Do not strike, bend or drop the “Memory Stick Duo” media.

• Do not disassemble or modify the “Memory Stick Duo” media.

• Do not expose the “Memory Stick Duo” media to water.

• Do not leave the “Memory Stick Duo” media within the reach of small children. They might accidentally

swallow it.

• Do not insert anything other than a “Memory Stick Duo” media into the “Memory Stick Duo” media slot.

Doing so will cause a malfunction.

• Do not use or store the “Memory Stick Duo” media under the following conditions:

– High temperature locations such as the hot interior of a car parked in direct sunlight

– Locations exposed to direct sunlight

– Humid locations or locations with corrosive substances present

“Memory Stick” media type Recording/Playback

Memory Stick Duo (without MagicGate) a*

Memory Stick Duo (with MagicGate) a*

MagicGate Memory Stick Duo a*

Memory Stick PRO Duo a*

Memory Stick PRO-HG Duo a*

Notes

Continued r

Table of

contents

Operation

MENU/Settings

Index

126

Notes on using the “Memory Stick Duo” media Adaptor (sold

separately)

• To use a “Memory Stick Duo” media with a “Memory Stick” media compliant device, be sure to insert

the “Memory Stick Duo” media into a “Memory Stick Duo” media Adaptor. If you insert a “Memory

Stick Duo” media into a “Memory Stick” media compliant device without a “Memory Stick Duo” media

Adaptor, you might not be able to remove it from the device.

• When inserting a “Memory Stick Duo” media into a “Memory Stick Duo” media Adaptor, make sure the

“Memory Stick Duo” media is inserted facing in the correct direction, then insert it all the way in.

Incorrect insertion may result in a malfunction.

• When using a “Memory Stick Duo” media inserted into a “Memory Stick Duo” media Adaptor with a

“Memory Stick” media compliant device, make sure that the “Memory Stick Duo” media Adaptor is

inserted facing the correct direction. Note that improper use may damage the equipment.

• Do not insert a “Memory Stick Duo” media Adaptor into a “Memory Stick” media compliant device

without a “Memory Stick Duo” media attached. Doing so may result in malfunction of the unit.

Notes on using “Memory Stick Micro” media (sold separately)

• To use a “Memory Stick Micro” media with the camera, be sure to insert the “Memory Stick Micro”

media into an “M2” Adaptor as large as of Duo size. If you insert a “Memory Stick Micro” media into the

camera without an “M2” Adaptor as large as of Duo size, you might not be able to remove it from the

camera.

• Do not leave the “Memory Stick Micro” media within the reach of small children. They might

accidentally swallow it.

Table of

contents

Operation

MENU/Settings

Index

127

Battery pack

On charging the battery pack

• We recommend charging the battery pack in an ambient temperature of between 10 °C to 30 °C (50 °F to

86 °F). The battery pack may not be effectively charged in temperatures outside this range.

Effective use of the battery pack

• Battery performance decreases in low temperature surroundings. So in cold places, the operational time

of the battery pack is shorter. We recommend the following to ensure longer battery pack use:

– Put the battery pack in a pocket close to your body to warm it up, and insert it in the camera

immediately before you start shooting.

• The battery pack will run out quickly if you use the flash or zoom frequently.

• We recommend having spare battery packs handy for two or three times the expected shooting time, and

making trial shots before taking the actual shots.

• Do not expose the battery pack to water. The battery pack is not water-resistant.

• Do not leave the battery pack in extremely hot places, such as in a car or under direct sunlight.

• You may not be able to turn on the camera or the battery pack may not be effectively charged if the

terminal section of the battery is dirty. In this case, wipe any dust with a soft cloth lightly to clean the

battery.

How to store the battery pack

• Fully discharge the battery pack before storing and store it in a cool, dry place. To maintain the battery

pack’s function, fully charge the battery pack and then fully discharge it on the camera at least once a

year while storing.

• To use the battery pack up, leave the camera in slideshow playback mode until the power goes off.

• To prevent staining the terminal, short-circuiting, etc., be sure to use a supplied battery case when

carrying or storing.

On battery life

• The battery life is limited. Battery capacity decreases over time and through repeated use. If decreased

usage time between charges becomes significant, it is probably time to replace it with a new one.

• The battery life varies according to how it is stored and the operating conditions and environment in

which each battery pack is used.

Compatible battery pack

• The NP-BG1 (supplied) can be used only in G type compatible Cyber-shot models.

• If you use the NP-FG1 battery pack (sold separately), the minutes also appear after the battery remaining

indicator ( 60 Min).

Table of

contents

Operation

MENU/Settings

Index

128

Battery charger

• NP-BG type, NP-FG type battery packs (and no others) can be charged in the battery charger (supplied).

Batteries other than the specified kind may leak, overheat, or explode if you attempt to charge them,

posing a risk of injury from electrocution and burns.

• Remove the charged battery pack from the battery charger. If you leave the charged battery pack in the

charger, battery life may be shortened.

• The CHARGE lamp of the supplied battery charger flashes in either way:

– Fast flashing: Turns the light on and off repeatedly at the interval of 0.15 seconds.

– Slow flashing: Turns the light on and off repeatedly at the interval of 1.5 seconds.

• When the CHARGE lamp flashes fast, remove the battery pack being charged, and then insert the same

battery pack into the battery charger securely again. When the CHARGE lamp flashes fast again, this

may indicate a battery error or that a battery pack other than the specified type has been inserted. Check

that the battery pack is the specified type. If the battery pack is the specified type, remove the battery

pack, replace it with a new one or another one and check if the battery charger operates correctly. If the

battery charger operates correctly, a battery error may have occurred.

• When the CHARGE lamp flashes slowly, it indicates that the battery charger stops charging temporarily

on standby. The battery charger stops charging and enters the standby status automatically when the

temperature is outside of the recommended operating temperature. When the temperature gets back

within the appropriate range, the battery charger resumes charging and the CHARGE lamp lights up

again. We recommend charging the battery pack in an ambient temperature of between 10 °C to 30 °C

(50 °F to 86 °F).

Table of

contents

Operation

MENU/Settings

Index

129

Index

Advanced Sports Shooting...........................................26

AF Illuminator ...................................................................73

AF range finder frame ....................................................52

Area Setting ........................................................................98

Auto Orientation ...............................................................77

Battery charger ................................................................128

Battery pack ......................................................................127

Beach .....................................................................................26

Beep........................................................................................80

Blink Alert...........................................................................79

Bracket Settings ................................................................46

Burst Settings .....................................................................45

Calendar................................................................................66

CD-ROM............................................................................104

Center AF.............................................................................52

Center-weighted metering ............................................54

Change REC.Folder.........................................................94

Clock Settings....................................................................99

COMPONENT ..................................................................85

Computer............................................................................103

Importing images.............................................106, 107

Connecting

Computer ....................................................................106

Printer...........................................................................110

TV ..................................................................................100

Continuous Playback ......................................................63

Control button ....................................................................14

Copy .......................................................................................96

Create REC.Folder...........................................................93

Date & Time Setting .......................................................99

Delete...............................................................................38, 68

Delete REC.Folder...........................................................95

Demo Mode ........................................................................83

Digital Zoom ......................................................................76

DISP .......................................................................................30

Disp. Resolution................................................................75

Download Music...............................................................89

DPOF .....................................................................................70

DRO .......................................................................................60

Easy Shooting ....................................................................20

Easy Viewing .....................................................................21

EV ...........................................................................................47

Exposure...............................................................................47

Face Detection ...................................................................58

File Number........................................................................97

Fireworks .............................................................................27

Flash.......................................................................................32

Focus......................................................................................52

Folder

Changing .......................................................................94

Creating .........................................................................93

Deleting .........................................................................95

Selecting........................................................................72

Format ...................................................................................92

Format Music .....................................................................90

Function Guide ..................................................................82

Gourmet ................................................................................26

Grid Line ..............................................................................74

HD(1080i)............................................................................85

High Sensitivity.................................................................26

Identifying parts ................................................................14

Image Index ........................................................................37

Image Size ...........................................................................41

Initialize................................................................................84

Install ...................................................................................104

Intelligent Auto Adjustment ........................................19

Internal memory................................................................18

ISO..........................................................................................48

Table of

contents

Operation

MENU/Settings

Index

130

Landscape ............................................................................26

Language Setting ..............................................................81

LUN Settings......................................................................88

Macintosh computer......................................................103

Manual Exposure Shooting ..........................................23

Mass Storage ......................................................................87

Memory card ........................................................................3

“Memory Stick Duo” media......................................125

MENU...................................................................................10

Metering Mode ..................................................................54

Mode dial .............................................................................17

Movie Mode........................................................................28

MTP........................................................................................87

Multi AF...............................................................................52

Multi connector ...............................................100, 106, 110

Multi-pattern metering ...................................................54

Music Transfer.........................................................104, 105

NTSC .............................................................................86, 102

Optical zoom ................................................................29, 76

OS..........................................................................................103

PAL.................................................................................86, 102

PC..........................................................................................103

Pet............................................................................................26

PictBridge ....................................................................87, 110

Pixel........................................................................................43

Playback ...............................................................................35

Playback zoom...................................................................36

PMB .....................................................................................104

PMB Portable...................................................................108

Power Save..........................................................................91

Precision digital zoom....................................................76

Print ................................................................................70, 110

Print order mark ........................................................70, 111

Program Auto .....................................................................22

Protect....................................................................................69

PTP .........................................................................................87

Red Eye Correction .........................................................67

Red Eye Reduction ..........................................................78

Retouch .................................................................................67

Rotate.....................................................................................71

Scene Recognition............................................................55

Scene Selection..................................................................26

Screen ....................................................................................30

SD............................................................................................85

Select Folder.......................................................................72

Self-diagnosis display...................................................120

Self-Portrait.........................................................................34

Self-Timer............................................................................34

Settings..................................................................................12

Shooting

Movie..............................................................................28

Still Image ....................................................................19

Shooting Direction...........................................................40

Slideshow.............................................................................63

Slideshow with music.....................................................64

Slow Synchro .....................................................................32

Smart zoom .........................................................................76

Smile Detection Sensitivity..........................................57

Smile Shutter ......................................................................33

Snow.......................................................................................26

Soft Snap..............................................................................26

Software..............................................................................104

Spot AF.................................................................................52

Spot metering .....................................................................54

SteadyShot...........................................................................62

Sweep Panorama...............................................................24

Trimming (Resize)...........................................................67

Troubleshooting ..............................................................112

TV .........................................................................................100

Twilight.................................................................................26

Twilight Portrait................................................................26

Unsharp masking ..............................................................67

USB Connect......................................................................87

Table of

contents

Operation

MENU/Settings

Index

131

VGA .......................................................................................41

Video Out.............................................................................86

View Mode..........................................................................66

Warning indicators and messages ...........................120

White Balance....................................................................50

Windows computer........................................................103

Zoom......................................................................................29

Table of

contents

Operation

MENU/Settings

Index

132

Notes on the License

“C Library”, “Expat”, “zlib”, “dtoa”, “pcre” and “libjpeg” software are provided in the camera.

We provide this software based on license agreements with their owners of copyright. Based on

requests by the owners of copyright of these software applications, we have an obligation to

inform you of the following. Please read the following sections.

Read “license1.pdf” in the “License” folder on the CD-ROM. You will find licenses (in English)

of “C Library”, “Expat”, “zlib”, “dtoa”, “pcre” and “libjpeg” software.

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO

LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR

(i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD

(“MPEG-4 VIDEO”)

AND/OR

(ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED

IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED

FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO.

NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.

ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL,

INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM

MPEG LA, LLC.

SEE

HTTP://WWW.MPEGLA.COM

On GNU GPL/LGPL applied software

The software that is eligible for the following GNU General Public License (hereinafter referred

to as “GPL”) or GNU Lesser General Public License (hereinafter referred to as “LGPL”) are

included in the camera.

This informs you that you have a right to have access to, modify, and redistribute source code for

these software programs under the conditions of the supplied GPL/LGPL.

Source code is provided on the web. Use the following URL to download it.

http://www.sony.net/Products/Linux/

We would prefer you do not contact us about the contents of source code.

Read “license2.pdf” in the “License” folder on the CD-ROM. You will find licenses (in English)

of “GPL”, and “LGPL” software.

To view the PDF, Adobe Reader is needed. If it is not installed on your computer, you can

download it from the Adobe Systems web page:

http://www.adobe.com/

Regarding the license for “Music Transfer” included on the

CD-ROM (supplied)

MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and

Thomson.

Sony DSC-H55 Cybershot Digital Still Camera

Product's Documents

User Manual

Specifications

Sony DSC-H55 Questions and Answers

Related Products

Sony DSC-G3 Cybershot Digital Still Camera

Sony DSC-M1 Cybershot Digital Still Camera

Sony DSC-HX20V Cybershot Digital Still Camera

Sony DSC-T2 Cybershot Digital Still Camera

Sony DSC-P150 Cybershot Digital Still Camera; Silver

Sony DSC-L1 Cybershot Digital Still Camera
