3-072-475-11(2)
2002 Sony Corporation
DVP-F41MS
CD/DVD Player
Operating Instructions
2
WARNING
To prevent fire or shock
hazard, do not expose
the unit to rain or
moisture.
To avoid electrical
shock, do not open the
cabinet. Refer servicing
to qualified personnel
only.
CAUTION
The use of optical instruments with
this product will increase eye hazard.
As the laser beam used in this CD/
DVD player is harmful to eyes, do
not attempt to disassemble the
cabinet.
Refer servicing to qualified
personnel only.
The following caution label is
located on the laser protective
housing inside the enclosure.
This symbol is
intended to alert the
user to the presence
of uninsulated
“dangerous
voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
This symbol is
intended to alert the
user to the presence
of important
operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK
MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
For customers in the U.S.A.
Owner’s Record
The model and serial numbers are
located at the bottom of the unit.
Record the serial number in the space
provided below. Refer to them
whenever you call upon your Sony
dealer regarding this product.
Model No. DVP-F41MS
Serial No.______________
CAUTION
You are cautioned that any change or
modifications not expressly
approved in this manual could void
your authority to operate this
equipment.
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to
Part 15 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed
and used in accordance with the
instructions, may cause harmful
interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the user is encouraged to try to
correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an out-
let on a circuit different from that to
which the receiver is connected.
– Consult the dealer or an experi-
enced radio/TV technician for
help.
Welcome!
Thank you for purchasing this Sony
CD/DVD Player. Before operating this
player, please read this manual
thoroughly and retain it for future
reference.
3
Precautions
On safety
• Caution – The use of optical instruments
with this product will increase eye hazard.
• Should any solid object or liquid fall into
the cabinet, unplug the player and have it
checked by qualified personnel before
operating it any further.
• Do not put any foreign objects in the DC IN
10.5 V (external power input) jack.
On power sources
• Use only the supplied AC power adaptor.
Do not use any other AC power adaptor. It
may cause a malfunction.
• If the AC power adaptor causes interference
to the radio or television reception, move it
away from the radio or television.
• Do not touch the AC power adaptor with
wet hands.
• The player is not disconnected from the AC
power source as long as it is connected to
the wall outlet, even if the player itself has
been turned off.
• If you are not going to use the player for a
long time, be sure to disconnect the player
from the wall outlet. To disconnect the AC
power cord, grasp the plug itself; never pull
the cord.
• Should the AC power cord need to be
changed, have it done at a qualified service
shop only.
• Use a commercially available AC plug
adaptor, if necessary, depending on the
design of the wall outlet.
On placement
• Place the player in a location with adequate
ventilation to prevent heat build-up in the
player.
• Do not place the player and the AC power
adaptor on a soft surface such as a rug.
• Do not place the player and the AC power
adaptor in a location near heat sources, or in
a place subject to direct sunlight, excessive
dust, or mechanical shock.
• Do not put any object on top of the player.
The player may be damaged.
On operation
• If the player is brought directly from a cold
to a warm location, or is placed in a very
damp room, moisture may condense on the
lenses inside the player. Should this occur,
the player may not operate properly. In this
case, remove the disc and leave the player
turned on for about half an hour until the
moisture evaporates.
• Do not insert a disc with non-standard
shape (e.g., card, heart) into the player. The
disc may not be ejected and cause a
malfunction.
• When you move the player, take out any
discs. If you don’t, the disc may be
damaged.
On adjusting volume
Do not turn up the volume while listening to
a section with very low level inputs or no
audio signals. If you do, the speakers may be
damaged when a peak level section is played.
On “Memory Stick”
• Do not insert any foreign object such as
metal into the “Memory Stick” slot. It may
cause a malfunction.
Polarity of the plug
Wall outlet
AC plug adaptor
AC-F21
continued
,
4
• When you remove the “Memory Stick,” do
not pull it forcibly. Remove the “Memory
Stick” as described on page 72.
On cleaning
Clean the cabinet, panel, and controls with a
soft cloth slightly moistened with a mild
detergent solution. Do not use any type of
abrasive pad, scouring powder or solvent
such as alcohol or benzine.
On cleaning discs
Do not use a commercially available cleaning
disc. It may cause a malfunction
If you have any questions or problems
concerning your player, please consult your
nearest Sony dealer.
IMPORTANT NOTICE
Caution: This player is capable of holding a
still video image or on-screen display
image on your television screen
indefinitely. If you leave the still video
image or on-screen display image displayed
on your TV for an extended period of time
you risk permanent damage to your
television screen. Projection televisions are
especially susceptible to this.
5
Table of Contents
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Welcome! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
This Player Can Play the Following Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Notes about the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Index to Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Guide to the Control Menu Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Quick Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 1: Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 2: Inserting Batteries into the Remote . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 3: TV Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Step 4: Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Hooking Up the Player. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Step 1: Connecting the Video Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Step 2: Connecting the Audio Cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Step 3: Attaching the Jack Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Step 4: Connecting the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Step 5: Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Playing Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Resuming Playback from the Point Where You Stopped the Disc
(Resume Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using the DVD’s Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Selecting “ORIGINAL” or “PLAY LIST” on a DVD-RW Disc . . . . . . . . . . . . . 41
Playing VIDEO CDs with PBC Functions (PBC Playback) . . . . . . . . . . . . . . 42
Various Play Mode Functions (Program Play, Shuffle Play, Repeat Play,
A-B Repeat Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Searching for a Scene . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Searching for a Particular Point on a Disc or a “MG Memory Stick”
(Scan, Slow-motion Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Searching for a Title/Chapter/Track/Index/Scene, etc. (Search mode) . . . . . 50
Viewing Information About the Disc . . . . . . . . . . . . . . . . . . . . . . 52
Viewing the Playing Time and Remaining Time on the Front Panel Display . 52
6
Checking the Playing Time and Remaining Time . . . . . . . . . . . . . . . . . . . . . .54
Checking the Play Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Sound Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Changing the Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
TV Virtual Surround Settings (TVS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Enjoying Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Changing the Angles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Displaying the Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Adjusting the Picture Quality (BNR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Playing a DATA-CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
About MP3 Audio Tracks and JPEG Image Files . . . . . . . . . . . . . . . . . . . . . . .65
Playing an MP3 Audio Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Viewing a JPEG Image File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Playing a “Memory Stick” . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
About the “Memory Stick” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Playing an ATRAC3 Audio Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Viewing a JPEG Image File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Using Various Additional Functions . . . . . . . . . . . . . . . . . . . . . .78
Locking Discs (Custom Parental Control, Parental Control). . . . . . . . . . . . . . .78
Operation Sound Effects (Sound Feedback) . . . . . . . . . . . . . . . . . . . . . . . . . .82
Controlling Your TV, etc. with the Supplied Remote . . . . . . . . . . . . . . . . . . . .83
Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Using the Setup Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Setting the Display or Sound Track Language (LANGUAGE SETUP) . . . . . .86
Settings for the Display (SCREEN SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Custom Settings (CUSTOM SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Settings for the Sound (AUDIO SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Self-diagnosis Function (When letters/numbers appear in the display) . . . . . .96
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Language Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
List of Setup Display Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
7
About this Manual
• Instructions in this manual describe the
controls on the remote. You can also use the
controls on the player if they have the same
or similar names as those on the remote.
• The icons used in this manual are described
below:
The following terms will be used to explain common
features in similar media.
– “DVD” for DVD VIDEOs, DVD-Rs and DVD-
RWs (Video mode/VR mode)
– “Memory Stick” for both “Memory Stick” and
“MG Memory Stick”
* Audio compression standard defined by ISO
(International Organization for Standardization)/
MPEG
**Adaptive Transform Acoustic Coding 3: Audio
compression technology
US and foreign patents licensed from Dolby
Laboratories.
This Player Can Play the
Following Discs
“DVD VIDEO” and “DVD-RW” are trademarks.
Region code
Your player has a region code printed on the
back of the unit and will only play DVDs
labeled with identical region codes.
DVDs labeled will also play on this
player.
If you try to play any other DVD, the
message “Playback prohibited by area
limitations.” will appear on the TV screen.
Depending on the DVD, no region code
indication may be labeled even though
playing the DVD is prohibited by area
restrictions.
Icon Meaning
Functions available for DVD
VIDEOs or DVD-Rs/DVD-
RWs in Video mode
Functions available for DVD-
RWs in VR (Video Recording)
mode
Functions available for VIDEO
CDs or CD-Rs/CD-RWs
Functions available for music
CDs or CD-Rs/CD-RWs
Functions available for MP3*
audio tracks or JPEG image
files on CD-ROMs/CD-Rs/
CD-RWs
Functions available for JPEG
image files on a “Memory
Stick”
Functions available for
ATRAC3** audio tracks or
JPEG image file on a
“MagicGate (MG) Memory
Stick”
z More convenient features
Format of discs
DVD VIDEO
DVD-RW
VIDEO CD
Music CD
ALL
Region Code
continued
,
8
Example of discs that the player
cannot play
The player cannot play the following discs:
• CD-ROMs/CD-Rs/RWs (except the discs
recorded in the following formats:
–Music CD format
–VIDEO CD format
–MP3 audio tracks and JPEG image files
which conform to ISO9660* level 1/
level 2/Joliet)
• Data part of CD-Extras
• DVD-ROMs
• DVD Audio discs
• HD layer on SACDs
* A logical format of files and folders on CD-ROMs,
defined by ISO (International Organization for
Standardization).
Also, the player cannot play the following
discs:
• A DVD VIDEO with a different region
code (page 98).
• A disc recorded in a color system other than
NTSC, such as PAL or SECAM. (This
player conforms to the NTSC color
system.)
• A disc that has a non-standard shape (e.g.,
card, heart).
• A disc with paper or stickers on it.
• A disc that has the adhesive of cellophane
tape or a sticker still left on it.
Note
On playing DVD-R/DVD-RW/CD-R/CD-RW
Some DVD-Rs, DVD-RWs, CD-Rs or CD-RWs
cannot be played on this player due to the recording
quality or physical condition of the disc, or the
characteristics of the recording device. The disc will
not play if it has not been correctly finalized.
Discs containing one-generation copy controlled
contents recorded with CPRM (Content Protection for
Recordable Media) protection cannot be played on this
player.
For more information, see the operating instructions
for the recording device.
Note that discs created in the Packet Write format also
cannot be played.
Note on playback operations of DVDs
and VIDEO CDs
Some playback operations of DVDs and
VIDEO CDs may be intentionally set by
software producers. Since this player plays
DVDs and VIDEO CDs according to the disc
contents the software producers designed,
some playback features may not be available.
Also, refer to the instructions supplied with
the DVDs or VIDEO CDs.
Copyrights
This product incorporates copyright
protection technology that is protected by
method claims of certain U.S. patents, other
intellectual property rights owned by
Macrovision Corporation, and other rights
owners. Use of this copyright protection
technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only,
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or
disassembly is prohibited.
9
Notes about the Discs
On handling discs
• To keep the disc clean, handle the disc by its
edge. Do not touch the surface.
• Do not expose the disc to direct sunlight or
heat sources such as hot air ducts, or leave
it in a car parked in direct sunlight as the
temperature may rise considerably inside
the car.
• After pressing A on the player to eject the
disc, do no leave the disc as it is. Remove it
completely from the player.
• After playing, store the disc in its case.
• If glue is present on the outer edge of the
disc, wipe the edge of the disc with the side
of a pen or pencil so that the glue is spread
evenly along the edge before inserting the
disc into the player. Be sure not to touch the
playback side of the disc when wiping the
edge.
• If burrs remain on the outer edge of the
disc, remove them by rubbing with the side
of a pen or pencil. If burrs are not removed,
discs may not load properly into the player,
or fragments of plastic adhering to the
playback side of the disc may cause
skipping in the sound.
On cleaning
• Before playing, clean the disc with a
cleaning cloth. Wipe the disc from the
center out.
• Do not use solvents such as benzine,
thinner, commercially available cleaners, or
anti-static spray intended for vinyl LPs.
10
Index to Parts and Controls
For more information, refer to the pages indicated in parentheses.
Front Panel
A MS (“Memory Stick”) button/indicator
(73)
Lights up in:
• orange in MS mode (“Memory Stick”
playback mode)
• yellow while reading the data in the
“Memory Stick”
It goes out in disc (playback) mode.
B MEMORY STICK (“Memory Stick”)
slot (72)
C ./> (previous/next) buttons (39)
D x (stop) button (38)
E X (pause) button (39, 82)
F N (play) button (38)
G Disc slot (38)
H Front panel display (11)
I (remote sensor) (17)
J SURROUND indicator (59)
K A (eject) button (39)
L ?/1 (power) button/indicator (38)
11
Front Panel Display
When playing back a DVD VIDEO/DVD-RW
When playing back a VIDEO CD (PBC)
Lights up when you
can change the angle
Disc type
Playing status
Lights up when BNR is
on (64)
Current play mode (A-B
Repeat Play) (47)
Current audio signal
(DTS format signal) (57)
Current title and chapter
number, playing time, etc. (52)
Current audio signal (Dolby Digital signal) (57)
Current scene number or playing
time (52)
Lights up when playing back a
VIDEO CD with PBC (42)
Playing status
Disc type
Current play mode (A-B Repeat Play) (47)
Lights up when BNR is on (64)
continued
,
12
When playing back a CD/DATA-CD (MP3 audio track)/VIDEO CD (without PBC)/
“MG Memory Stick” (ATRAC3 audio track)
When viewing a JPEG image on a DATA-CD/ “Memory Stick”
Side Panel
A DC IN 10.5 V jack (19)
B AUDIO OUT L/R jacks (19, 25, 26, 28)
C DIGITAL OUT (OPTICAL) jack (26,
28, 30)
D VIDEO OUT jack (19, 22)
E S-VIDEO OUT jack (22)
Playing status
Playing timeCurrent track
Disc type
(does not appear
for “Memory
Stick”)
Lights up when BNR is on
(64)
Current play mode (A-B Repeat Play) (47)
Current track and index
number, playing time, etc. (52)
Playing status
Current file numberCurrent album number
Current album and file number, file name, etc. (52)
Disc type
(does not appear
for “Memory
Stick”)
13
Remote
A MS (“Memory Stick”) button (73, 75)
B BNR (Block Noise Reduction) button
(64)
C TIME/TEXT button (52)
D SURROUND button (59)
E ANGLE button (62)
F AUDIO button (57)
G PROGRAM button (44)
H SHUFFLE button (46)
I REPEAT button (46)
J ./> PREV (previous) /NEXT
buttons (39)
K H PLAY button* (38)
L TOP MENU button (41)
M DISPLAY button (14, 85)
N SEARCH MODE button (50)
O TV/DVD switch (83)
P ?/1 (power) button (38)
Q TV operation buttons (83)
R SUBTITLE button (63)
S CLEAR button (44, 46, 47)
T VOL (volume) +/– buttons* (83)
U A-B button (47)
V REPLAY button (39)
W / SCAN/SLOW buttons (49)
X x STOP button (39)
Y X PAUSE button (39)
Z MENU button (41)(67)(73)
wj C/X/x/c buttons (34)
wk ORETURN button (42)
wl ENTER button (34)
* Use the tactile dot as a reference when operating the
player.
14
Guide to the Control Menu Display
Use the Control Menu to select a function that you would like to use. The Control Menu appears
when the DISPLAY button is pressed. For details, please refer to the page in parentheses.
List of Control Menu Items
OFF
1: ENGLISH
2: FRENCH
3: SPANISH
OFF
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
PLAY
Select: Cancel:
SUBTITLE
ENTER RETURN
Total number of titles, scenes, tracks or albums recorded
Currently playing title
(DVD), scene (VIDEO
CD), track (VIDEO CD/
CD), album (DATA-
CD/ “Memory Stick”)
Currently playing
chapter (DVD), index
(VIDEO CD/CD), track/
file (DATA-CD/
“Memory Stick”)
Playing time
Icon of selected
Control Menu
item
Control Menu
items
Function name of
selected Control
Menu item
Operation message
Total number of chapters,
indexes, tracks or files recorded
Playback status
(
N Playback, X
Pause,
x Stop, etc.)
Options
Current
setting
Type of disc being
played back (“MS” for
“Memory Stick”)
TITLE (page 50)/SCENE (page 50)/
TRACK (page 50)
Selects the title, scene, or track to be played.
CHAPTER (page 50)/INDEX (page
50)
Selects the chapter or index to be played.
TRACK (page 50, 67, 73) Selects the track to be played.
INDEX (page 50) Selects the index to be played.
ALBUM (audio) (page 67)
ALBUM (image) (page 69, 76)
Selects the album to be played.
FILE (page 69, 76) Selects the JPEG image file to be played.
TIME/TEXT (page 50) Checks the elapsed time and the remaining
playback time.
Input the time code for picture and music
searching.
Displays the DVD or CD text.
15
DATE Displays the recorded date, etc. of the current
JPEG image.
ORIGINAL/PLAY LIST (page 41) Selects the type of titles (ORIGINAL or PLAY
LIST) to be played when playing DVD-RW
(VR mode).
AUDIO (page 57) Changes the audio setting.
SUBTITLE (page 63) Displays the subtitles.
Changes the subtitle language.
ANGLE (page 62) Changes the angle.
TVS (TV Virtual Surround) (page 59) Selects the surround functions.
ADVANCED (page 55) Checks the information (bit rate or layer) on
the disc during playback.
PARENTAL CONTROL (page 78) Set to prohibit playback on this player.
SETUP (page 85) QUICK Setup (page 34)
Use Quick Setup to choose the desired
language for the on-screen display, the aspect
ratio of the TV and the audio outputs.
CUSTOM Setup (page 85)
In addition to the Quick Setup setting, you can
adjust other various settings.
RESET
Returns the settings in “SETUP” to the default
setting.
PROGRAM (page 44) Selects the title, chapter, or track to play in the
order you want.
SHUFFLE (page 46) Plays the title, chapter, or track in a random
order.
REPEAT (page 46) Plays the entire disc or “MG Memory Stick”
(all titles/all tracks), or one title/chapter/album/
track repeatedly.
A-B REPEAT (page 47) Specifies the parts you want to play repeatedly.
BNR (page 64) Adjusts the picture quality by reducing the
“block noise” or mosaic like patterns that
appear on your TV screen.
MEMORY STICK (page 73, 75) Selects the data type (ATRAC3 audio track or
JPEG image file) to be played when playing a
“Memory Stick.”
DATA-CD (page 67, 68) Selects the data type (MP3 audio track or JPEG
image file) to be played when playing a DATA-
CD.
continued
,
16
z Each time you press DISPLAY, the Control Menu display changes as follows:
Only Control Menu display 1 appears during CD or “Memory Stick” playback. The Control Menu items differ
depending on the type of the disc or “Memory Stick.”
z The Control Menu icon indicator lights up in green when you select any item except
“OFF” (“TVS,” “PROGRAM,” “SHUFFLE,” “REPEAT,” “A-B REPEAT,” “BNR” only). The “ANGLE” indicator
lights up in green only when the angles can be changed.
Control Menu display 1
m
Control Menu display 2
m
ADVANCED display (Appears if you select any setting other than “OFF.” See page 55.)
m
Control Menu display off
,
t
17
Getting Started
17
Getting Started
Quick Overview
A quick overview presented in this chapter will give you enough information to start using the
player for your enjoyment. To use the surround sound features of this player, refer to “Hookups”
on page 21.
Notes
• You cannot connect this player to a TV that does not have a video input jack.
• Be sure to turn off the power of each component before connecting.
Step 1: Unpacking
Check that you have the following items:
• Audio/video cord (pinplug x 3 y pinplug x 3) (1)
• Remote commander (1)
• Size AA (R6) batteries (2)
• AC power adaptor AC-F21 (1)
• AC power cord (1)
• Jack cover for vertical installation (1)
Step 2: Inserting Batteries into the Remote
You can control the player using the supplied remote. Insert two size AA (R6) batteries by
matching the 3 and # ends on the batteries to the markings inside the compartment. When using
the remote, point it at the remote sensor on the player.
continued
,
18
If you cannot operate the player with the remote
The player has 2 remote sensors, one at the top and one on the front (page 20). If one of the remote
sensor is exposed to direct sunlight or lighting apparatus, the remote may not operate correctly.
If this happens, select a remote sensor in the following way until you find one that works. (If the
MS indicator on the player is lit, turn it off by pressing MS.)
When the power is on and no disc is inserted in the player, press . for more than 2 seconds
while pressing x.
The selected remote sensor is displayed on the front panel display as follows:
* The default setting
Notes
• Do not leave the remote in an extremely hot or humid place.
• Do not drop any foreign object into the remote casing, particularly when replacing the batteries.
• Do not expose the remote sensor to direct light from the sun or lighting apparatus. Doing so may cause a
malfunction.
• If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from
battery leakage and corrosion.
BOTH* (The player
receives the remote
signal at both remote
sensors.)
TOP (The player
receives the remote
signal at the top
remote sensor.)
FRONT (The player
receives the remote
signal at the front
remote sensor.)
t
t
19
Getting Started
19
Step 3: TV Hookups
Remove the jack cover from the player (see fig. A). Connect the supplied audio/video cord and
power cord in the order (1~3) shown below. Be sure to connect the power cord last.
When connecting to a wide screen TV
Depending on the disc, the image may not fit your TV screen.
If you want to change the aspect ratio, please refer to page 87.
3 Power source
1 Audio/video cord
(supplied)
CD/DVD Player
TV
2 Power source
l: Signal flow
to video input
to AUDIO
OUT L
(red)
(white)
(yellow)
to VIDEO
OUT
(red)
(white)
(yellow)
to audio input
(yellow)
(white)
(red)
AC power adaptor
(AC-F21, supplied)
to
AUDIO
OUT R
(white)
(red)
(yellow)
AC power cord
(supplied)
20
Step 4: Playing a Disc
A Turn on the TV.
B Switch the input selector on the TV to the player.
C Press
?/1 on the player.
D Insert the disc into the disc slot with the playback side facing down.
E Press
N.
The player begins playing the disc.
After Step 5
Depending on the disc, a menu may be displayed on the TV screen. If so, select the item you want
from the menu and play the DVD VIDEO (page 41) or VIDEO CD disc (page 42).
To stop playing
Press x.
To take out the disc
Press A on the player, then remove the disc.
To turn off the player
Press ?/1. The player is set to standby mode and the ?/1 indicator lights up in red.
z
To play a DATA-CD, see page 67. You can play also a “Memory Stick” on this player, see page 73.
With the playback side facing down
A
Remote
sensor
Remote
sensor
21
Hookups
Hookups
Hooking Up the Player
Follow Steps 1 to 5 to hook up and adjust the settings of the player.
Before you start, turn off the power, check that you have all of the supplied accessories, and insert
the batteries into the remote (page 17). Remove the jack cover (page 19).
Notes
• Plug cords securely to prevent unwanted noise.
• Refer to the instructions supplied with the components to be connected.
22
Step 1: Connecting the Video Cords
Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord.
Select one of the patterns A or B, according to the input jack on your TV monitor, projector, or
AV amplifier (receiver).
Audio/video cord
(supplied)
S video cord
(not supplied)
CD/DVD player
AC power adaptor
(AC-F21, supplied)
TV, projector, AV
amplifier (receiver)
(yellow)
(yellow)
TV, projector, AV
amplifier (receiver)
(yellow)
l: Signal flow
to VIDEO
OUT
AC power cord
(supplied)
to S-VIDEO
OUT
23
Hookups
A If you are connecting to a video input jack
Connect the yellow plugs of the audio/video cord (supplied) to the yellow (video) jacks. You will
enjoy standard quality images.
Use the red and white plugs to connect to the audio input jacks (page 25).
B If you are connecting to an S VIDEO input jack
Connect the S VIDEO cord (not supplied). You will enjoy high quality images.
Note
Do not connect your player to a VCR. You may not receive a clear image on the TV screen if you pass the player
signals via the VCR.
Yellow (Video)
White (L)
Red (R)
Yellow (Video)
White (L)
Red (R)
VCR
CD/DVD player
TV
Connect directly.
24
Step 2: Connecting the Audio Cords
Refer to the chart below to select the connection that best suits your system. The surround effects
you will enjoy depend on the connections and components you use.
Select a connection
Select one of the following connections, through .
* Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are
trademarks of Dolby Laboratories. Confidential unpublished works. © 1992-1997 Dolby Laboratories. All rights
reserved.
**“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
Connection Components to be connected
(page 25)
TV (stereo)
(page 26)
Stereo amplifier (receiver)
(having L and R audio input jacks only, or having a digital input jack)
•2 speakers
(front L and R)
(page 26)
MD deck/DAT deck
(page 28)
AV amplifier (receiver) with a Dolby* Surround (Pro Logic) decoder
(having L and R audio input jacks only, or having a digital input jack)
•3 speakers
(front L and R, and rear (monaural))
•6 speakers
(front L and R, center, rear L and R, subwoofer)
(page 30)
AV amplifier (receiver) having a Dolby Digital or DTS** decoder, and
a digital input jack
•6 speakers
(front L and R, center, rear L and R, subwoofer)
A
D
A
B
B
C
D
25
Hookups
Connecting to your TV
This connection will use your TV speakers for sound.
xRecommended surround sound effects for this connection.
• TVS DYNAMIC (page 59)
• TVS WIDE (page 59)
The yellow plug is used for video signals (page 22).
A
Audio/video cord
(supplied)
CD/DVD player
TV
(white)
(red)
(yellow)
(white)
(red)
(yellow)
l: Signal flow
to audio input
to AUDIO
OUT L
to
AUDIO
OUT R
AC power cord
(supplied)
AC power adaptor
(AC-F21, supplied)
(white)
(red)
continued
,
26
Connecting to a stereo amplifier (receiver) and 2 speakers/Connecting to an
MD deck or DAT deck
This connection will use your 2 front speakers connected to your stereo amplifier (receiver) for
sound. If the stereo amplifier (receiver) has audio input jacks L and R only, use . If the
amplifier (receiver) has a digital input jack, use . When connecting to an MD deck or a DAT
deck, use . In this case, you can also connect the player directly to the MD deck or DAT
deck without using your stereo amplifier (receiver).
xRecommended surround sound effects for the connection only.
• TVS STANDARD (page 59)
z
In connection , you can use the supplied audio/video cord instead of using a separate audio cord.
z To realize better surround sound effects, make sure that your listening position is in between your speakers.
Notes
• If you select one of the TVS effects while playing a disc, no sound will come from your speakers with the
connection.
• MP3 audio and ATRAC3 audio tracks will not be output from the DIGITAL OUT (OPTICAL) jack.
B
B-1
B-2
B-2
B-1
B-1
B-2
27
Hookups
Stereo amplifier (receiver)
CD/DVD player
Stereo audio cord
(not supplied)
Optical digital cord
(not supplied)
to audio input
to optical digital
input
(white) (red)
(white)
(red)
[Speakers]
Front (L)
Front (R)
MD deck/DAT deck
or
l: Signal flow
to AUDIO
OUT R
to AUDIO
OUT L
to DIGITAL OUT
(OPTICAL)
AC power adaptor
(AC-F21, supplied)
AC power cord
(supplied)
(white)
(red)
continued
,
28
Connecting to a Dolby Surround (Pro Logic) decoder amplifier (receiver) and
3 to 6 speakers
This connection will allow you to enjoy the surround effects of the Dolby Surround (Pro Logic)
decoder on your amplifier (receiver). If you have an AV amplifier (receiver) equipped with a
Dolby Digital or DTS decoder, refer to page 30.
You can enjoy the Dolby Surround effects only when playing Dolby Surround audio or
multichannel audio (Dolby Digital) discs.
Pro Logic uses a minimum of 3 speakers (front L and R, and rear (monaural)). The surround
effects are enhanced if 6 speakers (front L and R, center, rear L and R, and subwoofer) are used.
If your amplifier (receiver) has R and L audio input jacks only, use . If your amplifier
(receiver) has a digital input jack, use .
xRecommended surround sound effects using this connection with your amplifier (receiver).
• Dolby Surround (Pro Logic) (page 91)
z
For correct speaker setting location, please refer to the operating instructions of the amplifier (receiver).
Note
MP3 audio and ATRAC3 audio tracks will not be output from the DIGITAL OUT (OPTICAL) jack.
C
C-1
C-2
29
Hookups
* When connecting 6 speakers, replace the monaural rear speaker with a center speaker, 2 rear speakers and a
subwoofer.
to audio input
CD/DVD player
Optical digital cord
(not supplied)
Stereo audio cord
(not supplied)
to optical digital
input
(white)
(red)
(white)
(red)
Amplifier (receiver) with
Dolby Surround decoder
[Speakers]
[Speakers]
Rear (L)
Rear (R)
Subwoofer
Center
Rear*
(mono)
Front (L)
Front (R)
l: Signal flow
or
to AUDIO
OUT R
to AUDIO
OUT L
to DIGITAL OUT
(OPTICAL)
AC power adaptor
(AC-F21, supplied)
AC power cord
(supplied)
(white)
(red)
continued
,
30
Connecting to an AV amplifier (receiver) with a digital input jack having a
Dolby Digital or DTS decoder, and 6 speakers
This connection will allow you to use the Dolby Digital or DTS decoder function of your AV
amplifier (receiver). You are not able to enjoy the TVS sound effects of the player.
xRecommended surround sound effects using this connection with your amplifier (receiver).
• Dolby Digital (5.1ch) (page 91)
• DTS (5.1ch) (page 91)
z
To enhance the surround sound effects, refer to the operating instructions of the amplifier (receiver) for correct
speaker setting location.
Notes
• After you have completed the connection, be sure to set “DOLBY DIGITAL” in “AUDIO SETUP” to “DOLBY
DIGITAL” (page 34). If your AV amplifier (receiver) has a DTS decoder, set “DTS” in “AUDIO SETUP” to “ON”
(page 34). Otherwise, no sound or a loud noise will come from the speakers.
• MP3 audio and ATRAC3 audio tracks will not be output from the DIGITAL OUT (OPTICAL) jack.
D
31
Hookups
to optical digital input
Optical digital cord (not
supplied)
CD/DVD player
[Speakers]
[Speakers]
AV amplifier (receiver) with a decoder
Front (R)
Front (L) Center
Rear (R)
Rear (L)
Subwoofer
l: Signal flow
to DIGITAL OUT
(OPTICAL)
AC power adaptor
(AC-F21, supplied)
AC power cord
(supplied)
32
Step 3: Attaching the Jack Cover
You can install the player horizontally, vertically or on the wall.
Notes
• Make sure that the connecting cords are not trapped by the jack cover.
• If you use commercially available cords, make sure that those cords are similar to the supplied cords in size. If the
cords are too thick or hard, or the plug is too large, you may not be able to attach the jack cover securely.
When you install the player horizontally
First, gather all the connecting cords together and let them pass through the side of the player.
Then attach the jack cover carefully not to trap the cords.
When you install the player vertically
First, gather all the connecting cords together and let them pass through the side of the player.
Then attach the jack cover for vertical installation (supplied) carefully not to trap the cords.
Notes
• When you place the player in a horizontal position, remove the jack cover for vertical installation.
• To move the player, hold the player itself. If you hold the flat part of the jack cover for vertical installation, it may
break.
• Do not place the player in a vertical position without attaching the jack cover for vertical installation. If you do not
attach it, the player will be unstable and may fall over.
33
Hookups
When you install the player on the wall
Attach the jack cover as in the same way for the horizontal installation.
Fastening screws are not supplied. You need to determine the appropriate hanging screws and/or
other necessary hardware needed to securely and safely fasten the unit to the wall. Placement of
the screws should be at the same height and should be 3 1/4 in. (80 mm) apart. The screws or other
fasteners should protrude by 3/16 to 7/32 in. (4 to 5 mm).
Please be sure you have selected fasteners or screws that will fit in the hanging holes on the
bottom of the unit. Remove the seals covering the hanging holes. Hang the player on the screws.
Push the player tightly against the wall.
Note
WHEN YOU DISCONNECT OR CONNECT THE CORDS, TAKE THE PLAYER DOWN FROM THE WALL.
Step 4: Connecting the Power Cord
Plug the player and TV power cords into an AC outlet.
Do not connect the power cord of your player to the “switched” power socket of an amplifier
(receiver). Otherwise, when you turn off the power of your amplifier (receiver), the settings for
the player may be lost.
3 1/4 in.
3/16 - 7/32 in.
3/16 in.
3/8 in.
34
Step 5: Quick Setup
Follow the steps below to make the minimum number of basic adjustments to use the player. To
skip an adjustment press >, to return to the previous adjustment, press ..
A Turn on the TV.
B Switch the input selector on the TV to the player.
C Press
?/1 on the player or the remote.
“Press [ENTER] to run QUICK SETUP.” appears at the bottom of the screen. If this message
does not appear, select “QUICK” (“QUICK”) under “SETUP” (“SETUP”) in the Control
Menu (page 85) to run Quick Setup.
D Press ENTER without inserting a disc.
The Setup Display for selecting the language used in the on-screen display appears.
E Press X/x to select a language.
The player uses the language selected here to display the menu and subtitles as well.
?/1
./>
X
/x
ENTER
?/1
LANGUAGE SETUP
OSD:
MENU:
AUDIO:
SUBTITLE:
FRENCH
ENGLISH
ENGLISH
SPANISH
PORTUGUESE
35
Hookups
F Press ENTER.
The Setup Display for selecting the aspect ratio of the TV to be connected appears.
G Press X/x to select the item.
H Press ENTER.
The Setup Display for selecting the type of jack used to connect your amplifier (receiver)
appears.
I Press X/x to select the item, then press ENTER.
• When “NO” or “AUDIO OUTPUT L/R” is selected, Quick Setup is finished and connections
are complete.
• When “DIGITAL OUTPUT” is selected, the Setup Display for “DOLBY DIGITAL”
appears. Proceed to Step 0.
TV Type You select Page
4:3 standard TV 4:3 LETTER BOX or 4:3
PAN SCAN
87
A wide-screen TV or 4:3 standard TV with the
wide-screen mode
16:9 87
SCREEN SETUP
TV TYPE:
SCREEN SAVER:
BACKGROUND:
4:3 PAN SCAN
4:3 LETTER BOX
16:9
4:3 LETTER BOX
YES
NO
Is this player connected to an amplifier
(receiver) ? Select the type of jack you
are using.
AUDIO OUTPUT L/R
DIGITAL OUTPUT
continued
,
36
J Press X/x to select the item.
Choose the item that matches the audio connection you selected in pages 26 to 30 (
through ).
K Press ENTER.
“DTS” is selected.
L Press X/x to select the item.
Choose the item that matches the audio connection you selected in pages 26 to 30 (
through ).
M Press ENTER.
Quick Setup is finished. All connections and setup operations are complete.
Note
You can directly start Quick Setup only when you run it for the first time.
To run Quick Setup a second time, select “QUICK” under “SETUP” in the Control Menu (page 85).
Audio Cord Connection Type You select Page
D-PCM 91
DOLBY DIGITAL (only if the
amplifier/receiver has a Dolby Digital
decoder)
91
Audio Cord Connection Type You select Page
OFF 91
ON (only if the amplifier/receiver has
a DTS decoder)
91
B
D
AUDIO SETUP
AUDIO ATT:
AUDIO DRC:
DIGITAL OUT:
DOLBY DIGITAL:
DTS:
OFF
STANDARD
ON
DOWNMIX:
DOLBY SURROUND
DOLBY DIGITAL
D-PCM
D-PCM
B-2 C-2
D
AUDIO SETUP
AUDIO ATT:
AUDIO DRC:
DIGITAL OUT:
DOLBY DIGITAL:
DTS:
OFF
STANDARD
ON
DOWNMIX:
DOLBY SURROUND
D-PCM
OFF
OFF
ON
B
D
B-2
C-2
D
37
Hookups
Enjoying the surround sound effects
To enjoy the surround sound effects of this player or your amplifier (receiver), the following
items must be set as described below for the audio connection you selected in pages 26 to 30
( through ). Each of these are the default settings and do not need to be adjusted when
you first connect the player. Refer to page 85 for using the Setup Display.
Audio Connection (pages 25 to 30)
No additional settings are needed.
• If the sound distorts even when the volume is turned down, set “AUDIO ATT” to “ON” (page
90).
Item You select Page
DOWNMIX DOLBY SURROUND 91
Item You select Page
DOWNMIX DOLBY SURROUND 91
DIGITAL OUT ON 91
B
D
A
B-1
C-1
B-2 C-2
D
38
Playing Discs
Playing Discs
When playing a disc, make sure that the MS
indicator is turned off (Disc mode).
To play a DATA-CD, see page 67.
Depending on the DVD or VIDEO CD, some
operations may be different or restricted.
Refer to the operating instructions supplied
with your disc.
1 Turn on your TV.
2 Switch the input selector on the TV
to the player.
When using an amplifier (receiver)
Turn on the amplifier (receiver) and
select the appropriate channel.
3 Press ?/1.
The ?/1 indicator (red) changes to green
and the front panel display lights up.
4 Insert a disc in the player.
If the MS indicator on the player is lit,
press MS to turn it off in stop mode. (Disc
mode)
5 Press N on the player or H on the
remote.
The player starts playback (continuous
play). Adjust the volume on the TV or the
amplifier (receiver).
After following Step 5
Depending on the disc, a menu may appear
on the TV screen. You can play the disc
interactively by following the instructions on
the menu. DVD (page 41), VIDEO CD (page
42).
To turn off the player
Press ?/1. The player enters standby mode
and the ?/1 indicator lights up in red. To turn
off the player completely, disconnect the AC
power cord. While playing a disc, do not
disconnect the AC power cord. Doing so may
cancel the menu settings. When you turn off
the player, first press x to stop playback and
then press ?/1.
Notes on playing DTS sound tracks on
a CD
• When playing DTS-encoded CDs,
excessive noise will be heard from the
x
?/1 button/indicator
N
H
x
AUDIO
?/1
MS
MS button/indicator
With the playback side
facing down
MS button/
indicator
39
Playing Discs
analog stereo jacks. To avoid possible
damage to the audio system, the consumer
should take proper precautions when the
analog stereo jacks of the player are
connected to an amplification system. To
enjoy DTS Digital Surround™ playback, an
external 5.1-channel decoder system must
be connected to the digital jack of the
player.
• Set the sound to “STEREO” using the
AUDIO button when you play DTS sound
tracks on a CD (page 57).
• Do not play DTS sound tracks without first
connecting the player to an audio
component having a built-in DTS decoder.
The player outputs the DTS signal via the
DIGITAL OUT (OPTICAL) jack even if
“DTS” in “AUDIO SETUP” is set to “OFF”
in the Setup Display (page 92), and may
affect your ears or cause your speakers to be
damaged.
Notes on playing DVDs with a DTS
sound track
• DTS audio signals are output only through
the DIGITAL OUT (OPTICAL) jack.
• If you connect the player to audio
equipment without a DTS decoder, do not
set “DTS” to “ON” in “AUDIO SETUP”
(page 92). A loud noise may come out from
the speakers, affecting your ears or causing
the speakers to be damaged.
• When you play a DVD with DTS sound
tracks, set “DTS” to “ON” in “AUDIO
SETUP” (page 92).
Notes
• When you insert an 8-cm (3-inch) disc, insert the
disc slowly at the center of the disc slot. If you
cannot eject the disc, consult your nearest Sony
dealer.
• No adapter is required in order to play 8-cm (3-inch)
discs on this player. If an adapter is used, damage to
the player may result; therefore, never use an adapter
when playing 8-cm (3-inch) discs.
Additional operations
z The Replay function is useful when you want to
review a scene or dialog that you missed.
Note
You may not be able to use the Replay function with
some scenes.
To Operation
Stop
Press
x
Pause
Press
X
Resume play after
pause
Press
X or H or N
Go to the next chapter,
track, or scene in
continuous play mode
Press
>
Go back to the
preceding chapter,
track, or scene in
continuous play mode
Press
.
Stop play and remove
the disc
Press
A
Replay a previous
scene (DVD only)
Press REPLAY
./>
x
XN
A
./>
H
x
X
REPLAY
40
Resuming Playback from
the Point Where You
Stopped the Disc (Resume
Play)
When you stop the disc, the player
remembers the point where you pressed x
and “RESUME” appears on the front panel
display. As long as you do not remove the
disc, Resume Play works even if the player
enters standby mode by pressing ?/1.
1 While playing a disc, press x to stop
playback.
“RESUME” appears on the front panel
display and you can restart the disc from
the point where you stopped the disc.
If “RESUME” does not appear, Resume
Play is not available.
2 Press H.
The player starts playback from the point
where you stopped the disc in Step 1.
z To play from the beginning of the disc, press x
twice, then press
H.
Notes
• Depending on where you stopped the disc, the player
may not resume playback from exactly the same
point.
• The point where you stopped playing is cleared
when:
– you disconnect the AC power cord.
– you change the play mode.
– you change the settings on the Setup Display.
– you switch to MS mode.
– the player enters standby mode (DATA-CD,
“Memory Stick” and “MG Memory Stick” only)
Hx
41
Playing Discs
Using the DVD’s Menu
A DVD VIDEO is divided into long sections
of a picture or a music feature called “titles.”
When you play a DVD VIDEO which
contains several titles, you can select the title
you want using the TOP MENU button.
When you play DVD VIDEOs that allow you
to select items such as the language for the
subtitles and the language for the sound,
select these items using the MENU button.
1 Press TOP MENU or MENU.
The disc’s menu appears on the TV
screen.
The contents of the menu vary from disc
to disc.
2 Press C/X/x/c to select the item
you want to play or change.
3 Press ENTER.
Selecting “ORIGINAL” or
“PLAY LIST” on a DVD-RW
Disc
Some DVD-RW discs in VR (Video
Recording) mode have two types of titles for
playback: originally recorded titles
(ORIGINAL) and titles that can be created on
recordable DVD players for editing (PLAY
LIST). You can select the type of titles to be
played.
1 Press DISPLAY in stop mode.
The Control Menu appears.
2 Press X/x to select
(ORIGINAL/PLAY LIST), then press
ENTER.
The options for “ORIGINAL/PLAY
LIST” appear.
T
OP MENU
C/X/x/c
ENTER
MENU
DISPLAY
X/x
ENTER
1 8
(
3 4
)
1 2
(
2 7
)
DVD-RW
PLAY LIST
PLAY LIST
ORIGINAL
STOP
continued
,
42
3 Press X/x to select the setting.
• PLAY LIST: plays the titles created
from “ORIGINAL” for editing.
• ORIGINAL: plays the titles originally
recorded.
4 Press ENTER.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
Note
This setting is canceled when you switch the player to
MS mode.
Playing VIDEO CDs with
PBC Functions (PBC Playback)
With PBC (Playback Control) functions, you
can enjoy simple interactive operations,
search functions, and other operations.
PBC playback allows you to play VIDEO
CDs interactively by following the menu on
the TV screen.
1 Start playing a VIDEO CD with PBC
functions.
The menu for your selection appears.
2 Select the item number you want by
pressing X/x.
3 Press ENTER.
4 Follow the instructions in the menu
for interactive operations.
Refer to the instructions supplied with
the disc, as the operating procedure may
differ according to the VIDEO CD.
To go back to the menu
Press ORETURN.
z
To play without using PBC, press ./>
while the player is stopped to select a track, then press
H or ENTER.
./>
X/x
x
O
RETURN
ENTER
H
43
Playing Discs
“Play without PBC.” appears on the TV screen and the
player starts continuous play. You cannot play still
pictures such as a menu.
To return to PBC playback, press
x twice then press
H.
Note
Depending on the VIDEO CD, “Press ENTER” in
Step 3 may appear as “Press SELECT” in the
instructions supplied with the disc. In this case, press
H.
Various Play Mode
Functions (Program Play, Shuffle
Play, Repeat Play, A-B Repeat Play)
You can set the following play modes:
• Program Play (page 44)
• Shuffle Play (page 46)
• Repeat Play (page 46)
• A-B Repeat Play (page 47)
Note
The play mode is canceled when:
– you eject the disc.
– the player enters standby mode by pressing
?/1.
– you press MS.
continued
,
44
Creating your own program (Program
Play)
You can play the contents of the discs in the
order you want by arranging the order of the
titles, chapters, or tracks to create your own
program. You can program up to 99 titles,
chapters, and tracks.
1 Press DISPLAY twice (once for CD).
The Control Menu is displayed.
2 Press X/x to select
(PROGRAM), then press ENTER.
The options for “PROGRAM” appear.
3 Press X/x to select “SETt,” then
press ENTER.
The display for programming appears.
4 Press c.
The cursor moves to the title or track (in
this case, “01”).
5 Select the title, chapter, or track you
want to program.
x When playing a DVD VIDEO
For example, select chapter “03” of title
“02.”
Press X/x to select “02” under “T,” then
press ENTER.
CLEAR
PROGRAM
H
ENTER X/x/c
DISPLAY
REPEAT
SHUFFLE
OFF
OFF
SET
ON
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
PLAY
PROGRAM
1. TITLE
ALL CLEAR
2. TITLE
– –
3. TITLE
– –
4. TITLE
– –
5. TITLE
– –
6. TITLE
– –
7. TITLE
– –
T
– –
01
02
03
04
05
Tracks or titles recorded on a disc
“TRACK” is displayed when you
play a VIDEO CD or a CD
PROGRAM
1. TITLE
– –
ALL CLEAR
2. TITLE
– –
3. TITLE
– –
4. TITLE
– –
5. TITLE
– –
6. TITLE
– –
7. TITLE
– –
T
C
ALL
01
02
03
04
05
06
– –
01
02
03
04
05
Chapters recorded on a disc
PROGRAM
1. TITLE
– –
ALL CLEAR
2. TITLE
– –
3. TITLE
– –
4. TITLE
– –
5. TITLE
– –
6. TITLE
– –
7. TITLE
– –
C
ALL
02
03
04
05
06
T
– –
01
02
03
04
05
01
45
Playing Discs
Next, press X/x to select “03” under
“C,” then press ENTER.
x When playing a VIDEO CD or CD
For example, select track “02.”
Press X/x to select “02” under “T,” then
press ENTER.
6 To program other titles, chapters, or
tracks, repeat Steps 4 to 5.
The programmed titles, chapters, and
tracks are displayed in the selected order.
7 Press H to start Program Play.
Program Play begins.
When the program ends, you can restart
the same program again by pressing H.
To return to normal play
Press CLEAR, or select “OFF” in Step 3.
To play the same program again, select “ON”
in Step 3 and press H.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
To change or cancel a program
1 Follow Steps 1 through 3 of “Creating
your own program (Program Play).”
2 In Step 4, select the program number of
the title, chapter, or track you want to
change or cancel using X/x, and press c.
3 Follow Step 5 for new programming. To
cancel a program, select “--” under “T,”
then press ENTER.
To cancel all the titles, chapters, or
tracks in the programmed order
1 Follow Steps 1 through 3 of “Creating
your own program (Program Play).”
2 Press X and select “ALL CLEAR.”
3 Press ENTER.
z
You can do Repeat Play or Shuffle Play of the
programmed titles, chapters, or tracks by pressing
REPEAT or SHUFFLE during Program Play. Or
activate “REPEAT” or “SHUFFLE” on the Control
Menu during Program Play.
z You can select “PROGRAM” directly by pressing
PROGRAM.
T
– –
01
02
03
04
05
PROGRAM
1. TITLE 0 2
–
0 3
ALL CLEAR
2. TITLE
– –
3. TITLE
– –
4. TITLE
– –
5. TITLE
– –
6. TITLE
– –
7. TITLE
– –
Selected title and chapter
PROGRAM
1. TRACK 0 2
ALL CLEAR
2. TRACK
– –
3. TRACK
– –
4. TRACK
– –
5. TRACK
– –
6. TRACK
– –
7. TRACK
– –
0:15:30
– –
01
02
03
04
05
T
Total time of the programmed
tracks
Selected track
continued
,
46
Playing in random order (Shuffle
Play)
You can have the player “shuffle” titles,
chapters, or tracks and play them in a random
order. Subsequent “shuffling” may produce a
different playing order.
1 Press DISPLAY twice (once for CD)
during playback.
The Control Menu is displayed.
2 Press X/x to select
(SHUFFLE), then press ENTER.
The options for “SHUFFLE” appear.
3 Press X/x to select the item.
x When playing a DVD VIDEO
• TITLE: Shuffles titles and plays
them in random order.
• CHAPTER: Shuffles chapters and
plays them in random order.
x When playing a VIDEO CD or CD
• TRACK: Shuffles tracks and plays
them in random order.
x During Program Play
• ON: Shuffles titles or tracks selected
in Program Play and plays them in
random order.
4 Press ENTER.
To return to normal play
Press CLEAR or select “OFF” in Step 3.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z
You can set the player to “shuffle” in stop mode as
well. After pressing SHUFFLE to select the item you
want to set, press
H. Shuffle Play starts.
z You can select “SHUFFLE” directly by pressing
SHUFFLE. Each time you press the button the item
changes.
Note
Up to 200 chapters in a disc can be played in random
order when “CHAPTER” is selected.
Playing repeatedly (Repeat Play)
You can play all of the titles or tracks on a
disc or “MG Memory Stick,” or a single title,
chapter, album, or track repeatedly.
You can use a combination of Shuffle or
Program Play modes.
CLEAR
SHUFFLE
H
ENTER
X/x
DISPLAY
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
OFF
CHAPTER
TITLE
OFF
DVD VIDEO
PLAY
CLEAR
REPEAT
H
ENTER
X/x
DISPLAY
47
Playing Discs
1 Press DISPLAY twice (once for CD/DATA-
CD/ “MG Memory Stick”) during
playback.
The Control Menu is displayed.
2 Press X/x to select
(REPEAT), then press ENTER.
The options for “REPEAT” appear.
3 Press X/x to select the item.
x When playing a DVD VIDEO
• DISC: Repeats all of the titles.
• TITLE: Repeats the current title on a
disc.
• CHAPTER: Repeats the current
chapter.
x When playing a DVD-RW
• DISC: Repeats all of the titles in the
selected type of titles (ORIGINAL/
PLAY LIST). (page 41)
• TITLE: Repeats the current title on a
disc.
• CHAPTER: Repeats the current
chapter.
x When playing a VIDEO CD or CD
• DISC: Repeats all of the tracks on a
disc.
• TRACK: Repeats the current track.
x When playing MP3 audio on a DATA-
CD
• DISC: Repeats all of the albums on
a disc.
• ALBUM: Repeats the current album.
• TRACK: Repeats the current track.
x When playing ATRAC3 audio tracks
on an “MG Memory Stick”
• ALL: Repeats all of the tracks.
• TRACK: Repeats the current track.
x During Program Play or Shuffle Play
• ON: Repeats Program Play or
Shuffle Play.
4 Press ENTER.
To return to normal play
Press CLEAR, or select “OFF” in Step 3.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z
You can set the player to “repeat” in stop mode as
well. After pressing REPEAT to select the item you
want to set, press
H. Repeat Play starts.
z You can select “REPEAT” directly by pressing
REPEAT.
z You cannot repeat JPEG image files.
Repeating a specific portion (A-B
Repeat Play)
You can play a specific portion of a title,
chapter, or track repeatedly. (This function is
useful when you want to memorize lyrics,
etc.)
)
1 Press DISPLAY twice (once for CD).
The Control Menu is displayed.
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
CHAPTER
DISC
OFF
TITLE
OFF
DVD VIDEO
PLAY
CLEAR
A-B
ENTER
DISPLAY
X/x
continued
,
48
2 Press X/x to select (A-B
REPEAT), then press ENTER.
The options for “A-B REPEAT” appear.
3 Press X/x to select “SET t,” then
press ENTER.
The “A-B REPEAT” setting display
appears.
4 During playback, when you find the
starting point (point A) of the portion to
be played repeatedly, press ENTER.
The starting point (point A) is set.
5 When you reach the ending point (point
B), press ENTER again.
The set points are displayed and the
player starts repeating this specific
portion.
“A-B” appears on the front panel display
during A-B Repeat Play.
To return to normal play
Press CLEAR, or select “OFF” in Step 3.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z
You can select “A-B REPEAT” directly by
pressing A-B. Press the button once to set the point A,
and press it again to set the point B.
Notes
• You can set A-B Repeat Play for only one specific
section.
• When you set A-B Repeat Play, the settings for
Shuffle Play, Repeat Play, and Program Play are
canceled.
• A-B Repeat Play does not work for titles containing
still pictures on a DVD-RW in VR mode.
• A-B Repeat Play does not work crossing different
titles (“ORIGINAL” or “PLAY LIST”) on a DVD-
RW in VR mode.
SET
OFF
OFF
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
PLAY
Set point A with .
A-B REPEAT
ENTER
A: 18 – 1 : 32 : 55
CHAPTER
TIME
Set point B with .
ENTER
A-B REPEAT
1 8
(
3 4
)
1 2
(
2 7
)
DVD VIDEO
PLAY
A: 18 – 1 : 32 : 55
B: 18 – 1 : 34 : 30
CHAPTER
TIME
ON
T
1 : 3 4 : 3 0
49
Searching for a Scene
Searching for a Scene
Searching for a Particular
Point on a Disc or a “MG
Memory Stick” (Scan, Slow-
motion Play)
You can locate a particular point on a disc
quickly by monitoring the picture or playing
back slowly.
Note
Depending on the DVD/VIDEO CD, you may not be
able to do some of the operations described.
Locating a point quickly by playing a
disc in fast forward or fast reverse
(Scan)
Press or while playing a disc.
When you find the point you want, press H
to return to normal speed.
Each time you press
or during
scan, the playback speed changes. Three
speeds are available. With each press the
indication changes as follows:
Playback direction
x2B (DVD VIDEO/CD only)
r
FF1M
r
FF2M
Opposite direction
x2b (DVD VIDEO only)
r
FR1m
r
FR2m
The “x2B”/ “x2b” playback speed is about
twice the normal speed.
The “FF2M”/ “FR2m” playback speed is
faster than “FF1M”/ “FR1m.”
z
You cannot view JPEG image files in fast forward
or fast reverse.
Watching frame by frame (Slow-
motion Play)
Press or when the player is in
pause mode. To return to the normal speed,
press H.
Each time you press
or during
Slow-motion Play, the playback speed
changes. Two speeds are available. With
each press the indication changes as follows:
Playback direction
SLOW2y y SLOW1y
Opposite direction (DVD VIDEO only)
SLOW2 y SLOW1
The “SLOW2y”/ “SLOW2 ” playback
speed is slower than “SLOW1y”/
“SLOW1 .”
H
/
y
y
y
y
50
Searching for a Title/
Chapter/Track/Index/
Scene, etc. (Search mode)
You can search a DVD disc by title or
chapter, and you can search a VIDEO CD or
CD by track, index, or scene. You can search
an audio track or image on a DATA-CD or
“Memory Stick” by album, track, or file.
As title and tracks are assigned unique
numbers on the disc or “Memory Stick,” you
can select the desired one by entering its
number. Or, you can search for a scene using
the time code.
1 Press DISPLAY.
The Control Menu appears.
2 Press X/x to select the search
method.
x When playing a DVD VIDEO/DVD-RW
(TITLE),
(CHAPTER), or
(TIME/TEXT)
Select “TIME/TEXT” for “Time search”
(see below).
x When playing a VIDEO CD
(TRACK) or
(INDEX)
x When playing a VIDEO CD with PBC
Playback
(SCENE)
x When playing a CD
(TRACK) or
(INDEX)
x When playing an audio on a DATA-CD
(MP3 audio track) or “MG Memory
Stick” (ATRAC3 audio track)
(ALBUM) (DATA-CD only)
or
(TRACK)
x When viewing a JPEG image file on a
DATA-CD or “Memory Stick”
(ALBUM) or
(FILE)
Example: when you select
(CHAPTER)
“
**
(
**
)” is selected (
**
refers to a
number).
The number in parentheses indicates the
total number of titles, chapters, tracks,
indexes, scenes, albums or files.
SEARCH
MODE
CLEAR
X/x/c
ENTER
DISPLAY
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
PLAY
Selected item
51
Searching for a Scene
3 Press ENTER.
“
**
(
**
)” changes to “-- (
**
).”
4 Select the number of the title, track,
scene, etc., you want by pressing
X/x to select the digit, following by
c to move the cursor.
If you make a mistake
Cancel the number by pressing CLEAR,
then select another number.
5 Press ENTER.
The player starts playback from the
selected number.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
To search for a scene using the time
code (Time search) (DVD VIDEO/DVD-
RW only)
1 In Step 2, select (TIME/
TEXT).
“T
**
:
**
:
**
” (playing time of the current
title) is selected.
2 Press ENTER.
“T
**
:
**
:
**
” changes to “T --:--:--.”
3 Input the time code using X/x/c, then
press ENTER.
For example, to find the scene at 2 hours,
10 minutes, and 20 seconds after the
beginning, just enter “2:10:20.”
z
When the Control Menu display is turned off, you
can search for a chapter, or track, etc. by pressing
SEARCH MODE followed by X/x/c and ENTER.
Notes
• When you search a DATA-CD or “Memory Stick,”
the number you should input is different from the
numbers included in the album, track or file name.
Input the album, track or file number indicating the
recording order on the DATA-CD or “Memory
Stick.”
• You cannot search for a still image on a DVD-RW
in VR mode.
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
– –
(
3 4
)
PLAY
52
Viewing Information About the Disc
Viewing the Playing Time
and Remaining Time on
the Front Panel Display
You can check information about the disc,
such as the remaining time, current number
of title of a DVD VIDEO/DVD-RW, or track
of a CD or VIDEO CD, using the front panel
display (page 11).
Press TIME/TEXT.
Each time you press TIME/TEXT while
playing the disc, the display changes as
shown in the following charts.
When playing a DVD VIDEO/DVD-RW
TIME/TEXT
Playing time of the current title
Remaining time of the
current title
Playing time of the
current chapter
Text
Remaining time of the
current chapter
Current title and
chapter number
Automatically
53
Viewing Information About the Disc
When playing a VIDEO CD (without
PBC functions) or CD
When playing a DATA-CD (MP3 audio
track) or “MG Memory Stick”
(ATRAC3 audio track)
z When playing VIDEO CDs with PBC functions,
the scene number or the playing time is displayed.
z The playing time and remaining time of the current
chapter, title, track, scene, or disc will also appear on
your TV screen. See the following section “Checking
the Playing Time and Remaining Time” for
instructions on how to read this information.
Notes
• Depending on the type of disc being played and the
playing mode, the above mentioned disc information
may not be displayed.
• Playing time of MP3 audio track may not be
displayed correctly.
Track playing time and the current track
number
Remaining time of the
current track
Playing time of the
disc
Remaining time of
the disc
Text
Current track and
index number
Automatically
Name of the current
track
Current track number and playing time
54
Checking the Playing
Time and Remaining Time
You can check the playing time and
remaining time of the current title, chapter, or
track, and the playing time or remaining time
of the disc, etc. Also, you can check the title
of music or image recorded on a disc or
“Memory Stick” such as DVD/CD texts.
1 Press DISPLAY during playback.
The Control Menu is displayed.
2 Press TIME/TEXT repeatedly to
change the time information.
The display and the kinds of time that you
can change depend on the disc you are
playing.
x When playing a DVD VIDEO/DVD-RW
•T
**
:
**
:
**
Playing time of the current title
(hour:minute:second)
•T–
**
:
**
:
**
Remaining time of the current title
•C
**
:
**
:
**
Playing time of the current chapter
•C–
**
:
**
:
**
Remaining time of the current
chapter
x When playing a VIDEO CD (with PBC
functions)
•
**
:
**
Playing time of the current scene
(minute:second)
x When playing a VIDEO CD (without
PBC functions) or CD
•T
**
:
**
Playing time of the current track
(minute:second)
•T–
**
:
**
Remaining time of the current track
•D
**
:
**
Playing time of the current disc
•D–
**
:
**
Remaining time of the current disc
x When playing a DATA-CD (MP3
audio) or “MG Memory Stick” (ATRAC3
audio track)
•
****
:
**
Playing time of the current track
(minute:second)
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z
When viewing a JPEG image file on a DATA-CD
or “Memory Stick,” recorded date will be displayed.
Checking the DVD/CD text
Press TIME/TEXT repeatedly in Step 2. If a
text (title of music or image on a disc or
“Memory Stick”) is recorded, the text
appears on the front panel display or TV
screen. If no text is recorded, “NO TEXT”
appears.
TIME/
TEXT
DISPLAY
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
PLAY
Playing time of title or
track, etc.
55
Viewing Information About the Disc
z If the text does not fit on a single line, you can see
the entire text by watching it scroll across the front
panel display.
z You can select the time and text directly by
pressing TIME/TEXT.
Notes
• Only letters of the alphabet can be displayed.
• This player can only display the first level of text,
such as the title.
Checking the Play
Information
You can check information such as the bit
rate or the DVD layer that is being played.
While playing a disc, an approximate bit rate
of the playback picture is always displayed as
Mbps (Mega bit per second) and the audio as
kbps (kilo bit per second).
Checking the play information of
DVD (ADVANCED)
1 Press DISPLAY during playback.
The Control Menu is displayed.
2 Press X/x to select
(ADVANCED), then press ENTER.
The options for “ADVANCED” appear.
TIME/TEXT
BRAHMS SYMPHONY NO – 4
Text (The track or file name is displayed
when playing a DATA-CD or “Memory
Stick.”)
ENTER
X/x
DISPLAY
TIME/TEXT
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
BIT RATE
DVD VIDEO
BIT RATE
05
10
kbps
Mbps
384
OFF
BIT RATE
LAYER
PLAY
continued
,
56
3 Press X/x to select items.
For each item, please refer to “Displays
of each item.”
• BIT RATE: displays the bit rate.
• LAYER: displays the layer and the
pick-up point.
4 Press ENTER.
To close the ADVANCED window
Select “OFF” in Step 3.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
Display of each item
By pressing DISPLAY repeatedly, you can
display either “BIT RATE” or “LAYER,”
whichever was selected in “ADVANCED.”
BIT RATE
Bit rate refers to the amount of video/audio
data per second in a disc. The higher the bit
rate, the larger the amount of data. When the
bit rate level is high, there is a large amount
of data. However, this does not always mean
that you can get higher quality pictures or
sounds.
LAYER
Indicates the approximate point where the
disc is playing.
If it is a dual-layer DVD, the player indicates
which layer is being read (“Layer 0” or
“Layer 1”).
For details on the layers, see page 97 (DVD
VIDEO).
Checking the play information of
DATA-CD or “MG Memory Stick”
By pressing TIME/TEXT while playing MP3
audio track on a DATA-CD or ATRAC3
audio track on an “MG Memory Stick” you
can display the audio bit rate (the amount of
data per second of the current audio).
BIT RATE
05
10
kbps
Mbps
384
Audio
Video
Appears when the DVD
has dual layers
T 17:30 128k PLAY
KARAOKE
RIVER SIDE
Bit rate
Album name
Track/file name
57
Sound Adjustments
Sound Adjustments
Changing the Sound
If the DVD VIDEO is recorded with
multilingual tracks, you can select the
language you want while playing the disc.
If the DVD VIDEO is recorded in multiple
audio formats (PCM, Dolby Digital, or DTS),
you can select the audio format you want
while playing the disc.
With stereo CDs, DATA-CDs, VIDEO CDs
or “MG Memory Stick,” you can select the
sound from the right or left channel and listen
to the sound of the selected channel through
both the right and left speakers. (In this case,
the sound loses its stereo effect.) For
example, when playing a disc containing a
song with the vocals on the right channel and
the instruments on the left channel, you can
select the left channel and hear the
instruments from both speakers.
1 Press DISPLAY during playback.
The Control Menu is displayed.
2 Press X/x to select
(AUDIO), then press ENTER.
The options for “AUDIO” appear.
3 Press X/x to select the desired
audio signal.
x When playing a DVD VIDEO
Depending on the DVD VIDEO, the
choice of language varies.
When 4 digits are displayed, they
represent the language code. Refer to the
language code list on page 101 to see
which language the code represents.
When the same language is displayed two
or more times, the disc is recorded in
multiple audio formats.
x When playing a DVD-RW
The types of sound tracks recorded on a
disc are displayed. The default setting is
underlined.
Example:
• 1: MAIN
(main sound)
• 1: SUB (sub sound)
• 1: MAIN+SUB (main and sub
sound)
x When playing a VIDEO CD, CD, DATA-
CD (MP3 audio) or “MG Memory Stick”
(ATRAC3 audio track)
The default setting is underlined.
• STEREO
: The standard stereo
sound
• 1/L: The sound of the left channel
(monaural)
• 2/R: The sound of the right channel
(monaural)
AUDIO
DISPLAY
ENTER
X/x
DVD VIDEO
2: ENGLISH
3:
FRENCH
1: ENGLISH
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
LRC
DOLBY DIGITAL 3/2.1
PROGRAM FORMAT
LFE
LS RS
1: ENGLISH
PLAY
continued
,
58
4 Press ENTER.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z You can select “AUDIO” directly by pressing
AUDIO. Each time you press the button, the item
changes.
Notes
• For discs not in multiple audio format, you cannot
change the sound.
• While playing a DVD, the sound may change
automatically.
Displaying the audio information of
the disc
When you select “AUDIO,” the channels
being played are displayed on the screen.
For example, in Dolby Digital format,
multiple signals ranging from monaural to
5.1 channel signals can be recorded on a
DVD VIDEO. Depending on the DVD
VIDEO, the number of the recorded channels
may differ.
*“PCM,” “DTS,” or “DOLBY DIGITAL” is
displayed.
In the case of “DOLBY DIGITAL,” the
channels in the playing track are displayed
by numbers as follows:
For Dolby Digital 5.1ch:
**The letters in the program format display
mean the following sound component.
The display examples are as follows:
• PCM (stereo)
• Dolby Surround
DVD VIDEO
1: ENGLISH
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
LRC
DOLBY DIGITAL 3/2.1
PROGRAM FORMAT
LFE
LS RS
PLAY
Current audio format*
Currently playing program format**
L: Front (left)
R: Front (right)
C: Center
LS: Rear (left)
RS: Rear (right)
S: Rear (monaural): The rear
component of the Dolby Surround
processed signal and the Dolby
Digital signal
LFE: Low Frequency Effect signal
DOLBY DIGITAL
3 / 2
.
1
LFE (Low Frequency
Effect) component 1
Rear component 2
Front component 2 +
Center component 1
PCM 48kHz 24bit
PROGRAM FORMAT
DOLBY SURROUND
DOLBY DIGITAL 2/0
L RC
S
PROGRAM FORMAT
59
Sound Adjustments
• Dolby Digital 5.1ch
“LFE” is enclosed in a solid line even if an
LFE signal component is not output.
•DTS
“LFE” is enclosed in a solid line even if an
LFE signal component is not output.
z When the signal contains rear signal components
such as “LS,” “RS” or “S,” the Surround effect is
enhanced (page 59).
Note
If “DTS” is set to “OFF” in “AUDIO SETUP,” the
DTS track selection option will not appear on the
screen even if the disc contains DTS tracks (page 92).
TV Virtual Surround
Settings (TVS)
When you connect a stereo TV or 2 front
speakers, TV Virtual Surround lets you enjoy
surround sound effects by using sound
imaging to create virtual rear speakers from
the sound of the front speakers (L: left, R:
right) without using actual rear speakers.
This function is designed to work with the
AUDIO OUT L/R jacks. Note that if you
select one of the TVS settings while playing
a DVD, the player does not output the Dolby
Digital signals from the DIGITAL OUT
(OPTICAL) jack (when you set “DOLBY
DIGITAL” in “AUDIO SETUP” to “D-
PCM”) (page 92).
1 Press DISPLAY during playback.
The Control Menu appears.
2 Press X/x to select (TVS),
then press ENTER.
The options for “TVS” appear.
LRC
DOLBY DIGITAL 3/2.1
PROGRAM FORMAT
LFE
LS RS
LRC
DTS 3/2.1
PROGRAM FORMAT
LFE
LS RS
SURROUND
DISPLAY
ENTER
X/x
OFF
TVS DYNAMIC
TVS WIDE
OFF
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
PLAY
continued
,
60
3 Press X/x to select one of the TVS
(TV Virtual Surround) sounds.
Refer to the explanations given for each
item.
• TVS DYNAMIC
• TVS WIDE
• TVS NIGHT
• TVS STANDARD
4 Press ENTER.
To reset the TVS setting
In Step 3, select “OFF.”
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
TVS DYNAMIC
Uses sound imaging to create virtual rear
speakers from the sound of the front speakers
(L, R) without using actual rear speakers. The
virtual speakers are reproduced as shown in
the illustration below. The sound imaging
effect is distinct and clearly reproduces each
aural element of the audio track.
This mode is effective when the distance
between the front L and R speakers is short,
such as with built-in speakers on a stereo TV.
TVS WIDE
Uses sound imaging to create virtual rear
speakers from the sound of the front speakers
(L, R) without using actual rear speakers. The
virtual speakers are reproduced as shown in
the illustration below. This gives the sound
an expanded effect that fills the area
surrounding the listener.
This mode is effective when the distance
between the front L and R speakers is short,
such as with built-in speakers on a stereo TV.
TVS NIGHT
The large sounds, such as explosions, are
suppressed, but the quieter sounds are
unaffected. This feature is useful when you
do not want to disturb other people but still
want to hear the dialog and enjoy the
surround sound effects of “TVS WIDE.”
TVS STANDARD
Uses sound imaging to create virtual rear
speakers from the sound of the front speakers
(L, R) without using actual rear speakers. The
virtual speakers are reproduced as shown in
the illustration below. Use this setting when
you want to use TVS with 2 separate speakers
and retain the sound quality.
TV
L: Left front speaker
R: Right front speaker
: Virtual speakers
TV
LR
61
Sound Adjustments
z You can select “TVS” directly by pressing
SURROUND. Each time you press the button, the
item changes. If you select any setting other than
“OFF,” the SURROUND indicator on the player lights
up.
Notes
• When you select an effect, the sound cuts off for a
moment.
• When the playing signal does not contain a signal for
the rear speakers (page 58), the surround effects may
be difficult to hear.
• When you select one of the TVS modes, turn off the
surround setting of the connected TV or amplifier
(receiver).
• Make sure that your listening position is between
and at an equal distance from your speakers, and that
the speakers are located in similar surroundings.
Otherwise, the TVS effect may be hard to discern.
• “TVS NIGHT” works only with Dolby Digital
audio. However, not all discs will respond to the
“TVS NIGHT” function in the same way.
• If you set “DOLBY DIGITAL” to “DOLBY
DIGITAL,” or “DTS” to “ON” (page 91), sound will
come from the DIGITAL OUT (OPTICAL) jack but
it will not have the TVS effect.
62
Enjoying Movies
Changing the Angles
If various angles (multi-angles) for a scene
are recorded on the DVD VIDEO, “ANGLE”
appears on the front panel display. This
means that you can change the viewing angle.
For example, while playing a scene of a train
in motion, you can display the view from
either the front of the train, the left window of
the train, or from the right window without
having the train’s movement interrupted.
1 Press DISPLAY during playback.
The Control Menu appears.
2 Press X/x to select
(ANGLE).
The number of the angle appears.
The number in parentheses indicates the
total number of angles.
3 Press c or ENTER.
The number of the angle changes to “-.”
4 Select the angle number using X/x,
then press ENTER.
The scene changes to the selected angle.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z You can select the angle directly by pressing
ANGLE. Each time you press the button, the angle
changes.
Note
Depending on the disc, you may not be able to change
the angles even if multi-angles are recorded on the
disc.
ANGLE
ENTER
DISPLAY
X/x
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
1
(
9
)
PLAY
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
DVD VIDEO
–
(
9
)
PLAY
63
Enjoying Movies
Displaying the Subtitles
If subtitles are recorded on the disc, you can
turn the subtitles on and off whenever you
want while playing. If multilingual subtitles
are recorded on the disc, you can change the
subtitle language while playing, and turn it on
or off whenever you want. For example, you
can select the language you want to practice
and turn the subtitles on for better
understanding.
1 Press DISPLAY during playback.
The Control Menu appears.
2 Press X/x to select
(SUBTITLE), then press ENTER.
The options for “SUBTITLE” appear.
3 Press X/x to select the setting.
x When playing a DVD VIDEO
Select the language.
Depending on the DVD VIDEO, the
choice of language varies.
When 4 digits are displayed, they
indicate the language code. Refer to the
language code list on page 101 to see
which language the code represents.
x When playing a DVD-RW
Select “ON.”
4 Press ENTER.
To cancel the SUBTITLE setting
Select “OFF” in Step 3.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z
You can select “SUBTITLE” directly by pressing
SUBTITLE. Each time you press the button, the item
changes.
Note
Depending on the disc, you may not be able to change
the subtitles even if multilingual subtitles are recorded
on it.
SUBTITLE
DISPLAY
ENTER
X/x
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
OFF
1: ENGLISH
2:
FRENCH
3: SPANISH
OFF
DVD VIDEO
PLAY
64
Adjusting the Picture
Quality (BNR)
The Block Noise Reduction (BNR) function
adjusts the picture quality by reducing the
“block noise” or mosaic like patterns that
appear on your TV screen.
1 Press DISPLAY twice during
playback.
The Control Menu appears.
2 Press X/x to select (BNR),
then press ENTER.
The options for “BNR” appear.
3 Press X/x to select a level.
As the value increases, the mosaic like
patterns on your TV screen will decrease.
• 1: reduces the “block noise”.
• 2: reduces the “block noise” more than
1.
• 3: reduces the “block noise” more than
2.
4 Press ENTER.
The disc plays with the setting you
selected.
To cancel the BNR setting
Select “OFF” in Step 3.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
z
You can select “BNR” directly by pressing BNR.
Each time you press the button, the level changes.
Notes
• If the outlines of the images on your screen should
become blurred, set “BNR” to “OFF.”
• Depending on the disc or the scene being played, the
“BNR” effect may be hard to discern.
BNR
DISPLAY
ENTER
X/x
OFF
1
2
3
DVD VIDEO
OFF
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
PLAY
65
Playing a DATA-CD
Playing a DATA-CD
About MP3 Audio Tracks
and JPEG Image Files
What is MP3/JPEG?
MP3 is audio compression technology that
satisfies the ISO/MPEG regulations.
JPEG is image compression technology.
Discs that the player can play
You can play MP3 audio tracks or JPEG
image files on CD-ROMs, CD-Rs or CD-
RWs (DATA-CD). However, the discs must
be recorded according to ISO9660 level 1,
level 2 or Joliet format for the player to
recognize the tracks (or files).
You can also play discs recorded in Multi
Session.
See the instructions supplied with the CD-R/
CD-RW drives and the recording software
(not supplied) for details on the recording
format.
Note on the multi-session disc
If MP3 audio tracks or JPEG image files are recorded
in the first session, the player will play MP3 audio
tracks or JPEG image files also in other sessions.
If audio tracks and images in Music CD format or
Video CD format are recorded in the first session, only
the first session will be played back.
Note
Since the player cannot play the discs created in the
Packet Write format, you cannot view the JPEG
images recorded using the following Sony products
(as of February, 2002):
– Digital Photo Printer DPP-SV88
– Digital Still Camera MVC-CD1000, MVC-
CD200, MVC-CD300
MP3 audio track or JPEG image file
that the player can play
The player can play the MP3 audio tracks or
JPEG image files:
• which have extension “.MP3” (MP3 audio
track) or “.JPG” (JPEG image file)
• which conform to the DCF* image file
format
* “Design rule for Camera File system”: Image
standards for digital cameras regulated by Japan
Electronic Industries Development Association
(JEIDA)
Notes
• The player will play any data with the extension
“.MP3” or “.JPG,” even if they are not in MP3 or
JPEG format. Playing this data may generate a loud
noise which could damage your speaker system.
• The player does not conform to audio in MP3PRO
format.
continued
,
66
Playback order of MP3 audio tracks
or JPEG image files
The albums, MP3 audio tracks, or JPEG
image files recorded in a DATA-CD will be
played as follows:
Structure of disc contents
When you insert a DATA-CD and press H,
the numbered tracks (or files) are played
sequentially, from 1 through 7. Any sub-
albums/tracks (or files) contained within a
currently selected album take priority over
the next album in the same tree. (Example: C
contains D so 4 is played before 5.)
When you press MENU and the list of album
names appears (page 67), the album names
are arranged in the following order: A t B
t C t D t F t G. Albums that do
not contain tracks (or files) (such as album
E) do not appear in the list.
z
If you add numbers (01, 02, 03, etc.) to the front of
the track/file names when you store the tracks (or files)
in a disc, the tracks and files will be played in that
order.
z Since a disc with many trees takes longer to start
playback, place your albums within the first two trees
when you store the tracks (or files) in a disc.
Notes
• Depending on the software you use to create the
DATA-CD, the playback order may differ from the
above illustration.
• The playback order above may not be applicable if
there are more than 999 albums and tracks (or files)
in the DATA-CD.
• The player can recognize up to 499th album (the
player will count just albums, including albums that
do not contain MP3 audio tracks and JPEG image
files). The player will not play any albums beyond
the first 499 album. Of the first 499 albums, the
player will play no more than a combined total of
999 albums and tracks (or files).
ROOT
Tree 1 Tree 2 Tree 3 Tree 4 Tree 5
Track (MP3 audio) or
File (JPEG image)
Album
67
Playing a DATA-CD
Playing an MP3 Audio
Track
MP3 audio tracks recorded on DATA-CDs
(CD-ROM, CD-R, CD-RW) can be played
on this player.
1 Insert a DATA-CD into the disc slot.
(If the MS indicator on the player is lit,
press MS to turn it off in stop mode.)
The Control Menu appears if an MP3
audio tracks or JPEG image file is
recorded on the DATA-CD.
2 Press X/x to select “AUDIO.”
3 Press H or ENTER.
The first MP3 audio track recorded on the
DATA-CD is played back.
To play the next or previous track
Press > or ..
z
You can view the disc information (page 52) or
scan (page 49) while playing MP3 audio tracks. You
can also activate Repeat Play (page 46), “AUDIO”
(page 57), and “TVS” (page 59).
z You can also use > or . on the player to
select “AUDIO” in Step 2.
z If you want to view JPEG image files after playing
MP3 audio tracks, press DISPLAY to display the
Control Menu. Select using X/x, then press
ENTER. Follow from Step 2 of “Viewing a JPEG
Image File” on page 68.
Note
The ID3 tag, which is the memory area partitioned in
MP3 audio for inputting music titles, etc., cannot be
displayed.
Selecting an album and track
1 After Step 3 in “Playing an MP3 Audio
Track,” press MENU.
The albums recorded on the DATA-CD
appear. When an album is being played,
its title is shaded.
./>
C/X/x/c
O
RETURN
ENTER
H
MENU
MS
DISPLAY
AUDIO
AUDIO
AUDIO
1
(
3 0
)
ROCK BEST HIT
KARAOKE
JAZZ
R&B
MY FAVORITE SONGS
CLASSICAL
SALSA OF CUBA
BOSSANOVA
List of album names
Highlighted album number
Total albums in the disc
continued
,
68
2 Press X/x to select the album you want
to play, then press ENTER.
Tracks in the album appear. When a track
is being played, its title is shaded.
3 Press X/x to select the track, then press
ENTER.
The player starts playing the selected
track.
To go to the next or previous page
Press c or C.
To return to the previous display
Press ORETURN.
To turn off the display
Press MENU.
z
By pressing MENU, you can display the album list
when the player is stopped.
Note
Only the letters in alphabet and numbers in the album/
track names can be displayed. Other characters appear
as an “*” (asterisk).
Viewing a JPEG Image File
JPEG image files recorded on DATA-CDs
(CD-ROM, CD-R, CD-RW) can be viewed
on this player. Note, however, that you can
view only the JPEG image files which
conform to the DCF image file format.
1 Insert a DATA-CD into the disc slot.
(If the MS indicator on the player is lit,
press MS to turn it off in stop mode.)
The Control Menu appears if an MP3
audio tracks or JPEG image file is
recorded on the DATA-CD.
2 Press X/x to select “IMAGE.”
AUDIO
JAZZ
1
(
2 5 6
)
01 SHE IS SPECIAL
02 ALL YOU NEED IS TO...
03 SPICY LIFE
04 HAPPY HOUR
05 RIVER SIDE
06 5
07 TAKE TIME, TAKE TIME
List of track names
Highlighted track number
Total tracks in the
album
./>
C/X/x/c
O
RETURN
ENTER
H
MENU
MS
DISPLAY
AUDIO
AUDIO
69
Playing a DATA-CD
3 Press H or ENTER.
The first JPEG image file recorded on the
DATA-CD is played back.
To play the next or previous file
Press > or ..
z
You can also use > or . on the player to
select “IMAGE” in Step 2.
z If you want to play MP3 audio tracks after viewing
JPEG image files, press DISPLAY to display the
Control Menu. Select using X/x, then press
ENTER. Follow from Step 2 of “Playing an MP3
Audio Track” on page 67.
Notes
• JPEG image files which are set to display larger than
4720 dots vertically or horizontally may not be
displayed.
• JPEG image files which do not fit the screen will be
reduced so they can be displayed properly.
Selecting an album and file
1 After Step 3 in “Viewing a JPEG Image
File,” press MENU.
The albums recorded on the DATA-CD
appear. When an album is being played,
its title is shaded.
2 Press X/x to select the album you want
to play, then press ENTER.
Files in the album appear. When a file is
being played, its title is shaded.
3 Press X/x to select the file, then press
ENTER.
The player starts playing the selected file.
To go to the next or previous page
Press c or C.
To return to the previous display
Press ORETURN.
To turn off the display
Press MENU.
z
By pressing MENU, you can display the album list
when the player is stopped.
Note
Only the letters in alphabet and numbers in the album/
file names can be displayed. Other characters appear
as an “*” (asterisk).
1
(
2
)
BIRTHDAY PARTY
WINTER FESTIVAL
List of album names
Highlighted album number
Total albums in the
disc
BIRTHDAY PARTY
1
(
2 8
)
SCENE01
SCENE02
SCENE03
SCENE04
SCENE05
SCENE06
SCENE07
List of file names
Highlighted file number
Total files in the album
continued
,
70
Rotating a JPEG image
You can rotate an image by 90 degrees.
Press C/c while viewing an image.
Each time you press c, the image rotates
clockwise by 90 degrees.
Each time you press C, the image rotates
counterclockwise by 90 degrees.
Example of when you press c once:
Rotating direction
71
Playing a “Memory Stick”
Playing a “Memory Stick”
About the “Memory Stick”
“Memory Stick” is a compact, portable and
versatile Integrated Circuit recording
medium with a data capacity that exceeds a
floppy disk. “Memory Stick” is specially
designed for exchanging and sharing digital
data among “Memory Stick” compatible
products. Because it is removable, the
“Memory Stick” can also be used for external
data storage.
Types of “Memory Stick”
There are two types of “Memory Stick;”
–“MagicGate (MG) Memory Stick”* that is
equipped with “MagicGate” copyright
protection technology.
–“Memory Stick”** that is not equipped
with “MagicGate” copyright protection
technology.
You can use both types of “Memory
Stick” with this player.
What is “MagicGate***”?
“MagicGate” is a copyright protection
technology**** for the “MG Memory Stick”
and compliant products. Authentication
ensures that protected content is transferred
only between compliant devices and a “MG
Memory Stick,” and that protected content is
recorded and transferred in an encrypted
format to prevent unauthorized copying or
playback.
Note on use
To avoid damaging data, do not
- remove the “Memory Stick” or disconnect
the power cord while playing it.
- use the “Memory Stick” in a location
subject to static electricity or electric noise.
On handling the “Memory Stick”
• The tactile protrusion on the rear surface of
a “MG Memory Stick” distinguishes it from
an ordinary “Memory Stick.” (B)
• To prolong the life of the “Memory Stick,”
use the storage case supplied with the
“Memory Stick.”
• Do not touch the “Memory Stick”
connector with your finger or metallic
objects. (A)
• Do not bend, drop or apply strong shock to
the “Memory Stick.”
• Do not disassemble or modify the “Memory
Stick.”
• Do not allow the “Memory Stick” to get
wet.
• Do not use or store the “Memory Stick” in a
location that is subject to:
- Extremely high temperature such as in a
car parked in the sun
- Direct sunlight
- High humidity or places with corrosive
substances
• Do not attach any other material than the
label supplied with the “Memory Stick” on
the label space. (C)
• Attach the label so that it does not stick out
from the proper attachment location.
• Do not stick one label on top of another.
• If the label is turned up at the corners or
loose, replace it with a new one.
Type of “Memory
Stick”
Recordable data
“MG Memory Stick” Audio data + Still image
+ General data
“Memory Stick” Still image + General
data
continued
,
72
Note
Attach the label correctly on the “Memory Stick” or
you may not be able to remove the “Memory Stick”
from the player.
* “MagicGate Memory Stick,” and are
trademarks of Sony Corporation.
**“Memory Stick” and are trademarks of Sony
Corporation.
***“MagicGate” and are
trademarks of Sony Corporation.
****The copyright protection technology of this
player conforms to the SDMI (Secure Digital Music
Initiative) standard.
Inserting a “Memory Stick”
Insert the “Memory Stick” securely into the
MEMORY STICK slot.
Notes
• Observe the side and direction carefully when
inserting a “Memory Stick.” Insert the “Memory
Stick” with the
v mark facing up, and in the
direction of the
v. Otherwise, the slot may be
damaged.
• Do not insert any objects other than a “Memory
Stick” into the slot. Doing so may cause a
malfunction.
To take out the “Memory Stick”
While the player is stopped, push and release
the “Memory Stick.”
Note
When you take out the “Memory Stick,” make sure
that the MS indicator is not lit in yellow. If you turn off
the power or disconnect the power cord while the MS
indicator is lit in yellow, the “Memory Stick” may be
damaged.
Insert until it
clicks.
“Memory Stick”
In the direction of the
v
MS indicator
73
Playing a “Memory Stick”
Playing an ATRAC3 Audio
Track
You can play ATRAC3 audio tracks recorded
on an “MG Memory Stick.”
Make sure the MS indicator is lit (MS mode)
when you play an “MG Memory Stick.”
1 Insert a “MG Memory Stick” into the
MEMORY STICK slot (page 72).
2 Press MS.
The MS indicator on the player lights up
(MS mode).
The Control Menu is displayed.
3 Press X/x to select “AUDIO.”
4 Press H or ENTER.
The first track recorded on the “MG
Memory Stick” is played back.
To play the next or previous track
Press > or ..
z
You can view the disc information (page 52) or
scan (page 49) while playing ATRAC3 audio tracks.
You can also activate Repeat Play (page 46),
“AUDIO” (page 57), and “TVS” (page 59).
z You can also use > or . on the player to
select “AUDIO” in Step 3.
z If you want to view JPEG image files after playing
ATRAC3 audio tracks, press DISPLAY to display the
Control Menu. Select using X/x, then press
ENTER. Follow from Step 3 of “Viewing a JPEG
Image File” on page 75.
Selecting a track
1 After Step 4 in “Playing an ATRAC3
Audio Track,” press MENU.
The audio tracks recorded on the “MG
Memory Stick” appear. When a track is
being played, its title is shaded.
2 Press X/x to select the track, then press
ENTER.
The player starts playing the selected
track.
MS
./>
H
DISPLAY
MENU
C/X/x/c
ORETURN
ENTER
AUDIO
AUDIO
AUDIO
MY FAVORITE SONGS
1
(
1 0 8
)
01 GREEN LEAVES
03 CONDOR
04 SOMEDAY, SOMEWHERE
02 P
05 BORN FREE
06 TOMORROW WILL COME
07 VERY IMPRESSIVE
List of track names
Highlighted track number
Total tracks in the
album
continued
,
74
To go to the next or previous page
Press c or C.
To return to the previous display
Press ORETURN.
To turn off the display
Press MENU.
To switch to disc mode
Press MS. The MS indicator goes out.
z
By pressing MENU, you can display the track list
when the player is stopped.
Notes
• Only the letters in alphabet and numbers in the
album/track names can be displayed. Other
characters appear as an “*” (asterisk).
• MS mode will be released when:
– the player enters standby mode
– the power cord is disconnected
Playing a track with a playback
period restriction (DATE/TIME
SETUP)
Set the current date and time so that you can
play an audio track with a playback period
restriction recorded on an “MG Memory
Stick.”
1 Press DISPLAY when the player is in
stop mode.
The Control Menu appears.
2 Press X/x to select (SETUP),
then press ENTER.
3 Press X/x to select “CUSTOM,” then
press ENTER.
The Setup Display appears.
4 Press X/x to select “CUSTOM SETUP,”
then press ENTER.
The “CUSTOM SETUP” display
appears.
5 Press X/x to select “DATE/TIME SETUP
t,” then press ENTER.
The “DATE/TIME SETUP” display
appears.
6 Press X/x to select a figure, then press
c.
The “Y (year)” is set, and the next item
“M (month)” will be highlighted.
7 Repeat Step 6 to set “M (month),” “D
(day),” “H (hour),” and “M (minute),”
then press ENTER.
When you press ENTER after setting “M
(minute),” the clock starts operating.
If you make a mistake
Press C repeatedly until the item you want to
correct is highlighted, then input the correct
number.
To turn off the Setup Display
Press DISPLAY repeatedly until the Setup
Display is turned off.
CUSTOM SETUP
DIMMER:
PAUSE MODE:
BRIGHT
AUTO
OFF
TRACK SELECTION:
DATE/TIME SETUP
OFF
AUTO PLAY:
2002 33 8 08
DATE/TIME SETUP
YDMMH
:AM//
CUSTOM SETUP
Start with the year.
75
Playing a “Memory Stick”
Note
When you disconnect the power cord, the date/time
setting will return to the factory settings.
Viewing a JPEG Image File
You can view JPEG image files recorded on
an “MG Memory Stick” or a “Memory
Stick.” Note, however, that the player can
display JPEG image files recorded using a
digital camera only if the image file format
and the directory structure are DCF
compliant.
Make sure the MS indicator is lit (MS mode)
when you play an “MG Memory Stick” or
“Memory Stick.”
1 Insert a “Memory Stick” into the
MEMORY STICK slot (page 72).
MS
./>
H
DISPLAY
MENU
C/X/x/c
ORETURN
ENTER
continued
,
76
2 Press MS.
The MS indicator on the player lights up
(MS mode).
The Control Menu is displayed.
3 Press X/x to select “IMAGE.”
4 Press H or ENTER.
The first image recorded on the “Memory
Stick” is played back.
To play the next or previous file
Press > or ..
z
You can also use > or . on the player to
select “IMAGE” in Step 3.
z If you want to play ATRAC3 audio tracks after
viewing JPEG image files, press DISPLAY to display
the Control Menu. Select using X/x, then press
ENTER. Follow from Step 3 of “Playing an ATRAC3
Audio Track” on page 73.
Notes
• JPEG image files which have been edited or
renamed on computers may not be displayed.
• JPEG image files which are set to display larger than
4720 dots vertically or horizontally may not be
displayed.
• JPEG image files which do not fit the screen will be
reduced so they can be displayed properly.
Selecting an album and file
1 After Step 4 in “Viewing a JPEG Image
File,” press MENU.
A list of the albums saved on the
“Memory Stick” appears. When an
album is being played, its title is shaded.
2 Press X/x to select an album, then press
ENTER.
The files in the album appear. When a file
is being played, its title is shaded.
3 Press X/x to select the file, then press
ENTER.
The player starts playing the selected file.
To go to the next or previous page
Press c or C.
To return to the previous display
Press ORETURN.
AUDIO
AUDIO
1
(
2
)
100MSDCF
101MSDCF
List of album names
Highlighted album number
Total albums in the
“Memory Stick”
100MSDCF
1
(
2 8
)
DSC00001
DSC00002
DSC00003
DSC00004
DSC00005
DSC00006
DSC00007
List of file names
Highlighted file number
Total files in the
“Memory Stick”
77
Playing a “Memory Stick”
To turn off the display
Press MENU.
To switch to disc mode
Press MS. The MS indicator goes out.
z
By pressing MENU, you can display the album list
when the player is stopped.
Notes
• Only the letters in alphabet and numbers in the
album/file names can be displayed. Other characters
appear as an “*” (asterisk).
• MS mode will be released when:
– the player enters standby mode
– the power cord is disconnected
Rotating a JPEG image
You can rotate an image by 90 degrees.
Press C/c while viewing an image.
Each time you press c, the image rotates
clockwise by 90 degrees.
Each time you press C, the image rotates
counterclockwise by 90 degrees.
Example of when you press c once:
Rotating direction
78
Using Various Additional
Functions
Locking Discs (Custom Parental
Control, Parental Control)
You can set two kinds of playback
restrictions for the desired disc.
• Custom Parental Control
You can set the playback restrictions so that
the player will not play inappropriate discs.
• Parental Control
Playback of some DVD VIDEOs can be
limited according to a predetermined level
such as the age of the users.
The same password is used for both Parental
Control and Custom Parental Control.
Custom Parental Control
You can set the same Custom Parental
Control password for up to 50 discs. When
you set the fifty-first disc, the first disc is
canceled.
1 Insert the disc you want to lock.
If the disc is playing, press x to stop
playback.
2 Press DISPLAY while the player is in
stop mode.
The Control Menu is displayed.
3 Press X/x to select
(PARENTAL CONTROL), then press
ENTER.
The options for “PARENTAL
CONTROL” appear.
4 Press X/x to select “ON t,” then
press ENTER.
x If you have not entered a password
The display for registering a new
password appears.
Enter a 4-digit password by pressing X/
x to select the digit, followed by c to
move the cursor. Then press ENTER.
The display for confirming the password
appears.
x When you have already registered a
password
The display for entering the password
appears.
x
ENTER
ORETURN
DISPLAY
C/X/x/c
OFF
PASSWORD
PLAYER
ON
DVD VIDEO
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
STOP
PARENTAL CONTROL
Enter a new 4-digit password, then
press
.
ENTER
PARENTAL CONTROL
Enter password, then press
.
ENTER
79
Using Various Additional Functions
5 Enter or re-enter your 4-digit password
by pressing X/x to select the digit,
followed by c to move the cursor. Then
press ENTER.
“Custom parental control is set.” appears
and then the screen returns to the Control
Menu display.
To turn off the Custom Parental
Control function
1 Follow Steps 1 through 3 of “Custom
Parental Control.”
2 Press X/x to select “OFF t,” then press
ENTER.
3 Enter your 4-digit password using X/x
to select the digit, followed by c to move
the cursor. Then press ENTER.
To play the disc for which Custom
Parental Control is set
1 Insert the disc for which Custom Parental
Control is set.
The “CUSTOM PARENTAL
CONTROL” display appears.
2 Enter your 4-digit password using X/x
to select the digit, followed by c to move
the cursor. Then press ENTER.
The player is ready for playback.
z If you forget your password, enter the 6-digit
number “199703” when the “CUSTOM PARENTAL
CONTROL” display asks you for your password, then
press ENTER. (Press c after the 4th digit to allow the
entire 6-digit number to be entered.) The display will
ask you to enter a new 4-digit password.
Parental Control (limiting playback
by children)
Playback of some DVD VIDEOs can be
limited according to a predetermined level
such as the age of the users. The
“PARENTAL CONTROL” function allows
you to set a playback limitation level.
A scene that is limited is not played, or it is
replaced by a different scene.
.
1 Press DISPLAY while the player is in
stop mode.
The Control Menu appears.
2 Press X/x to select
(PARENTAL CONTROL), then press
ENTER.
The options for “PARENTAL
CONTROL” appear.
CUSTOM PARENTAL CONTROL
Custom parental control is already
set. To play, enter your password
and press
.
ENTER
ENTER
ORETURN
DISPLAY
H
X/x/c
OFF
PASSWORD
PLAYER
ON
DVD VIDEO
STOP
1 8
(
3 4
)
1 2
(
2 7
)
T
1 : 3 2 : 5 5
continued
,
80
3 Press X/x to select “PLAYER t,” then
press ENTER.
x If you have not entered a password
The display for registering a new
password appears.
Enter a 4-digit password by pressing X/
x to select the digit, followed by c to
move the cursor. Then press ENTER.
The display for confirming the password
appears.
x When you have already registered a
password
The display for entering the password
appears.
4 Enter or re-enter your 4-digit password
by pressing X/x to select the digit,
followed by c to move the cursor. Then
press ENTER.
The display for setting the playback
limitation level appears.
5 Press X/x to select “STANDARD,” then
press ENTER.
The selection items for “STANDARD”
are displayed.
6 Press X/x to select a geographic area
as the playback limitation level, then
press ENTER.
The area is selected.
When you select “OTHERS t,” select
and enter the standard code in the table on
page 81 using X/x.
7 Press X/x to select “LEVEL,” then
press ENTER.
The selection items for “LEVEL” are
displayed.
8 Select the level you want using X/x,
then press ENTER.
Parental Control setting is complete.
PARENTAL CONTROL
Enter a new 4-digit password, then
press
.
ENTER
PARENTAL CONTROL
Enter password, then press
.
ENTER
PARENTAL CONTROL
LEVEL: OFF
USA
STANDARD:
PARENTAL CONTROL
LEVEL:
OFF
USA
STANDARD:
USA
OTHERS
PARENTAL CONTROL
LEVEL: OFF
OFF
STANDARD:
8:
7:
6:
5:
NC17
R
PARENTAL CONTROL
LEVEL:
STANDARD: USA
4: PG13
81
Using Various Additional Functions
The lower the value, the more strict the
limitation.
To turn off the Parental Control
function
Set “LEVEL” to “OFF” in Step 8.
To play a disc for which Parental
Control is set
1 Insert the disc and press H.
The “PARENTAL CONTROL” display
appears.
2 Enter your 4-digit password using X/x
to select the digit, followed by c to move
the cursor. Then press ENTER.
The player starts playback.
z If you forget your password, remove the disc and
repeat Steps 1 to 3 of “Parental Control (limiting
playback by children).” When you are asked to enter
your password, enter “199703,” then press ENTER.
(Press c after the 4th digit to allow the entire 6 digit
number to be entered.) The display will ask you to
enter a new 4-digit password. After you enter a new 4-
digit password, replace the disc in the player and press
H. When the “PARENTAL CONTROL” display
appears, enter your new password.
Notes
• When you play DVD VIDEOs which do not have the
Parental Control function, playback cannot be
limited on this player.
• Depending on the DVD VIDEO, you may be asked
to change the parental control level while playing the
disc. In this case, enter your password, then change
the level. If the Resume Play mode is canceled, the
level returns to the original level.
Area Code
Changing the password
1 Press DISPLAY while the player is in
stop mode.
The Control Menu appears.
2 Press X/x to select
(PARENTAL CONTROL), then press
ENTER.
The options for “PARENTAL
CONTROL” appear.
3 Press X/x to select “PASSWORD t,”
then press ENTER.
The display for entering the password
appears.
Standard Code
number
Argentina 2044
Australia 2047
Austria 2046
Belgium 2057
Brazil 2070
Canada 2079
Chile 2090
China 2092
Denmark 2115
Finland 2165
France 2174
Germany 2109
India 2248
Indonesia 2238
Italy 2254
Japan 2276
Standard Code
number
Korea 2304
Malaysia 2363
Mexico 2362
Netherlands 2376
New Zealand 2390
Norway 2379
Pakistan 2427
Philippines 2424
Portugal 2436
Russia 2489
Singapore 2501
Spain 2149
Sweden 2499
Switzerland 2086
Thailand 2528
United
Kingdom
2184
continued
,
82
4 Enter your 4-digit password using X/x to
select the digit, followed by c to move
the cursor. Then press ENTER.
5 Enter a new 4-digit password using X/x
to select the digit, followed by c to move
the cursor. Then press ENTER.
6 To confirm your password, re-enter it
using X/x to select the digit, followed by
c to move the cursor. Then press
ENTER.
If you make a mistake entering your
password
Press C before you press ENTER and input
the correct number.
If you make a mistake
Press ORETURN.
To turn off the Control Menu
Press DISPLAY repeatedly until the Control
Menu is turned off.
Operation Sound Effects
(Sound Feedback)
The player beeps when the following
operations are performed.
The default setting of the Sound Feedback
function is set to off.
Operation Operation sound
Power is turned on One beep
Power is turned off Two beeps
H is pressed
One beep
X is pressed
Two beeps
Playback is stopped One long beep
Operation is not possible Three beeps
83
Using Various Additional Functions
To set Sound Feedback
1 Press ?/1 on the player or the remote.
The ?/1 indicator lights up in green.
Make sure that the MS indicator is turned
off. If there is a disc in the player, press
A and remove the disc.
2 Press and hold X on the player for more
than two seconds.
You will hear one beep and the Sound
Feedback function is turned on.
To turn off the Sound Feedback
function
When there is no disc in the player and the
MS indicator is turned off, press and hold X
on the player for more than two seconds. You
will hear two beeps and the Sound Feedback
function is turned off.
Controlling Your TV, etc.
with the Supplied Remote
By adjusting the remote signal, you can
control your TV or Sony Active Speaker
System SA-F21 (not supplied) with the
supplied remote.
Notes
• Depending on the units being connected, you may
not be able to control your TV or Sony AV amplifier
(receiver) using some of the buttons below.
• If you enter a new TV code, the code previously
entered will be erased.
• When you replace the batteries of the remote, the TV
code may be reset to the default setting. Reset the
appropriate code.
Controlling TVs with the remote
1 Slide the TV/DVD switch to “TV.”
2 Hold down ?/1, and enter your TV’s
manufacturer’s code (see the table)
using C/X/x/c.
3 Release ?/1.
?/1 button/indicator
X
?/1
A
MS indicator
TV/VIDEO
VOL
?/1
TV/DVD
WIDE MODE
C/X/x/c
continued
,
84
Manufacturer’s codes of controllable
TVs
Controlling the TV
When you set the TV/DVD switch to “TV,”
you can control your TV using the buttons
below.
Controlling Active Speaker System
SA-F21
When you set the TV/DVD switch to
“DVD,” you can adjust the volume using
VOL +/–.
z
There are some Sony audio products you can
adjust the volume with the supplied remote.
By pressing You can
?/1
Turn the TV on or off
VOL (volume) +/– Adjust the volume of the
TV
TV/VIDEO Switch the TV’s input
source between the TV and
other input sources
WIDE MODE Switch to or from the wide
mode of a Sony wide TV
Manufacturer Press C/X/x/c to input code
Sony (default) XX
Fisher Xx
General Electric XC
JVC xX
Magnavox Xc
Panasonic cc
Philips Xc
Quasar cx
RCA XC
Samsung xc
Sanyo Xx
Sears cC or XC or Xx
Sharp cx
Teknika Xc
Toshiba cC
Zenith cX
85
Settings and Adjustments
Settings and Adjustments
Using the Setup Display
By using the Setup Display, you can make
various adjustments to items such as picture
and sound. You can also set a language for
the subtitles and the Setup Display, among
other things. For details on each Setup
Display item see page 86 through 92. For an
overall list of Setup Display items, see page
102.
Note
Playback settings stored in the disc take priority over
the Setup Display settings and not all the functions
described may work.
How to use the Setup Display
1 Press DISPLAY on the remote when the
player is in stop mode.
The Control Menu appears.
2 Press X/x to select (SETUP),
then press ENTER.
The options for “SETUP” appear.
3 Press X/x to select “CUSTOM,” then
press ENTER.
The Setup Display appears.
4 Press X/x to select the setup item from
the displayed list: “LANGUAGE SETUP,”
“SCREEN SETUP,” “CUSTOM SETUP,”
or “AUDIO SETUP.” Then press ENTER.
The selected setup item appears.
Example: “SCREEN SETUP”
5 Select an item using X/x, then press
ENTER.
The options for the selected item appear.
Example: “TV TYPE”
DISPLAY
ENTER
X/x
(
47
)
: :
QUICK
CUSTOM
RESET
DVD VIDEO
STOP
QUICK
LANGUAGE SETUP
MENU:
AUDIO:
SUBTITLE:
ORIGINAL
ENGLISH
OSD:
ENGLISH
ENGLISH
SCREEN SETUP
TV TYPE:
SCREEN SAVER:
BACKGROUND:
4:3 LETTER BOX
ON
JACKET PICTURE
Selected item
Setup items
SCREEN SETUP
TV TYPE:
SCREEN SAVER:
BACKGROUND:
4:3 LETTER BOX
4:3 LETTER BOX
4:3 PAN SCAN
16:9
Options
continued
,
86
6 Select a setting using X/x, then press
ENTER.
The setting is selected and setup is
complete.
Example: “16:9”
To turn off the Setup Display
Press DISPLAY repeatedly until the Setup
Display is turned off.
z
If you select “QUICK” in Step 3, you will enter the
Quick Setup mode (page 34).
Follow from Step 5 of the Quick Setup explanation to
make basic adjustments.
z If you select “RESET” in Step 3, you can reset all
of the “SETUP” settings on pages 102 to 103 to the
default settings (except for “DATE/TIME SETUP”).
After you select “RESET” and press ENTER, select
“YES” and press ENTER to reset the settings (it takes
a few seconds to complete), or select “NO” and press
ENTER to return to the Control Menu. Do not turn off
the player during resetting.
Setting the Display or
Sound Track Language
(LANGUAGE SETUP)
“LANGUAGE SETUP” allows you to set
various languages for the on-screen display
or sound track.
Select “LANGUAGE SETUP” in the Setup
Display. For details on using the display, see
“Using the Setup Display” (page 85).
xOSD (On-Screen Display)
Switches the display language on the screen.
Selects the language from the displayed list.
xMENU (DVD VIDEO only)
You can select the desired language for the
menu. Selects the language from the
displayed list.
xAUDIO (DVD VIDEO only)
Switches the language of the sound track.
Selects the language from the displayed list.
When you select “ORIGINAL,” the language
given priority in the disc is selected.
xSUBTITLE (DVD VIDEO only)
Switches the language of the subtitles
recorded on the DVD VIDEO.
Select the language from the displayed list.
When you select “AUDIO FOLLOW,” the
language for the subtitles changes according
to the language you selected for the sound
track.
SCREEN SETUP
TV TYPE:
SCREEN SAVER:
BACKGROUND:
16:9
ON
JACKET PICTURE
Selected setting
LANGUAGE SETUP
OSD:
MENU:
AUDIO:
SUBTITLE:
ENGLISH
ENGLISH
ORIGINAL
ENGLISH
87
Settings and Adjustments
z If you select “OTHERS t” in “MENU,”
“SUBTITLE,” and “AUDIO,” select and enter the
language code from the list using X/x to select the
digit, followed by c to move the cursor (page 101).
After you have made a selection, the language code (4
digits) is displayed the next time you select
“OTHERS t.”
Note
When you select a language that is not recorded on the
disc, one of the recorded languages will be
automatically selected (except for the “OSD”).
Settings for the Display
(SCREEN SETUP)
Choose settings according to the TV to be
connected.
Select “SCREEN SETUP” in the Setup
Display. For details on using the display, see
“Using the Setup Display” (page 85).
The default settings are underlined.
xTV TYPE
Selects the aspect ratio of the connected TV
(4:3 standard or wide).
4:3
LETTER
BOX
Select this when you connect a
4:3 screen TV. Displays a wide
picture with bands on the upper
and lower portions of the screen.
4:3 PAN
SCAN
Select this when you connect a
4:3 screen TV. Automatically
displays the wide picture on the
entire screen and cuts off the
portions that do not fit.
16:9 Select this when you connect a
wide-screen TV or a TV with a
wide mode function.
SCREEN SETUP
TV TYPE:
SCREEN SAVER:
BACKGROUND:
4:3 LETTER BOX
ON
JACKET PICTURE
continued
,
88
Note
Depending on the DVD, “4:3 LETTER BOX” may be
selected automatically instead of “4:3 PAN SCAN” or
vice versa.
xSCREEN SAVER
Turns on and off the screen saver so that the
screen saver image appears when you leave
the player in pause or stop mode for 15
minutes, or when you play back an audio or
JPEG image on a CD/DATA-CD/ “Memory
Stick” for more than 15 minutes. The screen
saver will help prevent your display device
from becoming damaged (ghosting). Press
H to turn off the screen saver.
xBACKGROUND
Selects the background color or picture on the
TV screen in stop mode or while playing a
CD/DATA-CD (MP3 audio track)/”MG
Memory Stick” (ATRAC3 audio track).
ON Turns on the screen saver.
OFF Turns off the screen saver.
4:3 LETTER BOX
4:3 PAN SCAN
16:9
JACKET
The jacket picture (still picture)
appears in the background, but
only when the jacket picture is
already recorded on the disc
(CD-EXTRA, etc.). If the disc
does not contain a jacket picture,
the “GRAPHICS” picture
appears.
GRAPHICS A preset picture stored in the
player appears in the background.
BLUE The background color is blue.
BLACK The background color is black.
89
Settings and Adjustments
Custom Settings (CUSTOM
SETUP)
Use this to set up playback related and other
settings.
Select “CUSTOM SETUP” in the Setup
Display. For details on using the display, see
“Using the Setup Display” (page 85).
The default settings are underlined.
xAUTO PLAY
Selects the Auto Play setting when you turn
on the player.
xDIMMER
Adjusts the lighting of the front panel
display.
xPAUSE MODE (DVD VIDEO/DVD-RW
only)
Selects the picture in pause mode.
xTRACK SELECTION (DVD VIDEO
only)
Gives the sound track which contains the
highest number of channels priority when
you play a DVD VIDEO on which multiple
audio formats (PCM, DTS or Dolby Digital
format) are recorded.
OFF Does not use “TIMER,”
“DEMO1,” or “DEMO2” to start
playback.
TIMER Starts playing when the player is
turned on.
A CD, DVD VIDEO or VIDEO
CD can be played at any time
when the player is connected to a
timer (not supplied).
DEMO1 Starts playing the first
demonstration automatically.
DEMO2 Starts playing the second
demonstration automatically.
CUSTOM SETUP
DIMMER:
PAUSE MODE:
BRIGHT
AUTO
OFF
TRACK SELECTION:
DATE/TIME SETUP
OFF
AUTO PLAY:
BRIGHT Makes the front panel display
bright.
DARK Makes the front panel display
dark.
OFF Turns off the lighting of the front
panel display.
AUTO Turn on the front panel display
for a few seconds when a button
on the player or remote is
pressed.
AUTO
The picture, including subjects
that move dynamically, is output
with no jitter. Normally, select
this position.
FRAME The picture, including subjects
that do not move dynamically, is
output in high resolution.
OFF
No priority given.
AUTO Priority given.
continued
,
90
Notes
• When you set the item to “AUTO,” the language
may change. The “TRACK SELECTION” setting
has higher priority than the “AUDIO” settings in
“LANGUAGE SETUP” (page 86).
• If you set “DTS” to “OFF” (page 92), the DTS sound
track is not played even if you set “TRACK
SELECTION” to “AUTO.”
• If PCM, DTS and Dolby Digital sound tracks have
the same number of channels, the player selects
PCM, DTS and Dolby Digital sound tracks in this
order.
• Depending on the DVD VIDEO, the audio channel
with priority may be predetermined. In this case, you
cannot give priority to the DTS or Dolby Digital
format by selecting “AUTO.”
xDATE/TIME SETUP t
Set the current date and time. See “Playing a
track with a playback period restriction
(DATE/TIME SETUP)” in”Playing an
ATRAC3 Audio Track” on page 74.
Settings for the Sound
(AUDIO SETUP)
“AUDIO SETUP” allows you to set the
sound according to the playback and
connection conditions.
Select “AUDIO SETUP” in the Setup
Display. For details on using the display, see
“Using the Setup Display” (page 85).
The default settings are underlined.
xAUDIO ATT (attenuation)
If the playback sound is distorted, set this
item to “ON.” The player reduces the audio
output level.
This function affects the output of the
following jacks:
–AUDIO OUT L/R jacks
OFF Turns off the audio attenuation.
Normally, select this position.
ON Reduces the audio output level so
that no sound distortion occurs.
Select this when the playback
sound from the speakers is
distorted.
AUDIO SETUP
AUDIO ATT:
AUDIO DRC:
DIGITAL OUT:
OFF
STANDARD
ON
DOWNMIX:
DOLBY SURROUND
DOLBY DIGITAL:
DTS:
D-PCM
OFF
91
Settings and Adjustments
xAUDIO DRC (Dynamic Range
Control) (DVD VIDEO/DVD-RW only)
Makes the sound clear when the volume is
turned down when playing a DVD that has
the “AUDIO DRC” function. This affects the
output from the following jacks:
–AUDIO OUT L/R jacks
–DIGITAL OUT (OPTICAL) jack only
when “DOLBY DIGITAL” is set to “D-
PCM” in “DIGITAL OUT” (page 92).
xDOWNMIX (DVD VIDEO/DVD-RW
only)
Switches the mixing down methods when
you play a DVD on which rear signal
components such as “Rear (left),” “Rear
(right),” or “Rear (monaural)” are recorded in
Dolby Digital format. For details on the rear
signal components, see “Displaying the audio
information of the disc” (page 58). This
function affects the output of the following
jacks:
–AUDIO OUT L/R jacks
–DIGITAL OUT (OPTICAL) jack when
“DOLBY DIGITAL” is set to “D-PCM” in
“DIGITAL OUT” (page 92).
xDIGITAL OUT
Selects if audio signals are output via the
DIGITAL OUT (OPTICAL) jack.
Note
MP3 audio and ATRAC3 audio tracks will not be
output from the DIGITAL OUT (OPTICAL) jack.
Setting the digital output signal
Switches the method of outputting audio
signals when you connect the following
component using an optical digital cord via
the DIGITAL OUT (OPTICAL) jack.
–Amplifier (receiver) with digital input jack
–AV amplifier (receiver) with a built-in DTS
or DOLBY DIGITAL decoder
–MD or DAT deck
For connection details, see page 26.
Select “DOLBY DIGITAL” and “DTS” after
setting “DIGITAL OUT” to “ON.”
STANDARD Normally, select this position.
TV MODE Makes the low sounds clear even
if you turn the volume down. It
is especially recommended
when you listen to the sound
using the speakers of the TV.
WIDE
RANGE
Gives you the feeling of being at
a live performance. When you
use high quality speakers, it is
even more effective.
DOLBY
SURROUND
Select this when the player is
connected to an audio
component that conforms to
Dolby Surround (Pro Logic).
The output signals which
reproduce the Dolby Surround
effect are downmixed to 2
channels.
NORMAL Select this when the player is
connected to an audio
component that does not
conform to Dolby Surround (Pro
Logic). All of the output signals
are downmixed to 2 channels
without the Dolby Surround
(Pro Logic) effect.
ON
Normally, select this position. When
you select “ON,” set “DOLBY
DIGITAL” and “DTS.” For details on
setting these items, see “Setting the
digital output signal.”
OFF The player does not output the audio
signals via the DIGITAL OUT
(OPTICAL) jack. The influence of the
digital circuit upon the analog circuit is
minimal.
AUDIO SETUP
AUDIO ATT:
AUDIO DRC:
DIGITAL OUT:
DOLBY DIGITAL:
DTS:
OFF
STANDARD
ON
DOWNMIX:
DOLBY SURROUND
D-PCM
OFF
continued
,
92
xDOLBY DIGITAL (DVD VIDEO/DVD-
RW only)
Selects the Dolby Digital signals output via
the DIGITAL OUT (OPTICAL) jack.
xDTS (DVD VIDEO only)
Selects if DTS signals are output via the
DIGITAL OUT (OPTICAL) jack.
Note
If you select one of the TVS settings while playing a
DVD, the player does not output the Dolby Digital
signals from the DIGITAL OUT (OPTICAL) jack
(when you set “DOLBY DIGITAL” in “AUDIO
SETUP” to “D-PCM”).
D-PCM Select this when the player is
connected to an audio component
lacking a built-in Dolby Digital
decoder. You can select whether
the signals conform to Dolby
Surround (Pro Logic) or not by
making adjustments to the
“DOWNMIX” item in “AUDIO
SETUP” (page 91).
DOLBY
DIGITAL
Select this when the player is
connected to an audio component
with a built-in Dolby Digital
decoder. If the player is connected
to an audio component lacking a
built-in Dolby Digital decoder, do
not set this. Otherwise, when you
play the Dolby Digital sound track,
a loud noise (or no sound) will
come out from the speakers,
affecting your ears or causing the
speakers to be damaged.
OFF
Select this when the player is
connected to an audio component
lacking a built-in DTS decoder. Note
that the DTS stereo signals are output
in this setting.
ON Select this when the player is
connected to an audio component
having a built-in DTS decoder.
If the player is connected to an audio
component lacking a built-in DTS
decoder, do not set this. Otherwise,
when you play the DTS sound track, a
loud noise (or no sound) will come
out from the speakers, affecting your
ears or causing the speakers to be
damaged.
93
Additional Information
Additional Information
Troubleshooting
If you experience any of the following
difficulties while using the player, use this
troubleshooting guide to help remedy the
problem before requesting repairs. Should
any problem persist, consult your nearest
Sony dealer.
Power
The power is not turned on.
, Check that the AC power adaptor and AC
power cord are connected securely.
There is no picture.
, The connecting cords are not connected
securely.
, The connecting cords are damaged.
, The player is not connected to the correct TV
input jack (page 22).
, The video input on the TV is not set so that you
can view pictures on the player.
Picture noise appears.
, The disc is dirty or flawed.
, If the picture output from your player goes
through your VCR to get to your TV, the copy-
protection signal applied to some DVD
programs could affect picture quality. If you
still experience problems even when you
connect your player directly to your TV,
please try connecting your player to your TV’s
S video input (page 22).
Even though you set the aspect ratio
in “TV TYPE” of “SCREEN SETUP,”
the picture does not fill the screen.
, The aspect ratio of the disc is fixed on your
DVD.
Sound
There is no sound.
, The connecting cord is not connected securely.
, The connecting cord is damaged.
, The player is connected to the wrong input
jack on the amplifier (receiver) (page 26, 28,
30).
, The amplifier (receiver) input is not changed
so that you can listen to the player.
, The player is in pause mode or in Slow-motion
Play mode.
, The player is in fast forward or fast reverse
mode.
, If the audio signal does not come through the
DIGITAL OUT (OPTICAL) jack, check the
audio settings (page 90).
, MP3 audio and ATRAC3 audio tracks will not
be output from the DIGITAL OUT
(OPTICAL) jack.
Sound is noisy.
, The disc is dirty or flawed.
, When playing a CD with DTS sound tracks,
noise will come from the AUDIO OUT L/R
jacks (page 38).
Sound distortion occurs.
, Set “AUDIO ATT” in “AUDIO SETUP” to
“ON” (page 90).
Operation
The remote does not function.
, There are obstacles between the remote and
the player.
, The distance between the remote and the
player is too far.
, The remote is not pointed at the remote sensor
on the player.
continued
,
94
, The remote sensor of the player is exposed to
strong light. Select a remote sensor that is not
exposed to strong light (page 18).
, The remote sensor you are trying to use is not
activated. Select the remote sensor you want to
use (page 18).
, The batteries in the remote are weak.
The disc does not play.
, There is no disc inside.
, The disc is upside down. Insert the disc with
the playback side facing down in the disc slot.
, The disc is skewed.
, The player cannot play CD-ROMs, etc. (page
8).
, The region code on the DVD VIDEO does not
match the player.
, Moisture has condensed inside the player.
Remove the disc and leave the player turned
on for about half an hour. Turn on the power
again before playing the disc (page 3).
, The player cannot play DVD-Rs, DVD-RWs,
CD-Rs, or CD-RWs that are not finalized.
, You are trying to play the wrong medium (disc
or “Memory Stick”) in the wrong mode (disc
mode or MS mode).
Press MS to select the correct mode. (The MS
indicator is lit in MS mode, and is off in disc
mode.)
One of the following messages
appears when you insert a “Memory
Stick” into the player.
“Memory Stick error”/ “Insert a
Memory Stick.”
, The player cannot recognize the “Memory
Stick.”
Eject the “Memory Stick” and insert it again.
“Data error”
, The ATRAC3 audio track/JPEG image file
you want to play is broken.
, You are trying to view the following data:
– JPEG image recorded by a digital camera
that image file format and directory structure
are not DCF compliant (page 75)
– JPEG image edited by a computer
– has the extension “.JPG” but not in JPEG
format
“Memory Stick type error”
, The “Memory Stick” is not compatible with
the player (for instance, the “Memory Stick” is
larger than 128MB, etc.).
“Format error”
, The “Memory Stick” was formatted in a way
that does not conform to the player (Windows
Explorer, etc.).
The following message appears when
you play the DATA-CD.
“Data error”
, The MP3 audio track/JPEG image file you
want to play is broken
, You are trying to view the following data:
– the JPEG image file format does not
comform to DCF (page 68)
– has the extension “.JPG” but not in JPEG
format
You cannot play MP3 audio tracks.
, You are trying to play the following data:
– recorded on an “Memory Stick” (The player
can play MP3 audio tracks recorded on
DATA-CDs only)
– does not conform to ISO9660 level 1, level 2
or Joliet
– recorded in MP3PRO
– has an extension other than “.MP3”
– has the extension “.MP3” but not in MP3
format
You cannot view JPEG image files
correctly.
, You are trying to view the following data:
– does not conform to ISO9660 level 1, level 2
or Joliet
– has an extension other than “.JPG”
– larger than 4720 dots vertically or
horizontally
– does not fit the screen (those images are
reduced)
95
Additional Information
The album/track/file names are not
displayed correctly.
, The album/track/file name appears as asterisks
(
*
).
The player can display only letters of the
alphabet and numbers. Other characters
appear as asterisks.
You cannot play ATRAC3 audio
tracks.
In the case of music data with
playback date restriction:
, The current date is not set, or was reset
because the power cord was disconnected.
Set the date and time (page 74).
, The date setting has expired. “Time limit
expired” appears on the display.
In the case of music data for which the
number of playback times is
restricted:
, The “MG Memory Stick” erasure prevention
switch is locked. “Copyright lock” appears on
the display.
Unlock the erasure prevention switch.
, The data has been played as many times as is
allowed. “Playback limit exceeded” appears
on the display.
The disc does not start playing from
the beginning.
, Program Play, Shuffle Play, Repeat Play or A-
B Repeat Play has been selected (page 43).
Press CLEAR to cancel these functions before
playing a disc.
, Resume Play has been selected.
During stop, press
x on the player or the
remote and then start playback (page 40).
, The disc automatically displays the menu.
The player starts playing the disc
automatically.
, The disc features an auto playback function.
, “AUTO PLAY” in “CUSTOM SETUP” is set
to “TIMER” (page 89).
Playback stops automatically.
, Some discs may contain an auto pause signal.
While playing such a disc, the player stops
playback at the auto pause signal.
You cannot perform some functions
such as stop, Scan, Slow-motion Play,
Repeat Play, Shuffle Play, or Program
Play.
, Depending on the disc, you may not be able to
do some of the operations above. See the
operating manual that comes with the disc.
Messages do not appear on the
screen in the language you want.
, In the Setup Display, select the desired
language for the on-screen display in “OSD”
under “LANGUAGE SETUP” (page 86).
The language for the sound track
cannot be changed.
, Multilingual tracks are not recorded on the
DVD VIDEO being played.
, The DVD VIDEO prohibits the changing of
the language for the sound track.
The subtitle language cannot be
changed.
, Multilingual subtitles are not recorded on the
DVD VIDEO being played.
, The DVD VIDEO prohibits the changing of
the subtitles.
The subtitle cannot be turned off.
, The DVD VIDEO prohibits the subtitles being
turned off.
The angles cannot be changed.
, Multi-angles are not recorded on the DVD
VIDEO being played.
, The angle can be changed only when the
“ANGLE” indicator lights up on the front
panel display (page 11).
, The DVD VIDEO prohibits changing of the
angles.
continued
,
96
The player does not operate properly.
, When static electricity, etc., causes the player
to operate abnormally, disconnect the AC
power cord once, then connect it again.
Nothing is displayed on the front
panel display.
, “DIMMER” in “CUSTOM SETUP” is set to
“OFF.” Set “DIMMER” to “BRIGHT” or
“DARK” (page 89). If you set to “AUTO,” the
display turns on only when you operate the
player.
5 numbers or letters are displayed on
the screen and on the front panel
display.
, The self-diagnosis function was activated.
(See the table on page 96.)
The disc cannot be removed and
“LOCKED” appears on the front panel
display.
, Contact your Sony dealer or local authorized
Sony service facility.
Self-diagnosis Function
(When letters/numbers appear in the
display)
When the self-diagnosis function is activated
to prevent the player from malfunctioning, a
five-character service number (e.g., C 13 00)
with a combination of a letter and digits
appears on the screen and the front panel
display. In this case, check the following
table.
First three
characters
of the
service
number
Cause and/or corrective
action
C 13 The disc is dirty.
, Clean the disc with a soft cloth
(page 9).
C 31 The disc is not inserted correctly.
, Re-insert the disc correctly.
E XX
(xx is a
number)
To prevent a malfunction, the
player has performed the self-
diagnosis function.
, Contact your nearest Sony
dealer or local authorized
Sony service facility and give
the 5-character service
number.
Example: E 61 10
C:13:00
97
Additional Information
Glossary
Album (page 67, 69, 76)
A unit in which to store JPEG image files or
MP3/ATRAC3 audio tracks on a DATA-
CDs or “Memory Stick.” (“Album” is an
exclusive definition for this player.)
ATRAC3 (page 73)
ATRAC3 (Adaptive Transform Acoustic
Coding 3), is audio compression technology
that satisfies the demand for high sound
quality and high compression rates. The
ATRAC3 compression rate is approximately
10 times higher than that of the audio CD
format, resulting in increased data capacity.
Chapter (page 11)
Sections of a picture or a music feature that
are smaller than titles. A title is composed of
several chapters. Depending on the disc, no
chapters may be recorded.
Dolby Digital (page 24, 92)
Digital audio compression technology
developed by Dolby Laboratories. This
technology conforms to 5.1-channel
surround sound. The rear channel is stereo
and there is a discrete subwoofer channel in
this format. Dolby Digital provides the same
5.1 discrete channels of high quality digital
audio found in Dolby Digital cinema audio
systems. Good channel separation is realized
because all of the channel data are recorded
discretely and little deterioration is realized
because all channel data processing is digital.
Dolby Surround (Pro Logic) (page 91)
Audio signal processing technology that
Dolby Laboratories developed for surround
sound. When the input signal contains a
surround component, the Pro Logic process
outputs the front, center, and rear signals. The
rear channel is monaural.
DTS (page 24, 92)
Digital audio compression technology that
Digital Theater Systems, Inc. developed.
This technology conforms to 5.1-channel
surround sound. The rear channel is stereo
and there is a discrete subwoofer channel in
this format. DTS provides the same 5.1
discrete channels of high quality digital
audio.
Good channel separation is realized because
all of the channel data is recorded discretely
and little deterioration is realized because all
channel data processing is digital.
DVD-RW (page 41)
A DVD-RW is a recordable and rewritable
disc with the same size as the DVD VIDEO.
The DVD-RW can be recorded in two
different modes: VR mode and Video mode.
VR (Video Recording) mode enables various
programming and editing functions, some of
which are limited in the case of Video mode.
Video mode complies with DVD VIDEO
format and is compatible with DVD players
while a DVD-RW recorded in VR mode can
only be played on DVD-RW compliant
players. The “DVD-RW” appears in this
manual, or the on-screen display refers to
DVD-RWs in VR mode.
DVD VIDEO (page 7)
A disc that contains up to 8 hours of moving
pictures even though its diameter is the same
as a CD.
The data capacity of a single-layer and
single-sided DVD is 4.7 GB (Giga Byte),
which is 7 times that of a CD. The data
capacity of a double-layer and single-sided
DVD is 8.5 GB, a single-layer and double-
sided DVD is 9.4 GB, and double-layer and
double-sided DVD is 17 GB.
The picture data uses the MPEG 2 format,
one of the worldwide standards of digital
compression technology. The picture data is
compressed to about 1/40 (average) of its
original size.
continued
,
98
The DVD VIDEO also uses a variable rate
coding technology that changes the data to be
allocated according to the status of the
picture. Audio information is recorded in
Dolby Digital as well as in PCM, allowing
you to enjoy a more real audio presence.
Furthermore, various advanced functions
such as the multi-angle, multilingual, and
Parental Control functions are provided with
the DVD VIDEO.
File (page 69, 76)
A JPEG image recorded on a DATA-CD or
“Memory Stick.” (“File” is an exclusive
definition for this player.) A single file
consists of a single image.
Index (CD)/Video Index (VIDEO CD) (page
50)
A number that divides a track into sections to
easily locate the point you want on a VIDEO
CD or CD. Depending on the disc, no index
may be recorded.
Parental Control (page 78)
A function of the DVD VIDEO used to limit
playback of the disc according to the age of
the user and the limitation level in each
country. The limitation varies from disc to
disc; when it is activated, or playback is
completely prohibited, violent scenes are
skipped or replaced with other scenes, etc.
Region Code (page 7)
This system is used to protect copyrights. A
region number is allocated on each DVD
player or DVD disc according to the sales
region. Each region code is shown on the
player as well as on the disc packaging. The
player can play the discs that match its region
code. The player can also play discs with the
mark. Even when the region code is not
shown on the DVD, the region limit may still
be activated.
SDMI
SDMI which stands for Secure Digital Music
Initiative, is a forum that consists of over 130
companies in the fields of recorded audio
content, computers, and consumer
electronics, dedicated to developing an
integrated method of copyright protection
technology that can be used worldwide.
SDMI is working to create a framework for
preventing improper usage of audio files and
to promote legal music distribution services.
Scene (page 11)
On a VIDEO CD with PBC (playback
control) functions, the menu screens, moving
pictures and still pictures are divided into
sections called “scenes.”
Title (page 11)
The longest section of a picture or music
feature on a DVD, movie, etc., in video
software, or the entire album in audio
software.
Track (page 11)
Sections of a picture or a music feature on a
VIDEO CD, CD, DATA-CD or “MG
Memory Stick” (the length of a song).
(“Track” in DATA-CD or “MG Memory
Stick” is an exclusive definition for this
player.)
TV Virtual Surround (TVS) (page 59)
Technology from Sony developed to produce
surround sound for home use using just a
stereo TV. Designed to work with the sound
characteristics of your TV, this technology
brings the excitement of surround sound to
your home using nothing more than your
stereo TV’s internal speakers. Furthermore,
various TVS modes are available. For
example, “TVS WIDE” uses just two
speakers to create a virtual sound
environment that makes you feel like you are
surrounded by multiple speakers.
ALL
99
Additional Information
Specifications
System
Laser Semiconductor laser
Signal format system NTSC
Audio characteristics (DVD/CD)
Frequency response DVD VIDEO (PCM 96 kHz): 2 Hz to 44 kHz (±1.0 dB)
DVD VIDEO (PCM 48 kHz): 2 Hz to 22 kHz (±0.5 dB)
CD/“MG Memory Stick” (ATRAC3): 2 Hz to 20 kHz (±0.5 dB)
Signal-to-noise ratio (S/N ratio) 115 dB (AUDIO OUT L/R jacks only)
Harmonic distortion 0.003%
Dynamic range DVD VIDEO: 103 dB
CD/“MG Memory Stick” (ATRAC3): 99 dB
Wow and flutter Less than detected value (±0.001% W PEAK)
The signals from AUDIO OUT L/R jacks are measured. When you play PCM sound tracks with a 96 kHz sampling
frequency, the output signal from the DIGITAL OUT (OPTICAL) jack is converted to 48 kHz sampling frequency.
Outputs
General
Power requirements DC 10.5 V
See page 3 for further information.
Power consumption 12 W
Dimensions (approx.) 252 × 60 × 183 mm (10 × 2 3/8 × 7 1/4 in.) (width/height/depth)
including projecting parts
Mass (approx.) 1.5 kg (3 lb. 5 oz.)
Operating temperature 5°C to 35°C (41°F to 95°F)
Operating humidity 25% to 80%
Jack name Jack type Maximum output
level
Load impedance
DIGITAL OUT
(OPTICAL)
Optical output jack -18 dBm Wave length 660 nm
AUDIO OUT L/R Phono jack 2 Vrms (50 kilohms) Over 10 kilohms
VIDEO OUT Phono jack 1.0 Vp-p 75 ohms, sync negative
S-VIDEO OUT 4-pin mini DIN Luminance signal:
1.0 Vp-p
Color signal:
0.286 Vp-p
75 ohms, sync negative
75 ohms terminated
continued
,
100
AC power adaptor
Model name AC-F21
Power requirements 100 – 240 V AC, 50/60 Hz
Output voltage DC 10.5 V, 1.3 A in operating mode
Operating temperature 5°C to 35°C (41°F to 95°F)
Storage temperature –20°C to 60°C (–4°F to 140°F)
Supplied accessories
See page 17.
Optional accessory
Active Speaker System SA-F21
Specifications and design are subject to change without notice.
ENERGY STAR is a U.S. registered mark. As an ENERGY STAR Partner, Sony Corporation has determined
that this product meets the
ENERGY STAR guidelines for energy efficiency.
101
Additional Information
Language Code List
For details, see page 57, 63, 86.
The language spellings conform to the ISO 639: 1988 (E/F) standard.
Code Language Code Language Code Language Code Language
1027 Afar
1028 Abkhazian
1032 Afrikaans
1039 Amharic
1044 Arabic
1045 Assamese
1051 Aymara
1052 Azerbaijani
1053 Bashkir
1057 Byelorussian
1059 Bulgarian
1060 Bihari
1061 Bislama
1066 Bengali;
Bangla
1067 Tibetan
1070 Breton
1079 Catalan
1093 Corsican
1097 Czech
1103 Welsh
1105 Danish
1109 German
1130 Bhutani
1142 Greek
1144 English
1145 Esperanto
1149 Spanish
1150 Estonian
1151 Basque
1157 Persian
1165 Finnish
1166 Fiji
1171 Faroese
1174 French
1181 Frisian
1183 Irish
1186 Scots
Gaelic
1194 Galician
1196 Guarani
1203 Gujarati
1209 Hausa
1217 Hindi
1226 Croatian
1229 Hungarian
1233 Armenian
1235 Interlingua
1239 Interlingue
1245 Inupiak
1248 Indonesian
1253 Icelandic
1254 Italian
1257 Hebrew
1261 Japanese
1269 Yiddish
1283 Javanese
1287 Georgian
1297 Kazakh
1298 Greenlandic
1299 Cambodian
1300 Kannada
1301 Korean
1305 Kashmiri
1307 Kurdish
1311 Kirghiz
1313 Latin
1326 Lingala
1327 Laothian
1332 Lithuanian
1334 Latvian;
Lettish
1345 Malagasy
1347 Maori
1349 Macedonian
1350 Malayalam
1352 Mongolian
1353 Moldavian
1356 Marathi
1357 Malay
1358 Maltese
1363 Burmese
1365 Nauru
1369 Nepali
1376 Dutch
1379 Norwegian
1393 Occitan
1403 (Afan)
Oromo
1408 Oriya
1417 Punjabi
1428 Polish
1435 Pashto;
Pushto
1436 Portuguese
1463 Quechua
1481 Rhaeto-
Romance
1482 Kirundi
1483 Romanian
1489 Russian
1491 Kinyarwanda
1495 Sanskrit
1498 Sindhi
1501 Sangho
1502 Serbo-
Croatian
1503 Singhalese
1505 Slovak
1506 Slovenian
1507 Samoan
1508 Shona
1509 Somali
1511 Albanian
1512 Serbian
1513 Siswati
1514 Sesotho
1515 Sundanese
1516 Swedish
1517 Swahili
1521 Tamil
1525 Telugu
1527 Tajik
1528 Thai
1529 Tigrinya
1531 Turkmen
1532 Tagalog
1534 Setswana
1535 Tonga
1538 Turkish
1539 Tsonga
1540 Tatar
1543 Twi
1557 Ukrainian
1564 Urdu
1572 Uzbek
1581 Vietnamese
1587 Volapük
1613 Wolof
1632 Xhosa
1665 Yoruba
1684 Chinese
1697 Zulu
1703 Not
specified
102
List of Setup Display Items
The default settings are underlined.
LANGUAGE SETUP (page 86)
SCREEN SETUP (page 87)
OSD ENGLISH
FRENCH
SPANISH
PORTUGUESE
MENU ENGLISH
FRENCH
SPANISH
PORTUGUESE
GERMAN
ITALIAN
DUTCH
CHINESE
JAPANESE
DANISH
SWEDISH
FINNISH
NORWEGIAN
RUSSIAN
OTHERS t
AUDIO ORIGINAL
(All other selections are same as the “MENU” language.)
SUBTITLE AUDIO FOLLOW
(All other selections are same as the “MENU” language.)
TV TYPE 4:3 LETTER BOX
4:3 PAN SCAN
16:9
SCREEN SAVER ON
OFF
BACKGROUND JACKET PICTURE
GRAPHICS
BLUE
BLACK
103
Additional Information
CUSTOM SETUP (page 89)
AUDIO SETUP (page 90)
AUTO PLAY OFF
TIMER
DEMO1
DEMO2
DIMMER BRIGHT
DARK
OFF
AUTO
PAUSE MODE AUTO
FRAME
TRACK SELECTION OFF
AUTO
DATE/TIME SETUP ,
AUDIO ATT OFF
ON
AUDIO DRC STANDARD
TV MODE
WIDE RANGE
DOWNMIX DOLBY SURROUND
NORMAL
DIGITAL OUT ON
DOLBY
DIGITAL
D-PCM
DOLBY DIGITAL
DTS OFF
ON
OFF
104
Index
Symbols
"MagicGate (MG) Memory
Stick"
71
"Memory Stick"
71
Numerics
16:9 87
4:3 LETTER BOX
87
4:3 PAN SCAN
87
5.1 Channel Surround
30
A
A-B Repeat Play 47
ADVANCED
55
ALBUM
67, 69, 76
Album
97
ANGLE
62
ATRAC3
7, 73, 97
AUDIO
57, 86
AUDIO ATT
90
AUDIO DRC
91
AUDIO SETUP
90
AUTO PLAY
89
B
BACKGROUND 88
Batteries
17
BNR
64
C
CD 38
CHAPTER
50
Chapter
97
Connecting
21
Continuous Play
CD/VIDEO CD/DVD
38
Control Menu Display
14
CUSTOM
85
CUSTOM PARENTAL
CONTROL
78
CUSTOM SETUP
89
D
DATA-CD 67, 68
DATE
15
DATE/TIME SETUP
74
DCF
65
DIGITAL OUT
91
Digital output
26, 28, 30, 91
DIMMER
89
Disc mode
38
Display
Control Menu Display
14
Front Panel Display
11
Setup Display
85
DOLBY DIGITAL
58, 92, 97
Dolby Surround (Pro Logic)
28, 91, 97
DOWNMIX
91
DTS
57, 92, 97
DVD
38, 97
DVD’s menu
41
F
Fast forward 49
Fast reverse
49
FILE
69, 76
File
98
Front Panel Display
11
H
Handling discs 9
Hooking up
21
I
INDEX 50
Index
98
J
JPEG 65, 68, 75
L
LANGUAGE SETUP 86
Locating
a specific point by watching
the TV screen
49
M
MEMORY STICK 73, 75
MENU
41, 86
MP3
65, 67
MS mode
73
O
On-screen display
Control Menu Display
14
Setup Display
85
ORIGINAL
41
ORIGINAL/PLAY LIST
41
OSD
86
P
PARENTAL CONTROL 79
PAUSE MODE
89
PBC Playback
42
PLAY LIST
41
PROGRAM
44
Program Play
44
Q
QUICK 86
Quick Setup
34
R
Remote 17
REPEAT
46
Repeat Play
46
Replay
39
RESET
86
Resume Play
40
S
SCENE 50
Scene
98
SCREEN SAVER
88
SCREEN SETUP
87
SETUP
85
Setup Display
85
SHUFFLE
46
Shuffle Play
46
Slow-motion Play
49
Speakers
hookups
26, 28, 30
Stand
32
SUBTITLE
86
Subtitles
63
SURROUND
59
S-VIDEO output
22
T
Time search 51
TIME/TEXT
50, 52
TITLE
50
Title
98
TRACK
50, 67, 73
Track
98
TRACK SELECTION
89
Troubleshooting
93
TV TYPE
87
TVS (TV Virtual Surround)
59, 98
Sony Corporation Printed in Japan
