Window Wall
AIR CONDITIONING RANGE
Australians love
a Kelvinator
For over 90 years, Kelvinator has been delivering reliability and
performance to Australian families. It’s a brand you can trust to get
the job done well and it’s easy to see why. There’s peace of mind in
knowing that with Kelvinator, you will be comfortable for years to come.
Designed for simplicity, longevity and superior performance,
you can simply sit back and enjoy the benefits.
Australians love a Kelvinator
Air conditioning features Choosing the right air conditioner
Go to Kelvinator.com.au/looking-for-an-air-conditioner
It’s important to select the right sized air conditioner for your room in order
to ensure effective and efficient cooling and heating.
1. Total size of room (m
2
)?
m
2
3. Do you have ceiling insulation?
2. Direction the main
window faces?
4. Do you require an air conditioner
that heats and cools or cools only?
Prior to installation selection should be verified by your authorised Kelvinator retailer.
ceiling insulated YES NO
glass area facing north or west south or east north or west south or east
window size large small large small large small large small
model
room size
m
2
room size
m
2
room size
m
2
room size
m
2
room size
m
2
room size
m
2
room size
m
2
room size
m
2
KWH16CMF 10 12 11 14 9 10 10 11
KWH22CRF / KWH22HRF 14 16 15 17 13 14 14 15
KWH27CRF / KWH27HRF 16 18 17 20 15 16 16 17
KWH39CRF / KWH39HRF 22 26 24 28 20 23 22 24
KWH52CRF / KWH52HRF 32 39 35 41 29 34 31 35
KWH60CRF / KWH60HRF 39 46 42 49 35 37 35 42
KWH22HRF, KWH27HRF, KWH39HRF,
KWH52HRF, KWH60HRF
(Heating and cooling)
KWH16CMF
(Cooling only)
Brand
All Kelvinator products go through rigorous
testing to ensure they meet stringent Australian
performance and quality standards.
Compact
The super compact design means that window
wall air conditioners are discreet and unobtrusive
in your home. They are also perfect for cooling
smaller family homes and space-restricted areas.
Fresh air delivery
The fresh air return provides additional
ventilation to your room and can also assist in
humidity control. The easy-to-service dust filter
removes dust and other larger airborne particles
for cleaner air.
Control from the comfort of
your armchair
All models come with a remote control that lets
you conveniently control all functions. Depending
on which model you choose, other great features
include auto air swing left-right to give a natural
feel to air movement, auto restart, climate control,
timer, sleep mode and a 3-speed fan for lower
energy consumption and greater comfort.
(Excluding model KWH16CMF).
Simple, economic and reliable
Because there are no separate indoor and
outdoor units, it’s easier to install a window wall
model. And because it’s a Kelvinator, you know it
is reliable and built to last.
KWH22CRF, KWH27CRF ,KWH39CRF,
KWH52CRF, KWH60CRF
(Cooling only)
model KWH16CMF KWH22CRF KWH27CRF KWH39CRF KWH52CRF KWH60CRF
capacity cool watts (Btu/h) 1600 2200 2700 3900 5200 6000
current rating (Amps) 10 10 10 10 10 15
dimensions (w x h x d) mm 350 x 450 x 580 375 x 560 x 668 375 x 560 x 668 428 x 660 x 700 428 x 660 x 770 428 x 660 x 770
refrigerant R32 R32 R32 R32 R32 R32
performance
indoor sound pressure (dBA)
high/low setting
49/45 50/46 50/46 50/46 55/51 55/51
outdoor sound pressure (dBA) 56 57 57 60 62 62
outdoor sound power (dBA) 66 67 67 70 72 72
air circulation max (ltr/s) 103 122 122 178 217 239
ambient temperature range (°C) 18 to 46 18 to 46 18 to 46 18 to 46 18 to 46 18 to 46
moisture removal (ltr/hr) 0.5 1.0 1.0 1.5 2.2 2.2
star rating cool 2.0 2.0 2.0 2.0 2.0 2.0
key features
fresh air return/dust filter
P/P P/P P/P P/P P/P P/P
wireless remote control/type N/A
P P P P P
manual operation
P P P P P P
sleep mode
P P P P P
*Will operate outside this range but at less than rated performance.
KWH16CMF
KWH22CRF, KWH27CRF ,KWH39CRF, KWH52CRF, KWH60CRF
KWH22HRF, KWH27HRF, KWH39HRF, KWH52HRF, KWH60HRF
model KWH22HRF KWH27HRF KWH39HRF KWH52HRF KWH60HRF
capacity cool watts (Btu/h) 2200 2700 3900 5200 6000
capacity heat watts (Btu/h) 1900 2450 3600 4800 5520
current rating (Amps) 10 10 10 10 15
dimensions (w x h x d) mm 375 x 560 x 668 375 x 560 x 668 428 x 660 x 700 428 x 660 x 770 428 x 660 x 770
refrigerant R32 R32 R32 R32 R32
performance
indoor sound pressure (dBA)
high/low setting
50/46 50/46 50/46 55/51 55/51
outdoor sound pressure (dBA) 57 57 60 62 62
outdoor sound power (dBA) 67 67 70 73 74
air circulation max (ltr/s) 122 122 183 217 244
ambient temperature range cooling (°C) 18 to 46 18 to 46 18 to 46 18 to 46 18 to 46
ambient temperature range heating (°C) -7 to 30 -7 to 30 -7 to 30 -7 to 30 -7 to 30
moisture removal (ltr/hr) 1.0 1.0 1.5 2.2 2.2
star rating cool/heat 2.0 / 2.0 2.0 / 2.0 2.0 / 2.0 2.0 / 2.0 2.0 / 2.0
key features
fresh air return/dust filter
P/P P/P P/P P/P P/P
wireless remote control/type
P P P P P
manual operation
P P P P P
sleep mode
P P P P P
*Will operate outside this range but at less than rated performance.
Please note: In accordance with the Electrolux warranty, Electrolux is not liable if the appliance is damaged by incomplete or improper installation.
For further information on our Kelvinator air conditioning range, or to obtain dimension and installation requirements please call 13 13 49 or visit kelvinator.com.au
Window wall
Cooling only specifications
Window wall
Reverse cycle specifications
