Installation instructions
For flush installation of a frameless hob
with cement set and sealing strips
J004133-R12
12/06/2018
J004133-R12
1
Validity
These installation instructions apply to the following models:
005, 008, 009, 027, 028, 031, 032, 039–041, 226, 307, 527, 533, 878, 973–979, 84A, 87A–91A, 94A–97A, 31001–31200
Accessories
Designation Article no.
Instant adhesive for installation of the steel angle (50 ml) B11657
Straight mixing nozzle, 10x B11656
TREMCLEAN isopropyl alcohol (1000 ml) 1056609
Black silicone FA880 (310 ml) B11555
Anthracite silicone FA880 (310 ml) B11556
White silicone FA880 (310 ml) 1031313
Stone grey silicone FA880 (310 ml) 1031314
Marble smoothing agent AA320 (1000 ml) B11557
Fugenboy set (silicone finishing tool set) B75158
In case of doubt as to the suitability of cement set materials, especially when using them for the first time, we recommend that
you carry out adhesion trials on test pieces or at non-visible locations.
Sealing strip set included with the hob
Art. no. Characteristics Thickness × width Length per roll
H63283 Sealing strip, open-cell (soft) 5mm × 8mm 2.75m
Spacer set (H60330) 0.5/1.0/2.0 × 7mm –
