KEEP THIS APPLIANCE AWAY FROM COMBUSTIBLE MATERIALS
MINIMUM CLEARANCES: REAR 400mm - SIDE 400mm - TOP 1200mm
Total Nominal gas consumption - 360g/h Injector Size 0.54mm
TROUBLESHOOTING
Lack of fuel
Piezo plug dirty
Dirty burner
Cartridge
misaligned
Dirty burner or
empty cartridge
Faulty knob
mechanism
Internal gas
pressure too
high
Improper
setting of
spark point
Set spark point
to 2-3mm away
from burner
Cool down
gas cartridge
Request for
inspection/repair
Clean burner
Replace cartridge
Reset correctly
Clean burner
Clean spark point
Replace cartridge
Solution
Cause
Problem
Continued
Burning
Slow
Burning
Uneven
Flame
Unstable
Flame
Gas Smell
No Burning
No Ignition
Stoppd
Working
While in Use
Due to continual development, specifications are subject to change without notice.
FOLD FOLD
FOLD
FOLD
BACK PAGE
FRONT PAGE
CARE AND CLEANING
• The outside of the cooker can be wiped clean with a mild solution of dish
washing detergent and finished off with a dry cloth. Do not use abrasive pads.
• We recommend the burner head be cleaned by gentle scrubbing with a dry
brush at least annually. Ensure that the burner ports are free of any obstructions.
• Occasionally clean the point of the piezo plug with a hard brush or file.
SAFETY TIPS
DO’S
• Turn gas off at ignition knob after use.
• Check that burner is fully extinguished before
disconnecting the gas cartridge.
• Remove the gas cartridge when not in use.
• Change the gas cartridge outside and away
from people.
• Check the seals before connecting a new
gas cartridge to the appliance.
• Always remove the cooker from the carry
case prior to use.
• Keep children away from this appliance.
• Make sure there is adequate ventilation
under the unit.
• Only operate on flat, horizontal surfaces.
• Use the cooker in cool places or in the shade.
Keep the cartridge compartment out of direct
sunlight.
• Always check the gas cartridge position inside
the compartment for leaks. If a leak occurs, turn
off the supply and remove the gas cartridge.
DON’TS
• DO NOT OPERATE IN AN ENCLOSED AREA.
• DO NOT operate in a boat, caravan or tent.
• DO NOT modify this appliance.
• DO NOT use the cooker in sand or on gravel
surfaces.
• DO NOT move the cooker while it is lit.
• Avoid using the cooker in very windy conditions.
• DO NOT use a cooking pan that is larger than
26cm in diameter.
• DO NOT use appliance as a room heater, clothes
drier or to ignite other fuel.
• DO NOT place articles on or against this appliance.
• DO NOT place chemicals or flammable materials,
or spray aerosols near this appliance.
• DO NOT leave unattended.
• DO NOT use in carry case.
Twin over-pressure safety devices - enhanced safety devices which sense
if pressure becomes too high. Firstly the cartridge is ejected and secondly
the gas supply is shut off to the burner.
Vitreous enamel spill tray/top with flame protection ring.
Cartridge lock lever and rotary piezo ignition.
Convenient storage and carry case.
Uses Gasmate bayonet cartridge (G4210 - sold separately).
Gas certified to Australian and New Zealand Standards.
with Hotplate
Gasmate
®
is a registered trademark of:
Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber, N.Z www.gasmate.co.nz
BUTANE TWIN STOVE
Model No. CS601, CS601Y, CS605Y, CS6095
Important: Retain these instructions for future use.
03699 03/18
WARNING - USE OUTDOORS ONLY
ONLY USE IN WELL VENTILATED AREAS.
CARBON MONOXIDE HAZARD - USING THIS APPLIANCE IN AN ENCLOSED SPACE MAY
CAUSE DEATH. DO NOT USE IN CARAVANS, TENTS, MARINE CRAFT, CARS, MOBILE
HOMES OR SIMILAR LOCATIONS.
NOT FOR COMMERCIAL USE
DO NOT USE MULTIPLE APPLIANCES TO HEAT A SINGLE COOKING DEVICE
DO NOT USE OVERSIZED COOKING DEVICES (MAXIMUM 26CM DIAMETER)
DO NOT USE AS A SPACE HEATER OR FOR ANY PURPOSE OTHER THAN COOKING
DURING USE AVOID BOIL OVER AND SPILLAGE
BTU MJ/h GAS CONSUMPTION
2 x 8,500 BTU 2 x 9MJ/h 2 x 180g/h
