Rev. 03-03-2016 Copyright (C) 2016, Heat Outdoor Living Page 1
INSTALLATION INSTRUCTIONS &USE & CARE GUIDE
AL-T7200 Versa BBQ Hood Series
CONTENTS:
Part 1 - Planning The Installation
Part 2 - Electrical Connection
Part 3 - Direction of Vent and Securing The Hood
Part 4 - Use & Care
Before beginning installation, please thoroughly read and become familiar with these instructions. Installation and
service must be completed by a qualified installer. Failure to properly install this product may void the warranty.
Please be advised that the Heat
®
AL-T7200 Series BBQ Hood MAY NOT be installed on a Patio or Lanai area that
does not have a roof over the BBQ Hood to protect it from direct rain or potential water ingress. This Hood should
be installed with a MINIMUM of three (3) feet of weather proof roof coverage on all sides that are not protected from
direct rain by an adjacent wall.
It is required that all duct work and roof openings be thoroughly sealed with the applicable tape and/or roof sealant
to prevent ingress of water.
Installer:
Please leave Installation Instructions with the BBQ hood owner.
Owner:
Please keep Installation Instructions for local electrical inspector’s use and for future reference.
WARNINGS: Must be followed carefully to avoid personal injury.
IMPORTANT: Must be followed carefully to avoid damage or incorrect installation.
TIPS: Contain helpful information to facilitate installation.
AL-T7200 Versa Series Models:
No Blower 1250 CFM
AL-T7236 AL-T7236-12
AL-T7242 AL-T7242-12
AL-T7248 AL-T7248-12
