DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
KP-48S35
1/16 inch = 1 inch Scale 16:1
43 1/2" x 52 1/2" x 21
FRONT VIEW
37 1/2"
52 1/2"
43 1/2 "
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
120V AC
60Hz
Remote Sensor
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX(201) 930-7891
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
46" Projection TV
143 Lbs (approx.)
310w(max)
7w(stby)
REMOTE SENSOR
TOP VIEW
38 7/8"
29 1/2"
40"
22 1/2"
10"
38 1/8"
28 1/2"
35"
2 5/8"
BOTTOM VIEW
36 7/8
33 7/8"
40 5 /8"
27 3/4
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
