User manual Dryer for GE GFDN110EL0WW

Table of contents

  • Safety Instructions
  • Operating Instructions
  • Control Panels
  • Cycle Options
  • Dryer Features
  • Reversing the Door Swing
  • Loading and Using the Dryer
  • Venting the Dryer
  • Connecting Inlet Hoses
  • Stacking
  • Troubleshooting Tips
  • Consumer Support
  • Warranty
  • Consumer Support

To store a My Cycle combination of settings:

  • Select your drying cycle.
  • Change DRY “Temp”, and SENSOR DRY “Level” settings to fit your needs.
  • Select any drying OPTIONS you want.
  • Press and hold the My Cycle pad for three seconds to store your selection. A beep will sound and the pad light will light up.

Extended Tumble

  • Minimizes wrinkles by adding approximately 60 minutes of no-heat tumbling after clothes are dry. The beeper will sound every two minutes as a reminder to remove the clothes. The ESTIMATED TIME REMAINING display will show 0:00.
  • The extended tumble time does not get added to the cycle time on the display

Delay Dry (on some models)

Use to delay the start of your dryer.

  • Choose your dry cycle and any options.
  • Press Delay Dry. You can increase the delay time in 1 hour increments using the Delay Dry button.
  • Press the Start pad to start the countdown.

Signal

  • Alerts you that the cycle is complete. The beeper will continue to sound every minute for the next 5 minutes, until the clothes have been removed. The clothes should be removed when the beeper goes off so wrinkles don’t set in.
  • Press Signal to select low, medium or high volume, or to turn the beeper off.

Estimated Time Remaining

  • Displays the approximate time remaining until the end of the cycle.
  • As the cycle begins, you will see an initial approximate total cycle time in the display. Then lights will “race” in the display. This means the dryer is continuously monitoring the amount of moisture in the load.
  • The lights will continue until the dryer senses a low level of moisture in the load. At that point, the dryer will calculate and display the approximate time remaining.

Remove Door
