For your safety the information in
this manual must be followed to minimize the risk
of fire or explosion or to prevent property damage,
personal injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquid in the vicinity of this or any other
machine.
- WHAT TO DO IF YOU SMELL GAS
· Do not try to light any machine.
· Do not touch any electrical switch; do not use
any phone in your building.
· Clear the room, building or area of all
occupants.
· Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier's
instructions.
· If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
Contents
SUBJECT PAGE
Pre-Installation Requirements 2
Electrical Requirements 2
Exhaust System Requirements 2-3
Gas Supply Requirements 3
Location of Your Dryer 4
Rough-In Dimensions 5
Unpacking 5
Reversing Door Swing 5
Electrical Installation 6
Grounding Requirements 6
Electrical Connections—3-wire 7
Electrical Connections—4-wire 7
Installation 8
Replacement Parts 8
Lint Blade Retaining Pin Location 8
Printed in U.S.A.
P/N 134206400 (0212)
Installation
Instructions
Gas & Electric
Dryer
Before beginning installation, carefully read these instructions. This will simplify the installation and ensure the dryer
is installed correctly and safely. Leave these instructions near the Dryer after installation for future reference.
NOTE: The electrical service to the Dryer must conform with local codes and ordinances and the latest edition of the
National Electrical Code, ANSI/NFP A 70.
NOTE: The gas service to the Dryer must conform with local codes and ordinances and the latest edition of the
National Fuel Gas Code ANSI Z223.1.
Pub # 31-15540
www.GEAppliances.com
